A Taxonomy of Metrics and Tests to Evaluate and Validate Properties of

Industrial Intrusion Detection Systems

Cyntia Vargas Martinez

1 a

and Birgit Vogel-Heuser

2 b

Bosch Rexroth AG, Bgm.-Dr.-Nebel-Str. 2, 97816 Lohr am Main, Germany

Institute of Automation and Information Systems, Technical University of Munich,

Boltzmannstr. 15, 85748 Garching bei M

unchen, Germany

cyntia.vargasmartinez2@boschrexroth.de, vogel-heuser@tum.de

Keywords:

Information Security, Industrial Automation Systems, Intrusion Detection, Network Security, System Testing,

System Validation.

Abstract:

The integration of Intrusion Detection Systems (IDS) in Industrial Automation Systems (IAS) has gained

popularity over the past years. This has occurred due to their ability to detect intrusions at a device and

network level. In order for these systems to provide effective and reliable protection, they must possess a set

of speciﬁc properties. These properties are inherent characteristics that depend on the IDS application ﬁeld, as

different ﬁelds provide different deployment conditions. Unfortunately, the evaluation and validation of such

properties for IAS has proven challenging, as current contributions often follow evaluation and validation

approaches from the IT domain that focus solely on the effectiveness of intrusion detection approaches; hence,

neglecting other aspects relevant to the industrial domain. This paper addresses this issue by presenting IDS

properties derived from trends and characteristics of IAS; as well as a taxonomy of metrics and tests to evaluate

and validate these properties. This taxonomy provides a foundation from which future IDS contributions for

IAS can be improved and reinforced by providing an overview of pertinent metrics and tests.

1 INTRODUCTION

Intrusion Detection Systems (IDS) are software ap-

plications capable of monitoring and analyzing events

and information from hosts and/or the network in or-

der to detect intrusions. Some contemporary IDS con-

tributions have claimed a high detection rate of over

95% (Tavallaee et al., 2010). Unfortunately, although

this high detection rate is their biggest allurement,

some other aspects have been neglected.

This is especially highlighted in (Paxson, 2007;

Tavallaee et al., 2010; Sommer and Paxson, 2010;

Bhuyan et al., 2014). Where the aspect most often

discussed is the qualitative and quantitative evaluation

of performance that has been hindered by the lack of

available datasets and the suitability of the evaluation

metrics. Other aspects that have been neglected are

properties that any IDS should possess. Some of these

properties (i.e., soundness, completeness, timeliness,

etc.) were ﬁrst described in earlier works by pioneers

in the ﬁeld of IDS as open issues that need to be ad-

https://orcid.org/0000-0002-4809-4304

https://orcid.org/0000-0003-2785-8819

dressed (Paxson, 2007; McHugh, 2001; Bhuyan et al.,

2014). Although these open issues have been known

for decades in the IT domain, their neglect has inher-

ited inadequate and/or incomplete evaluation and val-

idation practices for the industrial domain. The ad-

dressing of such open issues is imperative in industrial

IDS, as they may result in vulnerable or ﬂawed IDS

being deployed resulting in embedded vulnerabilities

or misidentiﬁcation of intrusions in IAS.

The main contribution of this paper is a taxon-

omy of metrics and tests that can be used to evaluate

and validate properties that industrial IDS should pos-

sess. These properties are abstracted from the afore-

mentioned open issues and the general characteristics

and features of current industrial IDS that contem-

plate general architectures of IAS. The metrics and

tests are identiﬁed through a literature review of IDS

contributions in both the IT and industrial domains.

This paper is structured as follows. Section 2 pro-

vides a brief overview of the current state of intrusion

detection in IAS. Section 3 describes abstracted prop-

erties that an IDS should possess based on the charac-

teristics and requirements of IAS. Section 4 presents

metrics and tests that can be used to evaluate and val-

Martinez, C. and Vogel-Heuser, B.

A Taxonomy of Metrics and Tests to Evaluate and Validate Properties of Industrial Intr usion Detection Systems.

DOI: 10.5220/0007833902010210

In Proceedings of the 16th International Joint Conference on e-Business and Telecommunications (ICETE 2019), pages 201-210

ISBN: 978-989-758-378-0

201

idate the properties derived in Section 3. Section 5

presents the proposed Taxonomy of metrics and tests.

Finally, Section 6 provides the conclusions.

2 OVERVIEW OF INTRUSION

DETECTION IN IAS

This Section provides an overview of research con-

tributions, as well as Open Source and Commercial

products, in the ﬁeld of intrusion detection in IAS.

2.1 Research Contributions

As it can be observed from survey literature (Zhu

and Sastry, 2010; Garitano et al., 2011; Mitchell and

Chen, 2014), three intrusion detection approaches are

predominant in research works.

The ﬁrst approach is the preference of network in-

trusion detection over host intrusion detection as ob-

served in (Zhu and Sastry, 2010; Mitchell and Chen,

2014). A Network IDS (NIDS) often consists of a

centralized software component that processes and

analyzes all data collected from the network in order

to detect intrusions and distributed units (often called

sensors) that capture (and sometimes pre-process or

ﬁlter) captured network data and forward it to the

centralized software component. The preference of

network intrusion detection over host intrusion detec-

tion comes from these distributed units that allow for

passive monitoring to be performed with the use of

network taps or port mirroring in switches, which al-

lows seamless integration in legacy systems and sys-

tems during runtime. It also provides scalability and

does not add overhead that may negatively inﬂuence

the automation system itself. Moreover, network data

collection is performed in strategical parts of the sys-

tem (e.g., between HMI and SCADA System and be-

tween HMI and PLC (Kleinmann and Wool, 2017))

in order to decrease costs and increase efﬁciency, as

only relevant and desired information is analyzed.

The second predominant approach is the prefer-

ence of anomaly-based over signature-based intru-

sion detection. In signature-based intrusion detec-

tion data or events collected are compared to well-

known intrusion patterns. On the other hand, in

anomaly-based intrusion detection intrusions are not

known; hence, everything that deviates from the nor-

mal behavior is considered as an intrusion (Udd et al.,

2016). Anomaly-based intrusion detection is favored

as signature-based intrusion detection is ineffective

against zero-day attacks and is also considered costly

due to the efforts required to generate its signatures.

The third, and ﬁnal, most predominant approach

is the preference to model automation process vari-

ables in order to detect system anomalies assumed to

be caused by intrusions. This is often achieved by ex-

tracting process variables from captured network traf-

ﬁc (Nivethan and Papa, 2016). The predominance of

these approaches in IAS is a result of the long lifetime

of this kind of systems and their often predictable be-

havior (Naedele and Biderbost, 2004).

Some of the most popular techniques imple-

mented to detect network intrusions are the follow-

ing. Speciﬁc signatures have been generated for in-

dustrial protocols in order to detect abnormal proto-

col behavior (Yang et al., 2014). Normal user and

service behavior have been modeled using statisti-

cal analysis from header information in (Kwon et al.,

2015) and (Valdes and Cheung, 2009) respectively.

More complex analysis techniques have implemented

classiﬁers (Zhang et al., 2016; Ponomarev and Atk-

ison, 2016), rule generators (Udd et al., 2016; Lit-

tler et al., 2013), One-Class Support Vector Machines

(OCSVM) (Maglaras and Jiang, 2014), etc.

2.2 Open Source and Commercial

industrial IDS

The two most widely known and used Open Source

NIDS are Zeek (formerly known as Bro) (Paxson,

1999) and Snort (Roesch, 1999). They are capable of

capturing, logging and analyzing network data. They

also have a predeﬁned set of signatures to detect well-

known threats. However, they can also be extended to

add personalized signatures or additional behavior.

Zeek ﬁlters unnecessary network data and feeds it

to an interpreter that evaluates it against scripts writ-

ten in the Bro scripting language (Paxson, 1999). This

allows Zeek to be extended as observed in (Udd et al.,

2016) where a parser was generated for IEC 60870-

5-104 protocol support. On the other hand, Snort

handles rules written in the Snort format. Preproces-

sors or plug-ins can also be integrated on it to add

additional behavior. Within the context of the Dig-

ital Bond Project Quickdraw, Snort rules for indus-

trial protocols (i.e., DNP3, Ethernet/IP and Modbus

TCP) were generated (Littler et al., 2013). These rules

have also been integrated into commercial IDS (Ma-

han et al., 2011). Zeek and Snort also share other

similarities with one-another, such as the conﬁgura-

bility of their intrusion responses which can be to ei-

ther monitor trafﬁc and block and/or report intrusions.

Commercial products with intrusion detection ca-

pabilities are often not marketed as industrial IDS but

as Centralized Management solutions with a strong

Cybersecurity focus or as Operational Technology

SECRYPT 2019 - 16th International Conference on Security and Cryptography

202

(OT) Management Systems; as their capabilities are

not only limited to intrusion detection, but they also

provide additional features that allow them to man-

age, monitor and visualize other system components.

Nonetheless, they are referred to as industrial IDS in

this paper as their architecture and behavior are simi-

lar to that of the research and open source NIDS previ-

ously discussed (i.e., they consist of Network Sensors

and a centralized software component).

Other capabilities commonly provided by these

solutions are logging, alerts, reports and graph gener-

ation that allow to visualize system events (e.g., intru-

sions detected). Some solutions provide more com-

plex capabilities such as interoperability with other

devices and applications such as ﬁrewalls and other

Security Information and Event Management Sys-

tems (SIEM) and vulnerability assessment tools. A

list of some fo these solutions can be found in the

Market Guide for Operational Technology Security

2017 (Perkins et al., 2017) by Gartner, Inc.

Unfortunately, more technical information regard-

ing the implemented techniques, operations and com-

putational performance of these solutions is not pub-

licly available and hence difﬁcult to obtain.

3 INDUSTRIAL IDS PROPERTIES

This section introduces properties that industrial IDS

should possess. These properties are derived from

open issues and neglected aspects identiﬁed from in-

dustrial IDS trends discussed in the previous section

and IAS operational requirements. These industrial

IDS trends have been summarized as follows:

• Predominance of Anomaly-based NIDS.

• Network Sensors that capture network trafﬁc are

strategically distributed across the system.

• Network Sensors forward captured data to a dedi-

cated system for analysis.

• The system that analyzes data obtained from the

Network Sensors is often centralized and located

at the control, supervisory or business level of the

automation hierarchy (Knapp, 2014). It may be

deployed in specialized hardware or in a preex-

isting device in the automation environment that

meets its computational requirements.

These tendencies convey that new components are

integrated into the industrial system. These compo-

nents communicate with one-another and consist of

both hardware and software. Their integration adds

new challenges, as their introduction into an automa-

tion system may affect its operation. In order to en-

sure that this does not occur, the operational require-

ments of the automation system must be considered.

These requirements are capabilities that an IAS must

possess in order to ensure its correct functionality.

They are deﬁned in (Stouffer et al., 2015) as the fol-

lowing: Real-time capabilities (OR1), High Avail-

ability (OR2), High Reliability and Fault Tolerance

(OR3), High Maintainability (OR4) and Constrained

Resources in certain embedded devices (OR5).

Considering the aforementioned trends and the

operational requirements of IAS, the following prop-

erties for industrial IDS have been derived from

(McHugh, 2001; Oryspayuli, 2006; Milenkoski et al.,

2015; Zarpel

ao et al., 2017):

• High Detection Accuracy (P1): Precise identiﬁca-

tion of intrusions. This means that an intrusion

is identiﬁed as an intrusion, which would require

a response. Whereas a non intrusive event is not

identiﬁed as an intrusion.

• Completeness (P2): Detection of a wide range of

intrusions.

• Real-time Intrusion Detection and Response or

Timeliness (P3): Immediate detection and re-

sponse in the presence of an intrusion. In other

words, the time elapsed between the occurrence

of an intrusion and its detection and response is as

close to zero as possible.

• Low Resource Consumption (P4): The amount

of computational resources (i.e., energy consump-

tion, network, CPU, ROM and RAM usage) used

by industrial IDS components are the necessary to

carry out their operation based on their required

functionality and features. This means that the re-

source consumption is optimized in order to liber-

ate computational resources that could be used by

other system components.

• Low Performance Overhead (P5): Direct or sec-

ondary effects of an IDS do not negatively inﬂu-

ence the correct operation of the IAS. Considering

the current industrial IDS trends, this indicates the

following. Network Sensors do not add additional

overhead to the industrial network. This is espe-

cially important, as the network load in industrial

networks is high. It also entails that software com-

ponents of the industrial IDS, that are not installed

on specialized IDS hardware but rather on other

IAS devices do not negatively inﬂuence the oper-

ation carried out by other automation components.

• High Processing Performance (P6): Computa-

tional operations carried out by IDS components

are performed in the shortest amount of time pos-

sible while maintaining reliable and high quality

A Taxonomy of Metrics and Tests to Evaluate and Validate Properties of Industrial Intrusion Detection Systems

203

results. Considering the current tendencies of in-

dustrial IDS, this indicates that IDS components

are capable of real-time and reliable processing of

highs amounts of data.

• Fault Tolerance (P7): The IDS is capable of

providing a degree of protection or functionality

even in the presence of faults in its components

(Lussier et al., 2004).

• Robustness (P8): The IDS is capable of maintain-

ing acceptable operation even in the presence of

unexpected or adversarial circumstances that dis-

turb its operation(Lussier et al., 2004).

• Resiliency (P9): The IDS is capable of recover-

ing from unexpected or adversarial circumstances

that may have caused disturbances in its operation

(Zhu and Basar, 2015).

• Data Validity (P10): Data processed by the

IDS is error-free. It is also authenticated and

protected against unauthorized modiﬁcations by

third-parties which could possibly invalidate the

results of the industrial IDS.

An IDS possessing these properties ensures the

fulﬁllment of IAS operational requirements as fol-

lows. High Detection Accuracy (P1), Completeness

(P2), Real-Time Intrusion Detection (P3), High Pro-

cessing Performance (P6) and Data Validity (P10)

guarantee that intrusions that may negatively affect

the correct operation of the automation system are

correctly identiﬁed in order to implement timely

countermeasures that may decrease or stop their ef-

fects. Hence, ensuring High Availability (OR2) and

maintaining High Reliability (OR3). Furthermore,

Low Resource Consumption (P4) and Low Perfor-

mance Overhead (P5) ensure industrial IDS do not

negatively inﬂuence the resources required to achieve

RT Capabilities (OR1). They also open the oppor-

tunity for components of industrial IDS to be de-

ployed in resource constrained devices (OR5). More-

over, High Maintainability (OR4) of the automation

system is possible thanks to the correct and timely

identiﬁcation of intrusions (P1 and P3) that guaran-

tee the execution of actions to decrease, stop or repair

the consequences of such intrusions. It is also sup-

ported by the Fault Tolerance (P7), Robustness (P8)

and Resiliency (P9) of industrial IDS, which ensure

the continuous operation of intrusion detection func-

tions even in the presence of disturbances caused by

faults or adversarial behavior. This is especially im-

portant in the presence of targeted attacks against the

industrial IDS. Consequently, they provide continu-

ous protection to the IAS that ensure its Availability

and Reliability (OR2 and OR3). An overview of this

is provided in Table 1.

Table 1: Industrial IDS properties and their relation to op-

erational requirements of Industrial Automation Systems

(IAS).

IDS Properties 1 2 3 4 5

P1-High Detection Accuracy

– X X X –

P2-Completeness

– X X – –

P3-RT ID and Response

– X X X –

P4-Low Resource Consumption

X – – – X

P5-Low Performance Overhead

X X – – X

P6-High Processing Performance

– X X – –

P7-Fault Tolerance

– X X X –

P8-Robustness

– X X X –

P9-Resiliency

– X X X –

P10-Data Validity

– X X – –

OR1: Real-time capabilities; OR2: High Availability;

OR3: High Reliability and Fault Tolerance; OR4: High

Maintainability; OR5: Constrained Resources.

Other properties such as interoperability, scalabil-

ity and extendability are not discussed in detail in

this contribution. This occurs, as these properties can

not be evaluated or validated with metrics or speciﬁc

tests, but rather depend on the speciﬁc features that

are integrated into industrial IDS. On the other hand,

the aforementioned properties are general attributes or

characteristics that should be considered for industrial

IDS with characteristics as those identiﬁed during the

analysis of trends. Additional properties may be con-

sidered in order to validate more speciﬁc approaches

or techniques. However, this is out of the scope of this

contribution.

4 METRICS AND TESTS TO

EVALUATE AND VALIDATE IDS

PROPERTIES

This section presents the taxonomy of metrics and

tests to evaluate and validate the aforementioned IDS

properties. These properties comprise the dimensions

of this taxonomy. Both metrics and tests allow to

quantitatively and qualitatively measure them.

The metrics allow to quantitatively evaluate cer-

tain properties. They have been classiﬁed according

to the data source of the values used for their calcu-

lation. These classes are: detection-, time-, compu-

tational resources- and IDS capacity metrics. This

classiﬁcation allows to identify which metrics can be

analyzed based on the available system or test infor-

mation. They have been abstracted from (McHugh,

2001; Kwon et al., 2015; Al-Jarrah et al., 2018;

Buczak and Guven, 2016; Almalawi et al., 2013;

Gupta and Chow, 2010; Brahmi et al., 2015; Lever-

sage and Byres, 2008; Mitchell and Chen, 2014).

SECRYPT 2019 - 16th International Conference on Security and Cryptography

204

On the other hand, tests describe events or sit-

uations under certain conditions and environments

(Athanasiades et al., 2003) where the behavior of

components is analyzed or measured, which allows

to use them as benchmarks from which metrics or

conclusions can be obtained. These tests have been

abstracted from the analysis of literature reviewed in

Section 2 and key contributions (Puketza et al., 1996;

Milenkoski et al., 2015; Durst et al., 1999).

4.1 Detection Metrics

Detection metrics are calculated from values result-

ing from the identiﬁcation or misidentiﬁcation of in-

trusions performed by an IDS and are often obtained

from IDS tests, as it is necessary to know the total

amount of intrusive and non-intrusive events that are

fed to the IDS. They are comprised of the following:

• True Positive (TP): Number of intrusion events

identiﬁed as intrusions.

• False Negative (FN): Number of intrusion events

not identiﬁed as intrusions.

• True Negative (TN): Number of non-intrusive

events not identiﬁed as intrusions.

• False Positive (FP): Number of non-intrusive

events identiﬁed as intrusions.

From these values, a set of evaluation metrics can

be obtained. Something characteristic that these met-

rics have is that they are used in machine learning to

evaluate algorithms used for classiﬁcation problems.

This occurs as intrusion detection is inherently a clas-

siﬁcation problem.

Standard Detection Metrics: The following

metrics are the most commonly used to evaluate IDS.

• True Positive Rate (TPR): It is also known as

Sensitivity, Recall or Detection Rate (DR). Ratio

of real intrusions detected from the total amount

of existing intrusions. See (1).

• True Negative Rate (TNR): It is also known

as Speciﬁcity. Ratio of real non-intrusive events

identiﬁed as such from the total amount of non-

intrusive events. See (1).

• False Positive Rate (FPR): It is also known as

False Alarm Rate (FAR) or Fall-out. Ratio of

non-intrusive events incorrectly identiﬁed as in-

trusions, from the total amount of non-intrusive

events. See (2)

• False Negative Rate (FNR): Ratio of undetected

intrusions from the total amount of real intrusions.

See (2).

T PR =

T P

T P + FN

T NR =

T N

T N + FP

(1)

FPR =

FP + T N

FNR =

FN + T P

(2)

Precision (Pr): Ratio of correctly identiﬁed intru-

sions from all detected intrusions (i.e., regardless

of whether or not they are really intrusive or non-

intrusive events). It is also known as Positive Predic-

tive Value (PPV) (Milenkoski et al., 2015).

Pr =

T P

T P + FP

(3)

Accuracy (ACC): Ratio of correctly classiﬁed intru-

sive events and non-intrusive events considering all

the classiﬁed events.

ACC =

T P + T N

T P + T N + FP + FN

(4)

F-score: Harmonic mean of precision and recall (i.e.,

DR or TPR) (Almalawi et al., 2013). It represents the

fraction of the detected intrusions that are valid.

F −score = 2 ·

Pr ·DR

Pr + DR

2 ·T P

2 ·T P + FP + FN

(5)

G-mean: Geometric mean of precision and recall

(i.e., DR or TPR). A high G-mean indicates a high

accuracy to detect intrusions.

G −mean =

√

Pr ·DR (6)

Matthews Correlation Coefﬁcient (MCC): Correla-

tion coefﬁcient between the observed and detected in-

trusions used when the difference between the amount

of samples of two classes is too big (e.g., too many

non-intrusive events and extremely few intrusions).

Its value is within the range of -1 (total misidentiﬁca-

tion of intrusion) and 1 (perfect detection). A value of

0 represents a random identiﬁcation (Al-Jarrah et al.,

2018).

MCC =

T P ·T N −FP ·FN

(T P + FP)(T P + FN)(T N +FP)(T N + FN)

(7)

ROC Graph: The Receiver Operating Character-

istic (ROC) graph allows to analyze the efﬁciency of

the detection rate. The values commonly plotted are

TPR vs FPR. Numerically, the area under the ROC

curve is considered (Buczak and Guven, 2016).

4.2 Timing Metrics

Timing metrics are calculated from values resulting

from the measurement of the temporal duration of

events. These events include events related to the IDS,

A Taxonomy of Metrics and Tests to Evaluate and Validate Properties of Industrial Intrusion Detection Systems

205

intrusions or other components that may interact with-

or that exist within the same environment as the IDS.

Training Time (TT): Time required for an

anomaly-based IDS to learn the expected normal be-

havior.

Intrusion Duration: Time elapsed between the

start and end of an intrusion.

Detection Time (DT): Time elapsed between the

start of an intrusion until it is detected by the IDS.

Response Time (RsT): Time elapsed between the

detection of an intrusion until its response action is

carried out.

Delay Time: Difference between the expected

time of an event and the later time in which it really

occurs. An example of this is the network delay. Net-

work delay refers to the packet delivery delay in an

industrial network (e.g end-to-end delay (Gupta and

Chow, 2010)). This delay may be caused by IDS, an

intrusion or other network components.

Processing Time per Event: Time elapsed since

an event has started to be processed by an IDS, un-

til a ﬁnal decision regarding that event is made (i.e.,

whether or not it is an intrusive event).

4.3 Computational Resources Metrics

The following metrics quantify computational re-

sources of certain system components. These com-

ponents may be part of an IDS or they may exist in

the same environment as one.

Percentage of Resource Utilization: Amount

of a computational resource (per unit or percentage)

used over a period of time. The resources that can

be measured are Network, CPU and Memory (i.e.,

RAM & ROM) utilization.

Network Bandwidth: Amount of data (per unit

or percentage) transmitted over the network (Brahmi

et al., 2015).

4.4 IDS Capacity Metrics

The following metrics measure speciﬁc abilities of an

IDS that are not related to detection accuracy.

IDS Throughput: Amount of events that can be

processed by an IDS during a given time. In NIDS, it

refers to the network trafﬁc that can be processed by

its Sensors and centralized analysis component.

Mean Time-to-Compromise (MTTC): Security

metric that estimates the time required by an at-

tacker to successfully impact a system (Leversage and

Byres, 2008). Different methodologies exist to esti-

mate this metric (McQueen et al., 2006; Leversage

and Byres, 2008; Nzoukou et al., 2013).

4.5 Intrusion Identiﬁcation Tests

Tests that verify the accuracy of an IDS (i.e., ability

to detect intrusions (Puketza et al., 1996)). In order

to provide validity to these tests, it is recommended

that data fed into an IDS has similar characteristics to

data that will be analyzed by it during normal oper-

ation. The use of predeﬁned datasets to evaluate the

accuracy of multiple intrusion detection approaches is

a common practice (Milenkoski et al., 2015; Mitchell

and Chen, 2014; Puketza et al., 1996), as it provides

reproducibility. However, what type of- and how data

is fed into the IDS depends on the type of IDS and the

main approaches implemented in it.

In anomaly-based approaches, datasets are com-

prised of normal and abnormal behavior. Unfortu-

nately, methodologies used to generate data with ab-

normal behavior may inﬂuence the quality of datasets

and hence, the validity of the test itself. This

has occurred with the dataset of the 1999 Interna-

tional Knowledge Discovery and Data Mining Com-

petition (KDD99) and the Defense Advanced Re-

search Projects Agency (DARPA) dataset DARPA98.

Both datasets have been considered as unsuitable

(McHugh, 2000). An alternative to these datasets are

the Industrial Control System Cyber Attack Datasets

(ICSCAD). These datasets have been popular for the

study of cyber attacks in IAS. Their description is pre-

sented in (Morris and Gao, 2014). They consist of

four datasets extracted from a gas pipeline and water

storage tank testbeds.

On the other hand, signature-based approaches are

more straightforward, as only the intrusions must be

fed to the IDS.

4.6 Resource Usage Tests

Tests that verify the amount of computational re-

sources used by IDS components (i.e., Network Sen-

sors and centralized analysis component), as it is im-

portant to evaluate how much CPU and memory uti-

lization is required. In (Milenkoski et al., 2015), two

different approaches are identiﬁed. The ﬁrst approach

refers to the calculation of the overall resources re-

quired by an IDS. The second approach refers to the

calculation of the resources required by individual

components of an IDS. In both instances, it is nec-

essary to perform the tests in both optimal and non-

optional conditions (i.e., together with stress tests), as

the resources used by the IDS may variate depend-

ing on these conditions. It is also crucial to perform

these tests with different conﬁguration settings. This

is especially important when the industrial IDS com-

ponents are expected to be deployed on embedded

SECRYPT 2019 - 16th International Conference on Security and Cryptography

206

hardware, which may require additional considera-

tions (e.g., task conﬁguration in Real-Time Operating

Systems). The results of these tests allow to deﬁne the

hardware requirements for IDS components.

4.7 Resource Overhead Tests

Tests that verify the degradation that may be caused

by IDS. This degradation is observed during the de-

crease of performance of other system components

that exist within the same environment. This per-

formance may consist of metrics such as computa-

tional resources metrics, timing metrics or other spe-

ciﬁc metrics relevant to the system component being

tested for degradation. These performance metrics

are obtained under two different conditions (i.e., with

and without an operational IDS). Performing these

tests with different IDS conﬁguration settings allows

to identify appropriate conﬁguration parameters for it.

4.8 Intrusion Detection Throughput

Tests

Tests that identify the amount of workload that can be

handled by IDS components (i.e., Network Sensors

and centralized analysis component). The workload

in Network Sensors is the amount of network trafﬁc

that is captured, preprocessed and forwarded to the

centralized analysis component. On the other hand,

the workload of the centralized analysis component is

the amount of data received from the Network Sen-

sors that can be processed. It is desirable that these

tests are carried out under optimal and non-optimal

conditions (similar to the resource usage tests).

4.9 Stress Tests

Tests that verify the IDS degradation under stressful

situations created by external inﬂuences such as third-

parties targeting IDS components (i.e., Network Sen-

sors and centralized analysis component). This degra-

dation can be observed during the IDS operation with

the decrease in intrusion detection metrics (e.g., ac-

curacy) and IDS capacity metrics; as well as the in-

crease in time and computational resource utilization

metrics. The most clear example of stressful situa-

tions are targeted attacks (Durst et al., 1999). In the

ﬁeld of IAS system faults may also generate stress.

5 TAXONOMY

The metrics and tests presented in the previous section

evaluate and validate the IDS properties discussed in

Section 3. However, not all metrics and tests are suit-

able for all properties. For this reason, a correlation

between metrics and tests; and the IDS properties that

they evaluate and validate is presented. An overview

of this correlation and the suggested taxonomy is pre-

sented in Table 2. The correlation between tests, met-

rics and properties is measured in three different de-

grees: high, medium and no correlation.

A high correlation (i.e., ++) provides a clear and

self-standing portrayal of the property. This means

that a metric or test can provide by itself a solid eval-

uation or validation of a property. On the other hand, a

medium correlation (i.e., +) provides semi-clear por-

trayal of the property. This means that for a metric or

test to evaluate or validate a property, it is necessary to

analyze their results with additional information (e.g.,

context, other metrics or tests, etc.). Furthermore, no

correlation (i.e., –) indicates that a metric or test is not

relevant for the evaluation or validation of a property.

Intrusion Detection Metrics grant an straightfor-

ward estimation of the High Detection Accuracy (P1)

of an IDS. They are obtained from a Intrusion Identiﬁ-

cation Test and also provide a notion of Completeness

(P2). Which is validated when a variety of different

intrusions are used for testing. Stress Tests can also be

used as they may contain complex adversarial models.

Time Metrics obtained during Intrusion Identiﬁca-

tion Test provide an estimation of Timeliness (P3).

Detection Time (DT), Response Time (RsT) and Pro-

cessing Time per Event provide a clear assessment of

the RT capabilities of an IDS. Training Time (TT)

provides a notion on usability on the time capabilities

of an IDS (e.g., how fast can the IDS start operating).

Furthermore, Network, Memory and CPU Utiliza-

tion Metrics provide an straightforward estimation of

the Low Resource Consumption (P4) and Low Per-

formance Overhead (P5) of an IDS. These metrics

are obtained from Resource Usage Tests. In addition

to these metrics and test, some Time and IDS met-

rics are considered to evaluate the Performance Over-

head (P5). Resource Overhead, Intrusion Detection

Throughput and Stress Tests may be used to obtain

these metrics. In addition, increase in Delay Time ob-

served in other components, as well as the decrease

in IDS Throughput also provide an estimate of over-

head in the system. Together with the previously men-

tioned metrics, Detection Time (DT) and Response

Time (RsT) can also be analyzed to ﬁnd appropriate

conﬁguration settings for the IDS, which would allow

to decrease its performance overhead.

Intrusion Detection and Time Metrics can be used

as a measure of quality for High Processing Perfor-

mance (P6), Fault Tolerance (P7), Robustness (P8)

and Resiliency(P8), as they provide a view of the IDS

A Taxonomy of Metrics and Tests to Evaluate and Validate Properties of Industrial Intrusion Detection Systems

207

Table 2: Taxonomy of metrics and tests to evaluate and validate industrial IDS properties.

Metric & Tests

P1 P2 P3 P4 P5 P6 P7 P8 P9 P10

Metrics

Detection

Standard Metrics ++ + — — — + + + + —

Precision (Pr) ++ + — — — + + + + —

Accuracy (Acc) ++ + — — — + + + + —

F-score ++ + — — — + + + + —

G-mean ++ + — — — + + + + —

MCC ++ + — — — + + + + —

ROC Graph ++ + — — — + + + + —

Time

Training Time (TT) — — + — — ++ — — — —

Intrusion Duration — — — — — — + + + —

Detection Time (DT) — — ++ — + ++ + + + —

Response Time (RsT) — — ++ — + ++ + + + —

Delay Time — — — — ++ — + + + —

Processing Time per Event — — ++ — + ++ + + + —

C. Rsrc.

Network Utilization — — — ++ ++ — — — — —

Memory Utilization — — — ++ ++ — — — — —

CPU Utilization — — — ++ ++ — — — — —

Network Bandwidth — — — ++ ++ — — — — —

Cap.

Throughput — — + — + ++ + + — —

MTTC — — — — — — ++ ++ + ++

Tests

Intrusion Identiﬁcation ++ + + — — + + + + —

Resource Usage — — — ++ ++ — — — — —

Resource Overhead — — — — ++ — — — — —

ID Throughput — — — — ++ — ++ ++ ++ —

Stress — + — — + — ++ ++ ++ ++

IDS Properties: P1: High Detection Accuracy; P2: Completeness; P3: Real-time Intrusion Detection; P4: Low Resource

Consumption; P5: Low Performance Overhead; P6: High Processing Performance; P7: Fault Tolerance; P8: Robustness;

P9: Resiliency; P10: Data Validity.

Correlation: ++: High; +: Medium; –: No Correlation. Other: C: Computational; Rsrc.: Resources; Cap.: Capacity.

performance. However, these metrics by themselves

are not enough to evaluate these properties.

A more accurate estimation of High Processing

Performance (P6) can be obtained by considering

the Training Time (TT), Detection Time (DT), Re-

sponse Time (RsT), Processing Time per Event and

IDS Throughput. As an IDS with a high processing

performance has the most accurate detection in the

shortest amount of time possible.

Besides Intrusion Detection Metrics, Timing met-

rics and Intrusion Detection Throughput and Stress

Tests support the assessment of Fault Tolerance (P7),

Robustness (P8) and Resiliency (P9). A fault tolerant,

robust and resilient IDS maintains a high accuracy

and real-time capabilities in the presence of faults or

other unexpected circumstances. It also has a behav-

ior as close to the optimal one it was designed for (i.e.,

IDS Throughput). Moreover, it has a high MTTC,

which means that an adversary should require more

time in order to compromise the system. The evalu-

ation of the MTTC allows to identify mechanisms to

harden or protect the IDS. This provides a notion of

Data Validity (P10).

6 CONCLUSIONS

The protection of IAS is critical to ensure their cor-

rect operation. Industrial IDS are a feasible solution

that can be seamlessly integrated in them for this, as

they can detect a wide range of intrusions. However,

before this integration occurs it is necessary to verify

that an IDS is efﬁcient, reliable and does not nega-

tively inﬂuence the operation of the target system (i.e.,

does not violate the operational requirements). In or-

der to do this, a qualitative and quantitative evalua-

tion of its performance must be made. The outcome

of this evaluation is to verify the suitability of IDS for

its deployment in an automation environment. Unfor-

tunately, from the analysis of literature performed in

this contribution; it was observed that the quality of

experimental evaluations from consulted IDS has of-

ten been overlooked (Tavallaee et al., 2010).

To address this issue, a taxonomy of metrics and

tests that allow to evaluate and validate properties of

an industrial IDS has been proposed. First, a set of

open issues in IDS in both the computer science and

automation ﬁeld have been identiﬁed. The identiﬁ-

SECRYPT 2019 - 16th International Conference on Security and Cryptography

208

cation of these open issues has been supported by

the consideration of operational requirements for IAS,

which allowed to deﬁne properties that an IDS should

have in order to be suitable for an automation environ-

ment. Afterwards, a set of metrics and tests to evalu-

ate and validate these properties have been abstracted

from reviewed literature. Furthermore, the presented

taxonomy allows to identify appropriate metrics and

tests to be considered during the development of an

industrial IDS depending on its desired properties.

The presented taxonomy focuses on analyzing the

overall performance of an industrial IDS and its inﬂu-

ence over the automation system. Aspects related to

speciﬁc implementation approaches or techniques are

not considered, as these may require additional tests

and metrics. Some examples of this are: performance

metrics for Machine Learning algorithms (Servin and

Kudenko, 2008), entropy metrics for anomaly detec-

tion (Marnerides et al., 2014), protocol-speciﬁc met-

rics (Kwon et al., 2015), etc.

REFERENCES

Al-Jarrah, O. Y., Al-Hammdi, Y., Yoo, P. D., Muhaidat, S.,

and Al-Qutayri, M. (2018). Semi-supervised multi-

layered clustering model for intrusion detection. Dig-

ital Communications and Networks, 4(4):277–286.

Almalawi, A., Tari, Z., Fahad, A., and Khalil, I. (2013).

A framework for improving the accuracy of unsuper-

vised intrusion detection for scada systems. In 2013

12th IEEE International Conference on Trust, Secu-

rity and Privacy in Computing and Communications

(TrustCom), pages 292–301.

Athanasiades, N., Abler, R., Levine, J., Owen, H., and

Riley, G. (2003). Intrusion detection testing and

benchmarking methodologies. In Proceedings First

IEEE International Workshop on Information Assur-

ance (IWIAS 2003), pages 63–72. IEEE.

Bhuyan, M. H., Bhattacharyya, D. K., and Kalita, J. K.

(2014). Network anomaly detection: Methods, sys-

tems and tools. IEEE Communications Surveys & Tu-

torials, 16(1):303–336.

Brahmi, I., Brahmi, H., and Yahia, S. B. (2015). A multi-

agents intrusion detection system using ontology and

clustering techniques. In Amine, A., Bellatreche, L.,

Elberrichi, Z., Neuhold, E. J., and Wrembel, R., edi-

tors, Computer Science and Its Applications, volume

456 of IFIP Advances in Information and Communi-

cation Technology, pages 381–393. Springer Interna-

tional Publishing, Cham.

Buczak, A. L. and Guven, E. (2016). A survey of data min-

ing and machine learning methods for cyber security

intrusion detection. IEEE Communications Surveys &

Tutorials, 18(2):1153–1176.

Durst, R., Champion, T., Witten, B., Miller, E., and Spag-

nuolo, L. (1999). Testing and evaluating computer

intrusion detection systems. Communications of the

ACM, 42(7):53–61.

Garitano, I., Uribeetxeberria, R., and Zurutuza, U. (2011).

A review of scada anomaly detection systems. In

Kacprzyk, J., Corchado, E., Sn

sel, V., Sedano, J.,

Hassanien, A. E., Calvo, J. L., and

Slzak, D., editors,

Soft Computing Models in Industrial and Environmen-

tal Applications, 6th International Conference SOCO

2011, volume 87 of Advances in Intelligent and Soft

Computing, pages 357–366. Springer Berlin Heidel-

berg, Berlin, Heidelberg.

Gupta, R. A. and Chow, M.-Y. (2010). Networked control

system: Overview and research trends. IEEE Trans-

actions on Industrial Electronics, 57(7):2527–2535.

Kleinmann, A. and Wool, A. (2017). Automatic con-

struction of statechart-based anomaly detection mod-

els for multi-threaded industrial control systems. ACM

Transactions on Intelligent Systems and Technology,

8(4):1–21.

Knapp, E. D. (2014). Industrial network security: Se-

curing critical infrastructure networks for smart grid,

scada, and other industrial control systems. Elsevier,

Waltham MA, 2nd edition edition.

Kwon, Y., Kim, H. K., Lim, Y. H., and Lim, J. I. (2015).

A behavior-based intrusion detection technique for

smart grid infrastructure. In 2015 IEEE Eindhoven

PowerTech, pages 1–6. IEEE.

Leversage, D. J. and Byres, E. J. (2008). Estimating a sys-

tem’s mean time-to-compromise. IEEE Security &

Privacy Magazine, 6(1):52–60.

Littler, T., Wang, H. F., Yang, Y., McLaughlin, K., and

Sezer, S. (2013). Rule-based intrusion detection sys-

tem for scada networks. In 2nd IET Renewable Power

Generation Conference (RPG 2013), pages 1–4. IET.

Lussier, B., Chatila, R., Ingrand, F., Killijian, M. O.,

and Powell, D. (2004). On fault tolerance and

robustness in autonomous systems. In the Third

IARP-IEEE/RAS-EURON Joint Workshop on Techni-

cal Challenges for Dependable Robots in Human En-

vironments 2004, pages 1–7. Citeseer.

Maglaras, L. A. and Jiang, J. (2014). Ocsvm model com-

bined with k-means recursive clustering for intrusion

detection in scada systems. In 2014 10th International

Conference on Heterogeneous Networking for Qual-

ity, Reliability, Security and Robustness (QShine),

pages 133–134.

Mahan, R. E., Fluckiger, J. D., Clements, S. L., Tews, C. W.,

Burnette, J. R., Goranson, C. A., and Kirkham, H.

(2011). Secure data transfer guidance for industrial

control and scada systems: Pnnl-20776.

Marnerides, A. K., Schaeffer-Filho, A., and Mauthe, A.

(2014). Trafﬁc anomaly diagnosis in internet back-

bone networks: A survey. Computer Networks,

73:224–243.

McHugh, J. (2000). Testing intrusion detection systems: A

critique of the 1998 and 1999 darpa intrusion detec-

tion system evaluations as performed by lincoln labo-

ratory. ACM Transactions on Information and System

Security, 3(4):262–294.

McHugh, J. (2001). Intrusion and intrusion detection. Inter-

national Journal of Information Security, 1(1):14–35.

A Taxonomy of Metrics and Tests to Evaluate and Validate Properties of Industrial Intrusion Detection Systems

209

McQueen, M. A., Boyer, W. F., Flynn, M. A., and Beitel,

G. A. (2006). Time-to-compromise model for cyber

risk reduction estimation. In Gollmann, D., Massacci,

F., and Yautsiukhin, A., editors, Quality of Protection,

volume 23 of Advances in Information Security, pages

49–64. Springer US, Boston, MA.

Milenkoski, A., Vieira, M., Kounev, S., Avritzer, A., and

Payne, B. D. (2015). Evaluating computer intrusion

detection systems: A survey of common practices.

ACM Computing Surveys, 48(1):1–41.

Mitchell, R. and Chen, I.-R. (2014). A survey of intrusion

detection techniques for cyber-physical systems. ACM

Computing Surveys, 46(4):1–29.

Morris, T. and Gao, W. (2014). Industrial control system

trafﬁc data sets for intrusion detection research. In

Butts, J. and Shenoi, S., editors, Critical Infrastruc-

ture Protection VIII, volume 441 of IFIP Advances in

Information and Communication Technology, pages

65–78. Springer Berlin Heidelberg, Berlin, Heidel-

berg.

Naedele, M. and Biderbost, O. (2004). Human-assisted in-

trusion detection for process control systems. In Pro-

ceedings of the Second International Conference on

Applied Cryptography and Network Security, pages

216–225. Citeseer.

Nivethan, J. and Papa, M. (2016). A scada intrusion de-

tection framework that incorporates process seman-

tics. In Trien, J. P., Prowell, S. J., Goodall, J. R., and

Bridges, R. A., editors, Proceedings of the 11th An-

nual Cyber and Information Security Research Con-

ference, pages 1–5. ACM.

Nzoukou, W., Wang, L., Jajodia, S., and Singhal, A. (2013).

A uniﬁed framework for measuring a network’s mean

time-to-compromise. In 2013 IEEE 32nd Interna-

tional Symposium on Reliable Distributed Systems

(SRDS), pages 215–224. IEEE.

Oryspayuli, O. D. (August 2006). What intrusion detection

approaches work well if only TCP/IP packet header

information is available? PhD thesis, Master Thesis,

Faculty of Electrical Engineering, Mathematics and

Computer Science, University of Twente, Enschede,

The Netherlands, Enschede, Netherlands.

Paxson, V. (1999). Bro: A system for detecting network

intruders in real-time. Computer Networks, 31(23-

24):2435–2463.

Paxson, V. (2007). Considerations and pitfalls for con-

ducting intrusion detection research: Keynote. In

Fourth GI International Conference on Detection of

Intrusions & Malware, and Vulnerability Assessment

(DIMVA).

Perkins, E., Contu, R., and Alaybeyi, S. B. (2017). Market

guide for operational technology security.

Ponomarev, S. and Atkison, T. (2016). Industrial control

system network intrusion detection by telemetry anal-

ysis. IEEE Transactions on Dependable and Secure

Computing, 13(2):252–260.

Puketza, N. J., Zhang, K., Chung, M., Mukherjee, B., and

Olsson, R. A. (1996). A methodology for testing in-

trusion detection systems. IEEE Transactions on Soft-

ware Engineering, 22(10):719–729.

Roesch, M. (1999). Snort - lightweight intrusion detection

for networks. In 13th USENIX Conference on System

Administration, LISA ’99, pages 229–238, Berkeley,

CA, USA. USENIX Association.

Servin, A. and Kudenko, D. (2008). Multi-agent rein-

forcement learning for intrusion detection. In Tuyls,

K., Nowe, A., Guessoum, Z., and Kudenko, D., ed-

itors, Adaptive Agents and Multi-Agent Systems III.

Adaptation and Multi-Agent Learning, volume 4865

of Lecture Notes in Computer Science, pages 211–

223. Springer Berlin Heidelberg, Berlin, Heidelberg.

Sommer, R. and Paxson, V. (2010). Outside the closed

world: On using machine learning for network intru-

sion detection. In 2010 IEEE Symposium on Security

and Privacy, pages 305–316. IEEE.

Stouffer, K., Pillitteri, V., Lightman, S., Abrams, M., and

Hahn, A. (2015). Guide to Industrial Control Systems

(ICS) Security: Supervisory, Control and Data Ac-

quisition (SCADA) Systems, Distributed Control Sys-

tems (DCS) and Other Control System Conﬁgura-

tions such as Programmable Logic Controllers (PLC):

NIST Special Publication 800-82. National Institute

of Standards and Technology, revision 2 edition.

Tavallaee, M., Stakhanova, N., and Ghorbani, A. A.

(2010). Toward credible evaluation of anomaly-based

intrusion-detection methods. IEEE Transactions on

Systems, Man, and Cybernetics, Part C (Applications

and Reviews), 40(5):516–524.

Udd, R., Asplund, M., Nadjm-Tehrani, S., Kazemtabrizi,

M., and Ekstedt, M. (2016). Exploiting bro for in-

trusion detection in a scada system. In Zhou, J. and

Lopez, J., editors, the 2nd ACM International Work-

shop on Cyber-Physical System Security, pages 44–

51. ACM.

Valdes, A. and Cheung, S. (2009). Communication pattern

anomaly detection in process control systems. In 2009

IEEE Conference on Technologies for Homeland Se-

curity (HST), pages 22–29. IEEE.

Yang, Y., McLaughlin, K., Sezer, S., Yuan, Y. B., and

Huang, W. (2014). Stateful intrusion detection for iec

60870-5-104 scada security. In 2014 IEEE PES Gen-

eral Meeting, pages 1–5. IEEE.

Zarpel

ao, B. B., Miani, R. S., Kawakani, C. T., and de Al-

varenga, S. C. (2017). A survey of intrusion detection

in internet of things. Journal of Network and Com-

puter Applications, 84:25–37.

Zhang, J., Gan, S., Liu, X., and Zhu, P. (2016). Intru-

sion detection in scada systems by trafﬁc periodicity

and telemetry analysis. In 2016 IEEE Symposium on

Computers and Communication (ISCC), pages 318–

325. IEEE.

Zhu, B. and Sastry, S. (2010). Scada-speciﬁc intrusion de-

tection/prevention systems: a survey and taxonomy.

In Proceedings of the 1st Workshop on Secure Control

Systems (SCS), volume 11, pages 1–7.

Zhu, Q. and Basar, T. (2015). Game-theoretic methods for

robustness, security, and resilience of cyberphysical

control systems: Games-in-games principle for opti-

mal cross-layer resilient control systems. IEEE Con-

trol Systems, 35(1):46–65.

SECRYPT 2019 - 16th International Conference on Security and Cryptography

210
