CkTail: Model Learning of Communicating Systems

ebastien Salva and Elliott Blot

LIMOS - UMR CNRS 6158, Clermont Auvergne University, France

Keywords:

Reverse Engineering, Model Learning, Communicating Systems, IOLTS, Dependency Graphs.

Abstract:

Event logs are helpful to ﬁgure out what is happening in a system or to diagnose the causes that led to an unex-

pected crash or security issue. Unfortunately, their growing sizes and lacks of abstraction make them difﬁcult

to interpret, especially when a system integrates several communicating components. This paper proposes

to learn models of communicating systems, e.g., Web service compositions, distributed applications, or IoT

systems, from their event logs in order to help engineers understand how they are functioning and diagnose

them. Our approach, called CkTail, generates one Input Output Labelled Transition System (IOLTS) for every

component participating in the communications and dependency graphs illustrating another viewpoint of the

system architecture. Compared to other model learning approaches, CkTail improves the precision of the gen-

erated models by better recognising sessions in event logs. Experimental results obtained from 9 case studies

show the effectiveness of CkTail to recover accurate and general models along with component dependency

graphs.

1 INTRODUCTION

Using event logs to debug systems in the short or long

term is an approach more and more considered in the

Industry. Logs strongly help investigate issues on pro-

duction environments, and usually increase the de-

velopers’ ability to handle and detect failures. But,

it is well-known that analysing log entries is often a

long and frustrating process as it usually requires to

cover very large ﬁles. Several approaches based upon

model learning propose to ease log analysis by build-

ing models that generalise the behaviours of systems

encoded in logs and by making them readable (Krka

et al., 2010; Ohmann et al., 2014; Salva and Blot,

2019; Salva and Durand, 2015; Pastore et al., 2017;

Biermann and Feldman, 1972; Mariani and Pastore,

2008; Beschastnikh et al., 2014). We consider in the

paper passive model learning approaches that infer a

speciﬁcation by gathering and analysing system exe-

cutions and concisely summarising the frequent inter-

action patterns as state machines that capture the sys-

tem behaviour (Ammons et al., 2002). The obtained

models, even if partial, can serve many purposes, e.g.,

they can be used as documentation, examined by de-

signers to ﬁnd bugs, or can be given to testing meth-

ods.

This paper focuses on the generation of models

of communicating systems from event logs although

some works already proposed solutions (Mariani and

Pastore, 2008; Beschastnikh et al., 2014; Salva and

Blot, 2019). The algorithm given in (Mariani and Pa-

store, 2008) segments event logs into execution traces

by considering two factors, component identiﬁcation

and user identiﬁcation, then models are built using

the kBehavior algorithm (Mariani et al., 2011). The

CSight tool (Beschastnikh et al., 2014) takes as in-

puts trace sets, which have to be manually built by

hands w.r.t. to several restrictions. Models are then

generated and reﬁned by means of invariants. We

also proposed the tool Assess (Salva and Blot, 2019),

which is specialised in the model learning of compo-

nent based systems from which the component inter-

actions are not observable. Assess splits event logs

into traces by looking for longer time delays between

messages. Then, it tries to detect implicit component

calls in traces and builds models encoding these calls

with new synchronisation actions. We observed that

these previous approaches suffer from one main is-

sue related to session recovery in event logs. We call

a session a temporary message interchange among

components forming a behaviour of the whole sys-

tem from one of its initial states to one of its ﬁnal

states. Recognising sessions in event logs helps ex-

tract “complete” traces and build more precise mod-

els. It is quite straightforward to recognise sessions

when a mechanism based on session identiﬁcation is

used. Unfortunately, many kinds of systems do not

use such mechanisms.

Salva, S. and Blot, E.

CkTail: Model Learning of Communicating Systems.

DOI: 10.5220/0009327400270038

In Proceedings of the 15th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2020), pages 27-38

ISBN: 978-989-758-421-3

Our approach, called Communicating system kTail

shortened CkTail, builds more precise models of com-

municating systems by better recognising sessions in

event logs with respect to 4 properties: association

of responses with their related requests, time delays,

data dependency and component identiﬁcation. To

design CkTail, we choose to extend the k-Tail tech-

nique (Biermann and Feldman, 1972) with the capa-

bility to build one model called Input Output Labelled

Transition System (IOLTS) for every component of

the system under learning. k-Tail is indeed well-know

to quickly and efﬁciently build generalised models

from traces. Furthermore, our approach also goes fur-

ther in model learning by proposing the generation of

dependency graphs. The latter show in a simple way

the directional dependencies observed among compo-

nents. We believe that this kind of graph completes

the behavioural models and will be helpful to evalu-

ate different kinds of model properties, e.g., testability

or security. In the paper, we deﬁne component depen-

dency over three expressions formulating these situa-

tions: direct component requests, nested requests and

data dependency. This deﬁnition aims to avoid the in-

ference of ambiguous dependency relations involving

one component to several potential components.

We performed an empirical evaluation based on

event logs collected from 9 case studies to assess the

precision of the models and of the dependency graphs.

We show that CkTail is more effective than the three

previously cited approaches.

The paper is organized as follows: we recall some

deﬁnitions about the IOLTS model in Section 2. Our

approach is presented in Section 3 with a motivating

example. The next section shows some results of our

experimentations. Section 5 discusses related work.

Section 6 summarises our contributions and draws

some perspectives for future work.

2 THE IOLTS MODEL

We express the behaviours of communicating compo-

nents with IOLTSs. This model is deﬁned in terms

of states and transitions labelled by input or output

actions, taken from a general action set L, which ex-

presses what happens. τ is a special symbol encoding

an internal (silent) action; it is common to denote the

set L ∪ τ by L

Deﬁnition 1 (IOLTS). An Input Output Labelled

Transition System (IOLTS) is a 4-tuple hQ,q0,Σ,→i

where:

• Q is a ﬁnite set of states; q0 is the initial state;

• Σ ∪ {τ} ⊆ L

is the ﬁnite set of actions, with τ

the internal (unobservable) action. Σ

⊆ Σ is

the countable set of input actions, Σ

⊆ Σ is the

countable set of output actions, with Σ

∩ Σ

• →⊆ Q × Σ ∪ {τ} × Q is a ﬁnite set of transitions.

A transition (q,a,q

) is also denoted q

−→ q

A trace is a ﬁnite sequence of observable actions in

∗

. For sake of readability, we also write l ∈ l

when

l is a subsequence of the sequence l

; last(l) refers to

the last element of l. Furthermore, to better match

the functioning of communicating systems, we as-

sume that an action has the form a(α) with a a la-

bel and α an assignment of parameters in P, with

P the set of parameter assignments. For example,

switch( f rom := c

,to := c

,cmd := On) is made up

of the label ”switch” followed by a parameter assign-

ment expressing the components involved in the com-

munication and a parameter of the switch command.

3 THE CkTail APPROACH

Given an event log, collected by monitoring tools on a

system under learning denoted SUL, CkTail extracts

traces, generates one IOLTS for every component or

software of SUL involved in the communications and

builds its dependency graph. Here, an IOLTS aims

at generalising the behaviours encoded in event logs

with inputs and outputs showing the messages re-

ceived and sent by a component.

The ability of CkTail to infer models is dependent

on several realistic assumptions made on SUL:

• A1 Event Log: the communications among the

components can be monitored by different tech-

niques, on components, on servers, by means of

wireless sniffers, etc. But, event logs have to be

collected in a synchronous environment made up

of synchronous communications. Furthermore,

the messages have to include timestamps given by

a global clock for ordering them. For simplicity,

we consider having one event log at the end of the

monitoring process;

• A2 Message Content: components produce mes-

sages that include two parameter assignments of

the form f rom := c, to := c expressing the com-

ponent source and the destination of a message.

Other parameter assignments may be used to en-

code data. Besides, a message is either identiﬁed

as a request or a response. Many protocols al-

low to easily and automatically distinguish both

of them;

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

• A3 Device Collaboration: components can run

in parallel and communicate with each other. To

recognise sessions of the system in event logs, we

assume that components follow this behaviour:

they cannot run multiple instances; requests are

processed by a component on a ﬁrst-come, ﬁrst

served basis. Besides, every response is associ-

ated to a request and vice-versa.

The last assumption helps process event logs with

the aim of extracting the messages of each compo-

nent into disjointed sequences of individual sessions.

It is possible to replace this assumption by the more

classical one stating that messages include an identi-

ﬁer allowing to observe whole collaborations among

components. This last assumption strongly eases the

trace extraction from event logs. Unfortunately, we

have observed that session identiﬁcation is seldom

used with communicating systems. Instead, we have

chosen to consider the assumption A3. But it is worth

noting that if a session mechanism is used in SUL, the

ﬁrst step of CkTail may be adapted (simpliﬁed) to still

detect dependencies among components.

3.1 CkTail Overview

Figure 1 illustrates an overview of the three steps of

CkTail. Initially, the user gives as inputs an event log

along with regular expressions. The raw messages

of the event log are ﬁrstly parsed and analysed with

these expressions to structure them into actions of the

form a(α) with a a label and α some parameter as-

signments. Figure 1 shows a list of 12 actions de-

rived from raw HTTP messages. The action struc-

ture meets the previous assumptions: the assignments

of the variables f rom and to indicate the sources and

destinations of the messages. For sake of readability,

the labels directly show whether an action encodes

either a request or a response. In this example, the

other parameter assignments are data expressing com-

mands (e.g., param:=heating, cmd:=on), temperature

values (e.g., param:=udevice, svalue:=66) or compo-

nent states (e.g., param:=udevice, svalue:=open). At

this stage, we can observe that there are 5 compo-

nents. But interpreting their interactions and what

they can do is still tricky because of lack of readability

and generalisation.

The ﬁrst step of CkTail is called Trace analysis.

It covers the action list derived from the event log

and aims at segmenting it into traces that capture ses-

sions. A trace is a subsequence of the action list that

meets some constraints formulated from the assump-

tions A1-A3. These constraints are detailed in Section

3.2 and summarised as follows. A response is always

associated to its related request in a trace (A3). Nested

requests (a request to a component that also performs

another request before giving a response) are always

kept together in a trace (A3). A trace gathers mes-

sages exchanged between components interacting to-

gether in a limited time delay (A1). And, a chain of

messages sharing the same data expresses a data de-

pendency among several components. This chain of

messages must be kept in the same trace (A2).

During this process, the component interactions

are also analysed for detecting component dependen-

cies. These dependencies are given under the form

of component lists c

.. .c

expressing that a com-

ponent c

depends on a component c

, which itself

depends on another component and so on. The set

Deps gathers these component lists. The example

of set Deps of Figure 1 captures several dependen-

cies. For instance, d

G is given by req1 as c

di-

rectly calls G. d

is given from the nested re-

quests req1req3, showing that d

calls G, which itself

calls d

before answering to d

. d

is a data de-

pendency observed between d

and d

related to the

shared value (svalue:=68) exchanged between the two

components.

The second step Dependency Graph Generation

takes back the set Deps, constructs Direct Acyclic

Graphs (DAGs) from the component lists and even-

tually computes the transitive closure of the DAGs.

These DAGs only capture the dependencies given in

Deps, i.e. two different lists c

and c

are not

associated to avoid the representation of false links

among components. The dependency graphs illus-

trated in Figure 1 (top right) show the dependent com-

ponents of every component of SUL. The compo-

nents required by some other ones can be retrieved

though. These graphs also show in our example that

the component G (a gateway) takes a central place as

it is required for d1 and d3, and it depends on d2 and

d4.

The third step Model Generation builds IOLTSs.

In the ﬁgure, the Step 3A Trace Partitioning begins by

preparing the set Traces(SUL). Every action is dou-

bled to give a pair output/input by separating the no-

tion of source/destination by means of the new param-

eter id assigned either to the source or to the destina-

tion of a message. During this process, Traces(SUL)

is partitioned into as many trace sets as components

found in SUL. Each trace set T

gathers only the

traces related to the component c. The Step 3B IOLTS

Generation transforms every set T

into an IOLTS by

converting traces into IOLTS path cycles, which are

joined on the initial state only. In our example, as

we have 5 trace sets, we obtain 5 IOLTSs. Finally,

the Step 3C IOLTS Reduction, applies the k-Tail algo-

rithm to the IOLTSs in order to merge their equiv-

CkTail: Model Learning of Communicating Systems

Figure 1: Approach overview.

alent states. With k-Tail, the equivalent states are

those having the same k-future, i.e. the same event

sequences having the maximum length k. In our ex-

ample, the states in white of the two IOLTSs L

and

are merged.

With these IOLTSs and the DAGs, it becomes eas-

ier to observe that SUL is made up of two sensors d

and d

connected to a gateway G. The ﬁrst is a motion

detector providing states and the second gives tem-

perature values. The gateway controls two actuators,

here two heating systems d

, d

, with respect to the

values provided by the sensors. When the d

state is

on, the heating systems are turned on. When d

sends

a temperature upper to 68, the gateway turns off the

heating system d

only and forwards the temperature

to d

in the meantime.

The CkTail steps are now detailed in the next sec-

tions.

3.2 Trace Analysis

As stated previously, this ﬁrst step covers an event log

to extract the trace set Traces(SUL) and the set Deps

of dependency lists. The messages of the event log

are ﬁrstly parsed and analysed with regular expres-

sions to retrieve actions of the form a(α). If the user

is not able to give these regular expressions, several

approaches and tools have been proposed to automat-

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

ically mine patterns from log ﬁles (Fu et al., 2009;

Makanju et al., 2012; Vaarandi and Pihelgas, 2015;

Messaoudi et al., 2018; Zhu et al., 2018). These pat-

terns may be used to quickly derive regular expres-

sions. The resulting actions have to meet the require-

ments given by the assumptions A1-A3. We deﬁne

the following notations to express some of these re-

quirements:

Deﬁnition 2. Let a(α) be an action in L

• f rom(a(α)) = c denotes the source of the mes-

sage,

• to(a(α)) = c denotes the destination,

• components(a(α)) = { f rom(a(α)),to(a(α))},

• time(a(α)) denotes the timestamps,

• data(a(α)) = α \ components(a(α)) \ time(a(

α)),

• isReq(a(α)), isResp(a(α)) are boolean expres-

sions expressing the nature of the message.

Once we have the list of actions, which we denote S,

this step segments it into traces by trying to recover

sessions. As we assume the latter are not identiﬁed,

we propose an algorithm that detects them by follow-

ing the assumptions A1-A3. To devise this algorithm,

we thoroughly derived a complete list of constraints

from A1-A3. Some of them are given in Table 1.

Given an action a(α), some constraints forbids start-

ing a new trace from a(α): with C1, a response must

be kept with its associated request in the same trace;

similarly, with C2, nested requests must remain to-

gether in the same trace. On the contrary, other con-

straints imply to cut the action list. For instance, C3

implies that a new component not yet observed that

sends a new request, is starting a new session. We

hence consider that this request starts a new trace.

Other constraints, e.g., C4, reﬂect incoherent cases

that do not meet our assumptions. C5 is a special con-

straint expressing that a component, which has pre-

viously participated in the current session, can send

a new request. The choice of keeping this new re-

quest or not in the current session is not obvious. To

make this choice, we propose to consider two other

factors, i.e., time delay and data dependency, with the

constraints C5.1 and C5.2. The notion of data depen-

dency will be presented in Section 3.3.

To be used by our trace analysis algorithm, we

have formulated these constraints with the notations

of Deﬁnition 2 completed with the following sets

and boolean expressions. We denote Lreq the set

of lists of pending requests made in parallel at a

given time, i.e. lists of actions a

(α

). ..a

(α

)

with isReq(a

(α

))

1≤i≤k

for which responses have

not yet been received. KC denotes the list of

Table 1: Some constraints derived from the assumptions

A1-A3.

C1 A response a

(α

) is associated to a request observed previously in

the same session

C2 A component that receives a request a

(α

) can call other compo-

nents to produce a response in the same session.

C3 A component not yet encountered that has no pending request can

send a new request a

(α

) and starts a new session.

C4 A component that previously requested another component, cannot

send a new request a

(α

), it needs to wait for the response of the

ﬁrst one.

C5 A component that has completed its request ﬂow (received or sent

requests) in a session, can send a new request a

(α

) to another

component. C5.1: if the time delay between this request and the

previous request made by this component is short, the request be-

longs to the session. C5.2: if this request shares data with previous

actions, then the request belongs to the same session as these ac-

tions.

Table 2: Constraint formalisation. C1 C2 and C5 are the

constraints allowing an action to be kept in a current trace.

Constraint

C1 isResp(a

(α

)) and ∃!l ∈ Lreq: f rom(a

(α

)) = to(last(l)) and

to(a

(α

)) = f rom(last(l))

C2 isReq(a

(α

)) and Lreq

= {l ∈ Lreq | f rom(a

(α

)) =

to(last(l))} 6=

0 and ¬pendingRequest( f rom(a

(α

)))

C5 isReq(a

(α

)) and f rom(a

(α

)) ∈ KC and ∀l ∈ Lreq :

f rom(a

(α

)) 6= to(last(l)) and ¬pendingRequest( f rom(a

(α

)))

known components involved in the session so far.

pendingRequest(c) is the boolean expression (∃c ∈

KC,∃l ∈ Lreq,a(α) ∈ l : c ∈ components(a(α))) that

evaluates whether the component c has sent (resp. re-

ceived) a request and has not yet received (resp. sent)

the response. From these notations, we have formu-

lated the above constraints, listed their boolean terms

and studied all their possible permutations. Table 2

lists the constraints expressing that an action a

(α

)

must be kept in the current trace when they hold.

Algorithms 1 and 2 implement the above con-

straints and segment an action list S into traces.

This recursive algorithm is initially called with

KeepSplit(S,S); it returns Traces(SUL) and the ﬁ-

nal component set C, which differs from KC, the set

of known components in a session. If the action list S

starts with a response (without having any request be-

fore), it is deleted (lines 1-3). Otherwise, a new trace

t is started with a ﬁrst request. The list of pending re-

quests Lreq is updated with the procedure Extend and

the set of known components KC is completed w.r.t.

this request. Then, every action a

(α

) of the list S is

covered to decide whether the action is kept in the cur-

rent trace (line 9). If the constraint C1 holds (receipt

of a response associated to a previous request), a

(α

)

is added to the trace t. The associated pending request

is removed from Lreq with the procedure Trim. If C2

CkTail: Model Learning of Communicating Systems

holds (receipt of a request that is nested to a previous

request in Lreq), a

(α

) is also added to the trace t.

To check whether C2 holds, a subset Lreq

of Lreq is

constructed: it is composed of the request sequences

ended by a request a(α) such that a(α)a

(α

) gives

form to nested requests. If Lreq

has several candi-

dates, i.e. request lists, we keep the list l ended by the

request having the earliest time-stamp (line 13). With

this condition, we comply with A3 (ﬁrst-come, ﬁrst

served basis). This list l is augmented with the current

request a

(α

) by calling the procedure Extend (line

14). The set of known components KC is updated.

Finally, when C5 holds (line 15), we evaluate the con-

straints C5.1 or C5.2 implemented by the procedures

Checktime and Checkdatadeps. If one of these pro-

cedures returns true, the request a

(α

) is added to the

trace t. The procedure Extend completes Lreq with

a new request list starting by a

(α

). The set KC is

still updated w.r.t. the request a

(α

). For any other

case, we put the action a

(α

) into a new action list t

(line 18). Once all the actions have been covered, the

trace t is added to Traces(SUL). If the action list t

is not empty, the algorithm is called again to split it

(line 23).

The procedure Checktime takes a trace t and a re-

quest a

(α

). Its purpose is to check whether the time

delay between this request and the previous one made

by the same component c is strongly lower than the

average time delay between two requests made by c.

This average time delay is denoted T (c). Its computa-

tion is made on the action list S. In short, we ﬁlter out

all the responses along with the requests not made by

the component c in S. Then, we compute the mean of

time delays between every request pairs. Checktime

also ﬁlters the trace t to keep the requests made by the

component c = f rom(a

(α

)). The procedure com-

putes the time delay between the request a

(α

) and

the previous one in the trace t. If this time delay is

lower to T (c), C5.1 holds, hence the procedure re-

turns true.

The procedure Checkdatadeps implements the

constraint C5.2 and checks whether a data depen-

dency exists in the trace t. The notion of dependency

among components is discussed in the next section.

3.3 Dependency Graph Generation

Before generating dependency graphs, we need to ex-

press what a component dependency is. Deﬁnition 3

relies on three expressions to formulate this notion.

The ﬁrst illustrates that a component c

depends on

another component c

when c

queries c

with a re-

quest. The second expression deals with nested re-

quests: if we have successive nested requests of the

Algorithm 1: KeepSplit(S, S

input : Action sequences S, S

output: Traces(SUL), Component set C

1 S

= a

(α

). .. a

(α

);

2 while isResp(a

(α

)) do

3 KeepSplit(S,a

(α

). .. a

(α

));

4 END;

5 t = a

(α

); Extend(Lreq,ε,t);

6 t

= ε;

7 KC = components(a

(α

));

8 i=2;

9 while i ≤ k do

10 Case C1 : t = t.a

(α

); Trim(Lreq, l);

11 Case C2 :

12 t = t.a

(α

);

13 take l ∈ Lreq

such that

∀l

6= l ∈ Lreq

: time(last(l) ≤ time(last(l

);

14 Extend(Lreq,l,t);

15 Case C5 and (Checktime(a

(α

),t) or

Checkdatadeps(a

(α

),S,t)) :

16 t = t.a

(α

);

17 Extend(Lreq,ε,t);

18 Else : t

= t

(α

);

19 KC = KC∪components(a

(α

));

20 i++;

21 Traces(SUL) = Traces(SUL) ∪ {t};

22 C = C ∪ KC;

23 if t

6= ε then

24 KeepSplit(S,t

);

form req1( f rom := c

,to := c)req2( f rom := c,to :=

), we deﬁne that c

depends on c, which itself de-

pends on c

and so on. The last expression refers to

data dependency. We say that c

depends on c

when

has sent a message a

(α

) with some data, if there

is a unique chain of messages a

(α

). ..a

(α

) from

sharing this data and if a

(α

) is a request whose

destination is c

Some dependency cases, or patterns, might have

been forgotten in this deﬁnition. For instance, when

there are two or more chains of messages sharing the

same data, addressed to the same component c, we ob-

serve that there is a data dependency among compo-

nents but we are unable to decide which dependency

relation is correct. Because of this ambiguity, none of

them is kept.

Deﬁnition 3 (Component Dependency).

Let c

∈ C, c

6= c

, and S an action list. We write

depends on c

iff:

1. c

calls c

: ∃a(α) ∈ S : isReq(a(α)),

f rom(a(α)) = c

,to(a(α)) = c

;

2. there is a nested request between c

and

: ∃a

(α

),a

(α

) ∈ S, ∀a(α) ∈ S:

isReq(a

(α

))

(i=1,2)

, isResp(a(α)), f rom(a

(

)) = c

, to(a

(α

)) = f rom(a

(α

)),

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

to(a

(α

)) = c

, to(a(α)) = c

¬(a

(α

)a(α)a

(α

) ∈ S);

3. there is a longest chain of messages from c

ended by a request to c

sharing the same data α:

∃l = a

(α

). ..a

(α

) ∈ S : DS(l,c

,α)

and ∀l

= a

(α

). ..a

(α

) ∈

S : DS(l

,α) and l

∈ l, with

DS(a

(α

). ..a

(α

,α) the boolean ex-

pression f rom(a

(α

)) = c

∧ to(a

(α

)) = c

∧

isReq(a

(α

))∧ to(a

(α

)) = f rom(a

i+1

(α

i+1

)

1≤i<k)

∧ α ⊆

(1≤i≤k)

The set Deps gathers component dependencies un-

der the form of component lists c

.. .c

. Compo-

nent dependencies are detected while Algorithm 1

builds traces by means of the procedures Extend and

Checkdatadeps. The procedure Extend detects the

two ﬁrst component dependency cases of Deﬁnition

3. It uses the set of pending requests Lreq to com-

plete the set Deps. Indeed, Algorithm 1 builds Lreq

in such a way that a sequence of Lreq is either a re-

quest (Case C5) or a list of nested pending requests

(Case C2). The procedure covers the component se-

quences lc = c

.. .c

k+1

of Lreq and adds the depen-

dency lists in Deps (line 8).

The procedure Checkdatadeps(a

(α

),S,t)

checks whether the last expression of Deﬁnition

3 holds. If there is a unique chain of mes-

sages a

(α

). ..(a

(α

) sharing the same data

α ∈ data(a

(α

)) and ﬁnished by the request a

(α

)

then the dependency to(a

(α

)). f rom(a

(α

)) is

added to Deps (line 15). If this chain of messages is

a subsequence of the current trace t.a

(α

), then the

constraint C5.2 is satisﬁed. As a consequence, the

procedure also returns true to Algorithm 1 to indicate

that this request must be kept in the current trace.

Algorithm 3 can now generate dependency graphs

from the set Deps. It partitions Deps to group the de-

pendency lists starting by the same component in the

same subset. This partitioning is performed by the

equivalence relation ∼

on C

∗

given by ∀l

∈ Deps,

with l

= c

.. .c

, l

= c

.. .c

, l

∼

iff c

= c

Given a partition C

, and a component list l ∈ C

, Al-

gorithm 3 builds a path of the DAG Dg

such that the

state is labelled by the n

component of l. Algo-

rithm 3 ﬁnally computes the transitive closure of the

DAGs to make all component dependencies visible.

3.4 Model Generation

This last step, implemented by Algorithm 4, generates

an IOLTS for every component previously encoun-

tered and stored in C. To build IOLTSs, the traces of

Algorithm 2.

1 Procedure Trim(Lreq, l) is

2 l

= remove(last(l));

3 Lreq = Lreq \ {l} ∪ {l

};

4 Procedure Extend(Lreq,l,t) is

5 l

= l.last(t) = a

(α

). .. a

(α

);

6 Lreq = Lreq \ {l} ∪ {l

};

7 //Compute component dependencies

8 lc = c

.. .c

k+1

such that c

= f rom(a

(α

))

(1≤ j≤k)

k+1

= to(a

(α

));

9 Deps = Deps ∪ {lc};

10 Procedure Checktime(a

(α

),t) is

11 t

= t\{a(α) | f rom(a

(α

)) 6= f rom(a(α)) or

isResp(a(α))};

12 return

(time(a

(α

)) −time(last(t

))) << T( f rom(a

(α

))));

13 Procedure Checkdatadeps(a

(α

),S,t) is

14 if ∃α ∈ data(a

(α

)), ∃l = a

(α

). .. a

(α

) ∈ S :

DS(l,to(a

(α

)), f rom(a

(α

)),α) and

∀l

= a

(α

). .. a

(α

) ∈ S :

DS(l

,to(a

(α

)), f rom(a

(α

)),α) and l

∈ l then

15 Deps = Deps ∪ {to(a

(α

)). f rom(a

(α

))};

16 if l ∈ t.a

(α

)) then

17 return true;

18 else

19 return false;

Algorithm 3: Device Dependency Graphs Generation.

input : Deps

output: Dependency graph set DG

1 foreach C

∈ Deps/ ∼

2 foreach c

.. .c

∈ C

3 add the path s

→ s

.. .s

k−1

→ s

to Dg

;

4 Dg

is the transitive closure of Dg

;

5 DG = DG ∪ {Dg

};

Traces(SUL) are transformed to integrate the notions

of input and output. Given a trace a

(α

). ..a

(α

every action is doubled by separating the component

source and the destination of the message. For an

action a

(α

), the algorithm writes a new trace com-

posed of the output !a

(α

) sent by the source of the

message, followed by the input ?a

(α

) received by

the destination (line 3). The source and the destina-

tion are now separated by a new assignment on the

parameter id. Next, these traces are segmented into

subsequences in such a way that a subsequence cap-

tures the behaviour of one component only. Subse-

quences are also grouped by component in trace sets

denoted T

with c a component of C (lines 4,5).

These trace sets are now lifted to the level

of IOLTSs. Given the trace set T

, a trace t =

(α

). ..a

(α

) ∈ T is transformed into the path

CkTail: Model Learning of Communicating Systems

(α

)

−−−−→ q

.. .q

k−1

(α

)

−−−−→ q0 such that the states

.. .q

k−1

are new states. These paths are joined on

the state q0 to build the IOLTS L

Deﬁnition 4 (IOLTS Generation). Let T

= {t

,. ..,

} be a trace set. L

= hQ,q0, Σ,→i is the IOLTS

derived from T

where:

• q0 is the initial state.

• Q,Σ,→ are deﬁned by the following rule:

(α

)...a

(α

)

(α

)

−−−−→q

...q

ik−1

(α

)

−−−→q0

Finally, Algorithm 4 applies the k-Tail algorithm to

generalise and reduce the IOLTSs by merging the

equivalent states having the same k-future. We use

k = 2 as recommended in (Lorenzoli et al., 2008; Lo

et al., 2012).

Algorithm 4: IOLTS Generation.

input : Traces(SUL)

output: LTSs L

.. .L

1 T = {};

2 foreach t = a

(α

). .. a

(α

) ∈ Traces(SUL)) do

3 t

=!a

(α

)?a

(α

). ..!a

(α

)?a

(α

) such that

= α

∪ {id := f rom(a

(α

))},

= α

∪ {id := to(a

(α

))}(1 ≤ i ≤ k);

4 foreach c ∈ C do

5 T

= T

∪ {t

\ {a(α) ∈ t

| id := c /∈ α}

6 foreach T

with c ∈ C do

7 Generate the LTS L

from T

;

8 Merge the equivalent states of L

with k-Tail(k = 2,L

);

4 PRELIMINARY EVALUATION

Our approach is implemented in Java and is released

as open source at https://github.com/Elblot/CkTail.

With this implementation, we conducted some exper-

iments in order to provide answers for the following

questions:

• RQ1: Can CkTail derive models that capture cor-

rect behaviours of SUL? RQ1 studies how the

models accept valid traces, i.e. traces extracted

from event logs but not used for the model gener-

ation, compared to the model learning tools spe-

cialised for communicating systems;

• RQ2: Can CkTail build models that reject abnor-

mal behaviours? This time, RQ2 investigates how

the models accept invalid traces;

• RQ3: Is CkTail able to detect accurate dependen-

cies among components?

4.1 Empirical Setup

RQ1 and RQ2 evaluate the precision of the models

generated by CkTail. We here compare CkTail with

3 other tools, CSight, Assess and the tool suite pro-

posed in (Mariani and Pastore, 2008) based upon the

tool kbehavior, which we denote LFkbehavior. To

perform an unbiased evaluation, we need to take into

consideration how these tools work. Assess is spe-

cialised to the model learning of component-based

systems systems from event logs in which the inter-

actions are not observable. Assess segments an event

log into traces every time it detects longer time delays

between messages. Then, it builds models integrat-

ing special actions expressing component calls and

proposes two strategies to synchronise these models

called Loosely-coupling and Decoupling. The latter

returns more general models than the former by al-

lowing the call of any component any time. We con-

sider both strategies in this evaluation. The approach

given in (Mariani and Pastore, 2008) can infer mod-

els of communicating systems by segmenting an event

log for each component of the system under learning

and by applying kbehavior on the trace sets to gener-

ate models. Finally, CSight only takes trace sets, one

set for each component.

The study has hence been conducted on several

use cases with several conﬁgurations. Firstly, from a

set of 7 devices (3 sensors, 2 gateways, 2 actuators),

we built 6 IoT systems denoted Con f 1 to Con f 6, by

varying the number of devices and the behaviours of

the gateway(s) after the receipt of data from the sen-

sors. One or two gateways can be used , themselves

interconnected to at least two sensors and one actu-

ator. In each conﬁguration, the components follow

a known dependency scheme, which will be used to

evaluate RQ3. We also extracted a log from another

IoT system denoted Con f 7, where 8 sensors send data

to a gateway. We were unable to build models from

any of these conﬁgurations with CSight after 5 hours

of computation, which was our limit for each exper-

iment. We observed that the ﬁrst steps of CSight

were achieved, but these were always followed by

successive time-outs while the model reﬁnement step.

Therefore, to compare CSight and CkTail, we took

back two trace sets available with the CSight imple-

mentation. The ﬁrst one was extracted from TCP logs,

and the second one from logs of the AlternatingBit

protocol. As we have trace sets instead of logs with

these two use cases, we only compare CSight with the

third step of CkTail.

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

Figure 2: Percentage of valid traces accepted by the models

generated with CkTail, Assess, Lfkbehavior.

4.2 RQ1: Can CkTail Derive Models

that Capture Correct Behaviours of

SUL?

To measure model correctness, we used a cross vali-

dation process, which partitions the event logs of ev-

ery conﬁguration Conf1 to 7 in one training set for

the model generation and one testing set. We limited

the process to one round, as segmenting an event log

cannot arbitrarily be done: we choose to separate an

event log into two parts with an approximative ratio

of 70% and 30%, taking care not to separate actions

that belong to the same session thanks to our knowl-

edge of the conﬁgurations. To avoid any bias, model

correctness is evaluated by generating valid trace sets

from the testing set by considering 3 ways used by the

3 tools. A ﬁrst trace set is generated by calling Algo-

rithm 1. A second trace set is obtained by splitting

the event log every time a long time delay is detected

among the messages (as in Assess). The last trace set

is achieved by extracting the messages of the event

log that share the same component identiﬁcation (as

in LFkbehavior). We obtained around 65 to 285 valid

traces for Conf 1 to 7.

Results: Figure 2 shows the percentage of valid

traces accepted for each conﬁguration and tool. The

bar-diagram ﬁrstly shows that the two conﬁgurations

TCP and AlternatingBit are not sufﬁcient to efﬁ-

ciently compare CkTail and CSight as the models

given by both tools accept all the valid traces. But

these have few states and the valid trace sets are small.

As stated earlier, we were unable to apply CSight on

larger trace sets. With the other conﬁgurations, the

models that accept the most of valid traces are always

those generated by CkTail. These models accept an

average of 91.90% of valid traces. The models built

by Assess tend to have close results as they accept

83.61% of the valid traces with the Loosely-coupling

strategy and 86.42% with the Decoupling strategy.

Figure 3: Percentage of invalid traces accepted for each

method and conﬁguration.

The models given by LFkbehavior accept an average

of 37.48% of valid traces in our experiments.

4.3 RQ2: Can CkTail Build Models that

Accept Abnormal Behaviours?

We evaluated how the models generated previously

accept invalid traces. The latter were generated by

applying these mutations on the valid traces used in

RQ1: repetition of actions, inversion of a request

with its associated response, and permutation of one

request in a sequence of nested requests. We built

about 100 invalid traces for the conﬁgurations Conf1

to Conf7, and 20 invalid traces for TCP and Alternat-

ingBit. Then, we measured the proportions of invalid

traces accepted by the models inferred from the same

conﬁgurations and training sets used for RQ1.

Results: Figure 3 shows the proportions of invalid

traces accepted by the models given by each tool in

each conﬁguration. The bar-diagram reveals that only

the models produced by Assess accept invalid be-

haviours. The Decoupling strategy of Assess gives

the highest percentages (up to 80%). The main reason

behind these results is that Assess is not designed to

learn models from message exchanged among com-

ponents. After studying the models, we indeed ob-

served that many request/response pairs are separated

into different models; as the Assess strategies allow

repetitive component calls, the models accept succes-

sive requests or responses. It results that these models

accept many invalid traces.

The results given with RQ1 and RQ2 tend to show

that the models produced by CkTail offer the best pre-

cision: not only they accept the highest ratio of valid

traces, but also reject all the invalid ones (as CSight

and LFkbehavior).

CkTail: Model Learning of Communicating Systems

4.4 RQ3: Is CkTail Able to Detect

Accurate Dependencies among

Components?

As CkTail is the only model learning tool able to infer

dependency graphs, we chose to evaluate this feature

by comparing the DAGs returned by CkTail to the de-

pendency graphs we manually built with our knowl-

edge of the systems under learning. For this study, we

took back the conﬁgurations for which we have event

logs. We listed the component dependency relations

found by CkTail and studied them to also provide the

incorrect dependencies.

Table 3: Recall and Precision of CkTail to detect compo-

nent dependencies; Recall is the percentage of the real de-

pendencies that are detected; Precision is the percentage of

detected dependencies that are correct.

Recall

of the dependencies

found by CkTail

Precision

of the dependencies

found by CkTail

Con f 1 100% 100%

Con f 2 61.5% 100%

Con f 3 83% 100%

Con f 4 73% 100%

Con f 5 64% 100%

Con f 6 80% 100%

Con f 7 100% 100%

Results: Table 3 shows the recall and precision of

the component dependencies detected by CkTail. On

average, CkTail ﬁnds 80.27% of the real dependencies

and all of them are correct. The missing dependencies

(recall below 100%) stem from Deﬁnition 3, which

strictly speciﬁes what a dependency is in our context,

but also restricts the possible dependency patterns to

avoid ambiguity. We indeed observed in these exper-

iments that CkTail was able to ﬁnd several chains of

messages sharing the same data addressed to the same

component c at the same time, meaning there are sev-

eral components that potentially have a dependency

with c. But, as we are unable to state which compo-

nent relationship is right, our algorithm leaved them

aside.

5 RELATED WORK

We observed in the literature that few approaches

were proposed to learn models from communicating

systems. Groz et al. introduced in (Groz et al., 2008)

an algorithm to generate a controllable approximation

of components through active testing. This kind of ac-

tive technique implies that the system is testable and

can be queried. The learning of the components is

done in isolation. A recent work lifts this constraint

by testing a system with unknown components by

means of a SAT solving method (Petrenko and Avel-

laneda, 2019). In contrast, our approach is passive,

and only learns models from logs. Requirements are

hence quite different.

Mariani et al. proposed in (Mariani and Pastore,

2008) an automatic detection of failures in log ﬁles by

means of model learning. Their approach segments

an event log with two strategies: per component or

per user. The former generates one model for each

component. Our evaluation shows that the trace seg-

mentation algorithm of CkTail, which relies on more

properties, improves the model precision.

CSight (Beschastnikh et al., 2014) is another tool

specialised in the model learning of communicat-

ing systems, where components exchange messages

through synchronous channels. It is assumed that

both the channels and components are known. Be-

sides, CSight requires speciﬁc trace sets, which are

segmented with one subset by component. CSight

follows ﬁve stages: 1) log parsing and mining of in-

variants 2) generation of a concrete FSM that captures

the functioning of the whole system by recomposing

the traces of the components; 3) generation of a more

concise abstract FSM; 4) model reﬁnement with in-

variants that must hold in models, and 5) generation

of Communicating FSM (CFSM). With CkTail, we

do not assume that the trace sets are already prepared.

We are given an event log from which CkTail tries

to detect sessions. Regarding the model generation,

CSight allows the use of internal actions (not used

in the communications). The current requirements

of CkTail prevent from considering internal actions

to build models, but we believe that this feature could

be added to CkTail in a future work. In theory, CSight

should yield more precise models than those given by

CkTail because CFMS are reﬁned by checking the sat-

isﬁability of invariant. But, in practice, we observed

that invariant mining and satisﬁability checking are

both costly and prevent CSight from taking as input

medium to large trace sets.

Compared to the previous approaches, CkTail also

has the capability of detecting component dependen-

cies and expresses them with DAGs.

Prior to this paper, we proposed in (Salva and

Blot, 2019) the approach and tool called Assess. Its

assumptions are different from those required with

CkTail or CSight. The main difference lies in the fact

that the communications among components are as-

sumed hidden (not available in event logs). Therefore,

Assess tries to detect implicit calls of components and

adds new synchronisation actions in the models to ex-

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

press them. Its algorithm is hence speciﬁc to this

assumption. We compared CkTail with Assess and,

as expected, we showed that Assess builds imprecise

models when event logs include communications.

6 CONCLUSION

This paper has proposed CkTail, an approach that

learns models of communicating systems from event

logs. Our algorithm improves the model precision

by integrating the identiﬁcation of dependency rela-

tions among components and by better detecting ses-

sions in event logs to extract traces. Unlike CSight,

which targets the same kind of systems, CkTail re-

quires as inputs one event log only. Then, it builds ex-

ecution traces while trying to recognise complete ses-

sions with respect to 4 constraints, whereas the other

approaches rely on one or two rules for the trace seg-

mentation. The constraints used by CkTail are specif-

ically related to communicating systems and restrict

the trace generation w.r.t. the association of request-

s/responses, time delay, data dependency, component

identiﬁcation. Besides, CkTail infers DAGs show-

ing the component dependencies. They offer another

viewpoint of the component interactions and system

architecture, and they may be used to different pur-

poses, e.g., testability measurement, or security anal-

ysis.

As future work, we ﬁrstly plan to evaluate CkTail

on further kinds of systems, e.g., Web service com-

positions. The trace analysis step relies upon some

assumptions for ﬁnding sessions in event logs when

these are not identiﬁed by means of a session mech-

anism. But, if sessions are clearly identiﬁed in mes-

sages, these assumptions can be relaxed and the algo-

rithm reduced. We will investigate this possibility in a

future work to redesign the ﬁrst step of CkTail so that

it also supports session identiﬁcation.

ACKNOWLEDGEMENT

Research supported by the French Project

VASOC (Auvergne-Rh

one-Alpes Region):

https://vasoc.limos.fr/

REFERENCES

Ammons, G., Bod

ık, R., and Larus, J. R. (2002). Mining

speciﬁcations. SIGPLAN Not., 37(1):4–16.

Beschastnikh, I., Brun, Y., Ernst, M. D., and Krishna-

murthy, A. (2014). Inferring models of concurrent

systems from logs of their behavior with csight. In

Proceedings of the 36th International Conference on

Software Engineering, ICSE 2014, pages 468–479,

New York, NY, USA. ACM.

Biermann, A. and Feldman, J. (1972). On the synthesis of

ﬁnite-state machines from samples of their behavior.

Computers, IEEE Transactions on, C-21(6):592–597.

Fu, Q., Lou, J.-G., Wang, Y., and Li, J. (2009). Execu-

tion anomaly detection in distributed systems through

unstructured log analysis. 2009 Ninth IEEE Interna-

tional Conference on Data Mining, pages 149–158.

Groz, R., Li, K., Petrenko, A., and Shahbaz, M. (2008).

Modular system veriﬁcation by inference, testing and

reachability analysis. In Suzuki, K., Higashino, T.,

Ulrich, A., and Hasegawa, T., editors, Testing of Soft-

ware and Communicating Systems, pages 216–233,

Berlin, Heidelberg. Springer Berlin Heidelberg.

Krka, I., Brun, Y., Popescu, D., Garcia, J., and Medvi-

dovic, N. (2010). Using dynamic execution traces and

program invariants to enhance behavioral model infer-

ence. In Proceedings of the 32Nd ACM/IEEE Interna-

tional Conference on Software Engineering - Volume

2, ICSE ’10, pages 179–182, New York, NY, USA.

ACM.

Lo, D., Mariani, L., and Santoro, M. (2012). Learning ex-

tended fsa from software: An empirical assessment.

Journal of Systems and Software, 85(9):2063 – 2076.

Selected papers from the 2011 Joint Working IEEE/I-

FIP Conference on Software Architecture (WICSA

2011).

Lorenzoli, D., Mariani, L., and Pezz

e, M. (2008). Auto-

matic generation of software behavioral models. In

Proceedings of the 30th International Conference on

Software Engineering, ICSE’08, pages 501–510, New

York, NY, USA. ACM.

Makanju, A., Zincir-Heywood, A. N., and Milios, E. E.

(2012). A lightweight algorithm for message type ex-

traction in system application logs. IEEE Transactions

on Knowledge and Data Engineering, 24(11):1921–

1936.

Mariani, L. and Pastore, F. (2008). Automated identiﬁcation

of failure causes in system logs. In Software Reliabil-

ity Engineering, 2008. ISSRE 2008. 19th International

Symposium on, pages 117–126.

Mariani, L., Pastore, F., and Pezze, M. (2011). Dy-

namic analysis for diagnosing integration faults. IEEE

Transactions on Software Engineering, 37(4):486–

508.

Messaoudi, S., Panichella, A., Bianculli, D., Briand, L., and

Sasnauskas, R. (2018). A search-based approach for

accurate identiﬁcation of log message formats. In Pro-

ceedings of the 26th Conference on Program Compre-

hension, ICPC ’18, pages 167–177, New York, NY,

USA. ACM.

Ohmann, T., Herzberg, M., Fiss, S., Halbert, A., Palyart,

M., Beschastnikh, I., and Brun, Y. (2014). Behavioral

resource-aware model inference. In Proceedings of

the 29th ACM/IEEE International Conference on Au-

tomated Software Engineering, ASE ’14, pages 19–

30, New York, NY, USA. ACM.

Pastore, F., Micucci, D., and Mariani, L. (2017). Timed k-

tail: Automatic inference of timed automata. In 2017

CkTail: Model Learning of Communicating Systems

IEEE International Conference on Software Testing,

Veriﬁcation and Validation (ICST), pages 401–411.

Petrenko, A. and Avellaneda, F. (2019). Learning commu-

nicating state machines. In Tests and Proofs - 13th

International Conference, TAP 2019, Held as Part of

the Third World Congress on Formal Methods 2019,

Porto, Portugal, October 9-11, 2019, Proceedings,

pages 112–128.

Salva, S. and Blot, E. (2019). Reverse engineering be-

havioural models of iot devices. In 31st International

Conference on Software Engineering & Knowledge

Engineering (SEKE), Lisbon, Portugal.

Salva, S. and Durand, W. (2015). Autofunk, a fast and

scalable framework for building formal models from

production systems. In Proceedings of the 9th ACM

International Conference on Distributed Event-Based

Systems, DEBS ’15, pages 193–204, New York, NY,

USA. ACM.

Vaarandi, R. and Pihelgas, M. (2015). Logcluster - a data

clustering and pattern mining algorithm for event logs.

In 2015 11th International Conference on Network

and Service Management (CNSM), pages 1–7.

Zhu, J., He, S., Liu, J., He, P., Xie, Q., Zheng, Z., and Lyu,

M. R. (2018). Tools and benchmarks for automated

log parsing. CoRR, abs/1811.03509.

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering
