PSSST! The Privacy System for Smart Service Platforms: An Enabler for

Conﬁdable Smart Environments

Christoph Stach

, Frank Steimle

, Clémentine Gritti

and Bernhard Mitschang

Institute for Parallel and Distributed Systems, University of Stuttgart, Universitätsstraße 38, 70569 Stuttgart, Germany

Department of Information Security and Communication Technology, NTNU, Elektro B, Gløshaugen, Trondheim, Norway

Keywords:

Privacy, Access Control, Internet of Things, Smart Service Platform, Sensors, Actuators, Stream Processing.

Abstract:

The Internet of Things and its applications are becoming increasingly popular. Especially Smart Service

Platforms like Alexa are in high demand. Such a platform retrieves data from sensors, processes them in a

back-end, and controls actuators in accordance with the results. Thereby, all aspects of our everyday life can be

managed. In this paper, we reveal the downsides of this technology by identifying its privacy threats based on a

real-world application. Our studies show that current privacy systems do not tackle these issues adequately.

Therefore, we introduce PSSST!, a user-friendly and comprehensive

rivacy

ystem for

mart

ervice Pla

forms

limiting the amount of disclosed private information while maximizing the quality of service at the same time.

1 INTRODUCTION

The Internet of Things (IoT) is nowadays monitor-

ing and controlling many aspects of our daily lives.

This becomes particularly apparent in the increasingly

popular Intelligent Personal Assistants such as Alexa.

These are technical tools that determine user requests

via sensors and subsequently fulﬁll them as effectively

as possible via actuators. In the case of Alexa, this is

represented by a speaker with a built-in microphone,

the so-called Echo

. Via the microphone, the user

can make requests in natural language to Alexa, e. g.,

“Alexa, what is the weather forecast tomorrow?”). The

captured voice message is then sent to the Alexa Cloud

service to analyze and interpret it. After the meaning

of the question is identiﬁed, a corresponding answer

is retrieved from a knowledge base. The data are then

sent back to Echo and read to the user (Chung et al.,

2017b).

As a result of this special kind of interaction, Alexa

is no longer seen as a technological gadget, but as a

strong social presence (Purington et al., 2017). There-

fore, users interact much more naturally with Alexa

so that the collected data provide deep insights into

their everyday lives (Orr and Sanchez, 2018). Users

are therefore increasingly concerned about whether

the provider of such a Smart Service Platform handles

these highly private data in a trustworthy manner. It

see https://www.amazon.com/echo

is also unknown whether only such data are collected

which are necessary to provide the speciﬁc services.

The user cannot verify which data are captured and

what knowledge can be derived from them. So, s/he

has to rely solely on the good nature of the platform

provider. Yet, studies show many potential privacy vul-

nerabilities in these platforms (Chung et al., 2017a).

On top of this, Alexa shares its data with various

third-party Cloud services (e. g., ridesharing providers)

and operates several compatible third-party IoT de-

vices (e. g., Smart Lighting Kits) (Chung et al., 2017b).

That is, even if the provider of the respective Smart

Service Platform is entirely trustworthy, its control

over the private data ends when such data have been

disclosed to these third parties (Alhadlaq et al., 2017).

Samsung even predicts that by 2020 all Samsung

household appliances will be interconnected. Then

sensors and actuators should be integrated into every

device so that these devices can interact with each

other autonomously (Samsung Newsroom, 2018).

Although Smart Services provide great conve-

nience for users, the privacy threats they pose are im-

mense (Apthorpe et al., 2016). So, there is an urgent

need for privacy systems for Smart Service Platforms.

In this respect, it is important to involve the user in

all decisions (Rashidi and Cook, 2009). Nevertheless,

the autonomous nature of the Smart Service Platform

must not be restricted unnecessarily in order to sustain

its service quality (Townsend et al., 2011). Due to this

balancing act, today’s privacy systems fail in the con-

Stach, C., Steimle, F., Gritti, C. and Mitschang, B.

PSSST! The Privacy System for Smart Service Platforms: An Enabler for Conﬁdable Smart Environments.

DOI: 10.5220/0007672900570068

In Proceedings of the 4th International Conference on Internet of Things, Big Data and Security (IoTBDS 2019), pages 57-68

ISBN: 978-989-758-369-8

text of Smart Service Platforms: they are unnecessary

restrictive (Schaub et al., 2017), are not tailored to the

privacy requirements of the users (Felt et al., 2012a),

and they overburden the users (Felt et al., 2012b).

For this reason, we introduce PSSST!, a novel

rivacy

ystem for

mart

ervice Pla

forms that is

designed to meet the speciﬁc requirements of such an

ecosystem. To this end we make the following ﬁve

contributions:

(1)

We provide insight into a Smart Ser-

vice Platform, namely MIALinx (Wieland et al., 2016),

and describe how it operates based on an exemplary

application scenario. From this, we derive both privacy

issues and requirements towards a privacy system in

such a context.

(2)

We introduce a mechanism to pre-

vent Smart Devices and Smart Service Platforms from

deriving speciﬁc knowledge about its users.

(3)

describe a method to prevent a Smart Service Platform

from bypassing this mechanism.

(4)

We ensure a high

quality of service despite the privacy measures.

(5)

combine these three security measures in PSSST!.

The remainder of the paper is structured as fol-

lows: In Section 2, an application scenario for a Smart

Service Platform is introduced. This exemplary sce-

nario illustrates the functionality of such a platform

and its inherent privacy threats. Subsequently, in Sec-

tion 3, requirements towards a privacy system for such

a platform are derived from this scenario. Section 4

discusses existing privacy approaches for Smart De-

vices and Smart Services. As these approaches do not

meet all the requirements towards a privacy system for

Smart Service Platforms, Section 5 ﬁrst introduces the

concept of our approach PSSST! before Section 6 de-

scribes its implementation. Section 7 assesses PSSST!

and reveals whether it fulﬁlls all requirements. Finally,

Section 8 concludes this paper.

2 APPLICATION SCENARIO

In the following we describe an example for a realistic

Smart Home application and identify the components

applied in this scenario (see Section 2.1). In this ex-

ample, an IoT platform, namely MIALinx, is used to

provide support for Smart Services. MIALinx eval-

uates simple IF-THIS-THEN-THAT (ITTT) rules to

react to speciﬁc events. Although IoT platforms such

as Alexa have a lot of further functionalities, the basic

principles of such a platform can be illustrated using

MIALinx as an example (see Section 2.2). Based on

this scenario, we describe inherent privacy risks of

such an IoT platform (see Section 2.3).

2.1 Application Example

Home heating is one of the major energy consumers

in a household. Therefore, increasing the efﬁciency

of home heating is an essential goal. With the help

of IoT technologies, a need-based heating control is

achievable. Figure 1 shows a setup for such an IoT

supported heating system. This application example is

inspired by the study of Kleiminger et al. (Kleiminger

et al., 2014). It reﬂects the state of the art of technology

in the ﬁeld of Smart Heating control.

A Smart Heating is basically a common heating

system that can be controlled remotely. For this pur-

pose, it can be accessed e. g. via Bluetooth. In our

application example it therefore represents an actuator.

Various sensors enable to determine the condition in a

Smart Home. For instance, Smart Thermostats can be

used to determine the temperature in each room. These

data are forwarded to a local Control Unit. This control

unit can thus detect when the temperature in a room

drops below a speciﬁed threshold. It can then trigger

the Smart Heating to reestablish the room temperature

as speciﬁed by the user.

However, the potential offered by such a Smart

Environment is considerably farther. Via Smart Room

Management sensors, such as microphones or cam-

eras, it is possible to determine in which rooms how

many people are currently present. In this way, un-

used or very crowded rooms can be heated less, which

signiﬁcantly reduces energy consumption. However,

the coordination and interpretation of all these data

sources exceed the capabilities of a user.

The automatic analysis and consolidation of all

these sensor data are therefore carried out by an exter-

nal service provider for the user. The user only speci-

ﬁes certain parameters (e. g., thresholds for his or her

individual comfortable temperature) and the service

provider generates corresponding rules. In addition,

the service providers have the capacities to store the

history data of their users and to perform analyses on

it. This enables them to learn more about the habits

of their users (e. g., the user is never at home on the

weekend) and to tailor their services accordingly (e. g.,

the room temperature can be decreased at weekends).

External service providers have another decisive

advantage: they are able to join data from different

Smart Environments. In our application example, we

chose the user’s Smart Car. Modern Smart Cars are

able to identify the driver, e. g., via individual keys for

each driver. In addition, such cars are not only able

to determine their current location, but they have also

access to various data sources. For instance, they can

retrieve real-time trafﬁc information, have access to

navigation data, and know the appointments a user has

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

Smart Home Service Provider

Location

Traffic

Information

Navigation

System

Personal

Organizer

User ID

Smart Car

Smart Heating Router

Smart

Thermostat

Control UnitSmart Room

Management

Cloud-based Smart

Service Platform

Figure 1: Setup of an IoT Supported Smart Heating System.

stored in his or her personal organizer. This enables

them to know when a user is driving home and when

s/he is likely to arrive there. By sharing this informa-

tion with the service provider, the Smart Heating can

be adjusted so that the temperature requested by the

user is reached as soon as s/he enters his or her home.

This application example illustrates that Smart Ser-

vices have to process data from various sensors and

have to be able to react to certain sensor values. A

variety of actuators must be triggered for this purpose.

Furthermore, it is evident that a platform for such

services must interact with and coordinate multiple

heterogeneous Smart Environments. A very simple

example of how such a platform operates is described

below based on MIALinx. Yet, the insights also apply

to other Smart Service Platforms, such as the Alexa

platform mentioned in the introduction.

2.2 MIALinx

MIALinx (Wieland et al., 2016) is a Smart Service

Platform designed for Industry

4.0

. It provides a ﬂexi-

ble and easy-to-use integration of assets on the shop

ﬂoor. The platform allows the creation and execution

of ITTT rules. Such a rule describes how to react to

certain sensor values, i. e., which actuators have to be

addressed. Despite its focus on an industrial context,

MIALinx can be applied to any given scenario.

The operating principle of MIALinx is shown in

Figure 2. MIALinx introduces an adapter concept in

order to be compatible to any given sensor and actuator.

An adapter is a digital twin for actual physical assets.

This means that for each sensor and actuator MIALinx

requires such an adapter, which can be seen as a driver

which can be added to the platform at runtime. The

adapters read the data from their corresponding sen-

sors and convert these raw data into values that can be

processed by MIALinx. For instance, the adapter of

a Smart Thermostat can convert its raw data into de-

grees Celsius. Likewise, the actuator adapters receive

commands from MIALinx and convert them into in-

structions that are executable by the physical actuators.

A single sensor can feed several adapters and a single

adapter can combine the data of several sensors (this

also applies to the actuators). For instance, an adapter

can represent a virtual Smart Room Management sen-

sor analyzing both camera data and microphone data

and determines how many people are in the room by

combining both types of data. Then, the adapter passes

only the amount of people to core of MIALinx, its rule

engine. Here virtual sensors are linked to virtual actu-

ators.

This linkage is realized via ITTT rules, where the

left side (IF) represents a virtual sensor and the right

side (THEN) a virtual actuator. In addition, a condition

is attached to the sensor values under which the rule

has to be executed. In the example given in Figure 2,

the heating should be turned down when the tempera-

ture is above 25

C and it should be increased when the

user arrives at home in less than 15 minutes. Machine

learning techniques can be applied to this rule base to

come up with new rules or to reﬁne existing ones.

Rule EngineVirtual SensorsPhysical

Sensors

Virtual Actuators Physical

Actuators

MIALinx

> 25°C < 15’

ITTT Rule Base

…

Figure 2: Basic Concept of a Smart Service Platform

exempliﬁed by MIALinx (cf. (Stach et al., 2018c)).

PSSST! The Privacy System for Smart Service Platforms: An Enabler for Conﬁdable Smart Environments

2.3 Privacy Threats

This application example reveals various privacy

threats due to the use of a Smart Service Platform:

The sensors share their data unrestrictedly with

the external service provider. The user cannot track or

control which data are transmitted (i. e., which data are

leaving his or her sphere of inﬂuence). For instance,

s/he cannot control whether the Smart Room Manage-

ment component only passes on the number of people

in a room or also its video and audio recordings.

The service provider may add further rules to

the rule base at any time (e. g., via machine learning).

While this is necessary to improve the service quality,

it can also be misused to spy on the user. For instance,

a rule could be added which sends an email to the

service provider, informing him or her when and how

long the user leaves the house.

The service provider is also able to control all

actuators at will. Depending on the actuator, this can

cause high costs or even hazards. For instance, the

user cannot restrict access to the heating system (e. g.,

set a limit for operating hours at the heating system).

The communication between the sensors and

actuators is not secured and can be intercepted.

Any data source can forward data to the service

provider. An attacker could therefore pretend to be

the user’s thermostat and use fake data to cause an

incorrect control of the heating system.

Sensors for home use are produced very cheap

and therefore often provide temporary wrong values.

This can trigger the wrong rules if the service provider

does not ﬁlter out such outliers.

3 REQUIREMENTS

These privacy threats result directly in requirements

towards a privacy system for Smart Service Platforms:

To prevent

, a privacy system has to be able to

control the use of private data as close to sensor as pos-

sible. The restriction method must be adapted to the

respective sensor, e. g., reducing the accuracy makes

sense for location data whereas this method cannot be

used for the user ID. Overall, the best privacy strategy

is not to pass on any data which are not required for

the intended Smart Service to the processing platform.

To prevent

, a privacy system has to be able

to monitor and control all data processed by a Smart

Service Platform. Only at the platform, all data are

available which are processable by the Smart Services.

All data sources have to be known to the privacy sys-

tem to enable it to analyze which knowledge can be

derived from the data. In addition to the real-time sen-

sor data, also the knowledge base of the platform (i. e.,

history data) has to be taken into account.

To prevent

, similar to

, also the use of

actuators has to be restricted locally at the actuator.

That is, the interface of actuators must be manipulated,

e. g., disable a function or restrict the use of a function.

To prevent

, the communication channels be-

tween the sensors / actuators and the Smart Service

Platform must be fully encrypted.

To prevent

, all sensors / actuators have to

authenticate to the Smart Service Platform.

To prevent

, all sensor data have to be val-

idated sensor-sided, i. e., before passing it on to the

Smart Service Platform. The options to deal with out-

liers largely depend on the respective sensor.

In addition, there are further requirements towards

such a privacy system in order to be effective:

The quality of the Smart Services must be retained.

If no data are shared with the platform, privacy is fully

protected, but the quality of service is nonexistent.

Whereas if all data are shared with the platform, the

quality of service is maximized, but there is no privacy.

Therefore, an adequate trade-off has to be achieved.

A Smart Service Platform is a dynamic execution

environment—new sensors and actuators can be added

at any time. So, a privacy system has to be extendable

to cope with such structural and technological changes.

The conﬁguration of the privacy system has to

be simple, as most users of Smart Services are no IT

experts. For this purpose, the speciﬁcation of privacy

requirements must not be at the sensor level, but at a

higher level. That is, the user describes which knowl-

edge about him or her has to be concealed (e. g., the

platform must not detect that the user is never at home

on weekends)—s/he does not want to worry about

which sensors might reveal this information.

4 RELATED WORK

The privacy approaches which are applicable to Smart

Service Platforms can be divided into four categories:

attribute-based privacy rules, context-sensitive privacy

rules, privacy via mock data, and statistical privacy

techniques. Some approaches have features of several

categories. When discussing related work, we do not

differentiate between approaches for Smart Devices

and approaches for IoT back-ends, as both have to be

considered by a privacy system (see

–

). The

overview is not intended to be exhaustive due to the

sheer number of similar approaches. We list represen-

tatives for the respective categories, only.

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

Attribute-based Privacy Rules.

Attribute-based pri-

vacy control is a relatively simple approach. In this

privacy technique, the user deﬁnes which attributes a

third party gets access to. In the simplest case, one

attribute comprises all data of a certain sensor class.

Transferred to the application example in Section 2.1,

a user could prohibit that GPS data are forwarded to

the Smart Service Platform. DEFCON (Migliavacca

et al., 2010) is such a privacy system for data streams.

All events of a restricted sensor are not processed or

forwarded—i. e., it appears that these events never oc-

curred. That can also be applied to databases. Kabra et

al. (Kabra et al., 2006) introduce a ﬁne-grained access

control for database queries. Speciﬁc rows or columns

can be excluded when processing a query, i. e., partic-

ular readings as well as sensor attributes (e. g., latitude

or longitude) can be concealed. Dr. Android and Mr.

Hide (Jeon et al., 2012) proceeds more ﬁne-grained,

as it also takes the data format of the respective source

into account. Depending on the data format, the user

has differently detailed restriction options.

Overall, all of these approaches have a common

shortcoming. Their attribute-based data ﬁltering is

highly restrictive. That is, a user either shares his or her

GPS data with a third party or s/he does not. However,

with this technique it is not possible to disclose only

when a user will arrive at home without sharing his

or her location permanently. So, either the privacy

protection or the service quality is heavily impaired.

Context-sensitive Privacy Rules.

A less restrictive

access control mechanism is enabled by context-based

privacy rules. This means, each access rule is linked to

an activation context. So, it is possible to share a user’s

GPS data only when s/he is close to his or her house,

i. e., only when it is relevant for controlling the Smart

Heating. ACStream (Cao et al., 2009) implements such

an access control for data stream systems. While in

ACStream the context refers only to the content of the

transmitted data, CRePE (Conti et al., 2010) uses any

available sensor data to deﬁne the context. However,

this leads to an increased complexity regarding the

description of the context. To reduce this complexity,

Wallis et al. (Wallis et al., 2018) take the application

domain into account and consider only aspects which

are relevant in the respective domain.

However, all these approaches have the problem

that they either consider only spatiotemporal data as

context or they completely overburden users with the

deﬁnition of a more complex context.

Privacy via Mock Data.

Approaches of the third cat-

egory do not restrict access to data sources but enable

users to reduce the data quality when necessary. In

this way it is possible to provide less trustworthy re-

cipients with manipulated or even completely random-

ized data. MockDroid (Beresford et al., 2011) imple-

ments this in a very minimalistic manner—the recipi-

ent only receives empty result sets. AppFence (Horny-

ack et al., 2011) therefore adopts a more comprehen-

sive approach towards data shadowing. Instead of

empty result sets, plausible mock data are returned—

i. e., the data are within the expected value range. For

instance, AppFence provides valid latitude and lon-

gitude data when mocking a real GPS source. How-

ever, these values still might be implausible (e. g., they

might point to a location in the middle of the ocean).

PRIVACY-AVARE (Alpers et al., 2018) therefore takes

the properties of the respective source into account. It

introduces a speciﬁc mocking technique for each data

source. For instance, when the accuracy of location

data are reduced, it is ensured that properties such as

direction of motion or traveled distance are preserved.

Yet, the impact on service quality is unpredictable

if data are arbitrarily manipulated, e. g., if the predicted

number of people in a room is incorrect, it is unclear

how this affects the Smart Heating. Moreover, the

intentional manipulation of data is a breach of contract,

if this results in a monetary advantage for the user.

Statistical Privacy Techniques.

Statistical Privacy

Techniques follow a completely different approach.

Instead of focusing on the data of a single user, these

approaches consider larger user groups. The basic idea

is that in this way an individual person vanishes into

the crowd. Thereby statistical information about the

dataset as a whole can be obtained without being able

to draw conclusions about individual users. Sopaoglu

and Abul (Sopaoglu and Abul, 2017) introduce a tech-

nique to ensure k-anonymity for big data processing

platforms—i. e., each record cannot be distinguished

from at least

k − 1

other records. Yet, k-anonymity

does not guarantee that each group of

records is het-

erogeneous whereby knowledge about an individual

user can still be gained. DAHOT (Kotecha and Garg,

2017), a privacy approach for data streams, prevents

such homogeneity attacks by ensuring the l-diversity

property as well—i. e., the intra-group diversity in each

group of

records is guaranteed. In order to prevent

an attacker from exploiting prior knowledge to identify

an individual within a group, FLEX (Johnson et al.,

2018) applies differential privacy (Dwork, 2006).

Yet, this cannot be applied to Smart Service Plat-

forms. These platforms have to be able to identify and

address each sensor and actuator individually—the ser-

vice must not activate

heating systems only because

one of the k users is on his or her way home.

An inherent problem of all these approaches, how-

ever, is their strict focus on raw data. Users, on the

other hand, think at a higher level of abstraction re-

garding their privacy—they know which information

PSSST! The Privacy System for Smart Service Platforms: An Enabler for Conﬁdable Smart Environments

they want to conceal but not which sensor data might

reveal this information. Therefore, users are not able to

specify their privacy requirements properly (Barth and

de Jong, 2017). Also, from a technical point of view,

these approaches are not capable of addressing com-

plex privacy requirements adequately. In such cases,

the privacy settings have to be much too restrictive and

thus impair the service quality unnecessarily.

5 CONCEPT OF PSSST!

Since on the one hand none of the existing privacy

solutions is suitable for Smart Service Platforms (see

Section 4) and on the other hand such a platform poses

a great threat potential (see Section 2.3), we have de-

veloped a concept for a novel privacy system for Smart

Service Platforms called PSSST!. Its basic architecture

with its three key components is shown in Figure 3.

PSSST! applies a two-layered privacy approach.

On the one hand, initial privacy control and access

restriction measures are enforced directly at the sensor

and actuator level. On the other hand, all communi-

cation with the Smart Service platform is secured via

a second access control layer. In this way PSSST!

brings together the best of both worlds. The privacy

components for the sensors and actuators are able to

monitor data where they are produced. In this way it

is ensured that no sensitive data are accessible from

these data sources and no third party is able to access

critical features of an actuator. In this layer, however,

only a very restrictive privacy control can be applied,

whereas the second layer knows the entire execution

context (all involved data sources) and is therefore able

to carry out a much more ﬁne-grained access control.

This second layer has to be implemented in the

Edge, i. e., on a central processing node of the respec-

tive Smart Environment. As several Smart Environ-

ments can provide data for a Smart Service, the in-

frastructure of the Smart Service Platform provider

would be the best execution environment for the pri-

vacy measures of this layer, from a technical point of

view. From a privacy point of view, however, this is out

of the question—this would put the fox in charge of the

henhouse. As a consequence, several Secure Access

Control Layers (one per Smart Environment) might

be responsible for a certain Smart Service. There is

therefore a Cloud-based master instance for the conﬁg-

uration and coordination of these layers. These three

components are detailed in the following.

Privacy Control for Sensors and Actuators.

As the

MIALinx example showed (see Section 2.2), there is

always a digital twin for each physical sensor or actu-

ator, via which a Smart Service Platform can interact

Smart Service

Platform

Adapter

…

Sensors & Actuators

Cloud-based Access

Control & Configuration

Secure

Access

Control

Layer

Query / Command

Data / Reply

Privacy

Settings &

Data

Access

Encoded

Policy

Access

Permission

Untrusted

Components

Trusted Components

Figure 3: Basic Architecture of PSSST!.

with the respective component. This is where PSSST!

steps in. This software has to be installed in the Smart

Environment which hosts the corresponding hardware.

That is, it is not controlled by Smart Service Platform

provider and so it can be enhanced.

These privacy extensions of PSSST! integrate the

features of attribute-based privacy rules and privacy via

mock data approaches. Thereby, for each sensor the

transmission of all data can be blocked—to the outside,

it appears as if the sensor is not sending any data.

For actuators, the public interface can be restricted,

i. e., less functions are available to the public. It is

also possible to manipulate individual sensor attributes,

e. g., reduce the accuracy of location data. Likewise, it

is possible to reduce the functionality of an actuator,

e. g., the Smart Heating cannot be set to a temperature

above 30

C. Since adapters have to be tailored to the

respective sensors or actuators anyway, it is possible in

PSSST! to adapt the privacy techniques to the sensors

and actuators similar to PRIVACY-AVARE.

The adapters are also able to verify sensor readings.

As adapters know the technical speciﬁcation of their

corresponding sensors, they are able to detect outliers.

Technical experts specify how to deal with corrupted

sensor values in such cases. For instance, these values

can be dropped, replaced by the last known valid value,

or corrected (e. g., replaced by the average value).

As the study of related work reveals, this approach

is unnecessarily restrictive. It is not possible to apply

context-based rules as each sensor only knows its own

data. Thus, outsourcing data processing entirely to

Smart Devices, as practiced in Secure Function Evalu-

ation (Mood and Butler, 2018), is not an option. This

approach also does not reﬂect the way people think

about privacy as it is based exclusively on data sources.

So, the PSSST! adapters must not be conﬁgured di-

rectly by the users. Rather, they are conﬁgured by the

central Secure Access Control Layer. This layer not

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

only holds the context knowledge from all data sources,

but also the view on privacy is more user-friendly.

Privacy Control for Smart Environments.

We ap-

ply a novel pattern-based access control mechanism in

the Secure Access Control Layer of PSSST!. The term

pattern refers to a certain chronological sequence of

sensor values. Each of these patterns can be assigned

to a certain implication. An example for such a pattern

is that the location of a user is in his or her house and

then the number of people in the house increases. This

pattern could indicate that the user is having a party.

As the detection of a pattern is not necessarily a bad

thing (it can either be used to spy on the user or to

control the Smart Heating), we distinguish between

public patterns, that should be detectable by a Smart

Service Platform, and private patterns, that have to

be concealed. The following example illustrates the

difﬁculties of this approach. Assuming A, B, and C are

sensor readings and the following data are transmitted:

t=5

− B

t=4

− A

t=3

− B

t=2

− C

t=1

The indices specify the timestamps of the readings,

e. g.,

t=1

was transmitted immediately before

t=2

Let

priv

be a private pattern and

pub

a public pattern:

priv

= C → B → A P

pub

= A → B → A

priv

could be concealed by dropping

t=3

. However,

this would also prevent the detection of

pub

at the

same time.

priv

could also be concealed by dropping

t=2

without affecting the detection of

pub

. Yet, if an

attacker knows that

occurs at any even timestamp,

s/he can still detect

priv

. Different techniques for

concealing private patterns have to be considered and

the one that has the least impact on the recognition of

public patterns (i. e., the service quality of the Smart

Service Platform) has to be chosen by PSSST!.

As a Smart Service Platform can only access sen-

sors and actuators via the Secure Access Control Layer,

these components have to register at that layer ﬁrst.

This registration process involves an authentication

step to ensure that no unauthorized components send

data to or receive messages from the platform.

However, this approach has the inherent problem

that each Smart Environment hosts its own instance of

this layer. To allow users to specify their privacy re-

quirements only once, and to ensure that these require-

ments are subsequently applied to all environments, a

central control unit is required to coordinate them.

Cloud-based Access Control and Conﬁguration.

Studies by Zheng et al. (Zheng et al., 2018) show

that Smart Home users are totally overburdened with

the speciﬁcation of their privacy requirements as they

cannot comprehend how their data are processed. On

the one hand, they fear that if they apply a particular

privacy setting, they will no longer be able to use a

certain Smart Service. On the other hand, they are not

aware of which data are collected at all.

For this very reason, we adopted a different ap-

proach in PSSST!. Users describe their privacy re-

quirements at a high level in natural language. They

solely focus on knowledge that must not be disclosed

to third parties without considering which data sources

are available to the Smart Service Platforms. Tech-

nology and domain experts then translate the require-

ments into private patterns. These experts know in

detail what data sources are available in a given Smart

Environment and what knowledge can be derived from

them. In addition to the privacy requirements, users

also specify the service quality they expect from a

Smart Service Platform. The technology and domain

experts deﬁne public patterns from these quality re-

quirements.

The speciﬁcation of quality requirements is not

mandatory for the user. It can also be done through the

Smart Service Platform, for example. But even if no

public patterns are deﬁned, PSSST! still can be used.

The public patterns only help to maximize the service

quality of Smart Services (see Section 6.2).

Once all patterns have been speciﬁed, they are con-

verted into conﬁgurations for the adapters and Secure

Access Control Layer and deployed to all Smart Envi-

ronments. If new sensors or actuators are added to an

environment, the central control unit is informed and

there the conﬁgurations are adjusted accordingly.

6 IMPLEMENTATION OF PSSST!

To realize PSSST!, we rely on established technolo-

gies, namely the PMP (Stach and Mitschang, 2013),

PATRON (Stach et al., 2018b), and CHARIOT (Gritti

et al., 2018). Yet, PSSST! is more than the sum of the

positive properties of these three technologies. The

concept of PSSST! yields synergy effects that not only

improve privacy and service quality, but also signiﬁ-

cantly reduce the computational overhead.

First, we detail in Section 6.1 how we can integrate

the PMP into the digital twins to enforce privacy and

at the same time validate the data. In Section 6.2

we address how PATRON realizes the privacy control

for Smart Environments. Then, we outline how the

policy-based access control mechanism of CHARIOT

can be used to authenticate the sensors and actuators

in Section 6.3. Finally, in Section 6.4 we describe

how PATRON’s tool support can be applied to the

conﬁguration mechanism of PSSST! in order to reduce

the experts’ effort and automatize most of their tasks.

PSSST! The Privacy System for Smart Service Platforms: An Enabler for Conﬁdable Smart Environments

Generic

Privacy

Adapter

Data

Blocking

Shamming

Privacy

Adapter

Mock

Data

Numeric

Privacy

Adapter

Alter

Accuracy

Selective

Privacy

Adapter

Restrain

Access

… …

Figure 4: Classiﬁcation of PSSST! Adapters.

6.1 The PMP Resources

The PMP (Stach and Mitschang, 2013) is a privacy

mechanism for Smart Devices. In a nutshell, the PMP

deploys content providers on the Smart Device that

run as background services. These content providers

are called PMP Resources. Each resource is respon-

sible for a speciﬁc type of data (e. g., location data,

health data, or contact data). The PMP ensures that

applications only have access to the respective data via

the Resources. For each data access, the responsible

Resource checks whether the requesting application is

allowed to query these data. Yet, the PMP not only re-

stricts access to data, but also access to critical system

functions. To this end, Resources are used as service

providers via which system functions are invoked.

Unlike many similar approaches, the PMP not only

enables users to deﬁne whether a certain request should

be executed or rejected. Rather, data access can be

restricted at a ﬁne-grained level. Depending on the

protected data source or system functionality, there

are different classes of PMP Resources. For instance,

there are Resources that support the randomization of

data, Resources that block certain data attributes, or

Resources that reduce the accuracy for numerical data.

Since the PMP is extendable, i. e., its plugin con-

cept allows to add Resources at runtime, it is feasible

to create and apply specialized Resources dedicated for

a speciﬁc use-case. For instance, Stach (Stach, 2018)

introduces a Resource, that enables users to control to

which domains an application may send data.

As the adapters of a Smart Service Platform have a

similar functionality, we can adopt the access control

features of the PMP Resources in PSSST!. That is,

the adapters verify before every data access whether it

satisﬁes the privacy policy. Figure 4 shows the privacy-

aware adapter classes, that we introduced in PSSST!.

Each adapter is able to block access to its data plus

there are adapters to provide mock data, to conceal

certain attributes, and to reduce the accuracy of the

data. Specialized adapters can be deployed if needed.

Stream Processing System

X = 70 X = 83 Z = 67 Y = 33Y = 87

t = 1t = 3t = 5t = 7t = 9

Y = 63

(a) Concealing Techniques for Stream Processing.

Virtual Data Store (VDS)

(b) Concealing Techniques for Data Stores.

Figure 5: Pattern-based Privacy Control in PSSST!.

6.2 The PATRON Execution Layer

PATRON (Stach et al., 2018b) is a privacy system for

the IoT. It provides an access control tier isolating data

sources from data consumers, i. e., it is able to monitor

the entire data transfer. To ensure privacy, PATRON

also relies on private patterns that have to be concealed

and public patterns that have to be detectable. Various

techniques can be used for this purpose (Zhang et al.,

2017). PATRON selects the technique that results in

the best service quality, i. e., the one causing the least

false positives (a public pattern is wrongly detected)

and false negatives (a public pattern is not detected).

To this end, the following quality metric is used:

QM =

∑

public_pattern

∗ w

pub_i

−

∑

f alse_positive

∗ w

f alse_ j

−

∑

private_pattern

∗ w

priv_k

Hence, the detected public patterns are counted and the

false positive as well as the revealed private patterns

are subtracted. Each factor is individually weighted,

e. g., to declare a private pattern as less privacy critical.

For each conﬁguration (i. e., a selection of concealing

techniques), this quality metric is calculated and the

one with the highest value is applied in PATRON.

Maximizing this metric is very computation-

intensive. As PSSST! ﬁlters data in its adapters al-

ready, the calculation is accelerated considerably.

The selected conﬁguration is then applied to both

real-time and history data (see Figure 5). As shown in

Figure 5(a), data can be dropped, the time stamps of

data can be swapped, additional data can be injected

into the data stream, or data values can be changed to

conceal private patterns in data streams (Palanisamy

et al., 2018). The concealing procedure for data stores

is shown in Figure 5(b). An abstraction layer (VDS)

is introduced for this purpose. Externally, the VDS

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

Sensor

Smart Service

Platform

ActuatorTrusted Execution

Environment

Honest-but-Curious

Cloud Service

Trusted

Authority

Figure 6: Adapter Authentication (cf. (Gritti et al., 2018)).

acts like the original data store. Internally however,

the VDS rewrites incoming queries, adds ﬁlters, and

applies anonymization functions to the query results to

conceal private patterns (Stach and Mitschang, 2018b).

6.3 The CHARIOT Protocol

In the IoT, most of the Smart Devices have very limited

resources in terms of memory and computing power.

For this reason, many sophisticated security mecha-

nisms cannot be applied to them. CHARIOT (Gritti

et al., 2018) addresses this problem. To this end, a

server-aided access control mechanism is introduced.

Via this mechanism IoT platforms are enabled to deter-

mine whether a certain Smart Device has the required

credentials to transmit its data to the platform or fetch

data from the platform. For this, it is necessary that

the devices authenticate to the platform. To ensure that

this does not compromise a user’s privacy (most Smart

Devices are explicitly linked to a user), an Attribute-

Based Signature is used (Gritti et al., 2019). Since the

computation of this signature is computation-intensive,

CHARIOT outsources such operations to the Cloud to

reduce the Smart Devices’ workload.

Figure 6 shows how CHARIOT can be applied to

PSSST!. Initially, a trusted authority creates a public

/ private key pair for each sensor and actuator. An

outsourcing key is sent to a Cloud service which is

considered as honest-but-curious, i. e., it is not fully

trusted. Whenever a sensor or actuator interacts with

the Smart Service Platform (via the Secure Access

Control Layer), it needs to sign all messages using its

attributes. The recipient can then verify the signature

without disclosing the identity of the sender. As this

signing process is costly, it is outsourced to the Cloud

service. This service operates with the outsourcing

key and the sensor or actuator only has to ﬁnalize the

signature with its private key. Due to this distributed

approach, the Cloud service cannot access the data.

This solves the problem that PATRON’s access con-

Smart Service

Platform

User

Domain

Experts with

Tool Support

Public

Patterns

Private

Patterns

Quality Metric

Configuration

for a Privacy

System

Requirements

Figure 7: PSSST! Conﬁguration Process.

trol tier cannot verify the identity of sensors and actua-

tors. In addition, by applying CHARIOT in PSSST!,

its asynchronous encryption can also be used to secure

all communication channels.

6.4 The PATRON Conﬁguration Layer

In PATRON (Stach et al., 2018b), users express their

privacy requirements in natural language to domain

experts, i. e., which knowledge must not be revealed

to a third party. The domain experts then analyze the

IoT setting (e. g., available data sources or data con-

sumers) and derive privacy threats. In addition, they

determine from which data the knowledge that has to

be concealed can be obtained. Based on this prepara-

tory work, they create the private patterns, which are

then converted into a conﬁguration for PATRON as

described in Section 6.2. Users can also formulate

service quality requirements, which are similarly con-

verted into public patterns. To reduce manual effort,

PATRON introduces tool support to assist experts in

identifying privacy threats (Mindermann et al., 2017).

ACCESSORS (Stach and Mitschang, 2018a) pro-

vides an additional support for the experts. Using

this modeling technique, experts can describe cor-

relations between data sources and derivable knowl-

edge. This model is used for further analyses. To this

end, the RAKE algorithm initially extracts keywords

from the privacy requirements. These keywords are

then correlated with the derivable information mod-

eled in ACCESSORS to identify privacy threatening

data sources. Since this can be done automatically,

domain experts only have to intervene manually if the

model has to be extended, e. g., when new data sources

PSSST! The Privacy System for Smart Service Platforms: An Enabler for Conﬁdable Smart Environments

are available. Using collaborative ﬁltering, it is also

possible to recommend further privacy requirements

that the user did not think about. EPICUREAN (Stach

and Steimle, 2019) is such a recommender system for

privacy requirements.

PSSST! makes use of all those tools. Figure 7 de-

picts the process of how a PSSST! conﬁguration is

generated. Similar to PATRON, users describe their

privacy requirements in natural language. Smart Ser-

vice Platforms can provide their requirements towards

data quality as well—i. e., they disclose partially which

patterns they need to detect in order to provide a cer-

tain service. The public and private patterns are then

derived from this information using PATRON’s tool

support as well as EPICUREAN’s machine learning

techniques. The therefore applied machine learning

models can be trained in a privacy-aware manner (Shu

et al., 2018). Subsequently, these patterns are deployed

in the Secure Access Control Layer of each relevant

Smart Environment. There, the quality metric deter-

mines which conﬁguration matches these patterns best.

Stach et al. (Stach et al., 2018a) discuss how conﬁg-

urations for a privacy system can be deployed in hetero-

geneous infrastructures whereas Giebler et al. (Giebler

et al., 2018) introduce an architecture to manage both

data streams and databases via a shared conﬁguration.

Since different Smart Environments are also very het-

erogeneous and have to deal with both real-time data

(via data stream processing systems) and history data

(via database systems), these approaches can be used

in PSSST! to distribute the conﬁguration.

7 DISCUSSION

In the following, we assess whether the concept and

implementation strategy of PSSST! meets all require-

ments towards a privacy system for Smart Service Plat-

forms (see Section 3) and thus eliminates all threats

caused by such a platform (see Section 2.3).

By extending the adapter concept and integrating

the techniques from the PMP Resources, data access

can be restricted directly at the sensor. The data can

either be completely suppressed or manipulated be-

fore they are forwarded (

). Via the Secure Access

Control Layer, PSSST! is able to monitor and con-

trol all data sources available in a Smart Environment.

Additionally, the VDSs in these layers contain the

complete data history. As all of the layer instances are

conﬁgured and coordinated by a central control unit,

PSSST! has total control over all data available to a

Smart Service Platform (

). Similar to the sensors,

also actuators can be secured by applying the con-

cept of PMP Resources to their adapters. In this way,

their functionality can be restricted (

). CHARIOT’s

asymmetric encryption can be used for both protecting

communication channels and authenticating sensors

and actuators. Thus, third parties can neither inter-

cept data nor inject corrupted data into the system (

). All sensor data must be obtained in PSSST!

via the adapters. These adapters are designed for the

respective sensor, i. e., they can verify the data and

handle sensor errors (R

The requirements that are not directly related to

privacy issues are addressed in PSSST! as well. While

private patterns are used to ensure privacy, PSSST!

uses public patterns to maximize the quality of Smart

Services. Its ﬁne-granular access control impairs data

quality as little as possible, so that even unspeciﬁed

public patterns can still be detected (

). The adapter

concept enables PSSST! to be extendable as required.

Therefore, it dynamically adapts to structural and tech-

nological changes in Smart Environments (e. g., adding

a new sensor) at any time. ACCESSORS enables ex-

perts to model new ﬁndings regarding the relation-

ships between data and derivable knowledge and to

apply them directly to existing and new Smart Ser-

vices. Thus, PSSST! is also extendable with regard to

new Smart Services (

). Finally, in PSSST! a user

deﬁnes his or her privacy requirements at a high level

in natural language. As a result, the conﬁguration is

user-friendly and the privacy settings exactly meet his

or her expectations. Additionally, EPICUREAN iden-

tiﬁes other relevant privacy requirements, whereby the

conﬁguration is further simpliﬁed (R

Thus, PSSST! meets all requirements towards a

privacy system for Smart Service Platforms and offers

a comprehensive privacy protection for such platforms.

8 CONCLUSION

Smart Services powered by IoT technologies are be-

coming increasingly popular. They are applied in var-

ious domains to facilitate our everyday life. Smart

Service Platforms such as Alexa collect all kinds of

sensor data and process these data in order to be able

to derive the current situation. Thereby they are able

to tailor their services to their users and even to react

autonomously to certain situations with the help of

actuators. An example of such a service is the user-

speciﬁc control of a Smart Heating.

However, these Smart Services also represent a se-

rious privacy threat, as they collect and process a great

amount of data on the one hand and on the other, they

are able to operate autonomously. In this paper we

therefore examined a real-world application example

for Smart Services and analyzed the functionality of a

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

Smart Service Platform. Based on these insights, we

were able to identify privacy threats related to Smart

Services. To address these threats, we speciﬁed re-

quirements towards a privacy system appropriate for

Smart Service Platforms. As state-of-the-art privacy

approaches do not meet these requirements properly

(i. e., they are overly restrictive, they overburden the

users, or they are not applicable to Smart Services),

we came up with a novel concept for a novel

rivacy

ystem for

mart

ervice Pla

forms called PSSST!.

For the realization of PSSST! we combined three exist-

ing privacy systems, namely the PMP, PATRON, and

CHARIOT. The ﬁnal evaluation of PSSST! conﬁrms

that our approach meets all requirements.

ACKNOWLEDGEMENTS

We thank the BW-Stiftung for ﬁnancing both, the

PATRON as well as the MIALinx research project

and the DFG for funding the SitOPT research project.

REFERENCES

Alhadlaq, A., Tang, J., Almaymoni, M., and Korolova, A.

(2017). Privacy in the Amazon Alexa Skills Ecosys-

tem. In Proceedings of the 17

Privacy Enhancing

Technologies Symposium, pages 1–2.

Alpers, S., Betz, S., Fritsch, A., Oberweis, A., Schiefer, G.,

and Wagner, M. (2018). Citizen Empowerment by

a Technical Approach for Privacy Enforcement. In

Proceedings of the 8

International Conference on

Cloud Computing and Services Science, pages 589–

595.

Apthorpe, N., Reisman, D., and Feamster, N. (2016). A

Smart Home is No Castle: Privacy Vulnerabilities of

Encrypted IoT Trafﬁc. In Proceedings of the 2016

Workshop on Data and Algorithmic Transparency,

pages 1–6.

Barth, S. and de Jong, M. D. T. (2017). The privacy para-

dox – Investigating discrepancies between expressed

privacy concerns and actual online behavior – A sys-

tematic literature review. Telematics and Informatics,

34(7):1038–1058.

Beresford, A. R., Rice, A., Skehin, N., and Sohan, R. (2011).

MockDroid: Trading Privacy for Application Func-

tionality on Smartphones. In Proceedings of the 12

Workshop on Mobile Computing Systems and Applica-

tions, pages 49–54.

Cao, J., Carminati, B., Ferrari, E., and Tan, K.-L. (2009). AC-

Stream: Enforcing Access Control over Data Streams.

In Proceedings of the 2009 IEEE International Confer-

ence on Data Engineering, pages 1495–1498.

Chung, H., Iorga, M., Voas, J., and Lee, S. (2017a). “Alexa,

Can I Trust You?”. Computer, 50(9):100–104.

Chung, H., Park, J., and Lee, S. (2017b). Digital forensic

approaches for Amazon Alexa ecosystem. Digital

Investigation, 22(Supplement):S15–S25.

Conti, M., Nguyen, V. T. N., and Crispo, B. (2010). CRePE:

Context-related Policy Enforcement for Android. In

Proceedings of the 13

International Conference on

Information Security, pages 331–345.

Dwork, C. (2006). Differential Privacy. In Proceedings of

the 33

International Conference on Automata, Lan-

guages and Programming, pages 1–12.

Felt, A. P., Egelman, S., and Wagner, D. (2012a). I’ve Got

99 Problems, but Vibration Ain’t One: A Survey of

Smartphone Users’ Concerns. In Proceedings of the

Second ACM Workshop on Security and Privacy in

Smartphones and Mobile Devices, pages 33–44.

Felt, A. P., Ha, E., Egelman, S., Haney, A., Chin, E., and

Wagner, D. (2012b). Android Permissions: User Atten-

tion, Comprehension, and Behavior. In Proceedings of

the Eighth Symposium on Usable Privacy and Security,

pages 3:1–3:14.

Giebler, C., Stach, C., Schwarz, H., and Mitschang, B.

(2018). BRAID — A Hybrid Processing Architecture

for Big Data. In Proceedings of the 7

International

Conference on Data Science, Technology and Applica-

tions, pages 294–301.

Gritti, C., Önen, M., and Molva, R. (2018). CHARIOT:

Cloud-Assisted Access Control for the Internet of

Things. In Proceedings of the 16

International Con-

ference on Privacy, Security and Trust, pages 1–5.

Gritti, C., Önen, M., and Molva, R. (2019). Privacy-

preserving delegatable authentication in the Internet

of Things. In Proceedings of the 34

ACM/SIGAPP

Symposium On Applied Computing, pages 1–8.

Hornyack, P., Han, S., Jung, J., Schechter, S., and Wetherall,

D. (2011). These Aren’t the Droids You’re Looking for:

Retroﬁtting Android to Protect Data from Imperious

Applications. In Proceedings of the 18

ACM Con-

ference on Computer and Communications Security,

pages 639–652.

Jeon, J., Micinski, K. K., Vaughan, J. A., Fogel, A., Reddy,

N., Foster, J. S., and Millstein, T. (2012). Dr. An-

droid and Mr. Hide: Fine-grained Permissions in An-

droid Applications. In Proceedings of the Second ACM

Workshop on Security and Privacy in Smartphones and

Mobile Devices, pages 3–14.

Johnson, N., Near, J. P., and Song, D. (2018). Towards Practi-

cal Differential Privacy for SQL Queries. Proceedings

of the VLDB Endowment, 11(5):526–539.

Kabra, G., Ramamurthy, R., and Sudarshan, S. (2006). Re-

dundancy and Information Leakage in Fine-grained

Access Control. In Proceedings of the 2006 ACM

SIGMOD International Conference on Management of

Data, pages 133–144.

Kleiminger, W., Mattern, F., and Santini, S. (2014). Predict-

ing household occupancy for smart heating control: A

comparative performance analysis of state-of-the-art

approaches. Energy and Buildings, 85:493–505.

Kotecha, R. and Garg, S. (2017). Preserving output-privacy

in data stream classiﬁcation. Progress in Artiﬁcial

Intelligence, 6(2):87–104.

PSSST! The Privacy System for Smart Service Platforms: An Enabler for Conﬁdable Smart Environments

Migliavacca, M., Papagiannis, I., Eyers, D. M., Shand, B.,

Bacon, J., and Pietzuch, P. (2010). DEFCON: High-

performance Event Processing with Information Secu-

rity. In Proceedings of the 2010 USENIX Conference

on USENIX Annual Technical Conference, pages 1–15.

Mindermann, K., Riedel, F., Abdulkhaleq, A., Stach, C.,

and Wagner, S. (2017). Exploratory Study of the Pri-

vacy Extension for System Theoretic Process Analysis

(STPA-Priv) to elicit Privacy Risks in eHealth. In Pro-

ceedings of the 2017 IEEE 4

International Workshop

on Evolving Security & Privacy Requirements Engi-

neering, pages 90–96.

Mood, B. and Butler, K. R. B. (2018). PAL: A pseudo assem-

bly language for optimizing secure function evaluation

in mobile devices. Journal of Information Security and

Applications, 40:78–91.

Orr, D. A. and Sanchez, L. (2018). Alexa, did you get that?

Determining the evidentiary value of data stored by the

Amazon Echo. Digital Investigation, 24:72–78.

Palanisamy, S. M., Dürr, F., Tariq, M. A., and Rothermel, K.

(2018). Preserving Privacy and Quality of Service in

Complex Event Processing Through Event Reordering.

In Proceedings of the 12

ACM International Confer-

ence on Distributed and Event-based Systems, pages

40–51.

Purington, A., Taft, J. G., Sannon, S., Bazarova, N. N.,

and Taylor, S. H. (2017). “Alexa is My New BFF”:

Social Roles, User Satisfaction, and Personiﬁcation of

the Amazon Echo. In Proceedings of the 2017 CHI

Conference Extended Abstracts on Human Factors in

Computing Systems, pages 2853–2859.

Rashidi, P. and Cook, D. J. (2009). Keeping the Resident in

the Loop: Adapting the Smart Home to the User. IEEE

Transactions on Systems, Man, and Cybernetics – Part

A: Systems and Humans, 39(5):949–959.

Samsung Newsroom (2018). Samsung Delivers Vi-

sion for Open and Intelligent IoT Experiences

to Simplify Everyday Life. Press release, Sam-

sung. https://news.samsung.com/us/samsung-vision-

iot-experiences-ces2018-press-conference.

Schaub, F., Balebako, R., and Cranor, L. F. (2017). De-

signing Effective Privacy Notices and Controls. IEEE

Internet Computing, 21(3):70–77.

Shu, J., Jia, X., Yang, K., and Wang, H. (2018). Privacy-

Preserving Task Recommendation Services for Crowd-

sourcing. IEEE Transactions on Services Computing,

pages 1–13.

Sopaoglu, U. and Abul, O. (2017). A Top-Down k-

Anonymization Implementation for Apache Spark. In

Proceedings of the 2017 IEEE International Confer-

ence on Big Data, pages 4513–4521.

Stach, C. (2018). Big Brother is Smart Watching You: Pri-

vacy Concerns about Health and Fitness Applications.

In Proceedings of the 4

International Conference on

Information Systems Security and Privacy, pages 13–

23.

Stach, C., Alpers, S., Betz, S., Dürr, F., Fritsch, A., Min-

dermann, K., Palanisamy, S. M., Schiefer, G., Wag-

ner, M., Mitschang, B., Oberweis, A., and Wagner, S.

(2018a). The AVARE PATRON - A Holistic Privacy

Approach for the Internet of Things. In Proceedings of

the 15

International Joint Conference on e-Business

and Telecommunications, pages 372–379.

Stach, C., Dürr, F., Mindermann, K., Palanisamy, S. M.,

and Wagner, S. (2018b). How a Pattern-based Privacy

System Contributes to Improve Context Recognition.

In Proceedings of the 2018 IEEE International Con-

ference on Pervasive Computing and Communications

Workshops, pages 238–243.

Stach, C. and Mitschang, B. (2013). Privacy Management

for Mobile Platforms – A Review of Concepts and

Approaches. In Proceedings of the 2013 IEEE 14

In-

ternational Conference on Mobile Data Management,

pages 305–313.

Stach, C. and Mitschang, B. (2018a). ACCESSORS: A Data-

Centric Permission Model for the Internet of Things.

In Proceedings of the 4

International Conference on

Information Systems Security and Privacy, pages 30–

40.

Stach, C. and Mitschang, B. (2018b). CURATOR—A Secure

Shared Object Store: Design, Implementation, and

Evaluation of a Manageable, Secure, and Performant

Data Exchange Mechanism for Smart Devices. In

Proceedings of the 33

ACM/SIGAPP Symposium On

Applied Computing, pages 533–540.

Stach, C. and Steimle, F. (2019). Recommender-based Pri-

vacy Requirements Elicitation — EPICUREAN: An

Approach to Simplify Privacy Settings in IoT Applica-

tions with Respect to the GDPR. In Proceedings of the

ACM/SIGAPP Symposium On Applied Computing,

pages 1–8.

Stach, C., Steimle, F., and Mitschang, B. (2018c). THOR —

Ein Datenschutzkonzept für die Industrie 4.0: Daten-

schutzsysteme für die Smart Factory zur Realisierung

der DSGVO. In Workshops der INFORMATIK 2018,

pages 71–83.

Townsend, D., Knoefel, F., and Goubran, R. (2011). Pri-

vacy versus autonomy: A tradeoff model for smart

home monitoring technologies. In Proceedings of the

2011 Annual International Conference of the IEEE

Engineering in Medicine and Biology Society, pages

4749–4752.

Wallis, K., Hüffmeyer, M., Koca, A. S., and Reich, C. (2018).

Access Rules Enhanced by Dynamic IIoT Context. In

Proceedings of the 3

International Conference on

Internet of Things, Big Data and Security, pages 204–

211.

Wieland, M., Hirmer, P., Steimle, F., Gröger, C., Mitschang,

B., Rehder, E., Lucke, D., Rahman, O. A., and Bauern-

hansl, T. (2016). Towards a Rule-based Manufacturing

Integration Assistant. Procedia CIRP, 57(1):213–218.

Zhang, J., Li, H., Liu, X., Luo, Y., Chen, F., Wang, H., and

Chang, L. (2017). On Efﬁcient and Robust Anonymiza-

tion for Privacy Protection on Massive Streaming Cat-

egorical Information. IEEE Transactions on Depend-

able and Secure Computing, 14(5):507–520.

Zheng, S., Apthorpe, N., Chetty, M., and Feamster, N.

(2018). User Perceptions of Smart Home IoT Privacy.

Proceedings of the ACM on Human-Computer Interac-

tion, 2(CSCW):200:1–200:20.

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security
