Using Application Layer Metrics to Detect Advanced SCADA Attacks

Peter Maynard, Kieran McLaughlin and Sakir Sezer

Centre for Secure Information Technologies, Queen’s University Belfast, BT3 9DT, Belfast, U.K.

Keywords:

ICS, IDS, Network, SCADA, Security, SIEM.

Abstract:

Current state-of-the-art intrusion detection and network monitoring systems have a tendency to focus on the

‘Five-Tuple’ features (protocol, IP src/dst and port src/dest). As a result there is a gap in visibility of security

at an application level. We propose a collection of network application layer metrics to provide a greater

insight into SCADA communications. These metrics are devised from an analysis of the industrial control

system (ICS) threat landscape and the current state-of-the-art detection systems. Our metrics are able to detect

a range of adversary capabilities which goes beyond previous literature in the SCADA domain.

1 INTRODUCTION

The problem with state-of-the-art network intrusion

detection systems (IDS) is the lack of ICS-speciﬁc

insight. Many solutions focus on extracting statis-

tics based on the traditional 5-tuple of ﬂow features.

However, this misses potentially valuable information

in the SCADA application layer, which may be used

to develop more detailed metrics, regarding the secu-

rity status and performance of the underlying physical

system.

The trend in the current state-of-the-art research

is to use machine learning methods to discover ma-

licious actions on the network. A common method

is to take low level packet captures and analyse them

for anomalous activity. e.g. (Terai et al., 2017) who

use packet inter-arrival time. We propose the use of

application layer packet analysis within the Process

Control enclave, and use that data to provide an ana-

lyst with deeper insight into the security status of the

ICS facility. These metrics can be used for different

applications ranging from intrusion detection, foren-

sics, or verifying compliance with security standards

and legislation. Legislation, such as the GDPR and

NIS Directive require active monitoring and historic

measurable indicators of progress. We have derived

a set of metrics loosely based on IEC 60870-5-104,

which can also be used on other ﬁeld bus protocols.

Contributions: (i) An analysis of industrial threat

actors and their capabilities. (ii) Review the current

state-of-the-art metrics for ICS. (iii) Proposed novel

metrics that enable deeper insight into SCADA net-

works, and allow for detecting anomalies within an

ICS system. (iv) Finally, we compare the current

state-of-the-art ICS intrusion detection systems with

the proposed metrics to show a much improved cov-

erage of attack activities in reconnaissance, interfer-

ence, DoS and covert communications. The paper is

structured as follows. Section 2 and 3, detail the ICS

threat landscape. Section 4 highlights related work

and ICS metrics. Section 5 details the proposed met-

rics drawing comparison between state-of-the-art IDS

proposals and our contributions.

2 ICS ENVIRONMENT

A high-level overview of an ICS network typically

can be broken down to three enclaves. 1. Busi-

ness 2. SCADA and 3. Process Control. Histor-

ically, SCADA enclaves were air-gapped, however,

in recent years it is common to ﬁnd one-way trafﬁc

from SCADA to the business enclave. A SCADA net-

work may contain a data historian, human machine

interface (HMI), and remote devices such as pro-

grammable logic controllers (PLC). The business en-

clave facilitates traditional systems used for account-

ing, human resources and analysing productivity of

the plant. The business network is the main entry

point for an adversary, typically communicating with

the SCADA network, requesting data used within per-

formance reports. The SCADA enclave contains HMI

software and monitoring equipment. Similar to the

business enclave, as vendors move towards open stan-

dards, the hardware requirements are becoming less

proprietary, allowing for the use of common off the

shelf software (Adobe Flash, Microsoft Windows and

418

Maynard, P., McLaughlin, K. and Sezer, S.

Using Application Layer Metrics to Detect Advanced SCADA Attacks.

DOI: 10.5220/0006656204180425

In Proceedings of the 4th International Conference on Information Systems Security and Privacy (ICISSP 2018), pages 418-425

ISBN: 978-989-758-282-0

Physical

Domain

PLC

HMI

Data

Historian

RTU

Enterprise

Workstations

Reporting

Process Control Enclave

SCADA Enclave

Business Enclave

Figure 1: High-level view of an ICS network.

*Unix). The SCADA enclave communicates with the

process control enclave, issuing commands and re-

ceiving state information from the physical systems.

The process control enclave contains devices that

communicate using specialised ﬁeld bus protocols i.e.

IEC104, Modbus-TCP, DNP-3 etc. The process con-

trol enclave can potentially span a large physical area.

On the other hand, this physically large enclave is of-

ten not segregated, and is conﬁgured as a single ﬂat

LAN. Such networks range from on-premises, to re-

mote locations such as autonomous substations. This

is a mission critical network which is sensitive to la-

tency. For example, if this were an electrical sub-

station there may be various meters providing power

readings that are collected by an RTU or IED and

transmitted up to the SCADA network. Alternatively,

an operator might need to issue a command to shut

down a system, which needs to be completed in a

timely and reliable manor.

Figure 1 shows the high-level of separation and re-

lationships between the four enclaves. This segmen-

tation works well with (Shostack, 2014) suggestion of

using ‘Trust Boundaries’ to identify where a risk may

initiate. Once the SCADA encalve has been breached,

any data received from the process control enclave

can not be trusted. This paper focuses on the com-

munications between the SCADA and Process control

enclave because of the restricted types of protocols

which should be seen between these networks. The

aim is to enable detection of malicious events affect-

ing the most critical systems as a priority to counter

system risks.

3 INDUSTRIAL THREAT MODEL

Typical threat modelling processes are asset/software-

centric. While this provides valuable insight into at-

tack paths and vulnerabilities within software, it fails

to highlight possible methods to detect network intru-

sions. ICS networks are well understood, but the lack

of information about the threat actors limits develop-

ment of defence systems. As such, the authors pro-

pose to perform an adversary/attack-centric approach

to modelling potential threats. The aim is to better

align detection metrics at the application layer with

the characteristics of realistic threats to the process

network.

Without understanding adversaries’ capabilities, it

will be difﬁcult to know where to place active de-

fences such as network security monitoring. This sec-

tion will deconstruct and model known adversaries of

industrial systems in order to highlight possible types

of attacks. NIST SP-800-82 (Stouffer et al., 2015)

deﬁned four primary adversary actors as Individual,

Group, Organisation, Nation-State. Each of these

have their own characteristics and capabilities. Stouf-

fer’s work aligns well with (Robinson, 2013), which

performed a comprehensive analysis of the SCADA

threat landscape. The proposed approach therefore

begins by aligning adversaries with attacks identiﬁed

from the state-of-the-art detection literature. Table 1

shows different attack capabilities which can be per-

formed by each threat actor. Depending on a per-

ceived threat model (e.g., a high risk of being attacked

by a group or organisation), defences can be prepared

against certain types of attacks.

Different classes of adversaries are now brieﬂy de-

ﬁned. An individual is a single person working alone.

Insiders which can range from on-site employees, re-

mote contractors or partner companies. The scope

of damage which these individuals could cause de-

pends on their level of privilege within the system.

The likely person could be a disgruntled employee or

script kiddie. Types of attacks from individuals can

range from port and device scanning to insider com-

promise resulting in signiﬁcant damage.

A group is one or more persons working together.

The amount of technical and domain knowledge is po-

tentially moderate to high. Groups can fall into two

categories, ad-hoc and established. An ad-hoc group

is likely to be performing basic incoherent attacks. An

established group would have more resources to at-

tract individuals with domain expertise. Their motiva-

tion would likely be political and fall into the ‘Hack-

tivist’ deﬁnition. Types of attacks which might be per-

formed are spear-phising, custom malware and noisy

reconnaissance.

Organisations, not unlike groups, consist of more

than one person, but have more domain knowledge

and technical abilities. They may be industrial com-

petitors, suppliers, partners, or customers. Their in-

tention may be corporate espionage or ﬁnancial gain,

an organisation would be able to perform advanced

reconnaissance as well as targeted malware for well

known devices. Nation-states have similar features

Using Application Layer Metrics to Detect Advanced SCADA Attacks

419

Table 1: Comparison of actors and capabilities.

Attack Stages

Individual

Group

Organisation

Nation-State

Reconnaissance

Network Scan

• • • •

Device/Protocol Scan

- • • •

Report Server Information

- - • •

Read Device Identiﬁcation

- - • •

Interference

Command Replay

- • • •

Command Injection

- • • •

Unauthorised Write

- - • •

Unauthorised Read

- • • •

Clear Counter/Diagnostic

Registers

- • • •

Rouge Device

- - • •

Firmware Tampering

- - • •

Denial of Service

TCP/UDP Spam

• • • •

Remote Restart

- - • •

Force PLC into Listen

Mode

- - • •

Covert

Covert Comms.

- - - •

Stealthy Deception Attack

- - - •

Malicious Firmware

- - • •

to the organisation threat actor, but have considerably

more capabilities than the others. A nation-state’s in-

tentions may be espionage and warfare. Typically,

they would use advanced methods such as the attacks

detailed by (Kleinmann et al., 2017), in which they

propose a stealthy attack on a SCADA system that is

protocol and process aware. A nation-state might use

covert channels within the SCADA enclave, such as

the one proposed by (Lemay et al., 2016), used for

command and control. Examples of such nation-state

attacks are the Ukrainian power outages of 2015/16,

and the Stuxnet malware.

4 RELATED WORK ON METRICS

Measurements provide a single-point-in-time view of

speciﬁc, discrete factors, while metrics are derived by

comparing a baseline to two or more measurements

over time. Measurements are made by counting, met-

rics are made from analysis. Another way of think-

ing is that measurements are objective raw data and

metrics are either objective or subjective human in-

terpretations of those data (Payne, 2006). A metric

should communicate useful information and be con-

sistent and cheap to produce. For a metric to be used

in further analysis it should be quantiﬁable, repeat-

able and speciﬁc to the context where it is applied.

(Rathbun and Homsher, 2009) (Pendleton et al., 2016)

reviewed the current state-of-the-art security metrics,

which can be broken down into four categories: 1)

Attack; 2) System Vulnerabilities; 3) Situational; and,

4) Defences. They discuss the use of intrusion detec-

tion metrics with a focus on the effectiveness of an

IDS. This can be used to compare detection systems.

For actual attack measurements, they focus on zero-

day vulnerabilities which provides a measurement of

the attack consequences in retrospect. They propose

measurements which allow for monitoring a botnet’s

applicability and how resourced it is, which can be

used in developing and deploying mitigation strate-

gies e.g. sink holes. (Zhang et al., 2016) have mod-

elled network diversity as a security metric to evalu-

ate network robustness against zero-day vulnerabili-

ties. They measured the number of distinct resources

within the network such as hosts, and host connec-

tivity, resources and any similarities. They designed

a probabilistic model which identiﬁes a path of least

resistance to compromise an asset.

Building on these concepts, the following sections

present and analyse existing work on the development

of metrics speciﬁc to ICS, focusing on three main

areas: 1) generic network metrics i.e. packet tim-

ing/length; 2) Physical metrics using data from the

physical domain; and 3) the SCADA application layer

as a source for deriving indicators of compromise.

4.1 Generic Network Metrics

(Terai et al., 2017), propose the use of Support Vector

Machines (SVM) to identify attacks on an ICS net-

work. However the SVM was trained on generic net-

work trafﬁc and would thus be unable to detect spe-

ciﬁc intrusions like SCADA based covert communi-

cation channels, which disguise command and control

(C2) within genuine ICS trafﬁc. (Rudman and Irwin,

2016) developed a framework to automatically iden-

tify network indicators of compromise (IOC) from

packet captures. By running the Dridex malware in

a dynamic sandbox they identiﬁed basic high-level

IOCs such as IP address ranges of control server and

frequently used protocols and ports. This is valuable

data which can be used to analyse the behaviour of

speciﬁc malware variants. However, it fails to gener-

ate any ICS speciﬁc IOCs.

(Wang et al., 2014), propose that by modelling

network connectivity along with policies and conﬁgu-

rations of a host, they can predict the number of zero-

day compromises needed to disrupt a critical asset.

The higher the number, the less likely the asset is to

be compromised. The model depends on the existence

of network connectivity which is not always available.

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

420

(Lemaire et al., 2017) have used machine reasoning to

identify vulnerabilities in an industrial system based

on NIST and ICS-CERT. They use the Systems Mod-

elling Language (SysML) to model the system and

perform an analysis. With this design, they are lim-

ited by the vulnerability database which is a) based

on known exploits and b) manually updated, which

can cause delays in detection.

(Zhang et al., 2015) have expanded on the model

of ‘mean-time-to-compromise’ (MTTC), used to es-

timate the time it takes for an adversary to compro-

mise an asset. Using Bayesian network attack graphs,

Zhang et.al are able to identify potential attack steps

and quantify various attack scenarios. The ﬁrst attack

graph is used to determine the probabilities of suc-

cessful exploitation of a vulnerability in the SCADA

enclave to gain root access. This is calculated by con-

sidering the ratio of exploits via CVE/CVSS scores.

The second is used to evaluate the probability of

successful compromise of the communication links

between the SCADA and process enclaves. They

decompose a man-in-the-middle (MITM) attack and

counter-measures are included within the model.

(Vasilomanolakis et al., 2016) developed a honey-

pot that emulates an ICS system, whereby they are

able to generate IDS rules automatically from the

results. They have emulated a range of ICS pro-

cesses, and able to detect different classes of attacks:

Single-Protocol Level Detection (SPLD); Multi-Stage

Level Detection (MSLD); and Payload Level Detec-

tion (PLD). However, they are restricted by collec-

tion biases, because the types of attacks that honey-

pots typically detect are automated scanning of well

known attacks.

4.2 Physical Metrics

(Urbina et al., 2016), model the physical state of the

system and compare the predicted values to actual

readings. The attacks they can detect are MITM-type

scenarios where the adversary is sending false sen-

sor data to the PLC. As they noted this is a noisy ap-

proach and easily detectable. They propose a sophis-

ticated stealthy attack, in which they monitor a spe-

ciﬁc value within the system and track it for changes.

They proposed a stateful and stateless method to de-

tect changes of the physical system to determine if an

attack had occurred. (Luchs and Doerr, 2017) pro-

posed IDS monitoring in remote ﬁeld devices, with

the intention to gain more visibility into the process

control enclave. They proposed additional monitor-

ing vectors such as acoustic levels, to identify com-

plex attacks such as Stuxnet. Luchs and Doerr mon-

itored the status of ﬁeld devices independently from

the HMI/PLC readings allowing for additional vali-

dation. This was used to conﬁrm whether the device

is operating within the manufacture’s speciﬁcation,

which is another vector for detecting anomalous ac-

tivity. While the proposed IDS does provide superior

insights into the process control enclave over tradi-

tional vectors, it would be unlikely to be adopted by

ICS operators in its current state, due to the complex-

ity of deployment. This is unlike traditional network

IDS, which can be quickly deployed and integrated

with existing systems with out bespoke conﬁguration.

4.3 SCADA Metrics

(Almalawi et al., 2016), have proposed a novel data-

driven clustering approach, based on the contents of

SCADA protocols. They are able to identify a set of

working states which represent the SCADA system.

From there, it is possible to cluster the states into

normal and abnormal. The states are derived from

data extracted from the Modbus-TCP protocol, i.e:

a) water ﬂow pressure, demand and level; b) Com-

mand value status and setting; and c) Pump status and

speed. A MITM attack was simulated and false water

readings were reported, which would cause the tanks

to empty. Trafﬁc is legitimate Modbus-TCP so no

alerts are generated. A possible solution to detect this

would be to monitor all the tanks and their respective

water levels, instead of individually.

(Gonzalez and Papa, 2007), developed a system

to passively monitor Modbus-TCP communications

and extract data relating to RTUs, e.g. device status

and network topology. They developed three compo-

nents: 1) Network Scanner; 2) Transaction Checker

consisting of: pairs that match sets of messages which

are passed on to the 3) Incremental network map-

per, which maintains a dynamic data structure stor-

ing the network topology and device status infor-

mation. (Nivethan and Papa, 2016), reviewed open

source ﬁrewalls with regards to industrial control us-

age. They choose to use iptables due to its ability

to perform application layer inspection. They identi-

ﬁed some Modbus-TCP ﬁelds for use in their exper-

iments, primarily focusing on the function code and

the data ﬁeld. They were able to prevent the follow-

ing attacks and enumeration known to work on the

ModBus-TCP protocol: a) Unauthorised Write; b)

Unauthorised Read; c) Clear counters and diagnos-

tic registers; d) Remote restart; e) Force PLC into

listen-only mode; f) Report Server information; and

g) Read device identiﬁcation. This is a typical pre-

vention mechanism which needs to be placed between

the PLC and the HMI, so it would only be put into

production if it is absolutely certain the blocked ac-

Using Application Layer Metrics to Detect Advanced SCADA Attacks

421

tions will not be needed in an emergency. Rather than

ﬁltering trafﬁc which meets the criteria, real system

operators are more likely to log the data for future

analysis.

(Jardine et al., 2016), built a non-invasive IDS,

which focuses on the legacy Siemens S7 protocol.

They extract data from packet captures, such as read,

write and logic code downloads. Additional trafﬁc

such as TCP/ARP/UDP are classed as ‘Other’. They

are able to identify intrusions using the following

heuristics: a) Quantity; b) Temporal; c) IP (Commu-

nication between the PLC and others); and d) PLC

Logic code download. A baseline was built on a net-

work capture of a few hours, features are then ver-

iﬁed by a domain expert. Their system is limited

to one PLC per instance of the IDS, which needs to

be conﬁgured to that speciﬁc PLC. (Hadziosmanovic

et al., 2012), performed an analysis of network and

host-based data to determine what is viable for use

in detecting network anomalies. They focused on the

results of the network analysis and analysed the ap-

plication payload along with basic TCP/IP features.

They mapped common communication patterns of an

ICS network by extracting TCP ﬂows and perform-

ing a coarse payload analysis. This was followed by

extracting activity patterns for each device and proto-

col. As with other related work they used 5-tuple and

Modbus function code. We have chosen six proposed

systems discussed above to perform an analysis of our

proposed metrics. They were chosen to speciﬁcally

cover the three categories, generic network, physical,

and SCADA speciﬁc. They are all able to detect their

targeted threat, yet not one is able to detect the full

range of threats.

5 NETWORK BASED METRICS

FOR ICS PROTOCOLS

This section will discuss the use of advanced appli-

cation layer metrics and how they are able to iden-

tify anomalies within both SCADA and process con-

trol enclaves. Section 4 highlighted common forms of

network metrics that are able to detect IT related at-

tacks. Many metrics do not consider the communica-

tion context. Focusing only on basic network charac-

teristics, 5-tuple, offers less insight into the process of

the underlying system and its security status. An ad-

vanced adversary (e.g. with high skill, resources, and

domain knowledge) when inﬁltrating a network will

attempt to conceal their actions. A common method is

to disguise their communications to appear as if they

are normal operation. With generic network metrics,

this would not be detected. To address these short-

comings, a range of metrics will now be presented

that take the communication context into account.

Table 2 contains the proposed network metrics for

use in SCADA and process control enclaves. The

metrics are broken down into three columns. Met-

ric: this is a short hand for the speciﬁc measurement

which is used as a reference to the issue. Metric Com-

putation: is the formula used to the measure the spe-

ciﬁc metric. Purpose: this provides a concise descrip-

tion of the types of threats the metric could indicate.

Not included in the table is direction of the trafﬁc;

either from the supervisory enclave or to the process

control. It is possible to measure in a single direction

or both. Enforcing this can identify breach of the trust

boundaries.

5.1 Comparison of Proposed Metrics

Table 3 compares the current state-of-the-art detec-

tion methods against the proposed metrics. The com-

parison is subdivided into four groupings: A) a single

metric; B) two metrics; C) three metrics; and D) four

or more metrics. Each grouping inherits the previ-

ous grouping, thus allowing for a more comprehen-

sive analysis of the trafﬁc. For example, detecting a

network scan (group A) can be done using only M0.

Where as, detecting an unauthorised read (group B)

would need M3 and M4, and since it is in group B, it

will inherit group A’s M0 which is also needed for the

attack detection. We now discuss the groups in more

detail.

Group A: Due to the consistently predictable na-

ture of the process control network, it is easy to iden-

tify non-targeting scanning and obtrusive communi-

cation by using simple metrics such as distinct proto-

cols, ports, IP addresses, and date timestamps.

Group B: By monitoring commands which get/set

values of remote devices, we are able to detect abnor-

mal values from legitimate (or illegitimate) devices.

This can indicate an adversary attempting to deter-

mine the status of the current system to escalate privi-

lege. By analysing the number of commands accepted

or rejected along with the values, we are able to detect

these actions.

Group C: The advantage of measuring the access

of each device at a protocol level allows for greater

insight into activities within the system which di-

rectly affect the SCADA domain, rather than basic

TCP/IP communication patterns. By understanding

the everyday operations at this level an analyst (or al-

gorithm) could identify anomalous activities. Mon-

itoring the command type and response at both the

source (SCADA) and destination (Process Control)

will enable better monitoring for replay and injection

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

422

Table 2: Proposed application layer metrics.

Metric

Computation

Purpose

M0: Generic

Protocol

Count the number of

distinct protocols

Detect any non-SCADA

speciﬁc communication,

this could be a result of

network probing.

M1: Firmware

update

Count the number of

update ﬁrmware

commands

Detect any unexpected

alteration of the behaviour

of devices which might

produce unwanted and

unpredictable results.

M2: Set value

Count the number of

set or update value

commands

Detect any unexpected

alteration of the behaviour

of devices which might

produce unwanted and

unpredictable results.

M3: Get value

Count the number of

get value commands

Detect an increase in

monitoring commands

which could result in a

denial of service of the

device.

M4: Accepted

Command

Count the number of

accepted commands

Detect an increase in

accepted commands which

could identify unexpected

behaviour within the

network.

M5: Rejected

Command

Count the number of

rejected commands

Detect an increase in

rejected commands which

could identify unexpected

behaviour within the

network.

M6: Command

Type

Count the number of

distinct command

types

Detect any unexpected

commands which could

alter the behaviour of

devices, or indicate

unauthorised access on the

network.

M7: Response

Type

Count the number of

distinct response

types

Detect any unexpected

responses which could

indicate strange devices

behaviour, or indicate

unauthorised access on the

network.

M8: Device

Address

Count the number of

distinct common

address (Link

Address)

Detect any unexpected

devices on the network and

identify most

communicating devices

which could indicate

misconﬁgurations.

M9:

Application

Address

Count the number of

distinct information

object addresses

(Application

Address)

Detect any unexpected

application addresses on the

network which could

identify misconﬁguration of

a device.

M10: Address

Count the number of

distinct addresses

(Link and

Application)

Detect any unexpected

addresses on the network

which could identify

misconﬁguration of a

device.

M11: Cause of

transmission

Count the distinct

CoT

Detect an unexpected CoT

which could indicate

abnormal behaviour within

the network.

M12: Avg.

Information

Objects

Count the average

number of

Information Objects

Detect a large amount of

data being transmitted

to/from a device. Which

could result in abnormal

behaviour within the

network.

Table 3: Comparison of proposed metrics and SoA detec-

tion methods.

Attack Stages

(Vasilomanolakis et al., 2016)

(Terai et al., 2017)

(Nivethan and Papa, 2016)

(Gonzalez and Papa, 2007)

(Jardine et al., 2016)

(Luchs and Doerr, 2017)

Proposed Metrics

Grouping

Reconnaissance

Network Scan • • • - • - M0 A

Device/Protocol Scan • - • • • - M3,6,7 C

Report Server Information • - • • - - M3,6,7 C

Read Device Identiﬁcation • - • • - • M7,12 B

Interference

Command Replay - • - - - • M4,5,7 C

Command Injection - - - - - • M4,5,7 C

Unauthorised Write - - • • • - M2,4 B

Unauthorised Read - - • • • - M3,4 B

Remotely Clear Registers - - • - • - M6,7 B

Rouge Device - - - • • - M8,9,10 C

Firmware Tampering - - - • • • M0,1 B

Denial of Service

TCP/UDP Spam • • • - • - M0 A

Remote Restart - - • - • - M4,6,7 C

Force PLC into Listen

Mode

- - • - - - M4,6,7,11 D

Covert

Covert Comms. - - - - - • M6,7,11,12 D

Stealthy Deception Attack - - - - • • M2,3,4,6,7 D

Malicious Firmware - - - - • • M0,1,5,6, D

7,9,10,11 D

attempts.

Group D: These metrics are dependent on the pro-

tocol used. Because of this, we are able to measure

the cause of a transmission (whether the packet is rou-

tine, manual, or as a reaction to an event). This can

provide an indication of the desired effect an attacker

is attempting to achieve, e.g. an intruder perform-

ing a DoS by initiating packets designed to cause the

remote device to operate in diagnostic or other non-

standard modes.

In the case of the stealthy deception attack (Klein-

mann et al., 2017), it would be a matter of placing

measuring sensors at multiple points across the net-

work. Using a combination of all the metrics, it is pos-

sible to highlight this attack. Covert command chan-

nel proposed by (Lemay et al., 2016) would be de-

tected by monitoring the values within the command’s

request and response (M6-7), along with the number

information objects and cause of transmissions (M11-

12). Malicious ﬁrmware where a self-propagating

worm was developed to run within the CPU of the

PLC such as (Spenneberg et al., 2016), would be de-

tected by monitoring the device addresses (M9-10),

ﬁrmware upload requests (M1) and command types

used (M4-7). Unavoidable variations in these metrics

caused by this attack will allow this attack pattern to

Using Application Layer Metrics to Detect Advanced SCADA Attacks

423

be discerned from the normal operations of the sys-

tem.

6 CONCLUSION

This paper highlights the threat actors that exist and

their capabilities in regards to an ICS network. This

is important when choosing what defences to de-

ploy. This work has expanded on (Gonzalez and Papa,

2007), and proposes novel metrics which are able to

detect a wider range of threats. This work also ad-

dresses a gap in the existing state-of-the-art and com-

mercial systems. In particular, (Terai et al., 2017;

Zhang et al., 2015) and (Vasilomanolakis et al., 2016)

are unable to detect adversaries which disguise their

activities within the application layer. The proposed

metrics can detect such intrusions. The metrics were

developed with the intention of providing a classiﬁ-

cation system with deeper insight into a SCADA net-

work. (Nivethan and Papa, 2016) and (Jardine et al.,

2016), consider the application layer, but they are lim-

ited to a single host with limited visibility to the ap-

plication. Without encoding knowledge of the sys-

tem into a detection system it will require a user with

domain knowledge to act on the results. As a next

step we intend to apply the metrics to real world ex-

periments to conﬁrm their effectiveness. This can be

validated by inputting the data into a SIEM and per-

forming baseline comparison with known normal op-

erations, as well as attack patterns. Finally, we plan

to experiment with one class SVMs to discover ma-

licious actions on the network. In conclusion, we

show that by creating and analysing metrics at the ap-

plication layer, it allows the detection of a multitude

of realistic threat types, which provides more com-

prehensive detection capabilities compared to exist-

ing state-of-the-art methods. It allows for lightweight

analysis which is suitable for multiple purposes, such

as forensics, SIEM integration, features for enhanced

machine learning approaches, and complying with le-

gal requirements.

ACKNOWLEDGEMENTS

This work was funded by EPSRC project ADAMA,

reference EP/N022866/1.

REFERENCES

Almalawi, A., Fahad, A., Tari, Z., Alamri, A., AlGhamdi,

R., and Zomaya, A. Y. (2016). An Efﬁcient Data-

Driven Clustering Technique to Detect Attacks in

SCADA Systems. IEEE Transactions on Information

Forensics and Security.

Gonzalez, J. and Papa, M. (2007). Passive scanning in Mod-

bus networks. Critical Infrastructure Protection.

Hadziosmanovic, D., Bolzoni, D., Etalle, S., and Hartel,

P. H. (2012). Challenges and opportunities in securing

industrial control systems. In Proceedings of the IEEE

Workshop on Complexity in Engineering. IEEE.

Jardine, W., Frey, S., Green, B., and Rashid, A. (2016).

SENAMI: Selective Non-Invasive Active Monitoring

for ICS Intrusion Detection. In Proceedings of the

2Nd ACM Workshop on Cyber-Physical Systems Se-

curity and Privacy.

Kleinmann, A., Amichay, O., Wool, A., Tenenbaum, D.,

Bar, O., and Lev, L. (2017). Stealthy Deception At-

tacks Against SCADA Systems. In arXiv CS.CR.

Lemaire, L., Vossaert, J., Jansen, J., and Naessens, V.

(2017). A logic-based framework for the security

analysis of Industrial Control Systems. Automatic

Control and Computer Sciences.

Lemay, A., Fernandez, J. M., and Knight, S. (2016). A

Modbus command and control channel. In IEEE Sys-

tems Conference.

Luchs, M. and Doerr, C. (2017). Last Line of Defense: A

Novel IDS Approach Against Advanced Threats in In-

dustrial Control Systems. In International Conference

on Detection of Intrusions and Malware & Vulnerabil-

ity Assessment.

Nivethan, J. and Papa, M. (2016). On the Use of Open-

source Firewalls in ICS/SCADA Systems. Inf. Sec. J.:

A Global Perspective.

Payne, S. C. (2006). A guide to security metrics. SANS

institute.

Pendleton, M., Garcia-Lebron, R., Cho, J.-H., and Xu, S.

(2016). A Survey on Systems Security Metrics. ACM

Computing Surveys.

Rathbun, D. and Homsher, L. (2009). Gathering security

metrics and reaping the rewards. SANS Institute, Oct.

Robinson, M. (2013). The SCADA Threat Landscape. In

ICS-CSR.

Rudman, L. and Irwin, B. (2016). Dridex: Analysis of the

trafﬁc and automatic generation of IOCs. In Informa-

tion Security for South Africa.

Shostack, A. (2014). Threat modeling: designing for secu-

rity. Wiley.

Spenneberg, R., Brggemann, M., and Schwartke, H. (2016).

Plc-blaster: A worm living solely in the plc. Black Hat

Asia, Marina Bay Sands, Singapore.

Stouffer, K., Pillitteri, V., Lightman, S., Abrams, M., and

Hahn, A. (2015). Guide to Industrial Control Systems

(ICS) Security. Technical Report NIST SP 800-82r2,

National Institute of Standards and Technology.

Terai, A., Abe, S., Kojima, S., Takano, Y., and Koshijima,

I. (2017). Cyber-Attack Detection for Industrial Con-

trol System Monitoring with Support Vector Machine

Based on Communication Proﬁle. IEEE European

Symposium on Security and Privacy Workshops.

Urbina, D., Cardenas, A., Tippenhauer, N. O., Valente, J.,

Faisal, M., Ruths, J., Candell, R., and Sandberg, H.

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

424

(2016). Limiting The Impact of Stealthy Attacks on

Industrial Control Systems. In NIST.

Vasilomanolakis, E., Srinivasa, S., Cordero, C. G., and

Mhlhuser, M. (2016). Multi-stage attack detec-

tion and signature generation with ICS honeypots.

In IEEE/IFIP Network Operations and Management

Symposium.

Wang, L., Jajodia, S., Singhal, A., Cheng, P., and Noel, S.

(2014). k-Zero Day Safety: A Network Security Met-

ric for Measuring the Risk of Unknown Vulnerabili-

ties. IEEE Transactions on Dependable and Secure

Computing.

Zhang, M., Wang, L., Jajodia, S., Singhal, A., and Al-

banese, M. (2016). Network Diversity: A Secu-

rity Metric for Evaluating the Resilience of Networks

Against Zero-Day Attacks. IEEE Transactions on In-

formation Forensics and Security.

Zhang, Y., Wang, L., Xiang, Y., and Ten, C. W. (2015).

Power System Reliability Evaluation With SCADA

Cybersecurity Considerations. IEEE Transactions on

Smart Grid.

Using Application Layer Metrics to Detect Advanced SCADA Attacks

425
