Towards a Framework for Classifying Chatbots
Daniel Braun
a
and Florian Matthes
Technical University of Munich, Department of Informatics, Munich, Germany
Keywords:
Chatbot, Conversational Interface, Natural Language Interface, Classification Framework.
Abstract:
From sophisticated personal voice assistants like Siri or Alexa to simplistic keyword-based search bots, today,
the label “chatbot” is used broadly for all kinds of systems that use natural language as input. However, the
systems summarized under this term are so diverse, that they often have very little in common with regard
to technology, usage, and their theoretical background. In order to make such systems more comparable, we
propose a framework that classifies chatbots based on six categories, which allow a meaningful comparison
based on features which are relevant for developers, scientists, and users. Ultimately, we hope to support the
scientific discourse, as well as the development of chatbots, by providing an instrument to classify and ana-
lyze different groups of chatbot systems regarding their requirements, possible evaluation strategies, available
toolsets, and other common features.
1 INTRODUCTION
In 1950, Alan Turing famously described what we
would call today a “chatbot” as part of his “Imita-
tion Game” (Turing, 1950), now better known as Tur-
ing Test. However, it still took 16 more years until
ELIZA (Weizenbaum, 1966) was developed, which is
today widely regarded as the first chatbot (Jia, 2009;
Abdul-Kader and Woods, 2015; Kerlyl et al., 2007).
The Term “chatbot” itself was not coined until
1994, another 28 years later, when Michael Mauldin
referred to such programs like ELIZA as “Chatter-
Bots” (Mauldin, 1994), because one could have in-
formal conversations with them (chats).
In the same year that ELIZA was released, Ryan
et al. described a system with a “Conversational In-
terface” (Ryan et al., 1966). Like ELIZA, their sys-
tem used a dialogue with the user as input, but un-
like “ChatterBots”, the system was focused on a very
narrow domain instead of general conversations. For
decades, the distinction between Conversational In-
terfaces and chatbots remained. Today, however, this
distinction has mostly vanished outside of very spe-
cialised scientific communities.
From sophisticated personal voice assistants like
Siri or Alexa to simplistic keyword-based search bots,
the label “chatbot” is used broadly for all kinds of
systems that use natural language as input. Recent
a
https://orcid.org/0000-0001-8120-3368
advances in natural language processing and machine
learning, as well as the creation of central platforms,
like Facebook and Telegram, sparked a new hype
around chatbots, which lead to rapid developments
within the industry, sometimes outpacing the progress
within the scientific community. In some areas, this
led to a lack of theoretical foundation.
One of them is the classification of chatbots. Since
even the distinction between conversational interfaces
and chatbots seems to have vanished, we are now
lacking means to comprehensively classify conversa-
tional systems. For scientists, such a classification is
important to compare and evaluate systems. A con-
versational interface which is focused on one specific
task has to be evaluated differently than a classical
“ChatterBot”.
For practitioners, a classification can help to de-
fine requirements and select the right tools. A
keyword-based search interface has different require-
ments than a voice-commanded personal assistant. In
this paper, we propose a framework for classifying
chatbots alongside features which are meaningful to
different stakeholders, in order to improve the devel-
opment of chatbots and connect industry and research
again more strongly.
496
Braun, D. and Matthes, F.
Towards a Framework for Classifying Chatbots.
DOI: 10.5220/0007772704960501
In Proceedings of the 21st International Conference on Enterprise Information Systems (ICEIS 2019), pages 496-501
ISBN: 978-989-758-372-8
Copyright
c
2019 by SCITEPRESS – Science and Technology Publications, Lda. All rights reserved
Discourse
Manager
Request Interpretation
Response Retrieval Message Generation
Knowledge Base
Contextual
Information
Analysis
Query Generation
Candidate Retrieval
Candidate Selection
Text Planning
Sentence Planning
Linguistic Realizer
Figure 1: Reference architecture for chatbots (Braun et al., 2017).
2 METHODOLOGY
In order to develop a classification framework that is
really relevant for the different stakeholder groups, we
followed a design science research approach (Hevner,
2007; Hevner and Chatterjee, 2010). The main arte-
fact we developed is the classification framework de-
scribed in Section 4. Our research contributes to all
cycles according to Hevner’s three-cycle view of de-
sign science (Hevner, 2007; Hevner et al., 2004).
In the previous section, we already explained how
such a framework would be beneficial for different in-
volved stakeholders (Relevance Cycle). The result of
the Design Cycle is the proposed framework, which
we also briefly evaluate in this paper by applying it to
different systems and evaluating the resulting classi-
fication. Last but not least, our research is grounded
on scientific literature as well as publications from in-
dustry, and informal expert interviews.
We hope that the developed framework will be an
appreciated contribution to the knowledge space of
chatbots and conversational interfaces and will lead
to a more differentiated engagement with the subject
(Rigor Cycle).
3 RELATED WORK
While, to the best of our knowledge, there have been
no attempts to develop an overarching framework to
classify chatbots based on all relevant features, differ-
ent researchers focused on individual aspects of chat-
bots in order to compare and classify them.
Shawar and Atwell e.g. compared “different
measurements metrics to evaluate a chatbot system”
(Shawar and Atwell, 2007). These included dialogue
efficiency metrics, dialog quality metrics, and user
satisfaction metrics. All measurements which are rel-
evant for both, scientists and developers, but only in-
directly for users.
Gianvecchio et al. proposed a classification sys-
tem in order to find out whether a given chat partner
is a chatbot or not (Gianvecchio et al., 2011) by tak-
ing into accounts factors like message size and inter-
message delay. A classification that is mainly relevant
for scientists.
On a more technical level, and therefore mainly
relevant for developers, Abdul-Kader and Woods pre-
sented a survey on chatbot design techniques by
analysing 25 Loebner price winning chatbots (Abdul-
Kader and Woods, 2015). Braun et al. evaluated Nat-
ural Language Understanding services for chatbots,
including services from IBM, Microsoft, Google, and
Facebook, and compared their classification quality
(Braun et al., 2017). Moreover, they also suggested a
reference architecture for chatbots shown in Figure 1.
4 PROPOSED FRAMEWORK
The framework we propose classifies chatbots based
on six different categories. In this section, we will
Towards a Framework for Classifying Chatbots
497
Table 1: Application of the classification framework to three different chatbot systems.
System
Classification Framework
Domain
I/O
Timing
Flow
Platform
Understanding
Text
Synchronous
Dynamic
Messenger
Social Media
Standalone
Notifications
Keywords
Contextual
Personalized
Autonomous
Siri
open
X
X
X
X
Mobility
mobility
X
X
X
X
X
Mildred
flights
X
X
X
X
X
Everyword
dict
X
X
X
describe these categories and why they are relevant.
Domain: The most decisive differentiator of chatbots
is the domain they operate on. On the one hand, there
are open domain systems like Alexa, Siri, and ELIZA,
on the other hand, there are systems which are re-
stricted to one or multiple domains, like weather re-
ports or making a reservation. This distinction revives
what used to be the differentiation between chatbots
and conversational interfaces but sharpens it at the
same time, by not only distinguishing between open
and domain-specific but also between the actual do-
mains. As mentioned before, for scientists this is e.g.
important with regard to the evaluation of a system.
• Input / Output:
This category differentiates between voice and
texts as input/output. This is especially relevant
with regard to technology choices, but also with
regard to the situations in which a chatbot can be
used (e.g. hands-free).
• Timing:
We also differentiate between synchronous and
asynchronous systems. If we talk to a voice
assistant or chat with a bot on Telegram we
expect an “immediate” answer, i.e. within
seconds. From a Twitter bot we might not neces-
sarily expect that. Synchronicity mostly imposes
challenges regarding the performance of a system.
• Flow:
The flow of a conversation, i.e. the order in which
messages are sent, can be either sequential or dy-
namic. A sequential chatbot for booking flights
would e.g. expect to first receive the departure air-
port, then the destination, and then the time, while
a dynamic system could process this information
in an arbitrary order.
• Platform:
In their early days, chatbots were mostly stan-
dalone applications. Today, most chatbots are part
of a messenger or social platform. Only voice as-
sistants like Amazon’s Alexa are still commonly
standalone applications or even separate devices.
• Understanding:
How “smart” a chatbot is perceived by its users
largely depends on what input the system is able
to understand. The “most stupid” systems do not
process any input at all, they are merely a no-
tification system which sends messages. More
complex systems rely on keyword detection, even
more sophisticated ones take into account the con-
text of a conversation, i.e. they consider previous
messages when interpreting new messages.
State-of-the-art systems take information about
the user from previous conversations or other
sources into account. Thus, over time, they be-
come more personalized to the needs of their
users. Beyond this, there would be chatbots which
are fully autonomous and not just communicate
with humans but also with other bots. However,
we do not expect to see such kinds of systems any-
time soon.
ICEIS 2019 - 21st International Conference on Enterprise Information Systems
498
5 APPLICATION
In order to perform a first evaluation, or rather a
“sanity check”, of our framework, we applied it to
classify four very different chatbot systems: Ap-
ple’s Siri, a Telegram chatbot for intermodal mobil-
ity (Braun et al., 2018), Mildred, a Facebook chatbot
from Lufthansa for online flight information (Sieber,
2019), and everyword, a Twitter bot that tweeted ev-
ery word in the English language. The results of the
classification are shown in Table 1.
The results show that the framework is able to
cover the wide variety of the four bots. From a prac-
titioners perspective, the classification gives a quick
and comprehensive overview of the requirements of
the different systems. In order to implement a bot like
Siri, one would e.g. need voice-to-text and text-to-
voice systems, as well as enough computing power
to handle incoming requests synchronously. On the
other end of the scale, everyword does not need any
NLU capabilities at all and no powerful servers, but a
connection to social media services.
From a scientific point-of-view, the classification
would e.g. help to decide how to evaluate the dif-
ferent systems (e.g. Turing test for Siri, task-based
evaluation for the Telegram and Facebook bot, and a
questionnaire-based evaluation for everyword).
From the user perspective, the evaluation e.g. clar-
ifies which types of input can be processed by the
chatbot and on which platforms it can be used.
Obviously, this is not a full-fledged evaluation and
the framework itself is still research in progress. Nev-
ertheless, we hope that discussing our proposal with
the scientific community will help us to improve it
and adapt it to the needs of potential users.
6 AVAILABLE TOOLSETS
As mentioned before, we believe that a classification
framework, like the one presented in this paper, has
the power to help developers and scientists to make
more educated decisions about which tools to use to
develop a chatbot. In this section, we provide some
examples, how a classification in the proposed frame-
work could correlate with the choice of existing de-
velopment tools.
6.1 RASA
RASA is a set of two open source libraries covering
natural language understanding and dialogue manage-
ment (Bocklisch et al., 2017).
1
Table 2 shows which
1
https://rasa.ai
requirements from the proposed classification frame-
work can be implemented using RASA. It shows that
RASA can e.g. handle textual input directly, but not
spoken language.
Table 2: Capabilities provided by RASA.
Tool Requirements Impl.
RASA
I/O
Voice
Text X
Timing
Synchronous X
Asynchronous
Flow
Sequential X
Dynamic X
Platform
Messenger X
Social Media
Standalone X
Understanding
Notifications
Keywords X
Contextual X
Personalised
Autonomous
Obviously, this does not mean that it is not possi-
ble to build voice-based chatbots with RASA, but it
indicates that some additional tool will be necessary
in order to build a chatbot that can be classified as
voice-based.
6.2 Kaldi
Table 3: Capabilities provided by Kaldi.
Tool Requirements Impl.
Kaldi
I/O
Voice X
Text
Timing
Synchronous
Asynchronous
Flow
Sequential
Dynamic
Platform
Messenger
Social Media
Standalone
Understanding
Notifications
Keywords
Contextual
Personalised
Autonomous
Kaldi
2
is an open source speech recognition li-
brary, i.e. Kaldi converts voice to text. (Povey et al.,
2011) As shown in Table 3, the library does not pro-
vide any NLU capabilities whatsoever, in combina-
2
kaldi-asr.org
Towards a Framework for Classifying Chatbots
499
tion with RASA however, it can help to build chatbots
that accept voice input.
The example of Kaldi already shows that the pro-
posed classification framework, which was designed
to classify whole systems, rather than single compo-
nents, is only partially applicable for this new task
since it cannot capture that Kaldi is only able to pro-
cess voice input, but not to produce voice output.
6.3 Chatfuel
Besides software libraries, online services are nowa-
days important tools for developers too. An exam-
ple of an online service for the creation of chatbots
is Chatfuel.
3
Chatfuel provides a WYSIWYG inter-
face which allows users to create end-to-end chatbots
without any programming skills. Given this end-to-
end approach, it is not surprising that Chatfuel im-
plements a lot of the classes from the classification
framework, as shown in Table 4
Table 4: Capabilities provided by Chatfuel.
Tool Requirements Impl.
C.f.
I/O
Voice
Text X
Timing
Synchronous X
Asynchronous X
Flow
Sequential X
Dynamic X
Platform
Messenger X
Social Media
Standalone
Understanding
Notifications X
Keywords X
Contextual X
Personalised
Autonomous
7 FUTURE WORK
In the future, we would like to link the framework
with technical requirements that arise from the char-
acteristics of different chatbot systems. That could
help software engineers and architects to elicitate re-
quirements for a chatbot system before building the
system.
Moreover, based on the classification, (open
source) software components or services could be
suggested which have proven to be helpful in fulfill-
ing the requirements imposed by the identified char-
3
https://chatfuel.com/
acteristics of a chatbot, as already briefly shown in
Section 6.
For existing systems, the classification framework
could be linked to evaluation strategies which could
help to conduct more meaningful and comparable
evaluations of chatbots.
Moreover, it would be desirable to pay more atten-
tion to the needs of users as stakeholders and further
investigate how a classification framework can help
users to pick the right service for their needs.
ACKNOWLEDGEMENTS
This work has been sponsored by the German Federal
Ministry of Education and Research (BMBF) grant
A-SUM 01IS17049.
REFERENCES
Abdul-Kader, S. A. and Woods, J. (2015). Survey on chat-
bot design techniques in speech conversation systems.
International Journal of Advanced Computer Science
and Applications, 6(7).
Bocklisch, T., Faulkner, J., Pawlowski, N., and Nichol,
A. (2017). Rasa: Open source language under-
standing and dialogue management. arXiv preprint
arXiv:1712.05181.
Braun, D., Hernandez-Mendez, A., Faber, A., Langen, M.,
and Matthes, F. (2018). Customer-centred intermodal
combination of mobility services with conversational
interfaces. In Drews, P., Funk, B., Niemeyer, P.,
and Xie, L., editors, Multikonferenz Wirtschaftsinfor-
matik (MKWI) 2018, volume 4. Leuphana Universit
¨
at
L
¨
uneburg.
Braun, D., Hernandez-Mendez, A., Matthes, F., and Lan-
gen, M. (2017). Evaluating natural language under-
standing services for conversational question answer-
ing systems. In Proceedings of the 18th Annual SIG-
dial Meeting on Discourse and Dialogue, pages 174–
185.
Gianvecchio, S., Xie, M., Wu, Z., and Wang, H. (2011).
Humans and bots in internet chat: measurement, anal-
ysis, and automated classification. IEEE/ACM Trans-
actions on Networking (TON), 19(5):1557–1571.
Hevner, A. and Chatterjee, S. (2010). Design science re-
search in information systems. In Design research in
information systems, pages 9–22. Springer.
Hevner, A. R. (2007). A three cycle view of design sci-
ence research. Scandinavian journal of information
systems, 19(2):4.
Hevner, A. R., March, S. T., Park, J., and Ram, S. (2004).
Design science in information systems research. Man-
agement Information Systems Quarterly, 28(1):75–
105.
ICEIS 2019 - 21st International Conference on Enterprise Information Systems
500
Jia, J. (2009). Csiec: A computer assisted english learn-
ing chatbot based on textual knowledge and reason-
ing. Knowledge-Based Systems, 22(4):249–255.
Kerlyl, A., Hall, P., and Bull, S. (2007). Bringing chat-
bots into education: Towards natural language negoti-
ation of open learner models. In Applications and In-
novations in Intelligent Systems XIV, pages 179–192.
Springer.
Mauldin, M. L. (1994). Chatterbots, tinymuds, and the tur-
ing test: Entering the loebner prize competition. In
AAAI, volume 94, pages 16–21.
Povey, D., Ghoshal, A., Boulianne, G., Burget, L., Glem-
bek, O., Goel, N., Hannemann, M., Motlicek, P., Qian,
Y., Schwarz, P., et al. (2011). The kaldi speech recog-
nition toolkit. Technical report, IEEE Signal Process-
ing Society.
Ryan, J. L., Crandall, R. L., and Medwedeff, M. C. (1966).
A conversational system for incremental compilation
and execution in a time-sharing environment. In Pro-
ceedings of the November 7-10, 1966, fall joint com-
puter conference, pages 1–21. ACM.
Shawar, B. A. and Atwell, E. (2007). Different measure-
ments metrics to evaluate a chatbot system. In Pro-
ceedings of the workshop on bridging the gap: Aca-
demic and industrial research in dialog technologies,
pages 89–96. Association for Computational Linguis-
tics.
Sieber, A. (2019). Dialogsysteme in der praxis. In Di-
alogroboter, pages 79–127. Springer.
Turing, A. (1950). Computing machinery and intelligence-
am turing. Mind, 59(236):433–460.
Weizenbaum, J. (1966). Eliza—a computer program for
the study of natural language communication between
man and machine. Communications of the ACM,
9(1):36–45.
Towards a Framework for Classifying Chatbots
501
