Adversarial Alignment of Class Prediction Uncertainties for Domain

Adaptation

Jeroen Manders

1,2

, Twan van Laarhoven

1,3

and Elena Marchiori

Institute for Computing and Information Science, Radboud University, Nijmegen, The Netherlands

TNO, The Netherlands

Faculty of Management, Science and Technology, Open University, Heerlen, The Netherlands

Keywords:

Adversarial Learning, Meta-learning.

Abstract:

We consider unsupervised domain adaptation: given labelled examples from a source domain and unlabelled

examples from a related target domain, the goal is to infer the labels of target examples. Under the assumption

that features from pre-trained deep neural networks are transferable across related domains, domain adaptation

reduces to aligning source and target domain at class prediction uncertainty level. We tackle this problem by

introducing a method based on adversarial learning which forces the label uncertainty predictions on the

target domain to be indistinguishable from those on the source domain. Pre-trained deep neural networks are

used to generate deep features having high transferability across related domains. We perform an extensive

experimental analysis of the proposed method over a wide set of publicly available pre-trained deep neural

networks. Results of our experiments on domain adaptation tasks for image classiﬁcation show that class

prediction uncertainty alignment with features extracted from pre-trained deep neural networks provides an

efﬁcient, robust and effective method for domain adaptation.

1 INTRODUCTION

In unsupervised domain adaptation, labelled exam-

ples from a source domain and unlabelled examples

from a related target domain are given. The goal is to

infer the labels of target examples. A straightforward

approach for tackling this problem is to label target

examples by just applying a deep neural network pre-

trained on data from a related domain. This approach

has been shown to work rather well in practice. The

reason is that deep networks learn feature represen-

tations which reduce domain discrepancy, although

they do not fully eliminate it (Yosinski et al., 2014).

If we assume that features from pre-trained deep neu-

ral networks indeed provide a good representation for

both source and target data, then in order to perform

domain adaptation one needs to align only source and

target label predictions in such representation, so only

at class label level. This paper investigates this novel

setting. We introduce a label alignment method to

force the uncertainty in the predicted labels on the tar-

get domain to be indistinguishable from that on the

source domain. The method is based on the adversar-

ial learning approach: it performs domain alignment

at class label level by learning a representation that is

at the same time discriminative for the labelled source

data yet incapable of discriminating the source and

target at prediction uncertainty level. Speciﬁcally, the

proposed method considers the class probabilities of

a label classiﬁer f as input of a domain discrimina-

tor g. The label classiﬁer f is trained to minimize the

standard supervised loss on the source domain while

the domain discriminator g is trained to distinguish

the class probabilities that the label classiﬁer f out-

puts on the source domain from those on the target

domain (see Fig. 1).

A limitation of this method is that it works only

under the assumption that source and target domains

have the same class distribution. This is because the

representation chosen to minimize the discrepancy

between domains depends on the domains class distri-

bution. If they are different, then the discrepancy be-

tween the domains in our representation will be large.

To overcome this limitation, we introduce a tai-

lored loss function to enforce the domains to have

equal class distributions during our training proce-

dure: we incorporate class weights in our loss func-

tion, one for each instance. Class weights of source

examples are ﬁxed and those of the target examples

are updated during optimization of our loss function.

Manders, J., van Laarhoven, T. and Marchiori, E.

Adversarial Alignment of Class Prediction Uncertainties for Domain Adaptation.

DOI: 10.5220/0007519602210231

In Proceedings of the 8th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2019), pages 221-231

ISBN: 978-989-758-351-3

221

Interestingly, training with this loss function leads

to an overestimation of the target domain predictions,

which results in an increased loss while stabilizing ac-

curacy. This approach favors robustness, because the

domain discriminator punishes overconﬁdence on the

source domain, the latter being a sign of overﬁtting.

We call the resulting domain adaptation method

LAD (Label Alignment with Deep features).

LAD uses deep features extracted from a pre-

trained deep neural network, so no ﬁne tuning of

the feature extractor is needed. As such, LAD is

more efﬁcient than end-to-end deep learning adapta-

tion methods.

Joint efforts from the machine learning research

community resulted in the public availability of dif-

ferent pre-trained deep neural network architectures

for visual classiﬁcation. These pre-trained models

provide a rich variety of feature extractors. Besides

trying to align label predictions, the other contribu-

tion of this paper is an extensive analysis of the same

method when changing the ‘feature extractor’ part by

exploring a wide set of existing pre-trained deep ar-

chitectures. This choice allows us to understand the

advantage of the approach when dealing with differ-

ent features.

An extensive experimental analysis shows that

LAD achieves consistent improvement in accuracy

across different pre-trained networks. Overall the

method achieves state of the art results on the stan-

dard Ofﬁce-31 and ImageCLEF-DA datasets, with a

neat improvement over competing baselines on harder

transfer tasks.

The main contributions of this paper can be sum-

marized as follows: 1) a speciﬁc setting for the do-

main adaptation problem; 2) a tailored method for

performing domain adaptation in this setting; 3) ex-

tensive analysis of the proposed method when chang-

ing its ‘feature extraction’ part.

2 RELATED WORK

There is a vast literature on domain adaptation (see

for instance the recent surveys (Weiss et al., 2016;

Csurka, 2017)).

Besides the optimization towards better source

domain class predictions, domain adaptation meth-

ods try to achieve domain invariance (Ben-David

et al., 2010). To achieve domain invariance there are

roughly two popular approaches: minimizing some

measure of domain discrepancy and using an adver-

sarial domain discriminator. Below we summarize

several recent methods based on deep neural net-

works.

Deep-CORAL (Sun and Saenko, 2016) aligns cor-

relations of layer activations in deep neural networks.

Deep Transfer Network (DTN) (Zhang et al., 2015)

employs a deep neural network to model and match

both the domains marginal and conditional distri-

butions. A popular measure used to minimize do-

main discrepancy is Maximum Mean Discrepancy

(MMD) (Gretton et al., 2009). This measure is used

in several recent domain adaptation methods. For

instance, DAN (Long et al., 2015) and RTN (Long

et al., 2016b) are end-to-end deep adaptation meth-

ods which use the sum of multiple MMD by match-

ing the feature distributions of multiple layers across

domains.

In adversarial learning a generator tries to fool

a discriminator so that it cannot distinguish be-

tween generated and real examples(Goodfellow et al.,

2014). Current work on adversarial domain adapta-

tion tries to trick a domain discriminator so that it

no longer can distinguish between features originat-

ing from either the source or target domain, which

results in domain invariant features to be trained.

For instance, ReverseGrad (Ganin and Lempit-

sky, 2015; Ganin et al., 2016) enforce the domains

to be indistinguishable by reversing the gradients of

the loss of the domain classiﬁer.

Recently (Tzeng et al., 2017) introduced a uni-

fying framework for adversarial transfer learning,

and proposed a new instance of this framework,

called Adversarial Discriminative Domain Adapta-

tion (ADDA), which combines discriminative mod-

eling, untied weight sharing, and a generative adver-

sarial network loss.

LAD’s alignment at label level is based on ad-

versarial learning. As such, it shares the theoretical

motivation of adversarial learning method for domain

adaptation, as explained e.g. in (Ganin et al., 2016).

Note that the idea of matching the classiﬁer layer

has been used in end-to-end domain adaptation meth-

ods based on deep learning, for instance DAN and

RTN, where both the feature layer and the classiﬁer

layer are aligned simultaneously using either MMD

or adversarial domain discriminator. The main dif-

ference between LAD and these works is the under-

lying scenario: LAD works under the assumption

that domain representations are already reasonably

matched through the use of a pre-trained deep neural

network for feature extraction. Therefore LAD per-

forms alignment only at class label level, by matching

label predictions. While in LAD the domain discrim-

inator takes as input (source and target) predictions of

the label classiﬁer, in all previous adversarial methods

for domain adaptation the domain discriminator takes

as input (source and target) features.

ICPRAM 2019 - 8th International Conference on Pattern Recognition Applications and Methods

222

3 CLASS PREDICTION

UNCERTAINTY ALIGNMENT

We are given a set S of source images and their labels

drawn from a source domain distribution P

(x,y), and

a set T of target images without their labels, drawn

from a target distribution P

(x,y). Our goal is to learn

a classiﬁer that correctly predicts the labels of T .

3.1 Label Alignment with Deep

Features

The proposed label alignment method shares the the-

oretical motivation of (adversarial learning) methods

for domain adaptation: ﬁnd a common representa-

tion that reduces the distance between source and tar-

get domain distributions (Ben-David et al., 2007). In

LAD, as in other adversarial adaptation methods, do-

main distance is reduced using a neural network (the

domain discriminator). In LAD the inputs of the net-

work are class probabilities (computed by softmax),

while in other adversarial methods, like Domain-

Adversarial Neural Networks (Ganin et al., 2016), the

input of the network are (deep) features.

The proposed method tries to align source and tar-

get domain at class label level using two models: a

label classiﬁer C(x, θ

), and a domain discriminator

D(y,θ

). Both of these functions are parameterized

by neural networks, θ

and θ

. For brevity we will

omit the parameters θ

and θ

. The label classiﬁer is

trained to minimize the following standard supervised

loss on the source domain S :

|S |

∑

(x,y)∈S

`(C(x),y), (1)

where `(p,y) = −

∑

log(p

) is the cross-entropy

loss, and x denotes the vector of features generated

using a pre-trained deep neural network.

The domain discriminator is trained to distinguish

the uncertainty of the predictions that C makes on the

source domain from the uncertainty of the predictions

on the target domain T . This is again a standard su-

pervised problem, predicting d = 1 for the source and

d = 0 for the target, given the output C(x) of the label

classiﬁer. The loss is

(C,D) =

|S |

∑

(x,y)∈S

`(D(C(x)),1)

|T |

∑

x∈T

`(D(C(x)),0). (2)

We want the label classiﬁer to ‘fool’ the domain

discriminator. This can be achieved by training it

to make the predictions on the two domains indis-

tinguishable. That means that we maximize L

with

respect to C. The resulting optimization problem is

therefore

min

max

(C,D). (3)

3.1.1 Class Weighted Loss Function

Since here we adversarially train a domain invariant

label classiﬁer on the level of predictions, it is nec-

essary that the label distribution of both domains is

the same, otherwise predictions towards certain labels

could be based on possible differences between label

occurrences in both domains.

This would have a negative effect and prevent do-

main alignment. Formally, let c

(y) = |{(x

) ∈

S | y = y

}|/|S | be the fraction of source instances

that have label y, and similarly let c

(y) be the (un-

known) fraction of target instances with label y under

the true labeling. Then if c

(y) 6= c

(y) and the la-

bel classiﬁer C makes perfect predictions, the domain

discriminator is able to distinguish the two domains,

based purely on the different conditional probabilities

P(y|d).

To overcome this problem we will switch to

weighted loss functions,

|S |

∑

(x,y)∈S

(x,y)`(C(x),y), (4)

(C,D) =

|S |

∑

(x,y)∈S

(x,y)`(D(C(x)),1)

|T |

∑

x∈T

(x)`(D(C(x)),0).

(5)

Where the weights for the source domain are

(x,y) =

max

)

(y)

. (6)

For the target domain we do not know the true labels,

so instead we use the predicted (pseudo)labels ˜y(x) =

argmax

C(x)

. So the weights are

(x) =

max

˜c

)

˜c

( ˜y(x))

, (7)

where

˜c

(y) = |{x

∈ T | y = ˜y(x

)}|/|T |.

With the weighted loss, the domain discriminator

cannot use the difference in conditional probability

of the class given the domain, since all classes occur

with the same total weight in both domains.

Adversarial Alignment of Class Prediction Uncertainties for Domain Adaptation

223

3.2 Architecture

The overall LAD architecture used in our experiments

is shown in Fig. 1. It consists of three parts: feature

extractor, label classiﬁer and domain discriminator.

3.2.1 Feature Extractor

We use a deep neural network pre-trained on the Im-

ageNet dataset (Russakovsky et al., 2015). The last

label prediction layer of a pre-trained network is omit-

ted and features are extracted from the second to last

layer, as this is presumably the layer with the lowest

maximum mean discrepancy (Tzeng et al., 2014).

To generate robust features, we use a form of data

augmentation, where different crops and ﬂips of each

image are passed through the network, and the fea-

tures are averaged.

In particular, for each image, its features are cal-

culated as follows. First, we resize the input image

to the input size of the network plus 64 pixels (for

example, for ResNet50, which expects a 224 × 224

input, we resize the image to 288 × 288 pixels). From

this resized image we take 9 crops spaced of 32 pixels

apart. This is repeated for the horizontally ﬂipped in-

put image, resulting in 18 different image crops. For

each image, crop features are extracted from the pre-

trained network. The ﬁnal features of the input image

are the averaged features of its 18 crops.

3.2.2 Label Classiﬁer

We consider a label classiﬁer consisting of two dense

(fully connected) layers of size 1024 with ReLu acti-

vation and 0.5 dropout (Srivastava et al., 2014), fol-

lowed by a dense layer with softmax activation for

label predictions.

3.2.3 Domain Discriminator

The considered domain discriminator has the same

structure as the label classiﬁer, but without dropout

layers. The domain discriminator is placed after the

softmax layer of the label classiﬁer, and behind a

gradient reversal layer (Ganin and Lempitsky, 2015;

Ganin et al., 2016) which acts as an identity function

on forward passes through the network, and reverses

the gradient on backward passes. This ensures that

we can use the gradient of L

to simultaneously max-

imize with respect to f and minimize with respect to

g in our optimization problem (3).

3.3 Training

All training is done with minibatch Stochastic Gradi-

ent Descent (SGD) with Nesterov momentum. Both

the label and domain loss is calculated with categor-

ical cross-entropy. For training, we assume that we

already extracted the features from a pre-trained deep

neural network. The training of LAD is different from

that of normal feedforward neural networks due to

having two instead of one loss function. Each training

step we draw a minibatch from both domains with-

out replacement, append the domain identiﬁer and,

for the source domain, the class labels. With these

inputs, training proceeds as follows: ﬁrst, the source

domain batch is used to train the label classiﬁer, then

the source and domain batches are concatenated and

together are used to train the domain discriminator.

We call one pass through the source domain an epoch.

The weights w

for the target domain are recom-

puted once per epoch. In the ﬁrst epoch we set the

weights to 1.

The complete training approach is displayed in

Algorithm 1.

A technical concern of this training procedure is

that as the labels for target domain data are unknown,

in the proposed method, the weights for each target

domain instance are estimated based on the predicted

labels, and then updated iteratively epoch by epoch.

However, there is no guarantee that the iterative pro-

cedure is able to ﬁnd an optimal solution for w

. That

means the estimation of w

may become worse and

worse. Nevertheless, under the assumption that fea-

tures extracted from the pre-trained deep neural net-

work are well transferable, and that source and target

domains are related, this phenomenon should not hap-

pen. This is indeed the case in practice, as substanti-

ated by results of our extensive empirical analysis.

4 EXPERIMENTS

We conduct extensive experiments on 12 adaptation

tasks from two real-life benchmark datasets. Datasets,

experimental setup and methods used in our compar-

ative analysis are described in detail below.

4.1 Datasets

We consider two benchmark datasets: Ofﬁce-31

(Saenko et al., 2010) and imageCLEF-DA

The Ofﬁce-31 dataset for visual domain adapta-

tion consists of three domains with images in 31 cat-

egories. The Amazon (A) domain with 2817 images

http://imageclef.org/2014/adaptation

ICPRAM 2019 - 8th International Conference on Pattern Recognition Applications and Methods

224

Input

Pre-trained DNN

Dense 1024, ReLu, Dropout

Dense, Softmax

Class label

Gradient Reversal Layer

Dense 1024, ReLu

Dense, Softmax

Domain label

Feature extractor

Label classiﬁer

Domain discriminator

Figure 1: LAD Architecture.

Algorithm 1: LAD.

Data: S = labeled source data, T = unlabeled tar-

get data

Result: Y = predicted labels for target domain

(x,y) ←



max

)



(y) for each (x,y) ∈ S

(x) ← 1 for each x ∈ T

for epoch ← 1,2, . . . , n

epochs

while available batches in S do

batch

← take batch from S

batch

← take batch from T

Perform a step of SGD on L

(C)

Perform a step of SGD on L

(C,D)

end while

Y ← ˜y(T )

(x) ←



max

)



/ ˜c

((x)) for each x ∈ T

end for

consists of images taken from Amazon.com product

pages. The DSLR (D) and Webcam (W) domains,

with respectively 498 and 795 images, consist of im-

ages taken with either a digital SLR or web camera

of the products in different environments. The im-

ages in each domain are unbalanced across the 31

categories, therefore we will use our data balancing

method. We report results on all possible domain

combinations A→D, A→W, D→A, D→W, W→A,

and W→D which is a good combination of difﬁcult

and easier domain adaptation tasks.

The imageCLEF-DA dataset is a benchmark

dataset for ImageCLEF 2014 domain adaptation chal-

lenge and consists of 12 common categories shared by

three public datasets which are seen as different do-

mains: Caltech-256 (C), ImageNet ILSVRC 2012 (I),

and Pascal VOC 2012 (P). This dataset is balanced,

with 50 images for each of the 12 categories for a to-

tal of 600 images per domain, making a good addi-

tion to the Ofﬁce-31 dataset. Since for each transfer

task the source is balanced, we omit our own balanc-

ing method when using this dataset. We report results

on all domain combinations: C→I, C→P, I→C, I→P,

P→C, P→I.

4.2 Experimental Setup

LAD is implemented on the Tensorﬂow (Abadi et al.,

2015) framework via the Keras (Chollet et al., 2015)

interface. The network and training parameters are

kept similar across all pre-trained architectures and

domain adaptation tasks of both datasets. Speciﬁcally,

we use stochastic gradient descent with a learning rate

of 0.001 and Nesterov momentum of 0.9, a batch size

of 32. All of these parameter settings are considered

default settings. In all our experiments we train each

model for n

epochs

= 1000 epochs. For each transfer

task we run LAD 10 times and report the average la-

bel classiﬁcation accuracy and standard deviation.

All algorithms are assessed in a fully transductive

setup where all unlabeled target instances are used

during training for predicting their labels. Labeled in-

stances of the ﬁrst domain are used as the source and

unlabeled instances of the second domain as the tar-

get. We evaluate the accuracy on the target domain as

the percentage of correctly labeled target instances.

In order to assess LAD’s transfer capability, we

consider a baseline variant, obtained by omitting the

domain discriminator from LAD, and trained on the

source data (no adaptation). For instance, Base-

line(DenseNet201) denotes the baseline variant with

the pre-trained DenseNet201 network as the feature

extractor. Network and training parameters are kept

the same as those of LAD across all tasks, besides

training for only 100 epochs which is roughly chosen

as optimal before overﬁtting becomes a problem.

In all experiments, we did not perform hyperpa-

rameter optimization, but just used default settings of

Keras.

5 RESULTS

In order to assess comparatively the performance of

LAD across different pre-trained architectures, we

Adversarial Alignment of Class Prediction Uncertainties for Domain Adaptation

225

conduct extensive experiments on the following pre-

trained architectures publicly available at Keras: Mo-

bileNet (Howard et al., 2017), VGG16 (Simonyan

and Zisserman, 2014), VGG19 (Simonyan and Zis-

serman, 2014), DenseNet (Huang et al., 2017), In-

ceptionV3 (Szegedy et al., 2016), Xception (Chol-

let, 2016), and InceptionResNetV2 (Szegedy et al.,

2017).

As shown in Table 1, on the Ofﬁce-31,

LAD(InceptionResNetV2) outperforms the other

variants with an average accuracy of 90.7%. Differ-

ences between architectures are very clear when look-

ing at their baseline results where the difference be-

tween the worst and best architecture is around 10%.

The InceptionResNetV2 pre-trained features are so

good and robust that without LAD they already out-

perform current state-of-the-art methods for domain

adaptation based on the ResNet50 architecture.

On the ResNet50 architecture LAD improves on

our baseline (no adaptation) on all tasks. The im-

provement is more evident on the harder tasks A→D,

D→A, A→W, and W→A. In particular, on A→W

more than 13% improvement is achieved (from 76.5

with no adaptation to 89.9 with adaptation).

The increase in target accuracy is larger when us-

ing less powerful architectures. For example, with

MobileNet, on the harder adaptation tasks D→A

and W→A, about 15% increase in target accuracy is

achieved (from 57.2 with no adaptation to 72.1 with

adaptation for D→A, and from 56.5 with no adapta-

tion to 71.3 with adaptation for W→A).

As shown in Table 2, on the ImageClef-DA adap-

tation tasks, the best average accuracy is obtained by

LAD with the Xception architecture, with an average

accuracy of 89.68%. Notably, on the C→I adaptation

task, using InceptionResNetV2 LAD gains about 11%

target accuracy over the Baseline (from 80.3 with no

adaptation to 91.5 with adaptation).

ImageCLEF-DA results of LAD based on

ResNet50 show that the best improvement over the

Baseline (no adaptation) is obtained on harder tasks.

For instance, on the C→I task (from 80.9 with no

adaptation to 88.5 with adaptation).

LAD consistently performs well on features from

pre-trained deep neural networks with different archi-

tectures.

Overall, results indicate that more recent pre-

trained models achieve very good performance and

that LAD consistently improves on the baselines.

These results provide further experimental evidence

that deep networks learn feature representations

which reduce domain discrepancy, but do not fully

eliminate it, even for architectures achieving excellent

performance, like InceptionResNetV2.

6 COMPARISON WITH

END-TO-END DEEP LEARNING

METHODS

To assess how results of LAD compare with the state-

of-the-art, we report published results of the following

end-to-end deep learning methods for domain adapta-

tion that ﬁne-tune a ResNet50 model pre-trained on

ImageNet: Deep Domain Confusion (DDC) (Tzeng

et al., 2014), Deep Adaptation Network (DAN) (Long

et al., 2015), Residual Transfer Network (RTN) (Long

et al., 2016b), Adversarial Discriminative Domain

Adaptation (ADDA) (Tzeng et al., 2017), Reverse

Gradient (RevGrad) (Ganin and Lempitsky, 2015).

Although all experiments were conducted under

the same transductive setup, results should be inter-

preted with care. There are various differences be-

tween the considered algorithms. For instance, end-

to-end training of a pre-trained deep architecture ver-

sus using the pre-trained architecture to extract fea-

tures, or hyper-parameters tuning vs using default set-

tings.

Overall, results indicate state of the art perfor-

mance of LAD, comparable or better than that of end-

to-end deep adaptation methods.

7 DISCUSSION

7.1 Effectiveness with Shallower

Pre-trained Deep Models

LAD depends on the quality of pseudo labels for com-

puting weights of target instances and for the model

construction. A natural concern is: What if target

classiﬁcation accuracy is too low? Will the alignment

of classiﬁer predictions still be effective? To inves-

tigate this issue, we consider the shallower network

AlexNet as feature extractor for the Ofﬁce-31 dataset.

Since this model is not available in Keras, we used

deep features from the 7th layer provided by (Tom-

masi and Tuytelaars, 2014). Table 5 shows results.

When using the less deep AlexNet architecture LAD

still improves on our baseline (no adaptation) on all

tasks. Also in this case, adaptation proves to be ef-

fective on harder tasks. For instance on W→A our

baseline obtains 46.1 accuracy, while with adaptation

54.8 accuracy is achieved.

ICPRAM 2019 - 8th International Conference on Pattern Recognition Applications and Methods

226

Table 1: Baseline and LAD average accuracy (with standard deviations) over 10 runs on the Ofﬁce-31 dataset for different

network architectures.

Method A → D A → W D → A D → W W → A W → D avg

Baseline(MobileNet) 74.5±1.5 73.5±0.6 57.2±0.6 97.8±0.2 56.5±0.6 99.4±0.2 76.5%

LAD(MobileNet) 82.2±1.8 89.3±2.5 72.1±0.5 98.9±0.1 71.3±3.2 99.8±0.1 85.6%

Baseline(VGG16) 76.5±1.1 73.7±1.2 61.9±0.6 96.6±0.3 60.4±0.6 99.7±0.1 78.1%

LAD(VGG16) 85.3±2.0 87.9±1.5 69.9±0.8 97.3±0.2 70.1±0.6 99.7±0.1 85.0%

Baseline(VGG19) 76.1±0.8 72.9±1.1 63.4±0.6 97.4±0.4 62.9±1.0 99.8±0.1 78.8%

LAD(VGG19) 83.9±1.8 87.7±0.7 71.0±0.8 98.2±0.3 71.5±0.8 99.9±0.1 85.4%

Baseline(ResNet50) 81.0±0.6 76.5±0.9 64.8±0.8 97.5±0.2 63.6±1.0 99.7±0.2 80.5%

LAD(ResNet50) 90.6±1.2 90.0±0.7 74.0±0.6 98.0±0.1 75.3±1.4 99.8±0.2 87.9%

Baseline(DenseNet201) 85.3±0.8 82.3±1.2 68.5±0.6 98.0±0.2 67.7±0.5 99.9±0.1 83.6%

LAD(DenseNet201) 93.1±0.8 94.7±0.9 77.2±0.8 98.6±0.1 77.7±0.7 99.9±0.1 90.2%

Baseline(InceptionV3) 85.9±0.8 82.4±0.7 72.8±0.4 97.5±0.4 72.8±0.3 99.0±0.3 85.1%

LAD(InceptionV3) 91.2±0.7 88.6±0.5 76.9±0.5 98.3±0.2 76.9±0.8 99.3±0.2 88.5%

Baseline(Xception) 85.2±0.7 83.9±0.7 72.1±0.4 97.0±0.2 71.9±0.5 99.7±0.1 85.0%

LAD(Xception) 91.0±1.5 92.9±0.5 78.6±0.3 98.1±0.1 78.1±0.8 100.0±0.1 89.8%

Baseline(InceptionResNetV2) 90.2±0.7 89.3±0.6 74.9±0.5 97.3±0.2 75.5±0.3 99.6±0.2 87.8%

LAD(InceptionResNetV2) 93.7±0.8 95.3±0.3 78.8±0.5 98.3±0.1 78.5±0.5 99.6±0.1 90.7%

Table 2: Baseline and LAD average accuracy (with standard deviations) over 10 runs on the ImageCLEF-DA dataset for

different network architectures.

Method C → I C → P I → C I → P P → C P → I avg

Baseline(MobileNet) 77.9±0.3 65.2±0.8 89.8±0.7 74.6±0.4 91.2±0.8 84.9±0.8 80.6%

LAD(MobileNet) 87.9±0.7 73.9±0.7 94.6±0.4 75.2±0.5 94.0±0.3 88.3±0.7 85.6%

Baseline(VGG16) 83.2±0.7 70.7±0.5 91.9±0.5 76.5±0.5 91.5±0.6 86.0±0.8 83.3%

LAD(VGG16) 89.6±0.5 76.7±0.8 94.3±0.3 76.2±0.8 94.4±0.4 88.8±0.9 86.7%

Baseline(VGG19) 84.7±0.7 70.9±0.4 92.0±0.3 76.6±0.4 91.6±0.5 85.8±0.7 83.6%

LAD(VGG19) 89.0±0.7 74.5±0.5 94.8±0.3 77.3±0.6 94.3±0.3 90.2±1.0 86.7%

Baseline(ResNet50) 80.9±1.3 68.0±1.0 92.2±0.5 76.1±0.4 91.8±0.5 88.4±0.8 82.9%

LAD(ResNet50) 88.5±1.0 74.0±1.0 95.2±0.4 76.8±0.7 94.1±0.2 90.6±0.6 86.5%

Baseline(DenseNet201) 87.7±0.7 71.6±0.6 93.6±0.4 78.3±0.4 94.3±0.5 90.8±0.8 86.1%

LAD(DenseNet201) 93.0±0.4 78.3±1.0 97.5±0.3 79.1±0.3 95.7±0.4 93.2±0.4 89.5%

Baseline(InceptionV3) 83.1±1.2 66.1±0.8 94.3±0.5 77.8±0.5 93.9±0.4 90.8±0.9 84.3%

LAD(InceptionV3) 92.8±0.3 75.9±0.9 95.9±0.3 78.3±0.5 95.8±0.3 94.2±0.5 88.8%

Baseline(Xception) 85.2±0.8 69.9±0.5 94.7±0.5 79.3±0.5 92.8±1.1 90.8±0.6 85.5%

LAD(Xception) 94.2±0.4 77.7±1.1 96.8±0.4 80.1±0.5 96.6±0.3 92.6±0.6 89.7%

Baseline(InceptionResNetV2) 80.3±0.9 67.8±0.9 90.3±1.9 79.3±0.5 88.4±0.9 89.7±0.8 82.6%

LAD(InceptionResNetV2) 91.5±0.7 75.9±0.9 97.2±0.3 80.6±0.5 95.0±0.3 92.3±1.2 88.7%

Table 3: Average accuracy (with standard deviations) on adaptation tasks from the Ofﬁce-31 dataset. All methods considered

use a ResNet50 model.

Method A → D A → W D → A D → W W → A W → D avg

DDC (Tzeng et al., 2014) 77.5±0.3 75.8±0.2 67.4±0.4 95.0±0.2 64.0±0.5 98.2±0.1 79.7%

DAN (Long et al., 2015) 78.4±0.2 83.8±0.4 66.7±0. 96.8±0.2 62.7±0.2 99.5±0.1 81.3%

RTN (Long et al., 2016b) 71.0±0.2 73.3±0.2 50.5±0.3 96.8±0.2 51.0±0.1 99.6±0.1 73.7%

RevGrad (Ganin and Lempitsky, 2015) 72.3±0.3 73.0±0.5 52.4±0.4 96.4±0.3 50.4±0.5 99.2±0.3 74.1%

ADDA (Tzeng et al., 2017) 77.8±0.3 86.2±0.5 69.5±0.4 96.2±0.3 68.9±0.5 98.4±0.3 82.9%

LAD 90.6±1.2 89.9±0.7 74.0±0.6 98.0±0.1 75.3±1.4 99.8±0.2 87.9%

Table 4: Average accuracy (with standard deviations) for various methods on the ImageCLEF-DA dataset, obtained with the

ResNet50 architecture.

Method I → P P → I I → C C → I C → P P → C avg

DAN (Long et al., 2015) 75.0±0.4 86.2±0.2 93.3±0.2 84.1±0.4 69.8±0.4 91.3±0.4 83.3%

RTN (Long et al., 2016a) 75.6±0.3 86.8±0.1 95.3±0.1 86.9±0.3 72.7±0.3 92.2±0.4 84.9%

RevGrad (Ganin and Lempitsky, 2015) 75.0±0.6 86.0±0.3 96.2±0.4 87.0±0.5 74.3±0.5 91.5±0.6 85.0%

LAD 76.8±0.7 90.6±0.6 95.2±0.3 88.5±1.0 74.0±1.0 94.1±0.2 86.5%

Adversarial Alignment of Class Prediction Uncertainties for Domain Adaptation

227

7.2 Robustness to the Choice of the

Number of Epochs

Looking at the learning curves in Fig. 2, we see that

the target domain classiﬁcation loss reaches a min-

imum after 50 to 150 epochs, after which it starts

to increase. However, the accuracy continues to in-

crease, and there is no sign of overﬁtting. Ganin &

Lempitsky (Ganin and Lempitsky, 2015) also report

this ﬁnding for their method, but it seems this phe-

nomenon is even more pronounced when aligning do-

mains on the level of predictions instead of features.

Indeed, aligning domains on predictions needs to en-

tail the same level of certainty of predictions for both

source and target domains, which leads to an overes-

timation of the target domain prediction certainty, to

match the certainty on the source domain. This over-

estimation in time results in an increased loss while

stabilizing accuracy: a higher certainty of target pre-

dictions makes it harder to switch predictions to an-

other class label.

Furthermore, while the certainty on the source do-

main leads to overconﬁdence of the label classiﬁer on

the target domain, the uncertainty about the target do-

main labels has a regularizing effect on the source do-

main. The label classiﬁer cannot become overconﬁ-

dent on the source domain, because then the source

domain predictions would not look like the initially

uncertain target domain predictions.

The stability of the target domain, together with

the regularizing effect of the label uncertainty on the

source domain makes LAD robust to the choice of the

number of epochs. The algorithm therefore does not

require early stopping.

7.3 Class Weights Importance with

Unbalanced Class Distributions

We have also investigated the importance of the

class weights introduced in our loss function (see

Section 3.1.1), by training the model without using

weights.

On the Ofﬁce-31 dataset, without class weights

LAD with ResNet50 features achieves an average ac-

curacy of 80.3%, compared to 87.9% when the loss

with class weights is used. The Ofﬁce-31 dataset has

unbalanced class distributions. In this case the loss

with weights prevents the use of this information, and

LAD obtains better performance.

On the other hand, on ImageCLEF-DA, not us-

ing class weights gives an average accuracy of 87.8%,

compared to 86.5% with weights. This happens be-

cause this dataset is fully class balanced. In that case,

performance does not drop when no weights are used

0 200 400

600

800 1,000

epochs

accuracy (%)

(a) Ofﬁce-31 accuracy.

0 200 400

600

800 1,000

0.6

0.7

0.8

epochs

class loss

(b) Ofﬁce-31 loss.

0 200 400

600

800 1,000

epochs

accuracy (%)

0 200 400

600

800 1,000

0.7

0.8

0.9

epochs

class loss

(d) ImageCLEF-DA loss.

Figure 2: Target domain classiﬁcation accuracy and clas-

siﬁcation loss when training for up to 1000 epochs. Made

with the ResNet50 architecture.

in the loss, because class distributions are already

fully class balanced.

In general, we can make no assumptions about the

target domain being balanced. In that case, we should

assume that the data is not class balanced, and use the

weighted loss functions, as is done in LAD.

ICPRAM 2019 - 8th International Conference on Pattern Recognition Applications and Methods

228

Table 5: Average accuracy (with standard deviations) on adaptation tasks from the Ofﬁce-31 dataset. LAD uses features

extracted from the 7th layer of the pre-trained AlexNet model.

Method A → D A → W D → A D → W W → A W → D avg

Baseline(DeCAF-fc7) 63.63±1.07 57.26±1.17 47.53±0.75 94.30±0.66 46.15±0.61 98.07±0.42 67.82%

LAD(DeCAF-fc7) 70.78±1.25 65.77±0.56 53.47±0.96 96.78±0.39 54.82±1.18 98.94±0.32 73.43%

(a) Baseline source. (b) Baseline target.

Figure 3: t-SNE feature visualization of Baseline and LAD

features on the A→W task from the Ofﬁce-31 dataset.

ResNet50 is the used pre-trained architecture. Features vi-

sualized from the second dense layer of our architecture

shown in Fig. 1.

7.4 Running Time

LAD does not perform ﬁne-tuning of large pre-trained

architecture weights and therefore is relatively fast

to train. On average over all different transfer tasks

a single epoch as described in algorithm 1 takes

0.4 seconds for Ofﬁce-31 and 0.2 seconds for the

imageCLEF-DA dataset when trained on a single

Nvidia GeForce GTX 1070.

7.5 Visualization of Deep Features

To get more insight into the feature representation

learned with LAD, we compare t-SNE (Maaten and

Hinton, 2008) feature visualizations of LAD features

with those of Baseline on the ResNet50 architecture.

For better comparability, we visualize features on the

difﬁcult A→W adaptation task. Visualized features

are from the second dense layer (see Fig. 1). Fig. 3

indicates that LAD features are better and more do-

main invariant than those of the baseline, since the

31 classes of the Ofﬁce-31 dataset are better distin-

guishable and the features from both domains are bet-

ter mapped on each other.

8 CONCLUSION

In this paper we introduced domain alignment at pre-

diction uncertainty level, to be used with features ex-

tracted from pre-trained deep neural networks. We

demonstrated effectiveness, efﬁciency, and robust-

ness through extensive experiments with diverse pre-

trained architectures and unsupervised domain adap-

tation tasks for image classiﬁcation.

In our experimental analysis, we did not per-

form hyperparameter optimization, but just used de-

fault settings of Keras. It is interesting to investigate

whether LAD performance could be further improved

by applying procedures for tuning hyperparameters in

a transfer learning setting, like (Zhong et al., 2010).

We have shown that training with our tailored loss

function favors robustness, because the domain dis-

criminator punishes overconﬁdence on the source do-

main, the latter being a sign of overﬁtting. It will be

interesting to investigate whether a similar technique

can also be used to prevent overﬁtting in other set-

tings, such as supervised learning.

A limitation and intrinsic characteristic of LAD is

that it does not directly align source and target fea-

tures, it does alignment only through the uncertainty

of predictions. This is a direct consequence of the

domain adaptation scenario investigated here. As a

consequence, LAD is sensitive to the choice of the

features. Although the results of our experiments

showed that in practice LAD works well across fea-

tures from various pre-trained deep neural networks,

its underlying assumption is the existence (and avail-

ability) of transferable (deep) features. On the other

hand, domain alignment at the feature level as per-

formed by previous domain adaptation methods, no-

tably RevGrad, does not rely on this assumption and

is therefore of more general applicability.

Nevertheless, our method for prediction uncer-

tainty alignment can be applied to any feature repre-

sentation that is good for source and target, so it is not

limited to pre-trained deep neural networks as feature

extractors. It will be interesting in future work to ex-

plore the utility of the method when used on the top of

Adversarial Alignment of Class Prediction Uncertainties for Domain Adaptation

229

domain adaptation methods based on feature transfor-

mation, like (Fernando et al., 2013; Sun et al., 2016).

REFERENCES

Abadi, M., Agarwal, A., Barham, P., Brevdo, E., Chen, Z.,

Citro, C., Corrado, G. S., Davis, A., Dean, J., Devin,

M., Ghemawat, S., Goodfellow, I., Harp, A., Irving,

G., Isard, M., Jia, Y., Jozefowicz, R., Kaiser, L., Kud-

lur, M., Levenberg, J., Man

e, D., Monga, R., Moore,

S., Murray, D., Olah, C., Schuster, M., Shlens, J.,

Steiner, B., Sutskever, I., Talwar, K., Tucker, P., Van-

houcke, V., Vasudevan, V., Vi

egas, F., Vinyals, O.,

Warden, P., Wattenberg, M., Wicke, M., Yu, Y., and

Zheng, X. (2015). TensorFlow: Large-scale machine

learning on heterogeneous systems. Software avail-

able from tensorﬂow.org.

Ben-David, S., Blitzer, J., Crammer, K., Kulesza, A.,

Pereira, F., and Vaughan, J. W. (2010). A theory of

learning from different domains. Machine learning,

79(1):151–175.

Ben-David, S., Blitzer, J., Crammer, K., and Pereira, F.

(2007). Analysis of representations for domain adap-

tation. In Advances in Neural Information Processing

Systems, pages 137–144.

Chollet, F. (2016). Xception: Deep learning with

depthwise separable convolutions. arXiv preprint

arXiv:1610.02357.

Chollet, F. et al. (2015). Keras. https://github.com/fchollet/

keras.

Csurka, G. (2017). Domain adaptation for visual appli-

cations: A comprehensive survey. arXiv preprint

arXiv:1702.05374.

Fernando, B., Habrard, A., Sebban, M., and Tuytelaars, T.

(2013). Unsupervised visual domain adaptation using

subspace alignment. In Proceedings of the 2013 IEEE

International Conference on Computer Vision, ICCV

’13, pages 2960–2967, Washington, DC, USA. IEEE

Computer Society.

Ganin, Y. and Lempitsky, V. (2015). Unsupervised domain

adaptation by backpropagation. In International Con-

ference on Machine Learning, pages 1180–1189.

Ganin, Y., Ustinova, E., Ajakan, H., Germain, P.,

Larochelle, H., Laviolette, F., Marchand, M., and

Lempitsky, V. (2016). Domain-adversarial training of

neural networks. Journal of Machine Learning Re-

search, 17(59):1–35.

Goodfellow, I., Pouget-Abadie, J., Mirza, M., Xu, B.,

Warde-Farley, D., Ozair, S., Courville, A., and Ben-

gio, Y. (2014). Generative adversarial nets. In Ad-

vances in Neural Information Processing Systems,

pages 2672–2680.

Gretton, A., Smola, A. J., Huang, J., Schmittfull, M., Borg-

wardt, K. M., and Sch

olkopf, B. (2009). Covariate

shift by kernel mean matching. In Joaquin Quinonero-

Candela, Masashi Sugiyama, A. S. N. D. L., editor,

Dataset Shift in Machine Learning, pages 131–160.

MIT press.

Howard, A. G., Zhu, M., Chen, B., Kalenichenko, D.,

Wang, W., Weyand, T., Andreetto, M., and Adam,

H. (2017). Mobilenets: Efﬁcient convolutional neu-

ral networks for mobile vision applications. arXiv

preprint arXiv:1704.04861.

Huang, G., Liu, Z., van der Maaten, L., and Weinberger,

K. Q. (2017). Densely connected convolutional net-

works. In 2017 IEEE Conference on Computer Vision

and Pattern Recognition (CVPR), pages 2261–2269.

Long, M., Cao, Y., Wang, J., and Jordan, M. (2015).

Learning transferable features with deep adaptation

networks. In International Conference on Machine

Learning, pages 97–105.

Long, M., Wang, J., and Jordan, M. I. (2016a). Deep trans-

fer learning with joint adaptation networks. arXiv

preprint arXiv:1605.06636.

Long, M., Zhu, H., Wang, J., and Jordan, M. I. (2016b).

Unsupervised domain adaptation with residual trans-

fer networks. In Advances in Neural Information Pro-

cessing Systems, pages 136–144.

Maaten, L. v. d. and Hinton, G. (2008). Visualizing data

using t-sne. Journal of Machine Learning Research,

9(Nov):2579–2605.

Russakovsky, O., Deng, J., Su, H., Krause, J., Satheesh, S.,

Ma, S., Huang, Z., Karpathy, A., Khosla, A., Bern-

stein, M., et al. (2015). Imagenet large scale visual

recognition challenge. International Journal of Com-

puter Vision, 115(3):211–252.

Saenko, K., Kulis, B., Fritz, M., and Darrell, T. (2010).

Adapting visual category models to new domains.

Computer Vision–ECCV 2010, pages 213–226.

Simonyan, K. and Zisserman, A. (2014). Very deep con-

volutional networks for large-scale image recognition.

arXiv preprint arXiv:1409.1556.

Srivastava, N., Hinton, G. E., Krizhevsky, A., Sutskever, I.,

and Salakhutdinov, R. (2014). Dropout: a simple way

to prevent neural networks from overﬁtting. Journal

of machine learning research, 15(1):1929–1958.

Sun, B., Feng, J., and Saenko, K. (2016). Return of frus-

tratingly easy domain adaptation. In Thirtieth AAAI

Conference on Artiﬁcial Intelligence.

Sun, B. and Saenko, K. (2016). Deep coral: Correla-

tion alignment for deep domain adaptation. In Com-

puter Vision–ECCV 2016 Workshops, pages 443–450.

Springer.

Szegedy, C., Ioffe, S., Vanhoucke, V., and Alemi, A. A.

(2017). Inception-v4, inception-resnet and the impact

of residual connections on learning. In AAAI, pages

4278–4284.

Szegedy, C., Vanhoucke, V., Ioffe, S., Shlens, J., and Wo-

jna, Z. (2016). Rethinking the inception architecture

for computer vision. In Proceedings of the IEEE Con-

ference on Computer Vision and Pattern Recognition,

pages 2818–2826.

Tommasi, T. and Tuytelaars, T. (2014). A testbed for cross-

dataset analysis. In European Conference on Com-

puter Vision, pages 18–31. Springer.

Tzeng, E., Hoffman, J., Saenko, K., and Darrell, T. (2017).

Adversarial discriminative domain adaptation. In

ICPRAM 2019 - 8th International Conference on Pattern Recognition Applications and Methods

230

2017 IEEE Conference on Computer Vision and Pat-

tern Recognition (CVPR), pages 2962–2971.

Tzeng, E., Hoffman, J., Zhang, N., Saenko, K., and Darrell,

T. (2014). Deep domain confusion: Maximizing for

domain invariance. arXiv preprint arXiv:1412.3474.

Weiss, K., Khoshgoftaar, T. M., and Wang, D. (2016). A

survey of transfer learning. Journal of Big Data,

3(1):9.

Yosinski, J., Clune, J., Bengio, Y., and Lipson, H. (2014).

How transferable are features in deep neural net-

works? In Advances in neural information processing

systems, pages 3320–3328.

Zhang, X., Yu, F. X., Chang, S.-F., and Wang, S. (2015).

Deep transfer network: Unsupervised domain adapta-

tion. arXiv preprint arXiv:1503.00591.

Zhong, E., Fan, W., Yang, Q., Verscheure, O., and Ren,

J. (2010). Cross validation framework to choose

amongst models and datasets for transfer learning. In

Joint European Conference on Machine Learning and

Knowledge Discovery in Databases, pages 547–562.

Springer.

Adversarial Alignment of Class Prediction Uncertainties for Domain Adaptation

231
