Cost-constrained Drone Presence Detection through Smart Sound

Processing

Joaqu

ın Garc

ıa-G

omez, Marta Bautista-Dur

an, Roberto Gil-Pita, Inma Moh

ıno-Herranz,

Miguel Aguilar-Ortega and C

esar Clares-Crespo

Department of Signal Theory and Communications, University of Alcal

a, Alcal

a de Henares 28805, Spain

Keywords:

Drone Detection, Smart Sound Processing, Feature Extraction, Feature Selection, Evolutionary Computation,

Cost Constraints.

Abstract:

Sometimes, drones lead to problems of invasion of privacy or access to restricted areas. Because of that, it is

important to develop a system capable of detecting the presence of these vehicles in real time in environments

where they could be used for malicious purposes. However, the computational cost associated to that system

must be limited if it has to work in an autonomous way. In this manuscript an algorithm based on Smart Sound

Processing techniques has been developed. Feature extraction, cost constrained feature selection and detection

processes, typically implemented in pattern recognition systems, are applied. Results show that it is possible

to detect the presence of drones with low cost feature subsets, where MFCCs and pitch are the most relevant

ones.

1 INTRODUCTION

The use of Unmanned Aerial Vehicles, also known

as drones, is on the rise in the society, mainly be-

cause of the advantages they offer. However, these

vehicles usually run into problems of invasion of pri-

vacy or access to hazardous areas (e.g. airports). For

this reason it is important to develop a system ca-

pable of detecting the presence of drones in partic-

ular environments where they could be used for mali-

cious purposes, such as households, public buildings

or restricted-access areas. In the state of the art there

are many studies which deal with this issue, trying to

detect and locate drones (Ganti and Kim, 2016). The

wide range of methods includes audio, video, temper-

ature, radar and radio frequency based detection.

Video detection systems can cover long distances,

but there is a difﬁculty when distinguishing between

drones and birds, even after including bird ﬂight pat-

terns which drones do not follow (Ganti and Kim,

2016). In addition, the computational cost of this kind

of systems is high. Talking about the temperature-

based detection, it is an efﬁcient solution if the drone

uses a propulsion engine, which usually appears in

ﬁxed-wing drones. However, most current drones are

made of plastic and their electric engines do not radi-

ate much heat.

Systems based on radar signal are useful for air-

craft detection, but the small size of the drones com-

plicates their detection. Some manuscripts are work-

ing on this alternative (Drozdowicz et al., 2016). Re-

lated to radio frequency based methods, they are use-

ful for the problem at hand since radio frequency is

the communication mode used between drones and

the remote controller (Nguyen et al., 2016). How-

ever, the use of Wi-Fi range (2.4-5 GHz) in no-license

channels causes the appearance of high interferences.

Some proposals have based their study on audio

information, mixed or not with video one. Some au-

thors propose the use of an array of microphones and

an infrared camera to get the information (Case et al.,

2008). They try to trace the path followed by the

drone through beamforming techniques. Others use

only one microphone, but they are focusing on detect-

ing a particular model of drone, so the results could

not be generalizable (King and Faruque, 2016). In one

manuscript, the authors analyze video information to

detect the difference between frames, and in this way

they track the drone movement, while they use audio

information for detecting the vehicle with a threshold

in frequency (Ganti and Kim, 2016). The problem is

that it is not very effective when background noise is

high. In addition, audio appears to be more reliable

for detecting drones according to some studies (Liu

et al., 2017).

This manuscript proposes a real-time implemen-

766

García-Gómez, J., Bautista-Durán, M., Gil-Pita, R., Mohíno-Herranz, I., Aguilar-Ortega, M. and Clares-Crespo, C.

Cost-constrained Drone Presence Detection through Smart Sound Processing.

DOI: 10.5220/0007556007660772

In Proceedings of the 8th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2019), pages 766-772

ISBN: 978-989-758-351-3

tation of an energy-efﬁcient system capable of detect-

ing drone presence in smart environments. We want

the system to work in an autonomous way, so com-

putational cost related to the clock frequency of the

processing units will be strictly constrained. In this

sense, evolutionary computation (i.e. genetic algo-

rithms) is proposed for selecting a reduced set of fea-

tures from the full set calculated previously, allowing

a good tradeoff between performance and computa-

tional cost.

2 SMART SOUND PROCESSING

(SSP) SYSTEM

In order to detect drone presence, our study will be

based on an efﬁcient system successfully used in other

applications, like violence detection (Bautista-Dur

et al., 2017). This is because this set includes fea-

tures like pitch, which can be useful for detecting the

frequency associated to the drone engine, as well as

the rotation speed, size and material of the propellers.

The system has the objective of studying solutions for

audio-based drone detection in real environments and

in real time, where the system has to make a decision

every T seconds. Fig. 1 shows the system diagram,

whose steps will be explained in the following sec-

tions.

Feature

Extraction

Feature

Selection

with

COST

CONSTRAINTS

Detector

BINARY

DECISION

Figure 1: Scheme of the system.

2.1 Feature Extraction

The objective of this step is to extract useful infor-

mation from the audio signal in the form of features.

There are several audio features that have demon-

strated to be really useful in other applications, funda-

mentally related to speech problems (Giannakopoulos

et al., 2006; Mohino et al., 2011; Gil-Pita et al., 2015).

In this manuscript we will apply this type of features

to the problem of drone detection. In this section a

theoretical description of the features will be made.

To extract the features, the audio segments of T sec-

onds are divided into M frames of L samples with an

overlap of S%. The following features have been con-

sidered:

• The Mel-Frequency Cepstral Coefﬁcients

(MFCCs). They are N parameters calculated

from the spectrum that are typically used for

speech recognition. With this measurement, a

compact representation of the spectral envelope is

obtained. The objective is to emulate the human

ear non-linear frequency response through a set

of ﬁlters on non-linearly spaced frequency bands

(Gil-Pita et al., 2015).

• The Delta Mel-Frequency Cepstral Coefﬁcients

(∆MFCCs). They are calculated differentiating

the previous MFCCs in two different time frames.

• The Pitch. This feature is related to the funda-

mental frequency and determines the tone of the

speech. It allows to distinguish a person from an-

other. In this manuscript the pitch is evaluated in

every frame through the autocorrelation of the er-

ror of a linear predictor with P coefﬁcients (Mo-

hino et al., 2011).

• The Harmonic Noise Rate (HNR). With this fea-

ture it is feasible to evaluate the purity of the

speech. It measures the relation between the har-

monic energy produced by the vocal cords and the

non-harmonic energy.

• The Ratio of Unvoiced time Frames (RUF). It

measures the presence or absence of clear or

strong speech. The computation consists of divid-

ing the number of time frames with detected pitch

by the total number of frames.

• The Short Time Energy (STE), which is the en-

ergy of the short speech segment. It is a simple

and effective parameter for both voiced and un-

voiced frames (Jalil et al., 2013).

• The Energy Entropy (EE). It allows to detect

changes in the energy level of the audio. It is use-

ful for detecting a quick emergence of a drone in

the environment due to rapid changes in the en-

ergy of the audio. To evaluate this measurement,

each time frame is divided into B blocks, and the

energy of each block is then measured.

• The Zero Crossing Rate (ZCR). It is one of the

most used audio features in time domain. To cal-

culate it, the number of sign changes is divided by

the total length of the frame.

• The Spectral Rolloff (SR). It is calculated in the

frequency domain and is deﬁned as the frequency

below which c% of the magnitude distribution

of Short Time Fourier Transform (STFT) coefﬁ-

cients are concentrated for a frame.

• The Spectral Centroid (SC) is the center of gravity

of the magnitude spectrum of the STFT.

• The Spectral Flux (SF) measures the spectral

changes between successive frames.

Cost-constrained Drone Presence Detection through Smart Sound Processing

767

Once these features have been extracted, some statis-

tics are applied to them (the mean and the standard

deviation).

2.2 Feature Selection with Cost

Constraints

If we want to get an energy-efﬁcient real time sys-

tem for detecting drone presence, it will have the re-

striction of consumption, as it will be implemented in

some place to work in an autonomous way. In this

scenario, computational cost is an important aspect

to consider. In order to calculate the computational

cost of our system, we have computed the resources

that each feature requires determining the number

of Floating Point Operations Per Second (FLOPS)

(Qian, 2015), which is directly related to the power

consumption of the device. The number of FLOPS of

the system will depend on the set of selected features,

so it must be taken into account which ones are used

in each case (Bautista-Dur

an et al., 2017).

Thus, the cost of each feature has been evaluated

and some equations are proposed with the objective

of generalizing the cost according to some parameters

that will be explained. As stated above, the feature

extraction process splits the audio frame of N

samples

(so that T = N

samples

/ f

, being f

the sampling fre-

quency) into M frames of L samples, with an overlap

between them of S%, so that:

M =



samples

S · L



(1)

Some aspects must be taken into account for the anal-

ysis. First of all, some features will have more impact

in cost than others (e.g. MFCCs or pitch-based ones).

In addition, some features need to apply the same pro-

cessing blocks, so their computation do not have to

be repeated. Considering the measurements of Sec-

tion 2.1, four processing blocks that are shared along

more than one measurement have been identiﬁed:

• The STFT is shared by the MFCCs, the ∆MFCCs,

the SR, the SC and the SF.

• The MFCCs are shared by the MFCCs and the

∆MFCCs.

• The pitch is shared by the HNR and the RUF.

• The energy is shared by the STE and the EE.

In Table 1 the four processing blocks and their

equations are shown. Four binary variables b

, b

and b

related to B

, B

and B

(the number of op-

erations associated to the previous processing blocks)

will be deﬁned to determine if the set of features se-

lected requires or not the evaluation of these blocks.

Thus, the total cost C will be calculated using Equa-

tion (2).

C =

∑

i=1

· B

∑

j=1

·C

, (2)

where C

is the additional cost of each feature and

is a binary value which indicates if the feature is

selected or not. Taking into account that the proposed

system makes a decision every T seconds, the FLOPS

can be evaluated.

As there are some features which are linked and

depend on others, we have grouped the measurements

into 8 groups: G

(including MFCCs and ∆MFCCs),

(including Pitch, HNR, and RUF), G

(STE), G

(EE), G

(ZCR), G

(SR), G

(SC) and G

(SF). The

groups, number of features of each measurement, val-

ues of b

, b

and b

, and the equations of addi-

tional cost C

associated to each measurement are de-

tailed in Table 2. There we can see a typical cost of

the problem at hand, considering each feature is se-

lected individually, so the shared blocks need to be

computed in each of them. The parameters used for

solving the equations are: B = 10 blocks, L = 512

samples, M = 31 frames, N = 25 MFCCs coefﬁcients,

P = 10 Levinson coefﬁcients and S = 50% overlap.

As it has been discussed, it is necessary to ﬁnd a

reduced set from the 117 features that allows obtain-

ing a good performance and controlling the compu-

tational cost of the system. For this purpose, evo-

lutionary algorithms have been implemented in the

manuscript (Haupt et al., 1998). The conﬁguration

of this algorithm includes the next parameters: 100

individuals, 10 parents, 90 regenerated sons, percent-

age of mutation of 2%, 30 generations, 10 repetitions

of the whole algorithm and minimization of the error

rate as adaptive function.

2.3 Detectors

To evaluate the results and make a decision about the

presence of drone sound, a detector has to be applied.

In the present case, two different detectors have been

used: the Least Squares Linear Discriminant (LSLD)

and a reduced version of the Least Squares Quadratic

Discriminant (LSQD). The computation of the two

detectors is shown in Equations 3 and 4. (Garc

ıa-

omez et al., 2016). They are obtained using the

Wiener-Hopf equations. (Van Trees, 2004)

y = w

∑

n=1

, (3)

y = w

∑

n=1

∑

n=1

∑

m=1

, (4)

ICPRAM 2019 - 8th International Conference on Pattern Recognition Applications and Methods

768

Table 1: Cost of the shared processing blocks.

Block Cost of the block (No. operations)

STFT B

= L(M − 1)(5log

L + 2) + 4L + 15

MFCCs B

= (L · S + 1)(M(2N + 5) + 10N + 23) + N(3N + 11) + N · M(2N + 7) + 29

Pitch B

= 2L · M(5log

L + P + 3) + M



P(2P

+ P + 2L + 1) − L



+ 1

Energy B

= M(2L + 3) − 4

Table 2: Details of the groups of features.

Group Caract No. feats b

Additional cost (No. operations) Typical cost (MFLOPS)

MFCCs 50 1 1 0 0 C

= 0 1.25

∆MFCCs 50 1 1 0 0 C

= N(M − 2) + 1 1.26

Pitch 2 0 0 1 0 C

= 0 2.21

HNR 2 0 0 1 0 C

= 9M 2.21

RUF 1 0 0 1 0 C

= M 2.21

STE 2 0 0 0 1 C

= 0 0.03

EE 2 0 0 0 1 C

= M (b2L/Bc + 3B −5) + 6B + 3 0.06

ZCR 2 0 0 0 0 C

= (6M + 1)(L −1) 0.10

SR 2 1 0 0 0 C

= M(5N + 8) + 2bM(L · S − 1)/3c 0.74

SC 2 1 0 0 0 C

= M (8N + L · S + 6) +L · S + 4 0.75

SF 2 1 0 0 0 C

= M (9N + 5) − 3N + 1 0.74

where x

and x

are the training patterns, w

and v

are the weights associated to them, w

is a bias term

and y is the combination of the training patterns. A

threshold will be applied to this combination to obtain

the binary decision about drone presence.

It is important to indicate that in the beginning

more complex detectors were considered (e.g. arti-

ﬁcial neural networks). However they were discarded

because the results were not as good as expected, due

to the fact that overtraining problems appear as the

dataset is not large enough.

3 RESULTS

To validate the system we have carried out some ex-

periments using a dataset of audio ﬁles. These audio

ﬁles have been divided in segments of T = 1 second,

which indicates how often a decision is made. All the

ﬁles have been resampled to a sampling frequency of

= 8,000 Hz. Each frame is divided in windows of

L = 512 length and S = 50% overlap between win-

dows, resulting in a total of M = 31 frames per seg-

ment. Then steps detailed in previous sections have

been followed, including feature extraction, feature

selection and detection.

The algorithm has been applied using a constraint

related to the computational cost. Some cost thresh-

olds measured in “Maximum number of Mega Float-

ing Operations Per Second” (MaxMFLOPS) have

been applied (0.5, 1, 1.5, 2, 2.5, 3, 3.5 and 4 MaxM-

FLOPS). This means that the sum of costs of the se-

lected features has to be below these values. The up-

per limit is never reached, since the cost associated to

the case of selecting all the features is below 4 MaxM-

FLOPS. Once the best features have been selected, a

trained detector makes the ﬁnal decision.

The datasets used in the state of the art are not

suitable for our problem for several reasons: they just

include a model of drone, or the environmental con-

ditions do not change. Because of that, we have used

a novel dataset that was developed in a previous work

(Garc

ıa-Gomez et al., 2017). In this dataset, drones

in motion and in a static position are included, as

well as different models of them (Cheerson CX10,

DJI Phantom 3, Eachine Racer 250, etc.). In order to

make the database more challenging, similar no-drone

sounds are included too (plane, helicopter, mower,

etc.). The main characteristics of the used database

are: total duration of 3671 seconds, duration of drone

sound of 1913 seconds, percentage of drone presence

of 50.08%, 36 fragments, minimum audio length of

6 seconds and maximum audio length of 316 sec-

onds. More details about the dataset can be found in

(Garc

ıa-Gomez et al., 2017).

The method of validation implemented has been

a tailored version of k-fold cross-validation, since it

allows avoiding loss of generalization of the results.

The data is divided in k subsets, so that each subset is

used for testing and the remaining k − 1 are used for

training. In the case at hand, 36 folds with different

size have been used, each fold containing a different

audio ﬁle. In that way, we ensure that data from the

same model of drone or with the same environmental

conditions are not used both for training and testing at

the same time.

Cost-constrained Drone Presence Detection through Smart Sound Processing

769

3.1 Analysis of the Computational Cost

Constraints

Now we will evaluate the effect of the limits in the

computational cost available, as well as the groups of

features more selected and useful. Table 3 displays

the error rate and the percentages of appearance (se-

lection rates) of the groups, in function of the maxi-

mum cost established in MFLOPS, using the LSLD.

The error rate is the sum of the decisions where the

system says there is drone presence and it fails be-

cause there is no drone in the environment, and vice

versa. It has been considered as appearance the se-

lection of one or more features from the group. The

same is displayed in Table 4 using LSQD.

At the beginning, the system selects groups G

and G

in almost 100% of the cases because of

the low threshold imposed (0.5 MaxMFLOPS). When

we increase this value to 1 MaxMFLOPS, the spectral

features appear. If the restriction is established in 1.5

MaxMFLOPS, the MFCCs start to be selected. When

we reach higher values of MFLOPS (3.5), group G

is selected, which is composed of features related to

the pitch. The case of 4.0 MaxMFLOPS allows the

algorithm to select whatever it needs, because the sum

of all the costs is lower than this value.

In general LSQD works better than LSLD, since

the error rate is lower in most cases, specially when

the cost constraint is very limiting. The importance

of some features is reﬂected in the table. For in-

stance, when group G

-MFCCs and ∆MFCCs- ap-

pears (from 1.5 MaxMFLOPS onwards) its appear-

ance is 100%. In fact, the parameter that best reﬂects

the importance of G

is the error rate, since it falls

signiﬁcantly when that group appears (in the case of

LSLD, from 57.5% of error to 28.5%, and in the case

of LSQD, from 41.9% to 23.4%). Something simi-

lar happens when G

-pitch, HNR and RUF- appears

(from 3.5 MaxMFLOPS onwards). Again, its selec-

tion rate is 100% and its contribution to the perfor-

mance of the system is really signiﬁcant (error falls

from 30.1% to 15.7% with LSLD and from 23.8% to

15.5% with LSQD). The importance of pitch could be

directly related to the particular frequency that drones

present, which is dependent on the size of the device,

the number of blades and the speed.

With regard to the rest of features, G

seems to

work well only when using LSLD because of its high

selection rate. The same applies to G

, but when us-

ing LSQD. Other features seem to be more robust to

changes in the detector used (G

, G

and G

), since

they present high selection rate for both detectors.

3.2 Analysis of the Model of Drone and

Other No-drone Sounds

Then, the error obtained in each of the models in-

cluded in the drone database will be analyzed. Table

5 shows the different models of drone, the duration of

each of them and the error obtained. In these results

the best constraint and detector in terms of error have

been selected from the previous cases (13.4% of error

with 4.0 MFLOPS and LSLD).

From Table 5 it can be seen that Parrot AR is

the best detected model (0% of error rate), while the

worst one is the UDI 817 (50% of error). This could

be because of its minor presence in the database. As

it can be observed, a large proportion of the database

belongs to DJI Phantom 3, which gets an error rate of

12.2%.

As mentioned previously, the dataset was devel-

oped including no-drone sounds present in smart city

environments, which can be easily confused with the

sound of a drone. In Table 6 the no-drone sounds, the

duration of them and the error obtained are detailed.

From the results it can be observed that the most

confusing sounds are the ﬁre siren, radial saw and

construction work (with error rates of 40.7%, 36.4%

and 22.5%, respectively). This could be because the

fundamental frequency of these sounds is in the range

of the drone frequency (one or two hundreds of Hz).

Likewise, other sounds like helicopter, excavator, mo-

torbike or plane are really well detected as no-drone

sounds, with error rates below 3%. This is especially

interesting in the case of other aerial vehicles (heli-

copter, plane), since they could be more conﬂicting

with drones as they share the same space of work (the

sky) and they could appear at the same time.

4 CONCLUSIONS

The aim of this work is to develop a system capa-

ble of detecting the presence of drones in real time.

To this end, different experiments related to Smart

Sound Processing (SSP) have been carried out, in-

cluding feature extraction, feature selection and de-

tectors. The objective of the algorithms is to minimize

the error rate while controlling the computational

cost. This has been reached through a constraint in

the number of operations per second (MFLOPS).

Related to the features selected, the results show

that MFCCs and features related to pitch are the best

subsets of features for the problem at hand, for both

linear and quadratic detectors. Depending on the de-

sired ﬁnal error rate and on the resources of the pro-

cessing device, a compromise should be reached be-

ICPRAM 2019 - 8th International Conference on Pattern Recognition Applications and Methods

770

Table 3: Cost, error rate and probability of appearance of the features groups with LSLD.

MaxMFLOPS (MFLOPS) 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0

Error Rate (%) 52.3 57.5 28.5 30.4 31.9 30.1 15.7 13.4

(MFCC+∆MFCC) 0.0 0.0 100.0 100.0 100.0 100.0 100.0 100.0

(Pitch+HNR+RUF) 0.0 0.0 0.0 0.0 0.0 0.0 100.0 100.0

(STE) 73.9 80.8 89.1 93.7 100.0 100.0 25.7 100.0

Selection G

(EE) 100.0 100.0 100.0 100.0 100.0 100.0 0.0 100.0

Rate (%) G

(ZCR) 91.7 13.6 84.7 83.2 89.0 91.6 0.0 95.3

(SR) 0.0 100.0 100.0 100.0 100.0 100.0 74.3 93.9

(SC) 0.0 92.9 96.1 100.0 100.0 91.3 74.3 100.0

(SF) 0.0 70.2 35.6 40.9 50.6 53.0 15.8 22.9

Table 4: Cost, error rate and probability of appearance of the features groups with LSQD.

MaxMFLOPS (MFLOPS) 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0

Error Rate (%) 37.8 41.9 23.4 24.2 22.0 23.8 15.5 15.2

(MFCC+∆MFCC) 0.0 0.0 100.0 100.0 100.0 100.0 100.0 100.0

(Pitch+HNR+RUF) 0.0 0.0 0.0 0.0 0.0 0.0 100.0 100.0

(STE) 18.7 11.0 0.0 0.0 0.0 0.0 0.0 0.0

Selection G

(EE) 78.4 46.1 100.0 100.0 100.0 100.0 0.0 100.0

Rate (%) G

(ZCR) 100.0 100.0 95.9 96.4 95.9 100.0 0.0 88.6

(SR) 0.0 100.0 100.0 100.0 100.0 100.0 100.0 100.0

(SC) 0.0 92.9 74.0 69.9 61.4 67.1 95.4 91.3

(SF) 0.0 100.0 100.0 100.0 100.0 100.0 61.2 96.6

Table 5: Error Rate of the different models of drones in-

cluded in the database.

Model of drone Duration (s) Error Rate (%)

DJI Phantom 3 1573 12.2

Cheerson CX10 284 13.0

Eachine Racer 250 171 21.6

Parrot AR 103 0.0

UDI 817 17 50.0

Table 6: Error Rate of the no-drone sound included in the

database.

No-drone sound Duration (s) Error Rate (%)

Plane 128 3.1

Helicopter 124 0.0

Hair clipper 249 14.1

Construction work 316 22.5

Excavator 147 0.0

Motorbike 150 1.3

Mower 268 8.2

Radial saw 22 36.4

Fire siren 135 40.7

Drag racer 55 7.1

tween the two parameters. On the one hand, if the sys-

tem requires high performance (13.4% of error rate),

the solution should include both the MFCCs and the

features related to pitch, with at least 3.5 MFLOPS.

On the other hand, a worst solution in terms of er-

ror rate could be reached (23.4%), but only using 1.5

MFLOPS in the system. Regarding to the detectors,

the results are better in quadratic case, specially when

the cost constraint is very restrictive.

In conclusion, the experiments developed show

that it is feasible to implement a real time system ca-

pable of detecting drone presence in an autonomous

way. That is possible thanks to the low cost features

proposed in the manuscript, which can be supported

by nowadays microprocessors.

ACKNOWLEDGEMENTS

This work has been funded by the University of Al-

cal

a under Project CCGP2017-EXP/060.

REFERENCES

Bautista-Dur

an, M., Garcıa-G

omez, J., Gil-Pita, R.,

Mohıno-Herranz, I., and Rosa-Zurera, M. (2017).

Energy-efﬁcient acoustic violence detector for smart

cities. Delta, 1:25.

Case, E. E., Zelnio, A. M., and Rigling, B. D. (2008).

Low-cost acoustic array for small uav detection and

tracking. In Aerospace and Electronics Conference,

2008. NAECON 2008. IEEE National, pages 110–

113. IEEE.

Drozdowicz, J., Wielgo, M., Samczynski, P., Kulpa,

K., Krzonkalla, J., Mordzonek, M., Bryl, M., and

Jakielaszek, Z. (2016). 35 ghz fmcw drone detection

Cost-constrained Drone Presence Detection through Smart Sound Processing

771

system. In Radar Symposium (IRS), 2016 17th Inter-

national, pages 1–4. IEEE.

Ganti, S. R. and Kim, Y. (2016). Implementation of de-

tection and tracking mechanism for small uas. In Un-

manned Aircraft Systems (ICUAS), 2016 International

Conference on, pages 1254–1260. IEEE.

Garc

ıa-G

omez, J., Bautista-Dur

an, M., Gil-Pita, R.,

Mohino-Herranz, I., and Rosa-Zurera, M. (2016). Vi-

olence detection in real environments for smart cities.

In Ubiquitous Computing and Ambient Intelligence,

pages 482–494. Springer.

Garc

ıa-Gomez, J., Bautista-Dur

an, M., Gil-Pita, R., and

Rosa-Zurera, M. (2017). Feature selection for real-

time acoustic drone detection using genetic algo-

rithms. In Audio Engineering Society Convention 142.

Audio Engineering Society.

Giannakopoulos, T., Kosmopoulos, D., Aristidou, A., and

Theodoridis, S. (2006). Violence content classiﬁca-

tion using audio features. In Hellenic Conference on

Artiﬁcial Intelligence, pages 502–507. Springer.

Gil-Pita, R., L

opez-Garrido, B., and Rosa-Zurera, M.

(2015). Tailored mfccs for sound environment clas-

siﬁcation in hearing aids. In Advanced Computer

and Communication Engineering Technology, pages

1037–1048. Springer.

Haupt, R. L., Haupt, S. E., and Haupt, S. E. (1998). Practi-

cal genetic algorithms, volume 2. Wiley New York.

Jalil, M., Butt, F. A., and Malik, A. (2013). Short-time en-

ergy, magnitude, zero crossing rate and autocorrela-

tion measurement for discriminating voiced and un-

voiced segments of speech signals. In Technological

Advances in Electrical, Electronics and Computer En-

gineering (TAEECE), 2013 International Conference

on, pages 208–212. IEEE.

King, J. M. and Faruque, I. (2016). Small unmanned aerial

vehicle passive range estimation from a single micro-

phone. In AIAA Atmospheric Flight Mechanics Con-

ference, page 3545.

Liu, H., Wei, Z., Chen, Y., Pan, J., Lin, L., and Ren, Y.

(2017). Drone detection based on an audio-assisted

camera array. In Multimedia Big Data (BigMM), 2017

IEEE Third International Conference on, pages 402–

406. IEEE.

Mohino, I., Gil-Pita, R., and

Alvarez, L. (2011). Stress de-

tection through emotional speech analysis. Advances

in Computer Science, pages 233–237.

Nguyen, P., Ravindranatha, M., Nguyen, A., Han, R., and

Vu, T. (2016). Investigating cost-effective rf-based de-

tection of drones. In Proceedings of the 2nd Workshop

on Micro Aerial Vehicle Networks, Systems, and Ap-

plications for Civilian Use, pages 17–22. ACM.

Qian, H. (2015). Counting the ﬂoating point operations

(ﬂops), matlab central ﬁle exchange, no. 50608, ver.

1.0, retrieved june 30, 2015.

Van Trees, H. L. (2004). Detection, estimation, and modu-

lation theory, part I: detection, estimation, and linear

modulation theory. John Wiley & Sons.

ICPRAM 2019 - 8th International Conference on Pattern Recognition Applications and Methods

772
