Longitudinal Evaluation of Software Quality Metrics in Open-Source

Applications

Arthur-Jozsef Molnar, Alexandra Neamt¸u and Simona Motogna

Faculty of Mathematics and Computer Science, Babes¸-Bolyai University, Cluj-Napoca, Romania

Keywords:

Software Product Quality, Software Metrics, Metric Correlations, Longitudinal Case Study.

Abstract:

Assessment of software quality remains the focus of important research efforts, with several proposed quality

models and assessment methodologies. ISO 25010 describes software quality in terms of characteristics such

as reliability, security or maintainability. In turn, these characteristics can be evaluated in terms of software

metric values, establishing a relation between software metrics and quality. However, a general metric-based

model for software quality does not yet exist. The diversity of software applications, metric deﬁnitions and

differences between proposed quality models all contribute to this. Our paper proposes a longitudinal evalu-

ation of the metric values and their relations in the context of three complex, open-source applications. We

cover the entire 18 year development history of the targeted applications. We explore typical values for metrics

associated with software product quality and explore their evolution in the context of software development.

We identify dependant metrics and explore the effect class size has on the strength of dependencies. At each

step, we compare the obtained results with relevant related work in order to contribute to a growing pool of

evidence towards our goal - a metric-based evaluation of software quality characteristics.

1 INTRODUCTION

Software development has undergone large changes

in the past decades. Technological advancement, to-

gether with large-scale digitization have lead to in-

creasing customer expectations regarding functional-

ity, ease of use and security. Software applications are

increasingly complex. Methodologies such as Agile

were developed to provide timely response to changes

in requirements, as well as to deliver working soft-

ware faster.

Increased system complexity requires new

methodologies and tools to ensure that software

remains reliable, maintainable and secure. Given

that ”you cannot control that which you cannot

measure” (DeMarco, 1986), it stands that software

measurement plays an important role in assessing

software quality characteristics. The ﬁeld of software

metrics has kept pace with the rapid development of

programming languages and paradigms, with many

proposed metrics that can play a role in assessing

software products.

Standards and methodologies for management

and quality assurance, such as those of the ISO fam-

ily

depend on quantitative data in order to measure

ISO 9126 and the newer ISO 25010 more speciﬁcally

key aspects of software product quality. Software

metrics provide such data, and there exists a large

body of research illustrating the relation between soft-

ware metric values and product quality (Chidamber

and Kemerer, 1994; Marinescu, 2005; Xu et al., 2008;

Kanellopoulos et al., 2010; Molnar and Motogna,

2017).

However, many of the studies that explore the re-

lation between software metrics and product quality

acknowledge that more data is required before general

models can be developed (Barkmann et al., 2009).

This is especially true given research that evaluates

metric data in a new light (Landman et al., 2014),

or that which challenges generally held assumptions

(Emam et al., 2001).

Our paper’s main objective is to provide a sound

foundation that can be leveraged in studying the rela-

tion between software metric values and product qual-

ity attributes. To achieve this, we propose a study that

complements and extends existing research on one

hand, and which ﬁlls identiﬁed gaps in the existing

body of knowledge. Our paper’s contributions can be

summed up as follows:

(i) A quantitative evaluation of metric values for all

released versions of three complex, open-source

software applications.

Molnar, A., Neam¸tu, A. and Motogna, S.

Longitudinal Evaluation of Software Quality Metrics in Open-Source Applications.

DOI: 10.5220/0007725600800091

In Proceedings of the 14th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2019), pages 80-91

ISBN: 978-989-758-375-9

(ii) A long-term exploratory study on the evolution

of metric values associated with software prod-

uct quality. Our study evaluates the entire public

development history of the target applications

over the course of 18 years.

(iii) Identiﬁcation of statistically correlated method

pairs. We evaluate correlation strength in the

context of each application together with study-

ing the confounding effect of class size on de-

pendent metrics.

(iv) An evaluation of our results in the context

of previous research that employed similar

methodology and compatible software tooling.

Most of the related work consists of singular ef-

forts difﬁcult to incorporate in future work due

to unclear study methodology, software tooling

or differences between metrics.

A ﬁrst important difference between the existing

literature and our proposed study lays in the selec-

tion of target applications. The prevalent approach

is to either hand-pick a number of applications for

which several versions are studied (Kanellopoulos

et al., 2010; Silva and Costa, 2015), or to carry out

a cross-sectional study of a large number of applica-

tions (Barkmann et al., 2009; Landman et al., 2014;

Lenhard et al., 2018). Our study includes the initial

application versions, which are rudimentary with re-

gards to functionality and bug-prone. We also study

the most current implementations, that have an ex-

panded feature set and enjoy a large user base. This

allows us to study how the values and relations be-

tween studied metrics evolve during long-term soft-

ware development.

A second important difference regards the selec-

tion of software metrics and extraction tools. We se-

lected metrics that express the most important charac-

teristics of object-oriented software: complexity, in-

heritance, coupling and cohesion (Marinescu, 2005;

ARISA Compendium - Understandability for Reuse,

2018) and that were also employed in previous re-

search targeting software quality (Landman et al.,

2014; Silva and Costa, 2015; Lenhard et al., 2018).

Given that for most metrics there exist several def-

initions (Lincke et al., 2008; Bakar and Boughton,

2012), the choice of metric tool is crucial for ob-

taining comparable results. This is compounded by

the fact that existing papers based on metric val-

ues often omit to specify the software tooling em-

ployed for value extraction. To address this, we’ve

used the VizzMaintenance tool

, which provides clear

deﬁnitions for the metrics. We discuss these in

http://www.arisa.se/vizz analyzer.php

the following section. More so, our approach al-

lows us to directly compare our results with (Bark-

mann et al., 2009), where authors undertake a cross-

sectional study of 146 software projects that are san-

itized in a manner similar with ours and where the

same tooling is used to extract metric information. To

the best of our knowledge, (Barkmann et al., 2009)

is the most relevant paper that we can use to validate

and further explore our ﬁndings.

2 PRELIMINARIES

2.1 Software Metrics

Software metrics are functions used to measure some

property of source code or its speciﬁcation. The

number and type of metrics available closely follows

software development trends. Some of the earliest

deﬁned metrics are some of the most widely used

and measure the number of source code lines, func-

tions, or modules in a system. Paradigms such as

object-orientedness resulted in new metrics, suited

to describe their speciﬁc concepts. In the case of

object-oriented software, these are structural com-

plexity, coupling, cohesion and inheritance (Mari-

nescu, 2005). Perhaps the most well-known suite of

such metrics is the Chidamber & Kemerer (CK) met-

ric suite (Chidamber and Kemerer, 1994).

Values for most established metrics can be ex-

tracted using metric extraction tools. These are avail-

able both as plugins, such as Metrics2

for Eclipse,

MetricsReloaded

for IntelliJ, or standalone tools

such as JHawk

. When doing so, one must take

into account the exact deﬁnition employed by the ex-

traction tool. Considering comment or empty lines

changes the reported number of lines of code. Count-

ing inherited attributes and methods affects the num-

bers reported for a class. The lack of cohesion in

methods (LCOM) metric, ﬁrst deﬁned by CK in (Chi-

damber and Kemerer, 1994), was reﬁned by Li and

Henry (Li and Henry, 1993a), and then by Hitz and

Montazeri (Hitz and Montazeri, 1995). Studies such

as (Lincke et al., 2008; Bakar and Boughton, 2012)

explore these differences as well as their impact when

building metric-based software quality models.

The situation is further confounded by differences

between programming languages. Basili et al. (Basili

et al., 1996) ﬁnd that C++ features such as multiple

inheritance, templates or friends are not covered by

http://metrics.sourceforge.net

https://plugins.jetbrains.com/plugin/93-metricsreloaded

http://www.virtualmachinery.com/jhawkprod.htm

Longitudinal Evaluation of Software Quality Metrics in Open-Source Applications

CK metrics. (Xu et al., 2008) and (Succi et al., 2005)

show that apparent relations between metric values

and software quality are language dependent.

As such, this section details the metric deﬁnitions

that were used in our research. Our selection includes

established size metrics together with some of the

most studied object-oriented metrics, including the

CK suite. All reported values were extracted using

VizzAnalyzer. Formal deﬁnitions for calculated met-

rics are available at (ARISA Compendium - Under-

standability for Reuse, 2018). The tool was previ-

ously used in (Barkmann et al., 2009; Lincke et al.,

2008), making our reported results directly compara-

ble.

• Coupling Between Objects (CBO) - number of

classes coupled to the one being measured. Two

classes are said to be coupled when one of them

uses methods or variables declared in the other

one. CBO is a cohesion metric that is indicative of

the effort needed for maintaining a class, as well

as testing it (Rodriguez and Harrison, 2001).

• Data Abstraction Coupling (DAC) - measures the

coupling complexity by counting the number of

referenced abstract data types. The measurement

excludes classes from the Java platform.

• Depth of Inheritance Tree (DIT) - measures the

maximum length of a path from the class node to

the inheritance hierarchy’s root. This deﬁnition

also covers the possibility of C++ like multiple

inheritance. DIT is a structural metric deﬁned for

object-oriented systems (Rodriguez and Harrison,

2001).

• Lack of Cohesion in Methods (LCOM) - the num-

ber of method pairs which have no cohesion via

common instance variables minus the number of

method pairs which have (Rodriguez and Harri-

son, 2001).

• Improvement to Lack of Cohesion in Methods (IL-

COM) - employs Hitz and Montazeri’s updated

deﬁnition for the LCOM metric (Hitz and Mon-

tazeri, 1995).

• Locality of Data (LD) - ratio between the local

and all the variables accessed by the class. LD is

a coupling metric deﬁned in (Hitz and Montazeri,

1995). Local data includes non-public and inher-

ited attributes, together with attributes accessed

via getters. Existing research (ARISA Com-

pendium - Understandability for Reuse, 2018)

posits a relation exists between LD and potential

for reuse and testability.

• Lines of Code (LOC) - number of lines of code for

the given class. While LOC belongs to the ﬁrst

software metrics, it remains applicable among the

widest varieties of programming languages and

retains utility when investigating the quality of a

software product (Rodriguez and Harrison, 2001).

Furthermore, studying the relation between LOC

and object-oriented metrics provides information

about the relation between system size and struc-

ture. Furthermore, existing research (Emam et al.,

2001) shows LOC to have a confounding effect

that must be controlled when building metric-

based quality models.

• Message Pass Coupling (MPC) - the number of

method calls to methods deﬁned in other classes.

MPC is a coupling metric illustrating the depen-

dency on other system classes.

• Number of Attributes and Methods (NAM) - size

metric that provides the number of static and in-

stance attributes and methods deﬁned by the class.

Does not count constructors, inherited ﬁelds or at-

tributes.

• Number of Children (NOC) - measures the num-

ber of classes that inherit from the given class. To-

gether with DIT, NOC is an inheritance related

metric (Rodriguez and Harrison, 2001; Sarker,

2005).

• Number of Methods (NOM) - measures the num-

ber of methods locally deﬁned by a class. Does

not count inherited methods, or constructors. The

number of locally added attributes for a class can

be computed as NAM − NOM.

• Response For a Class (RFC) - measures the num-

ber of methods that can be invoked in response

to a message of an object of a certain class or of

some method from that class. This metric counts

the number of calls to other classes from a cer-

tain one (Rodriguez and Harrison, 2001). RFC is

a complexity metric.

• Tight Class Cohesion (TCC) - measures the cohe-

sion between the public methods of a class. De-

ﬁned as the ratio between the number of public

method pairs that use the same instance of a class

attribute divided by the total number of public

method pairs of the class (Ott et al., 1970).

• Weighted Method Count (WMC) - measures the

complexity of a class, using the McCabe cyclo-

matic complexity to weight methods. Like RFC,

WMC is a complexity metric which provides an

indication of the effort required to maintain the

class (Rodriguez and Harrison, 2001).

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

2.2 Software Quality Models

One of the ﬁrst models for software quality was the

McCall model developed in 1976. It consisted in 55

quality characteristics, or factors, grouped in 11 main

characteristics. The Boehm model added new fac-

tors to the McCall model and emphasized the main-

tainability aspect. Several others were created, in-

cluding the Dromey and FURPS models (Bassam Al-

Badareen et al., 2011; Al-Qutaish and Ain, 2010).

Further development was taken up by the ISO, which

issued the ISO/IEC 9126 standard in 1991. The ISO

9126 provides a hierarchical model consisting of six

characteristics and 21 subcharacteristics. It draws

from previously developed standards, and is applica-

ble for every kind of software. ISO 9126 was fol-

lowed by the current version of the standard, ISO/IEC

25010:2011, which expands to 8 characteristics and

31 subcharacteristics. As an example, Maintainabil-

ity is one of the 8 characteristics, having subcharac-

teristics Modularity, Reusability, Analysability, Mod-

iﬁability and Testability.

2.3 Related Work

The importance given to software metrics is illus-

trated by the number of works that aim to build a

relation between metric values and software quality.

(Chidamber et al., 1998) explore the relation between

CK metrics and productivity, rework and design ef-

fort for managerial use. In (Li and Henry, 1993b),

authors employ object-oriented and size metrics to in-

vestigate whether metrics can be used as a predictor

of maintenance effort, which they deﬁne as the num-

ber of source code lines added, deleted or modiﬁed

at class level. Their case study consisted of three

years worth of maintenance changes for two Ada sys-

tems. They conﬁrmed the existence of a relation be-

tween metric values and class-level changes in source

code. In (Basili et al., 1996), authors employ the

same metrics to assess them as predictors of fault-

proneness using eight systems developed using C++.

They adapt CK metric deﬁnitions to C++ and empiri-

cally validate that all CK metrics, with the exception

of LCOM to be good fault predictors. In the case

of LCOM, authors theorize that the deﬁnition pro-

vided by CK is not conductive for detecting faults in-

duced by coupling. Another intriguing result is the

inverse relation found between NOC and fault prone-

ness. This is explained knowing that reused classes

are less fault prone, as reported by existing research

(Melo et al., 1995). (Tang et al., 1999) employ three

C++ systems with a known fault history to validate

the use of CK metrics, together with proposing ad-

ditional object-oriented metrics geared towards iden-

tifying fault-prone classes. Among established met-

rics, RFC and WMC are indicated as suited to the

task. CK metrics are again used by (Gyimothy et al.,

2005) as fault predictors within the Mozilla web and

mail open-source suite, using the project’s Bugzilla

repository as ground truth. Authors report that CBO

and LOC reliably indicate fault-prone classes, while

DIT and NOC are untrustworthy. In (Xu et al., 2008),

authors indicate LOC, WMC, CBO and RFC to be re-

liable in defect estimation when applied on a public

NASA data set, of which LOC appeared most reli-

able. However, they consider further research to be

required to identify further relations between metric

values, as well as those with dependent variables.

A number of works link object-oriented metrics

with quality attributes as deﬁned within ISO stan-

dards. (Kanellopoulos et al., 2010) links ISO 9126

software characteristics together with CK and other

object-oriented metrics and undertakes an experimen-

tal evaluation using two open-source Java software

servers. In (Molnar and Motogna, 2017), authors

propose a model based on the values for CBO, DIT,

WMC and ILCOM to describe changes to maintain-

ability as deﬁend by ISO 9126 and validate the pro-

posed model in a longitudinal study of open source

software. (Mohd and Khan, 2012) studies the un-

derstandability characteristic, which is modeled as

a linear combination of coupling, cohesion and in-

heritance, with coefﬁcients and representative met-

rics assigned to each. Interestingly, it is one of

the approaches where metric values are derived from

class diagrams and not directly using the source code.

(Dandashi, 2002) demonstrates a method to assess di-

rect quality attributes using indirect ones. The pa-

per also proposes relations between object-oriented

metrics and quality attributes. (Elish and Alshayeb,

2012) continue the work presented by (Dandashi,

2002) and study the six external quality attributes as

deﬁned by the ISO standard and the correlation be-

tween them and several software metrics. The paper

is focused on undertaking refactoring without affect-

ing software quality, as well as refactoring with the

purpose of improving speciﬁc quality attributes. In

(Gyimothy et al., 2005), authors study the relation be-

tween object-oriented metrics and software reliability

and evaluate it using open source software.

(Barkmann et al., 2009) carry out a large-scale

cross-sectional study of 146 Java applications. The

methodology is described in detail. Projects are

downloaded from open-source software repositories,

imported into an IDE and compiled to ensure the ab-

sence of syntax errors and missing dependencies. In-

formation about 16 metrics linked with product qual-

Longitudinal Evaluation of Software Quality Metrics in Open-Source Applications

ity is extracted using the VizzMaintenance tool. Au-

thors present metric distributions, descriptive statis-

tics and calculate metric dependencies.

While several presented papers study metric val-

ues and correlations, they are geared towards identi-

fying a relation between metric values and software

quality characteristics, such as those deﬁned by the

ISO standards. We believe that further work needs

to be undertaken to ensure the validity of these con-

clusions. This is especially true given the ﬁndings in

(Emam et al., 2001), where authors show that class

size affects metric correlation values. Their experi-

mental study involving a large scale framework shows

that in many cases, strong correlations are the result

of larger class sizes, instead of some other property.

Furthermore, a prevalent issue regards the use

of different deﬁnitions for metrics, tools to extract

them and target applications under study. This makes

follow-up studies difﬁcult to undertake, and compari-

son between studies impossible. As such, our objec-

tives included ensuring that the methodology, tooling

and results we obtained facilitate follow-up examina-

tion. The present paper discusses our methodology,

tooling, as well as our most important ﬁndings. Our

data set, including processed results for all consid-

ered metrics are available on our website

. Further-

more, we ensure that our study methodology and soft-

ware tooling is compatible with that used in (Bark-

mann et al., 2009). As such, we compare and eval-

uate our results with those already presented. This

enables us to employ results of existing research and

draw stronger conclusions.

3 EVALUATION

3.1 Target Applications

Selection of target applications was guided by sev-

eral criteria. First, we wanted our evaluation to be

representative for a large number of existing systems.

Second, given the popularity of large-scale, widely

used open source projects, as well as our require-

ment of having free access to application source code,

we settled on employing several such systems. We

searched for applications that are easy to set up and

which come without complex dependencies. This was

important in the context of existing research (Bark-

mann et al., 2009) that reported that over one third of

downloaded projects required additional work in or-

der to properly compile and run. Last but not least,

http://www.cs.ubbcluj.ro/ se/enase2019

we searched projects with a long development his-

tory, and with a large number of available versions.

This allows us to carry out a longitudinal study, an

observational research method in which metric data

is collected from each available version of the studied

applications, over a signiﬁcant period of time. This is

rather difﬁcult in the context of open-source software,

as many projects with a development time frame of

years undergo development hiatuses.

The applications chosen for our evaluation are the

jEdit

text editor, the FreeMind

mind mapping ap-

plication and the TuxGuitar

tablature editor. All

three are GUI-driven applications developed in Java

and hosted on SourceForge

jEdit is an open-source text editor in development

since 2000. The system already served as target ap-

plication for previous research in application testing

(Arlt et al., 2012; Yuan and Memon, 2010). jEdit has

a large number of users, having over 80k downloads

in 2018, and reaching over 8.9 million downloads in

its 18 years of existence

. jEdit also has plugin sup-

port, but no plugin source code was included in our

study.

FreeMind is a widely used mind-mapping appli-

cation. The application had 775k downloads in 2018

and similar to jEdit, it was also employed for empiri-

cal evaluation in software research (Arlt et al., 2012).

The source code evaluated in our study was down-

loaded from the project website and did not include

plugin code.

TuxGuitar is a multitrack guitar tablature edi-

tor that provides features for importing and exporting

various tablature formats. TuxGuitar is also a popu-

lar application, having over 229k downloads for 2018.

In contrast to jEdit and FreeMind, TuxGuitar source

code is bundled with code for importing and exporting

from various data formats, implemented in the form

of plugins. Since the code was included with the ap-

plication distribution, and it provides core functional-

ity for the system, it was included in our evaluation.

Table 1 provides information regarding the size of the

ﬁrst and last version of the evaluated target systems,

as an indication of their complexity.

All three projects have a full development log on

SourceForge, allowing us to analyze all released ver-

sions. In this paper, we are interested in a long-term

study of the applications. We analyze all their re-

leased versions, leading to 43 versions for jEdit, 38

for FreeMind and 26 for TuxGuitar.

http://jedit.org

http://freemind.sourceforge.net/wiki/index.php/Main Page

http://www.tuxguitar.com.ar

https://sourceforge.net

Download data points taken on December 23

, 2018

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

Table 1: First and last studied version of each target appli-

cation.

Application Version LOC Classes

jEdit

2.3.pre2 33,768 322

5.5.0 151,672 952

FreeMind

0.0.3 3,722 53

1.0.Beta2 63,799 587

TuxGuitar

0.1pre 11,209 122

1.5.2 108,495 1,618

All 107 resulting versions were imported into an

IDE. Each version was manually checked for the in-

clusion of library source code; when found, such code

was separated from application code into library ﬁles

on the application classpath, to ensure that it does

not distort measurement results. As applications were

tested under the Java 8 platform, several compilation

errors had to be addressed in the case of older appli-

cation versions developed under earlier platform ver-

sions. This was done with consideration not to affect

resulting metric values. Each application version was

started, and its functionalities were thoroughly tested

in order to ensure all required code was included.

Raw metric data was exported into spreadsheet format

and is available on our website. Scripts were devel-

oped to extract and aggregate metric and dependency

information. This was done for every application ver-

sion, as well as aggregated over each application as

well as overall.

3.2 Descriptive Statistics

We considered ﬁve data sets within our evaluation.

The ﬁrst one is the (Barkmann et al., 2009) data set,

consisting of a large cross-sectional study of singular

versions from 146 applications. The aggregated data

for each of our three studied applications resulted in

three per-application data sets. Finally, the aggregated

data from all 107 studied application versions resulted

in the overall data set. For the purposes of brevity,

the present section discusses the overall data set, and

references per-application information only where re-

quired.

Figure 1 illustrates metric histograms and the

overall data set, including descriptive statistics from

(Barkmann et al., 2009). The ﬁrst observation is that

metric distribution is similar in both studies, with

none of the metrics having a normal distribution.

With regards to extreme values, minimums are always

0, the lowest possible value, except for the LOC met-

ric, where it is 1. Differences between maximum val-

ues reported by us and (Barkmann et al., 2009) are as

expected much larger and due to outliers. These ob-

servations also hold for the application speciﬁc data

0, 5.61, 285, 3, 1

0, 6.71, 184, 4, 1

0, 4.62, 285, 3, 0

0, 6.04, 175, 4, 1

0, 0.65, 6, 0, 0

0, 1.46, 9, 1, 0

0, 0.97, 45, 1, 0

0, 0.99, 298, 1, 0

0, 147.41, 39813, 1, 0

0, 210.11, 1415498, 2, 0

0, 0.4, 22, 0, 0

0, 0.38, 36, 0, 0

1, 124.37, 7001, 43, 13

1, 166.9, 11045, 62, 13

0, 12.12, 552, 4, 0

0, 11.99, 1225, 3, 0

0, 9.42, 329, 4, 1

0, 11.12, 2297, 5, 1

0, 0.54, 300, 0, 0

0, 0.97, 2843, 0, 0

0, 6.11, 267, 3, 1

0, 7.28, 1190, 3, 1

0, 13.46, 407, 6, 2

0, 13.46, 1195, 6, 0

0, 0.14, 1, 0, 0

0, 0.16, 1, 0, 0

0, 12.85, 763, 5, 1

0, 14.87, 2475, 5, 1

Figure 1: Each histogram: minimum, mean, maximum, me-

dian, modus. Our results on top row, results from (Bark-

mann et al., 2009) on bottom row for comparison.

sets. Furthermore, metrics follow the distribution

shown in Figure 1 in each version of the studied ap-

plications.

Exploring the values for mean, median and modus

Longitudinal Evaluation of Software Quality Metrics in Open-Source Applications

Table 2: Mean metric values per application.

Application CBO DAC DIT ILCOM LCOM LD LOC MPC NAM NOC NOM RFC TCC WMC

FreeMind 5.36 4.21 0.78 0.99 197.61 0.48 108.61 10.92 9.75 0.64 6.87 13.54 0.13 12.50

jEdit 4.66 4.09 0.41 0.77 124.83 0.34 156.43 9.46 8.40 0.37 5.15 10.62 0.15 13.40

TuxGuitar 7.32 6.07 0.87 1.25 130.81 0.40 90.96 17.48 10.67 0.70 6.80 17.78 0.15 12.36

values proves more interesting. First, median and

modus values are very close in all ﬁve data sets, with

those presented in Figure 1 representative of applica-

tion speciﬁc data. Mean values however show more

variability. Table 2 shows mean metric values for each

application data set. Mean values for CBO, NAM,

NOM, TCC and WMC are close across all data sets.

However, the data for ILCOM, MPC and RFC can

be confounding. While overall aggregate results are

similar in our data set and (Barkmann et al., 2009),

they also indicate that application speciﬁc differences

exist.

3.3 Longitudinal Evaluation

In this section we discuss how metric values change

during target application development. Due to space

considerations, we eschew from including all descrip-

tive statistical data points

, which can be found on

our website.

The data points presented in Figure 1 were com-

puted for every metric and application version. Values

follow the distributions already presented for all met-

rics and application versions. Minimum and median

values are close to the overall ones presented in the

table. Maximum values show much greater variabil-

ity, but since these are represented by outliers we do

not detail them.

The rest of this section is dedicated to a discussion

of mean metric values. We believe our following ob-

servations are best accompanied by a description of

the minimum and maximum mean metric values, as

illustrated in Table 3. For each application, data under

the all header includes all application versions, while

data on the right-hand side was calculated taking into

consideration only the given versions. In the case of

FreeMind, these are versions later than, but including

1.0.0Alpha4.

For each application, we examined the changes to

mean values across the versions, and corroborated the

information with manual source code analysis. Each

application version was also run in order to determine

existing functionalities, as well as changes from pre-

vious versions.

The ﬁrst observation is that most signiﬁcant

changes to metric values are linked with the develop-

107 application versions x 14 studied metrics x 5 data

points = 7490 data points.

ment of the earliest application versions, before their

full feature set is implemented. This is most readily

observable for FreeMind and TuxGuitar, as their earli-

est versions (0.0.3 and 0.1pre respectively) are buggy

and lack a number of features prominent in future ver-

sions. For jEdit, the ﬁrst public version is 2.3pre2 and

it appears more feature complete and undergoes less

signiﬁcant changes. This is reﬂected both at applica-

tion functionality as well as metric value level.

The second observation is that for all three appli-

cations, there exist versions where mean metric val-

ues are greatly disrupted. Source code examination

revealed two culprits. The ﬁrst are changes to applica-

tion functionality. For jEdit, version 2.5 adds support

for FTP and virtual ﬁle systems, functionalities imple-

mented using a small number of classes having high

LOC and WMC. Many versions also include signiﬁ-

cant changes for the management of the text-editing

area, such as versions 4.0pre4, 4.3pre8, and 4.3pre16.

Version 5.0 also incorporates important changes, with

updates to most of the source code packages. Many

versions also included or updated complex code for

custom GUI components, such as versions 4.3pre4

and 4.3pre16. This situation is similar in the case

of FreeMind and TuxGuitar. The second culprit is

represented by versions that include important code

refactorings, which in many cases were not accompa-

nied by functional changes. This is the case for jEdit

2.4.2, where 21 classes having high LOC and WMC

values used to parse source code were replaced with a

uniﬁed implementation based on a general parser and

XML descriptors. Similarly, in version 3.0ﬁnal, 153

event handler classes with low LOC and WMC were

replaced with a centralized handler implementation.

We ﬁnd similar changes in FreeMind as well as Tux-

Guitar. We acknowledge that observed modiﬁcations

raise the question of how to measure source code de-

veloped in several languages, not all of which use an

imperative paradigm. However, while an important

topic in itself, it is beyond the scope of our current

work.

Our third observation is that once the application

architecture is stable and its core set of functionalities

is implemented, the variation in metric values is sig-

niﬁcantly reduced. This is also illustrated in Table 3.

For FreeMind and TuxGuitar, we considered the ear-

liest public release of versions 1.0 to be the ﬁrst ma-

ture version. As the ﬁrst public release of jEdit was

version 2.3pre2, we studied the development and fea-

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

Table 3: Extreme values for metric means per all application versions (left-hand side) and mature versions (right-hand side).

FreeMind jEdit TuxGuitar

all after 1.0.0Alpha4 all after 4.0pre4 all after 1.0rc1

Metric Min Max Min Max Min Max Min Max Min Max Min Max

CBO 3.89 6.15 5.33 5.57 3.85 4.91 4.29 4.91 6.03 7.88 7.06 7.88

DAC 2.67 5.30 4.20 4.38 3.45 4.30 3.77 4.30 4.76 6.97 5.16 6.97

DIT 0.15 1.69 0.70 1.03 0.32 0.70 0.32 0.43 0.45 1.07 0.78 1.07

ILCOM 0.81 1.04 0.99 1.04 0.49 0.83 0.79 0.83 1.07 1.46 1.15 1.46

LCOM 84.85 237.90 196.85 237.90 43.44 149.31 126.79 149.31 90.94 176.79 117.15 176.79

LD 0.30 0.52 0.48 0.51 0.23 0.37 0.34 0.37 0.35 0.50 0.35 0.50

LOC 63.35 157.84 100.05 110.79 91.29 177.37 158.64 177.37 73.13 116.69 73.13 115.25

MPC 6.99 13.20 10.59 10.92 6.79 10.05 9.34 10.05 14.26 22.85 14.65 22.85

NAM 7.06 10.09 9.85 10.09 5.18 9.19 8.53 9.19 9.41 12.98 9.41 12.98

NOC 0.15 1.44 0.59 0.63 0.29 0.65 0.29 0.38 0.45 0.92 0.58 0.92

NOM 5.26 7.06 6.88 6.99 3.16 5.49 5.28 5.46 6.13 8.13 6.13 8.13

RFC 9.74 15.17 13.49 13.62 7.91 11.14 10.39 11.14 14.81 22.21 15.80 22.21

TCC 0.03 0.16 0.14 0.16 0.06 0.17 0.14 0.17 0.12 0.22 0.12 0.18

WMC 8.52 14.41 12.32 12.55 8.52 15.05 13.43 15.05 10.63 15.38 10.63 15.38

ture history and settled on version 4.0pre4, released

January 2002 as its ﬁrst mature release. Table 3 illus-

trates that in the case of mature application versions,

the range of variation of mean metric values is nar-

rowed. Furthermore, we observe that trends exist in

the case of every applications. In our opinion, this is

a strong indication that further case studies focused

on longitudinal evaluation need to be undertaken, as

cross-sectional studies tend to coalesce all values and

lose application-speciﬁc context.

Our ﬁnal observation is related to an expectation

that mean metric values increase as applications be-

come more complex. While mitigated by functional

changes and refactorings, we ﬁnd this to be true in

the case of FreeMind and jEdit, especially for the size

metrics LOC, NAM and NOM. For TuxGuitar, the

observation holds until version 1.3.0, where a large

number of small-complexity classes were added to the

system, lowering mean metric values. For example,

mean LOC decreases from 115 in version 1.2.0 to 80

in 1.3.0, while mean NAM decreases from 12.96 to

9.85. This illustrates that ﬁrst of all, statistical data by

itself is of limited value when not complemented by

understanding the application context. Second of all,

it shows that application architecture has important,

measurable effects.

3.4 Dependent Metrics

Our goal is to identify dependent metrics and com-

pare our results with (Barkmann et al., 2009)’s cross-

sectional study. We aim to identify which metric

pairs show consistent correlation across applications

and application versions, as well as identify non-

dependent metrics. Furthermore, as existing research

identiﬁes class size to have a confounding effect on

metric dependency (Emam et al., 2001), we account

for class sizes by partitioning application classes into

quartiles.

As illustrated in Figure 1, none of the studied met-

rics are normally distributed. As such, the Spearman

rank correlation was used to calculate correlation in-

formation. Table 4 presents per application correla-

tion data, with strong correlations highlighted. We

also included data from (Barkmann et al., 2009), as it

is directly comparable.

We observe that our results are in agreement with

those of (Barkmann et al., 2009). Strong correlation

exists between certain metrics expressing coupling

(CBO and DAC), size (LOC, NOM and NAM) and

complexity (MPC, RFC and WMC). Inheritance met-

rics DIT and NOC are not dependent with any other

metrics, including each other. LD and TCC show

much stronger correlation in (Barkmann et al., 2009)

than in our study. Meanwhile, we ﬁnd LCOM to be

correlated with both size (LOC, NAM and NOM) as

well as complexity (MPC, RFC and WMC) metrics.

The LOC metric correlates with both size as well

as complexity metrics. Given the ﬁndings of (Emam

et al., 2001), the next step was to ascertain the ef-

fect of class size on identiﬁed correlations. We par-

titioned class sizes to quartiles and calculated the de-

pendency below the ﬁrst quartile (below Q1), in the

inter-quartile range as well as above the third quartile

(above Q3). The LOC metric was omitted, as it was

already used to partition the data. Table 5 presents the

mean metric correlations obtained. As the domain for

Spearman’s rank correlation is [−1, 1], mean correla-

tions were calculated by summing the absolute values

of correlation. Our observation conﬁrms the results

Longitudinal Evaluation of Software Quality Metrics in Open-Source Applications

Table 4: Correlation between studied metrics in FreeMind (top row), jEdit (second row), TuxGuitar (third row) and as reported

in (Barkmann et al., 2009) (bottom row).

Metric CBO DAC DIT ILCOM LCOM LD LOC MPC NAM NOC NOM RFC TCC WMC

DAC

0.978

0.988 1.000

0.969

0.982

DIT

0.289 0.303

0.182 0.202 1.000

0.186 0.100

0.529 0.528

ILCOM

0.460 0.496 0.086

0.446 0.464 -0.003 1.000

0.075 0.111 -0.296

0.539 0.414 0.391

LCOM

0.530 0.562 0.054 0.559

0.559 0.562 -0.038 0.406 1.000

0.209 0.210 -0.126 0.376

0.539 0.551 0.405 0.478

0.200 0.221 0.076 0.403 0.111

0.184 0.211 0.153 0.561 0.070 1.000

0.031 0.068 -0.206 0.437 0.114

0.315 0.334 0.430 0.794 0.449

LOC

0.587 0.617 0.090 0.562 0.770 0.257

0.773 0.781 -0.001 0.554 0.848 0.215 1.000

0.467 0.460 -0.146 0.345 0.667 0.160

0.581 0.600 0.142 0.477 0.580 0.325

MPC

0.837 0.817 0.229 0.468 0.604 0.173 0.661

0.837 0.828 0.064 0.448 0.759 0.150 0.871 1.000

0.620 0.567 0.035 0.185 0.564 0.042 0.825

0.830 0.813 0.534 0.576 0.597 0.505 0.667

NAM

0.690 0.729 0.111 0.720 0.867 0.329 0.850 0.714

0.711 0.720 -0.010 0.653 0.850 0.292 0.947 0.829 1.000

0.301 0.305 -0.230 0.571 0.783 0.290 0.788 0.597

0.519 0.533 0.165 0.632 0.682 0.468 0.837 0.627

NOC

-0.005 0.021 -0.035 0.106 0.148 0.014 0.062 0.021 0.133

-0.046 -0.031 -0.050 0.028 0.014 -0.005 0.017 -0.028 0.014 1.000

-0.029 -0.036 -0.062 0.024 0.014 0.023 -0.028 -0.026 0.015

0.061 0.087 0.406 0.572 0.380 0.620 -0.110 0.216 0.061

NOM

0.564 0.600 0.104 0.658 0.913 0.231 0.823 0.636 0.954 0.163

0.688 0.693 -0.055 0.590 0.907 0.207 0.947 0.841 0.966 0.032 1.000

0.327 0.334 -0.231 0.559 0.830 0.274 0.836 0.675 0.928 0.032

0.563 0.580 0.238 0.598 0.799 0.480 0.791 0.650 0.911 0.144

RFC

0.746 0.748 0.185 0.625 0.842 0.234 0.804 0.881 0.911 0.114 0.907

0.830 0.824 0.023 0.535 0.823 0.189 0.929 0.961 0.914 -0.004 0.935 1.000

0.539 0.494 -0.028 0.324 0.623 0.123 0.880 0.924 0.733 -0.003 0.821

0.717 0.709 0.277 0.529 0.715 0.019 0.801 0.817 0.837 0.022 0.907

TCC

0.020 0.025 0.021 0.112 -0.042 0.226 0.039 0.040 0.051 -0.022 0.021 0.043

0.058 0.070 0.051 0.252 -0.003 0.430 0.095 0.066 0.126 -0.049 0.087 0.081 1.000

0.081 0.094 -0.054 0.040 -0.053 0.258 0.039 -0.001 0.078 -0.050 0.026 0.011

0.336 0.355 0.543 0.781 0.468 0.803 0.269 0.510 0.411 0.841 0.455 0.367

WMC

0.534 0.559 0.087 0.618 0.861 0.232 0.891 0.693 0.903 0.124 0.932 0.904 0.047

0.708 0.708 -0.049 0.530 0.888 0.160 0.959 0.879 0.933 0.003 0.964 0.939 0.081 1.000

0.388 0.386 -0.173 0.373 0.725 0.160 0.950 0.820 0.792 -0.009 0.883 0.881 0.009

0.599 0.606 0.204 0.570 0.725 0.440 0.844 0.712 0.880 0.054 0.939 0.930 0.405

in (Emam et al., 2001), as class size has an important

effect on correlation strength. This is especially ob-

servable in the case of size and complexity metrics,

and less so for coupling and inheritance metrics.

At this point, we have identiﬁed metric pairs hav-

ing strong dependency, and checked our results with

those obtained by (Barkmann et al., 2009). Given the

longitudinal nature of our data, we were also inter-

ested in checking metric correlation strength across

application versions. In broad terms, our observations

mirror those presented in the previous section. Met-

ric correlations show greater variability in earlier ap-

plication versions, and tend to stabilize once applica-

tions mature. Strongly dependant metric pairs exhibit

this behaviour across all applications and application

versions. In the case of metric pairs having mean cor-

relation over 0.8 for each application, the minimum

correlation in a single application version was above

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

Table 5: Mean metric correlations partitioned by class size

(LOC). Top row represents classes below Q1, middle row

is inter-quartile range, bottom row represents classes above

Q3.

Metric FreeMind jEdit TuxGuitar

CBO

0.25 0.29 0.34

0.30 0.29 0.35

0.44 0.50 0.23

DAC

0.16 0.21 0.29

0.36 0.25 0.30

0.45 0.50 0.21

DIT

0.20 0.15 0.32

0.18 0.13 0.31

0.10 0.09 0.11

ILCOM

0.23 0.16 0.22

0.20 0.23 0.35

0.38 0.35 0.28

LCOM

0.33 0.24 0.29

0.28 0.18 0.33

0.51 0.52 0.39

0.21 0.15 0.14

0.24 0.20 0.21

0.07 0.06 0.13

MPC

0.25 0.26 0.35

0.26 0.26 0.31

0.46 0.54 0.40

NAM

0.39 0.20 0.28

0.41 0.25 0.32

0.56 0.57 0.41

NOC

0.17 0.10 0.11

0.11 0.07 0.10

0.12 0.03 0.10

NOM

0.36 0.27 0.31

0.39 0.30 0.40

0.53 0.57 0.46

RFC

0.35 0.30 0.36

0.44 0.34 0.29

0.56 0.58 0.42

TCC

0.15 0.07 0.16

0.14 0.16 0.11

0.12 0.09 0.10

WMC

0.33 0.26 0.30

0.38 0.27 0.33

0.49 0.56 0.41

0.7. When accounting for the confounding effect of

class size measured as LOC, correlations remained

strong for all identiﬁed metric pairs. This held true

both for classes having LOC below Q1 as well as in

the inter-quartile range. We also studied metric pairs

that appear to be uncorrelated. Our observations are

similar, but in reverse, as these metric pairs do not ex-

hibit strong correlation within any of the studied ap-

plication versions. In this case, class size did not seem

to affect measured correlations.

4 THREATS TO VALIDITY

Our study was carried out in four steps: application

preparation, data extraction, data processing and anal-

ysis. We documented all steps required to replicate

our study. All intermediate and complete ﬁnal re-

sults are available on our website. We ensured that

inﬂuencing factors did not exist beside the analyzed

source code. Exact deﬁnitions were provided for

the employed metrics. Each application version was

compiled and executed, and its functionalities man-

ually checked, to ensure that source code was com-

plete. Given that different extraction tools can yield

different results (Bakar and Boughton, 2012; Awang

Abu Bakar and Boughton, 2008), we double-checked

extracted metric values using the MetricsReloaded

tool.

To limit external threats to validity, we selected

three GUI-based applications developed in the same

programming language. Applications were prepared

and data extraction ﬁnalized before processing, to en-

sure the absence of selection bias. We presented the

most important results both separated by application,

as well as in aggregate form. We compared them with

a relevant large-scale, cross-sectional study of open-

source software that used a well deﬁned methodology.

However, we believe that more research is required

before our conclusions can be generalized to other ap-

plication types, such as libraries or non-GUI applica-

tions. Furthermore, our study remains limited by the

selection of programming language, metric deﬁnition

and application types.

5 CONCLUSIONS AND FUTURE

WORK

We carried out an exploratory evaluation regarding

the values of widely used software metrics, as well

as the relation between these values in the context of

three complex open-source, GUI-driven applications.

We analyzed our results for the entire development

history of the studied applications, and evaluated all

publicly released application versions. We structured

our study to ensure it is repeatable and evaluated our

results in the context of a comparable large-scale eval-

uation. The combined results aggregate metric data

from over 250 application versions

and provide a

sound foundation for further research.

The ﬁrst conclusion is that metric value distribu-

tions were consistent across the studies. Furthermore,

there is some similarity regarding median and mean

values. This is true especially when examining the

mature application versions in our study. We believe

our work can be used as a starting point to determine

metric threshold values indicating good design prac-

(Barkmann et al., 2009) evaluated 146 software

projects

Longitudinal Evaluation of Software Quality Metrics in Open-Source Applications

tices. Given the variation in metric values between

early and current application versions, we believe lon-

gitudinal studies to provide valuable contributions in

this regard.

The second conclusion is that strongly dependent

metric pairs can be identiﬁed. They are the same both

in our longitudinal evaluation as well as the referred

cross-sectional one. Our longitudinal examination has

shown these relations to be extremely stable across

all application versions, including the earliest ones.

These relations proved to be impervious to the effects

of class size. Their existence should be considered

when building software quality models based on met-

ric values. They can be used to select those metrics

that best express a system property, or to avoid intro-

ducing undesired collinearity.

Our third conclusion regards the differences be-

tween the trends in metric values and dependen-

cies between studied applications. Given that cross-

sectional studies are unable to capture this, it strength-

ens the importance of longitudinal studies.

We aim to extend our research to other applica-

tion types, including mobile as well as applications

where user interface code is not dominant. Our goal

is to study whether metric thresholds indicative of

good design and development practices can be estab-

lished. Furthermore, we aim to extend our research

to applications developed using different platforms,

and study the effect of the programming language

on metric values. The main goal is to establish a

metric-based model for software quality. While such

attempts have already been undertaken, they are not

based on a solid foundation of understanding the soft-

ware development process and its outcomes, narrow-

ing their range of application.

REFERENCES

Al-Qutaish, R. E. and Ain, A. (2010). Quality Models in

Software Engineering Literature: An Analytical and

Comparative Study. Technical Report 3.

ARISA Compendium - Understandability for Reuse

(2018). http://www.arisa.se/compendium/

node39.html#property:UnderstandabilityR.

accessed November, 2018.

Arlt, S., Banerjee, I., Bertolini, C., Memon, A. M., and

Schaf, M. (2012). Grey-box gui testing: Efﬁcient gen-

eration of event sequences. CoRR, abs/1205.4928.

Awang Abu Bakar, N. and Boughton, C. V. (2008). Using

a combination of measurement tools to extract metrics

from open source projects. In Khoshgoftaar, T., editor,

Proceeding (632) Software Engineering and Applica-

tions - 2008, pages 130–135. ACTA Press, Canada.

Bakar, N. S. A. A. and Boughton, C. V. (2012). Validation

of measurement tools to extract metrics from open

source projects. In 2012 IEEE Conference on Open

Systems, pages 1–6.

Barkmann, H., Lincke, R., and L

owe, W. (2009). Quanti-

tative evaluation of software quality metrics in open-

source projects. In 2009 International Conference on

Advanced Information Networking and Applications

Workshops, pages 1067–1072.

Basili, V. R., Briand, L. C., and Melo, W. L. (1996). A

validation of object-oriented design metrics as quality

indicators. IEEE Transactions on Software Engineer-

ing, 22(10):751–761.

Bassam Al-Badareen, A., Selamat, H., Jabar, M. A., Din,

J., and Turaev, S. (2011). Software Quality Models:

A Comparative Study, volume 179. Springer, Berlin,

Heidelberg.

Chidamber, S. R., Darcy, D. P., and Kemerer, C. F. (1998).

Managerial use of metrics for object-oriented soft-

ware: an exploratory analysis. IEEE Transactions on

Software Engineering, 24(8):629–639.

Chidamber, S. R. and Kemerer, C. F. (1994). A metrics

suite for object oriented design. IEEE Transactions

on Software Engineering, 20(6):476–493.

Dandashi, F. (2002). A method for assessing the reusabil-

ity of object-oriented code using a validated set of au-

tomated measurements. In Proceedings of the 2002

ACM Symposium on Applied Computing, SAC ’02,

pages 997–1003, New York, NY, USA. ACM.

DeMarco, T. (1986). Controlling Software Projects: Man-

agement, Measurement, and Estimates. Prentice Hall

PTR, Upper Saddle River, NJ, USA.

Elish, K. O. and Alshayeb, M. (2012). Using software qual-

ity attributes to classify refactoring to patterns. Jour-

nal of Software, pages 408–419.

Emam, K. E., Benlarbi, S., Goel, N., and Rai, S. N. (2001).

The confounding effect of class size on the validity of

object-oriented metrics. IEEE Transactions on Soft-

ware Engineering, 27(7):630–650.

Gyimothy, T., Ferenc, R., and Siket, I. (2005). Empirical

validation of object-oriented metrics on open source

software for fault prediction. IEEE Transactions on

Software Engineering, 31(10):897–910.

Hitz, M. and Montazeri, B. (1995). Measuring coupling

and cohesion in object-oriented systems. In Proceed-

ings of International Symposium on Applied Corpo-

rate Computing, pages 25–27.

Kanellopoulos, Y., Antonellis, P., Antoniou, D., Makris,

C., Theodoridis, E., Tjortjis, C., and Tsirakis, N.

(2010). Code quality evaluation methodology using

the ISO/IEC 9126 standard. International Journal of

Software Engineering & Applications, 1(3):17–36.

Landman, D., Serebrenik, A., and Vinju, J. (2014). Empir-

ical analysis of the relationship between cc and sloc

in a large corpus of java methods. In Proceedings of

the 2014 IEEE International Conference on Software

Maintenance and Evolution, ICSME ’14, pages 221–

230, Washington, DC, USA. IEEE Computer Society.

Lenhard, J., Blom, M., and Herold, S. (2018). Exploring the

suitability of source code metrics for indicating archi-

tectural inconsistencies.

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

Li, W. and Henry, S. (1993a). Maintenance metrics for the

object oriented paradigm. In [1993] Proceedings First

International Software Metrics Symposium, pages 52–

60.

Li, W. and Henry, S. (1993b). Object-oriented metrics that

predict maintainability. J. Syst. Softw., 23(2):111–122.

Lincke, R., Lundberg, J., and L

owe, W. (2008). Comparing

software metrics tools. In Proceedings of the 2008 in-

ternational symposium on Software testing and anal-

ysis - ISSTA ’08.

Marinescu, R. (2005). Measurement and quality in object-

oriented design. In 21st IEEE International Con-

ference on Software Maintenance (ICSM’05), pages

701–704.

Melo, W. L., Briand, L. C., and Basili, V. R. (1995). Mea-

suring the Impact of Reuse on Quality and Productiv-

ity in Object-Oriented Systems. Technical report.

Mohd, N. and Khan, P. R. (2012). An empirical validation

of understandability quantiﬁcation model. Procedia

Technology, 4.

Molnar, A. and Motogna, S. (2017). Discovering maintain-

ability changes in large software systems. In Proceed-

ings of the 27th International Workshop on Software

Measurement and 12th International Conference on

Software Process and Product Measurement, IWSM

Mensura ’17, pages 88–93, New York, NY, USA.

ACM.

Ott, L., Bieman, J. M., Kang, B.-K., and Mehra, B. (1970).

Developing Measures of Class Cohesion for Object-

Oriented Software. Technical report.

Rodriguez, D. and Harrison, R. (2001). An overview of

object-oriented design metrics.

Sarker, M. (2005). An overview of object oriented design

metrics. Ume

a University, Sweden.

Silva, R. and Costa, H. (2015). Graphical and statistical

analysis of the software evolution using coupling and

cohesion metrics - An exploratory study. In Proceed-

ings - 2015 41st Latin American Computing Confer-

ence, CLEI 2015.

Succi, G., Pedrycz, W., Djokic, S., Zuliani, P., and Russo,

B. (2005). An empirical exploration of the distribu-

tions of the Chidamber and Kemerer object-oriented

metrics suite. Empirical Software Engineering.

Tang, M.-H., Kao, M.-H., and Chen, M.-H. (1999). An

empirical study on object-oriented metrics. In Pro-

ceedings of the 6th International Symposium on Soft-

ware Metrics, METRICS ’99, pages 242–, Washing-

ton, DC, USA. IEEE Computer Society.

Xu, J., Ho, D., and Capretz, L. F. (2008). An empirical

validation of object-oriented design metrics for fault

prediction. Journal of Computer Science.

Yuan, X. and Memon, A. M. (2010). Generating event

sequence-based test cases using GUI run-time state

feedback. IEEE Transactions on Software Engineer-

ing, 36(1).

Longitudinal Evaluation of Software Quality Metrics in Open-Source Applications
