Playing the Role of Co-designers on Mobile PWAs: An Investigation of

End-Users Interaction

Giulia de Andrade Cardieri

and Luciana A. M. Zaina

Federal University of S˜ao Carlos, Sorocaba, S˜ao Paulo, Brazil

Keywords:

Progressive Web Apps, End-User Development, Experimental Study, Mobile Apps.

Abstract:

Progressive Web App (PWA) is a new approach that combines technology resources of both web and native

apps. End-User Development (EUD) is an approach from which end-users participate actively in a system’s

design process. PWAs are a recent technology and the impacts of associating EUD and PWAs have been

little exploited. To cover this gap, we proposed the PWA-EU approach in previous work. In this paper, we

present an investigation about end-users interactions when they act as co-designers on PWAs. We built a

mobile app based on the PWA-EU approach and conducted a study with 18 participants with eight acting as

co-designers of the app, and ten interacting as non-designers. We carried out a qualitative analysis from the

participants’ interaction focusing on the breakdowns communication and user experience (UX) of the partici-

pants. Our gathered evidence points out that even acting as co-designers participants still have communication

breakdowns. Moreover, those who acted as co-designs had a more satisfying experience than those who did

not.

1 INTRODUCTION

The use of mobile devices to access the internet is

more popular around the globe than the use of desk-

tops (Comscore, 2017). Mobile devices are consid-

ered part of individuals’ daily activities which include

access to different information systems such as on-

line banking, e-learning systems and so on (Casadei

et al., 2017). Designers and developers must con-

sider browsers and device limitations when working

with mobile or web apps. With those limitations in

mind, the need for adapting interfaces on different

screen sizes, resources, and dimensions becomes rel-

evant (Bueno and Zaina, 2017; Gull`a et al., 2015).

Responsive Web Design (RWD) arose as a popu-

lar solution to user interface (UI) adaptation for mo-

bile web apps (Marcotte, 2011). From the RWD ap-

proach, the interface adaptation runs automatically by

considering the device screen width, orientation, and

platform by CSS media queries (Bryant and Jones,

2012).

Progressive Web App (PWA) is proposed by

Google in 2015. It combines both web and native

apps technology resources. Initially, PWAs are pre-

sented as RWD mobile apps which after continuous

https://orcid.org/0000-0002-5537-1592

https://orcid.org/0000-0002-1736-544X

user interactions, progressively become more com-

plete and similar to the natives (Petele, 2016). This

feature provides an adaptive nature to PWAs since

their UIs get more complete according to the growth

of user interactions.

Considering end-users side, end-user develop-

ment (EUD) focuses on allowing users who are not

primarily interested in software to create, modify and

extend a system according to their needs. Meta-

design is a EUD approach in which the end-user can

participate actively in application development and is

not restricted to its use (Fischer, 2009).

The adaptive nature of PWAs brings great poten-

tial to be associated with meta-design since both ap-

proaches allow apps to become more complete while

the user builds a relationship with it. Due to that, the

aim of this paper was to investigate the issues and

the UX of end-users when they act as co-designers

on PWAs. We called co-designers individuals that

can change the user interface design on the app run-

time. To conduct our investigation, we deﬁned two

research questions (RQs): (i) Which communication

breakdowns come up when users play the role of co-

designers in a PWA?” and (ii) How are users’ percep-

tion of UX when interacting as co-designers?.

The traditional PWA approach was not prepared to

allow end-users to make their own preferences option.

476

Cardieri, G. and Zaina, L.

Playing the Role of Co-designers on Mobile PWAs: An Investigation of End-Users Interaction.

DOI: 10.5220/0009350804760486

In Proceedings of the 22nd International Conference on Enterprise Information Systems (ICEIS 2020) - Volume 2, pages 476-486

ISBN: 978-989-758-423-7

Taking into account this limitation we proposed the

PWA-EU approach (Cardieri and Zaina, 2019). Our

proposal is an extension of the traditional PWA archi-

tecture that includes meta-design in a way that users

can include their preferences to adapt interfaces on

run-time. Another motivation for the PWA-EU pro-

posal is the small number of studies on PWAs, espe-

cially when we consider the user perspective. Con-

sidering the aim of this paper, we built a mobile app

based on the PWA-EU approach to be used in our

study. We conducted a study with 18 participants, in

which eight acted as co-designers of the app, which

means they selected their preferences in order to cus-

tomize the PWA’s appearance, and ten interacted as

non-designers. We carried out a qualitative analysis

of recordings collected from the participants’ interac-

tion. We also analyzed the participants’ perceptions

of their experience with the approach.

The main contribution of our work is how the

communication breakdowns that can affect the expe-

rience of end-users when they act as co-designers. As

far as we know, this kind of investigation is the ﬁrst

one in the literature. Our ﬁndings can aid developers

in the creation of apps more self-guided from which

end-users can perform the role of co-designers. Be-

sides, our paper presents all the steps of a robust quali-

tative study in detail. This rich description of the qual-

itative study can be seen as an important academic

contribution by itself so it allows other researchers to

replicate the same study.

The rest of the paper is organized as follows: Sec-

tion 2 presents the fundamentals and related work;

the PWA we developed to our study is presented in

Section 3; the details of our study are discussed in

Section 4 and its results are in follow Section 5; in

Section 6 we return to our research questions to point

out the important results and make a comparison with

the literature as well as presents the limitations of our

study; and ﬁnally Section 7 discusses the conclusion

and future work.

2 BACKGROUND

2.1 PWA-EU Approach

We adopted PWA-EU to conduct our study. We have

proposed it in a previous work (Cardieri and Zaina,

2019). To provide a better understanding, we will

explain the approach brieﬂy. PWA-EU approach is

an extension of the PWA architecture in which users’

preferences are taken into account on the interface

adaptation at run-time. Developers and designers

should follow the architectural proposal to construct

apps from which end-users can modify the interface

in accordance with their preferences. The conception

initial steps of design is not a part of our proposal.

Rather than use methodologies such as user-centered

design or design thinking (Sharp et al., 2019), PWA-

EU provides a software architecture that allows in-

cluding features in the apps from which the end-user

can act as a co-designer.

Looking at Figure 1, we see on the left side the

traditional PWA is shown while our extension is on

the right side.

The User Design Model (UDM) (A) establishes

and combines different User App Preferences (E),

some examples are UI elements appearance, inter-

action methods, and content display formats such as

data and images. The User App Preferences are con-

nected to the app domain. For instance, on a PWA in

which end-users create lists, their preferences could

be linked to how each list element is displayed. More-

over, the relation between the app and User App Pref-

erences should be previouslydeﬁned by designers and

developers. These preferences have default settings

and follow meta-design principles, in which users can

change their preferences. Developers must select a

technology to store these preferences.

The Management Layer (B) is responsible for

including, editing and deleting the User App Prefer-

ences on the UDM. It can receive two different re-

quests from the PWA:(i) receiving and sending mod-

iﬁcations to the UDM, and (ii) for sending an up-

dated UDM to the Connection Layer. The Connec-

tion Layer (C) has three functions: (i) sending the

UDM to be stored, (ii) retrieving the UDM from the

storage, and (iii) sending the latest UDM to the Adap-

tation Engine. The ﬁrst scenario only occurs when the

UDM was updated by the user on the Management

Layer. The other scenarios happen when is necessary

to load a new UI on the PWA, which can occur when a

new UDM preference is set or when the user is brows-

ing through the app. The Adaptation Engine is the

link between the PWA-EU and the traditional PWA

architecture. It takes into account the UDM User App

Preferences to alter the app UI. Moreover, this engine

should store the app UI on cache memory and recover

it when necessary. We deﬁned the PWA-EU archi-

tecture into these three elements and the connection

with the Adaptation Engine following an adaptation

of the event-driven and the layered architectures for

software development (Richards, 2015). The event-

driven part is relevant since the PWA-EU architecture

depends on events triggered by users, such as modi-

fying the UDM or loading a new UI.

With regards to EUD, PWA-EU is based on the

guidelines presented in the meta-design framework

Playing the Role of Co-designers on Mobile PWAs: An Investigation of End-Users Interaction

477

User

...

Interface

Elements

Interacon

Methods

Datepicker

Select

Images

Content

Display

Format

Lists

Cards

Voice

Movements

...

User App Preferences (E)

User

Design

Model (A)

Modiﬁed PWA approach considering user preferences

Storage System (D)

Management

Layer (B)

Connecon

Layer (C)

2a.2

2a.4

2a.1

2a.3

2a.5

Adaptaon Engine (F)

HTML, CSS and JSHTML, CSS and JS

Tradional PWA approach

Cache (H) Web Host (G)

Figure 1: PWA-EU approach.

proposed by Fisher, Nakakoji & Ye (2009) as de-

scribed in the following: Support Human-problem In-

teraction - Designers and developers should analyze

the app domain and its end-users. After this analysis,

the User App Preferences are deﬁned and included as

part of PWA-EU’s UDM. Underdesign for Emergent

Behaviour - A PWA developed with PWA-EU has de-

fault options before the end-user initial interaction.

Due to that, the design of the app is not complete be-

fore end-users modiﬁed the default options by select-

ing their preferences on the UDM. Moreover, a new

design behavioris generated by architectural elements

every time the user changes their User App Prefer-

ences on the app. Share Control - Designers and de-

velopers are the original meta-designers who deﬁne

multiple User App Preferences during development.

At run time, the control of these preferences, that

affect app’s functionalities and appearance, is trans-

ferred to end-users who are acting as co-designers.

2.2 Related Work

As PWA is a recent technology, there are not many

works related to it. Biørn-Hansen et al. propose a

technical comparison between PWA, Native, Hybrid,

and Interpreted apps and concluded there is poten-

tial to PWAs unify web and native development with-

out the need of cross-platform frameworks (Biørn-

Hansen et al., 2017). Sharma et al. discusses the def-

inition of PWAs and compares their performance to

native and hybrid apps (Sharma et al., 2019). In our

previous paper (Cardieri and Zaina, 2018), we con-

ducted a UX-based comparison between PWA, Native

and Web apps, ﬁnding out that all three approaches

provided a satisfying experience to end-users. We

could not ﬁnd works in the PWA ﬁeld that take both

interface adaption or EUD into account. In contrast,

there are many works on interface adaption for mobile

apps, and on EUD (Bueno and Zaina, 2017; Manca

et al., 2013; Ghiani et al., 2014; Gull`a et al., 2015).

Danado & Patern´o proposes Puzzle, a framework

in which end-users with no programming experience

can develop or customize complex mobile apps and

connect their apps to web services and smart devices

(Danado and Patern`o, 2014). Costabile et al. propose

a EUD desktop app based on the software shaping

workshop (SSW) method in which a meta-design par-

ticipatory approach is adopted during the entire soft-

ware life cycle (Costabile et al., 2008). Namoun et

al. (2016) propose a model linking the features of

performing EUD in mobile devices to end-users’ at-

titudes towards and intent of doing this. In the stud-

ies, the authors considered participants with experi-

ence or not on EUD in mobile. The results show

that rather than creating apps the end-users have more

interest in customizing apps to improve their experi-

ence. Nonetheless, these works do not take PWA and

interface adaptation into account.

3 DEVELOPING A PWA-EU APP

A Calendar app following the PWA-EU approach

was developed to support our study (App available

at https://h1eneas.dlvr.cloud/). Calendar is a PWA

that allows users to manage events and their time (i.e.

event name, date, location, category, start, and end

time). Calendar was chosen because it represents a

common-sense domain avoiding the need for users to

learn about the app domain. To build the Calendar,

we considered the most popular frameworks in web

mobile app design, such as Bootstrap

and Material-

ize

. As PWA is a Google proposal based on Material

Design, we chose Materialize as the default design

for Calendar’s UI elements. Material Design consists

of guidelines, components, and tools that support the

best practices of UI design available as open-source

code (Clifton, 2015). We chose Vue.js

to develop

the front-end because it has a fast learning curve, its

applications are smaller to store when compared to

the other frameworks, it is easy to use in projects

https://getbootstrap.com/

http://materializecss.com

https://vuejs.org/

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

478

and availability of an ofﬁcial Vue.js PWA template

(Sheppard, 2017) (Rojas, 2020).

At the start we set up the User App Preferences

(see Fig 1). After conducting an investigation on

the Material Design guide and considering the na-

ture of the app (i.e. Calendar), we decided to cover

ﬁve UI elements: calendar, checkbox, input, select

and timepicker. We also introduced a second op-

tion in which users acting as co-designers could se-

lect. For each element, users acting as co-designers

could choose between a Material Design element

and a browser-default appearance as part of the User

App Preferences of the UDM. A browser-default look

changes according to the device and browser the user

is accessing. For instance, the input from Safari Mo-

bile for iOS shows a vertical scroll for the day, month

and year, while on Chrome Mobile for Android it dis-

plays a pop-up calendar.

Gestures and voice Interaction Methods (see Fig

1) were available. The swipe gesture was selected due

to some Material Design components recommending

its use, such as lists and cards. The voice synthe-

sis and speech recognition were included considering

they became a standard feature on smartphones (Cor-

bett and Weber, 2016). Complementing the User App

Preferences, Content Display Formats were selected

to provide users with distinct ways to read the infor-

mation on the app. Following Material Design guide-

lines, we deﬁned that users can choose between list

and card formats to display data, besides showing or

hiding images on the cards.

Each architectural element from PWA-EU and

the Adaptation Engine are represented on the Calen-

dar app. All three PWA-EU architectural elements

(UDM, Management, and Connection Layers) are de-

ﬁned in the My Design section. In this section, partic-

ipants could select and edit their user app preferences.

While the UDM’s values were visually represented

by My Design’s UI, the Connection and Management

Layers were built as sets of JS functions. Connection

Layer’s functions store and retrieve data from Local-

Storage and the Management Layer’s code changes

the values of user app preferences on the UDM. On

the other hand, the Adaptation Engine is formed by

multiple CSS and JS ﬁles that modify user app pref-

erences on Home and Include New Event sections.

4 EXPERIMENTAL STUDY

In next section we describe the planning, conduction

and analysis our study guided by (Lazar et al., 2017).

https://github.com/vuejs-templates/pwa

4.1 Planning

Participants were invited to take part in the study vol-

untarily via social networks like Twitter and Face-

book. The participants were selected by convenience,

according to their availability to take part in the study

(Lazar et al., 2017). We obtained two distinct groups

of participants who were separated based on their aca-

demic and professional experience (Namoun et al.,

2016). One group had participants from the technol-

ogy ﬁeld (i.e. developers and designers), we named

tech, and the other had participants from other pro-

fessional and academic ﬁelds, we named non-tech.

This separation avoids that only individuals with pre-

vious knowledge on UI design or development acted

as co-designers and indicates whether or not a differ-

ence stands between end-users co-designers who have

a technical proﬁle and those who do not have.

We selected the Communicability Evaluation

Method (CEM) (Leit˜ao and Souza, 2009) to conduct

our study and guide our analysis of communication

breakdowns (RQ1). We used the method to separate

into codes the recurring issues and interactions re-

garding users’ communication breakdown situations.

CEM is a semiotic engineering-based method that

aims to explore communication breakdowns between

the designed system and the user through the observa-

tion of how a group of users interacts with a particular

system. Considering that in our study part of the users

are also the designers (i.e. co-designers), these break-

downs can point out whether these individuals’ roles

as co-designers lead to more satisfying interactions,

and understand if even acting as co-designers users

still have communication breakdowns.

Moreover, we took the Self Assessment Manikin

(SAM) (Bradley and Lang, 1994) to collect the par-

ticipants’ experience after their interactions with the

application (RQ2). SAM is a pictograph evaluation

method to measure emotional responses from some

sort of stimulus. Three dimensions are considered by

this technique: pleasure (if the participant had a pos-

itive or negative reaction), arousal (body stimulation

level from an event or object) and dominance (feeling

in control of the situation or controlled by it). The

user chooses a value on a scale of one to nine on each

dimension, using images, to represent their emotions

after interactions. Participants answered questions re-

garding SAM after each task. Furthermore, when all

tasks were accomplished we conducted an interview

with four questions to have a broader comprehension

of the end-users’ perspective.

A pilot test was carried out with two participants.

We concluded that no changes were necessary and the

study could be run.

Playing the Role of Co-designers on Mobile PWAs: An Investigation of End-Users Interaction

479

4.2 Conduction

The study was conducted over four days in Soro-

caba, S˜ao Paulo, Brazil. We had a total of 20 partic-

ipants who were between 18 and 59 years old, me-

dian 23 years old. Most participants were under-

graduate students or had a degree. All participants

accepted the term of consent about the use of data

and images for academic ends. Besides the techni-

cal proﬁle separation (see Planning section), half of

the participants were randomly selected and named

co-designers due to having an active participation in

the setting of the UI design, by selecting their pref-

erences and customizing the app’s design. The other

ten participants interacted only with features that did

not make changes on the UI and were named non-

designers.

The participants’ observation took place individ-

ually and the researcher made notes regarding each

communication breakdown. Initially, each participant

received instructions about Calendar and the conduc-

tion of the study. For the co-designers, three tasks

were proposed. The tasks were speciﬁed as follow:

Task 0 - Co-designers - participants could set the

UDM by selecting their preferences regarding UI el-

ements, interaction methods, and display format op-

tions; Task 1 - Include events - participants included

two new events on the app; and Task 2 - Browse

events - Participants canceled and marked as ﬁnished

the previous included events. Non-designers run only

Task 1 and Task 2.

Only the description of the current task was dis-

played in text format on a laptop screen. We did

not introduce a time limit to the participants accom-

plished the tasks. All the participants used the same

mobile device, a Motorola Moto G4 Play running An-

droid 8.1. This avoided that differences in Android

operating system versions could introduce bias on in-

teraction data. The participants’ interactions with the

PWA were recorded by using DU Recorder

, installed

on the mobile device. In addition, the participants’ fa-

cial expressions and voice were captured by a laptop

camera placed in front of the participant. The think-

aloud protocol (Sharp et al., 2019) was adopted to

provide a better understanding of user interaction and

to assist the application of the CEM method. This

protocol requires users to speak their thoughts dur-

ing their interactions. Following the CEM method,

we prepared a semi-structured interview that asked a

question about the difﬁculties the participants had in

using the app.

http:/www.duapps.com/product/du-recorder.html

4.3 Analysis

The analysis was conducted by crossing-over four

data sources (i.e. SAM questionnaire, video record-

ings, screen recordings, and the main researcher’s

notes). Approximately, we collected ﬁve hours of

video recordings from user interactions on the mo-

bile device and recordings of user’s faces, and around

two hours of audio from the interviews. During a

pre-analysis of all video and audio recordings, two

samples were discarded. These participants were co-

designers, from both tech and non-tech groups, who

did not complete Task 0. In the end, we had 18 par-

ticipants, from which eight acted as co-designers and

the others as non-designers. Due to the sample size of

18 participants, we decided not to conduct an inferen-

tial statistical analysis. We carried out three rounds of

analysis with at least two cycles of data exploration

for each one. In the ﬁrst cycle, the ﬁrst author of this

paper explores the data, and after, in the next cycle,

the ﬁrst and second authors together revised, reﬁned,

and consolidated the outcomes.

In the ﬁrst round of analysis, the videos contain-

ing the users’ interactions on apps and facial expres-

sions were put together on the same video aiming to

enable easier and more precise identiﬁcation of each

evidence of a communication breakdown. For this,

we used the iMovie Software

. Regarding the inter-

view, we transcribed to text all conversationsrecorded

on audio between the users and the researcher. After

all the videos were combined, we started CEM’s tag-

ging step. The ﬁrst author of this paper watched all

video recordings twice, took notes of when, why and

where it occurred, and assigned a tag when a com-

munication breakdown was identiﬁed. A spreadsheet

was used to support all the analysis. We used the 13

tags proposed by the CEM method (Leit˜ao and Souza,

2009). These tags are natural language expressions

commonly found in human communications, which

the participants might utter during the thinking aloud

process.

In the second round, the chunks that were tagged

were revisited for the identiﬁcation of the main com-

munication breakdowns. Each tag was listed and

analyzed in two perspectives: (i) the frequency and

context of occurrence which was identiﬁed by list-

ing when, where and the probable reason each tag oc-

curred, and (ii) the existence of pattern in sequences

of tag types, such as grouping tags connected to the

similar communication breakdowns on multiple or

single participants. In each step of tagging, the ﬁrst

author conducted a double-checking of the results.

In the third round, we did a crossing-over among

https://www.apple.com/imovie/

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

480

the issues that have caused the observed breakdowns,

with the participants’ proﬁle, SAM answers, record-

ings and interview data.

5 FINDINGS

We organized our ﬁndings in two subsections consid-

ering the two RQs we should answer. Table 1 will

support us in our discussion regarding our ﬁndings.

It shows the proﬁle data of the participants and their

SAM feedback.

5.1 Communication Breakdowns

We analyzed the communication breakdowns that

were caused by the co-designers choices because only

these participants interfered with the app’s design.

These are problems inﬂuenced by the user prefer-

ences selected when participants were acting as co-

designers. Moreover, we counted seven communica-

tion breakdowns which came up from ﬁve participants

on a total of eight co-designers. The breakdownswere

categorized into four of the 13 tags (identiﬁed by let-

ter T) provided by CEM. Figure 2 shows the tags that

represent the breakdowns that arose when the users

were interacting with the Calendar app. The right-

most diagram indicates which breakdowns also oc-

curred as a consequence of co-designer actions. Fol-

lowing we concentrated on discussing the tags from

the third diagram. The other breakdowns are out of

the scope of this work due to they are related exclu-

sively to UI elements and technological expertise is-

sues.

T6 - What happened? tag is identiﬁed when

users repeat an operation because they could not see

or understand the effects of their actions. We saw ev-

idence of T6 from [P4] interaction on Task 2. Playing

the role of co-designer (i.e. performing Task 0), [P4]

changed the default design of content display format

(see the content display format on Fig 1) from card

to list. Explaining the preference after the execution

of Task 0, [P4] said: “I prefer the list rather than

card viewing...it shows the same data but allows me

to see more data at the same time”. Additionally, the

list format changed how the cancel and ﬁnish buttons

were displayed in a way the buttons contained only

symbols (i.e. an X and a checkmark, respectively)

representing the actions instead of the text format

from when the card format was selected. While per-

forming Task 2 [P4] was not sure which button can-

celed an event. After a time of hesitation, [P4] pressed

the cancel button and the app displayed a modal win-

dow requesting the participant to conﬁrm the action.

Rather than conﬁrming the cancellation, [P4] closed

the modal and reopened it right away, this time con-

ﬁrming the action. In the interview [P4] stated “That

was very practical, I just tested it once to be sure I

was clicking on the correct button”.

T8 - Where am I tag represents the communica-

tion breakdown when a user did not ﬁnd a particular

feature by pausing and searching it. T8 was identi-

ﬁed on [P8]’s interactions on Task 2, who likewise

[P4] selected the list as default content display for-

mat. Commenting on the selection, [P8] said: “It’s

an advantage as is faster to check events using the list

format”. Nonetheless, [P8] was insecure about which

button would perform the action to mark an event as

ﬁnished, as the buttons had only symbols and not text.

S/he stated: “Mark the event as ﬁnished? ... Let me

click here ... oh, ok! .. Yay!”. By analyzing this snip-

pet, we noticed that initially s/he was not sure which

UI element would perform this action. Yet, [P8] ﬁg-

ured it out in a few seconds and explained this break-

down over interview “I didn’t realize the ﬁnalize but-

ton was there, I initially tried to click over the list”.

However, a couple of minutes after this statement [P8]

recalled this issue afﬁrming “Finalizing an event was

easy.”.

The T9 - Oops tag occurs when a user momentar-

ily makes a mistake and immediately corrects it. S/he

sees that s/he has made a wrong step and usually ac-

tivates the “undo” function immediately. This break-

down was identiﬁed on [P7]’s interactions on Task 2,

a tech co-designer. Resembling [P4] and [P8], [P7]

selected the list as the preferred content display for-

mat on Task 0. S/he stated: “I prefer the list because

it ﬁts more data onto the screen, it’s very clear and

not cramped.”. Yet, s/he had issues to understand the

difference between cancel and mark as ﬁnished but-

tons. While trying to ﬁnish an event, [P7] spoke “The

button is asking me if I want to ﬁnish an event... I

don’t want to ﬁnish .. wait? Is it the same thing?...

ﬁnish an event, ok.”. By [P7]’s speech, we observe a

misunderstanding regarding the verbs cancel and ﬁn-

ish. Over the interview, s/he explained: “The action

buttons were not clear, I understand one of them is

positive and the other is negative. Still, the message

was very similar in both actions”.

On the T13 - Why doesn’t it? tag, the user is

trying to make sense of the designer message by re-

peating the steps of previous unsuccessful commu-

nication in order to ﬁnd out what went wrong. The

issue experienced by [P7] in the previous paragraph

is also connected to T13. On Task 2, [P7] repeated

the ‘mark as ﬁnished task’ until s/he understood the

difference between this and the cancel action. Ad-

ditionally, T13 also occurred with two other partici-

Playing the Role of Co-designers on Mobile PWAs: An Investigation of End-Users Interaction

481

Table 1: Participants’ proﬁle: P/A Experience - Professional/Academic Experience, and SAM results: PI - Pleasure Index, AI

- Arousal Index, DI - Dominance Index.

Participant Group Technical Proﬁle P/A Experience

Task 0 Task 1 Task 2

PI AI DI PI AI DI PI AI DI

P1 Co-designer Non-tech 2-4 years 8 7 9 9 9 9 9 9 9

P2 Co-designer Non-tech N/A 7 6 8 9 8 8,5 9 9 9

P3 Co-designer Tech 5 years or more 8 9 9 7,5 7,5 8,5 9 9 9

P4 Co-designer Non-tech 1-2 years 6 6 3 8 8,5 8,5 8 8 7,5

P5 Co-designer Non-tech Less than a year 8 9 7 9 9 9 9 9 9

P6 Co-designer Tech 2-4 years 7 9 8 8 9 8 8 9 7

P7 Co-designer Tech 2-4 years 6 8 8 5,5 5,5 6,5 5,5 4 5,5

P8 Co-designer Tech 5 years or more 7 5 9 9 9 7,5 9 9 9

P9 Non-designer Non-tech 5 years or more - - - 9 9 9 9 9 9

P10 Non-designer Non-tech 2-4 years - - - 8,5 9 8,5 9 9 9

P11 Non-designer Non-tech 5 years or more - - - 7,5 7,5 7,5 9 8 9

P12 Non-designer Tech 5 years or more - - - 7,5 8,5 9 9 9 9

P13 Non-designer Non-tech 1-2 years - - - 7 7,5 6,5 7 9 6

P14 Non-designer Tech 5 years or more - - - 7,5 9 9 8 9 9

P15 Non-designer Tech 1-2 years - - - 7 8,5 7,5 7,5 8,5 7,5

P16 Non-designer Non-tech 1-2 years - - - 7,5 7,5 8 9 9 9

P17 Non-designer Tech 5 years or more - - - 7 8 5 5 7,5 3,5

P18 Non-designer Tech 5 years or more - - - 8 9 8 8,5 8 9

pants on Task 1, in which participants had to include

an event. [P1] and [P2], co-designers from the non-

tech group, selected the Materialize’s datepicker in-

stead of the browser-default. The default behavior of

Materialize’s datepicker displays the current day with

a distinct font color that led participants to believe a

date was selected. Still, in order to choose a date,

users had to touch over a day and it would acquire a

different background color. This behavior is a feature

from Materialize, which is not considered a design er-

ror by the library. Both participants did not comment

on why they selected this datepicker instead of the

second option, which did not present this behavior.

Yet, [P1] explained “I did not enjoy the datepicker

because instead of performing two commands I wish

I could complete it in one.”. Conversely, [P2] did not

state difﬁculties. Other three participants selected this

datepicker, [P3] from the tech and [P4], [P5] from

the non-tech group. However, [P4] had the same

breakdown with the Materialize UI element on Task

0, which lead him/her to select the other datepicker

option.

As Materialize’s datepicker was the default on the

Calendar app, we can compare the T13 breakdown

with the non-designers. For non-designers, four (P11,

P13, P15, and P17) of the ten participants experienced

a similar issue. Two (P15 and P17) of these four

were from the tech group. This comparison points

out that even people who are acquainted with tech-

nology may have issues understanding Materialize’s

datepicker behavior. Most co-designers from the tech

group selected the second option, which displays a UI

element associated to the browser.

Even though three participants (P4, P8, and P7)

had distinct issues related to the list and action but-

tons on Task 2, two other tech participants, [P3] and

[P6], also selected the list as their content display for-

mat preference. Both [P3] and [P6] did not experi-

ence breakdowns, instead, both stated in the interview

that the action buttons were very clear. As the list

was not available as content display format for partic-

ipants who did not act as co-designers, we could not

make a relation with the non-designers participants.

Further, we looked at the results of the interview.

One question asked whether the co-designersfelt they

had better interactions due to their design choices. Six

from eight participants felt positive about this ques-

tion, [P8] felt neutral and [P2] disagreed. [P2] stated

“The choices don’t change a lot of things”. Yet, s/he

was a non-tech participant with initial difﬁculties in

understanding how the design options would be later

applied. The tech participant [P8] said the choices did

not interfere with posterior interactions. The other six

participants explained the preferences selection made

the navigation easier and more pleasant to interact.

Some examples are “The app was more pleasant as it

identiﬁes with your choices.”[P3]; and “The app gets

easier to interact”[P4].

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

482

Co-designers

Non-designers

T12

T13

T10

Tech

Non-Tech

T10

T13

T12

TechNon-Tech

T13

Only Co-designers

Figure 2: Participants communication breakdown tags divided by co-designers/non-designers, tech/non-tech and co-designers

from both tech/non-tech.

5.2 UX Perception

Our discussion on UX perception is performed on a

holistic overview throughout the interpretation of the

users’ feedback from SAM. Table 1 summarizes the

SAM dimensions and the participants’ responses per

task. When we look at participants’ results divided by

their technical proﬁle, we notice a contrast between

them. Hence, Figure 3 shows a comparison of both

groups on the co-designers’ feedback on Task 0. Fur-

ther, the SAM medians for co-designers are higher

on Task 1 in which interactions with UI elements are

linked to user app preferences. Yet, there were no

differences in the SAM values for Task 2, as users’

choices were not as visible as Task 1.

By associating the results of Table 1, Figure 3 and

taking into account all the co-designers (i.e. tech and

non-tech), we see an outlier regarding dominance in-

dex. This is a consequence of [P4] having selected

value 3 for this index. By checking the videos of the

participants’ interactions, we noticed that three non-

tech users (i.e. [P2], [P4] and [P5]) had difﬁculties

in understanding how to initiate Task 0 and were con-

fused about their role as co-designers. Yet, they were

having doubts about why and how their preferences

would affect their interactions. [P4], for instance, was

browsing through the design options for a minute and

asked the researcher for help: “I can’t understand

what I should do here”. On top of that, [P2] had ques-

tions about the consequences of the changes: “Where

can I see this element if I choose it?”. Moreover, [P5]

said: “But how do I know what is the difference be-

tween this or that checkbox?”. Brieﬂy, the researcher

answered all the questions and the participants had no

further issues regarding their initial difﬁculties. Even

though [P4]’s SAM values appear as outliers when

we take all co-designers into account, his/her dom-

inance index value is not an outlier when we focus

only on non-tech participants. As pointed out in Fig-

ure 3, non-tech individuals who took the role of co-

designers selected lower values on arousal and domi-

nance SAM dimensions, which might be the cause of

this remark.

[P2], [P5] and [P7] had difﬁculties in acting as co-

All

PI DIAI PI DIAI PI DIAI

Tech Non-tech

1 2 3 4 5 6 7 8 9

Task 0

Figure 3: UX perception of with Task 0.

designers. However, they struggle more on choices of

interaction methods (see interaction methods on Fig

1). Both from the non-tech group, [P2] and [P5] asked

the researcher for help, and [P2] stated: “This speech

recognition, what does it speciﬁcally do?”. Still,

[P2] was confused about other design choices such

as swipe movement and the datepicker. In both situ-

ations, the researcher gave a brief explanation about

what the design choices meant and participants con-

tinued their tasks. Yet, the tech group participant [P7]

stated that “I don’t like to use voice, I don’t like voice

synthesis or speech recognition ... I don’t understand

why both methods are separated, but it’s ﬁne”. This

issue could also be one of the causes of [P2] having at-

tributed lower valuesfor pleasure and arousal indexes.

On the other hand, [P5] selected high values for both

pleasure and arousal indexes. As the only represen-

tative of the tech group, [P7] selected 6 for pleasure

index. However, [P7] chose high values for the other

SAM indexes pointing out that the issue did not affect

the experience.

By observing Figures 4 and 5, we see the homo-

geneous feedback of the participants independently of

the task and their group. Task 1 boxplots show out-

liers linked to [P7] and [P16]. Both participants are

from the tech group, yet, [P7] was a co-designer and

[P16] was not. Comparing the data from both CEM

and SAM methods, we found out that [P7] and [P16]

had a common issue that was also experienced by

[P1], [P2], and [P3]. The issue came up during the use

of timepicker element, in which they had to include

an event with a speciﬁc time slot. Actually, all the

participants had some kind of difﬁculty while select-

Playing the Role of Co-designers on Mobile PWAs: An Investigation of End-Users Interaction

483

ing a precise time slot. We noticed this issue on both

timepicker options, materialize and web pattern. Dur-

ing the interview, [P16] related issues regarding the

timepicker’s accuracy: “It’s nice to have a timepicker

that spins to a precise time, but I had many difﬁculties

trying to select both zeros from 15:00. I’m not sure

if it is too accurate or not accurate at all”. No other

participants commented on this issue. Taking a look

at SAM indexes of [P1], [P2] and [P3], we notice that

this issue did not affect their UX. Nonetheless, [P3]

had lower values when compared to [P1] and [P2].

The results showed that this barrier has affected only

the SAM indexes of the tech participants.

The issue related to the datepicker described in the

previous subsection affected only part of the partici-

pants. When we observe [P1] and [P2] SAM results,

we notice they did not select lower indexes on Task 1.

The non-designers (i.e. P11, P13, P15, and P17) who

had this issue selected lower values on SAM indexes

for Task 1. This points out that the co-designers’ ex-

perience was not affected by this breakdown, yet, the

non-designers had a less satisfactory experience.

Co-designers

Non-designers

1 2 3 4 5 6 7 8 9

PI DIAI PI DIAI

1 2 3 4 5 6 7 8 9

Task 1 Task 2

Figure 4: Boxplots with SAM results categorized by partic-

ipants role.

Also connected to the communication breakdowns,

the issue regarding the list UI element did affect co-

designers UX. In Figures 4 and 5, we see the out-

liers in the boxplots of co-designers (pleasure and

arousal indexes) and of techs (arousal index) group

from Task 2. Besides that, all of SAM indexes of [P4]

are pointed out as outliers on the non-tech boxplot.

Yet, the values from [P4] did not come as outliers on

the co-designers boxplot. The experience reported by

[P8] showed the communication breakdown s/he has

faced did not bring consequences to his/her experi-

ence due to SAM values are high.

The other two outliers on Task 2 for pleasure and

dominance indexes were found from [P12] feedback

when seeing as the non-tech participant. His/her is-

sues are related to his/her own expectations regard-

ing the app (i.e. s/he wished a speciﬁc functional-

ity existed), not their UI elements or the PWA-EU

approach. Instead, the lower values arose when the

participant wanted extra functionality on the app in

which the ﬁnished and canceled events could be re-

stored. [P12] stated: “Wow, the event I marked as

ﬁnished just vanishes? I’m sad”. Likewise, [P12] and

[P16] outliers presented in Task 2 for pleasure and

dominance indexes on both non-designers and tech

boxplots are linked to the same expectation.

1 2 3 4 5 6 7 8 9

Non-Tech

Tech

Task 1

PI DIAI PI DIAI

Task 2

Task 1 Task 2

Figure 5: Boxplots with SAM results categorized by partic-

ipants experience.

6 DISCUSSION AND STUDY

LIMITATIONS

Considering the communication breakdowns results,

we answer the RQ1 “Which communication break-

downs come up when users play the role of co-

designers in a PWA?”. Even when users acted as

co-designers they experienced communication break-

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

484

downs. This remark is affected by users’ technical

background, such as programmers and designers who

are used to building and designing applications. Tech

participants had fewer breakdowns as they had more

expertise in the behavior and functionality of differ-

ent UI elements than non-tech ones. Although EUD

brings interest and motivation to non-tech end-users,

their lack of technical skills makes them not engage

as co-designers (Namoun et al., 2016).

Supporting by SAM results we can answer RQ2

“How are users’ perception of UX when interact-

ing as co-designers?”. By playing the role of co-

designers the participants had a more positive per-

ception as their active participation in the app design

could improve their experience. This remark could be

noticed especially in the pleasure index. When con-

sidering the technical proﬁle, the tech group demon-

strate less satisfaction than the non-tech. However,

while playing the role of co-designers the non-tech

individuals felt less dominant and aroused compar-

ing to the tech ones. Technical issues can introduce

situational limitations to non-tech end-users (Casadei

et al., 2017). These limitations are any kind of prob-

lem that comes up from environmental characteris-

tics and may jeopardize the UX (Henry et al., 2014).

One important motivation for end-users engaging in

EUD actions is the improvements that it can bring to

their experience (Fischer et al., 2017). Yet, one of

the biggest challenges to overcome is to simultane-

ously give end-users the empowerment of designing

apps and provide ways to support them with how to

do EUD (Namoun et al., 2016). In order to provide

more guidance, we could establish guidelines for the

development of the PWA-EU.

Since most issues pointed out in the results are

related to three UI elements (datepicker, timepicker,

and list), we can discuss if the identiﬁed breakdowns

are connected to the interaction with UI elements. As

reported in our previous paper (Cardieri and Zaina,

2018), despite bringing satisfaction, datepickers can

cause confusion and frustration on PWA users. More-

over, users have issues while including data via forms

on mobile apps as these elements have not changed

much since their ﬁrst design. Finally, lists seem like a

practical design for users, yet it raises serious acces-

sibility concerns (Casadei et al., 2017). Still, likewise

our previous study (Cardieri and Zaina, 2018), par-

ticipants achieved a satisfying UX even with issues

when interacting with the UI elements.

We took different actions as the sample of our

work can be considered a limitation (i.e. 18 partic-

ipants). First, we adopted four distinct data sources

that allowed us to triangulate data that provides re-

liability to the analysis. Yet, we assured all partici-

pants used the same mobile device in order to avoid

bias which could be caused by different Android ver-

sions. We also explored the data on distinct lenses

(i.e. SAM and CEM) and consequently getting rich

discussions of the results. We ensured all selected

participants were frequent users of mobile devices in

order to avoid problems related to the interaction with

the mobile platform. Still, our work is limited to the

use of certain UI elements, which were part of the

user app preferences and are connected to the user’s

experience, as pointed out in the discussion.

7 CONCLUSION AND FUTURE

WORK

This paper presented an investigation about end-users

acting as co-designers on PWAs. The ﬁndings re-

vealed that individuals with technology background

were less satisﬁed, but felt more dominant when act-

ing as co-designers. Conversely, grouping partici-

pants as those who acted as co-designers and the

ones who did not, we noticed the co-designers group

had more satisfying interactions on the posterior task

when compared to the ones who did not include their

preferences into the PWA.

Our work contributes to the discussion of how

end-users could activelyparticipate in the design. The

results show that there are some difﬁculties in playing

the role of co-designers and these can have a direct

impact on the overall UX. Working on more guided

mobile apps could be a start point for achieving an in-

clusive environmentfor end-users. We also present an

important discussion regarding the potential of com-

bining PWAs and EUD. PWA-EU could be seen as a

contribution for developers of apps in the sense it ar-

ranges the responsibilities from the architectural per-

spective of the application.

As future work, ﬁrst, we intend to reﬁne the PWA-

EU approach by adding recommendations on how de-

velopers can provide more guidance during interac-

tion and consequently support end-users in their role

of co-designers. For instance, only after the user in-

teracts with a user app preference (i.e. a UI element)

the different preference options are displayed. Fur-

ther, the app section in which the user can select their

preferences is progressivelybuilt according to user in-

teractions.

Playing the Role of Co-designers on Mobile PWAs: An Investigation of End-Users Interaction

485

ACKNOWLEDGMENTS

This study was ﬁnanced in part by the Coordenac¸˜ao

de Aperfeic¸oamento de Pessoal de N´ıvel Superior -

Brasil (CAPES) - Finance Code 001.

REFERENCES

Biørn-Hansen, A., Majchrzak, T. A., and Grønli, T.-M.

(2017). Progressive Web Apps: The Possible Web-

native Uniﬁer for Mobile Development. Proceedings

of the 13th Int. Conf. on Web Inform. Sys. and Tech.,

(Webist):344–351.

Bradley, M. and Lang, P. J. (1994). Measuring Emotion:

The Self-Assessment Manikin and the Semantic Dif-

ferential. Journal of Behavior Therapy and Experi-

mental Psychiatry, 25(1):49–59.

Bryant, J. and Jones, M. (2012). Responsive Web Design. In

Pro HTML5 Performance, volume 67. Apress, Berke-

ley, CA.

Bueno, D. C. and Zaina, L. M. (2017). HyMobWeb : A

hybrid adaptation of context-sensitive Web interfaces

with multimodality support in mobile devices. SBC

Journal on Interactive Systems.

Cardieri, G. A. and Zaina, L. A. M. (2019). PWA-EU: Ex-

tending PWA approach for promoting customization

based on user preferences. Proc. ACM Hum.-Comput.

Interact., 3(EICS).

Cardieri, G. A. and Zaina, L. M. (2018). Analyzing User

Experience in Mobile Web, Native and Progressive

Web Applications: A User and HCI Specialist Per-

spectives. In Proceedings of the 17th Brazilian Sym-

posium on Human Factors in Comp. Sys., IHC 2018,

pages 9:1–9:11.

Casadei, V., Granollers, T., and Zaina, L. (2017). Investigat-

ing accessibility issues of UI mobile design patterns

in online communities: A virtual ethnographic study.

In Proceedings of the XVI Brazilian Symp. on Human

Factors in Comp. Sys., IHC 2017, pages 33:1–33:10.

Clifton, I. G. (2015). Android User Interface Design: Im-

plementing Material Design for Developers. Addison-

Wesley Professional.

Comscore (2017). The global mobile report. http://bit.ly/

2ST47kf. Last checked on Nov 12, 2018.

Corbett, E. and Weber, A. (2016). What can I say?: Ad-

dressing user experience challenges of a mobile voice

user interface for accessibility. In Proceedings of the

18th Int. Conf. on HCI Interaction with Mobile De-

vices and Services, MobileHCI ’16, pages 72–82.

Costabile, M. F., Mussio, P., Parasiliti Provenza, L., and

Piccinno, A. (2008). End users as unwitting software

developers. In Proceedings of the 4th Int. Workshop

on End-user Soft. Engn - WEUSE ’08, pages 6–10.

Danado, J. and Patern`o, F. (2014). Puzzle: A mobile

application development environment using a jigsaw

metaphor. Journal of Visual Languages and Comp.,

25(4):297–315.

Fischer, G. (2009). End-user development and meta-design:

Foundations for cultures of participation. Lecture

Notes in Computer Science (including subseries Lec-

ture Notes in Artiﬁcial Intelligence and Lecture Notes

in Bioinformatics), 5435 LNCS:3–14.

Fischer, G., Fogli, D., and Piccinno, A. (2017). Revisiting

and broadening the meta-design framework for end-

user development. In New Perspectives in End-User

Development, pages 61–98. Springer, Cham.

Ghiani, G., Manca, M., Patern`o, F., and Porta, C. (2014).

Beyond responsive design: Context-dependent mul-

timodal augmentation of web applications. In 11th

Int. Conf. on Mobile Web and Intelligent Inform. Sys.

- MobiWis’14, volume 8640 LNCS, pages 71–85.

Gull`a, F., Ceccacci, S., Germani, M., and Cavalieri, L.

(2015). Design Adaptable and Adaptive User Inter-

faces: A Method to Manage the Information. In

Biosystems & Biorobotics, volume 11, pages 47–58.

Springer Internatinal Publishing.

Henry, S. L., Abou-Zahra, S., and Brewer, J. (2014). The

role of accessibility in a universal web. In Proceedings

of the 11th Web for All Conf., W4A ’14, pages 17:1–

17:4.

Lazar, J., Feng, J. H., and Hochheiser, H. (2017). Research

Methods in Human-Computer Interaction. 2 edition.

Leit˜ao, C. F. and Souza, C. S. (2009). Semiotic Engineering

Methods for Scientiﬁc Research in HCI. Morgan &

Claypool.

Manca, M., Patern`o, F., Santoro, C., and Spano, L. D.

(2013). Generation of multi-device adaptive multi-

modal web applications. In 10th Int. Conf. on Mobile

Web and Intelligent Inform. Sys. - MobiWis’13, vol-

ume 8093 LNCS, pages 218–232.

Marcotte, E. (2011). Responsive web design, a book apart.

http://bit.ly/32p3zFY. Last checked on Oct 30, 2017.

Namoun, A., Daskalopoulou, A., Mehandjiev, N., and Xun,

Z. (2016). Exploring mobile end user development:

Existing use and design factors. IEEE Transactions

on Software Engineering, 42(10):960–976.

Petele (2016). Your ﬁrst progressive web app. http://bit.ly/

3c5JlFI. Last checked on Sept 26, 2017.

Richards, M. (2015). Software Architecture Patterns.

O’Reilly Media.

Rojas, C. (2020). Making your ﬁrst progressive web app.

In Building Progressive Web Applications with Vue.

js, pages 1–46. Springer.

Sharma, V., Verma, R., Pathak, V., Paliwal, M., and Jain,

P. (2019). Progressive Web App (PWA) - One Stop

Solution for All Application Development Across All

Platforms. Int.Journal of Scientiﬁc Research in Comp.

Sci., Eng. and Inform. Tech., 5(2):1120–1122.

Sharp, H., Preece, J., and Rogers, Y. (2019). Interaction

Design-beyond human-computer interaction. John

Wiley & Sons.

Sheppard, D. (2017). Beginning progressive web app devel-

opment creating a native app experience on the web.

Apress.

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

486
