Public Key Infrastructure Issues for Enterprise Level Security

Kevin Foltz and William R. Simpson

Institute for Defense Analyses, 4850 Mark Center Drive, Alexandria, VA 22311, U.S.A.

Keywords: Enterprise, Public Key Infrastructure, System Design, Application Security, Security, Distinguished Name,

X.509, Certificate, Zero Trust Architecture.

Abstract: A public key infrastructure (PKI) provides a way to manage identities within an enterprise. Users are

provided public/private key pairs, and trusted certification authorities issue credentials binding a user name

to the associated public key for that user. This enables security functions by users within the enterprise, such

as authentication, signature creation and validation, encryption, and decryption. However, the enterprise

often interacts with partner enterprises and the open web, which may use different PKIs. Mobile devices do

not easily operate with hardware-based PKI tokens such as smartcards. Standard digital signatures lack

timing information such as validity or expiration. This paper examines some of the security challenges

related to PKI deployment in the context of Enterprise Level Security (ELS), an enterprise solution for a

high security environment.

1 INTRODUCTION

Public key infrastructure (PKI) is a commonly used

method for managing entity identities in large

enterprises. Standard PKI components include:

• Public key certificates

• Certificate repository

• Certificate revocation

• Key backup and recovery

• Non-repudiation of digital signatures

• Automatic update of key pairs and certificates

• Management of key histories

• Support for cross-certification

• Software implementation to use items listed

above

Together, these form the basis for an automatic,

transparent, and usable PKI (Entrust Datacard, 2019)

(Cooper et al., 2018).

The use of PKI is widespread on the public web,

as well as within enterprises. Web servers use

certificates from trusted certification authorities

(CAs) to authenticate to users connected from

remote locations through potentially untrusted or

hostile networks. Enterprises use PKI to provide

employees, servers, services, and other entities with

a convenient way to encrypt and decrypt data, sign

and verify content, and perform third-party

authentication, where neither party has an

established relationship prior to the authentication.

Enterprise Level Security (ELS) is an approach

for enterprise security that builds from basic

principles and concepts. PKI is one of the key

building blocks for ELS. However, for high security,

many issues arise in a practical PKI implementation

that are not commonly addressed. Naming of entities

in an enterprise is a core function that PKI relies on.

This affects not only PKI functions within an

enterprise, but interactions with partner

organizations and the web in general. Credential

management with mobile devices opens new

opportunities and challenges. Common functions,

such as signatures, in raw form lack many desirable

properties related to time and transitioning roles and

responsibilities.

This paper examines some of the key issues for

ELS PKI implementation. It identifies issues with

certain enterprise situations and describes solutions

to maintain security properties within the ELS-

enabled enterprise. This is part of a larger effort to

secure information sharing for the United States Air

Force (Foltz and Simpson, 2017; Foltz and Simpson,

2016a, Foltz and Simpson, 2016b).

Foltz, K. and Simpson, W.

Public Key Infrastructure Issues for Enterprise Level Security.

DOI: 10.5220/0009342000910098

In Proceedings of the 22nd International Conference on Enterprise Information Systems (ICEIS 2020) - Volume 1, pages 91-98

ISBN: 978-989-758-423-7

2 ELS BACKGROUND

ELS is an architectural approach for designing

security into a distributed web-based enterprise

system of information sharing. It focuses on identity

and access management as the root of security. PKI

is an important part of ELS, because it is the

preferred method for managing identities and

performing authentication. However, ELS is much

bigger than PKI. The key elements of ELS are

identified in this section (Simpson, 2016; Trias et al.,

2016).

ELS is an end-to-end security model. Unlike

many current architectures that use gateways,

proxies, and application layer firewalls, ELS allows

and encourages unbroken encrypted traffic between

requester and service provider. The entity endpoints

can directly authenticate each other and create an

encrypted communication path from one

authenticated entity to the other. This is in line with

the idea of a zero trust architecture (ZTA). Security

relies not on a secure network but on secure

authentication and authorization by and at the

endpoints.

ELS separates authentication from access and

privilege. This separation runs counter to the

common approach of using single sign-on (SSO) for

both. The SSO approach simplifies the process, but

it is a single point of failure. With ELS, a separate

Security Assertion Markup Language (SAML) token

is used for access and privilege, which is provided

when requester attributes satisfy access rules.

ELS attempts to automate much of the access

process. By defining access rules up front and

maintaining attributes of all entities in the enterprise,

access is quick to be granted and removed. As soon

as the relevant rules or attributes change, access is

dynamically recomputed to allow or deny access

accordingly. This removes the current lag in gaining

access and eliminates lingering access, which is the

cause of many security problems.

ELS includes asynchronous messaging and

content management solutions, as well as web-based

requests. These solutions both rely on digital

signatures by endpoints with PKI credentials. In

these cases, the content is signed at the time of

creation, but it might persist for long periods of time.

Messages are typically consumed quickly, but their

asynchronous nature means timeouts are much

longer, if they exist, than with synchronous web

traffic.

The main ELS issues for PKI are web-based

authentication and digital signatures for content and

messages.

3 NAMING ISSUES

PKI certificates are most meaningful if they use

meaningful names. Naming of entities in an

enterprise is therefore a critical first step in

establishing a secure PKI. Typically, the certificate

contains a name field and several attribute fields.

The distinguished name (DN) encompasses both the

name field and attributes, such as employee number

or other unique identifiers, and satisfies the primary

naming requirements of being unique and

meaningful. First and last names are used as part of

the DN to provide an immediate way for people to

recognize each other. The additional information

includes a unique identifier, which makes every DN

unique within the enterprise.

If the enterprise has internal structure, this may

be represented as additional fields in the DN. An

employee’s name and division may be included in

the DN, along with the organization name and

location. This helps to identify the individual by

defining the scope of activities or where they work.

A decision needs to be made about which

information is in the certificate and which

information is retrieved from other sources based on

the DN or other information in the certificate. For

simplicity, the PKI certificate should contain only

information relevant to establish the identity of an

individual. Remaining attributes should be stored in

authoritative content stores (ACSs) based on the DN

as in the PKI certificate.

It is important that each ACS is the authoritative

source of the attributes that it provides. It may be

duplicated for performance, ease of use, or other

reasons, but the duplicates must point back to the

original source, and any updates to attributes are

only authoritative when the single authoritative

source is updated.

Text-based names require special consideration

when they contain multiple parts. The X.509

standard (X.509, 1999-2012) addresses this issue

through the format of the certificate, which includes

separate identified fields with designated types and

lengths. The DN itself has a type and length, and the

components of it also have their own type and

length. This prevents ambiguities that can arise

through the use of simple text-based names.

However, the DN is often represented and used

in text instead of its binary X.509 format. A one-to-

one correspondence between X.509 format and other

formats is necessary to preserve uniqueness. This

often involves limiting the allowed content of the

attribute fields to prevent ambiguities between

delimiters and content.

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

4 NAME USE ISSUES

Establishing unique names and authoritative

attribute stores is not enough for a viable PKI. The

entities in the enterprise must actually use the

certificates, data sources, and other PKI services

effectively.

For a single enterprise with its own PKI, this is

fairly simple. However, when interacting with the

web or other partner enterprises with their own PKIs

and trusted root CAs, name use can get more

complicated.

For example, the U.S. Department of Defense

(DoD) hosts its own set of root CAs and

intermediate CAs. The root CAs sign the certificate

of each intermediate CA, which may directly issue

user certificates or continue the chain further to

more intermediate CAs. The process of user

authentication requires tracking this chain of CAs

back to a trusted root CA, as shown for Alice and

Bob on the left side of Figure 1. Chaining Alice’s

certificate to the trusted DoD root CA validates that

the her identity can be trusted.

However, an interesting problem occurs when

working with partner organizations. For example,

the U.S. Department of Veterans Affairs (VA) has

many current and former members of DoD, but it

has its own root CA, which is issued by a non-DoD

entity. If DoD and VA collaborate, VA users and

servers are part of a separate PKI. The first step is to

establish trust between these two PKIs. This allows

the DoD to trust certificates issued by the VA CA.

A potential problem arises, however, if the VA

creates a certificate with a DN that matches one

within the DoD PKI, as shown by the duplicate

certificate for Alice on the right of Figure 1. The

problem is that the DoD trusts the VA CA and will

trust the VA certificate, but the DN on the VA

certificate matches a possibly different entity’s

account within the DoD. As a result, someone with

such a VA DN would be able to access all the DoD

resources that the corresponding DoD entity has

access to.

An alternative situation is a rogue intermediate

CA in either organization. A rogue intermediate CA

could intentionally issue credentials with targeted

DoD DNs in an attempt to access those entities’

resources within DoD. For example, DoD CA #2

could issue Bob an additional credential with Alice’s

DN to provide Bob unauthorized access to Alice’s

resources.

Figure 1: Name confusion across PKIs.

This highlights the importance of not only

checking the full DN, but also the CA chain that the

DN is part of. A DoD-style DN that is issued by the

VA is highly suspect, and at the very least such a

credential should be flagged and denied normal DoD

access. Such measures could also be taken within

DoD to protect identities from rogue internal

intermediate CAs. More details of federation

approaches based on trust levels is provided in

(Foltz and Simpson, 2016c).

5 KEY GENERATION AND

DISTRIBUTION ISSUES

There are two types of private keys in a typical PKI

instantiation. The first is a signature or identification

key, which is used for authentication or digital

signatures. This is generated on secure hardware and

has no copies or duplicates. The hardware protects

the key from export so that there is only one copy in

existence. This is useful for managing identities and

non-repudiation. The entity associated with the

private key is provided the only copy of the private

key.

The second type of key is used for decryption,

and this is typically archived so that encrypted data

can be retrieved if the original decryption key is lost,

destroyed, or expired. Generation and distribution

for decryption keys is less secure than for identity or

signature keys because the decryption keys have

additional copies. Decryption keys can be generated

in hardware and transmitted in encrypted form to

other secure hardware, or they can be generated in or

copied to software.

Public Key Infrastructure Issues for Enterprise Level Security

Identity and signature keys must have a single

copy in order to preserve non-repudiation. This is

generated in secure hardware and never leaves the

hardware. The hardware provides an interface to use

the key but does not provide a method for extraction.

The Trusted Platform Module (TPM) is an approach

that uses hardware-based key management (Trusted

Computing Group, 2016), but current user key

management solutions typically use portable

external key stores, such as smart cards or

USB/FireWire devices.

The challenge for modern systems is how to

generate and use such keys on a mobile device.

External hardware key stores, such as smart cards or

USB/FireWire devices are convenient and secure for

generation, but using them with mobile devices can

be difficult. Integrated key storage and use within

the device is more convenient.

The first thing needed for device-level key

management is trusted hardware that is inseparable

from the device itself. This hardware generates

random key pairs and prevents the private key from

being extracted. It makes the public key available.

The private key can be used through a defined

interface, such as PKCS11 for signature or

authentication (Oasis, 2015). Such a hardware

module is much like an attached smart card or USB

stick with private key operations, except it is

embedded inside the device. It is independent from

the normal processor, and its internal structures are

not made available except through defined

interfaces.

As part of a PKI, such keys need certificates,

which could be loaded into the hardware module or

kept in normal storage. The challenge for the

enterprise CA is to validate that keys are generated

in such a secure hardware module. Smartcard or

USB stick credentials are installed onto known

custom hardware at manufacture time. Generating

keys on a mobile device after a user has taken

possession means that the state of the hardware is

uncertain. For example, a malicious user may

generate keys in software and claim that they were

generated in hardware. This could be from a

desktop, an application on the same mobile device,

or a custom-built or compromised mobile device

specifically designed to mimic the behavior of a

normal phone while actually making private keys

available. Alternatively, a hostile entity could

manufacture devices designed to compromise the

keys of users. If the device manufacturer is not

trusted, it is not possible to have a trusted PKI with

device-based keys.

With a trusted vendor, there are measures to stop

fake devices. The vendor first registers each phone

using an embedded public key that is installed at

manufacturing time. This is a permanent feature of

the trusted hardware and, hence, the device. The

enterprise, when issuing mobile devices, validates

that all such devices are listed in the vendor’s

registry and validates each device by performing a

private key operation with the device.

The next step is to ensure that the public key

presented for a certificate was generated on that

device. This requires hardware support with a special

operation. This is a signed assertion of key generation

by the trusted hardware. It certifies that the secure

hardware generated the provided public key and

associated private key by providing a signature using

the permanent embedded hardware key. The only way

to generate such a signed statement is when the

hardware generates and returns a new key.

This hardware operation ties the public key to a

known device and allows hardware-based

bootstrapping for further PKI development.

The public key associated with the device-based

user credential is unique. As a result, the key

generation process, which produced a device-

permanent-key signature of the user credential

public key, can be used with the registry of devices

to confirm which device a user request is coming

from. Combining this information with an attestation

report from the device certifying that the device is in

a valid state, the result is strong assurance that the

user request is coming from the proper user on a

device in a valid state.

An alternative approach would be to embed

device information in the user credential. If the

device public key is embedded in the user credential,

a server can extract this and use it to verify a signed

attestation report from the device.

The choice of whether to embed information in

user credentials or provide a registry is up to the

organization. Either solution provides a way to bind

a user to a device for a given request by using the

device-based user credential’s unique public key.

This process enables the enterprise to leverage the

convenience of credentials embedded within mobile

devices while preserving the hardware security

properties associated with smartcards and other

custom hardware key stores.

6 DIGITAL SIGNATURE ISSUES

When an entity signs digital content, it is intended to

mean “I approved this content.” However, digital

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

signatures in their raw form leave a lot of implicit

real-world information out. For example:

• When was the content approved?

• For how long is the approval valid?

• For how long is the digital signature valid?

• What happens at credential expiration?

• What if the signing credential is revoked?

• What happens for role-based signatures when

roles change?

These issues are not specific to digital signatures,

but they are issues that can be more precisely

addressed with a digital signature solution; thus

agreement on which solutions to implement and how

to implement them is important.

6.1 Time of Signature

The issue of when content is approved has a simple

solution, which involves explicitly noting the date

and time in the signed content. However, relying on

the signing party to provide the date allows the

possibility to pre-date or post-date documents.

To address this, a trusted third party validates the

time of the signature. This can be implemented as an

enterprise time service, and this service simply takes

content, appends a time stamp, and signs the

combined result. The original signer can then sign

the combined (content + time stamp + time service

signature) data to prove that the signature was done

after the time in the combined data. The time service

must be trusted to provide the proper date and time,

and its issuing CA must be trusted by the receiver.

To provide proof of signature before a certain time

instead of after, the signed content can be presented

to the time service for signature. For a time window,

the time service can be called both before and after

the original signer’s signature is applied. This

bounds the time of signature within the window

between the two times.

For a multi-signature document, each signature

can provide its own time window, a single window

can be applied to the full set of signatures, or any

combination of time stamps can be used throughout

the signature process, depending on the desired level

of granularity. Also, individual copies of the

document can be signed by individual members with

or without their own time stamps, and then the

combination of document and all time stamped

signatures can be time stamped upon aggregation.

This might be desirable if the order of signatures is

not important and parallelization is desired in the

signature process due to time or communication

constraints.

For signatures after a certain time, the time

service need not sign the content of a document.

Instead it could periodically provide a signed

statement of the current time. Inclusion of this

signed statement of time in the original signed

content would be one way to show a signature

occurred after a given time. However, this could not

be used to show that a signature was performed

before a given time.

6.2 Explicit Signature Validity

The validity time window of the signature is

sometimes shorter than that of the credential. For

example, a temporary authorization letter would

likely expire while the signing credential is valid. In

this case, the validity window can be included in the

content to be signed. Because this is set by the

original signer, no additional signatures are needed.

This would generally apply to policy documents that

are to be used to guide actions. Renewals are

possible, but they would require a new signature.

Another issue is if the certificate associated with

a document signature is revoked. The time of the

signature may be available, but the time of

revocation may not be provided in a validity check,

and just the current status is reported. This raises the

question of whether the document and its signature

should be considered valid. Additional information

may be of use in making this determination:

• When the revocation happened

• When the certificate first became invalid

(looking retroactively)

Figure 2: Credential compromise timeline.

The revocation time may be enough information

to determine validity. This assumes that a valid

certificate is actually valid and that the only factor in

determining the validity of the signature is

determining the validity of the certificate at the time

the signature was performed. The issue with this

approach is that revocations typically occur after

Public Key Infrastructure Issues for Enterprise Level Security

some sort of problem is discovered with the

certificate, its associated key, or the entity it refers

to. This provides a time period between the start of

the problem and its discovery and eventual

revocation action. An attacker could use such a time

period to create unauthorized signatures that the

enterprise would accept as valid.

As part of the revocation process, it may be

possible to determine the point at which the

credential was first considered invalid, which could

be significantly before the revocation. For example,

in the case of a missing or lost credential, the report

might come in a week or so after the user last saw

the credential. In this case, the validity window

should end at the last time the user had possession of

the credential, because any further use would be by

someone else and not valid. In the case of a

discovered insider attack, the certificate might be

considered invalid at a much earlier time, depending

on when the person was deemed to have turned

against the organization. Figure 2 illustrates the

different events on a timeline.

Implementing this requires the technical

capability to record and make available the

revocation time and validity time. It also requires the

process of determining the validity time as a part of

revocation. It requires the Online Certificate Status

Protocol (OCSP) or a related protocol to allow

queries and responses about the validity and

revocation times. A simple modification would be to

add a time to the OCSP request, which essentially

asks, “Was certificate C valid at time T?” instead of

just “Is certificate C valid?”

6.3 Signature Renewal

Signature renewal is generally used when a signing

credential becomes invalid. This includes expiration

or revocation. It may also involve changing roles

and permissions for role-based signatures, where the

position and authority, not the actual identity of the

individual, is what matters. The signature by

someone who changes roles may still be treated as

valid, or it may be considered no longer valid. Also,

the new person assuming the role may wish to

explicitly invalidate previous signed documents even

if they would otherwise be considered valid.

Implementing such policies requires central services

that maintain a list of signatures, their types,

properties, and ties into a database of roles and their

history. This builds on the basic PKI functions.

6.4 Signature Updates

Expiration is an issue when the signature outlives

the signature certificate. Because cryptography can

be broken, credentials are periodically replaced. At

replacement key length may increase because

existing techniques to break keys improve as

computational capabilities increase. The

cryptographic algorithms themselves may be

changed as well.

Longer-term signatures can be broken if the

underlying credentials are broken, so there is a

natural limit on how long a signature is valid.

Instead of simply indicating the validity period for

the signature, more complicated measures must be

taken so that old signatures are refreshed at a

sufficient rate to prevent cryptographic or other

attacks that are enabled by long periods of use.

Signatures provide a strong guarantee of identity

at a particular time, but maintaining this over time is

more difficult. It is generally not possible to

construct a practical and scalable security measure

that will survive for more than a few years, because

technology advances and allows prior security

measures to be broken more quickly each year. For

this reason, central maintenance of official

signatures may be required to maintain security over

time. An automatic or manual re-signing may

provide sufficient security, along with a history of

all prior signatures.

The goal is to refresh old signatures using new

keys or new technology before they become too old

to be trusted as valid. Signed time stamps on the

original and refreshed content are required to

establish a proper chain of security from original

signed content through to the current version. This

would use the trusted time service mentioned above

with a sequence such as the following:

Original signature:

1. Original content is time stamped (time

service adds time and signature)

2. Time stamped content is signed by original

signer

3. Signed content is time stamped a second

time

Signature refresh:

1. Original triple-signed content (date, signer,

date) is re-time stamped

2. Re-time stamped content is signed by

same or new entity using updated

keys/technology

3. Re-signed content is time stamped again

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

Further signature refreshing follows the same

process as above. With this process, it is possible

that invalid signatures exist for expired credentials,

especially ones with broken cryptographic methods.

It is important to monitor such aging signatures and

generate new signatures while the current ones are

still valid and secure.

The length of the signature chain grows over

time, and it provides a verifiable history of the

approval of the content. In addition, signed records

of certificate revocations, role assignments, and

other issues mentioned above must be maintained in

order to tie the signatures to the real-world.

7 ELS SOLUTION FOR PKI

The ELS solution attempts to address the issues

discussed. It starts with DNs for all users,

established by a central authority. These include the

name and unique identifying number in the CN and

organizational information in other fields of the DN.

The DNs are used in X.509 certificates that are

issued after a full background check, proper

authorization, and secure forms of identification are

presented in-person at a credential issuing station.

Certificates and associated keys are stored on

smartcards for use with laptops or desktop machines.

For mobile devices, only approved vendor

devices are supported, and they are enrolled in a

device management system. The devices generate

keys in a secure hardware enclave that is separate

from the main processing unit and only provides

defined interfaces for standard cryptographic

operations involving the private key. A factory-

installed and registered public/private key pair is

used for attestation reports that certify the status of

the device and its software. It also certifies the

creation of a new public/private key pair in

hardware.

Servers are provided a “security handler,” which

is code to be executed upon receipt of an incoming

request prior to application code. The security

handler examines the user credential, and for mobile

device credentials, it performs hardware validation

of the associated device where the credential is

stored, based on a registration of devices.

A time server provides two interfaces. One

provides a signed statement of the current time.

Another provides a signed statement that the given

content provided by the user was received at the

current time. This provides the ability to prove that a

document was signed within a certain time window.

Validity windows for signed statements are

provided by the signing entities. If the validity

exceeds the credential validity, it must be renewed at

expiration to remain valid. This may be by the

original signer or by an authorized individual at the

time of expiration. Formal signed documents are

stored as official records and retain the full history

of signatures.

One of the intentions for such a signature

process is to allow automated enforcement of policy

through PKI. If a valid signed statement (such as an

XML structure) exists, then certain automated

functions proceed; if not, they halt and produce alert

messages.

In ELS, two-way, end-to-end PKI-based

authentication is used for all web-based

communication. The identity validation checks the

full DN as well as the chain to a trusted root CA, and

it validates that the DN values of each certificate in

the chain are consistent with the issuing CA for that

certificate. OCSP is used for certificate validation,

and certificate revocation lists (CRLs) are

periodically updated for backup to support

operations when OCSP services fail or time out.

The web-based authentication portion of the ELS

PKI solution has been subjected to two rounds of

penetration testing. Other portions are currently in

development, such as the mobile device credential

management strategy and the higher granularity

signature approaches. Current mobile device

technology provides some native hardware

capabilities for key management, but full integration

into a working PKI on managed devices often

requires work-arounds that use software instead of

just hardware (Apple, 2019) (Samsung, 2019).

This work is part of a body of work for high-

assurance enterprise computing using web services.

8 CONCLUSIONS AND FUTURE

WORK

PKI is an integral part of the ELS solution for

enterprise security. It forms the basis for many

higher level security functions, such as

authentication, authorization, and content integrity.

This paper examines some of the challenges and

shortcomings when using PKI and provides methods

to use and extend the core PKI functionality to

provide desired enterprise functionality.

Future work includes the extension of signature

revocation and validity times to normal business use.

For example, if signatures by certain individuals are

Public Key Infrastructure Issues for Enterprise Level Security

only to be considered valid if executed during their

working hours or their shift hours, then a service can

be invoked to determine for a given signature time

whether the signer is authorized to sign. This is

important when signature credentials are associated

with the person’s role or location. Another variant is

to disable credentials when the owner is known to be

on vacation, traveling, or otherwise in a position

without the credentials. Such irregular intervals

could be handled in a way similar to normal business

hours using an external server to manage schedules.

The signature refreshing process, where the

number of signatures grows over time and each

signature encapsulates the prior ones, bears some

resemblance to a blockchain approach, such as that

used by Bitcoin (Bitcoin, 2019). The Bitcoin

blockchain has a similar problem that current

hashing and public key algorithms used for

transactions may be compromised later, and

algorithms and key sizes may change in the future.

This suggests that a blockchain may provide a

natural solution to the central signature repository.

However, the Bitcoin blockchain is decentralized

and requires vast computing resources to maintain,

and such a solution is not desirable for an enterprise.

Various private blockchain technologies attempt to

resolve this issue, but by making the blockchain

private, they give control to a central authority and

negate many of the features of the public blockchain.

Also, although many signatures are intended for

broad audiences, some are not, and a blockchain

approach that does not encrypt the content

appropriately is not an appropriate solution for

general digital signatures. Hence, current blockchain

technologies offer an approach that parallels some of

the concepts of digital signatures, and further work

in this area might provide a viable approach.

REFERENCES

Apple, “iOS Security, iOS 12.1”, November 2018,

https://www.apple.com/business/site/docs/iOS_Securit

y_Guide.pdf

Bitcoin, “Blockchain,” Bitcoin Developer Documentation,

available at https://bitcoin.org/en/blockchain-guide,

accessed December 9, 2019.

Cooper, D., et al., “Internet X.509 Public Key

Infrastructure Certificate and Certificate Revocation

List (CRL) Profile”, May 2018. Available at

https://tools.ietf.org/html/rfc5280, accessed December

9, 2019.

Entrust Datacard, “What is PKI?” available at

https://www.entrustdatacard.com/pages/what-is-pki,

accessed November 27, 2019.

Foltz, K. and Simpson, W., 2017. Enterprise Level

Security with Homomorphic Encryption. In

Proceedings of 19

International Conference on

Enterprise Information Systems (ICEIS 2017), Porto,

Portugal, April 26–29, 2017.

Foltz, K. and Simpson, W. R. 2016. “The Virtual

Application Data Center.” In: Proceedings of

Information Security Solutions Europe (ISSE) 2016.

Paris, France.

Foltz, K. and Simpson, W. R. 2016. “Enterprise Level

Security – Basic Security Model.” In: Proceedings of

the 20th World Multi-Conference on Systemics,

Cybernetics and Informatics: WMSCI, Volume I,

WMSCI 2016. Orlando, FL.

Foltz, K. and Simpson, W. R. 2016. “Federation for a

Secure Enterprise.” In: Proceedings of The Twenty-

first International Command and Control Research

and Technology Symposium (ICCRTS 2016). London,

UK.

Oasis, “PKCS #11 Cryptographic Token Interface Base

Specification Version 2.40,” Oasis Standard, April 14,

2015. Available at http://docs.oasis-open.org/pkcs11/

pkcs11-base/v2.40/os/pkcs11-base-v2.40-os.doc,

accessed December 9, 2019.

Samsung, “KNOX Platform Security”, Samsung

Developers website, Available at https://developer.

samsung.com/tech-insights/knox/platform-security

Simpson, W. R. 2016. Enterprise Level Security –

Securing Information Systems in an Uncertain World.

Boca Raton, FL: CRC Press, p. 397.

Trias, Eric D., et al. 2016. “Enterprise Level Security”,

Proceedings of the 35th MILCOM conference, DOI:

10.1109/MILCOM.2016.7795297 pp. 31-36,

http://ieeexplore.ieee.org/document/7795297/.

Trusted Computing Group, “TPM 2.0 Library

Specification”, September 29, 2016. https://trustedcom

putinggroup.org/resource/tpm-library-specification/

X.509 Standards

a) DoDI 8520.2, Public Key Infrastructure (PKI) and

Public Key (PK) Enabling, 24 May 2011

b) JTF-GNO CTO 06-02, Tasks for Phase I of PKI

Implementation, 17 January 2006

c) X.509 Certificate Policy for the United States

Department of Defense, Version 9.0, 9 February

2005

d) FPKI-Prof Federal PKI X.509 Certificate and CRL

Extensions Profile, Version 6, 12 October 2005

e) RFC Internet X.509 Public Key Infrastructure:

Certification Path Building, 2005

f) Public Key Cryptography Standard, PKCS #1

v2.2: RSA Cryptography Standard, RSA

Laboratories, Oct 27, 2012

g) PKCS#12 format PKCS #12 v1.0: Personal

Information Exchange Syntax Standard, RSA

Laboratories, June 1999.

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems
