A Flexible Framework for Program Evolution and Veriﬁcation

Olaf Owe, Jia-Chun Lin and Elahe Fazeldehkordi

Department of Informatics, University of Oslo, Norway

Keywords:

Program Evolution, Program Reasoning, Software Changes, Active Objects, Re-veriﬁcation, Flexibility.

Abstract:

We propose a ﬂexible framework for modeling of distributed systems, supporting evolution by means of un-

restricted modiﬁcations in such systems, and with support of veriﬁcation and re-veriﬁcation. We focus on the

setting of concurrent and object-oriented programs, and consider a core high-level modeling language sup-

porting active, concurrent objects. We show that our framework can deal with veriﬁcation of software changes

that are not possible to verify in comparable frameworks. We demonstrate the approach by variations over a

simple example.

1 INTRODUCTION

Program development is in general a complicated pro-

cess where many kinds of mistakes can be made, in-

cluding bad design decisions, unclear speciﬁcations,

misunderstandings, and erroneous code or speciﬁca-

tions. Problems made early may not be discovered

until much later. Redesigning or modifying code

made at an early stage in the software development

may affect many parts of the overall system. Making

changes in order to correct problematic decisions may

create new problems that are hard to foresee. These

kinds of problems are severe in the setting of con-

current programs when the interaction of the differ-

ent concurrent components is complicated, and also

in the setting of object-oriented programs, due to in-

heritance, late binding and code reuse.

We consider the setting of distributed, concurrent,

and object-oriented systems, and suggest a frame-

work for modeling, development, and evolution of

such systems – with support of veriﬁcation. Our

framework includes several life cycle aspects such

as (formal) requirement speciﬁcation, design, exe-

cutable modeling, analysis, and maintenance. The

framework allows unrestricted changes in code and

requirements, and includes a theory for reveriﬁcation

of a changed system. We include mechanisms for ef-

ﬁcient, imperative style programming in a distributed

setting, including non-blocking as well as blocking

remote method calls, combined with suspension and

scheduling control of processes inside an object. Our

goal is ﬂexibility, in the sense of support of unre-

stricted software changes and with simplicity of rever-

iﬁcation. We show that we can deal with software

changes that are not possible to verify in comparable

frameworks.

A framework that allows the simplest reveriﬁca-

tion of any given software change, has the best ﬂexi-

bility. Clearly incremental and modular reasoning are

preferable, as well as limiting the number of modules

to be affected by a given change. It is desirable to

avoid reveriﬁcation of the whole system when pos-

sible. Flexibility depends on the choice of program-

ming and speciﬁcation constructs, their semantics, as

well as the reasoning system. In particular ﬂexibility

is affected by the choice of abstraction mechanisms.

For instance, for shared variable concurrency it is hard

to analyze the effect of software changes, even with an

advanced reasoning framework. And synchronization

by signaling is notoriously hard to reason about. In

the setting of behavioral subtyping, a change in a sub-

class may violate superclasses requirements, thereby

limiting ﬂexibility.

Flexibility demands programming languages with

a compositional semantics and compositional reason-

ing frameworks. Compositional reasoning of classes

is supported by several approaches. Our framework

is based on a programming paradigm with composi-

tional semantics, cooperative scheduling to support

object-local synchronization control, using interface

abstraction to reduce dependencies between classes,

and the use of communication histories to enable

compositional speciﬁcation and reasoning.

In the presence of class inheritance, modularity of

each subclass is advantageous, as cross-class depen-

dencies hinder ﬂexibility. The strong dependencies of

behavioral subtyping can be reduced with the notion

of lazy behavioral subtyping (Dovland et al., 2010;

Owe, O., Lin, J. and Fazeldehkordi, E.

A Flexible Framework for Program Evolution and Veriﬁcation.

DOI: 10.5220/0007690301770189

In Proceedings of the 7th International Conference on Model-Driven Engineering and Software Development (MODELSWARD 2019), pages 177-189

ISBN: 978-989-758-358-2

177

Dovland et al., 2011); however, reasoning require-

ments to local calls in a superclass are imposed on

subclasses, which limits ﬂexibility. A framework for

evolution based on this approach is given in (Dovland

et al., 2012).

We observe that changing a class C in the mid-

dle of a class hierarchy may in general affect existing

subclasses as well as superclasses. Clearly code in-

herited from C in subclasses could lead to inconsisten-

cies, since C is changed. And requirements imposed

on C from superclasses may also lead to inconsisten-

cies, something which may in general be remediated

by changes in these superclasses, thereby affecting

other subclasses of these superclasses as well. If a

class is changed, it is undesirable that its superclasses

also need to be modiﬁed, as this can destroy ﬂexibil-

ity. This is the case in approaches where requirements

are pushed from superclasses to subclasses, as in the

case of behavioral subtyping. Therefore the seman-

tics of class inheritance matters, in particular when it

comes to inheritance of requirements.

In order to avoid this inherent ﬂexibility limita-

tion, we build on an approach with separation of the

reuse of code from the reuse of speciﬁcations to al-

low unrestricted reuse of code and speciﬁcations. In

particular we build on the approach of behavioral in-

terface subtyping (Owe, 2015) where each class is

only required to satisfy its own interface speciﬁca-

tions, and any invariant or other local speciﬁcations

given in the class. This means that a method rede-

ﬁned in a subclass is allowed to break the require-

ments of the superclass – which opens up for more

liberal modiﬁcations than work based on lazy behav-

ioral subtyping (Dovland et al., 2010; Dovland et al.,

2011), as no superclass requirements are imposed on a

subclass. This allows full control of the inheritance of

code and of requirements when a subclass is deﬁned

and when it is modiﬁed, which is needed to avoid

inconsistent speciﬁcations due to inheritance. Thus

in our approach we can avoid inconsistencies due to

superclass requirements, simply by controlling which

requirements to inherit.

We allow unrestricted changes of code and spec-

iﬁcations (assuming type correctness). This means

that one may write combinations of code and spec-

iﬁcations that are inconsistent, for instance when a

class does not satisfy the requirements of its inter-

face(s). The framework will detect such inconsisten-

cies so that they may be resolved, by changing code

and/or speciﬁcations. In order to determine the conse-

quences of changes in a (super)class, the framework

needs to keep track of dependencies of local calls.

As mentioned, we show that our framework can

deal with software changes that are not possible to

verify in comparable frameworks. We also show how

to reason within a hierarchy where some classes are

veriﬁed and others not. We demonstrate our frame-

work by examples.

2 LANGUAGE SETTING

We consider the setting of asynchronously commu-

nicating objects, so-called active objects, supporting

blocking and non-blocking remote calls, but not re-

mote ﬁeld access. In this setting, veriﬁcation of a

system of concurrent objects can be done composi-

tionally, verifying each class separately, letting each

class and interface refer to its local history, reﬂecting

the time sequence of communication events such as

method calls and returns. Each class can be veriﬁed in

a sequential manner, and a compositional rule states

that a global invariant referring to the global history

can be obtained by conjunction of the local invari-

ants (on local histories) together with a wellformed-

ness predicate relating the local histories.

For the purpose of this paper, we consider a

core high-level imperative modeling language, given

in Figure 1, inspired by the concurrency model of

Creol (Johnsen and Owe, 2007). The language is exe-

cutable with an interpreter in Rewriting logic/Maude

(Clavel et al., 2008). A program consists of interfaces

and classes. A class may implement a number of

interfaces. Class instances represent concurrent and

active objects. Local data structures are deﬁned by

(build-in or user-deﬁned) data types. An interface can

extend other (super)interfaces and add declarations of

methods and invariants.

A class can inherit from a superclass while remov-

ing/adding/redeﬁning method deﬁnitions, method

speciﬁcations and invariants. And ﬁelds w may be

added (an initial value r may be given, otherwise

the default value of the type is used). For simplic-

ity, we assume read-only access to method and class

parameters, and limit the discussion to single inher-

itance. When an interface extends another (su-

per)interface, all declarations and speciﬁcations are

inherited. When a class inherits another class

(the superclass), all code and speciﬁcations are inher-

ited unless redeﬁned: A pre/post pair (P) is inherited

unless another is stated, an invariant (I) is inherited

unless another is stated, the initialization code (s) is

inherited unless another is stated, and a method body

(B) is inherited unless the method is redeﬁned or re-

moved. Likewise, the implementation clause of the

superclass is inherited unless a new implementation

clause is provided, in which case the superclass im-

plementation clause is not inherited.

MODELSWARD 2019 - 7th International Conference on Model-Driven Engineering and Software Development

178

Pr ::= [In

∗

Cl]

program

In ::= interface F[ extends F

]

∗

} interface declaration

Cl ::= class C [([T cp]

)]

[ implements F

]

class deﬁnition

[ inherits C(e)]

[ removing m

]

inheritance mechanisms

{[T w [:= r]

]

∗

} class body

M ::= T m([T x]

∗

) B P

∗

method deﬁnition

S ::= T m([T x]

∗

) P

∗

method signature

B ::= {[[T x [:= r]

]

;]

[s;]

return r} method body

T ::= F | Any | Void | Bool | String | Int | Nat | ... types

v ::= x | w variables (local or ﬁeld)

e ::= null | this | caller | v | cp | f (e) | (e) pure expressions

r ::= e | new C(e) | e.m(e) | C : m(e) right-hand-side/call/new

s ::= skip | [v :=]

r | s;s basic statements

| await v := e.m(e) | await e releasing statements

| if e then s [ else s]

fi if statement

P ::= [ [ A,A ] ]

[ where A

]

pre-/postconditions

I ::= inv A

[ where A

]

invariant speciﬁcation

Figure 1: Language syntax. Speciﬁcation elements are written in blue. F denotes an interface name, C a class name, m a

method name, cp a formal class parameter, w a ﬁeld, x a method parameter or local variable. We use [ ] as meta parentheses

and superscipts ∗, +, and ?, for repetition, non-empty repetition, and optional parts, respectively. Expressions e are side-

effect free, and e denotes a (possibly empty) expression list. Assertions A are ﬁrst order Boolean expressions and may refer

to the local communication history h . A where clause deﬁnes auxiliary functions used for speciﬁcation purposes. Other

statements, such as while loops, can be added.

An object variable must be typed by an interface, not

by a class. A variable declared of interface F is called

an F variable. Though type checking the language

guarantees that for an F variable, the object referred

to by the variable at run-time implements F. This is

called the interface substitution principle (Owe and

Ryl, 1999; Johnsen and Owe, 2007; Johnsen et al.,

2006). A remote call v := o.m(e) is type correct if the

interface of o supports a method m such that the type

of the actual parameters e is a subtype of the formal

parameters of m and the output type of m is a subtype

of v. For simplicity, we assume type correctness, and

assume that a class does not offer two declarations of

the same method name.

Dot-notation is reserved for late bound method

calls, i.e., for a C object o (an object o of run-time

class C) a remote call o.m(...) binds to the deﬁnition

of method m in C, if any, or the closest superclass

with a deﬁnition of m. This deﬁnition of m is denoted

C :m, and is referred to as m of C. The notation C : m

may also be used in program code, resulting in static

binding. Thus C :m binds to the method m of class C

if deﬁned in C or the closest superclass. We assume

here that the static type checking will replace C :m by

B:m if the call binds to m of B.

We distinguish between public methods, those ex-

ported through an interface of the class, and private

methods, those that are not exported through any in-

terface of the class. Note that interface abstraction

deﬁnes the public-ness, rather than keywords such as

private and public. Thus a public method in a class

may be private in a subclass (and vice versa). Local

calls are possible with the syntax v := this.m(e), for

late bound calls, or v := C : m(e) for static calls. (We

let this have the enclosing class as its type.) Public

methods are required to maintain the class invariant.

Private methods may only be called locally, and may

not be used in non-blocking calls (since they may be

called in states violating the invariant).

Methods may be speciﬁed by pre/post speciﬁca-

tions. This is needed for reasoning about local calls,

for which the invariant may be violated, and is in par-

ticular useful for private methods, and other locally

called methods. Multiple pre/post speciﬁcations of

each method are allowed, and a class may implement

multiple interfaces. A class without an implements

list will implement the empty interface Any, which is

the superinterface of all interfaces.

We allow “negative” inheritance by the syntax

removing m

...., expressing that the listed

methods should not be inherited. By type checking it

must be ensured that public methods are not removed

and that the remaining methods in C (including inher-

ited ones) do not (directly or indirectly) lead to a call

on a removed method. The purpose of a removal is

to make a semantically simpler subclass, where irrel-

evant or problematic code is eliminated. In particular

this can be used to make veriﬁcation easier, and even

avoid veriﬁcation problems for instance when an in-

variant is redeﬁned. (Removal of ﬁelds will mainly be

A Flexible Framework for Program Evolution and Veriﬁcation

179

a typing issue.)

Apart from standard statements, we include both

static and dynamic calls, and we include cooperative

scheduling (with the await mechanism) allowing non-

blocking calls, something which is useful in a dis-

tributed concurrent setting.

2.1 History-based Speciﬁcation

Histories are used to capture the time sequence of

communication events. Global histories capture all

communication events in a distributed system, and lo-

cal histories capture all communication events seen

from a given component. The local history h of a

component o is part of the global history H, and these

are related by the equation h = H/o where H/o de-

notes the projection of the global history H to all com-

munication events involving o as either the sender or

receiver.

The invariant of a class C may refer to ﬁelds, the

local history h, class parameters, and this. An in-

variant must be maintained by each public method of

the class (possibly inherited), and a class must satisfy

each implemented interface (using projection on the

history to reﬂect the subset of methods visible through

the interface). A method speciﬁcation may in addition

refer to the formal parameters (including the caller)

and logical variables (primed variables), and a post-

condition may talk about the result (return). When

seen from another class with a larger alphabet, a C

invariant must hold on the alphabet of C.

The invariant of an interface F may refer to the

local history h and this, but not ﬁelds since these are

not visible at the interface level. When seen from an-

other class or interface with a larger alphabet, the F

invariant must hold on the alphabet of F. The local

history h of a class/interface is the time sequence of

communications events seen by this object. We deﬁne

the events below:

• a method call made by this object, denoted this →

o.m(e)

• a method call received by this object, denoted o 

this.m(e) (for m in the class)

• a method return made by this object, denoted o ←

this.m(e;e) (for m in the class)

• a method return received by this object, denoted

this  o.m(e;e), as well as

• a creation event made by this object, denoted

this → o. new C(e)

where o represents the other part in the communica-

tion. In the last event, F is the declared interface of

the variable receiving the new object, i.e., the inter-

face of v in the statement v := new C(e). In practice,

speciﬁcations using histories will often be concerned

about method completions, i.e., ← and  events,

since these capture input/output relations. For a given

method call, the ← event precedes the  event, which

is formalized by a wellformedness predicate.

Sequence Notation: A sequence is either empty or

of the form q;x where q is a sequence and x an ele-

ment. The notation q/s denotes the projection of q re-

stricted to elements in the set s, q ≤ q

denotes that q is

a preﬁx (head subsequence) of q

, x before x

in q

denotes that x appears before any occurrence of x

q, i.e., length(q

/x) ≤ length(q

) for any preﬁx q

of q. For a global history H, there must be a meaning-

ful ordering of the events:

(o → o

.m(e)) before (o  o

.m(e)) in H

(o  o

.m(e)) before (o ← o

.m(e;e)) in H

(o ← o

.m(e;e)) before (o  o

.m(e;e)) in H

→o. new C(e)) before (o →o

.m(e

)) in H

→o. new C(e)) before (o

→o.m(e

)) in H

expressing that messages are sent before they are re-

ceived, that method invocation must precede method

return, and that a creation event of o must precede

other o events. The conjunction of these properties

(universally quantiﬁed) expresses the wellformedness

predicate, used in the compositional rule for global

reasoning. The rule for object composition essentially

says that the global invariant is the conjunction of the

wellformedness predicate and all object interface in-

variants, each referring to its own alphabet. Since

the alphabets of the objects are by deﬁnition disjoint,

the wellformedness predicate is needed to connect the

different object invariants.

For a local history h, we let h/F denote the pro-

jection to events visible through F, i.e., events of the

form this → o. new C(e), this → o.m(e), and this 

o.m(e;e), as well as events of the form o  this.m(e)

and o ← this.m(e;e) for m offered by F. The same no-

tation applies to classes C, thus  this.m and ← this.m

events are restricted to methods deﬁned or inherited in

the class. An invariant I(h) of an interface F is under-

stood as I(h/F) in a subinterface or class. We there-

fore deﬁne I

(h) as I(h/F), and similarly for classes.

2.2 An Example with Reasoning

Figure 2 shows a minimalistic example deﬁning a

class BANK and a subclass BANKPLUS and related in-

terfaces. Interface Bank states that the balance (as re-

turned by bal) is the sum of amounts deposited (by

add) or withdrawn (by sub) from the bank account,

ignoring unsuccessful add and sub calls. In addition

it states that add calls always succeed. Interface Per-

fectBank extends Bank by stating that also sub calls

MODELSWARD 2019 - 7th International Conference on Model-Driven Engineering and Software Development

180

succeed, while interface BankPlus extends Bank by

stating that balance is always non-negative.

The code illustrates suspension, non-blocking and

blocking calls, static and late bound calls. Interface

and type names are capitalized while class names are

written in upper case letters. The speciﬁcation of

interface Bank illustrates history-based speciﬁcation.

In the inductive deﬁnition of sum, others is used to

match other cases, and underscore (_) is used to match

any expression. The keyword inv identiﬁes invari-

ants and where identiﬁes auxiliary function deﬁni-

tions. In assertions, inv refers to the current in-

variant, while C : inv refers to the invariant of class

C. The auxiliary function sum calculates the balance

from the local history. Note that only method-return

events are used in the speciﬁcation.

The subclass BANKPLUS inherits the pre/post spec-

iﬁcations of bal and add from BANK, but not the ones

for upd and sub, which are redeﬁned and therefore not

inherited. In fact the subclass violates the pre/post

speciﬁcations for upd and sub in BANK. BANKPLUS

does not support the BANK interface PerfectBank.

Therefore the implements clause is redeﬁned and

not inherited. In this example, the subclass does not

obey the requirements imposed by behavioral sub-

typing, nor by lazy behavioral subtyping. The re-

deﬁnition of upd in BANKPLUS does not satisfy the

BANK postcondition of upd, and therefore the veriﬁca-

tion of the redeﬁned upd will not succeed when using

the framework of lazy behavioral subtyping (since the

BANK postcondition of upd is needed for the local upd

calls in the veriﬁcation of BANK and therefore pushed

to subclasses). In our framework, the BANK postcon-

dition of upd is not imposed on the subclass, and

therefore the example can be veriﬁed without prob-

lems.

Figure 3 shows a subclass of BANKPLUS that could

be meaningful in a distributed setting. A transaction

is delayed as long as the balance is insufﬁcient. This

is done by means of an await statement, which sus-

pends the sub activation, but does not block the ob-

ject. Note that sub is inherited but not its speciﬁ-

cation. Class BANK2 implements the additional in-

terface PerfectBank, and it inherits from BANKPLUS

the invariant and all pre/post speciﬁcations, except the

ones for upd and sub, which are violated. Again rea-

soning with behavioral subtyping or lazy behavioral

subtyping breaks down, because the reasoning about

the (late bound) calls to upd in BANK depends on the

postcondition of upd, and therefore it is imposed on

all subclasses in the case of lazy behavioral subtyp-

ing. Our framework allows ﬂexible reuse of code and

speciﬁcations, without veriﬁcation problems, avoid-

ing harmful superclass requirements.

interface Bank {

Bool sub(Nat x)

Bool add(Nat x) [true, return= true]

Int bal() [true, return= sum(h)]

where

sum(empty) = 0,

sum(h;(_←this.add(x;true))) = sum(h)+x,

sum(h;(_←this.sub(x;true))) = sum(h)−x,

sum(h;others) = sum(h) }

interface PerfectBank extends Bank {

Bool sub(Nat x) [true, return= true] }

interface BankPlus extends Bank {

inv sum(h)>=0 }

class BANK implements PerfectBank {

Int bal:=0;

Bool upd(Int x) {bal:=bal+x;

return true} [true, return= true]

[inv, bal=sum(h)+x and return=true]

Bool add(Nat x){return this.upd(x)}

[true, return= true]

Bool sub(Nat x){return this.upd(−x)}

[true, return= true]

Int bal(){return bal} [true, return=bal]

inv bal=sum(h) }

class BANKPLUS implements BankPlus

inherits BANK{

Bool upd(Int x) {Bool ok:=(bal+x>=0);

if ok then ok:=BANK:upd(x) fi;

return ok} [inv, bal>=0 and bal=

sum(h)+if return then x else 0]

[b’=bal, return=(b’+x>= 0)]

Bool sub(Nat x) [b’=bal, return=(b’>= x)]

inv BANK:inv and bal >=0 }

class CLIENT{Seq[String] paid;

Bank acc:= new BANK;

Bool salary(Nat x){return acc.add(x)}

Bool bill(String kid, Nat x, Bank y){

Bool ok:=false;

if kid 6∈ paid then await ok:=acc.sub(x);

if ok then y.add(x); paid:=(paid;kid) fi

fi; return ok}

inv paid=allpaid(h)

where

allpaid(empty) = empty,

allpaid(h;_←this.bill(k,x,y;true))=(allpaid(h);k),

allpaid(h; others)=allpaid(h) }

Figure 2: A simple bank example including a possible

client class, where paid corresponds to successful bill pay-

ments. The call BANK:upd uses static binding.

A Flexible Framework for Program Evolution and Veriﬁcation

181

class BANK2 implements PerfectBank,

BankPlus inherits BANKPLUS {

Bool upd(Int x)

{await bal+x>=0; bal:=bal+x; return true}

[inv, bal=sum(h)+x and bal>=0 and return]

Bool sub(Nat x) [true, return= true] }

Figure 3: A subclass of class BANKPLUS.

Consider next that class BANKPLUS is changed for in-

stance by redeﬁning sub by

Bool sub(Nat x) { return BANK:sub(x+1)}

A fee of 1 unit is incorporated in the withdrawal.

In this case, class BANKPLUS can still be reveriﬁed,

but the subclass BANK2 is indirectly affected by this

change, and it is no longer a PerfectBank (because of

the fee). Thus to avoid this inconsistency, class BANK2

should be modiﬁed (say by removing PerfectBank as

an interface).

If a subclass of BANK redeﬁnes add and sub with-

out using upd, that subclass may remove method upd.

And a subclass of BANK implementing an interface

with add, but not sub, and with the same class in-

variant as class BANKPLUS, may remove method sub

in order to make invariant reasoning simpler.

2.3 Dynamic and Static Binding

Dynamic (late) binding implies that a method call to

m may behave differently depending on the class of

the object executing the method (called the actual

class), even for calls that bind to the same deﬁni-

tion, say the one found in a class C. For C1 and

C2 subclasses of C, it may be that there is a local

call this.n(x) in method m of C, and if n is redeﬁned

in both C1 and C2, an m call will bind n differently

depending on the actual class. For instance in the

Bank example, a call to sub binds to BANK :sub, but

the this.upd call in the body of BANK :sub binds to

BANKPLUS : upd or BANK : upd depending on the

class of the executing object, BANKPLUS or BANK,

respectively.

We let the function bind(C, m) return C if C has a

deﬁnition of m, otherwise the closest superclass of C

with a deﬁnition of m. When C is known, bind(C,m)

can be calculated, even with an open-ended class hier-

archy. For a static call D:m(. . .), the binding is known

statically (given by bind(D, m)), and we assume that

such a call is replaced by bind(D,m) : m(...) during

type checking. This makes the binding explicit. This

means that bind(C,D:m) equals bind(D,m) when C is

a subclass of D. For a late bound local call this.m(...)

appearing in a class C, the binding of m can be calcu-

lated statically for a given actual class of this.

In the approach of veriﬁcation based on behavioral

interface subtyping, we reconsider the call for each

possible actual class of this. Thus for each subclass

of C (deﬁned so far), we reconsider the veriﬁcation of

any inherited or reused methods. For each subclass

, the binding can then be done at veriﬁcation time,

binding this.m to bind(C

,m) and C :m to bind(C,m).

A complication in reasoning about local calls is

that a release point (programmed by an await state-

ment) should maintain the invariant of the actual class

(say D) as opposed to the enclosing class (C). Thus

reasoning about a release point occurring in a method

C : m must consider the invariant of the actual class,

which may be a subclass (D) of C. We therefore index

the derivation symbol (`) with the class of the execut-

ing object (as in `

), which is possible with behav-

ioral interface subtyping since all relevant proof obli-

gations are reconsidered for each subclass. In reason-

ing with behavioral subtyping, this is not needed since

reasoning about method m of C is made (once) for all

actual D. The latter approach makes reasoning sim-

ple (when it succeeds), whereas in our system, based

on behavioral interface subtyping, we may differen-

tiate the different versions of an inherited method in

the different subclasses. This gives more ﬁne-grained

control in the reasoning, which is valuable in the set-

ting of code reuse and program evolution. A pre/post

speciﬁcation of m in C will be based on the invariant

of C, which may be different from that of D. There-

fore a pre/post speciﬁcation of m in C can not in gen-

eral be guaranteed in a subclass D if C : m has local

calls or release points.

For example, consider two late bound m calls with

C1 and C2 as the actual classes. These can be referred

to by C1 : m and C2 : m, respectively. We have that

bind(C1, m) = bind(C2,m) when the closest deﬁni-

tion of m is in a common superclass of C1 and C2. A

call to m with C as the actual class may cause a local

call this.n(y) (directly or indirectly). In the veriﬁca-

tion, this call will then be re-analyzed with C as the

actual class, using the binding bind(C,n), and a static

call D : n(y) will be re-analyzed with C as the actual

class using the binding bind(D,m). The analysis of

these call is the same when bind(C,m) = bind(D,m)

and the method body has no local calls to methods

redeﬁned below D and no release points.

In order to do Hoare-style reasoning, we use a sys-

tem for deriving theorems of the form

[P] s [Q]

where C is the actual class, and the Hoare triple

[P] s [Q] states that if the statement(list) s is executed

in a state satisfying the precondition P the ﬁnal state

MODELSWARD 2019 - 7th International Conference on Model-Driven Engineering and Software Development

182

will satisfy the postcondition Q provided the execu-

tion of s terminates. Figure 4 presents sample proof

rules needed for the example. Note that the axiom

schema for assignment is as for sequential programs

without aliasing. (If we had allowed remote ﬁeld ac-

cess, this would no longer hold.) The notation Q

de-

notes (capture-free) textual substitution replacing all

free occurrences of the variable v by the expression e.

Similarly, Q

v,v

e,e

denotes simultaneous replacement (v

by e and v

by e

). Rules for sequential composition

and if-statements are as usual. Rules for while-loops

and recursive calls are also standard, but are omitted

here for brevity.

For a class C we use `

to prove the pre/post

veriﬁcation conditions for objects of that class. For

code in class C this corresponds to normal class-

based reasoning. For code inherited by C, reason-

ing about release points and local or self calls de-

pends on C, which reﬂects the actual class of this ob-

ject. According to rule self call, the call v := this.m(x)

is equivalent to the local call v := C : m(x) where

C is the class of this object. Rule local call states

that reasoning about v := B : m(e) reduces to reason-

ing about body

B:m

, adding effects on the history, and

where body

B:m

denotes the body of the deﬁnition of

method m in class B. The body of a method deﬁnition

m(x){s; return e} is given by

h := (h;caller  this.m(x));

s;return := e;

h := (h;caller ← this.m(x;return))

incorporating the effects on the local history reﬂecting

method call reception and method return.

Since each class is analyzed separately, we ob-

tain a modular and incremental veriﬁcation system

suitable for an open-ended class hierarchy, not un-

like (Din and Owe, 2014). In the analysis of a class

C we may need to consider superclasses of C, but

not subclasses. We may reuse superclass veriﬁcation

results as follows: For code inherited from a super-

class B, we may derive `

[P] s [Q] from `

[P] s [Q]

when s has no release points and no local calls lead-

ing to calls of methods redeﬁned below B. Other-

wise `

[P] s [Q] can be established by a new anal-

ysis of s and of any locally called methods in s.

In particular `

[P] v := B :m(x) [Q] follows from `

[P] v := B :m(x) [Q] when B : m has no release points

or local calls. In contrast to behavioral subtyping and

lazy behavioral subtyping, no requirements are im-

posed on subclasses.

3 PROOF OBLIGATIONS

For a given program we must ensure that each class

C satisﬁes the stated requirements of C, i.e., that the

implements clauses are satisﬁed (syntactically and

semantically), that the class invariants are maintained

by each method (except private ones), and that the

stated pre/post speciﬁcations are satisﬁed by the cor-

responding methods of the class. In this proof, in-

herited methods must be considered, while superclass

implementation claims, superclass invariants, and su-

perclass pre/post speciﬁcations, are not considered

(unless inherited).

Each class is veriﬁed in this sense (taking inher-

ited superclass code into consideration). Together

with correct typing of object variables, this ensures

that each object variable will satisfy its declared in-

terfaces, and each object of a (run-time) class C will

satisfy the interfaces of C. This ensures that the com-

positional rule for reasoning about concurrent object

systems is sound. Furthermore, each late bound local

call made at run-time with C as the run-time class of

the caller/callee will satisfy the pre/post speciﬁcation

given in C. since class C is (statically) veriﬁed. This

is reﬂected in the composition rule which considers

all veriﬁed callee classes.

We formalize the proof obligations expressing the

correctness of a program, class, interface claim, class

invariant, and method speciﬁcation. We consider the

following proof obligations, where each obligation

identiﬁes the relevant class C:

Program and Class Correctness

A program P is correct, denoted ` P ok , if each class

in the program is correct.

A class C is correct, denoted ` C ok , iff

` C sat F for each interface F speciﬁed in

the implements clause of C,

` C inv I for each stated (or explicitly in-

herited) invariant I of C,

m(x) sat [P,Q] for each method m(x) de-

ﬁned (or inherited) in C, and each speciﬁca-

tion [P,Q] stated (or inherited) in C for m,

where `

m(x) sat [P,Q] is veriﬁed by proving

[P] body

bind(C,m):m

[Q]

(as above), and ` C inv I is veriﬁed by proving

m(x) sat [I, I]

for each public method m(x) (possibly inherited) in

C and that the invariant holds initially, i.e., I holds

when h is replaced by the empty history and ﬁelds

by initial values; and ﬁnally, ` C sat F is veriﬁed by

A Flexible Framework for Program Evolution and Veriﬁcation

183

assign `

] v := e [Q]

history `

= h] s [h

≤ h]

await guard `

∧ L] await b [b ∧ I

∧ L]

new `

[∀v

.fresh(v

,h) ⇒ Q

v,h

,h;(this→v

. new C(e))

] v := new C(e) [Q]

simple call `

h;(this→o.m(e))

] o.m(e)[Q]

blocking call `

[∀v

.o 6= this ∧ Q

v,h

,h;(this→o.m(e));(thiso.m(e;v

))

] v := o.m(e) [Q]

non-blocking call

[P] await true [∀v

v,h

,h;(thiso.m(e;v

))

]

h;(this→o.m(e))

] await v := o.m(e) [Q]

self call

[P] v := bind(C, m) : m(e) [Q]

[P] v := this.m(e) [Q]

implicit self call

[P] v := bind(C, m) : m(e) [Q]

[o = this ∧ P] v := o.m(e) [Q]

local call

[P] body

B:m

h;(thisthis.m(e;v))

]

x,caller,h

e,this,h;(this→this.m(e))

∧ L] v := B : m(e)[Q

x,caller,return

e,this,v

∧ L]

sequence

[P] s [Q] `

[Q] s

[R]

[P] s;s

[R]

if-then-else

[P ∧ b] s [Q] `

[P ∧ ¬b] s

[Q]

[P] if b then s else s

fi [Q]

Figure 4: Hoare style rules and axioms. Primed variables represent fresh logical variables, fresh(v

,h) expresses that v

does not occur in h, and L denotes a local assertion, i.e., without occurrences of ﬁelds. In rules self call and static local call,

we assume that v does not occur in e. In rule local call we assume that x is the formal parameter list (which is read only).

Note that bind(C,m) is calculated at veriﬁcation time.

proving that the conjunction of the invariants I

(h) of

C implies the invariant of F, I

(considering methods

visible through F, as explained in Section 2.1):

∧

(h) ⇒ I

(h/F)

Type checking ensures that all methods of F are of-

fered in C, with a signature better or equal to that of F

(i.e., contravariant parameter types and covariant re-

turn types). And type checking ensures that removed

methods are not directly or indirectly called by meth-

ods (possibly inherited) in C, and that private methods

of C are not directly or indirectly called with await .

For a subclass C

of C, `

m(x) sat [P,Q] need

not imply `

m(x) sat [P,Q] even if m is not rede-

ﬁned, since the binding of local calls appearing in

the body of m in C may bind differently in the con-

text of C

(i.e., bind(C, n) versus bind(C

,n), respec-

tively). In general `

m(x) sat [P,Q] depends on re-

deﬁnition of m or locally called methods and possi-

ble C invariants in case of suspension (by await

statements). A redeﬁnition in C

of a locally called

method may violate the supertype speciﬁcation of that

method. A suspension point performed on a C

object

can only guarantee that the C

invariant is maintained,

which could be weaker than the C invariant. We there-

fore track these dependencies, and we may conclude

that `

m(x) sat [P,Q] implies `

m(x) sat [P,Q] if

m(x) sat [P,Q] does not depend on any redeﬁned

code and that any invariant used in the veriﬁcation is

respected by C

For a method m(x) inherited in C from a super-

class B, we may write

B:m(x) sat [P,Q]

rather than `

m(x) sat [P,Q] to visualize that

the method comes from the superclass B. Since

MODELSWARD 2019 - 7th International Conference on Model-Driven Engineering and Software Development

184

bind(C, B : m) equals bind(B, m), this is consis-

tent with the deﬁnition of `

m(x) sat [P,Q]. For

a method C : m without local calls or suspension

points, we have that `

C :m(x) sat [P,Q] reduces

to `

m(x) sat [P,Q]. This gives a practical way of

reusing proofs from superclasses.

4 SOFTWARE CHANGES

We now consider changing a system, i.e., changing

existing classes and adding new classes and inter-

faces. For instance, one may introduce a new inter-

face to make two independent subsystems interact,

adding support of the new interface in one or more

existing classes. An existing class D may be changed

by replacing methods, changing inheritance clauses,

implementation clauses, and/or speciﬁcations. This

can be understood by replacing the whole class deﬁ-

nition by another deﬁnition. The updated class D may

in general have a number of subclasses (at the time

when D is updated) and these are implicitly modiﬁed

if they inherit/reuse code from D. Thus, we need to

reverify the redeﬁned D, but in addition we need to

consider the affected subclasses of D.

We use the following syntax for deﬁning class up-

dates: update Cl, where the meta-symbol Cl de-

ﬁnes the syntax for class deﬁnitions, as in Figure 1.

Thus, a class update

update class D [([T cp]

)]

[ implements F

]

[ inherits C(e)]

[ removing m

]

{[T w [:= r]

]

∗

}

modiﬁes an existing class D by adding class parame-

ters cp

(if present), changing the interface support

to F

(if present), adding superclasses [C(e)]

(if

present), removing methods m

(if present), adding

ﬁelds w

(if present), adding initialization code s

(if present), adding/redeﬁning method deﬁnitions M

∗

(if present), changing method speciﬁcations S

∗

(if

present), and changing the invariant to I

∗

(if present).

For any optional item omitted, there is no change from

the original class. This is somewhat similar to the se-

mantics of inheritance, except that the modiﬁcations

are made on an existing class rather than a new sub-

class.

We consider correctness of the updated code, and

avoid complications such as run-time upgrades where

new and old versions of the updated code are part of

the running system. As before we assume type cor-

rectness. Consider that the redeﬁned D (let us refer

to it as

D) implements some interfaces, which may or

may not be the same as for D. If

D includes all in-

terfaces of D, all type correct calls to D objects will

be type correct and supported by

D objects as well;

and if the interface speciﬁcations are the same, global

reasoning from interface speciﬁcations of D objects is

not violated by replacing D objects by

D objects.

Consider next the case that a class is modiﬁed by

removing the support for an interface. In this case the

statement v := new D, becomes illegal when class D

is modiﬁed so that it no longer supports the interface

type of variable v. We may then change the statement

to v:= new B where B supports the interface. In gen-

eral we may need a sequence of changes in order to

obtain a desired resulting program, including changes

to C and other classes using D. (Subclasses that in-

herit the interface clause of D may then explicitly add

support for the interface, when desirable.)

The veriﬁcation obligations caused by the redeﬁ-

nition consist of verifying `

D ok and reveriﬁcation

of the subclasses of D since they may be affected by

the change. We ﬁrst mark the obligation ` D ok ,

as well as all sub-obligations, as pending. And for

each subclass D

we mark the obligation ` D

ok , as

well as all sub-obligations, as pending. Veriﬁcation of

D ok is then done as deﬁned above for the class re-

sulting from the update, and the subclasses of D must

be reveriﬁed. If an obligation depends on a pend-

ing sub-obligation, one should consider the latter ﬁrst.

Since subclasses may depend on classes deﬁned ear-

lier (as substantiated by Theorem 1 below), we recon-

sider the subclasses in the order deﬁned. For a sub-

class D

, the obligation ` D

ok should be marked as

pending if the proof made use of a result from D, say

m(v) sat [P,Q]. For each such D result, it sufﬁces

to prove `

m(v) sat [P,Q]. If all sub-obligations of

` D

ok can be reveriﬁed in this manner, the obliga-

tion ` D

ok is marked correct.

The state of a proof obligation indicates whether

it has been proved or not. We consider the states: cor-

rect, incorrect, pending. These express respectively

that the obligation is veriﬁed, that the (old) proof is no

longer valid, that veriﬁcation remains to be done. As

explained above, if a pending obligation can be veri-

ﬁed or be reduced to a correct obligation, its state can

be reset to correct. If a pending obligation cannot be

veriﬁed, its state can be set to incorrect. In some cases

it may be possible to reverify the obligation using ad-

ditional speciﬁcations of inherited or called methods,

but in general this may require human insight. Other-

wise further modiﬁcations are needed.

An advantage of our approach is that violations

caused by superclass modiﬁcations can be handled,

called modiﬁcation independence:

A Flexible Framework for Program Evolution and Veriﬁcation

185

Theorem 1 (Modiﬁcation Independence).

Assume that a class C is affected by a superclass mod-

iﬁcation such that some inherited superclass speciﬁ-

cations are violated in C. Then C can be modiﬁed

such that there is no violation.

Proof. Let [P,Q] be a violated m-speciﬁcation. If this

speciﬁcation is inherited, we simply change C by not

inheriting it and then the speciﬁcation is no longer re-

quired in C. And if [P,Q] is stated in C, we remove

the speciﬁcation. In case [I,I] is then removed for an

invariant I, we also remove the invariant from C, and

remove any interface of C depending on the invariant.

We may repeat this process until all violations are re-

moved.

This means that any undesired requirements due to

modiﬁcations in a superclass can be removed. Af-

ter removal one may add desired requirements and

then verify these requirements (modifying the class if

needed). In this way one may reverify that the stated

interfaces are satisﬁed. This gives full ﬂexibility of

properties while doing modiﬁcations, at the cost of

reconsidering subclasses in case the modiﬁcations re-

quire changes in subclasses.

Our approach may result in some veriﬁed classes

and some classes that are not yet veriﬁed. In this

imperfect setting we may still reason about the over-

all system by using the following formulation of the

global system invariant I(H) over the global history

I(H) , wf(H)

→o. new C(_)∈H

F∈C

(H/o)

this

where C is restricted to range over classes that are

tagged correct, i.e., those satisfying ` C ok . The

last conjunction ranges over all interfaces F imple-

mented by C. Here wf (H) denotes the welldeﬁned-

ness predicate, expressing the before ordering be-

tween events, given in Section 2.1.

This global invariant captures the partial knowl-

edge of the global history H given by the interface

invariants of the objects appearing in the system (pos-

sibly dynamically generated) considering only objects

of correct classes. This global reasoning rule essen-

tially turns off the interface invariants for the non-

correct classes.

Limitations: We assume type correctness. Thus

program changes must result in type correct pro-

grams. Removal of declarations of ﬁelds, methods,

parameters, and variables is only allowed when not in

use. Secondly we do not consider changes in an in-

terface I. This can be simulated by adding the new

version of I as a separate interface, making changes

wherever I (or a subinterface) is used, and then re-

moving the original I when no longer referred to.

Examples of Software Changes on BANK

Assume now that class BANK is changed so that upd

calls check, which returns true.

update class BANK implements PerfectBank{

Bool check(Int x){return true} [true, return]

Bool upd(Int x){Bool ok:=check(x);

if ok then bal:=bal+x fi; return ok}

[inv, bal=sum(h)+x and return=true] }

All other aspects of class BANK are kept unchanged,

including all BANK speciﬁcations. Thus inv refers

to the original invariant of BANK. Since check returns

true, the veriﬁcation of upd can be reused, and the

other veriﬁcation conditions of BANK are as before

and need not be reveriﬁed. And the veriﬁcation of

the added local method check is trivial. Furthermore,

the subclasses are not affected by this change. Thus

the veriﬁcation conditions caused by the class update

are straightforward.

However, if class BANKPLUS is changed by re-

deﬁning check(x) as in

update class BANKPLUS

{ Bool check(Int x){return bal+x>0} }

the local late bound call to upd(−x) in the inherited

method sub results in the value of bal − x > 0 to be

returned from sub. Again veriﬁcation conditions are

straightforward. In contrast this could not be veriﬁed

in the frameworks of (Dovland et al., 2015; Dovland

et al., 2012).

Adding a side effect in check such as if x <

0 then bal := bal − 1 fi would destroy the BANK

invariant, but not the BANKPLUS invariant. Then the

former should be removed.

Consider next the following update of class BANK

with a redeﬁnition of sub:

update class BANK{ Bool sub(Nat x)

{ bal:=bal−x; return true} }

The new version of BANK inherits the old interface

(PerfectBank), the methods add, bal, and upd, the old

invariant, the old speciﬁcation of sub (i.e., postcon-

dition retur n = true). The proof obligations amount

to ﬁrst verifying that the redeﬁned sub maintains the

invariant and satisﬁes the postcondition. This is triv-

ial. Secondly it must be veriﬁed that each subclass

is still ok . As subclass BANKPLUS now may allow

a negative balance, the BANKPLUS invariant bal ≥ 0

cannot be veriﬁed (because it is incorrect). We may

MODELSWARD 2019 - 7th International Conference on Model-Driven Engineering and Software Development

186

still do (limited) global invariant reasoning about a

system containing BANKPLUS objects.

To solve this inconsistency in BANKPLUS, we may

update this class by removing the support of interface

BankPlus and removing the last conjunct of the invari-

ant and the spec. of sub, and then reverify. Alterna-

tively, we may change BANKPLUS by redeﬁning sub

so that the old speciﬁcations can be reveriﬁed.

Finally, the redeﬁnition of sub in Section 2.2 can

be handled by removing interface PerfectBank in class

BANK2 and checking/adjusting any usage of new

BANK2 (as PerfectBank) in other classes.

5 RELATED WORK

In formal methods, the notion of reﬁnement is used to

reﬂect software development. A reﬁnement is in gen-

eral leading from a design with certain properties to a

design which preserves these properties while adding

more detail. In this way reﬁnement is semantics-

preserving (Ward and Bennett, 1995). Certain re-

ﬁnement logics support the addition of error values,

thereby semantics is preserved as long as no errors

appear. Banach et al. have argued for the need of

reﬁnement-like steps that go beyond the limitation

of semantics-preserving development (Banach et al.,

2007). But their approach does not support analysis

of program properties. Hu and Smith (Fu and Smith,

2008; Fu and Smith, 2011) consider veriﬁcation of

evolving Z speciﬁcations. However, they do not look

at changes to classes that may affect global system

properties.

In the setting of object-oriented programs with in-

heritance, behavioral subtyping is the most common

reasoning approach, restricting subclasses to obey the

super-class speciﬁcations (Liskov and Wing, 1994).

This means that subclasses must preserve behavior.

Lazy behavioral subtyping (Dovland et al., 2010;

Dovland et al., 2011) relaxes this condition; only be-

havior that is needed to verify local calls in a super-

class must be respected by a subclass redeﬁning the

method. This gives added ﬂexibility, allowing a larger

class of changes without breaking the requirements.

Interface abstraction allows reasoning about re-

mote calls to rely on the declared interface of the

callee. This means that changes in a (super)class im-

plementation may be done as long as the stated inter-

face support is respected, and as long as subclass rea-

soning is not affected. A calculus allowing changes

to methods, (super)classes and interfaces is presented

in (Dovland et al., 2012), based on lazy behavioral

subtyping. Program properties, represented by Hoare

triples, are classiﬁed in two categories for each class

C, representing the veriﬁed ones and the unresolved

(unveriﬁed) ones, U(C). The set of veriﬁed properties

of a given class C and method m is denoted G(C,m).

When the set of unveriﬁed program properties is veri-

ﬁed (i.e., U(C) is empty) the class is found to be cor-

rect in the sense that all pre/post method speciﬁca-

tions are satisﬁed by the corresponding implementa-

tion in a class as well as those in interfaces supported

by the class. Changes in code or speciﬁcations may

affect both categories. However, a program require-

ment added to U(C) may be impossible to verify (in

case the Hoare triple is not satisﬁed), and it will then

remain in U(C), and there is no guarantee that this

problem is detected.

The approach in (Dovland et al., 2015) addresses

transformation of classes and allow classes in the mid-

dle of a class hierarchy to be changed. Modiﬁcations

are archived by means of update operations modify

and simplify. The modify operations extend class def-

initions, allowing code such as new ﬁelds, method

deﬁnitions, guarantees, and interfaces to be added to

classes, and existing methods to be redeﬁned. The

simplify operation allows redundant methods to be re-

moved from class deﬁnitions. The approach does not

classify classes using G and U such as in (Dovland

et al., 2012), rather, for each update applied to a class,

all veriﬁcation work is done to methods affected by

the update. But, any superclass requirements needed

to handle local calls are imposed on subclasses, as

in (Dovland et al., 2012).

A number of works on asynchronously commu-

nicating concurrent objects consider certain forms of

software and/or speciﬁcation changes: The concept

of dynamic software updates allows changes to (su-

per)classes during run-time (Johnsen et al., 2005). A

challenge with run-time upgrades of distributed sys-

tems is the need to allow updates in a distributed man-

ner, and thereby allowing coexistence of different ver-

sions of the software (Ajmani et al., 2006; Johnsen

et al., 2005; Seifzadeh et al., 2013). In contrast to

these works, we are focusing on the reasoning as-

pects. Bannwart and Müller (Bannwart and Müller,

2006) consider program changes through refactoring,

and show how to preserve external behavior for a class

of non-trivial refactoring. However, they do not in-

clude changes that violate behaviors.

Another line of work considers proof reuse, in-

cluding partial reuse of proofs of earlier veriﬁed prop-

erties. This may require some storage of proof out-

lines or non-trivial veriﬁcation steps. This means that

when a module is corrected, one may try to rerun pre-

vious proofs to alleviate the veriﬁcation burden (Reif

and Stenzel, 1993). The notion of abstract method

calls allows reuse of abstract proof outlines, for a

A Flexible Framework for Program Evolution and Veriﬁcation

187

ﬁxed method body, while their instances may need

further work when other methods or requirements are

changed (Bubel et al., 2016; Hähnle et al., 2013). A

related approach is the use of symbolic predicates to

express requirements to general properties for a given

program without knowing what the concrete proper-

ties are (Din et al., 2018). These approaches sim-

plify the veriﬁcation task of evolving programs. The

amount of proof reuse can be balanced against the

amount of automation. Efﬁciently automated proofs

need not be reused while interactive proofs could ben-

eﬁt from reuse, if possible. Our approach is oriented

towards a language with a high degree of automation

of veriﬁcation conditions, and proof reuse is there-

fore not our focus. A recent work by Ulewicz et

al. (Ulewicz et al., 2016) supports a tight integration

of veriﬁcation of unchanged behavior (regression ver-

iﬁcation) with that of changed behavior (delta veriﬁ-

cation); but unrestricted changes are not supported.

The considered concurrency model is used by a

number of languages supporting active objects, in-

cluding ABS and Encore. The core language used

here is avoiding the use of futures, in order to sim-

plify the basic reasoning rules for method calls, as

discussed in a recent paper (Karami et al., 2019).

6 CONCLUSION

We have shown a ﬂexible framework for reasoning

about program reuse and evolution, considering an

imperative setting of distributed object-oriented com-

ponents. Flexibility with respect to reuse and inher-

itance, beyond the limitations of behavioral subtyp-

ing, requires that all objects are seen through an inter-

face (interface abstraction). Our approach builds on

the principle of behavioral interface subtyping, where

each class must support its declared interfaces, but

need not support interfaces of superclasses. This al-

lows the class hierarchy to be used for code reuse

while the interface hierarchy is used for behavioral

reuse. In contrast to lazy behavioral subtyping, no su-

perclass requirements are imposed on subclasses by

the framework. This gives a more ﬂexible frame-

work for software modiﬁcations than that of (Dov-

land et al., 2015; Dovland et al., 2012) since meth-

ods can be redeﬁned without restrictions caused by

superclasses. This means that we may deal with soft-

ware changes that cannot be veriﬁed with approaches

building on lazy behavioral subtyping. The example

demonstrated this. We are avoiding inconsistencies

that are inherent in frameworks building on behav-

ioral subtyping/lazy behavioral subtyping.

In our framework, modiﬁcations to a class C lead

to reveriﬁcation of that class, and subclasses must be

reconsidered when they inherit modiﬁed parts of C,

but superclasses need not be reveriﬁed. During rever-

iﬁcation, proofs can be reused as much as possible,

and further changes to the class and/or subclasses may

be done as needed.

Our framework considers the setting of active,

concurrent objects, for which Java code can be gen-

erated. We have demonstrated that Hoare-style rea-

soning is quite simple for this setting, in the sense that

reasoning is like sequential reasoning, with sequential

effects on the history added.

Our language supports late bound method calls.

However, for local method calls the language supports

static local calls as well as late bound local calls. The

notion of static local calls is needed in the framework

to reduce veriﬁcation conditions about late bound lo-

cal calls to veriﬁcation conditions about static local

calls. Our framework gives ﬁne-grained control of

reused code, where the handling of local calls, both

late bound and static ones, as well as suspension, is

essential. Static local calls are also useful in program-

ming, avoiding the fragile base class problem since

the binding is ﬁxed for such calls.

We build on results from (Owe, 2016) concerning

class inheritance. In contrast to that work, we con-

sider here program changes and evolution, supporting

modiﬁcation independence (Theorem 1), and give a

reasoning rule for partially reveriﬁed systems. In ad-

dition we provide here more ﬁne-grained control of

reused code, and a simpliﬁed treatment of (static and

late bound) local calls.

Our framework can be generalized to multiple

inheritance, which is supported by behavioral inter-

face subtyping. And the framework may be extended

to reason about dynamic (run-time) class upgrades,

assuming existing objects are upgraded in invariant

states, as in Creol (Johnsen et al., 2005), where new

calls run renewed code and suspended old calls run

old code. The new invariant must imply the old invari-

ant, and it must be veriﬁed that old methods maintain

the new invariant. This ensures that the interleaving

of new code and remaining old code is not harmful.

The requirements to an upgraded class are strength-

ened by these requirements, whereas the requirements

to subclasses are as described above.

REFERENCES

Ajmani, S., Liskov, B., and Shrira, L. (2006). Modular soft-

ware upgrades for distributed systems. In Thomas,

D., editor, ECOOP 2006 – Object-Oriented Program-

ming, pages 452–476. Springer.

MODELSWARD 2019 - 7th International Conference on Model-Driven Engineering and Software Development

188

Banach, R., Poppleton, M., Jeske, C., and Stepney, S.

(2007). Engineering and Theoretical Underpinnings

of Retrenchment. Science of Computer Programming,

67(2-3):301 – 329.

Bannwart, F. and Müller, P. (2006). Changing programs

correctly: Refactoring with speciﬁcations. In Misra,

J., Nipkow, T., and Sekerinski, E., editors, FM 2006:

Formal Methods, 14th International Symposium on

Formal Methods, Hamilton, Canada, August 21-27,

2006, Proceedings, volume 4085 of Lecture Notes in

Computer Science, pages 492–507. Springer.

Bubel, R., Damiani, F., Hähnle, R., Johnsen, E. B., Owe,

O., Schaefer, I., and Yu, I. C. (2016). Proof reposi-

tories for compositional veriﬁcation of evolving soft-

ware systems - managing change when proving soft-

ware correct. Transactions on Foundations for Mas-

tering Change, 1:130–156.

Clavel, M., Durán, F., Eker, S., Lincoln, P., Martí-oliet, N.,

Meseguer, J., and Talcott, C. (2008). Maude manual

(version 2.4).

Din, C. C., Johnsen, E. B., Owe, O., and Yu, I. C. (2018). A

modular reasoning system using uninterpreted predi-

cates for code reuse. Journal of Logical and Algebraic

Methods in Programming, 95:82–102.

Din, C. C. and Owe, O. (2014). A sound and complete rea-

soning system for asynchronous communication with

shared futures. Journal of Logical and Algebraic

Methods in Programming, 83(5-6):360–383.

Dovland, J., Johnsen, E. B., Owe, O., and Steffen, M.

(2010). Lazy behavioral subtyping. Journal of Logic

and Algebraic Programming, 79(7):578–607.

Dovland, J., Johnsen, E. B., Owe, O., and Steffen, M.

(2011). Incremental Reasoning with Lazy Behavioral

Subtyping for Multiple Inheritance. Science of Com-

pututer Programming, 76(10):915–941.

Dovland, J., Johnsen, E. B., Owe, O., and Yu, I. C.

(2015). A Proof System for Adaptable Class Hier-

archies. Journal of Logical and Algebraic Methods in

Programming, 84(1):37 – 53.

Dovland, J., Johnsen, E. B., and Yu, I. C. (2012). Track-

ing behavioral constraints during object-oriented soft-

ware evolution. In Margaria, T. and Steffen, B., ed-

itors, Leveraging Applications of Formal Methods,

Veriﬁcation and Validation. Technologies for Master-

ing Change, volume 7609 of Lecture Notes in Com-

puter Science, pages 253–268. Springer.

Fu, Z. and Smith, G. (2008). Towards more ﬂexible devel-

opment of z speciﬁcations. In 2008 2nd IFIP/IEEE In-

ternational Symposium on Theoretical Aspects of Soft-

ware Engineering, pages 281–288.

Fu, Z. and Smith, G. (2011). Property transformation under

speciﬁcation change. Frontiers of Computer Science

in China, 5(1):1–13.

Hähnle, R., Schaefer, I., and Bubel, R. (2013). Reuse

in Software Veriﬁcation by Abstract Method Calls.

In Bonacina, M. P., editor, Automated Deduction -

CADE-24 - 24th International Conference on Auto-

mated Deduction, Lake Placid, NY, USA, June 9-14,

2013. Proceedings, volume 7898 of Lecture Notes in

Computer Science, pages 300–314. Springer.

Johnsen, E. B. and Owe, O. (2007). An asynchronous com-

munication model for distributed concurrent objects.

Software & Systems Modeling, 6(1):35–58.

Johnsen, E. B., Owe, O., and Simplot-Ryl, I. (2005).

A dynamic class construct for asynchronous concur-

rent objects. In Steffen, M. and Zavattaro, G., ed-

itors, Proc. 7th International Conference on Formal

Methods for Open Object-Based Distributed Systems

(FMOODS’05), volume 3535 of Lecture Notes in

Computer Science, pages 15–30. Springer.

Johnsen, E. B., Owe, O., and Yu, I. C. (2006). Creol: A

type-safe object-oriented model for distributed con-

current systems. Theoretical Computer Science,

365(1–2):23–66.

Karami, F., Owe, O., and Ramezanifarkhani, T. (2019).

An evaluation of interaction paradigms for active ob-

jects. Journal of Logical and Algebraic Methods in

Programming, 103:154 – 183.

Liskov, B. H. and Wing, J. M. (1994). A behavioral no-

tion of subtyping. ACMTransactions on Programming

Languages and Systems, 16(6):1811–1841.

Owe, O. (2015). Veriﬁable programming of object-oriented

and distributed systems. In Petre, L. and Sekerinski,

E., editors, From Action System to Distributed Sys-

tems: The Reﬁnement Approach, pages 61–80. Tay-

lor&Francis.

Owe, O. (2016). Reasoning about inheritance and unre-

stricted reuse in object-oriented concurrent systems.

In Ábrahám, E. and Huisman, M., editors, Integrated

Formal Methods - 12th International Conference, IFM

2016, Reykjavik, Iceland, June 1-5, 2016, Proceed-

ings, volume 9681 of Lecture Notes in Computer Sci-

ence, pages 210–225. Springer.

Owe, O. and Ryl, I. (1999). On combining object orien-

tation, openness and reliability. In Proc. of the Nor-

wegian Informatics Conference (NIK’99), pages 187–

198. Tapir Academic Publisher.

Reif, W. and Stenzel, K. (1993). Reuse of proofs in soft-

ware veriﬁcation. In Shyamasundar, R., editor, Foun-

dations of Software Technology and Theoretical Com-

puter Science, volume 761 of Lecture Notes in Com-

puter Science, pages 284–293. Springer-Verlag.

Seifzadeh, H., Abolhassani, H., and Moshkenani, M. S.

(2013). A survey of dynamic software updating. Jour-

nal of Software: Evolution and Process, 25(5):535–

568.

Ulewicz, S., Ulbrich, M., Weigl, A., Kirsten, M., Wiebe,

F., Beckert, B., and Vogel-Heuser, B. (2016). A

veriﬁcation-supported evolution approach to assist

software application engineers in industrial factory

automation. In 2016 IEEE Internat. Symposium on

Assembly and Manufacturing (ISAM), pages 19–25.

Ward, M. P. and Bennett, K. H. (1995). Formal methods

to aid the evolution of software. International Journal

of Software Engineering and Knowledge Engineering,

05(01):25–47.

A Flexible Framework for Program Evolution and Veriﬁcation

189
