Location Extraction from Twitter Messages using Bidirectional Long

Short-Term Memory Model

Zi Chen

, Badal Pokharel

, Bingnan Li

and Samsung Lim

School of Civil & Environmental Engineering, University of New South Wales, Kensington, Sydney, Australia

Keywords: Named Entity Recognition, Location Extraction, Social Media, Deep Learning Model.

Abstract: Texts are a common form to encode location information which can be used crucially in disaster scenarios.

While Named Entity Recognition (NER) has been applied to location extraction from formal texts, its

performance on informal and colloquial texts such as social media messages is unsatisfactory. The geo-entities

in social media are often neglected or categorized into unknown or ‘other’ entity types such as person or

organisation. In this paper we proposed a Bidirectional Long Short-Term Memory (LSTM) Neural Netwok

to identify location information especially aiming to recognize rarely known local places in social media

messages. The contribution of both syntactic and semantic features to the classification results was explored

as well. The proposed method was validated on a Twitter dataset collected from typhoon-affected areas,

showing promising performance in detecting location information.

1 INTRODUCTION

Social media can be beneficial in disaster risk

reduction, response and recovery process (Ahmed,

2011), and Twitter stands out as an effective social

media platform because of its global extension and

the speed in which information gets disseminated

(Chatfield and Brajawidagda, 2013). While location

information can be crucial in disaster management,

Twitter offers three types of information for

extracting the location where the incident happens: (i)

geo-tagged texts or geo-coordinates (ii) users’

locations in their profiles (iii) location mentions in the

tweets. The previous studies show that the explicit

and accurate information about the place where an

event has happened can be gained with the tweets

having geo-coordinates (Nakaji and Yanai, 2012).

However, the tweets containing geo-coordinates are

rare among the whole Twitter stream. The location

information from the user’s profile can be an

alternative to detection of the place of event, but its

accuracy is not guaranteed. Therefore, the location

mentions in the tweet text accounts the most for the

https://orcid.org/0000-0001-5100-8393

https://orcid.org/0000-0001-5010-9205

https://orcid.org/0000-0003-3417-3295

https://orcid.org/0000-0001-9838-8960

location recognition, which requires further text

processing.

The text mining technique that is commonly used

to extract place names from texts is Named Entity

Recognition (NER). This method analyzes the text

based on Part-Of-Speech (POS) tagging and labels a

certain group of words as an entity category including

person, organisation or location. The technique

performs well for well-structured sentences and well-

known places, but not so good for the extraction of

local geo-entities from social media messages. It is

because the texts are usually written in informal or

random format due to geographic or non-geographic

ambiguities.

In order to improve the extraction of unknown

place names from the social media, we proposed a

model based on Bidirectional Long Short-Term

Memory (LSTM) Neural Netwok to recognize the

local geo-entities mentioned in soical media

messages. Stanford Named Entity Recognizer was

used to label the training data. The experimentation

was carried out to incorporate both syntactic and

semantic features in the model. In addtion to word

Chen, Z., Pokharel, B., Li, B. and Lim, S.

Location Extraction from Twitter Messages using Bidirectional Long Short-Term Memory Model.

DOI: 10.5220/0009338800450050

In Proceedings of the 6th International Conference on Geographical Information Systems Theory, Applications and Management (GISTAM 2020), pages 45-50

ISBN: 978-989-758-425-1

embedding, POS tags, letter cases and prepositions

are considered as well to augment the model.

2 RELATED WORK

The extraction of location mentions from texts is a

long-studied problem since texts are one of the most

common forms to encode geographic information, but

in this process the geo-referents of the location

mentions become ambiguous and even the boundaries

of the location mentions in text are difficult to

recognize without enough background information,

especially when the place name is abbreviated for

brevity. Naturally the place name extraction falls into

sub-problems: entity delimitation and toponym

disambiguation. The former delimitates the

boundaries of a place name, which is the focus of our

study, and the latter decides the most possible geo-

referent to the place name.

While entity delimitation can be solved by

matching with gazetteer (Sultanik and Fink, 2012) or

hard-coded rules (Cunningham et al., 2001), the

current NER tools or systems are generally more

powerful in extracting location mentions from formal

texts in terms of recall. One of the most renowned

NER systems is Stanford NER (Finkel, Grenager and

Manning, 2005) where a Conditional Random Field

(CRF) model incorporates long distance features to

identify named entities including location. Some

researchers have also attempted further augmentation

to the NER capability of extracting locations by

constructing a gazetteer from word clusters (Kazama

and Torisawa, 2008). Web NER aims at separating

complex place names from web pages by utilizing

capitalization cues and lexical statistics (Downey,

Broadhead and Etzioni, 2007).

However, the NER systems have shown

unsatisfactory performances on social media

messages (Bontcheva et al., 2013) mainly owing to

the informal and irregular expressions as well as the

short texts. An outstanding performance has been

achieved by Stanford NER when it is retrained by

annotated tweets (Lingad, Karimi and Yin, 2013), but

the annotation of social media messages is time-

consuming and elusive on large scale text processing.

Meanwhile LSTM is becoming a popular choice of

NER owing to its suitability for sequence

classification. Bi-LSTM-CRF networks using

contextualized embeddings were employed for

chemical NER (Awan et al., 2019). An exploratory

study on Indonesian Twitter Posts (Rachman et al.,

2018) used LSTM for NER and experimented on a

small dataset, on which it achieved a F1-score of 0.81

for location recognition.

Recent years have witnessed a lot of efforts

attempting to address the problem of extracting

location mentions from social media streams. A

model to predict the occurrence of location mentions

in a tweet was introduced and was found that this

preliminary process can enhance the accuracy of

entity delimitation (Hoang and Mothe, 2018). A

statistical language model was built in (Al-Olimat et

al., 2017) based on augmented and filtered region-

specific gazetteers from online resources such as

OpenStreetMap (OSM) to extract place names from

tweets, a F1-score of 0.85 was achieved while no

training data is required.

Unlike the studies above, we mainly focus on the

location mentions referring to geo-entities of small

scale, which rarely appear in most gazetteers. And a

deep learning model is constructed and trained on

Stanford NER annotated tweets, without manual

annotation.

3 METHODOLOGY

3.1 Model

We used a Bidirectional LSTM (Bi-LSTM) model,

which belongs to the category of Recurrent Neural

Networks (RNNs), to label whether a word is an

element of a location mention or not. RNN is an

appropriate approach for sequence classification due

to its capability of passing the output of one node to

its successor, which can be interpreted as the

influence of a word to the successive word. LSTM is

a specialized RNN which performs better on long

sequences while the impact of previous layers decay

along with vanishing gradient in RNN. LSTM

employs a mechanism called forget gates to control

the information flow in the neural network.

On the basis of LSTM, Bi-LSTM model is trained

on two directions of the input sequence, forward and

backward, providing comprehensive context

information of the target word. Bi-LSTM model has

been implemented on NER tasks and shown

competitive performances on benchmark datasets

(Chiu and Nichols, 2016).

As seen in Figure 1, features of the input sequence

are passed to the forward and backward LSTM layers

respectively in our model, the two outputs are

subsequently concatenated and passed to a fully

connected layer. Finally, a softmax layer outputs the

probability distribution over all the class labels.

GISTAM 2020 - 6th International Conference on Geographical Information Systems Theory, Applications and Management

Input

Features

Input

Features

Forward

LSTM

Forward

LSTM

Backward

LSTM

Backward

LSTM

Full-

connected

Layer

Full-

connected

Layer

Softmax

Output

Figure 1: Bi-LSTM model architecture.

3.2 Features

Apart from the Bi-LSTM model, we tested the

impacts of four categories of features on the

classification results: word embedding, POS tags,

capitalization and prepositions. Word embedding is a

word representation method that maps words to

continuous vectors in higher dimensions. It is

grounded on Distributional Hypothesis that words

with similar contexts are inclined to have similar

semantic meanings (Harris, 1954), and word

embedding encodes the context information in the

vector. Therefore, the similarity of two words can be

evaluated by the cosine value of their word vectors.

One of the most popular approaches of word

embedding is the Skip-Gram model. It is a fully

connected neural network that takes the one hot

encoding vector of the target word 𝑤



as input and

produces the conditional probability that an arbitrary

word 𝑤



from the vocabulary occurs in the context

window of 𝑤



. Parameters 𝜃 of the model are

optimized by maximizing the log-likelihood sum of

𝑃𝑤



𝑤



;𝜃.

The other three features, POS tags, capitalization

and prepositions are regarded as categorical data and

encoded into integers. POS tags are the labels that

denote the part of speech of a word such as noun, verb

or adjective. Since the location mentions are mostly

comprised of nouns, POS tags can signify the possible

occurrence of location mentions.

Another factor that could influence the

identification of location mentions is the

capitalization or case of a word. We consider the

capitalization in three categories: upper case, lower

case and title case.

Prepositions that can describe places or directions

such as ‘at’ or ‘in’ are also important indicators of

location mentions. We collect all the prepositions

regarding locations in a list and encode the

occurrence of prepositions in tweets as the list index.

The three indexed categorical features are mapped

and trained into corresponding embeddings in the

Bidirectional LSTM model and concatenated with the

pre-trained word embedding for each token or word

as can be seen in Figure 2.

Figure 2: Concatenated feature embeddings.

As the features employed to describe the data are

heuristic, we also explore the contribution of each

feature to the correct location mention labelling by

adjust the dimension of the feature in the following

experiments.

4 EXPERIMENTS

4.1 Dataset

The dataset we used in the experiments was collected

from Twitter via its official application programming

interfaces (APIs). From to 21st to 30th of August

2017 two consecutive typhoons Hato and Pakhar

affected Southern China area while two populated

coastal cities Hong Kong and Macau were severely

impacted. We collected and deduplicated tweets from

the two areas during the typhoon-impacted period and

extracted typhoon-related tweets by an augmented

Convolutional Neural Network (CNN), resulting in

10,996 tweets ready for location extraction.

4.2 Pre-processing

The named entities including location mentions in the

tweets were annotated via Stanford NER tools, and

POS tagging was implemented likewise using

Stanford POS tagger. Among 10,996 tweets location

mentions were found in 4,215 tweets. Considering

that Stanford NER tools can ignore the unknown

places only familiar to locals, we only used the 4,215

positive tweets as training data.

In order to test the proposed model on its

capability of detecting local place names, we

manually selected and labelled 100 tweets in which

Stanford NER misclassified the place names. The

word embeddings with dimension of 200 were pre-

trained by the Skip-Gram model on the Twitter

stream we collected. The embeddings of POS tags,

capitalization and prepositions were trained along

with the model.

4.3 Model Training

In the training process we leave one tenth of the

training data, which is 422 tweets, for validation, and

Location Extraction from Twitter Messages using Bidirectional Long Short-Term Memory Model

3,793 for training. If the validation loss is not

improved in 5 epochs the training process will be

terminated.

Figure 3 shows the variation of accuracy and loss

for training set and validation set when all the four

features are employed. The validation accuracy is

improved to 96% in comparison to 92% when only

word embedding is used, which proves that the

utilisation of syntactic features such as POS tags can

boost the model performance. In the following

subsection we will examine how the features

influence the model on the test set.

Figure 3: Model training.

4.4 Feature Evaluation

4.4.1 Individual Application of Feature

We first verify every feature separately on the test set.

In the training process all the tweets are padded to the

same length for alignment, the padded element is

labelled 0 as its location mention category. A word

that is part of a location mention is labelled 1, and

other words are 2. The positive label 1 accounts for

an extreme small proportion in the true labels of test

set at 1.18%.

In Table 1 we present the precision, recall and F1-

score of each label when only word embedding is

applied. The proposed model performs well on label

0 and 2 which are the majority of labels but fails to

predict any location mentions, resulting in all the

metrics of label 1 ending up being 0%.

Table 1: Classification results on word embedding.

Label Precision Recall F1-score

0 0.96 0.98 0.97

1 0.00 0.00 0.00

2 0.92 0.92 0.92

We further investigate in the classification

performance of other features on label 1 as shown in

Table 2. Best performance is achieved by POS tags

on every metric and the employment of prepositions

produces greatly inferior outcomes compared to POS

tags and capitalization.

Table 2: Classification results on other features.

Feature Precision Recall F1-score

POS tags 0.31 0.51 0.38

Capitalization 0.27 0.44 0.33

Prepositions 0.23 0.10 0.14

In general, individual application of feature

produces unsatisfactory results, which is mostly

caused by the imbalanced nature of data where

location mentions are exceedingly infrequent.

4.4.2 Combination of Features

After examining the individual application of the

semantic and syntactic features, the effects of hyper-

parameters of combined features are validated on the

test set to reach an optimal outcome for label 1. The

four hyper-parameters to be altered and their

candidate values are listed in Table 3.

Table 3: Hyper-parameters to be tested.

Padded

length

POS

embedding

Case

embedding

Preposition

embedding

50 30 20 10

60 40 30 20

70 50 40 30

Padded length is the alignment length that every

tweet will be padded or truncated to. The other

parameters are the dimensionalities of POS

embedding, case embedding and preposition

embedding.

In Table 4 with dimensionalities of case

embedding and preposition embedding fixed, padded

length and POS embedding dimension vary in

respective scopes. Overall improvements up to 12%

on F1-score are observed in comparison with the best

performance obtained by individual application of

POS tags.

Although no general rules on the variation of

padded length and POS embedding are discovered, it

can be obviously concluded that the incorporation of

semantic and syntactic features enhances the model

performance.

GISTAM 2020 - 6th International Conference on Geographical Information Systems Theory, Applications and Management

Table 4: Classification results under different padded

lengths and POS embedding dimensions.

Padded

length

POS

embedding

Precision Recall

F1-

score

50 30 0.42 0.46 0.44

50 40 0.42 0.61 0.50

50 50 0.35 0.61 0.44

60 30 0.38 0.58 0.46

60 40 0.35 0.67 0.46

60 50 0.32 0.53 0.40

70 30 0.31 0.60 0.41

70 40 0.36 0.58 0.44

70 50 0.37 0.55 0.44

Given fixed padded length and POS embedding

dimension, F1-score does not vary considerably along

with case or preposition embedding in Table 5. But

case embedding and preposition embedding of 20 or

30 are preferred.

Table 5: Classification results under different case

embedding and preposition embedding dimensions.

Case

embedding

Preposition

embedding

Precision Recall F1-

score

20 10 0.31 0.58 0.41

20 20 0.36 0.58 0.44

20 30 0.33 0.61 0.43

30 10 0.31 0.53 0.39

30 20 0.35 0.61 0.44

30 30 0.41 0.47 0.44

40 10 0.32 0.58 0.41

40 20 0.32 0.44 0.37

40 30 0.27 0.47 0.34

We also compare the proposed model to one of

off-the-shelf NER tools TwitterNLP (Ritter et al.,

2011) which is specialised for Twitter data. The

experiments are conducted on the same test set. In

Table 6 it can be seen that precision, recall and F1-

score have been largely increased, which proves the

capability of the proposed model on identifying

location mentions from social media messages.

Table 6: Comparison to TwitterNLP.

Model Precision Recall F1-score

Bi-LSTM 0.42 0.61 0.50

TwitterNLP 0.30 0.14 0.19

5 CONCLUSION

In this paper we proposed a model based on Bi-LSTM

Neural Network to detect the local geo-entities

mentioned in social media messages that are ignored

by Stanford NER. We have attained competitive

results on classification performance of the proposed

model with noisy training data. However, there is still

room for enhancement in the Bi-LSTM model

especially on precision. To cope with the issue of

imbalanced datasets, we can further under-sample the

majority negative labels, or integrate our model with

methods such as decision trees which are suitable for

imbalanced datasets. On the other hand, the training

data labelled by Stanford NER possibly contains

many false negative labels, where the concept of

multiple instance learning can be considered to solve

this problem.

ACKNOWLEDGEMENTS

This research is sponsored by China Scholarship

Council (CSC).

REFERENCES

Ahmed, A., 2011. Use of social media in disaster

management. In: International Conference on

Information Systems 2011, ICIS 2011. pp.4149–4159.

Al-Olimat, H.S., Thirunarayan, K., Shalin, V. and Sheth,

A., 2017. Location Name Extraction from Targeted

Text Streams using Gazetteer-based Statistical

Language Models. [online] Available at: <http:/

/arxiv.org/abs/1708.03105> [Accessed 9 Dec. 2019].

Awan, Z., Kahlke, T., Ralph, P.J. and Kennedy, P.J., 2019.

Chemical named entity recognition with deep

contextualized neural embeddings. In: IC3K 2019 -

Proceedings of the 11th International Joint Conference

on Knowledge Discovery, Knowledge Engineering and

Knowledge Management. pp.135–144.

Bontcheva, K., Derczynski, L., Funk, A., Greenwood,

M.A., Maynard, D. and Aswani, N., 2013. TwitIE: An

Open-Source Information Extraction Pipeline for

Microblog Text. [online] Available at: <https://

gate.ac.uk/wiki/twitie.html,> [Accessed 9 Dec. 2019].

Chatfield, A.T. and Brajawidagda, U., 2013. Twitter early

tsunami warning system: A case study in Indonesia’s

natural disaster management. In: Proceedings of the

Annual Hawaii International Conference on System

Sciences. pp.2050–2060.

Chiu, J.P.C. and Nichols, E., 2016. Named Entity

Recognition with Bidirectional LSTM-CNNs.

Transactions of the Association for Computational

Linguistics, [online] 4, pp.357–370. Available at:

Location Extraction from Twitter Messages using Bidirectional Long Short-Term Memory Model

<http://nlp.stanford.edu/projects/glove/> [Accessed 9

Dec. 2019].

Cunningham, H., Maynard, D., Bontcheva, K. and Tablan,

V., 2001. GATE: an Architecture for Development of

Robust HLT Applications. Proceedings of the 40th

Annual Meeting on Association for Computational

Linguistics - ACL ’02, [online] (July), p.168. Available

at: <http://gate.ac.uk.> [Accessed 9 Dec. 2019].

Downey, D., Broadhead, M. and Etzioni, O., 2007.

Locating complex named entities in web text. In: IJCAI

International Joint Conference on Artificial

Intelligence. pp.2733–2739.

Finkel, J.R., Grenager, T. and Manning, C., 2005.

Incorporating non-local information into information

extraction systems by Gibbs sampling. In: ACL-05 -

43rd Annual Meeting of the Association for

Computational Linguistics, Proceedings of the

Conference. pp.363–370.

Harris, Z.S., 1954. Distributional Structure. Distributional

Structure, WORD, [online] 10(3), pp.146–162.

Available at: <https://www.tandfonline.com/action/

journalInformation?journalCode=rwrd20> [Accessed 2

Jul. 2019].

Hoang, T.B.N. and Mothe, J., 2018. Location extraction

from tweets. Information Processing and Management,

54(2), pp.129–144.

Kazama, J. and Torisawa, K., 2008. Inducing gazetteers for

named entity recognition by large-scale clustering of

dependency relations. In: ACL-08: HLT - 46th Annual

Meeting of the Association for Computational

Linguistics: Human Language Technologies,

Proceedings of the Conference. pp.407–415.

Lingad, J., Karimi, S. and Yin, J., 2013. Location extraction

from disaster-related microblogs. In: WWW 2013

Companion - Proceedings of the 22nd International

Conference on World Wide Web. [online] New York,

New York, USA: ACM Press, pp.1017–1020.

Available at: <http://dl.acm.org/citation.cfm?doid=248

7788.2488108> [Accessed 8 Jul. 2019].

Nakaji, Y. and Yanai, K., 2012. Visualization of real-world

events with geotagged tweet photos. In: Proceedings of

the 2012 IEEE International Conference on Multimedia

and Expo Workshops, ICMEW 2012. pp.272–277.

Rachman, V., Savitri, S., Augustianti, F. and Mahendra, R.,

2018. Named entity recognition on Indonesian Twitter

posts using long short-term memory networks. In: 2017

International Conference on Advanced Computer

Science and Information Systems, ICACSIS 2017.

pp.228–232.

Ritter, A., Sam, C., Mausam and Etzioni, O., 2011. Named

entity recognition in tweets: An experimental study. In:

EMNLP 2011 - Conference on Empirical Methods in

Natural Language Processing, Proceedings of the

Conference. Association for Computational

Linguistics, pp.1524–1534.

Sultanik, E.A. and Fink, C., 2012. Rapid geotagging and

disambiguation of social media text via an indexed

gazetteer. In: ISCRAM 2012 Conference Proceedings -

9th International Conference on Information Systems

for Crisis Response and Management.

GISTAM 2020 - 6th International Conference on Geographical Information Systems Theory, Applications and Management
