An Automated and Distributed Machine Learning Framework for

Telecommunications Risk Management

ıs Ferreira

1,2 a

, Andr

e Pilastri

1 b

, Carlos Martins

3 c

, Pedro Santos

3 d

and Paulo Cortez

2 e

EPMQ - IT Engineering Maturity and Quality Lab, CCG ZGDV Institute, Guimar

aes, Portugal

ALGORITMI Centre, Dep. Information Systems, University of Minho, Guimar

aes, Portugal

WeDo Technologies, Braga, Portugal

Keywords:

Automated Machine Learning, Distributed Machine Learning, Supervised Learning, Risk Management.

Abstract:

Automation and scalability are currently two of the main challenges of Machine Learning. This paper proposes

an automated and distributed ML framework that automatically trains a supervised learning model and pro-

duces predictions independently of the dataset and with minimum human input. The framework was designed

for the domain of telecommunications risk management, which often requires supervised learning models that

need to be quickly updated by non-ML-experts and trained on vast amounts of data. Thus, the architecture

assumes a distributed environment, in order to deal with big data, and Automated Machine Learning (Au-

toML), to select and tune the ML models. The framework includes several modules: task detection (to detect

if classiﬁcation or regression), data preprocessing, feature selection, model training, and deployment. In this

paper, we detail the model training module. In order to select the computational technologies to be used in this

module, we ﬁrst analyzed the capabilities of an initial set of ﬁve modern AutoML tools: Auto-Keras, Auto-

Sklearn, Auto-Weka, H2O AutoML, and TransmogrifAI. Then, we performed a benchmarking of the only two

tools that address distributed ML (H2O AutoML and TransmogrifAI). Several comparison experiments were

held using three real-world datasets from the telecommunications domain (churn, event forecasting, and fraud

detection), allowing us to measure the computational effort and predictive capability of the AutoML tools.

1 INTRODUCTION

The rise of data, processing power, and sophisti-

cated learning algorithms opened the way for Ma-

chine Learning (ML) applications to deal with large

amounts of data and produce useful predictions (Dar-

wiche, 2018). When adopting ML in real-word ap-

plications, two particularly useful capabilities are dis-

tributed learning and AutoML. Distributed learning is

a natural solution to large scale ML problems when

there are memory and processing limitations. By us-

ing multiple computers or multi-core processors in

parallel, each processor can process a different ML

algorithm or portion of the data. This allows to over-

come memory and time constraints to growing data

just by adding new machines or processors (Peteiro-

https://orcid.org/0000-0002-4790-5128

https://orcid.org/0000-0002-4380-3220

https://orcid.org/0000-0002-0678-4868

https://orcid.org/0000-0002-4269-5838

https://orcid.org/0000-0002-7991-2090

Barral and Guijarro-Berdi

nas, 2013). Also, with the

increasing number of non-specialists working with

ML (Thornton et al., 2013), it is essential to allow

people with limited knowledge in the ﬁeld to easily

select and apply the best ML model. AutoML aims

to help solve this issue and it is particularly relevant

when constant model updates are required.

This paper proposes a technological architecture

that addressed these two ML challenges and that is

adjusted to the telecommunications risk management

domain. This domain often requires supervised learn-

ing tasks (e.g., churn detection) that need to be set and

continuously updated by non-ML-experts and that in-

volve big data. Thus, our architecture deﬁnes a set

of steps that automate the usual workﬂow of a super-

vised ML application, including modules for: task de-

tection, data preprocessing, feature selection, model

training, and deployment. This work particularly fo-

cuses on the model training module, which assumes a

distributed AutoML tool. In order to select the com-

putational ML tool, we ﬁrst analyzed the capabili-

ties of ﬁve AutoML tools (Auto-Keras, Auto-Sklearn,

Ferreira, L., Pilastri, A., Martins, C., Santos, P. and Cortez, P.

An Automated and Distributed Machine Learning Framework for Telecommunications Risk Management.

DOI: 10.5220/0008952800990107

In Proceedings of the 12th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2020) - Volume 2, pages 99-107

ISBN: 978-989-758-395-7; ISSN: 2184-433X

Auto-Weka, H2O AutoML, and TransmogrifAI). The

two tools with distributed ML capabilities (H2O Au-

toML and TransmogrifAI) were then compared ex-

perimentally. The comparison used three telecommu-

nications real-world datasets, related to churn (regres-

sion), event forecasting (time series) and fraud detec-

tion (classiﬁcation).

The paper is organized as follows. In Section 2,

we present the related work. Next, Section 3 details

the proposed ML architecture. Section 4 describes

the analyzed AutoML technologies and the datasets

used during the experimental tests. Then, Section 5

discusses the experimental results. Finally, Section 6

presents the main conclusions and future work direc-

tions.

2 RELATED WORK

Typically, ML applications operate in-memory. Thus,

when the computational complexity of the ML algo-

rithm exceeds the machine memory, it does not scale

properly. In this age of big data, there is a need

to develop scalable and efﬁcient algorithms that can

deal with as many training data as possible under the

constraints of memory and time (Peteiro-Barral and

Guijarro-Berdi

nas, 2013). In this work, we partic-

ularly address classical distributed ML, which dis-

tributes the computation among distinct processors,

each performing an ML task using a static dataset.

Another relevant ML issue is related to the proper

selection of the right algorithm to be used and the

optimization of its hyperparameters. This model se-

lection and tuning is often performed by using ML

expert knowledge, heuristics and several trial-and-

error experiments, often performed using ad-hoc se-

tups (Feurer et al., 2015). For non-ML-experts, this is

not a trivial task (Gibert et al., 2018). AutoML was

speciﬁcally developed to solve this issue (He et al.,

2019). It can be deﬁned as the automatic (without

user input) search for the best algorithm for a given

dataset and producing predictions on the test set. This

search can be controlled by some user-deﬁned con-

straints, such as memory usage or execution time

(Feurer et al., 2015).

Due to its relevance, several AutoML tools were

proposed. Examples of currently available open-

source tools include: Auto-Keras (Jin et al., 2018),

Auto-Sklearn (Feurer et al., 2015), Auto-Weka (Kot-

thoff et al., 2017), H2O AutoML (H2O.ai, 2019)

and TransmogrifAI (Salesforce, 2019). Within our

knowledge, there are scarce studies that compare

AutoML technologies. Most research works com-

pare a speciﬁc AutoML tool with a set of state-of-

the-art ML algorithms, such as presented in (Feurer

et al., 2015). Other studies compare the performance

of AutoML applications that were submitted to ML

automation challenges, such as executed in (Guyon

et al., 2019). Recently, a direct AutoML tool compar-

ison was performed using a classiﬁcation task (Gijs-

bers et al., 2019). Also in 2019, several AutoML tools

were compared by using different types of datasets,

grouped by task, number of rows, number of columns,

types of columns or balance between classes (Truong

et al., 2019). However, none of these recent Au-

toML comparison studies considered speciﬁcally the

distributed ML dimension. For instance, as shown in

Table 1, TransmogrifAI is one of the few AutoML

tools that contains a distributed ML capability, yet this

tool was not considered in the experimental compar-

isons. Moreover, the recent comparison studies did

not adopt speciﬁc telecommunications risk manage-

ment domain datasets, such as churn or fraud detec-

tion.

3 PROPOSED ARCHITECTURE

This paper is part of the R&D project “Intelligent Risk

Management for the Digital Age” (IRMDA), which

is being developed by leading software and analytics

Portuguese company. The main outcome of IRMDA

is the development of a scalable and automated ML

system to empower the software company Telecom-

munications clients, allowing them to easily deploy

and maintain supervised ML risk management appli-

cations. The scalable and automated are fundamen-

tal ML requirements of the system since the company

has a large number of clients that work with different

amounts of data (small or vast). Also, typically these

clients are non-ML-experts.

We propose an automated ML technological ar-

chitecture that tries to combine the full automation of

the ML workﬂow with the ability to be executed in a

distributed environment. With the developed pipeline,

it is possible to automatically deal with all steps of a

typical supervised ML workﬂow just by identifying a

dataset and its target column. Since the architecture

is prepared to be executed on a computational clus-

ter, with several processing nodes, this allows users to

deal with bigger datasets just by adding new machines

to the cluster, if needed. The architecture is illustrated

in Fig. 1. The main components of the pipeline are:

• Machine Learning task detection - currently set to

detect if the ML pipeline should be considered a

classiﬁcation (binary or multiclass) or a regres-

sion (pure regression or time series) task, based

on the user-selected dataset and the datatype of

ICAART 2020 - 12th International Conference on Agents and Artiﬁcial Intelligence

100

Figure 1: The proposed automated and scalable ML architecture.

the target column. The type of supervised tasks

handled will be expanded according to feedback

provided by software company clients and the Au-

toML tool capabilities. Interesting future possibil-

ities of tasks to be addressed are an ordinal clas-

siﬁcation or multi-target regression. This compo-

nent also automatically infers the dataset schema.

• Data Preprocessing - deals with missing data (e.g.,

average imputation), the encoding of categorical

features (one-hot transform), a transformation of

univariate time series into a dataset with time-

lagged inputs and the standardization of numeri-

cal features.

• Feature Selection - removes irrelevant features

from the dataset that can reduce the performance

of the ML models. Currently, this component

is implemented by using ﬁltering methods (e.g.,

correlation values, information gain). In future,

more sophisticated automatic feature selection ap-

proaches, such as provided by the TransmogrifAI

tool (Salesforce, 2019) or Apache Spark (which

can be used with the H2O Sparkling Water tool

(H2O, 2019)), will be addressed.

• Model training using AutoML - automatically

trains and tunes a set of ML models using a set

of constraints (e.g., time limit). This component

also identiﬁes the best model to be used on the test

set.

• Pipeline Deployment - saves the pipeline that will

be used on a test set. The pipeline ensures that the

test data goes through the same transformations

as the training data and that it uses the best model

obtained during the training to make predictions.

The proposed architecture assumes two main

phases (Fig. 1): a training phase and a test phase. The

training phase includes the creation of the pipeline

and the deﬁnition of the pipeline stages. In order

to process the pipeline, the user needs to select the

dataset that will serve as training data and identify

the target column. Then, the dataset is loaded and

its schema is inferred. The task detection module

analyzes the output target type, assuming a classiﬁ-

cation goal (binary or multiclass, depending on the

number of target labels) or a regression task (pure

or univariate time series, depending on if the dataset

contains several variables or just the output target).

The next steps consist of the deﬁnition of the pipeline

stages based on the selected ML task. Each stage ei-

ther transforms the data (e.g., dealing with missing

data, categorical one-hot encoding) or creates a model

based on the training data which will be used on the

test phase to transform the data.

This paper focuses on the AutoML component

of the architecture, which assumes a distributed ML

and that is tested using real-world datasets from the

telecommunications domain. In particular, we ana-

lyze and benchmark open-source AutoML tools, in

order to technologically instantiate this component.

The AutoML goal is to select the best ML algorithm

for a given supervised learning task, tuning its hy-

perparameters and ﬁtting the model to the training

data. After this phase, the best model is added to the

pipeline and this object is ready to be exported. When

necessary, the pipeline may be imported and executed

on test data. The new data will pass through every

stage and produce predictions.

We highlight that current version of the overall ar-

chitecture, which received a positive feedback from

the Portuguese software company of the IRMDA

project, is expected to be incrementally improved in

future research. In particular, we intend to evolve and

test the non AutoML components by using more real-

world datasets and feedback from the software com-

pany clients.

An Automated and Distributed Machine Learning Framework for Telecommunications Risk Management

101

4 MATERIALS AND METHODS

4.1 AutoML Tools

We ﬁrst analyzed an initial a set of ﬁve modern open-

source AutoML tools, to check if they could fulﬁl the

desired IRMDA project requirements.

4.1.1 Auto-Keras

Auto-Keras is an AutoML Python library. The focus

of Auto-Keras is Deep Learning and the automatic

search for architectures and hyperparameters of Deep

Learning models. The goal of Auto-Keras is to allow

domain experts with limited ML background to eas-

ily build and tune Deep Learning models (Jin et al.,

2018). Auto-Keras allows the user to specify a time

limit for the executions and the possibility of perform

data augmentation.

4.1.2 Auto-Sklearn

Auto-Sklearn uses the the ML scikit-learn library (Pe-

dregosa et al., 2011) to perform algorithm selection

and hyperparameter tuning. It is a Python module that

makes use of recent advances in Bayesian optimiza-

tion, metalearning and ensemble learning to increase

the efﬁciency (Feurer et al., 2015). Auto-Sklearn in-

cludes 15 ML algorithms, 14 feature preprocessing

methods and 4 data preprocessing methods.

4.1.3 Auto-Weka

Auto-Weka is a module of the WEKA ML tool (Wit-

ten et al., 2016). The Auto-Weka module is the

WEKA solution to the Combined Algorithm Selec-

tion and Hyperparameter Optimization (CASH) prob-

lem on classiﬁcation tasks (Thornton et al., 2013). In

its most recent version, Auto-Weka also supports re-

gression tasks (Kotthoff et al., 2017). Auto-Weka uses

27 WEKA learners, 10 metalearners and 2 ensemble

methods.

4.1.4 H2O AutoML

H2O is a ML and predictive analytics platform. It

works with in-memory data, using a distributed and

scalable architecture that allows the users to build ML

models on big data environments. H2O was built to

facilitate the production of ML models when work-

ing in an enterprise environment (Cook, 2016). The

H2O goal is to help non-ML-expert users to produce

models with high performance (H2O.ai, 2019).

The result of an AutoML execution is an object

that includes the leaderboard of all the models trained

and validated during the ML model search process.

The number of searched models is dependant of the

optional parameters selected by the user (e.g., time

limit, exclusion of algorithms). The models on the

leaderboard are sorted by an evaluation metric, which

by default is the Area Under Curve (AUC) for bi-

nary classiﬁcation, Mean Per Class Error for multi-

class classiﬁcation and Deviance for regression. H2O

AutoML applies most of H2O families of algorithms,

such as Gradient Boosting Machine (GBM), Gen-

eralized Linear Model (GLM), XGBoost, Random

Forest and Deep Learning algorithms. It also al-

lows very personalized executions for more advanced

users. The user optional parameters include the spec-

iﬁcation of a time limit, evaluation metric, stopping

metric, the possibility of excluding algorithms and au-

tomatic balancing of the training example classes.

4.1.5 TransmogrifAI

TransmogrifAI is a tool written in Scala that runs on

Apache Spark. It focuses on the automation of ML

applications, allowing the users to rapidly obtain ML

models with few manual settings. The automation ad-

dresses the ML model selection and also feature se-

lection and engineering phases (Salesforce, 2019).

The user only has to specify the dataset, the

schema and the target column. TransmogrifAI uses

these parameters to infer more precise attribute types

(e.g., phone numbers, zip codes) and automatically

discards input features that do not present a predictive

value. Depending on the type of problem that is being

modeled (classiﬁcation or regression), TransmogrifAI

trains a set of algorithms and a predeﬁned set of hy-

perparameters. The list of trained algorithms includes

Random Forest, Logistic Regression, Linear Regres-

sion and Naive Bayes, among others.

4.1.6 AutoML Tool Comparison

Table 1 presents the main characteristics of each Au-

toML tool in terms of: interface language, associated

platforms, current version and if it contains a Graphi-

cal User Interface and distributed ML mode.

For the experimental comparison study, two tools

were selected, H2O AutoML and TransmogrifAI,

since these are the only tools from Table 1 that include

a distributed ML capability. The list of ML algorithms

provided by the two computational tools are presented

in Table 2. The last two H2O algorithms are related

with stacking ensembles that reuse the searched in-

dividual ML models: all, which combines all model

predictions; and best, which considers only best pre-

dictive results per ML algorithm.

ICAART 2020 - 12th International Conference on Agents and Artiﬁcial Intelligence

102

Table 1: Summary of the characteristics of the AutoML technologies.

Auto-Keras Auto-Sklean Auto-Weka H2O AutoML TransmogrifAI

Interface language Python Python

Python

Scala

Associated platforms - - WEKA

AWS

Azure

Google Cloud

Spark

Current version pre-release 0.6.0 2.6.1 3.26.0.6 0.6.1

Graphical User Interface - - X X -

Distributed mode - - - X X

Table 2: List of algorithms implemented by H2O AutoML

and TransmogrifAI.

Algorithm H2O AutoML TransmogrifAI

Decision Trees

- X

Deep Learning X -

Extremely

Randomized

Forest

X -

Gradient-

Boosted Trees (GBT)

- X

Gradient Boosting

Machine (GBM)

X -

Generalized Linear

Model (GLM)

X -

Linear

Regression

- X

Linear Support

Vector Machine

- X

Logistic

Regression

- X

Naive Bayes

- X

Random Forest (RF)

X X

XGBoost X -

Stacking All (SA)

X -

Stacking Best (SB)

X -

4.2 Data

For the benchmark comparison study, we consider

three real-world datasets related with the telecommu-

nications domain. The datasets were provided by the

IRMDA project software company, which selected

them as representative of common risk management

ML tasks executed by the company. The datasets are

related with customer churn (binary classiﬁcation),

event forecasting (univariate time series) and telecom-

munications fraud detection (regression).

4.2.1 Customer Churn

The customer churn dataset contains records from the

software company clients. Each row includes the fea-

tures that characterize each client and the associated

probability for canceling the company analytics ser-

vice (churn), as deﬁned by the software company. The

dataset is rather small, with 189 rows and 21 attributes

(Table 3). In this work, the dataset is modeled as a

pure regression task, where the ML models attempt to

predict the numeric churn probability.

4.2.2 Event Forecasting

The event forecasting dataset contains the number

of telecommunication events of a certain type (e.g.,

phone calls, short messages) that occurred from

February to April of the year 2019. The total number

of events was aggregated on an hourly basis, resulting

in 1,418 records related with 59 days of hourly data.

Each record contains the respective timestamp and the

number of events in that interval, as described in Ta-

ble 4. The number of hourly events ranges from 3,747

to 56,320. Considering the dataset temporal charac-

teristics, it is modeled as a univariate time series task.

4.2.3 Fraud Detection

The fraud detection dataset includes data records

about phone calls performed between a sender (A)

and a receiver (B). Each row includes also the labeled

classiﬁcation of the call (“fraud” or “normal”), as

identiﬁed by the software company using their expert

fraud knowledge and analytic tools. The dataset much

larger than the previously described datasets, it con-

sists of more than 1 million data examples, which cor-

responds to a day of phone calls that were performed

using the same client telecommunications company.

The data attributes are described in Table 5. This

dataset is modeled as a binary classiﬁcation task.

An Automated and Distributed Machine Learning Framework for Telecommunications Risk Management

103

Table 3: Summary of the attributes of the churn dataset.

Attribute Description

tenure

Time since the beginning

of the contract

streaming quality

Resolution of the contract

prime video

If prime video is

contractualized or not

contract Duration of the contract

payment method

Speciﬁcation of

the method of payment

product name

Identiﬁcation of the product

platform The type of connectivity

ﬁnancial status

If the payment is late

or regularized

service latency Latency of the service

dropped frames Number of dropped frames

volume Information about volume

duration Information about duration

account number

Account identiﬁcation

number

service latency

category

Category of the

service latency attribute

dropped frames

category

Category of the

dropped frames attribute

volume

category

Category of

the volume attribute

duration

category

Category of the

duration attribute

tenure

category

Category of

the tenure attribute

account segment Age segment of the client

equipment

Equipment used

by the client

churn probability

Probability of canceling

the service (∈ [0, 1])

Table 4: Summary of the attributes of the event forecasting

dataset.

Attribute Description

Time Timestamp (yyyy-mm-dd hh:mm)

datapoints Number of events in that interval

Table 5: Summary of the attributes of the fraud dataset.

Attribute Description

A Number of the sender of the call

B Number of the receiver of the call

Result

Classiﬁcation of the call

(“fraud” or “normal”)

5 RESULTS

5.1 Experimental Setup

To benchmark the AutoML tools, we executed several

computational experiments using the three real-world

datasets. The tools were compared under the same ex-

perimental setup, which was run on a machine with an

i7-8700 Intel processor with 6 cores. A holdout split

was used to divide the datasets into training (with 3/4

of the data) and test (1/4) sets. For churn and fraud

dataset, the split was randomly selected, while for the

event forecasting data a time order division was used

(since the data is ordered in time). Using the train-

ing data, each AutoML tool optimizes a single perfor-

mance measure, which was set as the Mean Absolute

Error (MAE) for the regression tasks (churn and event

forecasting) and the AUC for the classiﬁcation data

(fraud detection). An internal 10-fold cross-validation

was used by both AutoML tools in order to get a vali-

dation set where the selected performance measure is

computed. For comparison purposes, for the test data

we also computed the Normalized MAE (NMAE, in

%, which is equal to the MAE divided by the target

range) and Root Mean Squared Error (RMSE) val-

ues for regression tasks, and the Precision and Recall

measures for the binary classiﬁcation.

We tested all ML algorithms from Table 2, except

for the Deep Learning, which was disabled from the

H2O due to two main reasons. First, it required a huge

computational effort, particularly for the large fraud

detection dataset. Second, to achieve a more fair com-

parison, since TransmogrifAI AutoML tool does not

include a Deep Learning algorithm. In order to allow

the execution of all ML algorithms, no computational

time execution limitation was used.

5.2 Churn

Two scenarios were designed to test the performance

of the AutoML tools. The ﬁrst scenario (1) assumes

all the attributes of the dataset as input features of

the ML models. The second scenario (2) uses an ini-

tial feature selection phase before training the models.

The goal was to test the automatic feature selection

option provided by TransmogrifAI. Under this sce-

nario, and for H2O, we used the features that were

considered more relevant by the best H2O performing

ML model for the ﬁrst scenario. The obtained results

are presented in Table 6, where the computational ex-

ecution time is presented in the minutes:seconds no-

tation.

ICAART 2020 - 12th International Conference on Agents and Artiﬁcial Intelligence

104

Table 6: Results for the churn data (best values in bold).

Tool Scenario

Execution

time

Best

algorithm

Test data

MAE NMAE RMSE

H2O AutoML

1 00:28 SA 0.112 11.2% 0.189

2 00:26 GLM 0.126 12.6% 0.186

TransmogrifAI

1 03:44 RF 0.210 21.0% 0.283

2 03:36 GBT 0.109 10.9% 0.136

5.3 Event Forecasting

Since both H2O AutoML and TransmogrifAI do not

have native univariate time series forecasting algo-

rithms (e.g., ARIMA, Holt-Winters), we performed

a transformation on the dataset by using a set of time

lags to create the regression inputs. These lags were

created using the CaseSeries function of the rminer

R package (Cortez, 2010), under three input, lagged

scenarios: 1 – with time lags t − 1, t − 24 and t − 25,

where t is the current time (corresponding to the pre-

vious hour, day and hour before that day); 2 – with all

time lags from the last 24 hours (from t −1 to t − 24);

and 3 – with the time lags t − 12, t − 24, t − 36 and

t − 48. The results for each scenario are presented in

Table 7.

5.4 Fraud Detection

The dataset is highly unbalanced, with only around

0.01% of the calls being illegitimate. In order to test

the effect of balancing methods, three scenarios were

analyzed during the training phase. The ﬁrst scenario

(1) used a simple oversampling which used “fraud”

records and a random selection (with replacement) of

“normal” cases. The second (2) and third (3) scenar-

ios use the Synthetic Minority Oversampling Tech-

nique (SMOTE), which is a more sophisticated bal-

ancing method that generates synthetic examples for

the minority class, such that the training data gets

more balanced (Chawla et al., 2002). The SMOTE

was used to generate 100% of new fraud cases in the

second scenario and 200% of extra fraud examples

in the third scenario. The test phase also considers

three scenarios of unseen data, with different normal

to fraud ratios: A – 50%/50%, thus balanced; B –

75%/24%; and C – 80%/20%. Table 8 shows the ob-

tained results.

5.5 Discussion

In terms of computational processing time, the results

show that in general a small effort is needed by the

AutoML tools. The highest execution time is related

with the fraud detection data for the H2O tool and it

corresponds to just around 9 minutes.

This small computational effort is explained by

several factors, including: usage of a distributed

ML and multi-core machine; usage of benchmark

telecommunications datasets that are either have a

small number of examples (churn, event forecasting)

or inputs (fraud detection); and the disabling of the

Deep Learning algorithm in the H2O tool. Never-

theless, the execution time results conﬁrm that the

AutoML can perform an automatic ML selection in

a reasonable time. And if larger datasets were an-

alyzed, the computational effort could be reduced

by adding more processing elements to the compu-

tational cluster. As for the tool comparison, H2O

AutoML required less time to process the regression

tasks (churn and event forecasting), while Transmo-

grifAI was faster for the classiﬁcation task.

In terms of the predictive performance, H2O Au-

toML obtained better results for three regression com-

parisons (for both MAE and RMSE: scenario 1 for

churn and scenarios 1 and 3 for event forecasting),

and seven classiﬁcation comparisons (when using the

AUC measure). TransmogrifAI obtained the best re-

sults in two regression scenarios and two classiﬁca-

tion ones. Overall, the AutoML predictive results are

of high quality and the tools do not present substantial

predictive differences. For example, all H2O AUC

test results are equal to or higher than 95%, which

corresponds to an excellent discrimination level. And

the largest AUC classiﬁcation difference when com-

pared with TransmogrifAI is just 3 percentage points.

Similarly, the best churn prediction models present a

NMAE value that corresponds to an interesting value

of around 10%. The tool NMAE differences are small

for scenario 2 (1.7 percentage points) but larger for

scenario 1 (9.8 percentage points). As for the event

forecasting, the predictions are of high quality, with

NMAE values ranging from 4.0% to 6.6%. The tool

NMAE differences are very small for scenarios 1 and

2, with percentage point differences of 0.10 and 0.07,

while the difference is larger for scenario 3 (1.68 per-

centage points).

The predictive results conﬁrm the potential of the

distributed AutoML technologies, which are capable

An Automated and Distributed Machine Learning Framework for Telecommunications Risk Management

105

Table 7: Results for the event forecasting data (best values in bold).

Tool Scenario

Execution

time

Best

algorithm

Test data

MAE NMAE RMSE

H2O AutoML

1 02:32 GBM 2673 5.08% 4032

2 02:53 GBM 2138 4.07% 3535

3 01:50 GBM 2589 4.92% 4079

TransmogrifAI

1 05:16 GBT 2725 5.18% 4332

2 05:00 RF 2101 4.00% 3441

3 03:47 RF 3468 6.60% 5212

Table 8: Results for the fraud detection data (best values in bold).

Tool

Train

Scenario

Execution

time

Best

algorithm

Test

Scenario

AUC Precision Recall

H2O

AutoML

1 05:20 GBM

A 0.97 0.99 0.98

B 0.95 0.99 0.97

C 0.95 0.98 0.99

2 07:18 GBM

A 0.99 1 0.99

B 0.97 0.99 0.98

C 0.97 0.99 0.96

3 08:54 GBM

A 0.99 1 0.99

B 0.99 0.99 0.98

C 0.98 0.99 0.98

TransmogrifAI

1 01:19 RF

A 0.98 0.99 0.96

B 0.93 0.98 0.97

C 0.92 0.98 0.93

2 01:45 RF

A 0.98 1 0.99

B 0.96 0.99 0.98

C 0.96 0.97 0.94

3 02:13 GBT

A 0.99 1 0.99

B 0.98 1 0.98

C 0.97 0.99 0.96

of achieving high-quality predictive results in a rea-

sonable amount of time and with a minimum hu-

man intervention. The obtained results were shown to

the risk management software and analytics company,

which opted to select the H2O AutoML tool for sev-

eral reasons. First, it provided better predictive results

for the majority of the tested scenarios. In particular,

when the AutoML tools presented the largest metric

differences, the best results were achieved by H2O.

Second, the company classiﬁed the tool as “more ma-

ture” software, since as shown in Table 1, it is avail-

able in different programming languages and it can

be integrated with more platforms (other than Spark).

Also, the H2O provided an easy to use Graphical User

Interface.

6 CONCLUSIONS

In this paper, we proposed a ML framework that

can handle the full ML workﬂow, including sev-

eral modules to identify the ML goal, preprocess the

data, select features, train models and deploy testing

pipelines with a minimum human input. The frame-

work was speciﬁcally designed within a R&D project

that includes a major Portuguese software and analyt-

ics company that provides risk management services

for the telecommunications domain. The telecommu-

nications clients are typically non-ML-experts. More-

over, they work with varying sized datasets (small or

large). Thus, the proposed ML framework works on a

cluster that uses distributed ML to ensure scalability

and makes use of AutoML capabilities to facilitate the

development and maintenance of the ML models.

ICAART 2020 - 12th International Conference on Agents and Artiﬁcial Intelligence

106

This work particularly focus on one of the core

components of the architecture: the model training

module. To instantiate technologically such model,

we ﬁrst analyzed the characteristics of ﬁve open-

source AutoML tools (Auto-Keras, Auto-Sklearn,

Auto-Weka, H2O AutoML and TransmogrifAI).

Then, we performed a benchmark experimental study

with the two tools that presented a distributed ML

capability: H2O AutoML and TransmogrifAI. The

experiments were conducted using three real-world

datasets provided by the software company (churn,

event forecasting and fraud detection). The obtained

results allowed us to evaluate the potential of both Au-

toML technologies for the model training module of

the proposed architecture.

Overall, the proposed framework received a pos-

itive feedback from the software company, which

opted to select the H2O AutoML tool for its model

training module. In future work, additional telecom-

munications datasets will be addressed, in order to

further benchmark the AutoML tools. In particular,

we wish to extend the framework ML capabilities to

handle more ML tasks (e.g., ordinal classiﬁcation,

multi-target regression). Moreover, we intend to fo-

cus the development on the remaining components of

the architecture, in order to select the best technolo-

gies to be used (e.g., for handling missing data).

ACKNOWLEDGEMENTS

This work was executed under the project IRMDA

- Intelligent Risk Management for the Digital Age,

Individual Project, NUP: POCI-01-0247-FEDER-

038526, co-funded by the Incentive System for Re-

search and Technological Development, from the

Thematic Operational Program Competitiveness of

the national framework program - Portugal2020.

REFERENCES

Chawla, N. V., Bowyer, K. W., Hall, L. O., and Kegelmeyer,

W. P. (2002). Smote: synthetic minority over-

sampling technique. Journal of artiﬁcial intelligence

research, 16:321–357.

Cook, D. (2016). Practical machine learning with H2O:

powerful, scalable techniques for deep learning and

AI. ” O’Reilly Media, Inc.”.

Cortez, P. (2010). Data mining with neural networks and

support vector machines using the r/rminer tool. In In-

dustrial Conference on Data Mining, pages 572–583.

Springer.

Darwiche, A. (2018). Human-level intelligence or animal-

like abilities? Commun. ACM, 61(10):56–67.

Feurer, M., Springenberg, J. T., and Hutter, F. (2015).

Initializing bayesian hyperparameter optimization via

meta-learning. In Twenty-Ninth AAAI Conference on

Artiﬁcial Intelligence.

Gibert, K., Izquierdo, J., S

anchez-Marr

e, M., Hamilton,

S. H., Rodr

ıguez-Roda, I., and Holmes, G. (2018).

Which method to use? an assessment of data mining

methods in environmental data science. Environmen-

tal modelling & software, 110:3–27.

Gijsbers, P., LeDell, E., Thomas, J., Poirier, S., Bischl, B.,

and Vanschoren, J. (2019). An open source automl

benchmark. arXiv preprint arXiv:1907.00909.

Guyon, I., Sun-Hosoya, L., Boull

e, M., Escalante, H. J.,

Escalera, S., Liu, Z., Jajetic, D., Ray, B., Saeed, M.,

Sebag, M., et al. (2019). Analysis of the automl

challenge series 2015–2018. In Automated Machine

Learning, pages 177–219. Springer.

H2O (2019). Sparkling water. http://docs.h2o.ai/

sparkling-water/2.4/latest-stable/doc/index.html.

H2O.ai (2019). Automl: Automatic machine learning. http:

//docs.h2o.ai/h2o/latest-stable/h2o-docs/automl.html.

He, X., Zhao, K., and Chu, X. (2019). Automl: A survey of

the state-of-the-art. arXiv preprint arXiv:1908.00709.

Jin, H., Song, Q., and Hu, X. (2018). Auto-keras: Ef-

ﬁcient neural architecture search with network mor-

phism. arXiv preprint arXiv:1806.10282.

Kotthoff, L., Thornton, C., Hoos, H. H., Hutter, F., and

Leyton-Brown, K. (2017). Auto-weka 2.0: Automatic

model selection and hyperparameter optimization in

weka. The Journal of Machine Learning Research,

18(1):826–830.

Pedregosa, F., Varoquaux, G., Gramfort, A., Michel, V.,

Thirion, B., Grisel, O., Blondel, M., Prettenhofer,

P., Weiss, R., Dubourg, V., et al. (2011). Scikit-

learn: Machine learning in python. Journal of ma-

chine learning research, 12(Oct):2825–2830.

Peteiro-Barral, D. and Guijarro-Berdi

nas, B. (2013). A

survey of methods for distributed machine learning.

Progress in Artiﬁcial Intelligence, 2(1):1–11.

Salesforce (2019). Transmogrifai. https://docs.transmogrif.

ai/en/stable/.

Thornton, C., Hutter, F., Hoos, H. H., and Leyton-Brown,

K. (2013). Auto-weka: Combined selection and

hyperparameter optimization of classiﬁcation algo-

rithms. In Proceedings of the 19th ACM SIGKDD in-

ternational conference on Knowledge discovery and

data mining, pages 847–855. ACM.

Truong, A., Walters, A., Goodsitt, J., Hines, K., Bruss, B.,

and Farivar, R. (2019). Towards automated machine

learning: Evaluation and comparison of automl ap-

proaches and tools. arXiv preprint arXiv:1908.05557.

Witten, I. H., Frank, E., Hall, M. A., and Pal, C. J. (2016).

Data Mining: Practical machine learning tools and

techniques. Morgan Kaufmann.

An Automated and Distributed Machine Learning Framework for Telecommunications Risk Management

107
