Template based Human Pose and Shape Estimation from a Single

RGB-D Image

Zhongguo Li, Anders Heyden and Magnus Oskarsson

Centre for Mathematical Sciences, Lund University, Sweden

Keywords:

Human Body Reconstruction, SMPL Model, 2D and 3D Pose, Pose and Shape Estimation.

Abstract:

Estimating the 3D model of the human body is needed for many applications. However, this is a challenging

problem since the human body inherently has a high complexity due to self-occlusions and articulation. We

present a method to reconstruct the 3D human body model from a single RGB-D image. 2D joint points

are ﬁrstly predicted by a CNN-based model called convolutional pose machine, and the 3D joint points are

calculated using the depth image. Then, we propose to utilize both 2D and 3D joint points, which provide more

information, to ﬁt a parametric body model (SMPL). This is implemented through minimizing an objective

function, which measures the difference of the joint points between the observed model and the parametric

model. The pose and shape parameters of the body are obtained through optimization and the ﬁnal 3D model

is estimated. The experiments on synthetic data and real data demonstrate that our method can estimate the

3D human body model correctly.

1 INTRODUCTION

Human body reconstruction is needed in many appli-

cations such as virtual and augmented reality, video

games and medical research. Various approaches

have been proposed to obtain 3D models of human

bodies during past decades. However, it is still a chal-

lenging problem from using one single image since

human body may have high complexity such artic-

ulation, self-occlusion, clothing and so on. Com-

mercial laser scanning system can acquire 3D mod-

els with high accuracy. But it is not acceptable for

ordinary consumers because of high cost and cum-

bersome equipment. Some other methods based on

RGB-D image sequences are also popular to build the

3D model (Izadi et al., 2011; Innmann et al., 2016;

Newcombe et al., 2015; Slavcheva et al., 2017). They

often requires the object to be static and rigid during

acquiring the image sequence, which is not appropri-

ate for a moving person.

It is possible now to create 3D human body mod-

els through combining human pose estimation and

some parametric models, especially with the imple-

mentation of deep neural network to 2D- (Xu et al.,

2017) and 3D- (Mehta et al., 2017) human pose es-

timation. These methods (Bogo et al., 2015; Huang

et al., 2017; Kanazawa et al., 2018) utilize a paramet-

ric body model to ﬁt 2D or 3D human pose which

can be well estimated by deep neural networks. They

are more efﬁcient and convenient because they do not

need to use expensive devices and too much images

with different views. This makes it possible to recon-

struct 3D human body through only one image. The

key step of these methods is to construct an objective

function to measure the difference between the para-

metric model and the person in the image. In many

cases only 2D pose is utilized to construct the objec-

tive function, which can not fully represent the joints

points of the human body in 3D space. Currently,

many methods based on deep neural networks have

been proposed to estimate 3D human pose, but are

not in general as accurate as 2D pose estimation.

In this paper we propose to use both 2D human

pose which is estimated by deep neural network and

3D human pose which is calculated from a depth im-

age to construct objective function. The 3D human

body models based on the skinned multi-person lin-

ear model (SMPL)(Loper and Black, 2014) are then

estimated by optimizing the objective function. This

parametric model gives means to better to describe

the pose and shape of the human body. More specif-

ically, the 2D human pose is estimated by Convolu-

tional Pose Machines (CPM) (Wei et al., 2016) which

predicts the 2D joint points by stacking convolutional

neural networks. For the 3D pose, we use a Kinect

sensor to acquire RGB-D images and the depth im-

574

Li, Z., Heyden, A. and Oskarsson, M.

Template based Human Pose and Shape Estimation from a Single RGB-D Image.

DOI: 10.5220/0007383605740581

In Proceedings of the 8th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2019), pages 574-581

ISBN: 978-989-758-351-3

Figure 1: The original image and the corresponding 3D

model from different view reconstructed by our method.

age provides depth information which can be used

for the computation of the corresponding 3D joint

points. Then, an objective function considering the

difference between the estimated pose and the pose

of the SMPL model is deﬁned. Through minimizing

the objective function, pose and shape parameters of

the SMPL model are estimated, which creates a 3D

human body model with certain accuracy. We com-

pare our method with an existing method which only

considers 2D pose to reconstruct the 3D human body

model and the experiments quantitatively and quali-

tatively show that our method has better performance

both on the accuracy of pose parameters and 3D ver-

tices.

In summary the contribution of our method is that

we use both 2D and 3D pose information based on the

SMPL human body model to estimate the 3D model

from a single RGB-D image.

2 RELATED WORK

Non-parametric model based methods often recon-

struct 3D scenes directly from images acquired by a

camera or depth sensor from multiple views. Regis-

tration is an important step for these methods, which

has been solved well for rigid transformations. How-

ever, the human body is inherently non-rigid and it is

a great challenge for non rigid registration. KinectFu-

sion (Izadi et al., 2011) is a well-known algorithm to

create 3D models in real time by incrementally merg-

ing the partial scans from a moving RGB-D sensor.

Inspired by this research, a number of methods (Ari

et al., 2014; Cui et al., 2012) have been proposed to

reconstruct 3D human body models for static persons.

However, they are not ideal approaches for the recon-

struction of the dynamic human body due to its com-

plex pose and the non-rigidity of the human body. In

order to tackle the non rigid problem, DynamicFu-

sion (Newcombe et al., 2015) is the pioneering work

and can reconstruct scene geometry in real time for

a slowly moving person. Some other methods such

as VolumeDeform (Innmann et al., 2016), Killing-

Fusion (Slavcheva et al., 2017) and BodyFusion (Yu

et al., 2017) have been proposed to improve the re-

sults based on the DynamicFusion. However, these

approaches only show good performance when the

motion of the human body is slow and only half of

the body is reconstructed. For more complex condi-

tions, researchers try to use multiple Kinect sensors

or several calibrated cameras to create the 3D human

body models, which can acquire accurate 3D mod-

els. In (Dou et al., 2016), the authors propose to

use eight Kinects to create accurate 3D models for

dynamic scenes. Multiple cameras are also used in

(Leroy et al., 2017) used to obtain the 3D shape of

the human body with complex actions. Although it

yields more accurate 3D human body models by us-

ing multiple devices, it is inconvenient and expensive

to require such an environment.

Parametric model-based methods reconstruct 3D

body models through using a template which always

encodes the pose and shape parameters to ﬁt the ob-

served images. Some methods ﬁrstly scan a model

as the template, and then insert a skeleton into the

template and use the template to ﬁt other dynamic

data. In (Guo et al., 2015; Li et al., 2009) the au-

thors propose novel nonrigid registration algorithms

and they implement the algorithms to register the pre-

scanned models to the partial scans of Kinect. (Zhang

et al., 2014) utilize KinectFusion to get the template

of the human body before ﬁtting the input data. Some

other algorithms based on this pipeline are also pre-

sented in (Xu et al., 2017; Zollhofer et al., 2014).

However, prescanning a templete depends on the al-

gorithm of reconstructing algorithm for rigid objects.

In order to better represent the human body, a number

of statistic human body models based on training on

thousands of individuals have been developed, such as

SCAPE (Anguelov et al., 2005), SMPL (Loper et al.,

2015) and so on (Pons-Moll et al., 2015). The SCAPE

model is used in (Weiss et al., 2011) to ﬁt the depth

image acquired by Kinect. Authors in (Bogo et al.,

2015) propose a detailed body reconstruction method

using an improved SCAPE model called Delta. There

are also many methods in which the SMPL model is

used. In (Bogo et al., 2014), the authors propose to

use a CNN model to extract 2D joint points and used

the information to ﬁt a parametric model. Huang et al

(Huang et al., 2017) use a similar idea but they extend

it to multiple view problems. In (Kanazawa et al.,

2018) an end-to-end adversarial learning method is

used to estimate the human pose and shape by ﬁtting

a parametric model. Alldieck et al (Alldieck et al.,

2018) propose to get the 3D human body model from

video based on the SMPL model using pose informa-

tion and transforming silhouettes to visual hull. In this

paper we also use a template based method to recon-

struct the 3D body model.

Template based Human Pose and Shape Estimation from a Single RGB-D Image

575

Figure 2: The overview of our method.

3 METHOD

The overview of our method is shown in Figure 2.

We ﬁrstly use an RGB-D camera with known intrin-

sic parameters to capture an RGB image and a depth

image. The skeleton is estimated by CPM, which de-

signs a sequential architecture composed of convolu-

tional networks to predict the 2D human pose. The

corresponding 3D pose can be computed through the

depth image and the intrinsic parameters of the cam-

era using

X(i, j, z) =



(i − c

( j − c

, z



, (1)

where i, j are the coordinates of 2D joint points in the

image plane, z is the corresponding depth for the point

(i, j) and f

, f

, c

are focal lengths and the optical

center of the camera. Then, using 2D and 3D pose si-

multaneously, we build an objective function to mea-

sure the difference between the SMPL model and the

observed person. Finally, the pose and shape param-

eters of the SMPL model can be estimated through

minimizing the objective function.

3.1 The SMPL Model

As stated in (Loper et al., 2015), the SMPL model

is a state-of-the-art human model for representing the

pose and shape of a human body model. The model

is a triangulated mesh with N = 6980 vertices and

is deﬁned as a function of shape and pose param-

eters. The shape parameters are represented as β

and they are the coefﬁcients of a linear shape space

which is learned from a dataset containing thousands

of registered scans. The pose parameters θ are de-

ﬁned as the joint angle rotations. There are 24 joint

points which contain 1 parent point and the pose of

each joints is represented as vector in R

encoding

the relative rotation with respect to its parent in the

kinematic tree. Therefore, the pose parameters have

23 × 3 + 3 = 72 elements. One of the advantages of

SMPL model is that the position of skeleton joints is

also deﬁned as a function of the shape parameters,

J(β). Then, the global coordinates of the joint points

which are represented as R

(J(β)) can be calculated

by considering the pose parameters θ. Using a per-

spective camera model, the joint points of the SMPL

model in global coordinates can be projected to the

image plane, which converts 3D joint points to 2D

joint points in the image. Here we have to note that

the order of the joint points in SMPL model is differ-

ent with the 2D human pose estimated by CPM.

3.2 Objective Function

In this part we will give the deﬁnition of the objective

function. In (Bogo et al., 2014), the objective func-

tion only takes 2D pose as prior knowledge. Although

some methods (Xu et al., 2017) also consider 3D pose

as the prior information, the data term in (Xu et al.,

2017) is deﬁned as an L

-distance function, which is

not stable and robust enough. The objective function

in our method will combine both 2D and 3D pose to

deﬁne the errors between joint points of the SMPL

model and the joint points estimated by the CPM. The

new data term can better represent the position of the

joint points, especially when the human body has oc-

clusions. Our experiments will demonstrate the per-

formance of the method. The error function is deﬁned

by the Geman-McClure penalty function ρ (Geman

and McClure, 1987) so that it can deal with the noisy

estimates (Bogo et al., 2014; Bogo et al., 2015; Huang

et al., 2017; Weiss et al., 2011). The Geman-McClure

function is deﬁned as

+ e

, (2)

where e is the error which is deﬁned by 2D and 3D

poses and σ is a constant (set to 100 in our experi-

ICPRAM 2019 - 8th International Conference on Pattern Recognition Applications and Methods

576

ments). In addition, regularization terms are also de-

ﬁned according to the prior information provided by

the SMPL model to make the results more stable and

natural. This gives the complete objective function in

our method as

E(β, θ) =E

(β, λ)+

(θ) + λ

(β),

(3)

where E

(β, λ) is the data term combining 2D and 3D

pose, E

(θ) and E

(θ) are two pose penalty functions

and E

(β) is the shape prior function. λ

, λ

and λ

are the weights for the pose and shape prior function.

The data term in our method is built based on

(Bogo et al., 2014). The difference of our method is

that we consider the 3D information in the data term.

The function is deﬁned as

(β, λ) =

∑

joints

ρ(Π(R

(J(β))) − J

∑

joints

ρ(R

(J(β)) − J

(4)

where Π(R

(J(β))) denotes the projection of 3D joint

points of the SMPL model by the camera Π. λ

the weight of the data term using 3D pose and it will

help to improve the robustness of the whole method.

The distance between the two joint points is measured

by a Geman-McClure penalty function. This new data

term, taking into account 3D pose, provides more spa-

tial information of joint points, which is useful when

some body parts are occluded by other objects or the

torso.

The regularization term is there to keep the pose

and shape of the human body natural and probable.

As shown in (Loper et al., 2015), SMPL is a statis-

tical human body model which is learned from large

datasets and it can provide strong prior information.

We use some of the pose and shape penalty functions

in (Bogo et al., 2014) in our method. For the pose reg-

ularization, the ﬁrst part is to keep elbow and knees

bending naturally and is deﬁned as

(θ) =

∑

exp(θ

), (5)

where θ

is the pose of the i-th joint. The second part

for the pose penalty is deﬁned as

(θ) = min



−log(cg

N (θ; µ

θ, j

, Σ

θ, j

)



, (6)

where N is a mixture of Gaussians function, g

the weight and c is a positive constant. The Gaussian

function is ﬁt to approximately 1 million poses which

are obtained by ﬁtting SMPL to the CMU marker data

using MoSh (Loper et al., 2014). There are more de-

tails in (Bogo et al., 2014). For the shape regulariza-

tion part, because the shape parameters of the SMPL

model are obtained by training a dataset, the shape

penalty function is also deﬁned based on this

(β) = β

−1

β, (7)

where Σ

−1

is a diagonal matrix and the elements on

the diagonal are the squared singular values. These

values can be estimated by Principal Component

Analysis from the SMPL training shape set.

3.3 Optimization

The optimization has two steps. The ﬁrst step is to

estimate the camera translation. Here the focal length

of the camera is known. The camera translation can

be estimated through similar triangles deﬁned by the

torso length of SMPL and the predicted 2D pose.

The second stage is to ﬁt the model through min-

imizing Eq. (3). The parameters for λ

and λ

will

decrease gradually during the optimization. Because

the human body may either be facing the camera or

not, we can ﬁrstly try an initialization and then rotate

by 180 degrees. And we choose the one with smaller

errors.

The procedure of minimization is implemented

through Powells dogleg method which is provided by

the python module OpenDR (Loper and Black, 2014)

and Chumpy. For a single image with size 240×320,

it takes about 3 minutes for the minimization on a

desktop machine.

4 EXPERIMENTS

Our method is qualitatively and quantitatively tested

on the synthetic dataset SURREAL (Varol et al.,

2017), the real dataset Human3.6M (Ionescu et al.,

2014) and some data acquired by Kinect. We com-

pare our method with SMPLify (Bogo et al., 2014)

which only used 2D joints to construct the data term.

The setting of the parameters in our experiments

were λ

= 100, λ

= 10. The optimization has

four stages and in each stage the maximum itera-

tion is 20. The weights λ

and λ

for each stage

are (404, 404, 57.4, 4.78) and (100, 50, 5, 1). For the

Geman-McClure penalty function, the parameter σ =

100.

4.1 Results on SURREAL

SURREAL is a synthetic dataset containing more

than 40,000 videos in which the human body mod-

els are generated based on the SMPL model. Each

video consists of 100 frames and the person in the

Template based Human Pose and Shape Estimation from a Single RGB-D Image

577

Figure 3: The results of some samples from the video in

SURREAL. The ﬁrst column is the sample from the video.

The second column is the ground truth. The third column is

the result of SMPLify. The last column is the result of our

method.

Figure 4: The error of the video in Figure 3. The left is the

error of 3D vertexes between the results from our method

and SMPLify and the ground truth.The right is the error of

pose parameters between the results from our method and

SMPLify and the ground truth.

video has different actions and backgrounds. Espe-

cially, the ground truth of the pose and shape pa-

rameters of the person in this dataset are known and

the 3D mesh of the person can be generated by us-

ing these parameters. Because the number of videos

in the dataset is too large, we only use two of them

to do the experiments. Figure 3 and 5 are qualita-

Figure 5: The results of some samples from the video in

SURREAL. The ﬁrst column is the sample from the video.

The second column is the ground truth. The third column is

the result of SMPLify. The last column is the result of our

method.

Figure 6: The error of the video in Figure 5. The top is the

error of 3D vertices between the results from our method

and SMPLify and the ground truth.The bottom is the error

of pose parameters between the results from our method and

SMPLify and the ground truth.

tive results of the experiments. In the ﬁrst column

of Figure 3 and 5, three frames of the two examples

are shown. The corresponding ground truth of the

3D mesh are given in the second column. The re-

sults of SMPLify and our method are shown in the

third and fourth columns of Figure 3 and 5. The er-

rors of the pose parameters and 3D vertices between

ICPRAM 2019 - 8th International Conference on Pattern Recognition Applications and Methods

578

(a) Direction (b) Phoning

Figure 7: The 3D model by our method from Human3.6M. For each subﬁgure the 2D and 3D joint points and 3D model from

different views are given. There are 4 actions: (a) Direction; (b) Phoning; (c) Sitting; and (d) Greeting.

Figure 8: The 3D model of images acquired by ourselves estimated by our method. From left to right: the image with 2D

joint points estimated by CPM, 3D joint points and 3D model from different view.

the ground truth and the estimated results are shown

in Figure 4 and 6, which is the quantitative results.

We can see from the two ﬁgures that the errors of

our method are smaller than SMPLify in general. In

addition, our method is more robust because the er-

rors of each frame in the two videos are more stable

when the 3D pose is used. Moreover, as shown in Fig-

ure 5, the results of SMPLify are obviously incorrect

because the human body bends to another direction.

This demonstrates that using only 2D pose can not

provide enough space information for the algorithm.

By contrast, our method can avoid this problem and

obtain more accurate results because the 3D joints can

provide more space information.

Template based Human Pose and Shape Estimation from a Single RGB-D Image

579

4.2 Results of Human3.6M

Human3.6M is a dataset containing 3.6 million 3D

human poses and corresponding images. The whole

dataset is obtained from four calibrated cameras

which ensures the accuracy of the 3D joint positions.

There are 11 subjects ( 6 males, 5 females ) in the

dataset and each of them perform 15 different actions.

In this experiment we only give the qualitative results

using some images from the ﬁrst subject (Direction,

Phoning, Sitting and Greeting) to test our method,

since the dataset does not have the ground truth of

pose parameters and 3D mesh. Figure 7 shows the

reconstructed 3D models of subject 1 with different

actions by our method.

We can see from Figure 7 that the 3D models es-

timated by our method for different actions roughly

have the same pose as the person in the original im-

ages. These images are taken from the back of the

person and some body parts are in the front of the

torso. For example, the arms of the person in Figure

7 (a) and (c) are occluded by the torso, which makes

it hard to to estimate the 3D model only using 2D in-

formation. Because the 3D joint points provide the

spatial information, our method can roughly estimate

the position of the arms. However, it also shows that

the shape of the body is not perfect for the person in

the original image. This is because the 2D and 3D

joint points have stronger prior information for the

pose but these cues do not provide enough shape in-

formation. We should also note that the pose of the

hands in the 3D body model is not estimated well be-

cause our method does not consider the hand pose.

4.3 Results from our Own Data

Here we show results on RGB-D images acquired by

Kinect. The person stands in front of the camera and

has different poses. The intrinsic parameters of the

camera used are f

= 262.5, f

= 262.5, c

= 159.75,

and c

= 119.75. The 2D points are detected through

the CPM model and the corresponding 3D joints are

computed by considering the depth image using the

intrinsic parameters.

Fitting results for the images are shown in Figure

8. The 2D joint points predicted by CPM are roughly

correct from the ﬁrst column in Figure 8. The 3D

pose is computed based on the 2D pose and depth im-

age and are also shown in the second column in Fig-

ure 8. The 3D model observed from several different

views is also shown from the third to sixth columns

in Figure 8. The 3D shape models are recovered from

one single RGB-D image. Although only one image

is used, the 3D model obtained by our method looks

quite close to the action of the person in the original

image.

5 CONCLUSIONS

We have presented a template-based 3D human body

reconstruction method using a single RGB-D images.

Our method considers both 2D joint points which can

be estimated by a CNN-based model and 3D joint

points which can be computed by the depth image.

Then, these joint points are used simultaneously to

ﬁt a parametric human body model, SMPL. The pose

and shape parameters can be estimated through mini-

mizing the distance of joint points between observed

images and the SMPL model. We test our method

on the data taken by ourselves and the Human3.6M

dataset. The results demonstrate that our method can

estimate the 3D mesh of the observed images well.

In future work, more shape information should be

considered to add to the objective function so that the

ﬁnal 3D model has good shape appearance. In addi-

tion, it is also possible to improve the accuracy of the

reconstruction by using more images from different

views.

ACKNOWLEDGEMENTS

This work was partially supported by the strategic re-

search projects ELLIIT, eSSENCE, the Sten K. John-

son foundation and the China Scholarship Council

(CSC).

REFERENCES

Alldieck, T., Magnor, M., Xu, W., Theobalt, C., and Pons-

Moll, G. (2018). Video based reconstruction of 3d

people models. In arXiv preprint arXiv:1803.04758.

Anguelov, D., Srinivasan, P., Koller, D., Thrun, S., Rodgers,

J., and Davis, J. (2005). Scape: Shape completion and

animation of people. ACM Trans. Graph., 24(3):408–

416.

Ari, S., Andrew, F., Ruizhe, W., Hao, L., Mark, B., Gerard,

M., and Evan, S. (2014). Rapid avatar capture and

simulation using commodity depth sensors. Computer

Animation and Virtual Worlds, 25(3-4):201–211.

Bogo, F., Black, M. J., Loper, M., and Romero, J. (2015).

Detailed full-body reconstructions of moving people

from monocular rgb-d sequences. In ICCV, pages

2300–2308.

Bogo, F., Kanazawa, A., Lassner, C., Gehler, P. V., Romero,

J., and Black, M. J. (2014). Keep it SMPL: automatic

estimation of 3d human pose and shape from a single

image. In ECCV.

ICPRAM 2019 - 8th International Conference on Pattern Recognition Applications and Methods

580

Cui, Y., Chang, W., N

oll, T., and Stricker, D. (2012). Kinec-

tavatar: Fully automatic body capture using a single

kinect. In Computer Vision - ACCV 2012 Workshops,

pages 133–147, Berlin, Heidelberg. Springer Berlin

Heidelberg.

Dou, M., Khamis, S., Degtyarev, Y., Davidson, P., Fanello,

S. R., Kowdle, A., Escolano, S. O., Rhemann, C.,

Kim, D., Taylor, J., Kohli, P., Tankovich, V., and

Izadi, S. (2016). Fusion4d: Real-time performance

capture of challenging scenes. ACM Trans. Graph.,

35(4):114:1–114:13.

Geman, S. and McClure, D. (1987). Statistical methods

for tomographic image reconstruction. Bulletin of the

International Statistical Institute, 52:5–21.

Guo, K., Xu, F., Wang, Y., Liu, Y., and Dai, Q. (2015). Ro-

bust non-rigid motion tracking and surface reconstruc-

tion using l0 regularization. In ICCV, pages 3083–

3091.

Huang, Y., Bogo, F., Lassner, C., Kanazawa, A., Gehler,

P. V., Romero, J., Akhter, I., and Black, M. J. (2017).

Towards accurate marker-less human shape and pose

estimation over time. In 3DV.

Innmann, M., Zollh

ofer, M., Nießner, M., Theobalt, C., and

Stamminger, M. (2016). Volumedeform: Real-time

volumetric non-rigid reconstruction. In ECCV.

Ionescu, C., Papava, D., Olaru, V., and Sminchisescu, C.

(2014). Human3.6m: Large scale datasets and pre-

dictive methods for 3d human sensing in natural envi-

ronments. IEEE Trans. Pattern Analysis and Machine

Intelligence, 36(7):1325–1339.

Izadi, S., Kim, D., Hilliges, O., Molyneaux, D., Newcombe,

R., Kohli, P., Shotton, J., Hodges, S., Freeman, D.,

Davison, A., and Fitzgibbon, A. (2011). Kinectfu-

sion: Real-time 3d reconstruction and interaction us-

ing a moving depth camera. In Proceedings of the 24th

Annual ACM Symposium on User Interface Software

and Technology, pages 559–568.

Kanazawa, A., Black, M. J., Jacobs, D. W., and Malik,

J. (2018). End-to-end recovery of human shape and

pose. In CVPR.

Leroy, V., Franco, J.-S., and Boyer, E. (2017). Multi-View

Dynamic Shape Reﬁnement Using Local Temporal

Integration. In ICCV.

Li, H., Adams, B., Guibas, L. J., and Pauly, M. (2009). Ro-

bust single-view geometry and motion reconstruction.

ACM Trans. Graph., pages 175:1–175:10.

Loper, M., Mahmood, N., and Black, M. J. (2014). Mosh:

Motion and shape capture from sparse markers. ACM

Trans. Graph., 33(6):220:1–220:13.

Loper, M., Mahmood, N., Romero, J., Pons-Moll, G., and

Black, M. J. (2015). Smpl: A skinned multi-person

linear model. ACM Trans. Graph., 34(6):248:1–

248:16.

Loper, M. M. and Black, M. J. (2014). OpenDR: An ap-

proximate differentiable renderer. In ECCV.

Mehta, D., Sridhar, S., Sotnychenko, O., Rhodin, H.,

Shaﬁei, M., Seidel, H.-P., Xu, W., Casas, D., and

Theobalt, C. (2017). Vnect: Real-time 3d human pose

estimation with a single rgb camera. ACM Transac-

tions on Graphics, 36(4).

Newcombe, R. A., Fox, D., and Seitz, S. M. (2015). Dy-

namicfusion: Reconstruction and tracking of non-

rigid scenes in real-time. In CVPR.

Pons-Moll, G., Romero, J., Mahmood, N., and Black, M. J.

(2015). Dyna: A model of dynamic human shape in

motion. ACM Trans. Graph., 34(4):120:1–120:14.

Slavcheva, M., Baust, M., Cremers, D., and Ilic, S. (2017).

KillingFusion: Non-rigid 3D Reconstruction without

Correspondences. In CVPR.

Varol, G., Romero, J., Martin, X., Mahmood, N., Black,

M. J., Laptev, I., and Schmid, C. (2017). Learning

from Synthetic Humans. In CVPR.

Wei, S.-E., Ramakrishna, V., Kanade, T., and Sheikh, Y.

(2016). Convolutional pose machines. In CVPR.

Weiss, A., Hirshberg, D., and Black, M. J. (2011). Home

3D body scans from noisy image and range data. In

ICCV.

Xu, W., Chatterjee, A., Zollh

ofer, M., Rhodin, H., Mehta,

D., Seidel, H., and Theobalt, C. (2017). Monoperfcap:

Human performance capture from monocular video.

CoRR, abs/1708.02136.

Yu, T., Guo, K., Xu, F., Dong, Y., Su, Z., Zhao, J., Li, J.,

Dai, Q., and Liu, Y. (2017). Bodyfusion: Real-time

capture of human motion and surface geometry using

a single depth camera. In ICCV.

Zhang, Q., Fu, B., Ye, M., and Yang, R. (2014). Quality

dynamic human body modeling using a single low-

cost depth camera. In CVPR, pages 676–683.

Zollhofer, M., Niessner, M., Izadi, S., Rehmann, C., Zach,

C., Fisher, M., Wu, C., Fitzgibbon, A., Loop, C.,

Theobalt, C., and Stamminger, M. (2014). Real-time

non-rigid reconstruction using an rgb-d camera. ACM

Trans. Graph., 33:156:1–156:12.

Template based Human Pose and Shape Estimation from a Single RGB-D Image

581
