ACCESSORS

A Data-Centric Permission Model for the Internet of Things

Christoph Stach and Bernhard Mitschang

Institute for Parallel and Distributed Systems, University of Stuttgart,

Universit

atsstraße 38, D-70569 Stuttgart, Germany

Keywords:

Permission Model, Data-Centric, Derivation Transparent, Fine-Grained, Context-Sensitive, IoT.

Abstract:

The Internet of Things (IoT) is gaining more and more relevance. Due to innovative IoT devices equipped with

novel sensors, new application domains come up continuously. These domains include Smart Homes, Smart

Health, and Smart Cars among others. As the devices not only collect a lot of data about the user, but also

share this information with each other, privacy is a key issue for IoT applications. However, traditional privacy

systems cannot be applied to the IoT directly due to different requirements towards the underlying permission

models. Therefore, we analyze existing permission models regarding their applicability in the IoT domain.

Based on this analysis, we come up with a novel permission model, implement it in a privacy system, and

assess its utility.

1 INTRODUCTION

The Internet of Things (IoT) is leaving the Early Adop-

ters stage as it is becoming more and more popular (Da-

vies et al., 2016). New Things, i. e., small gadgets with

sensors which are connected to the Internet, come onto

the market. Not only technology enthusiasts are inte-

rested in these devices, but they also get into the focus

of the general public. IoT has opened the way for

novel use cases in various domains including Smart

Homes, Smart Health, or Smart Cars (Aman et al.,

2017).

As the Things

are able to capture a lot of diverse

data about the user and they can share this informa-

tion with each other, IoT applications (or apps) gain a

comprehensive knowledge about their users. That way,

they are able to improve the quality of our everyday

life, as they are able to predict the most likely user

demands at an early stage and adapt their provided

services accordingly. However, the possible threats

deriving from such apps cannot be underestimated. In-

dividuals can be monitored permanently without their

knowledge. Therefore, IoT apps have an high impact

on privacy (Aggarwal et al., 2013).

Technical approaches are required to conceal sen-

sitive information and give users the ability to control

what happens with their data. However, most privacy

We use the generic term Thing for any kind of device

equipped with sensors and Internet access.

management systems overwhelm users. Generally,

such systems enable to restrict the usage of a certain

data processing unit. Yet, users cannot estimate which

threats originate from these entities (Felt et al., 2012).

From the data gathered for a data producer, a lot of

additional information can be derived (Perera et al.,

2014). For instance, a proximity sensor can disclose

the absolute location of a user also, when it gathers

the distance to a Thing with a stationary location. So,

a data-centric and thus comprehensible approach is

required to secure private data.

For this very reason, we provide the following ﬁve

contributions in our work:

(1)

We deduce requirements towards a permission mo-

del for IoT apps from a use-case scenario.

(2)

We analyze permission models which are applied

in existing privacy systems and provide a compre-

hensive overview of their features and their appli-

cability in the IoT domain.

(3)

We construct a d

ta-

entri

rmi

ion m

del for

the Internet of Things, called ACCESSORS.

(4)

We apply ACCESSORS to an existing pri-

vacy system, the

rivacy

anagement

latform

(PMP) (Stach and Mitschang, 2013, Stach and

Mitschang, 2014). However, we could use any of

the many similar privacy systems as a foundation

for our model without a loss of argument.

(5) We evaluate our model and assess its utility.

Stach, C. and Mitschang, B.

ACCESSORS - A Data-Centric Permission Model for the Internet of Things.

DOI: 10.5220/0006572100300040

In Proceedings of the 4th International Conference on Information Systems Security and Privacy (ICISSP 2018), pages 30-40

ISBN: 978-989-758-282-0

The remainder of this paper is as follows: Section 2

introduces a real-world use-case scenario to illus-

trate the challenges for a permission model for IoT

apps. Then, Section 3 postulates ﬁve key require-

ments for such a permission model. Section 4 discus-

ses various existing permission models. Our model—

ACCESSORS—is introduced in Section 5. Section 6

describes how to apply ACCESSORS to a privacy sy-

stem. Finally, Section 7 assesses our approach before

Section 8 concludes this work and gives a short outlook

on future work.

2 USE-CASE SCENARIO

(Istepanian et al., 2011) describe how IoT technologies

can be applied for non-invasive glucose level sensing

and diabetes management. To that end, the patients’

diabetes devices are linked via IPv6 connectivity to

their healthcare provider to forward any measured data.

Yet, patients do not know, which data exactly is for-

warded, especially since such a device is able to gather

various kinds of data. For instance, some devices also

add location data to each glucose metering, since this

information can be relevant for the diagnostic analy-

sis (Kn

oll, 2010, Stach and Schlindwein, 2012, Stach,

2016). By combining the gathered data, further kno-

wledge can be derived (e. g., a combination of blood

sugar values and location data enables to draw inferen-

ces about the user’s eating behavior as a rising blood

sugar level shortly after walking past a candy shop

indicates that the user has bought some sweets (Kn

oll,

2009)).

The number of available IoT health devices is con-

siderable growing. Each new generation comes up

with more sensors, offering a wider service spectrum

than the preceding generation (Vashist et al., 2014).

The accuracy of the sensors is also getting better and

better (Kovatchev et al., 2004). However, not every

IoT app requires such a high accuracy. Meaning that

from a privacy perspective, the data quality should

be downgraded in order to conceal some private in-

formation. While some of the data provided by such

IoT devices are uncritical from a privacy point of view

or so vital that the data is required all the time, other

sensitive data is required only in case of an emergency.

For instance, if a patient suffers an insulin shock, any

available data should be sent to his or her physician in

order to get the best medical attendance as possible.

In such a scenario a privacy system—or more spe-

ciﬁcally its permission model—has to meet several no-

vel requirements in order to be effective (Sicari et al.,

2015). For instance, a focus on data-centric protection

goals is becoming essential (Agrawal et al., 2012), es-

pecially since the processed information is assembled

from various sources which are not necessarily known

to the user (Takabi et al., 2010). Furthermore, as per-

manently new devices with new kinds of sensors are

rolled out, the permission model has to persist in such

a ﬂuctuating setting (Aggarwal et al., 2013).

3 REQUIREMENTS

SPECIFICATION

As the foregoing scenario illustrates, there are special

requirements towards a permission model for IoT apps

which are detailed in the following.

[R1] Data-Centric Policy Rules. In order to be com-

prehensible and manageable for users, permissions

have to refer to types of data (e. g., blood sugar level)

instead of data providers (e. g., glucometer). While

it is obviously that a glucometer meters the blood su-

gar level, some devices provide additionally location

data. If policy rules are based on data providers, a user

might allow a health app to use his or her glucometer

without knowing that s/he also gave access to such

non-medical data in the process. Moreover, the same

type of data can be provided by several providers (e. g.,

the blood sugar level is provided by glucometers as

well as Apple Watches). If a user wants to prohibit

access to his or her health data, then this rule has to be

applied to any possible provider.

[R2] Derivation Transparency.

An IoT app has

access to several sensors and thus various types of

data. By combining these, additional data can be deri-

ved. A permission model has to be able to represent

such coherences. For instance, if

can be derived

from

and

and a user prohibits access to

, then

an app must not be allowed to access

and

at the

same time. This can be archived by describing what

data can be derived from which sources. Then the user

can assign permissions at data level and the privacy sy-

stem has to apply corresponding rules to the associated

sources.

[R3] Extendable Permission Model.

The IoT is con-

stantly evolving as new sensor technologies or com-

munication standards arise. A static permission model,

i. e., a model with a ﬁxed set of protected entities, gets

outdated very fast. Therefore, the model has to be dyn-

amically extendable. In particular, all extensions have

to be backward compatible, that is, by extending the

model previous policy rules must not become invalid.

[R4] Fine-Grained Policy Rules.

In order to enable

a user to manage his or her data in a privacy-aware

manner, s/he requires total control over information

ACCESSORS - A Data-Centric Permission Model for the Internet of Things

Rule

[1,*]

createPolicy

[1,1]

define

Access

Permission

System

Function

Sensor

Application

[1,1]

is-a

Figure 1: The Permission Model Applied in Android.

distribution and disclosure. That implies that the per-

mission model has to support ﬁne-grained policy rules

in terms of two dimensions: On the one hand, the pro-

tected entities have to be ﬁne-grained. For instance,

Android provides a

Bluetooth

permission which con-

trols any data that is provided by a device via a Blue-

tooth connection—such a permission speciﬁes neither

a type of data nor a sensor. As a consequence, users

have to permit apps to use a Bluetooth headphone and

a Bluetooth medical device at the same time via a sin-

gle permission! On the other hand, a user has to have

several choices how to constrain a certain permission.

Most permission models allow Boolean decisions, only

(grant or deny). However, a permission for location

data also could restrict the accuracy of the data.

[R5] Context-Sensitive Policy Rules.

Since IoT apps

are often context-aware, that is, an app react on the situ-

ation it is currently used, also the policy rules should be

context-sensitive. For instance, a medical app should

have access to any kind of data in case of an emergency.

Otherwise, more restrictive policy rules should be app-

lied. We follow the context deﬁnition of (Dey, 2001),

i. e., “any information that can be used to characterize

the situation of an entity”.

4 RELATED WORK

Based on these requirements, we analyze permission

models which are currently used in the IoT context.

As the IoT is a highly heterogeneous environment with

various operating systems running on the Things, a

lot of different privacy systems and thus permission

models are being used which aggravates the privacy

issues. Yet, there are several approaches to establish

Android in the IoT, e. g., Android Things (Google Inc.,

2017) or RTAndroid (Kalkov et al., 2012). So, we

focus on Android-based privacy systems in our work.

However, as any mobile platform applies a compa-

rable permission-based privacy system, we loose no

argument by doing so (Barrera et al., 2010).

In Android a quite simple permission model is

applied (see Figure 1). Each Permission regulates

either the usage of a system functions (e. g., adding

entries to the calendar) or access to a sensor (e. g.,

the camera). An app which uses such a function or

sensor has to request the appropriate permission. For

Android

Permission

Normal

Permission

BLUETOOTH

INTERNET

…

Dangerous

Permission

CALL_PHONE

READ_SMS

…

Figure 2: Classiﬁcation of Android Permissions in Normal

and Dangerous Ones, cf. (Wei et al., 2012).

each granted request a policy rule is created. Most

permissions are automatically granted when an app

is installed, while dangerous permissions have to be

granted at runtime (Enck et al., 2009).

Whenever Google adds new permissions or rela-

bels existing permissions, app developers have to add

these permissions to their already released apps in or-

der to keep them operative (Sellwood and Crampton,

2013). Yet, a single permission can cover several sy-

stem functions or sensors, which makes it hard for

a user to comprehend the permissions. This is ag-

gravated by the fact that there are too many different

permissions, even for noncritical operations (e. g., the

usage of the vibration function) (Felt et al., 2012).

That is why Google no longer informs the user about

noncritical permissions, the so-called normal permis-

sion. However, Google classiﬁes access to the Internet

or the usage of Bluetooth device as safe operations

(see Figure 2), although both can have a severe impact

on the user’s privacy. Thus, such a basic permission

model is not applicable for the IoT.

(Sekar et al., 2012) introduce Selective Permissi-

ons. That is, any Android permission requested by an

app is stored in a Shadow Manifest which can be modi-

ﬁed at runtime. In this way, a user is able to withdraw

certain permissions similar to the Android runtime

permissions. Yet, the Selective Permissions have two

advantages. On the one hand, a user can withdraw any

permission and on the other hand a missing permission

does not lead to a security exception. Instead a null va-

lue is returned to the app. However, this approach does

not alter the Android permission model and therefore

it does not fulﬁll any of the requirements postulated in

Section 3 likewise.

ePE introduces a context-sensitive permission

model (Conti et al., 2011). Each access to a data

source, i. e., each permission request, can be linked

to a spatio-temporal context. This context deﬁnes a

condition under which the permission is granted. Yet,

the rules are mapped to Android permissions and there-

fore, CR

ePE has the same shortcomings as Android’s

permission model.

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

Apex introduces an XML-based policy language

in order to restrict the usage of Android permissi-

ons (Nauman et al., 2010). The user is able to deﬁne,

e. g., how often a certain permission can be used or in

which chronological order permissions can be granted.

Aside from such constraints, the permission model

allows no wide-ranging contextual constraints or ﬁne-

grained permission settings. Also, the model is neither

data-centric nor derivation transparent and it cannot be

extended as it is based on Android permissions.

In YAASE a user deﬁnes what operations a certain

app is allowed to perform on a resource, i. e., either

a content or service provider (Russello et al., 2011).

Data from these resources can be tagged, e. g., to dif-

ferentiate between public and private data provided by

the same resource. The user speciﬁes whether only cer-

tain tags are accessible for an app. Moreover, s/he can

deﬁne operations which have to be performed before

the data is forwarded to an app, e. g., a ﬁler operation

to remove sensitive data. That way, YAASE is able to

specify very ﬁne-grained policy rules. However, these

rules are not data-centric, derivation transparent, or

context-sensitive. Furthermore, the expandability of

the model is restricted to speciﬁed operations.

Sorbet mainly focuses on undesired information

ﬂows between apps (Fragkaki et al., 2012). To this

end, the underlying permission model allows to spe-

cify information-ﬂow constraints in order to prevent

privilege escalation. That way, Sorbet supports some

kind of context-sensitivity. In addition, the resources

protected by the permissions can be any kind of com-

ponent (e. g., services or content providers). So, the

permission model is extendable. Moreover, the model

allows to specify constraints that limit the usage of

certain permissions, e. g., by adding a lifespan to it.

This results in ﬁne-grained policy rules even though

Sorbet still deals with Boolean decisions. Also, Sorbet

neither supports data-centric nor derivation transparent

policy rules.

RetroSkeleton is an app rewriting system capable

of replacing method calls with arbitrary code frag-

ments (Davis et al., 2012, Davis and Chen, 2013). Its

policy consists of Clojure replacement commands. The

user is able to postulate derivation transparent, ﬁne-

grained, and context-sensitive policy rules—provided

that s/he has the required programming skills. Since

the model itself is generic and does not map to pre-

deﬁned permissions, it is extendable. Yet, as it only

replaces method calls, the model is not tailored to

data-centric permissions.

Constroid, which is based on the UCON

ABC

mo-

del (Park and Sandhu, 2004), provides subjects (e. g.,

processes) with rights to operate on data items (e. g.,

all business contacts) (Schreckling et al., 2012). The

data items can be associated with attributes (e. g., con-

tacts without a private phone number) to restrict the

access rights. Since the access rights are related to

data only, the considered operations are restricted to

create, read, update, and delete. Optional conditions

specify whether a rule is applicable under a certain

context. Yet, the model is not extendable and does not

support derivation transparent policy rules.

SPoX is a security policy speciﬁcation lan-

guage (Hamlen and Jones, 2008). SPoX rules deﬁne

a state machine that accepts any sequences of com-

mands that comply with the security policy. (Backes

et al., 2013) apply this language in their privacy sy-

stem called AppGuard. So, the user is able to formu-

late ﬁne-grained policy rules, e. g., by limiting network

access to a certain address. As any command can be re-

stricted by policy rules, AppGuard’s permission model

is extendable. That way, even novel data sources are

supported by AppGuard out of the box. By chaining

several rules, the user is able to model some kind of

derivation transparency. Also the context in which a

certain command is executed can be restricted (Backes

et al., 2014). However, these restrictions only refer to

the command sequence and not to the user’s context.

Moreover, the privacy model is not data-centric.

(Scoccia et al., 2017) introduce ﬂexible permissi-

ons for Android which are called AFP. In AFP the

permissions are bound to features of an app. That

is, an app is only allowed to request a permission in

order to perform a certain task. Moreover, AFP ena-

bles users to assign ﬁne-grained permissions, e. g., by

granting only access to selected contacts instead of the

whole contact list. Since AFP deﬁnes its own permis-

sions, the model is extendable. Yet, the policy rules

are neither data-centric nor derivation transparent.

DroidForce introduces data-centric policy ru-

les (Rasthofer et al., 2014). OSL (Hilty et al., 2007) is

used to specify the rules. In this way, temporal condi-

tions as well as cardinality and time constraints can be

added to each permission. Therefore both, ﬁne-grained

and context-sensitive policy rules are supported. The

key feature of DroidForce is its focus on data-centric

permissions. That is, the permissions are mapped to

data domains (e. g., location data or contacts data) rat-

her than system sensor functions. However, coheren-

ces between protected data sources cannot be modeled

and the applied model is not extendable.

The Privacy Management Platform (PMP) (Stach

and Mitschang, 2014) applies the Privacy Policy Mo-

del (PPM) (Stach and Mitschang, 2013) (see Figure 3).

The PPM is extendable and enables ﬁne-grained and

context-sensitive policy rules. It splits apps into self-

contained Service Features. In this way, permissions

are not granted to apps, but directly to the respective

ACCESSORS - A Data-Centric Permission Model for the Internet of Things

Privacy

Rule

[0,1]

[1,*]

createPolicy

[0,*]

define Resource

Data

Source

Data Sink

Service

Feature

specify

Application

[1,1]

[1,*]

[1,1]

is-a

Privacy

Setting

[1,1]

pool

activate

Resource

Group

[1,*]

[1,1]

Figure 3: The Privacy Policy Model (PPM).

Service Features. The permissions get an earmarking

for a certain purpose and the user can (de-)activate

these features according to his or her needs. Access to

data sources or sinks is provided via so-called Resour-

ces. Related Resources can be pooled in a Resource

Group (e. g., GPS and WiFi positioning are part of a

location Resource Group). For each Resource, a user

can deﬁne individual Privacy Settings (e. g., to reduce

the accuracy of location data for a certain Service Fea-

ture). The data from the Resources is also used to add

contextual constraints to each privacy rule to deﬁne

its scope of application. So, the PPM already meets

most of the requirements towards a permission model

for the IoT. Yet, it does not support data-centric policy

rules and therefore overstrains the user in such a hete-

rogeneous environment. This ﬂaw gets obvious in the

following Smart Health example:

If a user keeps an electronic health diary via a

Smart Health app for his or her Smartphone. Howe-

ver, s/he only wants to track his or her ﬁtness progress

including heart rate (pulse meter), activities (accelero-

meter and orientation sensor), and training locations

(GPS). Additionally, s/he wants to use the camera for

a visual documentation of his or her training progress.

For instance, a insurance company provide a special

tariff rate for users of this app which rewards a healthy

lifestyle.

Hence, a user might not want to share any data that

could indicate an illness such a the body temperature

with the app as this could lead to a higher insurance

rate. In the PPM, the user is therefore able to prohibit

this app to access a Bluetooth medical thermometer for

the purpose of measuring the body temperature. The

thermometer then is represented as a Resource and the

measuring is represented as a Service Feature.

However, if we assume that the Smartphone is

equipped with a thermographic camera, the user has

to be aware of this feature. If s/he does not consider

that, such a camera is also able to reveal his or her

body temperature. To prevent this s/he has to deﬁne an

additional Privacy Rule in the PPM for the measuring

Service Feature which prohibits the access of the ca-

mera Resource. For any data source s/he has to reﬂect

which knowledge can be derived from its data.

In theory, the PPM is indeed able to secure sen-

sitive data also for IoT apps. However, with an in-

creasing number of different sensors, it is almost im-

possible for a user to keep track of all the possible

data leaks due to the Resource-centric Policy Rules of

the PPM. Nevertheless, the PPM is a sound founda-

tion for ACCESSORS which introduces a data-centric

perspective.

5 THE ACCESSORS MODEL

As shown in the previous section, the PPM is well-

suited for Smartphone apps with a manageable amount

of sensors involved. In an IoT scenario with lots of

different sensors, another approach is required since

humans tend to think in a data-centric way. That is, a

user knows which data s/he wants to keep secret and

s/he does not want to bother about which sensor or

data source could reveal this type of data. For instance,

if a user wants to prohibit that an app has access to his

or her body temperature, this should be represented

via a single rule instead of one rule per data source

which holds this information. To this end, a permission

model has to be able to map data producers to the type

of data which is provided by them. In this way, a user

can select which type of data should be available to an

app (e. g., body temperature) and the model unfolds

which data sources have to be considered (e. g., me-

dical thermometer and thermographic camera). Our

approach of a d

ta-

entri

rmi

ion m

del for the

Inte

net of Thing

—or short ACCESSORS—is shown

in Figure 4. In the following, we detail its key compo-

nents and elaborate on how they contribute to meet the

ﬁve requirements.

Rule Core.

Similar to the PPM, an ACCESSORS policy

rule basically consists of three parts: an access pur-

pose, a permission to access a data processing unit

and a constraint. These triples compose the rule core.

Optionally, each policy rule can be linked to a con-

text under which it is activated (see Paragraph Context

Abstraction).

User Abstraction.

Any inquiring entity—i. e., an app,

a Smart Thing, or even a user—is able to specify one

or multiple access purposes that require access to a

protected type of data. An access purpose is a code

fragment within an app that carries out a single task.

For instance, such an access purpose in the use-case

scenario described in Section 2 could be the graphical

representation of metering locations on a map. That

A data processing unit is either a data producer or a

data consumer (see Paragraph Data Abstraction).

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

Context

Time /

Date

Location Situation

is-a

Rule

activate

[1,*]

[0,1]

[1,*]

createPolicy

[0,*]

define Access

Information

Data

Producer

Data

Consumer

derive

Source

Application

Smart

Thing

Sensor

Data

Storage

is-a

Sink

Application

Smart

Thing

Data

Storage

is-a

Constraint

Inquiring

Entity

Application

Smart

Thing

User

[1,*]

[1,1]

[1,*]

is-a

Rule Core Data Abstraction

Data Sink Abstraction

Data Source AbstractionContext Abstraction

User Abstraction

Access

Purpose

[1,1]

provide

control

[1,*]

specify

Boolean

Constraint

Integer

Constraint

Enum.

Constraint

String

Constraint

is-a

Constraint

Abstraction

derive

[1,*] [0,*]

Figure 4: ACCESSORS — The Data-Centric Permission Model for the Internet of Things.

way, permissions are not linked to an app but to a cer-

tain access purpose. As a consequence, a user can

decide, which access purposes are justiﬁed for a cer-

tain type of app and whether s/he wants to execute the

associated code fragment when it requires the speci-

ﬁed access permissions. Analogous to the PPM, non-

essential app features can be skipped to reduce the

amount of required private data. The user abstraction

assures that further types of Smart Things can be added

on demand.

Data Abstraction.

The data abstraction facilitates to

link permissions to both, data producers as well as

data consumers. However, the focus for both units

is on the type of data that is produced or consumed.

That is, an inquiring entity has to specify which data

it needs access to such as location data or health data

instead of a concrete data processing unit such as GPS

or a glucometer.

Data Sink Abstraction.

Each data consumer is asso-

ciated with several data sinks such as apps or services,

data storages, or even other Smart Things. In other

words, the user can specify policy rules how data can

be preprocessed for an app. For instance, s/he could al-

low an app to use a service which stores health data for

long-term monitoring of a particular health condition.

Data Source Abstraction.

Each data producer is as-

sociated with a certain type of information. An in-

formation is any aspect that can be derived from raw

data. That is, it can be the raw data itself (e. g., a single

blood sugar value) or any kind of higher order data

gained by combining several sources (e. g., a health

record containing data from various metering devices).

For each type of data diverse data sources can be spe-

ciﬁed in the ACCESSORS model. A data source does

not have to be a sensor necessarily, but also apps, data

storages, and Smart Things are qualiﬁed as data sour-

ces. In this way, complex coherences can be modeled

(e. g., the information “activity” can be derived either

by a combination of data from an accelerometer and a

position sensor or directly by a readout from a ﬁtness

tracker). Due to the data sink abstraction and data

source abstraction, the policy rules remain completely

detached from a concrete technology. The rules are

automatically adapted to the available data sources and

sinks.

Context Abstraction.

Optionally, an activation con-

text can be attached to each policy rule. This context

describes under which conditions a rule has to be en-

forced by a privacy system. The context is described

in accordance with (Dey, 2001) as a spatio-temporal

condition (e. g., a rule should only be applied during

working hours) or as a higher order situation (e. g., a

rule is only valid in case of a medical emergency). Hig-

her order situations can be modeled as a combination

of values from data producers.

Constraint Abstraction.

For each policy rule vari-

ous constraints can be deﬁned. The most basic one

is a Boolean constraint to grant or deny to process a

certain type of data

. Depending on the type of data,

ACCESSORS supports three additional constraint types:

integer constraints, enumeration constraint, and string

constraints. Integer constraints can be used to deﬁne

If the access permission is denied, the particular code

fragment is skipped in the app.

ACCESSORS - A Data-Centric Permission Model for the Internet of Things

an upper or lower boundary. For instance, a maximum

accuracy for a certain type of data such as location

data can be speciﬁed in this manner. An enumeration

constraint deﬁnes several valid setting options. For

instance, for health records there could be settings

granting access only to domain-speciﬁc record secti-

ons such as pulmonary data or cardiac data. Finally,

string constraints enable users to enter textual conditi-

ons. For instance, a user can declare a MAC address

of a Thing with which s/he wants to share his or her

health data. Thereby it is ensured that health data is

sent to the speciﬁed destination address, only.

All in all, ACCESSORS supports data-centric policy

rules as the focus of the permission is on types of data

instead of concrete data processing units. Since data

producers provide higher order information which can

be composed of data from several sources, ACCES-

SORS is able to model relations between various types

of data. As the policy rules interrelate access purposes,

access permissions, constraints, and contexts, only,

they are independent from concrete inquiring entities

or data producers and data consumers, respectively.

This means in effect that ACCESSORS has two types

of extensibility due to its abstraction layers. On the

one hand it can be broadened (e. g., by adding new

Things) and on the other hand it can be deepened (e. g.,

by adding new coherences between data sources if

new methods to derive a certain kind of information

from raw data are discovered). Policy rules modeled

with ACCESSORS are very ﬁne-grained. On the one

hand, the multi-valued constraints allow a highly pre-

cise vernier adjustment of the permission rights. On

the other hand, since the permissions are bound to a

certain access purpose and need not be granted to an

app in general, the user is able to tailor the privacy

policy entirely towards his or her needs. Lastly, each

policy rule can be enriched by an activation context.

This context is highly generic, since it can be compo-

sed of any data currently available.

When comparing the PPM (see Figure 3) with

ACCESSORS (see Figure 4), it is obvious that the two

models have several common components. The rule

core of ACCESSORS is almost equivalent to the PPM.

However, ACCESSORS has two signiﬁcant advantages:

a) ACCESSORS introduces abstraction layers for users,

data, data sinks, data sources, contexts, and constraints.

b) ACCESSORS considers a different protection goal.

While the PPM is designed for Smartphones and the-

refore considers only apps as potential attackers and

sensors or system functions as feasible targets (labeled

as Resources), ACCESSORS is entirely designed for the

IoT. On that account, not only the potential attackers

are interpreted in a wider sense—any kind of inqui-

ring entity is considered as an attacker, including apps,

Smart Things, and users—but also the targets which

are protected by ACCESSORS have a different focus.

The targets are geared to types of data instead of data

sinks or sources.

Nevertheless, it seems natural to map policy ru-

les deﬁned in ACCESSORS to PPM rules, due to the

similarity of the two models, as the PPM is already

applied to existing privacy systems such as the PMP.

In this way, we can exploit this infrastructure in order

to enforce ACCESSORS policy rules. We describe a

mapping of ACCESSORS policy rules to PPM rules in

the following section.

6 APPLICATION OF

ACCESSORS IN THE PMP

From a modeling point of view, the ﬁne-grained

structure of ACCESSORS with its highly branched ab-

straction layers is necessary in order to gain a high

expressiveness of the policy rules. However, from a

implementation point of view, the number of utilized

components should be kept low in order to reduce com-

plexity. On that account, a mapping of the detailed

ACCESSORS policy rules to similar PPM rules, is also

recommended.

To that end, it is necessary to convert the access

purposes speciﬁed by inquiring entities in ACCESSORS

to Service Features. However, a Service Feature also

deﬁnes certain permissions which are required in order

to execute a particular code fragment. The focus on a

broader range of possible attackers in ACCESSORS is

not contradictory to the Service Features and a one-to-

one mapping is possible without any further ado.

That is why the transition of data-centric targets

modeled in ACCESSORS into PPM Resources poses

the biggest problem for the mapping. In particular

this implies that all Resources have to be replaced by

new data-centric components. Nevertheless, ACCES-

SORS can be applied to the PMP, due to its modular

architecture. In the PMP, each Resource Group is im-

plemented as an independent functional unit which

can be installed individually. Moreover, additional Re-

sources can be added to a Resource Group at any point

of time (Stach, 2013). Therefore, existing Resources

can be replaced by new data-centric ones in order to

apply ACCESSORS to the PMP.

Figure 5a depicts the model of a Resource Group

for Smart Watches. The Resource Group deﬁnes a

common interface for all of its Resources. An arbitrary

Resource, which provides the required functionality,

can be plugged into the the Resource Group at runtime.

That is, the Resources are concrete implementation

artifacts of the interface for a given hardware (e. g., an

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

Resource Group

Resources

Privacy Settings

Apple Watch

Moto 360

…

Smart Watch

Read Time

Read Heart Rate

Show Notification

…

ISmartWatch

int getTime();

int getHeatRate();

…

(a) Model of a PMP Resource Group

Health Data

…

iHealth Smart

Glucometer

Apple Watch

Health Data

Analytics

…

Resource Group

Resources

Privacy Settings

Perform Metering

Read Blood Sugar Level

Process Blood Sugar Level

Read Heart Rate

Process Heart Rate

…

IHealthData

int getHeatRate();

…

(b) Application of ACCESSORS in the PMP

Figure 5: Mapping of ACCESSORS Rules to PMP Resource Groups.

Apple Watch or a Moto 360). The Resource Group

also deﬁnes feasible Privacy Settings, i. e., how the

user is able to restrict access to a particular Resource.

Figure 5b illustrates how this model has to be adap-

ted in order to make the PMP compatible to ACCES-

SORS privacy rules. In the ﬁrst instance, the hardware-

or service-based focus of the Resource Groups has to

be shifted to a data-centric one. The Resource Group

given in the example deals with any kind of health-

related data. This data can be provided by legit health

devices such as a glucometer or by novel Things such

as a Smart Watch. Moreover, this Resource Group

also deals with data consumers of health data such as

analytics libraries. In order to be able to plug in all

of these data processing units, the Resource Group’s

interface has to be broadened accordingly.

The PPM Resource Groups provide only a single

plug for one Resource at a time. To support deriva-

tion transparency, i. e., to be able to model data which

is assembled from various sources, the ACCESSORS

Resource Groups need multiple plugs. For instance,

it is possible to deduce the blood sugar level conside-

rably accurate by monitoring the activities of a user

and his or her eating behavior (Zeevi et al., 2015). So,

the Resource Group for health data has to be able to

plug in a Resource capturing physical activities and

a Resource gathering nutrition data, simultaneously.

Furthermore, each Resource can be associated with

multiple Resource Groups. For instance, a Smart Wa-

tch providing both, location and health data belongs

to a location Resource Group as well as a health data

Resource Group. The Privacy Settings for the new

data-centric Resource Groups are carried over from

the PPM’s Resources that are pooled in the respective

Resource Group.

That way, ACCESSORS can be mapped to the PPM.

PPM rules are executable on the PMP and similar

privacy systems. As the PMP runs on Android and

Android is becoming increasingly pertinent to the IoT,

such an implementation constitutes a serviceable pri-

vacy system for the IoT.

Table 1: Comparison of Current Permission Models.

Approach R1 R2 R3 R4 R5

Android 7 7 (3) 7 7

Selective

7 7 7 7 7

Permissions

ePE 7 7 7 7 3

Apex 7 7 7 (3) (3)

YAASE 7 7 (3) 3 7

Sorbet 7 7 3 (3) (3)

Retro-

7 (3) 3 (3) (3)

Skeleton

Constroid 3 7 7 (3) 3

AppGuard 7 (3) 3 3 (3)

AFP 7 7 3 3 3

DroidForce 3 7 7 3 3

PMP 7 3 3 3 3

ACCESSORS 3 3 3 3 3

7 DISCUSSION

ACCESSORS is outright

data-centric

since all of its

protected entities (data producers as well as data consu-

mers) are related to a certain type of data (e. g., health

data). Apps request access to such data without having

to specify which sensor or system function provides

this data. That way, ACCESSORS enables also

deri-

vation transparency

. Each protected data object can

originate from various sources. Additionally, multiple

sources can be combined in order to derive a certain

ACCESSORS - A Data-Centric Permission Model for the Internet of Things

type of data (e. g., the activity of a user can be de-

rived from an accelerometer in combination with a

position sensor). ACCESSORS enables to model a sin-

gle data source as the producer of highly diverse data,

e. g., an Apple Watch can produce location data as

well as health data. The ACCESSORS model is

exten-

dable

. On the one hand, additional data sources and

sinks can be added at runtime in order to react on fort-

hcoming hardware. For instance, the Apple Watch is

able to meter the blood sugar level after a glucome-

ter upgrade. On the other hand, our model supports

various types of entities. An inquiring entity can be

mapped to an app, a Smart Thing, or a user. That way,

ACCESSORS is not committed to a ﬁxed entity type.

In the IoT context where new Things arise frequently,

such an extensibility is essential. Moreover, ACCES-

SORS is

ﬁne-grained

and

context-sensitive

. That is,

multi-valued constraints as well as spatio-temporal or

situation-based conditions can be added to each policy

rule.

Table 1 summarizes the key characteristics of the

permission models analyzed in the work at hand (see

Section 4). Moreover, it provides a comparison of

ACCESSORS with these approaches. The examined

characteristics correspond to the postulated require-

ments in Section 3, namely

[R1]

data-centric policy

rules,

[R2]

derivation transparency,

[R3]

extendable

permission model,

[R4]

ﬁne-grained policy rules, and

[R5]

context-sensitive policy rules. Due to the compre-

hensive abstraction approach covering users, data, data

sinks, data sources, contexts, and constraints ACCES-

SORS is able to meet all requirements towards a per-

mission model for the IoT.

8 CONCLUSION

The IoT is becoming more and more popular. Intercon-

nected devices with novel sensors come onto the mar-

ket. As a consequence, innovative apps from highly

diverse domains including Smart Homes and Smart

Health are developed. Such apps gather a lot of data

about their users and derive further information from

this data. While these apps are able to improve the

quality of our everyday life, they also pose a threat

to user privacy. Therefore, technical approaches are

required to give users full control over their data.

For this reason, we postulate a requirements speci-

ﬁcation towards permission models for the IoT. Based

on these requirements, we provide a comprehensive

overview and assessment of currently existing permis-

sion models. Since none of these permission models is

appropriate for IoT apps, we introduce a d

ta-

entri

rmi

ion m

del for the Inte

net of Thing

called

ACCESSORS. We describe how privacy demands to-

wards IoT apps can be modeled in ACCESSORS. For

the implementation of ACCESSORS, we provide a map-

ping of the ACCESSORS policy rules to an existing

permission model, the

rivacy

olicy

odel (PPM).

We chose the PPM since it already fulﬁlls a lot of requi-

rements towards a permission model for the IoT. In this

way, ACCESSORS policy rules can be applied in an ac-

tual privacy system, such as the

rivacy

anagement

latform (PMP). An assessment demonstrates the uti-

lity of our approach.

Since many IoT apps fall back on online services

for data processing (e. g., (Steimle et al., 2017)), future

work has to investigate, how ACCESSORS-based policy

rules can be applied to a privacy mechanism for stream

processing systems. Therefore, this research is carried

on in the PATRON research project

. The focus of

PATRON is on complex event processing in distributed

systems and how ACCESSORS-like policy rules can be

applied in such a system (Stach et al., 2017).

ACKNOWLEDGEMENTS

This paper is part of the PATRON research project

which is commissioned by the Baden-Wrttemberg Stif-

tung gGmbH. The authors would like to thank the

BW-Stiftung for the funding of this research.

REFERENCES

Aggarwal, C. C., Ashish, N., and Sheth, A. (2013). The

Internet of Things: A Survey from the Data-Centric

Perspective, chapter 12, pages 383–428. Springer.

Agrawal, D., El Abbadi, A., and Wang, S. (2012). Secure and

Privacy-preserving Data Services in the Cloud: A Data

Centric View. Proceedings of the VLDB Endowment,

5(12):2028–2029.

Aman, M. N., Chua, K. C., and Sikdar, B. (2017). Secure

Data Provenance for the Internet of Things. In Pro-

ceedings of the 3

ACM International Workshop on

IoT Privacy, Trust, and Security, IoTPTS ’17, pages

11–14.

Backes, M., Gerling, S., Hammer, C., Maffei, M., and Styp-

Rekowsky, P. (2014). AppGuard – Fine-Grained Policy

Enforcement for Untrusted Android Applications, pa-

ges 213–231. Springer.

Backes, M., Gerling, S., Hammer, C., Maffei, M., and von

Styp-Rekowsky, P. (2013). AppGuard: Enforcing User

Requirements on Android Apps. In Proceedings of

the 19

International Conference on Tools and Algo-

rithms for the Construction and Analysis of Systems,

TACAS ’13, pages 543–548.

see http://patronresearch.de/

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

Barrera, D., Kayacik, H. G., van Oorschot, P. C., and Somay-

aji, A. (2010). A Methodology for Empirical Analysis

of Permission-based Security Models and Its Appli-

cation to Android. In Proceedings of the 17

ACM

Conference on Computer and Communications Secu-

rity, CCS ’10, pages 73–84.

Conti, M., Nguyen, V. T. N., and Crispo, B. (2011). CR

ePE:

Context-related Policy Enforcement for Android, pages

331–345. Springer.

Davies, N., Taft, N., Satyanarayanan, M., Clinch, S., and

Amos, B. (2016). Privacy Mediators: Helping IoT

Cross the Chasm. In Proceedings of the 17

Interna-

tional Workshop on Mobile Computing Systems and

Applications, HotMobile ’16, pages 39–44.

Davis, B. and Chen, H. (2013). RetroSkeleton: Retroﬁtting

Android Apps. In Proceeding of the 11

Annual Inter-

national Conference on Mobile Systems, Applications,

and Services, MobiSys ’13, pages 181–192.

Davis, B., Sanders, B., Khodaverdian, A., and Chen, H.

(2012). I-ARM-Droid: A Rewriting Framework for In-

App Reference Monitors for Android Applications. In

Proceedings of the 2012 IEEE Conference on Mobile

Security Technologies, MoST ’12, pages 28:1–28:9.

Dey, A. K. (2001). Understanding and Using Context. Per-

sonal and Ubiquitous Computing, 5(1):4–7.

Enck, W., Ongtang, M., and McDaniel, P. (2009). Under-

standing Android Security. IEEE Security and Privacy,

7(1):50–57.

Felt, A. P., Ha, E., Egelman, S., Haney, A., Chin, E., and

Wagner, D. (2012). Android Permissions: User Atten-

tion, Comprehension, and Behavior. In Proceedings of

the Eighth Symposium on Usable Privacy and Security,

SOUPS ’12, pages 3:1–3:14.

Fragkaki, E., Bauer, L., Jia, L., and Swasey, D. (2012).

Modeling and Enhancing Android’s Permission System,

pages 1–18. Springer.

Google Inc. (2017). Android Things.

https://developer.android.com/things.

Hamlen, K. W. and Jones, M. (2008). Aspect-oriented In-

lined Reference Monitors. In Proceedings of the Third

ACM SIGPLAN Workshop on Programming Languages

and Analysis for Security, PLAS ’08, pages 11–20.

Hilty, M., Pretschner, A., Basin, D., Schaefer, C., and Walter,

T. (2007). A Policy Language for Distributed Usage

Control, pages 531–546. Springer.

Istepanian, R. S. H., Hu, S., Philip, N., and Sungoor, A.

(2011). The Potential of Internet of m-health Things

“m-IoT” for Non-Invasive Glucose Level Sensing. In

Proceedings of the 2011 Annual International Confe-

rence of the IEEE Engineering in Medicine and Bio-

logy Society, EMBS ’11, pages 5264–5266.

Kalkov, I., Franke, D., Schommer, J. F., and Kowalewski, S.

(2012). A Real-time Extension to the Android Platform.

In Proceedings of the 10

International Workshop on

Java Technologies for Real-time and Embedded Sys-

tems, JTRES ’12, pages 105–114.

oll, M. (2009). Diabetes City: How Urban Game De-

sign Strategies Can Help Diabetics, pages 200–204.

Springer.

oll, M. (2010). “On the Top of High Towers . . . ” Discus-

sing Locations in a Mobile Health Game for Diabetics.

In Proceedings of the 2010 IADIS International Confe-

rence Game and Entertainment Technologies, MCCSIS

’10, pages 61–68.

Kovatchev, B. P., Gonder-Frederick, L. A., Cox, D. J., and

Clarke, W. L. (2004). Evaluating the Accuracy of

Continuous Glucose-Monitoring Sensors. Diabetes

Care, 27(8):1922–1928.

Nauman, M., Khan, S., and Zhang, X. (2010). Apex: Exten-

ding Android Permission Model and Enforcement with

User-deﬁned Runtime Constraints. In Proceedings of

the 5

ACM Symposium on Information, Computer

and Communications Security, ASIACCS ’10, pages

328–332.

Park, J. and Sandhu, R. (2004). The UCON

ABC

Usage

Control Model. ACM Transactions on Information and

System Security, 7(1):128–174.

Perera, C., Zaslavsky, A., and Christen, P. (2014). Con-

text Aware Computing for The Internet of Things: A

Survey. IEEE Communications Surveys & Tutorials,

16(1):414–454.

Rasthofer, S., Arzt, S., Lovat, E., and Bodden, E.

(2014). DroidForce: Enforcing Complex, Data-centric,

System-wide Policies in Android. In Proceedings of

the 2014 Ninth International Conference on Availabi-

lity, Reliability and Security, ARES ’14, pages 40–49.

Russello, G., Crispo, B., Fernandes, E., and Zhauniarovich,

Y. (2011). YAASE: Yet Another Android Security

Extension. In Proceeding of the 2011 IEEE Third In-

ternational Conference on Privacy, Security, Risk and

Trust and 2011 IEEE Third International Conference

on Social Computing, PASSAT ’11, pages 1033–1040.

Schreckling, D., Posegga, J., and Hausknecht, D. (2012).

Constroid: Data-centric Access Control for Android.

In Proceedings of the 27

Annual ACM Symposium on

Applied Computing, SAC ’12, pages 1478–1485.

Scoccia, G. L., Malavolta, I., Autili, M., Di Salle, A., and

Inverardi, P. (2017). User-centric Android Flexible

Permissions. In Proceedings of the 2017 IEEE/ACM

International Conference on Software Engineering

Companion, ICSE-C ’17, pages 365–367.

Sekar, L. P., Gankidi, V. R., and Subramanian, S. (2012).

Avoidance of Security Breach Through Selective Per-

missions in Android Operating System. ACM SIGS-

OFT Software Engineering Notes, 5(37):1–9.

Sellwood, J. and Crampton, J. (2013). Sleeping Android:

The Danger of Dormant Permissions. In Proceedings

of the Third ACM Workshop on Security and Privacy

in Smartphones & Mobile Devices, SPSM ’13, pages

55–66.

Sicari, S., Rizzardi, A., Grieco, L. A., and Coen-Porisini, A.

(2015). Security, privacy and trust in Internet of Things:

The road ahead. Computer Networks, 76:146–164.

Stach, C. (2013). How to Assure Privacy on Android Phones

and Devices? In Proceedings of the 2013 IEEE 14

In-

ternational Conference on Mobile Data Management,

MDM ’13, pages 350–352.

Stach, C. (2016). Secure Candy Castle — A Prototype for

Privacy-Aware mHealth Apps. In Proceedings of the

ACCESSORS - A Data-Centric Permission Model for the Internet of Things

2016 IEEE 17

International Conference on Mobile

Data Management, MDM ’16, pages 361–364.

Stach, C., D

urr, F., Mindermann, K., Palanisamy, S. M., Ta-

riq, M. A., Mitschang, B., and Wagner, S. (2017). PA-

TRON — Datenschutz in Datenstromverarbeitungssys-

temen. In Informatik 2017: Digitale Kulturen, Ta-

gungsband der 47. Jahrestagung der Gesellschaft f

Informatik e.V. (GI), 25.9-29.9.2017, Chemnitz, volume

275 of LNI, pages 1085–1096. (in German).

Stach, C. and Mitschang, B. (2013). Privacy Management

for Mobile Platforms – A Review of Concepts and

Approaches. In Proceedings of the 2013 IEEE 14

In-

ternational Conference on Mobile Data Management,

MDM ’13, pages 305–313.

Stach, C. and Mitschang, B. (2014). Design and Implemen-

tation of the Privacy Management Platform. In Procee-

dings of the 2014 IEEE 15

International Conference

on Mobile Data Management, MDM ’14, pages 69–72.

Stach, C. and Schlindwein, L. F. M. (2012). Candy Castle —

A Prototype for Pervasive Health Games. In Procee-

dings of the 2012 IEEE International Conference on

Pervasive Computing and Communications Workshops,

PerCom ’12, pages 501–503.

Steimle, F., Wieland, M., Mitschang, B., Wagner, S., and

Leymann, F. (2017). Extended Provisioning, Security

and Analysis Techniques for the ECHO Health Data

Management System. Computing, 99(2):183–201.

Takabi, H., Joshi, J. B. D., and Ahn, G. J. (2010). Security

and Privacy Challenges in Cloud Computing Environ-

ments. IEEE Security and Privacy, 8(6):24–31.

Vashist, S. K., Schneider, E. M., and Luong, J. H. (2014).

Commercial Smartphone-Based Devices and Smart

Applications for Personalized Healthcare Monitoring

and Management. Diagnostics, 4(3):104–128.

Wei, X., Gomez, L., Neamtiu, I., and Faloutsos, M. (2012).

Permission Evolution in the Android Ecosystem. In

Proceedings of the 28

Annual Computer Security

Applications Conference, ACSAC ’12, pages 31–40.

Zeevi, D., Korem, T., Zmora, N., Israeli, D., Rothschild, D.,

Weinberger, A., Ben-Yacov, O., Lador, D., Avnit-Sagi,

T., Lotan-Pompan, M., Suez, J., Mahdi, J. A., Matot, E.,

Malka, G., Kosower, N., Rein, M., Zilberman-Schapira,

G., Dohnalov

a, L., Pevsner-Fischer, M., Bikovsky, R.,

Halpern, Z., Elinav, E., and Segal, E. (2015). Persona-

lized Nutrition by Prediction of Glycemic Responses.

Cell, 163(5):1079–1094.

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy
