TASKWORK: A Cloud-aware Runtime System for Elastic Task-parallel

HPC Applications

Stefan Kehrer and Wolfgang Blochinger

Parallel and Distributed Computing Group, Reutlingen University, Germany

Keywords:

Cloud Computing, High Performance Computing, Task Parallelism, Elasticity of Parallel Computations.

Abstract:

With the capability of employing virtually unlimited compute resources, the cloud evolved into an attractive

execution environment for applications from the High Performance Computing (HPC) domain. By means

of elastic scaling, compute resources can be provisioned and decommissioned at runtime. This gives rise to

a new concept in HPC: Elasticity of parallel computations. However, it is still an open research question

to which extent HPC applications can beneﬁt from elastic scaling and how to leverage elasticity of parallel

computations. In this paper, we discuss how to address these challenges for HPC applications with dynamic

task parallelism and present TASKWORK, a cloud-aware runtime system based on our ﬁndings. TASKWORK

enables the implementation of elastic HPC applications by means of higher-level development frameworks and

solves corresponding coordination problems based on Apache ZooKeeper. For evaluation purposes, we discuss

a development framework for parallel branch-and-bound based on TASKWORK, show how to implement an

elastic HPC application, and report on measurements with respect to parallel efﬁciency and elastic scaling.

1 INTRODUCTION

The cloud evolved into an attractive execution en-

vironment for High Performance Computing (HPC)

workloads with beneﬁts such as on-demand access

to compute resources and pay-per-use (Netto et al.,

2018; Galante et al., 2016). Recently, Amazon

Web Services (AWS) and Microsoft Azure introduced

new cloud offerings optimized for HPC workloads.

Whereas traditional HPC clusters rely on static re-

source assignment, cloud offerings allow applications

to scale elastically, i.e., compute resources can be pro-

visioned and decommissioned at runtime. This gives

rise to a new concept in HPC: Elasticity of parallel

computations (Rajan and Thain, 2017; Galante et al.,

2016; Da Rosa Righi et al., 2016; Haussmann et al.,

2018). By leveraging elasticity, HPC applications

beneﬁt from ﬁne-grained cost control per application

run. For instance, processing time and/or the qual-

ity of results can be related to costs, allowing versa-

tile optimizations at runtime (Rajan and Thain, 2017;

Haussmann et al., 2018). But this novel opportunity

comes with many challenges that require research ef-

forts on all levels of parallel systems.

During the last years, there has been a growing in-

terest to make HPC applications cloud-aware (Gupta

et al., 2016; Gupta et al., 2013b; Da Rosa Righi et al.,

2016; Rajan et al., 2011). In particular, applications

have to cope with the effects of virtualization and re-

source pooling leading to ﬂuctuations in processing

times (Gupta et al., 2013b). Existing research also

shows how to employ elasticity for HPC applications

with simple communication and coordination patterns

(e.g., iterative-parallel workloads) (Rajan et al., 2011;

Da Rosa Righi et al., 2016). In these cases, problems

are iteratively decomposed into a set of independent

tasks, which can be farmed out for distributed com-

putation. However, it is still an open research ques-

tion to which extent other application classes from the

ﬁeld of HPC can beneﬁt from cloud-speciﬁc proper-

ties, how to leverage elasticity of parallel computa-

tions in these cases, and how to ensure cloud-aware

coordination of distributed compute resources.

In this paper, we discuss how to address these

challenges for HPC applications with dynamic task

parallelism. These applications are less sensitive

to heterogeneous processing speeds when compared

to data-intensive, tightly-coupled HPC applications

(Gupta et al., 2016; Gupta et al., 2013a), but comprise

unstructured interaction patterns and complex coor-

dination requirements. Prominent examples of this

application class include constraint satisfaction solv-

ing, graph search, n-body simulations, and raytracing

with applications in artiﬁcial intelligence, biochem-

198

Kehrer, S. and Blochinger, W.

TASKWORK: A Cloud-aware Runtime System for Elastic Task-parallel HPC Applications.

DOI: 10.5220/0007795501980209

In Proceedings of the 9th International Conference on Cloud Computing and Services Science (CLOSER 2019), pages 198-209

ISBN: 978-989-758-365-0

istry, electronic design automation, and astrophysics.

We discuss the challenges that have to be addressed

to make these applications cloud-aware and present

TASKWORK - a cloud-aware runtime system that

provides a solid foundation for implementing elas-

tic task-parallel HPC applications. In particular, we

make the following contributions:

• We present the conceptualization of a cloud-aware

runtime system for task-parallel HPC applica-

tions.

• We show how to leverage elasticity of paral-

lel computations and how to solve correspond-

ing coordination problems based on Apache

ZooKeeper

• We discuss a development framework for im-

plementing elastic branch-and-bound applications

with only minor effort required at the program-

ming level.

• We describe the design and implementation

of TASKWORK, an integrated runtime system

based on our ﬁndings, and report on performance

experiments in our OpenStack-based cloud envi-

ronment.

This paper is structured as follows. Sect. 2 describes

our conceptualization of a cloud-aware runtime sys-

tem for task-parallel HPC in the cloud. In Sect. 3, we

present TASKWORK - our integated runtime system

for elastic task-parallel HPC applications. We elabo-

rate on a branch-and-bound development framework

and describe its use in Sect. 4. The results of several

experiments related to parallel performance and elas-

tic scaling are presented in Sect. 5. Related work is

discussed in Sect. 6. Sect. 7 concludes this work.

2 CONCEPTUALIZATION OF A

CLOUD-AWARE RUNTIME

SYSTEM

To beneﬁt from cloud-speciﬁc characteristics, devel-

oping elastic HPC applications is a fundamental prob-

lem that has to be solved (Galante et al., 2016). At the

core of this problem lies the required dynamic adap-

tation of parallelism. At all times, the degree of log-

ical parallelism of the application has to ﬁt the phys-

ical parallelism given by the number of processing

units to achieve maximum efﬁciency. Traditionally,

the number of processing units has been considered as

static. In cloud environments, however, the number of

https://zookeeper.apache.org.

Scope of Runtime System

Task Generation

Load Balancing

Task Migration

Cloud Management

Program-level Parallelism

Logical Parallelism

(# of Tasks)

Physical Parallelism

(# of Processing Units)

Figure 1: Conceptualization of a cloud-aware runtime sys-

tem that adapts the logical parallelism, handles load balanc-

ing and task migration, and thus enables elastic scaling for

task-parallel HPC applications.

processing units can be scaled at runtime by employ-

ing cloud management tooling. As a result, applica-

tions have to dynamically adapt the degree of logical

parallelism based on a dynamically changing physi-

cal parallelism. At the same time, adapting the logi-

cal parallelism and mapping the logical parallelism to

the physical parallelism incurs overhead (in form of

excess computation, communication, and idle time).

Consequently, elastic HPC applications have to con-

tinuously consider a trade-off between the perfect ﬁt

of logical and physical parallelism on the one side and

minimizing overhead resulting from the adaptation of

logical parallelism and its mapping to the physical

parallelism on the other. Hence, ensuring elasticity

of parallel computations is a hard task as it intro-

duces new sources of overhead and thus leads to many

system-level challenges that have to be addressed to

ensure a high parallel efﬁciency.

Because we speciﬁcally focus on dynamic task

parallelism, the degree of logical parallelism can be

deﬁned as the current number of tasks. We argue that

a cloud-aware runtime system is required that trans-

parently controls the parallelism of an HPC applica-

tion to ensure elastic scaling. Fig. 1 shows our con-

ceptualization of such a runtime system. It allows

developers to mark parallelism in the program, auto-

matically adapts the logical parallelism by generating

tasks whenever required, and exploits available pro-

cessing units with maximum efﬁciency by mapping

the logical parallelism to the physical parallelism. An

application based on such a runtime system is elas-

tically scalable: Newly added compute nodes auto-

matically receive tasks by means of load balancing

and a task migration mechanism releases compute

nodes that have been selected for decommissioning

(cf. Fig. 1). Our approach is not limited to any spe-

ciﬁc cloud management approach or tooling: Cloud

management may comprise any kind of external deci-

sion making logic (e.g., based on processing time, the

TASKWORK: A Cloud-aware Runtime System for Elastic Task-parallel HPC Applications

199

quality of results, or costs) that ﬁnally adapts the num-

ber of processing units (i.e., the physical parallelism).

An example for such a cloud management approach

is given in (Haussmann et al., 2018), where costs are

considered to control the physical parallelism. In this

work, we focus on elasticity of parallel computations

and address related system-level challenges.

Besides elasticity, the characteristics of cloud en-

vironments lead to new architectural requirements

that have to be considered by HPC applications

(Kehrer and Blochinger, 2019). Due to virtualization

and resource pooling (leading to CPU timesharing

and memory overcommitment), ﬂuctuations in pro-

cessing times of individual processing units are the

common case (Gupta et al., 2016). Thus, in cloud en-

vironments processing units should be coupled in a

loosely manner by employing asynchronous commu-

nication mechanisms (e.g., for load balancing). Sim-

ilarly, inter-node synchronization should be loosely

coupled while guaranteeing individual progress. A

runtime system built for the cloud has to provide

such asynchronous communication and synchroniza-

tion mechanisms thus releasing developers from deal-

ing with these low-level complexities.

In this work, we show how to leverage elasticity

for applications with dynamic task parallelism. These

applications rely on dynamic problem decomposition

and thus support the generation of tasks at runtime.

Moreover, they are ideal candidates for cloud adop-

tion because they are less sensitive to heterogeneous

processing speeds when compared to data-intensive,

tightly-coupled HPC applications (Gupta et al., 2016;

Gupta et al., 2013a).

3 TASKWORK

In this section, we present TASKWORK, our cloud-

aware runtime system for task-parallel HPC applica-

tions, designed according to the principles discussed

in Sect. 2. TASKWORK comprises several interact-

ing components that enable elasticity of parallel com-

putations (cf. A , Fig. 2) and solve corresponding

coordination problems based on ZooKeeper (cf. B ,

Fig. 2). Based on these system-level foundations,

higher-level development frameworks and program-

ming models can be built (cf. C , Fig. 2), which facil-

itate the implementation of elastic HPC applications.

TASKWORK is implemented in Java and em-

ploys distributed memory parallelism by coordinating

a set of distributed compute nodes. TASKWORK’s

components are described in the following. At ﬁrst,

we brieﬂy describe the well-known task pool execu-

tion model that we use to manage tasks. Thereafter,

Development Frameworks / ProgrammingModels

Task-Parallel Applications

Leader Election

Task Pool Execution Model

Group Membership

ZooKeeper Client

Synchronization

Load Balancing

Task Migration

Termination Detection

ZooKeeper

TASKW RK

A A

Figure 2: TASKWORK is a cloud-aware runtime system

for elastic task-parallel HPC applications. Its components

support the construction of higher-level development frame-

works and programming models.

we provide details on ZooKeeper, which we employ

to solve coordination problems. Finally, we discuss

the components of TASKWORK.

3.1 Task Pool Execution Model

The task pool execution model (Grama et al., 2003)

decouples task generation and task processing by pro-

viding a data structure that can be used to store dy-

namically generated tasks and to fetch these tasks

later for processing. The task pool execution model is

fundamental for our runtime system to implement the

concepts depicted in Fig. 1: It manages tasks gener-

ated at runtime (deﬁning the logical parallelism) and

provides an appropriate interface for load balancing

and task migration mechanisms that enable elasticity

of parallel computations.

In general, a task pool can be implemented fol-

lowing a centralized or a distributed approach. A cen-

tralized task pool is located at a single node and ac-

cessible by all other nodes. To enable parallel pro-

cessing, tasks have to be transferred over the network.

By following this approach, there is a single instance

that has complete knowledge on the state of the sys-

tem, e.g., which node is executing which tasks. This

makes load balancing and coordination simple. How-

ever, the centralized approach becomes a sequential

bottleneck for a large number of nodes. On the other

hand, a distributed implementation leads to multiple

task pool instances, local to each node, forming a dis-

tributed task pool. The distributed task pool model de-

couples compute nodes from each other thus leading

to a highly scalable and asynchronous system. Fur-

ther, it enables local accesses to the task pool. On the

contrary, coordination becomes a non-trivial task by

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

200

following a distributed approach because nodes only

have partial knowledge. This speciﬁcally holds in

cloud environments, where compute nodes are pro-

visioned and decommissioned at runtime.

We favor the distributed task pool model, which,

in general, provides a better scalability (Poldner and

Kuchen, 2008) and leads to an asynchronous system,

thus matching the characteristics of cloud environ-

ments. To deal with the drawbacks of the distributed

task pool model, we enhance it with scalable coor-

dination and synchronization mechanisms based on

ZooKeeper.

3.2 ZooKeeper

ZooKeeper eases the implementation of primitives for

coordination, data distribution, synchronization, and

meta data management (Hunt et al., 2010). Its in-

terface allows clients to read from and write to a

tree-based data structure (consisting of data registers

called znodes). This data structure is replicated across

a set of ZooKeeper servers. Each server accepts client

connections and executes requests in FIFO order per

client session. Additionally, the API provides so-

called watches, which enable a client to receive no-

tiﬁcations of changes without polling. ZooKeeper

guarantees writes to be atomic; read operations are

answered locally by each server leading to eventual

consistency (Hunt et al., 2010). ZooKeeper’s design

ensures both high availability of stored data and high-

performance data access.

As the cloud is a highly dynamic and distributed

execution environment, coordination primitives such

as leader election and group membership are essen-

tially required. Based on ZooKeeper, leader elec-

tion and group membership can be implemented in a

straightforward manner (Junqueira and Reed, 2013).

However, speciﬁc challenges arise in the context of

the distributed task pool model: Global variables have

to be synchronized across tasks, which imposes addi-

tional dependencies, and as tasks can be generated at

each node, a termination detection mechanism is re-

quired to detect when the computation has been com-

pleted. We argue that ZooKeeper provides the means

to compensate the missing global knowledge in the

distributed task pool model and show how to solve

these problems.

3.3 Load Balancing

Load balancing is a fundamental aspect in cloud envi-

ronments to exploit newly added compute resources

efﬁciently. Moreover, it is a strong requirement of

applications with dynamic task parallelism due to dy-

namic problem decomposition. Load balancing can

be accomplished by either sending tasks to other com-

pute nodes (work sharing) or by fetching tasks from

other nodes (work stealing) (Blumofe et al., 1996).

As the transferral of tasks leads to overhead we fa-

vor work (task) stealing because communication is

only required when a compute node runs idle. In

TASKWORK, load balancing is accomplished by ob-

serving changes in the local task pool. Whenever the

local task pool is empty and all worker threads are

idle, task stealing is initiated. Task stealing is an ap-

proach where idle nodes send work requests to other

nodes in the cluster. These nodes answer the request

by sending a task from their local task pool to the re-

mote node.

Because the distributed task pool model lacks

knowledge about which compute nodes are busy and

which are idling, randomized task stealing has been

proven to yield the best performance (Blumofe and

Leiserson, 1999). However, in the cloud, the number

of compute nodes changes over time. Thus, up-to-

date information on the currently available compute

nodes is required. This information is provided by

the group membership component (cf. Fig. 2). Newly

added compute nodes automatically register them-

selves in ZooKeeper. Changes are obtained by all

other compute nodes by means of ZooKeeper watches

(Hunt et al., 2010).

3.4 Task Migration

To beneﬁt from elasticity, applications also have to

deal with the decommissioning of compute resources

at runtime. Hence, compute nodes that should be de-

commissioned have to send unﬁnished work to re-

maining nodes. This is ensured by the task migration

component. Whenever a compute node should be de-

commissioned, the task migration component stores

the current state of tasks being executed, stops the

worker thread, and sends all local tasks to remain-

ing nodes. To support task migration, developers sim-

ply specify an optimal interruption point in their pro-

gram. Therefore, the migrate operation can be used

to check if a task should be migrated (for an example

see Sect. 4.2). TASKWORK employs weak migra-

tion of tasks. This means that a serialized state gen-

erated from a task object is transferred across the net-

work. To facilitate the migration process, application-

speciﬁc snapshotting mechanisms can be provided by

developers.

TASKWORK: A Cloud-aware Runtime System for Elastic Task-parallel HPC Applications

201

3.5 Termination Detection

Traditionally, distributed algorithms (wave-based or

based on parental responsibility) have been preferred

for termination detection due to their superior scala-

bility characteristics (Grama et al., 2003). However,

maintaining a ring (wave-based) or tree (parental re-

sponsibility) structure across compute nodes in the

context of an elastically scaled distributed system im-

poses signiﬁcant overhead. To deal with this issue,

we propose a novel termination detection algorithm

based on ZooKeeper’s design principles.

Termination detection has to consider that tasks

are continuously generated at any time and on any

compute node in the system. However, an algorithm

can make use of the fact that new tasks are always

split from existing tasks, ultimately leading to a tree-

based task dependency structure. Our termination de-

tection algorithm employs this structure as follows:

Every task in the system maintains a list of its chil-

dren. During the lifecycle of a task, the taskID of

a child task is appended to this list when it is split

from the parent task. Moreover, we make use of a

global task list that is updated whenever a task is com-

pleted. To initialize this global task list, the taskID

of the root task is added to the list. At runtime, we

update the global task list for every completed task

considering its taskID as well as the taskIDs of all its

child tasks. Such an update procedure works as fol-

lows: Each taskID is either added to the global list if

it is not contained in the global list or removed from

the global list if it is contained. By following this up-

date procedure, termination can be deduced from an

empty global task list because all taskIDs are added

and removed exactly once: Either by an update pro-

cedure triggered after the task has been completed or

by an update procedure triggered by the completion

of the task’s parent task. To ensure that each taskID

leads to exactly two updates, TASKWORK guaran-

tees that tasks are completed exactly once. Based on

this assumption, our termination detection algorithm

ensures that the update procedure leads to exactly one

create and exactly one delete operation per taskID.

In the following, we describe our ZooKeeper-

based implementation that is comprised of two parts:

One for a coordinator that is determined with the

leader election component (cf. Algorithm 1) and one

for compute nodes (cf. Algorithm 2). The global task

list is stored in ZooKeeper and initialized with the

taskID of the root task (cf. Algorithm 1, C-1). This

is required because the root task has no parent task,

i.e., the update procedure with its taskID is triggered

only once: After the completion of the root task. At

runtime, a ﬁnite number of update operations add or

Algorithm 1: Termination Detection - Coordinator.

Task Pool, instance tp.

Application, instance app.

ZooKeeper Client, instance zk.

1: upon event <Init> do  C-0

2: if !zk.exists('/globallist') then

3: zk.create('/globallist');

4: end if

5: if !zk.exists('/txnIDs') then

6: zk.create('/txnIDs');

7: end if

8: upon event <tp, RootTaskEnqued | task> do  C-1

9: zk.getChildren('/globallist');

10: zk.create('/globallist/' + TaskID(task));

11: upon event <zk, Watch | w> do  C-2

12: if Type(w) = NodeChildrenChanged then

13: if zk.getChildren('/globallist') =

0 then

14: trigger <app, Terminated>

15: end if

16: end if

remove taskIDs. Termination can be deduced by the

coordinator from an empty global task list. There-

fore, a ZooKeeper watch is set to receive notiﬁcations

on changes of the list. C-2 of Algorithm 1 triggers a

termination event if all taskIDs have been removed.

Algorithm 2 implements the mechanisms to up-

date the task list at runtime. An update is executed

by the TrackTasks procedure, which is called by a

worker thread whenever a task is completed (cf. Al-

gorithm 2, CN-0). If a speciﬁc taskID is contained in

the task list, we request the removal of this taskID (cf.

Algorithm 2, line 12). If a taskID is not contained,

we request its creation (line 14). To avoid false posi-

tive termination decisions, we have to ensure that the

update procedure is executed atomically. We employ

ZooKeeper transactions to enforce an atomic update

of the global task list. This guarantees that termina-

tion cannot be detected due to an intermediate system

state, in which the global task list is empty until the

full update procedure (related to a single completed

task) has been executed. As the transaction might

fail, e.g., if a taskID should be created that has been

created by another compute node before our transac-

tion gets processed by ZooKeeper, we pass an asyn-

chronous callback to the commit operation that han-

dles potential failures (cf. Algorithm 2, line 17). In

the following, we discuss these potential failures.

We constructed the transaction as a set of create

and delete operations. Each create operation might

fail. In case of such a failure, another compute

node added the taskID before the local request was

processed. Moreover, delayed reads might lead to

a falsely constructed create operation. On the other

hand, delete operations are executed exactly once

because they are only requested if the corresponding

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

202

Algorithm 2: Termination Detection - Compute Node.

Worker Thread, instance wt.

ZooKeeper Client, instance zk.

1: upon event <wt, completedTask | task> do  CN-0

2: taskIDs ← TaskID(task) ∪ ChildTaskIDs(task);

3: TRACKTASKS(TASKIDS, NULL);

4: procedure TRACKTASKS(taskIDs, txnID)  CN-1

5: txn ← zk.transaction();

6: if txnID = null then

7: txnID ← generateTxnID();

8: end if

9: txn.create('/txnIDs/' + txnID);

10: for each taskID ∈ taskIDs do

11: if zk.exists('/globallist/' + taskID) then

12: txn.delete('/globallist/' + taskID);

13: else

14: txn.create('/globallist/' + taskID);

15: end if

16: end for

17: txn.commit(TXNCALLBACK, taskIDs, txnID);

18: end procedure

19: procedure TXNCALLBACK(taskIDs, txnID)  CN-2

20: if failed ∨ lost connection then

21: if !zk.exists('/txnIDs/' + txnID) then

22: TRACKTASKS(TASKIDS, TXNID);

23: end if

24: end if

25: end procedure

taskID is contained in the list (cf. Algorithm 2, line

11-12). Additionally, connection losses might also

lead to a failed transaction and, by default, handling

connection losses is a non-trivial task with ZooKeeper

(Junqueira and Reed, 2013). There are cases, in which

we cannot know if a transaction, which is interrupted

by a connection loss, has been processed or not. Sim-

ply executing the transaction again could compromise

our termination detection algorithm, ﬁnally leading to

a false positive or missing termination event. In the

following, we describe how our algorithm deals with

these issues.

CN-2 of Algorithm 2 shows the implementation of

the TxnCallback procedure, which handles the fail-

ures described above. Therefore, transactions that fail

are simply retried by calling the TrackTasks pro-

cedure again. To deal with connection losses, how-

ever, we enhanced the presented algorithm to in-

clude an additional create operation in each trans-

action constructed by the TrackTasks procedure.

This operation creates a unique znode /txnIDs/txnID,

where txnID is a globally unique ID generated for

each transaction (cf. Algorithm 2, line 6-8). This

allows us to check if a transaction has been pro-

cessed or not in case of a connection loss. CN-

2 of Algorithm 2 employs the txnID to avoid a re-

peated execution of committed transactions thus mak-

ing them idempotent. Even if the txnID exists but we

read an outdated ZooKeeper server state (in which

it seems to be nonexistent), the txnID passed to

the TrackTasks procedure avoids a repeated com-

mit thus ﬁnally maintaining a consistent system state.

As ZooKeeper guarantees that clients read up-to-date

values within a certain time bound, retrying a commit

of a transaction with an existing txnID stops eventu-

ally (cf. Algorithm 2, CN-2).

Our termination detection algorithm makes use

of ZooKeeper’s design principles by employing (1)

watches and notiﬁcations to be informed on relevant

updates to the system state, (2) fast read operations

for ensuring high-performance transaction construc-

tion, (3) asynchronous execution of operations for

non-blocking system behavior

, and (4) ZooKeeper’s

atomic writes and transactions in conjunction with

TASKWORK’s exactly once completion to ensure a

consistent system state.

3.6 Synchronization of Global Variables

Many non-trivial task-parallel applications require the

synchronization of global variables across tasks at

runtime. This synchronization leads to additional task

interaction patterns that the runtime system has to

cope with. TASKWORK’s synchronization compo-

nent allows developers to easily deﬁne global vari-

ables that are transparently shared across tasks.

Synchronization considers three hierarchy lev-

els: (1) task-level variables, which are updated for

each task executed by a worker thread, (2) node-

level variables, which are updated on each com-

pute node, and (3) global variables. Task-level vari-

ables are typically updated by the implemented pro-

gram and thus managed by the developer. To syn-

chronize node-level variables, we provide two opera-

tions: getVar for obtaining node-level variables and

setVar for setting node-level variables. Whenever

a node-level variable changes its value, we employ

ZooKeeper to update this variable globally, which en-

ables synchronization across all distributed compute

nodes. These generic operations allow developers to

address application-speciﬁc synchronization require-

ments, while TASKWORK handles the process of

synchronization.

3.7 Development Frameworks

TASKWORK is speciﬁcally designed for applications

with dynamic task parallelism and provides a generic

Note that we employed ZooKeeper’s asynchronous

API for all interactions with ZooKeeper. In some cases,

we used a synchronous-looking notation in the algorithmic

descriptions only for the purpose of better readability.

TASKWORK: A Cloud-aware Runtime System for Elastic Task-parallel HPC Applications

203

task abstraction that allows the speciﬁcation of cus-

tom task deﬁnitions. As described in Sect. 2, de-

velopers only mark program-level parallelism while

task generation, load balancing, and task migration

are handled automatically thus ensuring elasticity of

parallel computations. Therefore, developers specify

an application-speciﬁc split operation based on the

generic task abstraction to split work from an exist-

ing task. Afterwards, this split operation can be

used for implementing any application program that

dynamically creates tasks at runtime (for an example

see Sect. 4.2). To enable elasticity of parallel com-

putations, TASKWORK provides an execution mode

called potential splitting that adapts the logical paral-

lelism (number of tasks) in an automated manner. In

this mode, developers also implement the split op-

eration, but only specify a potential splitting point in

their application program with the potentialSplit

operation. Thus, the potentialSplit operation is

used to mark program-level parallelism. At runtime,

TASKWORK decides whether to create new tasks or

not depending on the current system load. Poten-

tial splitting automatically adapts the amount of tasks

generated and thus controls the logical parallelism of

the application (cf. Fig. 1). As a result, TASKWORK

manages the trade-off between perfect ﬁt of logical

and physical parallelism and minimizing overhead re-

sulting from task generation and task mapping as dis-

cussed in Sect. 2.

4 BRANCH-AND-BOUND

DEVELOPMENT

FRAMEWORK

We describe a development framework for par-

allel branch-and-bound applications based on

TASKWORK. Branch-and-bound is a well-known

meta-algorithm for solving search and optimization

problems with numerous applications in biochem-

istry, pattern recognition, ﬁnite geometry, model

checking, and ﬂeet and vehicle scheduling. In the

following, we brieﬂy explain the branch-and-bound

approach and employ our framework to develop an

example application.

4.1 Branch-and-Bound Applications

and the TSP

We explain the branch-and-bound approach by em-

ploying the Traveling Salesman Problem (TSP) as ex-

ample application. We chose the TSP as a represen-

tative application due to its wide use in research and

State

Scope of a Task

… …

…

Figure 3: For parallelization, we cut the state space tree of

a problem into several tasks, each capturing a subproblem

of the initial problem. However, because states in the state

space tree are explored as the computation proceeds, tasks

containing these states have to be created at runtime to avoid

load imbalance.

industry. The TSP states that a salesman has to make

a tour visiting n cities exactly once while ﬁnishing at

the city he starts from. The problem can be modeled

as a complete graph with n vertices, where each ver-

tex represents a city and each edge a path between

two cities. A nonnegative cost c(i, j ) occurs to travel

from city i to city j. The optimization goal is to ﬁnd a

tour whose total cost, i.e., the sum of individual costs

along the paths, is minimum (Cormen et al., 2009).

All feasible tours can be explored systematically

by employing a state space tree that enumerates all

states of the problem. The initial state (root of the

state space tree) is represented by the city the sales-

man starts from. From this (and all following states),

the salesman can follow any path to travel to one of

the unvisited cities, which leads to a new state. At

some point in time, all cities have been visited thus

leading to a leaf state, which represents a tour. Each

state can be evaluated with respect to its cost by sum-

ming up the individual costs of all paths taken. This

also holds for leaf states representing a tour. A search

procedure can be applied that dynamically explores

the complete state space tree and ﬁnally ﬁnds a tour

with minimum cost. However, brute force search can-

not be applied to large state space trees efﬁciently.

Instead of enumerating all possible states, branch-

and-bound makes use of existing knowledge to search

many paths in the state space tree only implicitly. The

following four operations enable an efﬁcient search

procedure:

Branching: If the current state is not a leaf state,

the next level of child states is generated by visiting

all unvisited cities that are directly accessible. Each

of these child states leads to a set of disjoint tours.

Evaluation: If the current state is a leaf state, we

evaluate the tour represented by this state with respect

to its total cost.

Bounding: At runtime, the tour whose total cost

is known to be minimum at a speciﬁc point in time

deﬁnes an upper bound for the ongoing search pro-

cedure. Any intermediate state in the state space tree

that evaluates to a higher cost can be proven to lead

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

204

to a tour with higher total costs and thus has not to be

explored any further. Moreover, lower bounds can be

calculated by solving a relaxed version of the problem

based on the current state (Sedgewick, 1984).

Pruning: We can prune parts of the state space

tree if the calculated lower bound of the current state

is larger or equal to the current upper bound. The

pruning operation is essential to make branch-and-

bound efﬁcient.

Following a branch-and-bound approach, a prob-

lem is decomposed into subproblems at runtime.

Each of these subproblems captures several states

of the state space tree and can be solved in paral-

lel. Technically, these subproblems are captured in

a set of tasks, which can be distributed across avail-

able compute nodes. However, several challenges

arise when we map branch-and-bound applications to

parallel and distributed architectures: Pruning intro-

duces work anomalies, which means that the amount

of work differs between sequential and parallel pro-

cessing as well as across parallel program runs due

to non-determinism of message delivery. Addition-

ally, the workload of branch-and-bound applications

is highly irregular, i.e., task sizes are not known a pri-

ori and unpredictable by nature. Consequently, solv-

ing the TSP requires the runtime system to cope with

dynamic problem decomposition and load balancing

to avoid idle processors. Every task that captures

a speciﬁc subproblem can produce new child tasks

(cf. Fig. 3). Thus, termination detection is another

strong requirement to detect if a computation has been

completed. Additionally, updates on the upper bound

have to be distributed fast to enable efﬁcient pruning

for subproblems processed simultaneously in the dis-

tributed system.

4.2 Design and Use of the Development

Framework

In the following, we describe a development frame-

work for parallel branch-and-bound on top of

TASKWORK. We employ the TSP as an example ap-

plication to show how to use the framework. Parallel

applications can be built with this framework without

considering low-level, technical details.

TASKWORK provides a generic task abstraction

that can be used to build new development frame-

works. In this context, we deﬁne a task as the traver-

sal of the subtrees rooted at all unvisited input states.

Additionally, each task has access to the graph struc-

ture describing the cities as vertices and the paths as

edges. This graph structure guides the exploratory

construction of the state space tree. All visited states

are marked in the graph. This representation allows

1 public void search() {

2 while(!openStates.isEmpty()){

3 if(migrate() ) return;

5 State currentState = openStates.getNext();

7 getUpperBound();

9 State[] children = currentState.branch();

10 for(State child : children) {

11 if(child.isLeafState()) {

12 if(child.getCost() < current_best_cost){

13 current_best_cost = child.getCost();

14 current_best_tour = child.getPath();

15 setUpperBound();

16 }

17 }else if(child.getLowerBound() < current_best_cost){

18 openStates.add(child);

19 }

20 }

22 potentialSplit();

23 }

24 }

Figure 4: The branch-and-bound development framework

allows developers to implement parallel search procedures

without considering low-level details such as concurrency,

load balancing, synchronization, and task migration.

to split the currently traversed state space tree to gen-

erate new tasks.

New tasks have to be created at runtime to

keep idling processors (and newly added ones)

busy. Therefore, the branch-and-bound task deﬁni-

tion allows the speciﬁcation of an application-speciﬁc

split operation. This operation branches the state

space tree by splitting off a new task from a cur-

rently executed task. This split-off task can be pro-

cessed by another worker thread running on another

compute node. To limit the amount of tasks gener-

ated, we make use of TASKWORK’s potential splits,

i.e, the split operation is only triggered, when new

tasks are actually required. As depicted in Fig. 4,

here, the potentialSplit operation is executed af-

ter a state has been evaluated. TASKWORK decides

if a split is required. If so, it executes the application-

speciﬁc split operation that takes tasks from the

openStates list to create a new (disjoint) task. Oth-

erwise it proceeds normally, i.e., it evaluates the next

state in the state space tree.

Task Migration: To enable task migration, de-

velopers check if migration is required (cf. Fig. 4). In

this case, a task simply stops its execution. The mi-

gration process itself is handled by TASKWORK (cf.

Sect. 3.4).

Bound Synchronization: Pruning is based on a

global upper bound. In case of the TSP, the total

cost of the best tour currently known is used as the

global upper bound. The distribution of the current

upper bound is essential to eliminate excess com-

putation (due to an outdated value). By employing

the synchronization component (cf. Sect. 3.6), we

initiate an update of the global upper bound when-

TASKWORK: A Cloud-aware Runtime System for Elastic Task-parallel HPC Applications

205

Table 1: Performance measurements of TSP instances.

Problem

Instance

[s]

(1 VM)

[s]

(60 VMs)

Speedup

(60 VMs)

Efﬁciency

(60 VMs)

TSP35

1195 32.9 ± 2.0 36.3 0.60

TSP35

1231 55.7 ± 4.0 22.1 0.37

TSP35

2483 103.5 ± 2.1 24.0 0.40

TSP35

3349 115.5 ± 6.3 29.0 0.48

TSP35

10286 167.4 ± 12.4 59.5 0.99

ever the local upper bound is better then the cur-

rent global upper bound observed. Technically, we

specify an update rule that compares the total costs

of two tours. If a better upper bound has been

detected, TASKWORK ensures that the new upper

bound is propagated through the hierarchy levels.

getUpperBound and setUpperBound (cf. Fig. 4) are

implemented based on the getVar and setVar oper-

ations (cf. Sect. 3.6).

Termination Detection: Termination detection is

transparently handled by TASKWORK.

5 EVALUATION

Our evaluation is threefold: (1) We report on the

parallel performance and scalability by measuring

speedups and efﬁciencies. (2) We measure the effects

of elastic scaling on the speedup of an application.

(3) Moreover, because TASKWORK heavily relies on

ZooKeeper, we provide several results that show that

ZooKeeper ﬁts our architectural requirements. For

evaluation purposes, we employ the TSP application

implemented with the parallel branch-and-bound de-

velopment framework.

Setup. TASKWORK compute nodes are oper-

ated on CentOS 7 virtual machines (VM) with 1

vCPU clocked at 2.6 GHz, 2 GB RAM, and 40 GB

disk. All VMs are deployed in our OpenStack-based

cloud environment. The underlying hardware con-

sists of identical servers, each equipped with two Intel

Xeon E5-2650v2 CPUs and 128 GB RAM. The vir-

tual network connecting tenant VMs is operated on a

10 GBit/s physical ethernet network. Each compute

node runs a worker thread and is connected to one of

three ZooKeeper servers (forming a ZooKeeper clus-

ter). Our experiments were performed during regular

multi-tenant operation.

Parallel Performance & Scalability. To evalu-

ate the parallel performance, we solved 5 randomly

generated instances of the 35 city symmetric TSP.

Speedups and efﬁciencies are based on the runtime

of a sequential implementation executed by a sin-

gle thread on the same VM type. We calculate the

lower bound (cf. Sect. 4.1) by adding the weight of a

minimum spanning tree (MST) of the not-yet visited

cities to the current path (Sedgewick, 1984; Archibald

et al., 2018). The MST itself is calculated based on

Prim’s algorithm (Prim, 1957). Table 1 shows the re-

sults of our measurements with three parallel program

runs per TSP instance. As we can see, the measured

performance is highly problem-speciﬁc. Note that,

as mentioned in Sect. 4.1, the pruning operation re-

sults in work anomalies, which means that the total

amount of work differs signiﬁcantly between sequen-

tial and parallel processing as well as across parallel

program runs thus rendering a systematic evaluation

of the system’s scalability infeasible. To deal with

this problem, we disabled pruning for our scalability

measurements. Fig. 5 shows the measured scalabil-

ity for two TSP instances with 14 and 15 cities with

a sequential runtime T

of 1170 and 16959 seconds,

respectively.

Elastic Scaling. Compute resources can be provi-

sioned or decommissioned easily by employing cloud

management tooling. However, to leverage elastic-

ity of parallel computations, the fundamental ques-

tion is: How fast can resources be effectively em-

ployed by an HPC application? This is a completely

new viewpoint from which cloud-aware parallel sys-

tems have to be evaluated. Traditional HPC metrics

do not cover this temporal aspect of elasticity. In the

following, we present an experiment that shows the

capability of TASKWORK to dynamically adapt to a

changing number of resources while maximizing the

speedup of the computation. To avoid work anoma-

lies, we disabled pruning to evaluate elastic scaling.

All measurements are based on the TSP instance with

14 cities.

Our experiment is described in Fig. 6 and com-

100

10 20 30 40 50 60

Parallel Efficiency [%]

▲

Speedup [#]

■

Compute Nodes (VMs) [#]

Speedup (TSP14)

Speedup (TSP15)

Efficiency (TSP14)

Efficiency (TSP15)

Figure 5: Speedups and efﬁciencies given are arithmetic

means based on 3 parallel program runs for 6 setups lead-

ing to 36 measurements in total. The highest and lowest

measured values per setup are depicted accordingly.

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

206

Compute Nodes (VMs) [#]

Runtime [s]

Phase P

10 VMs

1 2

50 VMs

40 VMs

30 VMs

20 VMs

Figure 6: To evaluate the elasticity of parallel computations,

we adapt the physical parallelism (given by the compute re-

sources employed) at times t

and t

and measure the effects

on the speedup S

prises three phases. We start our application with 10

compute nodes (VMs) in Phase P

. At time t

, we

scale out by adding more VMs to the computation.

To abstract from platform-speciﬁc VM startup times,

we employ VMs that are already running. At time

, we decommission the VMs added at t

. At phase

transition 1 , TASKWORK ensures task generation

and efﬁcient load balancing to exploit newly added

compute nodes. At phase transition 2 , the task mi-

gration component ensures graceful decommission-

ing of compute nodes (cf. Sect. 3.4). We can easily

see if newly added compute resources contribute to

the computation by comparing the measured speedup

(speedup with elastic scaling) with the baseline

speedup S

that we measured for a static setting with

10 VMs. To see how effectively new resources are

employed by TASKWORK, we tested several dura-

tions for Phase P

as well as different numbers of

VMs added (cf. Fig. 6) and calculated the percentage

change in speedup S

as follows:

− S

· 100 (1)

allows us to quantify the relative speedup im-

provements based on elastic scaling. Both S

and S

are arithmetic means calculated based on three pro-

gram runs. Fig. 7 shows the percentage change in

speedup achieved for different durations of Phase P

and different numbers of VMs added to the computa-

tion at runtime. 40 VMs added (leading to 50 VMs

in total) can be effectively employed in 15 seconds.

Higher speedup improvements can be achieved by in-

creasing the duration of Phase P

. We also see that for

a duration of 10 seconds, adding 40 VMs even leads to

a decrease in speedup whereas adding 20 VMs leads

to an increase in speedup (for the same duration). This

effect results from the higher parallel overhead (in

form of task generation, load balancing, and task mi-

gration) related to adding a higher number of VMs.

On the other hand, as expected, for higher durations

of Phase P

, employing a higher number of VMs leads

to better speedups. Note that the percentage of time

-10

0 5 10 15 20 25 30

Percentage Change in Speedup [%]

Duration of Phase P

[s]

20 VMs

30 VMs

40 VMs

50 VMs

Figure 7: We calculated the percentage change in speedup

based on different durations of Phase P

and different num-

bers of VMs added to the computation. The legend shows

the total number of VMs employed in Phase P

spent in Phase P

(with respect to the total runtime)

affects the actual percentage change in speedup, but

not the effects that we have described.

ZooKeeper. Because TASKWORK heavily re-

lies on ZooKeeper, we evaluate two fundamental as-

pects of our implementation: Its read/write ratio and

the usefulness of our termination detection algorithm.

For the termination detection algorithm, we measured

a read/write ratio of 2.6:1 on average. For group

membership, load balancing, and variable synchro-

nization each write operation leads to n reads, where

n is the number of compute nodes. Consequently,

our workload ﬁts ZooKeeper’s design principles as

it is built for systems with a read/write ratio of at

least 2:1 (Hunt et al., 2010). Further, we evaluate

our termination detection algorithm. For the termi-

nation detection algorithm, performance degradation

results from retrying to many operations due to con-

tention thus leading to excess computation. Hence, in

our case, we have to ensure that retrying transactions

does not dominate the execution time of the algorithm

(cf. Sect. 3.5). Additionally, replication of data across

ZooKeeper servers ampliﬁes this problem by provid-

ing a worse data accuracy. However, for our example

application, we measured that roughly 2% of all trans-

actions have been retried on average, which is a negli-

gible overhead and thus emphasizes the advantage of

our implementation.

6 RELATED WORK

It has been widely recognized that HPC applications

have to be adapted towards cloud-speciﬁc characteris-

tics to beneﬁt from on-demand resource access, elas-

ticity, and pay-per-use (Netto et al., 2018; Rajan et al.,

2011; Parashar et al., 2013; Rajan and Thain, 2017).

The authors of (Galante et al., 2016) propose the de-

TASKWORK: A Cloud-aware Runtime System for Elastic Task-parallel HPC Applications

207

velopment of new frameworks for building HPC ap-

plications optimized for cloud environments and dis-

cuss the importance of application support with re-

spect to elasticity. We follow this approach by pre-

senting a runtime system that does most of the heavy

lifting to implement cloud-aware HPC applications.

In (Gupta et al., 2016) an in-depth performance

analysis of different HPC applications is presented.

Based on their measurements, the authors describe

several strategies to make HPC applications cloud-

aware. A major issue is the speciﬁcation of the opti-

mal task size to balance various sources of overhead.

The authors of (Gupta et al., 2013b) address the

problem of ﬂuctuations in processing times, which

speciﬁcally affects tightly-coupled HPC applications.

A dynamic load balancer is introduced that continu-

ously monitors the load of each vCPU and reacts to

a measured imbalance. Whereas the authors rely on

overdecomposition to ensure dynamic load balancing,

our runtime system actively controls the logical paral-

lelism of an application to minimize task management

overhead. However, it is still an open research ques-

tion if applications without dynamic task parallelism

can beneﬁt from such an approach.

In (Da Rosa Righi et al., 2016), the authors enable

elasticity for iterative-parallel applications by em-

ploying a master/worker architecture. They make use

of an asynchronous elasticity mechanism that enables

scaling operations without blocking the application.

Whereas we speciﬁcally consider dynamic task par-

allelism, our runtime system also makes use of asyn-

chronous scaling operations. Moreover, our runtime

system handles communication and synchronization

asynchronously to hide network latencies and ﬂuctu-

ations in processing times.

Task-based parallelism was originally designed to

exploit shared memory architectures and used by sys-

tems such as Cilk (Blumofe et al., 1996). A major

characteristic of task-parallel approaches is that tasks

can be assigned dynamically to worker threads, which

ensures load balancing and thus effectively reduces

idle time. This approach also provides attractive ad-

vantages beyond shared memory architectures and

has been adopted for different environments includ-

ing clusters (Archibald et al., 2018) and grids (Anstre-

icher et al., 2002). As a result, the distributed task

pool model has been actively researched. The authors

of (Poldner and Kuchen, 2008) present a skeleton for

C++, which supports distributed memory parallelism

for branch-and-bound applications. Their skeleton

uses MPI communication mechanisms. The authors

of (Cunningham et al., 2014) propose a termination

detection mechanism based on ZooKeeper. However,

in contrast to our algorithm, their approach employs

the synchronous API of ZooKeeper. COHESION is

a microkernel-based platform for desktop grid com-

puting (Schulz et al., 2008; Blochinger et al., 2006).

It has been designed for task-parallel problems with

dynamic problem decomposition and tackles the chal-

lenges of desktop grids such as limited connectivity.

In this work, we present an approach to enable elastic

task-parallelism in cloud environments.

7 CONCLUSION AND FUTURE

WORK

In this work, we addressed several system-level chal-

lenges related to task-parallel HPC in the cloud and

presented a novel runtime system that manages the

complexities of cloud-aware applications. We showed

how to solve several coordination problems with

ZooKeeper and enhanced the well-known distributed

task pool execution model. Elasticity of parallel com-

putations is enabled by means of load balancing, task

migration, and application-speciﬁc task generation,

which requires only minor effort at the programming

level. Whereas our development framework is specif-

ically designed for branch-and-bound applications,

other applications with dynamic task parallelism such

as n-body simulations (Hannak et al., 2012) might

also beneﬁt from TASKWORK’s architecture.

Many research challenges are left on the path to-

wards cloud-aware HPC applications. Most interest-

ingly, it is not fully understood how to deal with mon-

etary costs of parallel computations in the cloud. To

ultimately beneﬁt from elastic scaling and pay-per-

use, new cost models are required. Speciﬁcally, ir-

regular task-parallel applications with unpredictable

resource requirements may beneﬁt from elasticity. In

this context, we are conﬁdent that TASKWORK pro-

vides a solid foundation for future research activi-

ties. We also plan to investigate container virtual-

ization for deploying HPC applications to cloud envi-

ronments (Kehrer and Blochinger, 2018b; Kehrer and

Blochinger, 2018a).

ACKNOWLEDGEMENTS

This research was partially funded by the Ministry

of Science of Baden-W

urttemberg, Germany, for the

Doctoral Program Services Computing.

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

208

REFERENCES

Anstreicher, K., Brixius, N., Goux, J.-P., and Linderoth, J.

(2002). Solving large quadratic assignment problems

on computational grids. Mathematical Programming,

91(3):563–588.

Archibald, B., Maier, P., McCreesh, C., Stewart, R., and

Trinder, P. (2018). Replicable parallel branch and

bound search. Journal of Parallel and Distributed

Computing, 113:92 – 114.

Blochinger, W., Dangelmayr, C., and Schulz, S. (2006).

Aspect-oriented parallel discrete optimization on the

cohesion desktop grid platform. In Cluster Computing

and the Grid, 2006. CCGRID 06. Sixth IEEE Interna-

tional Symposium on, volume 1, pages 49–56.

Blumofe, R. D., Joerg, C. F., Kuszmaul, B. C., Leiserson,

C. E., Randall, K. H., and Zhou, Y. (1996). Cilk:

An efﬁcient multithreaded runtime system. Journal

of Parallel and Distributed Computing, 37(1):55 – 69.

Blumofe, R. D. and Leiserson, C. E. (1999). Schedul-

ing multithreaded computations by work stealing. J.

ACM, 46(5):720–748.

Cormen, T., Leiserson, C., Rivest, R., and Stein, C. (2009).

Introduction to algorithms (3rd ed.).

Cunningham, D., Grove, D., Herta, B., Iyengar, A.,

Kawachiya, K., Murata, H., Saraswat, V., Takeuchi,

M., and Tardieu, O. (2014). Resilient x10: Efﬁcient

failure-aware programming. In Proceedings of the

19th ACM SIGPLAN Symposium on Principles and

Practice of Parallel Programming, PPoPP ’14, pages

67–80, New York, NY, USA. ACM.

Da Rosa Righi, R., Rodrigues, V. F., Da Costa, C. A.,

Galante, G., De Bona, L. C. E., and Ferreto, T. (2016).

Autoelastic: Automatic resource elasticity for high

performance applications in the cloud. IEEE Trans-

actions on Cloud Computing, 4(1):6–19.

Galante, G., De Bona, L. C. E., Mury, A. R., Schulze,

B., and Da Rosa Righi, R. (2016). An analysis of

public clouds elasticity in the execution of scientiﬁc

applications: a survey. Journal of Grid Computing,

14(2):193–216.

Grama, A., Gupta, A., Karypis, G., and Kumar, V. (2003).

Introduction to Parallel Computing. Pearson Educa-

tion, second edition.

Gupta, A., Faraboschi, P., Gioachin, F., Kale, L. V., Kauf-

mann, R., Lee, B., March, V., Milojicic, D., and Suen,

C. H. (2016). Evaluating and improving the perfor-

mance and scheduling of hpc applications in cloud.

IEEE Transactions on Cloud Computing, 4(3):307–

321.

Gupta, A., Kale, L. V., Gioachin, F., March, V., Suen, C. H.,

Lee, B. S., Faraboschi, P., Kaufmann, R., and Miloji-

cic, D. (2013a). The who, what, why, and how of high

performance computing in the cloud. In IEEE 5th In-

ternational Conference on Cloud Computing Technol-

ogy and Science, volume 1, pages 306–314.

Gupta, A., Sarood, O., Kale, L. V., and Milojicic, D.

(2013b). Improving hpc application performance

in cloud through dynamic load balancing. In

13th IEEE/ACM International Symposium on Cluster,

Cloud, and Grid Computing, pages 402–409.

Hannak, H., Blochinger, W., and Trieﬂinger, S. (2012). A

desktop grid enabled parallel barnes-hut algorithm. In

2012 IEEE 31st International Performance Comput-

ing and Communications Conference, pages 120–129.

Haussmann, J., Blochinger, W., and Kuechlin, W. (2018).

Cost-efﬁcient parallel processing of irregularly struc-

tured problems in cloud computing environments.

Cluster Computing.

Hunt, P., Konar, M., Junqueira, F. P., and Reed, B. (2010).

Zookeeper: Wait-free coordination for internet-scale

systems. In Proceedings of the 2010 USENIX Con-

ference on USENIX Annual Technical Conference,

USENIXATC’10, pages 11–11, Berkeley, CA, USA.

Junqueira, F. and Reed, B. (2013). ZooKeeper: distributed

process coordination. O’Reilly Media, Inc.

Kehrer, S. and Blochinger, W. (2018a). Autogenic: Au-

tomated generation of self-conﬁguring microservices.

In Proceedings of the 8th International Conference on

Cloud Computing and Services Science - Volume 1:

CLOSER,, pages 35–46. INSTICC, SciTePress.

Kehrer, S. and Blochinger, W. (2018b). Tosca-based con-

tainer orchestration on mesos. Computer Science -

Research and Development, 33(3):305–316.

Kehrer, S. and Blochinger, W. (2019). Migrating parallel

applications to the cloud: assessing cloud readiness

based on parallel design decisions. SICS Software-

Intensive Cyber-Physical Systems.

Netto, M. A. S., Calheiros, R. N., Rodrigues, E. R., Cunha,

R. L. F., and Buyya, R. (2018). Hpc cloud for sci-

entiﬁc and business applications: Taxonomy, vision,

and research challenges. ACM Computing Surveys

(CSUR), 51(1):8:1–8:29.

Parashar, M., AbdelBaky, M., Rodero, I., and Devarakonda,

A. (2013). Cloud paradigms and practices for com-

putational and data-enabled science and engineering.

Computing in Science Engineering, 15(4):10–18.

Poldner, M. and Kuchen, H. (2008). Algorithmic skeletons

for branch and bound. In Filipe, J., Shishkov, B., and

Helfert, M., editors, Software and Data Technologies,

pages 204–219, Berlin, Heidelberg. Springer.

Prim, R. C. (1957). Shortest connection networks and some

generalizations. The Bell System Technical Journal,

36(6):1389–1401.

Rajan, D., Canino, A., Izaguirre, J. A., and Thain, D.

(2011). Converting a high performance application

to an elastic cloud application. In IEEE Third Inter-

national Conference on Cloud Computing Technology

and Science (CloudCom), pages 383–390.

Rajan, D. and Thain, D. (2017). Designing self-tuning

split-map-merge applications for high cost-efﬁciency

in the cloud. IEEE Transactions on Cloud Computing,

5(2):303–316.

Schulz, S., Blochinger, W., Held, M., and Dangelmayr, C.

(2008). Cohesion — a microkernel based desktop grid

platform for irregular task-parallel applications. Fu-

ture Generation Computer Systems, 24(5):354 – 370.

Sedgewick, R. (1984). Algorithms. Addison-Wesley Pub-

lishing Co., Inc., Boston, MA, USA.

TASKWORK: A Cloud-aware Runtime System for Elastic Task-parallel HPC Applications

209
