Hunting Traits for Cryptojackers

Gabriel Jozsef Berecz

1,2 a

and Istvan-Gergely Czibula

1 b

Department of Computer Science, Babes¸-Bolyai University, M. Kog

alniceanu Street, Cluj-Napoca, Romania

Cyber Threat Proactive Defense Lab, Bitdefender, Romania

Keywords:

Cryptojacker, Computer Security, Learning-based Classiﬁer.

Abstract:

Cryptocurrencies are renowned world wide nowadays and they have been adopted in various industries. This

great success comes from both the technology innovation they brought to the world, the blockchain, and the

ﬁnancial opportunities they opened up for investors. One of the unpleasant aspects are the cybercriminals who

took advantage of this technology and have developed malicious software (i.e. cryptojacker) in order to gain

proﬁt by mining cryptocurrencies on their victims’ personal computer without any consent. This paper pro-

poses to analyze standalone cryptojackers, both statically and dynamically, with the aim of identifying speciﬁc

traits. The approach draws out features speciﬁc to cryptojackers that are selected using statistical methods and

explains why a cryptocurrency mining malware has such traits. Based on 20 selected speciﬁc features, three

different supervised learning classiﬁcation models have been trained, which are able to differentiate between

clean applications and cryptojackers reliably. In experiments, an average accuracy of ≈ 92.46% has been

achieved.

1 INTRODUCTION

In the past two years, cryptocurrencies have seen a

rapid growth. By the start of 2018, they achieved

a total market capitalization of 820 billion dol-

lars (Coinmarketcap, 2013). This great success can

be attributed to both the technology innovation it

brought to the world, the blockchain, and the ﬁnan-

cial opportunities it opened up for investors. Min-

ing is the process of validating transactions within the

blockchain network. A miner is a machine connected

to the blockchain network which validates transac-

tions within the network (Swan, 2015). Cybercrim-

inals took advantage of this technology and have de-

veloped malicious software in order to gain proﬁt by

mining cryptocurrencies on each victim’s personal

computer and collect the rewards in their wallets.

Thus, cryptojackers have become wide spread over

the Internet and many users are mining cryptocur-

rencies without consent. Since they have ﬁrst ap-

peared, cryptojackers have been noticed running in-

side a browser (i.e. browser-based cryptojackers that

execute Javascript code) (Eskandari et al., 2018) and

running locally on machines as standalone executa-

bles.

With the growth of Cryptocurrency market, cryp-

tojackers have become widely spread among Internet

https://orcid.org/0000-0002-0923-9742

https://orcid.org/0000-0003-0076-584X

users. They get executed through different methods,

some of them are usually malicious software such as

trojans, while other are delivered through complex at-

tacks like exploits or ﬁle-less attacks. Because they

are stealthy and, for the most of the time, unrecog-

nized, they are able to persist on an affected machine

for months. During the whole time, the attacker gains

his proﬁt while the user’s hardware components are

getting damaged. Once infected with such a threat, it

could take minutes up to months to notice that some-

thing is wrong, but the attack has to be detected as

early as possible in order to produce as little damage

as possible. Thus, a specialized component respon-

sible for identifying cryptojackers is required nowa-

days.

Moreover, Pastrana et al. (Pastrana and Suarez-

Tangil, 2019) have studied cryptojacking campaigns

presenting how attackers earned at least 56 million

USD. Their study proved that malicious actors are

nowadays targeting this kind of malware as it may

be unnoticeable by its victims and delivering proﬁt

continuously. This represents only a part of the min-

ing going on in the wild, not taking into consideration

users and companies that are the victims of this phe-

nomena without even knowing.

The term of cryptojacker refers to malicious soft-

ware used to stealthily mine cryptocurrencies, with-

out user’s consent. We focused on cryptojackers that

are standalone executable ﬁles as they have not been

386

Berecz, G. and Czibula, I.

Hunting Traits for Cryptojackers.

DOI: 10.5220/0007837403860393

In Proceedings of the 16th International Joint Conference on e-Business and Telecommunications (ICETE 2019), pages 386-393

ISBN: 978-989-758-378-0

studied in-depth, unlike the browser-based ones. The

features were extracted based on behavioral analysis

and static analysis of both cryptojackers and clean ap-

plications. The paper presents only those features that

are relevant and have a major contribution in the clas-

siﬁcation process.

Based on an in-depth analysis of cryptojackers,

along with a comparison between them and clean ap-

plications, this paper aims to answer the following

questions:

• Are there any anomalies in the characteristics (i.e.

features) of cryptojackers which could differenti-

ate them from any clean application?

• Why would a cryptojacker have a speciﬁc feature

present?

• Can we reliably separate clean applications from

cryptojackers based on speciﬁc features?

The ﬁrst question attempts to identify features

present among many cryptojackers, the second one

tries to explain the traits and behavior of such mali-

cious applications, while the third implies an experi-

mental evaluation. The main contributions of this pa-

per can be summarized as follows:

• Identify features that are speciﬁc to standalone

cryptojackers.

• Analyze and explain why would cryptojackers

have such a trait or behavior.

• Introduce and experimentally validate cryptojack-

ers classiﬁcation methods based on the identiﬁed

features.

The paper presents existing approaches and so-

lutions to the problem of cryptojacking detection in

Section 2. After that, the paper introduces our ap-

proach in Section 3 and continues with the experimen-

tal evidence of the proposed approach in Section 4.

Finally, in Section 5 we compare the results obtained

by our proposal with the ones already present in the

literature. Conclusions and future improvements are

discussed in Section 6.

2 RELATED WORK

Browser-based cryptojackers have been studied dur-

ing the past years and systems aiming to identify such

threats have been developed. The paper from Eskan-

dari et al. (Eskandari et al., 2018) presented the re-

cent trends in terms of cryptocurrency mining. Ac-

cording to their study, Coinhive (Coinhive, 2012) is

the most used Javascript cryptocurrency miner, repre-

senting 92.0% of the total number of websites using

Javascript cryptocurrency miners, followed in top 3

by JSEcoin (JSEcoin, 2017) and Crypto-Loot (Cryp-

toLOOT, 2017). Saad et al. (Saad et al., 2018) focused

on code-based analysis among browser-based crypto-

jackers, presenting code complexity features that are

used to identify cryptojacking Javascript code with an

accuracy of 96.4%. These two approaches present in-

formation related to browser-based cryptojackers, not

for standalone applications.

Krishnan et al. (Krishnan et al., 2015) discuss

about moving the mining process into cloud present-

ing the limitations of the traditional machines and

why cloud computing is the next step. A study (Tahir

et al., 2017) concerning cloud services was published,

in which the authors presented how virtual machines

from cloud are abused with the aim of mining cryp-

tocurrencies. Another approach (Sari and Kilic, 2017)

used Open Source Intelligence in order to investi-

gate vulnerabilities present in mining pools, having

the Mirai botnet (Antonakakis et al., 2017) as refer-

ence. Hong et al. (Hong et al., 2018) presented at-

tack vectors speciﬁc to browser-based cryptojackers

along with their distribution techniques. The frame-

work proposed by Rauchberger et al. (Rauchberger

et al., 2018) is specialized in scanning for cryptojack-

ers Javascript code and it revealed that in Alexa Top

1 million websites, there were 3,178 which contain

Javascript code mining cryptocurrencies.

In terms of generic malicious software detection,

Zabidi et al. (Zabidi et al., 2012) extract features

present among different malicious software families,

such as trying to identify if there is a debugger at-

tached to the running process or if the sample is

running inside a sandboxed environment. The sys-

tem proposed by Baldangombo (Baldangombo et al.,

2013) et al. detects malicious software using features

extracted from static analysis, using a total number of

25,592 features and 3 different classiﬁers (i.e. sup-

port vector machine, J48 and Naive Bayes) in order

to achieve a detection rate of 99.6%. In a survey for

automated dynamic malware analysis (Egele et al.,

2012) authors presented different approaches, such as

function call monitoring, functions parameters analy-

sis, data ﬂow tracking, instruction trace and persis-

tence methods. Also, an automatic behavior-based

classiﬁcation of generic malicious samples (Devesa

et al., 2010) has an average accuracy of 94.8% us-

ing four different classiﬁers. In order to detect poly-

morphic malware, Kim et al. (Kim and Moon, 2010)

present how dependency graphs can be used to iden-

tify malicious scripts. All these approaches are try-

ing to separate generic malware from clean appli-

cations, they are not targeting a speciﬁc malicious

class (i.e cryptojackers) and they are either static or

Hunting Traits for Cryptojackers

387

dynamic analyzing samples. Hybrid malware ap-

proaches have been published (Roundy and Miller,

2010) (Yang et al., 2015) (De Paola et al., 2018),

but they are generically classifying malicious appli-

cations, not focusing on a speciﬁc prevalent family,

the cryptojackers.

3 METHODOLOGY

Our approach for investigating and identifying stan-

dalone cryptojackers’ speciﬁc features consists of the

following steps:

• Step 1: Data gathering - collect various samples,

both cryptojackers and clean applications.

• Step 2: Feature extraction - collect information

from the gathered data.

• Step 3: Feature selection - choose features spe-

ciﬁc to cryptojackers using statistical methods.

• Step 4: Evaluation models - using the identiﬁed

features, build different supervised learning mod-

els.

• Step 5: Performance evaluation criteria - measure

performance for the evaluation models.

3.1 Data Gathering

We collected our data using the following sources:

• Hybrid-analysis (Hybrid-analysis, 2014) - auto-

mated malware analysis tool providing an in depth

description for the submitted samples. We used

this tool in order to gather applications labeled as

cryptocurrency mining software.

• Malshare (MalShare, 2013) - an online malicious

software repository that we used to gather more

cryptojackers.

• Other sources - the clean applications were col-

lected using Ninite (Ninite, 2009) software and

Filehippo (FileHippo, 2004).

In order to get as close as possible to the ground

truth, we have selected only clean applications that

are not detected by any anti virus company and cryp-

tojackers that are statically signed by at least 80% of

anti virus companies.

3.2 Feature Extraction

Each sample from the data set was analyzed both stat-

ically and dynamically using custom tools developed

speciﬁcally for this experiment (any other tool that ex-

tracts the below mentioned information is suitable).

The static features extracted consist of:

• Information from the executable’s header (it may

differ as it depends on the used operating system)

• Entropy (Lyda and Hamrock, 2007)

• Imported modules and functions.

• Exported functions and modules.

• Information about every section (name, raw size

and virtual size).

The second step in feature extraction was a dy-

namic analysis in which we monitored function calls

(i.e. API calls speciﬁc to the operating system). The

dynamic analysis step was required as many mali-

cious software, not just cryptojackers, resolve their

imports at runtime in order to avoid static detec-

tion (Moser et al., 2007). Also, many malicious ap-

plications, as well as clean applications, are delivered

obfuscated and packed, thus avoiding static analysis.

3.3 Feature Selection

Having the aforementioned information, we wanted

to see anomalies concerning cryptojackers. Thus, we

compute the most used (imported or run time called)

functions by cryptojackers and, at the same time,

rarely used by clean applications. By doing this we

can identify functions being frequently used by cryp-

tojackers. We do the same for imported modules in or-

der to hunt them, too. For every numerical feature ex-

tracted, we also separately compute the average value

among cryptojackers and clean applications. More-

over, identifying features that are speciﬁc to clean

applications, but are not present or rarely present at

cryptojackers, will contribute to a better separation of

these two classes. After having the ﬁnal features, we

are going to normalize every value using the formula:

− min(x)

max(x) − min(x)

(1)

3.4 Evaluation Model

To experimentally evaluate our selected features we

used three different classiﬁers already implemented

in the scikit-learn (Pedregosa et al., 2011) Python li-

brary:

• Support vector machine classiﬁcator (Wang,

2005). The kernel function used for the algorithm,

is the Radial Basis Function (Musavi et al., 1992)

where γ is obtained using Hastie et. al’s algo-

rithm (Hastie et al., 2004):

−γ||x−x

(2)

• Multi-layer perceptron classiﬁer (Riedmiller,

1994) experimentally tuned up using ReLU

SECRYPT 2019 - 16th International Conference on Security and Cryptography

388

activation function (Xu et al., 2015) and

Adam (Kingma and Ba, 2014) method for weight

optimization.

• Random forest classiﬁer (Pal, 2005) experimen-

tally optimized.

3.5 Performance Evaluation Criteria

The ﬁrst step in order to evaluate the performance is

cross validation. We split the data set in two sets:

training (consisting of 80% of the total samples) and

prediction (consisting of 20%). In order to measure

the model’s generalization ability, we applied K-fold

cross validation with k = 10. By doing so, the total

number of samples was 10 times split into 10 differ-

ent sets of training and prediction. In terms of perfor-

mance, we measure the results using the area under

the ROC curve (Metz, 1978) and the average value

over the 10 cases for accuracy, precision, recall (true

positive rate). They are calculated as equations (3),

(4) and (5) show, where tp (i.e. true positive) repre-

sents the number of cryptojackers correctly classiﬁed,

tn (i.e true negative) is the number of clean applica-

tions correctly classiﬁed, fp (i.e false positive) rep-

resents the number of cryptojackers classiﬁed wrong

and fn (i.e. false negative) is the number of clean ap-

plications being classiﬁed wrong.:

accuracy =

t p +tn

t p +tn + f p + f n

(3)

precision =

t p

t p + f p

(4)

recall =

t p

t p + f n

(5)

4 COMPUTATIONAL

EXPERIMENTS

In order to validate our approach, computational ex-

periments are needed. This section presents our re-

sults including the extracted features, the used mod-

els, accuracy, recall, precision and the ROC curve. All

experiments have been conducted on Windows oper-

ating system and all samples are Windows portable

executable ﬁles (Microsoft, 1991).

4.1 Data Set

The results presented in this paper are based on an

analysis of 11,766 cryptojackers and 11,374 clean ap-

plications summing up to a total number of 23,140

samples. The data set was collected from diverse

public sources such as honeypots, malicious URLs,

malicious email attachments, as presented in Sec-

tion 3. It contains various applications including

packed applications and applications using evasion

techniques (Aﬁanian et al., 2018), such as importing

modules and functions at runtime. All samples have

been run on a machine having installed as operating

system Windows 10 Redstone 3 (RS3). During the

analysis, the machine was connected to Internet.

4.2 Feature Analysis

As we already mentioned in our methodology, we ex-

tracted statistics related to our features and in the next

lines we analyze them. Table 1 presents functions fre-

quently being used by cryptojackers but not by clean

applications, ordered by the difference between cryp-

tojackers usage and clean applications usage.

The results presented in Table 1 reveal that

cryptojackers do have speciﬁc behavior that distin-

guishes them from clean applications. One no-

ticeable difference is the frequent use of time re-

lated functions (i.e.

localtime(32/64), ftime(32/64),

gmtime(32/64), etc.). They may be used during the

mining process as seed to generate random numbers

or simply for logging purposes. Another interesting

fact is the usage of network communication related

functions (i.e. inet ntoa, getpeername) as cryptojack-

ers have to communicate over the internet for mining

purposes. Cryptojackers also use hashing functions

during the mining process. As a result, cryptography

related functions are also present in the top 10 (i.e.

SHA256 Init and SHA256 Final).

Moving forward, we computed the same statis-

tics, but applied to imported modules in order to iden-

tify what libraries do cryptojackers use. The results

are presented in Table 2 and they conﬁrm once again

that cryptojackers frequently use network communi-

cation related modules (i.e. ws2 32.dll, libcurl-x.dll,

wldapi32.dll, wtsapi32.dll). One noticeable remark

about most used modules is that user32.dll (a library

responsible for creating user interfaces) is not being

used by cryptojackers as one of their goal is to remain

as stealthy as possible.

Having identiﬁed functions and modules most fre-

quently used by cryptojackers, we investigated their

traits further and computed the average values for

numerical values present in the portable executable

header. Table 3 presents a comparison between cryp-

tojackers and clean applications of the average value

of ﬁve features extracted from static analysis. The

ﬁve features were selected based on their signiﬁcance

and by the signiﬁcance between the two average val-

ues. Cryptojackers tend to have a larger image size

Hunting Traits for Cryptojackers

389

Table 1: Top 10 functions frequently used by cryptojackers, but rarely by clean applications.

Function name Cryptojackers usage (%) Clean usage (%) Difference

localtime(32/64) 41.6388 2.7876 38.8512

ftime(32/64) 37.3483 1.8357 35.5126

gmtime(32/64) 32.9938 1.3598 31.6340

inet ntoa 30.6664 4.2155 26.4509

getpeername 29.6817 5.7113 23.9703

curl slist append 20.5380 0.0679 20.4701

time(32/64) 22.0151 2.0397 19.9754

setusermatherr 22.0151 3.9435 18.0716

SHA256 Init 10.2690 0.3399 9.9291

SHA256 Final 10.2690 0.3399 9.9291

Table 2: Top 5 modules frequently used by cryptojackers, but rarely by clean applications.

Module name Cryptojackers usage (%) Clean usage (%) Difference

ws2 32.dll 56.1983 9.7909 46.4074

libcurl-x.dll (x is the version) 16.4585 1.0878 15.3707

wldap32.dll 15.7552 0.8159 14.9393

opencl.dll 13.9264 0.1359 13.7905

wtsapi32.dll 10.8317 2.2437 8.5880

due to the fact that they are usually delivered with-

out any external dependencies, the attacker aiming to

infect as many victims as possible (for example, if a

malware requires Python to be installed on a machine

in order to successfully execute an attack, it reduces

its possible victims as not all machines have Python

installed). Also, it can be observed that cryptojackers

import less functions, have less exports and a lower

size of headers than clean applications as they have

limited tasks to execute (these tasks refer to the cryp-

tocurrency mining process), while a clean application

usually is a much more complex piece of software.

To sum up, we have the top 10 functions fre-

quently used by cyptojackers along with the top 5 im-

ported modules and 5 features extracted during the

static analysis based on their average values. Based

on these 20 features we are going to train a classiﬁer

in order to separate between cryptojackers and clean

applications.

4.3 Classiﬁcation Model

Using the aforementioned features, we trained three

different supervised learning (Duda et al., 2012) clas-

siﬁers as mentioned in Section 3. We present the

achieved results along with the used values for the

classiﬁers’ parameters.

The support vector machine classiﬁer uses as a

kernel function the following:

−γ||x−x

, γ = 0.09 (6)

The multi-layer perceptron architecture consists

of 20 neurons on the input layer, two hidden layers

with 16 neurons each, and one output layer with 1

neuron giving the probability of being a cryptojacker.

The used learning rate is 0.0017, the penalization co-

efﬁcient used by the Adam optimization (Kingma and

Ba, 2014) is 0.0001 along with a maximum number of

50 iterations.

The random forest classiﬁer uses 15 estimators,

the Gini index (Gastwirth, 1972) as a measurement

for a split quality and maximum depth of 8 nodes.

Using these 3 classiﬁers, we obtained an average

accuracy of 92.4652% along with an average preci-

sion of 95.6311% and an average recall of 88.8128%.

The results presented in Table 4 reveal that our model

has a relatively low rate of false positives but tends

to miss cryptojackers. The false negative rate is ≈

11.2% (computed as 1 − recall), taking into consid-

eration that our model uses only 20 features that are

targeted for one class’ traits (i.e. cryptojackers), there

is room for improvement and we talk about what can

be further done in Section 6. Moreover, we present in

Figure 1 the ROC curve for the trained models.

5 DISCUSSION AND

COMPARISON TO RELATED

WORK

Now that we have gathered and presented all our re-

sults, we are going to discuss about them and we

will point out some major differences between our ap-

proach and the current available methods.

To begin with, in Section 4 we presented the av-

SECRYPT 2019 - 16th International Conference on Security and Cryptography

390

Table 3: A comparison of the average values for cryptojackers and clean applications on ﬁve features extracted from static

analysis.

Feature name Cryptojackers average value Clean applications average value

SizeOfImage (bytes) 21,320,884.1981 10,539,628.71987

OverlaySize (bytes) 1,357,925.2727 4,755,346.9559

NumberOfImportedFunctions 141.7411 269.6894

SizeOfHeaders 1718.6666 1843.2000

NumberOfExports 28.5625 50.5263

Table 4: Average accuracy, precision and recall for the used

classiﬁers.

Model Acc.(%) Precision(%) Recall(%)

SVM 91.5207 97.5696 84.8525

MLP 92.1696 92.6273 91.3216

RF 93.7054 96.6966 90.2643

Average 92.4652 95.6311 88.8128

Figure 1: ROC curve for the used classiﬁers: SVM, MLP

and Random forest.

erage accuracy, precision and recall for the classiﬁca-

tion models used. The average precision of 95.6311%

along with the average recall of 88.8128% reveal that

models based on cryptojackers speciﬁc traits are able

to tell if an application is a cryptocurrency mining

malware with very few false positives, but may miss

cryptojackers. In a real world scenario, due to cryp-

tocurrency mining malware popularity, a user is very

likely to come over such a threat. Supposing that a

common user comes up 10 new applications a month

and few of them (hardly 5 if the user clicks on ev-

erything while he is browsing the internet) are cryp-

tojackers (either they are downloaded from trusted

sources or attached to malicious content on emails

or delivered through other spreading techniques), a

model based on speciﬁc cryptojackers traits is going

to miss, on average, two cryptojackers in two and a

half months while triggering only one false positive.

The above mentioned simulation on a real world

scenario is not sufﬁcient for a user to be fully pro-

tected, but it points out the core idea of our research

paper. Cryptojackers do have speciﬁc traits that can

be exploited in order to detect such threats. More-

over, cryptojackers are very different in terms of be-

havior from a clean application as they usually run

stealthy, they intensively use APIs for network com-

munication, hashing, APIs that may be used to get a

seed for pseudo random number generators and they

have less imported functions, less exported functions

and their disk size is considerably higher as they aim

to have no dependencies (this way they are able to run

on different versions of the operating systems and on

machines with missing libraries).

Approaches presented in the literature refer to

generic malicious software detection. Multiple mal-

ware families are gathered into a single data set and

experiments are thus conducted. Our approach fo-

cuses on a speciﬁc malicious software, cryptojackers,

targeting their behavior and traits. By doing this, even

if cryptojackers are delivered through different attack

vectors (exploits, mail attachments, etc.) the payload

(i.e. the mining component) is going to be identiﬁed.

Also, our approach aims to identify speciﬁc traits to

a prevalent malicious family in order to emphasize

their importance in a classiﬁcation problem. Baldan-

gombo’s et al. (Baldangombo et al., 2013) solution

uses static analysis, if a cryptojacker is obfuscated as

presented by Konoth et al. (Konoth et al., 2019), their

solution is bypassed. Devesa et al. (Devesa et al.,

2010) behavior based classiﬁcation depends exclu-

sively on API calls to identify malware behavior, but

does not correlates this information with any static in-

formation.

The major importance of this paper is the fact that

it presents how traits for standalone cryptojackers can

be extracted in order to improve the security of a ma-

chine. It can be generalized to any operating system,

but our focus was the Windows operating system as

it is most used by regular users. On the other hand,

the results presented in the literature are referring to

browser-based cryptojackers and their focus is ana-

lyzing Javascript code, not the binary executable ﬁle

responsible for mining cryptocurrencies.

Hunting Traits for Cryptojackers

391

6 CONCLUSIONS AND FUTURE

WORK

Malicious software is everywhere across the Internet,

from adware popping up on many websites up to ran-

somware encrypting user’s ﬁle system. Security is-

sues are discovered every day in different software

and are quickly patched by developers. However,

many users decline to update their systems, leaving

their machines vulnerable to attacks, thus, making the

attacks easier by targeting vulnerable machines. Mal-

ware industry has grown over the past twenty years

and represents a way of living for attackers and has

registered huge proﬁt for them. New malware and

new attacking vectors are developed every day and

they are released in the wide world of the Internet.

Cryptojackers have produced more than 56 million

USD as stated by Pastrana et al. (Pastrana and Suarez-

Tangil, 2019).

In order to give a ﬁnal answer to the 3 main ques-

tions presented in the introductory part, we have to

point out that:

• Yes, there are anomalies in the characteristics of a

cryptojacker as we presented in Tables 1, 2, 3.

• In Section 5 we explained why cryptojackers have

speciﬁc features present.

• We experimentally proved in Section 4 using three

different classiﬁcation models that cryptojackers

can be reliably separated from clean applications

using only 20 features.

Due to the high number of recent cryptojacking at-

tacks, there is a need of a speciﬁc component in order

to protect users from such attacks. In order to achieve

that, cryptojackers had to be analyzed and features

speciﬁc to them extracted. We presented three dif-

ferent classiﬁcation models with an average accuracy

of ≈ 92.46% based on the features of cryptojackers

along with its advantages, disadvantages and a com-

parison to existing solutions.

The current classiﬁcation models rely on few fea-

tures related to function calls and portable executable

header. The main goal of the classiﬁcation models is

to provide an experimental validation for the extracted

features and emphasize their importance. A substan-

tial improvement would be to further analyze cryp-

tojackers behavior and traits in terms of ﬁle system

interactions (copied, written and read ﬁles), registry

interactions (queried, opened, written registry keys)

and network trafﬁc (packet analysis). Thus, even in

extreme cases where cryptojackers use custom made

libraries and functions to achieve their goal, there

would still be features revealing their malicious be-

havior. Another improvement would be to analyze the

clean applications traits in comparison to cryptojack-

ers (what traits are highly present at clean applications

but are rarely present at cryptojackers) in order to bet-

ter separate between these two classes.

REFERENCES

Aﬁanian, A., Niksefat, S., Sadeghiyan, B., and Baptiste,

D. (2018). Malware dynamic analysis evasion tech-

niques: A survey. arXiv preprint arXiv:1811.01190.

Antonakakis, M., April, T., Bailey, M., Bernhard, M.,

Bursztein, E., Cochran, J., Durumeric, Z., Halderman,

J. A., Invernizzi, L., Kallitsis, M., et al. (2017). Under-

standing the mirai botnet. In USENIX Security Sym-

posium, pages 1092–1110.

Baldangombo, U., Jambaljav, N., and Horng, S.-J. (2013).

A static malware detection system using data mining

methods. arXiv preprint arXiv:1308.2831.

Coinhive (2012). Coinhive monetize your business with

your users cpu power. https://coinhive.com/. Ac-

cessed: 2018-12-09.

Coinmarketcap (2013). Cryptocurrency market capitaliza-

tion. https://coinmarketcap.com/. Accessed: 2018-12-

09.

CryptoLOOT (2017). Earn more from your trafﬁc. https:

//crypto-loot.com/. Accessed: 2018-12-09.

De Paola, A., Gaglio, S., Re, G. L., and Morana, M. (2018).

A hybrid system for malware detection on big data.

In IEEE INFOCOM 2018-IEEE Conference on Com-

puter Communications Workshops (INFOCOM WK-

SHPS), pages 45–50. IEEE.

Devesa, J., Santos, I., Cantero, X., Penya, Y. K., and

Bringas, P. G. (2010). Automatic behaviour-based

analysis and classiﬁcation system for malware detec-

tion. ICEIS (2), 2:395–399.

Duda, R. O., Hart, P. E., and Stork, D. G. (2012). Pattern

classiﬁcation. John Wiley & Sons.

Egele, M., Scholte, T., Kirda, E., and Kruegel, C. (2012). A

survey on automated dynamic malware-analysis tech-

niques and tools. ACM computing surveys (CSUR),

44(2):6.

Eskandari, S., Leoutsarakos, A., Mursch, T., and Clark, J.

(2018). A ﬁrst look at browser-based cryptojacking.

arXiv preprint arXiv:1803.02887.

FileHippo (2004). Download free software. https://

ﬁlehippo.com/. Accessed: 2018-12-09.

Gastwirth, J. L. (1972). The estimation of the lorenz curve

and gini index. The review of economics and statistics,

pages 306–316.

Hastie, T., Rosset, S., Tibshirani, R., and Zhu, J. (2004).

The entire regularization path for the support vector

machine. Journal of Machine Learning Research,

5(Oct):1391–1415.

Hong, G., Yang, Z., Yang, S., Zhang, L., Nan, Y., Zhang,

Z., Yang, M., Zhang, Y., Qian, Z., and Duan, H.

(2018). How you get shot in the back: A systemat-

ical study about cryptojacking in the real world. In

SECRYPT 2019 - 16th International Conference on Security and Cryptography

392

Proceedings of the 2018 ACM SIGSAC Conference

on Computer and Communications Security, pages

1701–1713. ACM.

Hybrid-analysis (2014). Free automated malware analysis

service. https://www.hybrid-analysis.com/. Accessed:

2018-12-22.

JSEcoin (2017). Jsecoin: Digital currency - designed for

the web. https://jsecoin.com/. Accessed: 2018-12-09.

Kim, K. and Moon, B.-R. (2010). Malware detection

based on dependency graph using hybrid genetic al-

gorithm. In Proceedings of the 12th annual confer-

ence on Genetic and evolutionary computation, pages

1211–1218. ACM.

Kingma, D. P. and Ba, J. (2014). Adam: A

method for stochastic optimization. arXiv preprint

arXiv:1412.6980.

Konoth, R. K., van Wegberg, R., Moonsamy, V., and Bos,

H. (2019). Malicious cryptocurrency miners: Status

and outlook. arXiv preprint arXiv:1901.10794.

Krishnan, H. R., Saketh, S. Y., and Vaibhav, V. T. M. (2015).

Cryptocurrency mining-transition to cloud. Interna-

tional Journal of Advanced Computer Science and Ap-

plications, 6(9):115–124.

Lyda, R. and Hamrock, J. (2007). Using entropy analysis to

ﬁnd encrypted and packed malware. IEEE Security &

Privacy, 5(2).

MalShare (2013). Malware repository providing re-

searchers access to samples. https://malshare.com/.

Accessed: 2018-12-22.

Metz, C. E. (1978). Basic principles of roc analysis. In

Seminars in nuclear medicine, volume 8, pages 283–

298. Elsevier.

Microsoft (1991). Peering inside the pe: A tour of the

win32 portable executable ﬁle format. https://msdn.

microsoft.com/en-us/library/ms809762.aspx. Ac-

cessed: 2018-12-09.

Moser, A., Kruegel, C., and Kirda, E. (2007). Limits of

static analysis for malware detection. In Computer

security applications conference, 2007. ACSAC 2007.

Twenty-third annual, pages 421–430. IEEE.

Musavi, M. T., Ahmed, W., Chan, K. H., Faris, K. B., and

Hummels, D. M. (1992). On the training of radial

basis function classiﬁers. Neural networks, 5(4):595–

603.

Ninite (2009). Install or update multiple apps at once. https:

//ninite.com/. Accessed: 2018-12-22.

Pal, M. (2005). Random forest classiﬁer for remote sensing

classiﬁcation. International Journal of Remote Sens-

ing, 26(1):217–222.

Pastrana, S. and Suarez-Tangil, G. (2019). A ﬁrst look at

the crypto-mining malware ecosystem: A decade of

unrestricted wealth. arXiv preprint arXiv:1901.00846.

Pedregosa, F., Varoquaux, G., Gramfort, A., Michel, V.,

Thirion, B., Grisel, O., Blondel, M., Prettenhofer,

P., Weiss, R., Dubourg, V., Vanderplas, J., Passos,

A., Cournapeau, D., Brucher, M., Perrot, M., and

Duchesnay, E. (2011). Scikit-learn: Machine learning

in Python. Journal of Machine Learning Research,

12:2825–2830.

Rauchberger, J., Schrittwieser, S., Dam, T., Luh, R., Buhov,

D., P

otzelsberger, G., and Kim, H. (2018). The other

side of the coin: A framework for detecting and ana-

lyzing web-based cryptocurrency mining campaigns.

In Proceedings of the 13th International Conference

on Availability, Reliability and Security, page 18.

ACM.

Riedmiller, M. (1994). Advanced supervised learning

in multi-layer perceptrons—from backpropagation to

adaptive learning algorithms. Computer Standards &

Interfaces, 16(3):265–278.

Roundy, K. A. and Miller, B. P. (2010). Hybrid analysis

and control of malware. In International Workshop on

Recent Advances in Intrusion Detection, pages 317–

338. Springer.

Saad, M., Khormali, A., and Mohaisen, A. (2018). End-

to-end analysis of in-browser cryptojacking. arXiv

preprint arXiv:1809.02152.

Sari, A. and Kilic, S. (2017). Exploiting cryptocurrency

miners with oisnt techniques. Transactions on Net-

works and Communications, 5(6):62.

Swan, M. (2015). Blockchain: Blueprint for a new econ-

omy. ” O’Reilly Media, Inc.”.

Tahir, R., Huzaifa, M., Das, A., Ahmad, M., Gunter, C.,

Zaffar, F., Caesar, M., and Borisov, N. (2017). Min-

ing on someone else’s dime: Mitigating covert min-

ing operations in clouds and enterprises. In Interna-

tional Symposium on Research in Attacks, Intrusions,

and Defenses, pages 287–310. Springer.

Wang, L. (2005). Support vector machines: theory and ap-

plications, volume 177. Springer Science & Business

Media.

Xu, B., Wang, N., Chen, T., and Li, M. (2015). Empiri-

cal evaluation of rectiﬁed activations in convolutional

network. arXiv preprint arXiv:1505.00853.

Yang, R. R., Kang, V., Albouq, S., and Zohdy, M. A. (2015).

Application of hybrid machine learning to detect and

remove malware. Transactions on Machine Learning

and Artiﬁcial Intelligence, 3(4):16.

Zabidi, M. N. A., Maarof, M. A., and Zainal, A. (2012).

Malware analysis with multiple features. In Com-

puter Modelling and Simulation (UKSim), 2012 UK-

Sim 14th International Conference on, pages 231–

235. IEEE.

Hunting Traits for Cryptojackers

393
