Predicting CyberSecurity Incidents using Machine Learning Algorithms:

A Case Study of Korean SMEs

Alaa Mohasseb

, Benjamin Aziz

, Jeyong Jung

and Julak Lee

School of Computing, University of Portsmouth, U.K.

Institute of Criminal Justice Studies, University of Portsmouth, U.K.

Department of Security Management, Kyonggi University, Suwon, South Korea

Keywords:

Text Mining, Cybersecurity, Malware, Malicious Code, Machine Learning.

Abstract:

The increasing amount and complexity of cyber security attacks in recent years have made text analysis and

data-mining based techniques an important factor in detecting security threats. However, despite the popularity

of text and other data mining techniques, the cyber security community has remained somehow reluctant in

adopting an open approach to security-related data. In this paper, we analyze a dataset that has been collected

from ﬁve Small and Medium companies in South Korea, this dataset represents cyber security incidents and

response actions. We investigate how the data representing different incidents collected from multiple compa-

nies can help improve the classiﬁcation accuracy and help the classiﬁers in distinguishing between different

types of incidents. A model has been developed using text mining methods, such as n-gram, bag-of-words

and machine learning algorithms for the classiﬁcation of incidents and their response actions. Experimental

results have demonstrated good performance of the classiﬁers for the prediction of different types of response

and malware.

1 INTRODUCTION

The use of text analysis and data mining in detecting

vulnerabilities and Cyber security threats is an acti-

vity that has been going on for a number of years

now. The increasing amount and complexity of Cyber

security attacks in recent years have brought data mi-

ning techniques into the attention of researchers and

experts as an important technique in detecting such at-

tacks through the analysis of data and the side-effects

left by malware and spyware programs and the inci-

dents of network and host intrusions.

Text analysis and mining is widely used in many

Cyber security areas, such as malware detection and

classiﬁcation (Suh-Lee et al., 2016; Kakavand et al.,

2015; Norouzi et al., 2016; Fan et al., 2015; Hellal

and Romdhane, 2016; Lu et al., 2010; Fan et al., 2016;

Rieck et al., 2011; Ding et al., 2013) and malicious

code detection (Bahraminikoo et al., 2012; Schultz

et al., 2001; Shabtai et al., 2012).

In addition, the popularity of social media has

opened up the doors for text mining and analysis as

important techniques for increasing the knowledge

about users’ context, e.g. their location and time, and

combining that knowledge with other attributes rela-

ted to important events, topics, emotions and interests

(Inkpen, 2016). Other applications for such techni-

ques have included predicting links (Bartal et al.,

2009) and detecting leaks of conﬁdential data (Ojo-

awo et al., 2014), for example, private health infor-

mation that users may inadvertently share on social

media (Ghazinour et al., 2013). Moreover, text clus-

tering and analysis has also been used extensively in

digital forensics, e.g. as in (Decherchi et al., 2009)

where text clustering was applied to the Enron cor-

pus (Klimt and Yang, 2004), or in (Xylogiannopou-

los et al., 2017), where text mining algorithms were

applied to unclean, noisy or scrambled datasets that

can be obtained from electronic communications such

as SMS communications, or in (Hicks et al., 2016)

where text mining was used for performing Web text

analysis and forensics.

The Cyber security community has remained so-

mehow reluctant in adopting an open approach to

security-related data despite all the popularity of text

and other data mining techniques, due to many fac-

tors such as political factors, for example, the fear

of many organizations to share their data since these

data could reveal sensitive information. Others factors

are more technical, such as the metrics that should be

230

Mohasseb, A., Aziz, B., Jung, J. and Lee, J.

Predicting CyberSecurity Incidents using Machine Learning Algorithms: A Case Study of Korean SMEs.

DOI: 10.5220/0007309302300237

In Proceedings of the 5th International Conference on Information Systems Security and Privacy (ICISSP 2019), pages 230-237

ISBN: 978-989-758-359-9

used to quantify the security data themselves (Hoo,

2000) and he consistency, quality and the lack of con-

sensus on the nature of variables that should be mo-

nitored. Furthermore, There is also the factor that

related to whether past data are relevant to future

events (Parker, 1998). However, with the availability

of large and open security datasets and data-sharing

platforms backed by the reliability and reputation of

well-established organisations in the area of Cyber se-

curity, e.g. VCDB (VERIZON, ), CERT’s Knowledge

base at Carnegie Mellon University (CERT Coordi-

nation Center, ), SecRepo (Mike Sconzo, ), CAIDA

(Center for Applied Internet Data Analysis, ) and ot-

hers, we are starting to witness an increasing trend in

the usage of such datasets in gaining insight into how

incidents occur.

In this paper, we analyse a dataset that has been

collected from ﬁve Small and Medium Enterprises

(SMEs), which represents textual data describing Cy-

ber security incidents that occurred in those compa-

nies and the response actions that were applied. In ad-

dition, we investigate how the data representing diffe-

rent incidents collected from multiple companies can

help improve the classiﬁcation accuracy and help the

classiﬁers in distinguishing between different types

of incidents. This is achieved by focusing on two

sets of questions: the ﬁrst includes forward-looking

predictive questions, such as the prediction of future

responses from the type of malware or the name of

the malicious code encountered in previous incidents,

and the second includes backward-looking questions

that reverse-engineer the type of the malware or the

name of the malicious code from past responses to

incidents. The main objective of our analysis is to

demonstrate how a centralised hub may collect expe-

rience from multiple organisations in order to train a

single classiﬁer that can predict features of future Cy-

ber security incidents.

The rest of the paper is structured as follows.

Section 2, highlights other works in the literature re-

lated to the work presented in this paper. Section

3, outlines the research problem and our approach in

solving it. The experimental setup and results in ap-

plying the classiﬁcation problem to the Cyber security

incidents dataset are presented in section 4. Finally,

Section 5, concludes the paper and outlines some di-

rections for future research.

2 RELATED WORK

In this section we review related works for detecting

and classifying malware and malicious code using

text analysis and data mining methods. Data mining

techniques have many applications related to mal-

ware detection. In (Suh-Lee et al., 2016) authors de-

tect security threats using data mining, text classiﬁ-

cation, natural language processing, and machine le-

arning by extracting relevant information from vari-

ous unstructured log messages. Authors in (Kakavand

et al., 2015) proposed an anomaly detector model cal-

led Text Mining-Based Anomaly Detection (TMAD)

model to detect HTTP attacks in network trafﬁc. The

proposed model uses n-gram text categorization and

(Term Frequency, Inverse Document Frequency) TF-

IDF methods.

Different classiﬁcation methods have been pro-

posed by (Norouzi et al., 2016) in order to detect

malware programs based on the feature and beha-

vior of each malware program. In addition, authors

in (Fan et al., 2015), utilised hooking techniques to

trace the dynamic signatures that malware programs

try to hide, for the classiﬁcation process, machine le-

arning algorithms were used such as Na

ıve Bayesian,

J48 (Decision Tree), and Support Vector Machine.

In (Hellal and Romdhane, 2016) authors propo-

sed an approach that combines static analysis and

graph-mining techniques. In addition, a novel algo-

rithm was proposed, called Minimal Contrast Fre-

quent Subgraph Miner (MCFSM) algorithm, which

is used for extracting minimal discriminative and wi-

dely employed malicious behavioral patterns. Furt-

hermore, authors in (Lu et al., 2010) proposed a

new ensemble learning model, SVM-AR. The pro-

posed model combined features extracted from both

content-based and behavior-based analysis to repre-

sent instances. While in (Rieck et al., 2011) a frame-

work was proposed for the automatic analysis of mal-

ware behavior using machine learning. The frame-

work allows for automatically identifying novel clas-

ses of malware with similar behavior (clustering) and

assigning unknown malware to these discovered clas-

ses (classiﬁcation).

In (Ding et al., 2013), an Application Program-

ming Interface (API)-based association mining met-

hod was proposed for detecting malware. A classi-

ﬁcation method based on multiple association rules

was adopted. Furthermore, data mining-based malici-

ous code detectors have been proven to be successful

in detecting clearly malicious code, e.g. like viruses

and worms. In (Bahraminikoo et al., 2012) a met-

hod was proposed for spyware detection using data

mining techniques. The framework focused on DM-

based malicious code detectors using Breadth-First

Search (BFS) approach, which are known to work

well for detecting viruses and similar software.

In (Schultz et al., 2001) authors proposed a

data-mining framework that detects new, previously

Predicting CyberSecurity Incidents using Machine Learning Algorithms: A Case Study of Korean SMEs

231

unseen malicious executable accurately and automa-

tically. The data-mining framework automatically

found patterns in the data set and used these patterns

to detect a set of new malicious binaries. A Machine

learning algorithms were used such as RIPPER, Na

ıve

Bayes and Multi-Na

ıve Bayes. The authors in (Fan

et al., 2016) proposed a sequence mining algorithm

to discover malicious sequential patterns, based on

the instruction sequences extracted from the ﬁle sam-

ple set, and then a Nearest-Neighbor (ANN) classiﬁer

was constructed for malware detection based on the

discovered patterns. The developed data mining fra-

mework composed of the proposed sequential pattern

mining method and ANN classiﬁer.

Furthermore, authors in (Wang et al., 2006) pro-

posed an integrated architecture to defend against sur-

veillance spyware and used features extracted from

both static and dynamic analysis. These features were

ranked according to their information gains. In ad-

dition, a machine learning algorithm was used. In

(Abou-Assaleh et al., 2004), the authors presented a

method based on byte n-gram analysis to detect mali-

cious code using Common N-Gram analysis (CNG),

which relies on proﬁles for class representation. The

authors in (Shabtai et al., 2012) presented the in-

spected ﬁles using OpCode n-gram patterns, which

are extracted from the ﬁles after disassembly for de-

tecting unknown malicious code. The OpCode n-

gram patterns are used as features for the classiﬁca-

tion process.

Other works used machine learning techniques for

the detection classiﬁcation of malicious code. In (Hou

et al., 2010) authors proposed a malicious web page

detection using of machine learning techniques by

analyzing the characteristic of a malicious Web page.

In addition, authors in (Zhang et al., 2007) proposed

a method to automatically detecting malicious code

using the n-gram analysis. The proposed method used

selected features based on information gain. Finally,

in (Elovici et al., 2007) authors proposed an approach

for detecting malicious code using machine learning

techniques. Three machine learning algorithms were

used which are Decision trees, Neural Networks and

Bayesian Networks in order to determine whether a

suspicious executable ﬁle actually inhabits malicious

code.

3 THE PROPOSED APPROACH

The main scenario motivating our work is one in

which a centralized hub, shown in Figure 1, collects

data generated by multiple companies (organisations)

and therefore maintains a centralized dataset repre-

senting the collective experience of those companies.

The datasets collected from these companies are used

to train one centralized classiﬁer, which would then

have better performance than any individual instance

belonging to a single company.

Figure 1: Experience collection from n number of compa-

nies.

3.1 Description of the Dataset

The dataset represents Cyber security intrusion events

in ﬁve Small and Medium Enterprises (SMEs) over

a period of ten months, which were collected by

the KAITS Industrial Technology Security Hub

South Korea. The Hub is a public-private partners-

hip supported by governmental agencies in order to

support the sharing of knowledge, experience and ex-

pertise across SMEs.

The data for each SME are stored in a separate ﬁle.

There are 4643 entries overall. Each entry, expressed

as a row, has the following metadata:

• Date and Time of Occurrence: this is a value

representing the date and time of the incident’s

occurrence.

• End Device: this is a value representing the name

of the end device affected in the incident.

• Malicious Code: this is a value representing the

name of the malicious code detected in the inci-

dent.

• Response: this is a value representing the re-

sponse action that was applied to the malicious

code.

• Type of Malware: this is a value representing

the type of the malware (malicious code) detected

in the incident.

http://www.kaits.or.kr/index.do

ICISSP 2019 - 5th International Conference on Information Systems Security and Privacy

232

• Detail: this is a free text value to describe any

other detail about the incident.

An example entry from this dataset is shown be-

low:

(14/02/2017 11:58, rc0208-pc,

Gen:Variant.Mikey.57034, deleted, virus,

C:\Users\RC0208\AppData\Local\Temp\is-ANFS3.

tmp\SetupG.exe)

3.2 Research Problems

Our research in this paper is aimed at investigating

two kinds of problems, which we take a classiﬁcation

approach to solving them:

• The ﬁrst problem is forward-looking to attempt to

predict future aspects of Cyber security incidents.

More speciﬁcally, how an organization can gain

the ability to predict response actions to future

Cyber security incidents involving malware. We

consider two questions here: a) how to predict a

response action from the name of malicious code,

and b) how to predict a response action from the

type of malware involved in the incident.

• The second problem is backward-looking to in-

vestigate, for example, as part of a digital foren-

sics process, properties of current incidents. More

speciﬁcally, how an organization can utilize its

knowledge of the response actions in guiding di-

gital forensics analysis to determine the type of

malware or the name of the malicious code to in-

vestigate. We consider here two questions: c) how

to identify the type of the malware based on the

name of malicious code, and d) how to identify the

type of the malware based on the response action.

3.3 Data Anaylsis and Classiﬁcation

Model

In this section, we describe the processes that have

been taken for the analysis and classiﬁcation of the

dataset. A model has been developed using knime

software

, which makes use of the most used features

in text mining such as n-gram, Bag-of-Words, Snow-

ball Stemmer and stop words remover. This model

consists of three main parts (1) Data analysis and Pre-

processing, (2) Features Extraction and (3) Classiﬁca-

tion. The phases of the model are described below:

Phase 1: Data Analysis and Pre-processing: The

main objective of pre-processing is to clean the data

from noise in which this will help to improve the

accuracy of the results by reducing the errors in the

https://www.knime.com/

data. This is done by removing special characters and

stop words such as ”a” and ”the”, punctuation marks

such as question and exclamation marks, and num-

bers. In addition, all terms are converted to lowercase.

The resulting terms are used to generate the n-gram

features.

Phase 2: Features Extraction: Feature extraction

help in the analysis and classiﬁcation and also in im-

proving accuracy. The most commonly used features

in text mining are n-gram and bag-of-words. The mo-

del makes use of ”bigram” which is an n-gram for

n = 2, every two adjacent words create a bigram e.g.

”malware detection”. In this phase, a bag-of-words is

created containing all words (bigram). This bag-of-

words is ﬁltered based on the minimum frequency in

which terms that occur in less than the minimum fre-

quency are ﬁltered out and not used as features using

term frequency (TF) method.

Phase 3: Classiﬁcation: The classiﬁcation phase

is executed using machine learning algorithms such

as Na

ıve Bayes (NB) and Support Vector Machine

(SVM). In this phase, the n-gram features predictive

models are built, tested and compared. The dataset

is split into training and test set. The training dataset

is used for building the model, and the test dataset is

used to evaluate the performance of the model.

4 EXPERIMENTAL STUDY AND

RESULTS

The objective of the experimental study is to explore

the ability of machine learning classiﬁers to distin-

guish between (1) the different types of response ba-

sed on the given malicious code, (2) the different ty-

pes of response based on the given malware, (3) the

different types of malware according to the malicious

code and (4) the different types of malware based on

the different responses. Two machine learning algo-

rithms were used for the classiﬁcation process, which

are Na

ıve Bayes (NB) and Support Vector Machine

(SVM).

We have used the dataset that was selected from

ﬁve different companies provided by the KAITS In-

dustrial Technology Security Hub in South Korea.

The distribution of the data is given in Table 1. As

mentioned in Section 3, all the incidents of the ﬁve

companies were collected by a centralised hub and

the concatenated data were used for the experiment

with the objective of evaluating the performance of

the classiﬁers in distinguishing between different ty-

pes of incidents and investigating how different data

collected from multiple companies can help in impro-

ving the classiﬁcation accuracy.

Predicting CyberSecurity Incidents using Machine Learning Algorithms: A Case Study of Korean SMEs

233

Table 1: Data distribution.

Company Name Total Number of Incidents

Company 1(DF) 932

Company 2(MT) 633

Company 3(SE) 923

Company 4(EP) 448

Company 5(MS) 1707

Total 4643

4.1 Performance Evaluation Metrics

To assess the performance of the machine learning

classiﬁers performance indicators, such as accuracy,

precision, recall, and F-measure (Chinchor, 1992), are

calculated as shown in the following formulæ.

Accuracy =

# of correct predictions (TP+TN)

# of predictions (TP+TN+FP+FN)

Precision =

T P

T P + FP

Recall =

T P

T P + FN

F = 2 ×

Precision × Recall

Precision + Recall

• True Positive (TP): An instance that is positive

and is classiﬁed correctly as positive.

• True Negative (TN): An instance that is negative

and is classiﬁed correctly as negative.

• False Positive (FP): An instance that is negative

but is classiﬁed wrongly as positive.

• False Negative (FN): An instance that is positive

but is classiﬁed wrongly as negative.

4.2 Results

In this section, we present and analyse the results of

the machine learning algorithms for the four different

problems that were proposed.

4.2.1 Problem 1: Identifying the Different Types

of Response based on the Given Malicious

Code

Table 2 presents the classiﬁcation performance details

of the SVM and Na

ıve Bayes classiﬁers in identifying

the different types of response based on the given ma-

licious code. SVM has achieved an accuracy of 81%

while NB achieved an accuracy of 73%. Compa-

ring the performance of both classiﬁers, Both SVM

and NB had a zero precision, recall and f-measure

for response types ”Recovered” and ”Name Chan-

ged”. While both classiﬁers had a 100% precision,

recall, and f-measure for response type ”Blocked”.

For the rest of the types of response, NB could iden-

tify response type ”None” and achieved a recall of

50% while SVM had a zero precision, recall, and f-

measure for this type. In addition, for the response

type ”Segregated” and ”Deleted” SVM has the hig-

hest recall and f-measure while NB has the highest

precision. Furthermore, for the response type ”Not

deﬁned” SVM has the highest precision while NB has

the highest recall and f-measure.

Table 2: Performance of the classiﬁers in identifying the

different types of response based on the malicious code.

SV M NB

Accuracy: 81% 73%

Class: P R F P R F

None 0.00 0.00 0.00 0.11 0.50 0.18

Recovered 0.00 0.00 0.00 0.00 0.00 0.00

Segregated 0.90 0.72 0.80 0.91 0.55 0.68

Deleted 0.61 0.92 0.73 0.64 0.80 0.71

Not deﬁned 1.00 0.84 0.91 0.79 0.89 0.84

Blocked 1.00 1.00 1.00 1.00 1.00 1.00

Name Changed 0.00 0.00 0.00 0.00 0.00 0.00

4.2.2 Problem 2: Identifying the Different Types

of Response based on the Given Malware

Table 3 presents the classiﬁcation performance details

of the SVM and Na

ıve Bayes classiﬁers in identifying

the different types of response based on the given mal-

ware. SVM and NB achieved an accuracy of 73% and

72.8% respectively. Comparing the performance of

both classiﬁers, both classiﬁers failed to identify the

response type ”None, ”Recovered” and ”Name Chan-

ged”. In addition, both classiﬁers had similar preci-

sion, recall, and f-measure for response type ”Segre-

gated and ”Blocked” and nearly similar precision, re-

call and f-measure for response types ”Not deﬁned”

and Deleted”.

Table 3: Performance of the classiﬁers in identifying the

different types of response based on malware.

SV M NB

Accuracy: 73% 72.8%

Class: P R F P R F

None 0.00 0.00 0.00 0.00 0.00 0.00

Recovered 0.00 0.00 0.00 0.00 0.00 0.00

Segregated 0.83 0.13 0.23 0.83 0.13 0.23

Deleted 0.97 0.88 0.92 0.97 0.87 0.92

Not deﬁned 1.00 1.00 1.00 1.00 0.99 0.99

Blocked 0.43 1.00 0.60 0.43 1.00 0.60

Name Changed 0.00 0.00 0.00 0.00 0.00 0.00

ICISSP 2019 - 5th International Conference on Information Systems Security and Privacy

234

4.2.3 Problem 3: Identifying the Different Types

of Malware According to the Malicious

Code

Table 4 presents the classiﬁcation performance details

of the SVM and Na

ıve Bayes classiﬁers in identifying

the different types of malware according to the mali-

cious code. SVM achieved an accuracy of 77% while

NB achieved an accuracy of 70%. Both classiﬁers

could not identify malware type ”Web contents” and

NB achieved very low precision, recall, and f-measure

for malware type ”Downloaded ﬁle”, while SVM fai-

led to identify this type. In addition, SVM has the

highest recall of 100% for malware type ”Email at-

tachment”, while NB has the highest precision and

f-measure. Furthermore, SVM achieved the highest

precision and f-measure for malware type ”Spyware”,

while NB has the highest recall. For the malware type

”Virus”, SVM has the highest recall and f-measure

while NB has the highest precision.

Table 4: Performance of the classiﬁers in identifying the

different types of malware according to the malicious code.

SV M NB

Accuracy: 77% 70%

Class: P R F P R F

Email attachment 0.53 1.00 0.69 0.57 0.89 0.70

Spyware 1.00 0.86 0.92 0.79 0.89 0.84

Virus 0.90 0.75 0.82 0.98 0.54 0.69

Downloaded ﬁle 0.00 0.00 0.00 0.25 0.39 0.30

Web Contents 0.00 0.00 0.00 0.00 0.00 0.00

4.2.4 Problem 4: Identifying the Different Types

of Malware based on the Different

Responses

Table 5 presents the classiﬁcation performance de-

tails of the SVM and Na

ıve Bayes classiﬁers in iden-

tifying the different types of malware based on the

different responses. SVM and NB achieved similar

accuracy of 92%. In addition, SVM and NB failed to

identify malware types ”Downloaded ﬁle” and ”Web

contents”, while both classiﬁers had similar precision,

recall, and f-measure for malware types ”Email atta-

chment, ”Spyware” and ”Virus”.

Table 5: Performance of the classiﬁers in identifying the

different types of malware based on the different responses.

SV M NB

Accuracy: 92% 92%

Class: P R F P R F

Email attachment 0.99 0.88 0.93 0.99 0.88 0.93

Spyware 1.00 1.00 1.00 1.00 1.00 1.00

Virus 0.93 0.89 0.91 0.93 0.89 0.91

Downloaded ﬁle 0.00 0.00 0.00 0.00 0.00 0.00

Web Contents 0.00 0.00 0.00 0.00 0.00 0.00

4.3 Discussion

In this research, many factors have affected the iden-

tiﬁcation and classiﬁcation process using machine le-

arning. We will discuss the overall results below.

The overall results for the identiﬁcation of the dif-

ferent types of responses based on the given malicious

code indicated that SVM was the best classiﬁer, but

NB performed better due to the fact that it could iden-

tify ﬁve different type of the responses while SVM

only identify four types. While, the overall results for

the identiﬁcation of the different types of response ba-

sed on the given malware showed that SVM and NB

had nearly similar accuracy and precision, recall, and

f-measure for most response types in which SVM and

NB could identify four different types of the response.

The poor performance from the classiﬁers was due to

the fact that some types of malware were assigned by

the companies to multiple response types (e.g segre-

gated and name changed are assigned to malware type

virus) and the high and low frequency of some types

affected the classiﬁcation this because of the imba-

lance of the categories.

Furthermore, the overall results for the identiﬁca-

tion of the different types of malware according to the

malicious code indicated that SVM was the best clas-

siﬁer but NB performed better due to the fact that it

could identify ﬁve different type of the malware while

SVM only identify three types. While, the overall

results or the identiﬁcation of the different types of

malware based on the different responses showed that

SVM and NB performed well and had similar preci-

sion, recall, and f-measure for most response types

in which SVM and NB could identify three different

type of malware only.

Following from the discussion above, we observe

the following about the overall results:

(1) The classiﬁcation accuracy was affected by the

imbalance of the (dataset) categories and the

inconsistency of the categories that were used

across the ﬁve companies (e.g type of responses

and malware types) as shown in Tables 6 and 7.

This problem could not be handled due to the fact

that we are trying to solve real case problems and

applying an algorithm to handle class imbalance

will result in altering the given information.

(2) The classiﬁers performance was affected by the

multi-labeling of some of the categories.

(3) Malware types could actually be used for the iden-

tiﬁcation of malicious code even-though from a

security point of view there is no explicit research

showing that this is possible.

(4) Problem 2 was the most difﬁcult problem to pre-

Predicting CyberSecurity Incidents using Machine Learning Algorithms: A Case Study of Korean SMEs

235

Table 6: Type of responses distribution for ﬁve companies shows the imbalance of the data which affect the classiﬁcation

performance of the classiﬁers.

Type of Responses Co1 (DF) Co2 (MT) Co3 (SE) Co4 (EP) Co5 (MS) Total

Blocked 166 89 411 231 5 902

Deleted 39 98 172 91 1153 1553

Name Changed 2 2 10 4 2 20

None 65 3 43 9 4 124

Segregated 153 288 206 61 201 909

Not deﬁned 0 153 81 28 326 588

Recovered 42 0 0 24 10 76

Table 7: Type of malware distribution for ﬁve companies shows the imbalance of the data which affect the classiﬁcation

performance of the classiﬁers

Type of Malware Co1 (DF) Co2 (MT) Co3 (SE) Co4 (EP) Co5 (MS) Total

Email attachment 372 0 117 99 1140 1728

Spyware 93 153 81 27 326 680

Virus 467 480 725 322 87 2081

Downloaded ﬁle 0 0 0 0 149 149

Web Contents 0 0 0 0 5 5

dict in which the classiﬁers’ performance was the

lowest in this case.

(5) SVM is more suitable for the detection of types of

response using the malicious code, the detection

of types of response using malware. In addition

to the detection of malware based on the malici-

ous code. While SVM and NB could be used for

the detection of the types of malware using the

different types of response as their performance

results are similar.

5 CONCLUSION AND FUTURE

WORK

In this paper, a dataset collected from ﬁve SMEs

in South Korea was analysed to demonstrate how a

centralised hub may collect experience from multi-

ple organisations in order to train a single classiﬁer

that can predict features of future Cyber security in-

cidents. Moreover, a model has been developed using

text mining methods. Using machine learning algo-

rithms for the classiﬁcation of these incidents and

their response actions, experimental results showed

good performance of the classiﬁers in predicting dif-

ferent types of response and malware.

As future work, we are planning to test other Cy-

ber security datasets and evaluate the performance of

different machine learning algorithms. In addition,

we aim to investigate how handling class imbalance

can help to improve the classiﬁcation accuracy.

ACKNOWLEDGEMENTS

This work was supported by the University of

Portsmouth Themes Research and Innovation Fund

(TRIF) 2018 - grant number 41611.

REFERENCES

Abou-Assaleh, T., Cercone, N., Keselj, V., and Sweidan,

R. (2004). N-gram-based detection of new malicious

code. In Computer Software and Applications Con-

ference, 2004. COMPSAC 2004. Proceedings of the

28th Annual International, volume 2, pages 41–42.

IEEE.

Bahraminikoo, P., Yeganeh, M., and Babu, G. (2012). Uti-

lization data mining to detect spyware. IOSR Journal

of Computer Engineering (IOSRJCE), 4(3):01–04.

Bartal, A., Sasson, E., and Ravid, G. (2009). Predicting

links in social networks using text mining and sna. In

2009 International Conference on Advances in Social

Network Analysis and Mining, pages 131–136.

Center for Applied Internet Data Analysis. CAIDA Data.

Last accessed: 05.01.2017.

CERT Coordination Center. CERT Knowledgebase. Last

accessed: 14.01.2017.

Chinchor, N. (1992). Muc-4 evaluation metrics. In Pro-

ceedings of the 4th Conference on Message Under-

standing, MUC4 ’92, pages 22–29, Stroudsburg, PA,

USA. Association for Computational Linguistics.

Decherchi, S., Tacconi, S., Redi, J., Leoncini, A., Sangia-

como, F., and Zunino, R. (2009). Text clustering for

digital forensics analysis. In Herrero,

A., Gastaldo,

P., Zunino, R., and Corchado, E., editors, Computati-

onal Intelligence in Security for Information Systems,

pages 29–36, Berlin, Heidelberg. Springer Berlin Hei-

delberg.

ICISSP 2019 - 5th International Conference on Information Systems Security and Privacy

236

Ding, Y., Yuan, X., Tang, K., Xiao, X., and Zhang, Y.

(2013). A fast malware detection algorithm based on

objective-oriented association mining. computers &

security, 39:315–324.

Elovici, Y., Shabtai, A., Moskovitch, R., Tahan, G., and

Glezer, C. (2007). Applying machine learning techni-

ques for detection of malicious code in network trafﬁc.

In Annual Conference on Artiﬁcial Intelligence, pages

44–50. Springer.

Fan, C.-I., Hsiao, H.-W., Chou, C.-H., and Tseng, Y.-F.

(2015). Malware detection systems based on api log

data mining. In Computer Software and Applicati-

ons Conference (COMPSAC), 2015 IEEE 39th An-

nual, volume 3, pages 255–260. IEEE.

Fan, Y., Ye, Y., and Chen, L. (2016). Malicious sequen-

tial pattern mining for automatic malware detection.

Expert Systems with Applications, 52:16–25.

Ghazinour, K., Sokolova, M., and Matwin, S. (2013). De-

tecting health-related privacy leaks in social networks

using text mining tools. In Za

ıane, O. R. and Zilles, S.,

editors, Advances in Artiﬁcial Intelligence, pages 25–

39, Berlin, Heidelberg. Springer Berlin Heidelberg.

Hellal, A. and Romdhane, L. B. (2016). Minimal contrast

frequent pattern mining for malware detection. Com-

puters & Security, 62:19–32.

Hicks, C., Beebe, N., and Haliscak, B. (2016). Extending

web mining to digital forensics text mining. In AMCIS

2016: Surﬁng the IT Innovation Wave - 22nd Ameri-

cas Conference on Information Systems. Association

for Information Systems.

Hoo, K. J. S. (2000). How Much is Enough? A Risk-

Management Approach to Computer Security.

Hou, Y.-T., Chang, Y., Chen, T., Laih, C.-S., and Chen,

C.-M. (2010). Malicious web content detection by

machine learning. Expert Systems with Applications,

37(1):55–60.

Inkpen, D. (2016). Text Mining in Social Media for Secu-

rity Threats, pages 491–517. Springer International

Publishing, Cham.

Kakavand, M., Mustapha, N., Mustapha, A., and Abdullah,

M. T. (2015). A text mining-based anomaly detection

model in network security. Global Journal of Compu-

ter Science and Technology.

Klimt, B. and Yang, Y. (2004). The enron corpus: A new

dataset for email classiﬁcation research. In Boulicaut,

J.-F., Esposito, F., Giannotti, F., and Pedreschi, D.,

editors, Machine Learning: ECML 2004, pages 217–

226, Berlin, Heidelberg. Springer Berlin Heidelberg.

Lu, Y.-B., Din, S.-C., Zheng, C.-F., and Gao, B.-J. (2010).

Using multi-feature and classiﬁer ensembles to im-

prove malware detection. Journal of CCIT, 39(2):57–

72.

Mike Sconzo. SecRepo.com - Samples of Security Related

Data. Last accessed: 05.01.2017.

Norouzi, M., Souri, A., and Samad Zamini, M. (2016).

A data mining classiﬁcation approach for behavioral

malware detection. Journal of Computer Networks

and Communications, 2016:1.

Ojoawo, A. O., Fagbolu, O. O., Olaniyan, A. S., and So-

nubi, T. A. (2014). Data leak protection using text

mining and social network analysis. International

Journal of Engineering Research and Development,

10(12):14 – 22.

Parker, D. B. (1998). Fighting Computer Crime: A New

Framework for Protecting Information. John Wiley &

Sons, Inc., New York, NY, USA.

Rieck, K., Trinius, P., Willems, C., and Holz, T. (2011). Au-

tomatic analysis of malware behavior using machine

learning. Journal of Computer Security, 19(4):639–

668.

Schultz, M. G., Eskin, E., Zadok, F., and Stolfo, S. J. (2001).

Data mining methods for detection of new malici-

ous executables. In Security and Privacy, 2001. S&P

2001. Proceedings. 2001 IEEE Symposium on, pages

38–49. IEEE.

Shabtai, A., Moskovitch, R., Feher, C., Dolev, S., and Elo-

vici, Y. (2012). Detecting unknown malicious code by

applying classiﬁcation techniques on opcode patterns.

Security Informatics, 1(1):1.

Suh-Lee, C., Jo, J.-Y., and Kim, Y. (2016). Text mining for

security threat detection discovering hidden informa-

tion in unstructured log messages. In Communications

and Network Security (CNS), 2016 IEEE Conference

on, pages 252–260. IEEE.

VERIZON. VERIS Community Database. Last accessed:

21.11.2016.

Wang, T.-Y., Horng, S.-J., Su, M.-Y., Wu, C.-H., Wang, P.-

C., and Su, W.-Z. (2006). A surveillance spyware de-

tection system based on data mining methods. In Evo-

lutionary Computation, 2006. CEC 2006. IEEE Con-

gress on, pages 3236–3241. IEEE.

Xylogiannopoulos, K., Karampelas, P., and Alhajj, R.

(2017). Text mining in unclean, noisy or scrambled

datasets for digital forensics analytics. In 2017 Eu-

ropean Intelligence and Security Informatics Confe-

rence (EISIC), pages 76–83.

Zhang, B., Yin, J., Hao, J., Zhang, D., and Wang, S. (2007).

Malicious codes detection based on ensemble lear-

ning. In International Conference on Autonomic and

Trusted Computing, pages 468–477. Springer.

Predicting CyberSecurity Incidents using Machine Learning Algorithms: A Case Study of Korean SMEs

237
