Patterns in Textual Requirements Speciﬁcation

David

Senk

r and Petr Kroha

Faculty of Information Technology, Czech Technical University in Prague, Th

akurova 9, 160 00 Prague 6, Czech Republic

Keywords:

Textual Requirements Speciﬁcations, Ambiguity, Inconsistency, Incompleteness, Glossary, Text Mining,

Grammatical Inspection.

Abstract:

In this paper, we investigate methods of grammatical inspection to identify patterns in textual requirements

speciﬁcation. Unfortunately, a text in natural language includes additionally many inaccuracies caused by

ambiguity, inconsistency, and incompleteness. Our contribution is that using our patterns, we are able to extract

the information from the text that is necessary to ﬁx some of the problems mentioned above. We present our

implemented tool TEMOS that is able to detect some inaccuracies in a text and to generate fragments of the

UML class model from textual requirements speciﬁcation. We use external on-line resources to complete the

textual information of requirements.

1 INTRODUCTION

Writing requirements speciﬁcations in natural lan-

guage is a common practice in big software houses.

The market research (Luisa et al., 2004) states that ne-

arly 80 % of all requirements speciﬁcations are writ-

ten in natural language. The advantage of using na-

tural language is that it can be interpreted both by the

customer and by the analyst.

This increases quality of requirements that plays

an important role in the whole development process,

because the mistakes in requirements have the most

expensive impacts (Landh

außer et al., 2014).

Formulation of requirements in natural language

is also necessary because of the contract with clients.

The contract is then the primary relevant source,

which can be assessed in the event of a legal case.

Disadvantages of textual requirements are am-

biguity, inconsistency, and incompleteness of the tex-

tual speciﬁcation. Usually, writing requirements is

a cooperative work of several people who are often

distributed in various places. This is a source of in-

accuracies and misleading descriptions. Many words

may have more meanings (ambiguity), text can obtain

contradictions (inconsistency), and speciﬁcations of

some features can be omitted (incompleteness).

A computerized processing of requirements for-

mulated in natural language requires a collaboration

of engineers and experts coming from computational

linguistics. Nowadays, it is possible to choose from

a variety of natural language processing systems. In

our project, we used the system CoreNLP (Manning

et al., 2014) as a component.

The human IT analyst is typically a domain ex-

pert for software construction, but he or she is typi-

cally not focused on the business or organization kno-

wledge of the client. Therefore, his or her interpreta-

tion and understanding of textual requirements should

be confronted with the knowledge of semantics of the

text.

Computerized processing of natural language can

be supported by acquired semantic knowledge from

an appropriate corresponding ontology database. It

may be difﬁcult to obtain the ontology related to the

client’s domain – for many sectors, such ontology is

not available. On the other hand, ontology databases

for common language are available, e.g., WordNET,

ConceptNet, DBPedia, Freebase, OpenCyc.

Our goal was to design and implement such a tool

that assists mapping parts of textual requirements spe-

ciﬁcation to corresponding fragments of static UML

model with respect to possible ambiguity, inconsis-

tency, and incompleteness of the textual speciﬁcation.

Our paper is structured as follows. In Section 2,

we discuss related works. We present the problems

of textual requirements speciﬁcations in Section 3.

Then we brieﬂy explain the method of grammatical

inspection in Sections 4. In Section 5, we discuss

brieﬂy the problems to be solved. Our contribution

is presented in Sections 5.1. Our implementation is

presented in Section 6, the case study is in Section 7.

In Section 8, we conclude.

Šenký

r, D. and Kroha, P.

Patterns in Textual Requirements Speciﬁcation.

DOI: 10.5220/0006827301970204

In Proceedings of the 13th International Conference on Software Technologies (ICSOFT 2018), pages 197-204

ISBN: 978-989-758-320-9

197

2 RELATED WORK

There are many interesting papers proposing that re-

quirements engineering should be supported by tools

based on the linguistic approach.

In paper (Rolland and Proix, 1992), the authors

introduced a tool called OISCI. The mentioned tool

processes French natural language. The approach pre-

sented in the paper targets the creation of the characte-

rization of the parts of the sentence patterns that will

be thereafter matched. OISCI also uses a text gene-

ration technique from the conceptual speciﬁcation to

natural language for the validation purposes.

In paper (Ambriola and Gervasi, 1997), a web-

based system called Circe is presented that primary

processes Italian natural language (but may be also

adapted for other languages). It consists of partial

tools. For our purposes, the most interesting tool is

the main one called Cico. Cico performs recogni-

tion of natural language sentences and prepares inputs

for other tools – graphical representation, metrication,

and analysis. The paper presents the idea that requi-

rements speciﬁcation may be connected with a corre-

sponding glossary describing all the domain-speciﬁc

terms used in the requirements. The glossary also

handles synonyms of terms. Similarly to the previous

paper, Cico uses predeﬁned patterns that are matched

against the sentences from requirements speciﬁcation.

In papers (Kof, 2005) and (Kof, 2004), the NLP

approach is broken down into three groups. The ﬁrst

one is related to lexical methods, the second one build

syntactical methods (part-of-speech tagging), and the

last one is represented by semantic methods, i.e., by

methods that interpret each sentence as a logical for-

mula or looking for predeﬁned patterns.

Linguistic assistant for Domain Analysis (LIDA)

is a tool presented in the paper (Overmyer et al., 2001)

from 2001. According to previous tools, LIDA is con-

ceived as a supportive tool – it can recognize multi-

word phrases, retrieves base form of words (stemming

and lemmatization), presents frequency of words, etc.

– but it doesn’t contain algorithms for automatic re-

cognition of model elements. The decisions about

modeling are fully user-side, i.e., the user marks can-

didates for entities, attributes, and relations (inclusive

operations and roles).

In paper (Arellano et al., 2015), there is presented

tool TextReq based on The Natural Language Tool-

kit (NLTK). This toolkit is an open source platform

for natural language processing in Python. It is an al-

ternative to Stanford CoreNLP that is based on Java.

From the papers mentioned above, the concept pre-

sented in this paper is the closest one to our approach.

There are also papers about generating the dyna-

mic diagrams – e.g., Activity and Sequence Diagram

(Gulia and Choudhury, 2016). A nice survey of pa-

pers on this ﬁeld is given in (Dawood and Sahraoui,

2017).

3 PROBLEMS OF TEXTUAL

REQUIREMENTS

SPECIFICATIONS

The process of textual requirements processing,

which is implemented in our tool TEMOS, is repre-

sented in Fig. 1. The schema also contains the

swim lanes that visualize which parts are computed

by our algorithms (TEMOS swim lanes), and which

part is provided by Standford Core NLP framework

(the middle swim lane). We recall that our tool accep-

ted any free text as the input.

In the ﬁrst phase, the text is perceived as a plain se-

quence of characters. We have to identify some cases

that are not properly handled by Stanford Core NLP

system, e.g., ”his/her interpretation”.

3.1 Nature Language Processing using

Stanford CoreNLP

The text processing part of our tool is based on Stan-

ford CoreNLP (Manning et al., 2014) and on its an-

notators. Annotators are procedures solving the dif-

ferent parts of the linguistic processing and genera-

ting notations that describe the results. The tokeni-

zation annotator parses the input text and provides

lexical analysis. Tokens are used to build sentences

by annotator Words to Sentence Annotator. The an-

notator POS Tagger Annotator provides the part of

speech (POS) annotation (tagging) of every token –

such as noun, verb, adjective, etc. Interpunction and

other special characters are annotated with the same

character that their represent. The Morpha Annotator

generates base forms (lemmas) for every token.

From our point of view, the most interesting anno-

tator is called Dependency Parse Annotator. It analy-

zes the grammatical structure of a sentence and looks

for relationships between words (nominal subject(s)

of verb, dependency object(s) of verb, etc.). Fig. 2

presents the output of the dependencies annotation.

The dependency direction is indicated by an arrow.

Every sentence has one or more root words. These

are the words that have no input dependencies. In Fig.

2, there is one root word – bedroom. We can see that

the word bedroom is connected by a compound de-

pendency to the word hotel. It may indicate that a

hotel bedroom is a multi-word term, similarly like a

ICSOFT 2018 - 13th International Conference on Software Technologies

198

class Text Document Analysis

text

preprocessing

tokenization

sentence

segmentation

part of speech

tagging

lemmatization

dependencies

recognition

coreferencies

recognition

sentence

patterns

recognition

relations

recognition

classes and

attributes

recognition

TEMOS Stanford Core NLP

TEMOS

(& on-line resources)

glossary

construction

questions

generating

raw text

document

Figure 1: The Text Document Analysis.

The rentable space is either a hotel bedroom or a meeting room .

DT JJ NN VBZ CC DT NN NN CC DT NN NN .

cc compoundcompoundamod

det detdet

cc:preconj conj:or

cop punct

nsubj

Page 1 of 1

03.02.2017file:///F:/DP,%20prof.%20Kroha/Diplomová%20práce/untitled.svg

Figure 2: The Result of Dependency Parse Annotator – Enhanced++ Dependencies.

meeting room. The last annotator from Stanford Co-

reNLP that we use is Coref Annotator. Its purpose is

to identify to which words pronouns refer – as shown

in Fig. 3.

David likes blue cars . He is also a fan of busses .

Mention Mention

coref

Figure 3: The Result of Coref Annotator.

4 GRAMMATICAL INSPECTION

The idea of mapping parts of the text document to

UML class diagram components is based on the an-

notations. We use grammatical inspection – prima-

rily based on the dependencies recognition and part

of speech tagging – to identify grammatical roles of

words in textual requirements, i.e., object, subject,

etc. Similarly, as a user can highlight individual

words in the text editor, he/she can also assign an-

notations to individual words or group of words using

the editor included in TEMOS.

TEMOS introduces these annotation types:

• Class Annotation – a basic annotation that can ex-

ist separately.

• Attribute Annotation – the annotation that is asso-

ciated with the owner of the class annotation type.

• Relation Annotation – the annotation that medi-

ates a link between two and more class anno-

tations. Therefore, relation annotation contains

collections of source class annotations and target

class annotations.

Patterns in Textual Requirements Speciﬁcation

199

5 PROBLEMS TO BE SOLVED

Our approach opens a number of new problems that

we discuss in this section.

5.1 Problem of Suitable Patterns

According to (Kof, 2004), our approach of classes

and relations recognition belongs to semantic met-

hods. Similarly to paper (Rolland and Proix, 1992)

presented in Section 2, we adapt the pattern approach.

The pattern-based recognition is based on the idea

that the grammatical role of a word in a sentence cor-

responds with the role of the entity assigned to the

word that the entity plays in the model. The recogni-

tion process iterate through root words. With regard

to the part of speech tag of the current root word, it is

then matched against deﬁned patterns to recognize a

class, an attribute, or a relation. We use the following

notation for the graphic representation of patterns:

• components with a gray background or fore-

ground symbolize unrecognized parts of the pat-

tern

• components with a coloured background or fore-

ground symbolize recognized parts of the pattern,

• the notation 0..* above the word connection link

means, like in the E-R schema, that a target word

with this connection does not have to exists or

such words may exist 1 or more at the same time,

• similarly, the notation 1..* allows more than 1 tar-

get word at the same time, but it also requires at

least 1 such word.

5.1.1 Class/Attribute Sub-Pattern

The most of the following patterns contain this

class/attribute sub-pattern. If there is a pattern indica-

ting that some word may match the class annotation

or attribute annotation, this sub-pattern will be used

to ﬁnd the expanding words of the base word to ﬁnd

the full expression.

NOUN ROOT

NN NN

compound (0..*)

Page 1 of 1

17.12.2017file:///C:/Users/David/Downloads/brat%20(1).svg

Figure 4: The Class/Attribute Sub-Pattern.

On the ground floor, there is a living room.

IN DT NN ,NN EX VBZ DT NN NN .

expl compoundcompound

punct det

nmod:on

det

nsubj

punct

case

Page 1 of 1

17.12.2017file:///C:/Users/David/Downloads/brat%20(4).svg

Figure 5: The Class/Attribute Sub-Pattern Example Mat-

ching.

5.1.2 Class-Specialization Pattern

The class–specialization pattern is deﬁned by these

rules:

1. The root token must be a noun. This root token

will be the class annotation (C

2. There must exist a verb (V ) as a child of depen-

dency of type copula (brieﬂy cop). This verb must

be ”to be” verb.

3. There must exist a noun as a child of dependency

of type nominal subject (brieﬂy nsubj). This noun

will be the class annotation (C

4. If there exist any nouns as children of dependency

of type conjunct (brieﬂy conj), they will be the

class annotations (C

5. The relation annotation is created with the verb V

as a source token and C

as a source class annota-

tion and C

as target class annotations.

Let’s take a look at Fig. 2 again. The word bedroom

as a root token meets this pattern. Therefore, hotel

bedroom and meeting room are the specialization of

space.

The matching of this pattern (Fig. 6) against Fig.

2 is illustrated in Fig. 7.

NOUN NOUN "BE" VERB NOUN ROOT NOUN NOUN

NN NN VB NN NN NN NN

compound (0..*)

conj:or (0..*)

cop

nsubj

Figure 6: The Class Specialization Pattern.

5.1.3 Attribute Pattern #1

The goal of the attribute patterns is to identify attribu-

tes of classes and relations from textual requirements.

If the root token is identiﬁed as a verb, then there are

the following possibilities:

1. The root token must be ”to have” verb, or ”to

identify” verb, or ”to contain” verb.

2. There must exist a noun as a child of dependency

of type nominal subject (brieﬂy nsubj). This noun

will be the class annotation (C

3. There must exist a noun as a child of dependency

of type dependency object (brieﬂy dobj). This

noun will be the attribute annotation (A

4. If there exist any more nouns as children of de-

pendency of type dependency object, they will be

also marked by the attribute annotations (A

The matching of ”to have” version of this pattern

(Fig. 8) is illustrated in Fig. 9.

ICSOFT 2018 - 13th International Conference on Software Technologies

200

The rentable space is either a hotel bedroom or a meeting room.

DT JJ NN VBZ CC DT NN NN CC DT NN NN .

cc compoundcompoundamond

det detdet

cc:preconj conj:or

cop punct

nsubj

Page 1 of 1

17.12.2017file:///C:/Users/David/Downloads/brat%20(6).svg

Figure 7: The Class Specialization Pattern Matching Example.

NOUN NOUN ROOT ("HAVE" VERB) NOUN NOUN

NN NN VB NN NN

compound (0..*)

nsubj

(

0..*

)

Figure 8: The Attribute Pattern #1.

5.1.4 Attribute Pattern #2

The following type of attribute pattern is identiﬁed if

there is a noun that is not associated with any annota-

tion and that meets the following conditions:

1. The token must be a noun. This noun will be the

attribute annotation (A

2. There must exist a noun as a child of dependency

of type nominal modiﬁer of (brieﬂy nmod:of ).

This noun will have the class annotation (C

3. If there exist any nouns as children of dependency

of type conjunction by and (brieﬂy conj:and),

they will also have the attribute annotations

The matching of this pattern (Fig. 11) is illustrated in

Fig. 10.

5.1.5 General Relation Pattern

If no one of the above patterns can be matched, then

the general relation pattern is applied. Its structure

(nominal subject(s)—verb—dependency object(s)) is

shown in Fig. 12.

5.1.6 Adverbial Clause Modiﬁer Pattern

The previous pattern can be extended in the way of

adverbial clause modiﬁer. For example, in the sen-

tence ”Each bank has its own central computer to

maintain its own accounts and process transactions

against them.”, the general relation pattern extracts

information saying that the bank has the central com-

puter, and the adverbial clause modiﬁer pattern also

identiﬁes the purpose of this computer – maintaining

accounts and processing transactions.

5.2 Problem of Glossary

The signiﬁcant part of the textual requirements speci-

ﬁcation analysis is building a glossary of terms. Every

class candidate is automatically introduced as a term

of the glossary. Using the on-line ontology database

ConceptNet

, we present synonyms between terms

and existing classes. The on-line English dictionary

Wordnik

is used to provide a default deﬁnition of the

glossary term.

5.3 Problems of Ambiguity,

Inconsistency, and Incompleteness

The problem of ambiguity is related to our glossary -

see above. Primary, searching for synonyms can iden-

tify the same entity that is presented under different

labels in the text. Secondary, providing a default deﬁ-

nition of every glossary term and asking for the user’s

approval can lead to a better speciﬁcation of ambigu-

ous entities via iterations.

The problem of inconsistency means that requi-

rements speciﬁcation can obtain some contradictions.

Usually, it is not possible to reveal it by using only

tools of text processing. In our previous work (Kroha

et al., 2009), we used ontology modeling and descrip-

tion logic. However, this topic is very complex, and it

is out of the scope of this paper.

The problem of incompleteness means that docu-

ments contain no proper or not complete description

of entities. Similarly, an introduced entity which is

not further used indicates missing information. At the

very moment, our implemented tool uses two features

to check incompleteness. We use transitivity of Eng-

lish verbs for checking incompleteness of the textual

requirements and properties of the generated model

entities to check the incompleteness of the model.

Transitivity of English verbs – relations are chec-

ked in the way of correct usage of the verb. Eng-

lish verbs can take 0, 1, or 2 objects, depending on

the verb. Verbs without objects are called intransi-

tive, and the other ones are called transitive. Using

the dependencies recognition, we check if the verb

has any objects. If no object is found, we check the

verb against the list of intransitive verbs. On the con-

trary, the standalone sentence ”Administrator needs

to maintain.” contains transitive verb need, and the

information is missing about what needs to be main-

tained. Therefore, this sentence is suspicious and TE-

MOS generates warning for the user.

http://www.conceptnet.io

https://www.wordnik.com

Patterns in Textual Requirements Speciﬁcation

201

The rentable space always has a specified rent cost and area (measured in square meters).

DT JJ NN RB VBZ DT VBN NN NN CC NN ( VBN IN JJ NNS )

cccompoundadvmod amondamond

punct

dep

conj:and casensubj amonddet

det punct

dobj

punct

Page 1 of 1

17.12.2017file:///C:/Users/David/Downloads/brat.svg

Figure 9: The Attribute Pattern #1 Matching Example.

We would like to record a serial number and a display size of each television.

PRP MD VB TO VB DT JJ NN CC DT NN NN IN DT NN .

mark ccaux compoundamod det

xcompnsubj det det case

dobjnsubj:xsubj conj:and

nmod:of

dobj

punct

Page 1 of 1

17.12.2017

file:///C:/Users/David/Downloads/brat.svg

Figure 10: The Attribute Pattern #2 Matching Example.

NOUN ROOT NOUN NOUN NOUN NOUN

NN NN NN NN NN NN

compound (0..*) compound (0..*) compound (0..*)

nmod:of

Page 1 of 1

17.12.2017file:///C:/Users/David/Downloads/brat.svg

Figure 11: The Attribute Pattern #2.

NOUN NOUN VERB NOUN NOUN

NN NN VB NN NN

nsubj (1..*)compound (0..*) compound (0..*)

dobj (1..*)

Page 1 of 1

17.12.2017file:///C:/Users/David/Downloads/brat%20(1).svg

Figure 12: The General Relation Pattern.

Checking the model – we try to avoid the incom-

pleteness by checking if a class has at least one at-

tribute, and if it is in at least one relation to another

class. We generate a warning, if it is not the case.

This check is part of the model validation offered by

TEMOS.

We use the detected problems as a source for ge-

nerating warnings and questions for the user (Kroha,

2000). The user’s answer will change the textual

requirements speciﬁcation, and the process makes a

new iteration.

6 IMPLEMENTATION

Based on our approach, we designed and implemen-

ted a prototype of a software tool TEMOS. It is an

acronym formed from Textual Modelling System. We

would like to introduce a full-featured tool, therefore,

in addition to the possibility of highlight parts of the

textual requirements and their mapping to the UML

fragments by the user, TEMOS will provide automa-

tic text processing and automatic fragments mapping.

Due to domain-speciﬁc requirements, TEMOS hand-

les terms in an editable glossary. Based on the pro-

cessed text, TEMOS generates the found models in

various formats that can be used in the next step of

processing (checking the model validity, generation

of code fragments).

TEMOS was designed and implemented as client-

side multithreading application. As a component, it

includes Stanford CoreNLP framework, and therefore

the primary functionality is available without having

the Internet connection. If an Internet connection is

available, TEMOS can use the on-line resources men-

tioned below. The disadvantage of using free on-line

resources may be their limitation on the number of re-

quests. TEMOS-architecture is based on the Model-

View-Controller (MVC) pattern that corresponds to

the client-side JavaFX applications architecture.

7 A CASE STUDY

Building models based on the textual requirement

speciﬁcation is a creative activity. Textual require-

ments are written by experienced analysts in coopera-

tion with stakeholders using a speciﬁc simple structu-

red language in form of well-formed sentences. Dif-

ferent analysts can create different models from the

same requirements based on their experience. There-

fore, testing the quality of generated models by our

TEMOS tools and testing models, in general, is not an

easy task and may be – from a certain point of view

– subjective. In any case, it is out of the scope of this

short paper.

We prepared an example with the following struc-

ture. First, there are original requirements with high-

lighted parts that were recognized by patterns menti-

oned in square brackets. These are followed by the

generated model by TEMOS in the form of the UML

class diagram. This diagram was acquired using En-

terprise Architect after importing the model generated

by TEMOS in the XMI format. The example is also

supplemented with a brief comment on the quality of

the generated model.

The mentioned patterns are indexed by this table.

ICSOFT 2018 - 13th International Conference on Software Technologies

202

1 general relation pattern

2 class/attribute sub-pattern

3 attribute pattern #1

4 attribute pattern #2

5 class-specialization pattern

7.1 Hotel Booking System

This example was created by us, and it mostly con-

tains straightforward deﬁnitions (the structure of the

sentence is in the format: subject–verb–object(s))

which are, of course, the best for automated proces-

sing.

7.1.1 Original Requirements

1. We would like to create a hotel booking system.

[

2. Our business group owns many hotels. [1, 2]

3. Every hotel offers some rentable spaces. [1]

4. The rentable space always has a speciﬁed rent

cost and area (measured in square meters). [2,

5. The rentable space is either a hotel bedroom or a

conference room. [2, 5]

6. The hotel bedroom has a unique room number

and a number of beds. [3]

7. The hotel bedroom may contain a television. [1,

8. We would like to record a serial number and a

display size of each television. [2, 4]

9. Every hotel employs at least one receptionist. [1]

10. A receptionist takes care of reservations from

customers. [1]

11. Every booking has a customer and a selected ren-

table space. [1]

12. The customer is identiﬁed by name, surname,

and address. [3]

13. The reservation contains a start date and an end

date. [2, 3]

14. The booking also has a unique identiﬁer. [3]

15. Every conference room has a name and a maxi-

mum capacity. [2, 3]

16. The meeting room can contain a projection

screen. [2, 3]

7.1.2 The Generated Model

The generated model is in Fig. 13. The appearance

of this class diagram corresponds to the status after

accepting class uniﬁcation tips (booking=reservation

and conference room=meeting room).

7.1.3 Discussion

This example shows the recognition of all three ty-

pes of annotations (the class annotation, the relation

annotation, and the attribute annotation), and it also

shows the case of specialization between the class

space and subclasses hotel bedroom and conference

room.

This result is already very close to the real proces-

sing by the analyst. A human analyst would probably

not designate the name as a separate class – TEMOS

did not consider the name to be an attribute because

it is a shared information between two classes. The

second attribute of the class hotel bedroom should be

labeled as number of beds with respect to the 6th sen-

tence – unfortunately, the current version of Stanford

CoreNLP does not generate the necessary link here.

8 CONCLUSIONS

We designed and implemented the tool TEMOS that

is able to handle the requirements for the software sy-

stem written in plain text. Based on the tests from the

Section 7, TEMOS can be used for generating drafts

of UML class models. These models can be further

modiﬁed or may be exported for further processing

(XMI and ECORE formats) or may be visualized di-

rectly (DOT format).

Except of the suitable patterns, our contribution is

also in using on-line resources to support resolving

ambiguity and incompleteness.

Due to the high computational complexity (prima-

rily due to Stanford CoreNLP analysis), the client-

server architecture might be interesting. This archi-

tecture could also be used to collect data for the im-

provement of the analysis process.

Our further research is oriented on relation bet-

ween syntactic ambiguity, i.e., the kind of ambiguity

that can be resolved by means of computational lin-

guistics (e.g., co-occurring of words, discussing con-

tents of the glossary, etc.) with semantic ambiguity,

i.e., the other kind of ambiguity that can be resolved

only by means of roles of entities in the corresponding

domain and problem models.

Patterns in Textual Requirements Speciﬁcation

203

class Class Diagram of Hotel Booking System

business group

conference room

- m axi m um cap aci ty

- p roje ction screen

customer

- surn am e

- a ddress

hotel

hotel bedroom

- ro om num ber

- bed

name

receptionist

reservation

- sta rt d a te

- e nd d ate

- i d en tifie r

space

- re nt co st

- area

telev ision

- seria l num be r

- di spl a y size

em plo y

ha ve

take care of

ha ve

offe rown

ide nti fy

co n ta in

Figure 13: The Generated Class Diagram of Hotel Booking System.

REFERENCES

Ambriola, V. and Gervasi, V. (1997). Processing natural

language requirements. In Proceedings of the 12th In-

ternational Conference on Automated Software Engi-

neering (Formerly: KBSE), ASE ’97, pages 36–, Wa-

shington, DC, USA. IEEE Computer Society.

Arellano, A., Zontek-Carney, E., and Austin, M. (2015).

Frameworks for natural language processing of textual

requirements. 8:230–240.

Dawood, O. and Sahraoui, A. (2017). From requirements

engineering to uml using natural language processing

survey study. European Journal of Engineering Rese-

arch and Science, 2:44–50.

Gulia, S. and Choudhury, T. (2016). An efﬁcient automa-

ted design to generate uml diagram from natural lan-

guage speciﬁcations. In 2016 6th International Confe-

rence: Cloud System and Big Data Engineering (Con-

ﬂuence), pages 641–648.

Kof, L. (2004). An application of natural language proces-

sing to domain modelling: Two case studies. Inter-

national Journal on Computer Systems Science Engi-

neering, 20:37–52.

Kof, L. (2005). Natural language processing: Mature

enough for requirements documents analysis? In

Natural Language Processing and Information Sys-

tems, pages 91–102, Berlin, Heidelberg. Springer Ber-

lin Heidelberg.

Kroha, P. (2000). Preprocessing of requirements speciﬁca-

tion. In Database and Expert Systems Applications,

pages 675–684, Berlin, Heidelberg. Springer Berlin

Heidelberg.

Kroha, P., Janetzko, R., and Labra, J. E. (2009). Ontologies

in checking for inconsistency of requirements speciﬁ-

cation. Third International Conference on Advances

in Semantic Processing, pages 32–37.

Landh

außer, M., K

orner, S. J., and Tichy, W. F. (2014).

From requirements to uml models and back: How au-

tomatic processing of text can support requirements

engineering. Software Quality Journal, 22(1):121–

149.

Luisa, M., Mariangela, F., and Pierluigi, N. I. (2004). Mar-

ket research for requirements analysis using linguistic

tools. Requirements Engineering, 9(1):40–56.

Manning, C. D., Surdeanu, M., Bauer, J., Finkel, J., Be-

thard, S. J., and McClosky, D. (2014). The Stanford

CoreNLP natural language processing toolkit. In As-

sociation for Computational Linguistics (ACL) System

Demonstrations, pages 55–60.

Overmyer, S. P., Lavoie, B., and Rambow, O. (2001). Con-

ceptual modeling through linguistic analysis using

lida. In Proceedings of the 23rd International Confe-

rence on Software Engineering, ICSE ’01, pages 401–

410, Washington, DC, USA. IEEE Computer Society.

Rolland, C. and Proix, C. (1992). A natural language appro-

ach for requirements engineering. In Advanced Infor-

mation Systems Engineering, pages 257–277, Berlin,

Heidelberg. Springer Berlin Heidelberg.

ICSOFT 2018 - 13th International Conference on Software Technologies

204
