Japanese Cursive Character Recognition for Efﬁcient Transcription

Kazuya Ueki and Tomoka Kojima

School of Information Science, Meisei University, Tokyo, Japan

Keywords:

Character Recognition, Japanese Cursive Character, Kuzushiji, Convolutional Neural Network.

Abstract:

We conducted detailed experiments of Japanese cursive character recognition to promote Japanese historical

document transcription and digitization by using a publicly available kuzushiji dataset released by the Cen-

ter for Open Data in the Humanities (CODH). Using deep learning, we analyzed the causes of recognition

difﬁculties through a recognition experiment of over 1,500-class of kuzushiji characters. Furthermore, assu-

ming actual transcription conditions, we introduced a method to automatically determine which characters

should be held for judgment by identifying difﬁcult-to-recognize characters or characters that were not used

during training. As a result, we conﬁrmed that a classiﬁcation rate of more than 90% could be achieved by

narrowing down the characters to be classiﬁed even when a recognition model with a classiﬁcation rate of

73.10% was used. This function could improve transcribers’ ability to judge correctness from context in the

post-process—namely, the previous and subsequent characters.

1 INTRODUCTION

As Japanese characters have changed considerably

over time, it has become difﬁcult for non-experts

to read classical Japanese literature. By transcri-

bing historical documents, we are able to understand

the events of past eras. Therefore, research on the

transcription and digitization of historical documents

has been conducted. However, a vast number of li-

terary works have not yet been digitized. One of the

considerable barriers to this digitization is that Japa-

nese classical literature was written in a cursive style

using kuzushiji characters that are very difﬁcult to

read compared with the contemporary style.

The primary difﬁculty that arises in kuzushiji cha-

racter recognition is rooted in the fact that most

kuzushiji characters are very difﬁcult to distinguish

clearly from other characters because the writing style

varied among different eras and authors. Therefore, in

this study, assuming the actual transcription process,

we considered a method that could automatically de-

tect which characters were difﬁcult to classify using

deep learning and mark them as unknown characters

without making the ﬁnal decision.

2 RELATED WORK

Currently, handwritten characters can be recognized

with high accuracy by using convolutional neural ne-

tworks (CNNs). This trend has been highly motivated

by a CNN called LeNet with a convolution and po-

oling structure that was proposed by (LeCun et al.,

1989)(Lecun et al., 1998); this network successfully

recognized handwritten digits. CNNs have also been

widely used for recognizing kuzushiji characters in

classical literature and achieved relatively high accu-

racy (Hayasaka et al., 2016)(Ueda et al., 2018). These

studies on kuzushiji recognition have only focused on

classiﬁcations of less than 50 hiragana character cla-

sses. However, classical documents are not limited

to hiragana, as they also include katakana and kanji

characters. To create electronic texts of classical li-

terature or documents, it is necessary to recognize a

wide range of characters and improve the accuracy

with which they are transcribed. Based on this, we

focused on recognizing not only hiragana characters

but also katakana and kanji characters using the publi-

cly available kuzushiji dataset (Clanuwat et al., 2018).

When a text includes many character classes, we

need to address data imbalance problems. Yang et

al. conducted experiments of hand-written characters

from documents recorded by the government-general

of Taiwan from 1895 to 1945 (Yang et al., 2019). The

data imbalance problem was solved by applying data

augmentation when training deep learning models.

Reducing the labor load on transcribers was also

considered an important issue. Thus, a new type of

OCR technology was proposed by (Yamamoto and

Osawa, 2016) to reduce labor in high-load reprint

work. It was deemed important to divide reprinting

work among experts, non-experts, and an automated

402

Ueki, K. and Kojima, T.

Japanese Cursive Character Recognition for Efﬁcient Transcription.

DOI: 10.5220/0008913204020406

In Proceedings of the 9th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2020), pages 402-406

ISBN: 978-989-758-397-1; ISSN: 2184-4313

Figura 1: The number of images in each class in the ku-

zushiji dataset

Figura 2: Left: Examples of different characters with si-

milar shapes. Center: Examples of identical characters

with separate deformations caused by different jibo. Ri-

ght: Examples of differences in deformation despite being

linked to the same jibo depending on the work or writer.

process rather than relying on automating processing

entirely. The objective was not to achieve a deco-

ding accuracy of 100% with OCR automatic proces-

sing alone; rather, ambiguous letters were marked as

“ (geta)” and passed on to the expert in charge

of post-processing to make a decision. As a result,

it was possible to achieve rapid and high-precision

reprinting. We conducted an experiment to conﬁrm

whether it was possible to automatically eliminate er-

roneously classiﬁed characters or characters that were

not used in the training.

3 KUZUSHIJI RECOGNITION

EXPERIMENTS

3.1 Kuzushiji Image Dataset

We used the Japanese cursive kuzushiji character

image dataset (Clanuwat et al., 2018) released by the

Center for Open Data in the Humanities (CODH).

This kuzushiji database includes cropped images of

three different sets of characters—namely, hiragana,

katakana, and kanji. In total, 684,165 images with

4,645 character classes were included. These images

were cropped from 28 literary works written in the

Edo period (i.e., 1603–1868 AD). The number of ima-

ges in each class is heavily unbalanced. For example,

the classes with the largest and second largest num-

ber of images are “ ” (Unicode: U+306B) and

Figura 3: Neural Network Structure.

“ ” (Unicode: U+306E), which have 24,710 and

24,171 images, respectively. In contrast, many clas-

ses only have a few images, and 882 classes only have

one image. This data bias complicates recognition.

As we checked images in the dataset, many

characters were difﬁcult to distinguish clearly from

others due to the variation in their shape, as indicated

on the left in Fig. 2. There were also identical cha-

racters whose appearances differ greatly, as shown in

the center of Fig. 2. This is because hiragana and ka-

takana characters were originally derived from kanji

characters called jibo (maternal glyph), and identi-

cal hiragana and katakana characters were derived

from different jibo. Moreover, identical characters

may have the same jibo but be represented differen-

tly depending on the literary work or writer, as shown

on the right of Fig. 2.

3.2 Dividing the Data Used in the

Experiment

In this study, kuzushiji character images from 28 lite-

rary works were divided into training, validation, and

test datasets. The training data was used to train a

recognition model, and the validation data was used

to select the optimal model by evaluating the data

for each epoch. Test data was evaluated using the

trained model, and the model’s performance was mea-

sured. Speciﬁcally, character images from two bo-

oks (“Oraga Haru” and “Ugetsu Monogatari”) were

used as test data, and the remaining 26 literary works

were used as training or validation data. The number

of images in the 26 literary works was 628,136 with

4,493 character classes.

3.3 Neural Network Structure

In our experiments, we used the CNN architecture

of LeNet as shown in Fig. 3, which consists of two

convolution layers—including pooling layers and one

fully-connected layer with a softmax function—to ou-

tput probabilities for each character class. With regard

to the other layers, a rectiﬁed linear unit (ReLU) ac-

tivation function was used. Models were trained with

the AdaDelta algorithm.

Japanese Cursive Character Recognition for Efﬁcient Transcription

403

Figura 4: Classiﬁcation rate for each character class.

4 KUZUSHIJI RECOGNITION

EXPERIMENTS

In this section, we show how well various types of

characters can be recognized using deep learning and

analyze the causes of character misclassiﬁcation.

4.1 Data Used in the Experiments

As the number of images in each class was unbalan-

ced, we only used character classes with more than

20 images in the training set. The number of clas-

ses used in our experiments was 1,506. Because the

classiﬁcation rates tend to deteriorate for classes with

a limited number of training samples, training data

were augmented to ensure that the number of ima-

ges in each class was over one a hundred using the

following transformations: rotation (≤ 3 degrees),

width shift (≤ 0.03 × image_width), height shift (≤

0.03 × image_height), RGB channel shift (≤ 50),

shear transformation (≤ π/4), and zoom ([1 − 0.03 ×

image_size,1 + 0.03 × image_size]). After the data

augmentation, the number of images was 664,840.

We divided these images into training data (80%:

531,872 images) and validation data (20%: 132,968

images).

The total number of test data is 56,029 with 2,249

character classes. In the test data, many character cla-

sses were not included in the 26 literary works and

character classes that were excluded during training

because of the limited number of samples (less than

20 images in the class). By eliminating these charac-

ter classes, the number of images that could be recog-

nized was changed to 53,026.

Figura 5: Example images of the character “ ” (Uni-

code: U+5922) in the test data. Two images on the left

were misclassiﬁed as “ ”. Two images on the right were

misclassiﬁed as “ ”.

Figura 6: Top: Example images of the character “ ”

(Unicode: U+5922) in the training data. Middle: Example

images of the character “ ” (Unicode: U+85E4) in the

training data. Bottom: Example images of the character “

” (Unicode: U+7FA9) in the training data.

4.2 Experimental Results

The classiﬁcation rate for the test data was 73.10%

(= 40,952 / 56,029). When considering the character

classes in the training data only, the classiﬁcation ac-

curacy was 77.23% (= 40,952 / 53,026). However, the

average accuracy of each class was as low as 37.22%.

The classiﬁcation rate for each class is shown in Fig.

4. It is clear that many character classes could not be

correctly classiﬁed at all.

4.3 Error Analysis

By analyzing instances in which performance was

poor for speciﬁc characters, we were able to identify

certain root causes. Here, we show some typical mis-

classiﬁed examples.

The classiﬁcation rate of the character “ ”

(Unicode: U+5922), which is displayed in Fig. 5,

was very low at 8.8% (=3/34). As shown in the top

of Fig. 6, this character trained many variations in

shape. When this character was tested, most images

were misclassiﬁed as the character “ ” (Unicode:

U+85E4), which is shown in the middle of Fig. 6, or

the character “ ” (Unicode: U+7FA9), which is

shown in the bottom of Fig. 6. The left two images

of Fig. 5 were misclassiﬁed as the character “ ”,

and the right two images of Fig. 5 were misclassiﬁed

as the character “ ”.

Other examples are shown in Fig. 7. The cla-

ssiﬁcation rate for the character “ ” (Unicode:

ICPRAM 2020 - 9th International Conference on Pattern Recognition Applications and Methods

404

Figura 7: Example images of the character “ ” (Uni-

code: U+8336) in the test data.

Figura 8: Example images of the character “ ” (Uni-

code: U+8336) in the training data.

U+8336) was 4.2% (= 2 / 48). Corresponding trai-

ning data, which are shown in Fig. 8, include many

types of literary works and characters that were sty-

led differently by authors. Furthermore, as kuzushiji

characters were handwritten by different authors, the

character shape greatly differed in between training

and testing. Thus, kuzushiji character classiﬁcation

was notably difﬁcult.

4.4 Elimination of

Difﬁcult-to-Recognize Characters

In the test data derived from “Oraga Haru” and

“Ugetsu Monogatari,” there were characters that were

not included in the training data (26 literary works).

Furthermore, character classes with less than 20 ima-

ges in the training data were not trained. In the testing

process, it is difﬁcult to know whether there are unk-

nown characters that have not been trained. Thus, a

function that automatically eliminates such characters

is necessary. In this experiment, 3,003 of 56,029 ima-

ges in the test data were character classes that were

not trained.

The character recognition rate using the experi-

mental training model was 73.10%, which will lead

to a reduction in work efﬁciency when actually per-

forming transcription work. Therefore, it is important

to eliminate false recognition as much as possible and

leave only the correct recognition results.

Based on the error analysis described in the previ-

ous section, we found that the maximum output pro-

bability values from the softmax function tended to be

low if character images that were not correctly clas-

siﬁed were input to CNN. Thus, we conﬁrmed whe-

ther it was possible to eliminate erroneously classiﬁed

characters with low maximum output probability va-

lues (hereinafter referred to as conﬁdence values) by

using characters with high conﬁdence values. Spe-

ciﬁcally, conﬁdence values were used as a threshold,

and characters below the threshold were reserved as

unknown characters. As shown in the paper (Yama-

moto and Osawa, 2016), efﬁcient transcription will

be achieved by marking low-conﬁdence characters as

Figura 9: Relationship between the number of images that

can be classiﬁed and the classiﬁcation accuracy according

to the conﬁdence values. Horizontal axis: the threshold of

conﬁdence values. Vertical axis: the number of images that

can be classiﬁed (red), and the classiﬁcation rates (blue)

“ (geta),” and asking experts in the post-process

to make a ﬁnal judgment.

Figure 9 illustrates the relationship between the

classiﬁcation rates and the number of images that can

be classiﬁed when the threshold of conﬁdence values

is changed. For example, if tested images were limi-

ted to the conﬁdence value of 50% or more, the num-

ber of characters that could be classiﬁed was reduced

to 40,209. Among them, the number of correctly cla-

ssiﬁed images was 36,544, and the recognition rate

improved to 90.89% (= 36,544 / 40,209). When we

conﬁrmed the result of 3,003 images of the charac-

ter class not used for training, we found that 2,917

images (97.14%) could be eliminated, which was ex-

pected.

Figure 10 provides an example of the recognition

results of one page from “Ugetsu Monogatari.” When

the recognition results of the original book are dis-

played in typographical form, it is necessary to tell

transcribers in the post-process which characters have

low conﬁdence values. In this experiment, we displa-

yed characters with low conﬁdence values in the red

rectangles as shown in the center and on the right of

Fig. 10. If the conﬁdence value threshold is less than

50%, too many characters remained to be judged by

humans, so it was necessary to reduce the number of

characters to be eliminated in order to improve the

efﬁciency of transcription. However, if the threshold

of conﬁdence values was set to less than 10%, the nu-

mber of characters to be eliminated would be reduced.

Thus, it would be easier to predict characters with low

conﬁdence values from the previous and subsequent

characters with high conﬁdence values.

Japanese Cursive Character Recognition for Efﬁcient Transcription

405

Figura 10: Example of the recognition result of one page from “Ugetsu Monogatari.” Left: Original image of one page from

“Ugetsu Monogatari.” Center and right: Images showing the recognition results in print. Red rectangles indicate characters

with conﬁdence values of less than 50% and 10%, respectively.

5 SUMMARY

This study aims to improve the efﬁciency of transcri-

bing Japanese classical literature. We conducted the

experiments using deep learning to recognize Japa-

nese cursive kuzushiji characters with over 1,500 cla-

sses from a large-scale dataset. By augmenting the

data for classes with a small number of images, we

achieved a classiﬁcation rate of 73.10% for 1,506-

class character classiﬁcation, but the average classiﬁ-

cation rate over all classes was very low at 37.22%.

As this was not sufﬁcient to contribute to efﬁcient

transcription, we considered a method for automati-

cally eliminating images of characters that may be

erroneous or those that were not used for training.

We attempted to automatically eliminate such charac-

ters by focusing on the conﬁdence values from CNNs

and conﬁrmed that a recognition rate of 90% or more

could be achieved by changing the conﬁdence value

threshold.

However, future studies must consider characters

with low conﬁdence values. We also plan to imple-

ment the following measures to improve the transcrip-

tion process:

• We will implement a transcription system for

transcribers in the post-process and obtain the fe-

edback to improve the system. The system will

likely have to provide some candidate characters

for images with low conﬁdence values to improve

their ability to identify the correct character.

• We will incorporate rules based on expertise in ku-

zushiji characters in addition to improving recog-

nition technologies such as deep learning.

• We will incorporate character recognition beyond

the character-level, focusing on deriving informa-

tion from context—namely, word-, phrase-, and

sentence-level.

REFERENCES

Clanuwat, T., Bober-Irizar, M., Kitamoto, A., Lamb, A.,

Yamamoto, K., and Ha, D. (2018). Deep Learning for

Classical Japanese Literature. CoRR, abs/1812.01718.

Hayasaka, T., Ohno, W., Kato, Y., and Yamamoto, K.

(2016). Recognition of Hentaigana by Deep Learning

and Trial Production of WWW Application. In Proc.

of Information Processing Society of Japan (IPSJ)

Symposium, pages 2121–2129. (in Japanese).

LeCun, Y., Boser, B., Denker, J. S., Henderson, D., Howard,

R. E., Hubbard, W., and Jackel, L. D. (1989). Back-

propagation applied to handwritten zip code recogni-

tion. Neural Comput., 1(4):541–551.

Lecun, Y., Bottou, L., Bengio, Y., and Haffner, P. (1998).

Gradient-based learning applied to document recogni-

tion. In Proceedings of the IEEE, pages 2278–2324.

Ueda, K., Sonogashira, M., and Iiyama, M. (2018). Old Ja-

panese Character Recognition by Convolutional Neu-

ral Net and Character Aspect Ratio. In ELCAS Jour-

nal, volume 3, pages 88–90. (in Japanese).

Yamamoto, S. and Osawa, T. (2016). Labor saving for re-

printing Japanese rare classical books. In Journal of

Information Processing and Management, volume 58,

pages pp.819–827. (in Japanese).

Yang, Z., Doman, K., Yamada, M., and Mekada, Y. (2019).

Character recognition of modern Japanese ofﬁcial do-

cuments using CNN for imblanced learning data. In

Proc. of 2019 Int. Workshop on Advanced Image Te-

chnology (IWAIT), number 74. (in Japanese).

ICPRAM 2020 - 9th International Conference on Pattern Recognition Applications and Methods

406
