Decoy Systems with Low Energy Bluetooth Communication

Aaron Hunter and Ken Wong

BC Institute of Technology, Burnaby, Canada

Keywords:

Decoy Systems, Intrusion Detection and Response, Low Energy Bluetooth.

Abstract:

We propose an architecture for a decoy system that uses low energy Bluetooth devices for communication.

We argue that these devices can be effective not only due to low power consumption, but also because an

attacker can not detect the signal from a distance. As such, information sent from the decoy system to a

monitoring system is unlikely to be noticed by an attacker. We describe a physical system that we have

developed for testing and experimentation with this approach. The results so far are promising both in terms

of the effectiveness of monitoring, and also with respect to the hidden communication. Moreover, while the

decoy system is high-interaction, it does not lead to any system interruption on the main system. Our system

is novel in that it is developed from scratch, using low-cost hardware in a manner that accurately captures

the way communication would happen in a real system. We discuss the advantages and limitations of our

framework, and discuss possible approaches to establishing formal proofs of security for this kind of physical

system.

1 INTRODUCTION

Preventing break-ins and limiting the damage done

by an attacker is a key problem for security profes-

sionals. While it would be preferable to completely

block unauthorized access to systems, it is generally

accepted that this is not a realistic goal. As such, a

variety of decoy systems have been proposed to fool

an attacker into entry for the purpose of information

gathering. In order for these systems to be effective,

they need to do two things. First, they need to closely

resemble a real system. Second, they must be able to

log and communicate the behaviour of the would-be

attacker in a manner that can not be detected. In this

paper, we argue that one effective way to design such

systems is through the use of Bluetooth Low Energy

(BLE) devices.

This is a preliminary paper in which we argue

that BLE devices can be an important component of

a decoy system. This paper makes several contribu-

tions to research on decoy systems. First, we describe

the physical simulation that we have developed using

BLE devices for system monitoring and show that it

functions effectively. This demonstrates not only the

value offered by BLE devices for monitoring, but it

also provides a template for the development of low-

cost simulations of physical systems. The notion of

’undetectability’ of a BLE signal leads to a discus-

sion of proofs of knowledge; we suggest that formal

methods can be used to provide proofs of security of

our system, under the assumption that the BLE signal

can not be detected.

2 MOTIVATION

Many different techniques are used in practice to pre-

vent break-ins. Standard preventative measures in-

clude the use of ﬁrewalls, along with cryptographic

methods to protect important data. But it is well

known that ﬁrewalls are often mismanaged (Khan and

Gupta, 2013) and they are vulnerable to port-scanning

techniques (Kaur and Gurjot, 2014; Ahanger, 2014).

An intruder that gets past a ﬁrewall can often do a

great deal of damage, and they can even gain access

to protected data through vulnerabilities in crypto-

graphic software (Lazar et al., 2013). Due to the lim-

itations of purely preventative measures, the develop-

ment of decoy systems has been established as another

form of protection from attackers.

The simplest form of decoy system is a honeypot,

which is just a fake system that contains data resem-

bling a real system(Padda et al., 2016). The idea is to

lure a would-be attacker into the honeypot and keep

them busy looking at information while tracking their

behaviour. One problem with this approach is that at-

tackers can often detect when a system is fake. As

such, it is more effective to develop a real system that

404

Hunter, A. and Wong, K.

Decoy Systems with Low Energy Bluetooth Communication.

DOI: 10.5220/0006646604040409

In Proceedings of the 4th International Conference on Information Systems Security and Privacy (ICISSP 2018), pages 404-409

ISBN: 978-989-758-282-0

has all of the expected functionality, but simply does

not connect to real data or devices. The case for this

approach is presented in (Rowe and Rrushi, 2016) for

industrial control systems, but the basic idea applies

broadly to any system designed to lure and fool at-

tackers.

The second problem with a simple honeypot is

that it must communicate with a monitoring system,

but this communication can be detected by an at-

tacker. The simplest solution is to implement a sys-

tem with minimal communication, a so-called ‘low-

interaction’ honeypot. However, it is well-known that

such systems have limited use because they do not

track the actions of the attacker sufﬁciently (Ruther-

ford and White, 2016). In fact, if the system is not

monitored adequately, a honeypot can actually in-

crease the risk of theft of data from the real system

(Brown and Andel, 2016).

We are left then with the following problem. We

need a decoy system that communicates extensively

with the real system, but is not detectable to an at-

tacker. One idea is to avoid hard-wired connections

with the real system by using wireless (Bluetooth)

communication with the decoy (Fawaz et al., 2016).

In principle, this should allow high-interaction with

less risk of detection. There are two problems. First,

Bluetooth is expensive in terms of energy use; this is a

problem if the system is running for weeks or months

at a time. The second problem is that a Bluetooth sig-

nal is reasonably strong, and it can be detected by an

attacker with suitable hardware for monitoring wire-

less communication.

Both of the problems with Bluetooth communca-

tion can, in principle, be solved by using BLE de-

vices. These devices use much less energy than tra-

ditional Bluetooth, which allows them to be powered

continuously for months or years; this makes it pos-

sible to place the devices in locations where Wiﬁ ac-

cess points would be difﬁcult to power (Kriz et al.,

2016). Moreover, it is known that the low-energy sig-

nal can not be detected at a distance (Gogic et al.,

2016). But there are challenges in designing such a

system. The physical limitation is that the decoy sys-

tem needs to be within about 10 meters of the mon-

itoring system. But even at a short distance, there

are questions around the feasibility of communicat-

ing enough data quickly for monitoring using BLE

devices, because the communication rate for BLEs is

much slower than traditional Bluetooth. Moreover, in

order to guarantee privacy, we still require a crypto-

graphic handshake (Michalevsky et al., 2016).

Based on the situation outlined in this section, it

seems that BLE devices offer a promising solution to

developing effective, high-interaction decoy systems.

But we need to test this idea in a practical system ar-

chitecture in order to show that these advantages can

actually be obtained in a physical demonstration set-

ting. That is the main motivation for this paper.

3 THE PROPOSED

INFRASTRUCTURE

3.1 Hardware

We set up a physical simulation using three Raspberry

PI devices acting as servers. We used Raspberry PI

version 3, as it was a low-cost option capable of run-

ning a variety of operating systems. For this simula-

tion, we used Kali Linux.

• The Decoy: One of the devices represents the de-

coy system. It will contain data, and monitor the

activities of those that connect to it.

• The Attacker: A second device represents the at-

tacker. This is on the same physical network as

the decoy system.

• The Actual System: This device is on a different

network, and it represents the ’real’ system that is

being protected.

Each Linux server was conﬁgured with an internal

ﬁrewall and user authentication privileges. The actual

system was secured further with closed ports.

An Arduino electronic hardware device is used as

an interpreter for communication between the servers;

it is the key to align the BLE devices such that they

can communicate with each other on each server. This

interpreter was added to facilate data transfer, due

to difﬁculties encountered with BLE stand-alone de-

vices.

The interpreter device acts like the master con-

troller that can control each of the Raspberry PI elec-

tronic boards. Each Raspberry PI electronic board

acts like a peripheral or slave device. As such, the Ar-

duino device activates and deactivates the BLEs when

communication is required. The network design is

shown in Figure 1. As noted in the previous section,

since we are using BLEs, we need the devices to be

relatively close; in testing we required less than 10

meters between devices.

3.2 System Details

We wrote several applications to detect the presence

of an attack, and report activity to the monitoring sys-

tem through the BLE devices. All monitoring appli-

cations are written in Python. The basic activities of

the main monitoring application are the following:

Decoy Systems with Low Energy Bluetooth Communication

405

Figure 1: Network Conﬁguration.

1. Login detection: Every login to the decoy ma-

chine is detected, and considered an attack.

2. Information collection: The user ID, passwords

attempted, and session ID are collected.

3. Information transmission: The log ﬁle is sent to

a program that communicates with the BLE de-

vices.

All of these tasks are duplicated in the system,

through two copies of the main monitoring program.

This is a fail safe mechanism, in case the attacker

identiﬁes and disables the program running on the de-

coy system.

In addition to the main monitoring application,

several other programs handle related tasks. These

include scanning for BLE transmissions, establish-

ing a communication channel, and receiving trans-

mitted log ﬁles. The BLEs communicate with each

other through these applications, relying on the in-

terpreter to activate teh BLE devices and permit the

transmission of data. When the Interpreter is discon-

nected, all communication between the servers stops.

In this way, it secures the communication that is ﬂow-

ing through from the decoy system to the main sys-

tem.

This methodology allows us to limit the attackers

opportunity to compromise a system. It also allows

us to investigate and gather precise information about

the attackers position. There are limits to the method-

ology with respect to protecting the system. The

method of installing two application programs can be

interrupted and removed by the attackers. However,

it would be difﬁcult to remove both of the application

programs at once, especially as they are installed on

two separate servers and the backup application pro-

gram will not be active until the primary application

program fails. As noted previously, the BLEs provide

a better solution than Classical Bluetooth devices be-

cause the range makes it harder for an attacker to de-

tect the communication.

Testing of the system is performed as in Figure 2,

with remote login on all devices simultaneously. This

allows us to simulate attacker activity, and view the

results of monitoring in real time.

4 RESULTS

4.1 Testing

There are several kinds of result that can be discussed

from the development of this system. One entirely

practical result is the fact that we were actually able

to produce a working demonstration that uses BLEs

for communication. This is worth emphasizing as a

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

406

Figure 2: Remote Login.

result, because the physical conﬁguration of the sys-

tem was actually a technical challenge. In order to

get it to work, we had to experiment with a variety

of computing devices, a variety of BLE solutions, and

a variety of physical conﬁgurations for the network.

The result was a working system that includes the key

features required for testing.

Once the system was setup, all three servers ran

and communicated effectively. We were able to sim-

ulate attacks on the decoy system in which the at-

tacker’s activity was successfully logged, and the ac-

tual monitoring system successfully received the log

ﬁle containing the attacker’s IP address, session ID

and password. Since the monitoring system is only

connected to the decoy through the BLE interpreter,

we can verify that the BLE communication was ef-

fective when the decoy system was within 10 meters

of the monitoring system. However, when we moved

the decoy system further than 10 meters from the BLE

transmitter, then the log ﬁles were no longer trans-

mitted successfully. We did not do detailed testing to

ﬁnd the exact distance required, as this is not signif-

icant for our purposes. But our testing did indicate

that successful monitoring was dependent on proxim-

ity; when the devices were close enough, then the data

was tranmitted successfully on every attempt.

4.2 Implications

We successfully built a system that will detect an at-

tack, trace the attack and give an alert if there is an

attack by using BLE devices to data transfer between

servers. The results here show that the developed ap-

plication can monitor and gather information about

the attacker. However, one feature of the system that

we were not truly able to verify is the undetectability

of the BLE communication between the decoy and the

main server. As noted, we were able to verify the lim-

ited range of communication; but this is not exactly

the same as verifying undetectability. We know that

the signal is weak, and it can not be directly detected

physically at a distance. However, we need to con-

sider other possibilities:

• The attacker may have access to a close physical

sensor.

• The attacker may have some non-physical means

to detect the communication.

The ﬁrst point here is straightforward to address. In

practical settings, we would physically prevent an at-

tacker from having access within 10 meters of our

system. The second point is harder. We can not state

conclusively that the communication is undetectable,

only that it is physically undetectable from a distance.

We admit the possibility that an attacker could ‘ﬁg-

ure out’ that communication is occuring, or that an

attacker could have inside information.

We remark that the methodology here uses very

low-cost hardware to simulate a physical system. The

Raspberry PI devices running Linux offered a realistic

simulation of real servers, and the BLE devices com-

municating through an Arduino board allowed us to

use low-energy Bluetooth in the same way it would

be used on a real system. Hence, while the actual data

involved is very simple, our system accurately sim-

ulates the BLE-aspect of system monitoring that we

Decoy Systems with Low Energy Bluetooth Communication

407

set out to study. Therefore, we suggest that the ba-

sic approach here can be seen as a model for low-cost

prototyping of physical systems, particularly in a re-

search or education environment.

5 DISCUSSION

5.1 Theoretical Veriﬁcation

To this point, we have essentially established two

things. First, we have shown that it is possible to

set up a physical network that tracks an attacker’s be-

haviour while reporting this behaviour through a BLE

device. Second, we have reason to believe that the

BLE communication will not be detected by an at-

tacker, because the signal is so weak that it can not be

detected outside very close physical proximity. How-

ever, we really have not established in a precise sense

exactly what this means. To be more precise, we have

not provided any proof of correctness or any guaran-

tee that the system will work.

What we are actually interested in creating is a

system where we have knowledge that the attacker

does not. In particular, we would like the attacker to

be ignorant with respect to several things:

1. The attacker should not know that the system they

are viewing is fake.

2. The attacker should not know that we know what

they are doing.

3. The attacker should also be unaware of the fact

that their actions are being sent to a real system.

Of these points, the ﬁrst two are standard features of

any honeypot-like scenario. The key point that dis-

tinguishes our work here is the third one. We are in-

terested in having some sort of guarantee that the at-

tacker will not know what is happening. We have a

physical reason to believe communication will not be

detected, but we would like to work towards proofs of

security for this kind of system. In this section, we

brieﬂy provide some theoretical grounds for the anal-

ysis and veriﬁcation of the network architecture that

we have introduced.

5.2 Logical Modelling

There is a long history of using logics to model

knowledge and belief. The basic premise of much of

this work is that the state of the world can be captured

by an assignment of values to propositional variables.

As such, we start with a set F of propositional vari-

ables, and we deﬁne a state to be any assignment of

true/false values to these variables. A state represents

one possible conﬁguration of the world. We can con-

struct formulas from F by using the normal symbols

∧ (and), ∨ (or), and ¬ (not). We do not go further into

the logic here, and refer the reader to a standard book

such as (Enderton, 2001) for more details.

We also assume a set A of agents. The knowledge

of each agent is deﬁned through something called a

Kripke structure, which associates with each agent a

relation r

on the set of states. Informally, if r

(s, t),

then the agent A can not tell the difference between

the states s and t. If the actual state of the world is s,

we can therefore deﬁne the beliefs of A to be the set of

states t such that r

(s, t). Typically, we have restric-

tions on r

; for knowledge it is normally assumed to

be an equivalence relation. We refer the reader to (Fa-

gin et al., 2003) for a complete introduction to reason-

ing about knowledge in a multi-agent setting. There

are many variations of this approach in the literature.

We are not interested in producing a detailed log-

ical formulation of knowledge in this paper; it is suf-

ﬁcient to note that such a formalization is possible.

Hence, the following can all be formally stated, where

A stands for an attacker and S stands for a security ad-

ministrator:

• ¬Knows

( f ake)

• ¬Knows

(Knows

(action))

• ¬Knows

(sent(sys(action)))

Logics of knowledge in the tradition of BAN logic

(Burrows et al., 1990) can be used to formalize the

meaning of these statements. There are existing tools

for using such formalizations to formally prove the

security of systems (Cremers, 2008; Hunter et al.,

2013).

The question is then: What use are logics of

knowledge for the system currently under discussion?

The fact is that our practical demonstration does not

allow us to conclude anything about the knowledge

of the attacker. We know that the attacker performs

certain actions, and we communicate these actions

through a channel that we assert is hidden. We have

strong reason to believe that this communication is

undetectable, based on the physical properties of the

signal. But we really can not be precise about exactly

what this allows us to conclude in terms of guarantees

of system security.

By formalizing the communication in a logic of

action, we can be precise about the initial knowledge

of the attacker and the system administrator. We can

also be precise about the actions the system performs,

and whether or not they are visible to the attacker.

This allows us to track the knowledge of the attacker

accurately. At the same time, it allows us to go back

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

408

and reconsider, if it turns out that the attacker had

some reason to know about the log ﬁles transfer. A

clever attacker could actually deceive the system by

performing actions that they want logged.

In any event, this formalization would allow us to

state formal properties about the system, and then for-

mally prove them under ﬂexible assumptions about

the attackers behaviour. This formal analysis will take

our system from a practical demonstration to a prov-

ably secure architecture. We leave this formal aspect

for future work.

6 CONCLUSION

The paper describes an approach to setting up a de-

coy system where the actions of an attacker are logged

and transmitted to a monitoring system using BLE de-

vices. The results showed that this could be done ef-

fectively, provided that the decoy system is in close

physical proximity to the monitoring system. Sig-

niﬁcantly, the signal used to communicate could not

be detected at a distannce beyond 10 meters. This is

an advantage for physical systems, as it means an at-

tacker is less likely to know that they are being mon-

itored. While we acknowledge that an attacker might

be able to use non-physical means to determine they

are being monitored, the physical undetectability of

our signal does make it less likely that our decoy sys-

tem will be discovered. In the discussion, we brieﬂy

discussed how notions of undetectability and igno-

rance may be formalized to provide proofs of security

at a theoretical level.

Based on the results of the present research, future

work will enlist stronger ﬁlters such as adding addi-

tional authentication keys between each of the BLE

devices that can strengthen security in the system. For

instance, setting up an authentication key combina-

tion code that is required to be validated before en-

tering the BLE master controller , which is between

the Raspberry PI Linux servers. Not only will this

strengthen the security of the system, but it will also

prevent the attacker from being able to control the Ar-

duino electronic board, which is the master Bluetooth

key controller. Once the attacker compromise the Ar-

duino electronic board, they can have full accessibil-

ity to control the Bluetooth Low Energy devices and

that will allow the attacker to control the main system

too.

REFERENCES

Ahanger, T. A. (2014). Port scan a security concern. Inter-

national Journal of Engineering and Innovation Tech-

nology, 3(10):241–246.

Brown, A. and Andel, T. (2016). What’s in your honeypot?

In Proceedings of the 11th International Conference

on Cyber Warfare and Security, pages 370–377.

Burrows, M., Abadi, M., and Needham, R. (1990). A logic

of authentication. ACM Transactions on Computer

Systems, 8(1):18–36.

Cremers, C. (2008). The Scyther Tool: Veriﬁcation, falsiﬁ-

cation, and analysis of security protocols. In Com-

puter Aided Veriﬁcation, 20th International Confer-

ence, pages 1–30.

Enderton, H. (2001). A mathematical introduction to logic.

Harcourt/Academic Press, 2nd ed edition.

Fagin, R., Halpern, J., Moses, Y., and Vardi, M. (2003).

Reasoning About Knowledge. MIT Press.

Fawaz, K., Kim, K., and Shin, K. (2016). Protecting pri-

vacy of BLE device users. In Proceedings of the 25th

USENIX Security Symposium, pages 1205–1221.

Gogic, A., Mujcic, A., Ibric, S., and Suljanovic, N. (2016).

Performance analysis of bluetooth low energy mesh

routing algorithms in case of distaster prediction.

World Academy of Science, Engineering and Technol-

ogy, 10(6):1–7.

Hunter, A., Delgrande, J., and McBride, R. (2013). Protocol

veriﬁcation in a theory of action. In Proceedings of the

Canadian Conference on AI, pages 52–63.

Kaur, R. and Gurjot, S. (2014). Analysing port scanning

tools and security techniques. International Journal

of Electrical Electronics and Computer Science Engi-

neering, 1(5):58–64.

Khan, S. and Gupta, R. (2013). Future aspects of ﬁrewall in

internet security. IEC International Journal of Tech-

nology and Management, 1(1):30–36.

Kriz, P., Maly, F., and Kozel, T. (2016). Improving indoor

localization using bluetooth low energy beacons. Mo-

bile Information Systems, 62:1–11.

Lazar, D., Chen, H., Wang, X., and Zeldovich, N. (2013).

Why does cryptographic software fail? A case study

and open problems. In Proceedings of the 5th Asia-

Paciﬁc Workshop on Systems, pages 1–7.

Michalevsky, Y., Nath, S., and Liu, J. (2016). Mash-

able: Mobile application of secret handshakes over

bluetooth. In Proceedings of the ACM Annual Inter-

national Conference on Mobile Computing and Net-

working, pages 1–14.

Padda, S., Gupta, S., Apoorva, G., Lofty, S., and Kaur, A.

(2016). Honeypot: A security tool in intrusion detec-

tion. International Journal of Advanced Engineering,

Management and Science, 2(5):311–316.

Rowe, N. and Rrushi, J. (2016). Introduction to Cyber De-

ception. Springer, 1st ed edition.

Rutherford, J. and White, G. (2016). Using as improved cy-

bersecurity kill chain to develop an improved honey

community. IEEE Computer Society, pages 2624–

2632.

Decoy Systems with Low Energy Bluetooth Communication

409
