A Life Cycle Method for Device Management in Dynamic IoT

Environments

Daniel Del Gaudio, Maximilian Reichel and Pascal Hirmer

Institute for Parallel and Distributed Systems, University of Stuttgart, Universit

atsstraße 38, Stuttgart, Germany

Keywords:

Internet of Things, Discovery, Device Integration, Decentralization.

Abstract:

In the Internet of Things, interconnected devices communicate with each other through standardized internet

protocols to reach common goals. By doing so, they enable building complex, self-organizing applications,

such as Smart Cities, or Smart Factories. Especially in large IoT environments, newly appearing devices

as well as leaving or failing IoT devices are a great challenge. New devices need to be integrated into the

application whereas failing devices need to be dealt with. In a Smart City, newly appearing actors, for example,

smart phones or connected cars, appear and disappear all the time. Dealing with this dynamic is a great issue,

especially when done automatically. Consequently, in this paper, we introduce A Life Cycle Method for

Device Management in Dynamic IoT Environments. This method enables integrating newly appearing IoT

devices into IoT applications and, furthermore, offers means to cope with failing devices. Our approach is

evaluated through a system architecture and a corresponding prototypical implementation.

1 INTRODUCTION

The Internet of Things (IoT) is an evolving paradigm,

in which interconnected devices communicate with

each other through standardized internet protocols to

reach common goals (Vermesan and Friess, 2013).

Usually, such IoT devices are attached with sensors

and actuators to monitor the environment or inﬂuence

it (Granell et al., 2020). Famous examples for IoT

applications are Smart Homes, Smart Factories, or

Smart Cities (Harper, 2006; Lucke et al., 2008; Su

et al., 2011).

IoT environments are very dynamic, which means

that devices enter and leave these environments reg-

ularly. This, however, leads to the great challenge of

adapting to the new infrastructure. More precisely,

failing devices could lead to errors in the IoT applica-

tions or, for example, to monitoring inaccuracy due to

a decreased coverage of the environment with sensors.

In contrast, newly appearing devices can increase the

beneﬁt of the IoT application, for example, by new

sensors and actuators, computing power or better cov-

erage of the environment. In a Smart City, e.g., newly

entering connected cars need to be considered in traf-

ﬁc control, whereas leaving cars can be ignored.

The goal of the IoT is managing the environments

possibly autonomous with as little human interaction

as possible. When a new device enters the environ-

ment or a device leaves it, it does not make sense to

involve a human actor, such as a technician to ad-

just the application accordingly. Especially in large

scenarios, for example, in Smart Cities, the overhead

would be tremendous.

Hence, IoT applications should be able to involve

newly appearing devices or to cope with leaving or

failing devices automatically without any human in-

teraction. To solve this issue, in this paper, we intro-

duce A Life Cycle Method for Device Management in

Dynamic IoT Environments. Our approach includes

(i) a meta model to describe the behavior of an IoT

environment, (ii) a meta model to describe the struc-

ture of an IoT environment, (iii) the lifecycle method

to integrate new devices into existing environments

regarding their capabilities and the environment’s re-

quirements, and (iv) a system architecture to imple-

ment the method. Our approach is evaluated through

a prototypical implementation of this architecture.

In our approach, the goal is to keep everything as

decentralized as possible. More precisely, the num-

ber of central components should be kept as low as

possible since the vision of the IoT focusses on direct

machine-to-machine communication. Consequently,

only a single central components is required in our

approach, which copes with integrating new devices

into IoT environments. The devices, however, still

operate in a completely distributed and decentralized

Gaudio, D., Reichel, M. and Hirmer, P.

A Life Cycle Method for Device Management in Dynamic IoT Environments.

DOI: 10.5220/0009340900460056

In Proceedings of the 5th International Conference on Internet of Things, Big Data and Security (IoTBDS 2020), pages 46-56

ISBN: 978-989-758-426-8

Figure 1: Motivational Scenario.

manner. Note that integrating a new device into an

environment is difﬁcult to do decentralized, since one

must have an overview of the whole environment to

delegate an appropriate task. Hence, we decided to

handle this centrally.

The remainder of this paper is structured as fol-

lows: Section 2 describes a scenario we use to mo-

tivate our contribution. Section 3 introduces related

work that copes with the integration of IoT devices

in running IoT environments. Next, in Section 4 the

meta models are described that form the foundation

for our paper. Section 5 then describes our main con-

tribution: a lifecycle method for device management

in dynamic IoT environments. Section 6 then evalu-

ates the approach and Section 7 concludes the paper

and gives an outlook to future work.

2 MOTIVATION

In this chapter, we introduce a motivating scenario,

which serves as means to explain our approach and,

furthermore, to serve as a basis for evaluation pur-

poses. The domain of this motivating scenario is

Smart Cities. In this domain, a large number of de-

vices exist, such as Smart Cars or Smart Transporta-

tion in general, Wearables worn by pedestrians, or sta-

tionary edge servers. These devices are highly dy-

namic and heterogeneous. More precisely, a large

amount of devices enter and leave the environment

constantly. Manual registration of these devices is im-

possible due to the large amount.

The devices in our scenario intercommunicate de-

pendant on geographical proximity, user preferences,

or use cases. Furthermore, not only one IoT applica-

tion is employed in Smart Cities but many different

ones, partly using the same devices (e.g., Smart Park-

ing, Smart Transportation, Smart Grids). In this sce-

nario, we will speciﬁcally focus on automated trafﬁc

management of Smart Cars.

The goal in such environments is making it possi-

ble for devices to interact with each other in a highly

dynamic manner. For example, when a smart car en-

ters a city with a speciﬁc service for trafﬁc manage-

ment, this service needs information about the posi-

tion of the car in order to include it. However, usually

the car owner does not want to share his general po-

sition for privacy reasons. If the car had the appropri-

ate software and logic installed, it could preprocess

its position data to blur the position and only share

information that is required for trafﬁc management.

Furthermore, the trafﬁc management system gets re-

lieved since data arrives already preprocessed. The

great challenge in this scenario is integrating newly

entering cars into the trafﬁc management application

so that the car is registered, the required software is

deployed, and the car starts sending the appropriate

data. For obvious reasons, the whole process needs to

be done fully automatically.

With the contribution of this paper, we aim at solv-

ing the following challenges of this scenario: (i) dis-

covery and registration of IoT devices, in this scenario

Smart Cars, (ii) automated deployment of software

and application logic on heterogeneous IoT devices,

(iii) data processing on the IoT devices to increase

privacy and scalability, and (iv) seamless device com-

munication according to the speciﬁc application.

The introduced scenario is depicted in Figure 1.

A Life Cycle Method for Device Management in Dynamic IoT Environments

In this ﬁgure, ﬁrst, the smart car registers itself at the

nearest Road Side Unit, which is depicted on the mid-

dle top. In a second step, the Road Side Unit deploys

the appropriate application logic and software compo-

nents on the car. In this scenario and in the scope of

this paper, we assume that the IoT devices allow such

communication and are willing to collaborate with the

involved IoT applications.

Finally, once the appropriate application logic is

deployed, the car is able to communicate with the

other cars and Road Side Units in the Smart City ac-

cording to the speciﬁc regulations, which is the third

step in Figure 1.

3 RELATED WORK

In previous work (Del Gaudio and Hirmer, 2019), we

introduced a lightweight messaging engine to enable

device-to-device communication in the IoT. This mes-

saging engine handles information exchange between

devices in a dynamic, scalable, and robust manner.

Data processing is deﬁned by a processing model.

Data is exchanged in the form of messages contain-

ing a header and a payload with the actual data. In this

previous work, the messaging engine still lacks mech-

anisms to cope with the dynamic we aim for in this

paper. Hence, in this paper, we plan to enhance this

messaging engine so it can cope with newly added or

failing devices and enable a more dynamic device-to-

device communication.

Seeger et al. (Seeger et al., 2019) propose an ap-

proach to process data in IoT environments in a dis-

tributed manner, which is similar to ours. They model

data processing based on choreographies (Peltz,

2003). They also introduce a concept for failure de-

tection, where devices monitor themselves to detect

failures. In contrast to our work, Seeger et al. speciﬁ-

cally focus on device failures and their recovery in the

scope of their IoT choreographies. Newly appearing

devices, however, are not discovered and considered

automatically. Moreover, we aim at creating a more

generic approach, which is not only valid speciﬁcally

for choreographies but for all kinds of models.

Franco da Silva et al. and Hirmer et al. (Hirmer

et al., 2016; Franco da Silva et al., 2020; Franco da

Silva et al., 2019) propose the new IoT platform MBP

as well as means to map operators onto distributed

IoT devices and execute them. However, they do not

provide any mechanisms for coping with newly ap-

pearing devices or device failures.

Kodeswaran et al. (Kodeswaran et al., 2016) in-

troduce Idea – a system for efﬁcient failure manage-

ment in smart IoT environments. The core of the Idea

approach is a central system, which provides means

for monitoring failures of sensors and, if a failure oc-

curs, a scheduling component for maintenance. The

work focuses mostly on Smart Home applications. In

contrast to Kodeswaran et al., we not only cope with

failing devices but also integrate new devices into the

IoT applications. Furthermore, our approach is more

decentralized, whereas the Idea framework describes

a central system.

Similar to Kodeswaran et al., Kapitanova et

al. (Kapitanova et al., 2012) introduce a system to

handle non-stopping failures in Smart Home environ-

ments. Failure detection is done by machine learn-

ing algorithms. In contrast, we aim at a more tradi-

tional, lightweight monitoring approach and, further-

more, we also provide means to handle newly added

devices, not only the ones that fail.

Very similar to our approach is the research area

of discovery in the IoT. Datta et al. (Datta et al.,

2015) categorize related work in the area of discov-

ery into the following areas: distributed and peer-

to-peer discovery services, centralized architectures,

CoAP-based service discovery, semantic-based dis-

covery, search engines for resource directory, and uti-

lization of ONS and DNS.

Fredj et al. (Fredj et al., 2014) propose a semantic-

based service discovery using ontologies. A semantic

model that can be used to achieve discovery in such

a manner is IoT Lite (Bermudez-Edo et al., 2016).

We use a similar, however, more lightweight approach

that introduces a meta model that represents the IoT

devices of an application that is used for discovery

purposes. By doing so, discovery can be enabled

more efﬁciently in contrast to working with heavy-

weight ontology models.

CoAP-based discovery mechanisms can make use

of the resource discovery (/.well-known/core) inter-

face of a CoAP server, through which provided ser-

vices of the server can be retrieved (Shelby et al.,

2014; Shelby et al., 2013). Cirani et al. (Cirani et al.,

2014) propose an architecture for peer-to-peer-based

autonomous resource and service discovery in the

IoT. The architecture utilizes a central IoT gateway

and the CoAP resource discovery interface. In our pa-

per, we decided to focus on a more generic approach

for device discovery and integration that is not specif-

ically tailored to CoAP.

In conclusion, our thorough literature review of

related work shows that even though there are already

many works focusing either on device failures or on

device discovery and integration, there is yet no com-

bined approach, which provides the ﬂexibility, dy-

namics and genericity we aim for in this paper.

IoTBDS 2020 - 5th International Conference on Internet of Things, Big Data and Security

4 METAMODELS

For heterogeneous devices being able to intercommu-

nicate, we need standards to describe applications in

terms of communication.

In this section, we introduce two meta models,

which build the foundation for our lifecycle method:

(i) a data processing model, specifying the business

logic of an IoT application (Section 4.1), and (ii) a

structural description of IoT environments, including

devices, sensors, actuators, network, and communica-

tion (Section 4.2).

These models are necessary because data process-

ing should be decoupled from the actual devices that

execute data processing operations, which leads to a

clear separation of concerns. Hence, devices can be

added, removed, and exchanged without having to

adapt the processing model. Furthermore, an appli-

cation developer can model an IoT application via the

processing model without further knowledge of the

structure of the IoT environment in which the appli-

cation will be executed. Consequently, both models

are also fully decoupled and, thus, interchangeable.

We describe details of these models in the following.

4.1 Processing Model

Interactions between devices in IoT environments can

be described by directed graphs according to the pipes

and ﬁlters pattern (Meunier, 1995), which we refer to

as the processing model in this paper. In our experi-

ence, and as shown in related works (e.g., (Del Gau-

dio and Hirmer, 2019; Franco da Silva et al., 2019)),

the pipes and ﬁlters pattern is appropriate to describe

the behavior of an IoT environment.

Nodes in the processing model, i.e., the ﬁlters, are

referred to as operations and are not bound to speciﬁc

devices. Instead, they are associated with a set of re-

quirements, making it possible to dynamically choose

the right IoT device for the operator.

We deﬁne the processing model as a tupel DF =

(O, E, R, req) with the set of operations O, the set of

directed edges E = {e = (o

, o

)|o

, o

∈ O}, stating

that operation o

must be performed right before op-

eration o

, the set of requirements R, and the function

req : O → P (R), which links each operation to a set

of requirements. An example for a processing model

in JSON representation looks as follows:

{

"flow_id": "TrafficLightFlow",

"flow": {

"1": {

"operation": "SendPosition",

"requirements": ["PositionSensor"],

"next_oiid": "2"

"2": {

"operation": "SetSignals",

"requirements": ["TrafficSignals"],

"next_oiid": "3"

"3": {

"operation": "StopCar",

"requirements":

["AccelerationController"],

"next_oiid": none

}

In this example, flow_id deﬁnes a unique name

for each processing model. Each sub-element of flow

represents an operation. next_oiid indicates which

operation must be executed after SendPosition and

so forth. The processing model is depicted in Fig-

ure 2. The ﬁrst operation SendPosition is exe-

cuted by SmartCar1 by sending its position data to

SmartTrafficLight. It uses the data to execute

SetSignals and send the result to SmartCar2, in or-

der that it can timely react to the change of signals and

stop the car.

In the following sections, this processing models

is used to deﬁne the business logic (more precisely,

the data ﬂow) of the IoT applications.

4.2 Structural Description of IoT

Environments

Additionally to the behavior of the IoT applica-

tions, we need a model to specify the structure

of IoT environments. This involves all included

devices and connections between them. For this

model, we propose an undirected and weighted graph

E = (D, L, C, cap, w) with a set of devices D =

, . . . , d

}, that exist in the environment, a set of

links L = {l = {d

, d

}|d

, d

∈ D}, stating that device

can communicate with device d

and vice versa,

and a set of capabilities C. The function cap : D →

P (C) links each device with a set of capabilities in

order to match them with the requirements of the pro-

cessing model. The function w :→ Q associates each

link with a speciﬁc weight. The weight of a link in-

dicates the costs of delivering a message via the link.

The weight of a link can be very dynamic and must

be monitored during runtime.

The structural description needs to be changed by

devices being added and removed, which is the main

contribution of this paper. This model in JSON repre-

sentation is shown in the following example:

{

"device": {

A Life Cycle Method for Device Management in Dynamic IoT Environments

SmartCar2

SmartCar1 SmartTrafficLight

StopCarSetSignalsSendPosition

Operation: Data Flow:

Figure 2: Trafﬁc Light Processing Model.

"name": "SmartCar1",

"capabilities": [

"AccelerationController",

"PositionSensor",

"HighProcessingPower" ],

"address": "192.168.56.11",

"mac": "f0-f4-85-f5-41-e6-53",

"credentialGroup": "group1"

}

"device": {

"name": "SmartTrafficlight",

"capabilities": [

"TrafficSignals",

"MediumProcessingPower" ],

"address": "192.168.56.22",

"mac": "00-53-b7-ff-21-24-34",

"credentialGroup": "group1"

}

"link_1_2": {

"weight" : 2.3

"devices": [

"SmartCar1",

"SmartTrafficlight"]

}

5 LIFE CYCLE METHOD FOR

DEVICE MANAGEMENT

We propose a generic life cycle method with six steps

to integrate a new IoT device into an existing envi-

ronment, which is depicted in Figure 3. The lifecycle

method describes how one device can be integrated

into an existing IoT environment to work with the

other devices together. It describes the cycle terms of

entering, leaving, and reentering an IoT environment

of a single device. Furthermore, we propose a system

architecture that implements the life cycle, which is

depicted in Figure 4.

The cycle is started by the runtime agent on the de-

vice discovering the runtime management, represent-

ing our system for device integration (step 1). In the

second step, the device can register itself at an regis-

tration service by sending a registration message. The

registration service contains a database with the fol-

lowing data: (i) information about each device that is

registered, (ii) information about each operation that

can potentially be deployed and executed in the envi-

ronment, and (iii) information about which operation

is deployed on which device.

In the next step, the runtime management then de-

termines the proper set of operations to deploy on the

new device, as deﬁned by the processing model of

the IoT application (step 3). After that, it deploys the

associated software and conﬁgure it using the desig-

nated processing models (step 4).

The next step 5 represents the data processing, i.e.,

including the new IoT device into the execution of the

running processing models of the IoT environment.

The management runtime is now only responsible for

monitoring the new device and is not involved in the

machine-to-machine coordination. Hence, decentral-

ized data processing can still be ensured, which im-

proves the robustness due to no single point of failure.

Finally, in the last step 6 of our lifecycle method, the

device is removed from the environment, either inten-

tionally or by failure.

The details of these steps are described in the fol-

lowing sections.

5.1 Step 1: Server Discovery

The ﬁrst step of our lifecycle method is the server dis-

covery. In order for a device to be integrated in an

IoTBDS 2020 - 5th International Conference on Internet of Things, Big Data and Security

Step 1:

Server

Discovery

Step 2:

Device

Registration

Step 3:

Software

Determination

Step 4:

Software

Deployment

and

Configuration

Step 6:

Device

Removal

Step 5:

Data

Processing

and

Monitoring

Figure 3: Life Cycle Method.

IoT application, it must register itself at the registra-

tion component, i.e., the registration server.

We evaluated three possibilities how a device can

ﬁnd the registration server in a network: (i) the ad-

dress of the registration component is preconﬁgured

on the device, (ii) the device sends a broadcast or

multicast message into the network hoping that the

registration server receives it and sends a response, or

(iii) the server discovery is implemented into the net-

work via a DHCP or DNS server.

We do not further consider the ﬁrst solution, since

preconﬁguration of devices omits the dynamicity we

aim for in this paper. For example, when a device

enters a different environment, the address of the reg-

istration server might be different than the one that is

preconﬁgured. Furthermore, the address of the regis-

tration server could change anytime.

The third solution requires speciﬁcally conﬁgured

DNS or DHCP servers and is, thus, also not further

regarded. Consequently, we prefer the second solu-

tion, since it can be implemented by our system itself

without any critical dependencies. The runtime agent

on the devices sends broadcast messages into the net-

work and the registration server responds on receiving

the message. If the network does not allow broadcast-

ing, the other solutions can be considered as a backup.

5.2 Step 2: Device Registration

The second step of our lifecycle method comprises

the device registration. After a new device discovered

the address of the registration server (step 1), it reg-

isters itself by sending a registration message to the

registration server. An example of such a message for

our motivating scenario is depicted in the following:

{

"device": {

"name": "SmartCar2",

"capabilities": [

"AccelerationController",

"PositionSensor",

"HighProcessingPower"

"address": "192.168.56.11",

"mac": "12-43-b5-ae-fd-44-35",

"credentialGroup": "group2"

A Life Cycle Method for Device Management in Dynamic IoT Environments

IoT Environment

Runtime

Management

Application

Modelling

Tool

IoT Device

Edge

Server

Controller

Environment

Modelling

Too l

Model

Mapping

Device

Configuration

Device

Registration

and Monitor i ng

IoT Device

Messaging

Engine

Operato rs an d A dapters

Software

Deployment

Software

Repository

Structural Model

Processing Model

Sensors and Actuators

Runtime

Agent

Figure 4: Architecture to Apply Our Lifecycle Method for Device Integration.

"options": {

"ttl": 3600

}

The element device deﬁnes device-speciﬁc meta-

data. name is the self-given name for the device that

does not necessarily have to be unique. The subele-

ment capabilities is used to choose appropriate

operations for the device, address deﬁnes the IP ad-

dress, mac the MAC address, and credentialGroup

is used to deﬁne the credentials to access the de-

vice, for example, via SSH. Furthermore, the element

options is used for the registration process itself,

deﬁning important properties, such as ttl, determin-

ing the time-to-life for the registration as explained

in Section 5.5. The registration server stores the in-

formation about the device based on the registration

message. After step 2, the device is registered and

can be further processed.

5.3 Step 3: Software Determination

As the device is registered at the registration server,

the server must now determine a suitable set of opera-

tions, implementing speciﬁc business logic of an IoT

application, and deploy them on the device. This is

done in step 3 of our lifecycle method.

We determined three aspects to consider for

choosing suitable operations: (i) the capabilities of

the device in terms of sensors, actuators, and process-

ing power, (ii) the requirements of available opera-

tions in terms of sensors, actuators, and processing

power, and (iii) the speciﬁc characteristics of the en-

vironment the IoT applications are provided in.

In our architecture (cf. Figure 4), the Model Map-

ping component is responsible to map the capabilities

of the devices onto the most useful set of applications,

regarding all applications that are available.

We deﬁne the function f ul f ills(c, r) for each re-

quirement r ∈ R and each capability c ∈ C, which

evaluates to 1 if capability c fulﬁlls requirement r.

Therefore, we deﬁne the function executableBy(o, d)

for each operation o ∈ O and each device d ∈ D as

executableBy(o, d) =











1, ∀r ∈ req(o)∃c ∈ cap(d) :

f ul f ills(c, r) = 1

0, else

(1)

stating that o is executable by d in terms that for

each of requirement d, o offers a fulﬁlling capability.

For a new device d, we can now seek for the subset

of operations

= {o ∈ O|executableBy(o, d) = 1}, (2)

which contains all operations that are executable

by d and, thus, fulﬁlls aspects (i) and (ii).

In terms of aspect (iii), many different character-

istics must be considered when choosing which op-

eration is the most ”useful” for an environment. We

consider an operation as the most useful for an envi-

ronment if it is one that is not yet deployed on a device

at all, expanding the application’s coverage of the IoT

environment.

IoTBDS 2020 - 5th International Conference on Internet of Things, Big Data and Security

Furthermore, for choosing suitable operations to

be run of the devices, we evaluated two processing

patterns that need to be handled separately:

• Parallelizable Operations:

Parallelizable operations can be scaled horizon-

tally by deploying multiple instances of them.

Hence, when deploying such operations, it needs

to be considered whether scaling is required by

the speciﬁc IoT application. Furthermore, if all

available operations are already deployed, we

only look for parallelisable operations.

• Unique Operations:

A unique operation must be unique inside the en-

vironment, for example, because all data that is

processed by the operation must be consolidated

in one instance. Unique operations must be con-

sidered separately when choosing the operations

to be deployed.

To manage the operations in the environment, we

must keep track of operations that are already run-

ning, the workload of each operation, and the utiliza-

tion of resources of the devices. The set of opera-

tions that are executed by a given device d in the

context of any processing model is determined by

executedBy(d). In order to realize this, a sophisti-

cated monitoring of the IoT environment is essential.

However, this is not the focus of this paper. Hence, we

refer to existing work in IoT monitoring, for example,

provided by (Lazarescu, 2013).

5.4 Step 4: Software Deployment and

Conﬁguration

In the fourth step, the chosen operations need to be de-

ployed on the new device. For each operation the en-

vironment is able to perform, the associated software

components must be stored in the software repository

which is part of the registration server, as shown in

our system architecture (cf. Figure 4). These software

components can range from simple scripts to sophisti-

cated software applications, whereas only lightweight

components can be deployed onto resource-restricted

IoT hardware. This decision has already been made

in the previous step Software Determination.

The Software Deployment component of our ar-

chitecture extracts the necessary software compo-

nents from the software repository, connects to the

device, and starts installing the software and all re-

quired dependencies. This deployment step can be ei-

ther implemented manually using, for example, SSH

connections, or in a more sophisticated manner. One

approach for a more robust software deployment strat-

egy is offered by the OASIS standard TOSCA (OA-

SIS, 2013a; OASIS, 2013b). An open-source im-

plementation of TOSCA is, for example, provided

by OpenTOSCA (Binz et al., 2014). By using a

standard-based approach, such as TOSCA, the de-

ployment strategy is more future-proof than a non-

standard-based approach.

After all applications have been deployed, the

messaging engine on the devices (responsible for

machine-to-machine communication) must be conﬁg-

ured accordingly. The messaging engine needs the

operations it can perform, the section of the process-

ing model it participates in, and the node information

of devices it must interact with.

Furthermore, messaging engines on other devices

that need to interact with the new devices need the

information about the newly appeared device, more

speciﬁcally, which operations it provides and how

they can interact with it. A simpler but less scal-

able solution would be to inform each device in the

environment about the newly appeared device (for

example, through broadcasting) and, in this process,

hand over the necessary information about the new

device. However, since IoT devices often tend to be

constrained in terms of memory capacity and to min-

imize network trafﬁc, we do not consider this simple

solution.

In our approach, to compute all relevant devices

that need to communicate with a newly added device

d, the runtime management traverses the processing

model and looks for each operation in executedBy(d).

Every device that executes a predecessor of an op-

eration in executedBy(d) must be notiﬁed about d.

Vice versa, d must be notiﬁed about each device, that

executes a successor operation of each operation in

executedBy(o). By doing so, only the devices need

to be notiﬁed, which are required to interact with the

newly added device. This reduces the network traf-

ﬁc that would have been produced by broadcast mes-

sages and leads to a more tailored solution.

5.5 Step 5: Data Processing and

Monitoring

After deployment of the required software compo-

nents, the newly added device is ready to process data.

It can receive, process, and forward data according to

the processing models. Our system is now also able

to monitor the devices in the environment. To realize

this, each runtime agent sends health messages to the

server periodically. The frequency highly depends on

the use case, i.e., how critical device failures inﬂuence

the health of the application.

When the server receives no health message from

a device for a speciﬁed period of time, it assumes

A Life Cycle Method for Device Management in Dynamic IoT Environments

that the device has left the environment accidentally,

for example due to an occurring device failure. In

case the device leaves the environment voluntarily,

it deregisters itself. This will be discussed in more

depth in step 6. The time period is speciﬁed in ttl

in options in the registration message as introduced

in Section 5.2. This time period can be individual for

each device, since IoT environments tend to be highly

heterogeneous. In order to prevent unnecessary net-

work trafﬁc, choosing the right time period in which

devices send their heartbeat messages has to be con-

sidered wisely.

Furthermore, for device health monitoring, impor-

tant metrics are the weight of links (cf. Section 4)

and the resource utilization of devices. Monitoring

information can be used to detect bottlenecks and re-

act accordingly, for example, by deploying additional

software on devices in order to scale the application.

When the data processing is interrupted because

a device is not capable of ﬁnding an appropriate re-

ceiver for data, it can perform a request to the de-

vice registration and monitoring component, which

will then respond with the address of another device

hosting the desired operation or deploy the operation

on one.

5.6 Step 6: Device Removal

There are two ways a device is removed from the en-

vironment: on purpose, for example, when a Smart

Car leaves the city area, or accidentally, for example,

when the network connection is lost or when the de-

vice’s hardware fails.

When a device leaves the environment on purpose,

e.g. when it should be exchanged, it should be able to

backup all its data on the registration server. When

a new device enters the environment that is able to

perform one of the operations the leaving device per-

formed, the registration server can initialize the new

device with the backup data. By doing so, it can be

ensured that no data is left. Of course, this data needs

to be attached with a timespan until it gets stale. Espe-

cially streaming data in the IoT get stale very quickly,

thus, loses its usefulness after a short amount of time.

When a device leaves the environment acciden-

tally, loss of data can only be prevented by persis-

tently storing all data on the device hoping that it

reenters. If this is not the case, however, all data that

was stored on the device at the time of the failure is

lost. One solution to cope with this issue are periodi-

cal backups. However, it needs to be considered that

these backups lead to a signiﬁcant overhead regarding

computing and network resources. Hence, this trade-

off needs to be carefully considered for each applica-

tion separately.

After the last step of our lifecycle method, the de-

vice leaves the environment. At any time, the device

can re-enter and the whole method is re-initialized.

Note that if a device already contains the required

software components when re-entering, the method

can be signiﬁcantly accelerated. Thus, it also con-

siders previous iterations.

6 PROTOTYPE AND DISCUSSION

To evaluate our concept, we implemented a prototype

of the runtime management and the runtime agent,

running on the device itself (cf. Figure 4).

The agent application is implemented in Python to

guarantee a certain degree of lightweightness because

this agent is usually deployed onto resource-limited

IoT hardware. In contrast, the runtime management

components, running in a scalable cloud environment,

is implemented in Java.

These components communicate via CoAP, a

lightweight HTTP-like protocol. In order to imple-

ment the CoAP client and server applications, we

used the Python implementation CoAPthon (Tan-

ganelli et al., 2015) for the client and the Java imple-

mentation Californium (Kovatsch et al., 2014) for the

server. Furthermore, we use MongoDB

as database

to store information about registered devices on the

server. Furthermore, all communication payload is

serialized in JSON.

To simulate the trafﬁc management scenario de-

scribed in Section 2, we created an IoT environ-

ment with multiple mobile and stationary devices at-

tached to an OpenStack-managed

private cloud plat-

form running on an IBM Pureﬂex computing cluster

with 12 compute nodes. As IoT hardware, we used

Raspberry Pis

attached to different sensors and actu-

ators that are hosting the agent. A virtual machine in

the private cloud is hosting the runtime management

components. Using such a ﬂexible infrastructure en-

ables easy scaling of the runtime management com-

ponents and prevents them from becoming a single-

point-of-failure.

In order to set up our runtime management com-

ponent, a few simple steps need to be conducted, thus,

making it easy to set up in different scenarios by dif-

ferent stakeholders. First the runtime management

needs to be deployed on an application server run-

ning, e.g., on a virtual machine in the cloud or even on

https://www.mongodb.com

https://www.openstack.org

https://www.raspberrypi.org

IoTBDS 2020 - 5th International Conference on Internet of Things, Big Data and Security

an IoT device. Second, the runtime agent must be in-

stalled on each IoT device that is involved in the sce-

nario. Furthermore, each device needs a minor pre-

conﬁguration to be able to share its capabilities with

the runtime management. For many IoT devices, we

recommend automating this installation and conﬁgu-

ration step, using for example, TOSCA or other well-

known deployment tools, such as Ansible

As mentioned before, all additional software nec-

essary for a speciﬁc scenario should be stored in the

software repository and gets installed automatically

by the runtime management according to the process-

ing model for the scenario and the devices capabilities

in step 4 of our lifecycle method.

Our prototype shows that our concept can cope

with the challenges listed in Section 2. Devices are

automatically registered when they enter the area of

our environment and connect to the Wi-Fi (i). Soft-

ware is automatically deployed on each device ac-

cording to the processing model (ii). Data is (pre-

)processed on the devices by the deployed software

and is sent to the other devices according to the pro-

cessing and structural models ((iii) and (iv)).

Modelling distributed applications with the pro-

cessing model in Section 4.1 and the environment

with the structural model in Section 4.2 decouples ap-

plication development from executing environments

and, thus, creates dynamic IoT environments with in-

terchangeable devices. Data processing can be scaled

horizontally by adding more devices to the environ-

ment, since parallelizable operations are deployed au-

tomatically and load is balanced amongst them.

7 CONCLUSION

In this paper, we present A Life Cycle Method for

Device Management in Dynamic IoT Environments.

Using this method, newly appearing devices can be

seamlessly integrated into IoT applications without

the need for manual, time-consuming steps. In ad-

dition, we introduce concepts that allow coping with

failing devices or voluntarily leaving ones. Our

lifecycle method builds on meta models, describing

data processing and the IoT infrastructure landscape.

Based on these models, newly appearing devices can

be found, registered, necessary software can be in-

stalled and they can be integrated for data processing

in an IoT application. Finally, the device can be re-

tired either voluntarily or when it fails. Even in case

of a failure, we can support IoT applications in pro-

viding a robust way of data processing so that appli-

https://www.ansible.com/

cations do not fail when single devices do.

We implemented a prototype for our lifecycle

method in order to provide a proof-of-concept. In

the future, we aim at applying this prototype to more

complex scenarios in order to show the strengths of

our approach to an even greater extend.

ACKNOWLEDGEMENTS

This work is partially funded by the German Ministry

for Economy and Energy in the scope of the project

IC4F (01MA17008).

REFERENCES

Bermudez-Edo, M., Elsaleh, T., Barnaghi, P., and Taylor, K.

(2016). Iot-lite: a lightweight semantic model for the

internet of things. In 2016 Intl IEEE Conferences on

Ubiquitous Intelligence & Computing, Advanced and

Trusted Computing, Scalable Computing and Commu-

nications, Cloud and Big Data Computing, Internet

of People, and Smart World Congress (UIC/ATC/Scal-

Com/CBDCom/IoP/SmartWorld), pages 90–97. IEEE.

Binz, T., Breitenb

ucher, U., Kopp, O., and Leymann, F.

(2014). Tosca: portable automated deployment and

management of cloud applications. In Advanced Web

Services, pages 527–549. Springer.

Cirani, S., Davoli, L., Ferrari, G., L

eone, R., Medagliani, P.,

Picone, M., and Veltri, L. (2014). A scalable and self-

conﬁguring architecture for service discovery in the

internet of things. IEEE Internet of Things Journal,

1(5):508–521.

Datta, S. K., Da Costa, R. P. F., and Bonnet, C. (2015). Re-

source discovery in internet of things: Current trends

and future standardization aspects. In 2015 IEEE 2nd

World Forum on Internet of Things (WF-IoT), pages

542–547. IEEE.

Del Gaudio, D. and Hirmer, P. (2019). A lightweight mes-

saging engine for decentralized data processing in the

internet of things. SICS Software-Intensive Cyber-

Physical Systems.

Franco da Silva, A. C., Hirmer, P., and Mitschang, B.

(2019). Model-based operator placement for data pro-

cessing in iot environments. In 2019 IEEE Inter-

national Conference on Smart Computing (SMART-

COMP), pages 439–443. IEEE.

Franco da Silva, A. C., Hirmer, P., Schneider, J., Ulusal,

S., and Tavares Frigo, M. (2020). Mbp: Not just an

iot platform. In Proceedings of the 18th Annual IEEE

Intl. Conference on Pervasive Computing and Com-

munications.

Fredj, S. B., Boussard, M., Kofman, D., and Noirie, L.

(2014). Efﬁcient semantic-based iot service discovery

mechanism for dynamic environments. In 2014 IEEE

25th Annual International Symposium on Personal,

A Life Cycle Method for Device Management in Dynamic IoT Environments

Indoor, and Mobile Radio Communication (PIMRC),

pages 2088–2092. IEEE.

Granell, C., Kamilaris, A., Kotsev, A., Ostermann, F. O.,

and Trilles, S. (2020). Internet of Things, pages 387–

423. Springer Singapore, Singapore.

Harper, R. (2006). Inside the smart home. Springer Science

& Business Media.

Hirmer, P., Breitenb

ucher, U., da Silva, A. C. F., K

epes, K.,

Mitschang, B., and Wieland, M. (2016). Automating

the Provisioning and Conﬁguration of Devices in the

Internet of Things. Complex Systems Informatics and

Modeling Quarterly, 9:28–43.

Kapitanova, K., Hoque, E., Stankovic, J. A., Whitehouse,

K., and Son, S. H. (2012). Being smart about failures:

Assessing repairs in smart homes. In Proceedings of

the 2012 ACM Conference on Ubiquitous Computing,

UbiComp ’12, pages 51–60, New York, NY, USA.

ACM.

Kodeswaran, P. A., Kokku, R., Sen, S., and Srivatsa, M.

(2016). Idea: A system for efﬁcient failure manage-

ment in smart iot environments. In Proceedings of the

14th Annual International Conference on Mobile Sys-

tems, Applications, and Services, MobiSys ’16, pages

43–56, New York, NY, USA. ACM.

Kovatsch, M., Lanter, M., and Shelby, Z. (2014). Cali-

fornium: Scalable cloud services for the internet of

things with coap. In 2014 International Conference

on the Internet of Things (IOT), pages 1–6. IEEE.

Lazarescu, M. T. (2013). Design of a wsn platform for

long-term environmental monitoring for iot applica-

tions. IEEE Journal on Emerging and Selected Topics

in Circuits and Systems, 3(1):45–54.

Lucke, D., Constantinescu, C., and Westk

amper, E. (2008).

Smart factory-a step towards the next generation

of manufacturing. In Manufacturing systems and

technologies for the new frontier, pages 115–118.

Springer.

Meunier, R. (1995). The pipes and ﬁlters architecture. In

Pattern languages of program design, pages 427–440.

ACM Press/Addison-Wesley Publishing Co.

OASIS (2013a). Topology and Orchestration Speciﬁcation

for Cloud Applications.

OASIS (2013b). TOSCA Primer. Online.

Peltz, C. (2003). Web services orchestration and choreog-

raphy. Computer, (10):46–52.

Seeger, J., A. Deshmukh, R., Sarafov, V., and Br

oring, A.

(2019). Dynamic iot choreographies. IEEE Pervasive

Computing, 18:19–27.

Shelby, Z., Bormann, C., and Krco, S. (2013). Core re-

source directory.

Shelby, Z., Hartke, K., and Bormann, C. (2014). The con-

strained application protocol (coap). Technical report.

Su, K., Li, J., and Fu, H. (2011). Smart city and the ap-

plications. In 2011 international conference on elec-

tronics, communications and control (ICECC), pages

1028–1031. IEEE.

Tanganelli, G., Vallati, C., and Mingozzi, E. (2015).

Coapthon: Easy development of coap-based iot appli-

cations with python. In 2015 IEEE 2nd World Forum

on Internet of Things (WF-IoT), pages 63–68. IEEE.

Vermesan, O. and Friess, P. (2013). Internet of things: con-

verging technologies for smart environments and inte-

grated ecosystems. River publishers.

IoTBDS 2020 - 5th International Conference on Internet of Things, Big Data and Security
