Big Data Preprocessing as the Bridge between Big Data and Smart Data:

BigDaPSpark and BigDaPFlink Libraries

Diego Garc

ıa-Gil, Alejandro Alcalde-Barros, Juli

an Luengo, Salvador Garc

ıa and Francisco Herrera

Departamento de Ciencias de la Computaci

on e Inteligencia Artiﬁcial, Universidad de Granada, Granada, 18071, Spain

Keywords:

Big Data, Apache Spark, Data Preprocessing, Smart Data, Imbalanced, Classiﬁcation.

Abstract:

With the advent of Big Data, terabytes of data are generated and stored every second. This raw data is far from

being perfect, it contains many imperfections (noise, missing values, etc.) and is not suitable for analysis,

as it will led to wrong conclusions. Data preprocessing is the set of techniques devoted to polish, clean,

ﬁx, and improve that raw data. With this preprocessed data, we would be able to ﬁnd more patterns in it,

and to better explain the underlaying distribution of the data. This is what is called Smart Data, raw data

that has been preprocessed and is ready for being analyzed, data that contains valuable information that will

led to knowledge. In this work, we present two Big Data libraries for achieving Smart Data from Big Data,

BigDaPSpark and BigDaPFlink. They are built on top of two Big Data frameworks, Apache Spark and Apache

Flink. Both libraries contain a series of algorithms for Big Data preprocessing, ranging from noise cleaning,

to discretization, or data reduction, among many others. Additionally, we ilustrate the usage of the libraries

with two cases of use.

1 INTRODUCTION

In the Big Data era, the lack of human supervision,

and the automation in the data obtaining and storing

process have led to the acceptance that data will be

of low quality due to the presence of imperfections,

redundancies or inconsistencies, among other perni-

cious traits. These imperfections can be produced by

sensors failing, anomalous situations, or exogenous

factors, among others. Low quality in data can make

impossible the later learning process. The set of tech-

niques devoted to tackle those imperfections, and to

improve the quality of the data are known as Big Data

preprocessing (Garc

ıa et al., 2014). There are dif-

ferent families of Big Data preprocessing algorithms,

being the most widely used the data reduction tech-

niques, imperfect data methods, and imbalance data

handling. The term Smart Data (Iafrate, 2014) is used

to refer to the challenging process of transforming

that raw and low quality Big Data, into data that is

suitable for the posterior data mining or knowledge

extraction process. Therefore, achieving Smart Data

stands as the challenge of extracting useful informa-

tion from Big Data.

In the Big Data environment, we can ﬁnd a set

of frameworks devoted to work with that raw data.

Apache Spark is the most popular framework for

static Big Data processing. On the other hand,

Apache Flink (Garc

ıa-Gil et al., 2017) is focused on

online data streaming processing. Although both of

them include a library for machine learning, their

functionality for data preprocessing is very limited,

as they only include a few classic and basic algo-

rithms. This lack of Big Data preprocessing algo-

rithms, makes the step from Big Data to Smart Data

an even more challenging task.

In this paper, we introduce two Big Data pre-

processing libraries, BigDaPSpark and BigDaPFlink,

with all the latest algorithms for data preprocessing in

Big Data. Most of them are new proposals for Big

Data, while others are distributed and parallel ver-

sions of existing algorithms. These algorithms rep-

resent the state-of-the-art in Big Data preprocessing.

BigDaPSpark is focused on static data preprocessing,

built on top of Apache Spark. On the other hand, Big-

DaPFlink is oriented to online data preprocessing for

Apache Flink.

We have carried out a case of study as a sam-

ple of the use of the libraries. A noise ﬁltering al-

gorithm from BigDaPSpark have been tested using

SUSY dataset (5,000,000 instances & 18 attributes).

For BigDaPFlink, a discretization algorithm is se-

lected with ht sensor dataset (929,000 instances & 11

attributes).

324

García-Gil, D., Alcalde-Barros, A., Luengo, J., García, S. and Herrera, F.

Big Data Preprocessing as the Bridge between Big Data and Smart Data: BigDaPSpark and BigDaPFlink Libraries.

DOI: 10.5220/0007738503240331

In Proceedings of the 4th International Conference on Internet of Things, Big Data and Security (IoTBDS 2019), pages 324-331

ISBN: 978-989-758-369-8

The rest of the paper is organized as follows: Sec-

tion 2 introduces the concepts of data reduction, im-

perfect data and imbalanced learning, and describes

two existing Big Data libraries, MLlib and FlinkML.

Section 3 depicts our proposal, two Big Data libraries

for Big Data Preprocessing, one for Apache Spark, for

batch data preprocessing, and other in Apache Flink,

for data streaming preprocessing. Section 4 shows

two cases of use of the libraries. Finally, Section 5

concludes the paper.

2 BACKGROUND

In this section, we describe the most popular families

of data preprocessing algorithms: data reduction in

Section 2.1, imperfect data in Section 2.2, and imbal-

ance learning in Section 2.3. Finally, we provide an

insight into the Big Data libraries MLlib and FlinkML

in Section 2.4.

2.1 Data Reduction

Data Reduction is the set of techniques devoted to re-

duce the size of the original data, retaining as much

information as possible. These techniques not only

aim at obtaining a reduced set of the original data,

but also achieve a lower space requirement version of

the dataset. These reduced version of the datasets are

achieved by removing noisy instances, redundant and

irrelevant data that will led the learner to learn faster

and on a better quality data.

There are three different ways of performing data

reduction. Feature Selection (FS) methods and fea-

ture extraction techniques select the most relevant set

of features, or construct a new one. From the in-

stances point of view, we can differentiate between

Instance Selection (IS) methods (Garcia et al., 2012),

and Prototype Generation (PG) methods (Triguero

et al., 2012). The goal of an IS method is to obtain

a subset of the original data S, such that S does not

contain noisy, redundant or irrelevant instances, and

that the accuracy of the original data and the reduced

set is similar. On the other hand, PG methods can

generate artiﬁcial data points if necessary for a better

representation of the original data. As stated previ-

ously, the objective of data reduction methods is not

to just obtain a smaller version of the dataset.

The third way of performing data reduction is

through discretization. Discretization is the process of

transforming continuous values into categorical ones.

In other words, it transforms numerical attributes into

discrete ones, with a ﬁnite number of values (or inter-

vals). The objective is to reduce the complexity of the

data, and/or to remove outliers, as they will fall into

one of the top or bottom intervals.

2.2 Imperfect Data

Automation in data acquisition and the lack of manual

supervision entails that data can be imperfect. This

can be even more severe as the number of instances

and attributes grow (Fan et al., 2014). Although most

techniques and algorithms presume that the data is ac-

curate, data in the real world can be redundant or in-

consistent. Data can contain imperfections that will

disrupt the learning process if it is not taken into con-

sideration. These alterations can be caused by many

factors, but one of the most common are the presence

of noise and missing values (MVs).

Noise is an external process that changes or al-

ters the values of the attributes or classes of the in-

stances(Wu and Zhu, 2008). It leads to excessively

complex models with deteriorated performance. It

displaces or removes instances located in key areas

within a concrete class or can even disrupt the bound-

aries of the classes resulting in an increased bound-

aries overlap. Alleviating the effects of noise suppose

the identiﬁcation of noisy instances and their removal

or relabelling.

Another alteration present in the data is the pres-

ence of MVs. MVs deserve a special attention as it

has a critical impact in the learning process, as most

learners suppose that the data is complete. One simple

technique is to discard the MVs, but this can lead to

poor performance due to the elimination of informa-

tion. There are mechanisms in the literature to impute

(ﬁll-in) these MVs following some statistical proce-

dures.

2.3 Imbalanced Learning

Among different classiﬁcation scenarios, class imbal-

ance occurs when there is an uneven representation

of instances for the different classes. In the case of

binary classiﬁcation, if one class is over-represented

against the other, the classiﬁer will tend to focus on

the majority class. In some cases with extreme im-

balance, the minority class can be completely ignored

by the classiﬁers. For this reason, numerous efforts

have been carried out for correcting this imbalance

(Fern

andez et al., 2018).

We can categorize them in three categories: data

level approaches that rebalance the dataset, algorith-

mic level approaches that adapt the learning process

towards the minority classes, and cost-sensitive solu-

tions that adapt the cost with respect to the different

classes.

Big Data Preprocessing as the Bridge between Big Data and Smart Data: BigDaPSpark and BigDaPFlink Libraries

325

2.4 MLlib & FlinkML

Apache Spark and Apache Flink are two of the most

popular Big Data frameworks. The former is focused

on static data processing, while the second is oriented

to online data streaming. Both of them include a

Big Data library for machine learning with basic al-

gorithms for data preprocessing, namely MLlib for

Apache Spark, and FlinkML for Apache Flink.

MLlib is a very powerful machine learning library

built on top of Apache Spark (Meng et al., 2016). It

is prepared for working with huge amounts of data. It

is composed of two separated packages:

• mllib: the ﬁrst API of the library. It is built on top

of RDDs. In the future it will be replaced by the

new ml API.

• ml: the latest addition to the library. It is built on

top of DataFrames and DataSets and enables the

use of pipelines.

MLlib contains many algorithms devoted to classiﬁ-

cation, regression, clustering, etc. But also includes

some algorithms for data preprocessing, like feature

extraction, transformation, dimensionality reduction,

and selection. Although it may seem that it contains

plenty of algorithms for data preprocessing, it con-

tains only basic algorithms, such as normalizers, data

scalers, Principal Components Analysis or X

for FS,

etc.

FlinkML is a machine learning library focused on

data streaming. It is part of the Apache Flink project.

It contains only three algorithms for data preprocess-

ing, two of them being data scalers.

As we can see, both MLlib and FlinkML have al-

gorithms for data preprocessing, but they only offer a

limited set of them.

3 BIG DATA PREPROCESSING

LIBRARIES

In this section we explain in detail the two Big Data li-

braries for data preprocessing, BigDaPSpark and Big-

DaPFlink. These libraries contains a series of state-

of-the-art algorithms for two Big Data frameworks,

Apache Spark and Apache Flink. These libraries are

born with the objective of improving the Big Data

ecosystem with new algorithms for Big Data prepro-

cessing, in order to achieve Smart Data.

3.1 BigDaPSpark

This library is composed of a series of algorithms

for Big Data preprocessing under the Apache Spark

framework. It contains algorithms for feature se-

lection, discretization, noise ﬁltering, data reduction,

missing values imputation and imbalanced learning,

among others. The library is publicly available in

https://sci2s.ugr.es/BigDaPSpark.

3.1.1 Feature Selection

The library contains a FS framework, imple-

mented in a distributed fashion. It contains

multiple information-theory based FS algorithms,

like mRMR, InfoGain, JMI and other commonly

used FS ﬁlters (Ram

ırez-Gallego et al., 2018b).

It is also available as an Apache Spark pack-

age in https://spark-packages.org/package/sramirez/

spark-infotheoretic-feature-selection

3.1.2 Discretization

The library also contains two distributed and par-

allel discretizers for dealing with huge amounts of

data: A Distributed Evolutionary Multivariate Dis-

cretizer (DEMD) (Ram

ırez-Gallego et al., 2018), and

Minimum Description Length Discretizer (MDLP)

(Ram

ırez-Gallego et al., 2016). Both of these algo-

rithms are also available as Apache Spark packages.

• DEMD is an evolutionary discretizer. It uses bi-

nary chromosomes with a wrapper ﬁtness func-

tion that optimizes the interval selection prob-

lem by compensating two factors: the simple-

ness of the solutions, and the classiﬁcation ac-

curacy. In order to make DEMD able to cope

with huge amounts of data, the evaluation phase

has been distributed, splitting the set of chromo-

somes and the dataset into different partitions.

Then a random cross-evaluation process is per-

formed. It is available as an Apache Spark

package in https://spark-packages.org/package/

sramirez/spark-DEMD-discretizer.

• MDLP is a distributed discretizer that implements

Fayyad’s discretizer (Fayyad and Irani, 1993). It

is based on Minimum Description Length Prin-

ciple for treating non discrete datasets from a

distributed perspective. It supports sparse data,

multi-attribute processing and also is capable of

dealing with attributes with a huge number of

boundary points (<100K boundary points per

attribute). It is available as an Apache Spark

package in https://spark-packages.org/package/

sramirez/spark-MDLP-discretization.

3.1.3 Noise Filtering

This section of the library is composed of two sub-

libraries. The ﬁrst one contains three algorithms

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

326

for removing noise in Big Data datasets: Homoge-

neous Ensemble (HME-BD), Heterogeneous Ensem-

ble (HTE-BD), and ENN-BD. These algorithms are

based on ensembles of classiﬁers, they were origi-

nally proposed in (Garc

ıa-Gil et al., 2019). These al-

gorithms are also available as an Apache Spark pack-

age in https://spark-packages.org/package/djgarcia/

NoiseFramework.

• HME-BD is based on a partitioning scheme of the

dataset. It performs a k-fold of the input data,

splitting the data into k partitions. The test par-

tition is an unique 1kth of the fold, and the train is

the rest of the partition. Then it learns a deep Ran-

dom Forest (a Random Forest with deep trees) in

each fold, using the train partition as input. Once

the learning process is ﬁnished, each of the k mod-

els learned predict the corresponding test partition

of each fold. That way, the models will predict the

data that they didn’t see while they were learned.

The ﬁnal step is to remove the noisy instances.

This is done by a comparison of the original test

labels with the predicted by the learners. If the

labels are different, the instance is considered as

noisy and removed. Finally, all the ﬁltered par-

titions are joined together to compose a dataset

clean of noise.

• HTE-BD shares the same workﬂow as HME-BD,

but instead of using a unique classiﬁer, it uses

three of them. HTE-BD partitions the data per-

forming a k-fold of the input data the same way

as was described in HME-BD. Then it learns a

deep Random Forest, a Logistic Regression and a

1NN. With the predictions of the three models, a

voting strategy is used to determine if an instance

is noisy. There are two strategies available, ma-

jority and consensus. With the former only two

classiﬁers have to agree to take a decision. With

the second, all classiﬁers must agree to consider

an instance as noisy. The ﬁltered partitions are

joined to recompose the dataset without noise.

• ENN-BD is much simpler that the previous two. It

is based on the similarity between instances (Wil-

son, 1972). It performs a kNN (typically k=1 or

k=3) to the input data, and uses that same input

data for prediction. That way, the closest neigh-

bors for each instance are found. In order to

remove the noisy instances, those neighbors are

compared with the instance. If the label of the

neighbors differs from the original, the instance is

removed.

The second part of the noise library consists

of three algorithms for noise ﬁltering based on

kNN (Triguero et al., ): AllKNN BD, NCNEdit BD

and RNG BD. These algorithms are available as an

Apache Spark package in https://spark-packages.org/

package/djgarcia/SmartFiltering

• AllKNN BD: this method shares the same work-

ing scheme as ENN-BD with some exceptions.

Instead of learning a 1NN, it learns several times

kNN with different values of k (typically 1, 3

and 5) (Tomek, 1976). Each iteration it removes

the instances that does not agree with its closest

neighbors. As can be expected, it is a much ag-

gressive noise ﬁlter than ENN-BD, as it applies

kNN repeatedly.

• NCNEdit BD: this algorithm uses the k near-

est centroid neighborhood classiﬁcation rule with

the leave-one-out error estimate (S

anchez et al.,

2003). It discard instances if it is misclassiﬁed

using the kNCN classiﬁcation rule. In the NCN

classiﬁcation rule, the neighborhood is not only

deﬁned by the proximity of prototypes to a given

instance, but also for their symmetrical distribu-

tion around it.

• RNG BD: this noise ﬁlter computes the proximity

graph of the data (S

anchez et al., 1997). Then, all

the graph neighbors of each instance give a vote

for its class. If the label differs from the origi-

nal label, the instance is considered as noise and

removed.

3.1.4 Data Reduction

The library contains four algorithms for perform-

ing data reduction based on the kNN algorithm:

FCNN MR, SSMASFLSDE MR, RMHC MR and

MR DIS. As stated previously, the purpose of these

algorithms is to obtain a reduced set of the origi-

nal data that represents it as perfectly as possible.

Some of these algorithms are implemented using a

distributed framework, named MRPR (Triguero et al.,

2015). This framework enables the use of itera-

tive algorithms in Big Data environments by par-

titioning the input data in several chunks, and ap-

plying the corresponding algorithm independently to

each one of them. After that process is ﬁnished,

all the partitions are joined together using different

strategies. All these algorithms are available as an

Apache Spark Package in https://spark-packages.org/

package/djgarcia/SmartReduction.

• FCNN

MR: this algorithm is one of the most

extended and widely used in data reduction

(Angiulli, 2007). It is an order-independent algo-

rithm, based on the NN rule, to ﬁnd a consistent

subset of the training dataset. It has a quadratic

time complexity in the worst-case. It also have

Big Data Preprocessing as the Bridge between Big Data and Smart Data: BigDaPSpark and BigDaPFlink Libraries

327

showed to scale well on large and multidimen-

sional datasets.

• SSMASFLSDE MR: this algorithm is a hybrid

and evolutionary algorithm composed of two

methods. The ﬁrst one is a steady-state memetic

algorithm (SSMA) (Garc

ıa et al., 2008), that se-

lects the most representative instances of the train-

ing set. While the second one improves this subset

by modifying the values of the selected instances

with a scale factor local search in differential evo-

lution (SFLSDE)(Triguero et al., 2011).

• RMHC MR: Random Mutation Hill Climbing

(RMHC) is a powerful yet simple algorithm for

data reduction (Skalak, 1994). It starts by select-

ing a random sample of the data S. Then it ran-

domly replaces an instance of the sample with one

of the original data S

∗

. Next it uses both samples

to calculate the classiﬁcation accuracy in the com-

plete dataset, using the kNN algorithm. The sam-

ple with the best accuracy is kept for the next it-

eration, were another instance will be substituted.

After a determined number of iteration, the best

sample is chosen.

• MR DIS: is a parallel implementation of the

democratic IS algorithm (Arnaiz-Gonz

alez et al.,

2017). This algorithm applies a classic IS algo-

rithm over an equally partitioned training dataset.

The selected instances receive a vote. After a de-

termined number of rounds, instances with most

votes are removed from the data.

3.1.5 Missing Values Imputation

The library also contains two approaches, a global

and a local implementation, for MVs imputation us-

ing the k-Nearest Neighbor Imputation, k-Nearest

Neighbor - Local Imputation and k-Nearest Neigh-

bor Imputation - Global Imputation. The difference

among them is that the local version takes into ac-

count only the instances that are in the same partition,

and the global version considers all the instances in

the datasets. These algorithms are also available as an

Apache Spark package in https://spark-packages.org/

package/JMailloH/Smart Imputation.

3.1.6 Imbalance Learning

Two popular methods for balancing a dataset are

available in the library: Random UnderSampling

(RUS) and Random OverSampling (ROS) (Batista

et al., 2004). The former balances the dataset ran-

domly removing instances from the majority class un-

til the number of instances for both classes are iden-

tical. This approach works best when there is a high

redundancy in the dataset, and achieves a lighter rep-

resentation of the data storage-wide.

On the other hand, ROS reaches a balance in the

data by replicating randomly instances from the mi-

nority class from the original data, until the number

of instances from both classes is the same (or until a

replication factor is reached). Depending on the pos-

terior learning algorithm, the replication of instances

may lead to overﬁtting.

Both algorithms are available as an Apache Spark

package in https://spark-packages.org/package/

saradelrio/Imb-sampling-ROS and RUS.

3.1.7 Random Discretization and PCA

Classiﬁer

The library also contains a classiﬁer based on prepro-

cessing, named PCARDE (Garc

ıa-Gil et al., 2018).

This classiﬁer is a distributed ensemble method that

performs Random Discretization and Principal Com-

ponents Analysis, both to the input data, and then

joins the two resulting datasets. It is also available as

an Apache Spark package in https://spark-packages.

org/package/djgg/PCARD.

3.2 BigDaPFlink

This library contains six of the most popular and

widely used algorithms for data preprocessing in data

streaming. It is composed of three feature selec-

tion algorithms and three discretization algorithms.

The library is publicly available in https://sci2s.ugr.

es/BigDaPFlink.

3.2.1 Feature Selection

The library contains three of the most popular fea-

ture selection algorithms for data streaming in the lit-

erature: Information Gain, Online Feature Selection

(OFS), and Fast Correlation-Based Filter (FCBF).

• Information Gain is a feature selection algorithm

composed of two steps, an incremental feature

ranking method, and an incremental learning al-

gorithm that can consider a subset of the features

during prediction (Na

ıve Bayes) (Katakis et al.,

2005). First, the conditional entropy with respect

to the class is computed. Then, the information

gain is calculated for each attribute. Finally, once

the algorithm has all the information gains for

each feature, it selects the best N as features.

• OFS is an ε-greedy online feature selection

method based on feature weights generated by an

online classiﬁer (in this case a neural network)

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

328

which makes a trade-off between exploration and

exploitation of features (Wang et al., 2014).

• FCBF is a feature selection algorithm where the

class relevance and the correlation between each

feature pair of features are taken into account (Yu

and Liu, 2003). It is based on information theory,

it uses symmetrical uncertainty to calculate de-

pendencies of features and the class importance.

It starts with the full set of features and, using

a backward selection technique with a sequential

search strategy, it removes all the irrelevant and

redundant features. Finally, it stops when no more

features are left to eliminate.

3.2.2 Discretization

In this section we show the three online discretiza-

tion algorithms for data streaming available in the li-

brary: Incremental Discretization Algorithm (IDA),

Partition Incremental Discretization Algorithm (PiD)

and Local Online Fusion Discretizer (LOFD). Dis-

cretization in data streaming have the challenge of the

concept drift. These three methods tackle it in three

different ways.

• IDA performs an approximate quantile-based dis-

cretization on the entire encountered data stream

to date by keeping a random sample of the data

(Webb, 2014). This sample is then used to calcu-

late the cut points of the dataset. It uses the reser-

voir sampling algorithm to maintain this sample

randomly updated from the entire stream. In IDA

a sample of the data is used because it is not feasi-

ble nor possible to keep the complete data stream

in memory.

• PiD discretizes data streams in an incremental

manner (Gama and Pinto, 2006). The discretiza-

tion process is performed in two steps. The ﬁrst

step discretizes the data using more intervals than

required, keeping some statistics of it. The sec-

ond and ﬁnal step is to use that statistics to create

the ﬁnal discretization. It is constant in time and

space even for inﬁnite streams, as PiD processes

all the streaming examples in a single scan.

• LOFD is a very recent proposal for online data

streaming discretization. It is an online and

self-adaptive discretizer (Ram

ırez-Gallego et al.,

2018a). LOFD is capable of smoothly adapt its

interval limits, reducing the negative impact of

shifts (concept drift), and also to analyze the inter-

val labeling and interaction problems. The inter-

action between the discretizer and the learner al-

gorithm is addressed by providing two alike solu-

tions. LOFD generates an online and self-adaptive

discretization for streaming classiﬁcation whose

objective is to reduce the negative impact of ﬂuc-

tuations in evolving intervals.

4 CASES OF STUDY

In this section we show a real case of use of the two

proposed libraries, BigDaPSpark and BigDaPFlink.

We have selected one algorithm of each library:

HME-BD for noise ﬁltering, and PiD for data stream-

ing discretization. We show how to use them with

snippets of code, and the achieved results.

4.1 HME-BD

As stated previously, HME-BD is a noise ﬁltering

algorithm that removes noisy instances in a dataset.

Here we show how to use the algorithm in a real case

of study. For the dataset we have chosen SUSY dataset

(5,000,000 instances & 18 attributes), present in the

UCI repository (Dheeru and Karra Taniskidou, 2017).

To show the performance of the noise ﬁltering pro-

cess, we have added 4 levels of random noise (5%,

10%, 15% and 20%).

First, the data must be loaded in Apache

Spark. The dataset is required to be in the

RDD[LabeledPoint] format (default format for

Spark’s MLlib).

import or g . a p a c he . s p a r k . m l l i b .

v a l n T r e e s = 100

v a l maxDepth = 10

v a l n P a r t i t i o n s = 4

v a l s e e d = 12345

v a l hme model = new HME BD(

t r a i n i n g D a t a , / / RDD[ L a b e l e d P o i n t ]

nT re e s , / / s i z e o f t h e RFs

n P a r t i t i o n s , / / number o f p a r t i t i o n s

maxDepth , / / d e p t h o f t h e RFs

s e e d ) / / s e e d f o r t h e RFs

v a l hme = hme model . r u n F i l t e r ( )

Once the ﬁltering process is ﬁnished, the algo-

rithm returns a reduced RDD without the noisy in-

stances. Now that the data has been ﬁltered, we can

use the several classiﬁers available in Spark’s MLlib.

Here we show the results using MLlib’s Decision Tree

with an increased depth to 20.

Table 1 shows the accuracy results using SUSY

dataset. As we can see, HME-BD is able to keep al-

most the same accuracy with the increasing levels of

Big Data Preprocessing as the Bridge between Big Data and Smart Data: BigDaPSpark and BigDaPFlink Libraries

329

Table 1: Decision Tree test accuracy.

Dataset Noise (%) Original HME-BD

SUSY 5 79.94 79.99

10 79.15 79.85

15 78.21 79.81

20 77.09 79.71

noise. Also, from 5% of noise onward, HME-BD im-

proves the Original accuracy.

HME-BD also achieves very low runtimes, for

SUSY dataset, it takes 514 seconds to process it.

4.2 PiD

PiD is a discretizer for data streaming. Here we show

an example of the usage of the algorithm. In this case

of study, we are using the ht sensor dataset (929,000

instances & 11 attributes), also present in the UCI

repository. The ﬁrst step it to load the data into Flink’s

DataSet format. Once the data is loaded, the algo-

rithm can be used in the following way.

im p ort com . e l b a u l d e l p r o g r a m a d o r .

v a l p i d = P I D i s c r e t i z e r T r a n s f o r m e r ( )

. s e t A l p h a ( . 1 0 )

. s e t U p d a t e E x a m p l e s ( 5 0 )

. s e t L 1 B i n s ( 5 )

v a l s c a l e r = MinM axSca ler ( )

v a l p i p e l i n e = s c a l e r

. c h a i n T r a n s f o r m e r ( p i d )

p i p e l i n e f i t d a t a S e t

v a l r e s u l t = p i p e l i n e t r a n s f o r m d a t a S e t

The results using the ht sensor dataset with a de-

cision tree as a classiﬁer show that the accuracy im-

proves from a baseline of 70.13% without preprocess-

ing, to a 71.06% using PiD. Regarding computing

times, it takes 118 seconds of computing.

5 CONCLUSIONS

In this work, we have introduced two Big Data

preprocessing libraries. They are built on top of

two Big Data frameworks, one for Apache Spark,

BigDaPSpark, and another for Apache Flink, Big-

DaPFlink. They contain several algorithms for per-

forming data reduction, handling imperfect data, or

dealing with imbalanced data. We plan to expand the

list of available algorithms in the future. With these

algorithms, we have enabled the practitioner to efﬁ-

ciently achieve Smart Data from raw Big Data.

As we have seen, we can ﬁnd a wide spectrum

of techniques for Big Data preprocessing. However,

there is an open challenge related to the combination

and arrangement of these methods in order to achieve

the best possible outcome for a data mining process.

In (Garc

ıa et al., 2016), authors present the most pop-

ular and widely used data preprocessing algorithms,

studying the effects of different arrangements in the

data preprocessing chain. This challenge is even more

complex in Big Data scenarios, where there is a time

restriction. Methods that increase the amount of data

may affect posterior preprocessing techniques, mak-

ing them unable to cope with that amount of data.

This complexity may also be inﬂuenced by the de-

pendency of intermediate results, or the input that a

method requires and the output it provides.

ACKNOWLEDGMENTS

This work is supported by the Spanish National Re-

search Project TIN2017-89517-P.

REFERENCES

Angiulli, F. (2007). Fast nearest neighbor condensation

for large data sets classiﬁcation. IEEE Transactions

on Knowledge and Data Engineering, 19(11):1450–

1464.

Arnaiz-Gonz

alez,

A., Gonz

alez-Rogel, A., D

ıez-Pastor, J.-

F., and L

opez-Nozal, C. (2017). Mr-dis: democratic

instance selection for big data by mapreduce. Progress

in Artiﬁcial Intelligence, 6(3):211–219.

Batista, G. E. A. P. A., Prati, R. C., and Monard, M. C.

(2004). A study of the behavior of several methods for

balancing machine learning training data. SIGKDD

Explor. Newsl., 6(1):20–29.

Dheeru, D. and Karra Taniskidou, E. (2017). UCI machine

learning repository.

Fan, J., Han, F., and Liu, H. (2014). Challenges of big data

analysis. National science review, 1(2):293–314.

Fayyad, U. M. and Irani, K. B. (1993). Multi-interval dis-

cretization of continuous-valued attributes for classiﬁ-

cation learning. In IJCAI, pages 1022–1029.

Fern

andez, A., Garc

ıa, S., Galar, M., Prati, R. C.,

Krawczyk, B., and Herrera, F. (2018). Learning from

Imbalanced Data Sets. Springer Publishing Company.

Gama, J. and Pinto, C. (2006). Discretization from data

streams: applications to histograms and data mining.

In Proceedings of the 2006 ACM symposium on Ap-

plied computing, pages 662–667. ACM.

Garc

ıa, S., Luengo, J., and Herrera, F. (2016). Tutorial on

practical tips of the most inﬂuential data preprocess-

ing algorithms in data mining. Knowledge-Based Sys-

tems, 98:1 – 29.

Garc

ıa, S., Cano, J., and Herrera, F. (2008). A memetic al-

gorithm for evolutionary prototype selection: A scal-

IoTBDS 2019 - 4th International Conference on Internet of Things, Big Data and Security

330

ing up approach. Pattern Recognition, 41(8):2693–

2709.

Garcia, S., Derrac, J., Cano, J., and Herrera, F. (2012).

Prototype selection for nearest neighbor classiﬁcation:

Taxonomy and empirical study. IEEE transactions on

pattern analysis and machine intelligence, 34(3):417–

435.

Garc

ıa, S., Luengo, J., and Herrera, F. (2014). Data Pre-

processing in Data Mining. Springer Publishing Com-

pany, Incorporated.

Garc

ıa-Gil, D., Luengo, J., Garc

ıa, S., and Herrera, F.

(2019). Enabling Smart Data: Noise ﬁltering in Big

Data classiﬁcation. Information Sciences, 479:135 –

152.

Garc

ıa-Gil, D., Ram

ırez-Gallego, S., Garc

ıa, S., and Her-

rera, F. (2017). A comparison on scalability for batch

big data processing on apache spark and apache ﬂink.

Big Data Analytics, 2(1):1.

Garc

ıa-Gil, D., Ram

ırez-Gallego, S., Garc

ıa, S., and

Herrera, F. (2018). Principal Components Analy-

sis Random Discretization Ensemble for Big Data.

Knowledge-Based Systems, 150:166–174.

Iafrate, F. (2014). A Journey from Big Data to Smart Data,

pages 25–33. Springer International Publishing.

Katakis, I., Tsoumakas, G., and Vlahavas, I. (2005). On the

utility of incremental feature selection for the classiﬁ-

cation of textual data streams. In Panhellenic Confer-

ence on Informatics, pages 338–348. Springer.

Meng, X., Bradley, J., Yavuz, B., Sparks, E., Venkataraman,

S., Liu, D., Freeman, J., Tsai, D., Amde, M., Owen,

S., et al. (2016). Mllib: Machine learning in apache

spark. The Journal of Machine Learning Research,

17(1):1235–1241.

Ram

ırez-Gallego, S., Garc

ıa, S., and Herrera, F. (2018a).

Online entropy-based discretization for data stream-

ing classiﬁcation. Future Generation Computer Sys-

tems, 86:59–70.

Ram

ırez-Gallego, S., Garc

ıa, S., Mouri

no-Tal

ın, H.,

Mart

ınez-Rego, D., Bol

on-Canedo, V., Alonso-

Betanzos, A., Ben

ıtez, J. M., and Herrera, F. (2016).

Data discretization: taxonomy and big data challenge.

Wiley Interdisciplinary Reviews: Data Mining and

Knowledge Discovery, 6(1):5–21.

Ram

ırez-Gallego, S., Mouri

no-Tal

ın, H., Mart

ınez-Rego,

D., Bol

on-Canedo, V., Ben

ıtez, J. M., Alonso-

Betanzos, A., and Herrera, F. (2018b). An information

theory-based feature selection framework for big data

under apache spark. IEEE Transactions on Systems,

Man, and Cybernetics: Systems, 48(9):1441–1453.

Ram

ırez-Gallego, S., Garc

ıa, S., Ben

ıtez, J., and Herrera,

F. (2018). A distributed evolutionary multivariate

discretizer for big data processing on apache spark.

Swarm and Evolutionary Computation, 38:240 – 250.

anchez, J., Barandela, R., Marqu

es, A., Alejo, R., and

Badenas, J. (2003). Analysis of new techniques to ob-

tain quality training sets. Pattern Recognition Letters,

24(7):1015 – 1022.

anchez, J., Pla, F., and Ferri, F. (1997). Prototype selec-

tion for the nearest neighbour rule through proximity

graphs. Pattern Recognition Letters, 18(6):507 – 513.

Skalak, D. B. (1994). Prototype and feature selection by

sampling and random mutation hill climbing algo-

rithms. In Machine Learning Proceedings 1994, pages

293–301. Elsevier.

Tomek, I. (1976). An experiment with the edited nearest-

neighbor rule. IEEE Transactions on systems, Man,

and Cybernetics, (6):448–452.

Triguero, I., Derrac, J., Garcia, S., and Herrera, F. (2012). A

taxonomy and experimental study on prototype gener-

ation for nearest neighbor classiﬁcation. IEEE Trans-

actions on Systems, Man, and Cybernetics, Part C

(Applications and Reviews), 42(1):86–100.

Triguero, I., Garc

ıa, S., and Herrera, F. (2011). Differential

evolution for optimizing the positioning of prototypes

in nearest neighbor classiﬁcation. Pattern Recogni-

tion, 44(4):901–916.

Triguero, I., Garc

ıa-Gil, D., Maillo, J., Luengo, J., Garc

ıa,

S., and Herrera, F. Transforming big data into smart

data: An insight on the use of the k-nearest neigh-

bors algorithm to obtain quality data. Wiley Interdis-

ciplinary Reviews: Data Mining and Knowledge Dis-

covery, 0(0):e1289.

Triguero, I., Peralta, D., Bacardit, J., Garc

ıa, S., and Her-

rera, F. (2015). Mrpr: A mapreduce solution for pro-

totype reduction in big data classiﬁcation. neurocom-

puting, 150:331–345.

Wang, J., Zhao, P., Hoi, S. C., and Jin, R. (2014). On-

line feature selection and its applications. IEEE

Transactions on Knowledge and Data Engineering,

26(3):698–710.

Webb, G. I. (2014). Contrary to popular belief incremen-

tal discretization can be sound, computationally ef-

ﬁcient and extremely useful for streaming data. In

2014 IEEE International Conference on Data Mining,

pages 1031–1036.

Wilson, D. L. (1972). Asymptotic properties of nearest

neighbor rules using edited data. IEEE Transactions

on Systems, Man, and Cybernetics, SMC-2(3):408–

421.

Wu, X. and Zhu, X. (2008). Mining with noise knowledge:

error-aware data mining. IEEE Transactions on Sys-

tems, Man, and Cybernetics-Part A: Systems and Hu-

mans, 38(4):917–932.

Yu, L. and Liu, H. (2003). Feature selection for high-

dimensional data: A fast correlation-based ﬁlter solu-

tion. In Proceedings of the 20th international confer-

ence on machine learning (ICML-03), pages 856–863.

Big Data Preprocessing as the Bridge between Big Data and Smart Data: BigDaPSpark and BigDaPFlink Libraries

331
