IAGREE: Infrastructure-agnostic Resilience

Benchmark Tool for Cloud Native Platforms

Paulo Souza

1 a

, Wagner Marques

, R

omulo Reis

and Tiago Ferreto

Polytechnic School, Pontiﬁcal Catholic University of Rio Grande do Sul,

Ipiranga Avenue, 6681 - Building 32, Porto Alegre, Brazil

Keywords:

Cloud Computing, Cloud Native Platform, Resilience, Benchmark.

Abstract:

The cloud native approach is getting more and more popular with the proposal of decomposing application

into small components called microservices, which are designed to minimize the costs with upgrades and

maintenance and increase the resources usage efﬁciency. However, microservices architecture brings some

challenges such as preserving the manageability of the platforms, since the greater the number of microservices

the applications have, the greater the complexity of ensuring that everything is working as expected. In this

context, one of the concerns is to evaluate the resilience of platforms. Current resilience benchmark tools are

designed for running in speciﬁc infrastructures. Thus, in this paper we present IAGREE, a benchmark tool

designed for measuring multiple resilience metrics in cloud native platforms based on Cloud Foundry and

running upon any infrastructure.

1 INTRODUCTION

Cloud computing is becoming more and more popu-

lar among multiple-sized organizations by providing

beneﬁts such as commodity of running large-scale ap-

plications with no need to care about issues involving

local resources. Moreover, cloud also allows a better

resources utilization through the pay-per-use pricing

model, wherein cloud resources can be allocated and

deallocated on demand, so users only have to pay for

the resources they are actually being used (Nicoletti,

2016). By adopting such a strategy, customers avoid

issues related to underprovisioning, in cases when an

application gets more popular than expected result-

ing in revenue losses due to not having the computing

resources enough to meet the demand, or overprovi-

sioning, where applications do not meet the expec-

tations, and the reserved resources end to not being

used (Armbrust et al., 2010).

However, not every application architecture ex-

ploits the maximum potential of cloud environments.

For example, the monolithic architecture in which the

application logic is contained into a single deploy-

https://orcid.org/0000-0003-4945-3329

https://orcid.org/0000-0003-3304-5611

https://orcid.org/0000-0001-9949-3797

https://orcid.org/0000-0001-8485-529X

able unit has shown to be a suitable solution for small

systems. However, as the size of the application in-

creases, tasks involving scaling or performing main-

tenance become more difﬁcult due to challenges re-

lated to code readability and over-commitment to a

speciﬁc technology stack. In this context, the Cloud

Native approach arises with the proposal of taking

advantage of the microservices architecture to allow

on-premises applications to fully exploit the beneﬁts

of cloud computing by decomposing applications into

microservices that could be deployed and scaled inde-

pendently and do not need to be built with the same

technology stack (Balalaie et al., 2015).

Cloud native platforms offers an additional ab-

straction layer over the infrastructure by the adoption

of PaaS model. These platforms aim to simplify the

build, deployment, and management of cloud native

applications. These kind of applications are designed

to exploits the advantages of the cloud computing de-

livery model.

Despite the beneﬁts brought by cloud native, there

are still concerns regarding topics like resilience,

which is the ability to deliver and maintain a certain

level of service despite the failure of one or several

system components (Abbadi and Martin, 2011). Re-

silience issues in cloud services can lead to several

negative consequences, for example, system instabil-

ity, bottlenecks or downtime caused by unexpected

396

Souza, P., Marques, W., Reis, R. and Ferreto, T.

IAGREE: Infrastructure-agnostic Resilience Benchmark Tool for Cloud Native Platforms.

DOI: 10.5220/0007728503960403

In Proceedings of the 9th International Conference on Cloud Computing and Services Science (CLOSER 2019), pages 396-403

ISBN: 978-989-758-365-0

workload can lead to business revenue losses (CA

Technologies, Inc, 2018). Moreover, applications

without proper resilience schemes can demand con-

siderable costs with repair and replacement of cloud

components or data loss (Vishwanath and Nagappan,

2010). In cases of applications that do not employ ef-

ﬁcient resilience schemes, these kinds of failures can

cause SLAs violations, which can negatively affect all

the levels of cloud consumers: Final customers will

have problems with trying to access the cloud ser-

vices, Cloud service providers will suffer customer

attrition, and cloud platform and cloud infrastructure

providers will incur penalties for non-compliance of

the accorded SLAs.

One of the possible steps to improve aspects such

as resilience of a cloud native platform is monitor-

ing its behavior under different circumstances. In this

context, benchmarks play a signiﬁcant role, since they

can be used to measure and to compare different soft-

ware or hardware conﬁgurations. Besides, these tools

can also be used to implement improvements at the

platform based on collected metrics. Several bench-

mark tools were proposed; however, there is a lack of

benchmark tools designed to measure the resilience

of cloud native platforms.

In this sense, this paper presents a bench-

mark tool designed for measuring the resilience of

cloud native platforms. Based on this purpose, we

present the following contributions:

• A review of the beneﬁts and challenges brought

by the cloud native approach.

• A discussion around the relevance of measuring

resilience in cloud native platforms and metrics

that can be analyzed to achieve this purpose.

• An infrastructure-agnostic resilience benchmark

tool to measure the resilience of cloud native plat-

forms based on Cloud Foundry.

The remaining of this article is organized as fol-

lows: In Section 2 we present the theoretical back-

ground about some of the current topics on cloud

computing such as the need for strategies, which is

addressed by approaches such as cloud native, that

aims to improve the resources usage efﬁciency of ap-

plications running on the cloud. In Section 3 we

present the proposed benchmark tool, which is val-

idated in Section 4, where we present a Proof-of-

Concept that includes the use of our proposal to per-

form experiments in a real-world cloud native plat-

form. Then, in Section 5 we present other bench-

mark tools and compare them with our proposal, and

in Section 6 we present ﬁnal considerations and re-

search topics to be addressed in future researches.

2 BACKGROUND

Cloud computing consists of a model that provides

ubiquitous, conﬁgurable, on-demand access to com-

puting resources which include networks, servers,

storage, applications, and services through the Inter-

net (Mell et al., 2011). It also provides cost reduc-

tion, since customers pay just for the resources that

are consumed (Nicoletti, 2016). Due to these features,

many organizations employ cloud services to meet the

peak demand in their applications through services in

the cloud (Gajbhiye and Shrivastva, 2014).

By dealing with on-premises software, customers

must manage all levels of abstraction to make their

applications up and running, dealing with manners

of networking, storage, servers, runtimes, and so on.

On the other hand, cloud computing provides service

models that focus on delivering different levels of ab-

straction to meet the needs of customers more efﬁ-

ciently.

There are still many challenges in Cloud Comput-

ing. For instance, the interoperability among differ-

ent cloud services is still a big challenge. Also, Cloud

Computing is powered by virtualization, which pro-

vides several independent instances of virtual execu-

tion platforms, often called virtual machines (VMs).

However, applications have lower performance on

VMs than on physical machines. The overhead gener-

ated by the virtualization layer (hypervisor) is one of

the leading concerns in the context of virtualized en-

vironments. Therefore, identifying and reducing such

overhead has been the subject of several investiga-

tions (Li et al., 2017; SanWariya et al., 2016; Chen

et al., 2015).

In this context, Cloud Native approach emerges

with the proposal of decomposing applications into

small components designed to operate independently

called microservices. Each microservice is executed

on a container, so its possible to upgrade or replace

a microservice without having to modify the entire

application. Such modularity allows minimizing the

costs with upgrades and maintenance and increase

the resources usage efﬁciency (Amogh et al., 2017).

On the other hand, running microservices in sepa-

rated containers brings some challenges such as pre-

serving the manageability of the platforms, since the

higher the number of containers an applications has,

the greater the complexity of ensuring everything is

working as expected. Due to these challenges, there

is a concern on increasing the customers’ trust in the

services provided.

Service Level Agreements (SLAs) (which are

contractual agreements between service providers and

its customers) play a signiﬁcant role in this context,

IAGREE: Infrastructure-agnostic Resilience Benchmark Tool for Cloud Native Platforms

397

since they specify the quality of service (QoS) guar-

anteed by the providers so customers can verify if

the delivered QoS beﬁts that one was accorded (Pa-

tel et al., 2009). One element which is considered

in SLAs is resilience, which is the ability to deliver

and maintain a certain level of service despite the fail-

ure of one or several system components (Abbadi and

Martin, 2011).

There are tons of elements that can affect the oper-

ation of cloud services and must be considered when

building resilience mechanisms. One of the current

leading causes of failures in cloud computing services

is human errors, which is characterized by failures

caused by human actions (e.g., a cloud operator acci-

dentally erases a database registry required by a sys-

tem vital component). Other causes of system fail-

ures are disasters (like earthquakes and tornadoes) or

software failures (bugs or errors caused by malicious

software) which can also lead to critical failure sce-

narios (Colman-Meixner et al., 2016).

Resilience issues in cloud services can lead to

several negative consequences, for example, sys-

tem instability, bottlenecks or downtime caused by

unexpected workload can lead to business revenue

losses. Moreover, applications without proper re-

silience schemes can demand considerable costs with

repair and replacement of cloud components or data

loss (Vishwanath and Nagappan, 2010). In cases of

applications that do not employ efﬁcient resilience

schemes, these kinds of failures can cause SLAs vi-

olations, which can negatively affect all the levels of

cloud consumers: Final customers will have prob-

lems with trying to access the cloud services; Cloud

service providers will suffer customer attrition, and

cloud platform and cloud infrastructure providers will

incur penalties for non-compliance of the accorded

SLAs.

Cloud Computing takes advantage of the tradi-

tional IT model by providing dynamic resource provi-

sioning instead of delivering computational power ac-

cording to the peak demand (which leads to unneces-

sary costs with computing resources). However, fail-

ures are an undesired but inherent aspect when scaling

applications in the cloud (Zhang et al., 2010). More-

over, infrastructure manners such as the adopted vir-

tualization strategies can impact the resilience of ap-

plications.

Given that, one of the key aspects on achieving re-

silience in cloud environments is building a resilient

infrastructure that implements failure prevention tech-

niques like the isolation of applications’ layers and

components so even if some components get compro-

mised the rest of the system will be able to operate

normally (Salapura et al., 2013). In this context, the

relevance of measuring resilience stood out since it is

important to verify the efﬁciency of the implemented

resilience strategies. Accordingly, as shown in Fig-

ure 1, some resilience metrics should be taken into

account to measure a system or a platform:

• Mean Time To Failure (MTTF): often known

as uptime, MTTF refers to the average amount of

time that a system is available. MTTF is widely

used in SLA contracts to indicate how reliable a

system or a platform is based on the amount of

time it has spent without failing.

• Mean Time To Detect (MTTD): refers to the av-

erage amount of time it takes to detect a failure.

This metric is useful to measure the efﬁciency of

monitoring and incident management tools.

• Mean Time To Repair (MTTR): this metrics de-

notes to the average time spent to repair a failed

system. MTTR is a valuable metric to ﬁnd ways

to mitigate downtime.

• Mean Time To Between Failures (MTBF):

refers to the average time that elapses between

failures. It is a useful metric to predict the reli-

ability and availability of a platform accurately.

3 IAGREE ARCHTECTURE

DESIGN

IAGREE is an infrastructure-agnostic resilience

benchmark tool for cloud native platforms. It allows

the user to measure the resilience of Cloud-Foundry

based platforms by simulating failing scenarios of

a sample REST application while receiving user re-

quests (Figure 2). Our tool use commands provided

by the Cloud Foundry Command Line Interface (cf

CLI), which is used by Cloud Foundry and its based

platforms and allows the deployment, management,

and monitoring of applications. This makes IAGREE

compatible to any platform based on CF. Besides that,

this benchmark tool also enhances the agnostic to in-

frastructure characteristic from Cloud Foundry.

IAGREE uses features provided by a Cloud

Foundry component called Loggregator, which is re-

sponsible for collecting and streaming logs from the

applications and the platform itself.

Our proposal takes advantage of Loggregator’s ar-

chitecture to analyze the resilience provided by the

platform while applications are receiving requests

from multiple users and failing events occur. To sim-

ulate real user accesses, IAGREE generates multiple

concurrent requests using Siege, an open source tool

that allows simulating multiple user HTTP requests.

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

398

System Failure Begin Repair Resume Operations System Failure

Mean Time to

Detect (MTTD)

Mean Time to

Repair (MTTR)

Mean Time Between

Failures (MTBF)

Mean Time to

Failure (MTTF)

Figure 1: Different measures covered by resilience metrics.

Cloud Foundry

Load Balancer    App Instance Loggregator

   App Instance

Benchmark

Client

Requests App Logs

Figure 2: IAGREE benchmark tool design.

As illustrated in Figure 3, upon running IAGREE,

the ﬁrst step is to ask for API endpoint and creden-

tials (email and password) in order to establish a con-

nection to the platform. As soon as the benchmark

conﬁrms that cf CLI was able to authenticate the user

into a Cloud Foundry environment, it deploys a sam-

ple application to receive the requests. Once the ap-

plication deployment is ﬁnished, the benchmark starts

a log stream from the Loggregator and asks the user to

deﬁne three parameters: i) the amount of time the ap-

plication will be tested; ii) how many simulated users

will try to access the application simultaneously; and

iii) how many fails per minute the application will ex-

perience. Once those parameters are informed, the

benchmark tells Siege the desired conﬁguration and

the tests start. In the meantime, IAGREE may sends

requests to a route of the application which is conﬁg-

ured to crash the whole instance. since there is the

load balance component, any instance can stop. This

process is described in Algorithm 1.

As the benchmark ﬁnishes running the tests, it

parses the data from the log stream and presents

the results denoted by the following metrics: MTTF,

MTBF, MTTD, MTTR, mean response time per re-

quests, transactions per second, and throughput.

while time

current

<= time

total

send N simultaneous requests

foreach failureInstant f

∈ F do

send a request that will crash an app

instance

end

Algorithm 1: Strategy adopted by the proposed benchmark

to measure resilience of cloud native platforms.

4 PROOF-OF-CONCEPT

EXPERIMENTS

We conducted a proof-of-concept running our pro-

posal on Pivotal Web Services (Pivotal Web Services,

2018), which is a Cloud-Foundry based platform that

uses EC2 servers located in Northern Virginia (United

States). We did choose PWS since it automatically

handles distributing multiple instances applications

across multiple availability zones. We performed tests

in 8 different conﬁgurations gathering in each of them

MTTF, MTBF, MTTD, MTTR, mean response time

per requests (s), transactions per second, and through-

put (MB/s). Table 1 summarizes the set of conﬁgura-

tions explored by our experiments.

Table 1: Tested speciﬁcation.

App Instances Total Time Failures per Minute Concurrent Users

10 minutes

100

4.1 Mean Time To Failure

The results presented in Figure 4 showed that the im-

pact on an application’s availability caused by the

number of failures per minute varies according to the

number of instances an application have, especially

IAGREE: Infrastructure-agnostic Resilience Benchmark Tool for Cloud Native Platforms

399

infrastructure

Deploy benchmark

application

Deployment was

successful?

Create log stream

Yes

Conﬁgure

benchmark

parameters

Parameters are valid?

Execute resilience

benchmark tests

Parse and present

benchmark results

Yes

Figure 3: IAGREE process ﬂow.

as the number of users accessing the application in-

creases. In other words, the higher the number of

users accessing the application, the higher is the rel-

evance of scaling mechanisms since if an application

crashes due to insufﬁcient resources, its availability

could be severely impacted. Moreover, in the scenar-

ios with 2 failures per minute, the application with 2

instances suffered a 44% availability loss as the num-

ber of users accessing it increased from 50 to 100.

On the other hand, the application with 4 instances

only got an 8% availability loss. These results indi-

cate that the impact caused by a given number of fail-

ures could be signiﬁcantly higher in applications with

few instances.

4.2 Mean Time To Detect

The results in Figure 5 regarding the average time

that the platform took to detect failures show that in

scenarios where applications are suffering from sev-

eral and constant crashes, the higher the number of

users accessing the application, the greater the time

the platform would take to detect the failures. Espe-

cially in scenarios where failures do not crash the en-

tire instance (e.g., the web server stops working, but

the container where it is running continues to work)

and therefore are undetectable for instance healing

tools, monitoring mechanisms must parse more mas-

sive amounts of application logs to detect failures as

the number of requests increases, which could lead to

delayed detection of application failures. Besides, de-

tecting the failures in the 4 instances application took

12% longer, since the higher the number of instances

the app has, the higher the complexity of ensuring that

everything is working as expected.

4.3 Mean Time Between Failures

The results presented in Figure 6 highlighted the cor-

relation between the number of application instances

and the frequency of failure occurrences. In general

terms, the mean time between failures is highly de-

pendent on the number of failures per minute speci-

ﬁed to the benchmark. However, as we can see com-

paring the results of 2 and 4 instances, the bigger

the number of instances that an application have, the

smaller the interval between failures. This happens

because load balancers have a buffer that stores the

incoming requests to be distributed across the applica-

tion instances, then in scenarios with multiple simul-

taneous requests, increasing the number of applica-

tion instances reduces the delay to a request to be pro-

cessed. As the proposed benchmark simulates an ap-

plication failure by sending a request to a speciﬁc ap-

plication URL conﬁgured to crash the web server, in-

creasing the number of instances of the sample appli-

cation resulted in few waiting time to those requests

to be processed, which in its turn reduced the interval

between failures.

4.4 Mean Time To Repair

According to the results presented in Figure 7, in the

experiments with the 2 instances application, increas-

ing the number of failures from 2 to 4 caused a de-

lay to the platform to repair the application failures.

However, such a phenomenon does not appear in the

experiments with the 4 instances application. Besides,

considering that MTTR covers the time to detect fail-

ures (see Figure 1), the results also highlighted the

negative impact of having too frequent failures in ap-

plications with few instances, since the 2 instances ap-

plication took longer to be repaired despite demand-

ing less time to detect failures than the 4 instances

application.

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

400

50 Concurrent Users

100 Concurrent Users

2 42 4 2 42 4

Failures Per Minute

Mean Time To Failure (s)

2 Instances Application

Mean Time To Failure

50 Concurrent Users

100 Concurrent Users

2 42 4 2 42 4

Failures Per Minute

Mean Time To Failure (s)

4 Instances Application

Mean Time To Failure

Figure 4: Mean Time To Failure.

50 Concurrent Users

100 Concurrent Users

2 42 4 2 42 4

0.00

0.25

0.50

0.75

1.00

Failures Per Minute

Mean Time To Detect (s)

2 Instances Application

Mean Time To Detect

50 Concurrent Users

100 Concurrent Users

2 42 4 2 42 4

0.0

0.1

0.2

0.3

0.4

0.5

Failures Per Minute

Mean Time To Detect (s)

4 Instances Application

Mean Time To Detect

Figure 5: Mean Time To Detect.

50 Concurrent Users

100 Concurrent Users

2 42 4 2 42 4

Failures Per Minute

Mean Time Between Failures (s)

2 Instances Application

Mean Time Between Failures

50 Concurrent Users

100 Concurrent Users

2 42 4 2 42 4

Failures Per Minute

Mean Time Between Failures (s)

4 Instances Application

Mean Time Between Failures

Figure 6: Mean Time Between Failures.

50 Concurrent Users

100 Concurrent Users

2 42 4 2 42 4

Failures Per Minute

Mean Time To Repair (s)

2 Instances Application

Mean Time To Repair

50 Concurrent Users

100 Concurrent Users

2 42 4 2 42 4

Failures Per Minute

Mean Time To Repair (s)

4 Instances Application

Mean Time To Repair

Figure 7: Mean Time To Repair.

5 RELATED WORK

Rally (Rally, 2018) provides a framework for eval-

uating the performance of OpenStack components

as well as full production OpenStack cloud deploy-

ments. Rally automates and uniﬁes the deployment

of multiple OpenStack nodes, cloud veriﬁcation, test-

ing, and proﬁle creation. Rally generically does that,

making it possible to check whether OpenStack will

meet the business requirements.

Cloud CMP (Li et al., 2010) is a benchmark tool

developed to provide a systematic comparator of the

IAGREE: Infrastructure-agnostic Resilience Benchmark Tool for Cloud Native Platforms

401

performance and cost of cloud providers. CloudCMP

measures the elasticity, persistent storage and net-

working services offered by a cloud along with met-

rics that directly reﬂect on the performance of cus-

tomer applications. This tool was tested in various

cloud providers, including Amazon Web Services,

Microsoft Azure, Google AppEngine and Rackspace

CloudServers (LI et al., 2010).

HiBench (HiBench, 2018) is an open source

benchmark suite for Hadoop. This tool consists of

synthetic micro-benchmarks and real-world applica-

tions. The application currently has several work-

loads classiﬁed into four categories: Microbench-

marks, Web Search, Machine Learning, and Data

Compression. The microbenchmarks provide several

algorithms such as Sort, WordCount, Sleep, enhanced

DFSIO and TeraSort provided by Hadoop. These

benchmarks are used to represent a subset of real-

world MapReduce jobs. Web Search uses PageRank

and Nutch indexing benchmark tools. These bench-

mark tools are used since large-scale search indexing

is one of the most signiﬁcant uses of MapReduce. The

machine learning workloads provide Bayesian Classi-

ﬁcation and K-means Clustering implementations. It

worth noting that HiBench also provides several other

machine learning benchmark alternatives such as Lin-

ear Regression and Gradient Boosting Trees.

Cloud Suite (CloudSuite, 2018) is an open source

benchmark tool for cloud computing focused on pro-

viding scalability and performance evaluation on real-

world setups. Cloud Suite has a suite of benchmarks

that represent massive data manipulation with tight la-

tency constraints such as in-memory data analytics.

Among the tasks included in this set of benchmarks,

there are MapReduce, media streaming, SAT solving,

web hosting, and web search tasks. Cloud Suite is

compatible with private and public cloud platforms,

and the authors emphasize that it is integrated into

Google’s PerfKit Benchmarker

that helps to auto-

mate the benchmarking process.

Yahoo! Cloud Serving Benchmark (Cooper et al.,

2010) can be used to perform elasticity and scalability

evaluation in different cloud platforms such as Ama-

zon AWS, Microsoft Azure, and Google App Engine.

The authors deﬁned two benchmark tiers for evalu-

ating cloud serving systems: The ﬁrst tier focuses

on the latency of requests when the database is un-

der load. It aims to characterize this trade-off for

each database system by measuring performance as

the user requests increase. The second tier focuses on

examining the impact on performance as more ma-

chines are added to the system. In this tier, there are

PerfKit Benchmarker. Available at:

<github.com/GoogleCloudPlatform/PerfKitBenchmarker>.

two metrics: Scaleup and Elastic Speedup.

Chaos Monkey (Chaos Monkey, 2018) is a bench-

mark tool created by Netﬂix that randomly terminates

instances of virtual machines and containers inside

the production environment to simulate unexpected

failure events. Chaos Monkey follows the principles

of chaos engineering. Chaos Monkey was designed

to work with any backend that provides support for

Spinnaker, which is an open source, and a multi-cloud

continuous delivery platform for releasing software

changes with the intention to give velocity and con-

ﬁdence.

To the best of our knowledge, our proposal (IA-

GREE) is the only infrastructure-agnostic benchmark

tool that allows measuring the resilience of any cloud

native platform based on Cloud Foundry. Table 2

summarizes the differences between IAGREE and the

previous work.

6 CONCLUSIONS

Companies have adopted cloud computing because of

the functionalities it provides in a simple way and also

for the value that is lower than having an on-premise

solution. The cloud native approach was driven by

cloud computing and container technology, though

there is still resistance to migrating to cloud native

platform solutions. One of the reasons for this resis-

tance is the lack of how to reliably evaluate which

platform provides the resilience requirements for the

applications.

Thus, in this paper, a benchmark tool for resilience

for cloud native platforms called IAGREE was pro-

posed. This tool supports platforms based on Cloud

Foundry like the Pivotal Application Service. Be-

sides, it inherits the ability of the CF to be agnostic

to the infrastructure provider, running on both the in-

dustry’s top cloud service providers (AWS, GCP, Mi-

crosoft Azure) and on-premise.

A set of experiments was also performed to vali-

date the proposed tool, using Pivotal Web Services as

a platform provider. The results obtained by IAGREE

were analyzed based on the following resilience met-

rics: Mean Time To Repair, Mean Time Between Fail-

ures, Mean Time To Detect, Mean Time To Failure.

As future work, we intend to perform experiments on

a larger scale and with different conﬁgurations. We

also intend to execute them using different infrastruc-

ture providers in order to compare their performance.

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

402

Table 2: Comparison between IAGREE and other cloud benchmark tools.

Benchmark Evaluated Metrics Output Supported Infrastructures

Rally Elasticity CLI and HTML Infrastructure Agnostic

Cloud CMP Elasticity JSON

Amazon Web Services, Microsoft Azure,

Google Cloud Platform

HiBench Scalability and Performance CLI

Amazon Elastic Compute Cloud,

Microsoft Azure

Cloud Suite Scalability and Performance CLI Infrastructure Agnostic

Yahoo! Cloud Serving Benchmark Elasticity and Scalability CLI and HTML

Amazon Web Services, Microsoft Azure,

Google Cloud Platform

Chaos Monkey Resilience HTML

Amazon Web Services, Microsoft Azure,

Google Cloud Platform, Kubernetes-based

Platforms

IAGREE Resilience CLI and JSON Infrastructure Agnostic

ACKNOWLEDGEMENTS

This work was supported by the PDTI Program,

funded by Dell Computadores do Brasil Ltda (Law

8.248 / 91).

REFERENCES

Abbadi, I. M. and Martin, A. (2011). Trust in the cloud. in-

formation security technical report, 16(3-4):108–114.

Amogh, P., Veeramachaneni, G., Rangisetti, A. K., Tamma,

B. R., and Franklin, A. A. (2017). A cloud native

solution for dynamic auto scaling of mme in lte. In

Personal, Indoor, and Mobile Radio Communications

(PIMRC), 2017 IEEE 28th Annual International Sym-

posium on, pages 1–7. IEEE.

Armbrust, M., Fox, A., Grifﬁth, R., Joseph, A. D., Katz,

R., Konwinski, A., Lee, G., Patterson, D., Rabkin, A.,

Stoica, I., et al. (2010). A view of cloud computing.

Communications of the ACM, 53(4):50–58.

Balalaie, A., Heydarnoori, A., and Jamshidi, P. (2015). Mi-

grating to cloud-native architectures using microser-

vices: an experience report. In European Conference

on Service-Oriented and Cloud Computing, pages

201–215. Springer.

CA Technologies, Inc (2018). Available at: https://bit.ly/

2BVZhsx. Accessed: 2018-12-24.

Chaos Monkey (2018). Chaos monkey. Available at: https:

//github.com/Netﬂix/chaosmonkey. Accessed: 2018-

12-24.

Chen, L., Patel, S., Shen, H., and Zhou, Z. (2015). Proﬁling

and understanding virtualization overhead in cloud. In

Parallel Processing (ICPP), 2015 44th International

Conference on, pages 31–40. IEEE.

CloudSuite (2018). Cloudsuite. Available at: https://github.

com/parsa-epﬂ/cloudsuite. Accessed: 2018-12-24.

Colman-Meixner, C., Develder, C., Tornatore, M., and

Mukherjee, B. (2016). A survey on resiliency tech-

niques in cloud computing infrastructures and appli-

cations. IEEE Communications Surveys & Tutorials,

18(3):2244–2281.

Cooper, B. F., Silberstein, A., Tam, E., Ramakrishnan,

R., and Sears, R. (2010). Benchmarking cloud serv-

ing systems with ycsb. In Proceedings of the 1st

ACM symposium on Cloud computing, pages 143–

154. ACM.

Gajbhiye, A. and Shrivastva, K. M. P. (2014). Cloud com-

puting: Need, enabling technology, architecture, ad-

vantages and challenges. In Conﬂuence The Next Gen-

eration Information Technology Summit (Conﬂuence),

2014 5th International Conference-, pages 1–7. IEEE.

HiBench (2018). Hibench suite. Available at: https://github.

com/intel-hadoop/HiBench. Accessed: 2018-12-24.

Li, A., Yang, X., Kandula, S., and Zhang, M. (2010). Cloud-

cmp: comparing public cloud providers. In Proceed-

ings of the 10th ACM SIGCOMM conference on Inter-

net measurement, pages 1–14. ACM.

Li, Z., Kihl, M., Lu, Q., and Andersson, J. A. (2017). Per-

formance overhead comparison between hypervisor

and container based virtualization. In Advanced In-

formation Networking and Applications (AINA), 2017

IEEE 31st International Conference on, pages 955–

962. IEEE.

Mell, P., Grance, T., et al. (2011). The nist deﬁnition of

cloud computing.

Nicoletti, B. (2016). Cloud computing and procurement. In

Proceedings of the International Conference on Inter-

net of things and Cloud Computing, page 56. ACM.

Patel, P., Ranabahu, A. H., and Sheth, A. P. (2009). Service

level agreement in cloud computing.

Pivotal Web Services (2018). Available at: https:

//pivotal.io/platform/pivotal-application-service. Ac-

cessed: 2018-12-24.

Rally (2018). Rally benchmark. Available at: https://github.

com/openstack/rally. Accessed: 2018-12-24.

Salapura, V., Harper, R., and Viswanathan, M. (2013). Re-

silient cloud computing. IBM Journal of Research and

Development, 57(5):10–1.

SanWariya, A., Nair, R., and Shiwani, S. (2016). Analyzing

processing overhead of type-0 hypervisor for cloud

gaming. In Advances in Computing, Communication,

& Automation (ICACCA)(Spring), International Con-

ference on, pages 1–5. IEEE.

Vishwanath, K. V. and Nagappan, N. (2010). Characterizing

cloud computing hardware reliability. In Proceedings

of the 1st ACM symposium on Cloud computing, pages

193–204. ACM.

Zhang, Q., Cheng, L., and Boutaba, R. (2010). Cloud com-

puting: state-of-the-art and research challenges. Jour-

nal of internet services and applications, 1(1):7–18.

IAGREE: Infrastructure-agnostic Resilience Benchmark Tool for Cloud Native Platforms

403
