Accountant: Protection of Data Integrity and Identiﬁcation of Malicious

Nodes in In-network Data Processing

David Jost and Mathias Fischer

Universität Hamburg, Germany

Keywords:

Data Aggregation, Distributed Networks, Integrity, Attacker Identiﬁcation, Sensor Networks.

Abstract:

Data integrity in distributed data sensing and processing platforms or middlewares is an important issue,

especially if those platforms are open to anyone. To leverage the resources of participating nodes and to

enhance the scalability, nodes can be included in the data processing, e.g., in the aggregation of results. In an

open system, it is also likely that some participating nodes are malicious and lie about their sensed values or

about the results of data processed by them. Current approaches that preserve data integrity for in-network

processing require expensive cryptographic operations. With Accountant we propose a new approach, which

requires signiﬁcantly less computation at the expense of slightly more signalling overhead. Furthermore, our

approach cannot only preserve data integrity, but also allows to identify malicious nodes. For that, Accountant

uses multiple inner node-disjoint trees for data dissemination and hash trees for preserving the data integrity.

We compare it to existing solutions, showing that with only minor additional messaging overhead, Accountant

can protect the data integrity and can identify attackers at the same time.

1 INTRODUCTION

Smart cities are in close reach. They beneﬁt from

the rise of the Internet of Things (IoT) that manifests

in a multitude of deployed sensors that add to the

knowledge base of cities. These sensors, e.g., raise

large quantities of environmental data that is of in-

terest to (city) governments, organisations, but also

citizens (Bornholdt et al., 2019, Kumar and Madria,

2013).

To orchestrate sensors, and to store and process

the resulting data volume, distributed data sensing and

processing platforms or middlewares are deployed,

e.g., SANE (Bornholdt et al., 2019, Villanueva et al.,

2013, Mohamed et al., 2017). Some of these distrib-

uted platforms also come with in-network data pro-

cessing to make efﬁcient use of the resources of par-

ticipating nodes, e.g., for data aggregation (Fasolo

et al., 2007). Relaying nodes aggregate received data

to forward only single values and to reduce the data

to be exchanged.

However, especially in open data sensing and pro-

cessing platforms, nodes can be malicious and might

inject false data. The state of the art contains several

approaches, e.g., (Mahimkar and Rappaport, 2004,He

et al., 2008, Chen et al., 2012, Kumar and Madria,

2013), that can protect the data integrity during such

distributed data processing. However, all of them use

expensive cryptographic operations.

The main contribution of this paper is Accountant,

an integrity preserving data processing scheme that

can identify malicious nodes injecting either faked

values or suppressing the results of other nodes. The

approach focuses on data sensing and processing plat-

forms, like the SANE platform (Bornholdt et al.,

2019), in which in theory every node could commu-

nicate with any other node. Another assumption is

that nodes contribute to the measurements, directly

when the node is a sensor or indirectly when the

node is acting on behalf of attached sensors. For

this reason, it cannot be applied directly to Wireless

Sensor Networks (WSNs), but might be used to inter-

connect the base stations of different WSNs. Every

node joining the system is contributing its resources

for data sharing and processing. To ensure that the

in-network processing produces the correct outcome,

Accountant uses multiple inner node-disjoint overlay

trees. As a result, malicious nodes cannot lie about

the values of their children anymore. They can only

inﬂuence the result in the tree they are actually for-

warding information. In all other trees they are in

a leaf position. Accountant even goes one step fur-

ther and allows to identify malicious nodes. For that,

the integrity of exchanged information is protected by

Jost, D. and Fischer, M.

Accountant: Protection of Data Integrity and Identiﬁcation of Malicious Nodes in In-network Data Processing.

DOI: 10.5220/0008974405610568

In Proceedings of the 6th International Conference on Information Systems Security and Privacy (ICISSP 2020), pages 561-568

ISBN: 978-989-758-399-5; ISSN: 2184-4356

561

mapping exchanged message values to hash trees. We

evaluate the performance of Accountant by compar-

ing its message overhead and cryptographic overhead

to existing approaches. Our analysis indicates that

Accountant requires less computational power at the

expense of slightly more communication overhead.

The remainder of this paper is structured as fol-

lows: Section 2 describes the considered attacker

model, followed by related work in the ﬁeld of integ-

rity preservation in distributed networks in Section 3.

Accountant is described in detail in Section 4 and ana-

lyzed in Section 5. Finally, Section 6 concludes the

paper.

2 ATTACKER MODEL

In an open and distributed data sensing and processing

platform, data is contributed by most nodes in the net-

work and processed in a distributed fashion. Nodes

that forward data for others can modify, aggregate,

and relay data of other nodes. This results in differ-

ent attacker models, which attempt to modify the ﬁnal

aggregation result, described in the following:

• A node may lie about its own sensed values, but

does not lie consistently across different aggrega-

tion trees. This misinformation propagates in the

aggregation process and results in a wrong overall

result.

• The attacker may alter the data it receives from

other nodes, which it is supposed to aggregate.

The forwarded data then does not represent the

children’s original data anymore.

• A node may deny or suppress the data it received

from child nodes.

Furthermore, these three attacker types can come

at different numbers, and can either operate independ-

ently or in a colluding manner.

3 RELATED WORK

There exists a large body of work in the area of sensor

networks, and distributed data processing in such net-

works (Fasolo et al., 2007). These approaches are en-

abling aggregation over arbitrary networks, but can-

not preserve the integrity of the aggregated data. Cer-

tain concepts also take data integrity into account

(Mahimkar and Rappaport, 2004,He et al., 2008,Chen

et al., 2012, Kumar and Madria, 2013). Even though

these integrity preserving approaches are considered

for low power environments, they require either rel-

atively complex asymmetric cryptography, or a lot of

additional messaging. The following describes some

of those works, and highlights their problems in re-

gard to our goal of providing efﬁcient integrity pro-

tection and liar identiﬁcation in distributed networks.

SecureDAV (Mahimkar and Rappaport, 2004)

uses clusters to group nodes. Each cluster has spe-

cial node, the cluster head, which aggregates the data

of all the other nodes in the cluster. Afterwards, the

cluster head sends the aggregate back to its children,

so that they conﬁrm the legitimacy of the aggrega-

tion. The child nodes verify that the aggregate lies

within a certain threshold. If so, they sign the aggreg-

ate with their part of a secret share, which the cluster

head subsequently combines, to obtain a full signature

for the base station. Should not enough sensors confer

with the aggregation of the cluster head, the resulting

signature would be invalid. Additionally, the sensors

sign their values with a private key, from which the

cluster head constructs a Merkle Hash Tree (Merkle,

1990), veriﬁable by the base station. This avoids over-

reliance on the cluster heads. SecureDAV requires

asymmetric cryptographic operations, resulting in a

lot of computational load on sensors. Even though

the Merkle Hash Tree provides integrity, it is not used

to identify an attacker.

Sensors in iPDA (He et al., 2008) split their data

into multiple slices, encrypt them with pre-shared

keys, and send them to different aggregators. With

this, a sensor hides its value from a single aggregator,

preserving its data privacy. Intermediate nodes can

(additively) aggregate the received values and send

their aggregate towards the base station. Integrity is

provided by using multiple node-disjoint trees, where

nodes send their results over both trees, which do not

share any common nodes (except root). iPDA as well

does not provide any means to identify the source of

the mismatching values.

RCDA (Chen et al., 2012) provides data integrity

and raw data recoverability by encoding sensor data

into the stream of messages, allowing the base station

to recover all data and verify the result. The encod-

ing is effectively the original data stringed together.

It is encrypted with Elliptic Curve ElGamal (EC-EG)

and signed with the homomorphic signature scheme

by Boneh et al. (Boneh et al., 2003), both of which

allow for additive aggregation. In the end, the base

station is able to decode and verify all measurements.

This approach sends the entire raw data up to the base

station for it to verify. Additionally, it uses asymmet-

ric cryptography and does not identify the lying node.

Lastly, PIP (Kumar and Madria, 2013) describes a

scheme where nodes ﬁrst encrypt their data with EC-

EG, before splitting it and distributing it to neighbour-

ing nodes. This provides a certain anonymity towards

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

562

the cluster head, which will eventually receive all

parts from all its children, without being able to attrib-

ute it to one in particular. Integrity is provided via an

embedded integrity key, which can only be veriﬁed by

the base station. Aggregation is performed as of the

homomorphic properties of Shamir’s Secret Sharing

(SSS) and Recursive Secret Sharing (RSS, (Parakh

and Kak, 2010)) and a scrambling key. Similar to the

other approaches, PIP uses asymmetric cryptography

and does not detect which node actually lied.

These approaches show different ways on employ-

ing data integrity for in-network aggregation. Neither

of them takes attribution into account and most re-

quire rather intensive cryptographic operations. Thus

a new approach must integrate the identiﬁcation of at-

tackers into the integrity preservation while staying

lightweight.

4 SYSTEM MODEL

To perform aggregation in a structured manner, Ac-

countant utilises overlay trees to organise message

routing. It uses multiple inner node-disjoint trees,

so that data aggregation is performed over all trees in

parallel. The differently structured trees allow to dis-

close lying nodes and prevent denying nodes to sup-

press results of any of its children. By using enough

trees, a majority of valid results will be established,

exposing any incorrect behaviour. To identify the at-

tacker, cryptographic hashes in the form of a hash tree

are used. This allows Accountant to follow mismatch-

ing hashes and pinpoint the lying node in case the ag-

gregation results of different trees do not match. Sec-

tions 4.2 and 4.3 describe the overlay trees and hash

tree in more detail.

Accountant operates in two major phases. The

ﬁrst one is data aggregation (cf. Section 4.4), where

the nodes organized in overlay trees answer the re-

quest for data that is ﬂooded in the trees starting from

the root node r. The data aggregation starts at the

leaf nodes that forward their values to their parent

nodes. Intermediate nodes aggregate their value with

the ones obtained from their children, and forward the

result to their parents in all trees again. In addition,

each node adds a unique hash to its message. Ag-

gregating nodes combine those hashes according to

the rules of the hash tree computation. Reaching the

root node, the aggregated data of each overlay tree can

be compared with the others. If there are differences

in the results, a node has suppressed or lied about val-

ues of its children. This triggers the second phase.

In the second phase (cf. Section 4.5), lying nodes

are identiﬁed by using the information of overlay

trees and the hash tree. As the overlay trees provide

a majority of correct values, the erroneous trees can

easily be detected. The reported hashes of the er-

roneous trees are reproduced with hashes from cor-

rect ones, and the procedure follows level by level the

mismatching hashes. In the end, Accountant requires

only a subset of all hashes to actually identify the at-

tacker.

4.1 Assumptions

For our approach, we use the following assumptions:

• All nodes share a unique (symmetric) key (K

i,r

∀i ∈ V ) with the root node r, to allow them to

authenticate their hashes without having to use

asymmetric cryptography. We assume that every

node has obtained a certiﬁcate once during an ini-

tial bootstrapping from the root r. Both derive the

symmetric key from this as well as the unique re-

quest id, allowing them to share the secret without

directly exchanging it.

• Each node is an intermediate node in at most one

overlay tree and a leaf node in all others, as de-

scribed in Section 4.2.

• All nodes in the overlay can reach each other if

required.

4.2 Overlay Tree Construction

For Accountant to note differences in the aggregation,

it requires comparable aggregation results. These are

received via different overlay trees. All trees share

the same nodes, they are just differently ordered, such

that any node is an intermediate node in at most one

of those trees and a leaf node in all others (except the

root node that always stays the same). These inner

node-disjoint trees, as proposed by (Brinkmeier et al.,

2009), allow do disclose a malicious node that lies

about or drops the value of its children.

Figure 1 displays three trees with the same nodes,

rearranged accordingly to exhibit the property of in-

ner node-disjointness. The root node stays ﬁxed, as

it is the initiator of the requests. The graphic also

illustrates why those trees are necessary in the ﬁrst

place: Assuming node 2 is malicious, then it is able

to lie about the values of its children 3, 4, and 5 in

, without being noticed. But taking the other trees

into account, 2 has no longer the ability to inﬂuence

or dismiss the values any of its children sends to their

parent without being noticed. Thus, at the top of the

tree, the difference in values is visible.

For Accountant actually being able to identify in

which tree the error occurred, a majority of valid trees

Accountant: Protection of Data Integrity and Identiﬁcation of Malicious Nodes in In-network Data Processing

563

11 12

(a) T

1 2

(b) T

Figure 1: Three trees, constructed as described in Section 4.2, where each node is intermediate in at most one tree. As r is

ﬁxed, it is enough to only regard one subtree here to show the constraints.

with valid results is required. Thus, with m being

the number of attackers, n = 2m + 1 trees (Lamport,

2006) are necessary to obtain a correct result.

To meet the requirement of any node being in an

intermediate position in at most one tree, for all n

trees, it is necessary to use trees with enough leaf po-

sitions available. Equation 1 shows that this is solved

by setting the node degree d to at least the number of

trees n. l represents the required amount of leaf nodes

and N the number of total nodes in a tree.

l ≥ n ·bN/dc (1)

4.3 Hash Tree

To be able to identify misbehaving nodes, Accountant

uses a Merkle Hash Tree (Merkle, 1990). As can be

seen in Figure 2, each node’s hash represents a leaf

in the hash tree. They are then combined pairwise,

leading to a ﬁnal hash (h

1−8

in Figure 2). This reduces

the number of required hashes per level to represent

the same data. A combined hash can be reproduced

later on by combining the hashes it stems from.

Aggregating nodes of the overlay tree follow the

schema of the hash tree to combine hashes of their

descendants as soon as possible. As the overlay trees

differ in their order, nodes may not pass on the same

hashes in one tree as they do in another. Nonetheless

hashes are always combined in the same order as dic-

tated by the hash tree, which may result in aggregating

nodes passing on more than one hash, before they are

combined later on.

To indicate a hash of node i, generated in a speciﬁc

overlay tree t, h

is used.

4.4 Phase 1: Data Aggregation

The ﬁrst phase of Accountant describes the request

and aggregation of data. It may be divided into those

two stages of request and aggregation. All actions

are performed for each overlay tree individually. This

1−8

1−4

1−2

3−4

5−8

5−6

7−8

Figure 2: Design of a hash tree for eight sources.

allows us to focus on operations in one tree for now,

though they are applied for each tree.

In the stage of request, the root node r ﬂoods a

request for data on all available trees. This request

is then answer via a reverse-multicast starting at the

leaf positions in all overlay trees that are constructed

as described in Section 4.2. This allows r to gather

multiple views on the same data.

Aggregation: Leaf nodes answer directly with

their data v

and the hash h

of that data, which is com-

bined with the shared secret K

i,r

and a nonce ω (sup-

plied by r during the request) of that request (cf. Equa-

tion 3) to make it unique. Intermediate nodes aggreg-

ate the values received by their children together with

their own value (cf. Equation 2). Additionally, they

extend the list of hashes with their own and combine

any hashes according to the hash tree as given in Sec-

tion 4.3 (cf. Equation 4). As of the ﬁxed nature of the

hash tree, it will not correspond to the structure of the

overlay tree. Thus, nodes may send more than just

one hash, though combining as many as possible.

agg(i) = v

◦





j∈succ(i)

agg( j)



(2)

= hash(v

,ω,K

i,r

) (3)

data

= (v

,agg(i),{h

,...}) (4)

To provide an example, Figure 3 shows an excerpt

of the sent data in T

(cf. Figure 1a). Here, node 3

sends it data up to its parent 2. Node 2, being an inter-

mediate node, then combines all received values with

its own, producing the aggregate agg(2,3,4,5). Ad-

ditionally, the corresponding hashes are constructed:

the hashes of nodes 3 and 4 can be combined to h

3−4

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

564

data

= (v

,agg(3),{h

})

data

= (v

,agg(2,3,4,5), {h

3−4

})

Figure 3: Example of data sent in phase 1.

so that node 2 sends the set of h

, h

, and h

3−4

to its

parent 1.

Upon receiving the aggregations from the multiple

overlay trees, r can compare them with each other.

If not all off them match, an inconsistency has been

detected and phase 2 of identifying the liar can begin.

4.5 Phase 2: Identiﬁcation of Lying

Nodes

The second phase tries to iteratively narrow down the

lying node. Starting at the root it follows unmatching

hashes down the corresponding subtrees, eventually

leading to the lying node, i.e., the attacker.

Due to the majority of well-behaving trees

(cf. Section 4.2), we know which trees provided truth

and can limit the search to the erroneous trees. In the

example of one attacker (m = 1), this would also lead

to only one tree being investigated, as the other two

would match with each other.

Starting at the root node of the tree in question

(this is repeated for all other erroneous trees), the de-

livered hashes from the direct children are veriﬁed to

ﬁnd the unmatching subtree. Would we now follow

the normal style of a Merkle Hash Tree and verify sent

hashes by combining the children’s hashes, we would

not be able to detect lower/earlier manipulations, as

the henceforth combined hashes would verify the par-

ent, though they actually stem from a hash of false

data. Thus, we retrieve the hashes from other nodes,

which also calculated those, but in another (correct)

tree. This allows us to verify hashes in one tree with

values and/or hashes from another. As an example,

using the notation introduced in Section 4.3, the hash

of h

3−4

may be checked against h

3−4

= hash(h

Is a mismatch detected, the procedure is repeated

within that subtree in which the inconsistency has

been identiﬁed. On the other hand, if the hashes of

all children have successfully been veriﬁed, it indic-

ates that the parent/current node is the actual liar.

Algorithm 1 displays the described logic. Func-

tions lefthash and righthash return the child

hashes required to construct the hash of i. The actual

identiﬁcation function identify checks the hashes

of each subtree and continues to investigate into mis-

matching subtrees (cf. Line 7). If no mismatch has

been found, this subtree is correct and the parent p is

identiﬁed to be the malicious node (cf. Line 9).

Algorithm 1: Algorithm to detect a liar used in the

second phase of Accountant.

1 func identify(p, hashes):

Input: p = parent

hashes = hashes {h

t∈T

,...}

Data: T = erroneous trees

Data: G = correct trees

2 for h

∈ hashes do

3 l ← lefthash(h

)

4 r ← righthash(h

)

5 if l = r = NIL and h

6= h

g∈G

then

return i // i is a leaf

6 x ← hash(h

p∈G

q∈G

)

7 if x 6= h then // erroneous subtree

8 return identify(i,

| j ∈ i

.children})

9 return p // parent node is the liar

In conclusion, Accountant describes a protocol

consisting of the normal data aggregation phase and

the additional liar identiﬁcation phase. It requests

data over multiple aggregation trees, where the inner

nodes are only part of the aggregation at most once.

This allows Accountant to detect differentiations per-

formed by altering and denying attackers. Using the

simultaneously created hash trees, it identiﬁes the at-

tacker in a second phase.

5 EVALUATION

In this section, we will evaluate our presented ap-

proach, by comparing it to selected scenarios. The

following analyses each of the selected approaches

and compares them in regard to scalability. We use

the extended notation shown in Table 1.

Number of Messages. First, we analyse the number

of sent messages of one complete routine run, com-

paring simple, intuitive methods with existing work

and our approach.

Direct connection: Each node sends its data dir-

ectly to r, resulting in N messages sent. This is used as

a baseline for comparison with the other approaches.

A.1

= N (5)

Accountant: Protection of Data Integrity and Identiﬁcation of Malicious Nodes in In-network Data Processing

565

Table 1: Notation used in the evaluation.

m Number of attackers

n Number of trees (i.e. n = 2m + 1)

N Number of nodes per tree (i.e. N = |V |)

d Node degree (i.e. d ≥ n for Accountant)

H Height of a tree (i.e. H = log

Costs of asymmetric encryption

Costs of homomorphic operations

Costs of (secret) hashing

Without Aggregation Over the Tree: Each node sends

its data over the overlay tree to r. A message from a

leaf node has to traverse also its parental links, res-

ulting in l messages per node. This accumulates to

∑

H−1

i=0

(cf. Equation 6) messages in total.

A.2

H−1

∑

i=0

d − Hd

+ (H −1) · d

H+1

(1 − d)

d − log

N · d

log

(1 − d)

(log

N − 1) · d

log

N+1

(1 − d)

(6)

SecureDAV (Mahimkar and Rappaport, 2004): In Se-

cureDAV, each node sends its data to its parent, which

aggregates it, asks all children for veriﬁcation and

then forwards it. This results in three messages per

node. Additionally, integrity veriﬁcation is performed

over a Merkle Hash Tree, adding another log

H+1

A.3

= 3 · N + log

N + 1 (7)

PIP (Kumar and Madria, 2013): Messages are split

into x several pieces and distributed to a node’s x

neighbours. After that, nodes send the data to their

cluster head/parent. This gives 2x − 1 messages per

node, which can be summed up to 2N − 3, as the base

station does not forward any messages.

A.4

= 2 · N − 3 (8)

Accountant: Aggregating the data in the tree results in

constant size messages, so that the level of the sender

in a tree does not have any impact. We send e = N −1

messages up the overlay tree. Due to the necessary

integrity preservation, this is done for all n trees. We

do not add the overhead of the rarely performed liar

identiﬁcation, as this functionality is not part of the

normal operation mode. It would otherwise add a less

0 500 1,000 1,500 2,000 2,500 3,000 3,500 4,000 4,500 5,000

m = 1

Number of nodes (N)

Number of messages per node

direct

without aggregation

SecureDAV

PIP

Accountant

Figure 4: Number of messages a single node sends during

a normal routine with increasing number of participating

nodes for each of the described approaches.

Table 2: Scalability in regard to amount of messages given

in big O notation.

Direct O (N)

Without aggregation O



log

N · d

log



SecureDAV O (N)

PIP O (N)

Accountant O (n · N)

impactful amount of m·d ·log

H+1

= m·n·(log

N +

1) messages to the total.

A.5

= n · (N − 1) (9)

Figure 4 compares the costs of Equations 5 to 9. It

shows that Accountant is comparably efﬁcient as Se-

cureDAV. The communication over a tree without ag-

gregation performs, as expected, worst, as the tree is

not leveraged in any way. PIP performs best, as it

does not use back-and-forth communication like Se-

cureDAV or multiple overlay trees like Accountant.

Table 2 shows the above results in comparable big

O notation. Again, the tree communication without

aggregation performs worst, all others are classiﬁed

as O (N), whereby Accountant depends on the num-

ber of trees, meaning effectively the number of at-

tackers that are to be identiﬁable. Accountant per-

forms worse, because it supplies this feature of at-

tacker identiﬁcation. If it would only provide integ-

rity, the number of trees could be reduced to 2, leav-

ing it to be better than SecureDAV, though still less

efﬁcient than PIP.

Cryptographic Load. In our second analysis, we

highlight the differences in cryptographic overhead of

the different approaches. We assume costs for asym-

metric encryption (c

), homomorphic operations (c

and hashing (c

), to distinguish their impact on the

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

566

0 500 1,000 1,500 2,000 2,500 3,000 3,500 4,000 4,500 5,000

m = 1

= 6

= 2

= 1

Number of nodes (N)

Computational costs per node

homomorph

SecureDAV

PIP

Accountant

Figure 5: Costs of cryptographic operations a node has to

perform during a single routine in comparison to increasing

network size. The discussed approaches are shown, assum-

ing asymmetric cryptography to be six times more expens-

ive than hashing operations.

Table 3: Computational costs of cryptographic operations

in big O notation.

Hom. Enc. O (c

· N + c

· N)

SecureDAV O (c

· N + c

/N + c

· N)

PIP O



· N + c

· d

log



Accountant O (c

· n · N)

computational costs of the individual approach. We

assume asymmetric encryption to be the most the re-

source intensive operation, and homomorphic opera-

tions to be only bit more intensive than ordinary hash-

ing.

Homomorphic Encryption: We assume a system,

where each node encrypts its data with an asymmet-

ric, homomorphic cipher, e.g., ElGamal, for r. Nodes

pass data to their parent, which in turn aggregates the

data of its children and its own together as of the ho-

momorphic properties of the cipher. This continues

until the root node is reached. As a result, there will

be N messages encrypted, while bN/dc nodes also

perform the aggregation. This will result in crypto-

graphic costs of c

B.1

, seen in Equation 10.

B.1

= N · c

N/d

· c

(10)

SecureDAV: Nodes do not encrypt their data, but par-

tially sign the query of their cluster head for veriﬁc-

ation, which then combines the signatures. Both are

asymmetric operations, yielding costs of x · c

+ c

per node, resulting in c

· (N − 1) + c

/(N − 1). In

addition, hashes for the Merkle Hash Tree are gen-

erated, costing c



N + b(2

H+1

− 1)/2c



. This con-

cludes with costs c

B.2

as given by Equation 11.

B.2

= c

· (N − 1) +

N − 1

+ c



N +

log

N+1

− 1)/2

k

(11)

PIP: In PIP, nodes ﬁrstly encrypt their data, before

splitting and distributing it. The aggregation uses ho-

momorphic properties, which together returns costs

of N · c

+ c

· b(d

H+1

− 1)/2c.

B.3

= c

· N + c

j

log

N+1

− 1



(12)

Accountant: Each node hashes its data including a

unique secret, shared with r. Thus we have N hashing

operations and an additional b(2

H+1

− 1)/2c hashes

(without secret) for the binary hash tree, combining

existing messages to reduce message size. Including

the hash operations required for verifying hashes in

the second phase, this results in costs of c

B.2

as given

in Equation 13.

B.4

= c



n ·



N +

j

log

N+1

− 1



k

+ m · n · (log

N + 1))

(13)

Figure 5 shows the above equations in compar-

ison. We set asymmetric encryption to be six times

more expensive than normal hashing (based on EC-

EG and SHA3 instruction costs, as approximated

from (Gamal, 1985, Bertoni et al., 2009, Granlund,

2019, Fog, 2019)). As Accountant uses no asymmet-

ric cryptographic operations at all, it performs best

here. Even with more trees, it requires less compu-

tational power than the other approaches. The other

three approaches scale in the same manner and their

costs are mainly determined by the number of homo-

morphic operations.

Table 3 shows the corresponding abstraction of the

above results. It is visible, that Accountant performs

better, as long as c

≥ c

·n is valid, meaning it can use

more trees to be able to detect multiple attackers, and

still require less computational power than the other

approaches.

6 CONCLUSION

In this paper we proposed Accountant to efﬁciently

protect the integrity during data aggregation in dis-

tributed sensing and processing platforms. Our ap-

proach can detect attackers that either modify the val-

ues of their children or suppress them. Moreover, Ac-

countant is able to detect multiple attackers in the net-

work. It uses several inner node-disjoint aggregation

Accountant: Protection of Data Integrity and Identiﬁcation of Malicious Nodes in In-network Data Processing

567

trees to utilise redundant aggregation paths to com-

pare the outcome of the aggregation and uses hash

trees to be able to determine attackers.

Due to its efﬁcient cryptographic operations, Ac-

countant’s additional messaging overhead is com-

pensated by the lower computational power required

to perform. Accountant does only need to initiate the

second phase of identiﬁcation, if an attack has been

recognised, lowering its output of messages and re-

quired work in the normal case.

Future work will investigate the reduction of the

number of required trees, so that the overall network

footprint can be reduced.

REFERENCES

Bertoni, G., Daemen, J., Peeters, M., and Assche, G. V.

(2009). The road from panama to keccak via radiog-

atún. In Handschuh, H., Lucks, S., Preneel, B., and

Rogaway, P., editors, Symmetric Cryptography, 11.01.

- 16.01.2009, volume 09031 of Dagstuhl Seminar

Proceedings. Schloss Dagstuhl - Leibniz-Zentrum für

Informatik, Germany.

Boneh, D., Gentry, C., Lynn, B., and Shacham, H. (2003).

Aggregate and veriﬁably encrypted signatures from

bilinear maps. In Biham, E., editor, Advances in

Cryptology — EUROCRYPT 2003, pages 416–432,

Berlin, Heidelberg. Springer Berlin Heidelberg.

Bornholdt, H., Jost, D., Kisters, P., Rottleuthner, M., Bade,

D., Lamersdorf, W., Schmidt, T. C., and Fischer, M.

(2019). SANE: Smart networks for urban citizen

participation. In Proceedings of the IEEE 26th In-

ternational Conference on Telecommunications (ICT

2019).

Brinkmeier, M., Schäfer, G., and Strufe, T. (2009). Optim-

ally dos resistant p2p topologies for live multimedia

streaming. IEEE Transactions on Parallel and Dis-

tributed Systems, 20(6):831–844.

Chen, C.-M., Lin, Y.-H., Lin, Y.-C., and Sun, H.-M.

(2012). RCDA: Recoverable concealed data aggreg-

ation for data integrity in wireless sensor networks.

IEEE Transactions on Parallel and Distributed Sys-

tems, 23(4):727–734.

Fasolo, E., Rossi, M., Widmer, J., and Zorzi, M. (2007).

In-network aggregation techniques for wireless sensor

networks: a survey. IEEE Wireless Communications,

14(2):70–87.

Fog, A. (2019). 4. instruction tables. ht-

tps://www.agner.org/optimize/instruction_tables.pdf.

Accessed on 2019-12-17.

Gamal, T. E. (1985). A public key cryptosystem and a sig-

nature scheme based on discrete logarithms. IEEE

Trans. Information Theory, 31(4):469–472.

Granlund, T. (2019). Instruction latencies and through-

put for amd and intel x86 processors. ht-

tps://gmplib.org/ tege/x86-timing.pdf. Accessed on

2019-12-17.

He, W., Nguyen, H., Liu, X., Nahrstedt, K., and Abdelza-

her, T. (2008). iPDA: An integrity-protecting private

data aggregation scheme for wireless sensor networks.

In Proceedings - IEEE Military Communications Con-

ference MILCOM.

Kumar, V. and Madria, S. (2013). PIP: Privacy and integ-

rity preserving data aggregation in wireless sensor net-

works. 2013 IEEE 32nd International Symposium on

Reliable Distributed Systems, pages 10–19.

Lamport, L. (2006). Lower bounds for asynchronous con-

sensus. Distributed Computing, 19(2):104–125.

Mahimkar, A. and Rappaport, T. (2004). SecureDAV: a

secure data aggregation and veriﬁcation protocol for

sensor networks. In IEEE Global Telecommunica-

tions Conference, 2004. GLOBECOM ’04., volume 4,

pages 2175–2179. IEEE.

Merkle, R. C. (1990). A certiﬁed digital signature. In Lec-

ture Notes in Computer Science (including subseries

Lecture Notes in Artiﬁcial Intelligence and Lecture

Notes in Bioinformatics), volume 435 LNCS, pages

218–238.

Mohamed, N., Al-Jaroodi, J., Jawhar, I., Lazarova-Molnar,

S., and Mahmoud, S. (2017). Smartcityware: a

service-oriented middleware for cloud and fog en-

abled smart city services. Ieee Access, pages 17576–

17588.

Parakh, A. and Kak, S. C. (2010). Recursive secret sharing

for distributed storage and information hiding. CoRR,

abs/1001.3331.

Villanueva, F. J., Santoﬁmia, M. J., Villa, D., Barba, J., and

Lopez, J. C. (2013). Civitas: The smart city middle-

ware, from sensors to big data. In IMIS, 2013 Seventh

int. conf. on, pages 445–450. IEEE.

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

568
