WOBCompute: Architecture and Design Considerations

of a P2P Computing System

Levente Filep

Faculty of Mathematics and Computer Science, Babeș-Bolyai University, Mihail Kogălniceanu, Cluj-Napoca, Romania

Keywords: Peer-to-Peer Networks, Super-Peer Topology, Distributed Computing, Middleware.

Abstract: Regarding large-scale scientific computing, many alternative solutions to Cloud Computing Services exits,

which combine existing, cheap, commodity hardware into computational clusters. The majority of these, due

to their ease of deployment, are based on Client-Server architecture. Decentralized approaches employ some

form of Peer-to-Peer (P2P) design, however, due to their increased design complexity, and without major

benefits over the Client-Server ones, none of these systems gained wide popularity. The P2P system presented

in this paper features decentralized task coordination, the possibility of suspending, migrating and resuming

workload on different nodes, employs remote checkpoints to allow partial result recovery, and workload

tracking, which offers the possibility to initiate communication between them. Design considerations and

choices for this system are presented and discussed. The chosen topology is super-peer managed clusters

arranged in an extended start topology and evaluated by simulation. Such a system comes with enormous

design complexity; however, a middleware can hide these complexities, while providing the applications a

simple interface to access network resources. Harnessing idle computing resources, the system can be

deployed on a combination of in-house computer networks, personal and volunteer devices, as well as Cloud-

based VMs.

1 INTRODUCTION

In recent years Cloud Computing, in the form of

Cloud Services, has become the defacto choice for

large-scale scientific computing due to its availability

and low cost. Despite this, there are many instances

where this is out of reach for individuals or small

research groups.

Many alternative solutions exist that combine

existing, cheap, commodity hardware into

computational clusters, such as grid computing or

volunteer computing (Lavoie and Hendren, 2019).

The latter is achieved by utilizing a specialized

middleware to harness the idle computational

resources of volunteers. Such a middleware can also

be deployed in a combination of personal devices, in-

house computer networks, and even Cloud VMs.

Existing solutions are mostly centralized in nature,

based on Client-Server architecture, where the

centralized server(s) are responsible for task

coordination (creation, deployment and result

collection), while volunteer resources are utilized to

https://orcid.org/0000-0003-2095-0161

run these tasks. Due to their ease of deployment, this

kind of system, such as BOINC (Anderson, 2004),

has become the most widespread. Decentralized

approaches employ some form of Peer-to-Peer (P2P)

architecture, where each node takes part in both the

execution and the coordination of tasks. However,

P2P solutions have an increased design complexity

compared to the simplicity of Client-Server based

systems, and without providing additional benefits

(Lavoie and Hendren, 2019), these never gained

popularity, despite having the advantage of

decentralized task coordination, which, in case of

large projects, eliminates the need for costly, high-

performance centralized servers.

In this paper, a new P2P system is presented;

based on a previously presented model (Filep, 2019),

which is characterized by decentralized task

coordination (creation, deployment, and result

dissemination) as well as task tracking and remote

backups, which allows recovering partially

completed computation. Task tracking, in other

words, the ability to query task location, brings the

Filep, L.

WOBCompute: Architecture and Design Considerations of a P2P Computing System.

DOI: 10.5220/0009343100390049

In Proceedings of the 15th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2020), pages 39-49

ISBN: 978-989-758-421-3

possibility of parallel-branch communication. Such a

system comes with enormous complexity, however,

employing a specialized middleware, these

complexities can be hidden from the application. As

the middleware harness idle resources, the system can

also be deployed on a combination of in-house

computer networks, personal and volunteer devices,

as well as Cloud-based VMs. Design considerations

and choices regarding the system's topology and

middleware are also present and discussed.

Application design for such a computational system

is discussed in a different paper.

2 RELATED WORK

P2P systems are commonly used nowadays in data

networks, such as data sharing or streaming. As the

basis of computational networks, the P2P architecture

has not gained a wide interest in the literature,

arguably due to their design complexity. In Grids and

Volunteer Computing (VC), where the parallel tasks

can be computed independent of each other, the

client-server architecture is the popular choice for

such systems, as in the before-mentioned BOINC

(Anderson, 2004).

2.1 P2P Computing Systems

P2P architecture also influenced several computing

system designs. CompuP2P by Gupta et al. (2006) is

a lightweight architecture for internet computing,

using node clustering, called markets of computing

resources. Tiburcio and Spohn (2010) presented a

P2P based open-source computing grid. Gomathi and

Manimegalai (2013) presented the Hierarchically

distributed Peer-to-Peer (HP2PC) as a solution to

heterogeneity problems. Pérez-Miguel et. al. (2013)

presented a prototype P2P-HTC (P2P High

Throughput Computing) system based on Cassandra

(a distributed DHT based database) for distributed

queue based scheduling utilizing an FCFS (First

Come First Served) scheduling policy. DisCoP

(Castella et. al., 2015) is also a P2P system that

harnesses idle CPU cycles and a clustered topology

for resource location. These implementations,

however, didn’t gain huge popularity when compared

to BOINC.

2.2 Virtual Topology

P2P networks create a virtual topology over the

physical one, which directly results from the set of

rules the nodes use to connect between themselves.

Such an overlay can be structured or unstructured.

Structured P2P networks maintain a virtual topology

on top of the physical network layout (Ratnasamy et

al., 2001) aimed at increasing reliability, availability,

and search speed. Chord (Stoica et. al., 2001)

employs a ring topology and uses finger tables to

improve search efficiency. Tapestry (Zhao et al.,

2004) introduced the concept of backup- neighbor to

maintain the virtual overlay if a node becomes

unavailable.

The concept of super-peer with redundancy to

maintain cluster stability was proposed and evaluated

by Yang and Garcia-Molina (2003). However, the

super-peers concept by itself introduces a single point

of failure in the network. In the before-mentioned

paper, the authors also used redundancy and

concluded that this does not significantly affect the

overall bandwidth usage. They also proposed cluster

splitting for the network topology to adapt to an

increasing number of connecting nodes and cluster

merging in case of decreasing node number when

some clusters become too small; however, no exact

solution was proposed on how to perform these two

operations.

We often think of P2P systems as where all nodes

are equal; however, each node differs regarding their

computational performance, storage capabilities, and

available bandwidth (Jesi et. al., 2006). In the SG-2

protocol (Jesi et. al., 2006), a proximity-based super-

peer election is proposed, where each node has an

associated latency distance. The authors also state

that due to the constant change in the peers, the

maintained overlay is highly dynamic.

Clustering of peers as a search improvement was

proposed by Ye Feng et al. (2009) for the Gnutella

protocol, but also as recent as by Vimal and Srivatsa

(2019) for file sharing system search.

Several studies have analyzed the reliability of

super-peer based P2P networks. A study by Mitra et

al. (2008) finds that a super-peer ratio of less than 5%

sharply decreases reliability. Super-peer based

networks are also vulnerable to churn (De et. al.,

2016), where a large number of simultaneously

connecting or disconnecting nodes can divide the

network into isolated parts. In such cases, data

replication was proposed by Qi et al. (2019) as a

solution to data survivability.

3 SYSTEM ARCHITECTURE

WOBCompute is a P2P based computing system

based on a previously published model (Filep, 2019).

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

We can briefly summarize this model by its

characteristics:

- Workload (or task) creation is offloaded from

centralized servers to the peers; each workload starts

as a whole, and it is split based on other peer’s

requests for computation while also accounting for

their performance. In this case, the application itself

is responsible for splitting the workload, which

allows for multiple types of workloads, offering

better load balancing.

- The completed child workload result is

transferred to the parent task. The dissemination

process is also controlled by the application itself.

- Gateway(s) are used for the overall workload

injection and result collection.

- Computation of a workload can be suspended,

transferred to a different node and resumed.

- Workload locations can be queried by the

application for initiating communication between

them. The connection is opened directly to the target

node or via a super-peer if the target is behind NAT.

- The use of periodic remote checkpoints allows

the recovery of a partially computed workload, which

then can be resumed and even further split. The

application can choose whether to wait or recover a

workload.

To achieve the above objectives, the previously

presented model extends the notion of workload unit

with additional data fields: unique identifier (ID),

application identifier, parent and children identifier

(for result merging), checkpoint data (allows the

transfer and continuation of computation), boundary

information (identify data-set boundaries; if

required), estimated total and remaining

computational effort, state of computation, result data

(contains the partial result of the workload) and

metadata (for any application-specific use).

For ease of processing, transfer with minimal

bandwidth usage, and storage, the above fields are

incorporated into a single data-object represented as

a JSON structure, named Workload Object or WOB

in short. Furthermore, WOB size is to be kept at

minimal, therefore large analyzable data-sets are to be

acquired separately.

The concept of WOB based computing allows the

system to incorporate in-house computer networks

with volunteer provided resourced and Cloud-based

VMs. Furthermore, the possibility to track WOBs

opens possibility to initiate communication between

the parallel branches of an application. Due to

arbitrary latency between nodes, such application

design must be latency tolerant.

3.1 Network Topology Design

As mentioned before, P2P networks create a virtual

topology over the physical one. Starting from the base

model of the system, we need a search protocol to

query each WOB and a distributed storage for the

WOB backups. There are a variety of

implementations for both distributed search and

storage, however, in the author’s opinion, having two

more virtual overlays on top of the one created by the

middleware, would significantly increase the

system’s complexity.

DHT based systems have proven to be the fastest

when it comes to search, especially when dealing with

rare resources. In the presented system, each WOB

can be considered rare; however, due to constant

migration, creation, and dissemination of them,

especially with a large number of objects, the number

of update messages may significantly surpass those of

query messages. This can lead to significant

bandwidth and resource consumption to keep the

DHT up-to-date. It must be noted, that the above

statement is an assumption and was not tested

experimentally, however, to the author’s best

knowledge, how DHTs behave with extremely

frequent keys and value changes was not examined in

the literature.

WOB creation is driven by workload request

messages and therefore must reach all nodes. The

number of these messages can be problematic as a

WOB nears completion, in which case as more and

more nodes become starved, a huge number of

messages can overload and cripple the network.

Clustering of the nodes offers a pretty straightforward

solution: a cluster that contains starved nodes has no

reason to accept any workload request messages.

Furthermore, if a super-peer is aware that no more

workload is available, they can stop all outbound

request messages to other clusters. However, if more

workload becomes available (e.g. a new WOB is

injected via the gateway), workload notification

messages can unlock clusters and trigger the idle

nodes to request workload.

Several topologies, other than the previously

mentioned ones, have been proposed and

demonstrated to be resilient and efficient in resource

location, such as the AFT (Poenaru, 2016). To best of

the author’s knowledge, besides clustering with

super-peers, none can offer a cutoff solution to the

above-mentioned message flooding problem.

Furthermore, super-peers can act as a tracker of the

WOBs located within their cluster, thus search

queries can be limited only to them. A similar

proposal was made by Chmaj and Walkowiak (2013),

WOBCompute: Architecture and Design Considerations of a P2P Computing System

where, as opposed to the current design, the tracker is

also responsible for task scheduling.

For the above-discussed reasons, the chosen

topology is the super-peer driven clusters of peers,

arranged into an extended start superstructure, where

each cluster is connected to their parent.

Super-peers, given their role, will be referred to

as supervisors. The cluster supervisors keep a list of

all WOBs located within their cluster and their latest

backup. This way, the search only involves the

supervisors. Backup supervisors also keep a copy of

the WOB list and backups. Furthermore, they also

keep track of the available number of workload

present and idle nodes required for limiting workload

request messages.

The chosen topology does not exclude the

possibility of a later DHT implementation on top of

the current topology, where only the super-peers

would participate. Their redundancy would reduce

the number of joins into and disconnects from the

DHT topology, as one would leave, a backup super-

peer with already up-to-date indexes would take its

place.

As a project can be run on a combination of in-

house computer network, outside volunteers and

cloud resources, each project has its gateway, thus

each project has a separate logical topology. This is

required to separate the workload to maintain the

usage of allocated resources within the target project.

However, this does not exclude the possibility of one

peer participating in multiple projects.

Due to network latency between the nodes, we

can notice that while a task can initiate

communication between parallel branches of an

application, there are limitations to the types of

applications that can benefit from such a design. In

other words, the efficiency of an application

decreases as the number of messages in given time-

interval increases; with an increased number of

messages, an application will spend an ever increased

time on communication instead of computation.

3.1.1 Cluster Topology Considerations

The search efficiency is considerably impacted by the

number of clusters, meaning, the greater their

number, the more hops a query message has to take

to reach all of them. Reducing the cluster count and

still connect the same number of nodes can be

accomplished by increasing the number of nodes a

cluster accept. Since each node has a limited

connection capacity, the cluster members are

distributed among the supervisors. We can define a

cluster as balanced when the load ratio on all

supervisors is about equal. Balancing operations can

be triggered if a supervisor is overloaded.

In the current topology, each regular node is

connected to only one supervisor but is aware of all

other supervisors, as illustrated in Figure 1. In

contract, all supervisors are connected between them.

As a synchronized list of WOBs and their backups are

maintained, the persistent connection makes

messaging easier.

Node failure detection is accomplished through

regular heartbeat messages. If the connected

supervisor fails or leaves the network, the affected

nodes will connect to another supervisor from the

cluster. If this also fails, we consider the node

isolated, which then re-joins the network through the

gateway.

Figure 1: Cluster topology.

Changes in the available supervisors, such as

disconnects or elections, are advertised throughout

the cluster, so each node has an updated list of these.

3.1.2 Topology Stability

In the present system, WOB query misses are not

allowed as they can lead to computation losses. For

instance, if a WOB is partially computed, but the

query misses it due to isolated clusters, the querying

node may assume it to be lost and choose to re-create

it from a backup. Therefore, topology stability is

paramount.

Clusters are interconnected with the help of two

supervisors, one from each cluster. For additional

reliability, a backup connection is also maintained;

however, messages are not balanced between the two

connections. As a backup scenario, if a cluster gets

isolated from its parent, it will query the gateway for

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

a list of current clusters and attempt to connect to one.

This offers some stability in case of churn.

As the system harnesses idle cycles, when a node

is not participating in any computation, meaning its

compute resources are not free, they can still

participate, by user choice, in basic interconnection

functions. This in term further increases topology

stability.

3.1.3 Cluster Stability

Cluster internal stability is also an important factor. If

a supervisor fails, the connected nodes try to connect

to one of the known supervisors within the same

cluster. If those get overloaded and refuse the

connection, then we get isolated nodes; as the election

process of a new backup supervisor, followed by

balancing the existing supervisors can be more time-

consuming than the re-joining process of the node.

If a cluster becomes unviable (shrinks to very low

node number) we can consider it defunct. In this case,

the stored WOBs and WOB backups must be

transferred to either a better-suited neighbor cluster or

the gateway. We can notice that the system requires a

minimal constant number of participating nodes to

remain stable. Having a large number of nodes that

all disconnect a certain time of day, for example at

night, the gateway must act as storage for all WOBs,

otherwise, if nodes holding WOBs will not join the

network again, then significant parts of the overall

computation can be compromised, as child WOB

results cannot be disseminated without their parents.

Keeping a reserved connection capacity for each

supervisor reduces the chances of isolated nodes

occurring if a supervisor leaves the network.

Furthermore, supervisors can still accept connecting

nodes into the cluster by using their reserved capacity.

We can define the total connection capacity allocation

of a supervisor as:

𝐶



𝐶



𝐶



𝐶



(1)

where 𝐶



denotes the total capacity (minus the inter-

cluster connection if present), 𝐶



the number of

connections to all other supervisors within the cluster,

𝐶



is the reserved capacity, and 𝐶



the capacity

available for cluster member connections. Since we

balance the cluster members among the supervisors

(primary and backup), we can observe that the cluster

capacity can dramatically increase using this

technique, but we also notice that there is an upper

limit on the cluster size.

With a uniform capacity of 100 (fairly regular

setting on BitTorrent clients) on all nodes and a 𝐶



value of 0.1 of 𝐶



, as illustrated in Figure 2, 45% of a

Figure 2: Number of supervisors influence on cluster

capacity.

supervisor capacity allocated to super-peer

connections produces the optimal cluster size,

namely, 2070 of possible connected nodes.

Simplified, we can state that an optimal number

of supervisors per cluster are 45% of the lowest

supervisor capacity (𝐶



. A newly elected supervisor

connects to all other supervisors, and by doing so, in

the handshake process it advertises its capacity, so the

maximum number of supervisors can be adjusted

accordingly after each election. However, electing a

supervisor with low capacity should be avoided as it

triggers the demotion process, which removes the

lowest capacity supervisor first.

The connections in Equation 1 represent the

persistent ones. Temporary connections, such as

workload related, are not accounted for as they don't

have a significant impact here.

Supervisor Promotion. Supervisor election is

triggered when all supervisors exhaust their capacity.

The process is trivial: we select the best node based

on its capacity and bandwidth. Having a reserved

capacity on each supervisor allows the cluster to still

accept connections while the election process is

running, despite the cluster being temporary

overloaded.

Supervisor Demotion. Having too many supervisors

is not necessarily a problem; however, maintaining

the WOB indexes and backups utilizes an update

message for each occurring change, which must reach

each supervisor. To minimize the number of these

messages in the process, if the average used

supervisor capacity drops below a threshold value,

the lowest capacity supervisor is demoted. The

threshold value is a subjective choice with little

impact other than the number of update messages.

500

1000

1500

2000

2500

1 5 9 13 17 21 25 29 33 37 41 45 49 53 57 61

Cluster capacity

Number of supervisors

Number of Supervisors vs. Cluster size

Cluster capacity

WOBCompute: Architecture and Design Considerations of a P2P Computing System

Cluster Splitting. When a cluster gets overloaded,

and the maximum number of supervisors has been

reached, the splitting process is triggered, where

randomly selected supervisors along with the

connected nodes are split into a new cluster, while the

current cluster becomes its parent. The WOB indexes

and backups are also adjusted accordingly. As the

new cluster becomes functional, the gateway is

notified of this.

WOB List Consistency and Backups. A node

getting temporary isolated isn’t a critical issue as the

WOBs under processing still resides on it, and

computation can continue even if the node is

temporarily disconnected from the network.

Furthermore, the node address doesn’t change, so

workload related operations can still be carried out.

For this reason, once the node is detected missing, the

WOB entry at the former cluster isn't immediately

discarded, but marked as “outdated” and only later

removed. This marking prevents conflicting results of

the location query; for instance when the node joins

another cluster where it advertises it’s WOB. In such

a case the query of the WOB will return one

“outdated” result and one “fresh” which overrules the

first one. In the worst-case scenario, if the node didn’t

have time to join another cluster, then the “outdated”

result will still correctly indicate the WOB location.

As network time may be unreliable, WOB

backups are also stamped with an incremental

number.

When a WOB is completed, and its result merged

with the parent, the list entry and backup of the WOB

is removed. This minimizes the supervisor index list

and the amount of storage required to track the

WOBs. The removal process is triggered by the

parent node’s ACK message of the child WOB.

3.2 Communication and Messages

Node interconnection utilizes TCP protocol and

messages are represented in JSON structure. To

reduce bandwidth utilization, data communication is

compressed using ZLIB (Gailly and Adler, 2002)

streams. The use of compression is determined in the

handshake process between any two nodes.

A generic message contains the fields presented

in Table 1 but, depending on their type, some can be

empty or omitted.

Table 1: Message wrapper structure.

licationID Distribute

uni

ue ID

Messa

e UUID Uni

ue messa

e identifie

Messa

e of messa

SenderID Sende

node unique identifie

Sende

Address Sende

node IP:Port

DestID Destination node unique identifie

DestAddress Destination node IP:Port

Relayed Set to 1 if message was relayed by

a supe

Payloa

Contents of message

Separate node ID and address is used for relaying

messages through supervisors, but to also identify

nodes between IP address changes.

For fast message routing within the middleware,

the design-choice was to prefix the message types

according to their types. These are:

- WOB messages, prefixed “WOB_”. These include

the request, response offering, query, backup query,

transfer, location update, etc. and their appropriate

acknowledgment (ACK) messages.

- Peer messages, prefixed “NODE_”, which include

interconnection, handshake, and capacity advertising

messages.

- Cluster specific messages, prefixed “CL_”, include

supervisor election, cluster balancing and splitting,

but also WOB list and backup update, and cluster

interconnection messages.

- Application-specific types, are prefixed “APP_”,

and are passed to the application itself. These can be

used for messaging between different tasks.

3.3 Gateways and Bootstrapping

As dynamic task coordination eliminates the need for

centralized servers, a dedicated server is still required

to ask a gateway for bootstrapping the network, the

injection of a primary task, and computation result

extraction. Another role of the gateway is that of

failsafe storage for WOBs in case of cluster

dismemberment. Since the gateway has a simplified

function and no persistent connection is required to

be maintained to it by any supervisor, this can easily

be implemented as a web application.

Bootstrapping is the process of creating the initial

network overlay to which the rest of the nodes join.

The first joining node creates the first cluster to which

the rest of the nodes join. The join process consists of

the following steps:

Node contacts the Gateway to obtain the

list of optimal clusters (cluster id

with multiple supervisors)

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

If the Gateway is unreachable, attempt

to reconnect to the previous cluster

(if any)

From the obtained list, chose the best

one (based on latency)

Attempt to connect to cluster (try each

supervisor until one accepts the node)

If connection to all supervisors fail,

try next cluster; if all clusters

fail, repeat the process

As query time depends on the number of hoops the

message takes, the choice is to grow the existing

clusters to their maximum size before creating new

ones. This strategy can also be applied to maintain the

central cluster in the topology: if the member count

drops, the gateway will prioritize connecting nodes to

this. To perform such strategies, clusters supervisors

regularly update the gateway about their status.

While messages can be delivered to nodes behind

NAT, they are not allowed to become super-peers.

Theoretically, they could form a “local” cluster, but

no external connection could be initiated to them for

maintaining the overall network topology. On the

other hand, this imposes a limitation on network

bootstrapping, namely, it only can be started with

nodes that have an external IP address.

3.4 Middleware

The middleware plays an essential role in maintaining

the network structure, providing the required

functionalities (such as WOB indexing and backup

storage), but also by hiding the complexity of the

system, and provides a simplified way for application

developers to harness resources from across multiple

network nodes. Nonetheless, the utilization of

middleware results in additional communication and

computing overhead.

The communication overhead is the result of all

in- and outbound messages being routed through the

middleware. Given the JSON representation of the

WOB, the fields involved in the routing of a message

can be examined without unpacking and processing

the entire message, resulting in low processing time.

As the apps are run directly on the OS but still

controlled by the middleware via callbacks, this in

term causes slight, but additional overhead. By

design, as discussed below, these only occur on

starting or stopping the computation, and message

passing. Also, a small amount of processing is

utilized for application resource monitoring and

logging.

The internal structure of the middleware is illustrated

in Figure 3. For easy development and maintenance,

based on the "separation of responsibilities" design

principle, a component-like structure was chosen.

Next, the function of each component is summarized.

Figure 3: Middleware internal structure.

3.4.1 Network Manager

This component maintains all active peer connections

and handles the receiving of incoming messages

which then are forwarded to the Message Router. Due

to overhead considerations, outbound messages are

passed by the sender component directly to the

Network Manager with direct function calls, thus

bypassing the Message Router entirely.

3.4.2 Message Router

The Message router receives the incoming messages

from the Network manager and routes them to the

corresponding component. While the messages are

prefixed according to their types, the handling of

these overlaps different components.

The message router is also responsible for

relaying messages to nodes behind NAT; this routing

only involves application-specific messages. In short,

if such a message’s DestinationAddress is the current

node, but the DestID differs, then the DestID is

searched in the cluster members, and if found, the

message is relayed directly or via another supervisor

(to whom the destination node is connected). If not

found, then a delivery failure notification is returned.

While this is a solution to messaging nodes behind

NAT, an increased number of messages can quickly

overload the supervisor.

Admin comp. (WebAPI, WebSrv)

App.

Mana

WOB

Storage

Message

Route

Network manager

Cluster

Manage

WOBCompute: Architecture and Design Considerations of a P2P Computing System

3.4.3 Cluster Manager

When a node fulfils the supervisor role, then this

component is responsible for maintaining all cluster

functions, such as: maintaining a local WOB index,

answering WOB location queries and storing WOB

backups. Synchronization between supervisors is also

handled by this component with the use of differential

update messages (in other words, only changes are

advertised between these nodes).

If a node is a supervisor, then any messages

intended to supervisor from the local application is

also routed here.

3.4.4 WOB Storage

This component handles the effective storage of

WOBs, their backups, and answers the associated

request messages. WOB backups are stored at the

supervisor level; however, if a node gets disconnected

from its cluster, then the WOB backup (created at

checkpoint or node shutdown) will be stored on the

local peer until the connection is re-established. In

such a case, when the node re-enters the network, then

a query is made for the current status of the stored

WOB, as meanwhile this might have been recovered

and under processing or even completed. If this

occurs, then the stored WOB in question is discarded

from local storage and a new WOB request trigged.

3.4.5 Application Manager

The App. manager is responsible for application

scheduling (starting, suspending or stopping this),

and imposing resource usage limits based on

available idle resources and settings. A given

application is started before requesting any WOB to

ensure that these can start-up and be ready to handle

the WOB offerings. As a security measure, all

applications are run under a limited OS user.

Application setup is defined in the participating

project configuration, which contains the install, run,

and uninstall commands.

As the WOB object only contains workload

related data, but no executable code and the

application itself is downloaded from the project

URL, malicious code injection is not possible by a

remote node.

3.4.6 Admin Component

Combined with the Project manager and the internal

web server, these are responsible for joining projects,

downloading and installing applications, and

providing local and possibly remote administration

for peer configuration. The design choice was to

provide the local admin area via an internal webpage

and remote administration via a WebAPI call using

an authorization key. This can also be configured to

only accept connections from given IP addresses. The

local admin portal can also be disabled if remote

administration is enabled, which is useful when

setting up a local computer network.

3.4.7 Application API

For easing application development for this system,

an API is provided that resides before the middleware

and "translates" the incoming messages into

callbacks, to which the app can register, as illustrated

in Figure 4.

Figure 4: Application API.

The most important callbacks and functions can be

summarized as:

- The API provided Start() is to be called when the

application is ready to receive workload. The

request message is dispatched by the API.

- OnWOBInit: called when the workload is

received and computing data is to be extracted.

- OnCompute: registered function does the

effective computation. Interruption is done via

the CanCompute() function, which, if returns

false, then the computation is to be suspended.

Specialized hardware resources (such as GPU)

are to be acquired at the beginning of the

registered function. Since there is no guaranty

that the computation will be resumed on the

current node, the acquired resourced must be

released at the end of this function.

- OnCheckpoint: a checkpoint is requested by the

middleware. Checkpoint interval is a project

setting.

- OnAppExit: WOB data is to be packed as

preparation for application exit. The WOB will

be transferred off the node (if possible). Even if

computing is suspended, this function is called

Callbacks + functions

Application manager

App. API

Messages

Application code

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

0 2 4 6 8 10 12 14 16 18 20 22

Weekday pattern

Weekend pattern

when a node is shutting down to allow the

application to pack the WOB.

- OnWOBRequest: called when another node

requests workload from us. Request contains

node specifications. The answer is a workload

offering. The offered workload is to be locked to

prevent multiple offering.

- OnWOBOfferAck: triggered when the requester

node accepted our workload offering. The child

WOB can be created, prepared and dispatched.

On confirmation of receive, the

OnWOBChildAck callback is triggered. If the

Ack doesn’t arrive, then the application can

release the workload.

- NotifyWorkloadAvailable() is to be used when

additional workload becomes available. This will

broadcast a notification message which triggers

idle nodes to request workload.

- WOBQuery and WOBLocQuery functions can

be used to query the entire WOB with location or

only the location of a specific WOB.

- WOBMsg can be used to send application

specific messages.

- WOBReqBackup: can be used to retrieve an

existing backup of a WOB.

- WOBFinished is to be called when the current

WOB is finished. This will be automatically

transferred to the parent WOB location, where

the OnWOBChildFinished is triggered for its

result to be disseminated. The parent

acknowledges the WOB with the WOBFinished

function, to which this will be removed from the

supervisor’s indexes and backups.

As mentioned with the presentation of the base

model, when a WOB is created, a backup of this is

also created to preserve parent-child list consistency.

We can already see that while the middleware

offers simplified functions to harness the P2P

system’s resources, there is additional complexity to

application design.

4 TOPOLOGY SIMULATION

Simulation of topology was conducted using a

custom, purpose built simulator. The goal was to

simulate a variety of user compute resource

contribution; hence the number of joining and leaving

nodes was generated using an estimated online

number of computers per week, obtained from a local

internet provider. These numbers differ very little

between the weekdays, so one pattern was used for

weekday availability and one for the weekend,

illustrated in Figure 5.

Figure 5: Peer online patterns.

Bandwidth was assumed adequate for the connection

capacity. In practice, if such a scenario occurs, the

node decreases it's connection capacity accordingly.

The simulation was run for two weeks (internal clock)

and the data sampled hourly. The parameters are

presented in Table 2.

Table 2: Simulation parameters.

Numbe

of nodes 50,000

Node capacity (𝐶



)

Random from:

50,75,100,125,150

Reserve

cap. (𝐶



)

0.1

Min. su

ervisors 3

Max. supervisors

0.45 of Min(𝐶



) Sup.

Cluste

lit threshol

0.9

Cluste

interconnection 2

At the end of the simulation, as illustrated in Figure

6, the following results were obtained: peak number

of online nodes: 35995, isolated nodes: 264, total

clusters formed 85 and defunct clusters: 79. The first

clusters to become defunct were the leaf ones. The

other clusters had enough “weight” to survive a large

number of disconnecting nodes.

In the best-case scenario, the super-peers

managed to organize almost 36000 nodes into 8

clusters with the average size of 4499 (smallest: 4489,

largest: 4501) with the longest path of 3 hops. In the

worst-case observed, 35995 nodes were organized

into 15 clusters with an average size of 2399

(smallest: 2360, largest: 2406) and the longest path of

5 hops between them.

Using a redundant cluster interconnection, no

occurrence of isolated clusters was observed during

the simulation. Nonetheless, a catastrophic physical

network failure can still result in parts of the network

becoming isolated.

WOBCompute: Architecture and Design Considerations of a P2P Computing System

Figure 6: Topology simulation result.

5 CONCLUSIONS

In this paper, a P2P computing system’s architecture

and design considerations ware presented. Overall,

the numerous functions required to operate the system

leads to the inevitable increase in both design and

implementation complexity.

As in any P2P system design, the topology design

is influenced by the operation of the system,

specifically, decentralized task coordination, ability

to suspend, migrate, recover, and track workloads.

Task creation is driven by workload requests,

recovery is accomplished using a remote checkpoint

system, while workload tracking requires a search

mechanism. As mentioned by several literature

proposals, super-peers increase the search speed by

maintaining a list of connected peer resources, thus

reducing the number of peers needed to be queried. In

the presented system, super-peers also store the

workload checkpoints. Another benefit of clustering

is the super-peers ability to limit the workload query

messages in certain cases, which otherwise could

overload the network. Backup super-peers are used to

maintain cluster stability; as one super-peer exit or

fails, a backup can take its place, thus keeping the

cluster functional. Furthermore, it is desirable to have

a reduced number of clusters query messages have to

reach. Since each super-peer has a limited number of

connections it can accept, further increasing the size

of a cluster can be achieved by balancing the cluster

members between the super-peers. Concerning the

network overlay, the clusters are organized into an

extended star topology to reduce the number of hops

for a message to take to reach all clusters. Topology

simulations to verify the viability of the presented

network overlay ware also presented in the paper.

As discussed, such a system design, compared to

systems using client-server architecture, comes with

an enormous complexity needed to maintain network

overlay and provide the specified functionalities.

However, this complexity is hidden by the

middleware, which provides simple and

straightforward functions to utilize and build

computing applications. Nonetheless, such

applications come with additional complexity.

However, the benefit is, as in most P2P systems, the

decentralized task coordination, and the unique

characteristic of the presented system, the possibility

of suspending, transferring and recovering

workloads, and also locating workloads allows the

possibility of messaging between parallel tasks.

REFERENCES

Anderson, DP. (2004). Boinc: A system for public-resource

computing and storage. Proceedings of the 5th

IEEE/ACM International Workshop, 4-10. https://

doi.org/10.1109/GRID.2004.14

Castella, D., Solsona, F., Gine F. (2015). DisCoP: A P2P

Framework for Managing and Searching Computing

Markets. Journal of Grid Computing 13, 115-137.

https://doi.org/10.1007/s10723-014-9318-3

Chmaj, G. and Walkowiak, K. (2013). A P2P Computing

System for Overlay Networks. Future Generation

Computer Systems, 29(1), 242-249. https://doi.org/

10.1016/j.future.2010.11.009

De, S., Barik, M. S., Banerjee, I. (2016). Goal Based Threat

Modeling for Peer-to-Peer Cloud. Procedia Computer

5 000

10 000

15 000

20 000

25 000

30 000

35 000

40 000

w0_0_0

w0_0_8

w0_0_16

w0_1_0

w0_1_8

w0_1_16

w0_2_0

w0_2_8

w0_2_16

w0_3_0

w0_3_8

w0_3_16

w0_4_0

w0_4_8

w0_4_16

w0_5_0

w0_5_8

w0_5_16

w0_6_0

w0_6_8

w0_6_16

w1_0_0

w1_0_8

w1_0_16

w1_1_0

w1_1_8

w1_1_16

w1_2_0

w1_2_8

w1_2_16

w1_3_0

w1_3_8

w1_3_16

w1_4_0

w1_4_8

w1_4_16

w1_5_0

w1_5_8

w1_5_16

w1_6_0

w1_6_8

w1_6_16

Online nodes Clusters

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

Science (89), 64-72. https://doi.org/10.1016/j.procs.

2016.06.010

Filep, L. (2019). Model for Improved Load Balancing in

Volunteer Computing Platforms. 15th European,

Mediterranean, and Middle Eastern Conference,

LNBIP 341, 131–143. https://doi.org/10.1007/978-3-

030-11395-7_13

Gailly, J. and Adler, M. (2002), zlib Library. http://

zlib.net/index.html

Gomathi, S. and Manimegalai, D. (2013). Hierarchically

distributed Peer-to-Peer architecture for computational

grid. 2013 International Conference on Green High

Performance Computing (ICGHPC). https://doi.org/

10.1109/ICGHPC.2013.6533906

Gupta, R., Sekhri, V., Somani, A. (2016). CompuP2P: An

architecture for internet computing using Peer-to-Peer

networks. IEEE Trans. Parallel Distrib. Syst. 17(11),

1306-1320. https://doi.org/10.1109/TPDS.2006.149

Jesi, G. P., Montresor, A., Babaoglu, O. (2006). Proximity-

Aware Superpeer Overlay Topologies. Lecture Notes in

Computer Science, 43-57. https://doi.org/10.1007/

11767886_4

Lavoie, E., Hendren, L. (2019). Personal volunteer

computing. Proceedings of the 16th ACM International

Conference on Computing Frontiers (CF '19), 240-246.

https://doi.org/10.1145/3310273.3322819

Mitra, B., Ghose, S., Ganguly, N., Peruani, F. (2008).

Stability analysis of peer-to-peer networks against

churn. Pramana - J Phys, 71-263. https://doi.org/

10.1007/s12043-008-0159-0

Pérez-Miguel, C., Miguel-Alonso, J., & Mendiburu, A.

(2013). High throughput computing over peer-to-peer

networks. Future Generation Computer Systems, 29(1),

352–360. doi: https://doi.org/10.1016/

j.future.2011.08.011

Poenaru, A., Istrate, R., Pop, F. (2016). AFT: Adaptive and

fault tolerant peer-to-peer overlay - A user-centric

solution for data sharing, Future Generation Computer

Systems (80), 583-595. http://dx.doi.org/10.1016/

j.future.2016.05.022

Qi, X., Qiang, M., Liu, L. (2019). A balanced strategy to

improve data invulnerability in structured P2P system.

Peer-to-Peer Networking and Applications. https://

doi.org/10.1007/s12083-019-00773-9

Ratnasamy, S., Francis, P., Handley, M., Karp, R., Shenker,

S. (2001). A Scalable Content Addressable Network.

Proceedings of SIGCOMM 2001, 161-172. https://

doi.org/10.1145/383059.383072

Stoica, I., Morris, R., Karger, D., Kaashoek, M.F.,

Balakrishnan, H. (2001). Chord - A Scalable Peer-to-

peer Lookup Service for Internet Applications.

Proceedings of SIGCOMM, 149-160. https://doi.org/

10.1145/383059.383071

Tiburcio, P.G.S., Spohn, M.A. (2010). Ad hoc Grid: An

Adaptive and Self-Organizing Peer-to-Peer Computing

Grid. 10th International Conference on Computer and

Information Technology (CIT), 225-232. https://

doi.org/10.1109/CIT.2010.504

Vimal, S., Srivatsa, S.K. (2019). A file sharing system in

peer-to-peer network by a nearness-sensible method.

International Journal of Reasoning-based Intelligent

Systems (IJRIS), 11 (4). https://dx.doi.org/10.1504/

IJRIS.2019.103510

Yang, B., Garcia-Molina, H. (2003). Designing a super-

peer network. 19th International Conference on Data

Engineering. https://doi.org/doi:10.1109/icde.2003.

1260781

Ye, F., Zuo, F., Zhang, S. (2009). Routing Algorithm Based

on Gnutella Model. Computational Intelligence and

Intelligent Systems. https://doi.org/10.1007/978-3-642-

04962-0_2

Zhao, H., Huang, L., Stribling, R., Rhea, S.C., Joseph, A.D.,

Kubiatowicz, J.D. (2004). Tapestry - A Resilient

Global-Scale Overlay for Service Deployment. IEEE

Journal on Selected Areas in Communications 22, 41-

53. https://doi.org/10.1109/JSAC.2003.818784

WOBCompute: Architecture and Design Considerations of a P2P Computing System
