Of the Utmost Importance:

Resource Prioritization in HTTP/3 over QUIC

Robin Marx

, Tom De Decker

, Peter Quax

1,2

and Wim Lamotte

Hasselt University – tUL – EDM, Diepenbeek, Belgium

Flanders Make, Belgium

Keywords:

Web Performance, Resource Prioritization, Bandwidth Distribution, Network Scheduling, Measurements.

Abstract:

Not even ﬁve years after the standardization of HTTP/2, work is already well underway on HTTP/3. This

latest version is necessary to make optimal use of that other new and exiting protocol: QUIC. However, some

of QUIC’s unique characteristics make it challenging to keep HTTP/3’s functionalities on par with those of

HTTP/2. Especially the efforts on adapting the prioritization system, which governs how multiple resources

can be multiplexed on a single QUIC connection, have led to some difﬁcult to answer questions. This paper

aims to help answer some of those questions by being the ﬁrst to provide experimental evaluations and result

comparisons for 11 different possible HTTP/3 prioritization approaches in a variety of simulation settings. We

present some non-trivial insights, discuss advantages and disadvantages of various approaches, and provide

results-backed actionable advice to the standardization working group. We also help foster further experimen-

tation by contributing our complete HTTP/3 implementation, results dataset and custom visualizations to the

community.

1 INTRODUCTION

A revolution is coming to the internet in the form of

the nearly standardized transport-layer QUIC proto-

col (Langley, 2017). Sometimes called “TCP 2.0”,

QUIC combines over 30 years of practical inter-

net protocol experience into one neat package, using

UDP as a ﬂexible substrate. QUIC re-imagines loss

detection and recovery, adds full transport-layer end-

to-end encryption, allows for 0-RTT overhead con-

nection setups and, of main importance to this work,

solves the TCP Head-Of-Line (HOL) blocking prob-

lem.

Some of TCP’s main strengths, namely reliability

and in-order delivery, can lead to severe performance

problems in the event of heavy jitter or packet loss

(Goel et al., 2017). This is because a TCP connec-

tion considers all data transmitted over it as a sin-

gle, opaque bytestream; it has no knowledge of a

higher-layer application protocol, such as the ubiqui-

tous HTTP. This is problematic if those application

layer protocols multiplex data from various, indepen-

dent resources on the single TCP connection. For ex-

ample, when loading a web page using the HTTP/2

(H2) protocol (RFC7540, 2015) we typically down-

load several separate resources at the same time (e.g.,

HTML, JavaScript (JS), images). As H2 uses a sin-

gle underlying TCP connection, data for these distinct

resources is scheduled and multiplexed onto this con-

nection, allowing them to share the available band-

width.

As such, if a TCP packet containing data for just

one of these resources is delayed or lost, there should

be no reason that succeeding packets containing data

for the other independent resources, can not simply

be processed by the H2 layer. However, this is not

what happens in practice. As TCP is unaware of

the various HTTP resources, if a packet is lost, sub-

sequent packets cannot be processed until a retrans-

mit of the lost packet arrives. This is called HOL-

blocking, see the top part of Figure 1. While this may

seem a mild issue, it has been shown to be one of

the major downsides of the H2 protocol running on

top of TCP (Goel et al., 2017). The key contribution

of QUIC in this area is that it moves this concept of

independent resources (more generally referred to as

‘streams’) away from the application level down into

the transport layer protocol. QUIC is inherently aware

of several streams being multiplexed on its concep-

tual single connection, and will not block data from

stream A or C if there is loss on stream B. Thus it

solves TCP’s HOL-blocking problem, see the bottom

part of Figure 1. It is important to note though, that

within a single resource stream, all data is still deliv-

130

Marx, R., De Decker, T., Quax, P. and Lamotte, W.

Of the Utmost Importance: Resource Prioritization in HTTP/3 over QUIC.

DOI: 10.5220/0008191701300143

In Proceedings of the 15th International Conference on Web Information Systems and Technologies (WEBIST 2019), pages 130-143

ISBN: 978-989-758-386-5

4 3 2 1

QUIC HTTP

Step 1: data is put on the wire

TCP HTTP

Step 2: packet 2 is lost

4 3 2 1

QUIC HTTP

TCP HTTP

QUIC

HTTP

TCP

HTTP

Step 3: packets 3 and 4 arrive

QUIC

HTTP

TCP

HTTP

Step 4: TCP suffers HOL-

blocking, QUIC does not

Stream A (e.g., HTML) Stream B (e.g., JavaScript) Stream C (e.g., CSS)

Legend:

Figure 1: Head-Of-Line blocking in TCP vs QUIC. Lacking knowledge of the three independent streams, TCP is forced

to wait for the retransmit of packet 2 (2’). QUIC can instead pass packets 3 and 4 to HTTP immediately, where they are

processed before packet 2’.

ered in order and thus there is still HOL-blocking on

that level.

QUIC incorporating the concept of streams into its

transport layer design leaves H2 in a weird position,

as it also strongly deﬁnes stream semantics on the ap-

plication layer. Running H2 on QUIC directly without

changes would thus lead to two separate and compet-

ing multiplexers. As this can introduce much imple-

mentation complexity and inefﬁciencies, the choice

was made instead to deﬁne a new mapping of H2 onto

QUIC, which is now being called HTTP/3 (H3). De-

spite the higher version number, the intent is that H2

and H3 will exist side-by-side, the ﬁrst over TCP, the

latter over QUIC. Currently, H3 is still just a rela-

tively straightforward mapping of H2 onto QUIC; the

main change is that all of H3’s stream-speciﬁc ameni-

ties have been removed in favor of QUIC’s streams.

However, this seemingly simple mapping introduces

some subtle issues, as several concepts in H2 rely on a

strict ordering between several control messages. Due

to QUIC stream data now potentially being passed

onto the H3 layer out-of-order, some H2 approaches

no longer hold and need to be revised. Main among

them is the prioritization setup, which orchestrates

the aforementioned stream data scheduling and mul-

tiplexing logic.

At the time of writing, QUIC and H3 are still be-

ing standardized

within the dedicated IETF QUIC

working group. Recently, there have been many dis-

cussions on how to approach prioritization in H3.

This is only partly due to the out-of-order streams is-

sue though. Another important component is that sev-

eral implementations of H2’s prioritization approach

seem to severely underperform in real-world deploy-

ments (see Section 2.3). As H2’s prioritization system

was originally added without much practical experi-

ence or proof of validity, the working group is weary

of making the same mistake twice. It is torn between

wanting to retain as much consistency as possible be-

tween H3 and H2 on one hand, and attempting to ﬁx

tools.ietf.org/html/draft-ietf-quic-http

some of H2’s most glaring prioritization issues on the

other. This work explores both options. Firstly, we

explain the subtle issues and background underlying

the prioritization systems (Sections 2 and 3). Sec-

ondly, we compare different proposed approaches on

their various merits (Sections 3.3 and 4). Thirdly,

we perform experiments for 11 different prioritiza-

tion schemes on realistic websites in various condi-

tions (Section 5). Lastly, we make several action-

able recommendations to the wider QUIC commu-

nity in an in-depth discussion (Section 6). An ex-

tended version of this text, our source code, dataset,

results and visualizations are made publicly available

at https://h3.edm.uhasselt.be.

2 HTTP/2 PRIORITIZATION

2.1 Background: Web Page Loading

Web pages typically consist of different (types of)

resources (e.g., HTML, JavaScript (JS), CSS, font,

image ﬁles), which have very distinct characteristics

during the loading process. For example, HTML

can be parsed, processed and rendered incrementally.

This is different from JS and CSS ﬁles, which can be

parsed as data comes in but have to be fully down-

loaded to be executed and applied. Additionally, CSS

ﬁles are HTML render-blocking: the browser engine

cannot just continue rendering any HTML after a new

CSS ﬁle is included, as this CSS might impact what

that following HTML should look like. JS is even

worse; it is HTML parser-blocking, as it might pro-

grammatically change the HTML structure, removing

or adding elements. Consequently, JS and CSS ﬁles

referenced early in the HTML should be downloaded

as soon as possible.

Another issue is that not all the needed resources

are known up-front, as they are discovered incremen-

tally during the page load. Most are mentioned in the

HTML markup directly, but many (e.g., fonts, back-

Of the Utmost Importance: Resource Prioritization in HTTP/3 over QUIC

131

ground images) are often imported from within CSS

or JS ﬁles, and are only discovered when those ﬁles

are fully executed.

A ﬁnal aspect is that the user typically does not

get to see or interact with the full web page imme-

diately, as it often extends below the current screen

height. The immediately visible part is typically

called “Above The Fold” (ATF). As such, resources

that are ATF are conceptually more important than

those “Below The Fold”. Thus, resources that appear

ﬁrst in the HTML (and their direct children) are usu-

ally considered the most important ones.

Combining all these points, it is clear that web

pages can have very complex resource interdependen-

cies. Individual resource importance depends on its

type, precise function, (potentially) location within

the HTML and how many children it will end up in-

cluding. As much of this information is unknown to

the browser before the page load starts, user agents

typically resort to complex heuristics for determining

relative resource importance in practice. To compli-

cate things even more, all browser implementations

employ (subtly) different heuristics, see (Wang et al.,

2013) and (Wijnants et al., 2018).

2.2 Dependency Tree: What and Why?

This idea that the client should use heuristics to steer

the server’s resource scheduling underpins H2’s prior-

itization system. H2 provides the client with so called

PRIORITY frames, control messages that it can use

to communicate its desired per-resource scheduling

setup to the server. The practical system by which

this scheduling is accomplished on the server is in the

form of a “dependency tree”, in which each individ-

ual resource stream is represented as a single node.

Available bandwidth is then distributed across these

nodes by means of two simple rules: parents are trans-

ferred in full before their children, and sibling nodes

share bandwidth among each other based on assigned

weights. For example, given a sibling A with weight

128 (out of a maximum of 256) and a sibling B with

weight 64, A will receive 2/3 of the available band-

width, ideally resulting in the following scheduled

packet sequence: AABAABAAB. . . .

As such, the browsers have to map their inter-

nal heuristics onto this type of tree structure. While

the tree setup is tremendously ﬂexible and allows for

an abundance of approaches (Section 4.1), it is non-

trivial to deﬁne a good mapping for the heuristics in

practice. For example, it is unclear up-front what

this dependency tree should look like, as its form can

change frequently during the page load. If newly dis-

covered resources are of a higher priority than other,

B C

Make D

dependent on A

B C

exclusively non-exclusively

Figure 2: HTTP/2 dependencies: exclusivity.

Make E

dependent on C

If C was removed

If C is

still there

Figure 3: HTTP/2 behaviour when referenced parent does

not exist. E is added as a sibling of D on the root, (uninten-

tionally) sharing its bandwidth.

previously requested resources (which already have a

node in the tree), the browser might wish to initiate

a re-prioritization. This means the new, high-priority

resource node needs to somehow be added to the tree

so that it will (immediately) receive more bandwidth

than the already present, but lower-priority resource

nodes. As such, the tree’s structure can become very

volatile and complex.

H2 adds to this complexity by allowing various

ways for clients to (re-)prioritize resources. Firstly,

nodes can be added as children to a parent in two

ways: exclusively and non-exclusively. As can be

seen from Figure 2, non-exclusive addition is the ‘nor-

mal’, less-invasive way of adding nodes to the tree.

Exclusive addition however, changes all of the po-

tential siblings beneath a parent to instead become

children of the newly added node itself. This allows

aggressive (re-)prioritization, by displacing (large)

groups of nodes in a single operation. Secondly, as

nodes can depend upon other nodes, it is also possi-

ble to group nodes together under conceptual ‘place-

holder’ nodes: these do not necessarily represent a

real resource stream, but rather just serve as anchors

for other streams.

Now, whenever the server has the ability to send

packets, it re-processes the dependency tree, deter-

mining which resource data should be put on the wire.

Depending on the implementation, the frequent (re-

)processing of the tree to determine the proper next

resource can be non-trivial and computationally ex-

pensive. Additionally, there is the memory cost of

maintaining the tree structure. To combat this, servers

are allowed to remove nodes from the tree once their

resource is transmitted fully. However, this can lead

to problems if the client attempts to add a new node to

a parent node that was already removed. At this point,

H2 speciﬁes that the server should fall back to the

conceptual root of the tree as a parent instead. This

can unintentionally promote the importance of a re-

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

132

source, as it is now a sibling of more important nodes

under the root. See for example Figure 3, where on

the right side E should conceptually have been added

as a child of D instead. Note that while in this ex-

ample there is only one mis-prioritized node (E), its

possible that there are many at the same time, exacer-

bating the problem.

Given this complexity, one might start to wonder

why we decided it was the client that had to deter-

mine the resource priorities in the ﬁrst place. Could

we not make a similar argument that the server (usu-

ally) already has all the resources and thus has a good

overview from the start? We could also say that

the server is controlled by the web developers, who

have knowledge of the intended resource priorities

up front. While these seem like solid arguments, in

practice there are many reasons why this is typically

much easier said than done. Still, to support such

use cases, H2 also allows the server to simply ignore

the client’s PRIORITY messages and instead decide

upon the proper resource scheduling itself. As such,

our road to ﬂexibility seems complete, being able to

choose either client-side or server-side prioritization

and scheduling.

One might make the argument that this ﬂexible

setup is too complex just to support the requirements

of the web page loading use case. Indeed, as we will

see in Section 3, there are several proposals for H3

that dramatically simplify this setup (e.g., by not con-

structing a dynamic tree), while still supporting ﬁne-

grained bandwidth distribution. Why then was this

complex system chosen in the ﬁrst place? As with

many protocol design decisions, a lot of the ﬁner de-

tails are lost in the sands of time. From what we

were able to piece together from various H2 mail-

ing list threads

and conversations with original con-

tributors, it seems that it was mainly meant to sup-

port more advanced use cases for cross-connection

prioritization. For example, some parties envisioned

multiplexing multiple (H2) connections onto a sin-

gle H2 connection. This is for example interesting

in the case of a general purpose proxy/VPN server

or a load balancing/edge server in a Content Delivery

Network (CDN). Another use case was for browsers

to have multiple tabs/windows open of the same web

site, which can share the same, underlying H2 con-

nection.

Surely, you might think, if the dependency tree

scheduling was added to H2 to support these use

cases, they must be implemented and deployed at

scale? Sadly, this is not the case. To the best of our

knowledge and as indicated to us by many of the in-

volved companies, no browsers, CDNs, proxy or web

lists.w3.org/Public/ietf-http-wg/2019AprJun/0113.html

servers implement these advanced use cases today. In

fact, even the simpler use cases of ﬁne-grained band-

width sharing for a single web page load are barely

utilized or improperly implemented and deployed in

practice.

2.3 Related Work: Theory vs Practice

(Wijnants et al., 2018) looked at how modern

browsers utilize H2’s prioritization system in prac-

tice. They found that out of 10 investigated browsers,

only Mozilla’s Firefox constructs a non-trivial depen-

dency tree and prioritization scheme, using multiple

levels of placeholders and complex weight distribu-

tions (see Figure 9). Google’s Chrome instead opts

for a purely sequential model where all resources are

added to a parent exclusively. Apple’s Safari goes

the other route with a purely interleaved model where

all resources are added non-exclusively to the root,

using different weights to achieve proper schedul-

ing. Microsoft’s Edge browser (before its move to the

Chromium engine) neglected to specify any priorities

at all, relying on H2’s default behaviour of adding all

the resources to the root with a weight of 16 (leading

to a Round-Robin bandwidth distribution). They re-

viewed these various approaches, and concluded that

H2’s default Round-Robin behaviour is actually the

worst case scenario (see also Section 3.3), while the

other browsers’ approaches are also suboptimal.

Next, Patrick Meenan and Andy Davies inves-

tigated how well various H2 implementations actu-

ally (re-)prioritize resources in practice (Davies and

Meenan, 2018). They ﬁrst request some low-priority

resources. After a short delay, they then request a

few high priority resources, expecting them to re-

prioritize the dependency tree and be delivered as

soon as possible. They ﬁnd that out of 35 tested CDN

services and H2 web server implementations, only

9 actually properly support (re-)prioritization. They

posit that these problems arise for various reasons.

Firstly, some implementations simply have faulty

H2 implementations or servers do not adhere to the

client’s PRIORITY messages. Secondly, implemen-

tation inefﬁciencies cause data to be mis-prioritized

Thirdly, they identify various forms of ‘bufferbloat’ as

the main culprit. If deployments use too large buffers,

the risk exists that these buffers will be ﬁlled with

low-priority data before the high-priority requests ar-

rive. It is often difﬁcult or impossible to clear these

buffers to re-ﬁll them with high-priority data when

needed. (Patrick Meenan, 2018) suggests limiting the

application-level buffers’ size, and to use the BBR

blog.cloudﬂare.com/nginx-structural-enhancements-for-

http-2-performance

Of the Utmost Importance: Resource Prioritization in HTTP/3 over QUIC

133

congestion control mechanism as solutions. Finally,

akin to (Wijnants et al., 2018), they indicate that the

browsers’ heuristics and their mapping to the H2 de-

pendency mechanism are not optimal, and propose a

better scheme in (Patrick Meenan, 2019a), which we

will refer to as bucket later.

Next to this H2 speciﬁc work, there are also con-

tributions looking at optimal browser heuristics and

prioritization in general. The WProf paper (Wang

et al., 2013) looks at resource dependencies and their

impact on total page load performance. They instru-

ment the browser to determine the ‘critical resource

path’ for a page load and use that to up-front deter-

mine optimal resource ordering. Similarly, Polaris

(Netravali et al., 2016), Shandian (Wang et al., 2016)

and Vroom (Ruamviboonsuk et al., 2017) collect very

detailed loading information (down to the level of

the JS memory heap) and construct complex resource

transmission and computation scheduling schemes.

Polaris and Shandian claim speedups of 34% - 50%

faster page load times at the median, while Vroom

even reports a ﬂat median 5s load time reduction.

However, while their approaches are perfect candi-

dates for H2’s server-side prioritization, none of these

implementations choose that option. Instead they use

custom, JS-based schedulers or H2 Server Push.

At this time Cloudﬂare is the only commercial

party experimenting with advanced server-side H2

prioritization at scale, for which they employ the

bucket scheme from (Patrick Meenan, 2019a). This

scheme aligns more closely with their server imple-

mentation and is preferred over the web browser’s

PRIORITY messages. They claim improvements of

up to 50% for the original Edge browser. Overall, we

can conclude that advanced server-side prioritization

remains relatively unproven in practice.

3 HTTP/3 PRIORITIZATION

While the tenet of the QUIC working group has (so

far) mainly been to keep H3 as close to H2 as pos-

sible, lately there have been discussions on whether

to introduce major changes into the prioritization sys-

tem. Firstly, the dependency tree setup is quite com-

plex and little of its full potential is being used in the

wild. Secondly, due to QUIC’s independent streams,

the system can not be ported over to H3 in a triv-

ial manner. The working group has long struggled

with this latter aspect and has only very recently taken

steps to solve some of the issues that arise from the

QUIC mapping. We will now ﬁrst discuss which

problems were originally identiﬁed and which solu-

Make B exclusively

dependent on A

B arrives ﬁrst,

is supplanted by C

Make C exclusively

dependent on A

C arrives ﬁrst,

is supplanted by B

Figure 4: Exclusive dependency end state in HTTP/3 for

two concurrent operations is non-deterministic.

IP A : Make A

dependent on X

B arrives

before A

ROOT

IP A

arrives

IP B : Make B

dependent on A

IP B

HEADERS

IP A

HEADERS

Stream

Control

Stream

Figure 5: HTTP/3 before draft-22: B ‘steals’ bandwidth

from X. (IP: Initial PRIORITY message).

IP A : Make A

dependent on X

Headers arrive

before IPs

ROOT

IP B : Make B

dependent on A

HEADERS

Stream

Control

Stream

IP AIP B

ORPHAN

IP A

arrives

Figure 6: HTTP/3 after draft-22: A and B no longer steal

bandwidth from X and are sent only once X has ﬁnished.

tions where included up until draft version 20

of the

H3 Internet-Draft document. Then we look at how

and why those solutions were changed in draft ver-

sion 22 in July 2019

(due to a mistake in the process,

draft version 21 was never ofﬁcially published).

3.1 Before Draft-22

One of the major problems in bringing H2 prioritiza-

tion to H3 is in the concept of exclusive dependen-

cies, which can move multiple nodes in the tree (see

Section 2, Figure 2). This approach relies heavily on

the correct ordering of PRIORITY messages. As they

are sent on the resource stream they are meant to pro-

vide priority information on, this can lead to prob-

lems. Due to packet loss or jitter on the network,

in QUIC these PRIORITY messages sent on different

streams can now arrive out-of-order, leading to non-

deterministic dependency tree layouts, see Figure 4.

The original “solution” to this was simply to remove

exclusive dependencies from the protocol.

However, the non-deterministic ordering of QUIC

streams leads to other problems. For example, let’s

say A and B are requested immediately after each

other, with B indicating A as its parent. If B arrives

before A, the server does not yet have A in its depen-

dency tree. It then has two options: either append B

tools.ietf.org/html/draft-ietf-quic-http-20

tools.ietf.org/html/draft-ietf-quic-http-22

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

134

to the root of the tree (default fallback), or create a

“non-initialized” node for A and hope its PRIORITY

message will arrive soon. However, even in the sec-

ond case, A would have to be added to the root, since

we don’t know its real parent yet. This leads to the

problem discussed in 2.2 and Figure 3, where these

new streams potentially compete for bandwidth with

streams of much higher importance, see Figure 5. The

“solution” for this problem was to simply ignore it, as

in this case A should in fact be arriving pretty soon.

However, note that in the case of a packet loss on

a long-fat network (high bandwidth, high latency) a

retransmit of A’s PRIORITY message could keep B

mis-prioritized for over 1 Round-Trip-Time (RTT). If

B is relatively small and the connection’s congestion

window is large, B could potentially be fully transmit-

ted or put into buffers before A’s retransmitted request

arrives.

In order to partially alleviate this problem in the

case of updates to the priority of existing nodes (an

additional PRIORITY message is sent), H3 uses a

separate “control stream”. As this is a single, concep-

tual stream, all messages sent on it are fully-ordered,

and the updates are applied in the expected order.

As such, in draft-20, normal H3 modus operandi is

to send the initial PRIORITY message as the very

ﬁrst data on the resource stream itself, and subsequent

PRIORITY messages for that resource on the separate

control stream. However, this does not completely

eliminate all edge cases. As a potentially better solu-

tion, the text also allows implementations to send the

initial PRIORITY message on the control stream (see

the leftmost part of Figure 6). While this provides

deterministic tree buildup, it again suffers from the

same problem as above: if the request stream’s HTTP

headers arrive before the initial PRIORITY message

is received on the control stream, the request stream

is (temporarily) added as direct child of the root node.

In an attempt to prevent these issues from hap-

pening in practice, the concept of placeholder nodes

was revisited. In H2, servers could potentially remove

the placeholders from the tree prematurely, as they

were merely simulated using idle resource streams.

As such, in H3 these nodes are explicitly made sepa-

rate entities in the tree. They are created up-front at

the start of the connection to create a harness for the

prioritization setup, and are never removed. As such,

if resource nodes only depend on placeholders, those

parents will always be in the tree and these issues do

not occur. However, other edge cases still remained.

3.2 Draft-22

Given the suboptimal state of prioritization in draft-

20, working group members had their choice of two

main directions to continue in: Either attempt to

move the design even closer to H2 (e.g., by re-

introducing exclusive priorities) or introduce more

impactful changes to the setup (e.g., moving away

from the dependency tree setup). As proof was not

yet available that the second option would lead to

performance on par with or better than the H2 sta-

tus quo, for the time being, the working group de-

cided to bring H3’s prioritization system closer to

the original H2 setup. This was accomplished by

two main changes: Firstly, all PRIORITY messages

are now required to be sent on the control stream

where before the Initial PRIORITY messages could

be sent on the resource stream itself. As now all PRI-

ORITY altering information is fully ordered again,

this allows for the re-introduction of exclusive de-

pendencies into the speciﬁcation

. The downside of

this change however is that, as before, problems can

arise if PRIORITY messages on the control stream

are lost: unprioritized request streams are added di-

rectly to the root with a weight of 16 (the default H2

fallback behaviour), where they can unintentionally

“steal” bandwidth from higher-priority streams.

The best solution to that issue was deemed to

change this default fallback behaviour. Partly in

thanks to the early results of this work, the concept

of an “orphan placeholder” was introduced

to help

resolve this issue. This special purpose placeholder

replaces the dependency tree root as the default par-

ent for unprioritized nodes, but is not part of the nor-

mal dependency tree and has special semantics. The

text states that children of the Orphan Placeholder can

only be allotted bandwidth if none of the streams in

the main dependency tree can make progress (or there

are no more open prioritized streams under the root).

This means that unprioritized streams will never get to

send data as long as there is data available for priori-

tized streams, thus preventing the unintentional band-

width “stealing” (Figure 6).

3.3 Alternatives for HTTP/3 Priorities

Next to H3 draft-22, there also existed several propos-

als for H3 that aim to introduce alternative schemes to

the one deﬁned in H2. Several of these ﬂowed from

the aforementioned insight that a Round-Robin (RR)

bandwidth distribution scheme is undesirable in most

github.com/quicwg/base-drafts/issues/2754

github.com/quicwg/base-drafts/pull/2781

github.com/quicwg/base-drafts/pull/2690

Of the Utmost Importance: Resource Prioritization in HTTP/3 over QUIC

135

Priority

(critical)

. . .

(normal)

(idle)

Concurrency: 3 Concurrency: 2 Concurrency: 1

prefetch

Concurrency: 3 Concurrency: 2 Concurrency: 1

CSS

script


preload font

video

other

async script

HTML

Concurrency: 3 Concurrency: 2 Concurrency: 1

critical CSS

critical script

visible image

font

other critical

. . .

Figure 7: Proposal for HTTP/3 prioritization based on pri-

ority buckets, from (Patrick Meenan, 2019b).

web page loading use cases (Wijnants et al., 2018)

and (Patrick Meenan, 2019a). This is mainly because,

as discussed in Section 2.1, for many high-priority re-

sources (e.g., JS, CSS, fonts) it is imperative that they

are downloaded in full as soon as possible. As dis-

cussed in detail in Section 5 and as can be seen at

the top of Figure 8, RR bandwidth interleaving leads

to resource downloads being completed very late. As

such a more sequential scheduler, which for exam-

ple sends a single resource at a time, is a much better

approach for many important resources, while a RR

scheme is more apt for lower-priority resources that

can be incrementally used (e.g., progressive images).

Since at the time, H3 did not support exclusive ad-

dition of nodes anymore, this type of sequential pri-

oritization was more difﬁcult to obtain, and so many

of the proposals focus on ways to make this easier to

accomplish. A second main issue was the potential

overhead of placeholder nodes. As they are created

up-front and cannot be removed while the connection

remains alive, an attacker who sets up a large amount

of placeholders could potentially execute a memory-

based Denial of Service attack on the server. As a

response, servers can limit the amount of placehold-

ers a client is allowed to open. The question then be-

comes: how many is enough

? Some schemes might

require large amounts of placeholders for legitimate

reasons. As such, various proposals attempt to limit

the amount of placeholders needed

or eliminate the

need for them altogether. Thirdly, many feel H2’s

scheme is overly complex and would prefer to see

simpler schemes. Finally, a combination of client and

server-side scheduling, where both parties contribute

importance information at the same time, might have

some merits.

github.com/quicwg/base-drafts/issues/2734

github.com/quicwg/base-drafts/pull/2761

The ﬁrst proposal, termed bucket by us, is one

by Patrick Meenan from Cloudﬂare (Patrick Meenan,

2019b). He proposes to drop the dependency tree

setup and replace it with a simpler scheme of “priority

buckets”, see Figure 7. Buckets with a higher number

are processed in full before buckets with a lower num-

ber. Within the buckets, there are three concurrency

levels. Level three, called “Exclusive Sequential” pre-

empts the other two and sends its contents sequen-

tially by stream ID (streams that are opened earlier

are sent ﬁrst). Levels two (“Shared Sequential”) and

one (“Shared”) are each given 50% of the available

bandwidth if level three is empty. Within level two,

streams are again handled sequentially by lowest re-

source ID, while within level one, they follow a fair

Round-Robin scheduler. As can be seen in Figure 7,

this allows a nice and ﬁne-grained mapping to typi-

cal web page asset loading needs. This scheme was

deployed for H2 as well on Cloudﬂare’s edge servers

and they claim impressive speedups (Patrick Meenan,

2019a). Overall, this scheme is also easier to imple-

ment: all that is needed is a single byte per resource

stream to carry the priority and concurrency numbers.

Resources can easily be moved around by updating

these numbers.

A second proposal by Ian Swett from Google

called “strict priorities” attempts to integrate the se-

mantics of Patrick Meenan’s bucket proposal with the

existing priority tree setup. Nodes can now have both

a priority value and a weight, and siblings with a

higher priority are sent before others. By disallow-

ing streams to depend on each other (i.e., streams can

only have placeholders as parents), this proposal also

side-steps many of the issues discussed before, while

allowing sequential sending without needing exclu-

sive dependencies. With this scheme, as with the pre-

vious one, placeholders could also be bypassed com-

pletely. While we could describe this proposal as a

“best of both worlds” endeavour, it is also relatively

complex.

Thirdly, our own proposal

called “zeroweight”

has an aim to stay quite close to the default H2 setup.

The main change is that nodes can now have a weight

between 0 and 255 (where before it was in the range

1-256). Nodes with weight 0 and 255 exhibit spe-

cial behaviour, akin to Meenan’s sequential concur-

rency levels: siblings with weight 255 are processed

ﬁrst, in full and sequentially in lowest stream ID or-

der. Then, all siblings with weight between 254 and

1 are processed in a weighted Round-Robin fashion

(assigned bandwidth relative to their weights, see Sec-

tion 2.2). Finally, if all other siblings are processed,

github.com/quicwg/base-drafts/pull/2700

github.com/quicwg/base-drafts/pull/2723

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

136

do zero-weighted nodes get bandwidth, again sequen-

tially in the lowest stream ID order. Note that draft-

22’s Orphan Placeholder could thus be implemented

as a zero-weighted placeholder under the root. The

resulting tree can be viewed in Figure 10. While this

proposal requires just a few semantic changes to the

H2 system, and is thus easy to integrate in existing

implementations, it does represent a potentially large

placeholder overhead. To get fully similar behaviour

to the previous two proposals, one would need three

placeholders per priority bucket (i.e., nine for the ex-

ample in Figure 7), as opposed to zero in their pro-

posals. However, a simpler practical setup in the zero

weighting scheme, such as the one used in our evalu-

ations and in Figure 10, requires no placeholders.

Note that (our implementations of) both bucket

and zeroweight rely, at least in part, on some addi-

tional inside knowledge that is typically not found

in browser heuristics. For example, Figure 7 men-

tions a “visible image” while in practice, browsers

have no way of deﬁnitively knowing which images

will eventually be visible or not. As such, these

schemes partially emulate the previously mentioned

case of a combination of client and server-side pri-

orities, where the web developer explicitly indicates

some up-front priorities. Since the other discussed

schemes do not utilize this additional metadata, this

will in part explain the seemingly best-in-class per-

formance of bucket and zeroweight in our results.

Various other setups were proposed, among which

there was one suggesting to go back to the prioriti-

zation scheme of the SPDY protocol (SPDY, 2014).

SPDY was the predecessor of H2 and had just “eight

levels of strict priorities”. As Chrome’s default H2 be-

haviour can be seen as a sequential version of SPDY’s

setup, for this work we have also created a Round-

Robin version of SPDY’s general concept, termed

spdyrr.

It should be noted that none of these proposals in-

troduce radical new ideas. The basic concepts remain

those of sequential versus Round-Robin. All the dis-

cussed schemes mainly differ in how easy it is to im-

plement them, in their runtime overhead, their support

of resource re-prioritization and in how ﬁne-grainedly

they allow resource importance to be speciﬁed. Even

so, it is not immediately apparent that all these op-

tions will provide similar or better performance than

H2’s status quo. In fact, it is not even fully clear if

the current H2 prioritization schemes of the various

browsers are optimal. The results of (Wijnants et al.,

2018) at least seem to indicate that many browsers

use clearly sub par prioritization schemes. Given this

complex situation, the working group deemed that

working H3 implementations and evaluations of the

various schemes were required, which this work aims

to provide.

4 EXPERIMENTAL SETUP

4.1 Prioritization Schemes

For this work, we have implemented and evaluated

11 different prioritization schemes. Their main ap-

proaches are described in Table 1 and Figure 8 shows

to what kind of data scheduling they lead in prac-

tice. For example, as expected the Round-Robin rr

clearly has a very spread out way of scheduling data

for the various streams. The ﬁrefox, p+, s+ and

spdyrr schemes are quite similar, but include sub-

tle differences. Looking at the results for bucket we

see that the HTML resource (and the font that is

directly dependent on it) are delayed considerably,

which seems non-ideal. As such, we propose our own

variation, bucket HTML, which gives the HTML re-

source a higher priority. For this test page it dramat-

ically shortens the HTML and font ﬁle’s Time-To-

Completion (TTC). Note that we did not implement

Ian Swett’s proposal, as it should function identically

to bucket in our evaluation.

4.2 Evaluation Parameters

For easiest comparison with other work, we test the

11 prioritization schemes on the test corpus of (Wij-

nants et al., 2018). This corpus consists of 41 real web

pages from the Alexa top 1000 and Moz top 500 lists.

The corpus represents a good mix of simple and more

complex pages (10-214 resources), as well as small

and larger byte sizes (29KB-7400KB). See the origi-

nal paper for more details. We also add two synthetic

test pages: one of our own design that tests all types

of heuristics modern browses apply, and the one used

by (Davies and Meenan, 2018) (Section 2.3, Figure

8). These two pages can be seen as “stress-tests” and

are designed to highlight prioritization issues and be-

haviour. The full corpus is downloaded to disk and all

ﬁles are served from a single H3+QUIC server.

For this QUIC server, we choose the open source

TypeScript and NodeJS-based Quicker implementa-

tion (Robin Marx, Tom De Decker, 2019). We

have exhaustively tested the implementation to make

sure any inefﬁciencies stemming from the underlying

JavaScript engine did not lead to performance issues.

We choose Quicker because the high level language

makes it easy to add support for H3 and to implement

our various prioritization schemes. We test the valid-

Of the Utmost Importance: Resource Prioritization in HTTP/3 over QUIC

137

wrr

fifo

dfifo

firefox

spdyrr

bucket

bucket HTML

zeroweight

bucket HTML 280K

bucket HTML 1000K

ATF resource index.html top.js hidden1.jpg hidden2.jpg hidden3.jpg background.png font.woff2 hero.jpg bottom.js

Figure 8: Scheduling behaviour of various prioritization schemes for a single, synthetic test page from (Davies and Meenan,

2018). Each individual colored rectangle represents a single QUIC packet of 1400 bytes. Packets arrive at the client from left

to right. The bottom two lines show results with non-zero send buffers. Resources in the legend are listed in request-order

from left to right.

LEADERS

w=201

CSS

ID=2

w=32

FONT

ID=3

w=42

XHR

ID=5

w=32


ID=4

w=22

SCRIPT

ID=1

w=32

UNBLOCKED

w=101

BACKGROUND

w=1

FOLLOWERS

w=1

URGENT

w=240

SPECULATIVE

w=1

ASYNC

SCRIPT

ID=6

w=32

ROOT

HTML

ID=0

w=255

UNKNOWN

ID=7

w=16

Figure 9: Firefox’s HTTP/2 dependency tree.

ROOT

CSS

ID=2

w=255

FONT

ID=3

w=16

ASYNC

SCRIPT

ID=6

w=24


ID=4

w=8

XHR

ID=5

w=8

UNKNOWN

ID=7

w=0

Sent ﬁrst

Sent second

Sent third

These two parts

individually act

as ﬁfo

This part on

itself acts as wrr

HTML

ID=0

w=255

SCRIPT

ID=1

w=255

Figure 10: Tree for our HTTP/3 zero weighting proposal.

ity of our H3+QUIC implementation by achieving full

interoperability with seven other implementations.

On the client side, there is currently sadly no

browser available that supports H3. This also prevents

us from doing qualitative user studies at this time. As

such, we use the Quicker command line client instead.

However, we do closely emulate the browser’s ex-

pected behaviour by using the open source WProfX

tool

, an easy to use implementation of the con-

wprofx.cs.stonybrook.edu

cepts from the original WProf paper (Wang et al.,

2013). We host the test corpus on a local opti-

mized webserver (H2O) and load the pages via the

Google Chrome-integrated WProfX software. From

this load, the tool can extract detailed resource inter-

dependencies (e.g., was an image referenced in the

HTML directly or from inside a CSS ﬁle) and request

timing information. Our H3 client then performs a

“smart play-back” of the WProfX recording, taking

into account resource dependencies (e.g., if the cur-

rent prioritization scheme causes a CSS ﬁle to be de-

layed, the images or fonts it references will also be

delayed accordingly). The tool also indicates which

resources are on the “critical path” and are thus most

important to a fast page load.

None of the open source QUIC stacks (including

Quicker) currently has a performant congestion con-

trol implementation that has been shown to perform

on par with best in class TCP implementations. As

we want to focus on the raw performance of the pri-

oritization schemes and the order in which data is put

on the wire, we do not want to run the risk of inefﬁ-

cient congestion controllers skewing our results. We

instead manually tune the QUIC server to send out a

single packet of 1400 bytes containing response data

of exactly one resource stream every 10ms (i.e., sim-

ulating a steadily paced congestion controller). As

such, our results represent an “ideal” upper bound of

how well prioritization could perform in the absence

of network congestion and retransmits.

While we abstract away from ﬁne-grained con-

gestion control, we do simulate other behaviours.

Firstly, we experiment with the effect of small and

larger application-level send buffers, to determine if

we see the same detrimental “bufferbloat” effects as

in (Patrick Meenan, 2018). Secondly, to illustrate

QUIC’s resilience to HOL-blocking, we add a mode

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

138

Table 1: Prioritization schemes. The top seven are from

browser H2 implementations and (Wijnants et al., 2018).

The bottom four are proposals for H3.

Name Description

(Edge)

Fully fair Round-Robin. Each re-

source gets equal bandwidth.

wrr

(Safari)

Weighted Round-Robin. Resources

are interleaved non-equally, based on

weights.

ﬁfo First-In, First-Out. Fully sequential,

lower stream IDs are sent in full ﬁrst.

dﬁfo

(Chrome)

Dynamic ﬁfo. Sequential, but higher

stream IDs of higher priority can inter-

rupt lower stream IDs.

ﬁrefox Complex tree-based setup with multi-

ple weighted placeholders and wrr for

placeholder children. See Figure 9.

p+ Parallel+. Combines dﬁfo for high-

priority with separate wrr for medium

and low-priority resources (Wijnants

et al., 2018).

s+ Serial+. Combines dﬁfo for high

and medium-priority with ﬁrefox for

low-priority resources (Wijnants et al.,

2018).

spdyrr Five strict priority sequential buckets,

each performing wrr on their children.

The Round-Robin counterpart of dﬁfo.

bucket Patrick Meenan’s proposal, Figure 7.

bucket

HTML

Our variation on bucket (HTML con-

tent is in bucket 63 instead of 31 in

Figure 7).

zeroweight Our proposal, Figure 10.

to Quicker that simulates TCP’s behaviour (i.e., pack-

ets are only processed in-order). As we do not use

congestion control or retransmits, we instead employ

network jitter rather than packet loss to demonstrate

how QUIC proﬁts from having independent streams

(Section 5.2).

Due to our stable experimental setup we can not

simply use, for example, the total web page down-

load time as our metric, as these values are all identi-

cal per tested page across the different schemes. This

can easily be seen by understanding that each scheme

still needs to send the exact same amount of data;

it just does so in a different order. Instead, we will

mainly look at so-called “Above The Fold” (ATF) re-

sources. As discussed in Section 2.1, these resources

are either on the browser’s critical render path or con-

tribute substantially to what the user sees ﬁrst (e.g.,

large hero images). We combine WProfX’s critical

path calculations with a few manual additions to ar-

0.2

0.4

0.6

0.8

1.2

150

290

430

570

710

850

990

1130

1270

1410

1550

1690

1830

1970

2110

2250

2390

2530

2670

2810

% of ATF bytes downloaded

Time (ms)

bucket rr

BI = 21589

BI = 1506

Figure 11: ByteIndex (BI) for bucket and rr schemes.

Bucket is clearly faster for ATF resources. Looking at these

schemes in Figure 8, it is immediately clear why.

rive at an appropriate ATF resource set for each test

page. This ATF set typically contains the HTML, im-

portant JS and CSS, all fonts and prominent ‘hero im-

ages’. Non-hero (e.g., background) images that are

rendered above the fold are consciously not included

in this set (e.g., see “background.png” in Figure 8), as

they should have less of an impact on user experience.

However, we also cannot directly use, for exam-

ple, the mean TTC for these ATF resources as our

metric. For example, receiving most of the ATF ﬁles

very early and then receiving just a single one late is

generally considered better for user experience than

receiving all together at an intermediate point, though

both situations would give a similar mean TTC. To

get a better idea of the progress over time, we use

the ByteIndex (BI) web performance metric (Bocchi

et al., 2016). This metric estimates (visual) loading

progress over time by looking at the TTCs of (visually

impactful, e.g., ATF) resources. At a ﬁxed time inter-

val of 100ms we look at which of the resources under

consideration have been fully downloaded. The BI is

then deﬁned as taking the integral of the area above

the curve we get by plotting this download progress,

see Figure 11. Consequently as with normal web page

load times, lower BI values are better.

Practically, we instrument Quicker to log the full

H3 page loads in the proposed qlog standard logging

format

for QUIC and H3. We then write custom

tools to extract the needed BI values from these logs,

as well as new visualizations to display and verify our

results (Figures 8, 12 and 13).

5 RESULTS

5.1 Prioritization Schemes

Our main results are presented in Figure 12 and Ta-

ble 2. Like (Wijnants et al., 2018), we remark that

github.com/quiclog/internet-drafts

Of the Utmost Importance: Resource Prioritization in HTTP/3 over QUIC

139

Table 2: Mean speedup ratios compared to rr per other pri-

oritization scheme from Figure 12. Higher mean values are

better. #PH = number of placeholders used in this scheme.

Scheme #PH

Mean

All

Mean

ATF

Mean

1000K

wrr 0 1.05 1.49 1.28

ﬁfo 0 1.27 1.93 1.57

dﬁfo 5 1.27 2.30 1.72

ﬁrefox 6 1.07 1.22 1.25

p+ 3 1.17 2.20 1.64

s+ 8 1.14 1.45 1.56

spdyrr 5 1.14 1.96 1.57

bucket 0 1.20 2.13 1.82

bucket

HTML

0 1.20 2.49 1.83

zeroweight 0 1.15 2.8 1.9

the rr scheme is by far the worst performing of all

tested setups, with almost no data points performing

worse. As such, we take rr as the baseline and present

the other measurements in terms of a relative speedup

to that baseline result. As such, a speedup of x2 for

scheme Y means that, for a baseline rr BI of 1500,

Y achieves a BI of 750. Symmetrically, a slowdown

of /3 indicates that Y had a BI of 4500. We have

tested the schemes with application-level send buffers

of 14KB, 280KB and 1000KB, but found that these

had relatively small effects until the buffer grows sub-

stantially large. As such, we focus on results for send

buffers of 1000KB here.

Our main results are presented in Figure 12 and

Table 2. Like (Wijnants et al., 2018), we remark that

the rr scheme is by far the worst performing of all

tested setups, with almost no data points performing

worse. As such, we take rr as the baseline and present

the other measurements in terms of a relative speedup

to that baseline result. As such, a speedup of x2 for

scheme Y means that, for a baseline rr BI of 1500,

Y achieves a BI of 750. Symmetrically, a slowdown

of /3 indicates that Y had a BI of 4500. We have

tested the schemes with application-level send buffers

of 14KB, 280KB and 1000KB, but found that these

had relatively small effects until the buffer grows sub-

stantially large. As such, we focus on results for send

buffers of 1000KB here.

A few things are immediately clear from Figure

12: a) Almost all data points are indeed faster than rr.

b) With the exception of a few bad performers (i.e.,

ﬁrefox, wrr, s+), all schemes are able to provide im-

pressive gains of x3.5 to x5+ speedup factors for in-

dividual web pages. c) Medium sized pages seem to

proﬁt less from prioritization overall, with smaller and

larger pages showing larger relative advancements. d)

Of the well-performing schemes, there is not a clear,

single winner or a scheme that consistently improves

heavily upon rr for all tested pages. e) The impact

of the 1000KB send buffer is visible, but less impres-

sively so than the slowdowns of /2 reported in (Patrick

Meenan, 2018).

When looking at the mean ratios in Table 2, we

see similar trends. We have highlighted some of the

the highest and lowest values for each column. Taking

into account all page assets, even though the speedups

are all modest, it is clear that ﬁfo is a far better default

choice than rr. Looking at ATF resources only, it is

remarkable how badly some schemes implemented by

browsers perform (i.e., ﬁrefox and Safari’s wrr), while

Chrome’s dﬁfo is almost optimal, after bucket HTML

and zeroweight. Though all schemes suffer from

larger send buffers, bucket HTML and zeroweight

again come out on top. As mentioned before, the good

performance of these latter two schemes can be par-

tially attributed to giving hero images a higher server-

side priority, highlighting that indeed, there might be

merit in combining client and server-side directives.

While the reduced observed impact of larger send

buffers might seem unexpected and contrary to the

ﬁndings of (Patrick Meenan, 2018), it has a sim-

ple explanation in two parts. Firstly, larger send

buffers mainly impact the ability of the scheme to re-

prioritize its scheduler in response to late discovered

but important resources. In our data set however, we

seem to have few web pages that contain such highly

important late discoveries. Indeed, the test page

showing the most remarkable slowdown from the

larger send buffers was that of (Davies and Meenan,

2018) themselves (dropping from x9 speedup with-

out send buffer to x3 with 1000K). Secondly, as the

size of the send buffer grows, the resulting behaviour

more and more becomes that of ﬁfo, as requested re-

sources can be put into the buffer in their entirety im-

mediately. This is clearly visible in Figure 8. As we

have seen, ﬁfo performs well overall, so even larger

send buffers will also keep performing relatively well.

It is our opinion that the results seen by Davies and

Meenan for faulty prioritizations in the wild might

be less due to “bufferbloat” and more due to miscon-

ﬁgured or badly implemented H2 servers, or that the

observed impact is enlarged due to their choice of a

highly tuned test page.

To dig a bit deeper into some of the outliers, we

discuss two case studies. The ﬁrst is outlined in black

on Figure 12. This web page suffers a slowdown

of about /3 for three separate schemes, yet sees ma-

jor improvements of x4 in others. This speciﬁc page

has relatively few resources with highly speciﬁc roles.

Most importantly, it features a single, page-spanning

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

140

factor factor

speedup

slowdown

baseline

(rr)

All ATF 1000K

wrr

All ATF 1000K

fifo

All ATF 1000K

dfifo

All ATF 1000K

firefox

All ATF 1000K

spdyrr

All ATF 1000K

bucket

All ATF 1000K

bucket HTML

All ATF 1000K

zeroweight

= case study 1

= case study 2

Small webpage < 500KB Medium webpage > 500KB, < 1000KB Large webpage > 1000KB All = BI ALL, no send buffer ATF = BI ATF, no send buffer 1000K = BI ATF, 1000KB send buffer

Figure 12: ByteIndex (BI) speedup and slowdown ratios for 10 prioritization schemes compared to the baseline rr scheme.

Each datapoint represents a single web page, split out by total page byte size. Higher y values are better.

hero image that is relatively small in byte size. Next to

this, it includes several very large JS ﬁles which, even

though included in the HTML <head>, are marked as

“defer”. This means they will only execute once the

full page has ﬁnished downloading. As such, the hero

image is marked as an ATF resource, but the JS ﬁles

are not. As the image is discovered after the JS ﬁles,

it is stuck behind them in ﬁfo. For ﬁrefox (and sim-

ilarly s+), the image is in the “FOLLOWERS” cat-

egory (see Figure 9), while the JS ﬁles are in “UN-

BLOCKED”. While the group of the image receives

about twice the bandwidth as the JS (via the parent

“LEADERS” placeholder), the image is competing

with a critical CSS in the leaders, thus being delayed.

For the speedups, the schemes either know there is a

hero image (bucket (HTML) and zeroweight), allow

the smaller hero image to make fast progress via a

(semi) Round-Robin scheme or, in the case of dﬁfo,

accurately assign low priority to the JS ﬁles.

The second case study is outlined in blue on Fig-

ure 12. This web page interestingly has a few in-

stances where the 1000k send buffer outperforms

the normal ATF case. This is because this page’s

HTML ﬁle is comparatively very large (167KB). As

explained before, a large send buffer exhibits ﬁfo-

alike behaviour. Thus, for schemes where normally

the large HTML would be competing with other re-

sources (e.g., pmeenan and ﬁrefox), it now gets to

ﬁll the send buffers in its entirety, completing much

faster. Where in the previous case study Round-

Robin-alike schemes lead to smaller resources com-

pleting faster, here the large HTML ﬁle is instead

smeared out over a longer period of time due to in-

terleaving with the other (ATF) resources, leading to

relatively low gains for RR-alike schemes.

Finally, looking at Table 2, we can see that the

schemes using the most placeholders are partially

also those that showed sub par performance in vari-

ous conditions. Contrarily, the two best performing

schemes both use zero placeholders. With regards to

overall implementation complexity, bucket (HTML)

is the only scheme we actually implemented com-

pletely separately and this was indeed far easier than

the complex dependency tree implementation. How-

ever, deﬁning new schemes such as zeroweighting or

spdyrr for the dependency tree was also relatively

straightforward.

5.2 QUIC’s HOL-blocking Resilience

As mentioned in Section 4, we also try to deter-

mine the practical impact of QUIC’s absence of HOL-

blocking. We induce the HOL-blocking by introduc-

ing jitter for semi-random packets: about one packet

in four is delayed until 1-3 other packets have been

sent. For normal QUIC (jitter only), the 1-3 later

packets can just be processed and passed on to H3

upon arrival. To determine how much this matters in

practice, we implement a HOL-blocking mode in the

Quicker client. In this mode, the 1-3 later packets

are instead kept in a buffer until the delayed packet

arrives, simulating normal TCP behaviour. Partial re-

sults for both approaches can be seen in Figure 13.

In opposition to Figure 8 we can now clearly see

empty areas where no packets arrived. Packets that ar-

rive together, or that are HOL-blocked and then deliv-

ered to the H3 layer together, are drawn stacked verti-

cally. Comparing the two rr setups, we can clearly see

the beneﬁcial impact of QUIC’s independent streams:

rr jitter only has far fewer stacked packets (maximum

of two) than rr HOL-blocking, as packets containing

independent stream data can be processed directly. In

opposition, rr HOL-blocking shows various instances

of data from (critical) resources being blocked behind

Of the Utmost Importance: Resource Prioritization in HTTP/3 over QUIC

141

jitter only

HOL-blocking

fifo

jitter only

fifo

HOL-blocking

Figure 13: Scheduling behaviour under jitter and HOL-blocking conditions for the same test page as Figure 8. Packets that

are stacked vertically are passed from QUIC to HTTP/3 at the same time. The color legend and other semantics are the same

as Figure 8.

packets of other (non-critical) streams, leading to fre-

quent stacks of four packets.

However, we do not see similar HOL-blocking

resilience for the ﬁfo scheme. The reason for this

is simple: while QUIC removes inter-stream HOL-

blocking, data within a single stream still needs to be

delivered in-order. As in ﬁfo there is always only a

single stream in progress at a time, this stream will al-

ways HOL-block itself, undoing one of QUIC’s main

promised improvements.

6 DISCUSSION & CONCLUSION

Looking back on some of the questions the QUIC

working group had about changing H3’s prioritization

system in Section 3.3, we believe we can now answer

most of them.

Firstly, it is indeed a good goal to make sequential

behaviour easier to accomplish. As was shown time

and time again in our results in Section 5, more se-

quential schemes generally outperform more Round-

Robin-alike schemes. As such, we encourage the

working group to adopt ﬁfo as the default fallback be-

haviour, instead of rr.

Secondly, we immediately need to nuance our

previous point in the case of networks with high

packet loss or jitter. There the Round-Robin-alike

schemes might actually outperform the more sequen-

tial schemes when there are many parallel streams,

beneﬁtting fully from QUIC’s HOL-blocking re-

silience (Section 5.2). More experiments on actual

lossy networks with functioning congestion control

are needed however, to conﬁrm this hypothesis.

Thirdly, it is perfectly possible to switch to a sim-

pliﬁed prioritization framework while still fully sup-

porting the web browsing use case and without losing

performance. Schemes such as bucket HTML and ze-

roweight are easy to implement performantly, do not

require placeholders and seem to provide good base-

line performance for most sites.

Yet, we have a problem with the “most” in the

previous sentence. As our results and case studies

have also clearly shown, no single scheme performs

well for all types of web pages. This is a conclusion

we and related work keep repeating: it is almost im-

possible to come up with a perfect general purpose

scheme. This is why some systems (e.g., (Netravali

et al., 2016)) aim to automatically determine the ex-

act optimal scheme and why efforts such as “Prior-

ity Hints”

give developers options to manually indi-

cate resource priorities. However, we feel both these

complex automated systems and manual intervention

approaches require a lot of effort and do not scale

well. In summary, we want to get better performance

for individual web pages than default heuristics can

provide, but are unwilling to pay high automation or

manual labor costs.

So, Fourthly, we propose a different way forward.

We suggest that all H3 clients should ideally imple-

ment and support several more than one prioritization

scheme at the same time. Developers can then use

a low-overhead, easily automated “optimal scheme

ﬁnder” test to ﬁnd the scheme that performs best for

their speciﬁc page. They simply need to load their

page a few times per scheme using any compliant

H3 client. The optimal scheme(s) can then be stored

server-side and communicated to new clients during

their H3 connection setup. While the chosen sched-

uler might be less optimal than what a more advanced

system could provide, it should perform better than

general purpose heuristics, treading an attractive mid-

dle ground. Additionally, this approach is still com-

plementary to manual interventions such as priority

hints. The ideal combination with a good default

client-side scheme (such as bucket HTML) ensures

that even web servers that do not specify a preferred

scheme fall back to decent behaviour. This option

would require the working group to provide guidance

as to which schemes clients should support and how

to best tweak heuristics to them.

github.com/WICG/priority-hints

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

142

Finally, note that if we indeed want clients to sup-

port a wide array of schemes, this will probably only

be possible using a ﬂexible underlying system, such

as the dependency tree setup. The high ﬂexibility

is probably well worth the added complexity in the

long run. Additionally, as most H2 implementations

already support this more ﬂexible base framework,

our proposed approach of multiple schemes per client

could be recommended and implemented for existing

H2 stacks as well. Note that this proposal does limit

the options for the combination of client and server-

side prioritization. As discussed in Section 3.3, in

such a ﬂexible system it is difﬁcult to infer the client’s

semantics, especially if it is now choosing between

multiple schemes. However, we feel that this is an in-

herent problem of how we communicate priority in-

formation from the client to the server at the moment.

To make proper client and server-side combinations

possible, the client would need to send additional

metadata (e.g., if a resource is critical, render/parser-

blocking, can be processed incrementally, etc. (Sec-

tion 2.1)), rather than/next to building a dependency

tree directly. As this is a heavy departure from H2,

this approach is unlikely to make it into H3, but it

is worth further investigation. For now, we remark

that server-side directives can also be communicated

to the client, allowing it to apply them properly at

client-side while building the tree, as opposed to the

server changing the tree. This is the route taken by

the aforementioned Priority Hints proposal, and ﬁts

nicely with our proposal of having the server send the

client its preferred scheme.

As our general conclusion, we recommend to the

QUIC working group to remain with the existing H2

dependency tree system and to possibly even extend

it with new capabilities. The provided ﬂexibility is,

in our opinion, well worth the additional implementa-

tion complexity. Future work can assess QUIC’s ac-

tual HOL-blocking resilience on lossy networks, look

at the dynamics of cross-connection or multipath pri-

oritization, discuss new forms of PRIORITY meta-

data from client to server and implement a proof-of-

concept of the proposed ‘optimal scheme ﬁnder’.

ACKNOWLEDGEMENTS

Robin Marx is a SB PhD fellow at FWO, Research

Foundation Flanders, #1S02717N.

REFERENCES

Bocchi, E., De Cicco, L., and Rossi, D. (2016). Measur-

ing the quality of experience of web users. In Pro-

ceedings of the 2016 Workshop on QoE-based Anal-

ysis of Data Communication Networks, Internet-QoE

’16, pages 37–42. ACM.

Davies, A. and Meenan, P. (2018). HTTP/2 priorities test

page. Online, https://github.com/andydavies/http2-

prioritization-issues.

Goel, U., Steiner, M., Wittie, M. P., Ludin, S., and Flack,

M. (2017). Domain-sharding for faster http/2 in lossy

cellular networks. arXiv preprint arXiv:1707.05836.

Langley, A. e. a. (2017). The quic transport protocol: De-

sign and internet-scale deployment. In Proceedings

of the Conference of the ACM Special Interest Group

on Data Communication, SIGCOMM ’17, pages 183–

196. ACM.

Netravali, R., Goyal, A., Mickens, J., and Balakrishnan,

H. (2016). Polaris: Faster Page Loads Using Fine-

grained Dependency Tracking. In Proceedings of the

13th USENIX Conference on Networked Systems De-

sign and Implementation, NSDI’16, pages 123–136.

Patrick Meenan (2018). Optimizing HTTP/2 prioritiza-

tion with BBR and tcp notsent lowat. Online, https://

blog.cloudﬂare.com/http-2-prioritization-with-nginx.

Patrick Meenan (2019a). HTTP/2 priorities test

page. Online, https://blog.cloudﬂare.com/better-http-

2-prioritization-for-a-faster-web.

Patrick Meenan (2019b). HTTP/3 prioritization pro-

posal. Online, https://github.com/pmeenan/http3-

prioritization-proposal.

RFC7540 (2015). HTTP/2. Online, https://tools.ietf.org/

html/rfc7540.

Robin Marx, Tom De Decker (2019). Quicker: TypeScript

QUIC and HTTP/3 implementation. Online, https://

github.com/rmarx/quicker.

Ruamviboonsuk, V., Netravali, R., Uluyol, M., and Mad-

hyastha, H. V. (2017). Vroom: Accelerating the mo-

bile web with server-aided dependency resolution. In

Proc. of the ACM SIG on Data Communication, pages

390–403. ACM.

SPDY (2014). SPDY Protocol. Online, https://

www.chromium.org/spdy/spdy-protocol.

Wang, X. S., Balasubramanian, A., Krishnamurthy, A., and

Wetherall, D. (2013). Demystifying Page Load Per-

formance with WProf. In Proceedings of the USENIX

Conference on Networked Systems Design and Imple-

mentation, NSDI’13, pages 473–486.

Wang, X. S., Krishnamurthy, A., and Wetherall, D. (2016).

Speeding Up Web Page Loads with Shandian. In

Proc. of the 13th USENIX Conference on Networked

Systems Design and Implementation, NSDI’16, pages

109–122.

Wijnants, M., Marx, R., Quax, P., and Lamotte, W. (2018).

Http/2 prioritization and its impact on web perfor-

mance. In Proceedings of the 2018 World Wide Web

Conference, WWW ’18, pages 1755–1764. ACM.

Of the Utmost Importance: Resource Prioritization in HTTP/3 over QUIC

143
