Mediastinal Lymph Node Detection using Deep Learning

Jayant P. Singh

, Yuji Iwahori

, M. K. Bhuyan

, Hiroyasu Usami

, Taihei Oshiro

and Yasuhiro Shimizu

Indian Institute of Technology Guwahati, Assam, 781039, India

Chubu University, 487-8501, Japan

Aichi Cancer Center Hospital, 464-8681, Japan

Keywords:

Convolutional Neural Network, Computed Tomography, Lymph Nodes, U-Net, SVM, ITRST, FCN.

Abstract:

Accurate Lymph Node detection plays a signiﬁcant role in tumour staging, choice of therapy, and in predict-

ing the outcome of malignant diseases. Clinical examination to detect lymph node metastases alone is tedious

and error-prone due to the low contrast of surrounding structures in Computed Tomography (CT) and to their

varying shapes, poses, sizes, and sparsely distributed locations. (Oda et al., 2017) report 84.2% sensitivity at

9.1 false-positives per volume (FP/vol.) by local intensity structure analysis based on an Intensity Targeted

Radial Structure Tensor (ITRST). In this paper, we ﬁrst operate a candidate generation stage using U-Net

(modiﬁed fully convolutional network for segmentation of biomedical images), towards 100% sensitivity at

the cost of high FP levels to generate volumes of interest (VOI). Thereafter, we present an exhaustive analysis

of approaches using different representations (ways to decompose a 3D VOI) as input to train Convolutional

Neural Network (CNN), 3D CNN (convolutional neural network using 3D convolutions) classiﬁer. We also

evaluate SVMs trained on features extracted by the aforementioned CNN and 3D CNN. The candidate gen-

eration followed by false positive reduction to detect lymph nodes provides an alternative to compute and

memory intensive methods using 3D fully convolutional networks. We validate approaches on a dataset of 90

CT volumes with 388 mediastinal lymph nodes published by (Roth et al., 2014). Our best approach achieves

84% sensitivity at 2.88 FP/vol. in the mediastinum of chest CT volumes.

1 INTRODUCTION

Precise detection and segmentation of enlarged

Lymph Nodes (LNs) play an essential role in the treat-

ment and staging of many diseases, e.g., lung can-

cer, lymphadenopathy, lymphoma, and inﬂammation

which is essential prior to commencing treatment.

These pathologies can cause affected LN’s to become

enlarged, i.e., swell in size. Nodes are generally con-

sidered to be healthy if they are up to 1 cm in diameter.

Parametric analysis of size, shape and contour, num-

ber of nodes and nodal morphology is critical when

evaluating nodal disease. This assessment is typically

done manually and has potential pitfalls due to the

fact that both normal structures and other patholog-

ical processes can mimic attenuation coefﬁcients of

nodal disease. Furthermore, manual processing is te-

dious and might delay the clinical workﬂow. This

paper proposes an efﬁcient two-step method to auto-

matically detect enlarged LNs in a patient’s chest CT

scans.

Figure 1: Enlarged Lymph Node (Liu et al., 2016).

2 PREVIOUS WORK

Previous work on computer-aided detection (CADe)

systems for LNs mostly employs direct three-

dimensional information from volumetric CT images.

(Oda et al., 2018) proposed a mediastinal LN detec-

tion and segmentation method from chest CT volumes

based on fully convolutional networks (FCNs), 3D

U-Net. Experimental results showed that 95.5% of

lymph nodes were detected with 16.3 false positives

per CT volume but due to huge number of parame-

ters, the model is likely to overﬁt and several regions

Singh, J., Iwahori, Y., Bhuyan, M., Usami, H., Oshiro, T. and Shimizu, Y.

Mediastinal Lymph Node Detection using Deep Learning.

DOI: 10.5220/0008948801590166

In Proceedings of the 9th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2020), pages 159-166

ISBN: 978-989-758-397-1; ISSN: 2184-4313

159

Figure 2: Candidate Generation Results (U-Net): Top Left →Axial Slice; Top Right →Mask; Bottom→Output.

of chest anatomies should be included in dataset in

order to moderate the size imbalance between classes

and prevent oversegmentation. (Barbu et al., 2011)

and (Feulner et al., 2013) performed boosting-based

feature selection and integration over a large num-

ber of 3D Haar-like and steerable features followed

by veriﬁcation using gradient-aligned features to ob-

tain a strong binary classiﬁer for detecting LNs. Due

to the inherent high dimensionality and a large num-

ber of parameters, modeling complex 3D image struc-

tures for LN detection is non-trivial. Nevertheless,

interpretation of the volumetric context through the

selected model is vital for the accurate detection of

LNs. Particularly, lymph nodes have similar attenu-

ation relative to adjacent anatomic structures such as

vessels, heart, and esophagus. This results in large

number of false-positives (FP), to assure a moder-

ately high detection sensitivity as in (Feuerstein et al.,

2009), (Feuerstein et al., 2012) or only limited sensi-

tivity levels (Barbu et al., 2011) and (Feulner et al.,

2013). The good sensitivities achieved at low FP

range in (Barbu et al., 2011) are not directly com-

parable with the other studies since (Barbu et al.,

2011) report on axillary (83.0% detection rate with

1.0 false positive per volume on 131 volumes con-

taining 371 LN), pelvic and only some parts of the ab-

dominal regions (80.0% detection rate with 3.2 false

positives per volume on 54 volumes containing 569

LN). (Liu et al., 2016) performed simultaneous seg-

mentation of multiple anatomic structures by multi-

atlas label fusion followed by candidate generation by

random forest classiﬁcation and SVM classiﬁcation

on chest CT volumes from 70 patients. (Oda et al.,

2017) obtained candidate regions using the Intensity

Targeted Radial Structure Tensor (ITRST) ﬁlter and

removed false positives (FPs) using the support vec-

tor machine classiﬁer achieving 84.2% sensitivity at

9.1 FP/vol for mediastinal LN. However, some lymph

nodes initially detected by the ITRST ﬁlter are re-

moved by the SVM classiﬁer. We build upon the deep

learning techniques to prevent generating such false

negatives. (Roth et al., 2014) proposed a new 2.5D

representation for LN detection using the deep con-

volutional neural network (CNN) and reported 70%

sensitivity at 3 false positives per volume. However,

(Roth et al., 2014) do not explore the results of deep

learning in candidate generation and 3D convolutions

during false positive reduction. We also provide an

exhaustive analysis of different models with different

input representations, including 2.5D used by (Roth

et al., 2014). Extensions of FCNs to 3D medical data

have been proposed for LN detection, but the com-

putational cost and memory consumption are still too

high to be efﬁciently implemented in today’s general

computer graphics hardware units.

3 METHODOLOGY

The method can be best described as a unidirectional

pipeline consisting of broadly two sections, 3.1 and

3.2.

Section 3.1 purely focuses on ﬁnding the location

of probable enlarged lymph nodes in the mediastinum

of input chest CT volume and hence called Candi-

date Generation. It is deliberately operated at very

high sensitivity so that almost all lymph nodes are de-

tected. However, this also results in a large number of

false positives that need to be eliminated. Section 3.2

purely focuses on the reduction of false positives and

hence called False Positive Reduction.

3.1 Candidate Generation

We refer to the following methods for generation of

LN candidates with their respective use-cases.

3.1.1 U-Net

We use a modiﬁed U-Net architecture for detecting

LN candidates from mediastinal CT volumes. The U-

Net is a convolutional network architecture for fast

ICPRAM 2020 - 9th International Conference on Pattern Recognition Applications and Methods

160

and precise segmentation of biomedical images. As

clearly explained in (Ronneberger et al., 2015), it con-

sists of a contracting path and an expansive path. The

contracting path consists of the repeated application

of two 3 x 3 convolution (same padding), each fol-

lowed by a rectiﬁed linear unit and a 2 x 2 max pool-

ing operation for downsampling. At each downsam-

pling, the number of feature channels are doubled. To

avoid overﬁtting, we use dropout before max pooling

operation that behaves as a regularizer when training

the network. After each convolution layer, we use

batch normalization to reduce covariate shift allowing

each layer to learn by itself a little bit more indepen-

dently of other layers.

Figure 3: U-Net architecture (Ronneberger et al., 2015).

Every step in the expansive path consists of an up-

sampling of the feature map followed by a 3 x 3 up-

convolution (same padding) that halves the number of

the feature channels, a concatenation with the corre-

sponding feature map from the contracting path and

two 3 x 3 convolution each followed by a ReLU. At

the ﬁnal layer a 1 x 1 convolution is used to map each

16 component feature vector to the desired segmented

image (binary).

3.1.2 Training U-Net

Each CT volume is resampled to a voxel size of 1 mm

x 1mm x 1mm. A window of width 550 HU and level

25 HU is applied to resampled CT volume. All val-

ues less than -250 HU are mapped to -1000 HU, and

those above 300 HU are mapped to 1000 HU. The

network is trained on axial slices of CT volume. (An-

notations in the dataset included only shortest axis

in the axial view of LN in accordance with RECIST

criteria). For a given CT volume, the mask volume

is generated (programmatically) by drawing an ellip-

soid/sphere with center and shortest axis/diameter as

per given annotations. Thereafter, axial slices with at

least one annotated LN are cropped to 256 x 256 pix-

els about the center to contain the mediastinum with

a sufﬁcient margin. Alternatively, the mediastinum

can be extracted by segmenting lungs using a number

of morphological operations followed by appropri-

ate cropping of the region between segmented lungs.

Random rotations, horizontal ﬂips, shear, zoom (0.9-

1.1), horizontal and vertical translations are used for

data augmentation. Both input axial slice and cor-

responding mask are augmented dynamically during

training.

The output image is thresholded at 0.35-0.5, de-

pending on the required sensitivity level (>=0.35

represents part of a detected LN). Subsequently, the

centroids of the detected LNs is found by calculat-

ing moments of contours in the binarized image and

translating coordinates from a cropped 256 x 256 im-

age to original 512 x 512 axial view. The network

is trained till the “test” dice coefﬁcient reaches [0.60,

0.65] range. A much higher dice coefﬁcient may de-

feat the purpose of Section 3.1 to maintain high sen-

sitivity while detecting LNs, which could otherwise

adversely affect Section 3.2 in the aforementioned

pipeline.

3.1.3 Preliminary CADe

For comparison between different models (explained

later) and previous works on mediastinal LN detec-

tion, we use a preliminary CADe system for detecting

LN candidates from mediastinal (Liu et al., 2014) CT

volumes in which lungs are segmented automatically

and shape features by Hessian analysis, local scale,

and circular transformation are computed at voxel-

level. The system uses a spatial prior of anatom-

ical structures (lung, spine, esophagus, heart, etc)

via multi-atlas label fusion before detecting LN can-

didates using a Support Vector Machine (SVM) for

classiﬁcation.

3.2 False Positive Reduction

Corresponding to each candidate, a 3D VOI of shape

32 x 32 x 32 voxels is extracted with center same

as the candidate centroid. In order to increase train-

ing data variation and to avoid overﬁtting, each nor-

malized VOI is also ﬂipped (horizontal and vertical),

translated, and rotated along a random vector in 3D

space. Furthermore, each ﬂipped, translated, and ro-

tated VOI is augmented with Gaussian Noise, Gaus-

sian Offset, and Elastic Transform different number

of times depending on the scale of data augmentation.

Different sample and augmentation rates for positive

and negative VOIs are used to obtain a reasonably bal-

anced training set.

When classifying an unseen VOI, we make use of

Test Time Augmentation (TTA). It involves creating

Mediastinal Lymph Node Detection using Deep Learning

161

Figure 4: Data Augmentation Types and Positive Axial Lymph Node.

Table 1: BS = 32.

BS = 32 PRECISION SENSITIVITY F1 SCORE ROC AUC FP/vol.

2.5D-I (18x) 0.74 (+/- 0.03) 0.82 (+/- 0.06) 0.77 (+/- 0.03) 0.86 (+/- 0.02) 3.08

2.5D-I (34x) 0.79 (+/- 0.04) 0.83 (+/- 0.03) 0.81 (+/- 0.01) 0.87 (+/- 0.01) 3.74

2.5D-II (18x) 0.78 (+/- 0.04) 0.78 (+/- 0.08) 0.78 (+/- 0.03) 0.86 (+/- 0.03) 2.61

2.5D-II (34x) 0.78 (+/- 0.06) 0.82 (+/- 0.06) 0.80 (+/- 0.03) 0.87 (+/- 0.01) 2.97

3D (18x) 0.79 (+/- 0.05) 0.80 (+/- 0.08) 0.80 (+/- 0.05) 0.88 (+/- 0.03) 2.31

3D (34x) 0.80 (+/- 0.04) 0.84 (+/- 0.03) 0.82 (+/- 0.03) 0.89 (+/- 0.03) 2.88

2.5D-I TTA (18x) 0.82 (+/- 0.04) 0.80 (+/- 0.04) 0.81 (+/- 0.01) 0.90 (+/- 0.01) 2.11

2.5D-I TTA (34x) 0.85 (+/- 0.05) 0.83 (+/- 0.05) 0.84 (+/- 0.01) 0.93 (+/- 0.01) 2.78

2.5D-I SVM (18x) 0.79 (+/- 0.04) 0.75 (+/- 0.08) 0.76 (+/- 0.03) 0.87 (+/- 0.02) 2.49

2.5D-I SVM (34x) 0.81 (+/- 0.04) 0.77 (+/- 0.03) 0.79 (+/- 0.01) 0.88 (+/- 0.01) 2.77

2.5D-II SVM (18x) 0.81 (+/- 0.06) 0.74 (+/- 0.10) 0.77 (+/- 0.04) 0.87 (+/- 0.03) 2.37

2.5D-II SVM (34x) 0.82 (+/- 0.06) 0.75 (+/- 0.02) 0.78 (+/- 0.02) 0.88 (+/- 0.03) 2.39

3D SVM (18x) 0.81 (+/- 0.05) 0.76 (+/- 0.09) 0.78 (+/- 0.05) 0.89 (+/- 0.03) 2.20

3D SVM (34x) 0.84 (+/- 0.05) 0.78 (+/- 0.05) 0.81 (+/- 0.03) 0.89 (+/- 0.03) 2.38

2.5D-I TTA SVM (18x) 0.79 (+/- 0.03) 0.75 (+/- 0.02) 0.77 (+/- 0.02) 0.87 (+/- 0.01) 2.24

2.5D-I TTA SVM (34x) 0.83 (+/- 0.03) 0.77 (+/- 0.03) 0.80 (+/- 0.01) 0.89 (+/- 0.01) 2.42

multiple augmented copies of each VOI during test-

ing, having the model make a prediction for each, then

returning an ensemble of those predictions. Augmen-

tations are chosen to give the model the best oppor-

tunity for correctly classifying a given VOI and re-

duce generalization error. Apart from the aforemen-

tioned VOI augmentations, we also use shear angle in

counter-clockwise direction and zoom (0.8-1.2).

Depending on the scale of data augmentation, we

divide the analysis into two broad categories with sub-

categories in each. Let 3x be the number of candi-

date LNs (obtained from Section 3.1), both positive

and negative combined. Following are the broad cat-

egories based on data augmentation scale.

3.2.1 18x

3x increased to 18x using aforementioned data aug-

mentation.

3.2.2 34x

3x increased to 34x using aforementioned data aug-

mentation.

For each broad category following are the sub-

categories:

• 2.5D-I: VOI decomposed into three orthogonal

slices (axial, coronal and sagittal) through the cen-

ter. 32 x 32 x 3 input to CNN;

• 2.5D-II: VOI decomposed into 12 slices (4 axial,

4 coronal and 4 sagittal) through the center. 32 x

32 x 12 input to CNN;

• 3D: VOI as input to 3D CNN (CNN with 3D con-

volutions);

• 2.5D-I TTA: 2.5D-I used with test time augmen-

tation;

ICPRAM 2020 - 9th International Conference on Pattern Recognition Applications and Methods

162

• 2.5D-I SVM: SVM trained on features extracted

by CNN in 2.5D-I;

• 2.5D-II SVM: SVM trained on features extracted

by CNN in 2.5D-II;

• 3D SVM: SVM trained on features extracted by

3D CNN in 3D;

• 2.5D-I TTA SVM: SVM trained on features ex-

tracted by CNN in 2.5D-I TTA;

• Axial: Axial slice through center as input (32 x 32

x 1) to CNN;

• Coronal: Coronal slice through center as input to

CNN;

• Sagittal: Sagittal slice through center as input to

CNN.

3D CNN (Payan and Montana, 2015) uses 3D

convolutions (Figure 5), which apply a 3-dimensional

ﬁlter to the input volume, and the ﬁlter moves in

three directions to calculate low-level representations.

Their output is a 3-dimensional volume space such as

cube or cuboid. A 2D convolution ﬁlter on the other

hand, moves in two directions to give a 2-dimensional

matrix as output. The 3D activation map produced

during the convolution of a 3D CNN is necessary for

analyzing medical data where temporal or volumetric

context is important. The ability to leverage inter-

slice context in a volumetric patch can lead to im-

proved performance but comes with a computational

cost as a result of the increased number of parameters.

4 EVALUATION AND RESULTS

Radiologists labeled a total of 388 mediastinal LNs

as positives in CT images of 90 patients (Roth et al.,

2014). In order to impartially evaluate the perfor-

mance of different approaches mentioned in Section

3.2, close to 100% sensitivity at the LN candidate

generation stage is assumed by feeding the labeled

LNs into the set of CADe LN candidates (Section

3.1.3). The test dice coefﬁcient range [0.60, 0.65] for

candidate generation using U-Net in Section 3.1.2 is

suggested for the same reason. The false-positive de-

tections produced by the CADe system are used as

negative LN candidate examples for training models.

All patients are randomly split into ﬁve subsets (at the

patient level) to allow 5-fold cross validation. Note

that the data augmentation (Section 3.2) is performed

at the candidate lymph node level (number of candi-

date lymph nodes per patient can be greater than one)

keeping patient ID information intact to be used later

Figure 5: 3D convolution.

during 5-fold cross validation. Training deep learn-

ing models with RMSprop optimizer on an NVIDIA

GeForce GTX 1060 takes 6 - 22 hrs depending upon

category and sub-category (Section 3.2). We evalu-

ate an approach on the basis of Precision, Sensitivity,

F1 Score, ROC AUC, and False Positives per Volume.

18x and 34x in the table refer to the broad categories

of analysis Section 3.2.1 and Section 3.2.2 respec-

tively, based on the scale of data augmentation. We

perform analysis for batch sizes (BS) 32 and 128 as

summarized in Tables 1 and 2 respectively.

To justify that 3 channels, 1 each of the 3 orthog-

onal views in 2.5D-I; 12 channels, 4 each of the 3

orthogonal views in 2.5D-II and VOI in 3D are not

redundant, we also train CNN model with 1 channel

input under each category of data augmentation con-

taining 1 of the 3 orthogonal views at a time (see Table

3). As expected, in any of the single views, perfor-

mance is not satisfactory with F1 score and ROC in

[0.74, 0.76] and [0.82, 0.86] range, respectively. Sen-

sitivity is comparable with other corresponding sub-

categories but with much larger FP/vol. in [8.48, 9.82]

range.

5 CONCLUSION

Varying a threshold parameter on per-candidate prob-

ability allows us to compute the receiver operating

characteristic (ROC) curves (Figure 6 and Figure 7).

The performance improvement using more data

augmentation (34x) shows that it is beneﬁcial for

CNN to have larger, more varied, and comprehensive

datasets (which is coherent to the computer vision lit-

erature (Krizhevsky et al., 2012), (Zeiler and Fergus,

2014)). 3D CNN seems to perform better than 2D

CNN in 2.5D-I and 2.5D-II because of 3D convo-

lutions exploiting temporal/volumetric information.

2.5D-I with test time augmentation outperforms all

Mediastinal Lymph Node Detection using Deep Learning

163

Table 2: BS = 128.

BS = 128 PRECISION SENSITIVITY F1 SCORE ROC AUC FP/vol.

2.5D-I (18x) 0.76 (+/- 0.02) 0.79 (+/- 0.08) 0.77 (+/- 0.03) 0.86 (+/- 0.02) 3.18

2.5D-I (34x) 0.79 (+/- 0.04) 0.81 (+/- 0.04) 0.79 (+/- 0.02) 0.87 (+/- 0.01) 3.51

2.5D-II (18x) 0.78 (+/- 0.05) 0.77 (+/- 0.07) 0.77 (+/- 0.03) 0.86 (+/- 0.02) 2.64

2.5D-II (34x) 0.78 (+/- 0.07) 0.82 (+/- 0.03) 0.80 (+/- 0.03) 0.87 (+/- 0.03) 2.99

3D (18x) 0.78 (+/- 0.04) 0.80 (+/- 0.05) 0.79 (+/- 0.03) 0.87 (+/- 0.03) 2.61

3D (34x) 0.80 (+/- 0.06) 0.83 (+/- 0.04) 0.81 (+/- 0.02) 0.89 (+/- 0.03) 2.73

Table 3: Single Slice.

BS = 32 PRECISION SENSITIVITY F1 SCORE ROC AUC FP/vol.

Axial (18x) 0.67 (+/- 0.04) 0.83 (+/- 0.05) 0.74 (+/- 0.02) 0.84 (+/- 0.02) 9.82

Axial (34x) 0.72 (+/- 0.05) 0.82 (+/- 0.05) 0.76 (+/- 0.02) 0.86 (+/- 0.01) 9.20

Coronal (18x) 0.69 (+/- 0.06) 0.80 (+/- 0.04) 0.74 (+/- 0.03) 0.82 (+/- 0.02) 9.80

Coronal (34x) 0.73 (+/- 0.04) 0.81 (+/- 0.07) 0.76 (+/- 0.02) 0.84 (+/- 0.02) 9.15

Sagittal (18x) 0.72 (+/- 0.06) 0.78 (+/- 0.07) 0.74 (+/- 0.02) 0.83 (+/- 0.02) 8.56

Sagittal (34x) 0.75 (+/- 0.06) 0.78 (+/- 0.07) 0.76 (+/- 0.02) 0.85 (+/- 0.02) 8.48

(a) 2.5D-I (b) 2.5D-II

Figure 6: 18x Data Augmentation.

other subcategories with maximum F1 score and AUC

being 0.85 and 0.94, respectively, shown by 2.5D-I

TTA (34x). AUC and ROC exhibit signiﬁcant im-

provement in sensitivity levels at the range of clini-

cally relevant FP/vol. rates. (Roth et al., 2014) report

70% sensitivity at 3 FP/vol. in the mediastinum (3

fold cross validation on a dataset of 90 patients). (Liu

et al., 2016) report 88% sensitivity at 8 FP/vol. (chest

CT volumes from 70 patients with 316 enlarged me-

diastinal lymph nodes are used for validation), while

our best approach achieves 84% sensitivity at 2.88

FP/vol. in the mediastinum (dataset published by

ICPRAM 2020 - 9th International Conference on Pattern Recognition Applications and Methods

164

(a) 2.5D-I (b) 2.5D-II

Figure 7: 34x Data Augmentation.

(Roth et al., 2014)). Thus, the proposed method of

candidate generation deploying U-Net followed by

false positive reduction using different approaches in-

volving CNN, 3D CNN, SVM (Niu and Suen, 2012),

varying input representations of VOI as explained in

Section 3.2 and results tabulated in Tables 1, 2, 3 can

be used for efﬁcient detection of lymph nodes in a

patient’s chest CT scans. However, if 3D representa-

tions are exploited further for the volumetric context

in serial medical CT data with current advancements

in computing and memory hardware, results can be

greatly improved.

If two or more lymph nodes are very close to each

other then they might be considered as a single lymph

node during candidate generation using U-Net. This

reduces the number of detected lymph nodes which

is undesirable. It remains as future work to improve

the candidate generation step such that it can segment

touching (very close) lymph nodes. To this end, we

propose the use of deep learning architecture aimed

to solve instance segmentation.

ACKNOWLEDGEMENTS

Iwahori’s research is supported by JSPS Grant-in-Aid

for Scientiﬁc Research (C) (17K00252) and Chubu

University Grant.

REFERENCES

Barbu, A., Suehling, M., Xu, X., Liu, D., Zhou, S. K.,

and Comaniciu, D. (2011). Automatic detection and

segmentation of lymph nodes from ct data. In IEEE

Transactions on Medical Imaging. IEEE.

Feuerstein, M., Deguchi, D., Kitasaka, T., Iwano, S.,

Imaizumi, K., Hasegawa, Y., Suenaga, Y., and Mori,

K. (2009). Automatic mediastinal lymph node detec-

tion in chest ct. In Medical Imaging 2009: Computer-

Aided Diagnosis. International Society for Optics and

Photonics.

Feuerstein, M., Glocker, B., Kitasaka, T., Nakamura, Y.,

Iwano, S., and Mori, K. (2012). Mediastinal atlas cre-

ation from 3-d chest computed tomography images:

application to automated detection and station map-

ping of lymph nodes. In Medical image analysis. El-

sevier.

Mediastinal Lymph Node Detection using Deep Learning

165

Feulner, J., Zhou, S. K., Hammon, M., Hornegger, J., and

Comaniciu, D. (2013). Lymph node detection and seg-

mentation in chest ct data using discriminative learn-

ing and a spatial prior. In Medical image analysis.

Elsevier.

Krizhevsky, A., Sutskever, I., and Hinton, G. E. (2012). Im-

agenet classiﬁcation with deep convolutional neural

networks. In Advances in neural information process-

ing systems.

Liu, J., Hoffman, J., Zhao, J., Yao, J., Lu, L., Kim, L., Turk-

bey, E. B., and Summers, R. M. (2016). Mediastinal

lymph node detection and station mapping on chest

ct using spatial priors and random forest. In Medical

physics. Wiley Online Library.

Liu, J., Zhao, J., Hoffman, J., Yao, J., Zhang, W., Turkbey,

E. B., Wang, S., Kim, C., and Summers, R. M. (2014).

Mediastinal lymph node detection on thoracic ct scans

using spatial prior from multi-atlas label fusion. In

Medical Imaging 2014: Computer-Aided Diagnosis.

International Society for Optics and Photonics.

Niu, X.-X. and Suen, C. Y. (2012). A novel hybrid cnn–

svm classiﬁer for recognizing handwritten digits. In

Pattern Recognition. Elsevier.

Oda, H., Bhatia, K. K., Oda, M., Kitasaka, T., Iwano, S.,

Homma, H., Takabatake, H., Mori, M., Natori, H.,

Schnabel, J. A., et al. (2017). Automated mediasti-

nal lymph node detection from ct volumes based on

intensity targeted radial structure tensor analysis. In

Journal of Medical Imaging. International Society for

Optics and Photonics.

Oda, H., Roth, H. R., Bhatia, K. K., Oda, M., Kitasaka, T.,

Iwano, S., Homma, H., Takabatake, H., Mori, M., Na-

tori, H., et al. (2018). Dense volumetric detection and

segmentation of mediastinal lymph nodes in chest ct

images. In Medical Imaging 2018: Computer-Aided

Diagnosis. International Society for Optics and Pho-

tonics.

Payan, A. and Montana, G. (2015). Predicting alzheimer’s

disease: a neuroimaging study with 3d convolutional

neural networks. In arXiv preprint arXiv:1502.02506.

Ronneberger, O., Fischer, P., and Brox, T. (2015). U-net:

Convolutional networks for biomedical image seg-

mentation. In International Conference on Medical

image computing and computer-assisted intervention.

Springer.

Roth, H. R., Lu, L., Seff, A., Cherry, K. M., Hoffman, J.,

Wang, S., Liu, J., Turkbey, E., and Summers, R. M.

(2014). A new 2.5d representation for lymph node de-

tection using random sets of deep convolutional neural

network observations. In International conference on

medical image computing and computer-assisted in-

tervention. Springer International Publishing.

Zeiler, M. D. and Fergus, R. (2014). Visualizing and under-

standing convolutional networks. In European confer-

ence on computer vision. Springer.

ICPRAM 2020 - 9th International Conference on Pattern Recognition Applications and Methods

166
