Security Tests for Smart Toys

Luciano Gonc¸alves de Carvalho

1,2

and Marcelo Medeiros Eler

School of Arts, Sciences and Humanities, University of S

ao Paulo, Brazil

FATEC Mogi das Cruzes, S

ao Paulo State Technological College, Brazil

Keywords:

Smart Toys, Toy Computing, Security, Security Tests, Security Analysis.

Abstract:

Smart toys are becoming more and more common in many homes. As smart toys can gather data on the

context of the user’s activities (e.g., voice, walking, photo, etc.) through camera, microphone, GPS and various

sensors and store personalized and conﬁdential information (e.g., location, biography information, activities

pattern, etc.), security measures are required to assure their reliability, specially because they are mainly used

by vulnerable users, children. In fact, several security ﬂaws have been reported on smart toys available in

the market. Security incidents include information leakage, toys used as spies and outsiders interacting with

children via unauthorized connections. Some researchers have investigated smart toys vulnerabilities and risks

when it comes to security issues, many of them have studied how to assure privacy policies compliance, and

one researcher proposed general security requirements for smart toys. However, no work has proposed general

security analysis and tests to assure security requirements have been met. In this context, this paper discusses

security issues, threats and requirements in the context of smart toys and presents general security analysis

and tests for smart toys, all identiﬁed based on the Microsoft Security Development Lifecycle (SDL) process.

We believe this work contributes to this ﬁeld by providing manufacturers, developers and researchers with a

general guideline on how to handle security aspects when designing and developing smart toys.

1 INTRODUCTION

Recently, the toy market has been provided with a

new type of product: smart toys. A smart toy is a com-

bination of three components: a conventional physical

toy, such a stuffed pet or a robot, for instance, equip-

ped with sensors and electronic components to ena-

ble network communication and collect data; a mobile

device that connects with the physical toy to provide

mobile services; and a mobile application to interact

with the physical toy. Such a combination of compo-

nents are intended to provide users with more pleasant

and personalized experiences.

This special association between the physical toy

and a mobile device has been called toy compu-

ting (Rafferty and Hung, 2015). To avoid any misun-

derstanding, in this paper we consider smart toys

those that fall in the ﬁeld of toy computing, which

has an association between a physical toy and a mo-

bile device and application. We don’t refer to toys

that are intended to help children to become smarter

(e.g. puzzles) or toys with electronic parts that reacts

to environment stimuli and even learn patterns based

on user data and interaction (electronic toys).

Smart toys are examples of real-world objects that

can be part of an Internet of Things (IoT) network,

which is a pervasive and ubiquitous network that al-

low the interconnectivity of real-world objects. IoT

networks create a suitable environment to allow the

integration of physical objects into computer-based

systems aiming at improving efﬁciency, accuracy and

reduced human intervention in several domains. As

computer-based systems can control and retrieve in-

formation from physical objects, information security

has become one of the key concerns in IoT networks,

specially when conﬁdential data is involved.

As such, the security of smart toys has been a rai-

sing concern for users and parents, specially because

they are mostly used by children (Carr, 2017), which

are considered vulnerable in most countries and

cultures. In fact, many countries and communities

have created their own set of rules or regulations that

address data protection when it comes to children

interacting with online services, such as the COPPA

(Children’s Online Privacy Protection Act) from the

USA, the PIPEDA (Personal Information Protection

and Electronic Documentation Act) from CANADA,

and the GDPR (General Data Protection Regulation)

Gonçalves de Carvalho, L. and Medeiros Eler, M.

Security Tests for Smar t Toys.

DOI: 10.5220/0006776101110120

In Proceedings of the 20th International Conference on Enterprise Information Systems (ICEIS 2018), pages 111-120

ISBN: 978-989-758-298-1

111

from the European Parliament and the Council

of the European Union. Unfortunately, few policies

have been disclosed regarding security policies for

smart toys so far.

Given that the IoT market represents a huge re-

venue for several companies, security solutions have

been proposed such as the Industrial Security Appli-

ances (ISA) and Cisco ASA from CISCO Systems,

for example. However, they are very expensive soluti-

ons and aim at more complex infrastructures. Policies

and requirements have been also proposed to assure

the security of mobile services and applications (Bis-

was, 2012; Zapata et al., 2014; Nagappan and Shihab,

2016). Nonetheless, deﬁning such policies and requi-

rements for smart toys requires a separate investiga-

tion since they usually run in a less secure environ-

ment, e.g. with few security controls.

A smart toy is a more vulnerable device than a

mobile application because smart toys have an actual

physical toy (a simpler device than a smartphone or a

tablet, controlled by the mobile application) that may

also collect, manipulate and store information. Mo-

reover, it has network features to communicate with

the mobile device and other computational systems,

which increases the attack surface. As most smart

toys are manufactured by well known and establis-

hed companies, parents tend to believe their children

are safe around these products. However, according to

the Federal Bureau of Investigation (FBI) of the USA,

parents should be worried since ”security safeguards

for these toys can be overlooked in the rush to market

them and to make them easy to use” (FBI, 2017).

In fact, there have been several public reports on

security ﬂaws presented by best seller smart toys (Ba-

raniuk., 2016; Hackett, 2016; Newman, 2015; Cut-

hbertson, 2017; Franceschi-Bicchierai, 2016; Poulter,

2017; Jones and Meurer, 2016). Security issues in-

clude, for example, information leakages (biography

information, photos), toys used as spies, and outsiders

interacting with children via a smart toy. Such ﬂaws

may be a threat even to the children safety since they

can provide conﬁdential information (e.g. location),

and children can even unrestrictedly follow instructi-

ons given by the toy.

Such security issues motivated the FBI in the USA

to raise an alert for families on the risks such toys

can bring (FBI, 2017). According to them, many toys

sporting cloud-backed features such as speech recog-

nition or online content hosting ”could put the privacy

and safety of children at risk due to the large amount

of personal information that may be unwittingly dis-

closed.”.

In this context, it is crucial that speciﬁc measu-

res are taken towards assuring that smart toys are safe

for their users. Consequently, researchers have been

working in this speciﬁc subject (Ng et al., 2015; Raf-

ferty and Hung, 2015; Hung et al., 2016; Rafferty

et al., 2017a; Yankson et al., 2017). However, they

have only addressed security issues restricted to pri-

vacy and conﬁdentiality problems that, while very im-

portant, are not the only ones. Parental control me-

chanisms can mitigate relevant privacy issues, howe-

ver they cannot avoid attacks that compromise other

security properties.

In special, regarding general proposals for secu-

rity issues, we have previously identiﬁed 12 issues,

15 threats and 20 security requirements for a typical

toy computing scenario (de Carvalho and Eler, 2017).

This work was based on the Requirements and Design

phases of the Microsoft Security Development Life-

cycle (SDL) process, the STRIDE (Spooﬁng, Tampe-

ring, Repudiation, Information disclosure, Denial of

service and Elevation of privilege) approach, and the

COPPA and PIPPEDA regulation. However, we have

not discussed how the remaining phases of SDL pro-

cess – Implementation, Veriﬁcation and Release – can

be useful to verify and test smart toys to assure the se-

curity requirements have been met.

Therefore, this paper contributes to this particular

ﬁeld as follows:

• it extends our previous work by revising the is-

sues, threats and security requirements identiﬁed

for smart toys (de Carvalho and Eler, 2017), but

considering the GDPR from the European Union;

• it shows how the Implementation, Veriﬁcation and

Release phases of the SDL process can help deﬁ-

ning security analysis and tests for smart toys to

assure the security requirements have been met;

• it presents how smart toys available in the mar-

ket could have beneﬁted from the security issues,

threats, requirements, analysis and tests presented

and discussed in this work.

We believe our work can contribute not only with

well known smart toys manufacturers, which, in the-

ory, have resources to invest in a specialized team

to assure their products are reliable, but also with

researchers and developers that wants to create re-

liable smart toys to be used for several purposes.

For instance, researchers have designed a smart toy

called EDUCERE, stackable cubes with a data col-

lector module, as a resource to automatically de-

tect delays in psychomotor development in child-

ren (Guti

errez Garc

ıa et al., 2017). Another example

is StoryTech, a smart storytelling toy that encourages

children to produce their own stories by contributing

to narrative activities to make a positive impact on

their creativity (Kara et al., 2013).

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

112

This paper is organized as follows. Section 2

shows the background. Section 3 discusses related

work. Section 4 presents issues, threats and require-

ments for a typical toy computing environment, while

Section 5 shows the proposed security analysis and

tests for smart toys. Section 6 shows how some smart

toys currently available in the market could have been

beneﬁted from our work. Finally, concluding remarks

and future directions are presented in Section 7.

2 BACKGROUND

This section introduces basic concepts behind smart

toys and the security process used in this work.

2.1 Smart Toys

Recently, the growing interest for technological gad-

gets from people of all ages has promoted the deve-

lopment of high tech toys, also known as smart toys.

A smart toy is a device consisting of a physical toy

component that connects to one or more toy com-

puting services to facilitate game-play in the Cloud

through networking and sensory technologies to en-

hance the functionality of a traditional toy (Rafferty

and Hung, 2015).

A smart toy can also use camera, microphone and

various other sensors to capture voice, record videos

and photos, track location and to store personalized

information (Rafferty and Hung, 2015). A smart toy

can be considered an Internet of Thing object which

can collect contextual data on the context of the user

(e.g., time of day, location, weather, etc.) and provide

personalized services to enhance user’s experience.

Smart toys are in general composed of three parts:

a conventional physical toy (such as a car or a doll)

equipped with electronic components, sensors, and

software which enable wireless communication with

other computational systems via Wi-Fi, Bluetooth,

Near Field Communication (NFC); a mobile device

that provides the smart toys with mobile services to

enhance their functionalities; and a mobile applica-

tion that interacts with the physical toy. Figure 1

shows an illustration of this environment including

the user. Rafferty and Hung (2015) refer to this ﬁeld

of study as toy computing, which associates the phy-

sical computation (embed systems and sensors in a

traditional toy) with mobile services.

2.2 The Microsoft SDL Process

Microsoft SDL (Lipner, 2004; Microsoft, 2010)

stands for security software development, and aims

User

Physical

toy

Mobile

device

Smart toy

Figure 1: Toy computing environment.

at assuring the security of systems during the whole

development process. It has the following main pha-

ses:

1. Requirements: security requirements esta-

blishment, quality gates and bug bars deﬁnition

and documentation (set security and privacy

minimum levels), and security and privacy risk

analysis;

2. Design: design requirements establishment, at-

tack surface analysis and threat modeling;

3. Implementation: approved tools utilization, inse-

cure functions disable and static analysis execu-

tion;

4. Veriﬁcation: dynamic analysis and fuzzing tests

execution, and attack surface review;

5. Release: incident response plan elaboration, ﬁ-

nal security review execution and software rele-

ase. The SDL foresees its use in conjunction with

both conventional and agile software development

processes (Microsoft, 2011).

Requirements identiﬁcation is performed in Re-

quirements and Design phases. In the ﬁrst phase, mi-

nimum security and privacy quality levels are esta-

blished through quality gates and bug bars whereas,

in the design phase, security and privacy design spe-

ciﬁcation is built, which describe the security and pri-

vacy features that will be exposed directly to the user.

The security tests are identiﬁed based on the remai-

ning phases: Implementation, Veriﬁcation and Rele-

ase.

In the Implementation phase, static analysis is per-

formed aiming at ﬁnding security ﬂaws on the source

code. In general, the source code is automatically

analyzed by tools known as Static Application Secu-

rity Testing (SAST). In the Veriﬁcation phase, dyna-

mic analysis and fuzz testing are performed. Dynamic

analysis simulates attacks and monitors the software

aiming at ﬁnding vulnerabilities such as memory cor-

ruption and user privileges failures. Fuzz testing aims

at ﬁnding general ﬂaws in the system under test. In

the Release phase, penetration tests are performed to

ﬁnd all sort of vulnerabilities, either when no internal

information is available or when they are.

Security Tests for Smart Toys

113

3 RELATED WORK

Researchers have been working in security aspects

of smart toys since they emerged. They have been

paying special attention to privacy aspects. Rese-

archers have also investigated smart toys examples

aiming at identifying risks, security ﬂaws and vul-

nerabilities (Rafferty et al., 2017b; Dobbins, 2015),

or simply performing general analysis of smart toys

mentioning how vulnerable they are given their cha-

racteristics or how parents feel around such pro-

ducts (Taylor and Michael, 2016; McReynolds et al.,

2017).

Rafferty and her colleagues used a formal privacy

threat model to investigate privacy requirements for

toy computing (Rafferty and Hung, 2015). As a re-

sult, they have compiled six (6) privacy rights (pri-

vacy requirements). In a related project, they have

also proposed a privacy rule conceptual model where

parents/legal guardians are the owners of their child’s

data and provide consent to share the data collected

through access rules (Rafferty et al., 2017a).

Some researchers have discussed the seriousness

of privacy implication for smart toys and surveyed

related work on privacy issues within this dom-

ain (Yankson et al., 2017). They also discuss glo-

bal perspectives regarding legislation on such devices

and propose common best practices for parents and

manufactures to assure child safety. In the same to-

pic, Hung and his colleagues discuss related privacy

requirements for smart toys in a toy computing envi-

ronment with a case study on a commercial smart toy

called Hello Barbie from Mattel (Hung et al., 2016).

Although many work has been done in this area,

most of them focus on privacy and not in general se-

curity aspects. Moreover, most of them reports con-

cerns about smart toys vulnerabilities but do not pre-

sent any security requirements and how to ensure they

have been implemented. In that sense, we previously

presented a list of security issues, threats and require-

ments on a typical architecture of smart toys (de Car-

valho and Eler, 2017). However, we do not discuss

in this work how security analysis and tests should

be carried out in order to check whether the security

requirements have been met. Therefore, there is still

room for contributions in this area.

4 SECURITY ISSUES, THREATS

AND REQUIREMENTS FOR

SMART TOYS

We have previously identiﬁed 12 issues, 15 threats

and 20 security requirements based on the Require-

ments and Design phases of the Microsoft SDL pro-

cess, the STRIDE approach and regulations such as

PIPEDA and COPPA (de Carvalho and Eler, 2017).

We have revisited and extended our previous work

by considering an additional regulation: the GDPR,

from the European Union. Such regulation provided

us with more knowledge into how to strengthen and

unify data protection for all individuals, but, in the

case of our investigation, children’s data. As a result,

we have identiﬁed four more issues (I13 to I16) and

two more security requirements (SR21 and SR22).

The whole set of security issues that should be ad-

dressed regarding smart toys according to the afore-

mentioned regulations and standards are presented as

follows:

I1 Provide notice about information collection,

use and disclosure practices.

I2 Obtain parental consent for personal informa-

tion collecting, using and disclosing.

I3 Not promote unnecessary personal informa-

tion disclosure.

I4 Protect personal information conﬁdentiality,

integrity and availability.

I5 Provide the same protection level for third

party information processing.

I6 Implement procedures to protect personal in-

formation.

I7 Document the purposes for which personal in-

formation is collected.

I8 Obtain individual consent for the personal in-

formation collection, use or disclosure.

I9 Specify the type of personal information col-

lected.

I10 Retain personal information only as long as

necessary.

I11 Maintain personal information accurate, com-

plete and up-to-date as is necessary.

I12 Protect personal information against loss

or theft, unauthorized access, disclosure,

copying, use, or modiﬁcation.

I13 The request for consent must be given in an

intelligible and easily accessible form.

I14 Breach notiﬁcation is mandatory and data pro-

cessor are required to notify their customers.

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

114

I15 Data erasure of personal data, cease the further

dissemination of the data and halt processing

of the data for third parties.

I16 Inclusion of data protection from the onset of

the designing of systems.

The whole set of threats concerning smart toys are

presented as follows:

T1 Spooﬁng:

T1.1 The children is not playing, but the at-

tacker (insider), who wants to discover

conﬁdential information.

T1.2 An attacker is using another mobile de-

vice to control the toy (Bluetooth paral-

lelization).

T1.3 The mobile service provider is fake.

T2 Tampering:

T2.1 Unauthorized modiﬁcation of the conﬁ-

guration ﬁle of the mobile device (loads

a conﬁguration ﬁle not suitable for the

user).

T2.2 Unauthorized modiﬁcation of the in-

formation exchanged through network

communication between the compo-

nents (physical toy x mobile device x

access point/router).

T2.3 Unauthorized modiﬁcation of the data-

base in the mobile device (changes the

game points, user’s actions history, etc).

T3 Repudiation:

T3.1 User denies purchases of services,

accessories etc.

T4 Information disclosure:

T4.1 Disclosure of personal information sto-

red in the database.

T4.2 Disclosure of information used to re-

quest mobile services (localization, con-

text data etc).

T4.3 Disclosure of information stored in the

mobile device (photos, video, text mes-

sages etc).

T5 Denial of Service:

T5.1 A service inserts enough information in

the database to reach the full capacity of

the mobile device storage system.

T5.2 More than one device sends commands

to the physical toy making it not able to

provide the correct answer.

T5.3 An attacker denies access to mobile ser-

vices through the access point.

T6 Elevation of privilege:

T6.1 An attacker watches the data exchan-

ged by the network communication bet-

ween the mobile device and the toy, then

changes it to access the toy.

T6.2 An attacker watches the data exchanged

by the network communication between

the mobile device and the mobile servi-

ces, then changes it to access the mobile

services.

The whole set of security requirements identiﬁed

for a typical smart toy environment are the following:

SR01 The smart toy app must provide notice of

what information it collects and the further

use and disclosure practices.

SR02 The smart toy app must provide an speciﬁc

interface in order to identify user age and

obtain user consent before the personal in-

formation collection and manipulation; in

the case of child user, obtain veriﬁable pa-

rental consent and parental consent review.

SR03 The smart toy app must not ask for more

personal information in order to continue its

operation.

SR04 The smart toy app must authenticate users.

SR05 Communication between physical toy and

mobile device must use a protocol that al-

low authentication and authorization me-

chanisms.

SR06 Mobile services providers must own digital

certiﬁcates allowing identity veriﬁcation.

SR07 Conﬁguration ﬁle integrity must be main-

tained and veriﬁed in every mobile app play

session.

SR08 Every communication in toy computing en-

vironment must use cryptographic mecha-

nisms.

SR09 The Database Management Systems

(DBMS) must provide user authentication.

SR10 The DBMS must provide security mecha-

nisms against to external modiﬁcation of

stored data.

SR11 The smart toy app must request authenti-

cation renew before every ﬁnancial tran-

saction.

SR12 The DBMS must provide data encryption

feature or allow data encryption by third-

party tools.

Security Tests for Smart Toys

115

SR13 The smart toy app must encrypt personal in-

formation accessed from others apps inside

the same mobile device.

SR14 The mobile app must not access unneces-

sary ﬁles from others mobile apps inside the

same mobile device.

SR15 The mobile app must monitor and limit da-

tabase growth.

SR16 The physical toy must not accept com-

mands from mobile devices outside the cur-

rent play session.

SR17 Every communication must use secure pro-

tocol with cryptographic mechanisms.

SR18 The smart toy app must show the privacy

police when required.

SR19 The smart toy must delete every personal

information collected that is no longer use-

ful.

SR20 The smart toy must maintain personal infor-

mation accurate, complete and up-to-date

as is necessary.

SR21 The smart toy app must notify users about

security breach and enable updates.

SR22 The smart toy development and updates

must consider well-known security princi-

ples.

5 SECURITY TESTS FOR SMART

TOYS

Following the SDL process, we have identiﬁed tests

and analysis required to meet security issues and re-

quirements identiﬁed in the previous section based on

the Implementation, Veriﬁcation and Release phases.

As a consequence, we expect such measures to miti-

gate the threats we identiﬁed.

5.1 Implementation

During this phase, SAST (Static Application Security

Testing) tools are used to identify security ﬂaws in the

source code. Such tools can identify when best practi-

ces for security control are not implemented. For the

Android O.S., for instance, the tools QARK, Andro-

bugs and JAADAS are commonly used in this task,

for they are able to identify security ﬂaws regarding

the following classes and areas (OWASP, 2017):

• Data validation.

• Authentication.

• Session management.

• Authorization.

• Cryptography.

• Error and exception handling.

• Login procedures.

• Security conﬁgurations.

• Network architecture.

Accordingly, we have identiﬁed the security requi-

rements that can be veriﬁed by means of a static ana-

lysis tools. Table 1 shows the security requirements

and the corresponding security failure class it is rela-

ted to.

Table 1: Security Requirements and related security failures

classes.

Sec. Req. Security failure class

SR04 Authentication

SR05 Authentication and

Authorization

SR08 Criptography

SR09 Authentication

SR13 Criptography

SR17 Criptography

SR22 All classes

5.2 Veriﬁcation

In the Veriﬁcation phase, more specialized tests are

required to assure that the application meets the esta-

blished requirements. Therefore, each security requi-

rement which has not been veriﬁed yet is classiﬁed,

when applicable, according to one of the security test

classes (OWASP, 2013):

• Conﬁguration and Deployment management.

• Identity Management.

• Authentication.

• Authorization.

• Session Management.

• Input Validation.

• Error Handling.

• Weak Cryptography.

• Business logic.

• Client Side.

Although the presented security tests classes have

not been created for mobile applications, they are ge-

neric enough to be useful in this context. Therefore,

Table 2 shows each security requirement associate

with a corresponding test class.

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

116

Table 2: Security Requirements and corresponding security

test classes.

Sec. Req. Test class

SR06 Weak Cryptography

SR07 Business Logic

SR10 Business Logic

SR12 Weak Cryptography

SR14 Conﬁguration and Deployment

Management

SR15 Conﬁguration and Deployment

Management

SR19 Conﬁguration and Deployment

Management

Once each security test has been associated to a

security test class, it is possible to deﬁne more speciﬁc

and suitable security tests required to check whether

the application meet the security requirements. Follo-

wing we present the general security tests applicable

to this phase considering each security requirements

presented at Table 2.

Security Requirement: RS06

Test: Security tests in protocols with crypto-

graphy

Description:

– Check whether the certiﬁer authority is trust-

worthy.

– Check whether the certiﬁcate is valid.

– Check whether the website name is the same as

the certiﬁed one.

Security Requirement: SR07, SR10

Test: Integrity veriﬁcations test

Description:

– Checks whether the application does not allow

users to destroy the integrity of any part of the

system or its data.

Security Requirement: SR12

Test: Cryptography test

Description:

– Check whether the ﬁles stored at the database

are ciphered.

Security Requirement: SR14, SR19

Test: Application platform conﬁguration test

Description:

– Check the conﬁguration of each element of the

application architecture.

Security Requirement: SR15

Test: Application platform conﬁguration test

Description:

– Checks the database conﬁguration

5.3 Release

In the Release phase it is possible to verify, by means

of alpha and beta tests, all security requirements that

depends on a functional prototype or version of the

smart toy. Alpha tests are able to check the following

security requirements: SR1, SR2, SR3, SR11, SR16

and SR18, while the beta tests are able to check the

following security requirements: SR20 and SR21.

In the absence of alpha and beta tests, it is re-

commended that penetration tests to be used, as used

in the Hcon Security Testing Framework (HconSTF),

Samurai Web Testing Framework (SamuraiWTF) and

Samurai Project’s Security Testing Framework for

Utilities (SamuraiSTFU), for instance, but tailored

to the toy computing environment. Showing how to

tailor such tests to the toy computing environment is

not at the scope of this work.

6 SECURITY ANALYSIS AND

TESTS FOR SMART TOYS

AVAILABLE IN THE MARKET

We present an overview of a few smart toys available

in the market aiming at providing illustration of the

smart toys capabilities and specially how vulnerable

they can become. Most of the smart toys uses came-

ras, microphone and different sensors to collect, ob-

serve or infer personal information to provide custo-

mers with more personalized game experiences. The

data collected by the physical part of the smart toy are

sent to a mobile device and/or a server through a wi-

reless network. The mobile application of the smart

toy running in the mobile device, in turn, gets mobile

services provided by Internet servers.

Data collection may be a problem when appro-

priate security controls are missing because private

information could be exposed in a data leakage.

A quick search over the Internet for security is-

sues in smart toys will reveal security ﬂaws such

as private information leakages and outsiders inte-

racting with children via a smart toy (Baraniuk., 2016;

Hackett, 2016; Newman, 2015; Cuthbertson, 2017;

Franceschi-Bicchierai, 2016; Poulter, 2017; Jones

and Meurer, 2016).

We believe the 22 security requirements previ-

ously presented address many of the general secu-

rity issues related to the smart toys currently availa-

ble in the market. Following we present a description

of some smart toys, some publicly disclosed security

ﬂaws and some suggested requirements and test cases

that could have helped prevented the reported issues.

Security Tests for Smart Toys

117

Here, we have no intention of exhaustively explo-

ring all security requirements and possible tests for

smart toys available in the market since they have

many features. The purpose is to show that many

of the ﬂaws found in such toys could have been ad-

dressed if security measures have been made since

the Requirements elicitation phase of the develop-

ment process. Moreover, suggested tests are generic

since speciﬁc tests depends on speciﬁc architectures,

programming languages, libraries, APIs, which we do

not have access because they are not publicly availa-

ble. A summary of the tests and analysis performed

in each phase and associate requirements is presented

in Tables 3, 4 and 5.

6.1 CloudPets

A CloudPet is a stuffed pet with built in capabilities

and associated mobile services. Parents, relatives or

friends can record and send messages using an app

from anywhere in the world. A parent or guardian

gets the message on their CloudPet App and then ap-

proves it and delivers it wirelessly to the CloudPet.

Children can also record a message which can be de-

livered to a contact network anywhere in the world.

Spiral Toys, the CloudPets manufacturer, left cus-

tomer data of its CloudPets brand on a database that

wasn’t behind a ﬁrewall or password-protected. The

exposed database contained data on 821,396 registe-

red users, 371,970 friend records (proﬁle and email)

and 2,182,337 voice messages. The voice messages

were not in the database, but they were stored in an

Amazon S3 bucket that doesn’t require authentica-

tion. Moreover, customers used weak passwords ma-

king it trivial to log into their accounts and listen to

the saved messages. One of the biggest concern in this

context is that someone may be able to use disclosed

information to send inappropriate messages to child-

ren and to gather information on families, friends,

which may put children safety in risk.

According to our analysis, in the case of this smart

toy, meeting requirements SR09 (the DBMS must

provide user authentication) and SR12 (the DBMS

must provide data encryption feature) would have pre-

vented the security issues in which personal were

accessed by attackers due to security ﬂaws related to

database access.

Following the SDL process, in the Implementa-

tion phase, SAST tools could be used to check requi-

rement SR09. In the Veriﬁcation phase, Cryptography

test is suggested to check SR12. In the Release phase,

no test is applicable to the security requirements we

are considering in this example.

6.2 Smart Toy Bear

This Mattel Fisher-Price interactive learning smart

toy with voice and image recognition features are ca-

pable to collect data to adapt to create personalized

playing. Through the mobile app and a Wi-Fi con-

nection, the smart toy gets updates and the parents

can unlock bonus activities.

Some Internet servers may fail to authenticate

users and expose data and proﬁles. The Smart Toy



Bear vulnerability in the backend systems enabled at-

tackers to access private information

In the case of the Smart toy bear, implementing se-

curity requirements SR04, SR05, SR06, SR07, SR08,

SR12, SR16 e SR17 would have prevented security

issues caused by insecure APIs, which allowed attac-

kers to access personal information and to send com-

mands to the physical toy.

Table 3: Security requirements addressed by SAST tools at

the Implementation phase.

Smart toy Sec. Req. Sec. Test

CloudPets SR09

Toy bear SR04, SR05,

SR08, SR17 SAST Tool

Hello Barbie SR05, SR17

Cayla SR04, SR05

I-QUE SR04, SR05

Table 4: Security Requirements addressed by security tests

during the Veriﬁcation phase.

Smart toy Sec. Req. Sec. Test

CloudPets SR12 Cryptography tests

SR06 Security tests

in protocols

with cryptography

Toy bear SR07 Integrity veriﬁcation

tests

SR12 Cryptography tests

SR06 Security tests

in protocols

with cryptography

Hello Barbie SR07 Integrity veriﬁcation

tests

SR12 Cryptography tests

Cayla - Not applicable

I-QUE - Not applicable

Considering the SDL process, SAST tools can

check security requirements SR04, SR05, SR08 and

SR17 during Implementation phase. In the Veriﬁ-

cation phase, security tests in protocols with cryp-

tography can check SR06 while integrity veriﬁca-

tion tests can check SR07 and cryptography tests the

SR12. In the Release phase, an alpha test in which

a user sends commands to the physical toy during a

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

118

Table 5: Security Requirements addressed during the Release phase.

Smart toy Sec. Req. Sec. Test Description

CloudPets - Not applicable Not applicable

Toy bear SR16 alpha User sends commands to the physical toy during the game

session from another user.

Hello Barbie - Not applicable Not applicable

Cayla SR03 alpha User uses all resources of the toy without providing any

additional personal information.

I-QUE SR03 alpha User uses all resources of the toy without providing any

additional personal information.

game session from another user can help checking

SR16.

6.3 Hello Barbie

Another Mattel smart toy, the Hello Barbie is a doll

equipped with a microphone, speaker and a speech

recognition feature, allowing a two-way conversation

when connected to a Wi-Fi network. A mobile app is

required for account set up and allow parents to listen

child’s conversation with the toy. To improve conver-

sation, the toy store conversations and sent them to a

server in the Internet. Hello Barbie doll app, for ex-

ample, can automatically connect to unsecured Wi-Fi

networks and reveal conﬁdential information.

In this speciﬁc smart toy, satisfying security re-

quirements SR05, SR06, SR07, SR12 e SR17 would

have avoided the exploitation of several vulnerabili-

ties of communication interception, personal informa-

tion disclosure and insecure Wi-Fi connections.

During the Implementation phase of the SDL,

SAST tools can check SR05, SR17. In the Veriﬁ-

cation phase, security tests in protocols with cryp-

tography can check SR06 while integrity veriﬁca-

tion tests can check SR07 and cryptography tests the

SR12. In the release phase, no test is applicable in to

the security requirements we are considering in this

example.

6.4 Cayla and I-QUE Intelligent Robot

They are both smart toys from Genesis Toys that are

able to answer several questions and, to improve user

experience, connects to the Internet through a mo-

bile device. Genesis Toys was accused by consumer

groups in the US, among other things, of collecting

children’s personal data (Baraniuk., 2016). It was

possible to connect to the toys from any mobile de-

vice through Bluetooth. The data exchange between

physical toy and mobile device can be easily intercep-

ted.

In the case of these two smart toys, fulﬁlling se-

curity requirements SR03, SR04 e SR05 would have

prevented, among other security issues, that attachers

requested personal information from children through

non-authorized connections via Bluetooth, simply by

using any mobile device nearby the smart toy.

Considering the phases of the SDL, SAST tools

can check SR04 and SR05 for both toys. Tests of the

Veriﬁcation phase are not applicable, but in the Rele-

ase phase both smart toys can beneﬁt from using al-

pha tests in which a user uses all resources of the toy

but providing no additional information. Such test is

useful to check SR03.

7 CONCLUSIONS AND FUTURE

WORK

In this paper, we presented a contribution to the smart

toys ﬁeld in three ways. First, we revisited our previ-

ous work (de Carvalho and Eler, 2017) to include four

(4) security issues and two (2) security requirements.

Next, we presented general security analysis and tests

for smart toys based on the Implementation, Veriﬁca-

tion and Release phases of the SDL process, and on

related security issues, threats and requirements. Fi-

nally, we presented an analysis of smart toys available

in the market in which we discuss some of their secu-

rity ﬂaws publicly reported and how the security and

test requirements identiﬁed in this work could have

prevented some of the related ﬂaws.

The proposed security requirements, the analysis

and tests are generic and can be related to most smart

toys that ﬁts in the toy computing ﬁeld, in which there

is an association between a physical toy and a mo-

bile device and application. Concrete tests depends on

programming languages, speciﬁc architectures, libra-

ries and access to the smart toys, so the contribution

of this work is theoretical and general.

Even though wealthy and well known manufac-

turers have plenty of resources to perform a careful

security analysis to identify threats and implement se-

curity features, the security ﬂaws we discussed in this

paper are presented by these manufacturers. As stated

by the FBI (FBI, 2017), “security safeguards for these

Security Tests for Smart Toys

119

toys can be overlooked in the rush to market them and

to make them easy to use”. In fact, many of the repor-

ted ﬂaws could have been avoided by fulﬁlling simple

requirements and following a process to test each se-

curity requirement.

Therefore, however theoretical, we believe the se-

curity requirements presented in this work along with

the security analysis and tests might be useful not

only for well known manufacturers, but also for re-

searchers and developers who aim at creating reliable

smart toys for many purposes, such as the case of the

EDUCERE, the smart toy designed to help detecting

delays in children’s psychomotor development.

As future work, we intend to build a prototype of a

smart toy to concretely implement all tests proposed

for this context. Moreover, we plan to identify spe-

ciﬁc security patterns and ﬂaws that arises from toy

computing architectures.

REFERENCES

Baraniuk., C. (2016). Bbc news. call for privacy probes over

cayla doll and i-que toys.

Biswas, D. (2012). Privacy policies change management

for smartphones. In 2012 IEEE International Confe-

rence on Pervasive Computing and Communications

Workshops, pages 70–75.

Carr, J. (2017). The internet of toys – the impact on children

of a connected environment. Journal of Cyber Policy,

2(2):227–231.

Cuthbertson, A. (2017). Newsweek. internet-connected

teddy bear leaks 2 million voice recordings of parents

and children.

de Carvalho, L. G. and Eler, M. M. (2017). Security requi-

rements for smart toys. In ICEIS 2017 - Proceedings

of the 19th International Conference on Enterprise In-

formation Systems, volume 2, pages 144–154.

Dobbins, D. L. (2015). Analysis of Security Concerns and

Privacy Risks of Children’s Smart Toys. PhD thesis,

Washington University St. Louis, MO, USA.

FBI (2017). Federal bureau of investigation - consumer

notice: Internet-connected toys could present privacy

and contact concerns for children.

Franceschi-Bicchierai, L. (2016). Motherboard. hacked toy

company vtech’s tos now says it’s not liable for hacks.

Guti

errez Garc

ıa, A. M., Mart

ın Ruiz, L. M., Rivera, D.,

Vadillo, L., and Valero Duboy, A. M. (2017). A smart

toy to enhance the decision-making process at child-

ren’s psychomotor delay screenings: A pilot study. J

Med Internet Res, 19(5):e171.

Hackett, R. (2016). Fortune. this ﬁsher-price smart toy bear

had data-leak vulnerability.

Hung, P. C. K., Iqbal, F., Huang, S.-C., Melaisi, M., and

Pang, K. (2016). A Glance of Child’s Play Privacy

in Smart Toys, pages 217–231. Springer International

Publishing, Cham.

Jones, M. L. and Meurer, K. (2016). Can (and should)

hello barbie keep a secret? In 2016 IEEE Interna-

tional Symposium on Ethics in Engineering, Science

and Technology (ETHICS), pages 1–6.

Kara, N., Aydin, C. C., and Cagiltay, K. (2013). Investi-

gating the activities of children toward a smart story-

telling toy. Journal of Educational Technology & So-

ciety, 16(1):28–43.

Lipner, S. (2004). The trustworthy computing security

development lifecycle. In Proceedings of the 20th

Annual Computer Security Applications Conference,

ACSAC’04, pages 2–13, Washington, DC, USA.

IEEE Computer Society.

McReynolds, E., Hubbard, S., Lau, T., Saraf, A., Cakmak,

M., and Roesner, F. (2017). Toys that listen: A study

of parents, children, and internet-connected toys. In

Proceedings of the 2017 CHI Conference on Human

Factors in Computing Systems, CHI ’17, pages 5197–

5207, New York, NY, USA. ACM.

Microsoft (2010). Simpliﬁed implementation of the micro-

soft sdl.

Nagappan, M. and Shihab, E. (2016). Future trends in

software engineering research for mobile apps. In

2016 IEEE 23rd International Conference on Soft-

ware Analysis, Evolution, and Reengineering (SA-

NER), volume 5, pages 21–32.

Newman, J. (2015). Pc world. internet-connected hello bar-

bie doll can be hacked.

Ng, G., Chow, M., and Salgado, A. d. L. (2015). Toys and

Mobile Applications: Current Trends and Related Pri-

vacy Issues, pages 51–76. Springer International Pu-

blishing, Cham.

OWASP (2013). Owasp testing guide 4.0.

OWASP (2017). Open web application security project

(owasp) homepage - source code analysis tools.

Poulter, S. (2017). Daily mail - science and tech. how safe is

your child? best-selling smart toys have worrying se-

curity failures that let strangers talk to your little ones

without your knowledge.

Rafferty, L. and Hung, P. C. K. (2015). Introduction to Toy

Computing, pages 1–7. Springer International Publis-

hing, Cham.

Rafferty, L., Hung, P. C. K., Fantinato, M., Peres, S. M., Iq-

bal, F., Kuo, S.-Y., and Huang, S.-C. (2017a). Towards

a Privacy Rule Conceptual Model for Smart Toys, pa-

ges 85–102. Springer International Publishing, Cham.

Rafferty, L., Iqbal, F., and Hung, P. C. K. (2017b). A Se-

curity Threat Analysis of Smart Home Network with

Vulnerable Dynamic Agents, pages 127–147. Sprin-

ger International Publishing, Cham.

Taylor, E. and Michael, K. (2016). Smart toys that are the

stuff of nightmares [editorial]. IEEE Technology and

Society Magazine, 35(1):8–10.

Yankson, B., Iqbal, F., and Hung, P. C. K. (2017). Pri-

vacy Preservation Framework for Smart Connected

Toys, pages 149–164. Springer International Publis-

hing, Cham.

Zapata, B. C., Ni

nirola, A. H., Fern

andez-Alem

an, J. L.,

and Toval, A. (2014). Assessing the privacy policies in

mobile personal health records. In 2014 36th Annual

International Conference of the IEEE Engineering in

Medicine and Biology Society, pages 4956–4959.

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

120
