SMMDecoy: Detecting GPU Keyloggers using

Security by Deception Techniques

Ijlal Loutﬁ

Informatics Department, University of Oslo, Gaustadalleen 23B, Oslo, Norway

Keywords:

Keylogger, System Management Mode, Deception, Detection.

Abstract:

Human computer interaction is a fundamental part of the modern computing experience. Everyday, millions

of users rely on keyboards as their primary input interface, and use them to enter security sensitive information

such authentication credentials. These can be passwords, but also multi-authentication factors received from

other devices, such as One Time Passwords and SMS’s. Therefore, the security of the keyboard interface is

critical. Unfortunately, both PS/2 and USB keyboards have open buffers which are vulnerable to snifﬁng by

keyloggers. This paper focuses on the detection of the stealthiest variance of keyloggers, which is deployed

within IO devices ﬁrmware, such as GPUs. We propose to use principles of security by deception: We inject

decoy credentials into the open keyboard buffers, and give GPU keyloggers the opportunity to sniff them.

These decoy credentials are then sent to a remote server that can raise an alarm anytime an attacker uses them.

We assume a strong adversary that can infect both the GPU and the kernel. Therefore, we propose to deploy

the solution within System Management Mode, and leverage Intel Software Guard Extensions for network

communication. Both SMM and SGX are hardware protected against the OS and DMA, and provide thus

strong security guarantees to our solution, which we name SMMDecoy.

1 INTRODUCTION

Despite recent advances in user authentication, the

most commonly deployed mechanism in the internet

today is still passwords. Everyday, millions of users

rely on their username/password credentials to gain

access to security-sensitive digital services. How-

ever, password-based authentication is routinely com-

promised. The main attack vectors can be classiﬁed

in three categories: 1) the server side where pass-

word ﬁles are stored, 2) users’ bad cognitive habits

of choosing weak and redundant passwords or falling

prey to social engineering 3) and ﬁnally, vulnera-

bilities within end-user devices where passwords are

stored and operated on (Herley, 2009) (Florencio and

Herley, 2007).

As a matter of fact, over the past decade, we have

witnessed many password disclosures of high pro-

ﬁle companies such as Sony, Yahoo, and LinkedIn.

Analysis of these breaches revealed that many of

these online service providers implement bad security

practices, such as using unsalted hashes, and weak

deprecated hashing algorithms. The silver lining of

this slew of high proﬁle password compromises, is

the increased awareness about the issues, which has

prompted many companies to review and harden their

password servers’ security. Consequently, this has

been increasing the cost of attack of database servers,

and thus, turning the attention of attackers to endpoint

devices as a more attractive attack vector (Thomas

et al., 2017) (Holz et al., 2009).

Furthermore, the adoption of multi-factor authentica-

tion by many online service providers has further mo-

tivated attackers to focus on endpoints. For example,

many banks distribute One Time Password generators

(OTP) to their users, while others rely on out-of-band

methods such as SMS to send second factor authenti-

cators. However, users still need to input these second

factors into the same endpoint device where the pass-

word is entered. This mechanism consolidates the

whole authentication process into one attack vector,

aka the endpoint device, where they can be exposed

to a host of attacks. One such critical endpoint attack

vector is the keyboard device. Since users almost ex-

clusively use it as an input channel, it is of uttermost

importance that it preserves the conﬁdentiality and in-

tegrity of users’ data (Jacob, 1996).

580

Loutﬁ, I.

SMMDecoy: Detecting GPU Keyloggers using Security by Deception Techniques.

DOI: 10.5220/0007578505800587

In Proceedings of the 5th International Conference on Information Systems Security and Privacy (ICISSP 2019), pages 580-587

ISBN: 978-989-758-359-9

1.1 Problem Statement

Unfortunately, keyboards suffer from a big snifﬁng

problem. This is due to their hardware interface,

which is open for direct reading by privileged soft-

ware as well as DMA capable devices. This is true for

both PS/2 and USB keyboards (Ortolani and Crispo,

2012).

• for PS/2 keyboard, the data output buffer which

resides on the chipset keyboard controller and

is used to transfer scan codes upon a key

press/release, is exposed to the platform host

(Zhang et al., 2015b).

• For USB keyboards, the data transaction buffers

which are memory mapped are also exposed to the

host(Ladakis et al., 2013).

One critical malware category that takes advantage of

this insecure keyboard interface is keyboard sniffers,

more commonly referred to as keyloggers. Once they

infect a platform, keyloggers log keyboard activity,

and leak data to remote third parties. As documented

in numerous disclosed attacks, keyloggers pose a se-

rious threat against personal and ﬁnancial data, de-

spite continuous efforts to guard against them. For

instance, keyloggers have been used to steal 10775

unique bank account credentials for customers who

have shopping at Barnes and Noble stores over a pe-

riod of 7 months (Schmidt, 2012) . Even governmen-

tal agencies have relied for years on hard disk based

keylogges, as documents by recent leaks (Thomson,

2013) .While keyloggers can be implemented on ei-

ther hardware or software, we focus in this paper on

the latter, as it is much more widespread and assumes

a stronger attacker. Software keyloggers can be clas-

siﬁed under three categories: (Ortolani and Crispo,

2012):

• User-level Keyloggers: They often hook into

application-level API, but can also reliably de-

tected, through more privileged system level

hook-based techniques.

• Kernel-level Keyloggers: they hook into kernel-

level API, and by doing so, inadvertently mod-

ify the kernel’s code base, and thus its signa-

ture. Therefore, they can often be detected based

on integrity veriﬁcation and code attestation tech-

niques.

• Firmware Level Keylogger: They can exploit

ﬁrmware level vulnerabilities within the BIOS or

any IO device, especially ones which are open

to general computations such as modern GPUs.

Therefore, they live outside of the CPU execution

environment, and can evade its detection mecha-

nisms. They can rely on the IO device DMA ca-

pabilities to directly read and sniff the keyboard’s

data registers.

In this paper we focus on ﬁrmware level keyloggers,

and formulate our research questions as follows:

How can we reliably detect the presence of

stealthy GPU keyloggers on endpoint devices? This

research question is important the following reasons:

• The increased complexity of devices functional-

ity, which is correlated with an increased com-

plexity of its corresponding ﬁrmware, has made

the ﬁrmware attack vector signiﬁcantly larger.

• Many ﬁrmware malware categories, such keylog-

gers, do not need to hook into any kernel API

or structures. Therefore, system level detection

mechanisms such as code integrity and control

ﬂow integrity are inefﬁcient against it.

• CPU-based monitoring solutions, e.g. antivirus

systems, cannot monitor code residing on other

execution environments within other devices.

• The increasing ease of deploying ﬁrmware Mal-

ware. This is especially true for devices such

as GPUs, which have become open to general-

purpose computations. In fact, GPUs have been

traditionally used to process graphics rendering

code, relieving the CPU this way from these

heavy computations. However, the popularity of

the gaming and AI industries, and their increas-

ing demand for more GPU computational power

and functionality, has made GPU general pur-

pose computing much more extensive. Attacker

are naturally interested in exploiting this large at-

tack vector. Furthermore, 99 percent of world-

wide GPUs support GPGPU computations, which

greatly increases the infection ratio of GPU mal-

ware. This is different from previous ﬁrmware

attacks, which had to be more targeted, and thus

limited to smaller infection ratios (Ladakis et al.,

2013).

*For the remainder of this paper, we will use GPUs as

an example for devices’ ﬁrmware level software.

The solution proposed in this paper is inspired by

deception-based techniques, which are traditionally

used within the server side in order to harden the de-

tection of password database ﬁles breaches. An ex-

ample of such solutions are honeywords, where each

user is associated with one legitimate password, and n

fake ones. This directly increases the effort required

by attackers to brute force passwords. Furthermore,

in case a fake one is used, it automatically triggers

an alarm signalling a potential breach (Wang et al.,

2018).

Similarly, this paper’s main intuition is that we

need to deploy a transparent mechanism which can

SMMDecoy: Detecting GPU Keyloggers using Security by Deception Techniques

581

inject intentionally crafted noise, which mimics au-

thentication credentials, to the keyboard’s buffer, and

allow any potential GPU keyloggers to monitor and

sniff it. SMMDecoy would subsequently send a list

of injected decoy credentials to a remote third party.

We propose to deploy such a solution within System

management mode, SMM, in order to take advantage

of its integrity and transparency guarantees. We also

propose to use Intel Software Guard Extension remote

attestation capabilities to send decoy credentials over

the internet. We call our solution, SMMDecoy. The

rest of the paper is organized as follows: section 2

presents the necessary background. We then intro-

duce the threat model, the solution design, and its

message ﬂow. An overview of previous related work

is presented next. The paper closes with a set of con-

clusions as well as an overview of open questions and

suggested future work.

2 BACKGROUND

2.1 Keyboards Hardware Interface

Keyboards are such a proliﬁc part of everybody’s

computing experience. They are also a critical secu-

rity component, since they are used as the main input

channel on many types of endpoint devices and are

relied upon to communicate security sensitive infor-

mation to the system software and eventually to our

trusted online service providers. Examples of such

information are authentication credentials. There are

several ways of connecting a keyboard to an x86 In-

tel platform: they can be either wireless or wire-base.

For the latter, we can further classify the connections

as either PS/2 or USB based. While the latter rely

on a serialized protocol, their interface to the host is

different:

• The PS/2 Keyboard interface is composed of key-

board processor which resides inside the keyboard

itself, and a keyboard controller which is part of

the host chipset. The interface of the keyboard

controller has 2 pairs of output buffers in the di-

rection of the CPU, and 1 pair in the direction of

the keyboard. The output buffer is used to transfer

the scan code if a key is pressed. It is readable by

any software and causes keyboard snifﬁng prob-

lem (Brouwer, 2009).

• USB based keyboard don’t have a chipset-resident

keyboard controller. They have instead a host con-

troller and a root hub. The host controller is rep-

resented by a set of buffers and structures, which

are mapped to main memory, and are accessible

through a set of system registers, also creating a

snigging vulnerability (Brouwer, 2009).

2.2 Scan Codes

“A Scan Code is a data packet that represents the state

of a key. If a key is pressed, released, or held down,

a scan code is sent to the computers onboard key-

board controller. There are two types of scan codes:

Make Codes and Break Codes”, which are used for

the events of key press or release. For every keyboard

key, there exists a unique make code and break code.

When a user presses a key on the keyboard, a scan

key is sent to the keyboard chipset-resident controller,

which then buffers it on the output data buffer. It then

raises the Interrupt request line, which will cause the

IRQ 1 to be ﬁred if it is not masked. When the inter-

rupt is scheduled, the corresponding keyboard handler

reads the output buffer and converts the scan codes

into their corresponding key value. It is important to

note that the scan codes within the output buffer can

be read by software, even outside the interrupt han-

dler procedure, and this is the crux of the keyboard

snifﬁng challenge (Mike, 2009) (Brouwer, 2009) .

2.3 System Management Mode

System Management Mode, SMM, is a highly priv-

ileged x86 CPU mode. SMM code is part of the

BIOS code that resides on the SPI ﬂash memory.

During the system boot up and before the operat-

ing system is loaded, the BIOS loads SMM into a

hardware protected memory area referred to as SM-

RAM, and which is not addressable from any other

CPU mode, including kernel and VMX modes (Zhang

et al., 2015a). SMM implements a number of SMI

handlers, which traditionally handle system control

functions, such as power management. In order to ex-

ecute SMI handlers, an SMM pin should be asserted,

which will then trigger an SMM interrupt. Before the

system switches to SMM mode, the CPU state is se-

curely saved into SMRAM, so that it can return to it

upon exiting SMM. This makes SMM highly trans-

parent to all privileged system level software. This

feature has been recently motivating many novel ways

of using SMM for non-traditional purposes, e.g. de-

bugging and system introspection (Delgado and Kar-

avanic, 2018).

2.4 Software Guard Extensions

Intel’s SGX are security extensions which are come as

part newer Intel X86 CPUs. Its main aim is to instan-

tiate an isolated trusted execution environment within

ICISSP 2019 - 5th International Conference on Information Systems Security and Privacy

582

the user space, called an enclave. Enclave code and

data reside in specialized protected memory called en-

clave page cache (EPC), which encrypted, and hard-

ware protected. No privileged mode code can access

the enclave, including the OS and hypervisor. SGX

enclaves also rely on the intel management engine

EPID group identity to establish a remote attestation

protocol with Intel attestation servers, and through

it to third party service providers (Van Bulck et al.,

2017).

3 SOLUTION OVERVIEW

3.1 Threat Model

SMMDecoy assumes an active attacker who has un-

limited computing resources and can exploit zero-day

vulnerabilities of the host OS and user level applica-

tions. It also assumes that the GPU is compromised,

and so are all other I/O devices, with the exception

of the keyboard. Therefore, the only trusted compo-

nents of the system, are the BIOS and the keyboard.

SMMDecoy requires BIOS to be trusted only upon

boot up, and not during runtime. We also assume that

the attacker does not have physical access to the ma-

chine. We do not consider Denial-of-Service (DoS).

The BIOS is trusted because newer X86 platforms

are equipped with a Static Root of Trust of Measure-

ment, SRTM, with a corresponding secure implemen-

tation of a Core Root of Trust of Measurement, which

can ensure the code integrity of the BIOS upon boot.

Some solutions such as HP SureStart also ensure that

BIOS recovery as well, in case a code integrity com-

promise is detected.

3.2 High Level Architecture

The intuition behind SMMDecoy is to inject specially

crafted noise which mimics genuine authentication

credentials into the keyboard output buffers. We as-

sume that potential ﬁrmware keyloggers will be mon-

itoring the buffers. We will then communicate these

decoy credentials to relevant remote third parties. If

we detect any authentication attempt using any of the

reported decoy credentials, an alarm should be raised.

Such a detection mechanism would subsequently pro-

vide a wealth of information about how the malware

attack space, and the platforms from which it spreads.

Thus, the requirements of such a solution are as fol-

lows:

1. SMMDecoy should be implemented within a sys-

tem component that would allow it to be transpar-

ent to both the OS kernel and to the GPU malware.

2. The decoy authentication generation algorithm

should mimic real world passwords as much as

possible.

3. SMMDecoy should provide a mechanism for

communicating with third party remote servers

securely.

Figure 1: SMMDecoy Architecture: Trusted Components

in Green.

As ﬁgure 1 illustrates, SMMDecoy is made up of

two parts:

• SMMDecoy SMI handler :it is the trusted part,

and is used to generate decoy credentials, inject

them into the buffer interface, and then report

them to a remote server.

• SMMDecoy SGX enclave; It used to establish an

end-to-end secure channel between SMM and a

remote server, which will be responsible for rais-

ing alarms when a decoy credential is used by at-

tackers.

3.3 SMMDecoy Message Flow

At a conceptual level, SMMDecoy adopts the same

architecture for both PS/2 and USB keyboards. How-

ever, their interfaces are different and so are their

implementation details. We present SMMDecoy for

each keyboard separately.

Step 0: This is a common step for both implemen-

tations, and it takes place before the deployment of the

solution. We need to customize the BIOS ﬁrmware,

and add to it the SMMDecoy SMI interrupt. If this so-

lution is deployed within an enterprise environment,

this can be done as part of the platform provisioning

by the IT department. Upon system boot up, SM-

MDecoy SMI will be loaded securely into SMRAM.

From this point on, SMMDecoy message ﬂow will di-

verge depending on the keyboard connection, PS/2 or

USB, which can be detected upon boot up.

SMMDecoy: Detecting GPU Keyloggers using Security by Deception Techniques

583

3.3.1 PS/2 Message Flow

• In step 1, SMMDecoy SMI generates fake user

authentication credentials, which mimic legiti-

mate credentials (more details in section 4.5), and

converts them into scan codes.

• In step 2, SMMDecoy SMI is triggered based on

A timer. The system then enters SMM modes,

saves the CPU system state, as well the keyboard

buffer content into SMRAM. o SMIDecoy then

sends a 0xD2 command into the keyboard control

allows anything that is subsequently written into

the output buffer to appear as if it was generated

by the keyboard.

• step 3, SMMDecoy decoy injects the scan code

corresponding to the generated Decoy credentials

into the keyboard data output buffer, by writing

into address 0x60.

• In step 4, and after enough time elapsed to al-

low any potential ﬁrmware keylogger to sniff the

keyboard output buffer, SMMDecoy SMI restores

the state of the keyboard buffer, and exits SMM

mode. This restores the CPU state, and gives back

control to the OS so that it can resume its normal

execution.

• In Step 5, SMMDecoy periodically communicates

the list of decoy credential used to a remote server.

We differ the details of this step to section 3.7.

Figure 2: PS/2 SMMDecoy Message Flow.

3.4 USB Keyboard

• In step 1, SMMDecoy searches the system mem-

ory in order to ﬁnd the memory address for the

system keyboard buffer. In Linux, an attached

USB device is represented by a USB Request

Block (URB) structure, deﬁned in the linux/usb.h

header ﬁle of the Linux source tree. The keyboard

buffer is part of this URB structure. The SMI then

saves the physical address so as it can properly

access it (Ladakis et al., 2013).

• In step 2, SMMDecoy SMI generates decoy

credentials, which mimic legitimate credentials

(more details in section 3.6), and converts them

into scan codes. SMMDecoy SMI injects the scan

codes corresponding to the generated Decoy cre-

dentials into kernel keyboard bugger, which it ad-

dresses using its physical address.

• In step 3, and after enough time elapsed to al-

low any potential ﬁrmware keylogger to sniff the

keyboard output buffer, SMMDecoy SMI restores

the state of the keyboard buffer, and exits SMM

mode. This restores the CPU state, and gives back

control to the OS so that it can resume its normal

execution.

• In Step 4, SMMDecoy periodically communicates

the list of decoy credential used to a remote server.

We differ the details of this step to section 3.7.

3.5 Writing into the Buffer

For both the PS/2 and USB keyboards, we mentioned

that the SMMDecoy SMI injects decoy credentials

into either the output buffer of the system buffer.

However, this is an abstraction, since the buffer size

is limited and would require multiple coordinated

writes. For instance, the Linux keyboard buffer has

16 bytes, and each scan code is 3 bytes long. There-

fore, SMIDecoy is expected to perform multiple con-

secutive writes into the buffer (Mike, 2009).

3.6 Generating Fake Credentials

The injected decoy credentials need to be statistically

indistinguishable from genuine credentials. This can

be achieved by encoding password generation poli-

cies into the SMMDecoy SMI handler, such as using a

combination of characters and numbers, and having a

minimum password length. Furthermore, we can dy-

namically update this algorithm with contextual user

speciﬁc data, that the SMMDecoy handler would col-

lect from the system. Such as other passwords used

by the user, his name/ID. . . etc

3.7 Establishing a Secure Channel

between SGX Enclave and SMM

Deception techniques are useful only if we are able

to detect the decoy credentials being used or leaked

by potential malware at some point in time. For SM-

MDecoy, this can happen at two points:

• Local detection: SMM can choose well-crafted

patterns for the decoy credentials it injects. There-

fore, it could also intercept all outgoing networks

ICISSP 2019 - 5th International Conference on Information Systems Security and Privacy

584

packets and look for the same pattern. Such solu-

tions have been previously explored in the litera-

ture and are not the focus on this paper (Ortolani

et al., 2010)

• Remote detection: SMMDecoy can send the in-

jected decoy credentials to a remote server, which

might be the service provider whose credentials

we have been injecting into the keyboard buffer.

While the actions the remote server takes upon

detection of a used decoy credential are outside

of the scope of the paper, we discuss a number

of options here for the same of completeness. In

fact, decoy credentials can be used to augment an

already existing honeyword implementation. In

this case, SMMDecoy will increase the probabil-

ity of the attacker choosing a decoy honeyword to

authenticate to the server provider. Furthermore,

unlike a traditional honeyword which would only

signal the existence of a breach, SMMDecoy re-

veals a wealth of information about the malware

attack vector and the platforms from which it is

spreads. Decoy credentials could also be used as a

standalone honeyword where decoy accounts are

provisioned in order to allow the attacker to log

into them, and leave traces of their attack details,

such as the amount of money they transfer.

We have considered two approaches to achieving the

remote detection:

• Porting trusted network drivers into SMM.

• Relying on Intel SGX remote attestation.

While SMMDecoy proposes to use intel SGX, we dis-

cuss both approaches subsequently for completeness.

3.7.1 SMM Trusted Network Drivers

If SMMDecoy wants to send data over the network,

it needs to make use of the network drivers which

are part of OS. However, the latter is assumed to be

malicious within our threat model. This question has

been a common challenge for many SMM based so-

lution. One way it has been solved is by porting

commodity drivers into SMRAM. This has been pos-

sible because SMM mode is similar to kernel mode

where privileged CPU instructions are available. Au-

rora authors also argue that the mechanism of inter-

rupt rerouting helps SMM driver design concentrate

on the interrupt handling rather than device initializa-

tion or resource management, making it thus faster

(Liang et al., 2018).

3.7.2 Intel SGX Remote Attestation

In this approach, we propose to keep the SMMDecoy

SMI simple, and rely on the remote attestation capa-

bilities of Intel SGX to communicate with a remote

server. This approach also respects the threat model,

since Intel SGX enclaves are hardware protected from

the operating system.

Provisioning. Key provisioning happens once, and

it involves the following steps:

1. Authenticating SMMDecoy to Intel Remote

Server.

• During start-up, the BIOS uses the Intel remote

server PKI to establish a secure channel with it.

• The BIOS computes a token on the SMMDe-

coy to be loaded into SMRAM and sends its

hash signature to verify its integrity and prove

its identity.

2. Authenticating SGX enclave to Intel Remote

Server, using intel SGX remote attestation

3. The enclave generates a symmetric secret key K

which it securely forwards to the IAS, which se-

curely forwards the key to the SMMDecoy SMI

on the same platform as the SMMEnclave.

At this point, a unique session has been successfully

established.

Communication. Once a shared secret key is estab-

lished between SMMDecoy enclave and SMI, the in-

terrupt is ready to secretly send decoy credentials to

the enclave. The enclave then engages in a standard

remote attestation protocol and establishes a secure

channel with the remote server.

3.7.3 Proposed Implementation Details

We propose to use Coreboot as a BIOS distribution to

implement SMMDecoy on. Coreboot is “an extended

ﬁrmware platform that delivers a lightning fast and

secure boot experience on modern computers and em-

bedded systems. As an Open Source project, it pro-

vides auditability and maximum control over technol-

ogy”(Zhang, 2013). This is important for us to be able

to implement and deploy the custom SMMDecoy In-

terrupt handler into the platform.

4 RELATED WORK

In this section we discuss three lines of related work:

GPU malware detection, SMM based systems and se-

curity by deception.

In order to detect stealthy GPU malware, prior

work suggested monitoring the side effects the mal-

ware generates, as CPU solutions are unable to access

SMMDecoy: Detecting GPU Keyloggers using Security by Deception Techniques

585

and scan the GPU. However, these measurements are

only reliable in the case of malware which performs

bulk DMA transfers, which is not the case for GPU

keyloggers. Other work suggests using the cuda-gdb

real time debugging capabilities in order to monitor

the GPU’s access patterns. However, GPU malware

could remote debug points from its code base (Em-

bleton et al., 2008).

SMM has been traditionally used to secure the ex-

ecution of platform management functions such as

power and hear control. However, it has been in-

creasingly used to deploy security sensitive solutions,

which require strong hardware access control guar-

antees. Such systems are HyperCheck that is used

for hypervisor integrity veriﬁcation and IOCheck and

SMMDumper that scans system memory and dumps

it for forensic analysis (Reina et al., 2012) (Zhang,

2013). Aurora leverages SMM to provide intel SGX

enclaves enclaves with trusted network and time ser-

vices, by porting their corresponding drivers into

SMM (Liang et al., 2018). Researchers have also

been long aware of the keyboard snifﬁng problem.

TrustLogin proposes a solution to prevent credentials

leakage while they are from the keyboard to the Net-

work Interface Card, NICl. It uses SMM to encrypt

the credentials, and forward them securely to the NIC.

(Zhang et al., 2015b).

Finally, Deception and decoy has always been

part of the defence arsenal of cybersecurity. The

most widely discussed deception-based solution is ar-

guably honeypots. The intuition behind honeypots

is to ”provide fake information which is attractive to

attackers. The attacker, in searching for the honey

of interest comes across the honeypot, and starts to

taste of its wares. If they are appealing enough, the

attacker spends considerable time and effort getting

at the honey provided. If the attacker has ﬁnite re-

sources, the time spent going after the honeypot is

time not spent going after other things the honeypot

is intended to protect. If the attacker uses tools and

techniques in attacking the honeypot, some aspects

of those tools and techniques are revealed to the de-

fender in the attack on the honeypot” (Cohen, 2004).

The earliest and most notable use of honeypots was

in 1991 from ATT researcher in a paper called “jail”,

which aims to lure attacks in order to monitor their be-

haviour. Since that time, deception has increasingly

been explored as a key technology area for innova-

tion in information protection (Wang et al., 2018).The

idea of honeypots has been further explored more re-

cently, and applied to detect authentication into ﬁnan-

cial institutions, by creating an account which mimics

a real account through all its attributes, minus the fact

that it isn’t backed with any money which can actu-

ally be stolen. When an attacker gains access to such

accounts, it will be indistinguishable to them from

any other real account, as they will have access to

the same services, except the fact that the bank will

not be validating any money transfers linked to the

faked account. This constitutes a very efﬁcient solu-

tion not only for the detection of account breaches, but

also a great opportunity to learn about the behaviour,

strategy and intention of attackers (Juels and Rivest,

2013).

4.1 Conclusions and Future Work

In this paper, we presented SMMDecoy, a deception-

based technique to detect GPU keyloggers, which

sniff the open keyboard interface. We protect against

a strong adversary which can take control over the

platform’s user applications, kernel, and GPU. SM-

MDecoy generates and injects decoy credentials,

which should indistinguishable from legitimate ones.

They are then sniffed by the GPU malware. SMMDe-

coy relies on strong hardware enabled access control

mechanisms. It uses SMM to protect the integrity

and transparency of the decoy credentials’ injection.

It also uses SGX to establish a secure channel to a re-

mote server, over which the injected decoy credentials

would be forwarded. If a decoy credential is detected

to be used by a malware, an alarm should be raised.

Unlike traditional honeywords, an SMMDecoy alarm

reveals a wealth of information about how the mal-

ware spreads. The paper also discusses the implemen-

tation feasibility of SMMDecoy. Future work is to

naturally implement the solution and evaluate its per-

formance. We also plan to use SMMDecoy as part of

a longitude study in which we aim at detecting GPU,

and other ﬁrmware, malware which is not possible to

detect using traditional CPU based mechanisms.

ACKNOWLEDGEMENTS

The author would like to thank all of the reviewers.

This work is supported by the department of infor-

matics of the university of Oslo, and COINS Research

School of Computer and Information Security.

REFERENCES

Brouwer, A. (2009). The at keyboard controller.

Cohen, F. (2004). The use of deception techniques : Hon-

eypots and decoys.

ICISSP 2019 - 5th International Conference on Information Systems Security and Privacy

586

Delgado, B. and Karavanic, K. L. (2018). EPA-RIMM: A

framework for dynamic smm-based runtime integrity

measurement. CoRR, abs/1805.03755.

Embleton, S., Sparks, S., and Zou, C. (2008). Smm rootk-

its: A new breed of os independent malware. In Pro-

ceedings of the 4th International Conference on Se-

curity and Privacy in Communication Netowrks, Se-

cureComm ’08, pages 11:1–11:12, New York, NY,

USA. ACM.

Florencio, D. and Herley, C. (2007). A large-scale study

of web password habits. In Proceedings of the 16th

International Conference on World Wide Web, WWW

’07, pages 657–666, New York, NY, USA. ACM.

Herley, C. (2009). So long, and no thanks for the externali-

ties: The rational rejection of security advice by users.

In Proceedings of the 2009 Workshop on New Secu-

rity Paradigms Workshop, NSPW ’09, pages 133–144,

New York, NY, USA. ACM.

Holz, T., Engelberth, M., and Freiling, F. (2009). Learning

more about the underground economy: A case-study

of keyloggers and dropzones. In Proceedings of the

14th European Conference on Research in Computer

Security, ESORICS’09, pages 1–18, Berlin, Heidel-

berg. Springer-Verlag.

Jacob, R. J. K. (1996). Human-computer interaction: Input

devices. ACM Comput. Surv., 28(1):177–179.

Juels, A. and Rivest, R. L. (2013). Honeywords: Making

password-cracking detectable. In Proceedings of the

2013 ACM SIGSAC Conference on Computer ; Com-

munications Security, CCS ’13, pages 145–160, New

York, NY, USA. ACM.

Ladakis, E., Koromilas, L., Vasiliadis, G., Polychronakis,

M., and Ioannidis, S. (2013). You can type , but you

can ’ t hide : A stealthy gpu-based keylogger.

Liang, H., Li, M., Zhang, Q., Yu, Y., Jiang, L., and Chen,

Y. (2018). Aurora: Providing trusted system ser-

vices for enclaves on an untrusted system. CoRR,

abs/1802.03530.

Mike (2009). Operating systems development - keyboard.

Ortolani, S. and Crispo, B. (2012). Noisykey: Tolerating

keyloggers via keystrokes hiding. In Proceedings of

the 7th USENIX Conference on Hot Topics in Security,

HotSec’12, pages 2–2, Berkeley, CA, USA. USENIX

Association.

Ortolani, S., Giuffrida, C., and Crispo, B. (2010). Bait your

hook: A novel detection technique for keyloggers. In

Jha, S., Sommer, R., and Kreibich, C., editors, Re-

cent Advances in Intrusion Detection, pages 198–217,

Berlin, Heidelberg. Springer Berlin Heidelberg.

Reina, A., Fattori, A., Pagani, F., Cavallaro, L., and Br-

uschi, D. (2012). When hardware meets software: A

bulletproof solution to forensic memory acquisition.

In Proceedings of the 28th Annual Computer Security

Applications Conference, ACSAC ’12, pages 79–88,

New York, NY, USA. ACM.

Schmidt, M. S. (2012). Credit card data breach at barnes

noble stores.

Thomas, K., Li, F., Zand, A., Barrett, J., Ranieri, J., In-

vernizzi, L., Markov, Y., Comanescu, O., Eranti, V.,

Moscicki, A., Margolis, D., Paxson, V., and Bursztein,

E., editors (2017). Data breaches, phishing, or mal-

ware? Understanding the risks of stolen credentials.

Thomson, I. (2013). How the nsa hacks pcs, phones,

routers, hard disks ’at speed of light’: Spy tech cat-

alog leaks.

Van Bulck, J., Piessens, F., and Strackx, R. (2017). Sgx-

step: A practical attack framework for precise enclave

execution control. In Proceedings of the 2Nd Work-

shop on System Software for Trusted Execution, Sys-

TEX’17, pages 4:1–4:6, New York, NY, USA. ACM.

Wang, D., Cheng, H., Wang, P., Yan, J., and Huang,

X. (2018). A security analysis of honeywords. In

25th Annual Network and Distributed System Security

Symposium, NDSS 2018, San Diego, California, USA,

February 18-21, 2018.

Zhang, F. (2013). Iocheck: A framework to enhance the

security of i/o devices at runtime. In 2013 43rd An-

nual IEEE/IFIP Conference on Dependable Systems

and Networks Workshop (DSN-W), volume 00, pages

1–4.

Zhang, F., Leach, K., Stavrou, A., Wang, H., and Sun, K.

(2015a). Using hardware features for increased de-

bugging transparency. In 2015 IEEE Symposium on

Security and Privacy (SP), volume 00, pages 55–69.

Zhang, F., Leach, K., Wang, H., and Stavrou, A. (2015b).

Trustlogin: Securing password-login on commodity

operating systems. In Proceedings of the 10th ACM

Symposium on Information, Computer and Communi-

cations Security, ASIA CCS ’15, pages 333–344, New

York, NY, USA. ACM.

SMMDecoy: Detecting GPU Keyloggers using Security by Deception Techniques

587
