First Step Towards Enhancement of Searching Within Medical

Curriculum in Czech Language using Morphological Analysis

Matěj Karolyi, Jakub Ščavnický and Martin Komenda

Institute of Biostatistics and Analysis, Faculty of Medicine, Masaryk University, Brno, Czech Republic

Keywords: Morphological Analysis, Medical Curriculum, OPTIMED, Search Engine.

Abstract: This paper is focused on natural language processing techniques and morphological analysis of medical and

healthcare curriculum corpus in the Czech language. We show an overview of basic steps that should lead to

the improvement of search engine of an existing curriculum management system. The main goals of this initial

phase are: to understand the morphological analysis and the currently used morphological analyser, to explore

the possibilities of analyses and to deduce if these are suitable for the purposes of enhancing the search engine.

As results, we explain how the morphological analysis helped us to reduce the density of unique words

describing the curriculum and what are the key features of morphological analysis of the Czech language.

1 INTRODUCTION

Many innovative trends and ideas have appeared in

medical and healthcare curriculum development,

management and mapping during the last decade

(Dent, Harden and Hunt 2017, Komenda, Víta, et al.

2015, Brauer and Ferguson 2015). However, the

crucial goal is still the same: to better understand what

students learn and what teachers really teach. A

curriculum usually consists of a set of compulsory,

compulsory-optional and optional courses, where

a suitable combination of theoretically focused topics

together with a clinical teaching base are taught.

Curriculum designers have designed their study

programmes using various modules and components

(e.g. sequence blocks, events or competencies) and

descriptive attributes (e.g. category, keywords or

assessment form). As an illustration, the full metadata

description of the General Medicine study

programme at Masaryk University in the Czech

Republic covers in total approximately 2,500

standard pages, i.e. pages containing 1,800 characters

each (Komenda 2015). For a global in-depth

inspection and analysis of such a huge amount of data

records, an accurate search engine built on a given

curriculum is needed.

1.1 OPTIMED Platform

For the purposes of optimising and harmonising the

medical and healthcare curriculum, an original

curriculum management system (CurrMS) called

OPTIMED has been developed (Komenda, Schwarz,

et al. 2015). The OPTIMED platform covers a

detailed description of formal metadata associated

with the so-called building blocks: medical sections,

disciplines, courses, learning units, and

interconnections to the learning outcomes. Some of

these building blocks are associated with printed and

e-learning study materials. The organisation of these

metadata is mostly designed in the parametric form

supplemented with textual attributes in order to allow

further pre-processing and analyses. OPTIMED is

based on a modular design that divides the platform

into four independent modules providing separate

functionalities according to its use in practice: (i)

Learning outcome register, (ii) Learning unit register,

(iii) Browser, (iv) Reporting toolbox.

The Browser module is a full-text search engine,

which is designed to answer user search queries and

to provide the required results for the broad academic

community (students, teachers, guarantors,

curriculum designers and faculty management).

288

Karolyi, M., Š

cavnický, J. and Komenda, M.

First Step Towards Enhancement of Searching Within Medical Curriculum in Czech Language using Morphological Analysis.

DOI: 10.5220/0006757902880293

In Proceedings of the 10th International Conference on Computer Supported Education (CSEDU 2018), pages 288-293

ISBN: 978-989-758-291-2

1.2 Focus and Goals of the Study

This paper focuses on natural language processing

techniques used to process a medical and healthcare

curriculum corpus and provides the summary of basic

steps that should lead to the improvement of search

engine in the OPTIMED platform. The main

motivation is enhancement of already existing search

engine. Thanks to the enhancement by morphological

analysis, we will be able to return results that are even

more accurate. Because we are at the very start of our

efforts, we have defined our primary areas of interest

as follows: to understand the morphological analyser

and morphological analysis itself; to study the

analyser’s interface and general work with it; to

explore its possibilities; to analyse its outputs and to

evaluate if it is suitable for our purposes; and finally,

to design a procedure for its integration into the

existing platform. We have identified the following

research questions, which are focused on how to

perform morphological transformations of a medical

text: (i) Can we adopt the morphological analyser to

enhance the medical curriculum management system

(CurrMS)? (ii) Are we able to identify features of

morphological analysis that make the CurrMS search

engine more effective (more accurate and faster)? (iii)

Can we implement specific morphological analysis

features as an extension of the CurrMS search

engine?

2 METHODS

A morphological analysis is not a trivial problem in

the Czech language. There are some sophisticated

tools – the so-called morphological analysers – that

can be used for these purposes. One of them, Ajka

(Sedláček), is based on finite state machines; it is well

documented and ready to use via an online user

interface reachable by the web browser. Moreover, an

interface for PERL and Python is implemented by the

tool provider. Based on Ajka, Majka is another

morphological analyser for the Czech language.

Majka is a fast analyser which assigns basic word

forms and their corresponding grammatical tags to

one word on the input. This assignment is done only

in case when a given word on input is present in the

Majka’s vocabulary. This vocabulary can be extended

on demand. Majka is available in two forms: (i) as a

command line tool for batch processing of text files,

(ii) as a library in the form of calling functions in the

C language. Despite the fact that Majka is built on

Ajka and therefore gives more less the same results,

it is a more flexible, faster and independent

implementation based on a finite state machine

(ŠmerkandRychlý2009).

2.1 Majka Morphological Analyser

We decided to use the Majka morphological analyser

to enhance the full-text search within the OPTIMED

curriculum management system. The main reason for

selecting Majka was the availability of its binaries,

the vocabulary for assigning basic word forms and

tags to analysed words and the possibility of simple

integration in CurrMS using the command line.

Furthermore, the vocabulary we use was enriched by

a set of medical terms by courtesy of its authors.

Calling the Majka analyser on a word input

requires the specification of a vocabulary file. The

vocabulary files are essential for the finite state

machine, which is the computational engine of whole

analyser. There are several types of vocabularies: (i)

w-lt: from word to basic forms and tags, (ii) l-wt:

from basic form to all word forms and tags, (iii) lt-w:

from lemma and tag to word. All vocabularies in their

basic form can be downloaded from the developer’s

website (Šmerk 2007). We chose the right type of

vocabulary depending on the desired action from

Majka.

The basic command form using the w-lt

vocabulary is as follows:

$ echo robot|

majka -f majka.w-lt

This command passes the word “robot” to Majka,

which subsequently returns output (a list of relevant

words with tags) using the w-lt type of vocabulary for

the Czech language. The –f option enables the user to

specify the desired dictionary file. By default, Majka

is case-sensitive to names and titles; therefore, one

needs to add the option –i in order to correctly

analyse words in lowercase.

2.2 Attributes of Search Analysis

Majka’s output for a particular word is a list of

relevant basic word forms found in the vocabulary

with corresponding grammatical tags, where each

word and its tag is divided by a colon.

For example, analysis of the word ‘robot’ returns

the following output:

robot:k1gInSc1

robot:k1gInSc4

robot:k1gMnSc1

robota:k1gFnPc2

First Step Towards Enhancement of Searching Within Medical Curriculum in Czech Language using Morphological Analysis

289

Czech is a fusional language, which among others

means that each tag consists of several pairs of strings

which represent morphological features such as the

part of speech (pars orationis), gender (genus

grammaticum), number (numerus grammaticus),

paradigm (paradigma), case (casus garmmaticus) or

tense (tempus grammaticum). Some of these

properties are not available to all words, so tags might

be of different lengths. The first character of a pair

identifies the property, whereas the second character

is its value. In the first line of the example with word

“robot”, the grammatical tag k1gInSc1 is returned.

Meanings of each part of the tag are as follows:

 k1 – Character ‘k’ represents the part of

speech. In this case, ‘1’ stands for noun. In

the Czech language, we recognize 10

different parts of speech, see Table 1.

 gI – Character ‘g’ stands for the gender,

while ‘I’ specifies the masculine.

 nS – Character ‘n’ represents the number,

while ‘S’ stands for singular.

 c1 – Character ‘c’ stands for the case of a

particular word. In this case, ‘1’ specifies the

first paradigm. In the Czech language, we

recognize 7 different cases.

In summary, the first morphological result tells us

that one of the basic forms of the word “robot” is

indeed the word “robot” itself, which is a noun with a

masculine gender, in singular form, and in

nominative.

2.3 Integration to the Search Engine

The strong point of a fully integrated Majka is that all

functions can be called on demand. Thanks to its

application programming interface (API), functions

can be called and their returned outputs can be

processed by an existing PHP application, the

OPTIMED CurrMS. This application is based on the

Symfony framework (SensioLabs) and has been

designed for the development of web-based

applications and systems; the whole application is

used for curriculum development and management.

Our long-term goal is to refine the existing full-

text search engine by a morphological analysis, with

the aim of obtaining more relevant results to queries

of users. We have created two pieces of code

especially for the purposes of work with Majka.

The first piece of code is the CallMajka service: it

takes any string as the input and, for each word,

returns the most relevant basic form and a

corresponding tag based on a specific decision

algorithm. This service is created only as part of the

application responsible for the entire preparation of

data for Majka and also for all post-processing of data

that are produced by Majka.

The second piece of code is the

CallMajkaCommand, which is a PHP command that

calls Majka on a single input word. The command is

designed to be the only entry point of Majka’s output

to the application. All actions which somehow

communicate with the Majka’s interface must use a

functionality implemented within this command.

3 RESULTS

We were able to integrate and start using Majka

easily, thanks to the well-prepared application

programming interface, a robust documentation and

an on-demand created vocabulary. The vocabulary

was created from the whole content of the OPTIMED

platform. Therefore, we were sure that the vocabulary

used for our further analysis contained the most

relevant words depending on the current content.

During our initial phase of Majka integration into

the web-based application, we created several

analysis outputs. Their main purpose was to show the

power of morphological analyser for our needs. We

examined the distribution of occurring word types

(parts of speech) on the input, counts of most frequent

words and the analyser’s ability to reduce the number

of unique words of the corpus.

3.1 Dataset Transformation

The process of data transformation uses the

CallMajka service, which removes specific

punctuation marks (~`!@#$%^&*()_={}[]:;'<>,.?/)

using regular expression (regex), puts text to

lowercase and then splits it to separate words.

Afterwards, the CallMajka service calls Majka on

each word by the command line. Finally, one basic

word form with a corresponding tag for each input

word is selected algorithmically. For the purpose of

enhancing the medical query search, we agreed that

substantives, adjectives and verbs in singular form

and in nominative are most informative. Therefore,

based on these conditions, this algorithm decides

which basic form is the most relevant one. If the

vocabulary does not recognise the input word, the

algorithm labels the word as unclassified. The input

dataset that we used for the analysis contained more

than 860,000 words.

Using the CallMajka service, we acquired an

output dataset of a similar length but containing

transformed words. A mapping dictionary that

CSEDU 2018 - 10th International Conference on Computer Supported Education

290

consisted of each unique word, an algorithmically

selected basic word form, corresponding tag and its

frequency in dataset was the side product of this

transformation.

For example, the sentence “radioterapie tvoří

významnou součást léčby nádorových onemocnění”

on the input is transformed to an output which has the

following form: “radioterapie tvořit významný

součást léčba nádorový onemocnění”. All words

from the input are also present in the output (in same

places as in the original sentence) but they have

different word forms, which suits us more.

3.2 Output Structure

Using the dictionary output of dataset transformation,

we analysed the distribution of parts of speech using

the Majka tags. The division to presented categories

is created by Majka by default (Jakubícek, Kovár and

Šmerk 2011). Corresponding results are shown in

Table 1.

Table 1: Distribution of word types in output dataset.

Part of speech Dictionary

occurrence

(

)

Dataset

occurrence

(

)

Unclassifie

0.48013 0.15948

Interjections 0.00049 0.00113

Nouns 0.25877 0.42941

ectives 0.20702 0.19262

Pronouns 0.00227 0.01647

Numerals 0.00107 0.00176

Verbs 0.03725 0.05091

Adverbs 0.00979 0.01573

Pre

ositions 0.00026 0.01702

Con

unctions 0.00042 0.00518

Particles 0.00023 0.00140

Othe

0.00232 0.10889

It was obvious that the “unclassified” category

occupied a relatively large part of the distribution.

This result meant that the used vocabulary failed to

identify (i.e. did not contain) many of the input words.

However, by identifying these words and with the

help of Majka’s authors, we were able to add them to

the vocabulary iteratively. As we have already

mentioned earlier, we were mainly interested in

substantives, adjectives and verbs because they carry

the most information. Due to the identification of

these words and their further usage, we were able to

enhance the search engine. Furthermore, we were

able to reduce the density of unique words in output

by almost 28% in comparison to input dataset.

3.3 Most Frequent Words

In order to classify the most frequent words that are

relevant for our purposes, both input and output

datasets were cropped to subsets of words that were

at least three characters long. This action mainly

involved removing interjections, prepositions,

conjunctions and particles, i.e words that were not

informative enough. Afterwards, 30 most frequently

occurring words and corresponding total frequencies

were selected from both datasets. Results are shown

in Tables 2 and 3 below.

Table 2: Top 30 words and their frequencies from the input

dataset.

Czech word English

translation

Frequency

vyšetření examination 3,264

ři at 3,003

onemocnění illness 2,652

ndro

ndrome 2,550

ro fo

2,463

jsou are 2,205

základní

asic 2,166

oruch

disorders 2,064

nebo o

1,992

ich thei

1,935

cvičení exercise 1,631

nádory tumours 1,619

zkouška exa

1,506

forma form 1,499

léčba treatment 1,438

tera

ie thera

1,408

infekce infection 1,372

lékařství medicine 1,316

závěrečná final 1,303

ako as 1,294

nemoci diseases 1,285

oranění injury 1,169

řednáška lecture 1,146

opsat describe 1,109

dia

nostika dia

nosis 1,103

uňk

cells 1,082

říznak

toms 1,058

metody methods 1,043

systému syste

1,016

význa

importance 1,011

Table 3: Top 30 words and their frequencies from the output

dataset.

Czech word English

translation

Frequency

ýt

e 11,320

syndro

syndrome 3,384

vyšetření examination 3,383

orucha disorde

3,013

First Step Towards Enhancement of Searching Within Medical Curriculum in Czech Language using Morphological Analysis

291

Table 4: Top 30 words and their frequencies from the output

dataset (cont.).

ře to argue 3,010

léčba treatment 2,957

onemocnění illness 2,940

základní

asic 2,862

nádo

tumou

2,702

klinick

clinical 2,686

nemoc disease 2,672

ro fo

2,463

systé

syste

2,337

uňka cell 2,140

rotein

rotein 2,100

forma form 2,002

nebo o

1,992

acient

atient 1,980

student student 1,967

kter

which 1,965

ich thei

1,935

fakto

facto

1,900

opsat describe 1,879

infekce infection 1,858

tera

ie thera

1,727

rece

1,721

cvičení exercise 1,715

diagnostika diagnostics 1,714

znát know 1,604

ednotliv

individual 1,583

4 DISCUSSION

We consider our work to be very promising because

we were able to answer all stated research questions,

to achieve meaningful results and to complete

successfully the first step towards the integration of

morphological analyser into the search engine of the

OPTIMED curriculum management system. During

this phase, we closely cooperated with authors of the

Majka morphological analyser and we have extended

the analyser’s vocabulary by medical terms from the

OPTIMED database. Moreover, we have started to

analyse the OPTIMED curriculum corpus (input

dataset). The input dataset was transformed using the

Majka analyser and analysed with a corresponding

mapping dictionary.

Our subsequent analysis of word types (parts of

speech) showed that we reduced the density of unique

words in the output by almost 28%. Results of the

frequency analysis proved that the majority of basic

forms of transformed words come from the medical

background. This means that the transformation

process and the selected algorithm can indeed map

the curriculum terminology according to our

expectations.

Therefore, we plan to implement Majka fully as a

useful and effective tool for the OPTIMED search

engine improvement. Our concept is as follows:

nowadays, our users can search the OPTIMED

content by entering a particular search query; as a

result, they get a list of learning units containing the

entered keyword or phrase. The implementation of

Majka will reduce the searched content and increase

the accuracy of returned results at the same time. In

order to provide a fast OPTIMED search engine,

curriculum data will be pre-computed; but in the

access time, only the entered query will be computed.

During our future work will be defined concrete

process of search data preparation and results

retrieval using the morphological analysis as one of

enhancements.

ACKNOWLEDGEMENTS

The authors were supported from the following grant

projects: (i) MEDCIN – Medical Curriculum

Innovations – Reg. No. 2015-1-CZ01-KA203-

013935; this project has been funded from the

European Commission ERASMUS+ programme;

(ii) OPTIMED – implementation of new features for

effective searching – Reg. No. MUNI/FR/1568/2016;

this project has been funded from the specific

research and rector’s programme of the Masaryk

University.

REFERENCES

Brauer, D.G. and Ferguson, K.J. 2015. The integrated

curriculum in medical education: AMEE Guide No. 96.

Medical teacher, 37(4), pp.312–322.

Dent, J., Harden, R.M. and Hunt, D. 2017. A practical guide

for medical teachers. Elsevier Health Sciences.

Jakubícek, M., Kovár, V. and Šmerk, P. 2011. Czech

morphological tagset revisited. Proceedings of Recent

Advances in Slavonic Natural Language Processing,

20, pp.29–42.

Komenda, M., Schwarz, D., Vaitsis, C., Zary, N., Štěrba, J.

and Dušek, L. 2015. OPTIMED Platform: Curriculum

Harmonisation System for Medical and Healthcare

Education. Studies in Health Technology and

Informatics, 210, pp.511–515.

Komenda, M., Víta, M., Vaitsis, C., Schwarz, D., Pokorná,

A., Zary, N. and Dušek, L. 2015. Curriculum Mapping

with Academic Analytics in Medical and Healthcare

Education. PloS one, 10(12).

Sedláček, R. Ajka - morphological analyser of Czech.

Available from: https://nlp.fi.muni.cz/projekty/ajka

/index.html [Accessed November 5, 2017].

CSEDU 2018 - 10th International Conference on Computer Supported Education

292

SensioLabs Symfony, High Performance PHP Framework

for Web Development. Available from:

http://symfony.com/ [Accessed November 13, 2017].

Šmerk, P. 2007. Free natural language morphology for

Czech, Slovak, Polish, Swedish, German, French,

Italian, English, Portuguese, Catalan, Welsh, Spanish,

Galician, Asturian and Russian. Available from:

https://nlp.fi.muni.cz/czech-morphology-analyser/

[Accessed November 14, 2017].

Šmerk, P. and Rychlý, P. 2009. Majka – rychlý

morfologický analyzátor. Masaryk University.

Available from: https://www.muni.cz/en/research/

publications/935762 [Accessed November 5, 2017].

First Step Towards Enhancement of Searching Within Medical Curriculum in Czech Language using Morphological Analysis

293
