4. Summary
The method of melting ice with CFHW embedded in concrete pavement is effective. It is shown that,
with an input power of 400 W/m
2
and -5°C air temperature, the time of melting 6.5mm ice on
concrete pavement is 5.5 hours when the wind speed is 0.4 m/s. Compared with 0.4 m/s wind speed,
the time of melting ice is 4.5 hours longer than that of 4.0 m/s wind speed. The average 3D-IR
temperature of the pavement surface is close to 0°C for both 0.4 m/s and 4.0 m/s wind speeds when
the ice is melted completely. Compared with 0.4 m/s wind speed, the rise of pavement temperature is
more slowly when the wind speed is 4.0 m/s, and the time of the pavement temperature up to 0°C is
longer. The longitudinal temperature difference decreases with the increase of the depth, but the
decreased rate of the longitudinal temperature difference decreases gradually. Compared with 0.4 m/s
wind speed, the lateral temperature difference of pavement is slightly higher than that of 4.0 m/s
wind speed. The effective distance of the carbon fiber line affecting the lateral temperature
uniformity of the pavement is 10 cm. The wind speed is a very important factor affecting melting ice.
Field wind speed must be taken into account in the design of actual melting ice project.
Acknowledgments
This work was financially supported by Science and Technology Project of CAAC (MHRD201225),
Science and Technology Project of CAAC (MHRD20140107) and Science and Technology Project
of CAAC (20150225).
References
[1] Lee R C, Sackos J T, Nydahl J E and Pell K M, 1984 Bridge heating using ground-source heat
pipes, Transportation Research Record 962 51-56.
[2] Liu X B and Spitler J D, 2004 A simulation tool for the design of the hydronic bridge snow
melting system, Proceedings of the 12th International Road Weather Conference, Bingen
(on Rhine), Germany, June 16-18.
[3] Liu X B, Rees S J and Spitler J D, 2006 Modeling snow melting on heated pavement surfaces
part I: model development, Applied Thermal Engineering, 27 1115-1124.
[4] Xu H N and Tan Y Q, 2015 Modeling and operation strategy of pavement snow melting
systems utilizing low-temperature heating fluids, Energy, 80 666-676.
[5] Tuan C Y and Yehia S, 2004 Evaluation of electrically conductive concrete containing carbon
products for deicing, ACI Materials Journal 101 287-293.
[6] Hou Z F, Li Z Q, Guang K J, 2002 The joule heating analysis of electrically conductive
concrete for roadway deicing system, Seventh International Symposium on Structural
Engineering for Young Exports, Tianjin, China. 977-1001.
[7] Xie P and Beaudoin J J, 1995 Electrically conductive concrete and its application in deicing,
Proceedings of the Second CANMET/ACI International Symposium, Las Vegas, USA, 399-
417.
[8] Lai Y, Liu Y, Ma D X, 2014 Automatically melting snow on airport cement concrete
pavement with carbon fiber grille, Cold Regions Science and Technology 103 57-62.
[9] Zhao H M, Wang S G, Wu Z M and Che G J, 2010 Concrete slab installed with carbon fiber
heating wire for bridge deck deicing, Journal of Transportation Engineering 136 500-509.
[10] Zhao H M, Wu Z M, Wang S G, Zheng J J and Che G J, 2011 Concrete pavement deicing with
carbon fiber heating wires, Cold regions Science and Technology 65 413-420.
