Automatic Extraction of Legal Citations using Natural Language

Processing

Akshita Gheewala

, Chris Turner

and Jean-Rémi de Maistre

Jus Mundi, Paris, France

Surrey Business School, University of Surrey, Guildford, U.K.

Keywords: Natural Language Processing (NLP), International Law, Legal Citations, Java Annotation Patterns Engine

(JAPE).

Abstract: The accessibility of legal documents to the different actors of the judicial system needs to be ensured for the

implementation of a strong international rule of law. The gap of such accessibility is being addressed by the

Jus Mundi multilingual search-engine for International Law. The data updated on this platform is qualified

by skilled lawyers. However, the interconnection of references within such documents, is a key feature for

lawyers since, a major part of the legal research is analysing such citations to support their arguments. The

process of interconnecting such references can prove to be expensive as well as time-consuming, if completed

manually. Hence, the purpose of this research is to automatically extract such legal citations within

international law, using Natural Language Processing (NLP), enabling the interconnectivity of documents on

Jus Mundi. This study also discusses and addresses research gaps within this subject, especially in the domain

specific to International Law. The method followed to achieve the automation is building an adaptable model

through Regular-Expression based annotation language named JAPE (Java Annotation Patterns Engine). This

set of automatically extracted links are then to be integrated with the search engine, having direct implication

in the enablement of smoother navigation, making the law more accessible. This research also contributes to

the state of the art bringing closer the eventual use of NLP in applications used to interact with International

Law documents.

1 INTRODUCTION

Computer and cognitive technologies make it

possible today to understand the quantity and

diversity of legal data constituting International law.

Therefore, Jus Mundi, a search engine developed for

International Law, relies on this technological

progress to make legal data more accessible

worldwide in order to enhance the application of

international law and thus, strengthen the

international rule of law. The purpose of this research

is to automate the identification of references within

International Law through Natural Language

Processing. This research is conducted as a

supporting activity for Jus Mundi.

These documents entail International Treaties,

Cases, Awards, Decisions, Opinions and various

other documents. Case-law plays a critical role in

decision-making and legal reasoning pertaining to

International Law. Furthermore, when lawyers

identify certain precedents that support their

arguments in a legal dispute, they make a citation

towards that particular precedent. Various other

citations towards the law are made for such purposes.

Case law citations are referred to as a part of legal

analysis as they are used to support legal

argumentation. Currently, such links to the citations

are being added to the search engine manually

through a highly systematic state-of-art methodology.

It can be interesting and value additive to support Jus

Mundi with contributing to building a solution to this

problem through development of tools which support

legal professionals in their activities. The approach

towards resolving this problem is to build a model for

automatic identification of links within legal texts

through regular-expression based pattern recognition.

It is absolutely necessary to develop tools for

automatic identification of Legal texts, if the Law has

to remain available, manageable and realistic (Moens

et al., 2000). There is an existing need to make the

information in legal texts easily and automatically

accessible (Nguyen et al., 2018). We are presently

confronted with a large number of legal texts, being

constantly recorded in an electronic format.

202

Gheewala, A., Turner, C. and de Maistre, J.

Automatic Extraction of Legal Citations using Natural Language Processing.

DOI: 10.5220/0008052702020209

In Proceedings of the 15th International Conference on Web Information Systems and Technologies (WEBIST 2019), pages 202-209

ISBN: 978-989-758-386-5

Moreover, there has been a substantial development

specifically of international law over the last seventy

years. New treaties are signed and ratified every day.

The number of international courts and tribunals has

also seen a remarkable increase over a similar time

period. This evolution is not only quantitative. The

scope of international law is also widening. It no

longer concerns only nation states but also

individuals, companies, associations and

administrations. Thus, the number of documents

among which judges, lawyers, professors, etc. are led

to conduct their research has increased considerably.

Legal professionals usually rely on a combination of

information from primary, secondary or tertiary

sources. It is important to note that under pressing

conditions of information overload, the quality of

analysis by humans that read, collate and draft such

legal documents may have a detrimental effect.

When adhering to such legal texts, analysts need

to follow the citations within the texts. Enabling

easier navigation requires automated support for the

identification of the natural language expressions

used in citations. The approach for this study is to

build a Regular-expression based model for

automatic extraction of links from legal texts. This set

of links will be extracted in an appropriate format to

enable later integration with a search engine. This

task can be obtained through GATE, an open-source,

Natural Language Processing based platform

(Cunningham, 2017). The overall approach for

achieving this task is intended to be simple, concise

and at the same time, adequate and efficient.

2 RELEVANT RESEARCH

In industries such as Banking, Insurance, Law, Retail,

Wholesale, Transportation and Manufacturing, a

large proportion of industry related data exists in

textual form (Inzalkar et al., 2015). Hence, text

mining forms one of the major fields of data mining

for information extraction for both structured and

unstructured databases.

Text mining in the legal industry has been

explored by many practitioners right from the very

first attempts by Frank Shephard in 1873, to more

recent entities such as LexisNexis (2019) and

Westlaw (2019). Studying analysis specific to

citations, one of the key contributors (Garfield, 1955)

is often cited towards such analysis in science, who

argued that Shepard’s methodologies can also be

applied to scientific citations. Data from citation

indexes created by Garfield were also used for

extracting, aggregating and analysing quantitative

aspects of bibliographic information (Moed, 2005). It

can be said that the lawyers have placed the

foundations for citation analysis (Ogden, 1993),

however such research in the domain of scientific

reports has been developing much faster than in the

field of common law, despite the increasing size of

the legal database. A continuously increasing amount

of information available, along with widely improved

means of storing such data, may have led to

information overload. The constantly evolving legal

knowledge base including the growing amount of

available citations is no exception to this (Elliott et

al., 2013). Organisations such LexisNexis and

Westlaw have developed numerous resources that

have organized such information in a structured

format providing a streamlined research experience.

This includes their electronic citators like Shepard’s

Citations or KeyCite respectively. However, an

interesting study reveals that despite providing a

similar service, there can be found notable and

unexplained inconsistencies between the results

produced by both these applications (Mart, 2013).

Moreover, it is pointed out that it would be a

challenge for a researcher to gain full benefit of such

a huge amount of unfiltered data. Publishers are still

relying upon speciﬁcally trained humans to provide

case analysis (Geist, 2009). It can be concluded that

compilation of such citators would yet rely upon

human research of the case law, irrespective of the

progress made in automated data management and

retrieval. A manual annotation approach using

Regular Expressions, supervised by qualified lawyers

is hence apt to attain a balanced solution addressing

such gaps between technology and the Law.

There also exist studies which take up approaches

not related to regular expression for automated

reference resolution in Legal texts. Tran et al. (2014)

demonstrate a Four-step framework to deal with the

task: mention detection, contextual information

extraction, antecedent candidate extraction, and

antecedent determination. A significant component of

Legal references is the cross-reference type of citation

(reference to a paragraph or a section within the same

document). There are many different approaches

towards such link resolution. However, it is argued

that the majority of the aforementioned works fail to

sufficiently address the subtleties that arise during the

resolution task (Sannier et al., 2017). Existing

research does not clearly distinguish between simple

and complex cross referencing. A more flexible

framework is developed by Sannier et al. (2017) for

automated detection as well as a resolution of cross

references as an attempt to address the

aforementioned research gap. The framework is

Automatic Extraction of Legal Citations using Natural Language Processing

203

based on structuring the database into text schemas

followed by the resolution task executed through

GATE. Building on GATE workbench Sannier et al.

(2017) implement their approach into a tool named

LeCA (Legal Cross Reference Analyzer), primarily

built in JAPE. It consists of 13k lines of code within

114 JAPE scripts, with additionally supporting 5k

lines of JAVA code. This tool supports transforming

text into mark-up format, detection and resolution of

cross references as well as visualization and analysis.

Such an intricately built tool can however only be

applied towards cross-reference type of citations.

Deep learning approaches for text mining of legal

documents have gained in interest over recent years.

Moreno and Redondo (2016) highlight this interest in

deep learning and point to its potential for use with

legal documents. In applied work Chalkidis and

Androutsopoulos (2017) compare deep learning with

sliding windows, for the purpose of contract element

extraction, and conclude that in relation to token

classification such a method provides an

improvement in performance with fewer errors over

the latter approach. Ashley and Walker (2013) have

also investigated the use of deep learning in the

mining of legal decisions relating to a defined set of

medical cases, utilising the DeepQA architecture

from IBM Watson.

Recent developments in legal data analytics have

resulted in the creation of unprecedented tools for

identifying statistical, semantic as well as citation-

based patterns in large corpuses of legal repositories.

Such dramatic growth in data-centric approaches

have paved the way for new algorithmic approaches

to legal analysis and problem solving (Conrad et al.,

2018). With the increasing interest in recent times in

the adoption of machine learning, an approach

utilising such technology to resolve the automation

task is a valid target for further research.

3 METHODOLOGY

The focus of this research is to achieve automatic

identification of links within legal texts, using Natural

Language Processing. For such a purpose, it is

necessary to attain a precise knowledge of the

structure of International Law as well as the type of

references within each document. International Law

practitioners not only refer to Treaties and

Conventions between countries, but also Cases,

Decisions and Awards related to the Treaties and

Conventions. Consequently, the links within each of

the above documents are mainly external links with

legal instruments as their target. International Law

mainly consists of Investment Arbitration Law,

comprising of Treaties, Conventions, Cases,

Decisions, Awards and Opinions.

These documents are structured with a systematic

state-of-the art methodology within a UML class text

schema. Each document is hierarchically structured

into HTML mark-up defining Levels (Titles and

metadata), Articles (Number or Title of the Article)

and Elements (Paragraphs and Sub-paragraphs).

Decisions, Awards and Opinions are documents

released by the tribunals as an outcome for

investment arbitration cases. If “MINE v. Guinea” is

the short title for a case name, and “Decision of 22

December 2016” is the Decision by the tribunal, then

“ICSID Case of Maritime International Nominees

Establishment v. Republic of Guinea, Decision of 22

December 2016” is the complete text that will be used

to make a reference to this case in any other Awards,

Opinions or Decisions. The above can also be

mentioned along with its case number such as,

“ICSID Case No. ARB/ 87 /3”. At many points within

these legal texts, references are made to Treaties or

other related Cases to support legal arguments. These

links can be found to be present at any part of the

document including footnotes. For the current task,

links from each part of the document are to be

automatically extracted. Consequently, the whole of

the document including the footnotes are to be

processed through the model for complete extraction.

The nature of links, unlike cross-references, is

said to be external, in view of references made to

Articles not within the same document but a different

Award or Decision of a Case or another Treaty

altogether. As a result, the nature of a simple link is,

for example, “Article 24(a) of the BIT”. Here, ‘the

BIT’ is the name of the Treaty (Level) and ‘24(a)’ is

the destination of the Article -> Element. Links to

Cases increase the complexity for identification due

to the unique names of the parties involved. A

combination of Regular Expression rules will be

written to correctly identify such links. Taking into

consideration the magnitude of the database, it is

practical to conduct a pilot study of the end-to-end

process to test the feasibility. It will additionally

provide an estimate of the timeline required to build

a model that should be applicable to a variety of

structures of documents and links. The sample model,

built to extract a basic link to an Article of a Treaty

will be tested on two documents. One of these is a

Decision wherein the links are already manually

identified by a qualified Lawyer, in order to compare

the output results with correct links. The second

document is a Multilateral Treaty, which is selected

for the pilot study due to the large number of articles,

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

204

hence the length of a document, providing a diverse

set of links for tests. The approach for automatic

identification of links within legal texts is

demonstrated in (Fig 1).

Figure1: Overall Methodology.

The approach consists of three major steps.

Beginning with structuring the database for the

datastore to be loaded into GATE, followed by NLP

tasks performed within GATE ending with

integration of the output with the search engine. The

second step can be further divided into pre-

processing, running the model on the datastore and

improving and re-running the model until accuracy is

achieved. Accuracy in such a task can be in

accordance with the maximum number of links that

the model is able to correctly identify, as well as the

ability of the model to identify an appropriate start

position and the end position of the link. This can be

attained through JAPE rules, which will be illustrated

in Section 4 of this paper. Before JAPE can be applied

to the data, pre-processing tasks will be carried out on

structured data using English Tokeniser, Gazetteer,

Sentence Splitter, POS Tagger and Ortho Matcher.

Each step is executed in the respective order as above.

The tokenizer splits every single text into tokens with

an individual token kind suchlike, word, number or

punctuation. Each token kind is further allotted a

token-orthography (Allcaps, Uppercase or

Lowercase) in case of words, or allotted a

punctuation-kind in case of punctuation, respective to

the characteristics of the particular text. The

Gazetteer enables users to lookup predefined

categories of text including geographical data such as

name of countries, or a date including months and

years. Case names, Awards and Decisions within

International Law, consist of the name of at least one

country and the date on which it was implemented.

The Gazetteer is hence particularly applicable to

identify Case names, Awards and Decision types of

links. The execution of Sentence Splitter will result in

identifying parts of the data as sentences within the

text. These tasks are a pre-requisite to write Regular

Expression grammar utilizing the unique annotation

types for customizing the identification of more

complex legal links.

4 ANALYSIS OF THE CITATION

EXTRACTION APPROACH

It is important to begin with an understanding of the

structure of Legal texts pertaining to International

Law, as well as how they may be tailored into an

appropriate format to achieve the extraction of links.

The analysis begins with structuring the data using

Postgres SQL, followed by integrating the schema

with GATE platform, through the Datastore.

Understanding each type of reference made between

Legal documents is a definite pre-requisite to enable

following tasks. Furthermore, the analysis in GATE

consists of pre-processing the datastore by running

numerous NLP algorithms on the same. This step is

performed as a pre-requisite for the following main

step of the analysis, i.e. formulating JAPE rules that

are able to identify all the links mentioned in each

document in the datastore. In this vein, the

construction of codes building these rules is explained

in detail. Various challenges faced while performing

the analysis are also brought forward. Considering the

nature of the analysis on an unsupervised database,

the procedure of measuring the accuracy requires

manual supervision by skilled lawyers. However, the

manual tasks are only required for a one-time

examination of the output. This task is followed by

obtaining the output as a set of annotations in the

required format for further integration with the search

engine. The overall analysis mainly focuses on the

use of JAPE on the Legal texts for automatic

extraction of each of the mentioned references within

the data as an annotation that can be exported to the

search engine; this will then be treated as a link to the

document that the reference is made to. The legal data

is collected from public institutions, international

organizations and ministries of foreign affairs. The

following institutions have already agreed to share

their data with Jus Mundi: The International Court of

Justice, the International Centre for Settlement of

STRUCTURE THE DATABASE

DATASTORE

OUTPUT

www.jusmundi.com

JAPE

ANNOTATIONS

Automatic Extraction of Legal Citations using Natural Language Processing

205

Investment Disputes, the Permanent Court of

Arbitration and the Energy Charter Secretariat.

Secondly, this data is structured. Mainly, it consists

of extracting the text of the document from its original

format (often a PDF), checking it, and entrusting it to

several algorithms which will recognize its structure

(articles, paragraphs, table of contents, footnotes and

more). This also enables the next steps of qualifying

the data. Qualifying the data means identifying legal

concepts held within such a given set. Such steps

result from artificial intelligence but also from the

participation of lawyers. This is followed by enabling

interconnection, which leads to this research study.

The interconnection of references is a key-feature for

lawyers: in one click, they should be able to access all

documents relating to an article of a treaty or a

paragraph of a judgment/award.

Such qualified data is obtained from the schema

of the search engine through a Postgres SQL query.

As a result of this query execution, the data can be

exported as one file for one document. Hence, each

Treaty, Decision, Award or Opinion will be described

by an individual file. The data is originally obtained

in an HTML format. For the purpose of this analysis,

the data is loaded as HTML text in a “.txt” format.

Due to this, the text also includes HTML tags, which

will need to be included in the analysis and JAPE

rules. There exists an alternative of dealing with such

data in “.html” format, which is also a format

supported by GATE. However, in such a case the data

would appear in a text format without any HTML

tags. The start position and end position numbers of

an identified link is counted as per the number of

letters in the document. This position will differ in

both formats, due to the HTML tags present in the text

format which are also included in the count of

position number. It is vital to include the tags in the

count for detecting the position to support the later

integration of the output with the back-office of the

search engine, wherein the data is stored in the

original HTML text format. It can hence be justified

to operate with the HTML data in a text format for

further analysis.

The database consists of 3778 Treaties, 41 Acts,

1277 Cases, 1570 Opinions, 1937 Decisions as well

as 6091 other documents with a total of 14,694

documents. Moreover, each of the above documents

exist in more than just English, with a separate

version for each of the other languages. As an

example, a Treaty between the United Kingdom and

France will exist in English as well as French. In order

to build a model to be applied to such a magnitude of

data, it is practical to conduct a pilot study, as stated

in the methodology section of this paper. The results

of the short-analysis within a stipulated timeline

assured the feasibility of conducting further analysis.

The documents selected for the pilot study along with

a part of the datastore with maximum diversity, are

treated as a Gold Standard documents, in order to

train the model. The training dataset is curated under

the guidance of qualified lawyers, to obtain maximum

applicability of the JAPE rules on the entire dataset.

The basic pre-processing tasks for information

extraction are performed as follows. Running the

Tokenizer on Legal texts will help us differentiate

between Names beginning with an upper Initial or

abbreviations with ‘AllCaps’ types of word token.

Similarly, the Gazetteer will help us identify dates of

Awards and Decisions as well as the name of

countries as mentioned in the Case names. This is

followed by a sentence splitter which will complete

the pre-processing of the database.

The above steps allot labels to each text unit in the

data. Hence, the output after the above modules as

executed, is an annotated document. In order to

extract a combination of such annotations, we instruct

the software to match a certain pattern of particular

annotations. This in GATE, is achieved through JAPE

Transducer. JAPE Transducer runs a Java Annotation

Patterns Engine (JAPE) File, which is a regular

expression rule-based language. As a result of

executing this file on the data, GATE will create a set

of annotations named “Sample”, which will consist of

every text region starting with Article, followed by a

number. A JAPE rule is a set of rules which are

executed sequentially, matching regular expression

patterns over already created annotations by pre-

processing as well as strings. In the above example

Article is matched via a string which will only

identify the word “Article”. At the same time, the

following number is matched through an annotation

of ‘kind = number’. This will identify any number

followed by the string Article and not just a particular

number. A JAPE rule consists of an LHS (Left Hand

Side) which is all the rules applied for identification,

mentioned before the “-->”. Everything after the “--

>” is the RHS (Right Hand Side) part of the JAPE

rule, which is typically related to the output of the

matched text. The name for the set of annotations, as

well as the pattern in the output annotation can be

customized on the RHS part of the rule. A set of rules

on the LHS is referred to on the RHS by an allotted

label on both sides. A combination of such rules for

matching annotation and strings are carefully written

in a particular sequence, to identify a complete text of

a legal reference. Additionally, JAPE also provides

the classic regular expression operators like

Repetitions: (+,?,*), Alternative: “|”, Negation: “!” or

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

206

a range “[]” and more. Moreover, JAPE also provides

functions to deal with overlapping annotations in case

an identified text contains a complete additional set

of annotations within itself. This will be explored

later on in this chapter. For more advanced or specific

operations, the RHS of the JAPE rule can be written

in Java, since the entire rule is ultimately translated

into Java. An additional feature that can be applied to

matching patterns are the control options such as brill

or appelt style. The appelt control option is used for

this analysis due to the nature of the output required,

with the complete set of identified text as one

annotation. For example, given a reference such as

“Article 42(b) of the BIT”, various matches would be

identified such as “Article 42”, “Article 42(b),

“Article 42(b) of the BIT”. However, the reference is

identified correctly only if there is one complete

identified output that “Article 42(b) of the BIT”. A

JAPE file is loaded on the JAPE Transducer to run on

the datastore. GATE provides a JAPE Transducer by

default. However, considering the nature of this

analysis affecting the length of the code, JAPE Plus

Transducer is certainly a preferred executor. JAPE

Plus Transducer is an updated version of JAPE

Transducer, available as a plug-in. This not only

saves upon the execution time but also enables the

user to run the code on a large corpus at once. The

length of the code increases proportionately with the

number of words to be identified as a set. This can be

explained through the following details. The

methodology followed here describes a method

intended to achieve simple, and most common

matches first, followed by building upon the existing

code to match with more complex and unique types

of links. The code in the above example would

identify any text beginning with the word “Article”

which is followed by a number. However, the same

reference is also discovered in different forms like

“Art.” Or “Articles”. Such instances can be deal with

using the Alternative “|” function of Regular

Expressions. There also exists the possibility of

“Article” being followed by more than just a simple

number. For drafting rules to match all such patterns,

a study was conducted to understand each possible

pattern of different type of citations. A brief summary

of variety of such patterns are observed as follows:

“Article III(b) of the Treaty and Article 4.a of the

HCL”

“paragraph 5, sub-para 3 of the Hydrocarbon’s Law”

“Tecmed S.A. v. The United Mexican States, (ICSID

Case No. ARB (AF)/00/2), Partial Award of 13

November 2000”

Each of the above can be mentioned in more than one

form. For example, dates, case numbers, paragraph

numbers, may or may not be mentioned in brackets.

Also, while building a rule for complex cases, it is

important to keep the original identifications in place,

as an example, if the rule identifies the whole of the

above-mentioned link towards the treaty, it should

also still be able to identify the instance with just

“Article III(b)”. In such a case, for everything

following the number is treated as “?”, which matches

the patterns in case of zero or one occurrence. Similar

approach is built for all the optional occurrences such

as “of the”, “and” or brackets “(“,”)”. Different types

of references will have a different pattern. In total, 10

JAPE files are created for 10 different types of

references. Rules for each individual type of

reference are based on different foundations from

each other. For example, the Case-citations are

identified around the occurrence of “v” followed by a

“.”. In order to make the execution of such complex

codes more organized, macros are created within

JAPE which are then simply referred to within the

LHS of the code. The RHS deals with the output of

the identified text. The default output provides the

start and end position of the words. However, the

RHS is further improved to also include the text and

the length of the identified citations. This additionally

simplifies the review process for the Lawyers, which

will be discussed further in the following section of

the paper.

5 VALIDATION OF THE

APPROACH

It is established that due to the nature of the task on

an unsupervised Database, the method of evaluation

of the model involves manual validation. It is

important to remember that although such a review is

a manual activity, it is a one-time investment of

resources to evaluate a small set of data, to achieve

the automation for all links on a significantly larger

dataset. Once the procedure is completed, the model

can be applied even to all the additional data that

would be added in the future. A question to ask at this

point: is the model effective in its ability to

automatically extract citations? For the purpose of

evaluating the model following the training, 15

diverse set of International Treaties, Cases, Acts and

other documents with a total of 3206 pages were

selected as test data. Noting the scale-free nature of

citations, 25% of these pages were selected at

random. As a result, the model was run on a total of

Automatic Extraction of Legal Citations using Natural Language Processing

207

800 pages. The total number of links within the test

data as validated by supervisors are 1317. Table 1

shows the summary of the results after evaluation.

The model fails to identify 7 links, and incorrectly

identifies 2 links with partial identification possible

for 10 links. As a total, the number of links correctly

identified are 1298, giving 98.5% of correct

identifications. Construct validity is measured in

terms of precision and recall which for the following

results is 99.23% and 98.5% respectively. Construct

validity is measured in terms of precision and recall

which for the following results is 99.23% and 98.5%

respectively. It can be noticed that the maximum

errors have occurred with Act and Case type links. As

discussed earlier, the above types of links are based

on names of Rules or Parties respectively, hence they

may not follow a specific pattern. However, it can be

said that the written rules cover all the commonly

occurring patterns as well as most of the complex and

unique patterns. A case may be cited in multiple

ways, which is ultimately drafted under human

supervision. Hence, irrespective of the defined

framework for citations, slight discrepancies may

always be expected. It can be concluded that

resolving such a task with a rule-based approach, the

completeness of the rules will always be undefined.

As an alternate approach to overcome such issue,

rules can be based on strings containing the list of

names of all documents. However, such a rule will

neither identify anything beyond the list nor the alias

of any names existing in the list. Hence, current

analysis is preferred in order to widen the application

of the model. Another challenge faced in such

analysis is the incorrect identification of links due to

the issue of Break-line wherein the identified link is

extended even to the following sentence in cases

where the input patterns are matched. This problem

would occur if the data is directly loaded as a PDF.

However, this problem can be avoided by loading the

data in an HTML format, where the split is created as

a break-line after each sentence. This can also point

out the importance of structuring the data in a mark-

up format before processing the same. This also

addresses a challenge faced during similar research of

text deviating from its originally intended schema

(Sannier et al., 2017).

6 CONCLUSIONS

Making International Law more accessible would not

only enhance its utilization but also strengthen its

effectiveness. The underlying purpose of this research

is to create an automatic process for extracting links

within Legal Texts, further enabling such documents

to be interconnected within an International Law

Search Engine, Jus Mundi. Building a search engine

involves a vast range of NLP tasks including Text

Mining. With a rapid advancement in technology

enabling increased accessibility and navigation, it can

be interesting and value adding to pursue such

research. It is established that although research is

present within this domain, the task of developing

such a model specifically towards all of International

Law is explored for the first time in this research.

The outcome of this study is a model that

automatically identifies various types of citations

between Legal documents. This enables easier

navigation, supporting the activities of lawyers to

improve the quality of legal analysis on the relation

between different laws. This task is achieved using

Natural Language Processing techniques within

Table 1: Results of Citation Extraction Approach.

SR.N

Type of

Citation

Correctly

Identified

(True

Positives)

Partially

Identified

(False

Positive)

Missed

(True

Negative)

Incorrectly

Identified

(False

Negative)

Article

208

Treaty

219

Convention

129

Act

194

Case

389

Clause

Paragraph

TOTAL

1298

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

208

GATE workbench. This involves loading the data

extracted using Postgres SQL database, loaded as a

Datastore within GATE, followed by some pre-

processing steps. As a result of running the model on

test data, 98.5% of the citations are correctly

identified with a precision of 99.23%. The evaluation

suggests that this can certainly be a very concise and

less time-consuming approach to resolve such a

challenging problem. The results contribute to similar

existing studies by successfully resolving more than

just a set of cross references. However, there exists a

possibility of improving the output of such a model

through using JAVA on the RHS of the JAPE code.

This can provide further customizations also with

regard to detection of context within citations with

unknown contexts. This step will be implemented in

the future work in order to identify the targets for such

citations. This study will be extended to numerous

other language sets and in addition forthcoming

research with evaluate deep learning approaches in

comparison with the NLP application presented in

this paper. It is also the case that domains such as

social media feeds or scientific research paper

databases present further opportunities for legal

domain specific analysis with the NLP approach.

REFERENCES

Ashley, K.D. and Walker, V.R., 2013, June. Toward

constructing evidence-based legal arguments using

legal decision documents and machine learning. In

Proceedings of the Fourteenth International Conference

on Artificial Intelligence and Law (pp. 176-180). ACM.

Bhardwaj, R.K. and Madhusudan, M., 2016. Online Legal

Information System (OLIS) Leveraging Access to

Legal Information Resources in Indian

Environment. DESIDOC Journal of Library &

Information Technology, 36(1).

Chalkidis, I. and Androutsopoulos, I., 2017, December. A

Deep Learning Approach to Contract Element

Extraction. In JURIX (pp. 155-164).

Conrad, J.G. and Branting, L.K., 2018. Introduction to the

special issue on legal text analytics. Artificial

Intelligence and Law, 26(2), pp.99-102.

Cunningham, H., Maynard, D., Bontcheva, et al. 2017,

Developing language processing components with

GATE version 8. University of Sheffield, Dept. of

Computer Science.

de Maat, E., Winkels, R. and van Engers, T., 2009. Making

sense of legal texts. Formal Linguistics and Law, 212,

p.225.

Elliott, C. and Quinn, F., 2013. English legal system.

Pearson.

Garﬁeld, E., 1955. Citation indexes for

science. Science, 122, pp.108-111.

Geist, A., 2009. Using citation analysis techniques for

computer-assisted legal research in continental

jurisdictions.

Inzalkar, S. and Sharma, J., 2015. A survey on text mining-

techniques and application. International Journal of

Research In Science & Engineering, 24, pp.1-14.

Katayama, T., 2007. Legal engineering-an engineering

approach to laws in e-society age. In Proc. of the 1st

Intl. Workshop on JURISIN, 2007.

Katayama, T., Shimazu, A., Tojo, S., Futatsugi, K. and

Ochimizu, K., 2008. e-Society and legal

engineering. Journal of the Japanese Society for

Artificial Intelligence, 23(4), pp.529-536.

LexisNexis (2019) Lexis ® Library, [online]

https://www.lexisnexis.com/uk/legal/ accessed

08/04/19.

Mart, S.N., 2013. The case for curation: the relevance of

digest and citator results in westlaw and lexis. Legal

Reference Services Quarterly, 32(1-2), pp.13-53.

Moed, H.F., 2005. Citation analysis of scientific journals

and journal impact measures. Current Science,

pp.1990-1996.

Moens, M.F., Uyttendaele, C. and Dumortier, J., 2000.

Intelligent information extraction from legal

texts. Information & Communications Technology

Law, 9(1), pp.17-26.

Moreno, A. and Redondo, T., 2016. Text analytics: the

convergence of big data and artificial intelligence.

IJIMAI, 3(6), pp.57-64.

Nguyen, T.S., Nguyen, L.M., Tojo, S., Satoh, K. and

Shimazu, A., 2018. Recurrent neural network-based

models for recognizing requisite and effectuation parts

in legal texts. Artificial Intelligence and Law, pp.1-31.

Ogden, P., 1993. Mastering the lawless science of our law:

a story of legal citation indexes. Law Libr. J., 85, p.1.

Sannier, N., Adedjouma, M., Sabetzadeh, M. and Briand,

L., 2017. An automated framework for detection and

resolution of cross references in legal

texts. Requirements Engineering, 22(2), pp.215-237.

Tran, O.T., Ngo, B.X., Le Nguyen, M. and Shimazu, A.,

2014. Automated reference resolution in legal

texts. Artificial intelligence and law, 22(1), pp.29-60.

Westlaw (2019) Westlaw UK: The Leading Legal Research

Service [online]

https://legalsolutions.thomsonreuters.co.uk/en/product

s-services/westlaw-uk.html accessed 08/04/19

Wyner, A., Mochales-Palau, R., Moens, M.F. and Milward,

D., 2010. Approaches to text mining arguments from

legal cases. In Semantic processing of legal texts (pp.

60-79). Springer, Berlin, Heidelberg.

Automatic Extraction of Legal Citations using Natural Language Processing

209
