Effect of Item Representation and Item Comparison Models on Metrics

for Surprise in Recommender Systems

Andre Paulino de Lima

and Sarajane Marques Peres

School of Arts, Sciences and Humanities, University of S

ao Paulo, Brazil

Keywords:

Recommender Systems, Surprise Metric, Unexpectedness, Serendipity, Item Representation, Item Compari-

son, Off-line Evaluation.

Abstract:

Surprise is a property of recommender systems that has been receiving increasing attention owing to its links to

serendipity. Most of the metrics for surprise poorly agree with deﬁnitions employed in research areas that con-

ceptualise surprise as a human factor, and because of this, their use in the task of evaluating recommendations

may not produce the desired effect. We argue that metrics with the characteristics that are presumed by models

of surprise from the Cognitive Science may be more successful in that task. Moreover, we show that a metric

for surprise is sensitive to the choices of how items are represented and compared by the recommender. In this

paper, we review metrics for surprise in recommender systems, and analyse to which extent they align to two

competing cognitive models of surprise. For that metric with the highest agreement, we conducted an off-line

experiment to estimate the effect exerted on surprise by choices of item representation and comparison. We

explore 56 recommenders that vary in recommendation algorithms, and item representation and comparison.

The results show a large interaction between item representation and item comparison, which suggests that

new distance functions can be explored to promote serendipity in recommendations.

1 INTRODUCTION

The purpose of a Recommender System (RS) is to

enable its user to select an item within a universe of

items that is predominantly unknown by them. A rec-

ommender can suggest to its users any of the items

in its repository, and such items can represent any-

thing of interest to users, such as books, movies,

music, hotels, restaurants, or scientiﬁc articles. In

its most rudimentary form, a recommender produces

non-personalised recommendations by offering items

of popular interest to all users. In this case, an RS uses

descriptive statistics of the ratings given to the items

by the users to produce recommendations that con-

sist of items with higher expected rating. However,

numerous approaches have been proposed over time

to allow an RS to produce personalised recommen-

dations by making use of different sources of infor-

mation. To select the personalisation approach that is

the most appropriate for a given domain (e.g. movie

or music recommendation), it is necessary to deﬁne

an evaluation method that can be used to compare

https://orcid.org/0000-0002-3148-6686

https://orcid.org/0000-0003-3551-6480

the performance of different approaches and to deter-

mine which one makes the recommender more or less

competent in that domain. It must be noted that the

evaluation method can assist the owner of the system

not only in selecting a personalisation approach but

also in tuning a recommender instance, assuming that

owner of the system has a method for seeking optimal

parameters according to the objectives imposed by the

application. It must be said that, for a long time, the

most common property associated to the competence

of a recommender was its predictive accuracy.

As the research area evolved, a consensus on

the inadequacy of adopting accuracy as the only rel-

evant property for an application emerged among

researchers (Herlocker et al., 2004; McNee et al.,

2006). Nowadays, beyond-accuracy properties of rec-

ommender systems is known to play a critical role

in user satisfaction and, among these properties, sur-

prise has recently been the subject of several studies

owing to its links to serendipity (Adamopoulos and

Tuzhilin, 2011; Kaminskas and Bridge, 2014; Silveira

et al., 2017) and the problem of over-specialisation

in content-based recommenders (de Gemmis et al.,

2015), as well as its importance in some application

domains (Mour

ao et al., 2017). The notion of surprise

Paulino de Lima, A. and Peres, S.

Effect of Item Representation and Item Comparison Models on Metrics for Surprise in Recommender Systems.

DOI: 10.5220/0007677005130524

In Proceedings of the 21st International Conference on Enterprise Information Systems (ICEIS 2019), pages 513-524

ISBN: 978-989-758-372-8

513

generally reﬂects the capacity to make recommenda-

tions that are dissimilar from the items known to a

given user (Kaminskas and Bridge, 2014; Adamopou-

los and Tuzhilin, 2011; Zhang et al., 2012).

However, the metrics in the literature show a low

level of conceptual agreement with models of surprise

being investigated in Cognitive Science, in which sur-

prise is framed as a human factor. These metrics ex-

plore intuitions about how to assess the surprise ex-

perienced by a user when they are exposed to a rec-

ommendation list. They differ in terms of how much

they can meet requirements imposed by the subjectiv-

ity inherent in the perceptions of surprise, by the dy-

namism of the perception of a user who is constantly

exposed to new experiences, and by the difﬁculty of

evaluating the discrepancy (or distance) between what

is expected and what is observed. Analysing the rela-

tionship of measures with such capacities is the ﬁrst

step for those who intend to understand them. The

next step should be exploring the choice of models for

representing and comparing items, for instance, with

a view to evaluating a recommendation list in a rec-

ommender system (or to another application domain

of particular interest). Such choices are expected to

affect the performance of metrics. Since the knowl-

edge of which combinations of item representations,

item comparison and, in our case, recommender algo-

rithms have a greater or lesser impact on such metrics

generally comes from costly empirical experiments.

The documentation of results from experiments of

this nature is beneﬁcial for the acceleration of future

studies.

In this paper we present the effects of choices

related to item representation and item comparison

models on the results obtained by applying metrics

for surprise, considering combinations of: four item

representation models (count-based and prediction-

based distributional semantics models, sparse and fac-

torised user-item models); six distance functions to

implement item comparison models (Euclidean and

cosine distances as geometric intuitions, Jaccard dis-

tance as a combinatorial intuition, Kullback-Leibler

and Jensen-Shannon divergences as information in-

tuitions, and Aitchison distance as a statistical intu-

ition); and four algorithms to create recommendation

lists (factorisation and three variations of k-nearest

neighbours). The context of movies recommendation

was chosen to support the systematic experiment that

allowed the analysis of the effects. Thus, as contribu-

tions of this work we stand out:

1. proposition of an evaluation framework to support

analysis on the level of agreement of each metric

with two competing cognitive models of surprise:

the cognitive-evolutionary model (Meyer et al.,

1997) and the metacognitive explanation based

model (Foster and Keane, 2015). This framework

is introduced in section 3;

2. organisation and public availability of an extended

dataset which complements the MovieLens-1M

Dataset (Harper and Konstan, 2015) by explicitly

associating movies with their respective textual

short description obtained from online MovieLens

system. This extended dataset offers a richer ex-

perimentation environment to the academic com-

munity since it facilitates the conduction of ex-

periments with item content. Moreover, the pub-

lic availability improves the reproducibility con-

ditions related to the discussions developed in this

paper.

3. investigation on how a metric for surprise is af-

fected by choices of item representation (how

items are mapped to numerical representations)

and item comparison (what is the notion of sim-

ilarity that is captured), through a systematic ex-

perimentation that tests 56 recommenders exe-

cuted with the extended Movielens dataset.

This paper is organised as follows: Section 2

looks into the metrics of surprise proposed for rec-

ommender systems in the last decade, and the state-

of-the-art in off-line evaluation method for surprise.

Section 3 presents an analysis of the extent to which

each metric is in agreement with cognitive models of

surprise following a framework introduced in this pa-

per and justiﬁes the adoption in our experiment of the

metric that achieves the highest agreement. Section

4 describes the results obtained from an experiment

conducted to estimate the effect of item representa-

tion and item comparison on the surprise of a recom-

mender system. Section 5 presents our conclusions.

2 BACKGROUND

This section begins by addressing the relationship be-

tween surprise and other desired properties of recom-

mender systems, and a terminology issue that this re-

lation raises. Then, a review of metrics for surprise

is presented. The section ends with a brief descrip-

tion of the one plus random evaluation method, with

which the metrics can be used and tested.

2.1 The Property of Surprise

The challenge of discovering new items that might be

useful to a user has been the focus of a many works in

the literature on recommender systems. In general,

the approach involves ﬁnding new items that bear

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

514

some similarity to items which have been given good

ratings by a set of selected users. An even greater

challenge is to ﬁnd new items that do not resemble

items known to a user, yet would still be useful to

them. This would be a serendipitous recommenda-

tion. In Herlocker et al. (2002), the authors intro-

duced a deﬁnition of serendipity now widely cited:

“A serendipitous recommendation helps the user ﬁnd

a surprisingly interesting item he might not have oth-

erwise discovered.” In a sense, this deﬁnition sup-

ports a perspective whereby serendipity, as a system

property, results from the interaction of two other and

more fundamental properties: surprise and relevance.

In this view, being surprising and relevant (or useful)

to a user are the basic requirements of a serendipitous

recommendation.

It has been recently pointed out in Kaminskas and

Bridge (2016) that there is a conceptual overlap be-

tween the properties of novelty or unexpectedness and

the notion of surprise

. Thus, the same notion may

be associated with different names in the literature.

In this study, we subscribe to the categorisation sug-

gested by Kaminskas and Bridge (2016), in which (a)

novelty is related to the notion of an item being pop-

ular, and thus is not directly related to serendipity, (b)

unexpectedness usually conveys the same notion as

surprise, and (c) surprise can be regarded as a com-

ponent of serendipity. In view of this, our focus is

on the metrics for estimating surprise, and the met-

rics for serendipity or unexpectedness whose deﬁni-

tions involve the notion of surprise. We claim that the

metrics in the literature, although clearly distinct from

each other, all address some factors commonly related

to scale construction. We select two of these factors

to serve as contrasts in our analysis:

• Intrinsic vs extrinsic evaluation: some metrics

only use data that are internal to the system un-

der evaluation (Akiyama et al., 2010; Zhang et al.,

2012; Kaminskas and Bridge, 2014); other met-

rics use data made available by an external sys-

tem

in addition to data that is internal to the sys-

tem under evaluation (Murakami et al., 2008; Ge

et al., 2010; Adamopoulos and Tuzhilin, 2011).

• Subjective vs objective view: some metrics as-

sume that surprise is subjective in nature, since

it depends on the user past experience, which usu-

ally is represented by the set of items known to a

user (Murakami et al., 2008; Adamopoulos and

Tuzhilin, 2011; Zhang et al., 2012; Kaminskas

A similar overlap has been pointed out by Barto et al.

(2013) in the literature on cognitive science.

Such a system is often referred to as baseline system or

PPM - Primitive Prediction Model.

and Bridge, 2014); other metrics view surprise as

a property of the item (Ge et al., 2010; Akiyama

et al., 2010) and, thus, is independent of the users.

2.2 Metrics for Surprise

In this section, we review six surprise-related metrics.

All of them involve some notion of distance, but they

do not agree on the subjectivity of surprise, neither

on the necessity of the information used in the assess-

ment to be internal to the system being evaluated. Fig-

ure 1 illustrates how they are positioned with regard

to these two factors. In the ﬁgure, the metrics are pre-

sented by year of publication, and the ellipses show

trends or changes in the factors. This review is not

meant to be exhaustive but rather aims to capture the

main approaches that have evolved over the years.

2.2.1 A Metric for Unexpectedness

In Murakami et al. (2008), it was proposed a metric to

evaluate serendipity. It relies on the ideas that (a) rec-

ommendations made by a PPM are prone to be obvi-

ous, and (b) a serendipitous recommendation must be

non-obvious. The metric is calculated from a recom-

mendation list L produced for a user u by the system

being evaluated (Equation 1).

The predicate

rscore accounts for the predicted

relevance of an item L

to the user u, while isrel ac-

counts for surprise, and reﬂects the degree to which

an item L

is similar to items highly rated by the user

(a subjective view).

The metric performs an extrinsic evaluation be-

cause rscore (Equation 2) combines the relevance pre-

dicted by the system under evaluation (Pr) with the

relevance predicted by an external system (Pr

∗

unexp(L, u) =

|L|

∑

i=1

rscore(L

, u)× isrel(L

, u) (1)

rscore(L

, u) = max(Pr(L

, u)− Pr

∗

, u),0). (2)

2.2.2 A Metric for Serendipity

In Ge et al. (2010), another metric was devised to as-

sess serendipity. As shown in Equation 3, srd p is ap-

plied to a list L

, and estimates the average usefulness

of its items, L

. In Equation 4, L

is obtained from the

difference between the list L, generated by the system

under evaluation for the user u, and the list L

∗

, drawn

up for user u by an external system. This means that

The term predicate denotes a procedure that performs

some computation. It is similar to function except that its

domain and codomain are implicit, and thus no assurance

can be given about its success in completing a computation.

Effect of Item Representation and Item Comparison Models on Metrics for Surprise in Recommender Systems

515

Figure 1: Evolution of surprise-related metrics. A metric is classiﬁed as intrinsic if the data it uses are exclusively internal to

the system being evaluated, and it is classiﬁed as subjective if it explicitly identiﬁes the user experience in its deﬁnition.

comprises non-obvious, unexpected items, and ac-

counts for surprise. Thus, srd p performs an extrinsic

evaluation. In addition, we argue that it operates in an

objective way, since the user experience is not consid-

ered when surprise is assessed.

srd p(L

, u) =

∑

i=1

usefulness(L

, u) (3)

= L\L

∗

(4)

2.2.3 A Metric for General Unexpectedness

In Akiyama et al. (2010), it was set out a metric called

“general unexpectedness” that explores a combinato-

rial intuition: an item that shows a rare combination

of attributes must be taken as unexpected. It assumes

that each item has some content combined with it, in

the form of a set of attributes. This usually is the case

with content-based recommenders (de Gemmis et al.,

2015). As shown in Equation 5, the unexp metric is

estimated for L, the recommendation list produced to

user u by the system being evaluated, and this aggre-

gates the uscore obtained for each item L

. The us-

core, deﬁned in Equation 6, is the reciprocal of the

joint probability estimated for each possible pair of

attributes of L

. In this equation, A(L

) represents the

set of attributes that describe L

, N

denotes the num-

ber of items in the repository that have attribute a and

a,b

is the number of items that have both attributes

a and b. Thus an objective view is adopted since sur-

prise can be seen as a property of the content of an

item. Unlike the previously described metrics, this

one does not employ an external system, and, thus,

performs an intrinsic evaluation.

unexp(L) =

|L|

∑

i=1

uscore(L

) (5)

uscore(L

) =



|A(L

∑

a,b∈A(L

)

a,b

+ N

− N

a,b



−1

(6)

2.2.4 A New Metric for Unexpectedness

In Adamopoulos and Tuzhilin (2011), the proposed

metric explores an intuition about user expectation:

an item is expected by a user if it can be anticipated.

The unexp metric (Equation 7) is calculated from L,

the recommendation list produced for user u, and L

a list of obvious, expected items (Equation 8). The

recommendation list L

∗

is produced for user u by an

external system, E

represents the set of items that

have been rated by user u, and the predicate neigh-

bours represents the set of items in the system repos-

itory I that are similar to the items in E

up to some

degree speciﬁed by threshold parameters in θ. Thus,

this metric performs an extrinsic evaluation, and sub-

scribes to the subjective view.

unexp(L, L

) =

|L|

|L\L

| (7)

(u) = L

∗

∪ E

∪ neighbours(I, E

, θ) (8)

2.2.5 The Unserendipity Metric

In Zhang et al. (2012), it was considered that a

serendipitous recommendation must be dissimilar to

items known to the user, in a semantic sense. It resem-

bles the metric proposed by Akiyama et al. (2010),

since it assumes that each item is combined with some

content, but in this case, this content is organised as

vectors in R

. The metric is computed from the rec-

ommendation list L drawn up for user u (Equation 9),

and results in a score that is the average cosine simi-

larity obtained from the items in L and the set of items

known to the user, E

. It does not use an external sys-

tem (intrinsic evaluation), and it adheres to a subjec-

tive view of surprise. It must be noted that the metric

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

516

is scale-inverted: the lower the score, the more sur-

prising L is.

unsrd p(L, u) =

|L||E

∑

i∈L

∑

j∈E

cossim(i, j) (9)

2.2.6 A Metric for Surprise

In a similar way to Zhang et al. (2012), in Kaminskas

and Bridge (2014), it was argued that a surprising rec-

ommendation must be dissimilar to items known to

the user, but does not require that this dissimilarity

should be semantic in nature. They also explore the

interplay between the notions of distance and simi-

larity

. The metric is calculated from the recommen-

dation list L produced for user u (Equation 10) and

assesses the average surprise obtained for each item

in L. The surprise of an item i in L is estimated as

the minimum distance between i and the set E

con-

taining all items known to the user (Equation 11), or

as the maximum degree of similarity between i and

(Equation 12). The function dist is deﬁned as

the Jaccard distance between the set of attributes ex-

tracted from contents linked to items i and j, and sim

computes the normalised pointwise mutual informa-

tion score (NPMI) (Bouma, 2009) for the same items.

This metric does not use an external system (intrin-

sic evaluation), and supports a subjective view of sur-

prise, since it takes account of the user’s experience.

surprise(L, u) =

|L|

∑

i∈L

(i, E

) (10)

(i, E

) = min

j∈E

dist(i, j) (11)

(i, E

) = max

j∈E

sim(i, j) (12)

2.3 Evaluation Method for Surprise

All the metrics described in Section 2.2 evaluate a sin-

gle recommendation list. Thus, an evaluation method

is required to obtain an estimate of how the system

performs with regard to surprise. Most studies follow

a statistical procedure: a sample of users is randomly

drawn, recommendation lists are produced to those

users, surprise evaluations are made, and the average

surprise is taken as the desired estimate.

To estimate the recall property of a recommender

instance in a top-N recommendation task, the off-line

evaluation method one plus random can be adopted

(Cremonesi et al., 2008; Bellogin et al., 2011). This

method follows the intuition that, in a sufﬁciently

Given a distance function, a similarity can be derived

over the same domain (Deza and Deza, 2009).

large set L

that consists of items unknown to user

u, most of these items are irrelevant to u.

In Kaminskas and Bridge (2014) this method was

adapted to estimate the degree of surprise of a recom-

mender system. The original intuition of the method

is retained and, in addition, to computing an estimate

for recall, it also computes the average surprise ob-

tained from the recommendation lists produced for a

sample of users.

3 THE PROPERTY OF SURPRISE

REVISITED

As seen in the previous section, metrics for surprise

explore diverse intuitions to model the relationship

between the surprise experienced by a user and the

recommendation list that was presented to them. In

fact, we argue that a metric for surprise would beneﬁt

from, and should account for, the ideas that have been

explored in the ﬁeld of Cognitive Science about how

humans experience surprise.

Reisenzein et al. (2017) examined the extent to

which the experimental evidence supports current

models of surprise, in particular: the cognitive-

evolutionary model (Meyer et al., 1997), and the

metacognitive explanation-based model (Foster and

Keane, 2015)

According to the cognitive-evolutionary model,

the feeling of surprise emerges as a response to “un-

expected (schema-discrepant) events” that convey a

change in the environment. In contrast, the metacog-

nitive explanation-based model approaches surprise

as a response to a failure to track the cause of a change

in the environment. However, despite of any diver-

gences, the two theories converge about the subjective

nature of surprise, and, to some extent, both models

are aligned with the deﬁnition of surprise as a dis-

tance, as has been proposed in Itti and Baldi (2009).

As the ﬁrst contribution of this paper, we propose

a simple framework to assess the degree of coherence

between a metric for surprise and the set of charac-

teristics presumed by the cognitive models, and apply

it to the metrics for surprise reviewed in the previous

section. The result of this assessment is summarised

in Table 1, and, by adopting this framework, we argue

that the metric proposed by Kaminskas and Bridge

(2014) is in higher agreement to the cognitive models

of surprise because:

(a) it adopts a subjective view, unlike Ge et al. (2010);

Akiyama et al. (2010), and it does not depend on

This study reviews several models, but these two mod-

els are particularly useful to this analysis.

Effect of Item Representation and Item Comparison Models on Metrics for Surprise in Recommender Systems

517

Table 1: Metrics for surprise in recommender systems and their adherence to characteristics presumed by the two cognitive

models. A metric is adherent to the notion of subjectivity if it considers that surprise not only depends on the user experience

(column “is subjective”), but also that this experience must be exclusively internal to the user (column “is intrinsic”).

Subjectivity

Sensitivity to user experience

Metric Is subjective? Is intrinsic? Is dynamic?

(Ge et al., 2010) no — —

(Akiyama et al., 2010) no — —

(Murakami et al., 2008) yes no —

(Adamopoulos and Tuzhilin, 2011) yes no —

(Zhang et al., 2012) yes yes lower

(Kaminskas and Bridge, 2014) yes yes higher

information that resides externally to the system

being evaluated, unlike Murakami et al. (2008);

Adamopoulos and Tuzhilin (2011);

(b) it accounts for changes in the surprise of an un-

observed item, as the growth of the set of items

known to the user (E

), and is more sensitive in

this regard than the metric proposed by Zhang

et al. (2012);

tween a recommended item i and the items known

to the user, which embeds notions of distance.

However, this metric pursues a na

ıve intuition

about surprise and only gives a superﬁcial account of

the real user experience. For example, it can be seen

as an exhaustive search in the user memory E

for

similar events. From this perspective, it assumes that

every individual can recall every past event equally

well, and thus fails to account for known cognitive

biases, such as recall and retrievability biases. The

former refers to the relative ease to recall recent and

vivid events in relation to events that were observed

in a remote past or were unemotional (Tversky and

Kahneman, 1974; Bazerman and Moore, 2009). The

latter refers to how the subjective context can modify

the relative salience to our perception of the features

of an object, and the role that this salience plays in

our judgment of similarity (Tversky, 1977; Gershman,

2017).

Despite of these limitations, and in the absence of

metrics of higher ﬁdelity, we argue that this metric is

still useful to estimate surprise in recommender sys-

tems, and we adopt it in our experiment.

4 EXPERIMENTAL RESULTS

The second and third contributions of this paper re-

fer respectively to the extended dataset and to the

systematisation of an experiment that aim to analyse

the effects of item representation and item compari-

son models on the measures for surprise in a recom-

mender system. Both are presented in this section.

4.1 Experiment Setup

This section presents the dataset, method, models and

algorithms used in the experiment.

4.1.1 Dataset

The MovieLens-1M Dataset (Harper and Konstan,

2015) was used to build the repository of the recom-

mender system instance. The dataset contains 3,883

items (title of movies and a set of genres in which

each movie ﬁts), 6,040 users (demographic data) and

just over 1 million ratings (tuples containing a user, a

movie, the rating given by the user to the movie and

a temporal reference to when the rating was created).

To investigate the effect of item representation in the

metrics for surprise, the dataset was extended to com-

bine a short textual description to each movie.

This extension enables the adoption of data rep-

resentation models that rely on textual content to

produce item vectors. Thus, we enhanced the

MovieLens-1M dataset by combining a short textual

description to each item. These short descriptions

were collected from the online MovieLens system in

September 2017. Items whose description was not

available, too short, or not written in English were

rejected, as well as items with no rating. These con-

straints aim at controlling the variability between our

experiment speciﬁcations at the price of a small re-

duction in the number of items and ratings: 3,643 and

997,136, respectively. The extended dataset adopted

the same format that is employed by the MovieLens

datasets

The code and dataset can be downloaded from

https://github.com/andreplima/surprise-in-recsys.

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

518

4.1.2 Method

A controlled environment was created

. It has three

components: the experiment speciﬁcation (conﬁg), a

recommender system instance, and an evaluator. The

conﬁg speciﬁes: (a) a recommendation algorithm, (b)

an item representation scheme (i.e. how item vectors

are created), (c) an item comparison scheme (i.e. a

distance function that can be applied to item vectors),

and (d) a sample of users. The recommender system

produces a single recommendation list to each user

in the sample by means of the recommendation algo-

rithm speciﬁed in the conﬁg. The evaluator assesses

surprise in the lists by means of a surprise metric (Sec-

tion 3) and the one plus random method (Section 2.3).

The metric always uses the item representation and

distance function speciﬁed in the conﬁg. The sample

of users was drawn once and reused across all con-

ﬁgs, and its size (n = 362) was selected to obtain a

mean surprise estimate with a 5% error margin and

95% conﬁdence.

Given a target conﬁg, the evaluator assesses the

average degree of surprise of the recommendation

lists produced by the recommender system to the

users in the sample. The surprise obtained from each

recommendation list is collected, and the system-level

estimate is taken as the observed average. As detailed

next, each conﬁg speciﬁes one of four item represen-

tation schemes, one of six distance functions, and one

of four recommendation algorithms.

4.1.3 Item Representation

We selected four models, including models employed

in content-based and collaborative approaches: Mod-

els C and D are distributional semantics models

(DSM) based on the document-term matrix, and Mod-

els U and V are based on the user-item matrix:

• Model C (Count-based DSM) is a vector space

model of semantics (Baroni et al., 2014; Tur-

ney and Pantel, 2010). It uses the short tex-

tual description linked to the items to produce

a document-term matrix, from which the item

vectors are extracted. Tokens were stemmed by

means of the Snowball algorithm (Porter, 2001;

Loper and Bird, 2002) before computing tf-idf

scores for each short description (Manning et al.,

2008). Since this is a sparse model, item vectors

have 13,797 dimensions (the number of terms in

the corpus vocabulary).

• Model D (Predictive DSM) is another vector

space model of semantics. The Paragraph Vector

algorithm (Mikolov et al., 2013;

Reh

rek and So-

jka, 2010) is applied on the short descriptions to

extract item vectors. This model can be seen as a

factorised model induced from the document-term

matrix (Levy and Goldberg, 2014). Item vectors

with 100 dimensions were extracted.

• Model U (Sparse UI) is a sparse user-item model

(Ning et al., 2015). Each item i is represented as

a vector r

of length equal to the number of users

in the repository (6,040 users). A vector element

is taken as either the rating the user u has at-

tributed to item i, or zero if the item i was not rated

by the user u.

• Model V (Factorised UI) is a factorised user-item

model (Ning et al., 2015). Each item i is a column

vector q

∈ Q, which is obtained by the PureSVD

algorithm, that is detailed ahead. Item vectors

with 100 dimensions were extracted.

4.1.4 Item Comparison

Six distance functions were selected. They explore

distinct intuitions about separation when comparing

item vectors: Euclidean and cosine distances (ge-

ometric intuition), the Jaccard distance (combinato-

rial), the Kullback-Leibler and Jensen-Shannon di-

vergences (informational), and the Aitchison distance

(Egozcue et al., 2011) (statistical).

However, their application to item vectors from

some representation models is hindered owing to dif-

ferences in their domains: the Jaccard and Aitchi-

son distances, as well as the Kullback-Leibler and

the Jensen-Shannon divergences, require vectors with

non-negative elements, which means that they can

only be safely applied to vectors from Models C and

U; and the Kullback-Leibler and Jensen-Shannon di-

vergences, as well as the Aitchison distance, are not

deﬁned for item vectors with zero-valued elements.

This limitation was overcome by smoothing the item

vectors with the Bayesian Multiplicative Treatment

with Perks prior when needed (Egozcue et al., 2011).

In the conﬁg, distances are coded as follows: 0- Eu-

clidean, 1- cosine, 2- Jaccard, 3- Kullback-Leibler, 4-

Jensen-Shannon, and 5- Aitchison.

4.1.5 Recommendation Algorithms

Four algorithms were selected, encompassing collab-

orative ﬁltering or content-based approaches, and also

neighbourhood and factorisation techniques. It must

be noted that the choices of item representation and

comparison adopted by these algorithms move from

being independent of those used in surprise assess-

ment (algorithm FP) towards using the same deﬁni-

tions adopted by the surprise metric (algorithm N3):

Effect of Item Representation and Item Comparison Models on Metrics for Surprise in Recommender Systems

519

• PureSVD (FP) (Cremonesi et al., 2010): the pre-

dicted score, ˆr

, accounts for the main effects

of and interactions between user and item fac-

tors, and is exclusively computed from ratings:

ˆr

= r

· Q · q

, with the matrix Q being obtained

by factorising the user-item matrix (see Model U).

The score ˆr

is not inﬂuenced by the item repre-

sentation and distance function in the conﬁg.

• Item-kNN with shared distance (N1) (Koren and

Bell, 2015): in a similar vein, the predicted

score is exclusively computed from ratings using

a neighbourhood approach, and also accounts for

main effects and interactions between user and

item factors:

ˆr

= b

∑

j∈S

(i,u)

i j

u j

− b

u j

)

∑

j∈S

(i,u)

i j

, with (13)

= µ + b

+ b

, and s

i j

− 1

i j

− 1 − λ

i j

The neighbourhood S

(i, u) is the set that contains

the k-nearest neighbours of i that have been rated

by u (k = 50). The predicted score is not inﬂu-

enced by the item representation in the conﬁg, but

depends on its distance function: the similarity

weight ρ

i j

, as well as the neighbourhood S

(i, u),

are obtained by applying the distance function in

the conﬁg to item vectors (invariably) obtained

from the Q matrix (see Model V).

• Item-kNN with shared representation (N2): the

predicted score is obtained by Equation 13. How-

ever, now the score is inﬂuenced by the item rep-

resentation in the conﬁg, but does not depend on

its distance function: the similarity weight ρ

i j

, as

well as the neighbourhood S

(i, u), are obtained

by (invariably) applying the cosine similarity to

item vectors encoded as speciﬁed in the conﬁg.

As a result, the predicted score may result from

ratings and content data.

• Item-kNN with shared conﬁg (N3): the predicted

score ˆr

is computed by Equation 13. Now, the

score depends on the item representation and dis-

tance function in the conﬁg: the similarity weight

and the neighbourhood are obtained by applying a

distance function to item vectors encoded as spec-

iﬁed in the conﬁg. Thus, the predicted score may

combine ratings and content data.

4.2 Results

The process was applied to the 56 conﬁgs obtained by

combining recommendation algorithms (FP, N1, N2,

or N3) with compatible pairs of item representation

(C, D, V, or U) and distance function (0 to 5). Fig-

ure 2 shows the median and the interquartile range of

Figure 2: The results obtained from the 56 conﬁgs in the experiment: in the ﬁrst row are the results from Model C; in the

second row, from Model U; and from Models D and V in the third row, left and right, respectively. The notches around the

median represent its conﬁdence interval. The scale (abscissa) may differ across and within distances.

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

520

the surprise obtained from these conﬁgs. In summary,

these statistics showed that:

1. from the neighbourhood-based algorithms (N1 to

N3), the median surprise estimates that were ob-

tained are statistically indiscernible from one an-

other (exceptions in C0, V0, U1, U3, U4, and U5);

2. the median surprise obtained from the factorisa-

tion algorithm (FP) is lower than that obtained

from the neighbourhood algorithms (exceptions in

U0, V0, and U5).

To ensure soundness in the statistical analysis, the

conﬁgs were arranged into eight groups (Figure 3). In

each group, the shaded area delimits a 2 × 6 (Groups

1, 5 and 7) or 4 × 2 (Groups 2, 4, 6 and 8) factorial

experiment design. Owing to particular incompatibil-

ities

that arise in Group 3, it becomes a subset of the

Group 4 and, for that reason, it is not separately con-

sidered in the analysis.

To support the discussion of the next ﬁndings,

consider the pairwise distance distributions shown in

Figure 4; they vary in response to the item repre-

sentation and distance function speciﬁed in a con-

ﬁg. It must be noted that some distributions are nega-

tively skewed (cosine, Jaccard, Kullback-Leibler, and

Jensen-Shannon), and others are positively skewed

(Euclidean and Aitchison).

A repeated-measures ANOVA performed on the

results from Groups 1, 5, and 7 allowed us to explore

variances related to distance functions. At a signiﬁ-

cance level of p < 0.05, all main effects and interac-

tions were signiﬁcant, and contrasts revealed that:

1. the effect of distances with negatively skewed dis-

tributions (compared to other forms) in increas-

ing surprise was signiﬁcant; for the FP algorithm,

this increase was larger for Model C (r = 0.197),

whereas for algorithms N2 and N3 the increase

was larger for Model U (r = 0.211 and 0.264, re-

spectively);

2. for negatively skewed distances, no signiﬁ-

cant difference in surprise between informational

(Kullback-Leibler and Jensen-Shannon) and the

other distances (cosine and Jaccard) was obtained;

3. for informational distances, no signiﬁcant differ-

ence was obtained between the Kulback-Leibler

(asymmetric) and the Jensen-Shannon (symmet-

ric, based on the former).

A similar analysis performed on the results from

Groups 2, 4, 6, and 8 allowed us to explore variances

As the N1 algorithm uses item vectors from the Q ma-

trix, which has negative elements, some distances can not

be safely applied.

related to item representation. At p < 0.05, all main

effects and interactions were signiﬁcant, and contrasts

revealed that:

1. the effect of factorised models (compared to

sparse models) in decreasing surprise was signif-

icant only for the FP algorithm and was smaller

for Euclidean distance than for cosine distance

(r = 0.223);

2. for sparse models (C and U), the effect of using

content data (compared to ratings data) in increas-

ing surprise was signiﬁcant for algorithm FP, and

smaller for Euclidean distance than for cosine dis-

tance (r = 0.252);

3. for factorised models (D and V), the effect of

using content data (compared to ratings data)

in increasing surprise was signiﬁcant for the

neighbourhood-based algorithms N1, N2, and N3

(r = 0.492, 0.461, and 0.483, respectively), and

smaller for cosine than for Euclidean distance.

5 DISCUSSION AND

CONCLUSION

The aim of this work was to assess the effect that

item representation and item comparison models ex-

ert on surprise in recommender systems. We started

by devising a systematic procedure to (a) identify a

set of essential characteristics shared by two compet-

ing models of surprise in the literature on cognitive

science, (b) ﬁnd conceptual correlates of these char-

acteristics in the metrics for surprise of recommender

systems, and (c) select the surprise metric that is in

higher agreement to the cognitive models of surprise.

We then applied the selected metric to empirically as-

sess the effects that distinct models of item represen-

tation and comparison (i.e. how item vectors are ob-

tained and how the similarity between them is com-

puted), as well as recommendation algorithms, exert

on surprise.

Our ﬁndings indicate that conﬁgs with item com-

parison models (distance functions in Section 4.1.4)

that produce negatively skewed pairwise distributions

obtained higher levels of surprise in recommenders

that employ sparse representation models (Models C

and U in Section 4.1.3). In addition, employing con-

tent data in the neighbourhood-based algorithms (N1

to N3 in Section 4.1.5) increased surprise in recom-

menders with factorised models. It seems that the dis-

criminative power of a distance function, which is re-

ﬂected in the skew of its pairwise distribution, directly

relates to the level of surprise of the system. An im-

plication of this relationship is that the pairwise dis-

Effect of Item Representation and Item Comparison Models on Metrics for Surprise in Recommender Systems

521

Group 1 (FP)

Group 2 (FP)

Group 3

∗

(N1)

Group 4 (N1)

Group 5 (N2)

Group 6 (N2)

Group 7 (N3)

Group 8 (N3)

Figure 3: Eight arrangements of conﬁgs. The codes indicate item representations (1

character, see Item representation) and

distance functions (2

character, see Item comparison). Incompatible combinations are marked with a “-”.

Figure 4: Histograms of pairwise distances for compatible conﬁgs (i.e. combinations of an item representation model and

an item comparison model). In the ﬁrst row there are the results from Model C; in the second row, from Model U; and from

Models D and V in the third row, left and right, respectively. The distributions were obtained by computing the distance

between all pairs of items. The ordinate is in log scale and shows the number of pairs that keep the distance in the abscissa.

tribution can be used to predict the level of surprise of

a system. For example, factorisation approaches are

generally assumed to achieve higher accuracy and re-

call when compared to neighbourhood approaches, at

the cost of obtaining lower serendipity. However, as

the results show, recommenders with factorised mod-

els achieved higher surprise than neighbourhood ap-

proaches under certain conditions (positively skewed

distance in conﬁgs U0, V0, and U5). If one accepts

the deﬁnition of serendipity as being an interaction

between surprise and relevance, then strategies to in-

crease surprise, at an acceptable cost in other proper-

ties, may foster serendipity in recommendations.

In summary, this study corroborates the idea that,

in ofﬂine experiments, the assessment of how much

surprise a recommender embeds in its suggestions

heavily depends on how the similarity between items

is modelled. In other words, it may be the case that

the current metrics for surprise are not able to pro-

vide good estimates of the performance of the system.

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

522

Finally, it should be noted that the contributions pre-

sented here could also beneﬁt other research areas that

investigate surprise. We hope this work can show that

recommender systems might be a fruitful resource in

the investigation of surprise in other research areas.

REFERENCES

Adamopoulos, P. and Tuzhilin, A. (2011). On unexpect-

edness in recommender systems: Or how to expect

the unexpected. In Proceedings of the Workshop on

Novelty and Diversity in Recommender Systems at

the Fifth ACM International Conference on Recom-

mender Systems, DiveRS @ RecSys 2011, pages 11–

18, New York, NY, USA. ACM.

Akiyama, T., Obara, K., and Tanizaki, M. (2010). Pro-

posal and evaluation of serendipitous recommenda-

tion method using general unexpectedness. In Pro-

ceedings of the Workshop on the Practical Use of Rec-

ommender Systems, Algorithms and Technologies at

the Fouth ACM International Conference on Recom-

mender Systems, PRSAT @ RecSys 2010, pages 3–10,

New York, NY, USA. ACM.

Baroni, M., Dinu, G., and Kruszewski, G. (2014). Don’t

count, predict! a systematic comparison of context-

counting vs. context-predicting semantic vectors. In

Proceedings of the 52nd Annual Meeting of the As-

sociation for Computational Linguistics (Volume 1:

Long Papers), pages 238–247, Stroudsburg, PA, USA.

Association for Computational Linguistics.

Barto, A., Mirolli, M., and Baldassarre, G. (2013). Novelty

or surprise? Frontiers in Psychology, 4:907.

Bazerman, M. H. and Moore, D. A. (2009). Judgment in

managerial decision making. Wiley, Hoboken, NJ,

USA, 7th. edition.

Bellogin, A., Castells, P., and Cantador, I. (2011).

Precision-oriented evaluation of recommender sys-

tems: An algorithmic comparison. In Proceedings of

the Fifth ACM Conference on Recommender Systems,

RecSys ’11, pages 333–336, New York, NY, USA.

ACM.

Bouma, G. (2009). Normalized (pointwise) mutual infor-

mation in collocation extraction. In Proceedings of

the Conference of the German Society for Computa-

tional Linguistics and Language Technology, GSCL

2009, pages 31–40, Manheim, Germany. GSCL e.V.

Cremonesi, P., Koren, Y., and Turrin, R. (2010). Perfor-

mance of recommender algorithms on top-n recom-

mendation tasks. In Proceedings of the fourth ACM

conference on Recommender systems, pages 39–46.

ACM.

Cremonesi, P., Turrin, R., Lentini, E., and Matteucci, M.

(2008). An evaluation methodology for collaborative

recommender systems. In International Conference

on Automated Solutions for Cross Media Content and

Multi-Channel Distribution, AXMEDIS 2008, pages

224–231, Washington, DC, USA. IEEE.

de Gemmis, M., Lops, P., Musto, C., Narducci, F., and Se-

meraro, G. (2015). Semantics-aware content-based

recommender systems. In Ricci, F., Rokach, L., and

Shapira, B., editors, Recommender Systems Hand-

book, chapter 26, pages 119–159. Springer, New

York, NY, 2nd. edition.

Deza, M. M. and Deza, E. (2009). Encyclopedia of Dis-

tances. Springer, Berlin, Heidelberg.

Egozcue, J. J., Barcel

o-Vidal, C., Mart

ın-Fern

andez, J. A.,

Jarauta-Bragulat, E., D

ıaz-Barrero, J. L., and Mateu-

Figueras, G. (2011). Compositional Data Analysis,

chapter 11, pages 139–157. Wiley-Blackwell, Hobo-

ken, NJ, USA.

Foster, M. I. and Keane, M. T. (2015). Why some sur-

prises are more surprising than others: Surprise as a

metacognitive sense of explanatory difﬁculty. Cogni-

tive Psychology, 81:74–116.

Ge, M., Delgado-Battenfeld, C., and Jannach, D. (2010).

Beyond accuracy: Evaluating recommender systems

by coverage and serendipity. In Proceedings of the

Fourth ACM Conference on Recommender Systems,

RecSys ’10, pages 257–260, New York, NY, USA.

ACM.

Gershman, S. J. (2017). Similarity as inference. submitted.

Harper, F. M. and Konstan, J. A. (2015). The movielens

datasets: History and context. ACM Transactions on

Interactive Intelligent Systems (TiiS), 5(4):19.

Herlocker, J., Konstan, J. A., and Riedl, J. (2002). An

empirical analysis of design choices in neighborhood-

based collaborative ﬁltering algorithms. Information

retrieval, 5(4):287–310.

Herlocker, J. L., Konstan, J. A., Terveen, L. G., and Riedl,

J. T. (2004). Evaluating collaborative ﬁltering recom-

mender systems. ACM Transactions on Information

Systems (TOIS), 22(1):5–53.

Itti, L. and Baldi, P. (2009). Bayesian surprise attracts hu-

man attention. Vision research, 49(10):1295–1306.

Kaminskas, M. and Bridge, D. (2014). Measuring sur-

prise in recommender systems. In Proceedings of the

Workshop on Recommender Systems Evaluation: Di-

mensions and Design, at the 8th ACM Conference on

Recommender Systems, REDD @ RecSys ’14, pages

393–394, New York, NY, USA. ACM.

Kaminskas, M. and Bridge, D. (2016). Diversity, serendip-

ity, novelty, and coverage: A survey and empiri-

cal analysis of beyond-accuracy objectives in recom-

mender systems. ACM Trans. Interact. Intell. Syst.,

7(1):2:1–2:42.

Koren, Y. and Bell, R. (2015). Advances in collaborative

ﬁltering. In Ricci, F., Rokach, L., and Shapira, B.,

editors, Recommender Systems Handbook, chapter 3,

pages 77–118. Springer, New York, NY, 2nd. edition.

Levy, O. and Goldberg, Y. (2014). Neural word embedding

as implicit matrix factorization. In Advances in neural

information processing systems (NIPS), pages 2177–

2185.

Loper, E. and Bird, S. (2002). Nltk: The natural lan-

guage toolkit. In Proceedings of the ACL-02 Work-

shop on Effective Tools and Methodologies for Teach-

ing Natural Language Processing and Computational

Linguistics - Volume 1, ETMTNLP ’02, pages 63–

70, Stroudsburg, PA, USA. Association for Compu-

tational Linguistics.

Manning, C. D., Raghavan, P., and Sch

utze, H. (2008). In-

troduction to Information Retrieval. Cambridge Uni-

versity Press, New York, NY, USA.

Effect of Item Representation and Item Comparison Models on Metrics for Surprise in Recommender Systems

523

McNee, S. M., Riedl, J., and Konstan, J. A. (2006). Being

accurate is not enough: How accuracy metrics have

hurt recommender systems. In Extended Abstracts on

Human Factors in Computing Systems, CHI EA ’06,

pages 1097–1101, New York, NY, USA. ACM.

Meyer, W.-U., Reisenzein, R., and Sch

utzwohl, A. (1997).

Toward a process analysis of emotions: The case of

surprise. Motivation and Emotion, 21(3):251–274.

Mikolov, T., Sutskever, I., Chen, K., Corrado, G. S., and

Dean, J. (2013). Distributed representations of words

and phrases and their compositionality. In Burges, C.

J. C., Bottou, L., Welling, M., Ghahramani, Z., and

Weinberger, K. Q., editors, Advances in Neural In-

formation Processing Systems 26, pages 3111–3119.

Curran Associates, Inc., Red Hook, NY, USA.

Mour

ao, F., Rocha, L., Ara

ujo, C., Meira Jr, W., and Kon-

stan, J. (2017). What surprises does your past have for

you? Information Systems, 71:137–151.

Murakami, T., Mori, K., and Orihara, R. (2008). Metrics for

evaluating the serendipity of recommendation lists. In

Satoh, K., Inokuchi, A., Nagao, K., and Kawamura,

T., editors, New Frontiers in Artiﬁcial Intelligence,

pages 40–46, Berlin, Heidelberg. Springer.

Ning, X., Desrosiers, C., and Karypis, G. (2015). A com-

prehensive survey of neighborhood-based recommen-

dation methods. In Ricci, F., Rokach, L., and Shapira,

B., editors, Recommender Systems Handbook, chap-

ter 2, pages 37–76. Springer, New York, NY, 2nd. edi-

tion.

Porter, M. F. (2001). Snowball: A language for stemming

algorithms.

Reh

rek, R. and Sojka, P. (2010). Software Framework

for Topic Modelling with Large Corpora. In Proceed-

ings of the LREC 2010 Workshop on New Challenges

for NLP Frameworks, pages 45–50, Valletta, Malta.

ELRA.

Reisenzein, R., Horstmann, G., and Sch

utzwohl, A. (2017).

The cognitive-evolutionary model of surprise: A re-

view of the evidence. Topics in Cognitive Science,

(Online Early View).

Silveira, T., Rocha, L., Mour

ao, F., and Gonc¸alves, M.

(2017). A framework for unexpectedness evaluation

in recommendation. In Proceedings of the Symposium

on Applied Computing, SAC ’17, pages 1662–1667,

New York, NY, USA. ACM.

Turney, P. D. and Pantel, P. (2010). From frequency to

meaning: Vector space models of semantics. Journal

of Artiﬁcial Intelligence Research, 37(1):141–188.

Tversky, A. (1977). Features of similarity. Psychological

Review, 84(4):327.

Tversky, A. and Kahneman, D. (1974). Judgment un-

der uncertainty: Heuristics and biases. Science,

185(4157):1124–1131.

Zhang, Y. C., S

eaghdha, D. O., Quercia, D., and Jambor, T.

(2012). Auralist: Introducing serendipity into music

recommendation. In Proceedings of the Fifth ACM In-

ternational Conference on Web Search and Data Min-

ing, WSDM ’12, pages 13–22, New York, NY, USA.

ACM.

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

524
