environment. On the other side, VAG is an indirect
measuring technique. We are not able to determine
the thickness of a cartilage, but we measure the crepi-
tus intensity. Therefore, it will be difficult to achieve
a reliable relation between thickness and sound or de-
gree of disorder or injury. VAG can be used as a gate-
keeper technology and it is convenient to be used for
a long term usage to obtain trends and progress states.
6 CONCLUSION AND FUTURE
WORK
In the paper, we describe a new concept of using the
technology of vibroarthrography (VAG) by using sta-
tionary and mobile assessment of vibrations of human
joints during motion. Hereby, we describe the gen-
eral concept of a stationary assessment system and
outline the improvements. The analysis of the vibra-
tion pattern assessed with the enhanced VAG system
enables a high sophisticate classification with neu-
ral nets and the discrimination of healthy or injured
joints. Therefore, we propose to build up a compre-
hensive database, consisting of heterogeneous sensor
data assessed by the enhanced VAG sensor network.
The future work will be the application of the con-
cept and the implementation of a database. Further-
more, we will investigate the relevance of trajectories
of the leg and the interplay of muscle strength, ve-
nous insufficiency, and joint disease. VAG did not
found the respected dissemination or usage as a diag-
nosis tool so far, but we assume that the advantage of
a harmless, easy to perform and cheap analysis leads
to its establishment. We propose that not only injured
but also artificial joints can be analyzed.
ACKNOWLEDGMENTS
This work receives funding from the German Federal
Ministry for Economic Affairs and Energy by ZIM-
16KN04913, related to the project MOREBA.
REFERENCES
Abbott, S. C. and Cole, M. D. (2013). Vibration arthrom-
etry: a critical review. Critical reviews in biomedical
engineering, 41(3):223–242.
Altman, R., Asch, E., Bloch, D., Bole, G., Borenstein, D.,
Brandt, K., Christy, W., Cooke, T., Greenwald, R.,
Hochberg, M., et al. (1986). Development of crite-
ria for the classification and reporting of osteoarthri-
tis: classification of osteoarthritis of the knee. Arthri-
tis & Rheumatism: Official Journal of the American
College of Rheumatology, 29(8):1039–1049.
Andersen, R. E., Arendt-Nielsen, L., and Madeleine, P.
(2018). Knee joint vibroarthrography of asymp-
tomatic subjects during loaded flexion-extension
movements. Medical & biological engineering &
computing, 56(12):2301–2312.
Athavale, Y. and Krishnan, S. (2019). A telehealth system
framework for assessing knee-joint conditions using
vibroarthrographic signals. Biomedical Signal Pro-
cessing and Control.
Chu, M., Gradisar, I., and Mostardi, R. (1978). A nonin-
vasive electroacoustical evaluation technique of carti-
lage damage in pathological knee joint. Electronics
Letters, 16(4):437–442.
Chu, M. L., Gradisar, I. A., Railey, M. R., and Bowling,
G. F. (1976). Detection of knee joint diseases using
acoustical pattern recognition technique. Journal of
Biomechanics, 9(3):111–114.
Frank, C. B., Rangayyan, R. M., and Bell, G. D. (1990).
Analysis of knee joint sound signals for non-invasive
diagnosis of cartilage pathology. IEEE Engineering in
Medicine and Biology Magazine, 9(1):65–68.
Hollander, D. B., Yoshida, S., Tiwari, U., Saladino, A.,
Nguyen, M., Boudreaux, B., and Hadley, B. (2018).
Dynamic analysis of vibration, muscle firing, and
force as a novel model for non-invasive assessment
of joint disruption in the knee: A multiple case report.
The Open Neuroimaging Journal, 12(1).
Hueter, C. (1883). Grundriss der chirurgie. FCW Vogel.
Kernohan, W. G., Beverland, D. E., McCoy, G. F., Hamil-
ton, A., Watson, P., and Mollan, R. (1990). Vibration
arthrometry. a preview. Acta orthopaedica Scandinav-
ica, 61(1):70–79.
Kernohan, W. G., Beverland, D. E., McCoy, G. F., Shaw,
S. N., Wallace, R. G., McCullagh, G. C., and Mollan,
R. A. (1986). The diagnostic potential of vibration
arthrography. Clinical orthopaedics and related re-
search, (210):106–112.
Kim, K. S., Seo, J. H., Kang, J. U., and Song, C. G.
(2009). An enhanced algorithm for knee joint sound
classification using feature extraction based on time-
frequency analysis. Computer methods and programs
in biomedicine, 94(2):198–206.
Klemm, L., S
¨
uhn, T., Spiller, M., Illanes, A., Boese, A.,
and Friebe, M. (2019). Improved acquisition of vi-
broarthrographic signals of the knee joint.
McCauley, T. R., Kier, R., Lynch, K. J., and Jokl, P. (1992).
Chondromalacia patellae: diagnosis with mr imaging.
AJR. American journal of roentgenology, 158(1):101–
105.
McCoy, G. F., McCrea, J. D., Beverland, D. E., Kernohan,
W. G., and Mollan, R. (1987). Vibration arthrography
as a diagnostic aid in diseases of the knee. a prelim-
inary report. The Journal of bone and joint surgery.
British volume, 69(2):288–293.
Msayib, Y., Gaydecki, P., Callaghan, M., Dale, N., and Is-
mail, S. (2017). An intelligent remote monitoring sys-
tem for total knee arthroplasty patients. Journal of
medical systems, 41(6):90.
Murphy, L., Cisternas, M., Pasta, D., Helmick, C., and
Yelin, E. (2017). Medical expenditures and earnings
