Database Performance Comparisons:

An Inspection of Fairness

Uwe Hohenstein and Martin Jergler

Siemens AG, Corporate Technology, Otto-Hahn-Ring 6, Munich, Germany

Keywords: Performance, Comparison, Benchmark, Neo4j, PostgreSQL.

Abstract: Special benchmarks and performance comparisons have been published to analyze and stress the

outstanding performance of new database technologies. Quite often, the comparisons show that newly

upcoming database technologies provide higher performance than traditional relational ones.

In this paper, we show that these performance comparisons are not always meaningful and should not

encourage one to jump to fast conclusions. We revisit certain statements about comparisons between the

Neo4j graph database and relational systems and indicate a couple of possible reasons for coming up with

bad performance such as inappropriate or default configurations, and too straightforward implementations.

Moreover, we refute some stated issues about the bad performance of relational systems by using a

PostgreSQL database for commonly used test scenarios. We conclude with some considerations of fairness.

1 INTRODUCTION

Despite the dominating market share of relational

database management systems (DBMSs), new

database technologies permanently come up. Object-

oriented DBMSs proclaimed in the 90s a revolution,

promising to substitute traditional relational DBMSs

(RDBMSs). A little time later, XML databases arose

focussing on storing XML documents efficiently.

Since 2009, the NoSQL movement is gaining a

lot of attention. NoSQL stands for "not only SQL”

(http://www.nosql-database.org) although the name

has been chosen provokingly. Many products bring

up new ideas taking benefit from distribution, i.e.,

using a large amount of commodity computers to

scale out, or storing complex graph structures in a

specialized graph database.

Every new technology and its promoters claim

their products to be superior to traditional RDBMSs.

There are a lot of, sometimes emotional, discussions

on which technology is better, NoSQL or SQL.

(Moran, 2010) talks about techno-religious debates.

Those discussions are indeed very shallow from

a technical perspective. To make our discussion

more specific, we focus on the NoSQL category of

graph databases. Looking for existing comparisons,

we detected enthusiastic statements stressing the

advantages over RDBMSs accompanied by

performance measurements:

• “Graph databases outperform RDBMS on

connected data” (Khan, 2016)

• “The main benefit of native graph databases are

performance and scalability” (Khan, Ahmed,

and Shahzad, 2017)

• “So the graph database was 1000 times faster

for this particular use case” (Adell, 2013)

• “While MySQL did not finish within 2 hours,

Neo4j finished a traversal in less than 15

minutes” (Rodriguez, 2011).

Even if graph databases possess advantages which

are useful for specific applications, such general

statements must be treated carefully.

This led to our motivation for investigating those

statements in this paper. Thereby, our goal is not to

state that RDBMSs are still better. Rather we want

to stress on fairness – better unfairness – of such

statements and comparisons and prove our point of

view by measurements. This discussion of fairness

tackles several aspects such as:

• Is it equitable to take rather ad-hoc

configurations and settings?

• Is a warm start-up fair (especially if data sets

are larger than available main memory)?

• Is it fair to compare a query language (SQL)

with programming (e.g., Neo4j Pipes)?

• Are synthetic scenarios reasonable?

In particular, we show that:

• seemingly similar scenarios behave differently;

• database configurations and tuning are

important for performance and comparisons;

Hohenstein, U. and Jergler, M.

Database Performance Comparisons: An Inspection of Fairness.

DOI: 10.5220/0007926602430250

In Proceedings of the 8th International Conference on Data Science, Technology and Applications (DATA 2019), pages 243-250

ISBN: 978-989-758-377-3

243

• other data structures than the obvious or

traditional ones are advantageous;

• programming instead of using a query language

can improve performance.

The remainder of this paper is structured as

follows: In Section 2, we collect some related work

to underline the novelty of our investigation.

Afterwards, we elaborate in Section 3 upon

unfairness of existing comparisons and various

influencing factors before we conduct performance

measurements on PostgreSQL for common Neo4j

test scenarios in Section 4. In Section 5, we deduct

criteria for achieving a fair performance comparison.

Section 6 concludes the investigation and

presents some future work.

2 RELATED WORK

An early paper of (Hohenstein, et al., 1997)

criticizes standard benchmarks for object-oriented

database management systems (ODBMSs) like OO7

(Carey, et al., 1994) and statements made therein

like “ODBMSs are faster by factor 100”. In a case

study, a real application using Oracle was

transformed to several ODBMSs. The surprising

result of the performance measurements then

conducted that only a single ODBMS-based

implementation has the potential to be faster than the

original Oracle-based solution, while one ODBMS

was definitively much slower. Consequently, the

authors state that the best benchmark is the

application itself. The paper presents a methodology

for deriving application-specific benchmarks.

To our knowledge, no further work on fairness

of performance comparisons has been published so

far. Indeed, there are only some critical statements

from (Baach, 2015) “Comparing Neo4j to MySQL

without the use of Cypher is comparing apples and

oranges”. In the forum (Hacker, 2010) others also

argue that some comparisons are meaningless.

However, several performance investigations can

be found in the literature, which we tried to qualify.

(Khan, 2016) states that the technology of graph

databases is better than RDBMSs by explaining why

joins are bad for graph structures. He uses a simple

scenario that consists of Employees (E), Payments

(P) and Departments (D), related by one-to-many

relationships E-P and P-D. Then, qualifying two

departments by a query, the related payments are

retrieved via the employees. The complexity is

evaluated in Big-O notation. While RDBMS achieve

O(|E|*|P|) with nested loop joins and O(|E|+|P|) with

hash joins, Neo4j has an O(k) behavior. Neo4j’s

constant behaviour is explained as follows: “Using

hash indexing this gives O(1). Then the graph is

walked to find all the relevant payments, by first

visiting all employees in the departments, and

through them, all relevant payments. If we assume

that the number of payment results are k, then this

approach takes O(k).” However, it remains unclear

what “visiting all employees“ in Neo4j means and

how the internal data structures contribute to a better

performance compared to hash indexes in RDBMSs.

(Rodriguez, 2011) uses 1,000,000 nodes and

4,000,000 edges with a synthetic distribution:

Despite an average fan-out of 4, some nodes have a

higher number of edges. A test measures traversal

from a starting node to related nodes via 1 to 5 hops.

The result reveals that Neo4j is more than twice as

fast for 4 hops. For 5 hops, Neo4j required 14.37

minutes while MySQL was stopped after 2 hours.

The test of (Adell, 2013) detects if one person is

connected to another in 4 or fewer hops. The data set

contains 1,000,000 users with an average of 50

friends. Neo4j required 2ms for the check, while an

RDBMS was stopped after running several days.

Another comparison (Baach, 2015) uses 100,000

and 1,000,000 nodes with exactly 50 edges each. A

test counts the number of friends up to 5 hops. As a

surprising result, MySQL was about 6 times faster

than Neo4j. One potential reason for that might be

the use of the Cypher query language to perform

queries while (Rodriguez, 2011) sticks to the Pipes

framework, which seems to be very beneficial.

(Baach, 2015) considers a comparison SQL vs. the

Cypher language as fair, whereas SQL vs. Pipes

being unfair. Another reason for the result might be

some deeper thoughts about configuring MySQL.

(Vicknair et al, 2010) experiment with data sets

of size 1,000, 5,000, 10,000 and 100,000 nodes. In

contrast to others, they set up a direct acyclic graph.

Several tests traverse the graph, and count the nodes,

with 4 and 128 hops, count the number of nodes

with a certain payload, particularly with “<”

comparisons, and find all the orphan nodes. In

general, the execution times are less than 200 ms,

and do not show huge differences between Neo4j

and MySQL. In fact, the data sets are small and

enable in-memory processing.

(Khan, et al., 2017) compare Oracle 11g and

Neo4j using a Medical Diagnostic System. The data

set comprises about 28,000 patients, 625,721 patient

visits, 869,666 patient-IssueMed records, to mention

the main tables. Five count queries join two or three

tables. While Oracle performs queries in a few

seconds (depending on the query), Neo4j requires

about 0.3 sec.

DATA 2019 - 8th International Conference on Data Science, Technology and Applications

244

(Joishi and Sureka, 2015) use some process-

mining algorithms for their comparison of MySQL

and Neo4j: finding similarity between actors based

on the intersection of activities and analysing causal

dependencies between actors in carrying out a

business process. MySQL is 32 times faster than

Neo4j for similarity, while Neo4j attains a perform-

ance boost of a magnitude of 7x over MySQL for

the second test.

(Martinez et al., 2016) also compare the per-

formance of MySQL and Neo4j. Using three

randomly generated data sets (1,000, 10,000 and

100,000 entries), 12 multi-join queries of a health

application are tested. MySQL performs better than

Neo4j in most cases but has a poor performance for

larger data sets. It is important to note that no

indexes were added in both database systems.

3 FAIRNESS OF COMPARISONS

In the following, we explain why we think that

published performance comparisons are unfair and

should be seen sceptically.

3.1 Scope of Comparison

As already mentioned, the literature contains many

exciting statements about the Neo4j performance.

For example, (Khan, 2016) proves that graph data-

bases are better than RDBMSs by a theoretical

comparison of internal algorithms based on Big Os

without explaining in detail why the internal Neo4j

structures are better. A comparison of technologies

at that level is not valid anyway.

Similarly, a comparison between a product X

and RDBMSs in general as in (Adell, 2013) is

wrong per se: Showing that Neo4j is faster than

MySQL does not prove that Neo4j is faster than any

relational DBMS. There are other products, too.

3.2 Small Test Data Sets

Performance tests are often performed with small

data sets, e.g., 1000, 5000, 10,000 (Vicknair et al,

2010). Even graphs with 100,000 nodes (Baach,

2015) are not really large. This means that a test is

basically testing in-memory capabilities: All the data

fits into the accordingly sized memory.

These evaluations are only representative for

applications for which the memory is available w.r.t.

the amount of data. Results cannot be generalized

for larger data sets since they do not cover disk

accesses, which will then certainly be required.

3.3 Warm Start

The first execution of a query is slow because data is

fetched from disk and the query execution plan has

to be derived. Further executions, also with different

values, are faster because the execution plan is

already available and data is in the cache. That is

why performance comparisons like (Baach, 2015)

first initialize the cache by fetching all the needed

data in a warm start. Moreover, the cache size is

perfectly adjusted. This sounds reasonable at a first

glance, but usually not a few (tested) tables are used

and accessed in applications. Accesses to other

tables will interfere and disturb the first cached data,

but remain untested. Hence, a warm start is

representative only if all the data – not only that

used in tests – fits into memory completely.

3.4 Using Standard Configurations

DBMSs possess many parameters, which are

important for performance. However, in

performance comparisons, standard configurations

are used more or less. For example, (Martinez et al.,

2016) state that “The deployed database servers

were not optimized” and “No index was added to the

basic implementation”.

The cache size is one important parameter,

which is partially considered. Other parameters, e.g.,

the space for temporal data, affect sorting and

eliminating duplicates. Indeed, tuning database

configurations can speed up accesses drastically.

3.5 Over-tuning

If a benchmark stimulates only a few parts of an

application, tuning the benchmark can lead to a

highly optimal test program for exactly that portion.

There is a danger of over-tuning a specific scenario

or query (especially with a warm start). However,

such a specific tuning might have a negative and

invisible impact on other – potentially non-tested –

scenarios such as inserts or deletes.

3.6 Synthetic Test Scenarios

Most of the published benchmarks and comparisons

are synthetic in the sense that they abstract from

concrete applications. They aim at being generic

hand and reducing the effort for implementing and

performing tests. (Barry, 1994) states that it is easy

to spend $100,000 for implementing a benchmark,

especially if tests have to be implemented on

severval systems. Certainly, standard and simplified

Database Performance Comparisons: An Inspection of Fairness

245

benchmarks help to reduce the implementation

effort. However, it is questionable whether those

tests are representative for a particular application.

Results of comparisons are only representative if

tests coincide with the application in mind. Thus, the

tested operations must reflect the characteristic

accesses of a given application.

Most comparisons fail in this respect. For

example, benchmarks for graph databases use a

configurable number of nodes and relationships

(e.g., Vicknair et al, 2010), thereupon performing

typically traversals along connections between nodes

as the use case. The tests are thus rather synthetic.

Thus, it is not possible to adapt a benchmark to the

demands of a specific application beyond con-

figuring some few parameters. Tests are performed

by changing a few factors such as the number of

nodes (Vicknair et al, 2010) (Baach, 2015) or the

fan-out of relationships. Such a parameterization

does not help to let a benchmark become more

representative. It is legitimate to question whether

simple and slightly configurable tests could be

representative for an application at all.

There are mostly no tests for mixed scenarios

with queries, inserts, updates, and deletes combined

in one test. Hence, just a few isolated features are

compared. Real life applications surely perform

other accesses.

Furthermore, there are different understandings

of what a traversal is. Sometimes, a traversal

retrieves all related nodes via up to n hops,

sometimes it only counts the connected nodes. Other

tests determine all possible connections between two

nodes, or simply detect whether two nodes are

related via up to n hops. Beside the fact that such

tests are scenarios that are advantageous for graph

databases, these similar scenarios show huge

differences in performance as we will see later.

3.7 Implementation Issues

Some comparisons compare tests written in pure

SQL with the procedural Neo4j Pipes framework

instead of the Cypher query language. Moreover, the

test of (Baach, 2015), comparing SQL with the

Neo4j Cypher query language, comes along with a

winner MySQL. Obviously, the Cypher language

does not perform as well as the Pipes framework.

We doubt that comparing SQL with the Pipes

framework is fair.

Another point is about using a straightforward

database schema. There are other options partially

requiring stored procedures, which should be tried

out in a comparison.

3.8 Data Distribution

Performance typically depends not only on the test

scenario and test data such as the number of nodes

and the number of edges, but also on the distribution

of data for individual nodes. For example, the

selected starting node is relevant, since each node

has a different number of related nodes over n hops.

The best implementation solution can change when

using different start and end nodes!

3.9 Evaluation

Even if a benchmark seems to be representative, the

evaluation results may be unfair and may diminish

the value of the results. Typically, several test sce-

narios for traversals, inserts, removals, queries are

performed, being simple in nature and executed in

isolation and independent of each other. Also, each

test is often parameterized leading to several results.

Thus, a benchmark comprises a collection of in-

dependent results. This means particular per-

formance values have to be somehow aggregated in

order to get an overall result. Detailed analyses are

possible, but it is questionable how to correctly

extrapolate from results for simple operations to

complex logic of the real application. A particular

system is able to win a comparison by just

aggregating and interpreting the results in the right

way – a system might have won most test cases,

have best average over all the test cases, be leading

for some “relevant” weighting of test cases etc.

4 PERFORMANCE TESTS

All these issues often lead to results proving that

graph databases are 100 times faster than relational

systems, (Adell, 2013). Such statements, worded

quite general, must at least be seen relative to the

test scenarios and their relevance.

In order to support our statements, we performed

some experiments with a PostgreSQL database. We

intentionally used an older version 9.5 because

several comparisons of RDBMS vs. Neo4j are also

older. Hence, there is no advantage for the RDBMS

by using the most recent state of technology.

We take three “traversal” scenarios from

published comparisons: Scenario ALL(n) starts with

a random node and determines all nodes reachable

by less than n hops. Another scenario PATHS(n)

determines only the paths between two given nodes

related by k hops, while EXISTS(n) checks whether

two given nodes are related by k hops, k<=n.

DATA 2019 - 8th International Conference on Data Science, Technology and Applications

246

Table 1: PATHS(5) results for investigating indexes.

Test1 Cold Start Warm Start

First [sec] First [sec] Second [sec]

Index

stdev

no 62.88 3.26 59.67 0.60 60.25 1.74

yes 23.78 5.27 4.54 1.55 6.43 1.17

The tests ran in an isolated environment without

any parallel database accesses or other running

applications. Each test was performed 3 times. The

average of measurements was taken. All the tests use

the same laptop running Windows 7 with a dual-core

processor, 12 GB of RAM, and a 465 GB SSD disk.

Hence, the machine is not oversized.

It is important to note that we do not perform a

direct comparison with Neo4j – because benchmarks

are unfair. Instead, our goal is to put some published

statements into perspective.

4.1 Test Results for 500,000 Nodes

We experimented with two differently sized

databases. The first database contains 500,000 nodes

with 50 edges to other randomly selected nodes.

Test 1: Impact of Indexes for Scenario PATHS.

Our test series starts with a PostgreSQL standard

configuration (especially a very small cache size of

128 MB). We apply the frequently used database

schema of (Adell, 2013) consisting of one table

Friends (id int, friend int). Each node is identified by

a unique

id; friend is a foreign key that refers back to

a friend’s node, i.e., all those records that refer to the

same

id form the collection of friends for that node.

The first test has the purpose to illustrate the

impact of indexes. A corresponding SQL query for

Scenario PATHS(5) is sketched out in Figure 1.

select f1.id, f2.id, f3.id, f4.id, f5.id, f5.friend

from Friends f1

join Friends f2 on f2.id=f1.friend

join Friends f3 on f3.id=f2.friend

join Friends f4 on f4.id=f3.friend

join Friends f5 on f5.id=f4.friend

where f1.id = :x and f5.friend = :y

union

select f1.id, f2.id, f3.id, f4.id, f4.friend, null …

union

select f1.id, f2.id, f3.id, f3.friend, null, null ...

union

select f1.id, f2.id, f2.friend, null, null, null ...

union

select f1.id, f1.friend, null, null, null, null

from Friends f1 where f1.id = :x and f1.friend = :y;

Figure 1: SQL statement for Scenario PATHS(5).

The query computes the complete paths including all

the intermediate nodes; :x and :y represent the start

and end nodes, resp. The query is executed after a

restart of the computer (cold start), and afterwards

simply immediately executed additional three times,

now with a “warm” cache. In a second step, different

start and end points are taken for the same query.

Results are summarized in Table 1.

The test pinpoints a huge difference: Indexes are

essential for achieving performance – this is not a

surprise. The difference is even higher for a warm

start. A lack of basic indexes – maybe due to a too

naive implementation or a standard configuration

(cf. Section 3.4) – can heavily falsify benchmark

results.

Due to the obvious need for indexes, all the

further tests will be done with indexes.

Test 2: Cold/Warm Start.

Table 1 also contains the PATHS(5) results for a

comparison between warm and cold start. The

intention of this test is to investigate how the system

behaves in case of loading data from disk. This is

relevant since we cannot assume all the data in

memory for larger applications.

The difference between cold and warm start is

minimal for the test without indexes because table

data has to be loaded anyway. Using indexes, there

is a large difference between cold and warm start.

Thus, a test should not only be restricted to warm

start tests (cf. Section 3.3).

Test 3: Implementation Variants.

The next test illustrates the impact of query tuning.

Scenario EXISTS checks the existence of

connections between two nodes. In contrast to

PATHS, we are satisfied with an answer, connected

or not. There are at least three possible queries:

a) simply perform the query for PATHS (cf.

Figure 1) and check for a non-empty result;

b) add a

LIMIT 1 at the end of the PATHS query to

obtain just a single first connection;

c) add a

LIMIT 1 for each sub-query in order to

stop the execution early after the first hit:

(select f5.friend … limit 1) union … union

(select f1.friend … limit 1)

Table 2 shows the enormous speed-up for Variant c).

Consequently, searching for alternative implementa-

tions or queries can be very effective – even if as

simple as here! Taking one straightforward solution

is not reasonable (cf. Section 3.7). Note that no

connections for 1 to 4 hops exist for our test. Hence,

the multi-join queries are executed.

Database Performance Comparisons: An Inspection of Fairness

247

Test 4: Data Distribution.

Next, we show that test data and parameters have an

impact on performance (cf. 3.8). We use PATHS(5)

with different start and end nodes, resulting in

different numbers of connections. Table 2 shows

how execution times depend on the chosen start and

end nodes, and. The smaller the number of retrieved

connections is, the faster the query performs.

Table 2: Results for Test 3, 4, and 5.

Test

Variant

Cold [sec] Warm [sec]

stdev

Test 3

a) 23.78 5.27 4.54 1.55

b) 19.81 1.61 4.79 1.07

c) 2.39 0.13 0.057 0.02

Test 4

479 recs 15.18 1.27 3.32 0.64

797 recs 23.78 5.27 4.54 1.55

Test 5

128MB 23.78 5.27 4.54 1.55

1024MB 25.58 0.92 0.46 0.03

Similarly, the order of sub-queries is important

for Scenario EXISTS(5) in Test 3. If there are no

hop-1 and hop-2 but hop-3 connections, the query is

fastest if the hop-3 sub-query occurs first and

immediately stops execution. The possibility of

choosing the right nodes has an influence on results.

Knowing the data set, the implementation can be

“improved”. This is also a form of over-tuning (cf.

Section 3.5) by consciously “tuning” the order of

sub-queries according to data.

Test 5: Larger Cache Size.

The default cache in PostgreSQL with 128MB is far

too small for our table data of 864 MB and index

data of 1607 MB. Only 5% of the overall data fits

into the cache. Consequently, many reads happen

from disk. To improve the cache hit ratio, we

increase memory by factor 8 to 1024 MB in order to

have more data in memory, but still not sufficient to

keep all the data.

The results for PATHS(5) with a larger cache are

also presented in Table 2. The difference between a

small (default) and large cache for a cold start is

ignorable; the data must be fetched from disk

anyway. However for a warm start, we recognize

more than factor 8 of speed up. That is, sticking to

default configurations falsifies results (cf. 3.4).

Please note there are many further tuning

parameters, e.g., the use of temporal space to speed

up sorting and duplicate elimination.

Test 6: Different Implementations and

Structures.

So far, we have used straightforward table structures

and SQL for “implementing” the scenarios. How-

ever, there are alternatives for data structures and/or

implementing the computation logic, which are often

not considered (cf. Section 3.7). For example, in-

stead of a table

Friends(id, friend), we can use an

array-valued column in a table FriendsWithArray(id

int, friends int[]).

Each node is represented by just a

single record independent of the number of friends.

Turning to Scenario ALL, the query for getting

the nodes for 4 hops starting with

:x looks like:

select distinct f1.id as fid, f1.friends into tmp3

from FriendsWithArray f1 where f1.id = :x;

insert into tmp3 select distinct f2.id, f2.friends

from FriendsWithArray f1, FriendsWithArray f2,

generate_subscripts(f1.friends,1) i1,

where f1.id = :x and f1.friends[i1] = f2.id

union ... union

select distinct f4.id, f4.friends

from FriendsWithArray f1, FriendsWithArray f2,

generate_subscripts(f1.friends,1) i1,

generate_subscripts(f2.friends,1) i2,

FriendsWithArray f3, FriendsWithArray f4,

generate_subscripts(f3.friends,1) i3,

where f1.id = :x and f1.friends[i1] = f2.id

and f2.friends[i2] = f3.id and f3.friends[i3] = f4.id

Figure 2: Query for ALL scenario with arrays.

f1.friends

is an array that contains the friends of the

hop. The built-in function generate_subscripts is

applied to an array-valued column and returns a set

of indices to which a variable

i can then be bound.

The variable is used to access a the i-th field in the

array by means of

friends[i] to be used in joins

between array elements (i.e., sons) and Ids.

Test ALL(4) “Old” is computed with a single

SQL query similar to Figure 1, however, returning

related nodes for a start node

:x instead of paths. The

“New” variant proceeds stepwise using a stored

procedure following the query structure of Figure 2.

The result is stored in a temporary table

tmp4, which

is then used in another query to unnest the node Ids:

select distinct t3.id, friends[i] as friend into tmp4

from tmp3 t3, generate_subscripts(t3.friends,1) i

For ALL(5) “New”, two additional steps are added:

select f5.id, f5.friends into tmp5

from FriendsWithArray f5, tmp4 t4

where f5.id = t4.friend;

select distinct t5.friends[i] -- unnest

from tmp5 t5, generate_subscripts(t5.friends,1) i;

Table 3 shows that the computation of related

nodes over 5 hops is possible in about half a minute

– as opposed to several hours as stated in

(Rodriguez, 2011) (Adell, 2013). As expected, the

results with the larger cache size are even better.

DATA 2019 - 8th International Conference on Data Science, Technology and Applications

248

Table 3: Results for Scenario ALL.

Variant [sec]

Small Cache Large Cache

stdev

ALL(4) “Old” 16.43 3.21 16.28 2.87

ALL(4) “New” 8.76 3.54 4.54 1.98

ALL(5) “New” 28.67 3.26 24.55 1.75

The improved performance is paid by some

drawbacks. The table violates the first normal form

but is still easy (maybe even easier) to understand.

Also, inserts and deletes become more complicated.

A stored procedure might help to handle the logic.

Test 7: Differences in Traversal Scenarios.

Comparing the previous results, we recognize the

different performance behaviour of the various

“traversal” scenarios ALL/PATHS/EXISTS: In a

warm start, PATHS(5) is fast with about 5 seconds,

and EXISTS(5) is even very fast (a few milli-

seconds) with an optimized query. However, finding

nodes in ALL(5) is slower with half a minute. This

illustrates how important the chosen scenario and its

semantics is, even if scenarios might look quite

similar (cf. Section 3.6).

Test 8: JDBC Configuration.

So far, we have executed tests interactively with the

PostgreSQL console. However, database access will

be typically invoked by means of JDBC, ADO.NET,

or an object/relational mapping tool. Hence, another

factor enters the game having impact on

performance.

We consider fetching the query result in Java

with JDBC. One important option in JDBC is the

fetch size, which can be set by

setFetchSize(n). The

fetch size determines how many records are

transferred from the database server to the client

program: If a record is requested by the client, a bulk

of n records is physically prefetched, already serving

this and the next n-1 successive requests, too.

We used ALL(4) and executed the “Old” query

with different fetch sizes. The query executed in 30

seconds with a size of 1 (typically being the default)

and 18 seconds with a size of 1000. This a huge

difference, especially since the query execution itself

consumes about 15 sec. Again, relying on defaults

affects the performance negatively (cf. Section 3.4).

4.2 Second Database

In order to elaborate more on another facet of 3.8,

we use a larger database with 5,000,000 nodes each

having four randomly chosen friends. The results for

the bad performing One-SQL-statement of ALL(n)

(cf. Figure 1) are shown in Table 4. Even n=9 and

n=10 achieve moderate execution times despite the

higher number of hops. Thus, compared to the

previous database, the fan out seems to be one

decisive factor for performance results (cf. 3.8).

Table 4: Results for ALL scenario (large cache).

Cold [sec] Warm [sec] Number of

returned values

stdev

Stdev

LL(9)

20.66 0.22 8.01 0.05

334,247

LL(10)

37.44 3.86 26.40 0.41

1,172,908

5 THOUGHTS ABOUT FAIRNESS

Having discussed some performance scenarios and

thereby achieving different results than often

presented in the literature, we turn to the question

what fairness of performance comparisons means.

At first, it is an absolute precondition for fairness

to supply the same environment with the same

resources such as hardware, processor, operating

system, network, disks, RAM, degree of test

isolation and the same overall test conditions etc.

But if the size of memory for the DBMS is pre-

fixed, it is starting to become unfair. DBMSs like

Neo4j are Java-based and execute queries at the

client, making a lot of memory in the JVM more

advantageous. RDBMSs process queries in the

server instead. Consequently, a smaller JVM might

be sufficient in order to leave more RAM for the

DBMS. Hence, resources cannot be set equally for

all the test candidates since the settings not only

depend on an application and its data, but also on the

type of DBMS.

The rules for performing benchmarks also have a

strong impact on the expressiveness of results.

Conditions must not be too restrictive: Every test

should implement the same universe of discourse

with the same functionality. But a tester should not

be forced to use a specific database schema, a query

language etc. For example, benchmarks for

ODBMSs, e.g., (Carey, DeWitt, and Naughton,

1994), often dictated testers the same neutral

implementation. Instead, there should be freedom

for using SQL or not.

The execution of benchmarks or tests often relies

on default configurations. Parameters such as the

database cache size are set to default or configured

at good guess, and tuning is neglected. The OO7

benchmark (Carey, DeWitt, and Naughton, 1994)

legitimates such a proceeding by stating that normal

programmers cannot tune a system effectively. This

Database Performance Comparisons: An Inspection of Fairness

249

statement is doubtful in our opinion. Most DBMSs

do require an appropriate tuning in order to optimize

performance. As we have demonstrated, simple

tuning measures like creating indexes already

improve performance considerably; but there are

much more screws to turn. This potential must be

used for sustainable results.

Performance comparisons are certainly fair if

infinite time is at the tester’s disposal. This is quite

infeasible, however, the following attenuation makes

sense: Each tester of a DBMS should obtain the

same, sufficient, amount of time. Furthermore, each

implementer of a test must have the same degree of

skills and knowledge of a particular database

candidate. Otherwise, different skills should be

considered for restricting the time. Anyway, the time

limit must not be too tight, there should be sufficient

time to avoid too straightforward, often naive,

solutions. Having enough time allows a programmer

to try out concepts in several variants and to tune the

overall system.

Finally, it is important to have realistic and

holistic test scenarios. This particularly means that

scenarios should cover representative and complete

use cases with a mixed set of operations. This also

reduces the risk of over-tuning and evaluating or

aggregating partial results in a convenient manner.

6 CONCLUSIONS

Publications about new database technologies often

claim to be superior to traditional technologies such

as relational database products. This is proven by

means of technical performance comparisons.

We picked up some published statements that

compare the graph database Neo4j with relational

systems coming up with some huge performance

gains for Neo4j. The overall goal of this paper was

to discuss those “sweeping” statements. We revealed

some common test scenarios with a PostgreSQL

database and illustrated a huge spectrum of

performance depending on factors such as

configuration, database schemas, tuning etc.

Moreover, we achieved good results for those

critical scenarios that were proven to be bad for

RDBMSs. One important conclusion was that a

good and comparable performance can often be

achieved if doing it in the right way. The message

should be that each system can be tuned for

particular use cases: A deeper investigation becomes

absolutely indispensable for reliable results.

Hence, we want to encourage people to perform

own benchmarks if tools have to be compared

instead of blindly believing in published

comparisons. We made an attempt to give some

recommendations to achieve fair comparisons.

Our future work will enlarge the scope to other

NoSQL categories. That said, we want to focus on

covering further potential advantages of NoSQL

products such as distribution, scalability etc.

REFERENCES

Adell, J., 2013. Performance of Graph vs. Relational

Databases. https://dzone.com/articles/performance-

graph-vs [last access 2019/5/1].

Baach, J., 2015. Neo4j Performance Compared to

MySQL. https://baach.de/Members/jhb/neo4j-per-for

mance-compared-to-mysql [last access 2019/5/1].

Barry, D., 1994. Should you take the plunge? Object

Magazine 3(6), 1994.

Carey, M., DeWitt, D. and Naughton, J., 1994. The OO7

Benchmark. ACM SIGMOD 1994.

Hacker, 2010. NoSQL vs. RDBMS: Let the flames begin.

https://news.ycombinator.com/item?id=1221598 [last

access 2019/5/1].

Hohenstein, U., Pleßer, V. and Heller, R., 1997.

Evaluating the Performance of Object-Oriented

Database Systems by Means of a Concrete

Application. 8th DEXA Workshop, Toulouse 1997.

Joishi, J. and Sureka, A., 2015. Graph or Relational

Databases: A Speed Comparison for Process Mining

Algorithm. Proc. Of 19th International Database

Engineering & Applications Symposium, Yokohama,

2015.

Khan, W., Ahmed, W. and Shahzad, E., 2017. Predictive

Performance Comparison Analysis of Relational &

NoSQL Graph Databases. Int. Journal of Advanced

Computer Science and Applications 8(5), January

2017.

Khan, Q., 2016. Why Graph Databases Outperform

RDBMS on Connected Data. https://dzone.com/

articles/why-are-native-graph-databases-more-efficient

-than [last access 2019/5/1].

Martinez, A., Mora, R., Alvarado, D. et al., 2016. A

Comparison between a Relational Database and a

Graph Database in the context of a Personalized

Cancer Treatment Application. Proc. of Alberto

Mendelzon International Workshop on Foundations of

Data Management, Panama City 2016.

Moran, B., 2010. RDBMS vs. NoSQL: And the Winner

is .... http://www.itprotoday.com/microsoft-sql-server

/rdbms-vs-nosql-and-winner, 2010 [last access

2019/5/1].

Rodriguez, M., 2011. MySQL vs. Neo4j on a Large-Scale

Graph Traversal. https://dzone.com/articles/mysql-vs-

neo4j-large-scale [last access 2019/5/1].

Vicknair, C., Macias, M., Nan. X., et al., 2010. A Com-

parison Between a Graph and a Relational Database: A

Data Provenance View. Proc. of 48th Annual

Southeast Regional Conference, 2010, Oxford, (USA).

DATA 2019 - 8th International Conference on Data Science, Technology and Applications

250
