Simulating the Impact of Annotation Guidelines and Annotated Data on

Extracting App Features from App Reviews

Faiz Ali Shah, Kairit Sirts and Dietmar Pfahl

Institute of Computer Science, University of Tartu, J. Liivi 2, 50409, Tartu, Estonia

Keywords:

App Feature Extraction, Supervised Machine Learning, Annotation Guidelines, Requirements Engineering.

Abstract:

The quality of automatic app feature extraction from app reviews depends on various aspects, e.g. the feature

extraction method, training and evaluation datasets, evaluation method etc. Annotation guidelines used to

guide the annotation of training and evaluation datasets can have a considerable impact to the quality of the

whole system but it is one of the aspects that is often overlooked. We conducted a study in which we explore

the effects of annotation guidelines to the quality of app feature extraction. We propose several changes

to the existing annotation guidelines with the goal of making the extracted app features more useful to app

developers. We test the proposed changes via simulating the application of the new annotation guidelines

and evaluating the performance of the supervised machine learning models trained on datasets annotated with

initial and simulated annotation guidelines. While the overall performance of automatic app feature extraction

remains the same as compared to the model trained on the dataset with initial annotations, the features extracted

by the model trained on the dataset with simulated new annotations are less noisy and more informative to app

developers.

1 INTRODUCTION

App marketplaces provide app users a channel to sub-

mit feedback in the form of a review. Users in these

reviews provide valuable information such as fea-

ture requests, bug reports, user experience, and eval-

uation of app features (Pagano and Maalej, 2013).

The analysis of opinions expressed about different

features of an app in user reviews offers opportuni-

ties and insights to both app users and app develop-

ers. For app developers, it is useful to monitor the

“health” of app features in the context of release plan-

ning (Maalej et al., 2016) as well as to evaluate prod-

uct competitiveness and quality (Shah et al., 2016).

From the users’ perspective, such information helps

decide which app to select from a wide range of com-

peting apps. Both Apple’s App Store and Google’s

Play Store receive enormous amounts of reviews ev-

ery day rendering a manual analysis infeasible and

demanding automated methods. One standard ap-

proach towards automation is to generate sentiment

summaries of a product at feature-level involving two

steps (Zhang and Liu, 2014): 1) identiﬁcation of app

features (also called aspect terms or opinion targets

in the opinion mining literature) in user reviews, and

2) determination and aggregation of sentiments ex-

pressed on product features identiﬁed in the previous

step.

Since identifying product features in user reviews

is a crucial step for generating sentiment summaries,

several prior studies on app review analysis have ex-

clusively focused on this step. Previous work on as-

pect extraction from app reviews includes using topic

modeling (Guzman and Maalej, 2014) and an ap-

proach called SAFE (Simple Approach for Feature

Extraction) based on manually extracted rules (Jo-

hann et al., 2017). The performance reported with

these two approaches is summarized in the ﬁrst two

rows of Table 1. Although these results seem to indi-

cate that the topic modeling and the SAFE approach

are complementary with regards to precision and re-

call, they are not directly comparable because the au-

thors used different sets of app reviews, different an-

notation guidelines (AGs) and different performance

evaluation methods. Johann et al. (2017) compared

the performance of a version of the topic modeling

approach proposed by Guzman et al. (2014) on their

set of app reviews using the same AGs and evalua-

tion procedure as in the SAFE approach. These re-

sults, shown in the 3rd row of Table 1, indicate that

the performance of the topic modeling approach is

much lower than reported in the original paper and

384

Shah, F., Sirts, K. and Pfahl, D.

Simulating the Impact of Annotation Guidelines and Annotated Data on Extracting App Features from App Reviews.

DOI: 10.5220/0007909703840396

In Proceedings of the 14th International Conference on Software Technologies (ICSOFT 2019), pages 384-396

ISBN: 978-989-758-379-7

Table 1: Performance obtained with different approaches to

extract features from app reviews.

Ref Approach Prec Rec F1

Guzman et al. (2014) Topic modeling (1) 0.58 0.52 0.55

Johann et al. (2017) SAFE 0.24 0.71 0.36

Johann et al. (2017) Topic modeling (2) 0.22 0.28 0.24

Sanger et al. (2016) CRF 0.69 0.56 0.62

also worse than that of the SAFE approach, in par-

ticular with regards to recall. Another recent study

for extracting features from app reviews, conducted

on German language reviews (S

anger et al., 2016),

used a supervised machine learning method of Con-

ditional Random Fields (CRF) (Lafferty et al., 2001).

Previously, CRF method has been successfully ap-

plied to extract features from LAPTOP and RESTAU-

RANT reviews (Pontiki et al., 2016; Liu et al., 2015),

which serve as standard aspect extraction benchmark

datasets in sentiment analysis community. The results

of Sanger et al. (2016), shown in the last row of Ta-

ble 1, suggest that supervised machine learning meth-

ods might have an advantage over unsupervised and

rule-based methods (such as SAFE) also for extract-

ing features from English app reviews, given that an-

notated training data is available.

There are several questions previous studies fail

to answer when developing systems for automatically

extracting features from app reviews. An important

question is related to the annotation of app features:

Which word or sequence of words in a review con-

stitutes an app feature? Training a feature extraction

system using supervised machine learning methods

requires a training set where all feature instances are

annotated

. Unsupervised or rule-based systems do

not need an annotated training set but they need an

annotated test set to evaluate how well the system

performs. Clearly, the exact annotation procedure,

operationalized via AGs, potentially affects both

the evaluation results and the usefulness of those

results to app developers. This motivates our research

question:

RQ: To what extent is automatic feature extraction

from app reviews sensitive to the used AGs?

To study this research question, we use two avail-

able app review datasets that are both annotated with

app features using different AGs: 1) English app

review data contributed by Guzman et al. (2014),

which includes annotated reviews of seven apps from

App Store and Play Store (GUZMAN dataset) and

2) German app review data published by Sanger et al.

(2016), which contains annotated reviews from eleven

Note that we use the words annotated and labeled as

synonyms in this article.

app categories of Play Store (SANGER dataset).

Furthermore, we employed two undergraduate

students as annotators. Each of them annotated in-

dependently 500 reviews of the seven apps contained

in the GUZMAN dataset

following the AGs proposed

by Sanger et al. (2016). Because the inter-annotator

agreement between the two annotators on the newly

annotated dataset is low (Dice index = 0.28), we treat

the annotations of the two annotators as two different

datasets.

We train and evaluate supervised CRF models on

all datasets, i.e., the GUZMAN dataset, the SANGER

dataset, and the datasets annotated by our student an-

notators using cross-category validation (CCV) set-

tings. The CCV training regime assumes that reviews

of different app categories share enough common in-

formation that a model trained on the reviews belong-

ing to one set of apps or app categories will general-

ize to the apps or app categories whose reviews the

model has not seen during training. In this training

regime, we select to hold out one app category and

train the model on the app reviews of all other cate-

gories. Finally, we test on the app reviews of the held-

out app category. This procedure is repeated until all

categories have been held out in turn. Then we use

the average feature extraction performance of these

models as a proxy for evaluating the goodness of the

AGs. We simulate several changes in AGs and as-

sess their effect using the performance of the predic-

tive CRF modeling. Using this procedure, we are able

to propose several changes to the app feature AGs that

improve the quality of the annotated app reviews for

both training and evaluation purposes.

2 RELATED WORK

Several methods for extracting app features from app

reviews have been proposed. Guzman et al. (2014)

used unsupervised LDA topic modeling (Blei et al.,

2003) for automatic extraction of app features from

user reviews of seven apps (three from App Store

and four from Play Store). The extracted app fea-

tures were evaluated against human labeled app fea-

tures. The study of Gu et al. (2015) classiﬁes re-

view sentences into categories, such as feature evalu-

ation, praise, feature requests, bug reports and others,

and then extracts app features using 26 manually de-

signed rules only from those sentences that belong to

the feature evaluation category. Johann et al. (2017)

The particular apps from which the reviews are taken

are not known.

Reviews annotated by our students may differ from

those in the GUZMAN dataset.

Simulating the Impact of Annotation Guidelines and Annotated Data on Extracting App Features from App Reviews

385

proposed a rule-based approach SAFE that uses Part-

of-Speech (POS) and sentence patterns for extracting

app features from app descriptions and user reviews.

Malik et al. (Malik et al., 2018) uses syntactic rela-

tions between the features and opinion words for the

extraction of app features from user reviews.

A few studies focus on summarizing reviews that

are informative for developers using topic models

(Guzman et al., 2015; Panichella et al., 2015; Luiz

et al., 2018). Recently, supervised machine learning

approaches have been used to classify app reviews

into functional and non-functional requirements (Lu

and Liang, 2017; Kurtanovi

c and Maalej, 2017).

Instead of trying to directly extract app features,

the study of (Vu et al., 2015) extract all potential key-

words from user reviews and rank them based on the

review rating and occurrence frequency. Their ap-

proach also has the ability to cluster or expand the set

of extracted keywords based on their semantic simi-

larity. The study of (Keertipati et al., 2016) extracted

nouns as candidate app features from the app review

sentences but they did not perform an evaluation to

check whether the extracted features actually repre-

sent true app features.

All of the aforementioned studies related to app

feature extraction use different techniques, review

datasets and AGs; therefore, the results reported in

these studies are not directly comparable to each

other. Additionally, without having access to differ-

ent datasets and AGs, it is difﬁcult to assess the qual-

ity of the annotations that were used to evaluate the

systems. We were able to obtain the evaluation set of

Guzman et al. (2014) together with its AGs and we

use this dataset as one of the annotated experimental

training sets (GUZMAN dataset) in our study.

In the literature, much research (Kang and Zhou,

2017) is dedicated to automatic extraction of features

from product reviews in the LAPTOP and RESTAU-

RANT domains. The best results have been achieved

using supervised learning approach such as Condi-

tional Random Fields (CRF) and Convolutional Neu-

ral Network (CNN) (Pontiki et al., 2016; Poria et al.,

2016). We know of only one study that used super-

vised sequence tagging model (i.e., CRF) for auto-

matic extraction of app features from app reviews has

been performed by Sanger et al. (2016) on German

app reviews.

3 STUDY DESIGN

We study our Research Question RQ by evaluating the

results of several simulation experiments on app re-

view data with human-annotated app features. These

experiments include several variables, some of which

are ﬁxed and some are systematically altered to study

the Research Questions. Table 2 summarizes all de-

sign variables.

Table 2: Summary of design variables.

GIVEN DESIGN VARIABLES

1. Annotation guidelines

a) SANGER annotation guidelines (German and English)

b) GUZMAN annotation guidelines (English)

2. Annotated datasets

1) SANGER dataset (S

anger et al., 2016), annotated using SANGER guidelines

2) SHAH dataset: annotated by two annotators using translated SANGER guide-

lines.

a) SHAH-I: SHAH dataset labeled by annotator I.

b) SHAH-II: SHAH dataset labeled by annotator II.

3) GUZMAN dataset (Guzman and Maalej, 2014), annotated using GUZMAN

guidelines

3. Modeling approach: CRF model with the following features extracted from the

current word and its context of two preceding and two following words:

a) the words themselves

b) POS of the words in the sentence

c) one to four character preﬁxes and sufﬁxes of the words

d) the position of the words

e) the stylistics of each word (e.g. case, digit, symbol, alphanumeric)

4. Evaluation methods

a) Type-based exact match

b) Type-based partial match

5. Training procedure

• CCV: Cross-Category Validation on the full dataset

MANIPULATED DESIGN VARIABLES

6. Data processing ﬂow

Step 1 (Pre-processing): remove non-consecutive app features, remove

app reviews with no annotated features

Step 2 (Simulation step I): Remove pseudo-features

Step 3 (Simulation step II): Remove app features that do not contain a

NOUN

Step 4 (Simulation step III): Remove app features that are longer than

three words

To study Research Question RQ we use all Given

Design Variables 1 to 4 and adopt CCV as training

procedure to explore the effects of the Data Process-

ing steps simulating the changes in the AGs. We as-

sume that the quality of the training data annotations

and the accuracy of the app feature extraction model

are positively correlated. Thus, we use model accu-

racy on the test set to assess the impact of a change in

the AGs. We train and evaluate CRF-based app fea-

ture extraction models on all our annotated datasets

after each Data Processing steps and assess their accu-

racies to approximate how each step affects the qual-

ity of the annotations.

In the following, we describe all design variables

in detail.

ICSOFT 2019 - 14th International Conference on Software Technologies

386

3.1 Annotation Guidelines

Our experimental datasets (described more thor-

oughly in the next subsection) are annotated using two

distinct set of AGs, i.e., GUZMAN and SANGER AGs.

The GUZMAN AGs

were developed by Guzman

et al. (2014) to annotate their evaluation set. These

AGs deﬁne an app feature as a description of speciﬁc

app functionality visible to the user (such as upload-

ing ﬁles or sending emails), a speciﬁc screen of the

app, a general quality of the app (such as time needed

to load or size of storage) or a speciﬁc technical char-

acteristic (e.g. a network protocol or HTML5). The

AGs encourage to annotate the exact words used in

the text but do not enforce it. The guidelines explicitly

allow for annotating app features consisting of non-

consecutive words.

The SANGER AGs

were developed by Sanger

et al. (2016) to annotate app features, subjective

phrases, and relationships between them. We trans-

lated these guidelines from German into English.

SANGER AGs deﬁne as an app feature “anything that

is part of the application or in some form connected

with the app”. This includes existing and requested

app features, bugs and errors as well as entities refer-

ring to non-functional features such as usability, de-

sign, price, license, permissions, advertisements and

updates. The guidelines explicitly instruct to annotate

the mentions of the app itself as a feature. Instructions

also ask to annotate implicit features represented by

a single verb such as runs. Annotators are encour-

aged to keep the annotated features as short as possi-

ble although a particular length limit is not set. The

SANGER guidelines speciﬁcally require not to include

function words into annotated app features, which

probably also inﬂuences the length of the annotated

app features. Although no explicit mention about an-

notating consecutive vs non-consecutive words as fea-

tures is made, all example features only consist of

consecutive words.

Although both AGs can be used to label the same

information—features in app reviews—they have dif-

ferences which may inﬂuence how well the data an-

notated with these guidelines can be used to train a

model for automatic feature extraction.

1) Using feature annotations not comprised of exact

words used in the review text will make any auto-

matic use of these annotations very difﬁcult. Al-

though this practice is discouraged in the GUZ-

MAN guidelines, it is not explicitly prohibited.

https://mast.informatik.uni-hamburg.de/wp-

content/uploads/2014/03/Coding Guide.pdf

Available from http://www.romanklinger.de/scare/

2) Annotating non-consecutive app features, allowed

in GUZMAN guidelines, restricts the types of

models that can be used. In particular, sequence

tagging models like Conditional Random Fields

and Recurrent Neural Networks, which produce

state-of-the-art results on the feature extraction

task (Liu et al., 2015), can only process features

consisting of consecutive words.

3) The instruction in SANGER guidelines to anno-

tate mentions and references to the app itself is

most probably motivated by the particular task of

Sanger et al. (2016) to learn to extract both app

features and their relations to subjective phrases.

In the context of plain app feature extraction these

features can be considered pseudo-features, as

they not give any useful information to the app

developers.

4) Similarly, the instruction in SANGER guidelines

to annotate standalone abstract verbs such as runs

is probably motivated by the joint task of learning

both app features and subjective phrases. In the

context of app feature extraction these aspects will

likely cause problems because they are difﬁcult to

distinguish from other generic verbs not labeled as

app features. Also, these very generic app features

are likely of very little value to the developers.

3.2 Annotated Datasets

We have at our disposal four annotated app review

datasets: GUZMAN dataset, SANGER dataset and two

versions of SHAH datasets. We present some char-

acteristics of these datasets in Table A of Appendix

Note that we do not show data per individual app but

aggregated per app category. Each review dataset is

characterized using the following information:

a) the total number of reviews;

b) the total number of sentences in all reviews;

c) the total number of annotated app features in (to-

kens);

d) the number of distinct app features (types);

e) the number of app features consisting of a single

word only;

f) the number of app features consisting of at least

two words;

g) the type-token ratio of annotated app features (the

number of feature types divided by the number of

feature tokens).

The GUZMAN dataset

was used as an evaluation

set in the study performed by Guzman et al. (2014).

https://ﬁgshare.com/s/2bad5b1507ac0f6a8a43

The dataset was obtained from the authors of Guzman

et al. (2014)

Simulating the Impact of Annotation Guidelines and Annotated Data on Extracting App Features from App Reviews

387

It contains annotated app reviews in English language

from six different app categories. Most app categories

contain reviews from one app only: AngryBirds from

Games category, TripAdvisor from Travel category,

PicsArt from Photography category, Pinterest from

Social category and Whatsapp from Communication

category. The only exception is the Productivity cate-

gory which contains reviews from two apps: Dropbox

and Evernote. According to Guzman et al. (2014),

400 reviews were annotated for each app. However,

from Table it can be seen that the GUZMAN dataset in-

cludes less than 400 reviews in each category. This is

because the GUZMAN dataset

only contains reviews

with at least one annotated app feature.

The SANGER dataset

was developed and used by

Sanger et al. (2016). It contains reviews in German

language. The SANGER dataset has the same number

of reviews in each app category. The reviews in each

category come from 10 to 15 different apps but the

origin of each particular review is unknown to us. In

addition to app features, this dataset is also annotated

with subjective phrases and relations between features

and subjective phrases. However, we only use the an-

notated app features and ignore all other annotations.

In addition to the two datasets available from other

researchers, we created the SHAH dataset. The app

reviews included in this dataset were selected by ran-

domly sampling 500 reviews per app from the total

pool of reviews assembled by Guzman et al. (2014)

for their study. The app categories and apps in each

category are the same as in the GUZMAN dataset.

Similar to Guzman et al. (2014), since each app has

its own user rating distribution, we used a stratiﬁed

sampling procedure to sample the reviews using the

distribution over ratings as stratum. For measuring the

inter-annotator agreement, we adopted the Dice co-

efﬁcient (Pavlopoulos and Androutsopoulos, 2014),

which ranges between 0 and 1 where 1 means total

agreement and 0 total disagreement. The Dice co-

efﬁcient value between the two annotators was 0.28

which denotes a low agreement between the annota-

tors. Because of that, we decided to treat the annota-

tions of both annotators as different datasets resulting

in two annotated SHAH datasets: SHAH-I and SHAH-

II containing the annotations of the ﬁrst and the sec-

ond annotator respectively.

Based on the statistics, several differences be-

tween the datasets are visible. Firstly, the GUZMAN

dataset differs strongly from the other datasets by

having multi-word features twice as often as single-

From the dataset we obtained from the authors of Guz-

man et al. (2014) the reviews without any annotated app

features had been ﬁltered out.

Available from http://www.romanklinger.de/scare/

word features. In contrast, the SHAH-II and SANGER

datasets have more single-word features than multi-

word features and in the SHAH-I dataset the numbers

are balanced. Several reasons may account for these

differences, including how each annotator interpreted

the AGs given to them, but we believe that this dif-

ference might also characterize the differences in the

AGs themselves.

The second main difference manifests itself in the

average number of app features per review. This

quantity is largest for the GUZMAN dataset and small-

est for both SHAH datasets with the SANGER dataset

falling in-between. We attribute this difference to fact

that the GUZMAN dataset only consists of reviews that

contain at least one annotated app feature while the

other datasets may also contain reviews without a sin-

gle annotated app feature.

Thirdly, also the type-token ratio of app features

is largest for the GUZMAN dataset indicating that the

proportion of distinct app features is largest in this

dataset. This can be explained by the large number

of multi-word app features: the longer the features

the more likely they consist of a unique sequence of

words.

3.3 Modeling Approach

We adopt the Conditional Random Field (CRF) (Laf-

ferty et al., 2001), a supervised learning method to

train the models for all our experiments. CRF is a

sequence tagging model which tags each word in the

app review text with a label. Similarly to Sanger et

al. (2016) we use the BIO labeling scheme, where the

tag B is used to annotate the ﬁrst word of each app

feature, I labels the rest of the words inside the app

feature and the label O is used to tag all words that are

outside of the app feature. We use an implementation

based on CRFSuite

which was used as a CRF base-

line by Liu et al. (2015) on LAPTOP and RESTAU-

RANT product review datasets. The hand-crafted fea-

tures used in the CRF model are the same as used by

Liu et al. (2015), they are summarized in Table 2.

The study by Liu et al. (2015) showed that using

word embeddings (Mikolov et al., 2013) as additional

features improves CRF model performance. There-

fore, we included word embeddings as features in our

experiments. For the datasets in English language

(GUZMAN and SHAH datasets), we used SENNA em-

beddings (Collobert et al., 2011)

. For the SANGER

dataset in German language, we used the embed-

dings

trained on Wikipedia articles.

https://github.com/pdsujnow/opinion-target

https://ronan.collobert.com/senna/

https://spinningbytes.com/resources/word-

ICSOFT 2019 - 14th International Conference on Software Technologies

388

3.4 Evaluation Procedures

We evaluate all results by computing precision, recall

and F1-score of the predicted app features. Since app

feature annotations themselves may be noisy and am-

biguous, which manifests itself in low agreement be-

tween annotators (for instance (Guzman and Maalej,

2014) reported an agreement of 53% on annotated

app features), we adopt type-based evaluation meth-

ods using both exact and partial matching between

predicted and human-annotated features (see Part 4

in Table 2).

Exact match requires the predicted and annotated

app features to match exactly. For instance, if the

annotated feature is to upload video then in order to

count a match the predicted app feature must consist

of exactly the same words. If the model predicts up-

load video as feature leaving the particle to untagged

the prediction is counted as false positive under the

exact match scheme.

Partial match allows a mismatch when compar-

ing predicted app features with human-annotated fea-

tures in the evaluation set. We allow a difference of

one word. Under the partial match scheme, the pre-

dicted feature upload video will be counted as true

positive even if the human-annotated feature is to up-

load video, whereas the predicted feature video would

be a false positive because it differs from the human-

annotated feature by more than one word. Similarly,

a predicted feature failed to upload video would be

counted as true positive under partial match but an

even longer predicted feature like failed to upload

video to will be counted as false positive.

Type-based evaluation counts and evaluates each

app feature type only once, regardless of how many

times it occurs in the review texts. In order to cluster

together different instances of the same app feature

type, the features are ﬁrst lemmatized using Snow-

ball

stemmer available in NLTK library and then

matched based on their lemmas. The type-based eval-

uation procedure is unbiased by the frequencies of the

single app feature types. While the token-based eval-

uation measures can become artiﬁcially high when the

annotated training and test set contain a single high-

frequency simple one-word app feature, the type-

based evaluation gives equal credit to all different app

features, regardless of their frequency.

3.5 Data Processing

The data processing steps adopted in our study com-

prise one pre-processing step and three steps for sim-

embeddings/

http://www.nltk.org/ modules/nltk/stem/snowball.html

ulating the changes in AGs.

The Pre-processing Step is necessary to unify all

experimental annotated datasets to bring them to sim-

ilar starting point. First of all, GUZMAN dataset

can also include annotations of non-consecutive app

features. Because the CRF model can only learn

app features consisting of consecutive words, we re-

move all non-consecutive app features from GUZ-

MAN dataset because leaving them in would put the

GUZMAN datasets and GUZMAN AGs into a dis-

advantaged position compared to the SANGER and

SHAH datasets annotated with SANGER guidelines

where annotated app features always consist of only

consecutive words. After that, we remove all reviews

from the datasets that do not contain any annotated

app feature. We do this because the annotated GUZ-

MAN dataset we obtained from the authors of (Guz-

man and Maalej, 2014) is a subset of all the reviews

originally annotated by Guzman et al. (2014)—the

annotated reviews containing no app features were

left out. Although removing such reviews biases the

datasets, it makes the SANGER and SHAH datasets

comparable to the GUZMAN dataset in terms of app

feature distribution over reviews.

Simulation Step I removes all annotated features

not referring to app functional or non-functional as-

pects but only to app itself either by the app name or

by explicitly using the words such as app or appli-

cation and other similar pseudo-features. This step

simulates the change in the SANGER AGs such that

the command to annotate the references to the app it-

self are removed. Because GUZMAN AGs do not re-

quire to annotate such pseudo-features this simulation

step only changes the annotations of the SANGER and

SHAH datasets. After this step, the reviews without

any annotated app features are removed again to en-

sure that the feature distributions over all datasets are

similar.

Simulation Step II removes all app features that do

not contain a noun. Previous studies (Zamani et al.,

2014; Keertipati et al., 2016) use this simple heuristic

to identify app features from user reviews. This sim-

ulation step ensures that annotated app feature should

be speciﬁc enough and this can only be achieved by

requiring the presence of a noun phrase. For instance,

an app feature such as to upload, which consists of

a particle and a verb and does not include a noun, is

too non-speciﬁc to understand what kind to function-

ality the feature refers to. Thus, after this simulation

step, these kinds of word sequences are not consid-

ered as app features anymore, whereas a similar word

sequence to upload video, which speciﬁes the action

with a noun, will be kept. This simulation step mostly

removes short generic app features annotated accord-

Simulating the Impact of Annotation Guidelines and Annotated Data on Extracting App Features from App Reviews

389

ing to SANGER guidelines.

Simulation Step III removes all app features that

are longer than three words. We believe that useful

features cannot be too long because otherwise they

become too speciﬁc and noisy. We attempt to simu-

late the change in AGs that would limit the maximum

length of an app feature to three words with a very

crude heuristic that just removes the longer features

from the dataset. Although a better heuristic would

be to develop a set of rules to shorten the app features

appropriately we opted here for the simplest strategy,

believing that it will be good enough for our purpose

of testing the potential effect of such a guideline.

3.6 Training Procedure

We use a cross-category validation (CCV) training

procedure in our study. The CCV training procedure

assumes that the annotated training data consists of

app reviews belonging to several different app cate-

gories. Then the reviews of each app category are

held out in turn and the model is trained on the re-

views in the other app categories. Finally the trained

model is evaluated on the held-out reviews. We use

cross-category validation instead of cross-app valida-

tion because both in GUZMAN and SHAH datasets,

with one exception we have the reviews of just one

app in each of the app categories. In SANGER dataset,

although each category contains reviews from several

apps, we do not have the app name annotations at-

tached to each review and thus we could not separate

the reviews of different apps into different subsets.

4 RESULTS

In this section, we present the results of our study

and answer the research question (RQ). For better

readability, we only show aggregated results for each

dataset in Table 3. Detailed results at app category

level can be found in the Appendix

(Tables B to E).

Before we describe the contents of Table 3, we

summarize characteristics of the labeled datasets used

in our study before and after each processing step.

The exact numbers can be found in Figure A of Ap-

pendix

. The annotated datasets at the Baseline, i.e.,

before applying Step 1 (Pre-processing) correspond

to those described in Section 3.2. Several phenom-

ena can be observed when comparing the evolution

of dataset characteristics from before Step 1 to af-

ter Step 4. Due to the nature of the data processing

steps, the numbers of app features steadily decrease

in all datasets, both token-wise and type-wise, and

several of the characteristics of the four datasets con-

verge. For example, at the Baseline, the type-token

ratio of app features varies in the range [0.31, 0.75],

while after Step 4, the variation is reduced to the range

[0.69, 0.79]. In other words, in Step 4, most of the fea-

ture instances occur only once or twice in each of the

datasets. Similarly, the average number of features

per review, which initially varies in the range [0.31,

1.80], reduces to a range of [0.31, 1.06] after the Step

4. For the GUZMAN, SHAH-I, and SHAH-II datasets

the portion of single-word features converges from

variation in range [0.32, 0.71] to variation in range

[0.31, 0.37]. Only for the SANGER dataset, the por-

tion of single-word features stays high (with a small

reduction from 0.84 to 0.76). One explanation for the

high portion of single-word features in the SANGER

dataset could be that the German language allows

for noun compositions replacing multiple-word noun

phrases.

Table 3: Model performance after data processing.

Processing Exact Types Partial Types

Step Prec Rec F1 Prec Rec F1

a) GUZMAN dataset:

Step 1: Pre-processing 45.5 14.6 21.4 68.9 26.2 37.2

Step 2: Simulation I 44.5 14.0 20.7 68.1 25.4 36.1

Step 3: Simulation II 43.3 13.0 19.1 66.5 23.2 33.1

Step 4: Simulation III-3 48.0 15.4 22.5 74.9 29.9 41.8

b) SHAH-I dataset:

Step 1: Pre-processing 60.1 27.6 37.4 80.0 42.3 55.0

Step 2: Simulation I 50.5 13.2 20.5 69.5 22.5 33.6

Step 3: Simulation II 58.6 12.9 20.9 78.8 22.1 34.1

Step 4: Simulation III-3 60.2 15.2 24.1 82.0 25.8 39.0

c) SHAH-II dataset:

Step 1: Pre-processing 46.0 14.3 21.4 64.2 21.3 31.5

Step 2: Simulation I 48.9 12.4 18.8 68.2 17.2 25.9

Step 3: Simulation II 40.4 13.2 19.2 56.6 17.7 25.9

Step 4: Simulation III-3 57.8 14.2 22.3 68.0 18.5 28.4

d) SANGER dataset:

Step 1: Pre-processing 63.5 38.9 47.7 74.7 49.6 59.2

Step 2: Simulation I 60.8 32.1 41.4 71.8 40.7 51.3

Step 3: Simulation II 54.8 32.0 40.0 66.5 40.9 50.3

Step 4: Simulation III-3 57.2 30.6 39.5 68.5 39.0 49.3

In the following, we highlight interesting results

shown in Table 3. For each experiment, the ta-

ble shows precision, recall and F1-measure when

applying the evaluation procedures EXACT MATCH

(TYPE), and PARTIAL MATCH (TYPE) as described

in Section 3.4. The ﬁrst row in each section of Ta-

ble 3 (Step 1: Pre-processing) shows the performance

after ﬁltering out non-consecutive app features and re-

moving reviews that do not mention app features. For

all datasets precision is consistently better than recall

for both evaluation procedures. Partial matching, as

expected, yields better performance than exact match-

ing. The performance varies largely between datasets.

The models built using the GUZMAN and SHAH-II

datasets clearly perform worse than those built using

ICSOFT 2019 - 14th International Conference on Software Technologies

390

the SHAH-I and SANGER datasets. When looking

at the dataset characteristics, one sees the following

similarities between the datasets on which the models

perform better as compared to the datasets where the

models perform worse:

• The SHAH-I and SANGER datasets have a larger

share of single-word app features (71% and 84%)

than the GUZMAN and SHAH-II datasets (36%

and 49%).

• The SHAH-I and SANGER datasets have a lower

type-token ratio (0.31 and 0.52) than the GUZ-

MAN and SHAH-II datasets (0.74 and 0.62).

After Step 1, it seems that the language used in the

review datasets (German in the case of the SANGER

dataset and English in the case of the SHAH-I dataset)

does not have a distinguishing impact on model per-

formance. The impact of the two AGs seems to be

mixed.

Even though we used the translated SANGER

AGs when annotating the SHAH dataset, the perfor-

mances of SHAH-I-based and SHAH-II-based models

are very different. The performance of the SHAH-II-

based model is even worse than the performance of

the GUZMAN-based model where a different AG was

used. We speculated that one possible reason for the

difference in performance could be that the SANGER

AGs explicitly instruct annotating references to the

app itself as a feature. Following this instruction au-

tomatically increases the number of single-word fea-

tures and lowers the type-token ratio as the repeated

mentioning of the app itself increases the token count

but not the type count. When inspecting the SHAH-II

dataset, we noticed that the annotator seemed to have

ignored this instruction. Since the frequent annota-

tion of references to the app itself in a review seems

to artiﬁcially boost the performance of the feature ex-

traction models, while it does not have any practical

value to correctly predict the occurrence of a feature

referring to the app itself, we decided to remove the

annotations of app-references in our datasets.

The second row in each section of Table 3 (Step

2: Simulation I) shows the performance after ﬁltering

out app features referring to the app itself. Apply-

ing Step 2 simulates a change in the AGs, i.e., the

explicit mentioning that references to the app itself

should not be annotated. As can be seen in Figure

A in the Appendix

, in Step 2, all datasets have a

high type-token ratio in the range [0.68, 0.78]. All

English datasets have a low share of single-word fea-

tures in the range [35%, 38%], while the one German

dataset (SANGER) still has a relatively large portion of

single-word features (77%). As expected, all results

on datasets with previously high performance (SHAH-

I and SANGER) drop considerably, especially the re-

call on the SHAH-I dataset.

The third row in each section of Table 3 (Step 3:

Simulation II) shows the performance of our mod-

els after removing app features that do not contain

a noun. This step was motivated by the assumption

that app features not containing a noun (such as run-

ning or runs) are too unspeciﬁc to be useful for the

developers. Since the SANGER AGs instruct to anno-

tate implicit features represented by a single verb, we

expected a signiﬁcant drop of the number of app fea-

tures for the SANGER and SHAH datasets and also an

over-proportional reduction of the number of single-

word app features. Surprisingly, it turned out that

the number of app features dropped equally strongly

for the GUZMAN dataset, and for all datasets the por-

tion of single-word app features also signiﬁcantly de-

creased but not much as compared to Step 2 (Simula-

tion I), while the type-token ratio slightly increased.

The German dataset SANGER still has a high portion

of single-word app features (now 74%). The average

number of app features per review narrows down after

this step to the range [0.39,1.42] and is decreasing for

all the datasets.

Figure 1: Average f1-score for exact and partial evalua-

tion types when applying different cut-offs to the number

of words in app features.

Overall, compared to the performance obtained

after Step 2 (Simulation I), the recall remains roughly

the same for all datasets. In terms of precision, we ex-

pected it to improve. If the annotated feature set con-

tains short and vague verbal aspects that also would

be used as non-aspect terms in the text (e.g. using

or updating), it might be very difﬁcult for the model

to detect certain instances of these words as features.

Simulating the Impact of Annotation Guidelines and Annotated Data on Extracting App Features from App Reviews

391

We expected that removing such features from the an-

notated set would thus improve precision. The re-

sults show, however, that the precision increases only

on the SHAH-I dataset while on all other datasets it

dropped. This can happen if the short and vague-

meaning verbal features share the same characteris-

tics with the self-references—the distinct number of

such features is small but their frequency is high, in

which case it is relatively simple for the model to spot

them and removing these features from the annota-

tions causes the precision to drop.

The performance results shown for Steps 1 to 3

were achieved with annotations of app features (as-

pects) consisting of any number of words. Since

long aspects potentially have a negative effect on

model performance, we investigated whether impos-

ing a maximum length could achieve better perfor-

mance. Figure 1 summarizes the outcomes of our ex-

periments. For the SANGER dataset, the performance

was uniform across all choices of cutoffs. Therefore,

we only show the average performances of the three

English datasets. The two plots shown in Figure 1

show the minimum, maximum, and average F1-score

for app features containing a number of words not

greater than 1, 2, 3, 4 and with inﬁnite length. The

upper plot corresponds to exact type-based evalua-

tion, while the lower plot represents partial type-based

evaluation. In both plots, the best average perfor-

mance is achieved when the app features consisting of

more than three words are removed. The performance

of our models after limiting the number of words in

app features to a maximum of three words is shown in

the last row of each section in Table 3 (Step 4: Simu-

lation III-3). The effect on performance is uniformly

positive for all datasets. The precision for partial type-

based evaluation is in the range [68%,82%].

In summary, we can state that by simulating the

application of modiﬁed AGs we achieve a feature pre-

diction precision comparable to that received after the

application of the original GUZMAN and SANGER

guidelines. The advantage of the models created

based on annotated datasets achieved by simulating

the modiﬁed guidelines is that the predicted app fea-

tures are more useful for developers since they are

crisper (only one to three words of length) and corre-

late better with actual app features than with pseudo-

features such as references to the app itself. The new

rules included in the modiﬁed (improved) guidelines

can be summarized as follows:

• Only annotate app features consisting of consecu-

tive words;

• Do not annotate references to the app itself;

• Only annotate app features containing a noun;

• Restrict the length of the annotated app features to

maximum three words.

5 DISCUSSION

In this section, we ﬁrst explain the value of our pro-

posed new AGs. Then we discuss limitations of our

study.

5.1 Usefulness of the New AGs

The main goal of our study was to investigate the im-

pact of AGs and annotated data on extracting app fea-

tures from app reviews and to improve existing AGs

such that (1) the performance of the app feature ex-

traction task gets better in terms of f1 score and (2)

the set of extracted app features is more useful to soft-

ware developers.

Section 4 (Results) presented the step-by-step im-

pact to the performance of the app feature extrac-

tion when simulating the effects of changing the used

AGs. It turned out that with our proposed new AGs,

a small performance improvement over the baseline

situation could be achieved. However, this is not the

only advantage of our new AGs. In the following we

argue that not only the performance of the app fea-

ture extraction task can be improved but that the set

of annotated and extracted app features itself is more

relevant for software developers when using our new

AGs.

We will illustrate what we mean by “more relevant

for software developers” in two steps with the help of

examples. In the ﬁrst step, we demonstrate that the

simulated application of our new AGs actually pro-

duces an annotated dataset that contains a larger share

of annotated app features that are useful to software

developers. In the second step, we demonstrate that

this positive effect of our new AGs also propagates to

the set of extracted app features.

Table F in Appendix

shows samples of app fea-

tures in the original labeled datasets and in the anno-

tated datasets after the simulated application of our

new AGs. We randomly picked one app category

from each of the English datasets, i.e., in categories

‘Photography’ (GUZMAN), ‘Social’ (SHAH-I), and

‘Game’ (SHAH-II). We manually classiﬁed each app

feature as either ‘useful’ or ‘not useful’ and then com-

pared how the numbers of useful and not useful app

features change after simulated application of our new

AGs. Not useful app features have bold font.

We consider an app feature to be useful when it

seems to be related to actual functionality of an app.

ICSOFT 2019 - 14th International Conference on Software Technologies

392

For example capture full resolution, decorating pic-

tures and online scrapbooking seem to be clearly ref-

erencing to some functionality in the app of categories

‘Photography’ and ‘Social’. Aspects are not useful

when they are too generic to be connected with a

speciﬁc functionality (e.g., share or version 1.5.1).

As shown by the study (Groen et al., 2017), non-

functional aspects of an app (e.g, easy to use) can be

identiﬁed with high precision using language patterns.

Therefore, our concern in this study is to extract app

functional aspects.

App features in the upper part of Table F in Ap-

pendix

correspond to a random sample of those app

features that remained in the set of app features after

simulated application of the new AGs. The numbers

behind each app feature correspond to the token count

before and after the simulated application of the new

AGs. In some cases the token number changed. App

features in the lower part of Table correspond to those

app features that were completely removed from the

set of app features after simulated application of our

new AGs.

Table 4: The number of app features (type) manually classi-

ﬁed as either ‘useful’ or ‘not useful’ in app categories Pho-

tography (GUZMAN), Social (SHAH-I) and Game (SHAH-

II).

App Before/after Useful Not useful Total

category simulation features features features

Photography

Before 50 77 127

After 37 41 78

Social

Before 47 19 66

After 38 8 44

Game

Before 57 22 79

After 49 13 62

The ideal impact of the simulated application of

our new AGs corresponds to removing all useless app

features and keeping only the useful app features. We

calculated the impact of our AGs based on the num-

bers of manually classiﬁed ‘useful’ and ‘not useful’

app features in three app categories before and after

the simulation of new AGs (see Table 4). The actual

numbers (based on type count) for each of the three

apps are as follows:

• Category ‘Photography’ (GUZMAN): the percent-

age of useful app features kept equals 53%; the

percentage of useless app features removed equals

47%; the ratio between useful and useless app fea-

tures improved from 50/77=0.65 before the appli-

cation of our new AGs to 37/41=0.90 afterwards;

• Category ‘Social’ (SHAH-I): the percentage of

useful app features kept equals 77%; the percent-

age of useless app features removed equals 58%;

the ratio between useful and useless app features

improved from 47/19=2.47 before the application

of our new AGs to 36/18=4.50 afterwards;

• Category ‘Game’ (SHAH-II): the percentage of

useful app features kept equals 86%; the percent-

age of useless app features removed equals 41%;

the ratio between useful and useless app features

improved from 57/22=2.59 before the application

of our new AGs to 49/13=3.77 afterwards.

The data shows for each of the three sample cases

that the ratio between the number of useful and not

useful app features is increasing when applying our

new AGs. We computed the percentages based on

type counts of app features because there can be cases

like, for example, the app feature editing. The app

feature editing occurred 13 times in the app of cat-

egory ‘Photography’ before the simulated application

of our new AGs and ﬁve times afterwards. We assume

that eight occurrences of editing were removed due to

the guideline ‘Only annotate app features containing a

noun’, i.e., because after simulating the application of

our new AGs editing was predicted to be an app fea-

ture when it was used as a noun. Note that the word

editing when used as a verb is not helpful for software

developers because it does not provide information

about the purpose or object of editing and thus it is

difﬁcult to decide whether the mentioning of editing

is related to the edit functionality as such or just a spe-

cial situation in which something was edited. On the

other hand, if editing is mentioned in the grammati-

cal form of noun, it is more probable that whatever

is said in the sentence with the word editing refers to

the edit functionality in general. A similar case is pin-

ning mentioned in the reviews of the app in category

‘Social’. Here three of the seven original app feature

predictions disappeared after simulated application of

our new AGs.

After convincing ourselves that the simulated ap-

plication of new AGs actually results in more useful

app feature annotations, we checked whether this ef-

fect also propagates to the set of extracted app fea-

tures. Table 5 shows the impact on the number of use-

ful and useless app features in model’s extracted app

features, when training CRF models with the origi-

nal annotated datasets and when training CRF models

using the annotated datasets after the simulated appli-

cation of our new AGs. We picked the same app cat-

egories as before from each of the English datasets,

i.e., from categories ’Photography’ (GUZMAN), ’So-

cial’ (SHAH-I), and ’Game’ (SHAH-II). We manually

classiﬁed each app feature as either ’useful’ or ’not

useful’ and then compare how the numbers of use-

ful and not useful app features change when simulat-

ing the application of our new AGs. The actual type

counts for each of the three apps are:

Simulating the Impact of Annotation Guidelines and Annotated Data on Extracting App Features from App Reviews

393

• Category ‘Photography’ (GUZMAN): the ratio be-

tween useful and useless app features improved

from 21/25=0.84 before the application of our

new AGs to 17/10=1.7 afterwards;

• Category ‘Social’ (SHAH-I): the ratio between

useful and useless app features improved from

17/18=0.94 before the application of our new AGs

to 8/6=1.33 afterwards;

• Category ‘Game’ (SHAH-II): the ratio between

useful and useless app features improved from

11/21=0.52 before the application of our new AGs

to 13/14=0.93 afterwards.

Table 5: Model’s extracted app features (type) are manu-

ally classiﬁed as either ‘useful’ or ‘not useful’ in app cate-

gories Photography (GUZMAN), Social (SHAH-I) and Game

(SHAH-II), before and after the simulation of AGs.

App Before/After Useful Not useful Total

category simulation features features features

Photography

Before 21 25 46

After 17 10 27

Social

Before 17 18 35

After 8 6 14

Game

Before 11 21 32

After 13 14 27

Figure 2 summarizes our results and expectations

with regards to the effectiveness of our new AGs

(based on type-wise analysis of the three selected app

categories). Each of the six rectangles corresponds to

the total set of annotated (upper row) and extracted

(lower row) app features. The blue portion in each

rectangle corresponds to the share of useful app fea-

tures (UFs) while the orange portion corresponds to

the share of useless app features (¬UFs). The calcu-

lated ratios between UFs and ¬UFs clearly show an

improvement for the simulated application of our new

AGs not only in the annotated datasets but also in the

set of extracted features. This strengthens our expec-

tation that a real application of the new AGs, which

presumably yields exclusively useful features in the

annotated dataset (thus an exclusively blue rectangle

on the right in the upper row of Figure 2) would result

in an even further improved ratio between UFs and

¬UFs in the set of extracted app features when com-

paring to the baseline and the simulated application

of our new AGs (as indicated by the small portion of

orange in the rectangle on the right in the lower row

of Figure 2).

5.2 Limitations of the Study

In some cases it is not fully clear why an app fea-

ture was removed or kept. These cases could be due

to inaccuracies of the POS tagger used in Step 2 of

Figure 2: Ratios between useful and not useful app features

(annotated and extracted) for three analyzed app categories.

the simulated application of our new AGs. For exam-

ple, it is unclear why only two out of three occasions

of free were removed in category ‘Photography’ as it

is hard to imagine a context in which free could be

considered to be a noun in a review text. Overall,

our new AGs removed most of the useless app fea-

tures in app categories ‘Social’ (SHAH-I) and ‘Game’

(SHAH-II). When removing the not useful app fea-

tures, the lower performance (53%) on app category

‘Photography’ (GUZMAN) is due to a large number of

annotations referring to mobile devices, app versions,

app updates and non-functional app features.

Note that we only simulated the application of

our new AGs on the labeled datasets. We expect

that the application of the new AGs by actual peo-

ple could have resulted in more useful annotations of

app features in the ﬁrst place. The application of our

new AGs automatically removes app features that are

longer than 3-words. However, in the direct appli-

cation of our new AGs, a longer app feature might

simply have been annotated with fewer words rather

than completely been removed as we did in Simula-

tion Step 3. For instance, a 5-word app feature sorting

functionality in board section annotated in app cate-

gory ‘Social’ of the SHAH-I dataset could be labeled

as an admissible 2-word app feature sorting function-

ality.

Our study is restricted to the use of the CRF model

which limits app features to be annotated as consec-

utive words. Therefore, when limiting annotations to

a maximum 3-word app features, it might be impos-

sible to annotate app features consisting of consecu-

tive words; in such cases CRF (or any other sequences

tagging model) cannot be applied or we would have to

drop those app features (or soften the rule of having

maximum 3-words app features). For instance, a 5-

word app feature edit pictures in a high quality can

be reduced to the following two meaningful represen-

tations of 3-word app features: edit high quality or

edit picture quality. However, both 3-word app fea-

ture representations are not consecutive.

We only found two published AGs associated with

publicly available annotated app review datasets. The

ICSOFT 2019 - 14th International Conference on Software Technologies

394

problem we encounter is that either annotated datasets

were not published or when they had been pub-

lished it is unclear what annotation rules/guidelines

were applied. In other domains, e.g., LAPTOP and

RESTAURANT, the standard guidelines and bench-

mark datasets are contributed by the research com-

munity SEMEVAL to perform the task of product

feature extraction and its evaluation. Similar to the

SEVEMAL research community, the app review min-

ing research community could contribute standard-

ized guidelines and benchmark datasets to help re-

searchers in the development of systems performing

ﬁne-grained sentiment analysis at app feature-level.

We created two new labeled datasets SHAH-I and

SHAH-II in English, using the English translated ver-

sion of the German SANGER AGs. The translation

from German to English of SANGER guidelines is

performed using Google translation service. In or-

der to make sure that the translated guidelines have

sufﬁcient quality to be used for the annotation of re-

views in English language, one of the author of this

paper, who is a native German speaker and have a full

command of the English language, read the English

translated version of the AGs and found it adequately

accurate for the annotation task.

The validity of our results depends partly on

the reliability of the annotations of the SHAH-I and

SHAH-II datasets. In addition, the assessment of the

usefulness of the results produced when using our

simulated AGs depends on the reliability of the sub-

jective classiﬁcation of annotated and extracted app

features into ‘useful’ and ‘not useful’. Since each

of these tasks was performed by one person, relia-

bility might be limited. However, since we not only

used our own annotations (i.e., datasets SHAH-I and

SHAH-II) but applied our analyses also to datasets

published in the literature and the trend of our results

was similar for all our used datasets, we believe that

the existing limitations of reliability for the mentioned

tasks is not a major threat to validity of our results.

6 CONCLUSION

Previously, several techniques have been used for

automatic app feature extraction from app re-

views, including (a) unsupervised topic modeling,

(b) rule-based methods, (c) supervised machine learn-

ing approaches. While unsupervised and rule-based

approaches only require annotated data for evaluation

purposes, supervised machine learning methods also

need it for training the model. In either case, the qual-

ity of the annotations can considerably affect the eval-

uation results. When the annotations contain many

complex app features that are difﬁcult to extract, then

model performance will be artiﬁcially low, especially

when these features are infrequent and thus not of

much actual interest for app developers. On the other

hand, when the annotations contain many short and

frequent app features that are easy to detect but not

informative for developers then model performance

will be artiﬁcially high.

In this paper, we study the impact of AGs by con-

trolling other design parameters as much as possi-

ble. We used four different labeled datasets annotated

with two different AGs. For the app feature extraction

technique we adopted the supervised CRF method. To

our best knowledge, this is the ﬁrst study that explores

the impact of AGs and labeled datasets for app fea-

ture extraction from user reviews. As a result of our

study, we propose several changes to the existing AGs

to avoid the annotation of useless app features.

Our research question RQ started from the obser-

vation that the app feature annotations and thus subse-

quently also automatic feature extraction results var-

ied considerably on different datasets, even though

they used the same AGs to annotate the app features

and even when the annotated app reviews themselves

were identical (SHAH-I vs SHAH-II). We hypothe-

sised that these differences are at least partly due to

the AGs that were used to label these datasets. We

proposed several changes to the AGs and evaluated

the effect of their simulated application using the eval-

uation results of the CRF modeling. The proposed

changes in AGs include (a) instructing to annotate

only consecutive words as app features, (b) discour-

aging the annotations to the references of the app it-

self, (c) instructing to annotate only noun phrases as

app features, i.e. every app feature must contain a

noun, and (d) instruct to annotate app features with

the length of maximum three words. When simulat-

ing the application of our AGs, we were able to retain

the precision of the app feature extraction. Moreover,

the annotated features in both training and test sets

become more informative and less noisy.

The main limitation of our study is the simulation

of the new AGs on the labeled review datasets which

resulted in removing a number of app features rather

than reformulating them according to the new guide-

lines. Regardless of that, we believe that the real ap-

plication of the new AGs by human annotators would

have produced a set of app features that are useful and

refer to the functional aspects of an app. However,

this hypothesis is yet to be conﬁrmed by evaluating

the proposed AGs by giving them to real human an-

notators for labeling app features in user reviews.

Simulating the Impact of Annotation Guidelines and Annotated Data on Extracting App Features from App Reviews

395

ACKNOWLEDGMENTS

We are grateful to Emitza Guzman and Mario Sanger

for sharing their review datasets. This research was

supported by the institutional research grant IUT20-

55 of the Estonian Research Council and the Estonian

Center of Excellence in ICT research (EXCITE).

REFERENCES

Blei, D. M., Ng, A. Y., and Jordan, M. I. (2003). Latent

dirichlet allocation. Journal of machine Learning re-

search, 3(Jan):993–1022.

Collobert, R., Weston, J., Bottou, L., Karlen, M.,

Kavukcuoglu, K., and Kuksa, P. (2011). Natural lan-

guage processing (slmost) from scratch. Journal of

Machine Learning Research, 12(Aug):2493–2537.

Groen, E. C., Kopczyska, S., Hauer, M. P., Krafft, T. D.,

and Doerr, J. (2017). Users the hidden software prod-

uct quality experts?: A study on how app users re-

port quality aspects in online reviews. In 2017 IEEE

25th International Requirements Engineering Confer-

ence (RE), pages 80–89.

Guzman, E., Aly, O., and Bruegge, B. (2015). Retrieving

diverse opinions from app reviews. In Proceedings of

ESEM’15, pages 1–10. IEEE.

Guzman, E. and Maalej, W. (2014). How do users like

this feature? a ﬁne grained sentiment analysis of app

reviews. In Proceedings of RE’14, pages 153–162.

IEEE.

Johann, T., Stanik, C., B., A. M. A., and Maalej, W. (2017).

Safe: A simple approach for feature extraction from

app descriptions and app reviews. In Proceedings of

RE’17, pages 21–30. IEEE.

Kang, Y. and Zhou, L. (2017). Rube: Rule-based methods

for extracting product features from online consumer

reviews. Information & Management, 54(2):166–176.

Keertipati, S., Savarimuthu, B. T. R., and Licorish, S. A.

(2016). Approaches for prioritizing feature improve-

ments extracted from app reviews. In Proceedings of

EASE’16, page 33. ACM.

Kurtanovi

c, Z. and Maalej, W. (2017). Automatically clas-

sifying functional and non-functional requirements

using supervised machine learning. In Proceedings

of RE’17, pages 490–495. IEEE.

Lafferty, J., McCallum, A., and Pereira, F. (2001). Con-

ditional random ﬁelds: Probabilistic models for seg-

menting and labeling sequence data. In Proceedings

of ICML’01, pages 282–289.

Liu, P., Joty, S. R., and Meng, H. M. (2015). Fine-grained

opinion mining with recurrent neural networks and

word embeddings. In Proceedings of EMNLP’15,

pages 1433–1443.

Lu, M. and Liang, P. (2017). Automatic classiﬁcation

of non-functional requirements from augmented app

user reviews. In Proceedings of EASE’17, pages 344–

353. ACM.

Luiz, W., Viegas, F., Alencar, R., Mour

ao, F., Salles,

T., Carvalho, D., Gonc¸alves, M. A., and Rocha,

L. (2018). A feature-oriented sentiment rating for

mobile app reviews. In Proceedings of WWW’18,

pages 1909–1918, Republic and Canton of Geneva,

Switzerland. International World Wide Web Confer-

ences Steering Committee.

Maalej, W., Nayebi, M., Johann, T., and Ruhe, G. (2016).

Toward data-driven requirements engineering. IEEE

Software, 33(1):48–54.

Malik, H., Shakshuki, E. M., and Yoo, W.-S. (2018). Com-

paring mobile apps by identifying hot features. Future

Generation Computer Systems.

Mikolov, T., Sutskever, I., Chen, K., Corrado, G. S., and

Dean, J. (2013). Distributed representations of words

and phrases and their compositionality. In Proceed-

ings of NIPS’13, pages 3111–3119.

Pagano, D. and Maalej, W. (2013). User feedback in the

appstore: An empirical study. In Proceedings of

RE’13, pages 125–134. IEEE.

Panichella, S., Di Sorbo, A., Guzman, E., Visaggio, C. A.,

Canfora, G., and Gall, H. C. (2015). How can i im-

prove my app? classifying user reviews for software

maintenance and evolution. In Proceedings of IC-

SME’15, pages 281–290. IEEE.

Pavlopoulos, J. and Androutsopoulos, I. (2014). Aspect

term extraction for sentiment analysis: New datasets,

new evaluation measures and an improved unsuper-

vised method. In Proceedings of the 5th Workshop on

Language Analysis for Social Media, pages 44–52.

Pontiki, M., Galanis, D., Papageorgiou, H., Androutsopou-

los, I., Manandhar, S., AL-Smadi, M., Al-Ayyoub,

M., Zhao, Y., Qin, B., De Clercq, O., et al. (2016).

Semeval-2016 task 5: Aspect based sentiment anal-

ysis. In Proceedings of SemEval’16, pages 19–30.

ACL.

Poria, S., Cambria, E., and Gelbukh, A. (2016). Aspect ex-

traction for opinion mining with a deep convolutional

neural network. Knowledge-Based Systems, 108:42–

49.

anger, M., Leser, U., Kemmerer, S., Adolphs, P., Klinger,

R., Calzolari, N., Choukri, K., Declerck, T., Grobel-

nik, M., and Maegaard, B. (2016). Scare-the senti-

ment corpus of app reviews with ﬁne-grained annota-

tions in german. In Proceedings of LREC’16.

Shah, F. A., Sabanin, Y., and Pfahl, D. (2016). Feature-

based evaluation of competing apps. In Proceedings of

the International Workshop on App Market Analytics,

pages 15–21. ACM.

Vu, P. M., Nguyen, T. T., Pham, H. V., and Nguyen,

T. T. (2015). Mining user opinions in mobile app re-

views: A keyword-based approach. In Proceedings of

ASE’15, pages 749–759. IEEE.

Zamani, S., Lee, S. P., Shokripour, R., and Anvik, J.

(2014). A noun-based approach to feature location us-

ing time-aware term-weighting. Information and Soft-

ware Technology, 56(8):991–1011.

Zhang, L. and Liu, B. (2014). Aspect and entity extraction

for opinion mining. In Data Mining and Knowledge

Discovery for Big Data, pages 1–40. Springer.

ICSOFT 2019 - 14th International Conference on Software Technologies

396
