Revisiting Higher-order Computational Attacks against White-box

Implementations

Houssem Maghrebi and Davide Alessio

UL Identity Management & Security, France

Keywords:

White-box Cryptography, Masking, Higher-order Computational Attacks, Leakage Detection, AES.

Abstract:

White-box cryptography was ﬁrst introduced by Chow et al. in 2002 as a software technique for implementing

cryptographic algorithms in a secure way that protects secret keys in an untrusted environment. Ever since,

Chow et al.’s design has been subject to the well-known Differential Computation Analysis (DCA). To resist

DCA, a natural approach that white-box designers investigated is to apply the common side-channel counter-

measures such as masking. In this paper, we suggest applying the well-studied leakage detection methods to

assess the security of masked white-box implementations. Then, we extend some well-known side-channel

attacks (i.e. the bucketing computation analysis, the mutual information analysis, and the collision attack) to

the higher-order case to defeat higher-order masked white-box implementations. To illustrate the effectiveness

of these attacks, we perform a practical evaluation against a ﬁrst-order masked white-box implementation.

The obtained results have demonstrated the practicability of these attacks in a real-world scenario.

1 INTRODUCTION

1.1 White-box Implementations and

Computational Attacks

In 2002, Chow et al. introduced the ﬁrst white-

box implementations of AES and DES block ci-

phers (Chow et al., 2003a; Chow et al., 2003b). The

main idea behind was to embed the secret key in

the implementation using a network of precomputed

Look-Up Tables (LUTs) composed with some linear

and non-linear random encodings to protect the inter-

mediate states between the LUTs. The knowledge of

one or all of these LUTs shall not give any informa-

tion about the embedded secret key. To implement

this design, two types of encodings shall be consid-

ered:

• Internal Encodings: are non-linear bijections ap-

plied to the input and/or the output of each LUT

to hide its entries and/or its outputs. This cate-

gory encompasses the so-called mixing bijections

which are linear transformation applied to the in-

put and output of each LUT to add more confu-

sion to the implementation and ensure the crypto-

graphic diffusion property.

• External Encodings: are bijective mappings ap-

plied to decode the plaintext from the sending pro-

cess and to encode the resulting ciphertext to the

receiving process.

To defeat white-box implementations, Bos et al.

proposed in (Bos et al., 2016) the Differential Com-

putational Analysis (DCA). This attack is the soft-

ware adaptation of the well-known Differential Power

Analysis (DPA) (Kocher et al., 1999). Speciﬁcally,

the idea of the DCA consists in monitoring the mem-

ory addresses (as well as the stack, the CPU instruc-

tions, . . . ) accessed during the encryption process and

recording them in the so-called computation traces

(aka software execution traces). Then, a statistical

analysis is performed to compute the correlation be-

tween a prediction of the targeted sensitive variable

(that depends on a key guess) and each sample of the

collected computation traces. The secret key corre-

sponds to the key guess for which the highest correla-

tion peak is obtained.

Since the publication of the DCA, several re-

searchers have investigated the adaptation of either

the well-studied side-channel attacks (Rivain and

Wang, 2019) or the algebraic cryptanalysis tech-

niques (Zeyad et al., 2019) to perform computational

attacks in the white-box context. For instance, au-

thors in (Rivain and Wang, 2019) proposed a soft-

ware version of the collision attack and the Mutual

Information Analysis (MIA). The experimental re-

sults performed on several publicly available white-

Maghrebi, H. and Alessio, D.

Revisiting Higher-order Computational Attacks against White-box Implementations.

DOI: 10.5220/0008874602650272

In Proceedings of the 6th International Conference on Information Systems Security and Privacy (ICISSP 2020), pages 265-272

ISBN: 978-989-758-399-5; ISSN: 2184-4356

265

box AES implementations have shown signiﬁcant im-

provements in terms of trace complexity compared to

the DCA. Recently, Zeyad et al. have suggested the

Bucketing Computation Analysis (BCA) in (Zeyad

et al., 2019). This attack is inherently inspired by

a cryptanalysis technique named statistical bucketing

attack. The authors have demonstrated that this attack

is very efﬁcient to defeat some sophisticated white-

box AES implementations (e.g. the WhibOx 2016

contest) with a ﬁxed amount of traces (precisely 1024

traces to break a white-box AES implementation).

1.2 Masking and Higher-order

Computational Attacks

Obviously, the well-studied side-channel countermea-

sures can be adapted and applied to protect white-

box implementations. One common countermeasure

is to apply masking which consists in sharing the

intermediate variable into several mutually indepen-

dent shares. In (Bogdanov et al., 2019), Bogdanov et

al. investigated the approach of applying higher-order

masking to resist DCA. Furthermore, the authors in-

troduced, for the ﬁrst time, the extension of the DCA

to the higher-order case and analyzed the security of

the masking countermeasure against these attacks in

the context of white-box implementation.

1.3 Our Contributions

Following the investigations done in (Bogdanov et al.,

2019), we propose in this work:

• A Second-order BCA: We extend in Sec. 3 the

BCA to the second-order. Then, we demonstrate

how this attack can defeat an internally encoded

masked white-box implementation with exactly

the same low trace complexity as for the ﬁrst-

order version studied in (Zeyad et al., 2019).

• A Higher-order MIA: We suggest in Sec. 4

two fashions of applying higher-order MIA in the

context of white-box implementation. Both ap-

proaches are compared through practical experi-

ments in terms of key-recovery efﬁciency and per-

formance.

• A Higher-order Collision Attack: We study in

Sec. 5 the higher-order version of collision attacks

to defeat masked implementations. Then, we pro-

vide in Sec. 6 a comparison of the efﬁciency of

the proposed attacks.

All our analyses are validated through practical

experiments on the same ﬁrst-order masked white-

box AES implementation. Furthermore, we made the

computation traces collected on this reference imple-

mentation publicly available (SM, 2019). The goal

is twofold: (1) to ease the reproduction of our re-

sults by the white-box community and (2) to provide

a commonly masked database (as no such traces from

a masked implementation are available so far). In ad-

dition, the source code of some of our proposed at-

tacks is publicly available as well.

2 PRELIMINARIES AND STUDY

FRAMEWORK

2.1 Notations and Deﬁnitions

Along this paper, we use the following notations. The

bold block capitals X denote matrices. The i

column

vector of a matrix X is denoted by X[i]. The random

variables are denoted by uppercase Latin letters, like

X, while the lowercase letter x denotes a particular

realization of X. The entropy H[X] of a random vari-

able X aims at measuring the amount of information

provided by an observation of X.

The intersection of two sets of values A and B is

denoted by A ∩ B and is deﬁned as A ∩ B = {x | x ∈

A and x ∈ B}. Two sets are disjoint if they have no

elements in common, that is, A and B are disjoint if

A ∩ B =

To perform his attack, the adversary targets an in-

termediate sensitive variable which is a function of a

plaintext x and a guessable secret key k

∗

. Then, for

each key guess k, he computes a prediction of the

target sensitive variable denoted φ(x, k) (or φ(k) for

short) and measures the dependency between this pre-

diction and the acquired traces. For our practical ex-

periments, we target the Sbox output of the ﬁrst round

of an AES, i.e. φ(x, k) = Sbox(x ⊕ k).

2.2 Assumptions

The analyses and conclusions drawn in this work are

done under the three following assumptions:

Assumption 1 (Nibble-encoded Naked White-box

Implementations). The targeted white-box imple-

mentations are nibble-encoded using an internal en-

coding. No external encoding is applied.

Remark 1. Nibble-encoding is the most common en-

coding size used for white-box AES implementations.

We stress the fact that Assumption 1 is mandatory (ac-

cording to (Zeyad et al., 2019)) for the study of the

BCA described in Sec. 3. However, for the other in-

vestigated attack techniques in this work this assump-

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

266

tion can be relaxed (i.e. the results can be generalized

to any encoding size).

Assumption 2 (Similarity Encoding). The most sig-

niﬁcant (respectively the least signiﬁcant) nibbles of

the masks used to protect the sensitive variable are

encoded with exactly the same encoding function ap-

plied on the most signiﬁcant (respectively the least

signiﬁcant) nibbles of the masked sensitive variable.

Remark 2. To the best of our knowledge, no masked

white-box implementation is publicly available yet.

We stress the fact that the publicly available Lee’s

CASE 1 implementation (Lee, 2018) partially involves

masking techniques to only protect the ﬁrst and last

round of the implementation. Therefore, this im-

plementation was broken when applying ﬁrst-order

DCA and BCA (Rivain and Wang, 2019; Zeyad et al.,

2019)

. To apply masking to protect a full white-

box implementation, several options could be inves-

tigated on how to internally encode the intermediate

masked data and mask values. From our point of view,

the most natural and straightforward way is to use

the same encoding functions to protect these sensi-

tive variables. Indeed, in (Lee et al., 2018) Lee et al.

have followed the same strategy to apply their par-

tial masking and they have justiﬁed their choice by

the fact that it makes the unmasking operation easier.

At the end, Assumption 2 is motivated by (1) the lack

of reference masked implementations and (2) the fact

that this encoding strategy is realistic (due to its sim-

plicity). We keep the study of other encoding strate-

gies in a masked context as a future work.

Assumption 3 (Perfect Synchronization). The tar-

geted white-box implementations are only protected

with higher-order masking. No shufﬂing or any ran-

dom delays is introduced to de-synchronize the ac-

quired computation traces.

2.3 Targeted White-box

Implementation

As introduced earlier, we study in this work the ex-

tension of some well-known side-channel attacks to

the higher-order case when applied on masked white-

box implementations. When a d

-order masking is

applied, each sensitive variable Z is split into d + 1

shares s

, s

, . . . , s

such that s

⊕ s

⊕ ··· ⊕ s

= Z.

Usually, the d shares s

, . . . , s

(called the masks) are

randomly picked up and the last one s

(called the

masked variable) is processed such that it satisﬁes the

previous equality. Under assumption 3, we only focus

This implementation is not considered in this work for

the aforementioned reasons.

on higher-order masking as a unique countermeasure

applied to ensure protection.

For our experimental validation, we restrict the as-

sessment of our proposed higher-order attacks against

ﬁrst-order masked white-box AES implementations.

That is, we only evaluated the second-order versions.

To do so, we implement a ﬁrst-order masked white-

box AES implementation under the three assumptions

formulated in Sec. 2.2. This implementation is based

on the classical Chow et al.’s white-box design rely-

ing on an internal encoding but with the major dif-

ference that every Tbox input and output is protected

with an independent random mask. So, masking is

applied on the whole implementation and all rounds.

Moreover, our implementation is based on the well-

known Global Look Up table (GLUT) method (Prouff

and Rivain, 2007; Maghrebi et al., 2012). That is,

the concatenation of the encoded masked data and the

encoded mask is provided as an input to the masked

Tboxes. The resulting size of our reference imple-

mentation is 41, 5 Megabytes.

Then, we collect the computation traces using an

internal tool that monitors the read memory access

during the execution of this ﬁrst-order masked im-

plementation. Each collected value during the acqui-

sition phase is decomposed into several nibbles and

then stored in the computation trace (Assumption 1).

The collected traces are publicly available in (SM,

2019) to ease the reproducibility of our results. This

trace database will serve as a reference for evaluating

our proposed attacks in practice.

3 BUCKETING COMPUTATION

ANALYSIS

3.1 Background

In (Zeyad et al., 2019), Zeyad et al. introduced a new

computational attack called Bucketing Computational

Analysis (BCA) to defeat unprotected white-box im-

plementation. The core idea of BCA is that if two sen-

sitive intermediate variables for two different plain-

texts do not collide, then their encodings (using a de-

terministic bijection) should not collide as well. We

recall in Algorithm 1 the pseudo-code describing the

different steps of the BCA when applied on white-box

AES implementations (Zeyad et al., 2019).

The BCA consists of 3 phases. During the pre-

computation phase, for each key guess k, the attacker

split the 256 plaintexts x (each corresponds to a differ-

ent Sbox input) into two sets (I

0,k

and I

1,k

) according

to the resulting bucketing nibble d = S

(x ⊕ k) =

Revisiting Higher-order Computational Attacks against White-box Implementations

267

Algorithm 1: BCA on white-box AES implementations.

Inputs: a targeted AES Sbox S of the ﬁrst round and

its corresponding S

(s.t. ∀x ∈ GF(2

), S

(x) =

S(x)&0xF)

Output: good guess of the sub-key

∗ ∗ ∗ Pre-computation phase ∗∗ ∗

1: Compute a set I of 256 plaintexts each corre-

sponding to a different input of S

2: Pick two values d

and d

such that: 0 ≤ d

≤ 15

3: for each key guess k ∈ [0, 255] do

4: Split the plaintexts into two sets I

0,k

and I

1,k

w.r.t to the nibble d of S

5: end for

∗ ∗ ∗ Acquisition phase ∗ ∗ ∗

6: Acquire a set of 256 traces T = (t

i, j

)

0≤i≤255

0≤ j≤n

∗ ∗ ∗ Key-recovery phase ∗ ∗ ∗

7: Initialize a result vector R with 256 zeros

8: for each key guess k ∈ [0, 255] do

9: Group the traces into V

and V

w.r.t. to the

sorted plaintexts in I

0,k

and I

1,k

10: for each sample j in the trace do

11: if V

[ j] ∩ V

[ j] =

0 then : R[k] = R[k]+ 1

12: end if

13: end for

14: end for

15: The good sub-key guess corresponds to k ∈

[0, 255] that maximizes R[k]

S(x ⊕ k)&0xF; i.e. x in I

0,k

(respectively in I

1,k

) if

d = d

(respectively if d = d

). Regarding the choice

of the values d

and d

, the authors in (Zeyad et al.,

2019) emphasized the use of d

= 0 and d

= 0xF.

In the sequel, we will use these two values as rec-

ommended. Then, during the acquisition phase, the

attacker acquires 256 computation traces. Finally, the

key recovery phase consists in sorting the computa-

tion traces into two buckets denoted V

and V

de-

pending on the bucketing nibble d (whose value de-

pend on a key guess). Then, it counts the number of

disjoint columns in V

and V

. The good key value

corresponds to the key guess for which the number of

disjoint columns is maximal.

Throughout several experiments, the authors have

demonstrated that this attack is an efﬁcient alternative

to the DCA. Indeed, the required amount of traces to

recover 4 bytes of the key is ﬁxed (256 traces for a

white-box AES implementation). However, as stated

by the authors in (Zeyad et al., 2019), when mask-

ing is properly applied as a countermeasure, then the

BCA fails to recover the key. Our goal is to extend

the BCA to the second-order case to defeat masked

white-box implementations. We keep the study of the

generalization of BCA to an order greater than two as

a future work.

3.2 Extension to the Second-order Case

Let’s consider a ﬁrst-order masked white-box AES

implementation for which c computation traces of n

samples each were acquired T = (t

i, j

)

0≤i≤c

0≤ j≤n

. Then,

according to Sec. 4 of (Bogdanov et al., 2019) and un-

der Assumption 3 there exists a ﬁxed couple ( j

∗

, j

∗

)

such that (t

i, j

∗

i, j

∗

) are the shares (i.e. the mask and

the masked value) of the target secret variable S(x

⊕

∗

) for any i in [0, c]. To check if the BCA can be ex-

tended to the second-order case, the arising question

is whether (V

[ j

∗

]⊕V

[ j

∗

]) and (V

[ j

∗

]⊕V

[ j

∗

]) are

disjoint sets only for the correct key guess k

∗

To answer this question, let’s consider a couple of

plaintexts (x

, x

) such that x

∈ I

0,k

∗

and x

∈ I

1,k

∗

, B

a 4-bit encoding function, and m

and m

the masks

used during the encryption of x

and x

respectively.

Then, on one hand, we have x

∈ I

0,k

∗

implies (under

Assumption 2) that:

][ j

∗

] ⊕ V

][ j

∗

]

= B



&0xF



⊕ B



(S(x

⊕ k

∗

) ⊕ m

)&0xF



= B



&0xF



⊕ B



(S(x

⊕ k

∗

)&0xF

{z }

) ⊕ (m

&0xF)



= B



&0xF



⊕ B



&0xF



= 0 . (1)

On the other hand, x

∈ I

1,k

∗

implies that:

][ j

∗

] ⊕ V

][ j

∗

]

= B



&0xF



⊕ B



(S(x

⊕ k

∗

) ⊕ m

)&0xF



= B



&0xF



⊕ B



(S(x

⊕ k

∗

)&0xF

| {z }

=0xF

) ⊕ (m

&0xF)



= B



&0xF



⊕ B



0xF ⊕ (m

&0xF)



= B



&0xF



⊕ B



&0xF



. (2)

Since B is bijective then V

][ j

∗

] ⊕ V

][ j

∗

] is

non-null. Consequently, Eq. (1) and Eq. (2) prove

that the sets (V

[ j

∗

] ⊕ V

[ j

∗

]) and (V

[ j

∗

] ⊕ V

[ j

∗

])

are disjoint for the good key guess. For a wrong key

guess k, it is obvious that these sets have common val-

ues. Indeed, for any x

∈ I

0,k

(respectively x

∈ I

1,k

)

such that k 6= k

∗

, S(x

⊕ k

∗

) (respectively S(x

⊕ k

∗

))

is a random value. Now, as the intersection between

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

268

two sets containing random values is non-null (for

some cardinality), then the sets (V

[ j

∗

] ⊕ V

[ j

∗

]) and

[ j

∗

] ⊕ V

[ j

∗

]) are only disjoint for the good key

guess k

∗

which prove the soundness of our proposal.

It is worth noting that the same soundness proof can

be generalized to handle any value of the bucketing

nibble pair (d

, d

So, the core idea of the second-order BCA is to

search for two time samples ( j

∗

, j

∗

) in the traces such

that (V

[ j

∗

] ⊕ V

[ j

∗

]) and (V

[ j

∗

] ⊕ V

[ j

∗

]) are dis-

joints. To further discard the false positives, we em-

phases the use of the two following additional criteria

that should be only fulﬁlled for the good key guess:

(1) the set (V

[ j

∗

] ⊕ V

[ j

∗

]) is null and (2) the set

[ j

∗

]⊕V

[ j

∗

]) contains non-constant values (as the

mask m

in Eq. (2) should be different from one en-

cryption to another).

The complexity of the second-order BCA (as for

any higher-order attack investigated in this work)

highly depends on the size of the targeted area of

interest to detect the leakages of the mask and the

masked variable. To reduce this complexity, we rec-

ommend ﬁltering the computation traces (i.e. re-

moving the common constant values) as suggested

in (Zeyad et al., 2019) and applying the different hints

proposed in (Goubin et al., 2019) to reduce the dimen-

sionnality of the traces.

Finally, we suggest an improvement for the ﬁrst-

order BCA reported in (Zeyad et al., 2019) to avoid

the appearance of some false positive in some practi-

cal white-box evaluations. The idea is that, for each

disjoint columns in V

and V

, the attacker has to

check if V

and V

are constant sets. Indeed, follow-

ing the reasoning in Eq. (1) and Eq. (2), V

and V

should contain respectively B(0) and B(0xF) for the

good key guess.

3.3 Experimental Results

To check the effectiveness of the extended BCA in

a real-world scenario, we develop the second-order

BCA. The source code of our implementation is pub-

licly available in (SM, 2019). Then, we run the attack

on the acquired traces of our masked white-box AES

implementation described in Sec. 2.3.

The obtained results demonstrate that the 16 bytes

of the AES key were recovered. It is worth noting that

thanks to the new criteria suggested in this work, no

false positives were detected for the false key guesses

(i.e. R[k] remains equal to zero when k is different

from k

∗

4 MUTUAL INFORMATION

ANALYSIS

4.1 Background

In 2008, Gierlichs et al. have proposed a new

side-channel distinguisher called Mutual Information

Analysis (MIA) (Gierlichs et al., 2008). It is an at-

tractive alternative to the Correlation Power Analy-

sis as it exploits any kind of dependency (linear or

non-linear) between the leakage measurements and

the predicted data. The MIA has been largely studied

and tested on several implementations (Batina et al.,

2011; Gierlichs et al., 2008; Prouff and Rivain, 2009).

The core idea consists in estimating the mutual in-

formation between the leakage measurements L and

the predictions φ(k) for every key guess k, that is:

∆

MIA

(k) = H[L] − H[L|φ(k)]. The correct guess of

the key k

∗

corresponds to the key for which ∆

MIA

(k)

is maximum. Since H[L] does not depend on the

key guesses, then the adversary can equivalently look

for the key that minimizes the conditional entropy

H[L|φ(k)]. The major practical issue of mutual infor-

mation is the estimation of the statistical distribution

of the leakages. Several methods have been proposed

in the literature: histograms, kernel density function,

parametric estimation (Prouff and Rivain, 2009). We

discuss in Sec. 4.2 how we dealt with this problematic

to conduct our practical attacks.

To the best of our knowledge, the ﬁrst report on

the use of MIA in the context of white-box evaluation

was provided by Rivain et al. in (Rivain and Wang,

2019). Indeed, the authors have assessed the pub-

licly available white-box AES implementation No-

SuchCon 2013) against an improved version of the

MIA. The obtained results have proven that this attack

is efﬁcient to break internally-encoded implementa-

tion with only few traces (60 traces) compared to the

DCA (4000 traces). This is expected as the depen-

dency between the leakage and the predictions in the

white-box context is non-linear (due to the usage of

the internal-encoding to hide the implementation in-

termediate values). In the following section, our goal

is to extend the MIA to higher-order context to target

masked white-box implementations.

4.2 Extension to the Higher-order Case

In 2009, Prouff et al. have proposed in (Prouff and

Rivain, 2009) a generalization of the MIA to higher-

orders. Let’s consider a d

-order masked implemen-

tation and assume that the adversary knows exactly

the manipulation times of the used masks and masked

data. Hence, he is able to recover the corresponding

Revisiting Higher-order Computational Attacks against White-box Implementations

269

(d + 1)-tuples of leakages L = (L

, L

, . . . , L

). Then,

the higher-order MIA consists in ﬁnding the key guess

that minimizes the conditional entropy H[L|φ(k)].

It is noticeable that the probability density function

(pdf) of the variable L|φ(k) is often assumed to be a

multivariate Gaussian mixture whose entropy can be

estimated as for the ﬁrst-order case using histograms,

kernel density function or parametric estimation.

To efﬁciently apply the higher-order MIA (Prouff

and Rivain, 2009) in the context of masked white-box

implementation, we focus on the two following prac-

tical challenges:

The Choice of the PDF Estimation Method. In

side-channel context, the estimation of the mutual

information is a major practical issue as it involves

some complex pdf estimation methods. It is worth

noting that the results of these methods have a strong

impact on the efﬁciency of the MIA (Batina et al.,

2011). In white-box context, the computation traces

contains non-noisy values. Hence, the estimated pdfs

are discrete which makes the practical evaluation sim-

pler (as also argued in (Rivain and Wang, 2019)). In

such context, the histogram estimation seems to be

the easier (natural) method to consider. That said,

the optimal choice of the bin width is also an issue

in statistical theory. For simple distribution, reason-

able choices of the bin width are the Scott rule and the

Freedman-Diaconis rule. However, under Assump-

tion 1, the computation traces contain values in the

range [0, 15]. Thus, the natural choice of the number

of bins we consider is 16 (i.e. bin width equals to 1)

The Choice of the Leakage Combination Func-

tion. To apply a d

-order MIA in the white-box con-

text, one can apply directly the side-channel approach

described in (Prouff and Rivain, 2009). That is, the

adversary has to consider d-tuples of leakages and

look for the key guess that minimizes the conditional

entropy of the multivariate pdf (L|φ(k)). Another ap-

proach, that we investigate in this work, consists in

combining the d-tuples of leakages by applying the

XOR function. Said differently, the idea is to min-

imize the conditional entropy of the uni-variate pdf

(

i=d

i=0

|φ(k)).

Indeed, under Assumption 3, the computation

traces (and hence the leakages L

) contains the ex-

act value of the manipulated variable (i.e. the com-

putation traces are noise-free). Thus, by applying the

XOR combination, the adversary converts the leak-

ages from multivariate to uni-variate context where

the pdf estimation is much easier from a computa-

Commonly, the number of bins should be equal to

(encoding size)

tional complexity perspective

. In the meantime, we

could expect that both approaches should lead to the

same key recovery efﬁciency. Indeed, since the com-

putation traces are noise-free, then their processing

using the XOR combination function will not induce

an information loss (which is the case when perform-

ing higher-order DPA-like attacks that involve prod-

uct and absolute difference combinations in a side-

channel context where the traces are noisy (Prouff and

Rivain, 2009)).

To verify this intuition, we compare in the follow-

ing section both approaches when targeting our refer-

ence masked white-box AES implementation.

4.3 Experimental Results

We implement two versions of a second-order MIA:

the ﬁrst one is based on an estimation of a bi-variate

pdf and the second one is based on the XOR com-

bination of the leakages and then an estimation of

the resulting uni-variate pdf. The pdf estimation is

based on the histogram method with a ﬁxed number

of bins (16) as discussed previously. Then, we tar-

get our masked white-box implementation using 150

computation traces.

The obtained results have proven that both attack

versions have succeeded to recover the complete AES

key using. To compare the efﬁciency of both ap-

proaches, we compute the evolution of the success

rate of each method according to an increasing num-

ber of used computation traces. The outcomes of this

experiment have conﬁrmed our claim that both meth-

ods have the same key recovery efﬁciency. In the

meantime, it is worth noting that the XOR combina-

tion based second-order MIA is two times faster than

the multivariate one. This behavior is quite expected

for the reasons we discussed in the previous section.

We provide the source code of our second-order MIA

in (SM, 2019).

5 COLLISION ATTACK

5.1 Background

Recently, Rivain et al. have proposed a collision at-

tack to defeat internally-encoded white-box imple-

mentations (Rivain and Wang, 2019). The proposed

attack is inspired by the DCA. The major difference

It is obvious that the estimation of a multivariate pdf

is more time-consuming than an uni-variate one (see for in-

stance the discussions in (Prouff and Rivain, 2009; Gier-

lichs et al., 2010).

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

270

is that the collision attack is based on the process-

ing of a pair of plaintexts (instead of one plaintext

as for DCA) to build the prediction vector and the

corresponding Collision Computation Traces (CCT).

That is, for each key guess k and each pair of in-

puts (x

, x

), the adversary computes the Pearson cor-

relation coefﬁcient ρ(δ

L(x

)L(x

)

, δ

φ(x

,k)φ(x

,k)

) where

is the “vector adaptation” of the well-known Kro-

necker delta function and L(x) is the computation

trace collected while processing the input x. The se-

cret key corresponds to the key guess for which the

highest correlation peak is obtained.

So, the core idea of this collision attack is that

if some sensitive variable collides for a pair of in-

puts, so does the corresponding encoded variable in

the computation (as the encoding functions are bi-

jective). One improvement of this attack we sug-

gest from a performance perspective and which we

validate through simulation and practical experiments

is to consider the equality distinguisher instead of

computing the correlation. Indeed, the adversary can

count, for each key guess, the number of times the

prediction vector δ

φ(x

,k)φ(x

,k)

and the vector of the

targeted samples in the CCT δ

L(x

)L(x

)

are equal. This

equality counter is maximum for the good key guess.

The authors in (Rivain and Wang, 2019) have suc-

cessfully applied this attack on some publicly avail-

able white-box implementations and have demon-

strated that the trace complexity is quite low com-

pared to DCA. In the following section, we study the

extension of this DCA-like collision attack to target

higher-order masked white-box implementations.

5.2 Extension to the Higher-order Case

Let’s assume that an adversary recovers the (d +

1)-tuples of leakages (L

, . . . , L

) from a d

-order

masked white-box implementation. Then, to apply

the (d +1)

-order collision attack, he has to compute

for each key guess and each pair of inputs (x

, x

) the

following distinguisher:

ρ(

i=0

) ⊕

i=0

), δ

φ(x

,k)φ(x

,k)

) . (3)

The soundness of our proposed d

-order collision

attack is inherently based on the soundness of the

(d + 1)

-order DCA under Assumption 3. In fact, the

(d + 1)

-order DCA is deﬁned as ρ(

i=0

(x), φ(x, k))

for every input x. When considering any pair of

inputs (x

, x

), the (d + 1)

-order DCA rewrites

ρ(

i=0

) ⊕

i=0

), φ(x

, k) ⊕ φ(x

, k)). Now,

Table 1: Comparison of the studied second-order attacks

when targeting a masked white-box implementation.

Attack Execution Number

method time (s) of traces

DCA 4.28 310

BCA 5.67 256

MIA (XOR) 15.58 150

MIA (multivariate) 34.11 150

Collision 70.15 500

since we are focusing on the study of the collision

during the processing of two different inputs x

and

, the relevant values of the prediction vector are

when φ(x

, k) ⊕ φ(x

, k) = 0. Thus, one can trans-

form the prediction vector from φ(x

, k) ⊕ φ(x

, k) to

φ(x

,k)φ(x

,k)

to obtain the distinguisher described in

Eq. (3). Said differently, the correlation is only com-

puted for the pair of plaintexts for which a collision

occurs for a key guess k (i.e. φ(x

, k) = φ(x

, k)).

5.3 Experimental Results

We validate ﬁrst the soundness of the extended col-

lision attack through simulation and we provide the

source code of its second-order version along with the

used simulated traces in (SM, 2019). Then, we run

the attack on the computation traces collected from

our reference masked white-box implementation. The

obtained results have demonstrated the practicability

of the attack. Indeed, we succeed to recover the AES

key using 500 computation traces.

6 ATTACK COMPARISON

We provide in Tab. 1 a comparison of the results ob-

tained for the studied attacks in this work. For the

sake of comparison, we perform as well the second-

order DCA as described in (Bogdanov et al., 2019).

For a fair comparison, we target the same areas of

interest to search for the leaking points of the mask

and the masked sensitive variable. All the attacks are

executed on a Linux machine with an Intel Core i7

processor at 3.60GHz and 16 GB of RAM.

The most efﬁcient attack in terms of traces com-

plexity is the MIA. This is expected due to its abil-

ity to capture the non-linear dependency between the

leakage and the predictions. In terms of performance,

the MIA based on the XOR combination is faster than

the multivariate version. This could be explained, as

already discussed in Sec. 4, by the fact that the esti-

mation of the conditional entropy of multivariate ran-

dom variables is more time-consuming compared to

Revisiting Higher-order Computational Attacks against White-box Implementations

271

the univariate case. The second-order BCA offers the

best trade-off between the execution time and trace

complexity and hence it is a good alternative to the

second-order MIA. Finally, when masking is involved

then the DCA is better than the collision attack. In-

deed, the collision attack (w.r.t. to Eq. (3)) can be

seen as a particular case of the DCA where the corre-

lation is only computed when a collision is detected.

However, the collision attack remains a good candi-

date to consider in an unmasked context as demon-

strated in (Rivain and Wang, 2019).

7 CONCLUSION

In this work, we considered the evaluation of higher-

order masked white-box implementations. Indeed,

we extended some well-known computational attacks

to the higher-order context. The practical evaluation

of these attacks had shown their efﬁciency to defeat

masked white-box implementations.

As a future work, we intend to study these higher-

order computational attacks when relaxing the as-

sumptions formulated in Sec. 2.2.

REFERENCES

(2019). Supporting materials.

https://github.com/Bucketing/HO-attacks-on-WB.

Batina, L., Gierlichs, B., Prouff, E., Rivain, M., Standaert,

F.-X., and Veyrat-Charvillon, N. (2011). Mutual In-

formation Analysis: a Comprehensive Study. J. Cryp-

tology, 24(2):269–291.

Bogdanov, A., Rivain, M., Vejre, P. S., and Wang, J.

(2019). Higher-order DCA against standard side-

channel countermeasures. In COSADE 2019, Darm-

stadt, Germany, April 3-5, 2019, Proceedings, pages

118–141.

Bos, J. W., Hubain, C., Michiels, W., and Teuwen, P. (2016).

Differential computation analysis: Hiding your white-

box designs is not enough. In CHES 2016, pages 215–

236, Berlin, Heidelberg. Springer Berlin Heidelberg.

Chow, S., Eisen, P., Johnson, H., and van Oorschot,

P. C. (2003a). A white-box des implementation for

drm applications. In Feigenbaum, J., editor, Digital

Rights Management, pages 1–15, Berlin, Heidelberg.

Springer Berlin Heidelberg.

Chow, S., Eisen, P. A., Johnson, H., and Oorschot, P. C. v.

(2003b). White-box cryptography and an aes imple-

mentation. In SAC 2002, pages 250–270, London,

UK, UK. Springer-Verlag.

Gierlichs, B., Batina, L., Preneel, B., and Verbauwhede,

I. (2010). Revisiting higher-order dpa attacks:. In

Pieprzyk, J., editor, Topics in Cryptology - CT-RSA

2010, pages 221–234, Berlin, Heidelberg. Springer

Berlin Heidelberg.

Gierlichs, B., Batina, L., Tuyls, P., and Preneel, B. (2008).

Mutual information analysis. In CHES 2010, volume

5154 of Lecture Notes in Computer Science, pages

426–442. Springer. Washington, D.C., USA.

Goubin, L., Paillier, P., Rivain, M., and Wang, J. (2019).

How to reveal the secrets of an obscure white-box im-

plementation. Journal of Cryptographic Engineering.

Kocher, P. C., Jaffe, J., and Jun, B. (1999). Differential

power analysis. CRYPTO ’99, pages 388–397, Lon-

don, UK, UK. Springer-Verlag.

Lee, S. (2018). Lee’s CASE 1 implementation.

https://github.com/SideChannelMarvels/Deadpool

/tree/master/wbs aes lee case1.

Lee, S., Kim, T., and Kang, Y. (2018). A masked white-box

cryptographic implementation for protecting against

differential computation analysis. IEEE Transactions

on Information Forensics and Security, 13(10):2602–

2615.

Maghrebi, H., Prouff, E., Guilley, S., and Danger, J.-L.

(2012). A ﬁrst-order leak-free masking countermea-

sure. In Dunkelman, O., editor, Topics in Cryptology

– CT-RSA 2012, pages 156–170, Berlin, Heidelberg.

Springer Berlin Heidelberg.

Prouff, E. and Rivain, M. (2007). A generic method for

secure sbox implementation. In Kim, S., Yung, M.,

and Lee, H.-W., editors, Information Security Appli-

cations, pages 227–244, Berlin, Heidelberg. Springer

Berlin Heidelberg.

Prouff, E. and Rivain, M. (2009). Theoretical and Practical

Aspects of Mutual Information Based Side Channel

Analysis. In Springer, editor, ACNS, volume 5536 of

LNCS, pages 499–518. Paris-Rocquencourt, France.

Rivain, M. and Wang, J. (2019). Analysis and improvement

of differential computation attacks against internally-

encoded white-box implementations. IACR TCHES,

2019(2):225–255.

Zeyad, M., Maghrebi, H., Alessio, D., and Batteux, B.

(2019). Another look on bucketing attack to de-

feat white-box implementations. In Polian, I. and

ottinger, M., editors, COSADE, pages 99–117,

Cham. Springer International Publishing.

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

272
