OC-ORAM: Constant Bandwidth ORAM with Smaller Block Size using

Oblivious Clear Algorithm

Linru Zhang

, Gongxian Zeng

, Yuechen Chen

, Nairen Cao

, Siu-Ming Yiu

and Zheli Liu

Department of Computer Science, The University of Hong Kong, HKSAR, China

Department of Computer Science, Georgetown University, U.S.A.

College of Computer and Control Engineering, Nankay University, Tianjin, China

Keywords:

ORAM, Constant Communication Overhead, Oblivious Clear Algorithm.

Abstract:

Oblivious RAM has been studied extensively. A recent direction is to allow the server to perform computations

instead of being a storage device only. This model substantially reduces the communication between the server

and the client, making constant bandwidth communication (the number of blocks transmitted) feasible. It is

obvious that the larger the block size, the easier it is to construct a constant bandwidth ORAM scheme. Also, a

lower bound of sub-logarithmic bandwidth was given if we do not use expensive homomorphic multiplications.

The question of “whether constant bandwidth with smaller block size without homomorphic multiplications

is achievable” remains open. In this paper, we show that the block can be further reduced to O(log

N) using

only additive homomorphic operations. Technically, we design a non-trivial oblivious clear algorithm with

very small bandwidth to improve the eviction algorithm in ORAM for which the lower bound proof does not

apply. As an additional beneﬁt, we are able to reduce the server storage due to the reduction in bucket size.

1 INTRODUCTION

Oblivious RAM (ORAM) is a block-based storage

structure together with a series of algorithms, which

allows a client to outsource storage to an untrusted

server, while the server learns nothing about the

client’s access pattern, i.e., the sequence of data

blocks actually accessed by the client. It is one of ef-

ﬁcient approaches to protect access pattern(di Vimer-

cati et al., 2011; di Vimercati et al., 2016). The con-

cept of ORAM, with a hierarchical structure, was ﬁrst

proposed by Goldreich (Goldreich and Ostrovsky,

1996). Several works of hierarchical structure(Boneh

et al., 2011; Goldreich, 1987; Goodrich and Mitzen-

macher, 2011; Goodrich et al., 2011; Goodrich et al.,

2012; Lu and Ostrovsky, 2013; Williams and Sion,

2012) have been proposed to improve the efﬁciency of

ORAM. However, hierarchical structure has a draw-

back of poor worst-case efﬁciency. A breakthrough

came from the novel tree-based structure proposed by

Shi et al. (Shi et al., 2011), which was further im-

proved by many subsequent works (e.g. (Chung et al.,

2014; Gentry et al., 2013; Stefanov et al., 2013)). In

this tree-based structure, the server storage is treated

as a binary tree in which each node is a bucket that

can hold up to a ﬁxed number of blocks. It contains

an access algorithm to fetch the required block and an

eviction algorithm to reshufﬂe the data blocks from

the root to the leaves. Tree-based ORAM avoids the

high worst-case cost of the hierarchical ORAM and

achieves better efﬁciency.

The original ORAM model assumes that the

server acts as a storage device that only allows the

client to read and write. Under this model, re-

searchers focus on improving the bandwidth overhead

(the amount of communication between the client and

the server to serve a client request) from O(log

N) to

O(logN) (Path ORAM (Stefanov et al., 2013)) where

N is the number of data blocks. However, due to

the simple server setting, constant or sub-logarithmic

bandwidth seems not achievable.

Server-with-Computation ORAM. In order to over-

come this bandwidth barrier, Mayberry et al. (May-

berry et al., 2014) proposed a new model that allows

the server to perform some computations. The new

model is widely used in cloud setting. In this model,

the computations are outsourced to the server. And

the client just sends messages to drive the compu-

tations and retrieve the required blocks. Intuitively,

the client can instruct the server to “compress” all

transmitted blocks and “hide” the required blocks in-

side before sending over to decrease the bandwidth.

Zhang, L., Zeng, G., Chen, Y., Cao, N., Yiu, S. and Liu, Z.

OC-ORAM: Constant Bandwidth ORAM with Smaller Block Size using Oblivious Clear Algorithm.

DOI: 10.5220/0007924701490160

In Proceedings of the 16th International Joint Conference on e-Business and Telecommunications (ICETE 2019), pages 149-160

ISBN: 978-989-758-378-0

149

But then at least one data block B must be returned

from the server to the client. If we use the number of

blocks to evaluate the bandwidth of ORAM schemes,

constant bandwidth (i.e., O(1) blocks) is the natu-

ral target. The size of a block, |B|, becomes an is-

sue. The client sends instructions to drive operations

on server. Aiming for obliviousness, each instruction

should drive actions on all blocks in one path. So the

size of an instruction is always related to the number

of blocks in one path (i.e., related to the number of

blocks in one bucket times the number of buckets).

When considering constant bandwidth, the size of in-

structions should be bounded by the block size |B|.

The larger the bucket size, the larger block size it is.

Under this model, Devadas et al. (Devadas et al.,

2016) proposed a tree-based Onion ORAM scheme

that achieves O(1) communication overhead (con-

stant number of blocks) by applying homomorphic

multiplications, but it requires a large block size of

O(log

N) to bound all intermediate transmitted mes-

sages. An open question is how small a block of an

ORAM scheme can be while still achieving constant

bandwidth.

Two improved schemes C-ORAM and CHf-

ORAM were proposed. C-ORAM was proposed by

Moataz et al. (Moataz et al., 2015b) to improve the

block size to O(log

N) while keeping O(1) com-

munication overhead in the worst case and it only

needs additively homomorphic operation and Private

Information Retrieval (PIR) operation. CHf-ORAM

(Moataz et al., 2015a) also claimed to achieve O(1)

bandwidth overhead with even smaller block size of

O(log

N) using simple XOR-based PIR and four

non-colluding servers. However, (Abraham et al.,

2017) found security ﬂaws in both CHf-ORAM and

C-ORAM. The eviction algorithms in their schemes,

which push all blocks from one bucket to its two chil-

dren, cause a leakage of buckets’ distribution by ob-

serving the behaviour of several evictions. (Abra-

ham et al., 2017) later derived a Ω(log

N) band-

width lower bound for the ORAM model with PIR

and PIR-write operations. Here, c is the stash size in

the client side and D is the number of blocks on which

PIR read/write operations are performed. Practically,

c and D can be set to O(logN), i.e., the lower bound

can be interpreted as Ω(

logN

loglogN

), which implies that,

in such a model, sub-logarithmic bandwidth is achiev-

able but constant bandwidth seems still impossible.

Very recently, a new distributed tree-based ORAM

scheme (S

ORAM) was proposed (Hoang et al.,

2017) which achieves O(1) client-server bandwidth.

ORAM does not rely on the direct computation of

PIR, so the lower bound in (Abraham et al., 2017)

does not apply. Technically, it uses Shamir Secret

Sharing along with a secure multi-party multiplica-

tion protocol using more than one server to perform

the eviction operations in Onion ORAM in a more ef-

ﬁcient way. It is a breakthrough to use more than one

server to reduce the communication bandwidth and

further reduce the block size. Based on the communi-

cation analysis of (Hoang et al., 2017)

, we conclude

that the block size is O(log

N), and at least 3 servers

are needed.

An open problem is whether the block size (the

best result is O(log

N)) can be further reduced while

maintaining constant bandwidth. Additionally, notice

that all schemes (Devadas et al., 2016; Moataz et al.,

2015b; Abraham et al., 2017; Hoang et al., 2017;

Moataz et al., 2015a) use the same eviction strategy,

which leads to O(log N) bucket size. So the total

server storage in these schemes is O(N logN) blocks.

Whether the server storage can be reduced (the lower

bound should be O(N)) is another open question.

1.1 Our Contributions

Over the past four years, researchers have come a

long way to achieve constant bandwidth and reduce

the block size in the new server-with-computation

ORAM model. (Devadas et al., 2016) introduces an

eviction algorithm, which ﬁrst pushes all useful (real)

blocks down on a chosen path from the root to the

leaf node and then clears all the noisy blocks on the

path except the leaf node. All previous works(Moataz

et al., 2015b; Moataz et al., 2015a; Hoang et al., 2017)

try to apply several technologies (PIR, Secret Shar-

ing) to perform the eviction algorithm in (Devadas

et al., 2016) more efﬁciently, but none of them try

to improve the eviction algorithm itself. On the other

hand, we notice that such an eviction algorithm causes

a large bucket size (O(log N)), which would ﬁnally

cause a ‘log N’ factor in both block size and server

storage. To further reduce the block size for constant

bandwidth, we need to solve two problems: (i) de-

The client-server communication complexity

in (Hoang et al., 2017) is at least O(|B| + (H +

1)(2Z

dlog

pe)), where |B| is the size of block,

H = O(log N) is the height of binary tree, Z = O(log N)

is the bucket size and p is a prime used in Shamir Se-

cret Sharing. Note that when B is larger than dlog

pe,

the client would split the data into equal-sized chunks.

While each block B should contain an index and the

size of the index is O(logN), dlog

pe times the number

of chunks should be at least O(log N). The paper does

not count the number of chunks into bandwidth analysis

(i.e., it is viewed as a constant). Actually, the dlog

parts in its analysis means dlog

pe times the number of

chunks. Combining this parameters together, we can get

|B| ∈ O(|B| +(H +1)(2Z

dlog

pe)) = O(log

N).

SECRYPT 2019 - 16th International Conference on Security and Cryptography

150

riving an improved eviction strategy; and (ii) bypass-

ing the lower bound barrier in (Abraham et al., 2017).

The followings show how we tackle these two prob-

lems. By combining these two solutions, we come

up with a novel two-server oblivious clear protocol

which is the core component of our proposed OC-

ORAM scheme.

1) Deriving an Improved Eviction Strategy. We

propose a high-level idea that just moves some blocks

from one bucket to one of its child when doing evic-

tion, instead of pushing all blocks in one bucket to

its two children. Then O(1) bucket size is proved

large enough to achieve negligible overﬂow probabil-

ity. However, some “useless” blocks will reside in the

same buckets with “useful” blocks, which will occupy

the bucket’s space and result in failure if we do not

clear them. Thus, we need a new noise-clearing algo-

rithm that supports oblivious clearing of the “useless”

slots.

2) Bypassing the Lower Bound Barrier. Recall

that the lower bound in (Abraham et al., 2017) is

derived by computing the number of operations (read,

write, PIR-read and PIR-write). So this lower bound

is on the number of operations. Under the condition

that each of the 4 kinds of operations results in

at least 1 block’s bandwidth, the lower bound on

the number of blocks is equal to the lower bound

on the number of operations. If we can overcome

the constraint that each operation corresponds to at

least 1 block of bandwidth, it is possible to achieve

constant bandwidth while using logarithmic number

of operations. More precisely, if we can have a new

operation OP with bandwidth V < O(

log

) blocks,

by calling this operation frequently (O(logN) times)

constant bandwidth is achievable.

Combining the two ideas, we introduce a Two-

server Oblivious Clear Protocol (2SOC Protocol).

1) The bandwidth overhead of this protocol is V =

O(logN +|M |) bits, where |M | is the length of plain-

text. It will be proved later that such bandwidth is ob-

vious smaller than O(

log

) blocks. 2) 2SOC Proto-

col can be used in ORAM scheme to clear the ‘use-

less’ blocks. So our improved eviction algorithm can

be performed efﬁciently.

Applying this algorithm, we propose a new

ORAM scheme achieving O(1) bandwidth overhead.

Compared with the existing secure constant commu-

nication construction Onion ORAM(Devadas et al.,

2016) and S

ORAM(Hoang et al., 2017), our scheme

only requires a block size of O(log

N) with a small

constant factor. Different from others, we focus on

improving the eviction algorithm to reduce the bucket

size. It brings another beneﬁt that the server side

storage is reduced to O(N) blocks. Table 1 summa-

rizes our improvements when compared to existing

schemes in server-with-computation model. Note that

besides reducing the block size, we achieve the opti-

mal server storage, which closes the gap between the

upper bound and the lower bound.

The following summarizes our contributions in

the paper:

– We propose a novel 2-server oblivious clear proto-

col based on two non-colluding servers. It brings

a new idea to update bucket’s content without

downloading any block to the client. This clear

algorithm can be regarded as the new operation

with O(1) bandwidth.

– We propose an efﬁcient new constant ORAM

scheme (OC-ORAM) based on the clear algo-

rithm with the properties described in Theorem 1.

We believe that the block size we achieved is the

lowest possible with existing additive homomor-

phic encryption schemes since all these schemes

require a block size of at least O(log

N). We re-

mark that we can also achieve optimal server stor-

age of O(N).

Theorem 1. To outsource N blocks with block

size B = O(γ) database, where γ is a security pa-

rameter of encryption scheme, OC-ORAM is se-

cure under the standard model, and costs O(1)

blocks bandwidth, O(N) blocks server storage,

O(logN) client storage, and achieves negligible

failure probability in N.

2 PRELIMINARIES

2.1 ORAM Basics

We now present the basics of ORAM, to illustrate its

important features.

We build on the tree-based ORAM framework of

(Shi et al., 2011), which organizes server storage as a

binary tree of nodes. In all tree-based ORAMs, each

block is mapped to a random path and each block can

only live in a bucket along that path or in client side

at any time. The client maintains a local position map

to store the path mapped to each block. In most cases,

there is a stash in the client side, which is used to store

the blocks returned by the server temporarily.

When blocks are added to the ORAM, they start at

the root of the tree. As access operations continue, the

ORAM needs an eviction process that pushes blocks

OC-ORAM: Constant Bandwidth ORAM with Smaller Block Size using Oblivious Clear Algorithm

151

Table 1: Comparison with existing sever-with-computation ORAM schemes.

Scheme

Bandwidth

overhead

total # of bits

(bandwidth)

Block size

(bits)

Server

storage

# of

servers

Secure?

Onion ORAM O(1) O(log

N) O(log

N) O(N log N) 1 Yes

C-ORAM O(1) O(log

N) O(log

N) O(N log N) 1 No

CHf-ORAM O(1) O(log

N) O(log

N) O(N log N) 4 No

ORAM in (Abraham et al., 2017) O(

logN

loglogN

) O(

log

loglogN

) O(log

N) O(N log N) 2 Yes

ORAM O(1) O(log

N) O(log

N) O(N log N) ≥ 3 Yes

OC-ORAM O(1) O(log

N) O(log

N) O(N) 2 Yes

towards their tagged leaves. Usually, this is accom-

plished by picking a path in the tree and pushing all

the blocks on that path as far as possible towards the

leaf node.

To avoid incurring large client storage, the posi-

tion map should be recursively stored in other smaller

ORAMs (Shi et al., 2011). When the data block size

is Ω(log

N) bits for an N block ORAM (which is the

case for our result), the asymptotic costs of recursion

are insigniﬁcant relative to the main ORAM(Stefanov

et al., 2013). So we no longer consider the bandwidth

cost of recursion in the rest of the paper.

We show the deﬁnition of Access Pattern and se-

curity of ORAM refer to (Stefanov et al., 2013)

Deﬁnition 1. Access Pattern: Let A(~y) denote the

sequence of access to the remote server storage given

the data request sequence ~y from client. Speciﬁcally,

~y = {(op

,data

),..., (op

,data

)}, L

= |~y|,

and op

denotes a operation of either read(a

) or

write(a

,data

). In addition, a

is logical identiﬁers

of the block.

Deﬁnition 2. Security Deﬁnition: An ORAM con-

struction is said to be secure if (1) Correctness the

ORAM construction is correct in the sense that it re-

turns correct results for any input ~y with probability

≤ 1 − negl(|~y|). (2) Security For any two data re-

quests~y and~z of the same length, their access patterns

A(~y) and A(~z) are computationally indistinguishable

by anyone but the client.

2.2 Private Information Retrieval

Private information retrieval (PIR) is a useful tool

that allows the client to retrieve one data block from

an unprocessed database known to a server, reveal-

ing nothing to the server about which block is down-

loaded(Chor et al., 1995). There are two categories

of PIR algorithms: one processes database in a sin-

gle server and the other assumes the existence of at

least two non-colluding servers. Single server PIR

algorithms(Cachin et al., 1999; Gentry and Ramzan,

2005; Kushilevitz and Ostrovsky, 1997) designed by

applying homomorphic encryption have been used

in (Devadas et al., 2016; Moataz et al., 2015b) to

reduce bandwidth overhead. PIR on two or more

non-colluding servers is based on very simple oper-

ations such as XOR operation, which has been used

in (Moataz et al., 2015a). In this paper, we will use a

variant of two-server PIR and we will show the details

in Section 4.

3 A NEW EVICTION AND CLEAR

ALGORITHM

In this section, we propose the formal deﬁnition of the

Two-Server Oblivious Clear Protocol (2SOC Proto-

col) we used to achieve constant bandwidth, together

with the security deﬁnition. The concrete construc-

tion will be introduced in the next section.

3.1 Intuition of the Algorithm

We introduce how this algorithm comes up when con-

sidering how to derive new eviction algorithm and re-

duce the buckets’ load.

Aiming for O(1) bucket size, inspired by

Path ORAM(Stefanov et al., 2013) and Circuit

ORAM(Wang et al., 2015), we propose a new evic-

tion algorithm that just move some blocks (at most 1

block from each bucket) to one of its child along the

eviction path. However, after this eviction, the real

blocks and noisy blocks will reside in the same buck-

ets on the path. So we cannot directly clear all the

buckets as in (Moataz et al., 2015b). Therefore, we

design a new algorithm that supports oblivious clear-

ing of the noisy blocks while keeping other’s plaintext

unchanged

. It is obvious that this algorithm could

change the system states while being hidden from the

server and can be performed frequently, so it can be

Oblivious clearing means that change the data in the

slot into Enc(0), and keeping other unchanged means that

re-encrypt the data in the slots.

SECRYPT 2019 - 16th International Conference on Security and Cryptography

152

used to overcome the limitation of the lower bound

proof if we can realize it with small bandwidth.

This clear algorithm can be easily realized if fully

homomorphic encryption (FHE) is used to encrypt

data. We can send a sequence of Enc(0) and Enc(1),

where each Enc(0) is corresponding to the noisy

block and Enc(1) is corresponding to the real block.

However, FHE is too expensive and far from practical.

When considering only use additively homomorphic

encryption (AHE), we ﬁnd that it is hard to achieve.

Inspired by (Catalano and Fiore, 2015), we use

two non-colluding servers A and B to design our algo-

rithm. Novelly, we store an encryption of m on server

A and an encryption of −m on server B, where m is the

data of one block. Then, by multiplying same coefﬁ-

cient k on m, −m and summing them up we can get 0.

And by multiplying different coefﬁcient k, k −1 on m,

−m and summing them up we can get m. Addition-

ally, in order to preserve obliviousness, the message

sent by the client to drive the clear operation should

not leak any information about which block is cleared.

Based on the above ideas, we store Enc(x), m + x

on server A and Enc(y), −m + y on server B, where

x,y are two random numbers and Enc is an AHE. As

proved in (Catalano and Fiore, 2015), as long as A

and B are non-colluding, each server cannot recover

m. For each noisy block, the client sends the same

random numbers (k

) to A and B, then A will get

Enc(k

(x + y)),k

(x + y) and B will get Enc(k

(x +

y)),k

(x + y), both of which can be viewed as an en-

cryption of 0. For each real block, the client sends

− 1) to A and (k

− 1,k

) to B, then A will get

Enc(k

x + (k

− 1)y),m + k

x + (k

− 1)y and B will

get Enc(k

y + (k

− 1)x),−m + k

y + (k

− 1)x, both

of which can be viewed as a re-encryption of m.

Now, we can present our 2-server oblivious clear

protocol. This protocol can be applied to a two-server

model and achieve the function that obliviously clears

noisy blocks for one bucket with small bandwidth.

3.2 Algorithm and Security Deﬁnition

Here comes the deﬁnitions of 2SOC Protocol.

Deﬁnition 3. A protocol for two-server oblivi-

ous clear protocol is a tuple of algorithms based

on the a public key encryption scheme P K E =

(Setup, Encrypt, Decrypt). It takes as input a bit b

from the client. The protocol works as follows:

KeyGen(1

): the key generation algorithm takes

the security parameter λ and outputs a secret key sk

and a public key pk by running P K E.Setup(1

The algorithm generates an operation sequence OP =

{op

,...,op

} and sends it to two servers.

Encrypt(m,pk): the encryption algorithm takes

as input pk and a message m ∈ M . It outputs two

ciphertexts C

(1)

= P K E.Encrypt(pk, f

(m,r

)) and

(2)

= P K E .Encrypt(pk, f

(m,r

)), where f

, f

M × R → M are two transformation functions and

R is the randomness space.These two ciphertexts are

stored in two servers respectively.

VecGen(b,pk): the vector generation algorithm

takes as input the bit b. If b = 0, then the algorithm

generates (V

(1)

(2)

) that supports the clear noisy op-

eration. Else if b = 1, then the algorithm generates

(1)

(2)

) for the keep real operation. Finally, the

algorithm sends V

(1)

and V

(2)

to two servers respec-

tively.

Clear Noisy: For i ∈ 1, 2, server i performs

(op

,...,op

) ∈ OP in sequence with the inputs

(i)

and V

(i)

, and outputs a new ciphertext C

(i)

P K E.Encrypt(pk, f

(0,r

)).

Keep Real: For i ∈ 1, 2, server i performs

(op

,...,op

) ∈ OP in sequence with the inputs

(i)

and V

(i)

, and outputs a new ciphertext C

(i)

P K E.Encrypt(pk, f

(m,r

)).

Informally, a 2SOC protocol should guarantee that

any adversary who has access to the pair (C

(i)

i = 1 or 2 should not learn anything about both the

plaintext and the value of b. We formalize this prop-

erty using the approach of indistinguishable security.

Deﬁnition 4. (2SOC Indistinguishable Security) Let

2SOC be a 2SOC protocol as deﬁned above, and A be

a PPT adversary. Consider the following experiment:

Experiment Exp

2S.IND

2SOC,A

(λ)

(pk, sk) ← 2SOC.KeyGen(1

)

(m,i) ← A(pk)

(1)

(2)

) ← 2SOC.Encrypt(pk, m)

(1)

(2)

) ← 2SOC.VecGen(b, pk)

T M

(1)

← 2S

(1)

); T M

(2)

← 2S

(2)

)

← A(C

(i)

,T M

(1)

,T M

(2)

)

If b

= b return 1. Else, return 0.

T M

(1)

,T M

(2)

is the transformation messages(if any)

between two servers to complete the clear noisy

or keep real operation. 2S

means the protocol

performing ‘clear noisy’ operation and 2S

means

the protocol performing ‘keep real’ operation. Let

Adv

2S.IND

2SOC,A

(λ) = Pr[Exp

2S.IND

2SOC,A

(λ)] −

. We say that

2SOC is IND secure if for any PPT A it holds

Adv

2S.IND

2SOC,A

(λ) = negl(λ).

By using 2SOC protocol, we can design a new

eviction algorithm to reduce bucket size. The con-

structions of 2SOC and OC-ORAM will be shown in

section 4. We will discuss how 2SOC bypasses the

lower bound.

OC-ORAM: Constant Bandwidth ORAM with Smaller Block Size using Oblivious Clear Algorithm

153

4 OUR CONSTRUCTION

In this section, we will show the construction of 2SOC

protocol and our ORAM scheme. Intuitively, 2SOC

protocol is used to clear the noisy blocks in buck-

ets after eviction. When considering the security of

ORAM scheme, the server cannot distinguish which

block is noisy. So the 2SOC protocol should be IND-

secure (deﬁned in Deﬁnition 4). More precisely, for

a bucket D, a clear vector W

is needed, and each

item w

∈ W

is corresponding to a data block b

D. After some computations between w

and b

, the

data block is either cleared or re-encrypted. The dif-

ferent parts of the vector W

should be indistinguish-

able to any adversary. We will ﬁrst show our over-

all OC-ORAM construction and then follow by the

2SOC protocol construction.

4.1 OC-ORAM Construction

Our ORAM builds on the tree-based ORAM frame-

work and shares many similar features with most tree-

based constructions.

Stash. When the client reads or writes a block, this

block will be added into the stash. The stash is a lin-

ear structure of size R = O(log N) in the secure stor-

age on the client side.

Position Map. The client stores a position map. x :=

position[b] means that block b is currently mapped to

the x-th leaf node, i.e., block b resides in some bucket

in the path from the root to the x-th leaf node. The

size of position map is N log N bits. As shown in Sec-

tion 2.1, we can leverage the recursion technique to

reduce the client side storage.

Bucket Conﬁguration. Let N be the block number of

the out-source database which is the power of 2. Our

scheme is a binary tree with L + 1 levels and 2

O(N) leaves. Precisely, each bucket contains Z = µ ·z

blocks, where z is a constant indicates the number of

slots needed to hold real data blocks and µ > 2 is a

multiplicative constant that gives extra room for noisy

blocks. Additionally, each bucket contains IND-CPA

encrypted meta-information named Headers, includ-

ing additional information about a bucket’s contents.

Headers. Bucket headers determine how permuta-

tions are generated, which blocks will be moved down

and which blocks are supposed to be cleared. A

bucket header is comprised of two parts: the ﬁrst part

stores the information whether each block is noisy,

real or empty(encryption of 0) data, while the second

one keeps the block identiﬁer.

Two-server Structure. Our scheme is based on a

two-server model. Let A and B are two non-colluding

servers with the same size. Both A and B are orga-

nized as a binary tree. Two servers share a common

position map and always perform the same operation

at the same time. For each block b whose data is m,

we choose two random values x,y ← M , where M is

the plaintext space, then store C

= (Enc(x), m + x)

on server A and C

= (Enc(y),−m + y) on server

B, where Enc is a appropriate additively homomor-

phic encryption scheme (such as Paillier cryptosys-

tem (Paillier, 1999)). Therefore, each block is always

in the same position of both A and B. For simplicity,

we only discuss one server in the following text and

show the differences between them when necessary.

Access Operation. To access a block b in a server,

i.e., read or write, the client ﬁrst fetches the corre-

sponding position tag tag from the position map. This

tag deﬁnes a unique path Path(tag) starting from the

root of the ORAM tree and going to a speciﬁc leaf

given by the tag. The element might reside in any

bucket in this path. To retrieve this element, the client

ﬁnds the position of it through the headers and makes

use of a PIRread.

• Firstly, the client downloads the headers of all

buckets in Path(tag) and searches for the bucket

which contains b. Denote that b

is that i-th block

in the path Path(tag) and j is the corresponding

position of block b in this path.

• Then the client generates two vectors E

,...,e

= (e

,...,e

) ∈ {0,1}

, where e

= e

for all i 6= j and e

1 j

6= e

2 j

. Then the client sends

to server A and E

to server B.

• After receiving vector from the client, server A

does α

∑

+ x

) on the second part of

block, and does β

= ⊕

Enc(x

) on the ﬁrst part

of block, where ⊕ represents the homomorphic

addition computation and m

is the correspond-

ing content in block b

. Similarly, server B does

∑

(−m

+ y

) and β

= ⊕

Enc(y

Then server A returns α

,β

to the client and

server B returns α

,β

to the client.

• After receiving responses from two servers,

the client does α = α

+ α

∑

−

)) +

∑

+ e

) and β = Dec(β

⊕ β

) =

∑

+ e

), where Dec is the decryption al-

gorithm. Finally, the client does (e

1 j

− e

2 j

)(α −

β) = (e

1 j

− e

2 j

1 j

− e

2 j

) = m

. So the client

can recover the data m

of requested block b.

• Afterwards, two evict operations according to re-

verse lexicographic order are performed. Finally,

if the number of real blocks in the root is less than

z after one evict operation, then a block is written

back from stash.

SECRYPT 2019 - 16th International Conference on Security and Cryptography

154

4.2 Evict Operation

The last process we need to introduce is the evict op-

eration, which aims at moving blocks from top to

bottom along a path. We propose an efﬁcient pre-

determined eviction method with small bandwidth

overhead between the server and the client, while no

entire block needs to be downloaded. In particular,

we come up with a novel way to reduce the number

of clear vectors by adjusting the buckets’ distribution

along the eviction path. Since permutation is much

smaller than the clear vector, our scheme saves the

communication cost. The details will be shown be-

low and the security analysis is in Section 5.

Eviction Algorithm. Since no more than constant

date blocks could be downloaded and only small per-

mutations or vectors can be sent to drive the evic-

tion operations by the client, the traditional eviction

method that downloads all blocks in the evict path

and writes them back one by one is not feasible at

all. Inspired by Circuit ORAM(Wang et al., 2015),

we can use a pre-processing algorithm to determine

which blocks should be moved down and to indicate

their destinations according to the header of the evict

path Path(tag). Then the client can drive the move

down process by small bandwidth messages (such as

permutations).

Pre-processing Algorithm. The inputs of the pre-

processing algorithm are a set of headers. The out-

puts of the algorithm is a sequence of destinations

of each block. The details of the algorithm can

be found in Algorithm 1(Appendix A), in which

PrepareDeepest and PrepareTarget are two sub-

algorithms in (Wang et al., 2015). The ﬁrst outputs

an array deepest[1, . . . , L], where deepest[i] stores

the level of the deepest block that can legally store

in bucket Path(tag,i). The second outputs an array

target[1, . . . , L], where target[i] stores which level the

deepest block in Path(tag,i) will be evicted to. Due

to the space limitation, we omit the details of these

two sub-algorithms. Readers can refer to (Wang et al.,

2015) for details. Therefore, the remaining challenge

is to implement the move down operation and clear

noisy operation obliviously.

Move Down Operation. There is at most 1 block that

has to be moved down in each bucket along the evict

path based on the results from the pre-processing al-

gorithm. And there is no intersection bucket between

the moving ways of any two data blocks. In order to

keep obliviousness, this block should be moved down

along the path one bucket by one bucket, i.e., if we

want to move block b from B

to B

i+ j

, then we have

to move it to B

i+1

ﬁrstly and then to B

i+2

and arrive

i+ j

after j moves. Without loss of generality, we

show the approach of how to move block b from B

i+1

• Firstly, the client retrieves a copy of header of B

and changes other real blocks’ mark from “real”

to “noisy” in the duplicate header H

• Secondly, the client generates a permutation Π ac-

cording to H

and H

i+1

, which ensures all ”real”

blocks in both buckets corresponding to “empty”

slots.

• Thirdly, the server performs Π to B

and merges it

into B

i+1

by homomorphic additions.

• Finally, update the headers H

, H

i+1

, and delete

the duplicate H

Clear Noisy Operation. After the moving down op-

eration, some noisy blocks appear since two buckets

are merged. A clear noisy algorithm is needed to

guarantee that there are enough empty room for the

following move down operation. We show the sim-

ple algorithm and its improvement. Both of them are

built on a two-server oblivious clear protocol(2SOC

Protocol).

By sending two clear vectors to two servers re-

spectively, 2SOC protocol supports performing clear

noisy and keeps real operations obliviously. For con-

venience, we use α to denote the size of each ele-

ment in clear vector. The length of the clear vector

is equal to the bucket size(µz = O(1)) since each ele-

ment in the clear vector is corresponding to one block.

The client designs two clear vectors for each bucket,

so O(log N) vectors are needed in one eviction op-

eration. Then the total communication overhead be-

tween the client and servers in clear noisy operation is

O(µzαlogN) = O(α log N), which should be bounded

by the block size in our result.

Next, we introduce an improved clear noisy algo-

rithm to further reduce the bandwidth:

• At the beginning of an evict operation, the client

generates a conﬁguration of bucket D

randomly

together with a corresponding header H

. D

in-

cludes z real blocks and µz −z empty blocks. Sim-

ilarly, a conﬁguration of bucket D

randomly to-

gether with a corresponding header H

. D

in-

cludes z + 1 real blocks and µz − (z + 1) empty

blocks is also generated by the client. Then

two pairs of clear vectors (W

) for D

and

) for D

is designed according to the

2S-DCNA Protocol.

• After the server merges B

into B

i+1

by taking

moving down operation, the client generates a

permutation Π

according to two headers H

and

under the condition that all real blocks in B

OC-ORAM: Constant Bandwidth ORAM with Smaller Block Size using Oblivious Clear Algorithm

155

are in the same position as D

after performing Π

to B

. Then do the same operation to B

i+1

and D

It is easy to know that the real blocks in H

is at

most z and the real blocks in H

i+1

is at most z + 1,

so the permutations always exist.

• Finally we use (W

),(W

) for the two

buckets to do the clear operation, after which at

least µz − z blocks in B

and µz − (z + 1) blocks in

i+1

will become an empty block.

The size of permutation is µz log µz, so the total over-

head of this improved operation is O(µzlog µz log N +

α) = O(α + logN). A log N factor is saved compared

with the original one when α > log N, which is always

true. In the rest of paper, we will use this improved

clear noisy operation. In Section 5, we will prove that

such permutations will never leak any information re-

lated to the bucket load to the server, with the help of

the reverse lexicographic eviction order.

4.3 2SOC Protocol and Clear Vector

In this section, we will introduce the basic proto-

col for clear vector construction, two-server oblivious

clear protocol(2SOC Protocol), which is inspired by

(Catalano and Fiore, 2015), and followed by the con-

struction of the clear vector.

2SOC Protocol is a technique that obliviously per-

forms one of these two operations: 1) Change data

into Enc(0); 2) Keep the value unchanged and re-

encrypt it. By sending clear vectors to servers and per-

forming some computations between the vectors and

data blocks, we can clear some blocks from noisy to 0

while keeping others’ value unchanged. The protocol

is based on any additively homomorphic encryption.

Before showing the construction, there is a very

mild property (i.e. public-space homomorphic en-

cryption) that the additively homomorphic encryption

needs to satisfy. The details can be referred to (Cata-

lano and Fiore, 2015). Most existing additively ho-

momorphic encryption schemes based on number the-

ory are public-space. Furthermore, we note that also

the more recent lattice-based homomorphic encryp-

tion schemes also satisfy our notion of public-space.

A 2SOC Protocol. Our construction builds upon

a public-space additively homomorphic encryption.

The construction includes three parts, server A, server

B and client. Now comes the precise descriptions of

our scheme (based on a public-space additively ho-

momorphic encryption H E = (KeyGen,Enc, Dec)),

where ⊕ is the homomorphic addition:

Encryption and Storage Organization: The ran-

domized encryption algorithm chooses two random

value x, y ← M and run H E.KeyGen(1

) to get the

public key pk. Then set C

(1)

= (Enc(pk, x), m + x) =

,m + x) ∈ C × M , which is stored in A, and set

(2)

= (Enc(pk, y), −m +y) = (c

,−m+y) ∈ C ×M ,

which is stored in B.

Clear Noisy: Client chooses k

← M uni-

formly under the condition that k

both have

inverse in M . We can make this condition

easy to satisfy by choosing suitable additively

homomorphic encryption scheme. Then send

(1)

= V

(2)

= (k

) to A and B respectively.

Then, A computes that C

(1)

= (k

· c

(m + x)),

(1)

= (k

· c

(m + x)), and sends C

(1)

to B.

B computes that C

(2)

= (k

· c

(−m + y)),

(2)

= (k

· c

(−m + y)), and sends C

(2)

to A.

Finally, A does that C

0(1)

= ((k

·c

)⊕(k

·c

),k

(m+

x) + k

(−m + y)) = (Enc(pk, k

(x + y)), k

(x + y)),

and B can do the similar computations to get

0(2)

= (Enc(pk, k

(x + y)), k

(x + y)). It is obvious

that both C

0(1)

and C

(2) are representatives of

encryption of 0.

Keep Real: Similarly, client chooses k

← M

uniformly under the condition that k

both

have inverse in M . Then send V

(1)

= (k

− 1)

to A and sends V

(2)

= (k

− 1, k

) to B. A and

B perform same computation to get C

0(1)

(Enc(pk,k

x + (k

− 1)y), m + k

x + (k

− 1)y),

0(2)

= (Enc(pk, (k

− 1)x + k

y),−m + (k

− 1)x +

y), which are representatives of re-encryption of m.

Furthermore, we will show that our protocol is

IND secure under our the deﬁnition in Section 3. We

formalize this property in the following theorem.

Theorem 2. If H E is IND-CPA secure, then Our 2S-

DOCA protocol is a IND secure protocol under Deﬁ-

nition 4.

Proof sketch. We proof Theorem 2 via a sequence

of hybrid experiments from the IND-security game,

and then we show the experiments are indistinguish-

able. Through the sequence of experiments, we show

that it gives the adversary the same view by replac-

ing b by 1 − b under the condition that the encryption

scheme is IND-secure. The details of the proof can be

found in Appendix B

4.3.1 Clear Vector Construction

Now, we give the construction of the clear vector.

For any bucket D = (b

,...b

µz

), we design two clear

vectors W

= (w

,...,w

Dµz

) for server A and W

SECRYPT 2019 - 16th International Conference on Security and Cryptography

156

,...,w

Dµz

) for server B. If b

,i ∈ {1, ...,µz} is a

real block, then set W

= (k

− 1),W

= (k

−

1,k

) according to the above 2SOC protocol. Other-

wise if b

, j ∈ {1,...,µz} is a noisy or empty block,

then set W

= (k

),W

= (k

) similarly. Fi-

nally, the client sends W

to server A and W

server B and lets them perform the computations de-

ﬁned in the protocol.

5 OC-ORAM ANALYSIS

We analyze the bandwidth overhead and server stor-

age ﬁrst, which leads to our main result. The proof of

correctness and security (which are deﬁned in Deﬁni-

tion 2) of OC-ORAM will be given in Section 5.2 and

full version.

5.1 Bandwidth Overhead and Storage

Analysis

In this section, we discuss the bandwidth overhead

and the server storage size of OC-ORAM. The band-

width in OC-ORAM contains two parts: Client-

Server communication bandwidth and Server-Server

communication bandwidth. And the block size can be

derived by Client-Server communication bandwidth

overhead.

Client-server Bandwidth Evaluations and Block

Size. The bandwidth overhead is deﬁned as the to-

tal amount of communication in one Access process.

The Access is composed of scheduled evict opera-

tions, a PIR read, and no more than two PIR writes.

Compared to the PIR read and write vectors, the size

of headers (O(µzlog N)) are negligible. For the sake

of clarity, we therefore avoid including them in our

asymptotic analysis.

The moving down operation of eviction pro-

cess always involves O(log N) permutations with

size O(µz log µz) bits, so the total overhead is

O(logNµz log µz) bits. The clear noisy operation of

eviction process also involves O(log N) permutations

with size O(µz log µz) bits. And two clear vectors for

two servers whose size are O(µz|M |) bits. Therefore,

the total amount of overhead of the eviction operation

is O(2logNµz log µz + 2µz|M |).

The size of PIR read vector is O(µzlog N), and the

size of PIR write vector’ size is O(γµz) bits, where

γ is the length of ciphertext in additively homomor-

phic encryption, which is obvious larger than |M |.

Finally, the PIR read operation will return a block

with size O(|B|) bits as the result of an access op-

eration. In conclusion, the communication overhead

in the whole process is O(2logNµz log µz + 2µz|M |+

µzlogN + 2γµz + |B|) = O(logNµzlogµz + γµz + |B|).

To have constant bandwidth, the block size should

be |B| = O(log Nµz log µz + γµz). With z = O(1) and

µ = O(1), we achieve |B| = O(logN +γ). In practice,

we choose γ ∈ O(λ

) and λ ∈ ω(log N), the parameter

set of which is the same as Onion ORAM(Devadas

et al., 2016), so γ dominates log N. Therefore, block

size is |B| = O(γ) = O(log

N). And the constant fac-

tor of |B| is not large, since we will show that µ > 2

and z ≥ 4 is enough to avoid overﬂowing in section

5.2.

Additionally, notice that the bandwidth overhead

of the clear noisy operation is O(µz log µz log N +

µz|M |) = O(log N + |M |) bits. When setting |M | =

logN, the bandwidth is O(log N) bits, which is

smaller than O(

log

) blocks (O(

log

) blocks

equals to O(

log

) × |B| > log N bits). So our new

clear algorithm can bypass the lower bound in (Abra-

ham et al., 2017).

Server-server Bandwidth Evaluations. The com-

munication between two servers mainly occurs in

the evict operation. For each bucket in the evict

operation, the two servers will send a ciphertext-

form-message to the other according to our 2SOC

protocol, the length of which is O(µz(γ + |M |)).

Since there are O(log N) buckets in one evict path,

so the total amount of communication between two

servers are O(log Nµz(γ + |M |)). When applying

the above parameters, we get O(log Nµz(γ + |M |)) =

O(logNµzγ) = O(log

N), which is the same as the

client-server bandwidth overhead in (Moataz et al.,

2015b; Hoang et al., 2017). The communication be-

tween servers is much cheaper than it between the

client and the server, so our scheme is more practi-

cal than their schemes.

Server Storage Size. The storage structure in the

server side is two binary trees (one in each server),

whose height is O(logN), and the size of each bucket

is O(µz) = O(1) blocks. So the total server side

storage is O(2µz · 2

logN

) = O(N) blocks. But in ex-

isting constructions (Moataz et al., 2015b; Devadas

et al., 2016; Moataz et al., 2015a; Abraham et al.,

2017; Hoang et al., 2017), the size of each bucket

is O(log N) blocks, so the total server side storage is

O(N log N) blocks. Compared with them, we reduce

a logN factor in the server storage.

OC-ORAM: Constant Bandwidth ORAM with Smaller Block Size using Oblivious Clear Algorithm

157

5.2 Correctness Analysis for

OC-ORAM

In this section, we discuss the correctness of OC-

ORAM. As deﬁned in Deﬁnition 2, the correctness

states that the ORAM returns correct results for any

input sequence~y with probability ≤ 1 −negl(|~y|). Al-

ternatively, we can prove the correctness by showing

the probability of a failure occurs is negligible. To be-

gin with the analysis, we outline two failure types in

OC-ORAM:

- F

: Blocks with value of encrypted zero in the

evict path is less than z

- F

: Overﬂow of the stash on the client side

Lemma 1. When the constant factor µ > 2 (which is

always true in OC-ORAM), the number of blocks with

value of encrypted zero in each bucket along the evict

path is at least z after the eviction.

The proof of Lemma 1 can be found in Appendix

Lemma 2. Let z ≥ 4. Let st(ORAM

µz

[

s]) be a random

variable denoting the stash size after access sequence

s for OC-ORAM with bucket size µz (µ > 2). Then, for

any access sequence

Pr[st(ORAM

µz

[

s]) > R] ≤ e

−R

where probability is taken over the ORAM algo-

rithm’s randomness.

The proof of Lemma 2 can be refer to (Wang et al.,

2015).

Theorem 3. OC-ORAM is a correct ORAM scheme

by Deﬁnition 2 (1).

The proof of Theorem 3 can be found in Appendix

6 CONCLUSIONS

In this paper, we propose a secure constant band-

width ORAM scheme (OC-ORAM) with smaller

block size. Recently, (Abraham et al., 2017) gives the

lower bound in number of operations is O(log

when combining ORAM with PIR operations. How-

ever, the operations (read, write, PIR read and PIR

write) involved in lower bound computation in ex-

isting schemes have large bandwidth (at least O(1)

blocks). Therefore the lower bound in bandwidth is

also O(log

N). According to our analysis, if we

can design a new operation that has small bandwidth,

then it is possible to achieve constant bandwidth while

use logarithmic operations. Technically, we propose

a new 2-server oblivious clear protocol (2SOC Pro-

tocol) which is proved IND-secure, and is applied

in our eviction phase to achieve constant bandwidth

ORAM. With this improved eviction algorithm, we

can reduce the bucket size to O(1) blocks, resulting

in reducing both the size of block and server stor-

age by a O(log N) multiplicative factor. We believe

that our scheme achieved the lower bound for block

size for existing additively homomorphic encryption

schemes.

REFERENCES

Abraham, I., Fletcher, C. W., Nayak, K., Pinkas, B., and

Ren, L. (2017). Asymptotically tight bounds for com-

posing oram with pir. In IACR International Workshop

on Public Key Cryptography, pages 91–120. Springer.

Boneh, D., Mazieres, D., and Popa, R. A. (2011). Remote

oblivious storage: Making oblivious ram practical.

Cachin, C., Micali, S., and Stadler, M. (1999). Compu-

tationally private information retrieval with polylog-

arithmic communication. In International Confer-

ence on the Theory and Applications of Cryptographic

Techniques, pages 402–414. Springer.

Catalano, D. and Fiore, D. (2015). Using linearly-

homomorphic encryption to evaluate degree-2 func-

tions on encrypted data. In Proceedings of the 22nd

ACM SIGSAC Conference on Computer and Commu-

nications Security, pages 1518–1529. ACM.

Chor, B., Goldreich, O., Kushilevitz, E., and Sudan, M.

(1995). Private information retrieval. In Foundations

of Computer Science, 1995. Proceedings., 36th An-

nual Symposium on, pages 41–50. IEEE.

Chung, K.-M., Liu, Z., and Pass, R. (2014). Statistically-

secure oram with\ tilde {O}(\ logˆ 2 n) overhead.

In Advances in Cryptology–ASIACRYPT 2014, pages

62–81. Springer.

Devadas, S., van Dijk, M., Fletcher, C. W., Ren, L., Shi,

E., and Wichs, D. (2016). Onion oram: A constant

bandwidth blowup oblivious ram. In Theory of Cryp-

tography, pages 145–174. Springer.

di Vimercati, S. D. C., Foresti, S., Moretti, R., Paraboschi,

S., Pelosi, G., and Samarati, P. (2016). A dynamic

tree-based data structure for access privacy in the

cloud. In 2016 IEEE International Conference on

Cloud Computing Technology and Science (Cloud-

Com), pages 391–398. IEEE.

di Vimercati, S. D. C., Foresti, S., Paraboschi, S., Pelosi,

G., and Samarati, P. (2011). Efﬁcient and private ac-

cess to outsourced data. In 2011 31st International

Conference on Distributed Computing Systems, pages

710–719. IEEE.

Gentry, C., Goldman, K. A., Halevi, S., Julta, C., Raykova,

M., and Wichs, D. (2013). Optimizing oram and us-

ing it efﬁciently for secure computation. In Privacy

Enhancing Technologies, pages 1–18. Springer.

Gentry, C. and Ramzan, Z. (2005). Single-database private

information retrieval with constant communication

SECRYPT 2019 - 16th International Conference on Security and Cryptography

158

rate. In International Colloquium on Automata, Lan-

guages, and Programming, pages 803–815. Springer.

Goldreich, O. (1987). Towards a theory of software protec-

tion and simulation by oblivious rams. In Proceedings

of the nineteenth annual ACM symposium on Theory

of computing, pages 182–194. ACM.

Goldreich, O. and Ostrovsky, R. (1996). Software protec-

tion and simulation on oblivious rams. Journal of the

ACM (JACM), 43(3):431–473.

Goodrich, M. T. and Mitzenmacher, M. (2011). Privacy-

preserving access of outsourced data via oblivious ram

simulation. In Automata, Languages and Program-

ming, pages 576–587. Springer.

Goodrich, M. T., Mitzenmacher, M., Ohrimenko, O., and

Tamassia, R. (2011). Oblivious ram simulation with

efﬁcient worst-case access overhead. In Proceedings

of the 3rd ACM workshop on Cloud computing secu-

rity workshop, pages 95–100. ACM.

Goodrich, M. T., Mitzenmacher, M., Ohrimenko, O., and

Tamassia, R. (2012). Practical oblivious storage. In

Proceedings of the second ACM conference on Data

and Application Security and Privacy, pages 13–24.

ACM.

Hoang, T., Ozkaptan, C. D., Yavuz, A. A., Guajardo, J., and

Nguyen, T. (2017). S3oram: A computation-efﬁcient

and constant client bandwidth blowup oram with

shamir secret sharing. Cryptology ePrint Archive, Re-

port 2017/819. http://eprint.iacr.org/2017/819.

Kushilevitz, E. and Ostrovsky, R. (1997). Replication is not

needed: Single database, computationally-private in-

formation retrieval. In Foundations of Computer Sci-

ence, 1997. Proceedings., 38th Annual Symposium on,

pages 364–373. IEEE.

Lu, S. and Ostrovsky, R. (2013). Distributed oblivious ram

for secure two-party computation. In Theory of Cryp-

tography, pages 377–396. Springer.

Mayberry, T., Blass, E.-O., and Chan, A. H. (2014). Efﬁ-

cient private ﬁle retrieval by combining oram and pir.

In NDSS. Citeseer.

Moataz, T., Blass, E.-O., and Mayberry, T. (2015a). Chf-

oram: a constant communication oram without ho-

momorphic encryption. Technical report, Cryptology

ePrint Archive, Report 2015/1116.

Moataz, T., Mayberry, T., and Blass, E.-O. (2015b). Con-

stant communication oram with small blocksize. In

Proceedings of the 22nd ACM SIGSAC Conference on

Computer and Communications Security, pages 862–

873. ACM.

Paillier, P. (1999). Public-key cryptosystems based

on composite degree residuosity classes. In Ad-

vances in cryptology-EUROCRYPT’99, pages 223–

238. Springer.

Shi, E., Chan, T.-H. H., Stefanov, E., and Li, M. (2011).

Oblivious ram with o ((logn) 3) worst-case cost. In

Advances in Cryptology–ASIACRYPT 2011, pages

197–214. Springer.

Stefanov, E., Van Dijk, M., Shi, E., Fletcher, C., Ren, L., Yu,

X., and Devadas, S. (2013). Path oram: An extremely

simple oblivious ram protocol. In Proceedings of the

2013 ACM SIGSAC conference on Computer & com-

munications security, pages 299–310. ACM.

Wang, X., Chan, H., and Shi, E. (2015). Circuit oram: On

tightness of the goldreich-ostrovsky lower bound. In

Proceedings of the 22nd ACM SIGSAC Conference on

Computer and Communications Security, pages 850–

861. ACM.

Williams, P. and Sion, R. (2012). Single round access pri-

vacy on outsourced storage. In Proceedings of the

2012 ACM conference on Computer and communica-

tions security, pages 293–304. ACM.

APPENDIX

A PRE-PROCESSING

ALGORITHM IN SECTION 4.2

Algorithm 1: Pre-processing algorithm.

procedure PRE-PROCESSING(path)

Call the PrepareDeepest and PrepareTarget

subroutines to pre-process arrays deepest and

target

( f lag, pos, des)

← (0,0,0)

for i ← 0toL do

if target[i] 6= ⊥ then

pos[i] ← 0

for j ← 0toµz do

if path[i][ j] can be move deeper

than path[i][pos[i]] then

pos[i] ← j

end if

end for

f lag[i] ← 1

des[i] ← target[i]

end if

end for

return ( f lag, pos, des)

end procedure

B PROOFS

B.1 Proof of Theorem 2

Proof. We proof the security via a sequence of

hybrid experiments, and then we show they are

indistinguishable.

Hybrid H1: This is the IND game (Table 2).

OC-ORAM: Constant Bandwidth ORAM with Smaller Block Size using Oblivious Clear Algorithm

159

Table 2: H1: IND-Security Game.

Experiment Exp

2S.IND

2SOC,A

(λ)

(pk, sk) ← 2SOC.KeyGen(1

)

(m,i) ← A(pk)

(1)

(2)

) ← 2SOC.Encrypt(pk, m)

(1)

(2)

) ← 2SOC.VecGen(b, pk)

T M

(1)

← 2S

(1)

); T M

(2)

← 2S

(2)

← A(C

(i)

,T M

(1)

,T M

(2)

)

If b

= b return 1. Else return 0.

Hybrid H2: This is like H2 except that the vectors

are generated by invoking the algorithm H2.VecGen

deﬁned as follows:

H2.VecGen(b, pk): The algorithm calls

(i)

= (k

) ← 2SOC.VecGen(b, pk). If b = 0,

then sets k

= k

+ (i − 1), k

= k

+ (2 − i). And re-

turns V

(i)

= (k

− (i − 1), k

− (2 − i)). Else if b = 1,

then sets k

= k

, k

= k

. And returns V

(i)

= (k

Table 3: H2 Experiment.

Experiment Exp

2S.IND

2SOC,A

(λ)

(pk, sk) ← 2SOC.KeyGen(1

)

(m,i) ← A(pk)

(1)

(2)

) ← 2SOC.Encrypt(pk, m)

(1)

(2)

) ← H2.VecGen(b, pk)

T M

(1)

← 2S

(1)

); T M

(2)

← 2S

(2)

← A(C

(i)

,T M

(1)

,T M

(2)

)

If b

= b return 1. Else return 0.

Notice that if b = 0, k

−(i − 1) = (k

+(i − 1))−(i −

1) = k

, k

− (2 − i) = (k

+ (2 − i)) − (2 − i) = k

Else if b = 1, we also have k

= k

and k

= k

. So,

H1 and H2 are indistinguishable.

However, after calling H2.VecGen, the function

of b (clear noisy or keep real) has been reversed, i.e.

if b = 0 (which means than the operation is supposed

to be ‘clear noisy’), the experiment does ‘keep real’

operation (based on k

) actually and vice versa.

Hybrid H3: This is like H2 except that the

vectors are generated by invoking the algorithm

2SOC.VecGen. Notice that the elements in vec-

tors (k

) are generated randomly, and other

computations are independent of b, so H2 and H3

are indistinguishable. Through this sequence of

experiments, we show that it gives the adversary the

same view by replacing b by 1 − b. Therefore, when

the additive homomorphic encryption is IND-CPA

secure, the advantage of the adversary is negligible.

Table 4: H3 Experiment.

Experiment Exp

2S.IND

2SOC,A

(λ)

(pk, sk) ← 2SOC.KeyGen(1

)

(m,i) ← A(pk)

(1)

(2)

) ← 2SOC.Encrypt(pk, m)

(1)

1−b

(2)

) ← H2.VecGen(1 − b, pk)

T M

(1)

1−b

← 2S

1−b

(1)

1−b

);

T M

(2)

1−b

← 2S

1−b

(2)

1−b

← A(C

(i)

1−b

,T M

(1)

1−b

,T M

(2)

1−b

)

If b

= b return 1. Else return 0.

B.2 Proof of Lemma 1

Proof. Each bucket contains at least 2z + 1 slots. In

addition, there are at most z + 1 real blocks in each

bucket at any time in eviction (at most z original real

blocks and at most 1 block is moved down from its

parent). Thus the sum of noisy blocks and empty

blocks is at least z.

In Clear noisy operation, the client generates clear

vectors which keep at most z + 1 blocks intact and

clear other µz − (z + 1) ≥ (2z + 1) − (z + 1) = z blocks

to empty blocks. In particular, the empty block is set

as the encryption of zero. so the number of blocks

with value of encrypted zero along the evict path is at

least z after the eviction operation.

B.3 Proof of Theorem 3

Proof. By Lemma 1, we can infer that when a new

evict operation begins, each bucket in the evict path

has at least z empty slots. Each bucket should contain

no more than z real blocks before a evict operation.

So F

will never happen. Therefore it can be proved

that the number of empty blocks is enough to perform

the evict operation correctly. By Lemma 2, the proba-

bility of stash overﬂow is negligible. Combining them

together, OC-ORAM is correct.

SECRYPT 2019 - 16th International Conference on Security and Cryptography

160
