Turning the Tables: Authoring as an Asset Rather than a Burden

Toby Dragon

Department of Computer Science, Ithaca College, 953 Danby Rd, Ithaca, NY, U.S.A.

Keywords: Authoring Tool, Concept Map, Domain Model, Intelligent Tutoring System, Factor Analysis.

Abstract: We argue that authoring of Intelligent Tutoring Systems can be beneficial for instructors that choose to author

content, rather than a time-consuming burden as it is often seen. In order to make this a reality, the authoring

process must be easy to understand, must provide immediate benefit to the instructor doing the authoring, and

must allow for incremental development and improvement. We describe a methodology that meets all of these

needs using concept maps as a basis for authoring. The methodology creates a basis for intelligent support

that helps authors improve their course organization and content as they work on the authoring task. We also

present details of the rapid prototype being developed to apply the methodology and the initial experiences

from its use.

1 INTRODUCTION

Intelligent Tutoring Systems (ITS) have been

demonstrated to be effective, but often these systems

are limited to a specific domain and set of content.

This is due to the nature of ITS, in that most systems

necessitate some type of domain model, a formal

structure that the intelligent system can navigate to

connect specific assessment data to some greater

understanding of the domain. Customizing these

domain models to cater to different domains or to

different content can be costly and unwieldy. This

problem has been considered a major limitation of

ITS research, creating concern that although ITS

systems are effective, these systems might not scale

well. Historically, this concern has been addressed by

authoring tools that allow researchers and instructors

to create and/or modify the domain model in an

intuitive fashion, generally without programming.

Even these tools can be expensive in terms of

instructor time, although creators of authoring tools

offer innovative measures to combat this problem

(e.g., Aleven et al., 2006). Many instructors do not

have the time or do not feel the need to understand the

purpose and internal structure of domain models, and

therefore authoring tools can seem impractical.

In this narrow view, we may be considering the

wrong client and the wrong customer for our ITS

authoring process. In contrast to the over-burdened

instructor who is disinterested in this process, many

instructors are not only willing to have a hand in the

authoring of their course content, they insist upon it.

The entire field of Instructional Design (ID) is

grounded in this process of creating and honing

course content. Instructional designers work with

instructors to continually refine their class materials,

organization, and content. They seek out opportunity

to do this work. Earlier work in relating ID and ITS

development discussed the mutual benefits and

promise of integrating these activities (Capell and

Dannenberg, 1993), but our literature review reveals

little beyond these initial attempts. We also see the

topic increasing in relevance, as the motivation to

define one's own materials and organize custom

courses is growing in potential and popularity due to

the ever expanding set of mix-and-match materials

available. The Open Educational Resources (OER)

movement (Atkins, Brown, & Hammond, 2007)

exemplifies the wealth of materials available from

which instructors can pick and choose.

We argue that this type of instructor would want

to author content using an authoring tool, if that

authoring tool helps improve their course content in

addition to providing a domain model for an ITS. In

a foundational review of ITS authoring tools, Murray

recognized that one of the main challenges of

authoring tool use is the amount of scaffolding the

authoring tool can provide during the model creation

process (Murray, 2003). We argue that providing

intelligent support during the authoring process can

offer exactly that type of scaffolding, helping

instructors make their course organization and

308

Dragon, T.

Turning the Tables: Authoring as an Asset Rather than a Burden.

DOI: 10.5220/0006761503080315

In Proceedings of the 10th International Conference on Computer Supported Education (CSEDU 2018), pages 308-315

ISBN: 978-989-758-291-2

content better while simultaneously creating a

domain model for an ITS. Specifically, the authoring

tool can help instructors formalize their process, give

a concrete structure that can be shared, assessed and

iterated upon, and give feedback about the content of

the produced domain model. This feedback can

highlight potential issues with course content and

areas ripe for improvement. Additionally, the process

would produce an artifact (the domain model) utilized

by an ITS to support both instructors and students

while running the course.

We present a generic type of domain model that

can be used across many domains and a methodology

that can be used to create an authoring process

including feedback for the author. This methodology

provides instructors a flexible, easy-to-understand

process which can help them aggregate and organize

their course content. This same system can then

provide a basis for meaningful ITS feedback to

inform and support teachers and students. We have a

rapid prototype of this methodology and have begun

to employ it in the domain of computer science

education. We will refer to this prototype and its use

to demonstrate the power of this authoring approach.

2 RELATED WORK

This work combines ideas from a wide variety of

specific fields including: ITS authoring tools,

instructional design, concept mapping, factor

analysis, knowledge factor analysis, and ITS systems

that operate with similar types of domain models. We

then pull these ideas together into a coherent vision of

an authoring methodology. Due to the wide variety of

disparate related work, we generally reference related

work in the relevant section, rather than grouping it

into a unified section.

In terms of directly related work to the larger ideas

presented in this paper, we should highlight three

particular works. Kumar presents an argument for

using the same type of domain model we present,

along with arguments about the relevance of this

domain model and benefits for the students using the

ITS (Kumar, 2006). Cen, Koedinger, and Junker

present a similar technique to giving authors feedback

through factor analysis (Cen, Koedinger, and Junker,

2006). We see these works as complimentary, since

we are synthesizing ideas from both, and because

their focus is on the student benefit of a better domain

model (which we assume for this paper), while we

focus on the potential advantage for the instructor as

well. Mitrovic et al. present an authoring tool that

uses a similar approach (Mitrovic et al. 2009) and

their team demonstrates some positive outcomes for

authors (Suraweera, 2004).

3 THE AUTHORING PROCESS

We have several goals to consider when developing

the generic approach to domain models and to the

authoring process itself. First and foremost,

instructors interested in designing their own course

content do not want to be constrained by the authoring

tool. The process and model should be simple and

intuitive enough to be easily understood by

instructors. It should also be flexible, and allow for

iterative improvement and added refinement/

complexity. For these reasons, the domain model

must be easily editable and offer a wide variance in

complexity (i.e., domain models should be useful and

understandable when simple or complex). We want

instructors to create content "their way," and in their

own time. We want them to experiment with models

and refine them based on experience.

3.1 Concept Map as the Domain Model

To offer this type of intuitive domain model, we rely

on concept mapping (Plotnick, 1997). Concept maps

are composed of nodes and edges; nodes representing

concepts and edges representing relationships

between those concepts. The task given to instructors

is to identify key concepts to be taught and their

interrelations. Each of these maps could provide great

detail, or remain fairly high-level. Figures 1 and 2

show two example concept maps for a course at

different levels of detail. These maps have been

developed using our authoring process,

demonstrating the variety of maps that could be used

productively.

Figure 1: A high-level concept map for an introductory

computer science course. This type of map can be produced

quickly, and can still be useful to an ITS.

Turning the Tables: Authoring as an Asset Rather than a Burden

309

Figure 2: A detailed concept map for the same introductory computer science course. This map was produced through

successive revisions beyond the one presented in Figure 1. Revising and adding detail helped the instructor reconsider course

content, and the resulting map is more useful as a domain model for an ITS.

Concept mapping has been applied in many

domains as an instructional or assessment tool,

particularly natural science domains (Novak, 1990).

This process has been shown to be useful as a means

of instructional design, which is similar to the

approach we recommend (Starr & Krajcik, 1990).

These types of concept maps have been used as

domain models for ITS and the benefits noted

(Kumar, 2006).

Development of these concept maps could be

considered burdensome, particularly if the benefit

were perceived to be only for the ITS and not for the

creator of the concept map. We need an authoring

process that is immediately rewarding. We describe

our proposed process, and detail how the instructor

benefits. These benefits include intelligent feedback

we can give authors to promote their reflection on,

and improvement of, their course organization and

content.

3.2 The Authoring Process

We believe that creating these concept maps can be

an intuitive, productive authoring process especially

if supported by an intelligent system. We now walk

through the steps to apply our methodology and

prototype in order to demonstrate that such a process

could be implemented with current technology.

There are four main steps to this process, each one

important from an instructional design perspective.

3.2.1 Identifying Concepts

First, the author must collect a set of concepts to be

included in the map. We suggest many sources of this

type of information that should be considered,

including: course syllabi, explicit student learning

objectives, table of contents of related textbooks, etc.

At least some of these sources should be available to

any instructor, and so defining the set of included

concepts should be a process to help the instructor

decide: from all the possibilities, what are the most

important concepts to be the focus of this course?

3.2.2 Relating Concepts

The next task is to relate these concepts to one

another. In the concept mapping process, relations

can be named freely as one develops their map. Since

this creates complexity for the author and challenge

of interpretation for the ITS using the domain model,

we currently consider only one type of relationship in

our concept maps. An edge pointing from one concept

to another indicates that one concept "is a part of" the

other concept. This relationship is purposely loose,

and can be considered for aggregation (e.g., Figure 2

shows that all specific data types such as integers and

floats "are a part of" understanding data types) or a

prerequisite structure (e.g., Figure 2 shows that you

need to understand Boolean expressions to

understand if statements). This simplification is for

prototyping, and the idea of introducing different

CSEDU 2018 - 10th International Conference on Computer Supported Education

310

types of relationships and the resulting helpfulness to

instructors and to the ITS are areas for future

research.

For our prototype, we ask instructors to draw

these graphs on whiteboard, paper, or with an online

diagramming tool (e.g., draw.io

). Our research team

takes these drawings and converts them into a JSON

format representing nodes and links. While we do not

currently have an automated process for this, the

existence of such online drawing tools and the fact

that other ITS have offered the ability to draw such

diagrams, e.g., the LASAD system (Loll & Pinkwart,

2013) demonstrates the feasibility of automating this

process.

3.2.3 Identifying Resources

Once a tentative concept map has been established,

the next task is to identify the resources involved.

Resources represent the actual content with which

students interact. We refer to three different types of

resources: instruction, practice, and assessment. Any

given resource can be one, two, or all three of these

types. For example, a textbook or YouTube video

might be purely instruction. A homework assignment

graded and returned to students might be practice and

assessment. An online textbook with interactive

exercises might be all three. An exam not handed

back to students might be solely assessment.

Generally, an already-established course has a set

of resources defined. For our prototype, we represent

these resources with only labels, URLs, and id strings.

There are many sources from which to gather this

information. For instruction and practice, instructors

can consider their own presentations from class, the

textbook if one is used, online resources, etc. For

assessment, the spreadsheet used for grading the

course has the id information of all assessment as the

labels for columns. For this reason, our prototype can

accept grading spreadsheets to collect assessment

information. Currently the system accepts

spreadsheet output from both Sakai

and ZyBooks

Future implementations could accept any variety of

output from Learning Management Systems (LMS).

Another promising source for specific assessment

information is concept inventories, which fit well

within our system because they aim to assess specific

concepts within a domain. These concept inventories

are used often in natural sciences (Libarkin, 2008) but

are also being applied to other domains (e.g.,

Almstrum et al., 2006).

3.2.4 Relating Resources

With a tentative concept map and set of resources

established, the task is now to relate the resources to

the concepts. This is the most crucial and productive

part of the process, as the instructor needs to consider

specifically how each resource is related to a set of

concepts to be taught, and similarly, how each

concept should be explicated through a specific set of

resources. This part of the process generally causes

deep reflection for the instructor, and will

undoubtedly cause reconsideration of the structure of

the map and the included resources. It can also be the

most overwhelming part of the process, as the number

of permutations of resources to concepts is not

reasonable for a human to consider all at once. We

now discuss methods for offering intelligent feedback

during the authoring process, with particular attention

to this phase of relating resources to concepts that is

most challenging, but also most rewarding for

authors.

4 FEEDBACK FOR AUTHOR

REFLECTION

While the authoring process alone can help

instructors consider their course organization and

content, intelligent support for this process helps

them see immediate benefit. This type of support

comes in two forms which represent two aspects of

artificial intelligence: theory-driven approaches and

data-driven approaches. Considering theory-driven

approaches, there are certain rules or constraints

about the structure of the concept map indicate the

potential need for reflection or improvement. Data-

driven approaches allow us to use assessment

information from students to validate, question, or

explore the map created by instructors, again

highlighting areas for reflection.

4.1 Structural Feedback

The first and most obvious form of feedback on the

concept mapping task is recognition of missing

resources, or missing connections to resources.

Specifically, the system can check for concepts that

have no assessment or no related materials and alert

the instructor. Similarly, there may be assessments or

materials that are used in the course but not related to

the concept map. These may sound like obvious

mistakes, but they are very possible to make due to

the number of concepts and resources that might be

included. Additionally, the reality of the issues

Turning the Tables: Authoring as an Asset Rather than a Burden

311

identified and their solutions is much more subtle

than might be expected. Consider some example

scenarios that have occurred when working with our

prototype.

An instructor found that a specific exam question

was not connectable to the graph. Upon inspection, it

was recognized that the question was added as a

check on a semi-related topic that was discussed in

class. However, the instructor decided that this topic

was not important enough to warrant a node in the

map. The instructor now had a few possibilities, each

representing a different instructional design choice.

They could remove the question, and even possibly

the material from class, if it is truly not important.

They could make it a part of the map, and possibly

relate other resources, if it is deemed important

enough. In this specific case, the instructor found

upon reflection that this small topic could be

presented as an example of a greater concept from the

course. This caused the instructor to change the

concept map and the resource links. The instructor

also slightly changed the way the topic was presented

to the class, and the ordering of topics presented. This

demonstrates how the automated feedback on this

authoring process yielded tangible results on the

course organization. However, we should note that no

action at all was required. The instructor could have

decided to leave the exam question, change nothing

else, and the assessment merely wouldn't be related to

anything in the concept map.

Another productive example that occurred in use

of our prototype was the recognition of large, general

assessment without any narrow, specific assessment.

This was recognized by the system as a set of low-

level concepts that had no related assessment. Upon

inspection, the instructor realized that there was a

wealth of assessment of the high-level topics that rely

on these low level topics. Again the instructor could

have left this situation alone if they thought it

sufficient, but bringing attention to the content in this

way caused reflection. If there is no assessment of

these individual, low-level skills, how could the

students themselves know whether they had the

appropriate building blocks for the high-level

concept? When the assessment of high-level concept

showed problems, what specifically should the

student study? This prompted the instructor to add

some short homework assignments that allowed

students to address the low-level concepts directly

before addressing the high-level concept for which

they were necessary.

In these scenarios, we see subtle issues that are

easily recognized by an intelligent system during the

authoring process and result in productive reflection

and course improvement.

4.2 Data-Driven Feedback

Moving beyond the structural feedback, a system can

also utilize student assessment data to either validate

the domain model or recognize areas for potential

improvement. We approach this problem using factor

analysis (Thompson, 2004). Factor analysis considers

a set of observed variables in an attempt to identify a

potentially lower number of unobserved variables

called factors. In our case, we consider the grades on

assessment resources to be our observed variables,

and the unobserved factors to be representative of our

concepts, the underlying smaller set of variables that

dictate assessment performance. Other ITS

researchers have applied factor analysis to learning

models (Gong et al., 2001; Cen et al., 2006). Cen et

al. take a similar approach to ours, applying factor

analysis for reflection on the domain model, but they

focus on working with domain experts to produce

widely-applicable, static domain models. They

highlight the model improvement for the ITS, rather

than also considering the direct benefit for instructors

and their courses as they instructors develop the

models themselves.

We want to deliver this factor analysis to

instructors, allowing them to analyze their own

concept maps to stimulate their reflection and help

them improve their map, thereby improving their

content and the resulting domain model. Our

prototype system uses the R programming language

with the Structural Equation Modeling package

perform these analyses. Two kinds of factor analysis

offer different potential uses. Confirmatory analysis

can help instructors validate their concept maps or

question certain aspects of them. Exploratory analysis

offers an overview of the relationship between

resources, allowing a semi-automated manner of

creating a map and allowing instructors to reconsider

their map as a whole.

4.2.1 Confirmatory Factor Analysis

Confirmatory analysis is performed after the concept

map has been authored and data is available for the

assessment resources. It is important to note that the

data need not be collected after the concept map has

been established. As long as the instructor has data

from the specific assessment used (e.g., exam

questions, homework, etc.), they can apply analysis to

any configuration of concept map.

CSEDU 2018 - 10th International Conference on Computer Supported Education

312

Confirmatory factor analysis will take the map

and the data set as input, and return a set of weights

for each edge in the concept graph. The instructor can

then consider those edges to decide if the data is

supportive of their concept map. Low weights on

edges indicate that the data does not show a strong

correlation between concept and resource, even if the

instructor considers there to be one.

This analysis can lead to interesting reflection and

course improvement for instructors. For example, an

instructor might link an assignment to three concepts

from the concept map, but after running confirmatory

factor analysis, discover that the weight on one edge

is very small comparatively. Upon consideration, the

instructor sees that, while the assignment does

technically relate to the third concept, the task related

to that concept is so simple that no one has answered

that portion of the assessment incorrectly due to this

concept. This causes the instructor to remove that

connection from the map. However, upon doing so,

the instructor recognizes that the concept now has no

assessment. This means that the concept basically

never had solid assessment, and therefore the

instructor re-thinks the assignment to ensure proper

assessment of the concept.

4.2.2 Exploratory Factor Analysis

Exploratory analysis offers a more general type of

information to help the instructor reflect. This

analysis takes only the assessment data as input, and

produces the best-fit set of factors and their relations

to the assessment resources. In other words,

exploratory analysis creates its own concept graph,

one layer deep, showing the underlying factors

calculated from the resources.

This information is particularly useful to an

instructor that has not yet formed a concept map.

These emergent nodes are indications from the data

of distinct high-level concepts that independently

dictate performance on individual tasks. The

instructor can review the grouped assessments to

reverse engineer and label the specific factors

identified. Similarly, instructors that have concept

maps already created can consider these

automatically-generated maps to identify the

relationship between that and their own creation. This

can potentially motivate a major reorganization of the

concept map to better fit the reality of the assessment

used.

This functionality has only recently been added to

the prototype, and so reflection on its usefulness is

still forthcoming. Initial attempts intrigued instructors

and motivated the team to consider methods for

automatically, temporarily simplifying the concept

map to make the factor analysis results more useful.

4.2.3 Simplifying for Data-Driven Analysis

From our experience applying these techniques to real

data sets, we have found that meaningful results on

large, complex graphs such as the one presented in

Figure 1 are less likely because our theoretical model

is so fine-grained. Instructors are unlikely to have

enough assessment items at any given low-level

concept or enough data collected to find the statistical

validation.

We can still check for meaningful results within

the context of these maps by considering larger

portions of the concept map. In this way, we simplify

the model to check if it can be validated or improved

on a more course-grain level. We engage in this

process programmatically rather than manually. The

system can iteratively remove the lowest nodes in the

concept graph, and relate the resources from these

lower concepts directly to the higher-level concepts.

We can engage in this iterative simplification for as

many or as few steps as we deem productive. For

example, Figure 3 shows the concept map from

Figure 2 with three iterations of simplification.

Figure 3: The concept map from Figure 2, with three

successive iterations of simplification.

One can see that while not the same, this

automatically generated map is quite similar to the

early version of a simple map created by the author

(Figure 1). With only 15 nodes instead of 32, the data-

driven approaches have a much higher chance of

finding statistical significance to recognize hidden

factors appropriately. We are currently experimenting

with methods of simplifying the graph one step at a

time and calculating the confirmatory analysis at each

stage, potentially automatically recognizing a level of

simplification that might be most interesting for

authors to consider.

Turning the Tables: Authoring as an Asset Rather than a Burden

313

5 USING THE DOMAIN MODEL

The focus of this paper is the methods of ensuring

value for the instructors while they author within our

system. This will ensure that domain models are

authored often and with enthusiasm. We have

demonstrated the manner which authoring itself can

benefit an instructor interested in improving their

course, both in process and through intelligent

support. However, we must also note the obvious

additional benefit: a domain model that can be shared

with students and instructors, and also used by an ITS

to provide assessment and feedback for the instructor

and for students.

First, this domain model itself is a useful artifact

for explicating the instructor's vision of a course. In

our experimentation, we have observed instructors

using the maps to communicate with other instructors

when co-teaching courses. We also note that

instructors have used the maps in class to motivate the

learning of low-level concepts that enable the

learning of high-level concepts. The visualization

offers a direct means of communicating the

importance of the concepts and their interrelation.

Of course, the initial reason to create a domain

model is to perform intelligent analysis and feedback.

While the inner-workings of an entire ITS that could

use this domain model are outside the scope of this

paper, there are many systems to consider that have

proven effective using similar types of domain

models (e.g., Dragon et al., 2006; Kumar, 2006;

Sosnovsky & Brusilovsky, 2015). We now highlight

the potential types of assessment and feedback that

are clearly enabled through such a domain model, and

are available through our system (anonymized

citation).

We can calculate estimated knowledge of each

concept by using the concept map structure and its

relation to assessment scores. This is accomplished

by aggregating scores from the related assessments to

the concepts, and recursively moving up through the

map in a post-order traversal. The result is knowledge

estimates at a conceptual level, rather than an

assignment level. This has been demonstrated to be

successful in other tutoring systems (Kumar, 2006).

We present these results directly to students and

instructors using a color-coded visualization of the

map to present this information as an Open Learner

Model (OLM), which has been demonstrated to be

effective (Bull & Kay, 2010).

Using these estimates, the system can also use the

encoded information about the instruction and

practice resources in order to offer suggestions about

where students can learn about certain concepts, and

where they can find appropriate practice problems.

The last type of intelligent support we offer based

on this domain model is group suggestion for

temporary in-class collaboration efforts. Using the

knowledge estimates for different students, teams can

be identified that need to focus on specific concepts,

or that might be helpful to one another (anonymized

citation).

6 CONCLUSIONS

We argue that the authoring process can be

productive and rewarding, rather than burdensome.

However, we need to identify the right people to do

the job (those that want to engage in ID) and give

them tools that empower them to improve their

courses while simultaneously producing a useful

artifact for ITS. Our proposed solution is a concept

mapping process to produce a domain model. This

process relies upon feedback from the structure and

factor analysis in order to produce tangible benefits

for instructors as well as better domain models. If

instructors recognize improvement in their class

organization and content when engaging in authoring,

they are more likely to spend the time necessary to

complete the task well.

The described process is also supportive of

authors in that it can be completed gradually and

iteratively, and it is useful in many contexts even

when not complete (in fact, one could argue that the

given authoring task is never complete, any more than

a course design is complete). Authors working with

our prototypes have created concept maps, but not

connected any resources (electing to connect the

resources during the semester as the resources are

used). These instructors could still use the maps as

means of communication with other instructors and

students. Other instructors chose to implement only

portions of their course in the map, selecting the most

complex portions that lead to the most confusion and

are most in need of reflection in terms of course

design. The system is then applicable and fully

functional for this portion of the course, and the

concept map can grow to include other portions of the

course in time.

Finally, we envision this process being used on a

grand scale within a department as well. The same

techniques discussed at a course level could be

applied at the curriculum level, and the related

resources and resulting knowledge estimates could

give in-depth assessment information to program

directors about the successes and challenges for a

CSEDU 2018 - 10th International Conference on Computer Supported Education

314

given program. While we have not yet implemented

this within our current work, others have used concept

maps as a means of curriculum evaluation

(Edmondson, 1995) and we see our work as an

extension and potential drastic improvement of those

efforts.

Overall, If we can make the authoring process a

reasonable investment with a clear benefit,

instructional designers will then see the value of

authoring beyond the ITS it customizes. This can in

turn create an environment where wealth of reliable,

validated domain models across different domains are

available for use in ITS. With the low barrier to entry,

obvious direct benefits, and unlimited ability to

refine, we argue that our methodology has the

potential to change the future landscape of ITS,

creating an abundance of ever-improving domain

models.

REFERENCES

Aleven, V., Sewall, J., McLaren, B. M., & Koedinger, K.

R. (2006, July). Rapid authoring of intelligent tutors for

real-world and experimental use. In Advanced Learning

Technologies, 2006. Sixth International Conference on

(pp. 847-851). IEEE.

Almstrum, V. L., Henderson, P. B., Harvey, V., Heeren, C.,

Marion, W., Riedesel, C., & Tew, A. E. 2006, June.

Concept inventories in computer science for the topic

discrete mathematics. In ITiCSE-WGR '06. ACM, New

York, NY, USA, 132-145. DOI:

10.1145/1189215.1189182.

Atkins, D. E., Brown, J. S., & Hammond, A. L. (2007). A

review of the open educational resources (OER)

movement: Achievements, challenges, and new

opportunities (pp. 1-84). Creative common.

Bull, Susan, and Judy Kay. 2010. "Open learner models."

Advances in intelligent tutoring systems: 301-322.

Cen, H., Koedinger, K., & Junker, B. (2006, June).

Learning factors analysis–a general method for

cognitive model evaluation and improvement. In

International Conference on Intelligent Tutoring

Systems (pp. 164-175). Springer, Berlin, Heidelberg.

Capell, P., & Dannenberg, R. B. (1993). Instructional

design and intelligent tutoring: Theory and the

precision of design. IJAIED, 4(1), 95-121.

Dragon, T., Woolf, B., Marshall, D., & Murray, T. (2006).

Coaching within a domain independent inquiry

https://www.draw.io/

https://www.sakaiproject.org/

http://www.zybooks.com/

https://cran.r-project.org/web/packages/sem/index.html.

environment. In Intelligent Tutoring Systems (pp. 144-

153). Springer Berlin/Heidelberg.

Edmondson, K. M. 1995. Concept mapping for the

development of medical curricula. Journal of Research

in Science Teaching, 32(7), 777-793.

Gong, Y., Beck, J. E., & Heffernan, N. T. (2011). How to

construct more accurate student models: Comparing

and optimizing knowledge tracing and performance

factor analysis. International Journal of Artificial

Intelligence in Education, 21(1-2), 27-46.

Kumar, A. N. (2006). Using Enhanced Concept Map for

Student Modeling in Programming Tutors. In FLAIRS

Conference (pp. 527-532).

Libarkin, J. (2008, October). Concept inventories in higher

education science. In National Research Council

Promising Practices in Undergraduate STEM

Education Workshop 2.

Loll, F., & Pinkwart, N. (2013). LASAD: Flexible

representations for computer-based collaborative

argumentation. International Journal of Human-

Computer Studies, 71(1), 91-109.

Mitrovic, A. et al. (2009). ASPIRE: An Authoring System

and Deployment Environment for Constraint-Based

Tutors. IJAIED, 19(2), 155-188.

Murray, T. (2003). An Overview of Intelligent Tutoring

System Authoring Tools: Updated analysis of the state

of the art. In Authoring tools for advanced technology

learning environments (pp. 491-544). Springer

Netherlands.

Novak, J. D. 1990. Concept mapping: A useful tool for

science education. Journal of research in science

teaching, 27(10), 937-949.

Plotnick, E. (1997). Concept Mapping: A Graphical System

for Understanding the Relationship between Concepts.

ERIC Digest.

Sosnovsky, S., & Brusilovsky, P. 2015. Evaluation of topic-

based adaptation and student modeling in QuizGuide.

User Modeling and User-Adapted Interaction, 25(4),

371-424.

Starr, M. L., & Krajcik, J. S. 1990. Concept maps as a

heuristic for science curriculum development: Toward

improvement in process and product. Journal of

research in science teaching, 27(10), 987-1000.

Suraweera, P., Mitrovic, A., & Martin, B. (2004a). The

Role of Domain Ontology in Knowledge Acquisition

for ITSs. In J. Lester, R. M. Vicari. F. Paraguacu (Eds.)

Intelligent Tutoring Systems 2004 (pp. 207-216).

Berlin: Springer.

Thompson, B. (2004). Exploratory and confirmatory factor

analysis: Understanding concepts and applications.

American Psychological Association.

Turning the Tables: Authoring as an Asset Rather than a Burden

315
