Associative Classiﬁcation in Big Data through a G3P Approach

J. M. Luna, F. Padillo and S. Ventura

Department of Computer Science and Numerical Analysis, University of Cordoba, Spain

Keywords:

Big Data, Associative Classiﬁcation, Evolutionary Computation.

Abstract:

The associative classiﬁcation ﬁeld includes really interesting approaches for building reliable classiﬁers and

any of these approaches generally work on four different phases (data discretization, pattern mining, rule

mining, and classiﬁer building). This number of phases is a handicap when big datasets are analysed. The aim

of this work is to propose a novel evolutionary algorithm for efﬁciently building associative classiﬁers in Big

Data. The proposed model works in only two phases (a grammar-guided genetic programming framework is

performed in each phase): 1) mining reliable association rules; 2) building an accurate classiﬁer by ranking

and combining the previously mined rules. The proposal has been implemented on Apache Spark to take

advantage of the distributed computing. The experimental analysis was performend on 40 well-known datasets

and considering 13 algorithms taken from literature. A series of non-parametric tests has also been carried

out to determine statistical differences. Results are quite promising in terms of reliability and efﬁciency on

high-dimensional data.

1 INTRODUCTION

Nowadays, data storage is getting cheaper and

cheaper what implies an increment in the efforts for

analyzing and extracting valuable information from

large datasets. This issue has motivated recent re-

search studies on Big Data (Chen et al., 2012), which

encompasses a set of techniques to face up problems

derived from the management and analysis of huge

quantities of data. In data analysis, two different

tasks are considered: descriptive tasks, which depict

intrinsic and important properties of data (Agrawal

et al., 1993); and predictive tasks, which predict out-

put variables for unseen data (Han and Kamber, 2011)

by learning a mapping between a set of input vari-

ables and the output variable. Focusing on predic-

tive tasks, different methodologies can be considered

to build accurate models that predict the output vari-

able: rule-based systems (Han and Kamber, 2011),

decision trees (Quinlan, 1993) and support vector ma-

chines (Cortes and Vapnik, 1995), just to list a few.

From all these methodologies, rule-based classiﬁers

provide a high-level of interpretability and, therefore,

classiﬁcation results can be explained since rules tend

to be easily understood and interpreted by the end-

user. An example of such systems is classiﬁcation

based on association rule mining, generally known

as associative classiﬁcation (AC) (Ventura and Luna,

2018), which integrates a descriptive task (association

rule mining (Agrawal et al., 1993)) in the process of

inferring a new classiﬁer (Liu et al., 1998).

AC algorithms generally operate in four phases.

First, data transformation in which continuous at-

tributes are preprocessed and deﬁned in a discrete do-

main. Second, the attribute values are combined and

characterized by an occurrence value beyond a given

threshold. Third, association rules (the consequent

is ﬁxed to the class variable) are produced from the

set of frequent attributes previously obtained. Finally,

rules are ranked and post-processed to build an accu-

rate classiﬁer. However, these numerous phases, spe-

cially when working on Big Data, become unfeasible

to be addressed by existing methodologies even when

advanced techniques in distributed computing (Dean

and Ghemawat, 2008) are considered. At this point,

a reduction in the number of required phases has

been recently addressed by considering evolutionary

algorithms (EAs) (Alcal

a-Fdez et al., 2011). Here,

rules were directly mined without a previous step of

extracting patterns (combination of attribute values).

Nevertheless, even for a lower number of phases, the

computational complexity in Big Data is still a hand-

icap since it exponentially increases with the number

of variables (2

−1 solutions can be found from k vari-

ables). Recent approaches (MRAC (Bechini et al.,

2016), MRAC+ (Bechini et al., 2016), DAC (Ven-

turini et al., 2017), etc.) have dealt with the prob-

lem through current advances in distributed comput-

Luna, J., Padillo, F. and Ventura, S.

Associative Classiﬁcation in Big Data through a G3P Approach.

DOI: 10.5220/0007688400940102

In Proceedings of the 4th International Conference on Internet of Things, Big Data and Security (IoTBDS 2019), pages 94-102

ISBN: 978-989-758-369-8

ing even though they were based on classical algo-

rithms and only provided an improvement in runtime.

The aim of this paper is therefore to propose a

new grammar-guided genetic programming (G3P) al-

gorithm for AC on Big Data by considering Spark.

G3P has been already studied in mining association

rules (Ventura and Luna, 2016), and it has proved to

obtain excellent results in both introducing subjective

knowledge into the mining process and constraining

the search space by including syntax constraints. An

important feature of the proposed algorithm, which

really improves the state-of-the-art, is the running on

just two phases: 1) mining reliable association rules;

and 2) building an accurate classiﬁer. In the ﬁrst

stage, the best rules for each class are obtained by

means of multiple and independent evolutionary pro-

cesses (no discretization step is required since the use

of a grammar enables continuous features to be en-

coded). In the second stage, the set of the previ-

ously mined rules are ranked and combined to form

an accurate classiﬁer. Since rules for each class is ob-

tained, it is guaranteed that minority/majority classes

are equally considered. This is an additional major

feature of the proposal since many AC approaches are

focused on improvements of classiﬁcation accuracy,

not paying attention to the imbalance problem. In

an experimental analysis, the proposal has been com-

pared to multiple AC approaches as well as traditional

classiﬁcation algorithms. In this study, both sequen-

tial and trending MapReduce AC algorithms are con-

sidered and compared. Experiments were performed

on a total of 40 datasets and results were validated by

non-parametric statistical tests.

The rest of the paper is organized as follows. Sec-

tion 2 presents the most relevant deﬁnitions and re-

lated work; Section 3 describes the proposed algo-

rithm; Section 4 presents the experimental results, and

some concluding remarks are outlined in Section 5.

2 PRELIMINARIES

In this section, the associative classiﬁcation task is

formally deﬁned as well as some Big Data architec-

tures.

2.1 Associative Classiﬁcation

In 1998, Liu et al. (Liu et al., 1998) connected associ-

ation rule mining (ARM) and classiﬁcation rule min-

ing to give rise to the task known as associative clas-

siﬁcation (AC). The aim of this task was to build an

accurate and high interpretable classiﬁer by means of

rules obtained from ARM techniques. In order to ob-

tain this kind of classiﬁers many methods have been

proposed along the years (Thabtah, 2007), almost all

of them being based on exhaustive search ARM algo-

rithms (Agrawal et al., 1993). In general, existing AC

approaches work on four different steps, which is a

real handicap when computationally expensive prob-

lems are addressed. For instance, the extraction of

patterns (itemsets) and association rules from them

implies two different and computationally hard prob-

lems (the number of solutions exponentially increases

with the number of items in data) (Padillo et al.,

2017). To overcome these and other problems (work-

ing on continuous domains), some researchers have

focused on the application of evolutionary algorithms

(EAs) for performing the AC task. At this point, the

combination of EAs with emerging paradigms like

MapReduce to process high volumes of data in an ac-

curate and efﬁcient fashion is a trending topic (Padillo

et al., 2017).

2.2 Big Data Architectures

MapReduce (Dean and Ghemawat, 2008) is a re-

cent paradigm, ﬁrstly implemented by Hadoop (Lam,

2010), of distributed computing for Big Data in which

programs are composed of two main stages, that is,

map and reduce. In the map phase each mapper pro-

cesses a subset of input data and produces a set of

hk, vi pairs. Finally, the reducer takes this new list

to produce the ﬁnal values. A major drawback of

Hadoop, however, is it imposes an acyclic data ﬂow

graph, and there are applications (iterative or inter-

active analysis (Zaharia et al., 2010)) that cannot be

efﬁciently modeled through this kind of graph. Be-

sides, Hadoop cannot keep intermediate data in mem-

ory for faster performance. To solve these downsides,

Apache Spark has risen up for solving all the deﬁ-

ciencies of Hadoop, introducing an abstraction called

RDD (Resilient Distributed Datasets) to store data in

main memory as well as a new approach that consid-

ers micro-batch technology.

3 G3P PROPOSAL

The proposed grammar-guided genetic programming

(G3P) algorithm has been designed to be parallel

without affecting the ﬁnal accuracy. A major fea-

ture of the proposed model, named G3P-AC, is it

works in two stages: 1) mining reliable association

rules; 2) building an accurate classiﬁer by ranking

and combining the previously mined rules. The ﬁrst

step is responsible for extracting the best set of rules

Associative Classiﬁcation in Big Data through a G3P Approach

G = (Σ

, Σ

, P, S) with:

S = <Rule>

= {<Rule>, <Antecedent>, <Consequent>, <Condition>, <Nominal>,

<Numerical>}

= {attribute, value, AND, =, IN, Min value, Max value, class}

P = {<Rule> ⇐ <Antecedent>, <Consequent> ;

<Antecedent> ⇐ <Condition> (AND <Condition>)* ;

<Consequent> ⇐ class = value ;

<Condition> ⇐ <Numerical> | <Nominal> ;

<Numerical> ⇐ name IN Min value, Max value ;

<Nominal> ⇐ name = value ;

}

Figure 1: Context-free grammar deﬁned for the rule extraction stage of the proposed algorithm. The grammar is expressed in

extended BNF notation.

for each class by means of several evolutionary pro-

cesses (one per class). Such evolutionary processes

follow a normal generational genetic algorithm with

elitism in which the best solutions found until that

moment are kept unaltered. The quality of the so-

lutions is measured by a ﬁtness function (taking val-

ues in the range [0, 1] where the higher the better) that

was designed to obtain a good trade-off between re-

liability (conﬁdence of the rule) and frequency with

regard to the class, that is, F(R) = con f idence(R) ×

support(R)/support(Y ) for a rule R ≡ X → Y . This

ﬁrst stage starts by encoding a set of individuals

through a number of production rules from a context-

free grammar (see Figure 1). Thanks to this grammar,

an expert in the domain may determine the maximum

or minimum length of the rules (in the form of class

association rules), and the kind of conditions each rule

should include (Ventura and Luna, 2016). This evolu-

tionary process works in an iterative fashion through

a number of generations previously ﬁxed by the end-

user. However, this iterative process may ﬁnish with-

out reaching the maximum number of generations in

situations where the average ﬁtness value of individ-

uals within the elite does not change for a number of

generations. Additionally, in order to guarantee the

quality of the solutions and to avoid redundant solu-

tions a pattern weighting scheme is used in the elite

population (Herrera et al., 2011). Finally, in order to

produce new individuals, a tournament selector is ap-

plied in each iteration of the evolutionary process and

new individuals are then obtained by the traditional

G3P genetic operators, producing a new population

that will update both the previous one and the elite.

The genetic operators used to produce new solutions

are two well-known operators that have proved to ob-

tain promising results in G3P (McKay et al., 2010).

The second stage of the proposed algorithm fol-

lows an evolutionary process that is similar to the

one of the ﬁrst stage. In this second stage, how-

ever, the aim is to ﬁlter, sort and arrange previously

mined rules to form a ﬁnal classiﬁer. Unlike the pre-

vious stage, individuals are represented in a differ-

ent fashion since now each individual represents a

set of rules that will form the ﬁnal classiﬁer (not a

single rule as in the ﬁrst stage). It is important to

remark that no rule can be produced in this phase

and it only works with those previously obtained in

the ﬁrst phase. This second phase considers a gram-

mar (see Figure 2) to customize the shape of the ﬁnal

classifer. Here, the quality of the solutions (sets of

rules that represents a classiﬁer) is calculated as the

average accuracy in training for each class. Given

an individual ind, the ﬁtness function F is deﬁned

as F(ind) = (1/l) ∗ (

∑

n=1

accuracy

/m). Here, m is

the number of classes, l the number of rules included

in ind and accuracy

is the accuracy in the training

set for the class c. It was designed to avoid classi-

ﬁers including a large number of rules and to penal-

ize classiﬁers that ignore minority class. Similarly to

the previous stage, the genetic operators used to pro-

duce new solutions are two well-known operators that

have proved to obtain promising results (McKay et al.,

2010).

These two stages have been designed to be run on

a cluster of computers that includes a central com-

puter (driver program) acting as point of coordination,

and several additional nodes that collaboratively work

G = (Σ

, Σ

, P, S) with:

S = Classiﬁer

= {<Classiﬁer>, <Rules>, <DefaultClass>}

= {rule, class, =, value}

P = {<Classiﬁer> ⇐ <Rules> <DefaultClass> ;

<Rules> ⇐ rule (rule)* ;

<DefaultClass> ⇐ class = value ;

}

Figure 2: Context-free grammar deﬁned for the rule selec-

tion stage of the proposed algorithm. The grammar is ex-

pressed in extended BNF notation. The terminal symbol

rule represents an individual from the previous phase (see

grammar shown in Figure 1).

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

Algorithm 1: Proposed algorithm on Spark - Rule extraction stage.

procedure Driver

1: pool rules ←

2: for all c in classes do

3: new Thread() do

4: P

0,c

← Generate a random population of n rules following the grammar with class c

5: elite

←

6: for i = 0 to #Generations do

7: MapReduce to evaluate rules from (P

i,c

)

8: elite

← Maintain elitism using P

i,c

∪ elite

9: Stop if mean(elite

) has not changed in a number of generations speciﬁed by the user

10: selected invididuals ← Tournament selector to P

i,c

11: for all pair in selected individuals do

12: o f f spring ← pair

13: if Rand number(0,1) > Prob

cro

then

14: o f f spring ← Cross o f f spring

15: end if

16: for all individual of the o f f spring do

17: if Rand number(0,1) > Prob

mut

then

18: o f f spring ← Mutate individual

19: end if

20: end for

21: end for

22: P

i+1,c

← o f f spring ∪ best n individuals from elite

23: end for

24: pool rules ← pool rules ∪ elite

25: end

26: end for

end procedure

procedure Map(instance, P

i,c

)

1: for all r in P

i,c

2: measures ← r.evaluate(instance)

3: emit(r, measures)

4: end for

end procedure

procedure Reduce(r, measures)

1: finalMeasures ← (0, 0, 0) // Support antecedent, consequent and rule

2: for all measure in measures do

3: for i = 0 to 2 do

4: f inalMeasures[i] ← f inalMeasures[i] + measure[i]

5: end for

6: end for

7: fitness ← calculateFitness( f inalMeasures)

8: emit(r, f itness)

end procedure

with the driver. The two phases (rule extraction and

rule selection) are described as follows:

• Rule Extraction. The driver program starts by

creating as many threads as classes exist in data

(see Driver procedure of Algorithm 1). After

that, each thread enqueues several MapReduce

jobs (which will run on several compute nodes)

to evaluate its population. In the Map proce-

dure (see Algorithm 1), the input for each map-

per is a chunk of data and the population. A

group of pairs hkey,valuei are generated by each

mapper, key being the rule, value representing a

tuple of support values (antecedent, consequent

and whole rule). Reducers (see Reduce pro-

cedure, Algorithm 1), on the contrary, receive

the previously created hkey, valuei pairs as in-

put. Here, the global support values for an-

tecedent (support(X)), consequent (support(Y ))

and rule (support(R)) are obtained for each in-

dividual. Once, these three measures have being

calculated, the ﬁtness function is obtained as F(R)

= con f idence(R) × support(R)/support(Y ) and

the rules (individuals) are returned to their respec-

tive threads. Each thread continues its evolution-

ary process until a new population is required to

be evaluated and the previous process repeated.

Associative Classiﬁcation in Big Data through a G3P Approach

∑

i=0

numberGenerations(c

) represents the num-

ber of MapReduce jobs, where m is the number of

classes, and numberGenerations(c

) is the num-

ber of generations for the i-th class. Once all the

threads end, a pool of rules is obtained by gath-

ering rules for each class (obtained by different

threads). This pool of rules is saved on distributed

structures of storage as RDD for Spark, enabling

a distributed fast access as well as a large quantity

of results to be saved.

• Rule Selection. In this second phase, the eval-

uation process is the only procedure to be paral-

lelized. In this regard, Algorithm 2 shows pseudo-

code for the evaluation process through a MapRe-

duce Job. The Map procedure (see Algorithm 2)

receives two elements as input: a subset of the

dataset, and the population. A group of pairs

hkey,valuei is generated by each mapper, where

the key is the rule-set, and the value is a tuple

with the accuracy values per class. The reducer

procedure (see Algorithm 2), on the contrary, re-

ceives the previously created hkey,valuei pairs as

input. Its goal is to calculate the total accuracy

values per class (considering the whole dataset).

After that, the ﬁtness function is calculated as

F(rule − set) =

∗

∑

n=1

accuracy

and the rule-set

is returned. The output of the reducer is the eval-

uated population considering the whole dataset.

4 EXPERIMENTAL ANALYSIS

The aim of this section is to study the behaviour

of our proposal on more than 40 well-known

datasets (see Table 1)— all of them are available at

KEEL (Triguero et al., 2017) repository. Results are

compared to multiple AC algorithms by considering

a series of non-parametric tests. All the experiments

have been run on a HPC cluster comprising 12 com-

pute nodes, with two Intel E5-2620 microprocessors

at 2 GHz and 24 GB DDR memory. Cluster operating

system was Linux CentOS 6.3. As for the speciﬁc de-

tails of the used software, the experiments have been

run on Spark 2.0.0. To quantify the usefulness of

the solutions in this experimental analysis both accu-

racy rate (Han and Kamber, 2011) and Cohen’s kappa

rate (Ben-David, 2008) are considered. A 10-fold

stratiﬁed cross-validation has been used, and each al-

gorithm has been executed 5 times. Thus, the results

for each dataset are the average result of 50 different

runs. The algorithms used in this experimental anal-

ysis are divided into two main groups, that is, clas-

sical and Big Data algorithms. As for classical algo-

rithms, it includes CBA (Liu et al., 1998), CBA2 (Liu

Table 1: List of datasets (in alphabetical order) used for the

experimental study. They have been categorized into two

categories: classical datasets and Big Data datasets.

Datasets #Attributes #Instances #Classes

Classical datasets

Appendicitis 7 106 2

Australian 14 690 2

Banana 2 5,300 2

Breast 9 277 2

Cleveland 13 297 5

Contraceptive 9 1,473 3

Flare 11 1,066 6

German 20 1,000 2

Hayes-roth 4 160 3

Heart 13 270 2

Iris 4 150 3

Lymphography 18 148 4

Magic 10 19,020 2

Mammographic 5 830 2

Monk-2 6 432 2

Mushroom 22 5,644 2

Page-blocks 10 5,472 5

Phoneme 5 5,404 2

Pima 8 768 2

Post-operative 8 87 3

Saheart 9 462 2

Spectfheart 44 267 2

Splice 60 3,190 3

Tae 5 151 3

Tic-tac-toe

9 958 2

Titanic 3 2,201 2

Vehicle 18 846 4

Wine 13 178 3

Winequality 11 4,898 7

Wisconsin 9 683 2

Big Data datasets

Census 40 299,285 2

CoverType 54 581,012 2

Hepmass 28 10,500,000 2

Higgs 28 11,000,000 2

Poker 10 1,025,010 11

Kddcup1999 41 4,898,431 23

KDD99 2 41 4,856,151 2

KDD99 5 41 4,856,151 5

Record-Linkage 12 5,749,132 2

Sussy 18 5,000,000 2

et al., 2001), CMAR (Li et al., 2001), CPAR (Yin

and Han, 2003) and FARCHD (Alcal

a-Fdez et al.,

2011). Additionally, four classical rule-based classiﬁ-

cation algorithms have been considered: C4.5 (Quin-

lan, 1993), RIPPER (Cohen, 1995), CORE (Tan et al.,

2006) and OneR (Holte, 1993). As for AC algo-

rithms designed for Big Data, the following are con-

sidered: MRAC (Bechini et al., 2016), MRAC+ (Be-

chini et al., 2016), DAC (Venturini et al., 2017) and

DFAC-FFP (Segatori et al., 2018).

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

Algorithm 2: Proposed algorithm on Spark - Rule selection stage.

procedure Algorithm

1: P

← Initialize a random population of n individuals (classiﬁers) including rules from pool rules

2: for i = 0 to #Generations do

3: for all ruleset in population do

4: MapReduce to evaluate ruleset

5: end for

6: best individual ← Best individual from P

7: Stop if best individual(P

) has not improved in a number of generations speciﬁed by the user

8: selected invididuals ← Apply tournament selector to P

9: for all pair in selected individuals do

10: o f f spring ← pair

11: if Rand number(0,1) > Prob

cro

then

12: o f f spring ← Cross o f f spring

13: end if

14: for all individual of the o f f spring do

15: if Rand number(0,1) > Prob

mut

then

16: o f f spring ← Mutate individual

17: end if

18: end for

19: end for

20: P

i+1

← o f f spring ∪ best invididual

21: end for

22: de f ault class ← Class whose frequency of occurrence is the highest

23: Classify using best individual and de f ault class

end procedure

procedure Map(chunk, ruleset)

1: accuracy class ← (0, ..., 0) // One per class in data

2: for all instance in chunk do

3: accuracy class[instance.class] ← accuracy class[instance.class] + Accuracy of ruleset in instance

4: end for

5: emit(ruleset, accuracy class)

end procedure

procedure Reduce(ruleset, accuracy class)

1: f inal accuracy class ← (0, ..., 0) // As many as classes exist in dataset

2: for all accuracy class in accuracy class do

3: for i = 0 until number classes do

4: f inal accuracy class[i] ← accuracy class[i]

5: end for

6: end for

7: f itness ← ruleset.calculateFitness( f inal accuracy class)

8: emit(ruleset, f itness)

end procedure

4.1 Quality of the Solutions

All the classical algorithms were run on the classical

datasets and the rankings for both accuracy and kappa

measures are shown in Table 2. Focusing on accu-

racy (see Table 2a), it is obtained that CMAR obtained

the worst result and it may be caused by the fact that

CMAR is based on exhaustive search algorithms that

cannot be directly run on continuous domains, requir-

ing therefore a discretization step that implies data-

loss. Besides, CMAR optimizes the conﬁdence mea-

sure in isolation, generating very speciﬁc classiﬁers

that are not able to correctly predict unseen examples.

On the other hand, AC algorithms such as FARCHD,

CPAR and our proposal (G3P-AC) obtained the best

results with really small differences among them. Fi-

nally, focusing on the Kappa metric (see Table 2b),

very similar results were obtained and the three best

algorithms in ranking were FARCHD, CPAR and our

proposal.

The next step in this experimental analysis is the

study of whether there exist statistical differences

among all the algorithms and, therefore, several non-

parametric tests were carried out. First, a Friedman

test has been performed on the accuracy measure, ob-

taining a X

= 77.55 with a critical value of 21.66 and

a p-value = 4.93

−13

. In the same way, a X

= 70.66

with a critical value of 21.66 and a p-value = 1.12

−11

has been obtained for the Kappa metric. In both cases,

and considering a value α = 0.01, it is not possible

Associative Classiﬁcation in Big Data through a G3P Approach

Table 2: Average ranking for each algorithm (sorted in de-

scending order) according to the Friedman test.

Algorithm Ranking

CMAR 7.916

OneR 7.350

CORE

7.150

CBA 6.233

Ripper 5.950

CBA2 4.816

C4.5 4.233

FARCHD 3.983

CPAR 3.683

G3P-AC 3.683

(a) Accuracy measure.

Algorithm Ranking

OneR 7.850

CMAR 7.400

CORE

7.383

CBA 6.100

Ripper 4.966

CBA2 4.766

C4.5 4.383

CPAR 4.283

FARCHD 4.150

G3P-AC 3.716

(b) Kappa measure.

Table 3: p-values for the Holland test with α = 0.01.

Vs G3P-AC

CBA 0.035

CBA2 0.933

CMAR 0.000

FARCHD 0.999

C4.5 0.998

Ripper 0.100

CORE 0.000

OneR 0.000

(a) Accuracy measure.

Vs G3P-AC

CBA 0.060

CBA2 0.965

CMAR 0.000

CPAR 0.999

FARCHD 1.000

C4.5 0.999

Ripper 0.890

CORE

0.000

OneR 0.000

(b) Kappa measure.

to assert that all the algorithm equally behave. In

this regard, a post-hoc test is performed (see Table 3)

by considering α = 0.01. Focusing on the accuracy

measure and taking our proposal as control, the post-

hoct test (see Table 3a) denotes some statistical dif-

ferences with regard to CMAR, CORE and OneR. It

should be noted that our proposal and CPAR did not

obtain any statistical differences so th post-hoc test

was not performed on them. In this sense, a Wilcoxon

signed rank test has been carried out on CPAR and

our proposal, obtaining a Z-value = −0.6582 with p-

value = 0.50926. It is therefore not possible to assert

that, at a signiﬁcance level of α = 0.01, there is a sig-

niﬁcant difference between them. Finally, the same

process is carried out for the kappa measure, taking

the algorithm that achieved the best ranking as con-

trol (see Table 3b). Results revealed that there are sta-

tistical differences with regard to CMAR, CORE and

OneR.

Finally, the same analysis related to accuracy

and kappa measures was carried out on Big Data

approaches (see Table 4). In order to analyze

whether exists any statistical difference, several non-

parametric tests are carried out. Focusing on accu-

racy, the Friedman test revealed a X

= 23.12 with

a critical value of 13.277 and a p-value = 0.0001.

Table 4: Average ranking for each algorithm (sorted in de-

scending order) according to the Friedman test when Big

Data datasets are considered.

Algorithm Ranking

DAC 4.350

MRAC 4.150

MRAC+ 2.700

DFAC-FFP 2.150

G3P-AC 1.650

(a) Accuracy measure.

Algorithm Ranking

DAC 4.600

MRAC 4.100

MRAC+ 2.600

DFAC-FFP 1.900

G3P-AC 1.800

(b) Kappa measure.

Table 5: Comparison of our G3P-AC proposal and the other

algorithms for both accuracy and kappa measures. p-values

for Holland test with α = 0.01.

MRAC MRAC+ DAC DFAC-FFP

Accuracy 0.004 0.447 0.001 0.821

Kappa 0.009 0.697 0.001 0.888

Considering the Kappa measure, results for Friedman

was X

= 26.32 with a critical value of 13.277 and

a p-value = 2.72 · 10

−5

. For both measures, with

α = 0.01, it is possible to assert not all the algo-

rithms equally behave. A post-hoc test is therefore

performed to determine the algorithms that present

some differences. According to the results (see Ta-

ble 5 including Holland test with α = 0.01), DAC and

MRAC behave statistically worse than the rest of al-

gorithms. On the contrary, our G3P-AC algorithm,

DFAC-FFP and MRAC+ did not present any statisti-

cal difference in terms of quality.

4.2 Efﬁciency

In this second analysis, it is interesting to analyse the

efﬁciency of the proposal when it is compared to other

AC algorithms. First, we compare our proposal based

on Spark (see Table 6) to classical methods similarly

we did in the previous section for the reliability of

the model. The Friedman test revealed a X

= 175.85

with a critical value of 9 and a p-value = 2.2 · 10

−16

Considering a α = 0.01 it is possible to assert not all

the algorithms equally behave. Focusing on the efﬁ-

ciency and taking our proposal as control, the post-

hoct test (see Table 7) denotes some statistical dif-

ferences with regard to CMAR, CPAR, Ripper and

C4.5, our proposal performing worse. On the con-

trary, the Spark proposal does not obtain any statis-

tical difference with regard to other proposals. At

this point, it is important to remark that the proposal

(based on Spark) was designed to be run on truly big

datasets so the behaviour on small or classical datasets

was expected. It is obvious that those algorithms like

C4.5, Ripper, CPAR, CMAR, etc that were designed

to work on small data should be better in performance

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

100

Table 6: Average ranking for each algorithm (sorted in de-

scending order) according to the Friedman test.

Algorithm Ranking

FARCHD 8.600

CORE 8.050

OneR

8.317

G3P-AC 6.933

CBA 6.100

CBA2 4.967

CMAR 3.800

CPAR 3.467

Ripper 2.900

C4.5 1.867

Table 7: p-values for the Holland test with α = 0.01.

Vs G3P-AC

FARCHD 0.396

CORE 0.799

OneR 0.617

CBA 0.868

CBA2 0.194

CMAR 0.002

CPAR 0.000

Ripper 0.000

C4.5 0.000

than those based on MapReduce that require to dis-

tribute and gather information. As a result, this exper-

imental analysis demonstrate that the use of MapRe-

duce approaches are desiderable only for Big Data

and should be avoid for classical datasets.

Finally, it is essential to demonstrate the perfor-

mance of our proposal when Big Data are analyzed.

In this regard, the proposal is compared to AC al-

gorithms for Big Data (MRAC, MRAC+, DAC and

DFAC-FFP) on a series of datasets of high dimen-

sionality (see Table 1). The experimental results

(see Table 8) considering the Friedman test revealed

a X

= 28.26 with a critical value of 4 and a p-

value = 1.1 ·10

−5

. Considering a α = 0.01 it is possi-

ble to assert not all the algorithms equally behave and

a post-hoct test (see Table 9) is performed taking our

proposal as control. Results denote that our proposal

performs statistically better than DAC and DFAC-FFP

in efﬁciency. With regard to MRAC+ and MRAC, no

statistical difference was found, but our proposal ob-

tained the best ranking. Thus, it is demonstrated the

promising behaviour of our proposal when it is ap-

plied to truly Big Data.

Table 8: Average ranking for each algorithm (sorted in de-

scending order) according to the Friedman test.

Algorithm Ranking

DFAC-FFP 4.500

DAC 4.200

MRAC

2.850

MRAC+ 1.950

G3P-AC 1.500

Table 9: p-values for the Holland test with α = 0.01.

MRAC+ MRAC DAC DFAC-FFP

G3P-AC 0.774 0.251 0.001 0.000

5 CONCLUSIONS

In this work a grammar-guided genetic programming

algorithm for associative classiﬁcation in Big Data,

named G3P-AC, has been proposed. The novelty of

this approach is that it is eminently designed to be as

parallel as possible without affecting the accuracy and

interpretability of the classiﬁer. This proposal, imple-

mented in Apache Spark, obtained really promising

results in terms of the reliability of the resulting pre-

dictive model. In fact, it performs better than many

of existing AC algorithms (classical and Big Data ap-

proaches) as well as classical classiﬁcation algorithms

(not based on associative classiﬁcation). According

to the efﬁciency, it has been demonstrated that the

proposal should be avoid when small datasets are re-

quired to be analysed but it performs really well on

Big Data.

ACKNOWLEDGEMENTS

This research was supported by the Spanish Min-

istry of Economy and Competitiveness and the Euro-

pean Regional Development Fund, projects TIN2017-

83445-P

REFERENCES

Agrawal, R., Imieli

nski, T., and Swami, A. (1993). Min-

ing association rules between sets of items in large

databases. SIGMOD Rec., 22(2):207–216.

Alcal

a-Fdez, J., Alcal

a, R., and Herrera, F. (2011). A fuzzy

association rule-based classiﬁcation model for high-

dimensional problems with genetic rule selection and

lateral tuning. IEEE Transactions on Fuzzy Systems,

19(5):857–872.

Associative Classiﬁcation in Big Data through a G3P Approach

101

Bechini, A., Marcelloni, F., and Segatori, A. (2016). A

mapreduce solution for associative classiﬁcation of

big data. Information Sciences, 332:33–55.

Ben-David, A. (2008). Comparison of classiﬁcation accu-

racy using cohen’s weighted kappa. Expert Systems

with Applications, 34(2):825 – 832.

Chen, H., Chiang, R., and Storey, V. (2012). Business

intelligence and analytics: From big data to big im-

pact. MIS Quarterly: Management Information Sys-

tems, 36(4):1165–1188.

Cohen, W. (1995). Fast effective rule induction. In Ma-

chine Learning: Proceedings of the Twelfth Interna-

tional Conference, pages 1–10.

Cortes, C. and Vapnik, V. (1995). Support vector networks.

Machine Learning, 20:273–297.

Dean, J. and Ghemawat, S. (2008). MapReduce: Simpliﬁed

Data Processing on Large Clusters. Communications

of the ACM - 50th anniversary issue: 1958 - 2008,

51(1):107–113.

Han, J. and Kamber, M. (2011). Data Mining: Concepts

and Techniques. Morgan Kaufmann.

Herrera, F., Carmona, C. J., Gonz

alez, P., and del Jesus,

M. J. (2011). An overview on subgroup discovery:

foundations and applications. Knowledge and Infor-

mation Systems, 29(3):495–525.

Holte, R. (1993). Very simple classiﬁcation rules per-

form well on most commonly used datasets. Machine

Learning, 11:63–91.

Lam, C. (2010). Hadoop in Action. Manning Publications

Co., Greenwich, CT, USA, 1st edition.

Li, W., Han, J., and Pei, J. (2001). Cmar: Accurate and efﬁ-

cient classiﬁcation based on multiple class-association

rules. In 2001 IEEE International Conference on Data

Mining(ICDM01), pages 369–376.

Liu, B., Hsu, W., and Ma, Y. (1998). Integrating classiﬁca-

tion and association rule mining. In 4th International

Conference on Knowledge Discovery and Data Min-

ing(KDD98), pages 80–86.

Liu, B., Ma, Y., and Wong, C. (2001). Classiﬁcation Using

Association Rules: Weaknesses and Enhancements,

pages 591–601. Kluwer Academic Publishers.

McKay, R. I., Hoai, N. X., Whigham, P. A., Shan, Y., and

O’Neill, M. (2010). Grammar-based genetic program-

ming: a survey. Genetic Programming and Evolvable

Machines, 11:365–396.

Padillo, F., Luna, J. M., and Ventura, S. (2017). Exhaustive

search algorithms to mine subgroups on big data us-

ing apache spark. Progress in Artiﬁcial Intelligence,

6(2):145–158.

Quinlan, R. (1993). C4.5: Programs for Machine Learning.

Morgan Kaufmann Publishers, San Mateo, CA.

Segatori, A., Bechini, A., Ducange, P., and Marcelloni,

F. (2018). A distributed fuzzy associative classi-

ﬁer for big data. IEEE Transactions on Cybernetics,

48(9):2656–2669.

Tan, K., Yu, Q., and Ang, J. (2006). A coevolutionary algo-

rithm for rules discovery in data mining. International

Journal of Systems Science, 37(12):835–864.

Thabtah, F. A. (2007). A review of associative classiﬁcation

mining. Knowledge Engineering Review, 22(1):37–

65.

Triguero, I., Gonz

alez, S., Moyano, J. M., Garc

ıa, S., Al-

cal

a-Fdez, J., Luengo, J., Fern

andez, A., del Jes

us,

M. J., S

anchez, L., and Herrera, F. (2017). Keel 3.0:

an open source software for multi-stage analysis in

data mining. International Journal of Computational

Intelligence Systems, 10(1):1238–1249.

Ventura, S. and Luna, J. M. (2016). Pattern Mining with

Evolutionary Algorithms. Springer International Pub-

lishing.

Ventura, S. and Luna, J. M. (2018). Supervised Descriptive

Pattern Mining. Springer International Publishing.

Venturini, L., Baralis, E., and Garza, P. (2017). Scaling as-

sociative classiﬁcation for very large datasets. Journal

of Big Data, 4(1).

Yin, X. and Han, J. (2003). Cpar: Classiﬁcation based

on predictive association rules. In 3rd SIAM Inter-

national Conference on Data Mining(SDM03), pages

331–335.

Zaharia, M., Chowdhury, M., Franklin, M. J., Shenker, S.,

and Stoica, I. (2010). Spark: Cluster computing with

working sets. In Proceedings of the 2nd USENIX

Conference on Hot Topics in Cloud Computing, Hot-

Cloud’10, Berkeley, CA, USA.

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

102
