Assessing Testing Strategies for Access Control Systems: A Controlled

Experiment

Said Daoudagh

1,2 a

, Francesca Lonetti

1 b

and Eda Marchetti

1 c

ISTI-CNR, Pisa, Italy

Department of Computer Science, University of Pisa, Pisa, Italy

Keywords:

Access Control Systems, Controlled Experiment, Testing.

Abstract:

This paper presents a Controlled Experiment (CE) for assessing testing strategies in the context of Access

Control (AC); more precisely, the CE is performed by considering the AC Systems (ACSs) based on the

XACML Standard. We formalized the goal of the CE, and we assessed two available test cases generation

strategies in terms of three metrics: Effectiveness, Size and Average Percentage Faults Detected (APFD). The

experiment operation is described and the main results are analyzed.

1 INTRODUCTION

Access Control Systems (ACSs) play a critical role

inside the information technology systems. They

are concerned with determining the allowed activi-

ties of legitimate users, ensuring that only the in-

tended subjects can access the protected data and re-

sources. Most of the existing access control systems

rely on the eXtensible Access Control Markup Lan-

guage (XACML) (OASIS, 2013), the de facto stan-

dard for the speciﬁcation of policies and requests.

Testing of access control systems represents a

key activity to guarantee the trustworthiness of sensi-

tive data and protect information technology systems

against inappropriate or undesired user access. Sev-

eral strategies for the generation of test cases (i.e., ac-

cess requests) for access control systems have been

deﬁned in scientiﬁc literature. They leverage the ap-

plication of the combinatorial approaches to XACML

policies values for generating test inputs (Bertolino

et al., 2013b; Bertolino et al., 2012a; Martin and Xie,

2006); or exploit change-impact analysis for test cases

generation starting from policies speciﬁcation (Mar-

tin and Xie, 2007); or are based on the representa-

tion of policy-implied behavior by means of mod-

els (Mouelhi et al., 2008; Daoudagh et al., 2019b)

The need for effective and efﬁcient evaluation

methods of test cases generation strategies is growing

https://orcid.org/0000-0002-3073-6217

https://orcid.org/0000-0002-4864-2219

https://orcid.org/0000-0003-4223-8036

in order to gain conﬁdence that a system meets its se-

curity requirements. Indeed, the selection of the most

effective test generation strategy for the access con-

trol systems allows: i) on one side to exercise all the

security-critical aspects and discover all the possible

faults of the access control systems; ii) on the other

side to develop a successful and cost-effective test-

ing phase. The assessment of the most effective test

cases generation strategies for XACML based access

control systems usually relies on several techniques,

e.g., coverage (Martin et al., 2006) or mutation anal-

ysis (Bertolino et al., 2013a) and is based on speciﬁc

metrics and evidences gathered or from formal assur-

ance techniques or from experimental evaluations.

However, in software engineering there is still an

important lack in the application of standardized and

systematic procedures for performing assessment or

generalization of case studies results. Usually, associ-

ating to the results the standard means or the deviation

values as well as their conﬁdence levels are the syn-

onymous of statistical evidences. But, these values

are meaningless if the testing process cannot be rig-

orously conducted and, more important, replicated.

Indeed, software engineering research activities still

miss the knowledge of what is a Controlled Exper-

iment and how to apply it. Controlled experiments

have a very long application history in disciplines as

medicine, biology and chemistry, because they are

the most effective means for minimizing the effect of

variables which are not of interest of the study. The

Controlled Experiment lets to focus on an object, pop-

ulation, or any other variable which a scientist would

Daoudagh, S., Lonetti, F. and Marchetti, E.

Assessing Testing Strategies for Access Control Systems: A Controlled Experiment.

DOI: 10.5220/0008974201070118

In Proceedings of the 6th International Conference on Information Systems Security and Privacy (ICISSP 2020), pages 107-118

ISBN: 978-989-758-399-5; ISSN: 2184-4356

107

like to control and ﬁxes the exact conditions in which

the experiment can be performed and replicated: no

deviations in the environment of the experiment can

inﬂuence the ﬁnal results.

Even if well known Controlled Experiments are

rarely applied in software engineering (Jedlitschka

and Pfahl, 2005) and speciﬁcally in software test-

ing (Do et al., 2005) with the aim of obtaining reliabil-

ity as well as generalization of results, in the context

of testing of XACML based access control systems

there is a complete lack of such kind of well deﬁned

approaches.

Thus, the aim of this paper: to provide for

the ﬁst time a Controlled Experiment for eval-

uating two XACML based test cases generation

strategies available in literature, speciﬁcally Mul-

tiple Combinatorial (Bertolino et al., 2013b) and

XACMET (Daoudagh et al., 2019b). We use the

Goal Question Metric (GQM) template (Basili and

Rombach, 1988) to formalize the goal of the ex-

periment and deﬁne three metrics that are: effec-

tiveness, size and average percentage faults detected

(APFD). Moreover, as infrastructure for perform-

ing the controlled experiment, our proposal leverages

the XACML Mutation Framework (XMF) (Daoudagh

et al., 2019a) that allows for replicability of the ex-

periment as well as generalization of results, ﬁnding

aggregating, and ﬁnally reducing of experimentation

costs.

In summary, the main contribution of the paper

is the formal deﬁnition of a Controlled Experiment

within the access control domain. Therefore, accord-

ing to (Wohlin et al., 2012; Juzgado and Moreno,

2001), we present the thee main steps:

• the deﬁnition of a controlled experiment for the

evaluation of two test cases generation strategies;

• the instrumentation and execution of the experi-

ment;

• the analysis of the results.

Outline. Section 2 introduces the basic concepts

used in the remaining sections. We deﬁne goals, con-

text and variables of our controlled experiment in Sec-

tion 3. Then, Section 4 presents the execution of the

experiment whereas Section 5 provides an analysis of

the results. Section 6 presents related works. Finally,

Section 7 shows discussions and conclusions.

2 BACKGROUND

Access Control. Access Control (AC) is a mech-

anism used to restrict access to data or systems ac-

cording to Access Control Policy (ACP), i.e., a set of

rules that specify who has access to which resources

and under which circumstances (Sandhu and Sama-

rati, 1994).

Among the AC models proposed in the litera-

ture, we refer to the Attribute-Based Access Control

(ABAC) (Jin et al., 2012) which is currently one of

the most adopted in industrial environment (Hu et al.,

2019).

The basic idea of ABAC is to use attributes of dif-

ferent entities to formulate access control decisions

regarding a subject’s (e.g., user or process) access on

an object (e.g., ﬁle or database) in a system. The au-

thorization decisions are obtained by means of autho-

rization policies speciﬁed using a policy speciﬁcation

language. ABAC policies are a set of rules deﬁned

based on the attributes of subjects, objects and opera-

tions as well as other attributes, such as contextual or

environmental attributes.

The ABAC model is usually implemented using

the XACML (OASIS, 2013) standard that deﬁnes

ACPs and access control decision requests/responses

in a XML format. A XACML policy deﬁnes the ac-

cess control requirements of a protected system. An

access request that aims at accessing a protected re-

source is ﬁrst evaluated against the policy, after which

the access is granted or denied. A XACML Request is

composed of four main elements: 1. Subject, the en-

tity requesting the access; 2. Resource, the requested

object that is described in terms of attributes; 3. Ac-

tion, the operation that the subject wants to perform;

and 4. Environment, the contextual information such

as the request time and the location. The core compo-

nent of a XACML Policy is the Rule, which represents

the basic enforceable element: it is composed of an

Effect (Deny or Permit value); Target and Condition

which deﬁnes the applicability of the rule. The rules

are evaluated by the Policy Decision Point (PDP)

which is the AC component in charge of formulating

an authorization decision. In particular, the effect of

the rule is returned by the PDP when the evaluation of

a given request meets the constrains of its target and

condition. For more details about XACML we refer

to its speciﬁcation (OASIS, 2013).

Testing of Access Control Mechanisms. A typical

AC systems testing process, shown in Figure 1, con-

sists of at least four main steps: (A) test cases genera-

tion; (B) mutants generation; (C) test cases execution;

and ﬁnally, (D) results analysis.

The ﬁrst step is related to the generation of

test cases (step A ) for the aim of generating a

test suite starting from a given ACP. Among the

available test cases generation strategies we refer to

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

108

two different approaches: (1) Multiple Combinato-

rial strategy provided by X-CREATE tool (Bertolino

et al., 2013b) generates test inputs using combina-

torial approach of the XACML policies values; and

(2) XACMET (Bertolino et al., 2012b; Bertolino et al.,

2018) strategy based on the expected behavior of an

XACML-based PDP. The next step ( B in Figure 1) is

related to the generation of PDP mutants; the mutated

versions of the PDP can be generated by applying a

set of mutation operators. The basic idea of mutation

testing is to simulate typical programmer’s mistakes,

by seeding syntactic faults in the original program in

order to produce a set of faulty programs, called mu-

tants, each one containing one fault. The main pur-

pose of mutation testing is to assess the adequacy of

a test suite. Each test case is executed on the original

program and its mutants (in our case the PDP and the

its mutated versions), then outputs are collected (i.e.,

the authorization responses): if the mutant’s output is

different from the original program’s one, the fault is

detected and the mutant is said to be killed. The muta-

tion score is the ratio of the number of detected faults

over the total number of seeded faults and indicates

the effectiveness of the test suite.

The results of steps A and B are then used in

the next phase (step C in Figure 1), that allows the

execution of test cases on the original PDP and on its

mutated versions. Finally, the result of step C is used

in step D of the testing process (see Figure 1).

Figure 1: Workﬂow of the Testing Process.

All the above steps must be performed automati-

cally to speed-up the testing phase. Among the au-

tomated frameworks for testing purpose of AC sys-

tems currently available, in this paper we refer to the

XACML Mutation Framework (XMF) “which pro-

vides three main functionalities: test case genera-

tion, execution and assessment, and mutants gener-

ation” (Daoudagh et al., 2019a).

3 EXPERIMENTS DEFINITION

AND PLANNING

The controlled experiment deﬁnition consists of three

main steps: i) deﬁning the goal of the experiment,

the research questions and the associated Hypothe-

ses that have to be formally tested as in Section 3.1;

ii) introducing the context of the experiment as well

as the variables, the subjects and the object of the

experiment as in Section 3.2; iii) designing and in-

strumenting the experiment, i.e., the realization of the

means for performing the experiment and monitoring

it, without affecting the control of the experiment as

in Section 3.3.

3.1 Goal and Hypotheses Formulation

According to the Goal Question Metric (GQM) tem-

plate (Basili and Rombach, 1988), our research goal

is as follows:

Analyze two Test Generation Strategies

(T GS

and T GS

) for the purpose of evalu-

ation with respect to their Effectiveness, Size

and APFD of test suite produced from the

point of view of the researcher in the context

of XACML policy decision point testing.

In order to address the goal of our experiment, we

deﬁned three research questions and their associated

hypotheses:

• RQ1 Effectiveness: How much does the qual-

ity of a test suite produced by Strategy

(T GS

)

differ from the quality of test suite produced by

Strategy

(T GS

) in terms of Effectiveness, i.e.,

the mutation score? For evaluating the effective-

ness of the strategies we consider full test suites

derived from each strategy;

• RQ2 Size: How much does the cost of a test

suite produced by Strategy

differ from the cost of

test suite produced by Strategy

in terms of Size,

i.e., the number of test cases? For evaluating the

cost of the strategies in terms of the number of

XACML requests generated, we assume that all

requests have the same cost in terms of generation

and evaluation as well as verdict veriﬁcation;

• RQ3 APFD: How much does the Average Per-

centage Faults Detected (APFD) of a test suite

produced by Strategy

differ from the APFD of

test suite produced by Strategy

To answer the above research questions, the fol-

lowing Null Hypotheses have been deﬁned:

• H

0E f f

: µ

E f f TGS

= µ

E f f TGS

the Strategy

ﬁnds

on average the same number of faults, i.e., the ef-

fectiveness, as the Strategy

, where µ denotes the

average percentage of the killed mutants using the

complete test suites generated by the two strate-

gies;

Assessing Testing Strategies for Access Control Systems: A Controlled Experiment

109

• H

0Size

: µ

SizeT GS

= µ

SizeT GS

the size of test suite

is equal for Strategy

and Strategy

;

• H

0APFD

: µ

APFDT GS

= µ

APFDT GS

the average

APFD is equal for Strategy

and Strategy

A null hypothesis states that there are no real under-

lying trends or patterns in the experiment setting; the

only reasons for differences in the observations are

coincidental. This is the hypothesis that we want to

reject with a higher signiﬁcance. When the null hy-

pothesis can be rejected with relatively high conﬁ-

dence, it is possible to formulate an alternative hy-

pothesis, as follows:

• H

1E f f

= ¬H

0E f f

;

• H

1Size

= ¬H

0Size

;

• H

1APFD

= ¬H

0APFD

3.2 Context, Variables and Subjects

Selection

In the context of Access Control Systems (ACSs),

the aim of our controlled experiment is the evaluation

of test cases generation strategies by means of the

mutation analysis at the level of the Java based PDP

engine. The comparison involves the effectiveness

of the test suite generated by each strategy, the cost

associated to each test suite in terms of its size and

the velocity at which that effectiveness is reached.

According to the classiﬁcation of the experiment

context in (Wohlin et al., 2012), the comparison

of the selected test strategies has been conducted

through a Multi-test within object study, i.e., a kind of

controlled experiment that examines a single object

across a set of subjects. In this experiment the object

is the PDP engine, while the subjects are the XACML

policies.

The variables involved in the experiment are: one

Independent variable, i.e., the test case generation

strategy with two levels or alternatives (treatments)

for the main factor (i.e., Level 1 and Level 2) and three

Dependent Variables, i.e., the Effectiveness, the Size

(or the cost) of the test suites and the APFD metrics.

The Object of the experiment is the Policy Decision

Point developed by Sun, SunPDP (Sun Microsystems,

2006).

According to (Juzgado and Moreno, 2001), the

Parameter, that could inﬂuence the result of the ex-

periment or, alternatively, the response variable, is the

Mutation Generator tool or strategy used to gener-

ate the mutated versions of the PDP. Among the cur-

rently available tools, we selected the µJava tool (Ma

et al., 2006; seung Ma et al., 2005), but other solutions

could be selected, such as Javalanche (Schuler and

Zeller, 2009), Major (Just, 2014) or Judy (Madeyski

and Radyk, 2010).

Finally, we deﬁned the Subjects involved in the

experiment, i.e., the XACML Policies. According to

the recommendation in (Juzgado and Moreno, 2001),

the selection is closely connected to the generalization

of the results from the experiment, thus the selection

must be representative for that population.

For this, we considered a set of real-world

XACML policies taken from real contexts and Euro-

pean projects as summarized in Table 1. In particular,

the columns represent the number of rules, conditions,

subjects, resources, actions and distinct functions

within each policy. As in the table, policies named

demo-5, demo-11 and demo-26 have been taken from

the Open Source repository software Fedora (Flex-

ible Extensible Digital Object Repository Architec-

ture) (fed, 2019) for controlling the access to the

administered digital contents; the remaining six are

those released by the TAS3 European project (TAS3

Project, ).

The GQM template, considering the context of

Access Control, is as the following:

Analyze Multiple Combinatorial and

XACMET Strategies for the purpose of

evaluation with respect to their effectiveness

and size of test suite produced from the point

of view of the researcher in the context of

XACML policy decision point testing.

3.3 Experiment Design and

Instrumentation

The comparison between the performances of the dif-

ferent test strategies has been deﬁned using the Paired

Comparison design, a particular kind of one factor

with two treatments (Wohlin et al., 2012)

. In this

design, each subject uses both treatments on the same

object. In the context of this paper it can be translated

into: both test strategies (Multiple Combinatorial and

XACMET) have to be applied to each XACML pol-

icy and both the obtained test suites evaluated using

the SunPDP and its mutants.

According to (Wohlin et al., 2012), an important

step for the controlled experiment is the instrumenta-

tion, i.e., the realization of the means for performing

the experiment and monitoring it. In particular, the

instruments considered are of three types, namely ob-

jects, guidelines and measurement instruments.

The same design is called “randomized paired com-

parison design: two alternatives on one experimental unit”

in (Juzgado and Moreno, 2001).

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

110

Table 1: XACML Policies Subjects.

Xacml Policy Functionality

# Rule # Cond # Sub # Res # Act # Funct

2 73020419964 2 6 5 3 3 0 4

create-document-policy 3 2 1 2 1 3

demo-5 3 2 2 3 2 4

demo-11 3 2 2 3 1 5

demo-26 2 1 1 3 1 4

read-document-policy 4 3 2 4 1 3

read-informationunit-policy 2 1 0 2 1 2

read-patient-policy 4 3 2 4 1 3

Xacml-Nottingham-Policy-1 3 0 24 3 3 2

Object. When planning for an experiment, it is im-

portant to choose objects that are appropriate. The

object of our experiment is an XACML-based PDP

named Sun PDP (Sun Microsystems, 2006), which

is an open source implementation of the OASIS

XACML standard, written in Java. We decided on

Sun’s PDP engine because it is currently one of the

most mature and widely used engine for XACML pol-

icy evaluation, which provides complete support for

all the mandatory features of XACML 2.0 as well as

a number of optional features. This engine supports

also all the standard attribute types, functions and

combining algorithms and includes APIs for adding

new functionalities as needed. The Sun PDP source

code is broken into ten packages: seven packages in-

clude the core implementation, two packages include

classes used for the conﬁguration code, rarely used

by programmers, and one package contains test code

samples.

The comparison of the selected test strategies re-

quired the deﬁnition of the SunPDP Mutants. There-

fore, through the Mutation Generator and Mutation

Integrator components, the mutation operators (both

class-level and method-level operators) have been ap-

plied to the Sun PDP code and executable mutant ver-

sions derived.

Guidelines and Measurement. Guidelines are

needed to guide the participants in the experiment

and they include process descriptions and checklists.

Measurements are conducted via data collection that

in human-intensive experiments are generally per-

formed by manual forms or interviews. Since we con-

ducted a technology-oriented experiment, we embed-

ded both aspects in the automation process. Speciﬁ-

cally, we leveraged the functionalities of XMF frame-

work, i.e., test cases generation, mutants generation,

test cases execution and results analysis, to perform

our controlled experiment and automatically collect

the data.

4 EXPERIMENT OPERATION

The experiment operation mainly consists of three

steps: preparation, execution and data validation.

Speciﬁcally, the preparation step focuses on the

preparation of the subjects, object and the material

needed.

In our experiment, the preparation step consists of:

XACML policy selection, XACML requests genera-

tion, XACML based PDP selection, and ﬁnally the

mutants generator selection.

During the execution step, the XACML requests

are evaluated and obtained data are collected.

Finally, during the data validation step, the depen-

dent variables are calculated, the collected data are

managed and analyzed so to provide a valid picture of

the experiment. In the following sections, we report

the results of our data validation.

4.1 Data Validation

The data validation phase includes: i) a former de-

scriptive statistics, which allows the visualization of

the information using informal representations. In our

experiment, these statistics span from the number of

generated requests, to the distribution of the mutants

on the different Java PDP classes, to the evaluation of

the different test case executions. Even if simple and

informal, these descriptive statistics let both to high-

light an important criticality on the data set consid-

ered, that could have compromised the entire experi-

ment, and to ﬁnd out the corrective actions for solv-

ing it. Due to space limitation, in the following we

report only the number of executions and the number

Assessing Testing Strategies for Access Control Systems: A Controlled Experiment

111

of distinct mutants. ii) a latter formal description of

the experiment results. In our experiment we focused

on the Paired T-Test with Null Hypothesis and present

the results in Section 5.

Number of Executions. Table 2 reports for each

of the nine XACML policies, the number of exe-

cutions for the test suites derived by the XACMET

and the Multiple combinatorial test strategies (sec-

ond and third column respectively). The total amount

of executions is reported in the last column of the

table. From the data collected, as reported in the

last row, only 16% of the executions is performed by

XACMET strategy, meaning that testing cost of such

strategy is very low compared to the one of the Mul-

tiple Combinatorial strategy.

Table 2: Number of Executions by XACML Policy and

Strategy.

Xacml Policy # of Executions All

XACMET Mulitlple

2 73020419964 2 12320 481800 494120

create-document-policy 13560 96360 109920

demo-11 104390 321200 425590

demo-26 64240 128480 192720

demo-5 128480 674520 803000

read-document-policy 4014 240900 244914

read-informationunit-policy 27752 48180 75932

read-patient-policy 48180 240900 289080

Xacml-Nottingham-Policy-1 38892 55072 93964

All 441828 2287412 2729240

For aim of completeness, for each XACML pol-

icy, Figure 2 reports the percentage of executions for

the two testing strategies considered. In particular,

the blue bars (black in black and white printing) re-

fer to the XACMET testing strategy, while the orange

bars (light gray in black and white printing) report the

percentage of executions of Multiple Combinatorial

strategy.

Figure 2: % of Executions by XACML policy, by

XACMET and Multiple strategy.

Number of Distinct Mutants. The information

about the number of executions can be analyzed also

from the point of view of how many distinct mu-

tated PDPs are evaluated by each XACML policy.

In particular, Table 3 reports, in the second column,

the number of distinct mutated PDPs considering the

XACMET strategy, while in the third column those

related to the Multiple Combinatorial ones are pre-

sented. By analyzing the data in the table only four

of the nine XACML policies are evaluated by all mu-

tated PDPs set. Speciﬁcally, for the ﬁrst, second, sixth

and seventh policies listed in the Table, only the test

suite derived by the Multiple Combinatorial strategy

is able to execute all the mutated PDPs; for the last

policies neither of the two test suites is able to exe-

cute all the mutated PDPs.

Table 3: Number of Distinct MutatedPDP Evaluated by

XACML Policy and Strategy.

Xacml Policy # of Distinct MutatedPDP All

XACMET Mulitlple

2 73020419964 2 1540 8030 9570

create-document-policy 2712 8030 10742

demo-11 8030 8030 16060

demo-26 8030 8030 16060

demo-5 8030 8030 16060

read-document-policy 669 8030 8699

read-informationunit-policy 6938 8030 14968

read-patient-policy 8030 8030 16060

Xacml-Nottingham-Policy-1 1389 3442 4831

All 45368 67682 113050

The results reported in this table highlighted an

important criticality for the evaluation of the con-

trolled experiment metrics (Effectiveness and APFD).

Indeed, because there is a difference in the number

of distinct mutated PDPs for the two test suites, the

Hypotheses testing could be invalidated and conse-

quently also the answers to the target RQs. For a fair

experiment and evaluation, it is important to guaran-

tee that both strategies are evaluated using the same

set of mutated PDPs. Therefore, the data sets have

been reduced considering only the minimal common

set of mutated PDPs for each test strategy.

As natural consequence such reduction has also an

impact on the number of executions for the test suites

derived by the XACMET and the Multiple combina-

torial strategies as reported in Table 4. The compar-

ison of the data of this table with those reported in

the previous one (Table 2) shows that the reduction

has the biggest impact on the Multiple Combinatorial

strategy. For the sake of completeness we report, in

Table 5, the percentage of reduction of executions as-

sociated to each XACML policy.

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

112

Table 4: Number of Reduced Executions by XACML Pol-

icy and Strategy.

Xacml Policy # of Executions All

XACMET Mulitlple

2 73020419964 2 12320 92400 104720

create-document-policy 13560 32544 46104

demo-11 104390 321200 425590

demo-26 64240 128480 192720

demo-5 128480 674520 803000

read-document-policy 4014 20070 24084

read-informationunit-policy 27752 41628 69380

read-patient-policy 48180 240900 289080

Xacml-Nottingham-Policy-1 38892 22224 61116

All 441828 1573966 2015794

Table 5: % of Reduced Executions by XACML Policy and

Strategy.

Xacml Policy # of Distinct MutatedPDP % of Reduction

XACMET Mulitlple Multiple All

2 73020419964 2 1540 1540 81% 79%

create-document-policy 2712 2712 66% 58%

demo-11 8030 8030 0% 0%

demo-26 8030 8030 0% 0%

demo-5 8030 8030 0% 0%

read-document-policy 669 669 92% 90%

read-informationunit-policy 6938 6938 14% 9%

read-patient-policy 8030 8030 0% 0%

Xacml-Nottingham-Policy-1 1389 1389 60% 35%

ALL 45368 45368 31% 26%

5 RESULTS

According to (Juzgado and Moreno, 2001; Wohlin

et al., 2012), we applied the Paired T-Test to formally

verify the Null Hypothesis with the conﬁdence level

of 95%. This choice was a natural consequence of

the type of design adopted, i.e, the paired comparison.

Following the standard best practices, we decided to

accept a probability of 5% of committing a Type-1-

Error (Wohlin et al., 2012), i.e., the Null Hypothesis

is rejected if the computed p-value is less or equal to

0,05 (al pha = 0.05).

Stating from the data collected we generated the

necessary sample data so as to test each Null Hy-

pothesis formulated in Section 3. In the next subsec-

tions detailed results for each research question are

reported and discussed.

5.1 RQ 1: Effectiveness

As presented in Section 3 the aim of RQ 1 is to An-

alyze Multiple and XACMET Strategies for the pur-

pose of evaluation with respect to their test suite ef-

fectiveness from the point of view of the researcher

in the context of XACML PDP testing without con-

straints (i.e., considering the whole test suite gener-

ated).

A general attribute for the evaluation of the quality

of a test cases generation strategy is its effectiveness,

deﬁned in terms of number (or percentage) of mutated

PDPs killed. Therefore the effectiveness is calculated

as:

E f f ectiveness =

#mutatedPDPsKilled

#mutatedPDPs

It is important to remark that in order to correctly

compute this measure the number of distinct killed

mutants by each strategy and on each policy must be

considered. The samples relative to the effectiveness

of Multiple Combinatorial and XACMET test strate-

gies for Null Hypothesis testing (H

0E f f

) are reported

in Table 6 (columns 2 and 3). In particular, the up-

per part of the table reports the samples associated to

each test cases generation strategy, while the lower

part reports some statistical information of each sam-

ple. Both the strategies have a similar behaviour: the

test suites are able to kill less than 20% of the mutated

PDPs.

Table 6: RQ 1: Effectiveness and RQ 2: Size.

Xacml Policies Subjects Effectiveness Size

Multiple XACMET Multiple XACMET

2 73020419964 2 2,14 13,57 60 9

create-document-policy 15,30 14,93 16 5

demo-11 8,78 8,89 40 13

demo-26 7,67 8,97 16 8

demo-5 9,18 9,14 84 16

read-document-policy 19,88 19,43 30 6

read-informationunit-policy 8,59 8,91 6 4

read-patient-policy 7,68 8,79 30 6

Xacml-Nottingham-Policy-1 19,65 19,65 16 18

Samples Statistics

N 9 9 9 9

Missing Count 0 0 0 0

Mean 10,987 12,4766 33,1111 9,4444

Standard Deviation 5,988 4,6064 24,9822 5,0525

Standard Error Mean 1,996 1,5355 8,3274 1,6841

This informal observation is conﬁrmed also by the

results of the Paired T-test associated to H

0E f f

(Ta-

ble 7, column 2).

Because the p-value obtained is 0, 2705 > 0.05,

from the sample considered there is no difference

from the point of view of effectiveness between the

two test strategies.

For sure, the low values of fault detection effec-

tiveness obtained in this experiment are not encour-

aging for any kind of test strategy. However from

a deeper analysis we highlighted the two following

main reasons.

First, the choice of XACML policies: these are

real ones, therefore they contain the mostly used func-

tionalities and constructs. They are not artiﬁcially de-

veloped for testing objective; therefore, they are not

a complete representation of the XACML policy pop-

Assessing Testing Strategies for Access Control Systems: A Controlled Experiment

113

ulation. However, here the target is to asses the ef-

fectiveness of the test strategy on the few functions,

data types, XACML elements that are currently used

in the practice, so to focus as much as possible the

testing activity on the most critical aspects.

The second reason concerns the mutation oper-

ators adopted. The operators implemented in the

framework for the generation of mutated PDPs are the

standard ones and are applicable to any kind of Java

program. They do not consider the peculiarities of the

XACML language and therefore could not be targeted

by the XACML requests used as a tests input.

Thanks to this analysis we were able to discover

two possible important improvements for the imple-

mented testing framework as well as precious hints

for future research activity in improving the mutation

operators set and test strategy deﬁnitions.

5.2 RQ 2: Size

As presented in section 3, the aim of the RQ 2 is to

Analyze Multiple and XACMET Strategies for the

purpose of evaluation with respect to their cost in

terms of number of test cases generated from the

point of view of the researcher in the context of bud-

get programming.

An important aspect for the selection of a test

cases generation strategy is its cost evaluated in terms

of: the time for the test cases execution and the time

necessary for the debugging activity. Supposing that

each test case has potentially the same impact on the

overall testing effort, the execution time becomes di-

rectly connected with the number of test cases exe-

cuted: i.e., the size of a test suite represents also its

cost.

The samples relative to the sizes of Multiple

Combinatorial and XACMET test strategies for Null

Hypothesis testing (H

0Size

) are reported in Table 6

(columns 4 and 5). In particular, the upper part of

the table reports the samples associated to each test

cases generation strategies, while the lower part re-

ports some statistical information of each sample.

Except for Xacml-Nottingham-Policy-1 policy,

XACMET strategy generates smaller test suites with

respect to those generated by Multiple combinato-

rial. Considering the size metric, the test suites of

XACMET cost about 70% less than those of Multiple

Combinatorial one, but reaching the same quality in

terms of errors found or mutants killed.

This result is formally conﬁrmed by the Paired T-

test associated to H

0Size

and illustrated in Table 7, col-

umn 3. The p-value obtained (0, 0253 < 0.05) sug-

gests, rejecting the Null Hypothesis H

0Size

, of no dif-

ference from the point of view of the size between the

Table 7: Paired T-Test: RQ 1 (Effectiveness) and RQ

2(Size).

RQs RQ 1 RQ 2

Label Multiple - XACMET

t -1,1838 2,7426

df 8 8

p-value (2-tailed) 0,2705 0,0253

Mean -1,4896 22,6667

Standard Deviation 3,7749 24,7942

Standard Error Mean 1,2583 8,2647

CI (Lower Bound) -4,3913 3,6082

CI (Upper Bound) 1,412 41,7251

two test strategies. Therefore we can conclude that the

XACMET strategy outperformed Multiple strategy in

terms of cost.

5.3 RQ 3: APFD

As presented in section 3 the aim of RQ 3 is to An-

alyze Multiple and XACMET Strategies for the pur-

pose of evaluation with respect to their effectiveness

in terms of APFD from the point of view of the re-

searcher in the context of interruption of XACML

PDP testing activity.

For unexpected time constraints or budgets reduc-

tion reasons, the testing activity could be interrupted

before its overall completion. In this case, not all the

test case could be executed with a consequent risk for

the ﬁnal quality and efﬁciency of the product devel-

oped.

In this case, the standard metrics adopted for mea-

suring such a risk is the APFD metric, which is calcu-

lated by taking the weighted average of the percent-

age of faults detected during the execution of the test

suite. It is formally deﬁned as follows (Elbaum et al.,

2002):

APFD =

∑

n−1

i=1

n × l

where, n is the number of test cases in the test suite T,

l is the number of faults, and F

is the number of faults

detected by at least one test case among the ﬁrst i test

cases in T.

By construction, APFD values range from 0 to

1; higher values imply faster (better) fault detection

rates. Thus APFD is commonly used to evaluate the

prioritization techniques because it is able to estimate

the speed with which an ordered test suite can reach

the maximum number of discovered faults. In other

words, it is the measure of how quickly the faults are

detected by a testing strategy. Improving the rate of

fault detection can have an impact on the testing cost

and effort: software engineers may locate and correct-

ing faults earlier in advance and better evaluate the

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

114

risk of test activity interruption (Elbaum et al., 2002;

Bertolino et al., 2015).

Since the APFD measure is connected to the con-

cept of (ordered) test suites having the same cardinal-

ity, its application in this experiment requires that the

number of XACML requests generated by the Multi-

ple Combinatorial and XACMET test strategy is the

same. For this, the following corrective actions have

been applied:

Test suite size and requests selection the cardinality

N of the test suite has been ﬁxed to the minimum

one between the values of the Multiple Combina-

torial and XACMET test strategy and the N test

cases randomly selected among those available.

Prioritize the test cases each reduced test suite has

been ordered in terms of mutated PDPs killed, so

to assure the optimal fault detection effectiveness

of each set.

APFD calculation for each ordered test suite the

APFD has been calculated.

Considering in detail the Prioritize the test cases

action, the technique used, called mutation-based

heuristic, is a greedy-optimal selection of test cases

computed on the mutation coverage. The heuristic is

a sub-optimal algorithm, since it orders the test cases

according to the cumulative number of different mu-

tants killed. For implementing the selected heuris-

tic the mutated PDPs killed by each test case have

been organized into a matrix (request, mutated PDPs)

where each cell(i, j) is equal to 1 if the i-th request

kills the j-th mutated PDP, and 0 otherwise.

Informally, the algorithm for implementing the

mutation-based heuristic works as follows:

1. it calculates the number of killed PDPs for each

request;

2. it selects the request s.t. the number of killed

PDPs is maximum;

3. it removes the request and the mutated PDPs

killed by such request from the matrix;

4. it repeats the steps 1-3 until all requests are se-

lected.

To avoid experimental bias, the above steps have

been repeated ten times and the APFD computed.

The samples relative to the APFD of Multiple

Combinatorial and XACMET test strategies for Null

Hypothesis testing (H

0APFD

) are reported in Table 8

(columns 2 and 3). In particular the upper part of

the table reports the samples associated to each test

case generation strategies, while the lower part reports

some statistical information of each sample. The re-

sults of the Paired T-test associated to H

0APFD

are il-

lustrated in Table 9. Because the p-value obtained is

Table 8: RQ 3: APFD.

Xacml Policies Subjects APFD

Multiple XACMET

2 73020419964 2 0,932588598 0,9159689

create-document-policy 0,843173312 0,876790123

demo-11 0,956210668 0,953673777

demo-26 0,931931707 0,917708333

demo-5 0,964039803 0,965003406

read-document-policy 0,874445036 0,905128205

read-informationunit-policy 0,779981164 0,849919094

read-patient-policy 0,85009274 0,893767705

Xacml-Nottingham-Policy-1 0,980102041 0,978416605

Samples Statistics

N 9 9

Mean 0,9014 0,9174

Standard Deviation 0,0676 0,0422

Standard Error Mean 0,0225 0,0141

Table 9: Paired T-Test: RQ 3(APFD).

RQs RQ 3

Label XACMET - Multiple

t 1,6135

df 8

p-value (2-tailed) 0,1453

Mean 0,016

Standard Deviation 0,0297

Standard Error Mean 0,0099

Conﬁdence Interval Probability 0.95

Conﬁdence Interval of the Difference (Lower Bound) -0,0069

Conﬁdence Interval of the Difference (Upper Bound) 0,0388

0, 1453 > 0.05, from the sample considered there is

no difference from the point of view of the APFD be-

tween the two test strategies, i.e., XACMET and Mul-

tiple Combinatorial have the same velocity in reach-

ing their effectiveness.

6 RELATED WORK

The work presented in this paper spans over two main

research directions: (1) XACML based test gener-

ation strategies and (2) modeling and supporting of

controlled experiment in the context of access control

systems.

XACML based Tests Generation. Considering

the automated test cases generation, solutions have

been proposed for testing either the XACML pol-

icy or the PDP implementation (Bertolino et al.,

2014; Bertolino et al., 2013b). Among them, the

most referred ones use combinatorial approaches

for test cases generation. Speciﬁcally, the X-

CREATE tool (Bertolino et al., 2013b) and the Tar-

gen tool (Martin and Xie, 2006) generate test in-

puts using combinatorial approaches of the XACML

policies values and the truth values of independent

Assessing Testing Strategies for Access Control Systems: A Controlled Experiment

115

clauses of policy values, respectively, whereas the

work in (Pretschner et al., 2008) applies combinato-

rial analysis to the elements of the model (role names,

permission names, context names) to derive test cases.

Alternatively, the Cirg approach (Martin and Xie,

2007) applies change impact analysis for test case

generation starting from policy speciﬁcation. Speciﬁ-

cally, it provides a framework able to derive test cases

as counterexamples that evidence semantic difference

between two different versions of the policy under

test.

Other approaches leverage existing symbolic ex-

ecution techniques for generating test cases. Speciﬁ-

cally, in (Li et al., 2014), ﬁrst the access control policy

under test is converted into semantically equivalent C

Code Representation (CCR). Then, the CCR is sym-

bolically executed to generate test inputs.

Differently from the above approaches, the work

in (Daoudagh et al., 2019b) proposes the XACMET

strategy based on the expected behavior of an

XACML-based PDP. XACMET models the expected

behaviour of the evaluation of a given XACML policy

as a labeled graph and guarantees the full path cover-

age of such graph. The test cases generated are used

only for the PDP testing purposes. The main beneﬁts

of XACMET deal with i) the derivation of XACML

requests that explicitly take into account the seman-

tics of XACML functions as well as the policy and

rule combining algorithms; ii) the derivation for each

test request of its expected verdict.

In the controlled experiment presented in this

paper, we aim to compare the Multiple Combina-

torial strategy implemented into X-CREATE tool

(Bertolino et al., 2013b) and the XACMET strat-

egy (Daoudagh et al., 2019b) in terms of effective-

ness, size and APFD.

Supporting Controlled Experiment. Empirical

validations play a key role in the evaluation of a soft-

ware system. Validation in software engineering dis-

cipline, as in other research ﬁelds, relies on build-

ing different models of this discipline, i.e., modeling

the objects of the domain, the processes manipulating

the objects, the relations between processes and ob-

jects (Wohlin et al., 2012). The authors of (Wohlin

et al., 2012) give ﬁrst an overview of empirical strate-

gies such as surveys, case studies, experiments and

then deﬁne the main steps of experiment process such

as scoping, planning, operation, analysis and interpre-

tation, presentation and package.

The work in (Briand and Labiche, 2004) discusses

speciﬁc challenges and issues of performing empiri-

cal studies with software testing techniques whereas

the authors of (Do et al., 2005) identify two main

complementary classes of empirical studies addressed

in software testing: case studies (Runeson and H

ost,

2008) and controlled experiments (Jedlitschka and

Pfahl, 2005).

Controlled experimentation in software testing

leverages numerous software artifacts, including for

instance different versions of software systems, test

suites, test object, fault data, mutated software. Ob-

taining such artifacts and organizing them in an envi-

ronment able to support controlled experimentation is

a difﬁcult task.

The work in (Do et al., 2005; Do et al., 2004)

presents ﬁrst a survey of papers on testing that pro-

vide empirical studies identifying the main challenges

of experimentation in software testing. These identi-

ﬁed challenges are then used for designing and con-

structing an extensible infrastructure able to support

controlled experimentation with software testing and

regression testing techniques. This infrastructure pro-

vides guidelines for object selection, organization,

and setup processes with the aim of reducing the costs

of executing and replicating controlled experiments as

well as aggregating results across experiments.

In this paper, we aim to leverage the advantages

of the controlled experiments in the context of access

control by deﬁning and executing a controlled exper-

iment for the evaluation of two test cases generation

strategies adopted in literature.

7 DISCUSSION AND

CONCLUSIONS

Automation and replication are two important aspects

for the assessment of the effectiveness of different

testing strategies and key factors for the overall testing

process. Thus, the target of the paper: deﬁning and

executing a controlled experiment for the compari-

son of two test cases generation strategies, speciﬁcally

Multiple Combinatorial and XACMET approach, in

the context of access control.

According to the analysis and results in the pre-

sented experiment, the two strategies have the same

effectiveness (RQ1) and behaviour in terms of APFD

(RQ3), while they are signiﬁcantly different in terms

of cardinality of the test suites (RQ2), and therefore

in their cost. This means that in case of budgets or

effort constraints, because both of the test strategies

provided the same performance in terms of fault de-

tection, applying the XACMET approach could be a

winning solution for reducing testing time and guar-

anteeing the same product quality.

A crucial aspect emerged during the comparative

experiment analysis, that has never been considered

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

116

before in the literature related to the assessment of

XACML based systems: during the test suite execu-

tion, there is the possibility that different sets of dis-

tinct Mutated PDPs can be executed by different test

strategies. Ignoring such data evidence and compar-

ing the test strategies just in terms of effectiveness or

APFD could really produce invalid conclusions and

therefore wrong test strategy selection. By leveraging

XMF and the data collected during the experiment ex-

ecution, the mitigation of such a risk was possible and

a correct evaluation provided.

Concerning the validity of the experiment, i.e., the

amount of conﬁdence in the results, the important key

factors are Subjects, Object and Parameters of the ex-

periment. Here below the strategies used to minimize

the threats to validity are described.

With respect to conﬁdence in the results, the con-

trolled experiment used data and measurements that

satisfy the principles of independence, homogeneity

and normality.

With respect to internal validity the crucial points

are: the policy used, the PDP engine selected and the

tool integrated for the generation of the mutants set.

Concerning the Subject of the experiment, the poli-

cies included in the XMF framework are a good rep-

resentative of real world XACML Policies, because

they contain most of the constructs and functionalities

actually used in the practice. However different poli-

cies, like for instance those of XACML conformance

test suite, may produce different results. The Object

of the experiment, i.e., the Sun PDP implementation

integrated in the XMF framework, is one of the most

adopted in access control systems and therefore its

quality and performance are well established. How-

ever, different XACML-based implementations could

be considered. Finally, considering the Parameter of

the experiment, i.e., the tool integrated for the deriva-

tion of the mutants set, we included the already ex-

isting µJava tool because it is one of the most widely

used in object oriented environment. Previous works

guarantee that its performance can be comparable to

others available, however it could be possible that

other mutation tools may produce different results.

With respect to external validity, we compared

two test strategies: Multiple Combinatorial test strat-

egy, provided by X-CREATE, which is one of the

most referred in the context of access control systems,

and an innovative one, the XACMET test strategy,

so as to have elements of comparable performance.

Other strategies could have been considered and dif-

ferent results provided, but the purpose was only to

show the use of controlled experiment for test strat-

egy comparison and not to select the best one.

For future work, we plan to generalize our con-

trolled experiment by considering different subjects,

for instance the conformance test suite, different ob-

jects, i.e., different PDPs, and extend the set of con-

sidered dependent variables. Moreover, we plan to

deﬁne and perform further controlled experiments in

the context of access control for evaluating other test-

ing techniques, for mutation generation or test suites

reduction or prioritization.

ACKNOWLEDGEMENTS

This work is partially supported by CyberSec4Europe

Grant agreement ID: 830929.

REFERENCES

(2019). Fedora Commons Repository Software. http:

//fedora-commons.org/.

Basili, V. R. and Rombach, H. D. (1988). The tame

project: towards improvement-oriented software envi-

ronments. IEEE Transactions on Software Engineer-

ing, 14(6):758–773.

Bertolino, A., Daoudagh, S., Kateb, D. E., Henard, C.,

Traon, Y. L., Lonetti, F., Marchetti, E., Mouelhi, T.,

and Papadakis, M. (2015). Similarity testing for ac-

cess control. Information and Software Technology,

58:355 – 372.

Bertolino, A., Daoudagh, S., Lonetti, F., and Marchetti, E.

(2012a). Automatic XACML Requests Generation for

Policy Testing. In Proc. of ICST, pages 842–849.

Bertolino, A., Daoudagh, S., Lonetti, F., and Marchetti, E.

(2012b). Modelling and Testing of XACML policies.

In 2012-TR-010.

Bertolino, A., Daoudagh, S., Lonetti, F., and Marchetti., E.

(2013a). XACMUT: XACML 2.0 Mutants Generator.

In Proc. of 8th International Workshop on Mutation

Analysis, pages 28–33.

Bertolino, A., Daoudagh, S., Lonetti, F., and Marchetti, E.

(2018). An automated model-based test oracle for ac-

cess control systems. In Proceedings of the 13th In-

ternational Workshop on Automation of Software Test,

AST@ICSE 2018, Gothenburg, Sweden, May 28-29,

2018, pages 2–8.

Bertolino, A., Daoudagh, S., Lonetti, F., Marchetti, E., Mar-

tinelli, F., and Mori, P. (2014). Testing of polpa-

based usage control systems. Software Quality Jour-

nal, 22(2):241–271.

Bertolino, A., Daoudagh, S., Lonetti, F., Marchetti, E., and

Schilders, L. (2013b). Automated testing of extensible

access control markup language-based access control

systems. IET Software, 7(4):203–212.

Briand, L. and Labiche, Y. (2004). Empirical studies of soft-

ware testing techniques: Challenges, practical strate-

gies, and future research. SIGSOFT Softw. Eng. Notes,

29(5):1–3.

Assessing Testing Strategies for Access Control Systems: A Controlled Experiment

117

Daoudagh, S., Lonetti, F., and Marchetti, E. (2019a). A

framework for the validation of access control sys-

tems. In Saracino, A. and Mori, P., editors, Proceed-

ings of the 2nd International Workshop on Emerging

Technologies for Authorization and Authentication.

Daoudagh, S., Lonetti, F., and Marchetti, E. (2019b).

XACMET: XACML Testing & Modeling. Software

Quality Journal.

Do, H., Elbaum, S., and Rothermel, G. (2004). Infrastruc-

ture support for controlled experimentation with soft-

ware testing and regression testing techniques. In Em-

pirical Software Engineering, 2004. ISESE’04. Pro-

ceedings. 2004 International Symposium on, pages

60–70. IEEE.

Do, H., Elbaum, S., and Rothermel, G. (2005). Supporting

controlled experimentation with testing techniques:

An infrastructure and its potential impact. Empirical

Software Engineering, 10(4):405–435.

Elbaum, S., Malishevsky, A. G., and Rothermel, G. (2002).

Test case prioritization: A family of empirical stud-

ies. IEEE Transactions on Software Engineering,

28(2):159–182.

Hu, C. T., Ferraiolo, D. F., Kuhn, D. R., Schnitzer, A., San-

dlin, K., Miller, R., and Scarfone, K. (2019). Guide

to attribute based access control (abac) deﬁnition and

considerations [includes updates as of 02-25-2019].

Technical report.

Jedlitschka, A. and Pfahl, D. (2005). Reporting guidelines

for controlled experiments in software engineering. In

Empirical Software Engineering, 2005. 2005 Interna-

tional Symposium on, pages 10–pp. IEEE.

Jin, X., Krishnan, R., and Sandhu, R. (2012). A uniﬁed

attribute-based access control model covering dac,

mac and rbac. In Data and Applications Security

and Privacy XXVI, pages 41–55, Berlin, Heidelberg.

Springer Berlin Heidelberg.

Just, R. (2014). The major mutation framework: Efﬁcient

and scalable mutation analysis for java. In Proceed-

ings of the 2014 international symposium on software

testing and analysis, pages 433–436. ACM.

Juzgado, N. J. and Moreno, A. M. (2001). Basics of soft-

ware engineering experimentation. Kluwer.

Li, Y., Li, Y., Wang, L., and Chen, G. (2014). Automatic

xacml requests generation for testing access control

policies. In SEKE, pages 217–222.

Ma, Y.-S., Offutt, J., and Kwon, Y.-R. (2006). MuJava: a

mutation system for Java. In Proceedings of the ICSE,

pages 827–830.

Madeyski, L. and Radyk, N. (2010). Judy - a mutation test-

ing tool for java. IET Software, 4(1):32–42.

Martin, E. and Xie, T. (2006). Automated test generation

for access control policies. In Supplemental Proc. of

ISSRE.

Martin, E. and Xie, T. (2007). Automated test generation for

access control policies via change-impact analysis. In

Proc. of SESS, pages 5–11.

Martin, E., Xie, T., and Yu, T. (2006). Deﬁning and measur-

ing policy coverage in testing access control policies.

In Proc. of ICICS, pages 139–158.

Mouelhi, T., Fleurey, F., and Baudry, B. (2008). A generic

metamodel for security policies mutation. In Proc. of

ICSTW, pages 278–286.

OASIS (22 Jan 2013). eXtensible Access Con-

trol Markup Language (XACML) Version 3.0.

http://docs.oasis-open.org/xacml/3.0/xacml-3.

0-core-spec-os-en.pdf.

Pretschner, A., Mouelhi, T., and Le Traon, Y. (2008).

Model-based tests for access control policies. In Proc.

of ICST, pages 338–347.

Runeson, P. and H

ost, M. (2008). Guidelines for conduct-

ing and reporting case study research in software engi-

neering. Empirical Software Engineering, 14(2):131.

Sandhu, R. S. and Samarati, P. (1994). Access control: prin-

ciple and practice. IEEE Communications Magazine,

32(9):40–48.

Schuler, D. and Zeller, A. (2009). Javalanche: Efﬁcient mu-

tation testing for java. In Proceedings of ESEC/FSE,

pages 297–298, New York, NY, USA. ACM.

seung Ma, Y., Offutt, J., and Kwon, Y. R. (2005). Mujava

: An automated class mutation system. Journal of

Software Testing, Veriﬁcation and Reliability, 15:97–

133.

Sun Microsystems (2006). Sun’s XACML Implementation.

http://sunxacml.sourceforge.net/.

TAS3 Project. Trusted Architecture for Securely Shared

Services. https://cordis.europa.eu/project/rcn/85331/

results/en.

Wohlin, C., Runeson, P., H

ost, M., Ohlsson, M. C., Reg-

nell, B., and Wessl

en, A. (2012). Experimentation in

software engineering. Springer Science & Business

Media.

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

118
