Systematization of Threats and Requirements for Private Messaging with

Untrusted Servers: The Case of e-Mailing and Instant Messaging

Iraklis Symeonidis

and Gabriele Lenzini

SnT, University of Luxembourg, Luxembourg

Keywords:

Security, Privacy, Threat Modeling, Decentralization, System Model, Private Messaging.

Abstract:

Modern email and instant messaging applications often offer private communications. In doing so, they share

common concerns about how security and privacy can be compromised, how they should face similar threats,

and how to comply with comparable system requirements. Assuming a scenario where servers may not be

trusted, we review and analyze a list of threats speciﬁcally against message delivering, archiving, and contact

synchronization. We also describe a list of requirements intended for whom undertakes the task of implement-

ing secure and private messaging. The cryptographic solutions available to mitigate the threats and to comply

with the requirements may differ, as the two applications are built on different assumptions and technologies.

1 INTRODUCTION

Long stating facts have made clear to the public that

governments routinely collect and invest in the abil-

ity to massively eavesdrop private messages of cit-

izens (Stanger, 2019). In response to such revela-

tions, and sensitized to preserve the “right to pri-

vacy” (e.g., see (European Parliament and the Eu-

ropean Council, 2016)) beyond trusting authorities,

messaging servers, and communication channels, an

increasing number of companies are investing in pri-

vate messaging solutions (Unger et al., 2015). Private

messaging can be realized, for instance, in E-mailing

applications (e.g., Protonmail, p≡p (Marques et al.,

2019)). It can be offered in instance messaging (e.g.,

Signal, Telegram).

Whatever the hosting system, E-mailing or a In-

stant Messaging (IM), private messaging should en-

sure that, in an written exchange between peers, no

one but the sender and the intended receiver(s) are ca-

pable of reading the messages at any time: past, cur-

rent, and future.

Realizing this goal can be challenging despite the

many off-the-shelves security APIs and libraries to-

day available for software engineers. In the two

types of systems, private messaging may realize dif-

ferent mitigation mechanisms or satisfy different de-

sign choices. For instance, conﬁdentiality can be

https://orcid.org/0000-0003-4494-6685

https://orcid.org/0000-0001-8229-3270

preserved in multiple ways and with various cryp-

tographic primitives and, in a situation where lack

of privacy may endanger one’s life, such as in in-

vestigative journalism, such solutions are expected

to be more stringent than those called for in situa-

tions where users relaxedly exchange messages with

a broad public.

It must be said that the urgency of realizing private

messaging is lively debated. As it has been already es-

tablished for paper mail, secrecy of correspondence is

regarded as a fundamental legal principle of democra-

cies in many countries (Marotta and Russell, 2013). It

is often argued that preserving the privacy of commu-

nication between humans should be taken for granted;

that it should be respected and protected as a funda-

mental human right (Council of Europe: European

Court of Human Rights, 2016); and that the commu-

nication of peers has to be protected in a self-evident

manner. An ongoing discussion, mainly following

the revelation by Edward Snowden and other whistle-

blowers (Stanger, 2019), evaluates whether protec-

tions should be delivered by the offering technology

and independent of what the user wants to write or

why. In this discussion, E-mailing and messaging sys-

tems are regarded as the central and most prominent

digital communication means using which to realize

that legal principle.

The problem is that composing security compo-

nents without a clear understanding of the threats

leads to unclear or incomplete privacy guarantees.

Without that understanding, an application is likely

Symeonidis, I. and Lenzini, G.

Systematization of Threats and Requirements for Private Messaging with Untrusted Servers: The Case of e-Mailing and Instant Messaging.

DOI: 10.5220/0009003805930602

In Proceedings of the 6th International Conference on Information Systems Security and Privacy (ICISSP 2020), pages 593-602

ISBN: 978-989-758-399-5; ISSN: 2184-4356

593

to need to be patched to ﬁx vulnerabilities discovered

in the meantime (Dkg, 2019; Rijhansen, 2019), and

this is not optimal. Better, it is an approach capable

of ensuring privacy-by-design: here the appropriate

workﬂow demands ﬁrst deciding against what threats

one intends to uphold and then listing the related func-

tional requirements, to fulﬁl which appropriate solu-

tions are selected.

Contribution. In reference to both E-mailing and

IM, we describe the entities involved, the operations,

and the system features of such applications. While

discussing similarities in the two types of applica-

tions, we highlight the differences. Considering users

and systems as assets and assuming that servers may

be untrustworthy, we also orderly catalogue threats

against privacy messaging, and discuss security re-

quirements to mitigate them.

As such, this work offers a systematization of

threats and requirements for use of experts. The work

aim to assist them to assess current E-mailing and IM

applications and to design implement more robust pri-

vate messaging systems. Although limited to three

speciﬁc protocols in private messaging (messages ex-

change, search and archiving, and contact synchro-

nization), our list of threats and requirements carry al-

ready a quite rich set of challenges for whomever aims

to realize private messaging in E-mailing and IM.

It is also an introduction to private messaging for

non-experts.

2 BACKGROUND AND RELATED

WORK

E-mailing and IM are two types of messaging appli-

cations. E-mailing depends on Simple Mail Trans-

fer Protocol (SMTP) for email transmission (Klensin,

2008). SMTP has been designed with no built-in se-

curity. As a result, there is no prevention from ad-

versaries aiming for eavesdropping, spooﬁng, and im-

personating email messages and addresses. IM in-

stead, depends on Extensible Messaging and Presence

Protocol (XMPP), a near-real-time messaging proto-

col consisting of relatively small chunks of Exten-

sible Markup Language (XML) structured data be-

tween network endpoints (Saint-Andre, 2004). For

XMPP, Transport Layer Security (TLS) offers chan-

nel encryption between the application peers, for in-

stance a user client and its IM server.

E-mailing stands for high-latency and asyn-

chronous communication in message delivery. It

means that the communicating parties are not required

to be simultaneously online (Resnick, 2008). IM

is traditionally considered as low-latency and syn-

chronous, with the peers required to be online in order

to exchange messages (Saint-Andre, 2011). However,

nowadays certain instant messaging applications al-

low high-latency and asynchronous message delivery.

WhatsApp and Signal (Signal, 2013) as examples of

new generation IM. Despite the differences, messag-

ing applications offer common features such as trans-

mitting messages, archiving, searching, and option-

ally recipient’s identity veriﬁcation and contacts list

management.

For E-mailing and IM, there are protocols that

enable users to exchange messages in a secure and

privacy-enhancing way. Clark et al. (Clark et al.,

2018) lists the state of the art protocols for secure E-

mailing and Shirazi et al., (Shirazi et al., 2018) for

privacy with the main focus on anonymous remail-

ers. Unger et al. (Unger et al., 2015) list protocols for

secure messaging, and Ermoshina et al. (Ermoshina

et al., 2016) provides a short overview of decentral-

ized E-mailing and IM applications. To the best of

our knowledge, there is no existing work that method-

ologically analyzes the security and privacy threats

and corresponding requirements for private messag-

ing.

3 METHODOLOGY

For a system model analysis in private messaging we

extracted the entities involved and the features that

a system considers by following the work of (Saint-

Andre, 2011; Klensin, 2008; Unger et al., 2015; Clark

et al., 2018; Ermoshina et al., 2016; Shirazi et al.,

2018) (see Fig. 1).

With a focus on private messaging consider-

ing untrusted servers, we compile the list of secu-

rity and privacy threats for both E-mailing and IM.

To distinguish and group the classes of threats and

requirements we apply the STRIDE threat model-

ing (Howard and Lipner, 2009; Microsoft, 2010) for

security and LINDDUN (Deng et al., 2011) for pri-

vacy. Both frameworks are used by the industry and

the research community nowadays (Danezis et al.,

2015; Symeonidis et al., 2017).

We need to stress that we extended LINDDUN

threat modeling in two different ways. We incorpo-

rate content unawareness to policy and consent non-

compliance threat. Note that, content unawareness

is considered as a principle of policy and consent

non-compliance under General Data Protection Reg-

ulation (GDPR) (European Parliament and the Euro-

pean Council, 2016), and thus we consider under the

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

594

policy requirement. Moreover, we extended LIND-

DUN to include the privacy interdependence privacy

threat. There are scenarios where the privacy of in-

dividuals is bound to be affected by the decisions of

others (Bicz

ok and Chia, 2013). For example, a re-

cipient of an email can forward a message to others

without the original sender’s notiﬁcation and consent.

Moreover, in messaging systems such as on What-

sApp, users can upload their contacts list in messag-

ing servers. It enables the servers to learn and extract

information about the network of users, enabling pri-

vacy interdependence.

4 SYSTEM MODEL

This section outlines a private messaging system. It

describes the entities involved, the information as user

assets that can be collected by the system, and the fea-

tures of a private messaging system. We follow the re-

quirements extracted from real world systems and ap-

plications as well as from the academic literature for

E-mailing and instant messaging (Unger et al., 2015;

Clark et al., 2018; Ermoshina et al., 2016).

4.1 Operations and Entities

We describe a set of operations and corresponding en-

tities that are involved in E-mailing and IM messaging

systems.

Users as Sender and Receiver(s): The communi-

cating parties who exchange messages, typically re-

ferred to as senders and receivers.

Trust Establishment (TE): Supports Operations

for: (i) authenticating a user, (ii) storing and dis-

tributing cryptographic material as well as (ii) syn-

chronizing contacts of users. It utilizes identity man-

agement, key management and contact management

servers. Note that, the operations that occur for TE

are system dependent and can vary.

Message Exchange (ME): Supports operations for

message delivery and synchronization. It utilizes E-

mailing and IM servers for the delivery and synchro-

nization of messages between users i.e., the sender

and receiver(s).

Networking Nodes (NetND): is referred to all

the Internet nodes for interconnected users and E-

mailing/IM servers.

Third Party: is any other entity interacting with

the messaging system.

4.2 System Features and User Assets

In addition to enabling communication, i.e., send-

ing and receiving messages and attachments, there

is a minimum set of common features that both E-

mailing and IM systems should offer: (i) Archive and

Search through messages and attachments; (ii) Con-

tacts synchronization, and search; (iii) Group Mes-

sages exchange; (iv) Multi-device synchronization of

messages and contacts across devices. In this work,

we focus on threats and requirements for messages

exchange, archiving/search and contact synchroniza-

tion.

Considering untrusted servers, the following as-

sets of users needs to be protected in private messag-

ing systems: (i) Identity and Identiﬁcation Material of

sender/receiver such as e-mail, phone numbers, and

public keys; (ii) Contacts List consisting of but not

limited to e-mail, phone numbers, names, and public

keys; (iii) Content as text and attachments; (iv) Meta-

data consisting of but not limited to the identity of the

sender/receiver, packet size, and timing.

5 THREATS AND

REQUIREMENTS

5.1 Adversarial Model

An adversary is any entity that leverages threats

against a system. The goal of an adversary is to gain

improper access to messages or any information from

or about the users. An adversary can be anyone who is

involved in communication such as, the users, the TE

and ME entities (e.g., the E-mailing and IM servers),

the Networking Nodes (NetND), the Third Party (TP),

or even a subset of all those entities.

Types of an adversary can be distinguished de-

pending on whether the entity is a passive eavesdrop-

per or an active participant in the communication and

on whether it is internal to the private messaging sys-

tem or an external TP one (see Table 1).

Table 1: Adversarial Model: passive/active and inter-

nal/external adversaries on user/system assets.

Passive Active

User assets System assets

Internal

(TE, ME, User)

read (server) read + write (server) execute (server)

External

(TP)

read (link) read + write (link) availability attack (server)

Passive vs Active. A passive attacker can only

eavesdrop (i.e., read) messages and off-line process

them. It cannot interfere with the execution of the

Systematization of Threats and Requirements for Private Messaging with Untrusted Servers: The Case of e-Mailing and Instant Messaging

595

LAYER 1: Trust establishment

LAYER 2: Content

IM server!

(e.g., XMPP)

LAYER 3: Networking

Identity, Key and Contact Management server!

(e.g., OpenPGP)

Alice

Bob

H | B

E-mail / IM

H | B

E-mail / IM

H | B

E-mail / IM

Sender

Receiver

Email servers!

(e.g., SMTP)

Third Party

IM: Instant Messaging"

Message format:!

H: Header (i.e., metadata)!

B: Body (i.e., text, attachments)

Figure 1: Communication systems: emailing, instant messaging and key management servers.

communication protocol. An active attacker can tam-

per with a protocol’s messages: it can read and write

messages, can execute commands for gaining access

to system resources, and delay or replay messages.

Internal vs External. An internal adversary can

seize control of one or of multiple entities that are

part of the system. It aims to extract information

from a speciﬁc entity or to prevent a message from

being sent. An external adversary can only com-

promise the communication channels, eavesdrop and

tamper with the messages, such as performing Man-

in-The-Middle (MiTM) attacks. It can also monitor

and control several parts of the network, granting the

adversary the ability to correlate network trafﬁc (Mur-

doch and Danezis, 2005) such as performing timing

attacks (Levine et al., 2004; Zhu et al., 2010).

Attackers can combine adversarial properties to

increase the effectiveness and the probability of suc-

cess of an attack. For instance, an external passive

attacker can monitor multiple channels of a system,

whereas an active internal adversary can tamper with

the messages of a targeted server (e.g., the E-mailing

and IM servers) (D

ıaz et al., 2002). In this work, we

focus on TE and ME, excluding attacks on network-

ing nodes (NetND).

Assumptions. We assume that end-points are se-

cure and authenticated. For instance, mobile devices

are malware free and users need to authenticate ac-

cessing their phones.

5.2 Security Threats and Requirements

We describe the security threats and corresponding re-

quirements in six main classes, namely: spooﬁng and

entity authentication; tampering with data and data

authentication, repudiation and non-repudiation; in-

formation disclosure and conﬁdentiality, denial-of-

service and availability; elevation of privilege and au-

thorization (see Table 2).

Spooﬁng and Entity Authentication. Spooﬁng oc-

curs when an adversary successfully impersonates the

proﬁle of a valid user, gaining improper access to the

information exchanged in the system. Spooﬁng is a

critical step in phishing, spamming and in MiTM at-

tacks (Hu and Wang, 2018). Here, we focus on threats

related to establishing End-to-End (E2E) encryption

such as public key spooﬁng attacks.

Public key spooﬁng threat is posed when a com-

municating party receives and utilize cryptographic

material (i.e., a public key) that does not correspond

to an intended user, recipient of a message in the sys-

tem. For example, spooﬁng is when Alice receives a

public key that she assumes be Bob’s key when in-

stead the key is Eve’s. That can occur in the presence

of an adversarial identity management server during

TE. An active identity management adversary can at-

tempt to provide counterfeit cryptographic material,

such as public keys, to the intended communicating

parties.

To mitigate spooﬁng threats, entity authentication

mechanisms should be in place. Public key veriﬁca-

tion is crucial between the communicating users in

private messaging systems considering untrusted key

management servers. To verify that a user is the le-

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

596

gitimate owner of a public key, peer-to-peer solutions

to key veriﬁcation systems exist (Finney et al., 2007;

Garﬁnkel, 1995), where users utilizing out-of-band

channels to manually to the veriﬁcation. Here, users

can verify the ﬁngerprints or some more usable alter-

natives, like trustwords (Marques et al., 2019). Peer-

to-peer solutions have limitations in key veriﬁcation

and management (i.e., distribution, synchronization,

and revocation) between the communication entities,

though. Other approaches are possible to ensure au-

thentication even when servers are untrusted. Keys

can be stored encrypted, for instance. Keys can be

authenticated and agreed in a distributed manner with

the use of multiparty computation.

Tampering with Data and Data Authentication.

Tampering with data occurs when an adversary al-

ter the messages exchanged between the ME enti-

ties in the system. For instance, an adversary may

(stealthily) change the content of an E-mailing or an

instant message.

To contain this threat, data authentication of mes-

sages exchanged needs to be guaranteed: users should

be able to verify that messages have not been mod-

iﬁed in transit, and only veriﬁed messages should

be accepted. Nowadays, application encryption and

data authentication exist between the E-mailing and

IM servers during the ME as a minimum secu-

rity requirement in commercial messaging systems

such as Gmail and Facebook messenger. For in-

stance STARTTTLS offers e-mail encryption from

IM (Saint-Andre, 2004) and e-mail for SMTP (Hoff-

man, 2002) and IMAP/POP3 (Newman, 1999). Thus,

network nodes cannot read and alter the messages

during message transit but the E-mailing and IM

servers. Thus, end-to-end data authentication should

be guaranteed such as with Message Authentication

Code (MAC) and digital signatures in combination.

Repudiation, Non-repudiation, and Accountabil-

ity. Adversaries can repudiate the status of a mes-

sage to users or the ME entities of the system. For in-

stance, an adversary may attempt to deny having sent

or received an E-mailing or an instant message. Users

who are involved during the communication can be

considered as adversaries assuming TE and ME enti-

ties as passive adversaries. That is an reasonable as-

sumption, as it is against their interest of companies

such as Google and Facebook messenger to not per-

form the operations of E-mailing and IM properly.

To mitigate repudiation threats non-repudiation of

actions performed and accountability must be guar-

anteed. Non-repudiation of an action can consist of a

proof of origin, submission, delivery, and receipt be-

tween the intended users (Zhou and Gollmann, 1997).

Non-repudiation can be achieved with the use of cryp-

tographic primitives, such as digital signatures, and

audit trails, such as timestamps.

Information Disclosure and Conﬁdentiality. In-

formation disclosure happens when an adversary suc-

ceeds in revealing the content of messages exchanged.

The adversary can attempt to perform MiTM and

eavesdrop the conversations of users in messaging

systems. Therefore, conﬁdentiality of messages ex-

changed within a system should be guaranteed. Com-

munication conﬁdentiality ensures that the messages

exchanged are only readable by the involved users.

Considering untrusted ME servers, the solution of

E2E encryption is essential in contrast to applica-

tion layer encryption aiming to mitigate MiTM at-

tacks. Conﬁdentiality of messages for E2E encryption

systems can be achieved with encryption schemes

such as symmetric, asymmetric, and malleable en-

cryption (Borisov et al., 2004).

Another challenged to conﬁdentiality is the stor-

age and archiving of messages exchange. An adver-

sary can passively collect and store messages in an

attempt to retrieve or break the E2E encryption keys

and compromise future or past messages. Perfect for-

ward and backward secrecy needs to be guaranteed

for private messaging. It ensures that past messages

cannot be recovered retroactively. Essentially, in key

agreement protocols, past session keys are not com-

promised even if long-term keys are compromised.

Here, we stress, there are difference between E-

mailing’s and IM’s solutions to achieve perfect for-

ward secrecy. For low latency protocols, i.e., IM,

where users are online, perfect forward secrecy can

be achieved generating session keys such as using

Difﬁe-Hellman key agreement (Menezes et al., 1996;

Difﬁe and Hellman, 1976) in Off-The-Record (OTR)

messaging (Borisov et al., 2004). However, the

high-latency of E-mailing makes the session keys ap-

proach impractical (Borisov et al., 2004). Both Al-

ice and Bob required to be online since the key ex-

change must be completed before the message is

sent. Perfect forward secrecy for high-latency sys-

tems can be achieved with solutions such as ring sig-

natures (Rivest et al., 2001).

If for a compromise of long-term keys subsequent

cipher-texts cannot be decrypted, then the protocol

guarantees also backward secrecy for private messag-

ing (Borisov et al., 2004).

Denial of Service Attacks and Availability.

Denial-of-Service attack (DoS) occurs when adver-

sary manages to make system inaccessible to one or

Systematization of Threats and Requirements for Private Messaging with Untrusted Servers: The Case of e-Mailing and Instant Messaging

597

more users. For instance, an adversary may target

the TE and ME entities of the messaging system

such as the Identity Management, the IM and the

E-mailing server (Dkg, 2019; Rijhansen, 2019). The

capabilities of an adversary can be from script kiddies

to even state-sponsored adversaries, considered as

active external TP adversaries. To reduce the threat of

DoS, availability of the system must be guaranteed.

Network security tools such as intrusion prevention

systems and redundant systems such as utilizing

multiparty computation are of help for this goal.

Elevation of Privilege and Authorization. Eleva-

tion of privileges occurs when an adversary aims to

gain access to the assets of other users or the re-

sources of the system. For instance, an adversary

may attempt to become an administrator of a message

group or a superuser of the system aiming at retriev-

ing users’ messages or executing operations as a super

user. Therefore, authorization mechanisms such as

access control lists that comply with the principle of

least privilege for user accounts and processes should

be applied.

5.3 Privacy Threats and Requirements

We describe the privacy threats and the corresponding

requirements in seven main classes, namely: linka-

bility and unlinkability, identiﬁability and anonymity,

non-repudiation and deniability, detectability and un-

detectability, information disclosure and conﬁdential-

ity, privacy interdependence and privacy indepen-

dence, policy noncompliance and policy compliance

(see Table 2).

Identiﬁability and Anonymity. Identiﬁability is

deﬁned as the extent to which a speciﬁc user can

be identiﬁed from a set of users, the identiﬁability

set. Identiﬁcation is the process of linking informa-

tion to allow the inference of the identity of a speciﬁc

user (Cooper et al., 2013). An adversary can identify

a speciﬁc user by examining an Item of Interest (IOI)

such as the identity of a sender / receiver (i.e., e-mail

or phone number) or an action performed. For in-

stance, a passive ME internal adversary such as the

IM and E-mailing servers, may identify the sender

of a message by examining the headers (i.e., meta-

data) or the body of a message exchanged. Moreover,

an active TP external adversary might try to examine

the metadata of a message in transit or to correlate

trafﬁc trafﬁc (Zhu et al., 2010) executing timing at-

tacks (Levine et al., 2004), even in the E2E encryption

messaging systems (Levine et al., 2004).

To mitigate identiﬁability threats, the anonymity

of users must be guaranteed. Anonymity is deﬁned

from the attackers perspective as the “attacker can-

not sufﬁciently identify the subject within a set of

subjects, the anonymity set” (Pﬁtzmann and Hansen,

2010). In order to make anonymity possible, there

always need to be a set of possible users such that

for an adversary the communicating user is equally

likely to be of any other user in the set (D

ıaz et al.,

2002; Symeonidis and Hoeneisen, 2019). Thus, an

adversary cannot identify who is the sender of a

message. Anonymity can be achieved with the use

of pseudonyms and cryptographic schemes such as

anonymous re-mailers (i.e., mixnets) (Shirazi et al.,

2018), and secret sharing.

Linkability and Unlinkability. Linkability occurs

when an adversary can sufﬁciently distinguish within

a given system that two or more IOIs, such as sub-

jects (i.e., users), objects (i.e., messages), or actions

are related to each other (Pﬁtzmann and Hansen,

2010). For instance, an adversary may be able to re-

late pseudonyms by analysing exchanged messages

and deduce that the pseudonyms belong to one user

(though the user may not necessarily be identiﬁed in

this process). Therefore, unlinkability of IOIs should

be guaranteed through the use of pseudonyms as well

as cryptographic schemes such as anonymous creden-

tials (Camenisch and Lysyanskaya, 2004).

Non-repudiation and Deniability. Non-

repudiation can be a threat to a user’s privacy

for private messaging systems, in contrast to security.

As we prior discussed, non-repudiation should be

guaranteed for users. However, non-repudiation

carries a potential threat in itself when it is used

against a user in certain instances. For example,

whistle-blowers may ﬁnd non-repudiation used

against them by adversaries, particularly in countries

with strict censorship policies and in cases where

human lives are at stake. Adversaries in these situ-

ations may seek to use shreds of evidence collected

within a communication system to prove to others

that a whistle-blowing user was the originator of a

speciﬁc message (Symeonidis and Hoeneisen, 2019).

Therefore, plausible deniability is essential for these

users, to ensure that an adversary can neither conﬁrm

nor contradict that a speciﬁc user sent a particular

message. For example, Bob or Eve is unable to

claim authorship of a message that was from Alice.

Deniability can be guaranteed through the use of

cryptographic protocols such as OTR for private

messaging (Borisov et al., 2004).

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

598

Detectability / Observatility and Undetectability.

Detectability occurs when an adversary is able to suf-

ﬁciently distinguish an IOI, such as messages ex-

changed within the system, from random noise (Pﬁtz-

mann and Hansen, 2010). Observability occurs

when that detectability occurs along with a loss of

anonymity for the entities within that same system.

An adversary can exploit the states of detectability

and anonymity in order to detect, infer and possi-

bly identify users within a system. The threat posed

by an adversary can be a passive ME internal adver-

sary eavesdropping communication of messages ex-

changed. It can also be an active TP external by

seizing control of several entities and communication

links. That grants the adversary the ability to corre-

late and control trafﬁc (Zhu et al., 2010) in order to

execute timing attacks, even in the end-to-end com-

munication systems (Levine et al., 2004).

Therefore, undetectability of IOIs should be guar-

anteed, which together with preserving the anonymity

of users it also ensures unobservability. Undetectabil-

ity for an IOI is deﬁned as that “the attacker can-

not sufﬁciently distinguish whether it exists or not”

while unobservability also incorporates “anonymity

of the subject(s) involved in the IOI” (Pﬁtzmann

and Hansen, 2010). Undetectability can be achieved

through the use of cryptographic schemes such as

mix-nets (Shirazi et al., 2018; Symeonidis and

Hoeneisen, 2019) and obfuscation mechanisms such

as the insertion of dummy trafﬁc within a system.

Information Disclosure and Conﬁdentiality. In-

formation disclosure - or loss of conﬁdentiality -

about users, message content, metadata, or other in-

formation is not only a security but also a privacy

threat that a communicating system can face. For ex-

ample, a successful MiTM attack can yield message

content and metadata that can be used to determine

not only the content of a message by also with whom a

speciﬁc user communicates with, and how frequently.

To guarantee the conﬁdentiality of messages and pre-

vent information disclosure, security measures need

to be guaranteed with the use of cryptographic primi-

tives and protocols such as symmetric, asymmetric or

homomorphic encryption and secret sharing.

Privacy Interdependence and Privacy Indepen-

dence. Privacy interdependence is deﬁned as the

scenario when the privacy of users is affected by de-

cisions taken and actions initiated by anyone but the

user thyself (Symeonidis, 2018). Privacy interdepen-

dence is related to relational and spatial privacy as

there were deﬁned by Clark (Roger Clarke, 2016) and

Bicz

ok (Bicz

ok and Chia, 2013). Relational privacy

considers how a user relates to and communicate with

other users (Bicz

ok and Chia, 2013). For instance, a

passive TE (i.e., identity, and key management server)

and ME servers can learn the contacts that a user is

related to such as names, phone numbers, E-mailing

addresses and public keys from the contacts list of a

user. With spatial privacy a user is affected by the ac-

tions of another user on the invasion on the virtual on-

line space of a user (Bicz

ok and Chia, 2013). For in-

stance, a user might forward a message to other users

without the notiﬁcation and consent of the involved

users affecting their privacy. Therefore, independent

privacy is essential and must be guaranteed for each

user in private messaging systems. It needs to ensure

the transparency and direct consent to the informa-

tion sharing by the users that are involved in com-

municating. Moreover, to safeguard individual pri-

vacy protocols considering cryptographic primitives

such as zero-knowledge proofs and multiparty com-

putation needs to be designed and implemented.

Policy Non-compliance and Policy Compliance

Policy non-compliance can be a threat to the privacy

of users in a private messaging system. An adversary,

can attempt to collect and process information about

users in E-mailing and IM without the users’ aware-

ness, notiﬁcation and explicit consent such as for ad-

vertisement purposes. That can result in unauthorized

processing of users information under the GDPR (Eu-

ropean Parliament and the European Council, 2016)

resulting in proﬁling, and censorship. Therefore, data

protection policy compliance must be guaranteed. It

can be achieved with auditing tools such as with Data

Protection Impact Assessment (European Commis-

sion, ) considering the (European Parliament and the

European Council, 2016).

6 LIMITATIONS AND

DISCUSSION

We compiled a preliminary, yet rich, list threats and

requirements for private messaging systems. How-

ever, to fulﬁll the requirements, one needs to refer to

speciﬁc cryptographic protocols. This task is left as

future work.

At the level where our work stands (i.e., threats

and requirements) certain system differences between

E-mailing and IM are neglected. We expect these dif-

ferences emerging and impacting design choices. For

example, OTRv4 protocol (Bini and Celi, 2018) con-

siders these difference to provide E2E while preserv-

ing the same security and privacy requirements for

both systems.

Systematization of Threats and Requirements for Private Messaging with Untrusted Servers: The Case of e-Mailing and Instant Messaging

599

7 CONCLUSION

This paper’s goal has been that of systematically dis-

cuss threats against private messaging in the two do-

mains of E-mailing and IM when servers are un-

trusted. The two application types have strong sim-

ilarities, which allowed us to apply for both the same

threat modelling methodologies; but they are not

identical and already from our analysis relevant dif-

ference emerged due to the different nature, on-line

and off-line, of the two communication paradigms.

Fulﬁl the same requirements, such as perfect forward

secrecy, calls for different solutions.

We provided a detailed and comparative analysis

of the systems, describing the entities involved, the

operations, and the system features. We have identi-

ﬁed, discussed, and catalogued the classes of threats

that can exploit the assets of users and the system. We

have, for each threat, discussed the opposing security

and privacy requirements.

Our investigation remains within the scope of spe-

ciﬁc features of privacy messaging: messages ex-

change, search and archiving, and contact synchro-

nization. We intend for the future to extend the anal-

ysis to other features, such as, key management and

key synchronization among different devices.

ACKNOWLEDGMENTS

We would like to thank Nana Karlstetter and Bernie

Hoeneisen from p≡p foundation for the inputs and all

the anonymous reviewers for their constructive feed-

back. The authors are supported by the pEp Security

SA / SnT partnership project ”Protocols for Privacy

Security Analysis”.

REFERENCES

Bicz

ok, G. and Chia, P. H. (2013). Interdependent privacy:

Let me share your data. In Financial Cryptography

and Data Security - 17th International Conference,

FC 2013, Okinawa, Japan, April 1-5, 2013, Revised

Selected Papers, pages 338–353.

Bini, O. and Celi, S. (2018). No evidence of communication

and implementing a protocol: Off-the-record protocol

version 4. Hotpets.

Borisov, N., Goldberg, I., and Brewer, E. A. (2004). Off-

the-record communication, or, why not to use PGP. In

Proceedings of the 2004 ACM Workshop on Privacy in

the Electronic Society, WPES 2004, Washington, DC,

USA, October 28, 2004, pages 77–84.

Camenisch, J. and Lysyanskaya, A. (2004). Signa-

ture schemes and anonymous credentials from bilin-

ear maps. In Advances in Cryptology - CRYPTO

2004, 24th Annual International CryptologyConfer-

ence, Santa Barbara, California, USA, August 15-19,

2004, Proceedings, pages 56–72.

Clark, J., van Oorschot, P. C., Ruoti, S., Seamons, K. E.,

and Zappala, D. (2018). Securing email. CoRR,

abs/1804.07706.

Cooper, A., Tschofenig, H., Aboba, B., Peterson, J., Morris,

J., Hansen, M., and Smith, R. (2013). Privacy Consid-

erations for Internet Protocols. RFC 6973.

Council of Europe: European Court of Human Rights

(2016). Guide on Article 8 of the European Conven-

tion on Human Rights - Right to respect for private

and family life. https://www.echr.coe.int/Documents/

Guide Art 8 ENG.pdf. Accessed December, 2019.

Danezis, G., Domingo-Ferrer, J., Hansen, M., Hoepman, J.,

etayer, D. L., Tirtea, R., and Schiffner, S. (2015).

Privacy and data protection by design - from policy to

engineering. CoRR, abs/1501.03726.

Deng, M., Wuyts, K., Scandariato, R., Preneel, B., and

Joosen, W. (2011). A privacy threat analysis frame-

work: supporting the elicitation and fulﬁllment of

privacy requirements. Requirements Engineering,

16(1):3–32.

ıaz, C., Seys, S., Claessens, J., and Preneel, B. (2002).

Towards measuring anonymity. In Privacy Enhancing

Technologies, Second International Workshop, PET

2002, San Francisco, CA, USA, April 14-15, 2002, Re-

vised Papers, pages 54–68.

Difﬁe, W. and Hellman, M. E. (1976). New directions

in cryptography. IEEE Trans. Information Theory,

22(6):644–654.

Dkg (2019). OpenPGP Certiﬁcate Flooding.

https://dkg.ﬁfthhorseman.net/blog/openpgp-

certiﬁcate-ﬂooding.html. Accessed December,

2019.

Ermoshina, K., Musiani, F., and Halpin, H. (2016). End-

to-end encrypted messaging protocols: An overview.

In Internet Science - Third International Conference,

INSCI 2016, Florence, Italy, September 12-14, 2016,

Proceedings, pages 244–254.

European Commission. Guidelines on Data Protection

Impact Assessment (DPIA) and determining whether

processing is “likely to result in a high risk” for the

purposes of Regulation 2016/679 (17/EN WP 248).

http://ec.europa.eu/newsroom/document.cfm?doc

id=44137. Accessed May, 2018.

European Parliament and the European Council (2016).

Regulation (EU) 2016/679 of the European Parlia-

ment and of the Council of 27 April 2016 on the pro-

tection of natural persons with regard to the process-

ing of personal data and on the free movement of such

data, and repealing Directive 95/46/EC (General Data

Protection Regulation), OJ L119, 4.5.2016. 59:1–87.

Finney, H., Donnerhacke, L., Callas, J., Thayer, R. L., and

Shaw, D. (2007). OpenPGP Message Format. RFC

4880.

Garﬁnkel, S. (1995). PGP - pretty good privacy: encryption

for everyone (2. ed.). O’Reilly.

Hoffman, P. (2002). SMTP Service Extension for Secure

SMTP over Transport Layer Security. RFC 3207.

Howard, M. and Lipner, S. (2009). The security develop-

ment lifecycle. O’Reilly Media, Incorporated.

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

600

Hu, H. and Wang, G. (2018). End-to-end measurements

of email spooﬁng attacks. In 27th USENIX Security

Symposium, USENIX Security 2018, Baltimore, MD,

USA, August 15-17, 2018., pages 1095–1112.

Klensin, J. (2008). Simple Mail Transfer Protocol. RFC

5321.

Levine, B., Reiter, M., Wang, C., and Wright, M. (2004).

Timing attacks in low-latency mix systems (extended

abstract). In Financial Cryptography, 8th Interna-

tional Conference, FC 2004, Key West, FL, USA,

February 9-12, 2004. Revised Papers, pages 251–265.

Marotta, D. J. and Russell, M. (2013). Sup-

port for The Right to Privacy of Correspon-

dence. http://www.marottaonmoney.com/support-for-

the-right-to-privacy-of-correspondence/. Accessed

December, 2019.

Marques, H., Luck, C., and Hoeneisen, B. (2019). pretty

Easy privacy (pEp): Privacy by Default. Internet-Draft

draft-birk-pep-04, Internet Engineering Task Force.

Work in Progress.

Menezes, A., Oorschot, P., and Vanstone, S. (1996). Hand-

book of Applied Cryptography. CRC Press.

Microsoft (2010). Improving Web Application Security:

Threats and Countermeasures. Accessed May, 2016.

Murdoch, S. J. and Danezis, G. (2005). Low-cost trafﬁc

analysis of tor. In 2005 IEEE Symposium on Security

and Privacy (S&P 2005), 8-11 May 2005, Oakland,

CA, USA, pages 183–195.

Newman, C. (1999). Using TLS with IMAP, POP3 and

ACAP. RFC 2595.

Pﬁtzmann, A. and Hansen, M. (2010). A terminol-

ogy for talking about privacy by data minimization:

Anonymity, unlinkability, undetectability, unobserv-

ability, pseudonymity, and identity management.

Resnick, P. (2008). Internet Message Format. RFC 5322.

Rijhansen (2019). SKS Keyserver Network Under Attack.

https://gist.github.com/rjhansen. Accessed December,

2019.

Rivest, R. L., Shamir, A., and Tauman, Y. (2001). How

to leak a secret. In Advances in Cryptology - ASI-

ACRYPT 2001, 7th International Conference on the

Theory and Application of Cryptology and Informa-

tion Security, Gold Coast, Australia, December 9-13,

2001, Proceedings, pages 552–565.

Roger Clarke (2016). Introduction to Dataveillance

and Information Privacy, and Deﬁnitions of

Terms (1997) (revised in 1999, 2005, 2006).

http://www.rogerclarke.com/DV/Intro.html. Ac-

cessed October, 2019.

Saint-Andre, P. (2004). Extensible Messaging and Presence

Protocol (XMPP): Core. RFC 3920.

Saint-Andre, P. (2011). Extensible Messaging and Pres-

ence Protocol (XMPP): Instant Messaging and Pres-

ence. RFC 6121.

Shirazi, F., Simeonovski, M., Asghar, M. R., Backes, M.,

and D

ıaz, C. (2018). A survey on routing in anony-

mous communication protocols. ACM Comput. Surv.,

51(3):51:1–51:39.

Signal (2013). Forward secrecy for asynchronous mes-

sages. https://signal.org/blog/asynchronous-security.

Accessed July, 2019.

Stanger, A. (2019). Whistleblowers: Honesty in America

from Washington to Trump. Yale Univ. Press.

Symeonidis, I. (2018). Analysis and Design of Privacy-

Enhancing Information Sharing Systems. PhD

thesis, ESAT, imec-COSIC, KU Leuven , Kas-

teelpark Arenberg 10, 3001 Leuven, Belgium.

http://hdl.handle.net/10993/37607.

Symeonidis, I., Aly, A., Mustafa, M. A., Mennink, B.,

Dhooghe, S., and Preneel, B. (2017). Sepcar: A secure

and privacy-enhancing protocol for car access provi-

sion. In Computer Security - ESORICS 2017 - 22nd

European Symposium on Research in Computer Secu-

rity, Oslo, Norway, September 11-15, 2017, Proceed-

ings, Part II, pages 475–493.

Symeonidis, I. and Hoeneisen, B. (2019). Privacy and Se-

curity Threat Analysis and Requirements for Private

Messaging. Internet-Draft draft-symeonidis-medup-

requirements-00, Internet Engineering Task Force.

Work in Progress.

Unger, N., Dechand, S., Bonneau, J., Fahl, S., Perl, H.,

Goldberg, I., and Smith, M. (2015). Sok: Secure mes-

saging. In 2015 IEEE Symposium on Security and Pri-

vacy, SP 2015, San Jose, CA, USA, May 17-21, 2015,

pages 232–249.

Zhou, J. and Gollmann, D. (1997). Evidence and non-

repudiation. J. Netw. Comput. Appl., 20(3):267–281.

Zhu, Y., Fu, X., Graham, B., Bettati, R., and Zhao, W.

(2010). Correlation-based trafﬁc analysis attacks on

anonymity networks. IEEE Trans. Parallel Distrib.

Syst., 21(7):954–967.

Systematization of Threats and Requirements for Private Messaging with Untrusted Servers: The Case of e-Mailing and Instant Messaging

601

Table 2: Entities that can be utilized as adversaries for private messaging systems.

User Assets System Assets

Adversarial model:

Passive  / Active  — Internal ¨ (TE, ME, User)

Passive  / Active  — External ˚ (TP)

(e-mail, phone #)

(Pk, certiﬁcates)

Contacts

list

Message content

(Text, attachments)

Metadata

(Sender, receiver, packet size)

TE Servers

ME Servers

Classes of Threats Classes of Requirements

Spooﬁng S

 — ¨ (TE)

 — ˚ (TP)

- - - - EA Entity Authentication

Tampering with Data T - -

 — ¨ (ME)

 — ˚ (TP)

- - DA Data Authentication

Origin / Delivery - -

 — ¨ (User)

- - Origin / Delivery

Repudiation

Submission / Receipt

- -

 — ¨ (User)

- -

Submission / Receipt

Non-repudiation

Current - -

 — ¨ (ME)

 — ˚ (TP)

- - Current

Information

Disclosure

Previous / Future

Messages

- -

 — ¨ (ME)

 — ˚ (TP)

- -

Forward / Backward

Secrecy

Conﬁdentiality

Denial of Service D - - - -

 — ˚ (TP)

Av Availability

Elevation of Privilege E - - - -

 — ¨ (User)

 — ˚ (TP)

A Authorization

Linkability L - -

 — ¨ (ME)

 — ˚ (TP)

 — ¨ (ME)

 — ˚ (TP)

- An Unlinkability

Identiﬁability I - -

 — ¨ (ME)

 — ˚ (TP)

 — ¨ (ME)

 — ˚ (TP)

- Un Anonymity

Origin / Delivery - -

 — ¨ (ME, User(receiver))

 — ˚ (TP)

 — ¨ (ME)

 — ˚ (TP)

- Origin / Delivery

Non-repudiation

Submission / Receipt

- -

 — ¨ (ME, User(receiver))

 — ˚ (TP)

 — ¨ (ME)

 — ˚ (TP)

Den

Submission / Receipt

Deniability

Detectability D - -

 — ¨ (ME)

 — ˚ (TP)

 — ¨ (ME)

 — ˚ (TP)

- UnDect Undetectability

Current - -

 — ¨ (ME)

 — ˚ (TP)

 — ¨ (ME)

 — ˚ (TP)

- Current

Information

Disclosure Previous / Future

- -

 — ¨ (ME)

 — ˚ (TP)

 — ¨ (ME)

 — ˚ (TP)

Forward / Backward

Conﬁdentiality

Privacy Interdependence I -

 — ¨ (TE, ME, User)  — ¨ (ME, User(receiver))

- - PI Privacy Independence

Policy non-compliance N

 — ¨ (TE, ME)  — ¨ (TE, ME)  — ¨ (TE, ME)  — ¨ (TE, ME)

- PN Policy compliance

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

602
