A Security Framework to Protect Data in Cloud Storage

Farashazillah Yahya

, Victor Chang

, Robert John Walters

and Gary Brian Wills

Faculty of Computing and Informatics, Universiti Malaysia Sabah, Kota Kinabalu, Sabah, Malaysia

International Business School Suzhou, Xi'an Jiaotong-Liverpool University, Suzhou, China

Electronics and Computer Science, University of Southampton, Southampton, U.K.

Keywords: Availability, Authenticity, Cloud Storage, Confidentiality, Integrity, Non Repudiation, Reliability, Security

Framework.

Abstract: With the success and widespread adoption of Cloud Computing Cloud storage has become the storage option

of choice for many computer users wishing to keep their data online. This paper presents a framework to

explore and evaluate security threats to data held in Cloud Storage. The Cloud Storage Security Framework

(CSSF) has been developed both from consideration of established good practice as described in existing

literature and the opinions of cloud storage managers and experts using a questionnaire and separate

interviews. The purpose of the framework is to support researchers and managers of Cloud storage to

understand the nine identified factors of security in Cloud storage and how to ensure security measures are

successful. CSSF can also integrate with another framework to produce a greater impact and strengthens its

research contributions.

1 INTRODUCTION

With recent improvements to the availability,

reliability and bandwidth of internet connections,

Cloud computing has become a viable and highly

attractive alternative to conventional computing for

both individuals and business. A principal advantage

is that using Cloud computing permits rapid

adjustment of computing capabilities according to

circumstances. This enables users to pay only for the

facilities they need whilst retaining flexibility to buy

extra resources when required. These advantages

apply equally to computing processing power and

data storage and the number of service providers

offering both has increased significantly in recent

years. It is estimated that in 2016 a typical Cloud

storage user has at least 3.3. terabytes of data stored.

There is also a significant increase in the use of

commercial service providers; Dropbox, Box and

Google Drive amongst others for personal storage

(Gartner 2012). However, along with the cost and

accessibility advantages, using Cloud based data

storage services brings with it concerns about safety

and security of valuable and potentially sensitive data

(Zissis and Lekkas, 2012). There are regular reports

of security breaches of poorly secured Cloud storage

whereby outsiders have been able to discover

passwords or exploit insecure APIs to gain access to

unencrypted data (CSA, 2013a; GTISC and GTRI,

2013, Shaikh and Haider, 2011). There is significant

variety in the techniques used from simple methods

such as brute force discovery of passwords to more

sophisticated approaches to read unencrypted files by

compromising insecure service provider’s APIs or the

Cloud service itself.

Efforts are being made by the service providers to

address the problem, such as two-factor

authentication and file encryption which make

accessing data more difficult for outsiders.

Unfortunately, these approaches can be unpopular

with service providers and authorised users since they

usually compromise usability and performance of

Cloud storage services in what has become a highly

competitive market (Honan, 2012; Zarandioon et al.,

2012; Zhand and Chen, 2012; Zhao and Yue, 2014).

Whilst it is recognised that security is an issue in

the provision of Cloud computing services, including

the establishment of security frameworks and

industry standards and best practices, previous work

has addressed the security of generic Cloud services.

There has been very little work directed at

understanding issues and challenges specific to the

provision of Cloud storage services.

Yahya, F., Chang, V., Walters, R. and Wills, G.

A Security Framework to Protect Data in Cloud Storage.

DOI: 10.5220/0007737603070314

In Proceedings of the 4th International Conference on Internet of Things, Big Data and Security (IoTBDS 2019), pages 307-314

ISBN: 978-989-758-369-8

307

2 CLOUD STORAGE

Cloud computing in general may be considered to be

a style of computing which is delivered by internet

technologies for users to access applications and other

resources (Weiss 2007, Mell and Grance 2009;

Vanquero et al. 2009). Cloud storage is a term used

where the service provided in the Cloud is retention

of data. Commercial Cloud storage provided by

public Cloud service providers may also be referred

to as Utility storage (Wu et al., 2010). Cloud storage

provides the user with access to a flexible, scalable

and provisioned virtual storage architecture, usually

via an API (Ju et al., 2011). Services widely offered

include storage protocols such as iSCSI (Satran et al.

2004), file storage (Miller, 2013) or databases or web

servers. The data is stored on distributed servers

which may be accessed from anywhere through the

Internet. The service provider uses virtualization

techniques to maintain, operate and manage the

storage (Wu et al., 2010).

3 SECURITY GOALS

The adoption of Cloud storage can result in

improvements to security of the data held,

particularly where the storage service used is

provided by a commercial Cloud service provider

since, whilst management of the data is important to

the owner, this activity will not normally be the

owner’s principal activity. In contrast, managing data

is central to the activities of a commercial Cloud

storage service provider and it is consequently to be

expected that such a provider will implement stronger

and more recent security technologies than the data

owner (Ryan, 2013). At the same time, adoption of

Cloud storage brings some additional issues arising

from data being stored on internet connected shared

hardware.

The widely accepted security goals of

confidentiality, integrity and availability, commonly

referred to as CIA have been extended to include non

repudiation, authenticity and reliability (ISECT,

2014a; CSA, 2013b; ISO/IEC, 2016). The

implementation of a secure service requires policies,

procedures and control in addition to technical

measures to keep user data safe (Brock and

Goscinski, 2010, Firesmith, 2004; Takabi et al., 2010;

Zeiss and Lekkas, 2012). This is a continuous process

involving both policy implantation and technical

measures (Firesmith, 2004; Brock and Goscinski,

2010; Tkabi et al., 2010; Zissis and Lekkas, 2012;

Mapp et al., 2014) to meet the following goals:

• Ensuring confidentiality. Data must be handled

correctly to prevent unauthorised exposure and

ensure only those intended are able to gain access to

the data through the application of access,

authentication and authorisation controls to ensure

access to data is only permitted to verified users with

the necessary permissions (Vrable et al., 2012; Mapp

et al., 2014; El Booz et al., 2016).

• Integrity checks. It is important that when users

retrieve data which has been stored, they receive their

data back unchanged from when it was stored. It is

therefore necessary for storage service providers to

implement integrity tests to ensure they are able to

detect when data have been altered. A common

approach is to use a hash or checksum from the

contents of units of data. Generation of these

checksums is often combined with the encryption of

data where this is used in connection with ensuring

confidentiality (Bowers et al., 2009; Yao et al., 2010).

• Maintaining availability. Although users need

assurance that their data is safely stored and protected

from unauthorised access, they also need timely

access to their data. Hence, it is important for the

service provider to ensure (server side) availability by

ensuring the service is protected from both physical

failures such as power failures and network

disruption, and logical issues such as denial of service

attacks as a result of malicious attacks. Storage

providers have a variety of measures available to

ensure continued availability, including mirroring of

data in multiple clouds (Firesmith, 2004; Mapp et al.,

2014; Takabi et al. 2010).

• Non repudiation of data. Attribution or

provenance of data enables owners and other users to

be confident that data cannot be disputed, including

preventing a recipient from denying data have been

received and is necessary in transactional interactions

(Firesmith, 2004).

• Preserving authenticity. Data authenticity is

concerned with its original creation by its author and

ensuring that it has not suffered subsequent alteration.

For example, when a document includes a digital

signature, anyone using the document can use the

signature to establish that the content and form of the

document they have is unchanged from that created

by the original writer (Brock and Goscinski, 2010;

Zissis and Lekkas, 2012).

• Reliability of service provider. Service provider

reliability is related to maintenance of availability but

is also concerned with wider issues of the ability of

the service provider to provide the offered (or

intended) service consistently. In addition to

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

308

provision of satisfactory availability, the service

provider needs to have proper procedures and

mechanisms such as logging, monitoring and version

controls to ensure smooth running of their services

and contingencies to handle exceptional events.

There are International and Industry Standards

and Best Practice guidelines which have been widely

adopted by major Cloud service providers including

Amazon, Oracle, RedHat and Salesforce (CSA, 2013;

NIST, 2013a; ISECT, 2014b; ISO/IEC, 2016;

ENISA, 2009; CPNI, 2014a; ASD, 2014b). A

summary of these is given in Table 1.

Table 1: Summary of International and Industry Security

Standards, Guidelines and Best Practice.

Goals

CSA

NIST

ISECT

ENISA

CPNI

ASD

√

* C – Confidentiality, I – Integrity, Av – Availability,

N – Non-repudiation, At – Authenticity, R – Reliability

4 CLASSIFICATION OF

THREATS

In the context of computer system security, a

vulnerability is a weakness of the system which may

be exploited to achieve unauthorised access or other

harm to the system. Alone a vulnerability is not a

problem so long as it is undetected or remains

unknown to potential attackers. However,

vulnerabilities need to be addressed as, once potential

attackers are able to identify them and discover how

to exploit them, possibly in combination with others,

they become a threat. Vulnerabilities can include all

weaknesses of system which permit disruption of the

system by misleading users, phishing, triggering

incorrect system behaviour by introduction of false

information or denial of service attacks as well as

more “traditional” weaknesses such as weak or

ineffective passwords, session hijacking and

interception or alteration of data in transit (Chang and

Ramachandran, 2016; Wang et al., 2010; Sabahi,

2011; CSA, 2013a). A threat model enables

designers to estimate risks from attackers.

Recognised threat analysis techniques include

DREAD and STRIDE (Swiderski and Snyder, 2004)

but these only provide industry best practice or

standards which generally need adjustment or

enhancement to fit particular systems (Myagmar et

al., 2005).

For this study, threats were modelled using a three

step process (Myagmar, 2005), characterising the

system, identifying system assets and identifying

system concerns as described in the following

sections.

4.1 Characterising the System

A cloud storage system has three participants: the

users, the clouds and the storage provider(s)

(Gruschka and Jensen, 2010). Interactions between

these participants take place at the two interfaces

between them. It involves with three steps as follows.

Firstly, users are authenticated and get access to their

respective Cloud storage. Secondly, they can send

commands and messages to Cloud Storage and

execute commands, such as uploading files. Thirdly,

service provider can receive commands and messages

from users and store files. These three steps can be

done seamlessly within seconds. Examples of

interactions include a user requesting a service or a

service requesting additional storage from the service

provider. Attacks may be analysed by examining the

interactions between the elements of this model.

4.2 Identifying System Assets

Each of the system participants offers a particular

interface to the others which may all be subject to

attacks as follows, see Figure 1.

user-to-service user-to-cloud

service-to-user cloud-to-user

service-to-cloud cloud-to-service

Figure 1: Inter-participant interfaces.

• Service to user. Provided by the server, this layer

is subject to different types of attacks, including

account hijacking, SQL Injection and privilege

escalation (CSA, 2013b).

• User to service. Threats to this interface involve

user programmes requesting services, including

browser malware or phishing based attacks

(Marlinspike, 2009; CSA, 2013b).

A Security Framework to Protect Data in Cloud Storage

309

• Cloud to service. Although the separation

between the service instance and the cloud provider

may not always be clear, threats to this interface

include exhaustion attacks directed at triggering the

provider to provide excess resources or attacks on the

system hypervisor (CSA, 2013b).

• Service to cloud. All kinds of attack against

Cloud systems by services, including privacy related

attacks and tampering with data.

• User to cloud and Cloud to user. These include

all kinds of attack which may be made by the user

against the cloud provider, which may include

inducing users to delete data, phishing based attacks

or presentation of falsified usage accounts.

4.3 Identifying System Concerns

Many concerns may arise from within or outside the

system from authorised users, others who masquerade

as genuine users or have managed to bypass security

mechanisms (Myagmar et al., 2005). Others arise

from innocent errors or external factors such as severe

weather or other natural disasters. The goal is to

establish risks to the system based on the information

gathered.

Each threat is the damage an adversary may inflict

on the system (Swiderski and Snyder, 2004) which

may be described as the capability of the adversary.

A reasonable start to threat modelling is known

system concerns and vulnerabilities. Each of these

then needs to be considered carefully to in the context

of the quality and suitability to the system. There are

fourteen security concerns and factors worth to be

investigated (Gruschka and Jensen, 2010; Shaikh and

Haider, 2011; CSA, 2013a; GTISC and GTRI, 2013).

They are presented in Table 2 and Table 3, so that

threat classification can be compared in details.

Each security factor may be mapped to security

concerns showing the potential effects of each on the

system. This shows security factors and concerns

using the CSA Control Matrix (CSA, 2013 a, 2013 b),

to which reliability has been added as an additional

factor.

In this work, STRIDE has been used it matches

the results of the threat identification process. In

general, threats fall into six types or classes

depending on their effect (Swiderski and Snyder,

2004). They are:

1. Spoofing – Using false credentials to gain

access to protected assets.

2. Tampering – Mounting an attack by changing

data.

3. Repudiation – Denying having taken actions in

circumstances where the target is unable to

prove otherwise.

4. Information Disclosure – Unauthorised release

of data.

5. Denial of Service – Actions which reduce the

ability of legitimate users to access resources

6. Elevation of Privilege – Exploitation by users

able to gain access to system features reserved

for others.

In defining a threat model, the modeller defines

attacks and prioritises them. Using a risk assessment,

each threat is given a priority and mapped to a

mitigation mechanism. With the concerns identified,

the security factors have been identified as shown in

Table 2 and Table 3.

Table 2: Threat classification with STRIDE threat

modelling.

Threat Classification

STRIDE Threat

Modelling

Data Breach

√

Data Leakage and loss

√

Insecure APIs

√

Account hijacking

√

Denial of Service

√

Malicious insiders

√

Inadequate cloud

planning

√

Cloud related malware

√

Closure of cloud

service

√

Shared technology

vulnerabilities

√

Insufficient due

diligence

√

* S –Spoofing identity, T – Tampering with data,

R – Repudiation, I- Information disclosure, D – Denial of

Service, E – Elevation of privilege

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

310

Table 3: Threat classification with security factors.

Threat

Classification

Security Factors

Data Breach

√

Data Leakage and

loss

√

Insecure APIs

√

Account hijacking

√

Denial of Service

√

Abuse of cloud

planning

√

Inadequate cloud

planning

√

Cloud related

malware

√

Closure of cloud

service

√

Natural disaster

√

Hardware failure

√

Shared technology

vulnerabilities

√

* C – Confidentiality, I – Integrity, Av – Availability,

N – Non-repudiation, At – Authenticity, R – Reliability

5 (DEVELOPMENT OF) CLOUD

STORAGE SECURITY

FRAMEWORK (CSSF)

This section proposes a security framework for Cloud

storage. As already indicated, there is little existing

work concerned specifically with factors affecting

security or to investigate appropriate frameworks for

Cloud storage. This section proposes an appropriate

framework together which the process used in its

development. An outline of the process is given in

Figure 2.

5.1 Framework Development Process

An initial review revealed that, despite the great

growth in use of Cloud based storage, there is very

little existing work concerned specifically with Cloud

Storage security. Hence the development of the

framework proposed here which seeks to identify

security factors and concerns in Cloud storage.

5.2 Listing Unique Factors

Factors were identified from a review of existing

work on security frameworks for Cloud computing in

general and Cloud storage in particular as described

above. The factors identified from Cloud Security

research are presented as follows (Catteddu and

Hogben, 2009; CSA, 2013b; NIST, 2013a; ASD,

2014b; ISO/IEC, 2016). Firstly, confidentiality, it

refers to whether data is unavailable to the

unauthorised entities. Secondly, integrity, it measures

whether data is complete and accurate. Thirdly,

availability, it is focused on whether data can be

accessed and used on demand for the authorised

entity. Fourthly, non-repudiation, it deals with the

ability to validate the occurrence of a claimed event

and its originating entities. Fifthly, authenticity, it

means if data is original as it claims. Lastly,

reliability, it refers to the ability to demonstrate

consistent results. To accommodate these six factors,

Table 4 lists a further seven factors identified from

secure Cloud Storage research. In all, a total of 13

goal driven factors and 20 potential characteristics

were identified.

Figure 2: Development of the Cloud Storage Security

Framework (CSSF).

5.3 Grouping Factors with Similar

Meanings

Following completion of Section 5.3 and Table 4,

each of the factors revealed were considered for

inclusion in the final framework. This involved

consideration of whether a factor is unique to its area

or whether it could be mapped to a factor, or a

combination of factors in the other area as well as

consideration of the extent to which the factor is

relevant and important in the context of Cloud

Cloud Storage Security

Confidentiality factor

Integrity factor

Availability factor

Non Repudiation factor

Authenticity factor

Reliability factor

Group Factors with similar

meaning

Unique factors

Direct mapping factors

A Security Framework to Protect Data in Cloud Storage

311

storage. With this comparison completed, there

remain seven distinct factors which are included in

the final framework.

5.4 The Proposed Cloud Storage

Security Framework

The final Cloud Security Storage Framework (CSSF)

is presented as follows. Firstly, Cloud Storage

Security, since its policies and security procedures are

important. Secondly, confidentiality, it deals with

users’ identification and authorisation for accessing

data. Thirdly, integrity, it specialises in accurate

ownership and encryption of data. Fourthly,

availability, it deals with up-to-date available and

accessibility of data. Fifthly, non-repudiation, it is

focused on accurate time stamping of accessed data

with right user signature. Sixthly, authenticity, it

checks data upon authentication and synchronised

data in the storage. Lastly, reliability, it presents

consistency and validity of Cloud service.

CSSF framework can also work together with

other framework such as Cloud Computing Adoption

Framework (CCAF) to ensure all the services are

valid and data can be protected in real-time. Chang et

al (2016) present CCAF, which designs and develop

Cloud services. The security is based on multi-

layered security as follows. Firstly, firewall and

authentication to execute all the seven factors in

CSSF. The second layer is based on the intrusion

detection and prevention system to minimise the

impacts of security. The third layer is on encryption

and its main purpose is to identify any comprised and

disguised data mixed with real and validated data.

Petabytes of data were in the data centre. Real-time

largescale tests were conducted. Results showed that

CCAF can protect more than 99% of data under the

intensive penetration tests. In this case, CSSF

provides guidelines and important foundation to build

up the first layer of defence to make Cloud Storage

more robust and resilient. Case studies from

organisations that adopt our recommendations can be

presented to illustrate the positive impacts and

research contributions offered by the blended

approach. Therefore, getting two frameworks to work

together can provide better security services for users.

Table 4: Factors from secure cloud storage research.

Security Factors

Characteristics/Elements

Sources

Cloud Storage Security

Security policy, security procedure

Firesmith, 2004; Brock and Goscinshki,

2010; Takabi et al., 2010; Zissis and

Lekkas, 2012; Mapp et al., 2014

Ensuring

Confidentiality

Identification of Cloud storage user,

authorisation to access data

Bessani et al., 2011; Kamara et al., 2011;

Popa et al., 2011; Stefanov and Dijik,

2012; Zhou et al., 2013; Yao et al., 2013;

Mapp et al., 2014; Tawalbeh et al., 2015;

Vu at al., 2015; El-Booz et al., 2016

Integrity Checks on

Remote Data

Accurate ownership of data,

encryption of data

AlZain et al., 2011; Bessani et al., 2011;

Kamara et al., 2011; Mahajan et al.,

2011; Napal et al., 2011; Vrable et al.,

2012; Mu et al., 2012; Stefanov and

Dijik, 2012; Wang et al., 2013; Ahou et

al., 2013; Tawalbeh et al., 2015; El-Booz

et al., 2016.

Maintaining

Availability

Access to data, up-to-data available

data

ALZain, et al., 2011; Bessani et al.,

2011; Mahajan et al., 2011; Popa et al.,

2011; Mu et al., 2012; Stefanov and

Dijik, 2012; Mapp et al., 2014; Vu et al.,

2015.

Guaranteeing

Non-repudiation to

Data

Accurate time-stamping of accessed

data, assurance with user signature

Wang et al., 2013; Tawalbeh et al.,

2015; El-Booz et al., 2016.

Preserving

Authenticity

Verified data based on authentication,

synchronised data in storage

Yao et al., 2013; Mapp et al., 2014; Vu

et al., 2015; El-Booz et al., 2016.

Reliability of Service

Provider

Consistency of Cloud service, valid

service

Bessani et al., 2011; Mahajan et al.,

2011; Stefanov and Dijik, 2012; Mapp et

al., 2015, Vu et al., 2015.

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

312

6 CONCLUSIONS

With recent improvements to the availability,

reliability and bandwidth of internet connections,

Cloud computing has become a viable and highly

attractive alternative to conventional computing for

both individuals and business enabling users to pay

only for the facilities they need whilst retaining

flexibility to buy extra resources when required.

However, along with the cost and accessibility

advantages, using Cloud based data storage services

brings with it concerns about safety and security of

valuable and potentially sensitive data (Zissis and

Lekkas, 2012) and there are regular reports of security

breaches of poorly secured Cloud. Efforts are being

made by the service providers to address the problem.

However, whilst there exist frameworks and industry

standards and best practices for generic Cloud

services, there has been very little work directed at

understanding issues and challenges specific to the

provision of Cloud storage services.

This paper has described work to identify factors

relevant to security of Cloud storage by considering

existing work on security, Cloud security in general

and Cloud storage in particular. Having analysed the

resulting factors and items for distinct element,

common themes and duplication, the results

presented as the framework given in Section 5. The

joint work with CCAF can produce a greater impact

and more validated research contributions, so that

users and data can be protected in real-time. Future

work may also include integration with other

frameworks to demonstrate that our work can provide

not only recommendation and guidelines, but also the

real examples and case studies of building secure

services.

REFERENCES

AlZain, M. A., Soh, B., and Pardede, E., 2011. MCDB:

Using Multi-Clouds to Ensure Security in Cloud

Computing. Proceedings - IEEE 9th International

Conference on Dependable, Autonomic and Secure

Computing, DASC 2011, 784–791.

Bessani, A., Correia, M., Quaresma, B., Andre, F., and

Sousa, P., 2011. DEPSKY: Dependable and Secure

Storage in a Cloud-of-Clouds. In: EuroSys’11 -

Architecture. 31–45.

Bowers, K. D., Juels, A., and Oprea, A., 2009. HAIL: A

High-Availability and Integrity Layer for Cloud

Storage. In: CCS. 187–198.

Brock, M. and Goscinski, A., 2010. Toward a Framework

for Cloud Security. In: Lecture Notes in Computer

Science. Springer Berlin Heidelberg, 254–263.

Catteddu, D., and Hogben, G. (2009). Cloud computing risk

assessment. European Network and Information

Security Agency (ENISA), 583-592.

Chang, V., and Ramachandran, M. 2016. Towards

achieving data security with the cloud computing

adoption framework. IEEE Trans. Services Computing,

9(1), 138-151.

CPNI, 2014b. Reducing the Cyber Risk in 10 Critical Areas

White Paper [online]. Centre for the Protection of

National Infrastructure (CPNI). Available from:

https://www.gov.uk/government/uploads/system/uploa

ds/attachment_data/file/395716/10_

steps_ten_critical_areas.pdf pdf [Accessed 22 Dec

2018].

CSA, 2013a. Cloud Computing Vulnerability Incidents: A

Statistical Overview Report [online]. Cloud Security

Alliance (CSA). Available from:

https://cloudsecurityalliance.org/download/cloud-

computing-vulnerability-incidents-a- statistical-

overview/ [Accessed 22 Dec 2018].

CSA, 2013b. The Notorious Nine: Cloud Computing Top

Threats in 2013 Report [online]. Cloud Security

Alliance (CSA). Available from:

https://downloads.cloudsecurityalliance.org/initiatives/

top_threats/The_Notorious_Nine_Cl

oud_Computing_Top_Threats_in_2013.pdf [Accessed

22 Dec 2018].

El-Booz, S. A., Attiya, G., & El-Fishawy, N. 2016. A secure

cloud storage system combining time-based one-time

password and automatic blocker protocol. EURASIP

Journal on Information Security, 2016(1), 13.

ENISA, 2009. Glossary — ENISA [online].

Available from:

http://www.enisa.europa.eu/activities/risk-

management/current-risk/risk-management-

inventory/glossary pdf [Accessed 22 Dec 2018].

Firesmith, D., 2004. Specifying Reusable Security

Requirements. Journal of Object Technology, 3 (1), 61–

75.

Gartner, 2012. Newsroom: Consumers Will Store More

Than a Third of Their Digital Content in the Cloud by

2016.

GTISC and GTRI, 2013. Emerging Cyber Threats Report

2014 [online]. Georgia Tech Information Security

Center (GTISC) and Georgia Tech Research Institute

(GTRI), Georgia Tech Cyber Security Summit 2013.

Available:

https://www.gtisc.gatech.edu/pdf/Threats_Report_201

4.pdf [Accessed 22 Dec 2018].

Gruschka, N. and Jensen, M., 2010. Attack Surfaces: A

Taxonomy for Attacks on Cloud Services. 2010 IEEE

3rd International Conference on Cloud Computing,

276–279.

Honan, M., 2012. Kill the Password: Why a String of

Characters Can’t Protect Us Anymore. WIRED, 9–16.

ISECT, 2014a. ISO / IEC 27017 — Information technology

— Security techniques — Code of practice for

information security controls based on ISO / IEC 27002

for cloud services (DRAFT ), 3–5.

A Security Framework to Protect Data in Cloud Storage

313

ISECT, 2014b. ISO / IEC 27018 : 2014 — Information

technology — Security techniques — Code of practice

for protection of Personally Identifiable Information (

PII ) in public clouds acting as PII processors, 27001–

27003.

ISO/IEC, 2016. ISO/IEC 27000:2016(en), Information

technology — Security techniques — Information

security management systems — Overview and

vocabulary [online]. Available from:

https://www.iso.org/obp/ui/#iso:std:iso-iec:27000:ed-

4:v1:en [Accessed 1 Jan 2019].

Mapp, G., Aiash, M., Ondiege, B., and Clarke, M., 2014.

Exploring a New Security Framework for Cloud

Storage Using Capabilities. In Proceedings - IEEE 8th

International Symposium on Service Oriented System

Engineering (SOSE), 484–489.

Marlinspike, M., 2009. More Tricks For Defeating SSL In

Practice. Black Hat USA.

Mell, P. and Grance, T., 2009. The NIST Definition of

Cloud Computing. National Institute of Standards and

Technology, 53 (6).

Merkle, R. C., 1988. A Digital Signature Based on a

Conventional Encryption Function. Crypto, 10.

Mertens, D. M., 2010. Publishing Mixed Methods

Research. Journal of Mixed Methods Research, 5, 3–6.

Miller, R., 2013. How Dropbox Stores Stuff for 200 Million

Users. Data Center Knowledge, 2013–2016.

Myagmar, S., Lee, A. J., and Yurcik, W., 2005. Threat

Modeling as a Basis for Security Requirements. In

Proceedings of the 2005 ACM Workshop on Storage

Security and Survivability (StorageSS ’05), 94–102.

NIST, 2013a. Security and Privacy Controls for Federal

Information Systems and Organizations. National

Institute of Standards and Technology (NIST) Special

Publication 800-53 Revision 4.

Popa, R. A., Lorch, J. R., Molnar, D., Wang, H. J., &

Zhuang, L. 2011, June. Enabling Security in Cloud

Storage SLAs with CloudProof. In USENIX Annual

Technical Conference (Vol. 242, pp. 355-368).

Ryan, M. D., 2013. Cloud Computing Security: The

Scientific Challenge, and a Survey of Solutions. Journal

of Systems and Software, 86 (9), 2263–2268.

Satran, J., Meth, K., Sapuntzakis, C., and Chadalapaka, M.,

2004. Internet Small Computer Systems Interface

(iSCSI) [online]. Available from:

http://www.ietf.org/rfc/rfc3720.txt [Accessed 5 Jan

2019].

Shaikh, F. B. and Haider, S., 2011. Security Threats in

Cloud Computing. 6th International Conference on

Internet Technology and Secured Transactions, Abu

Dhabi, UAE, (December), 11–14

Stefanov, E., van Dijik, M., Juels, A., & Oprea, A., 2012,

December. Iris: A scalable cloud file system with

efficient integrity checks. In Proceedings of the 28th

Annual Computer Security Applications Conference

(pp. 229-238). ACM.

Swiderski, F. and Snyder, W., 2004. Threat Modeling.

Microsoft Press.

Tabachnick, B. G. and Fidell, L. S., 2007. Multivariate

Analysis of Variance and Covariance. Using

Multivariate Statistics, 3, 402–407.

Tawalbeh, O., Darwazeh, N. S., Al-Qassas, R. S., &

AlDosari, F. (2015). A secure cloud computing model

based on data classification. Procedia Computer

Science, 52, 1153-1158.

Vaquero, L. M., Rodero-Merino, L., Caceras, J., and

Lindner, M., 2009. A Break in the Clouds: Towards a

Cloud Definition. ACM SIGCOMM Computer

Communication Review, 39 (1), 50–55.

Vrable, M., Savage, S., and Voelker, G. M. G., 2012.

Bluesky: A Cloud-Backed File System for

the Enterprise. Fast ’12 [online], 19. Available from:

http://cseweb.ucsd.edu/~voelker/pubs/blueskyfast12.pdf%

5Cnhttp://static.usenix.org/event/fast12/tech/full_pape

rs/Vrable.pdf%5Cnhttp://

dl.acm.org/citation.cfm?id=2208461.2208480.

Vu, Q. H., Colombo, M., Asal, R., Sajjad, A., El-Moussa,

F. A., and Dimitrakos, T., 2015. Secure Cloud Storage:

A Framework for Data Protection as a Service in the

Multi-Cloud Environment. 2015 IEEE Conference on

Communications and NetworkSecurity, CNS 2015,

638–642.

Weiss, A., 2007. Computing in the Clouds. netWorker

Magazine - Cloud computing: PC functions move onto

the web, (Volume II, Issue 4), 16–25.

Wu, J., Ping, L., Ge, X., Ya, W., and Fu, J., 2010. Cloud

storage as the Infrastructure of Cloud Computing. In:

Proceedings - 2010 International Conference on

Intelligent Computing and Cognitive Informatics,

ICICCI 2010. 380–383.

Yao, C., Xu, L., and Huang, X., 2013. A Secure Cloud

Storage System from Threshold Encryption.

Proceedings - 5th International Conference on

Intelligent Networking and Collaborative Systems,

INCoS 2013, 541–545.

Zhao, R. and Yue, C., 2014. Toward a Secure and Usable

Cloud-Based Password Manager for Web Browsers.

Computers & Security, 46, 32–47.

Zhou, L., Varadharajan, V., and Hitchens, M., 2013.

Achieving Secure Role-Based Access Control on

Encrypted Data in Cloud Storage. Information

Forensics and Security, IEEE Transactions on, 8 (12),

1947–1960.

Zikmund, W., Babin, B., Carr, J., and Griffin, M., 2012.

Business Research Methods. 9th ed. Cengage Learning.

Zissis, D. and Lekkas, D., 2012. Addressing Cloud

Computing Security Issues. Future Generation

Computer Systems, 28 (3), 583–592.

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

314
