Mutating UML State Machine Behavior with Semantic Mutation

Operators

Anna Derezinska

and Łukasz Zaremba

Institute of Computer Science, Warsaw University of Technology, Nowowiejska 15/19, Warsaw, Poland

Keywords: Model-Driven Software Development, State Machine, Code Generation, Mutation Testing, Framework for

Executable UML (FXU), C#.

Abstract: In Model-Driven Software Development (MDSD), an application can be built using classes and their state

machines as source models. The final application can be tested as any source code. In this paper, we discuss

a specific approach to mutation testing in which modifications relate to different variants of behavioural

features modelled by UML state machines, while testing deals with standard executions of the final

application against its test cases. We have proposed several mutation operators aimed at mutating behaviour

of UML state machines. The operators take into account event processing, time management, behaviour of

complex states with orthogonal regions, and usage of history pseudostates. Different possible semantic

interpretations are associated with each operator. The operators have been implemented in the Framework for

eXecutable UML (FXU). The framework, that supports code generation from UML classes and state machines

and building target C# applications, has been extended to realize mutation testing with use of multiple libraries.

The semantic mutation operators have been verified in some MDSD experiments.

1 INTRODUCTION

Model-Driven Software Development (MDSD) can

be aimed at production of high quality software in a

reasonable time or at a rapid prototyping (Liddle,

2011). In both cases the target software should reflect

behavioral features introduced in source models. It

has been assumed that building an application based

on an automatically generated code gains benefits of

high-level modelling and analysis. Model to code

transformation uses mainly structural models, as

UML classes (Batouta et al., 2017).

However, behavioral models, e.g., state machines,

are also utilized (Dominguez et al., 2012). State

machines are widely used in the embedded system

domain, and other application areas (Liebel et al.,

2018); though code generation is still not very

common in the industrial practice. Moreover,

building of such applications impose requirements on

their consistency to the source models and

verification of the final code.

The latter can be supported by mutation testing.

Mutation testing is an approach primarily used for

assessment of test set quality and generation of tests

https: //orcid.org/0000-0001-8792-203X

satisfying selected criteria (Jia and Harman, 2011). In

a standard mutation testing process, syntactic

changes, so-called mutations, are injected into a

source code and supposed to be detected by test cases.

Modified programs, mutants, are run against tests. An

evidence of an abnormal program behaviour, i.e.

killing of a mutant, admits ability of tests to detect

program faults. It could confirm quality of a test suite

in regard to the type of faults introduced by mutation

operators during generation of the mutant. The notion

of mutations used in this paper follow concepts from

mutation testing, and not from genetic algorithms.

Different variations of the standard mutation

testing process have been considered, including

various software artefacts to be mutated and tested.

Not only a program code, but also different kinds of

models and specifications have been used as a source

in a mutation testing process, (Belli et al., 2016).

Among models, mutating of state machines has also

been discussed (Trakhtenbrot, 2007).

Moreover, mutation testing operators can refer not

only to syntactical changes of an input artefact, i.e.

code, model, or specification, but also to its semantic

variations or other implementation features (Clark et

Derezinska, A. and Zaremba, Ł.

Mutating UML State Machine Behavior with Semantic Mutation Operators.

DOI: 10.5220/0007735003850393

In Proceedings of the 14th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2019), pages 385-393

ISBN: 978-989-758-375-9

385

al., 2013), (Trakhtenbrot, 2010), (Trakhtenbrot,

2017).

Mutation testing could be combined with MDSD

approach in various ways. We propose mutation of

semantic features of state machines that are source

models in the program development. However,

mutation testing results are interpreted not on a model

level but on the level of a final application; as in the

typical mutation testing of a program. Tests should be

capable to detect different kinds of software flaws.

Among others they should verify correctness of usage

of the state machine formalism to design the project

corresponding to given requirements.

Presentation of semantic operators to behavioural

features of UML state machines and their possible

interpretation variants consistent to the UML

specification, is the main contribution of the paper.

The proposed operators have been implemented in a

tool and verified in a case study. To the best of our

knowledge it is the first implementation of mutation

operators of such kind.

In this paper we assume an MDSD process in

which an executable application is created based on

UML classes and hierarchical state machine models

(Pilitowski and Derezinska, 2007). The final code

project is built with all necessary library notions, so

the target application can be run as any other general–

purpose application in a standard environment. The

variety of semantics is realised by a “multiple library”

approach, which has been selected after comparison

of four different architectural approaches (Derezinska

and Zaremba, 2018).

This mutation testing approach has been

implemented in FXU – a tool that supports code

generation from UML classes and their behavioral

state machines with the target to C# applications

(FXU, 2019).

The next Section is devoted to the background of

the work. Semantic mutation operators of state

machines are discussed in Section III. Section IV

describes implementation of the approach in FXU.

Section V informs about conducted experiments.

Section VI summarises related work and Section VII

concludes the paper.

2 SEMANTIC MUTATION IN

MDSD

Considering mutation testing in an MDSD process,

the following general mutation categories can be

recognised, which refer to elements that are mutated:

A) design or construction mutation,

B) semantic mutation,

C) semantic consequence-oriented mutation.

The first category has been mostly used in mutation

of source code and UML models, but is not a subject

of this paper.

2.1 Semantic Mutation

Introduction of semantic mutation is associated with

modification of realization of specific

transformations rather than modification of

transformation effects. In comparison to the A)

category, semantic mutation does not modify a source

form of a model or code. Semantic mutations rely on

other interpretations of an intermediate form.

Usually, transformation rules from a source to an

intermediate form have to be modified.

Semantic mutation can be applied to models,

therefore transformation of a model to a source code

or to another model notation results in another code-

model or another meaning-behavior in dependence on

an applied mutation. Semantic mutations referring to

UML state machines are important as there are many

semantic variants consistent with the UML

specification (UML, 2017).

Semantic mutation can also be used for a program

code. In the contrast to traditional mutation, in this

case a source code is not modified but its

interpretation is changed. For example, in different

programming languages, a scope and precision of

embedded types can be different (Clark, Dan and

Hierons, 2013).

2.2 Semantic Consequence-oriented

Mutation

This mutation category relates to realization of a

specific meaning of a programming concept that was

modelled. For example, a final system behavior could

be determined by one of system realizations, which is

consistent with a given semantics. However, behavior

of this system can be nondeterministic. Different

correct scenarios can follow realization of execution

of models from orthogonal regions of a state machine.

Execution order of operations in orthogonal regions

is undefined by the specification. Consequently,

many combinations of such operation execution can

encounter. Therefore, semantic consequence-oriented

mutation could imitate different behavioral

combinations in a situation of this kind.

This mutation category principally differs from

the previous ones. In this case, a generated mutant

corresponds to a correct system behavior, and should

not be killed by a test suite. Application of tests with

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

386

such mutants is based on the integration of the

mutated system with other parts.

This kind of mutation was treated as an

implementation-oriented mutation (Trakhtenbrot,

2010) specified in the context of the Harel statecharts

(Harel, 1987). However, the approach to realization

of such mutations proposed in this paper is different

to those from Trachtenbrot.

3 SEMANTIC MUTATION

OPERATORS FOR STATE

MACHINE BEHAVIORS

Different aspects of state machine behaviour have

been considered. Therefore, we have distinguished

several groups of semantic mutation operators:

I. Event processing.

II. Time management.

III. State behavior in regions belonging to the same

orthogonal complex state.

IV. Processing of history pseudostate.

It is assumed that all variants of the possible state

machine behavior are consistent with the UML

specification (UML, 2017). We discuss exemplary

selected operators belonging to all above groups, and

possible interpretation variants that might be

associated with the operators. The selection of

operators originates from the previous research

(Derezinska and Pilitowski, 2009), (Derezinska and

Szczykulski, 2012) and covers a wide range of

possible topics and their interpretations, but of course

is not exhaustive.

3.1 Operators of Event Processing

The semantics of UML requires processing of one

event per time according to the rule of run-to-

completion step. Encountering of events is stored in a

queue, so-called an event pool. A policy of the queue

is undefined, hence various queue policies could be

considered as interpretation variants.

Moreover, there exists a possibility to defer an

event. An event could be deferred, if no transition

exists that could be traversed due to this event

consumption and in the same time this event is

denoted as deferred by at least one of states that

belong to the current active configuration. The

deferred event is kept in the event pool until it can

trigger a transition, or a configuration is reached in

which it is not deferred any more. Processing of

deferred events requires deciding of some

interpretation issues and resolving of conflicts about

an order of deferred event evaluation.

In result we have considered the five following

mutation operators of event processing and their

several interpretation variants:

I.1. Selection of Queue Policy of Events:

I.1.1) FIFO,

I.1.2) FIFO, except completion and time events,

I.1.3) priority queue – priorities are associated

with the different types of events,

I.1.4) priority queue – priorities are associated

with different events,

I.1.5) LIFO.

I.2. Detection Policy for a Change Event:

I.2.1) periodical checking of the expression value,

I.2.2) checking of the expression value once

during a completion step,

I.2.3) immediate reaction to detection of change

of the expression value (i.e. from False to True).

I.3. Removal of a Change Event from an Event Pool:

I.3.1) changing of the expression value to False

causes removal of an event associated with this

expression from the event pool,

I.3.2) the expression is assessed during evaluation

of the associated event. The event is removed if

the expression is False.

I.3.3) further changes in a value of the associated

expression have no impact on the event

processing.

I.4. Interpretation of an Event Deferment:

I.4.1) an event deferment is realized as a

placement of the event again in the event pool (as

if it has encountered again),

I.4.2) an event deferment causes adding the event

to a special pool of deferred events, which is

global for the whole state machine,

I.4.3) due to an event deferment the event is

placed in a special pool of deferred events, which

is defined locally for each state of the state

machine.

I.5. Processing of Events deferred by the Same State:

options I.5.1) - I.5.4) are the same as in I.1.

3.2 Operators of Time Management

The UML specification does not assume any specific

time delays between consecutive time events, or any

predefined event processing time (neither a minimal

time, nor a maximal one). Due to such universal

foundation, different semantic variants could be

applied to time processing in dependence to a selected

application domain. We have identified the following

operator and its three interpretation variants:

II.1 Selection of Time Processing Policy in a State

Machine:

Mutating UML State Machine Behavior with Semantic Mutation Operators

387

II.1.1) processing of consecutive events one after

another,

II.1.2) processing based on a logical clock for time

measurement,

II.1.3) processing based on a chronometric clock

for time measurement.

3.3 Operators of Orthogonal States

A complex orthogonal state consists of many regions.

An event processing in such a state may cause

execution of many transitions during a run-to-

completion step. Only one transition can be executed

in a region. Transitions in the orthogonal regions are

executed simultaneously, which could be differently

interpreted. In realization of a transition we consider

three actions: exiting a source state, transition

execution, and entering a target state. These actions

have been referred in the following three operators

dealing with transitions in orthogonal regions:

III.1. Execution Policy of Actions to exit from Source

States which are executed Simultaneously:

III.1.1) concurrent execution (physically true

concurrent – e.g. using different cores, or different

processors),

III.1.2) parallel execution (e.g. might be realized

by many threads on the same core),

III.1.3) sequential execution (might be given an

execution order).

III.2. Execution Policy of Transitions to be Executed

Simultaneously:

options III.2.1- 2.3) are the same as in III.1.

III.3. Execution Policy of Actions to enter Target

States which are Executed Simultaneously:

options III.3.1- 3.3) are the same as in III.1.

The next operator deals with orthogonal states were

not all initial states are directly defined, but no history

pseudostate is used.

III.4 Default Entering a Complex State including at

least One Region without an Initial Pseudostate:

III.4.1) the model is treated as ill-defined,

III.4.2) the ambiguous regions are omitted,

III.4.3) the ambiguous regions are counted as

successfully executed,

III.4.4) initial states are selected in the ambiguous

regions.

3.4 Operators of History Pseudostates

In this operator group we consider application of

history pseudostates, referring to both cases of a

shallow and deep history. There are various situations

that might be interpreted in different ways. One is

calling of a nonexistent default history pseudostate.

Another is entering a complex orthogonal state via

history. Hence, there are two operators:

IV.1. Selection of a History Pseudostate

Interpretation:

IV.1.1) a history pseudostate refers to all regions

of the complex orthogonal state in which it is

included,

IV.1.2) a history pseudostate only refers to the

region in which it is included,

IV.1.3) a history pseudostate refers to the region

in which it is included, and also to other regions

of its orthogonal state to which no concurrent

direct entry exists,

IV.1.4) a history pseudostate is accepted to be

valid only if there are concurrent direct entries to

all other regions of the orthogonal state, in which

it is included. Otherwise, the model is counted to

be ill-modelled.

IV.2. Default Entry to an Orthogonal State Via a

History Pseudostate:

IV.2.1) lack of a default history pseudostate

results in a default entering a region(s),

IV.2.2) regions that do not include default history

pseudostates are considered to be executed.

3.5 Operators for Semantic

Consequence-Oriented Mutation of

State Machines

Some operators from the third category have also

been considered. A mutant of the second category can

be regarded as a pair: a final code and its semantics.

In the case of the third category, a mutant could be

specified by a 3-tuple: a code, a semantics, and a

constraint of the semantics.

Introduction of a mutation operator results here

not in changing of a semantics, as in the second

category, but in applying some limits to a selected

semantics. Therefore, an operator is specified in

relation to a chosen semantic variant.

We have proposed the following mutation

operators of this kind:

V.1 Deterministic Order of Execution of Concurrent

Entries into Orthogonal Regions (it refers to the

III.1.1 semantic variant).

V.2 Deterministic Order of Execution of Concurrent

Transitions in Orthogonal Regions (it refers to the

III.2.1 semantic variant).

V.3 Deterministic Order of Execution of Concurrent

Exits from Orthogonal Regions (it refers to the III.3.1

semantic variant).

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

388

4 IMPLEMENTATION OF

SEMANTIC MUTATION

OPERATORS IN FXU

The discussed approach has been incorporated into an

MDSD process supported by the Framework for

eXecutable UML (FXU, 2019). The FXU tool has

been designed to transform UML models into

executable code of a general purpose language

(Pilitowski and Derezinska, 2007). It was focused on

code generation for all notions of behavioral state

machines, including complex states with orthogonal

regions, different pseudostates, also with history

pseudostate, etc. It was the first tool that supported

the C# language as a transformation target, and it has

still been treating state machines in the most

comprehensive way within this technology domain.

The framework was extended with different versions,

e.g. considering time concepts from the OMG

MARTE profile (Derezinska and Szczykulski, 2017).

The framework includes two main parts: FXU

Generator and FXU Run-Time Library. The

Generator transforms UML classes and their

behavioral state machines into the corresponding C#

code. The Library contains implementation of all

state machine concepts. After code transformation, a

final application is built as a project including the

generated code and the library. Consequently, it can

be run independently in the .NET environment as any

other general-purpose application.

UML models are statically verified during model

to code transformation (Pilitowski and Derezinska,

2007). Furthermore, FXU runtime library supports

dynamic verification completed during a program

execution. Apart from this, the mutation operators are

another means of model verification that have been

incorporated into the framework.

Four different architectural approaches to

realization of semantic mutation have been examined

(Derezinska and Zaremba, 2018). The basic

complexity metrics were analyzed and compared.

After this evaluation, a solution based on a

“configurable library” was selected and implemented

in FXU. In this case, semantics is expressed in a set

of configurable rules that is combined with a target

application. Each mutant refers to configurable

semantic rules and the target application can be

executed in accordance to its semantics. Moreover,

two strategies, i.e. all-state machines and one selected

state machine, that could be chosen by a user, were

implemented.

Realizations of all state machine details and

semantic variants are encapsulated in the run-time

library. Source code is generated from the class and

state machine models. The model-to-code

transformation is responsible only for correct

construction of state machines from the components

provided by the library. Compilation of the code is

performed only once, regardless of the applied

semantic mutation operators.

Different semantic variants are driven by selected

mutation operators providing, in result, appropriate

semantic configurations. Based on these

configurations, the desired library versions are used

during the application run-time. The application can

be executed for any semantic configuration and any

test suit, if necessary.

A reconfigured architecture of the FXU Library

supports different approaches to state machine

behavior, including semantic mutation operators and

semantic consequence-oriented mutations. The

refactored Run-Time Library consists of the

following main components:

StateMachineLogic – implements concepts

from the state machine domain,

Interfaces - includes interfaces for classes of

the state machine elements used by generated code,

and interfaces for internal communication,

Infrastructure – implements an

intermediate layer used by generated code,

Marte - implements selected time concepts from

the OMG MARTE profile.

5 EXPERIMENTS

The MDSD experiments have been conducted

combined with mutation testing using semantic

mutation. The subject of experiments was a case

study that had been used in some previous research

on model-driven development (Derezinska and

Szczykulski, 2013). The case study concerned

modelling of a presence server in a social network. It

covered processing user statuses; in particular, user’s

presence, location, communication possibilities,

activities, etc.

The presence server model consisted of three

main layers dealing with communication with a

client, controlling of presence statuses, and

communication with other systems. Each layer was

modelled by packages comprising its classes and

additional subpackages. Behaviour of the classes was

specified by their state machines. The whole model

included about twenty classes and interfaces as well

as about seventeen state machines.

The model of presence server was processed by

the FXU generator, i.e. class and state machine

models were transformed into C# source code, and a

Mutating UML State Machine Behavior with Semantic Mutation Operators

389

code project and appropriate semantic configuration

files were created. The selected server functionality

was implemented or simulated by refinement of

appropriate methods.

The aim of current experiments was not only

evaluation of an MDSD process, but also verification

of the final application. Different variants of the

application and their behaviour could have been

compared. The variants corresponded to different

semantic variants of UML state machines. In result,

behavioural correspondence of an application variant

to an interpretation of a related model could have

been examined.

A set of unit tests for the application was

developed and placed into a test project that belonged

to the same VS solution. The test project included

also a configuration file of a state machine semantics.

Each test class was extended with a method

initializing the FXU run-time environment.

There were tests developed to check correctness

of only one class and its behavior specified by its state

machine. Other kinds of tests were devoted to

verification of a whole subsystem, for example

servicing of a data publishing request. A test started

with an initialization of an object of the presence

server. Next, a request for status publishing was

created and delivered to the server via TCP. Then, it

was verified whether an expected status was set in

places of concern.

In order to perform semantic mutation testing,

configurations of semantic mutants were used.

Configurations mutated semantics for the whole

execution of a single test, if a test checked only one

class and its state machine. If a test referred to a whole

subsystem, two types of mutants were configured,

namely:

1) All state machines of the involved classes

behaved according to the same semantic variant

within the same test run.

2) Different state machines of the involved classes

used various semantic variants within the same

test run.

The mutated applications were run against all test

cases. The mutation testing process was supported by

an add-in to VS that managed execution of mutants

with tests.

The created tests have finished with correct results

in the created environment. We have not observed

any discrepancies between requirements expressed in

the input models and behaviour of the final

applications, assuming given semantic variants.

However, it should be noted, that this model was

formerly evaluated with its basic semantics and

thoughtfully verified (Derezinska and Szczykulski,

2013). The main goal of the experiment was to verify

the semantic mutation testing process combined with

MDSD and the tool support, and not to find model

errors or semantic flaws in the case study.

6 RELATED WORK

There are different areas of research that have

contributed to the presented work: model-to-code

transformation (in particular from state machines),

variation points in behaviour of state machines, and

processes of mutation testing.

6.1 Code Generation from State

Machines

A straightforward transformation from UML models

to code is based on class models. However, while

dealing with behavioral specification, a

transformation can be extended with state machine

models. There are many approaches to reproduce

these models in a code, such as replicating states by

attributes, using state design patterns, and others

(Dominguez et al., 2012), (Sunitha and Samuel,

2016), (Samek, 2002), (Badreddin et al., 2014),

(Pilitowski and Derezinska, 2007). A special

attention has been devoted to transformation of

advanced modelling features of state machines,

including composite states (Sunitha and Samuel,

2016), (Badreddin et al., 2014), or states with history

pseudostates (Derezinska and Pilitowski, 2009).

Contemporarily, several tools support code

generation from UML state machines (IBM RSA,

2018). They usually respect only a subset of state

machine concepts, while more advanced notions,

such as complex states, in particular orthogonal

regions in states, deep and shallow history

pseudostates, deferred events, entry/do/exit actions or

internal transitions might be omitted (Samek, 2002).

There are some solutions that apply more

comprehensive set of state machine concepts, as IBM

Raphsody (IBM RRD, 2018), Umple (Badreddin et

al., 2014), FXU (FXU, 2019), although most of them

do not support the C# language.

In this paper we discuss an approach based on the

full UML state machine specification. The target is an

application built in a general-purpose programming

language. Concerning implementation issues we used

C# and Visual Studio environment.

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

390

6.2 Interpretation Issues of State

Machines

Models of UML state machines have been originated

from the concepts proposed by Harel (1987). The

official UML specification (UML, 2017) has always

been imprecise, and included some unspecified

places, previously called semantic variation points

(Beeck, 1994). All in all, they should be resolved in

different ways when a model has to be interpreted or

a model-based application has to be built and

executed.

There are various ways to handle these problems.

In (Chauvel and Jezequel, 2005) authors stipulate

different variants to be decided by a user. Selected

decisions, about event handling and queuing policies,

can be also taken by a user in the Umple tool

(Badreddin et al., 2014). Another generic approach to

creation of a code generator parametrized with

semantic variants has been discussed in (Prout et al.,

2012). However, in most of implemented solutions,

there are different resolutions of behavioral

interpretation problems, but often without precise

statements about selections taken.

During development of the FXU tool, different

problems of state machine interpretation have been

faced and decided (Derezinska and Pilitowski, 2009),

(Derezinska and Szczykulski, 2012). Moreover, it

could be possible to incorporate different variants of

state machine behaviour into solutions offered to a

user, and they could be treated as possible

modifications in mutation testing.

6.3 Mutation Testing

Mutation testing approach has been employed to

applications written in different programming

languages (Jia and Harman, 2011), also including C#

(Derezinska and Szustek, 2012), (Derezinska and

Trzpil, 2015). This methodology was also used to

mutate UML models (Belli et al., 2016).

Some research was also devoted to mutation of

automata-based models. Many of these works were

dealing with syntactical changes of diagrams

(Trakhtenbrot, 2007).

Behavioral models, mainly state machines, have

been also studied as an object of semantic mutation

(Clark et al., 2013), in some variants called also an

implementation mutation (Trakhtenbrot, 2007),

(Trakhtenbrot, 2010). In this kind of mutation there

are no changes introduced into a model graph

structure, but different semantic interpretations are

considered (Trakhtenbrot, 2017), (Bartolini, 2017).

7 CONCLUSIONS

Different operators to semantic mutation of state

machines have been introduced. The operators and

their selected possible interpretations have been

implemented in the FXU, the framework that

supports building C# applications from class and state

machine models. The semantic mutations were

applied in mutation testing experiments. Their

behaviour was consisted with the expectations.

There are many possibilities of the future

enhancement of the approach. Basing on the mutation

facility developed in the framework, other mutation

operators corresponding to different behavioral

variants of state machines can be added. These

variants could deal with other interpretations of UML

state machines, or solutions consistent with other

semantics than derived from the UML specification.

Moreover, structural mutations of state machine

models could also be incorporated into the

framework. Such mutations deal with other flaws of

models than the ones covered in this paper.

While using the current FXU add-in for the Visual

Studio, unit tests can be automatically executed for

any number of mutants. However, defining of tests

and their configuration requires a manual work,

which could be automated.

Finally, the concerned applications were

developed in the C# language. The model-driven

development of a program could be combined with

the mutation testing performed at the source code

level with standard and object-oriented operators of

C# (Derezinska and Szustek, 2012) or with operators

applied at the intermediate code (CIL - Common

Intermediate Language of .NET) (Derezinska and

Trzpil, 2015).

REFERENCES

Badreddin, O. et al., 2014. Enhanced code generation from

UML composite state machines. In: Proceedings of the

2nd International Conference on Model-Driven

Engineering and Software Development

(MODELSWARD). SCITEPRESS - Science and

Technology Publications. pp. 235-245. doi:

10.5220/0004699602350245.

Bartolini, C., 2017. Software testing techniques revisited

for OWL ontologies. In: Hammoudi S., Pires L., Selic

B., Desfray P., eds., Model-Driven Engineering and

Software Development. MODELSWARD, 2016. CCIS,

vol 692. Springer, Cham, pp. 132-153. doi:

10.1007/978-3-319-66302-9_7.

Batouta, Z. I. et al., 2017. Automation in code generation:

tertiary and systematic mapping review. In: 4th IEEE

Mutating UML State Machine Behavior with Semantic Mutation Operators

391

International Colloquium on Information Science and

Technology (CIST), IEEE. art. no. 7805042, pp. 200-

205. doi: 10.1109/cist.2016.7805042.

Beeck von der, M., 1994. A comparison of statecharts

variants. In: Proc. of the 3rd International Symposium

Organized Jointly with the Working Group Provably

Correct Systems on Formal Techniques in Real-Time

and Fault-Tolerant Systems, London, LNCS 863, pp.

128-148.

Belli, F. et al., 2016. Model-based mutation testing—

approach and case studies. Science of Computer

Programming. Elsevier BV, 120(1), pp. 25–48. doi:

10.1016/j.scico.2016.01.003.

Chauvel, F. and Jézéquel, J.-M., 2005. Code generation

from UML models with semantic variation points. In:

Proceedings of 8th International Conference Model

Driven Engineering Languages and Systems. LNCS

vol. 3713 Springer Berlin Heidelberg, pp. 54–68. doi:

10.1007/11557432_5.

Clark, J. A., Dan, H. and Hierons, R. M., 2013. Semantic

mutation testing. Science of Computer Programming.

Elsevier BV, 78(4), pp. 345–363. doi:

10.1016/j.scico.2011.03.011.

Derezinska, A. and Pilitowski, R., 2009. Interpretation of

history pseudostates in orthogonal states of UML state

machines. In: Next Generation Information

Technologies and Systems. LNCS vol. 5831, Springer

Berlin Heidelberg, pp. 26–37. doi: 10.1007/978-3-642-

04941-5_5.

Derezinska, A. and Szczykulski, M., 2012. Interpretation

problems in code generation from UML state machines

- a comparative study. In: T. Kwater, Ed Computing in

Science and Technology 2011: Monographs in Applied

Informatics, Department of Applied Informatics

Faculty of Applied Informatics and Mathematics,

Warsaw University of Life Sciences, pp. 36-50.

Derezinska, A. and Szczykulski, M., 2013. Towards C#

application development using UML state machines: a

case study. In: T. Sobh, K. Elleithy, eds., Emerging

Trends in Computing, Informatics, System Sciences,

and Engineering. LNEE. vol. 151 Springer New York,

pp. 793–803. doi: 10.1007/978-1-4614-3558-7_68.

Derezinska, A. and Szczykulski, M., 2017. Advances in

transformation of MARTE profile time concepts in

Model-Driven Software Development. In: Software

Engineering Trends and Techniques in Intelligent

Systems (CSOC 2017), AISC. Vol. 575 Springer

International Publishing, pp. 385–395. doi:

10.1007/978-3-319-57141-6_42.

Derezinska, A. and Szustek, A., 2012. Object-oriented

testing capabilities and performance evaluation of the

C# mutation system. In: Advances in Software

Engineering Techniques. LNCS, vol. 7054, Springer

Berlin Heidelberg, pp. 229–242. doi: 10.1007/978-3-

642-28038-2_18.

Derezinska, A. and Trzpil, P., 2015 Mutation testing

process combined with Test-Driven Development in

.NET environment. In: Proceedings of the 10th

International Conference DepCoS-RELCOMEX,

Advances in Intelligent Systems and Computing. Vol.

365. Springer International Publishing, pp. 131–140.

doi: 10.1007/978-3-319-19216-1_13.

Derezinska, A. and Zaremba, Ł., 2018. Approaches to

semantic mutation of behavioral state machines in

Model-Driven Software Development. In: Proceedings

of the 2018 Federated Conference on Computer

Science and Information Systems. ACSIS, vol. 15, pp

863–866, IEEE. doi: 10.15439/2018f313.

Dominguez, E. et al., 2012. A systematic review of code

generation proposals from state machine specifications.

Information and Software Technology. Elsevier BV,

54(10), pp. 1045–1066. doi:

10.1016/j.infsof.2012.04.008.

FXU (Framework for eXecutable UML). [Online]

Available from: http://galera.ii.pw.edu.pl/~adr/FXU/

[Accessed: 2

Jan 2019].

Harel, D., 1987. A visual formalism for complex systems.

In: Science of Computer Programming, Amsterdam,

pp. 231-274.

IBM RSA (Rational Software Architect). [Online]

Available from:

https://www.ibm.com/developerworks/downloads/r/ar

chitect [Accessed: 7

Dec 2018]

IBM RRD (Rational Rhapsody Developer). [Online]

Available from:

https://www.ibm.com/developerworks/downloads/r/rh

apsodydeveloper/ [Accessed: 7

Dec 2018]

Jia, Y. and Harman, M., 2011. An analysis and survey of

the development of mutation testing. IEEE

Transactions on Software Engineering, Institute of

Electrical and Electronics Engineers (IEEE), 37(5), pp.

649–678. doi: 10.1109/tse.2010.62.

Liddle, S. W., 2011. Model-Driven Software Development.

In: D.W. Embley, B. Thalheim, eds., Handbook of

Conceptual Modeling, Springer, pp. 17-54.

Liebel, G. et al., 2018. Model-based engineering in the

embedded systems domain: an industrial survey on the

state-of-practice. Software & Systems Modeling.

Springer Nature, 17(1), pp. 91–113. doi:

10.1007/s10270-016-0523-3.

Pilitowski, R. and Derezinska, A., 2007. Code generation

and execution framework for UML 2.0 classes and state

machines. In: T. Sobh, ed., Innovations and Advanced

Techniques in Computer and Information Sciences and

Engineering. Springer Netherlands, pp. 421–427. doi:

10.1007/978-1-4020-6268-1_75.

Prout, A. et al., 2012. Code generation for a family of

executable modelling notations. Software & Systems

Modeling. 11(2), Springer Nature, pp. 251–272. doi:

10.1007/s10270-010-0176-6.

Samek, M., 2002. Practical statecharts in C/C++: quantum

programming for embedded systems. CMP Books.

Sunitha, E. V. and Samuel, P., 2016. Object Oriented

method to implement the hierarchical and concurrent

states in UML State Chart Diagrams. In: Software

Engineering Research, Management and Applications.

Vol.654, Springer International Publishing, pp. 133–

149. doi: 10.1007/978-3-319-33903-0_10.

Trakhtenbrot, M., 2007. New mutations for evaluation of

specification and implementation levels of adequacy in

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

392

testing of Statecharts models. In: Proceedings of

Testing: Academic and Industrial Conference Practice

and Research Techniques - MUTATION (TAICPART-

MUTATION 2007). IEEE. pp. 151-160. doi:

10.1109/taic.part.2007.23.

Trakhtenbrot, M., 2010. Implementation-oriented mutation

testing of Statechart models. In: IEEE International

Conference on Software Testing Verification and

Validation Workshops (ICSTW), pp.120-125. IEEE.

doi: 10.1109/icstw.2010.55.

Trakhtenbrot, M., 2017. Mutation patterns for temporal

requirements of reactive systems. In: IEEE

International Conference on Software Testing,

Verification and Validation Workshops (ICSTW). pp.

116- 121. IEEE. doi: 10.1109/icstw.2017.27.

UML (Unified Modelling Language), 2017. [Online]

Available from: http://www.omg.org/spec/UML,

[Accessed: 7

Dec 2018].

Mutating UML State Machine Behavior with Semantic Mutation Operators

393
