Designing and Implementing Elastically Scalable Services

A State-of-the-art Technology Review

Kiyana Bahadori and Tullio Vardanega

Brain, Mind, Computer Science PhD Course, University of Padova, Italy

Keywords:

Service, Service-Oriented Architecture, Microservice Architecture, Cloud Computing, Elastic Scalabiity,

Orchestration.

Abstract:

The prospect of fast and affordable on-demand service delivery over the Internet proceeds from the very

notion of Cloud Computing. For service providers, the ability to afford those beneﬁts to the user is contingent

on attaining rapid elasticity in service design and implementation, which is a very open research goal as yet.

With a view to this challenge, this paper draws a trajectory that, starting from a better understanding of the

principal service design features, relates them to the microservice architectural style and its implications on

elastic scalability, most notably dynamic orchestration, and concludes reviewing how well state-of-the-art

technology fares for their implementation.

1 INTRODUCTION

Cloud computing has imposed itself as an attractive

novel operational model for hosting and delivering

IT services over the Internet (Zhang et al., 2010).

Its central tenet of as-a-service provisioning, to the

user (from the application perspective) and to the ser-

vice provider (from the implementation perspective),

meets the technology and economic requirements of

todays acquisition pattern of IT infrastructure (Arm-

brust et al., 2009).

In fact, the promised beneﬁts of cost-effectiveness

favoring pay-as-you-go pricing model, scalability and

reliability, appeal major IT companies to meet their

business objectives in a Cloud environment (An-

drikopoulos et al., 2013)(Buyya et al., 2009)(Khajeh-

Hosseini et al., 2012)(Tran et al., 2011). However,

from the service provider point of view, the cost is

outweighed by economic beneﬁts of elasticity and

transference of risk especially in an occurrence of

over and under-provisioning of resource (Armbrust

et al., 2010). In that context, the goal of service

providers is to design and implement service portfo-

lios capable of satisfying given service level objec-

tives (SLO), in the face of ﬂuctuating user demand,

while keeping operational costs at bay. Elasticity as

the ability to conserve resources at a ﬁne grain with

as fast as possible lead time allows matching resource

to workload much more closely which result in cost

savings for service providers (Armbrust et al., 2010).

To this end, service design and implementation must

both seek and provide for elastic scalability (Herbst

et al., 2013). In this paper, we address challenges re-

lated to that endeavour.

Contribution: This paper ﬁrst attempt to clarify the

notion of service and its requirements which is much

overloaded and frequently misunderstood. In the

quest for a service-based architecture that can guide

service design, it justiﬁes the adaptation of the mi-

croservice architecture style. Subsequently, we look

into state-of-the-art technology to assist the imple-

mentation of elastic scalability, concentrating on dy-

namic orchestration, which is one particular facet of

that general quality. This work addresses two speciﬁc

research questions. (RQ1) What are the design re-

quirements that most relate to elasticity? (RQ2) How

far does state-of-the-art technology help achieve elas-

ticity?

The remainder of this paper is organized as fol-

lows: We brieﬂy explain the notion of service in Sec-

tion 2. Section 3 discusses the design implications of

service orientation. Section 4 shows how container-

ization is the response to the rapid horizontal scala-

bility and relates containers to microservices, high-

lighting how the former provides best ﬁtting support

for the adoption of the later. Section 5 assesses how

state-of-the-art technology solutions cover the needs

for dynamic orchestration. Section 6 draws some con-

clusions.

Bahadori, K. and Vardanega, T.

Designing and Implementing Elastically Scalable Services.

DOI: 10.5220/0006781705570564

In Proceedings of the 8th International Conference on Cloud Computing and Services Science (CLOSER 2018), pages 557-564

ISBN: 978-989-758-295-0

557

2 UNDERSTANDING THE

NOTION OF SERVICE

The ﬁrst widespread use of the notion of service, in

relation to software systems, arose as part of the Ser-

vice Oriented Architecture (SOA) initiative. In the

context of SOA, the term service is deﬁned as an in-

dependent logical unit, which provides functionality

for a speciﬁc business process and can be composed

with other services to form an application (Erl, 2007).

Another connotation of service emerged in Cloud

Computing as part of the X-as-a-service model,

coined to evoke the manner of contract-based, pay-

as-you-go utility delivering (Fehling et al., 2014).

The union of the two perspectives sets a most am-

bitious goal: building a software application by agile

aggregation of service units in such a way that the ex-

posed capabilities are realized with the least resource

consumption, and then delivered and consumed as

metered utilities with assured quality of service.

Several qualities are required of services to ﬁt this

bill. In this paper, we brieﬂy review them, to give

directions to service designers. We begin our review

from the need for services to be composable and in-

dependently deployable (Serrano et al., 2011)(Stine,

2015)(Mazmanov et al., 2013).

2.1 Composability and Independent

Deployability

Enterprise IT architectures have to leverage and im-

prove the existing suite of applications to address

changing the business requirements rapidly (Kim

et al., 2016; Humble and Molesky, 2011). Other

than for deprecated silo-ed monoliths (Richardson,

2017), the functionality provided by a single service

is normally insufﬁcient to respond alone to all user

requests. For example, the powering of an online

shopping site rests on a multiplicity of services, rang-

ing displaying, carting, payment processing, monitor-

ing and shipping, which may either be procured from

third-parties or provided by specialized development

units inside the business organization. In other words,

a service normally needs to collaborate with other ser-

vices to pursue a speciﬁc business goal, and the fab-

ric of such collaboration may change with the goal.

This collaborative trait requires services to warrant

composability (Serrano et al., 2011), i.e., the ability

to participate, unchanged, in different aggregates as

business demand requires (Tao et al., 2013)(Rao and

Su, 2004). Another essential trait of a service that

helps meet the requirements of elastic scalability is

being independently deployable (desirably, by fully

automated machinery (Lewis and Fowler, 2014)). It

provides an ability for a developer to deploy, update,

test and investigate directly on a particular service

without affecting the rest of the system. Therefore

each service can be scaled independently of other ser-

vices. Moreover, the isolation of each service ad-

dresses the challenge of the technology stack. This,

in fact, is completely different from using monolithic

application where components must be deployed to-

gether. Composability and independent deployability

proceed from service design with the following char-

acteristics.

Explicit Boundaries. A service possesses an inter-

face speciﬁcation that describes its functionality and

exposes for the use of other services. That inter-

face, separate from the corresponding implementa-

tion, forms the boundary of that service, and con-

tains all that one needs to know to interact with it.

The boundary for a service is deﬁned by means of

a contract (Cibraro et al., 2010). A contract con-

tains a schema and associated service policies (for

style of interaction, persistence, guarantee, etc.), and

is published using different mechanisms, initially via

WSDL (Christensen et al., 2001), and later through

REST API (Masse, 2011) and GRPC (Wang et al.,

1993). The schema deﬁnes the structure of the data

message, agnostic to programming languages (hence

intrinsically interoperable), needed to request a spe-

ciﬁc service functionality.

Policy-driven Interoperability. W3C’s notion of

web service was the ﬁrst practical solution to assure

network-based interoperability (David Booth, 2004;

Cohen, 2002). Service policies provide a conﬁg-

urable set of semantic stipulations concerning service

expectations or requirements expressed in machine-

readable language.

For example, an online shopping service may re-

quire a security policy enforcing a speciﬁc service

level (requiring an ID) and the users who do not com-

ply are not allowed to continue. The security policy

can be used with other related services such as ship-

ping. Augmenting service interfaces with policy stip-

ulations strengthens the assurance of service guaran-

tees across technology boundaries.

Loose Coupling. A well-deﬁned service boundary

goes hand in hand with the self-contained-ness of

the functionality set exposed in its service interface,

and therefore with the degree of loose coupling and

autonomy of its implementation. Loose coupling is

had when you do what your service interface declares

(without incurring chains of dependencies) and do

not place arbitrary constraints on your context of use

CLOSER 2018 - 8th International Conference on Cloud Computing and Services Science

558

(hence being ﬁt for reuse in multiple compositions)

(Fehling et al., 2014).

Self-containedness. A service interface is self-

contained if its implementation can be independently

managed (for instance, replicated or migrated) and

versioned (so long as in a backward-compatible man-

ner) without affecting the rest of the system (Erl,

2007).

Statelessness. Separation between service execu-

tion and state information enables replication, which

is one of the essential dimensions of scalability (Ab-

bott and Fisher, 2009). Statelessness (Erl, 2007) is the

name that designates this design quality.

3 BREAKING DOWN THE

MONOLITH

Accepted wisdom has it that the journey toward well-

versed service orientation, which fully meets the re-

quirements discussed in section 2, conventionally de-

parts from its farthest opposite: the rightfully depre-

cated monolith (Lewis and Fowler, 2014). The mono-

lith architecture assembles all that the application

needs to offer into one single sticky bundle, which

epitomizes the notion of single point of failure, is un-

able to scale efﬁciently, and suffers the worst pain of

the dependency hell (Merkel, 2014).

What is much less understood is the pitfall that

trips most incautious practitioners: ending up build-

ing a distributed monolith formed of ”microliths”,

that is, a collection of single-instance (not scalable)

mono-services (only with a cooler name) that com-

municate over blocking protocols (Steel et al., 2017).

On the solid footsteps of successful adopters such

as Amazon (Kamer, 2011), LinkedIn (Ihde, 2015),

Netﬂix (Mauro, 2015), the end point of that trans-

formative journey should arguably be the microser-

vice architecture (Dragoni et al., 2016). This is no

easy journey, though. One of the biggest difﬁculties

in getting there safely is with cutting the right bound-

ary for individual microservices, neither too coarse,

which would be just one tad smaller monolith, nor too

ﬁne-grained, as in a distributed-object system, with

painful service latency and maddeningly complex or-

chestration.

One driving criterion that helps cut the service

boundary right is to focus on the scalability con-

cern. Scalability is the ability to deploy cost-effective

strategies for extending one’s capacity (Weinstock

and Goodenough, 2006). Scalability can be obtained

in two ways: vertical or horizontal. Vertical scaling

(aka scale-up) is the ability to increase, in quantity or

capacity, the resources availed to a single instance of

the service of interest. The extent of this strategy is

evidently upper-bounded by the capacity of the host-

ing server (Varia, 2010; Vaquero et al., 2011). Hor-

izontal scaling (aka scale-out) is the ability to aggre-

gate multiple units, transparently, into a single logical

entity to adapt to different workload proﬁles (Beau-

mont, 2017). Replication is one central dimension to

this strategy.

In fact, to meet the goals stated earlier, we need

to pursue elastic scalability (aka elasticity), that is,

the combination of strategy and means that allow dy-

namic resource provisioning and releasing, while pre-

serving service continuity, and that are amenable to

full automation (Armbrust et al., 2010).

Speed and precision are the qualifying traits of

elasticity (Herbst et al., 2013). As the number of re-

quests for particular service increases (respectively,

decreases), the speed of resource provisioning (re-

spectively, releasing) should vary in accord with the

speed of demand variation, fully transparent to the

user. The latter quality, which one might call fru-

gality, prevents wastefulness in the ratio of provision-

ing over need, by matching the footprint of resource

deployment to the level of demand as exactly as the

grain of service design allows. It is the balance of

those two qualities that sanctions the goodness of the

service boundary.

Numerous studies (e.g., (Namiot and Sneps-Sneppe,

2014; Balalaie et al., 2016; Balalaie et al., 2015;

Dragoni et al., 2017; Villamizar et al., 2015;

Krylovskiy et al., 2015)) show that adopting the mi-

croservice architecture helps pursue those goals.

To better understanding, we illustrate the methodol-

ogy which monolithic and microservice architecture

uses to handle the scalability in Figure 1.

Figure 1: Scalability in monolithic and microservice archi-

tectures.

Having multiple independent units collaborate in pro-

viding a response to a user request most deﬁnitely in-

curs coordination overheads that must be addressed

by orchestration (Venugopal, 2016).

Designing and Implementing Elastically Scalable Services

559

Orchestration can be understood as the automated

management and coordination of complex software

system, constituted of collaborative parts, and their

associated (computing) resources (Venugopal, 2016).

The entry level of of orchestration entails automating

the deployment of the application by means of Con-

tinuous Integration and Continuous Delivery (CI/CD)

solutions such as Chef (Nelson-Smith, 2013), Ansible

(Hall, 2013) and Jenkins (Jenkins, 2017).

Of course, to align with elastic scalability, orches-

tration must be dynamic, that is, able to support the

adjustment of resource provisioning and service de-

ployment required to either follow reactively or (bet-

ter) adapt predictively to ﬂuctuating user demand.

Having multiple independent units collaborate in

providing a response to a user request most deﬁnitely

incurs coordination overheads that must be addressed

by orchestration (Venugopal, 2016).

Orchestration can be understood as the automated

management and coordination of complex software

system, constituted of collaborative parts, and their

associated (computing) resources (Venugopal, 2016).

The entry level of of orchestration entails automating

the deployment of the application by means of Con-

tinuous Integration and Continuous Delivery (CI/CD)

solutions such as Chef (Nelson-Smith, 2013), Ansible

(Hall, 2013) and Jenkins (Jenkins, 2017).

Of course, to align with elastic scalability, orches-

tration must be dynamic, that is, able to support the

adjustment of resource provisioning and service de-

ployment required to either follow reactively or (bet-

ter) adapt predictively to ﬂuctuating user demand.

4 RAPID SERVICE SCALING

USING CONTAINERIZATION

Virtualization is the fundamental techonology that

utilize resources by creating virtual logical partition

from a shared pool of resources to meet principle

of elastic scalability for service (Armbrust et al.,

2009)(Zhang et al., 2010). To this end, hypervised

virtualization has been a major enabler for Cloud

computing. Its primary bounty includes isolation

(which it assures) and self-sufﬁciency, that is, no ex-

ternal dependency and perfect loose coupling (which

it allows for), both being much desired qualities for

service-oriented applications. In addition to, or per-

haps as a reﬂection of, being too resource-costly, how-

ever, classic hypervised virtualization technology is

fundamentally unable to respond to the rapidity re-

quirements put forward by elastic horizontal scal-

ing (Pahl and Xiong, 2013).

Container-based virtualization, which originates

from the Linux Container project (LXC), is much bet-

ter apt at the scaling, while still assuring excellent iso-

lation (Pahl and Xiong, 2013). The container uses

the kernel of the host operating system to run mul-

tiple root ﬁle systems. The name ”container” desig-

nates each such root ﬁle system (Docker, 2017) and

holds the code and libraries that constitute the con-

tained application, while sharing the host operating

system with all other entities that run on it. This shar-

ing is a blessing but also a weakness; the latter be-

cause it requires the application to actually run on the

host OS, renouncing interoperability. Containers use

namespaces to cater for isolation among processes

and cgroups to limit and control resources usage in

individual process.

Because of their leaner nature, containers con-

sume less resources (so that one single host can ac-

commodate many containers) and are lighter and eas-

ier to house and transport, faster to deploy, boot and

shut down than virtual machines (Dua et al., 2014). It

is not surprising therefore that containers were found

to be up to 10 times faster to bootstrap than virtual

machines (Felter et al., 2015).

Docker is an open-source container technology

based on the LXC technique, which is built around

a container engine (Docker, 2017). A Docker con-

tainer is composed of two parts: a pile of images

and one container. Images are a collection of dif-

ferent read-only ﬁle systems stacked on top of each

other using the Advanced multi-layered Uniﬁcation

File-system (AuFS), which implements union mount-

ing that allows separate ﬁle systems or directories

to be overlaid into a single coherent ﬁle system.

A container is the writable image that sits on the

top layer of the said image stack. A microser-

vice architecture is a collection of multiple inde-

pendent deployable services written in a variety of

language and frameworks, which communicate with

high-level, application-independent protocols (Lewis

and Fowler, 2014)(Newman, 2015). Each service

needs to be provided with its required resources in a

fast, reliable and cost-effective way, and then needs to

be run, upgraded and replaced independently. These

requirements speak of containers (Pahl, 2015). There

are two approaches to deploying application using

containers: one-to-one and one-to-many (Richardson,

2016). The classiﬁcation criterion is the number of

services housed in the container, which deﬁnes its

granularity. The one app (service) per container ap-

proach allows each individual service to run on a ded-

icated container, so that one container hosts only one

service and each service is packaged as a container

image. This solution eases horizontal scaling, pro-

vides fast build/rebuild of the container, and allows

CLOSER 2018 - 8th International Conference on Cloud Computing and Services Science

560

the same container to be reused for multiple different

purposes in the same system. The major downside of

this approach is that it may yield a large number of

containers, and thus considerable overhead for inter-

action and management. The one-to-many solution,

where each container houses multiple services, ad-

dresses this very concern, without however answering

the question of which services to gather into which

container.

5 REVIEWING TECHNOLOGY

SUPPORT FOR DYNAMIC

ORCHESTRATION

The complementary speciﬁcation in the direction of

designing and implementing elastic scalability for the

deﬁnition of dynamic orchestration we discussed in

Section 4 requires the technology solutions to sup-

port efﬁcient resource allocation and coordination.

The scheduler is an essential component of an ideal

dynamic orchestration solution, as it is the entity in

charge of generating a dynamic execution plan that

responds to changes in user demand.

The scheduler must generate dynamic statistics on

the state of the resources that it manages, to compute

the best possible service-resource mapping, using ei-

ther reactive or proactive strategies.

Reactive approaches respond to demand ﬂuctu-

ation when predictions are not available. Exam-

ples of this solution appear in most commercial solu-

tions such as RightScale (RightScale, 2017) and AWS

(Amazon, 2017).

Proactive approaches use predicted demand to al-

locate resources before they are needed (Gong et al.,

2010; Nguyen et al., 2013; Dawoud et al., 2011). In

using proactive approaches, the accuracy of demand

prediction and provisioning is obviously critical to

saving costs with utility computing (Tsai et al., 2010).

A modern scheduler should provide support for

the following features:

• Afﬁnity / Anti-afﬁnity, to implement restrictions

that enforce given entities to always be adjacent

or separate to one another. An afﬁnity rule simply

means the ability to ensure that certain workload

or virtual server always runs on the same host.

Anti-afﬁnity works in the opposite way, with the

same impact as Afﬁnity.

• Taint and toleration, to mark a particular (log-

ical/physical) computing node as un-schedulable

so that no container will be scheduled on it other

than those that explicitly tolerate the taint. This

requirement can also be used to keep away a node

with a particular speciﬁcation (e.g., a physical re-

source) from the others and dedicate it to given

workload. It also allows rolling application up-

grades of a cluster with almost no downtime.

• Custom schedulers, to delegate responsibility for

scheduling an arbitrary subset of hosts to the user,

alongside with the default scheduler.

To examine how current state-of-the-art technol-

ogy meets the requirements for elasticity, we look in

Kubernetes (Kubernetes, 2017)(Brewer, 2015), Open-

Shift (OpenShift, 2017), DockerSwarm (Docker,

2017), as the most widely used solutions for the dy-

namic orchestration.

Kubernetes. One of the ﬁrst open source orchestra-

tion platform written in Google’s Go programming

language. Its architecture is based on a set of mas-

ter and worker (Minion) nodes. Within each node,

there are groups of containers called pods, which

share resource and are deployed together. Pods play

a signiﬁcant role in placing workload across a clus-

ter of nodes. Kubernetes uses architectural descrip-

tions, written in JSON or YAML, to describe the de-

sired state of services, which it feeds to the master

node. The master node devolves all dynamic orches-

tration tasks onto worker nodes. Kubernetes provides

Required and Preferred rules. Required rules need

to be met before a pod can be scheduled. Preferred

rules do not guarantee enforcement. Kubernetes also

uses a replication controller with a reactive approach

to instantiate pods as required.

Kubernetes provides pods and nodes with afﬁnity

/anti-afﬁnity attributes. It deﬁnes rules as a set of la-

bels for pods, which determines how nodes schedule

them. Anti-afﬁnity rules use negative operators.

Kubernetes marks nodes to avoid them to be

scheduled. The Kubectl command creates a taint

on nodes marks them un-schedulable by any pod that

does not have a toleration for taint with the corre-

sponding key-value.

Kuberenes at v1.6 supports customs schedulers in

a way that allows users to provide a name for their

custom scheduler and ignore the default one. Cus-

tom strategies are completely custom, meaning that

the user must write an ad-hoc plugin to use them.

OpenShift. A dynamic orchestration platform built

on top of Kubernetes, hence it inherits the capabil-

ities of its ancestor. By default, its container plat-

form scheduler is responsible for the placement of

new pods onto nodes within the cluster. It reads data

from the pod and tries to select the most appropriate

node, based on its conﬁguration policies. It does not

Designing and Implementing Elastically Scalable Services

561

modify the pod, and simply creates a binding for the

pod that ties it to the particular node.

Docker Swarm. It is a native orchestration tool

for the Docker Engine, which supports deploying

and running multi-container applications on different

hosts. The term swarm refers to the cluster of phys-

ical/virtual machines (Docker engines), called nodes,

where services are deployed. Its architecture uses one

master and multiple worker nodes.

The key concepts in it are services and tasks. Ser-

vice designates the tasks that need to execute on the

worker nodes, as speciﬁed in the tasks’ desired state.

Tasks represent atomic scheduling units of work as-

sociated to a speciﬁc container. Docker Swarm uses

a declarative description, called Compose ﬁle, written

in YAML to describe services.

The swarm manager is responsible for scheduling

the task (container) to worker nodes (hosts). Docker

Swarm places a set of ﬁlters on nodes and containers

to support the ﬁrst two requirements mentioned ear-

lier. Node ﬁlters constraint and health operate on

Docker hosts to select a subset of nodes for schedul-

ing. The node ﬁlter containerslots with a number

value is used to prevent launching containers above a

given threshold on the node.

Docker Swarm offers three strategies, called

spread, binpack, random, to manage cluster as-

signment according to need. Under the spread strat-

egy (which is the default one), it computes ranking

according to the nodes available CPU and RAM, at-

tempting to balance load across nodes. The binpack

strategy attempts to ﬁll up the most used hosts, leav-

ing spare capacity in less used ones. The random

strategy (which is primarily intended for debugging)

assigns computation randomly among the nodes that

can schedule it.

As mentioned earlier, scheduler is an essential

component to achieve optimal provisioning that re-

sponse to changes in user demand.

Concentrating on the scheduler to achieve opti-

mal provisioning in the mentioned technologies, we

observe that all are using predictive approaches to

achieve elasticity. As, using resources have boot-

times that vary, depending on the application, from

a couple of minutes to even 30-40 minutes to load all

the components needed. Even in the container world,

spawning a new large-image container on a new node

while the network is under stress, will easily take 5

to 10 minutes. The same holds for shut-down times.

Therefore, the longer the boot time will result in con-

suming more resource and less efﬁciency. So, the

more important it becomes to be proactive and pro-

vide required resources in advance to achieve effec-

tive elasticity. This justiﬁes investigating proactive al-

gorithms in place / along with reactive ones to achieve

effective elasticity.

6 CONCLUSIONS

The technology exploration that we have made in this

paper shows that there continues to be a gap between

what state-of-the-art solutions have to offer in the way

of support for elastic scalability and the full range of

requirements that such a need entails. Accordingly,

proactive approaches to resource scheduling are the

most acute need that is not supported as yet other

than in early research prototypes. To this end, our

future research goal is to design, implement and com-

paratively evaluate experimental proactive resource

allocation algorithms, which Cloud service provider

could employ to achieve rapid elasticity and leverage

it for a more proﬁcient use of DevOps.

REFERENCES

Abbott, M. L. and Fisher, M. T. (2009). The Art of Scalabil-

ity: Scalable Web Architecture, Processes, and Orga-

nizations for the Modern Enterprise. Addison-Wesley

Professional, 1st edition.

Amazon (2017). Amazon Web Service. https://aws.amazon.

com/.

Andrikopoulos, V., Binz, T., Leymann, F., and Strauch, S.

(2013). How to adapt applications for the cloud envi-

ronment. Computing, 95(6):493–535.

Armbrust, M., Fox, A., Grifﬁth, R., Joseph, A. D., Katz,

R., Konwinski, A., Lee, G., Patterson, D., Rabkin, A.,

Stoica, I., and Zaharia, M. (2010). A view of cloud

computing. Commun. ACM, 53(4):50–58.

Armbrust, M., Fox, A., Grifﬁth, R., Joseph, A. D., Katz,

R. H., Konwinski, A., Lee, G., Patterson, D. A.,

Rabkin, A., Stoica, I., et al. (2009). Above the clouds:

A berkeley view of cloud computing. Technical re-

port, Technical Report UCB/EECS-2009-28, EECS

Department, University of California, Berkeley.

Balalaie, A., Heydarnoori, A., and Jamshidi, P. (2015). Mi-

grating to cloud-native architectures using microser-

vices: an experience report. In European Conference

on Service-Oriented and Cloud Computing, pages

201–215. Springer.

Balalaie, A., Heydarnoori, A., and Jamshidi, P. (2016). Mi-

croservices architecture enables devops: migration to

a cloud-native architecture. IEEE Software, 33(3):42–

52.

Beaumont, D. (2017). How to explain verti-

cal and horizontal scaling in the cloud.

https://www.ibm.com/blogs/cloud-computing/2014/

04/explain-vertical-horizontal-scaling-cloud/.

CLOSER 2018 - 8th International Conference on Cloud Computing and Services Science

562

Brewer, E. A. (2015). Kubernetes and the path to cloud

native. In Proceedings of the Sixth ACM Symposium

on Cloud Computing, SoCC ’15, pages 167–167, New

York, NY, USA. ACM.

Buyya, R., Yeo, C. S., Venugopal, S., Broberg, J., and

Brandic, I. (2009). Cloud computing and emerging

it platforms: Vision, hype, and reality for delivering

computing as the 5th utility. Future Generation com-

puter systems, 25(6):599–616.

Christensen, E., Curbera, F., Meredith, G., and Weer-

awarana, S. (2001). Web Service Description Lan-

guage (WSDL) 1.1 W3C Note. Technical report,

World Wide Web Consortium (W3C).

Cibraro, P., Claeys, K., Cozzolino, F., and Grabner, J.

(2010). Professional WCF 4: Windows communica-

tion foundation with. NET 4. John Wiley & Sons.

Cohen, F. (2002). Understanding web service interoperabil-

ity. IBM Technical Library.

David Booth, Hewlett-Packard, H. H. F. M. E. N. I. M. C.

C. F. D. O. (11 February2004). Web services architec-

ture, w3c working group note.

Dawoud, W., Takouna, I., and Meinel, C. (2011). Elas-

tic vm for cloud resources provisioning optimization.

Advances in Computing and Communications, pages

431–445.

Docker (2017). What is docker. https://www.docker.com/

what-docker.

Dragoni, N., Giallorenzo, S., Lafuente, A. L., Mazzara, M.,

Montesi, F., Mustaﬁn, R., and Saﬁna, L. (2016). Mi-

croservices: yesterday, today, and tomorrow. arXiv

preprint arXiv:1606.04036.

Dragoni, N., Lanese, I., Larsen, S. T., Mazzara, M.,

Mustaﬁn, R., and Saﬁna, L. (2017). Microservices:

How to make your application scale. arXiv preprint

arXiv:1702.07149.

Dua, R., Raja, A. R., and Kakadia, D. (2014). Virtualization

vs containerization to support paas. In Cloud Engi-

neering (IC2E), 2014 IEEE International Conference

on, pages 610–614. IEEE.

Erl, T. (2007). Soa: principles of service design. Prentice

Hall Press.

Fehling, C., Leymann, F., Retter, R., Schupeck, W., and

Arbitter, P. (2014). Cloud computing patterns: funda-

mentals to design, build, and manage cloud applica-

tions. Springer Science & Business Media.

Felter, W., Ferreira, A., Rajamony, R., and Rubio, J. (2015).

An updated performance comparison of virtual ma-

chines and linux containers. In Performance Analysis

of Systems and Software (ISPASS), 2015 IEEE Inter-

national Symposium On, pages 171–172. IEEE.

Gong, Z., Gu, X., and Wilkes, J. (2010). Press: Predictive

elastic resource scaling for cloud systems. In Network

and Service Management (CNSM), 2010 International

Conference on, pages 9–16. Ieee.

Hall, D. (2013). Ansible Conﬁguration Management. Packt

Publishing.

Herbst, N. R., Kounev, S., and Reussner, R. (2013). Elastic-

ity in cloud computing: What it is, and what it is not.

In Proceedings of the 10th International Conference

on Autonomic Computing (ICAC 13), pages 23–27.

Humble, J. and Molesky, J. (2011). Why enterprises must

adopt devops to enable continuous delivery. Cutter IT

Journal, 24(8):6.

Ihde, S. (2015). InfoQ — From a Monolith

to Microservices + REST: the Evolution of

LinkedIn’s Service Architecture. [Online].

http://www.infoq.com/presentations/linkedin-

microservices-urn/.

Jenkins (2017). Jenkins. https://jenkins.io/.

Kamer, S. (2011). GIGAOM, The Biggest Thing

Amazon Got Right: The Platform. [Online].

https://gigaom.com/2011/10/12/419-the-biggest-

thing-amazon-got-right-the-platform/.

Khajeh-Hosseini, A., Greenwood, D., Smith, J. W., and

Sommerville, I. (2012). The cloud adoption toolkit:

supporting cloud adoption decisions in the enterprise.

Software: Practice and Experience, 42(4):447–465.

Kim, G., Debois, P., Willis, J., and Humble, J. (2016).

The DevOps Handbook: How to Create World-Class

Agility, Reliability, and Security in Technology Orga-

nizations. IT Revolution Press.

Krylovskiy, A., Jahn, M., and Patti, E. (2015). Designing

a smart city internet of things platform with microser-

vice architecture. In Future Internet of Things and

Cloud (FiCloud), 2015 3rd International Conference

on, pages 25–30. IEEE.

Kubernetes (2017). Kubernetes. https://kubernetes.io/docs/

tutorials/kubernetes-basics/.

Lewis, J. and Fowler, M. (2014). Microservices: a deﬁnition

of this new architectural term. Mars.

Masse, M. (2011). REST API Design Rulebook: Design-

ing Consistent RESTful Web Service Interfaces. ”

O’Reilly Media, Inc.”.

Mauro, T. (2015). Nginx — Adopting Microservices at

Netﬂix: Lessons for Architectural Design.[Online].

https://www.nginx.com/blog/microservices-at-

netﬂix-architectural-best-practices/.

Mazmanov, D., Curescu, C., Olsson, H., Ton, A., and

Kempf, J. (2013). Handling performance sensitive na-

tive cloud applications with distributed cloud comput-

ing and sla management. In Proceedings of the 2013

IEEE/ACM 6th International Conference on Utility

and Cloud Computing, UCC ’13, pages 470–475,

Washington, DC, USA. IEEE Computer Society.

Merkel, D. (2014). Docker: lightweight linux containers for

consistent development and deployment. Linux Jour-

nal, 2014(239):2.

Namiot, D. and Sneps-Sneppe, M. (2014). On micro-

services architecture. International Journal of Open

Information Technologies, 2(9):24–27.

Nelson-Smith, S. (2013). Chef: The Deﬁnitive Guide.

O’Reilly Media, Inc.

Newman, S. (2015). Building microservices: designing

ﬁne-grained systems. ” O’Reilly Media, Inc.”.

Nguyen, H., Shen, Z., Gu, X., Subbiah, S., and Wilkes,

J. (2013). Agile: Elastic distributed resource scaling

for infrastructure-as-a-service. In ICAC, volume 13,

pages 69–82.

OpenShift (2017). Container Application Platform by the

Open Source Leader. https://www.openshift.com/.

Designing and Implementing Elastically Scalable Services

563

Pahl, C. (2015). Containerization and the paas cloud. IEEE

Cloud Computing, 2(3):24–31.

Pahl, C. and Xiong, H. (2013). Migration to paas clouds-

migration process and architectural concerns. In

Maintenance and Evolution of Service-Oriented and

Cloud-Based Systems (MESOCA), 2013 IEEE 7th In-

ternational Symposium on the, pages 86–91. IEEE.

Rao, J. and Su, X. (2004). A survey of automated web

service composition methods. In SWSWPC, volume

3387, pages 43–54. Springer.

Richardson, C. (2017). Monolithic architecture.

http://microservices.io/patterns/monolithic.html.

Richardson, C. (February 10, 2016). Choos-

ing a Microservices Deployment Strat-

egy. https://www.nginx.com/blog/deploying-

microservices/.

RightScale (2017). RightScale. https://www.

rightscale.com/.

Serrano, M., Shi, L., Foghl

u, M.

O., and Donnelly, W.

(2011). Cloud services composition support by us-

ing semantic annotation and linked data. In Inter-

national Joint Conference on Knowledge Discovery,

Knowledge Engineering, and Knowledge Manage-

ment, pages 278–293. Springer.

Steel, E., Berube, Y., Bon

er, J., Britton, K., and Coatta,

T. (2017). Hootsuite: In pursuit of reactive systems.

ACM Queue, 15(3):60.

Stine, M. (2015). Migrating to cloud-native application ar-

chitectures.

Tao, F., LaiLi, Y., Xu, L., and Zhang, L. (2013). Fc-

paco-rm: a parallel method for service composi-

tion optimal-selection in cloud manufacturing sys-

tem. IEEE Transactions on Industrial Informatics,

9(4):2023–2033.

Tran, V., Keung, J., Liu, A., and Fekete, A. (2011). Applica-

tion migration to cloud: a taxonomy of critical factors.

In Proceedings of the 2nd international workshop on

software engineering for cloud computing, pages 22–

28. ACM.

Tsai, W.-T., Sun, X., and Balasooriya, J. (2010). Service-

oriented cloud computing architecture. In Information

Technology: New Generations (ITNG), 2010 Seventh

International Conference on, pages 684–689. IEEE.

Vaquero, L. M., Rodero-Merino, L., and Buyya, R. (2011).

Dynamically scaling applications in the cloud. ACM

SIGCOMM Computer Communication Re, 41(1):45–

52.

Varia, J. (2010). Architecting for the cloud: Best practices.

Amazon Web Services, 1:1–21.

Venugopal, S. (2016). Cloud orchestration technolo-

gies,ibm. https://www.ibm.com/developerworks/

cloud/library/cl-cloud-orchestration-technologies-

trs/index.html.

Villamizar, M., Garc

es, O., Castro, H., Verano, M., Sala-

manca, L., Casallas, R., and Gil, S. (2015). Evaluating

the monolithic and the microservice architecture pat-

tern to deploy web applications in the cloud. In Com-

puting Colombian Conference (10CCC), 2015 10th,

pages 583–590. IEEE.

Wang, X., Zhao, H., and Zhu, J. (1993). Grpc: A communi-

cation cooperation mechanism in distributed systems.

SIGOPS Oper. Syst. Rev., 27(3):75–86.

Weinstock, C. B. and Goodenough, J. B. (2006). On system

scalability. Technical report, CARNEGIE-MELLON

UNIV PITTSBURGH PA SOFTWARE ENGINEER-

ING INST.

Zhang, Q., Cheng, L., and Boutaba, R. (2010). Cloud com-

puting: state-of-the-art and research challenges. Jour-

nal of internet services and applications, 1(1):7–18.

CLOSER 2018 - 8th International Conference on Cloud Computing and Services Science

564
