Rule-based Security Monitoring of Containerized Workloads

Holger Gantikow

, Christoph Reich

, Martin Knahl

and Nathan Clarke

Science+Computing ag, Atos, Tuebingen, Germany

Institute for Cloud Computing and IT Security, Furtwangen University, Furtwangen, DE, Germany

Faculty of Business Information Systems, Furtwangen University, Furtwangen, DE, Germany

Center for Security, Communications and Network Research, Plymouth University, Plymouth, U.K.

Keywords:

Container Virtualization, Docker, Security, Monitoring, Anomalous Behavior, System Call Tracing.

Abstract:

In order to further support the secure operation of containerized environments and to extend already estab-

lished security measures, we propose a rule-based security monitoring, which can be used for the detection

of a variety of misuse and attacks. The capabilities of the open-source tools used to monitor containers are

closely examined and the possibility of detecting undesired behavior is evaluated on the basis of various sce-

narios. Further, the limits of the approach taken and the associated performance overhead will be discussed.

The results show that the proposed approach is effective in many scenarios and comes at a low performance

overhead cost.

1 INTRODUCTION

Over the last few years, Linux containers have led

to a strong trend towards lightweight virtualization,

where only the application and its dependencies rep-

resent the content of the virtualized unit, omitting a

virtual machine with an independent operating sys-

tem. Because the virtualization takes place at the op-

erating system level, all containers running on one

host share the very same Linux kernel, which in turn

handles the virtualization. This leads to reduced re-

source requirements (Felter et al., 2015), that are

particularly beneﬁcial for scalable, distributed mi-

croservice architectures. For this purpose, contain-

ers are preferably used for underlying basic compo-

nents such as databases, message brokers, service dis-

covery services or web/application servers. In addi-

tion, container technologies play an important role

when it comes to managing software in DevOps en-

vironments. There they offer, integrated into corre-

sponding Continuous Integration, Delivery and De-

ployment (CI/CD) tools and pipelines, the possibility

to package applications and their dependencies auto-

matically in a standardized image format and to sub-

sequently deploy them independent of the underlying

Linux distribution. Containers have also established

themselves in the domain of High Performance Com-

puting (HPC) and Scientiﬁc Computing in general.

There they serve with low performance overhead as

appropriate means to improve the portability of ap-

plications across different systems and institutions, to

simplify the handling of user-provided applications

and to ensure the reproducibility of experiments.

According to current surveys (Sysdig, 2018), the

most widespread container runtime is still Docker

with a share of 83% of the investigated systems,

followed by rkt with 12%. However, there is also

a considerable number of runtime engines designed

for a speciﬁc purpose or domain. Especially in the

ﬁeld of HPC, where Charliecloud (Priedhorsky et al.,

2017), Shifter (Jacobsen and Canon, 2015) and espe-

cially Singularity (Kurtzer et al., 2017) are far more

widespread than Docker, but in most cases use other

isolation mechanisms than the general purpose run-

times, which are in the focus of this paper. While

overall interest in utilizing containers due to their ben-

eﬁts is still rising, container security, or the lack of

thereof (Combe et al., 2016), is still listed the most

frequent challenge to overcome when adopting con-

tainers (Portworx, 2018), even though the situation

has improved signiﬁcantly in recent years as a result

of the integration of several security mechanisms.

In this paper, we propose the use of rule-based se-

curity monitoring to increase the security level in a

containerized environment. We explore the applica-

bility of the approach to detect several types of mis-

use and potential attacks and discuss the limitations

of the described approach, as well as the associated

Gantikow, H., Reich, C., Knahl, M. and Clarke, N.

Rule-based Security Monitoring of Containerized Workloads.

DOI: 10.5220/0007770005430550

In Proceedings of the 9th International Conference on Cloud Computing and Services Science (CLOSER 2019), pages 543-550

ISBN: 978-989-758-365-0

543

monitoring-related performance overhead.

The rest of this paper is organized as follows.

Section 2 introduces the basic security mechanisms

that exist in the domain of container virtualization.

Section 3 details which special characteristics exist

regarding monitoring compared to hypervisor-based

virtualization. Section 4 discusses related work to

further secure containerized workloads. Section 5

presents the proposed rule-based security monitoring

approach that is evaluated in Section 6. Section 7 dis-

cusses the current limitations and future work, before

we conclude in Section 8.

2 CONTAINERS AND SECURITY

Container isolate workloads by using Linux features

like the Control Groups (cgroups) for metering and

limiting resources as CPU share, memory and IO,

as well as Kernel Namespaces. These provide pro-

cesses their own limited view of the shared host sys-

tem. Linux currently implements seven namespaces

and is able to provide isolated instances of cgroups,

IPC, Network, Mount, PID, User, UTS.

In addition to these fundamental isolation mecha-

nisms, support for additional already established se-

curity mechanisms has been integrated into the con-

tainer runtimes over time. These include, for in-

stance, support for components such as AppArmor

and SELinux that use the Linux Security Module in-

terface and are used for implementing Mandatory Ac-

cess Control (MAC). They can be applied to directly

control the access rights of individual processes and

thus reduce the risk of potentially harmful effects in

the event of an error or attack. The kernel feature Se-

cure Computing Mode (seccomp) allows to explicitly

deny certain system calls of the Linux kernel for a

container and to create a basic sandbox. For exam-

ple, by disallowing the chown system call it can be

prevented that inside a container the ﬁle ownership

can be changed. The use of these mechanisms require

in-depth knowledge of the requirements of a speciﬁc

container. To maintain high compatibility with the

widest range of containers the default proﬁles sup-

plied typically contain a less restrictive set of rules

and should be adjusted subsequently on a per con-

tainer basis.

Complementing these essential mechanisms, fur-

ther preventive security measures that can be applied

to secure containerized environments are described in

an overview paper (Gantikow et al., 2016). Among

the most important are CVE scanners for the static

analysis of vulnerabilities in container images, user

namespaces to remap the root user inside the con-

tainer to a less-privileged user on the host and ca-

pabilities, which allow superuser privileges to be

dropped in functional groups. Seccomp is more ﬁne-

granular, as it is based on single system calls, whereas

the capability SYS ADMIN offers a very extensive

range of functions, which in principle can be ex-

ploited to deactivate other security measures (Walsh,

2016).

Although there are many ways to ensure the oper-

ational security of containerized environments and to

protect hosts and containers running in parallel from

malicious workloads in one container, the isolation

provided by containers is still considered to be weaker

compared to hypervisor-based virtualization.

However, better protection against Information

Leakage is still evolving, as the Linux kernel does not

yet provide a fully developed approach to partitioning

all available resources and subsystems that can be uti-

lized by containers. There are still a number of limita-

tions that make it possible to collect more information

about the host from inside the container than would be

possible from a VM. Especially the /proc ﬁle system

is problematic, because it exposes many information

leakage channels (Gao et al., 2017), allowing an op-

timized attack by the information retrieved. Another

potential area of threat is the risk of privilege esca-

lation, i.e. the obtaining of elevated access rights to

the system or even a container breakout. Even if the

greatest risk here is posed by improperly running con-

tainers with elevated privileges (Stoler, 2019), for ex-

ample by applying the –privileged ﬂag at container

startup, leading to security settings so that the con-

tainer behaves practically like a process running out-

side the container, this risk should not be underesti-

mated.

We therefore propose to add a security mea-

sure, the adoption of a rule-based security monitor-

ing of containerized workloads with the aim of de-

tecting misuse and attempted common attacks. For

the scope of this paper, we focus on the detection

of some widespread scenarios and take advantage of

container-speciﬁc characteristics in monitoring. Use

cases include monitoring for unauthorized ﬁle access

as it can precede information leakage, launching un-

expected network connections and applications, at-

tempting privilege escalation, and monitoring a num-

ber of additional elements on the host system.

3 CONTAINERS AND

MONITORING

While containers improve the ﬂexibility and portabil-

ity of workload execution, they make it difﬁcult to

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

544

monitor these workloads when using traditional pro-

cess and performance monitoring tools. Among the

reasons for that is that it is considered best practice

to isolate containerized workloads by separating them

with a single process per container model. Adding a

monitoring agent to each container would both break

this model, thus the simplicity of containers, but also

require the modiﬁcation of the containerized image.

The addition of such a third party application to user

provided images may represent an intolerable condi-

tion for scenarios where users want to ensure the in-

tegrity of their code. Therefore the establishment of a

monitoring process within a container is not suitable

in most cases. The limited suitability also applies to

the approach of a separate sidecar container, which

is placed alongside each container and takes over the

monitoring functionality in a dedicated manner. This

approach would need extended privileges and suffers

from high additional overhead.

Therefore, we suggest the use of one monitoring

agent per host for our approach. This offers the advan-

tages that the overhead caused by additional monitor-

ing containers is eliminated, that the one process per

container model can be preserved, that no monitoring

agent has to be introduced into the individual contain-

ers and thus a modiﬁcation of user supplied images

can be omitted. By monitoring the system calls issued

by a container, the host is able to obtain a very accu-

rate picture of the operations running inside the con-

tainer. By supplementing traditional metrics (includ-

ing CPU load, memory usage, network and block I/O,

and number of running processes), which can also be

captured at host level, a comprehensive overall level

of information about the state of a container can be ag-

gregated. In addition, it should be mentioned that the

collected state information can be directly assigned

to the respective containerized workload, since there

are no possible concurrent activities caused by a guest

operating system that could distort the overall picture.

This type of monitoring allows a rule-based approach

for the detection of common security events and at-

tempted attacks of containerized workloads.

4 RELATED WORK

There are a number of methods for increasing the

protection of containerized environments which im-

prove the existing Linux security mechanisms that are

nowadays supported by container runtimes. These in-

clude SPEAKER (Lei et al., 2017), which uses dif-

ferent seccomp proﬁles for the start-up phase of the

container and its actual operational phase, or Lic-

Shield (Mattetti et al., 2015) which generates policies

for AppArmor with the help of a behavioral learning

phase.

Although approaches (Nikolai, 2014) exist in

hypervisor-based environments that only use per-

formance metrics to detect malicious behavior and

would be transferable to containerized environments,

system calls are still the preferred data source when

it comes to detecting malicious behavior. This goes

back to the seminal work of Forrest (Forrest et al.,

1996), who proposed sequences of system calls as

an appropriate differentiator between normal and

anomalous behavior. However, the accuracy of this

approach suffered from concurrency on the host caus-

ing distortions of results, such as parallel services.

Containerized workloads reduce this risk, since only

one application typically runs in one container which

avoids concurrency noticeable.

Abed et al. (Abed et al., 2015) applies the ap-

proach of using strace to containers and found it

suited to be used for anomaly detection without re-

quiring any prior knowledge of the container. Unfor-

tunately, the utilized bag of system calls approach is

generally vulnerable to mimicry attacks (Kang et al.,

2005).

Another paper dealing with the practicability of

Falco is provided by Borhani (Alex Borhani, 2017),

although it focuses on Incidence Response rather than

the limitations of the approach.

The use of machine learning approaches to mon-

itor workloads based on system calls is also inves-

tigated by a number of authors, including Maggi et

al. (Maggi et al., 2010) using Markov models for

anomaly detection based on system calls and their ar-

guments. This approach was extended by (Koucham

et al., 2015) by the incorporation of domain knowl-

edge and system call speciﬁc context information.

Kolosnjaji et al. (Kolosnjaji et al., 2016) described

an approach with neural networks based on convo-

lutional and recurrent network layers which allows

them to improve the performance of detecting mal-

ware. The approach of Dymshits et al. (Dymshits

et al., 2017), which focuses on distributed collection

and processing of large volumes of data, investigates

sequences of system call count vectors and uses a

LSTM-based architecture.

5 OVERVIEW OF PROPOSED

SYSTEM

Our approach is based on the Open Source tools Sys-

dig (Sysdig, 2019b) and Falco (Sysdig, 2019a). They

both distinguish from other approaches such as using

strace and eBPF (Fleming, 2017) by a native support

Rule-based Security Monitoring of Containerized Workloads

545

for containers (Docker, rkt, LXC). Their ability to ac-

tivate ﬁlters to restrict the collection of data, primarily

system calls, to single containers signiﬁcantly helps

to reduce the effort associated with container-speciﬁc

monitoring and also offers the potential to reduce the

amount of data that has to be collected and processed.

5.1 Sysdig

Sysdig consists of a Linux kernel module (sys-

dig probe) and a daemon. Through the kernel mod-

ule, all system calls coming from applications and

containers are captured and sent to the daemon for

further processing. The daemon can either be exe-

cuted on the host system or within a privileged con-

tainer. The functionality of Sysdig extends over sev-

eral well-known analysis and monitoring tools, in-

cluding strace and tcpdump and also includes transac-

tion tracing. This allows capturing not only the state

of the system (CPU load, running processes), but also

actions as accessing ﬁles or establishing network con-

nections. To limit the amount of data, it is possible to

deﬁne ﬁlters for incoming events. These can be based

on speciﬁc system calls, the source of an event, such

as speciﬁc containers or processes, or attributes of the

respective event.

5.2 Falco

Falco complements the system call capture function-

ality of Sysdig with the ability to detect abnormal ac-

tivities. It is based on the same kernel module as

Sysdig and implements a behavioral activity moni-

tor whose policies can be deﬁned based around the

Sysdig ﬁlter options as condition. It can be used to

identify, using an appropriate set of rules, whether

a container deviates in its behavior from the desired

state and shows signs of anomalous behavior. Such

anomalous activities inside a container could repre-

sent starting unauthorized applications in a container,

browsing unusual ﬁle system paths, or attempting to

write to paths containing system ﬁles and binaries.

Falco, however, only detects violations, so that mit-

igation of the detected anomalous behavior must take

place subsequently. Another limitation of Falco is that

it is only suitable for detecting point anomalies, such

as the occurrence of a certain event, as starting of a

certain application, or the use of a unauthorized sys-

tem call. Currently there is no possibility to map con-

textual anomalies or collective anomalies through the

available rules set. This limits the detection possi-

bilities to some extent, as the following investigation

shows.

5.3 Architecture

Figure 1: Proposed Rule-based Security Monitoring Archi-

tecture.

Figure 1 shows the corresponding architecture. As

already described, both Sysdig and Falco use the (sys-

dig probe) kernel module which utilizes the Linux

kernel facility tracepoints to capture system calls.

System calls are of high value when it comes to trac-

ing the behavior of a (possibly containerized) applica-

tion, since already every ﬁle access leaves a meaning-

ful trace at the transition from the process-to-kernel

boundary, also known as the system call interface.

This way, besides the call names, also the arguments

and the return values can be obtained and evaluated.

While Sysdig is mostly used for displaying and pro-

cessing captured events, Falco provides the possibility

to decide on the basis of predeﬁned rule sets (Figure

1, Rules) if there is anomalous behavior and to per-

form a corresponding notiﬁcation (Figure 1, Incident

Notiﬁcation) using logging frameworks, messengers

or plain e-mail. We are currently thinking about ex-

panding this functionally and introducing mitigation

measures based on the severity of the event.

6 EVALUATION

For our evaluation we have chosen a two-phase ap-

proach: in the ﬁrst phase we manually examine

whether and how certain behavior can be recognized

with Sysdig and, if possible, transfer the condition

that is needed to recognize the undesired activity into

a Falco rule set. In the second phase the created Falco

rule set was tested for the possibility of automatic

recognition.

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

546

6.1 Test Environment

The evaluation was carried out in a virtualized test en-

vironment. This means, referring to Figure 1, that the

host system is actually a virtual machine in our case.

However, this has no inﬂuence on the functionality of

the described approach. We used the following com-

ponents in a VM with 1 Core and 4GB of memory and

did not impose additional container resource limits:

OS: Debian GNU/Linux 9.5 (stretch)

Kernel: 4.9.0-8-amd64

Docker: Docker version 18.06.1-ce, build e68fc7a

Sysdig: 0.24.1

Falco: 0.13.0

Unless otherwise speciﬁed we used Debian

GNU/Linux 9.5 (stretch) as container image.

6.2 Studied Misuse and Attacks

Unauthorized File Access. For the test setup of the

Unauthorized File Access we used the deliberately in-

secure web application WebGoat (OWASP, 2018). We

used the already-available webgoat image on Docker-

hub and evaluated the detectability of the task Bypass

a Path Based Access Control Scheme. This represents

a directory traversal attack where the successful at-

tacker can access ﬁles outside the root directory of

the web server. Such an attack is often used to gain

access to conﬁguration ﬁles with passwords.

The following code represents the Sysdig condi-

tion, which also serves as the basis for a Falco rule

set.

container.name=webgoat

and evt.type=open

and evt.dir="<"

and fd.type=file

and not (fd.directory contains "/webapp")

The condition is true if the container name

is web-

goat and the system call open accesses a ﬁle outside

a path containing the string /webapp.

The example shows that it can be easily gener-

alized and can be used, in addition to restricting a

service to its corresponding root directory, to moni-

tor activity to access to non-namespaced resources or

other resources that could lead to information leak-

age. An attempted write access, for example to direc-

tories containing system binaries, can also be detected

in this way. Furthermore, the condition itself can be

The container name refers to the name of the running

container instance as returned by docker ps and not to the

image name in general. The respective container ID (con-

tainer.id) could also be used as an alternative to the name.

extended by further event parameters that have to be

fulﬁlled, so that it is possible to detect when a process

not approved for this purpose tries to access a speciﬁc

device.

Start of Unauthorized Application. A similarly

well generalizable test case is the detection of the

Start of Unauthorized Applications inside a container.

list: authorized_processes

items: [ps, hostname]

condition:

container.name=debian-test

and evt.type=execve

and evt.dir="<"

and not (proc.name in (authorized_processes))

The condition thus recognizes the execution of pro-

grams that are not ps or hostname. This can be used to

allow a container to start only its corresponding ser-

vice and to log, for example, if a crypto miner or a

(remote) shell is started, as might be the case in a suc-

cessful remote attack. The list authorized processes

serves as a white list here.

Container Breakout (using nsenter). Another test

case examined was the detection of certain processes

that are related to speciﬁc threats, i.e. are maintained

on a black list if necessary. In this example the com-

mand nsenter was used to run a process within the

name spaces of another process, which is detectable

by ﬁltering for the system call setns. Although this

mechanism is typically blocked from within a con-

tainer by other measures, there is still a risk of mis-

conﬁguration. In addition, it can be useful to be able

to log the access from the host into a container by this

procedure by adapting the container identiﬁer to con-

tainer.id = host.

Unexpected Network Connection. In order to detect

if a container establishes undesired connections to the

internet, for example to download malicious code for

an exploit or to open a remote shell, the detectability

of Unexpected Network Connections was also exam-

ined. This can be implemented by creating a white list

with approved targets or limiting it to speciﬁc TCP

ports.

Loading of Kernel Module. Although it is not pos-

sible in the default conﬁguration to load kernel mod-

ules on the host from the container, the recent break-

out from a Docker evaluation environment Play with

Docker (Stoler, 2019) inspired us to consider this

case. As described in the referenced case, this can

lead to a privilege escalation with full administrative

privileges on the host and thus control over additional

containers.

Denial of Service (DoS). Even though (if applied)

cgroups can prevent a resource starvation of the host

and other containers in terms of CPU shares and

memory, there is the possibility, depending on the

Rule-based Security Monitoring of Containerized Workloads

547

conﬁguration, to ﬁll up shared ﬁle systems, which is

why this test case had to be investigated.

Buffer Overﬂow. The last test case examined was

whether it is in principle possible to detect buffer

overﬂows using our rule-based approach. Abusing a

buffer overﬂow is a common security exploit, so that

memory areas with executable code are overwritten

with malicious code, which can be the basis for an

attack.

6.3 Results

Table 1 shows the summary of the ﬁndings and also

lists what can be used as a characteristic when creat-

ing the condition used for detection.

It should be noted that in almost all cases it is pos-

sible to create a rule set for Falco if a Sysdig condi-

tion allows detection of the event. As already implied

upon presenting the test cases, it is straightforward to

detect access to non-authorized ﬁles, the start of non-

authorized applications and cases derived from those

scenarios, either via the violation of a white list or ex-

plicitly via a black list.

The detection of a DoS attack can in principle be

detected with Sysdig, but requires that it is combined

with a different behavioral monitor than Falco, since it

is not possible with Falco to detect, for example, high

frequent occurrence of write access or network con-

nections. There is no support for an event frequency

as of writing.

Also the detection of a Buffer Overﬂow is not pos-

sible in the desired way, as it is typically also not de-

tectable by static analysis. The execution of an exploit

would generate multiple system calls. However, Falco

can only detect anomalies from a single system call.

In this scenario, the order and combination are also

of importance and the approach to detect one speciﬁc

exploit could not be generalized. As a workaround it

would be possible to detect the startup of an exploit by

process name. Yet this requires knowledge of the spe-

ciﬁc exploit to be able to detect its execution through a

blacklist - and is not very promising either, as it could

be bypassed by simply renaming the exploit.

7 DISCUSSION

According to our understanding, there are a number

of restrictions on the tools examined which should

not go unmentioned. This includes the restriction that

there is no possibility to detect attacks that show up by

an increased number of accesses, for example a DoS

against a service or if a high volume of data is trans-

ferred automatically. Falco’s current rule set does not

provide the possibility to consider frequencies or load

conditions, even if they could be determined in prin-

ciple.

In addition, the rule creation procedure shows that

precise knowledge of the services running in the con-

tainers must be available in order to enable effective

security monitoring. This includes communication

endpoints, required ﬁle paths and program names. In

an environment where hundreds of similar containers

are started fully automated, this can be irrelevant, but

the necessary effort should not be neglected in smaller

more individual environments. Especially when using

containers for interactive work - which is not recom-

mended. A further limitation concerns the white list

approach, which does not protect against malicious

code being disguised as a program on the white list

when knowledge of the rules is involved.

On a positive note, the tools utilized can also be

applied to other container environments, even though

we have only examined the use with Docker here. The

kernel module provides a generic interface, so that ex-

isting rule sets can be reused when changing container

runtimes. Furthermore, from a security point of view,

it may be worthwhile to monitor not only the individ-

ual containers running on a host, but at least container

life cycle operations performed on the host itself, such

as starting/stopping a container, to get a complete pic-

ture of the environment.

7.1 Performance Evaluation

To determine the performance overhead caused by se-

curity monitoring, we made use of a traditional bench-

mark tool: Sysbench (Kopytov, 2019), of which we

created a containerized version. To exclude buffering

effects when using the ﬁlesystem-level benchmark

ﬁleio included with Sysbench, we used it with a test

ﬁle four times the amount of the available memory.

During each 5min run of the benchmark a correspond-

ing capture ﬁle was created with Sysdig and after-

wards several performance indicators of the sysbench-

ﬁleio run were evaluated.

In order to be able to rate how high the beneﬁt of

using ﬁlters is a) a full capture and b) a capture with

an active ﬁlter was created, which limited the record-

ing to the open() system call, as one would use if one

only wanted to log ﬁle accesses of a container. As

baseline served measurements of the sysbench-ﬁleio

without activated Sysdig capturing and all benchmark

runs (deactivated Sysdig, Sysdig with full capture,

Sysdig with ﬁlter) were averaged over three runs each.

All runs were performed in the same virtual test envi-

ronment described in Section 6.1.

It was observed that over several measurements

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

548

Table 1: Summary of the detectability of various misuse and attack scenarios using Sysdig and Falco.

Scenario Sysdig Falco Characteristic

Unauthorized File Access Yes Yes Violation of white list

Start of Unauthorized Applications Yes Yes Violation of white list

Container Breakout Yes Yes Black list - nsenter called - or violation of white list

Unexpected Network Connection Yes Yes Violation of white list

Loading of Kernel Module Yes Yes Black list - insmod called - or violation of white list

Denial of Service Yes No Frequency of occurrences

Buffer Overﬂow No No Not applicable

Table 2: Sysdig overhead for various statistics of sysbench-ﬁleio benchmark in comparison to baseline run without Sysdig.

sysbench-ﬁleio statistic Sysdig with full capture Sysdig with ﬁlter

Operations performed (total) 1,81% 0,00%

Requests/sec executed 4,72% 2,97%

Total number of events 4,72% 2,97%

Total time taken by event execution 5,48% 0,67%

Per-request statistics: “avg” in ms 10,53% 3,51%

Average Overhead 5,45% 2,02%

the average overhead in case a) (full capture) was

5,45%, whereas the use of the ﬁlter reduced the

overhead in case b) to 2,02%. The use of the ﬁl-

ter also affected the size of the capture ﬁle. In b)

only 270 events needed to be recorded, resulting in

a 1,2MB trace ﬁle, whereas the unﬁltered case a)

logged 3.270.522 events in a 270MB ﬁle on average.

This implies, that if possible, ﬁlters should be acti-

vated for data and overhead reduction. The overhead,

broken down by individual sysbench-ﬁleio statistic, is

shown in Table 2.

8 CONCLUSIONS

The explored approach shows a general applicability

of rule-based security monitoring for containerized

workloads with low performance overhead. It allows

a large number of undesired behavior to be detected

with relatively low effort. Especially if containers

are used as automatically orchestrated infrastructure

components and are not used for interactive work, it

is useful to create a rule for each container, which in-

forms about the start of a program in the container

other than the expected service. This can also be ap-

plied to ﬁle accesses.

In addition, logging mechanisms for container ac-

cess should be established at host level (via monitor-

ing the use of the commands docker exec or nsenter

or the related system call setns) and the tools be inte-

grated into appropriate incident response processes in

order to timely initiate appropriate mitigation. In ad-

dition, for debugging and auditing purposes, it offers

the possibility to log the complete run of a container

to trace it afterwards. However, this should primarily

be used for short-lived containers or additional ﬁlters

should be applied, as the performance overhead anal-

ysis showed, that without ﬁlters almost 1MB trace ﬁle

was generated per second.

In cases where it is not possible to create a sim-

ple set of rules, ideally by automatisms, further safe-

guarding mechanisms which monitor the behavior of

a container at runtime and compare it with a reference

model should be considered, as the investigated ap-

proach requires prior knowledge about the workload.

Future work is planed to investigate distributed se-

curity monitoring, especially of workloads that inter-

act with each other in a distributed way. For this pur-

pose Sysdig already offers interfaces for monitoring

the container schedulers Kubernetes and Swarm, fur-

thermore a commercial product. We also want to in-

vestigate how the generation of rule sets can be auto-

mated, as well as how additional misuses and attacks

can be integrated.

REFERENCES

Abed, A. S., Clancy, T. C., and Levy, D. S. (2015). Ap-

plying bag of system calls for anomalous behavior de-

tection of applications in linux containers. 2015 IEEE

Globecom Workshops, GC Wkshps 2015 - Proceed-

ings.

Rule-based Security Monitoring of Containerized Workloads

549

Alex Borhani (2017). Anomaly Detection, Alerting, and

Incident Response for Containers. SANS Institute In-

foSec Reading Room, (GIAC GCIH Gold Certiﬁca-

tion).

Combe, T., Martin, A., and Di Pietro, R. (2016). To Docker

or Not to Docker: A Security Perspective. IEEE Cloud

Computing, 3(5):54–62.

Dymshits, M., Myara, B., and Tolpin, D. (2017). Process

monitoring on sequences of system call count vectors.

Proceedings - International Carnahan Conference on

Security Technology, 2017-October:1–5.

Felter, W., Ferreira, A., Rajamony, R., and Rubio, J. (2015).

An updated performance comparison of virtual ma-

chines and linux containers. In 2015 IEEE Interna-

tional Symposium on Performance Analysis of Sys-

tems and Software (ISPASS), pages 171–172.

Fleming, M. (2017). A thorough introduction to ebpf. [ON-

LINE] Available at: https://lwn.net/Articles/740157/.

[Accessed 14 January 2019].

Forrest, S., Hofmeyr, S., Somayaji, A., and Longstaff, T.

(1996). A sense of self for Unix processes. In Pro-

ceedings 1996 IEEE Symposium on Security and Pri-

vacy, pages 120–128.

Gantikow, H., Reich, C., Knahl, M., and Clarke, N. (2016).

Providing security in container-based HPC runtime

environments. Lecture Notes in Computer Science

(including subseries Lecture Notes in Artiﬁcial Intel-

ligence and Lecture Notes in Bioinformatics), 9945

LNCS:685–695.

Gao, X., Gu, Z., Kayaalp, M., Pendarakis, D., and Wang, H.

(2017). ContainerLeaks: Emerging Security Threats

of Information Leakages in Container Clouds. Pro-

ceedings - 47th Annual IEEE/IFIP International Con-

ference on Dependable Systems and Networks, DSN

2017, pages 237–248.

Jacobsen, D. M. and Canon, R. S. (2015). Contain This,

Unleashing Docker for HPC. Cray User Group 2015,

page 14.

Kang, D.-k., Fuller, D., and Honavar, V. (2005). Learning

Classiﬁers for Misuse Detection Using a Bag of Sys-

tem Calls Representation. Proceedings of the 2005

IEEE Workshop on Information Assurance and Secu-

rity United States Military Academy, West Point, NY,

pages 511–516.

Kolosnjaji, B., Zarras, A., Webster, G., and Eckert, C.

(2016). Deep learning for classiﬁcation of malware

system call sequences. In Lecture Notes in Computer

Science (including subseries Lecture Notes in Artiﬁ-

cial Intelligence and Lecture Notes in Bioinformatics),

volume 9992 LNAI, pages 137–149.

Kopytov, A. (2019). Sysbench: Scriptable database and sys-

tem performance benchmark. [ONLINE] Available at:

https://github.com/akopytov/sysbench. [Accessed 14

January 2019].

Koucham, O., Rachidi, T., and Assem, N. (2015). Host

intrusion detection using system call argument-based

clustering combined with Bayesian classiﬁcation. In-

telliSys 2015 - Proceedings of 2015 SAI Intelligent

Systems Conference, pages 1010–1016.

Kurtzer, G. M., Sochat, V., Bauer, M. W., Favre, T., Capota,

M., and Chakravarty, M. (2017). Singularity: Scien-

tiﬁc containers for mobility of compute. Plos One,

12(5):e0177459.

Lei, L., Sun, J., Sun, K., Sheneﬁel, C., Ma, R., Wang, Y.,

and Li, Q. (2017). SPEAKER: Split-phase execution

of application containers. In Lecture Notes in Com-

puter Science (including subseries Lecture Notes in

Artiﬁcial Intelligence and Lecture Notes in Bioinfor-

matics), volume 10327 LNCS, pages 230–251.

Maggi, F., Matteucci, M., and Zanero, S. (2010). Detecting

intrusions through system call sequence and argument

analysis. IEEE Transactions on Dependable and Se-

cure Computing, 7(4):381–395.

Mattetti, M., Shulman-Peleg, A., Allouche, Y., Corradi,

A., Dolev, S., and Foschini, L. (2015). Securing the

infrastructure and the workloads of linux containers.

2015 IEEE Conference on Communications and Net-

workSecurity, CNS 2015, (Spc):559–567.

Nikolai, J. (2014). Hypervisor-based cloud intrusion detec-

tion system. 2014 International Conference on Com-

puting, Networking and Communications (ICNC).

OWASP (2018). Owasp webgoat project. [ONLINE]

Available at: https://www.owasp.org/index.php/

Category:OWASP WebGoat Project. [Accessed 14

January 2019].

Portworx (2018). 2018 Container Adoption Survey. Tech-

nical report.

Priedhorsky, R., Randles, T. C., and Randles, T. (2017).

Charliecloud: Unprivileged containers for user-

deﬁned software stacks in HPC. SC17: International

Conference for High Performance Computing, Net-

working, Storage and Analysis, 17:p1–10.

Stoler, N. (2019). How i hacked play-with-docker and re-

motely ran code on the host. [ONLINE] Available at:

https://www.cyberark.com/threat-research-blog/how-

i-hacked-play-with-docker-and-remotely-ran-code-

on-the-host/. [Accessed 14 January 2019].

Sysdig (2018). Docker Usage Report 2018 - An inside look

at shifting container usage trends.

Sysdig (2019a). Sysdig falco: Behavioral activity moni-

toring with container support. [ONLINE] Available

at: https://github.com/draios/oss-falco. [Accessed 14

January 2019].

Sysdig (2019b). Sysdig: Linux system exploration

and troubleshooting tool with ﬁrst class sup-

port for containers. [ONLINE] Available at:

https://github.com/draios/sysdig. [Accessed 14 Jan-

uary 2019].

Walsh, D. (2016). Container tidbits: Adding ca-

pabilities to a container. [ONLINE] Available

at: https://rhelblog.redhat.com/2016/11/30/container-

tidbits-adding-capabilities-to-a-container/. [Accessed

10 January 2019].

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

550
