A Practical Approach to Stakeholder-driven Determination of Security

Requirements based on the GDPR and Common Criteria

Sandra Domenique Zinsmaier

1,2,4 a

, Hanno Langweg

2,3 b

and Marcel Waldvogel

4 c

Siemens Logistics GmbH, Konstanz, Germany

HTWG Konstanz University of Applied Sciences, Konstanz, Germany

Department of Information Security and Communication Technology, Faculty of Information Technology and Electrical

Engineering, NTNU, Norwegian University of Science and Technology, Gjøvik, Norway

University of Konstanz, Konstanz, Germany

Keywords:

Common Criteria, GDPR, Privacy by Design, Requirements Engineering, Security by Design.

Abstract:

We propose and apply a requirements engineering approach that focuses on security and privacy properties

and takes into account various stakeholder interests. The proposed methodology facilitates the integration of

security and privacy by design into the requirements engineering process. Thus, speciﬁc, detailed security

and privacy requirements can be implemented from the very beginning of a software project. The method is

applied to an exemplary application scenario in the logistics industry. The approach includes the application

of threat and risk rating methodologies, a technique to derive technical requirements from legal texts, as well

as a matching process to avoid duplication and accumulate all essential requirements.

1 INTRODUCTION

Requirements engineering is a fundamental procedure

in every software development lifecycle. Nowadays,

it is essential to develop software products that con-

sider security and privacy by design from the very

beginning. Therefore, there exists a need for spe-

ciﬁc, detailed security and privacy requirements that

also ensure legally compliant software. This is not

holistically considered by classical requirements en-

gineering techniques. Therefore, we developed an ap-

proach that provides a structured way to identify re-

quirements from various stakeholders, match related

requirements to avoid duplication and track require-

ments for compliance assertion.

Certiﬁcations like ISO 27001 or Common Criteria

(CC) are required by customers more often such that

vendors of software products have to consider getting

their products or organization certiﬁed. According to

Art. 24(3) of the General Data Protection Regulation

(GDPR), compliance with a code of conduct or cer-

tiﬁcation may be used to prove lawfulness to certain

articles of the GDPR. Thus, it is interesting to ﬁnd the

delta between requirements from the various stake-

holders and accumulate all necessary requirements in

https://orcid.org/0000-0002-3811-6151

https://orcid.org/0000-0002-4156-5775

https://orcid.org/0000-0003-1665-0166

the very beginning of the software project.

The proposed approach assembles requirements

that emerge from various stakeholders, e.g., vendor,

customer, government, as well as requirements from

an aspired CC evaluation (by evaluating CC security

functional requirements (SFRs) that are described in

CC Part 2 (Common Criteria, 2017)). We apply the

methodology to a practical scenario in the logistics

industry. As a result, we present a list of detailed re-

quirements that – once implemented – make the ex-

emplary software product compliant with the GDPR

and partially prepared for a CC evaluation.

The remainder of this paper is structured as fol-

lows. Section 2 provides an overview of related re-

search. Then, the application scenario and methodol-

ogy are described in sections 3 and 4. The method is

applied to the exemplary application scenario in sec-

tion 5. We conclude with a discussion in section 6.

2 RELATED WORK

We elaborate on three interconnected areas of work in

the context of requirements engineering: GDPR com-

pliance, threat and risk assessment, as well as Com-

mon Criteria.

In (Palmirani et al., 2018; Bartolini et al., 2018b),

a model for legal reasoning and compliance with re-

Zinsmaier, S., Langweg, H. and Waldvogel, M.

A Practical Approach to Stakeholder-driven Determination of Security Requirements based on the GDPR and Common Criteria.

DOI: 10.5220/0008960604730480

In Proceedings of the 6th International Conference on Information Systems Security and Privacy (ICISSP 2020), pages 473-480

ISBN: 978-989-758-399-5; ISSN: 2184-4356

473

gard to the GDPR is proposed using logic formulæ.

This model is validated in (Bartolini et al., 2018a) on

Art. 5(1)(a) and Art. 7(1) GDPR using the methodol-

ogy proposed in (Bartolini et al., 2018b). While this

approach provides a formalization of GDPR articles

in a human-readable format that could then be used

to validate compliance to the law, it still lacks bridg-

ing the gap between legal requirements and technical

requirements.

The work by (Pandit et al., 2018b) utilizes the

GDPRov ontology developed in (Pandit and Lewis,

2017) along with the GDPRtEXT resource presented

in (Pandit et al., 2018a) in order to provide a way to

represent and query GDPR compliance obligations.

Again, the approach lacks referring to speciﬁc techni-

cal requirements based on the identiﬁed legal require-

ments.

A methodology for auditing GDPR compliance is

proposed by (Basin et al., 2018). Their inter-process

data-ﬂow model includes the formal notion of busi-

ness process modelling for identifying and imple-

menting the purpose for data processing as well as

automated algorithmic veriﬁcation of GDPR compli-

ance which may be complemented by human interac-

tions. The work focuses only on the following con-

cepts of the GDPR: purpose limitation, data minimi-

sation, consent and the right to be forgotten.

How ISO 27001 can help to achieve GDPR com-

pliance is described in (Lopes et al., 2019). While

many useful parallels are shown and best practices

from ISO 27001 provide useful technical details for

complying to certain GDPR requirements, it is con-

cluded that conforming to ISO 27001 does not guar-

antee GDPR compliance; however, it facilitates cer-

tain aspects.

An IoT healthcare system is taken as application

scenario in order to design a GDPR compliant sys-

tem by (Kamm

uller, 2018; Kamm

uller et al., 2019).

However, compliance of the system is not traceable as

there are no references to corresponding GDPR Arti-

cles.

In the context of data protection by design, the re-

search by (Dewitte et al., 2019) shows that there is

a discrepancy in risk assessment between legal ex-

perts (making data protection impact assessment) and

software engineers (doing threat modeling). Require-

ments are deﬁned and categorized as legal descrip-

tion requirements or architectural description require-

ments. They show which state-of-the-art threat mod-

eling techniques fulﬁll which legal and architectural

requirements in order to do a comprehensive risk as-

sessment. As a result, none of the methodologies sup-

port all requirements in both categories – legal and ar-

chitectural. Instead, most categories fulﬁll either legal

or architectural requirements. Thus, previous work

(Ringmann and Langweg, 2017) ﬁrst conducted the

risk assessment using STRIDE, resulting in an initial

set of architectural requirements. These requirements

are expanded and matched by technical requirements

which were derived from legal requirements in (Ring-

mann et al., 2018).

To the dichotomy between data protection impact

assessments and threat modeling with the focus on

privacy by design refers (Sion et al., 2019). Their ap-

proach provides a meta-model for a data protection

architectural viewpoint using data ﬂow diagrams and

including the reference to requirements imposed by

the GDPR (e.g., data-minimization, purpose limita-

tion). However, the approach lacks security-related

requirements with regard to the GDPR. A summary

of related research bridging the gap between legal and

computer science approaches to privacy is provided

by (Nissim et al., 2018).

(Jensen et al., 2019) propose a research agenda re-

garding the alignment of software development with

GDPR requirements. A summary of related research

regarding bridging the gap between legal and com-

puter science approaches to privacy is provided by

(Nissim et al., 2018).

The work by (Yin and Qiu, 2010) bridges the gap

between CC security functional requirements (SFR)

and traditional requirements description language by

proposing a three stages security requirements devel-

opment model. In (Amara et al., 2019), security re-

quirements are deﬁned from CC for software devel-

opment and applied in a case study.

Another approach to bridge the gap between ab-

stract legal requirements and concrete technical re-

quirements is presented by (Br

aunlich et al., 2011;

Simi

c-Draws et al., 2013) through the application of

the method KORA in combination with Common Cri-

teria. KORA is the abbreviation for “Konkretisierung

rechtlicher Anforderungen” (concretization of legal

requirements) which was introduced by (Hammer

et al., 1992) and has been used in German legal re-

search. The work by (Br

aunlich et al., 2011) com-

bines the application of CC with KORA in the ap-

plication context of ballot secrecy. In continuation,

(Simi

c-Draws et al., 2013) presents a framework that

integrates KORA in the context of CC and ISO 27001.

The framework is then also applied to a ballot secrecy

scenario. In (Simi

c-Draws et al., 2013), the process

steps of CC and ISO 27001 are matched to the four

process steps in KORA. Previous work (Ringmann

et al., 2018) applied KORA to the GDPR and identi-

ﬁed 74 generic, reusable technical requirements that

can be applied to software products which process

personal data.

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

474

3 APPLICATION SCENARIO

For the example application, we choose a scenario

within the logistics domain that is presented in (Ring-

mann and Langweg, 2017). In order to deliver items

from one location to another, it is necessary to iden-

tify the destination information which is placed upon

the item in writing. This information can be present

in various forms, e.g., handwriting, typewriting, bar

code, on a form, or an address label. As a result, per-

sonal data that is processed usually includes a per-

son’s postal address and name. The process between

posting an item for sending and ﬁnal delivery of the

item to the destination location includes one or mul-

tiple sorting stages where items with similar destina-

tions are assembled. At each sorting stage, a machine

determines the destination information of an item by

scanning the item with cameras, extracting the loca-

tion of an address through highly specialized optical

character recognition (OCR) software and then rout-

ing the item to a delivery vehicle for further/ﬁnal dis-

tribution. This process is similar for correctly sort-

ing and processing mail, packages as well as baggage

items.

While the sorting machine does the physical rout-

ing, the information processing is done on a computer

where OCR algorithms extract address information

from the scanned image. Identiﬁed destination ad-

dresses are then compared to corresponding entries

in a data dictionary and, eventually, identiﬁed address

data is sent back to the sorting machine as a structured

dataset that contains the destination information. This

simpliﬁed process is displayed in Fig. 1. For the re-

mainder of this paper, we work with the following

components of the sorting process:

• Scans of personal data: images from the scanner,

interface to the scanner

• Data dictionary (DB): database of ad-

dresses/routing information, interface from

the software to the data dictionary

• Software/Algorithms: software solution, also in-

cluding physical hardware

• Identiﬁed personal data: structured dataset con-

taining routing information, interface to sorting

machine

4 METHOD

The proposed methodology leverages upon (Ring-

mann and Langweg, 2017; Ringmann et al., 2018).

Figure 1: Simpliﬁed sorting process.

First, main stakeholder interests and threat scenar-

ios for the proposed application scenario are identi-

ﬁed in (Ringmann and Langweg, 2017) utilizing the

STRIDE methodology (Microsoft, 2009) – focusing

on the stakeholders vendor and customer (in this case

operator) of the software product. While STRIDE is

utilized here, it is possible to use other threat mod-

els. Next, a risk analysis using DREAD is performed

– concluding the threat and risk assessment. Again,

different risk assessment methods can also be ap-

plied. For exampel, regarding the requirement for pri-

vacy by design and default, it could be beneﬁcial to

consider a privacy threat analysis methodology like

LINDDUN (Wuyts et al., 2014). Based on the results

from STRIDE and DREAD, a ﬁrst set of detailed se-

curity requirements that mitigate the threats is devel-

oped. In order to prioritize the importance of the de-

tailed security requirements, it would make sense to

assign a cumulative DREAD risk rating score where

the highest risk level of the corresponding STRIDE

threat scenario is assigned to the detailed requirement.

In (Ringmann et al., 2018), generic technical re-

quirements are proposed for compliance with the

GDPR. This way, the government as a stakeholder

is considered with its enforced rules and regulations.

From the 74 technical requirements, we select a col-

lection that applies to our application scenario. Based

on the selected set of technical requirements, we start

a matching process. For each detailed security re-

quirement from the threat and risk assessment, it is

checked whether there exists a similar/related tech-

nical requirement from the GDPR. This process is

done top-down: the GDPR article that ﬁrst requires

something related to a detailed security requirement

from the threat and risk assessment is used as a pri-

mary source; other articles may have redundant re-

quirements. Matches are entered into an expanded list

of detailed requirements. Furthermore, for each tech-

nical requirement from the GDPR that has no match

from the risk assessment, new, detailed requirements

that are needed to fulﬁll the technical requirement are

added to the list. Finally, we further expand the list

of detailed requirements by a column for Common

Criteria SFRs. Again, for each SFR, it is checked

whether there exists a similar/related detailed require-

ment. Related in this context may also mean that it

A Practical Approach to Stakeholder-driven Determination of Security Requirements based on the GDPR and Common Criteria

475

Table 1: Stakeholder interests regarding conﬁdentiality (C), integrity (I), availability (A), transparency (T), unlinkability (U),

data minimization (M) and intervenability (V).

Scans of personal data Data dictionary Software/Algorithms Identiﬁed personal data

Stakeholder

C I A T U M V C I A T U M V C I A T U M V C I A T U M V

Vendor

Customer

Supplier

Sender

Receiver

Government

L.E.

Society

would be beneﬁcial to additionally include the pro-

posals from the SFR into an existing detailed require-

ment.

5 APPLYING THE

METHODOLOGY

Before performing a threat analysis, the interests of

the stakeholders must be determined. Based on the

work in (Ringmann and Langweg, 2017; Ringmann

et al., 2018) we propose to identify stakeholder in-

terests regarding the security principles conﬁdential-

ity (C), integrity (I) and availability (A) as well as the

privacy principles transparency (T), unlinkability (U),

data minimization (M) and intervenability by the data

subject (V). In context of the application scenario, the

following stakeholders must be considered: vendor

(data processor), customer/operator (data controller),

supplier, sender, receiver (data subject), government,

law enforcement (L.E.), society. The resulting matrix

of stakeholder interests is displayed in table 1. No in-

terest is represented by white cells, partial interest by

grey cells and full interest by black cells. For exam-

ple, a receiver always has full interest regarding C, T,

U, M, and V of all components (except for C of the

software). The integrity and availability of the scans

and identiﬁed personal data are not as important since

in case the machine is not working (correctly), man-

ual sorting will still be possible. Regarding the C, I, A

of the software/algorithms, the receiver is indifferent.

When having to prioritize which parts of the

matrix of interests will be fulﬁlled by the software,

the vendor will implement his own requirements ﬁrst.

Then, the vendor will consider the customer’s require-

ments as these might be essential to be met in order

to actually sell the software product. The interests of

third parties like sender, receiver, government, and

society will be considered to be met for compliance

reasons. The GDPR with its possible ﬁnes provides

a legitimate reason to take a closer look at compli-

ance with relevant rules and regulations enforced by

the government.

5.1 STRIDE Threat Analysis

Based on the interests of the stakeholders vendor and

cutomer/operator, Microsoft’s STRIDE model (Mi-

crosoft, 2009) is used for identifying threats to the

software. For the application scenario and its com-

ponents Scanner, Dictionary,Software, and Identiﬁed

data in total 34 threats were identiﬁed in (Ringmann

and Langweg, 2017). In order to avoid endless tables

and brieﬂy provide a demonstrable example of our

methodology, in this section and the following, we

will only take a closer look at threats in the STRIDE

category Tampering which are presented in table 2.

For the remaining steps of the methodology, we will

only consider threat number (TNo.) 13 of the com-

ponent Scanner: “unreadable images of the scanned

items through misconﬁguration of the scanner’s soft-

ware/hardware”.

Table 2: Threats for category Tampering.

Component TNo. Threat

Scanner 13

Unreadable images of the scanned items

through misconﬁguration of the scanner’s

software/hardware

Dictionary 14 Items are sorted incorrectly

Software 15

(incl. underlying components): Software

degradation, incorrect sorting, damaged

hardware, information disclosure, and

unavailability of the system

Identiﬁed

data

16 Faulty sorting, too many rejects

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

476

Table 3: DREAD assessment for category Tampering.

Component TNo. Threat Da R E A Di

Impact

(Da+A)/2

Likelihood

(R+E+Di)/3

DREAD

score

Risk

rating

Scanner 13

Unreadable images of the scanned

items through misconﬁguration of

the scanner’s software/hardware

1 0 0 1 0 1 0 0.5 Low

Dictionary 14 Items are sorted incorrectly 2 1 2 1 2 1.5 1.67 1.58

Medium

Software 15

Software degradation, incorrect

sorting, damaged hardware,

information disclosure, and

unavailability of the system

2 1 2 1 1 1.5 1.33 1.42

Medium

Identiﬁed

data

16 Faulty sorting, too many rejects 2 1 1 1 1 1.5 1 1.25

Medium

5.2 DREAD Assessment

Next, the threat scenarios are evaluated according to

the associated risks by using the DREAD methodol-

ogy (Marshall and Hudek, 2018). The DREAD risk

score is composed of the mean from impact and like-

lihood. The impact score builds the average from the

DREAD categories Damage potential and Affected

users. The likelihood score is composed of the mean

from the categories Reproducibility, Exploitability,

and Disocverability. Scores range from 0 to 3. The

computations of the risk scores were made utilizing

the DREAD score calculator for the Dradis Frame-

work (Martin et al., 2018). Based on the DREAD

score, a risk level can be assigned. For the purpose

of applying the DREAD methodology to the threat

scenarios, the risk rating is assumed as follows:

• Low: DREAD score ≤ 1

• Medium: 1 < DREAD score ≤ 2

• High: 2 < DREAD score ≤ 3

The scores and risk levels can be assigned in var-

ious ways. Since a threat and risk analysis (TRA) is

demanded in Article 32 of the GDPR, it makes sense

to utilize this initial TRA to document the values and

resulting measures, and therefore, already fulﬁlling a

GDPR requirement. An exemplary DREAD assess-

ment for the application scenario and corresponding

threats from STRIDE category tampering is presented

in table 3. The scores for the application example

are estimates and did not involve any real analysis.

However, it can be challenging to get all stakehold-

ers involved in the risk assessment process including

ﬁnding experts who can actually identify threats and

evaluate the corresponding risks.

Table 4: Detailed requirements that mitigate TNo. 13.

RNo. Detailed requirement TNo.

limit physical access to scanner (and

other hardware components)

2, 13, 21, 27

role-based user management for the

software

5, 13, 14, 22, 23

deﬁnition of an access control policy for

the software (role-based)

5, 13, 14, 22, 23

software/database(sw): document which

roles/users are authorized to read/write/

create/modify which resources

13, 16

OS: document which users/groups are

authorized to read/write/create/modify

which resources related to the system

13, 16

processes are running only with the

allowed privileges (esp. not root)

13, 16, 19

limit rights to write/modify ﬁles that

contain personal data to users/processes

that speciﬁcally need those rights

13, 14, 15, 16

5.3 Requirements for Threat Mitigation

Based on the threat scenarios, it is necessary to de-

ﬁne requirements that mitigate the threats and thus,

improve the security of the software product. For the

proposed scenario, a complete list of security require-

ments was developed but cannot be displayed in this

paper. Therefore, we will focus on tasks that mitigate

threat number (TNo.) 13 of the component Scanner:

“unreadable images of the scanned items through mis-

conﬁguration of the scanner’s software/hardware” for

the remainder of this paper. Results are displayed in

table 4.

These detailed requirements will serve as a ﬁrst

basis for the matching process. While these require-

ments are based on the interests of the stakeholders

vendor and customer/operator, it is necessary to take

a look at the requirements from the government im-

posed through rules and regulations, i.e., the GDPR.

A Practical Approach to Stakeholder-driven Determination of Security Requirements based on the GDPR and Common Criteria

477

Table 5: Requirements from GDPR for TNo. 13.

GNo Requirement from GDPR

Article

GDPR

Recital

GDPR

Further

GDPR

reference

Matched

RNo

Secure authentication and authorization mechanisms for all components that allow access

to personal data including access to networks, services, and systems

5(1)(f)

39(12)

49(1-2)

25(2)

32(1)(b)

32(2)

Deﬁnition of an access control policy on the basis of an identity management where

access control is limited to speciﬁc roles or attributes (who is allowed to do what with the

personal data)

5(1)(f)

39(12)

49(1-2)

25(2)

8 Limitation of rights for writing or changing ﬁles that contain personal data 5(1)(f) 32(1)(b)

10 Document which roles are authorized to read/write/create/modify which resources 5(1)(f) 32(1)(b)

5.4 Selection of Applicable Technical

Requirements from GDPR

A list of technical requirements from the GDPR was

derived in (Ringmann et al., 2018). In the context

of this article, it is determined for each technical re-

quirement whether it applies to the planned software

project or not. For the utilized exemplary scenario,

it was evaluated that only 40 out of 74 requirements

have to be fulﬁlled. The 34 other requirements were

either partly not applicable to the software project

(e.g., no proﬁling, data transfer outside of the coun-

try), already fulﬁlled (e.g., threat and risk analysis,

auditable documentation of lawfulness), or to be ful-

ﬁlled by the future operator (e.g., privacy notice, data

protection policy, interaction with the data subject).

Regarding the minimal application scenario, for threat

number (TNo.) 13 the following requirements based

on the GDPR are identiﬁed in table 5.

5.5 Match Requirements

The matching process is split into two parts. First,

for the requirements from GDPR which apply to

the software project, it is determined which of the

ﬁrst 50 detailed requirements that resulted from the

STRIDE/DREAD analysis match to which applica-

ble requirement from the GDPR. When no match is

found, a new entry for a detailed requirement is made.

As a result to the existing 50 detailed requirements, 16

more requirements are added. They can also be called

technical design measures, as this matching process is

the last step from the method KORA that was applied

in (Ringmann et al., 2018).

Finally, the matching process is enhanced by yet

another dimension. According to Art. 24(3), com-

pliance with a code of conduct or certiﬁcation may

be used to prove lawfulness of certain articles of the

GDPR. Therefore, the Common Criteria SFRs that are

described in CC Part 2 (Common Criteria, 2017) are

evaluated.

The work by (Simi

c-Draws et al., 2013) applies

the KORA method in the context of CC and ISO

27001. It matches the process steps of CC and ISO

27001 to the four process steps in KORA. As a result,

the SFRs from CC Part 2 match in the deﬁnition part

to KORA step 3: deﬁnition of technical requirements.

The implementation of the SFRs is then considered

to be part of KORA step 4: deﬁnition of technical de-

sign proposals. In the context of this exemplary appli-

cation scenario, the SFRs are matched to the derived

security requirements.

A summary of what is needed for a CC evaluation

is also provided by (Simi

c-Draws et al., 2013). In CC

Part 1, the general model is described. As a result,

usually a lot more steps need to be taken, e.g., deﬁn-

ing the Target of Evaluation, Evaluation Assurance

Level, Security Problem Deﬁnition, Security Objec-

tives before looking at the SFRs. Part of a CC evalu-

ation is to select various SFRs that mitigate threats

identiﬁed in the Security Problem Deﬁnition which

then need to be proven to be fulﬁlled by the system to

be evaluated. However, for the purpose of matching

security requirements in the context of this exemplary

application scenario, it sufﬁces to look at the SFRs.

The matching process is then continued by deter-

mining for each CC SFR whether there exists a tech-

nical design proposal which deals with the kind of re-

quirement. For the reduced application scenario, table

6 presents the detailed requirements for TNo. 13 after

the matching process including references to GDPR

compliance as well as CC SFRs.

6 CONCLUSION AND

DISCUSSION

As a result, we present a list of detailed security requi-

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

478

Table 6: Matched detailed requirements for TNo. 13.

RNo. Detailed requirement TNo. GNo.

Article

GDPR

Recital

GDPR

Further

GDPR

reference

CC SFRs

Limit physical access to scanner (and other hardware

components)

2, 13, 21,

1 5(1)(f)

39(12),

49(1-2)

25(2)

32(1)(b)

32(2)

FPT PHP.1.1

13 Role-based user management for the software

5, 13, 14,

22, 23

2 5(1)(f)

39(12),

49(1-2)

25(2)

FDP ACF.1.1

FIA USB.1.1

FIA ATD.1.1

FMT MSA.1.1

Deﬁnition of an access control policy for the software

(role-based)

5, 13, 14,

22, 23

2 5(1)(f)

39(12),

49(1-2)

25(2) FAU SAR.1.1

Software/database(sw): document which roles/users are

authorized to read/write/create/modify which resources

13, 16 10 5(1)(f) 32(1)(b)

FDP ACC.1.1

FMT MSA.1.1

OS: Document which users/groups are authorized to

read/write/create/modify which resources related to the

system

13, 16 10 5(1)(f) 32(1)(b)

FDP ACC.1.1

FMT MSA.1.1

Processes are running only with the allowed privileges

(esp. not root)

13, 16, 19 8 5(1)(f) 32(1)(b)

Limit rights to write/modify ﬁles that contain personal

data to users/processes that speciﬁcally need those

rights

13, 14, 15,

8 5(1)(f) 32(1)(b)

rements that – once implemented – make a software

product GDPR-compliant and partially prepared for a

CC evaluation. The proposed methodology facilitates

the integration of security and privacy by design into

the requirements engineering process. Thus, speciﬁc,

detailed security and privacy requirements are imple-

mented from the very beginning of a software project.

We learned that even for the presented application

scenario, the requirements engineering turned out to

be quite complex. However, the approach provides

a structured way to identify requirements from vari-

ous sources, match related requirements to avoid du-

plication and track requirements for compliance as-

sertion. The complexity will be reduced when utiliz-

ing requirements engineering tools instead of matri-

ces (e.g., usage of labels, categories, priorities, status

of implementation, etc.).

We found that our method uncovered require-

ments that had previously been unaddressed by the

methods in use by the company.

Limitations of this paper refer to the following

topics: selection of laws, kind of personal data, kind

of certiﬁcation, redundancy issues, and risk assess-

ment. The GDPR is not the only law that needs to

be considered. National data protection laws can be

more restrictive or liberating in certain areas, thus,

overruling articles stated in the GDPR. Furthermore,

other laws might be of importance for a software

project, e.g., for the application scenario, postal laws

play an important role. Therefore, it may be neces-

sary to apply the KORA method to applying laws in

order to identify further requirements. Other projects

may need to consider further requirements when pro-

cessing special categories of personal data or personal

data of children. There exist various certiﬁcation pos-

sibilities. While some certiﬁcations may be obtained

for a product (e.g., Common Criteria), others can only

be obtained for the entire organization or its processes

(e.g., ISO 27001). Thus, the decision to pursue a cer-

tiﬁcation may not be related to the software project.

When certiﬁcations are already in place, it must be

checked in which ways they already support com-

pliance with laws and regulations. Doing threat as-

sessment requires a certain expertise. The risk rat-

ing score is an important property of each require-

ment. However, it was not possible to disclose fur-

ther risk values for the application scenario. Regard-

ing requirements for fulﬁlling privacy by design and

by default, further threat modeling should be consid-

ered, e.g. in applying LINDDUN (Wuyts et al., 2014).

The requirements matching process is vulnerable to

redundancy issues which may lead to an increased

complexity and a reduced traceablilty to correspond-

ing GDPR articles or requirements from a standard

or code of conduct. In conclusion, for each of these

limitations further requirements may evolve.

REFERENCES

Amara, N., Huang, Z., and Ali, A. (2019). Modelling secu-

rity requirements for software development with com-

A Practical Approach to Stakeholder-driven Determination of Security Requirements based on the GDPR and Common Criteria

479

mon criteria. In Wang, G., Feng, J., Bhuiyan, M. Z. A.,

and Lu, R., editors, Security, Privacy, and Anonymity

in Computation, Communication, and Storage, pages

78–88, Cham. Springer International Publishing.

Bartolini, C., Lenzini, G., and Santos, C. (2018a). A Legal

Validation of a Formal Representation of GDPR Arti-

cles. In Proceedings of the 2nd JURIX Workshop on

Technologies for Regulatory Compliance (Terecom).

Bartolini, C., Lenzini, G., and Santos, C. (2018b). An inter-

disciplinary methodology to validate formal represen-

tations of legal text applied to the GDPR. In Proceed-

ings of the Twelfth International Workshop on Juris-

informatics (JURISIN).

Basin, D., Debois, S., and Hildebrandt, T. (2018). On

Purpose and by Necessity: Compliance Under the

GDPR. In Meiklejohn, S. and Sako, K., editors, Fi-

nancial Cryptography and Data Security, pages 20–

37, Berlin, Heidelberg. Springer Berlin Heidelberg.

aunlich, K., Richter, P., Grimm, R., and Roßnagel, A.

(2011). Verbindung von CC-Schutzproﬁlen mit der

Methode rechtlicher IT-Gestaltung KORA. Daten-

schutz und Datensicherheit-DuD, 35(2):129–135.

Common Criteria (2017). Common Criteria for Informa-

tion Technology Security Evaluation, Part 2: Security

functional components. Version 3.1 Revision 5.

Dewitte, P., Wuyts, K., Sion, L., Van Landuyt, D.,

Emanuilov, I., Valcke, P., and Joosen, W. (2019).

A comparison of system description models for data

protection by design. In Proceedings of the 34th

ACM/SIGAPP Symposium on Applied Computing,

SAC ’19, pages 1512–1515, New York, NY, USA.

ACM.

Hammer, V., Roßnagel, A., and Pordesch, U. (1992).

KORA: Konkretisierung rechtlicher Anforderungen zu

technischen Gestaltungsvorschl

agen f

ur IuK-Systeme.

Number 100 in Arbeitspapier. provet.

Jensen, M., Kapila, S., and Gruschka, N. (2019). Towards

Aligning GDPR Compliance with Software Develop-

ment: A Research Agenda. In Proceedings of the 5th

International Conference on Information Systems Se-

curity and Privacy - Volume 1: ICISSP,, pages 389–

396. INSTICC, SciTePress.

Kamm

uller, F. (2018). Formal Modeling and Analysis of

Data Protection for GDPR Compliance of IoT Health-

care Systems. In 2018 IEEE International Confer-

ence on Systems, Man, and Cybernetics (SMC), pages

3319–3324.

Kamm

uller, F., Ogunyanwo, O. O., and Probst, C. W.

(2019). Designing Data Protection for GDPR Com-

pliance into IoT Healthcare Systems. arXiv e-prints.

arXiv:1901.02426v1.

Lopes, I. M., Guarda, T., and Oliveira, P. (2019). How ISO

27001 Can Help Achieve GDPR Compliance. In 2019

14th Iberian Conference on Information Systems and

Technologies (CISTI), pages 1–6.

Marshall, D. and Hudek, T. (2018). Threat modeling for

drivers. last accessed on 2019-07-19.

Martin, D., Villa, X., Bogner, T., and Manaloto, A. (2018).

DREAD score calculator for Dradis. Version 3.11.0.

Microsoft (2009). The STRIDE Threat Model.

https://msdn.microsoft.com/en-us/library/ee823878

(v=cs.20).aspx. Last accessed on 2019-08-21.

Nissim, K., Bembenek, A., Wood, A., Bun, M., Gaboardi,

M., Gasser, U., O’Brien, D., Steinke, T., and Vadhan,

S. (2018). Bridging the gap between computer science

and legal approaches to privacy. In Harvard Journal of

Law & Technology, volume 31, pages 687–780. Har-

vard Journal of Law & Technology, Harvard Journal

of Law & Technology.

Palmirani, M., Martoni, M., Rossi, A., Bartolini, C., and

Robaldo, L. (2018). PrOnto: Privacy ontology for le-

gal reasoning. In K

o, A. and Francesconi, E., editors,

Electronic Government and the Information Systems

Perspective, pages 139–152, Cham. Springer Interna-

tional Publishing.

Pandit, H. J., Fatema, K., O’Sullivan, D., and Lewis, D.

(2018a). GDPRtEXT - GDPR as a Linked Data Re-

source.

Pandit, H. J. and Lewis, D. (2017). Modelling Provenance

for GDPR Compliance using Linked Open Data Vo-

cabularies. In Proceedings of the 5th Workshop on

Society, Privacy and the Semantic Web - Policy and

Technology (PrivOn2017) (PrivOn).

Pandit, H. J., OSullivan, D., and Lewis, D. (2018b).

Queryable provenance metadata for GDPR compli-

ance. Procedia Computer Science, 137:262–268.

Ringmann, S. D. and Langweg, H. (2017). Determining

security requirements for cloud-supported routing of

physical goods. In 2017 IEEE Conference on Com-

munications and Network Security (CNS), pages 514–

521. IEEE.

Ringmann, S. D., Langweg, H., and Waldvogel, M. (2018).

Requirements for Legally Compliant Software Based

on the GDPR. In Panetto, H., Debruyne, C., Proper,

H. A., Ardagna, C. A., Roman, D., and Meersman, R.,

editors, On the Move to Meaningful Internet Systems.

OTM 2018 Conferences, pages 258–276. Springer In-

ternational Publishing.

Simi

c-Draws, D., Neumann, S., Kahlert, A., Richter,

P., Grimm, R., Volkamer, M., and Roßnagel, A.

(2013). Holistic and law compatible IT security eval-

uation: Integration of common criteria, ISO 27001/IT-

Grundschutz and KORA. International Journal of In-

formation Security and Privacy, 7(3):16–35.

Sion, L., Dewitte, P., Van Landuyt, D., Wuyts, K.,

Emanuilov, I., Valcke, P., and Joosen, W. (2019). An

architectural view for data protection by design. In

2019 IEEE International Conference on Software Ar-

chitecture (ICSA), pages 11–20.

Wuyts, K., Scandariato, R., Joosen, W., Deng, M., and Pre-

neel, B. (2014). LINDDUN privacy threat modeling.

https://linddun.org/index.php. Last accessed 2019-10-

22.

Yin, L. and Qiu, F. (2010). A novel method of security re-

quirements development integrated common criteria.

In 2010 International Conference On Computer De-

sign and Applications, volume 5, pages V5–531–V5–

535.

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

480
