A Framework for Context-dependent User Interface Adaptation

Stephan K

olker

, Felix Schwinger

1,2

and Karl-Heinz Krempels

1,2

Information Systems, RWTH Aachen University, Aachen, Germany

Fraunhofer Institute for Applied Information Technology FIT, Aachen, Germany

Keywords:

Context, Context-aware Applications, User Interface, Human-computer Interaction, Adaptation.

Abstract:

Mobile information systems are operated in a large variety of different contexts – especially during intermodal

journeys. Every context has a distinct set of properties, so the suitability of user interfaces differs in various

contexts. But currently, the representation of information on user interfaces is hard-coded. Therefore, we

propose a dynamic adaptation of user interfaces to the context of use to increase the value of an information

system to the user. The proposed system focuses on travel information systems but is designed in a way that

it is generalizable to other application domains. The adaptation system works as an independent service that

acts as a broker in the communication between an application and the user. This service transforms messages

between a user- and a system-oriented representation. The context of use, the device conﬁguration, and user

preferences affect the calculated user-oriented representation.

1 MOTIVATION AND

INTRODUCTION

In recent years, powerful and ﬂexible, yet small and

handy mobile information systems have been devel-

oped and became widely available to the public. They

do not only provide useful information, but also en-

tertainment and means of communication with other

people. Due to their high portability and usefulness,

such information systems are used in a diverse set of

environments, such as at home, at the working place

or during traveling.

A context is a collection of information on the

situation of an entity. This includes information on the

entity itself, its physical and social environment and

all other entities with an inﬂuence on it. An entity can

be a human, an object or a place (Dey, 2001; Strang

and Linnhoff-Popien, 2003).

Most contemporary mobile devices are equipped

with a multitude of different sensors, such as ac-

celerometers, cameras or light sensors. The data col-

lected from those sensors give information systems

access to a wide range of information on the current

context of use (Johnson and Trivedi, 2011).

In this paper, we especially examined the mobility

aspect of potential users, as a variety of different con-

texts can occur during a journey (H

orold et al., 2013).

Each context has different properties and makes differ-

ent demands on the human-computer interaction (Kol-

ski et al., 2011). For example, when carrying luggage

with both hands, tactile interaction with an informa-

tion system is inconvenient because both hands are

already occupied. In this situation, the user has to stop

walking and put down the luggage to be able to input

information into an information system. Likewise, the

use of graphical user interfaces (GUIs) while driving

a car or walking is dangerous. The interaction with a

GUI usually distracts the vision of the user. The con-

sequence is a highly increased crash potential (Smith,

2014).

The user interface (UI) of most information sys-

tems is hard-coded in the form of GUIs that are con-

trolled over tactile communication means (Edwards

and Mynatt, 1994). However, as illustrated in the

examples above, this hard-coding of UIs results in re-

stricted access of the user to the information system in

certain situations.

To provide the optimal human-computer interac-

tion in each context of use, the user interface must

automatically adapt to the current context of use using

the available communication resources. Hence, each

message between the user and the system is rendered

with the currently most suitable modality on the most

suitable output device. This increases the number of

situations where an information system can be used.

We attempt to sketch a framework for the automatic

adaptation of multimodal user interfaces to the current

context. The remainder of the paper is structured as

418

Kölker, S., Schwinger, F. and Krempels, K.

A Framework for Context-dependent User Interface Adaptation.

DOI: 10.5220/0008487200002366

In Proceedings of the 15th International Conference on Web Information Systems and Technologies (WEBIST 2019), pages 418-425

ISBN: 978-989-758-386-5; ISSN: 2184-3252

follows: Section 2 introduces the current State of the

Art regarding multimodal UIs and adaptation systems.

In Section 3, we present our approach to the problem,

whereas Section 4 concludes the paper with a brief

summary and highlights future work.

2 STATE OF THE ART

Current widely used travel information systems, such

as car navigation systems or Google Maps usually use

hard-coded UIs that are optimized for a speciﬁc con-

text of use. Most commonly, GUIs are used for the pre-

sentation of information to the user and tactile UIs to

receive information (Edwards and Mynatt, 1994). Ad-

ditionally, speech-based interaction is common among

travel information systems to present information to

drivers. The general topic of context-aware computing

is not a recent one, we refer the reader to recent sur-

veys in the area for a more general overview: (Chen

and Kotz, 2000; Jaimes and Sebe, 2007; Dumas et al.,

2009; Hong et al., 2009)

(Mitrevska et al., 2015) present a context-aware

in-car information system that interacts with the user

via speech, gesture and displays. Their system enables

the user to interact with speciﬁc objects in the environ-

ment of the car (e.g., a restaurant) to retrieve further

information about them or to access associated ser-

vices (e.g., reserving a table), but the user interaction

is not dynamically adapted to the current context.

An XML-based language for describing multi-

modal UIs on different levels of abstraction is intro-

duced by (Vanderdonckt et al., 2004). This language

supports the device- and modality-independent devel-

opment of multimodal UIs and provides transforma-

tions between different forms of UIs. An iterative

process for the design of mobile information systems

with multimodal interfaces is proposed by (Lemmel

et al., 2008). The result of the design process is a set

of UIs for different contexts of use designed by UI de-

velopers. The automated synthesis of UIs for different

contexts is not examined in their work.

A system for the automated synthesis of UIs is

proposed by (Falb et al., 2006). They represent the

human-computer interaction by communicative acts

and introduce a meta-model for the description of inter-

actions. The UI is automatically generated for various

possible output devices based on an interaction de-

scription, but does not take the context of use into

account.

Besides car navigation systems and PDAs/smart-

phones, further device classes have been evaluated

with regard to their suitability for travel navigation.

Travel navigation systems on the basis of smartwatches

are proposed by (Pielot et al., 2010), (Zargamy et al.,

2013), and (Samsel et al., 2015). The suitability of

vibration for presenting navigational instructions to

travelers is examined by (Pielot et al., 2012). (Eis

et al., 2017) introduce a travel navigation system with

smart glasses and (Rehman and Cao, 2016) compare

handheld-based navigation with navigation on smart

glasses.

(Baus et al., 2002) present a pedestrian navigation

system that provides the user with context-dependent

information while adapting the presentation of this in-

formation to the capabilities of the employed hardware

and the information needs of the user. A process for

the adaptation of UIs to hardware capabilities and user

preferences is described by (Christoph and Krempels,

2007; Christoph et al., 2010). They represent UIs as a

sequence of elementary interaction objects. Those in-

teraction objects are represented in XML and adapted

via XSLT. The dynamic adaptation of GUIs during

runtime is discussed by (Criado et al., 2010). They

present a meta-model for the description of GUIs that

allows incremental adaptation.

3 APPROACH

In this section, we are introducing our automated user

interface adaptation system. The UI adaptation sys-

tem is designed as an independent service that acts

as a broker in the communication between the user

and an information system. An information system is

the client of this adaptation service. The UI adapta-

tion service is responsible for the context-dependent

generation of a UI, the reception of user inputs and,

optionally, the interpretation of user inputs.

An overview of the system is given in Figure 1. In-

stead of generating a UI, an information system sends

a message to the UI adaptation service. The UI adapta-

tion service calculates a suitable representation for this

message based on the context of use. The service for-

wards this representation to the rendering engine which

renders the UI. The UI adaptation service directly re-

ceives user inputs and extracts useful information from

it. Afterwards, it sends the information to the target

application.

3.1 Service Interfaces

For the context-dependent adaptation of a UI, the UI

adaptation service interacts with a client information

service, a context detection service, and a renderer. In

this section, a representation of data on those interfaces

is proposed.

A Framework for Context-dependent User Interface Adaptation

419

Dialogue manager

Adaptation Service

Data

Client app

Fusion engine

Context manager

update

retrieve

Rendering

document

Raw user

inputs

User Interface

Context Detection Service

Multimodal Fission

World

User

Devices

Figure 1: Overview over the components of the UI adapta-

tion service.

The Information Service Interface.

The human-

computer interaction can be modeled by the Agent

Communication Language (ACL) proposed by the

Foundation for Intelligent Physical Agents (FIPA,

2002a). In the framework of FIPA ACL, each message

between two agents is a communicative act which con-

tains information about the communicants, the content

of the message and the conversation (e. g., interaction

protocol and conversation ID). A conversation is a

sequence of communicative acts. The interaction pro-

tocol restricts the number of those sequences (Odell

et al., 2001). In (FIPA, 2002b), several types of com-

municative acts are proposed, such as:

Inform:

the sender provides the recipient with infor-

mation,

Query:

the sender requests the recipient to perform a

speciﬁc action and to provide the sender with the

result of this action, and

Request:

the sender requests the recipient to perform

a speciﬁc action.

The content of a communicative act can be represented

by an ontology. Established ontology languages are the

Resource Description Framework (RDF) (Cyganiak

et al., 2014) and the Web Ontology Language (OWL)

(Schreiber and Dean, 2004).

Context Interface.

The context manager is the com-

ponent within the UI adaptation service that retrieves

and maintains context models. An external context

detection service provides the context manager with a

description of the current context of use.

A context of use can be described by ontological

models because ontologies provide a formal model

that facilitates knowledge sharing and reuse across

different entities (Strang and Linnhoff-Popien, 2003;

Wang et al., 2004). Ontologies are a tool for the formal

modeling of concepts and their interrelations (Gruber,

1993). A predeﬁned set of inference rules allows to

infer implicit knowledge from an ontology. As a spe-

cialization of logic programs, ontologies can also be

translated into logic programs and extended with logi-

cal rules (Baader, 2010; Wang et al., 2004).

The Renderer Interface.

At the renderer interface,

the UI adaptation service provides a UI renderer with a

description of the ﬁnal UI. The format of this descrip-

tion highly depends on the targeted platform.

3.2 Transformation of Information into

a User-friendly Representation

We formally describe the transformation of informa-

tion from an application into a user-friendly represen-

tation as a function

trans

out

that maps from the input

documents to an output document:

trans

out

: D

× D

CDS

× D

→ D

out

where

denotes the set of documents in the lan-

guage of communicative acts,

CDS

the set of docu-

ments in the language of the context detection service,

the set of documents in the language of the user

preferences,

the set of documents in the language

of the device proﬁle, and

out

the set of documents in

the language that is understood by the renderer. The

function

trans

out

is a composition of the following

functions:

• trans pui : D

→ D

PU I

(transformation from

speech acts to prototypical UIs),

• adapt : D

PU I

× D

CDS

× D

→ D

PU I

(context-dependent adaptation of prototypical user

interfaces), and

• inst ui : D

PU I

→ D

out

(instantiation of the out-

put document),

where

PU I

denotes the set of documents in the lan-

guage of the prototypical user interfaces. A prototypi-

cal UI is a system- and implementation-independent

description of a UI that is subject to adaptation. An

overview over the composition of the functions is given

in Figure 2.

Representation of Prototypical User Interfaces.

In this work, we represent the prototypical user inter-

face as a set of elementary interaction objects (eIOs),

as introduced by (Christoph and Krempels, 2007). El-

ementary interaction objects are non-decomposable

objects that enable a user to interact with a system.

To be applicable to the problem at hand, we extend

the deﬁnition of eIOs by (Christoph and Krempels,

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

420

Information

Service

Context

Service

User

proﬁle

Device

proﬁle

trans pui

adapt

inst ui

description

PU I

out

CDS

Figure 2: Overview of the transformation function

trans

out

and its components.

2007). In this extended deﬁnition, an eIO has the

following properties:

•

Type of the interaction object, one of the following:

–

Single select: selection of one single element

from a given list

–

Multiple select: selection of multiple elements

from a given list

– Input: input of information into the system

– Inform: output of information to the user

– Action: initiate an action in the system

• Description of the interaction object (optional)

• Content of the object, if needed

•

Content representation (output device, representa-

tion medium, modality

and modality properties

)

• Natural language of the content

• Unique identiﬁer of the element for reference

Transformation of Communicative Acts into Pro-

totypical User Interfaces.

A communicative act is

transformed into an eIO based on the performative, the

identity of the sender and receiver and the associated

interaction protocol. The performatives from (FIPA,

2002b) are classiﬁed into either one of two classes:

informs or requests. Informs are used to inform the

receiver of a message about a given subject without

requesting any speciﬁc action. The purpose of requests

is to invoke a speciﬁc behavior in the receiver of the

message. Feedback about the results of an action can

be part of this behavior. The associated interaction

protocol speciﬁes whether feedback is expected.

e. g., text, image, or speech

e. g., font color, size, or voice

As visualized in Table 1, the eIO types can be ar-

ranged into a two-dimensional space spanned by the

performative class and the direction of the communi-

cation. This arrangement and the above-mentioned

classiﬁcation of performatives together deﬁne a map-

ping from communicative acts to eIOs.

Adaptation of Prototypical User Interfaces.

Sub-

ject to adaptation is the content representation of every

eIO. As shown in Figure 2, the adaptation of the eIO

document is based on the context of use and the user

and device proﬁle information.

To resolve possible ambiguities and contradictions

among the input documents, we deﬁne a hierarchy of

the input documents: In case of a conﬂict between the

device proﬁle and the user proﬁle the system discards

the information from the user proﬁle. The reason for

this is that the device proﬁle deﬁnes the technically

possible means of communication, whereas the user

proﬁle deﬁnes abilities, but also preferences of the

user. The implications from the context of use to the

UI are assigned to the lowest priority because they are

desirable, yet optional properties of the UI.

On a high level, the UI adaptation procedure works

as follows:

Remove all preferences from the user proﬁle that

are in conﬂict with the device proﬁle (this yields

the adjusted user proﬁle)

From the set of all theoretically possible content

representations, determine the set of admissible

content representations R

admissible

Find the best content representation(s)

best

from

admissible

for the current context

according to

an evaluation function eval:

best

= argmax

cr∈R

admissible

eval(C, cr)

Set the properties of all eIOs according to

best

the device proﬁle and the adjusted user proﬁle

The adaptation system determines the set of ad-

missible content representations based on the avail-

able output devices, their interaction capabilities, the

abilities of the user and the message content. The

message content imposes restrictions on the available

modalities (e. g., image data cannot be represented by

vibration).

The evaluation function

eval

assigns a rating to a

context and a content representation.

eval : C × R → R,

where

denotes the set of all possible contexts and

the set of all content representations. A more detailed

A Framework for Context-dependent User Interface Adaptation

421

Table 1: Characterization of eIOs by the direction of the communication and the interaction type.

Direction

System → User User → System

Performative

class

Inform Inform Input, selection

Request (without feedback) Inform Action

Request (with feedback) Inform + inputs and selections Action

Device

PresentationMedium

Modality

ModalityProperty

CommunicationMean

Channel

hasComponent

hasMedium

addressesChannel

hasModality

assignedTo

hasModalityProperty

Figure 3: Communication infrastructure ontology.

description of

eval

is given in Section 3.3. If mul-

tiple content representations have an optimal rating,

the renderer renders the UI using all optimal content

representations concurrently.

Implementation of Content Representation

Search.

For the search of the best content represen-

tations, a compact representation of all admissible

combinations of output devices, modalities and

modality properties is needed. In the following,

we refer to this representation as communication

infrastructure. The communication infrastructure is

modeled by an RDF ontology. Figure 3 shows the

corresponding RDF schema.

A communication infrastructure has a hierarchi-

cal structure: on the ﬁrst levels are available devices.

Every device can usually access several presentation

media. Each presentation medium addresses a spe-

ciﬁc communication channel and has a set of avail-

able modalities. Each modality is assigned to exactly

one communication channel and has a set of possi-

ble modality properties. Due to this structure, a path

from a device to a modality property describes a valid

content representation. Besides, the abstract concept

of communication means with

hasComponent

rela-

tions is included.

CommunicationMean

is as a super-

class of all aforementioned communication means and

hasComponent

is a generalization of all other relations

preﬁxed with “

has

”. This allows for a more generic

deﬁnition of the search algorithm.

The search algorithm is a uniform-cost search on

the RDF graph of the communication infrastructure

(Russell and Norvig, 2018). For the search, only

hasComponent

relations are considered. The search

starts on all nodes with no incoming edge (root nodes).

The cost of an edge is determined by the evaluation

of the target node of the edge in the current context.

The result of the search is the set of all best-rated paths

from one of the root nodes to a leaf node. The rating

for a path is the combination of the ratings of all edges

on that path.

This algorithm is applicable to a wide variety of

different device conﬁgurations because it relies on a

generic graph structure for the representation of the

communication infrastructure. Consequently, this al-

gorithm is well-adapted to use cases with automated

recognition of connected devices and easily customiz-

able preferences.

Instantiation of the User Interface.

The instantia-

tion of the UI is highly platform-speciﬁc. Each mo-

bile device platform provides a unique UI description

language (Thornsby, 2016; D’areglia, 2018). Com-

mon to all platforms is the possibility to write ap-

plications with HTML, CSS and JavaScript, e. g.,

through Progressive Web Apps (Ater, 2017) or frame-

works (Wargo, 2012). To support a broad range of plat-

forms, it is sensible to use HTML, CSS and JavaScript

for the deﬁnition of the ﬁnal UI. It is possible to deﬁne

a mapping from graphical eIOs to HTML and CSS

and from auditive and tactile eIOs to JavaScript code

snippets.

3.3 Suitability of User Interfaces in

Contexts

The evaluation function

eval

(cf. Section 3.2) deter-

mines the suitability of a UI in a given context. In this

section, we propose an implementation for the evalua-

tion function. This implementation is targeted towards

journey contexts.

Classiﬁcation of Journey Contexts.

Instead of clas-

sifying journey contexts into distinct context classes,

such as in (H

orold et al., 2013), journey contexts are

identiﬁed by partial context descriptions because many

context aspects have to be considered in the evaluation.

A partial context description is an expression that de-

scribes parts of a context. Partial context descriptions

identify the class of all contexts that match the descrip-

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

422

tion and allow for very ﬁne-grained context classes.

For example, the partial context description “rainy and

crowded” refers to the class of all contexts with rainy

weather and a crowded environment. A partial context

description can be implemented as a query in predicate

logic.

Representation of an Rating.

A rating can be rep-

resented by a real value

r ∈ [0, 1] ⊂ R

, where

r = 1

stands for “suitable” and

r = 0

for “unsuitable”. The

combination function

⊕

should meet the following

requirements:

• ([0, 1], ⊕)

is a monoid with “suitable” (i.e., 1) as

identity element.

• ⊕

is monotonically increasing, i.e., if

, r

) ≤

, r

), then r

⊕r

≤ r

⊕r

•

The result of the combination of two ratings sat-

isﬁes the rating semantics, i.e.,

⊕r

= 1

means

“suitable” and r

⊕r

= 0 means “unsuitable”.

•

The result of a combination with “unsuitable” is

always “unsuitable”, i.e., r ⊕0 = 0.

The multiplication function meets these requirements

for the chosen value range. Consequently, the combi-

nation of two ratings

and

is their multiplication

· r

Mapping from Contexts to User Interfaces.

content representation is a combination of multiple

communication means. Due to the large variety of

possible content representations, the assignment of a

suitability value to each single content representation

is hard. Let a context

be represented as a set of

all possible partial context descriptions that hold in

Then, the evaluation function can be represented as

eval(C, cr) =

c∈C

cm∈cr

eval

(c, cm),

where

eval

is the evaluation of a single communica-

tion mean in a context.

The value of

eval

(c, cm)

is retrieved from lookup

tables. These lookup tables contain suitability eval-

uations of communication means assigned to partial

context descriptions. Due to the high number of possi-

ble partial context descriptions

and the fact that most

communication means are suitable in most contexts,

the lookup table does not need to contain all possible

evaluations. Instead, a default value is introduced and

only those values are given that deviate from this de-

fault value. This default value is the identity element

of ([0, 1] , ⊕), i. e., “suitable” or 1.

For example, the following subset of the set of all

partial context descriptions is already uncountably inﬁnite:

{temperature = x | x ∈ R}.

3.4 Transformation of Information

from the User

The proposed UI adaptation service is able to receive

information from the user on any available input chan-

nel. This enables the user to freely choose the most

suitable input channel. This decision is based on the

assumption that the user knows best which communi-

cation channel is the most suitable one in the current

context.

In general, two basic modes of human-computer

interaction from the perspective of the user can be

distinguished:

Proactive Communication:

the user initiates a com-

munication with the information service.

Reactive Communication:

the user responds to a

previous action of the information service accord-

ing to an interaction protocol.

To support proactive communication, the client infor-

mation service has to provide the adaptation service

with a set of functions for the current application mode.

For reactive communication, the adaptation service has

to augment the prototypical UI with additional interac-

tion objects for user input during the adaptation.

Processing User Input.

The user input is ﬁrst reg-

istered at the UI. Inputs are either GUI events or raw

data (e. g., audio or video data). These inputs are for-

warded to the UI adaptation service. If the input data

type matches the expected data type in the interaction

protocol of the conversation, the data is directly for-

warded to the client. Otherwise, the adaptation service

interprets the input data. An interpretation, for ex-

ample, can be the translation of spoken speech into a

textual representation, or the mapping of a touch event

to an intent. The necessary interpretation procedure is

determined based on the input and output data types

of predeﬁned interpretation procedures.

Multimodal systems employ a fusion engine for the

coordination of multiple incoming data streams (Du-

mas et al., 2009). The proposed UI adaptation ser-

vice supports concurrent multimodality (Nigay and

Coutaz, 1993), so such coordination is not necessary

here. Here, the task of the fusion engine is to link

the incoming messages from the user to conversations.

This linkage is possible by keeping track of which

interaction object corresponds to which conversation.

At last, a communicative act is generated and sent

to the client information service. The ﬁelds conver-

sation id, sender and receiver are ﬁlled with the ap-

propriate information and the raw or interpreted input

data is added as the content of the communicative act.

A Framework for Context-dependent User Interface Adaptation

423

3.5 Dialogue Manager

The dialogue manager provides and manages informa-

tion about conversations (Dumas et al., 2009). This

includes the communication history, the states of all

conversations and the interaction protocols. Further-

more, the dialogue manager validates communicative

acts in the context of a conversation and determines

the expected type of data of a communicative act cor-

responding to an interaction protocol.

4 CONCLUSION AND FUTURE

WORK

In this work, we proposed a context-dependent UI

adaptation system. This system is a service that trans-

forms messages between a system- and a user-oriented

representation depending on the context of use.

Messages between an application and the adapta-

tion service are represented as communicative acts and

translated into a prototypical UI. Elementary interac-

tion objects (eIOs) describe prototypical UIs, whereas

an ontology models the context of use. The content

representation of the eIOs is adapted to the context of

use via a uniform-cost search on a communication in-

frastructure graph and an evaluation function. Finally,

the prototypical UI is transcribed into a document that

can be rendered and presented to the user by the tar-

geted rendering engine. Messages from a user are

received by the adaptation service, processed in the

context of the associated conversation and forwarded

to the client application as communicative acts.

In future work, suitable evaluation functions for

speciﬁc domains should be deﬁned, a functional pro-

totype of the system should be implemented and the

system should be tested in real-life environments with

potential users, including developers and end-users of

the UI. The system and the evaluation function should

then be reﬁned based on user feedback and observa-

tions from those tests.

Regarding the introduction of smartwatches, smart

glasses, and smart speakers in the recent past, it is

likely that users will interact with multiple devices on

a regular basis. The proposed system can provide a

framework for the seamless interaction between appli-

cations and users across different devices.

REFERENCES

Ater, T. (2017). Building Progressive Web Apps: Bringing

the Power of Native to the Browser. O’Reilly Media.

Baader, F. (2010). The Description Logic Handbook. Cam-

bridge University Press.

Baus, J., Kr

uger, A., and Wahlster, W. (2002). A resource-

adaptive mobile navigation system. In Proceedings of

the 7th International Conference on Intelligent User

Interfaces, IUI ’02, pages 15–22, New York, NY, USA.

ACM.

Chen, G. and Kotz, D. (2000). A survey of context-aware mo-

bile computing research. Technical report, Department

of Computer Science, Dartmouth College, Hanover,

NH, USA.

Christoph, U. and Krempels, K.-H. (2007). Automatisierte

Integration von Informationsdiensten. PIK - Praxis

der Informationsverarbeitung und Kommunikation,

30(2):112–120.

Christoph, U., Krempels, K.-H., von Stulpnagel, J., and

Terwelp, C. (2010). Automatic context detection of a

mobile user. Proceedings of the International Confer-

ence on Wireless Information Networks and Systems

(WINSYS), 2010, pages 1–6.

Criado, J., Vicente Chicote, C., Iribarne, L., and Padilla, N.

(2010). A model-driven approach to graphical user

interface runtime adaptation. CEUR Workshop Pro-

ceedings, 641.

Cyganiak, R., Wood, D., and Lanthaler, M. (2014). Rdf 1.1

concepts and abstract syntax. Technical report, World

Wide Web Consortium (W3C). Accessed on January

03rd, 2019 at http://www.w3.org/TR/2014/REC-rdf11-

concepts-20140225/.

D’areglia, Y. (2018). Learning iOS UI Development. Packt

Publishing.

Dey, A. K. (2001). Understanding and using context. Per-

sonal and Ubiquitous Computing, 5(1):4–7.

Dumas, B., Lalanne, D., and Oviatt, S. (2009). Multimodal

interfaces: A survey of principles, models and frame-

works. In Lecture Notes in Computer Science, pages

3–26. Springer Berlin Heidelberg.

Edwards, W. K. and Mynatt, E. D. (1994). An architecture

for transforming graphical interfaces. In Proceedings

of the 7th annual ACM symposium on User interface

software and technology - UIST '94. ACM Press.

Eis, A., Klose, E. M., Hegenberg, J., and Schmidt, L. (2017).

Szenariobasierter prototyp f

ur ein reiseassistenzsystem

mit datenbrillen. In Burghardt, M., Wimmer, R., Wolff,

C., and Womser-Hacker, C., editors, Mensch und Com-

puter 2017 – Tagungsband, volume 17, pages 203–214,

Regensburg, Germany. Gesellschaft f

ur Informatik e.V.,

Gesellschaft f

ur Informatik e.V.

Falb, J., Rock, T., and Arnautovic, E. (2006). Using com-

municative acts in interaction design speciﬁcations

for automated synthesis of user interfaces. In 21st

IEEE/ACM International Conference on Automated

Software Engineering (ASE 2006). IEEE.

FIPA (2002a). FIPA ACL Message Structure Speciﬁcation.

Technical Report SC00061G, Foundation for Intelli-

gent Physical Agents (FIPA), Geneva, Switzerland.

FIPA (2002b). FIPA Communicative Act Library Speciﬁ-

cation. Technical Report SC00037J, Foundation for

Intelligent Physical Agents (FIPA), Geneva, Switzer-

land.

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

424

Gruber, T. R. (1993). A translation approach to portable

ontology speciﬁcations. Knowledge Acquisition,

5(2):199–220.

Hong, J., Suh, E., and Kim, S. (2009). Context-aware sys-

tems: A literature review and classiﬁcation. Expert

Systems with Applications, 36(4):8509–8522.

orold, S., Mayas, C., and Kr

omker, H. (2013). Analyz-

ing varying environmental contexts in public transport.

In Kurosu, M., editor, Human-Computer Interaction.

Human-Centred Design Approaches, Methods, Tools,

and Environments, pages 85–94, Berlin, Heidelberg.

Springer Berlin Heidelberg.

Jaimes, A. and Sebe, N. (2007). Multimodal hu-

man–computer interaction: A survey. Computer Vision

and Image Understanding, 108(1-2):116–134.

Johnson, D. A. and Trivedi, M. M. (2011). Driving style

recognition using a smartphone as a sensor platform.

In 2011 14th International IEEE Conference on Intelli-

gent Transportation Systems (ITSC), pages 1609–1615.

Kolski, C., Uster, G., Robert, J.-M., Oliveira, K., and David,

B. (2011). Interaction in mobility: The evaluation of

interactive systems used by travellers in transportation

contexts. In Human-Computer Interaction. Towards

Mobile and Intelligent Interaction Environments, pages

301–310. Springer Berlin Heidelberg.

Lemmel

a, S., Vetek, A., M

akel

a, K., and Trendaﬁlov, D.

(2008). Designing and evaluating multimodal interac-

tion for mobile contexts. In Proceedings of the 10th

international conference on Multimodal interfaces -

IMCI '08. ACM Press.

Mitrevska, M., Moniri, M. M., Nesselrath, R., Schwartz, T.,

Feld, M., Korber, Y., Deru, M., and Muller, C. (2015).

SiAM - situation-adaptive multimodal interaction for

innovative mobility concepts of the future. In 2015

International Conference on Intelligent Environments.

IEEE.

Nigay, L. and Coutaz, J. (1993). A design space for multi-

modal systems. In Proceedings of the SIGCHI confer-

ence on Human factors in computing systems - CHI

93,

pages 172–178, Amsterdam, The Netherlands. ACM

Press.

Odell, J., Parunak, H. V. D., and Bauer, B. (2001). Represent-

ing agent interaction protocols in uml. In Ciancarini, P.

and Wooldridge, M., editors, Agent-Oriented Software

Engineering, pages 121—140. Springer.

Pielot, M., Poppinga, B., Heuten, W., and Boll, S. (2012).

PocketNavigator: Studying tactile navigation systems

in-situ. In Proceedings of the SIGCHI Conference on

Human Factors in Computing Systems, CHI ’12, pages

3131–3140, New York, NY, USA. ACM.

Pielot, M., Poppinga, B., Vester, B., Kazakova, A., Brammer,

L., and Boll, S. (2010). Natch: A watch-like display

for less distracting pedestrian navigation. In Ziegler, J.

and Schmidt, A., editors, Mensch & Computer 2010:

Interaktive Kulturen, pages 291–300, M

unchen. Olden-

bourg Verlag.

Rehman, U. and Cao, S. (2016). Augmented-reality-based

indoor navigation: A comparative analysis of handheld

devices versus google glass. In IEEE Transactions on

Human-Machine Systems, volume 47, page 1–12. Insti-

tute of Electrical and Electronics Engineers (IEEE).

Russell, S. and Norvig, P. (2018). Artiﬁcial Intelligence: A

Modern Approach, Global Edition. Addison Wesley.

Samsel, C., Dudschenko, I., Kluth, W., and Krempels, K.-H.

(2015). Using wearables for travel assistance. Pro-

ceedings of the 11th International Conference on Web

Information Systems and Technologies.

Schreiber, G. and Dean, M. (2004). OWL web ontology

language reference. https://www.w3.org/TR/owl-ref/.

Accessed on November 6th, 2018.

Smith, A. (2014). More than half of cell owners affected by

’distracted walking’. http://www.pewresearch.org/fact-

tank/2014/01/02/more-than-half-of-cell-owners-

affected-by-distracted-walking/. Accessed on

15.09.2018.

Strang, T. and Linnhoff-Popien, C. (2003). Service interop-

erability on context level in ubiquitous computing en-

vironments. In International Conference on Advances

in Infrastructure for Electronic Business, Education,

Science, Medicine, and Mobile Technologies on the

Internet.

Thornsby, J. (2016). Android UI Design. O’Reilly Media.

Vanderdonckt, J., Limbourg, Q., Michotte, B., Bouillon, L.,

Trevisan, D. Q., and Florins, M. (2004). USIXML:

a user interface description language for specifying

multimodal user interfaces. In Proceedings of W3C

Workshop on Multimodal Interaction WMI.

Wang, X. H., Zhang, D. Q., Gu, T., and Pung, H. K. (2004).

Ontology based context modeling and reasoning using

OWL. In IEEE Annual Conference on Pervasive Com-

puting and Communications Workshops, 2004. Pro-

ceedings of the Second. IEEE.

Wargo, J. M. (2012). PhoneGap Essentials: Building Cross-

platform Mobile Apps. Addison-Wesley Professional.

Zargamy, A., Sakai, H., Ganh

or, R., and Oberwandling,

G. (2013). Fußg

angernavigation im urbanen Raum -

Designvorschlag. In Boll, S., Maaß, S., and Malaka, R.,

editors, Mensch & Computer 2013: Interaktive Vielfalt,

pages 365–368, Munich, Germany. Oldenbourg Verlag.

A Framework for Context-dependent User Interface Adaptation

425
