Schema Matching with Frequent Changes on Semi-Structured Input

Files: A Machine Learning Approach on Biological Product Data

Oliver Schmidts

, Bodo Kraft

, Ines Siebigteroth

and Albert Zündorf

FH Aachen, University of Applied Sciences, Germany

University of Kassel, Germany

Keywords:

Schema Matching, Machine Learning, Classiﬁcation, Natural Language Processing, Named Entity Recogni-

tion.

Abstract:

For small to medium sized enterprises matching schemas is still a time consuming manual task. Even ex-

pensive commercial solutions perform poorly, if the context is not suitable for the product. In this paper,

we provide an approach based on concept name learning from known transformations to discover correspon-

dences between two schemas. We solve schema matching as a classiﬁcation task. Additionally, we provide

a named entity recognition approach to analyze, how the classiﬁcation task relates to named entity recogni-

tion. Benchmarking against other machine learning models shows that when choosing a good learning model,

schema matching based on concept name similarity can outperform other approaches and complex algorithms

in terms of precision and F1-measure. Hence, our approach is able to build the foundation for improved

automation of complex data integration applications for small to medium sized enterprises.

1 INTRODUCTION

Operators of webshops usually use extract-transform-

load (ETL) workﬂows as an approach to ﬁll their

backing data warehouse (DW). These workﬂows need

to be capable to handle a heterogeneous set of var-

ious data formats. Hence, one of the most frequent

performed activities in ETL workﬂows are schema

transformations (Vassiliadis et al., 2009). The task of

schema transformation is especially challenging for

small to medium sized enterprises (SMEs), since their

business model relies on their suppliers’ product data,

yet they do not possess enough market power to en-

force a standardized schema.

Data integration needs to be engineered depend-

ing on the data source, which is a time consuming

step. Schema matching is a tedious manual part of

this engineering process, that requires domain experts

depending on the complexity of data. Multiple indus-

trial grade tools (e.g. IBM InfoSphere Data Architect)

or open source tools (e.g. Talend Studio) aim to sim-

plify this process, but often these solutions perform

poorly depending on the context and domain. This

applies in particular to the ﬁeld of biological product

data, where schemas of product data are not standard-

ized concerning language and naming labels.

Driven by a collaboration project with an SME to

automate the data integration process from receiving

data of product suppliers to webshop integration, we

focus on schema transformation of semi-structured

tabular data. Tabular data are characterized by the

separation of header and content, where the content

of each column refers to a single header. All data are

only available as string without further information on

context or relations between different columns.

This paper provides the following contributions:

• We propose a machine learning (ML) approach

to match tabular schemas, which contain minimal

textual metadata. This approach solves schema

matching as classiﬁcation task by learning from

known concept transformations.

• We introduce a named entity recognition (NER)

approach to analyze, how the classiﬁcation task

relates to NER.

• We evaluate the matching performance of differ-

ent ML models in a study on biological product

data.

The remainder of this paper is organized as fol-

lows: In Section 2 we provide background informa-

tion about the application domain and well under-

stood approaches for schema matching. In Section 3

and Section 4 we introduce learning approaches lever-

aging simple text processing and classiﬁcation algo-

208

Schmidts, O., Kraft, B., Siebigteroth, I. and Zündorf, A.

Schema Matching with Frequent Changes on Semi-Structured Input Files: A Machine Learning Approach on Biological Product Data.

DOI: 10.5220/0007723602080215

In Proceedings of the 21st International Conference on Enterprise Information Systems (ICEIS 2019), pages 208-215

ISBN: 978-989-758-372-8

Daily

New

Weekly

Monthly

Mail

FTP

Cloud

...

Inbox System

txt

csv

xlsx

pdf

...

Document

Format

Product Information Inbox

Document Format

Unication to semi-

structured csv

Manual

ETL-System

Concept

Unication

Manual

Extract

Transform

Load

Website

Product Updates

Figure 1: Simpliﬁed process of product data integration from suppliers to webshop.

rithms. Afterwards we evaluate and compare the

learning approaches to state-of-the-art approaches in

Section 5 and Section 6. Section 7 concludes this pa-

per in regards to the research questions.

2 BACKGROUND

Figure 1 illustrates a simpliﬁed process from prod-

uct data delivery to searchable product data. Update

cycles of product data differ in frequency (daily to

monthly) and it is not guaranteed, that a supplier uses

the same schema twice. Thus, an individual data inte-

gration workﬂow might be required every time a sup-

plier sends an update. Additional product suppliers

may require new individual workﬂows. Our collab-

orating SME has to deal with frequent product data

updates (up to 20 per month) for approximately two

million products by roughly 500 suppliers.

Product data may occur in any kind of format from

unstructured language based text to semi-structured

ﬁles (e. g. csv), and therefore require a manual uniﬁ-

cation process (format and schema) before data can be

processed by an ETL pipeline. The conversion of text

based product information to semi-structured ﬁles is a

manual task, which may be supported by approaches

of natural language processing (NLP).

To match the schema of a tabular input ﬁle to a tar-

get schema, a combination of label and content infor-

mation to corresponding concepts of a target schema

may be utilized. Figure 2 shows the possible rela-

tions between input concepts and and target concepts.

We focus on terminological similarity between label

names of input and target concepts in 1:1 or n:1 rela-

tions. This issue deﬁnition is heavily motivated by the

biological product data domain of our SME collabora-

tion: n:1 relations emerge most frequently, while 1:n

or n:m relations emerge rarely.

Multiple grown approaches (Madhavan et al.,

Catalog

Special_Price ($)

List Price

Application tested

Catalog

Special_Price ($)

List Price

Application tested

T1: Input Schema

Supplier_Product_ID

Baseprice

Application_Advice

Application

T2: Target Schema

1:1 n:1 1:n

Relations

Input Concepts C

Target Concepts C

Figure 2: Schema matching of two tabular schemas with

different relations between corresponding concepts using

label names from the application domain.

2001; Do and Rahm, 2002; Melnik et al., 2002) fo-

cus on matching XML schemas. These schemas pro-

vide a tree structure and metadata (e. g. relation be-

tween elements, data types). Cupid (Madhavan et al.,

2001) represents a matching approach, which quan-

tiﬁes similarity by combining structural information

and data type similarities. COMA (Do and Rahm,

2002) combines a set of different matchers, such as

ngrams, synonyms, name paths and data types, on dif-

ferent levels of a schema. Therefore, COMA is able to

match semi-structured schemas as well as structured

schemas. More recent approaches aim for schema

mediation (Saleem et al., 2008) or ontology merg-

ing (Raunich and Rahm, 2011).

Different approaches show, that name similar-

ity can be used to match two concepts (Do and

Rahm, 2002; Madhavan et al., 2005). Although these

approaches do not rely solely on name similarity,

they have proven, that name similarity is an impor-

tant parameter for matching schemas. Madhavan et

Schema Matching with Frequent Changes on Semi-Structured Input Files: A Machine Learning Approach on Biological Product Data

209

feature creation

from set of sim-

ilarity metrics

and target concepts

target

concept

model creation

from concept

transformations

trained

model

concept

transfor-

mation DB

use

feature vector generation model training engine

machine learning

algorithm

model from training

matched

schema

estimation

use in production phase

use

ML production phase

input schema

Figure 3: A ML system for supervised learning consisting

of three parts: feature vector generation, model training and

the system in production phase.

al. (Madhavan et al., 2005) proposed to use a name

learner based on classiﬁcation methods as part of

their approach to avoid spelling errors or incomplete

names. This name learner tries to identify frequent

word roots to quantify similarity between concept

names.

Another option for determining the column label

similarity are token based or character based simi-

larity functions (Wang et al., 2011). Examples for

character based similarity functions are the minimum

number of single character edit operations required

to transform one string into another (Levenshtein-

Similarity) or cosine similarity. A more recent

approach by Zhang et al. (2014) extends classical

schema matching tools by crowdsourcing.

3 LEARNING APPROACH

In order to detect corresponding concepts in two

schemas, we try to estimate the similarity between

each input concept of the input schema C

= {c

..c

}

and each target concept from the set of all target con-

cepts C

= {c

..c

}. We build a ML model by lever-

aging lexical and phonetic similarity between input

and target concepts using known concept transforma-

tion provided as a ground truth, where target concepts

serve as classes to be distinguished.

A ML system for solving the classiﬁcation prob-

lem requires three integral components (c. f. Fig-

ure 3): a feature generation engine, a training en-

gine, learning a matching model using those vectors,

and a classiﬁcation engine, using the derived model

to match input schemas to target concepts.

3.1 Feature Creation

It is important to ﬁnd a feature vector, that covers mul-

tiple aspects of string similarity, to receive good es-

timations from a learning model. We use functions

from the set of similarity functions Sim according to

the following Deﬁnition:

Deﬁnition 1 (Similarity Function).

Sim ={sim|sim : strings × strings → [0..1],

∀a ∈ strings : sim(a, a) = 1,

∀a,b ∈ strings : sim(a, b) = sim(b, a)}

A similarity function takes two strings and deter-

mines the similarity of these, where zero represents

no similarity and one is an exact match. How-

ever, the computed similarities may cause ambigu-

ous mappings. To reduce this issue, we use a set

of similarity functions S

sim

= (s

, . . . , s

), s

∈ Sim

composed of lexical similarity (Cosine-Similarity,

Greedy-Tiling (Wise, 1993), Levenshtein-Similarity,

Longest-Subsequence, Monge-Elkan (Monge and

Elkan, 1997)) and phonetic similarity functions

(Metaphone (Philips, 2000)). Further similarity func-

tions such as structural measures (ngrams) or token

measures, could be added. Applying every function

in S to two strings a and b results in a feature vector

(a,b) = hs

(a,b) ... s

(a,b)i.

3.2 Training Data

As depicted in Figure 3, a database with known con-

cept transformations provides ground truth training

data for each classiﬁcation approach. Training a clas-

siﬁcation model requires speciﬁc samples for every

class to recognize; thus our training data consists of

pairs of concept variations C

= {c

..c

} and the cor-

responding target concept. Given a pair of corre-

sponding concepts (c

) ∈ G, where G is the ground

truth, training data can be generated by evaluating

) and labeling the resulting vector with the

target concept c

3.3 Classiﬁcation Models

To evaluate the effectiveness of different classiﬁcation

models, we distinguish learning models into binary

and multiclass classiﬁcation.

Binary classiﬁcation can only decide between two

classes: either the input concept c

corresponds to the

target concept c

or not. Due to this property, we

need to build an individual model for every target con-

cept and compare their estimates. Given a concept to

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

210

match, we estimate matches by evaluating all mod-

els. Every model returns a conﬁdence for a target con-

cept and a conﬁdence for "other". Discarding results

for "other" leads to a ranking among all trained tar-

get concepts, where the target concept with the high-

est conﬁdence equals the combined prediction of all

models.

We use conservative stochastic kernel logistic re-

gression (CSKLR) (Zhang et al., 2012) as a binary

classiﬁer, which obtains sparse solutions by conser-

vatively rejecting updates, based on a binomial distri-

bution of the error on each update. The model was

trained according to Section 3.2 with the restriction

that a positive example for one class is a negative one

for all other classes. Hence, the label is either the cor-

responding target concept or else "other".

An alternative approach is multiclass classiﬁca-

tion. Instead of building a separate model for each tar-

get concept, we build one model for multiple classes.

To achieve this, we adapt the feature vector creation.

Given C

and an input concept c

, we de-

termine the multiclass feature vector f

) =

h f

), f

), . . . , f

)i. Hence, we

compare an input concept to every possible target

concept. Using this multiclass approach leads to a

high number of features and classes, which restricts

the choice of classiﬁers. For this reason we chose the

extra randomized trees (ERT) classiﬁer (Geurts et al.,

2006), which is an ensemble method, built on top of

Extra Tree. The randomness of trees provides high

variance, yet a low bias.

4 NAMED ENTITY BASED

CLASSIFICATION

Natural language processing (NLP) provides ap-

proaches deriving structured information from natu-

ral language texts. One technique from this ﬁeld, the

named entity recognition (NER), is an approach for

extracting information such as persons, organizations,

locations, and others.

To build a NLP application, which detects named

entities, complex tools are required. Most NLP

tools use a supervised learning approach to derive

named entities from plain text. Therefore, an anno-

tated corpus containing a set of samples with cor-

responding named entities is required as a training

dataset (Schreiber et al., 2018). During the produc-

tion phase, a NER tool uses a derived model to detect

named entities in a natural language text.

Usually, the ﬁrst tool to use in a NLP applica-

tion is text segmentation, where a sentence is splitted

into a sequence of tokens. Tokens are not limited to

words, but also include punctuation marks and special

characters. Based on the token structure, a NER tool

searches for named entities in each sentence.

We now describe a schema matching approach

based on NER and how a corpus with customized

named entities can be derived from the target concept

database (DB) as a result.

4.1 Corpus Preparation

The ﬁrst step when applying NER approaches to a

schema matching task, is building an annotated cor-

pus, which serves as training data. Hence, we need to

convert the concept transformation to a natural lan-

guage document.

Every target concept from the DB represents a

named entity to be detected in a sentence, and thus

a NER approach requires concept variations to repre-

sent sentences and named entities at the same time.

To clarify this procedure, consider the following ex-

ample.

Given the input schema of Figure 2, Spe-

cial_Price ($) and List Price correspond to the same

target concept (Baseprice). Therefore, Baseprice

is a named entity NLP tools shall detect. Spe-

cial_Price ($) and List Price are variations of this

concept. By interpreting Special_Price ($) as a sen-

tence, NLP tools become applicable. Firstly, we apply

text segmentation to split the concept variations into

tokens (e. g. Special, _, Price, (, $ , ) ). Afterwards,

we annotate these tokens with the corresponding tar-

get concept as named entities.

The resulting document, contains a lot of short

sentences, which are segmented into tokens and an-

notated with named entities, which allows us to train

NER tools to match schemas.

4.2 NER Pipeline

The performance of NER tools varies depending on

the application domain. For example, in some do-

mains the NER tool of StanfordNLP

might work bet-

ter than the NER approach of OpenNLP

. To work

around this issue we use NLPf

(Schreiber et al.,

2018), a framework for creating custom NLP models

and pipelines. NLPf allows us to determine the best

performing combination (pipeline) of a range of NLP

tools and thus train a domain speciﬁc model.

We used this framework to derive a best perform-

ing pipeline for schema matching based on our an-

notated corpus through NLPf, considering the ap-

https://nlp.stanford.edu/

https://opennlp.apache.org/

https://gitlab.com/schrieveslaach/NLPf

Schema Matching with Frequent Changes on Semi-Structured Input Files: A Machine Learning Approach on Biological Product Data

211

proaches of OpenNLP and StanfordNLP for text seg-

mentation and NER.

5 EXPERIMENTAL STUDY

We evaluate different machine learning approaches in

an experimental study with real data gathered from

integration jobs of biological product data.

5.1 Model Setup

Naive Bayes, binary CSKLR and multiclass ERT use

the same set of similarity functions (S

sim

), as provided

in Section 3.1, to generate the features. Each learn-

ing algorithm uses the default parameter conﬁgura-

tion as suggested by the original authors. To get an

overview of which approach performs best on the bi-

ological product data, we include further approaches

to the evaluation.

• A pragmatic approach that calculates the average

similarity of S

sim

for each known concept varia-

tion is stored in the concept transformation DB.

The target concept corresponding to an input con-

cept, is estimated by the maximum average sim-

ilarity of all variations. This approach could be

implemented easily by any SME and should be

outperformed by learning approaches.

• COMA (Massmann et al., 2011) is a mature ap-

proach to match schemas and ontologies. How-

ever, it should be mentioned that COMA is not de-

signed to match schemas solely based on concept

names of tables. We used the default trigram con-

ﬁguration, and provided appropriate synonyms

and abbreviations. Since we do not have relational

tables, COMA can not exploit further properties

(e. g. data types).

• We built an annotated corpus according to the pre-

vious section from the same concept transforma-

tion DB as other ML approaches. Every named

entity corresponds to a target concept. We evalu-

ate the derived NER model in this study. We were

particularly interested in seeing differences be-

tween the NER approach and classiﬁcation based

on similarity metrics. We expected the similar-

ity function based ML approach to perform bet-

ter compared to NER, since input data are of low

quality and for some target concepts, training data

are limited.

5.2 Training Setup

Each learning approach (Naive Bayes, CSKLR, ERT)

uses the system depicted in Figure 3. They differ

solely by the algorithm utilized and whether they use

binary or multiclass feature vectors. All approaches

use the same ground truth to train their models. In our

evaluation scenario, training data consists of about

600 concept variations. The training dataset is imbal-

anced, meaning not every target concept has the same

number of variations. The original schema consisted

of over 100 concepts. However, we had to reduce the

schema to 53 concepts due to the lack of sufﬁcient

training data by excluding concepts with less than 15

schema variations.

5.3 Evaluation Scenario

To analyze the performance of all approaches, we

gathered a gold standard of concept mappings from

manually executed integration jobs. During that pro-

cess we excluded duplicates and took care of not mix-

ing any training and test data. To ensure test data and

training data are disjoint, we removed concept varia-

tions from the gold standard, which also occurred in

the training data as well. The resulting gold standard

consists of over 1000 concept mappings from schema

transformations.

Since we aggregated our test data from real jobs,

our test data is imbalanced. We therefore provide pre-

cision and F1-measure to compare the performance

of the approaches in the domain of biological product

data.

6 STUDY RESULTS

Table 1 provides detailed information about average

precision, recall and F1-measure, which have been

achieved on the evaluation scenario by the various ap-

proaches.

Table 1: Average results matching the test set over 53 target

concepts grouped by approach.

Approaches

Scores Bayes CSKLR ERT pragmatic COMA NER

Precision 0.45 0.71 0.69 0.66 0.60 0.45

Recall 0.45 0.49 0.51 0.58 0.53 0.09

F1-measure 0.38 0.53 0.55 0.58 0.49 0.13

Naive Bayes achieved an average precision and

recall of 0.45, while the average F1-measure only

achieved a score of 0.38. Therefore, Naive Bayes

achieves almost the lowest values for each measure.

Despite its poor performance Naive Bayes is reported

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

212

to be a standard name matcher, thus providing lots of

potential for improvement.

Both more advanced classiﬁcation approaches,

CSKLR and ERT, achieve signiﬁcantly higher aver-

age precision in our study. CSKLR reaches the high-

est precision of all approaches (0.71) closely followed

by the ERT approach (0.69), both outperforming the

pragmatic approach. However, results of the prag-

matic approach were better than expected. The per-

formance indicates, that choosing the maximum aver-

age value of multiple similarity functions is an effec-

tive approach for a small to medium sized enterprise

(SME) to start with. The average precision of 0.66

is close to the precision of ERT (0.69), and thus sig-

niﬁcantly higher than the achieved precision of Naive

Bayes. Additionally, the pragmatic approach achieves

the highest recall and F1-measure of all evaluated ap-

proaches. Results show, that choosing a sophisticated

learning model, leads to signiﬁcant higher precision

of concept matchings.

COMA achieves a better precision than the do-

main specialized Naive Bayes approach. However,

precision is lower than in more advanced models and

the pragmatic approach. This result can be explained

by the limitation of using simple similarity matchers

since no further information is available for COMA in

our study. Furthermore, COMA is not as specialized

to the application domain as learning approaches.

An overall noticeable result is, that recall for

CSKLR, ERT and COMA is almost similar (around

0.5). Recall of Naive Bayes is close to 0.5 as well. Re-

call might therefore be limited, due to the low quality

of data.

NER performs worst in every measure. While

reaching the precision of Naive Bayes, recall and F1-

measure are extremely low. We explain this result by

showing more details in the following section.

6.1 Detailed Results

CSKLR achieves satisfying results in terms of pre-

cision. 19 of 53 target classes are matched with

a precision of >0.9. Both, ERT and COMA reach

13/53, closely followed by the pragmatic approach

with 12/53. Naive Bayes only reaches a minimal pre-

cision of 0.9 in 9 of 53 cases. Surprisingly, the NER

approach is able to identify 18 of 53 target concepts

with a precision of 1.0. However, the model derived

by our annotated corpus seems to be extraordinary

sensitive. This is indicated by overall low F1-measure

for any target concept as depicted in Table 3.

Table 2 and Table 3 show more detailed match re-

sults in terms of precision and F1-measure on a repre-

sentative subset of 11 of 53 target labels for all evalu-

ated approaches.

Table 2: Precision details on a representative subset of 11

of 53 target labels.

Precision of Approaches

Target Concepts Bayes CSKLR ERT pragmatic COMA NER

ProductUrlHtml 0.35 0.56 0.78 0.86 0.66 1.00

Epitope 0.50 1.00 1.00 0.66 1.00 0.00

Immunogen 0.35 0.50 0.40 0.40 0.75 1.00

handlingAdvice 0.18 1.00 0.50 0.50 0.67 0.50

productNameOriginal 0.60 0.69 0.63 0.51 0.50 1.00

Gene1 0.72 0.88 0.80 0.69 0.36 0.75

ProductUrlPdf 0.15 0.00 0.80 0.66 0.36 0.75

Isotype 0.91 0.75 0.80 1.00 0.91 0.00

Purity 1.00 1.00 1.00 0.66 0.67 1.00

Description 0.17 0.67 0.38 0.56 0.60 0.40

AssayPrecision 0.17 1.00 1.00 0.50 0.25 0.00

Table 3: F1-measure details on a representative subset of 11

of 53 target labels.

F1-measure of Approaches

Target Concepts Bayes CSKLR ERT pragmatic COMA NER

ProductUrlHtml 0.25 0.14 0.54 0.65 0.56 0.15

Epitope 0.48 0.63 0.20 0.60 0.53 0.00

Immunogen 0.50 0.43 0.27 0.27 0.81 0.18

handlingAdvice 0.29 0.80 0.40 0.57 0.66 0.40

productNameOriginal 0.49 0.51 0.58 0.57 0.42 0.09

Gene1 0.28 0.85 0.51 0.67 0.43 0.11

ProductUrlPdf 0.16 0.00 0.65 0.60 0.20 0.18

Isotype 0.91 0.85 0.76 0.73 0.87 0.00

Purity 0.50 0.80 0.80 0.67 0.67 0.50

Description 0.14 0.17 0.33 0.46 0.29 0.08

AssayPrecision 0.29 0.80 0.67 0.50 0.40 0.00

CSKLR achieves high precision for the major-

ity of target concepts. However, no input concept

could be matched with the target productUrlPdf by

CSKLR. productUrlPdf always seems to be missrec-

ognized as productUrlHtml. CSKLR achieves preci-

sion of 1.0 for four target concepts, but recall ranges

from 0.09 (productUrlHtml, Description) to 1.0 (as-

sayPrecision). This result is probably related to the

use of language. Anything can be interpreted as de-

scription, while assayPrecision is very domain spe-

ciﬁc with a small range of variations. The suboptimal

matching performance for Immunogen is explainable

by looking into the training data. Product suppliers

use similar terms for epitopes and immunogens. This

makes it hard for a learning approach to distinguish

between these terms.

ERT suffers the same recognition issues for epi-

topes and immunogens. However, ERT is able to bet-

ter distinguish between productUrlHtml and produc-

tUrlPdf. Results of ERT for other target concepts are

a little lower than results of CSKLR.

The results of COMA show a perfect precision for

Epitope like CSKLR and ERT. Nevertheless, COMA

clearly outperforms every other approach in differen-

tiating between Immunogen and Epitope.

The approach based on NER provides high preci-

sion, yet low F1-measure. If an input concept can be

matched to a target concept, NER achieves high pre-

cision. The overall precision of 0.45 (c. f. Table 1) re-

sults from the NER approach not beeing able to recog-

Schema Matching with Frequent Changes on Semi-Structured Input Files: A Machine Learning Approach on Biological Product Data

213

nize some concepts as named entities. Interestingly,

NER achieves high precision, where other classiﬁers

do not and vice versa except for Purity. However,

the low F1-measure indicates, that NER is unable to

generalize concepts, and thus only detects the most

obvious matchings. This theory also explains the rel-

atively high precision across the board.

6.2 Additional Experiments

We brieﬂy mention results of smaller, to some extend

manual experiments with feature vector creation and

different approaches.

• We extended the feature vector by trigram simi-

larity. We found that models including trigrams

as features performed signiﬁcantly worse than

models based on other similarity functions. For

all learning approaches, precision, recall and F1-

measure dropped by 0.03-0.05. Learning similar-

ity exclusively from trigram similarity lead to sig-

niﬁcantly worse results. The default conﬁguration

COMA suggests trigram matchers as well. We as-

sume, that our input data from real jobs lack suf-

ﬁcient quality for trigrams to achieve satisfying

results. Preparing concepts, using specialized text

segmentation approaches and further preparation,

could potentially improve the performance. Fur-

ther methods are deﬁnitely required to detect false

labeling by data suppliers.

• CSKLR and ERT aim to match 1:1 or n:1 relations

between input and target labels. Nevertheless,

both approaches indicate 1:n relations through the

score for small n (<=3). 1:n relations are indicated

if the highest two or three scores are close to each

other and >0.3.

• Special characters related to currency like $ or

are repeatably matched to the Baseprice label by

ERT, though it has never been trained with it as

special synonym. Only some concept variations

contain these special characters.

• We did not have enough variation for every tar-

get concept. However, it is possible to see the

result "nothing matches" indicated in the scores

when this condition occurs, if the highest score of

a learning matcher is <0.1.

• Intentional typos can be recognized correctly by

the binary CSKLR matcher. ERT recognizes only

some of them. For example concentratoin is

matched to Application_Advice instead of concen-

tration.

• The NER model seems to be very sensitive to dif-

ferent data formats. A lot of concept variations

for Baseprice contain numbers (e. g. List Price

2018). A concept variation containing a number is

detected correctly as named entity. If the number

is removed, the NER model is not able to further

on match the concept variation to the correspond-

ing target concept. Hence, we need to improve

modeling further.

Overall we conclude, that schema matching based

on concept names can be improved by using sophis-

ticated ML approaches, trained from known label

transformations. The matching results for single tar-

get concepts are depending on the derived learning

model. However, the combination of multiple ap-

proaches in an ensemble method (e. g. majority vote)

may cover weaknesses and emphasize strengths of

single approaches.

7 CONCLUSION

In this paper we presented different ML approaches

to schema matching based on concept names. We

showed, that multiple character based similarity func-

tions can be applied to build a feature vector. Further,

we introduced a NER approach for schema matching

tasks, where target concepts are used as named enti-

ties.

We evaluated and compared all approaches in a

study, to determine the practicability in real world

scenarios in the biology domain. Furthermore, we

compared the results to two non learning approaches,

which includes a pragmatic approach and the mature

schema matching system COMA.

The result shows, that a schema matching system,

based solely on learning concept name similarity, is

able to reach the same range of precision as the ap-

proach of Madhavan et al. (2005), even for data of

low quality. However, precision and F1-measure need

further improvements. Matching performance varies

for single concepts, depending on the learning method

used. Moreover, the results indicate, that classiﬁ-

cation approaches with sophisticated models outper-

form COMA with the standard trigram conﬁguration

as well as the NER approach.

We provide two ideas: Firstly, we combine his-

torical information on concept transformations with

simple similarity metrics to learn from. This simplic-

ity allows customization to special needs of SMEs.

Therefore, they can experiment with learning meth-

ods that are well suited for their domain. Secondly,

we introduce a NER based approach, which is trained

on an annotated corpus of known labels.

Automation of schema matching in an industrial

environment requires a precision of over 0.9. Due

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

214

to this requirement further improvement of match-

ing precision and recall is required as well. Other-

wise, the cost of integration errors and manual cor-

rection prevails any beneﬁt. To achieve further im-

provements, different concept name matching sys-

tems could be combined by using a majority voting.

Since the approaches we provide in this paper

achieve a lower precision than required for full au-

tomation, we built a recommending engine to inte-

grate research prototypes into industrial applications,

according to the MEDIATION approach (Schreiber

et al., 2017; Schmidts et al., 2018), to assist manual

data integration tasks. Additionally, the approaches

are used in a quality assurance system to aug-

ment possible wrong matches in manually matched

schemas.

REFERENCES

Do, H.-H. and Rahm, E. (2002). COMA: A System

for Flexible Combination of Schema Matching Ap-

proaches. In Proceedings of the 28th International

Conference on Very Large Data Bases, VLDB ’02,

pages 610–621, Hong Kong, China. VLDB Endow-

ment.

Geurts, P., Ernst, D., and Wehenkel, L. (2006). Extremely

randomized trees. Machine Learning, 63(1):3–42.

Madhavan, J., Bernstein, P. A., and Rahm, E. (2001).

Generic schema matching with cupid. In vldb, vol-

ume 1, pages 49–58.

Madhavan, J. et al. (2005). Corpus-Based Schema Match-

ing. In 21st International Conference on Data En-

gineering (ICDE’05), pages 57–68, Tokyo, Japan.

IEEE.

Massmann, S. et al. (2011). Evolution of the COMA match

system. In Proceedings of the 6th International Con-

ference on Ontology Matching-Volume 814, pages 49–

60. CEUR-WS. org.

Melnik, S., Garcia-Molina, H., and Rahm, E. (2002). Sim-

ilarity ﬂooding: a versatile graph matching algorithm

and its application to schema matching. In Proceed-

ings 18th International Conference on Data Engineer-

ing, pages 117–128, San Jose, CA, USA. IEEE Com-

put. Soc.

Monge, A. and Elkan, C. (1997). An Efﬁcient Domain-

Independent Algorithm for Detecting Approximately

Duplicate Database Records.

Philips, L. (2000). The Double Metaphone Search Algo-

rithm. C/C++ Users J., 18(6):38–43.

Raunich, S. and Rahm, E. (2011). ATOM: Automatic

target-driven ontology merging. In 2011 IEEE 27th

International Conference on Data Engineering, pages

1276–1279.

Saleem, K., Bellahsene, Z., and Hunt, E. (2008).

PORSCHE: Performance ORiented SCHEma media-

tion. Information Systems, 33(7):637–657.

Schmidts, O. et al. (2018). Continuously Evaluated Re-

search Projects in Collaborative Decoupled Environ-

ments. In Proceedings of the 5th International Work-

shop on Software Engineering Research and Indus-

trial Practice, SER&IP ’18, pages 2–9, New York,

NY, USA. ACM.

Schreiber, M., Kraft, B., and Zündorf, A. (2017). Metrics

Driven Research Collaboration: Focusing on Com-

mon Project Goals Continuously. In 2017 IEEE/ACM

4th International Workshop on Software Engineering

Research and Industrial Practice (SER IP), pages 41–

47.

Schreiber, M., Kraft, B., and Zündorf, A. (2018). NLP Lean

Programming Framework: Developing NLP Applica-

tions More Effectively. In Proceedings of the 2018

Conference of the North American Chapter of the As-

sociation for Computational Linguistics: Demonstra-

tions, pages 1–5, New Orleans, Louisiana. Associa-

tion for Computational Linguistics.

Vassiliadis, P., Simitsis, A., and Baikousi, E. (2009). A Tax-

onomy of ETL Activities. In Proceedings of the ACM

Twelfth International Workshop on Data Warehousing

and OLAP, DOLAP ’09, pages 25–32, New York, NY,

USA. ACM.

Wang, J., Li, G., and Fe, J. (2011). Fast-join: An efﬁcient

method for fuzzy token matching based string similar-

ity join. In 2011 IEEE 27th International Conference

on Data Engineering, pages 458–469.

Wise, M. J. (1993). String similarity via greedy string tiling

and running Karp-Rabin matching. Online Preprint,

Dec, 119.

Zhang, C. J. et al. (2014). CrowdMatcher: Crowd-assisted

Schema Matching. In Proceedings of the 2014 ACM

SIGMOD International Conference on Management

of Data, SIGMOD ’14, pages 721–724, New York,

NY, USA. ACM.

Zhang, L. et al. (2012). Efﬁcient Online Learning for Large-

Scale Sparse Kernel Logistic Regression. In AAAI.

Schema Matching with Frequent Changes on Semi-Structured Input Files: A Machine Learning Approach on Biological Product Data

215
